Jensen VX-6020 Operating Instructions

VX6020
Navigation Operating Instructions
160
watts peak
40W x 4
VX6020
2
VX6020
WARNINGS AND PRECAUTIONS
WARNING! Please read and follow the following safety precautions. Failure to follow the instructions below may increase your risk of collision and personal injury.
The Attention - Please Drive Safely! Screen is displayed each time the iGO primo software is turned ON as a reminder to make use of the system’s navigational aids in a safe manner.
Before using the software, read this entire manual. Make sure that you are familiar with the system’s features and know how to operate the system. Proper use of the iGO primo software includes the following guidelines:
The iGO primo software is not a substitute for your personal judgment. The route suggestions should never supersede any local trac regulation or your personal judgment and /or knowledge of safe driving practices. Prior to completing any maneuvers suggested by your iGO primo software (for example, a U-turn or a left turn), verify that you can legally and safely complete the maneuver. Do not follow route suggestions if they direct you to perform an unsafe or illegal maneuver, would place you in an unsafe situation, or would route you into an area that you consider unsafe.
Glance at the screen only when necessary and safe to do so. Let the computer voice guide you. If prolonged viewing is necessary, pull o the road to a safe location.
Do not use the iGO primo software to locate emergency services (such as police, re stations, hospitals, and clinics). The database may not include all emergency service providers. Use your own best judgment and ask for directions in these situations.
If the vehicle is in motion, only a passenger should program the iGO primo soft­ware. The driver should not program the system unless the vehicle is parked in a safe location.
The iGO primo software’s map database provides information on suggested routes without regard to factors that may aect your driving experience or the time re­quired to arrive at your destination. For example, the system does not reect road detours, closures or construction, some road characteristics (e.g., road surface, slope or grade, weight or height restrictions, etc.), temporary trac congestion, weather conditions, and similar factors.
3
VX6020
iGO primo software provides turn-by-turn visual and voice assistance to direct you to your selected destination. The software quickly calculates step-by-step directions to any destination available on the included navigation map.
The iGO primo software uses Global Positioning System (GPS) satellites, and a digital roadway map database to calculate and display travel directions. The sys­tem’s GPS antenna receives signals from a constellation of 24 satellites orbiting the earth and uses the strongest signals to determine your position to within meters.
Vehicle Position
The iGO primo software’s computer considers vehicle speed and heading changes, together with longitude and latitude information, to accurately determine vehicle heading and position on a digital map.
Signals from GPS satellites are used to determine the vehicle location. Three (good) or four (best) satellites must be received to accurately determine location. The GPS reception status is indicated by the GPS symbol on the map.
Map and Information Database
The map database used by your iGO primo software was created using high-resolution aerial and land based data collection.
Car navigation maps are frequently updated. While the database was judged to be as accurate as possible at the time of its release, a map database can never be 100% accurate. Road information that is maintained in the map databases, such as turn restrictions or road names may change over time.
iGO primo mapping is supported by the mapping manufacturer. iGO oers periodic updates for data such as roads, new addresses, and other navigational information that will keep your navigation system up to date and provide the best possible experience. For updates and add-on options, please visit their website at www.naviextras.com. A free program called “toolbox” can be downloaded from this site so you can create a copy of your map as a backup, as well as assist in easily checking for updates and optional features that are available. We recommend that you back up your map because If your map becomes damaged or erased, or if the card is lost without being backed up, you will need to purchase a new map package.
To report incorrect information, missing addresses, or other map data, click on “REPORT A MAP ERROR” under the SUPPORT section of www.naviextras.com. Errors will be veried and corrected in a future map update.
We recommend that you check your map with this system now and every six months to insure you always have the most up-to-date operating system and maps.
4
VX6020
SAFETY INFORMATION
User Agreement
When the unit is rst turned on, you will see the following message, warning you to operate your navigation system appropriately:
You must agree to the above notice before using the navigation software.
Tap to proceed to the Navigation Menu.
5
VX6020
Driver Safety Rules
The following safety rules must be followed to prevent accidents that can result in
injury or death to yourself or others:
• The driver should operate the device only when the vehicle is stopped. Only a vehicle passenger should operate the device while the vehicle is moving. When driving, the need to view the display is minimal. Voice prompts will guide you to your destinations.
• It is your responsibility to comply with all trac laws.
• The navigation software is designed to assist you in the process of reaching
your destination. It is not a substitute for attentiveness and good judgement.
• It is your responsibility to disregard any unsafe, hazardous, or illegal route suggestions.
• The device does not include, analyze, process, consider, or reect any of the following:
a. Legal restrictions (such as vehicular type, weight, height, width, load
and speed restrictions); b. Road slope or grade, bridge height, width, weight, or other limits; c. Population density; d. Neighborhood quality or safety; e. Availability or proximity of law enforcement, emergency rescue,
medical, or other assistance; f. Construction work zones or hazards; g. Road or lane closures; h. Road, trac, or trac facilities’ safety or condition; i. Weather conditions; j. Pavement characteristics or conditions; k. Special events; l. Trac congestion.
• While every attempt is made to ensure that the database is accurate,
roadways, points of interest, and business and service locations may change over time.
• Do not use the unit to navigate to a police station, hospital, etc. in an
emergency. Call 911 for assistance.
• Laws in some states prohibit wearing stereo headphones or may prohibit use
or placement of a navigation device while operating a motor vehicle. Please contact your state’s Department of Motor Vehicles for information.
6
VX6020
WARNINGS AND PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Vehicle Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Map Information and Database . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
SAFETY INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
User Agreement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Driver Safety Rules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
QUICK START GUIDE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Key Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
About GPS and GNSS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Acquiring a Satellite Signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
GETTING STARTED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Accessing the Navigation Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Adjusting the Navigation Voice Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
INITIAL SETUP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Free Latest Map Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
NAVIGATION MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
BUTTONS AND OTHER CONTROLS ON THE SCREEN . . . . . . . . . . . . . . . . . . . . . . . . . .19
Using Keyboards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Beyond Single Screen Tap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
MAP SCREEN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Navigating on the Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Position Markers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Objects on the Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Manipulating the Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
Quick Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Where Am I? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
NAVIGATING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
SELECTING THE DESTINATION OF A ROUTE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Entering an Address or Part of an Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Selecting the Destination from the Places of Interest . . . . . . . . . . . . . . . . . . .64
Selecting a Map Location as the Destination . . . . . . . . . . . . . . . . . . . . . . . . . . .80
Selecting the Destination from Your Favorites . . . . . . . . . . . . . . . . . . . . . . . . . .81
Selecting One of the Most Likely Destinations (Smart History) . . . . . . . . . .83
Selecting a Recent Destination from the History . . . . . . . . . . . . . . . . . . . . . . . .85
Entering the Coordinates of the Destination . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
Building a Route from the List of Destinations (Create Route) . . . . . . . . . . .89
VIEWING THE ENTIRE ROUTE ON THE MAP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
CHECKING ROUTE PARAMETERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .92
7
VX6020
MODIFYING THE ROUTE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .93
Selecting a New Destination When Already Having a Route . . . . . . . . . . . . .93
Setting a New Starting Position for the Route . . . . . . . . . . . . . . . . . . . . . . . . . .94
Editing the List of Destinations (Edit Route) . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Pausing the Active Route . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
Canceling the Active Route . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97
Checking Route Alternatives When Planning the Route . . . . . . . . . . . . . . . . .98
Checking Route Alternatives for an Existing Route . . . . . . . . . . . . . . . . . . . . . .99
Changing the Vehicle Used In Route Planning . . . . . . . . . . . . . . . . . . . . . . . . 101
Changing the Road Types Used In Route Planning . . . . . . . . . . . . . . . . . . . . 102
SAVING A LOCATION AS A FAVORITE DESTINATION . . . . . . . . . . . . . . . . . . . . . . . . 103
SAVING A LOCATION AS AN ALERT POINT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
EDITING AN ALERT POINT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
WATCHING THE SIMULATION OF THE ROUTE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
REFERENCE GUIDE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
CONCEPTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Smart Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Daytime and Night Color Themes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Route Calculation and Recalculation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Green Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
Road Safety Cameras and Other Proximity Alert Points . . . . . . . . . . . . . . . 114
Speed Limit Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
GPS Position Quality Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
Stored Trac Information In Route Planning . . . . . . . . . . . . . . . . . . . . . . . . . 115
‘MORE’ MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 116
SETTINGS MENU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Sound and Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Customize Quick Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Trac Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Route Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Green Routing Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Map Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Visual Guidance Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130
Display Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Regional Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Trip Monitor Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
GLOSSARY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
END USER LICENSE AGREEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
8
VX6020
QUICK START GUIDE
Follow these six easy steps and you are on your way. NOTE: Before operating your iGO Primo software, please carefully read and follow
the instructions provided in the “Warnings and Precautions” section of this manual.
Step 1 - Access the navigation function:
You can access the navigation function by pressing the front panel NAV button. Step 2 - Start Up: After the iGO primo software starts, you will see the reminder warning to use your
iGO primo software safely and lawfully.
Step 3 - Access the Main Menu:
Press access the Navigation Menu:
9
VX6020
Step 4 - Select a Destination:
You have many ways to select a destination. Select by touching screen:
• Tap to select your destination by entering an address or selecting
a place of interest, a location on the map or one of your Favorite destinations. You can also look up your recent destinations from the Smart History, enter a coordinate or use the location saved in a photo.
• Tap to display the route parameters and the route in its full
length on the map. You can also perform route-related actions such as editing or canceling your route, setting a start point for the route, picking route alternatives, avoiding parts of the route, simulating navigation or adding the destination to your Favorites.
• Tap to customize the way the navigation software works, simulate
demo routes, or to run some additional applications.
• Tap to start navigating on the map. The button itself is a miniature
live map that shows your current position, the recommended route and the surrounding map area. Tap the button to enlarge the map to the full screen.
Step 5 - Map/Guide Along Route
Proceed to the highlighted route and drive while the iGO primo software provides guidance to your destination.
10
VX6020
Step 6 - Arriving at Your Destination
When you are near your destination, the destination is indicated by a
checkered ag symbol .
Refer to the rest of this manual to become more familiar with the many options available on your iGO primo software.
11
VX6020
INTRODUCTION
We hope that you enjoy using your new navigation system. This manual is designed to help you get the most out of your system.
This navigation system leads you straight to your destination. You can navigate and plan your route with an easy-to-use and intuitive interface, plan your trip to suit your personal preferences and interests, and nd and save (bookmark) interesting destinations before you begin your trip.
Key Features
• English, French and Spanish Voice
• Tele Atlas Map Data
• 11 Million Points of Interest
• 4GB SD Card with Continental US, Alaska, Hawaii, and Puerto Rico
• Latest Map Guarantee (Limited time only - Must be used within 90 days of initial activation)
• Compatible with Jensen VX6020 multimedia receiver
Specications
• SiRF Prima Processor
• Processor Speed 600MHz
• NAND Flash 256MB
• GPS Receiver - SiRF
12
VX6020
About GPS and GNSS
The unit uses a vehicle Global Positioning System (GPS)-based navigation device which uses digital map data to guide you from your selected location A to location B, using location information obtained from a Global Navigation Satellite System (GNSS).
A GNSS consists of a set of satellites that transmit high-frequency radio signals containing time, direction, and distance data that can be picked up by a receiver, allowing users to pinpoint their precise locations anywhere around the globe. Navigation Satellite Receivers (GPS devices) use this transmitted information to calculate an exact location on the Earth. Every point on Earth can be identied by latitude and longitude. The receiver uses the information sent by at least three satellites and determines the coordinates of the receiving device.
By comparing the time the signals were transmitted from the satellites and the time they were recorded, the receiver calculates how far away each satellite is. The distance of the receiver from three or more satellites reects its position on the surface of the planet. Using these distance measurements, the receiver might also be able to calculate speed, bearing, trip time, distance to destination, altitude, etc. The GPS position may be displayed as a point on a digital map (at least three satellites’ signals must be received) and as the GPS device moves the corresponding trace is displayed as well.
Please keep in mind that although the radio signals of navigation satellites will pass through clouds, glass, plastic, and other lightweight materials, satellite­navigation receivers will not work underground or in some enclosed spaces.
13
VX6020
Acquiring a Satellite Signal
The initial GPS location lock is best established when your vehicle is parked. If the device is in motion, the signal can take longer to initially connect. Once the initial coordinates are established, the software will follow you as you move and navigate.
Drive your vehicle to an open area where the GPS signal can be clearly received and park the vehicle. If the device is in motion, the signal can take longer to initially connect.
If you cannot acquire the signal, drive to another location. If the signal is still unobtainable, check your antenna installation.
Once a GPS signal has been established, verify that the information display clock time (time displayed on the radio) matches the navigation system clock. With an established GPS signal, the software will follow you as you move and navigate.
The GPS reception quality icon shows the current accuracy of the position information.
Icon Description
iGO primo has no connection to the GPS receiver: GPS navigation is not possible.
Devices with a built-in GPS receiver are permanently connected. On such devices, the icon does not appear in normal circumstances.
iGO primo is connected to the GPS receiver, but the signal is too weak and the receiver cannot determine the GPS position.
GPS navigation is not possible.
Only a few satellites are received. Position information is available, but elevation (altitude) cannot be calculated.
GPS navigation is possible, but the position error may be signicant.
Altitude information is available, the position is a 3D position.
GPS navigation is possible.
14
VX6020
GETTING STARTED
iGO primo is optimized for in-car use. There is no need to use a stylus. You can use it easily by tapping the screen buttons and the map with your ngertips.
Accessing the Navigation Software
Press the MENU button and touch the Navigation icon to access navigation mode.
Adjusting the Navigation Voice Volume
While the Navigation is on and a route has been programmed, the Navigation will speak commands. While the Navigation is speaking, adjust the volume by turning the radio volume knob. The Navigation volume will remain at this level and when done speaking will return to the previous source (ie, radio) at the volume level set for that source.
The main volume must be set above zero in order to hear the spoken directions. If the radio is muted, the Bluetooth (if equipped) engaged in a call, or the volume knob has been turned to zero, the navigation will not be heard but your visual directions will continue.
Selecting / Listening to a Source while Navigating
While navigating, other sources may be selected and listened to such as AM-FM Tuner, CD, etc. To listen to another source while navigating, press the SRC button and then select a source from the Source Menu. Navigation voice prompts will be heard automatically, although the navigation map cannot be seen. To view the navigation screen, but continue to listen to the selected source, press the NAV/ WIDE button.
15
VX6020
INITIAL SETUP
When using the navigation software for the rst time, an initial setup process starts automatically. Do as follows:
1. Select the written language of the application interface. Later you can change it in Regional settings.
2. Read the End User License Agreement. Tap to continue.
3. The Conguration Wizard starts. Tap to continue.
4. Select the language and speaker used for voice guidance messages. Later you
can change it in Sound and Warnings settings.
16
VX6020
5. If needed, modify the time format and unit settings. Later you can change them in Regional settings.
6. If needed, modify the default route planning options. Later you can change them in Route settings.
7. The initial setup is now complete. The Conguration Wizard can be restarted later from the Settings menu.
After the initial setup, the Navigation Menu appears and you can start using iGO primo.
Free Latest Map Guarantee
Visit www.naviextras.com to register your map. (Limited time only - Must be used within 90 days of initial activation).
NOTE: Map MUST be run in your navigation device one time before attempting
registration. Follow the instructions on-line.
17
VX6020
NAVIGATION MENU
You can reach all parts of iGO primo from the Navigation Menu.
You have the following options:
• Tap to select your destination by entering an address or selecting
a place of interest, a location on the map or one of your Favorite destinations. You can also look up your recent destinations from the Smart History, enter a coordinate or use the location saved in a photo.
• Tap to display the route parameters and the route in its full
length on the map. You can also perform route-related actions such as editing or canceling your route, setting a start point for the route, picking route alternatives, avoiding parts of the route, simulating navigation or adding the destination to your Favorites.
• Tap to customize the way the navigation software works, simulate
demo routes, or to run some additional applications.
• Tap to start navigating on the map. The button itself is a miniature
live map that shows your current position, the recommended route and the surrounding map area. Tap the button to enlarge the map to the full screen.
18
VX6020
BUTTONS AND OTHER CONTROLS ON THE SCREEN
When you are using iGO primo, you usually tap buttons on the touch screen. You only need to conrm selections or changes if the application needs to restart,
it needs to perform a major reconguration, or you are about to lose some of your data or settings. Otherwise, iGO primo saves your selections and applies the new settings without conrmation as soon as you use the controls.
Type Example Description How to Use It
Button
Button with value
Icon Shows status
Tap it to initiate a function, to open a new screen, or to set a parameter.
Some buttons display the current value of a eld or setting. Tap the button to change the value. After the change, the new value is shown on the button.
information.
Tap it once.
Tap it once.
Some icons also function as a button. Tap them once.
19
VX6020
List When you need to
select from several options, they appear in a list.
Radio button
Switch
Slider
Virtual keyboard
When there are only a few choices, radio buttons may be used instead of lists. Only one value can be selected.
When there are only two choices, a checkmark shows whether the feature is enabled.
When a feature can be set to dierent values in a range, iGO primo shows an indicator on a gauge that displays and sets the value
Alphabetic and alphanumeric keyboards to enter text and numbers.
Grab the list anywhere and slide your nger up or down. Depending on the speed of the sliding, the list will scroll fast or slow, only a bit or until the end.
Alternatively, move between pages with
the and buttons and tap the value that you want.
Tap one of the buttons to select a new value.
Tap it to turn the switch on or o.
• Drag the handle to move the slider to its new position.
• Tap the slider where you want the handle to appear; the thumb jumps there.
Each key is a touch screen button.
20
VX6020
Using Keyboards
You only need to enter letters or numbers when you cannot avoid it. You can type with your ngertips on the full-screen keyboards and you can switch between various keyboard layouts, for example English, Greek or numerical.
Task Instruction
Switching to another keyboard layout, for example from an English keyboard to a Greek keyboard.
Correcting your entry on the keyboard.
Entering a space, for example between a rst name and a family name or in multi-word street names.
Entering numbers and symbols.
Finalizing the keyboard entry (accepting the suggested search result).
Finalizing the keyboard entry (opening the list of search results).
Finalizing the keyboard entry (saving your input).
Canceling the keyboard entry (returning to the previous screen).
Tap the select the new keyboard layout from the list.
Tap character(s). Tap and hold the button to delete several characters or the entire input string.
Tap the center of the screen.
Tap to switch to a keyboard oering numeric and symbol characters.
Tap
Tap
Tap .
Tap .
to remove the unneeded
button at the bottom
.
button and
.
21
VX6020
Beyond Single Screen Tap
You usually need to tap the screen only once. However, some useful features can be accessed with combined touch screen tapping. Those are the following:
Action Details
Tapping and holding the screen.
Gestures (drag & drop). You need to drag and drop the screen only in cases
Tap and keep pressing the following buttons to reach extra functions:
• Tap and hold on list and menu screens: the Map screen appears.
• Tap and hold any of the , , , ,
, and buttons on the Map screen: you can
rotate, tilt or scale the map continuously.
• Tap and hold on keyboard screens: you can delete several characters quickly.
• Tap and hold or in long lists: you can scroll pages continuously.
like:
• Moving the handle on a slider.
• Scrolling the list: grab the list anywhere and slide your nger up or down. Depending on the speed of the sliding, the list will scroll fast or slow, only a bit or until the end.
• Moving the map in map browsing mode: grab the map, and move it in the desired direction.
22
VX6020
MAP SCREEN
The Map screen is the most frequently used screen of iGO primo.
Navigating On the Map
A small live map is displayed on the startup screen, the Navigation Menu, as a part
of the button.
To enlarge this small map and open the Map screen, tap . This map shows the current position (the Vehimarker, a red arrow by default), the
recommended route (an orange line), and the surrounding map area. When there is no GPS position, the Vehimarker is transparent. It shows your last
known position. You see colored dots circling around a satellite symbol in the top left corner. The
more green dots you see, the closer you are to get the valid GPS position.
23
VX6020
When GPS position is available, the Vehimarker is displayed in full color, now showing your current position.
There are screen buttons and data elds on the screen to help you navigate. During navigation, the screen shows route information.
By default, only one data eld is displayed in the bottom right corner. Tap this eld to see all route data elds.
Tap any of the data elds to suppress others and display only the selected one. The data elds are dierent when you are navigating an active route and when you have no specied destination (the orange line is not displayed).
24
VX6020
Default data elds when cruising without a destination (tap and hold any of the elds to change its value):
Field Description
Shows your current speed given by the GPS receiver.
Shows the speed limit of the current road if the map contains it.
Shows the current time corrected with time zone oset. The accurate time comes from the GPS satellites, and the time zone information comes from the map or it can be set manually in Regional settings. (The current time is always displayed in the top left corner of menu screens.)
Default data elds when navigating a route (tap and hold any of the elds to change its value):
Field Description
Shows the distance you need to travel on the route before reaching your nal destination.
Shows the time needed to reach the nal destination of the route based on information available for the remaining segments of the route. Historical trac data or trac patterns are also taken into account whenever such information exists..
Shows the estimated arrival time at the nal destination of the route based on information available for the remaining segments of the route. Historical trac data or trac patterns are also taken into account whenever such infromation exists.
25
VX6020
Position Markers
Vehimarker and Lock-on-Road
When your GPS position is available, iGO primo marks your current position with the Vehimarker. By default, this marker is a red arrow, but you can change this icon in Settings.
The exact location of the Vehimarker depends on the vehicle type used for route calculation. The vehicle type can be selected in Route settings.
• If you choose pedestrian: The Vehimarker is at your exact GPS position. The direction of the icon shows your current heading.
• If you choose any of the vehicles: The Vehimarker may not show your exact GPS position and heading. If roads are near, it is aligned to the nearest road to suppress GPS position errors, and the direction of the icon is aligned to the direction of the road.
Selected Map Location (Cursor) and Selected Map Object
You can mark a map location in the following ways:
• Tap the map when navigating,
• Tap the map when you are asked to conrm the destination at the end of a search, or
• Tap the map in Find on Map.
When a map location is selected, the Cursor appears at the selected point on the map.
The Cursor is displayed with a radiating red dot ( ) to make it visible at all zoom levels.
The location of the Cursor can be used as the destination of the route, a new alert point, you can search for Places around it, or you can save this location as one of your Favorite destinations.
You can also select some of the objects on the map. If you tap the map at the icon of a Place of Interest or an alert point, the object will be selected (you see a red circling border around the object), and you can get information about this object or use it as a route point.
26
VX6020
Objects On the Map
Streets and Roads
iGO primo shows the streets in a way that is similar to how the paper road maps show them. Their width and colors correspond to their importance: you can easily tell a freeway from a small street.
Turn Preview and Next Street
When navigating a route, the top section of the Map screen shows information about the next route event (maneuver) and the next street or the next city/town.
There is a eld in the top left corner that displays the next maneuver. Both the type of the event (turn, trac circle, exiting freeway, etc.) and its distance from the current position are displayed.
A smaller icon shows the type of the second next maneuver if it is near the rst one. Otherwise, only the next maneuver is displayed.
27
VX6020
Most of these icons are very intuitive. The following table lists some of the frequently shown route events. The same symbols are used in both elds:
Icon Description
Turn left.
Turn right.
Turn back.
Bear right.
Turn sharp left.
Keep left.
28
Continue straight in the intersection.
Go left on the trac circle, 3rd exit (next maneuver).
Enter trac circle (second next maneuver).
Enter freeway.
Exit freeway.
Board ferry.
VX6020
Leave ferry.
Approaching a waypoint.
Approaching the destination.
Lane Information and Signposts
When navigating on multilane roads, it is important to take the appropriate lane in order to follow the recommended route. If lane information is available in the map data, iGO primo displays the lanes and their directions using small arrows at the bottom of the map. Highlighted arrows represent the lanes you need to take.
Where additional information is available, signposts substitute arrows. Signposts are displayed at the top of the map. The color and style of the signposts are similar to the real ones you can see above road or by the roadside. They show the available destinations and the number of the road the lane leads to.
All signposts look similar when cruising (when there is no recommended route). When navigating a route, only the signpost that points to the lane(s) to be taken is displayed in vivid colors; all others are darker.
29
VX6020
Junction View
If you are approaching a freeway exit or a complex intersection and the needed information exists, the map is replaced with a 3D view of the junction. The lanes you need to take are displayed with arrows. Signposts can also be present if information is available.
3D Object Types
iGO primo supports the following 3D object types:
Type Description
3D terrain 3D terrain map data shows changes in terrain, elevations or
depressions in the land when you view the map in 2D, and use it to plot the route map in 3D when you navigate. Hills and mountains are shown in the background of the 3D map, and illustrated by color and shading on the 2D map.
Elevated roads Complex intersections and vertically isolated roads (such as
overpasses or bridges) are displayed in 3D.
3D landmarks Landmarks are 3D artistic or block representations of
prominent or well-known objects.
30
VX6020
Elements of the Active Route
iGO primo shows the route in the following way:
Symbol Name Description
Current GPS position and Start point
Waypoint (intermediate destination)
Your current position displayed on the map.
• In pedestrian mode it is the exact GPS position.
• If a vehicle is selected for route calculation and roads are near, the symbol is snapped onto the nearest road.
Normally if GPS position is available, the route starts from the current position. If there is no valid GPS position, iGO primo uses the last known position as the start point.
An intermediate destination of the route before reaching the nal destination.
Destination (end point) The nal destination of the route.
Route color The route always stands out with its
color on the map, both in daytime and in night color mode.
Streets and roads that are excluded from the navigation
Streets and roads that are aected by trac events
You can choose whether you want to use or avoid certain road types. However, when iGO primo cannot avoid such roads, the route will include them and it will show them in a color that is dierent from the route color.
Road segments may be aected by trac events received. These streets and roads are displayed in an alternate color, and small symbols displayed along the route show the type of the trac event.
31
VX6020
Manipulating the Map
Tap the map anywhere to browse it during navigation. The map stops following the current position (the Vehimarker, a red arrow by default, is not locked in a x position on the screen any more) and control buttons appear to help you modify the map view.
32
VX6020
Action Button(s) Description
Moving the map with drag & drop.
Zooming in and out
Tilting up and down
Rotating left and right
2D or 3D view
No buttons You can move the map in any
direction: tap and hold the map, and move your nger towards the direction you want to move the map.
Changes how much of the map is
,
,
,
,
displayed on the screen. iGO primo uses high-quality vector
maps that let you examine the map at various zoom levels, always with optimized content. It always displays street names and other text with the same font size, never upside-down, and you only see the streets and objects that you need.
Map scaling has a limit in 3D map view mode. If you zoom out further, the map switches to 2D view mode.
Tap the button once to modify the view in large steps, or tap and hold the button to modify it continuously and smoothly.
Changes the vertical view angle of the map in 3D mode.
Tap the button once to modify the view in large steps, or tap and hold the button to modify it continuously and smoothly.
Changes the horizontal view angle of the map.
Tap the button once to modify the view in large steps, or tap and hold the button to modify it continuously and smoothly.
Tap this button to switch between the 3D perspective and 2D top­down map view modes.
33
VX6020
Compass in 2D map view mode
Compass in 3D map view mode
Location information
Return to normal navigation
Additional options
Select destination
,
,
The direction of the compass shows North.
Tap the button to switch to North-up view, and then tap again to rotate the map in the previous direction.
The direction of the compass shows North.
Tap the button to switch to North-up view, and then tap again to rotate the map in the previous direction.
Tap this button to open a new screen with information about the selected map point, the Cursor.
Tap this button to move the map back to follow the current GPS position. Automatic map rotation is also re-enabled.
The map manipulation buttons disappear and navigation continues.
Tap this button to open a list of additional features like saving the Cursor as a Favorite destination, or searching for Places around the Cursor.
Tap this button to select the Cursor as a new destination. The route is automatically calculated.
34
VX6020
Quick Menu
The Quick menu is a selection of controls and functions that are frequently needed during navigation.
It can be opened directly from the Map screen by tapping .
The menu will close after a few seconds of inactivity or if you tap . The menu will also close if you initiate simple controls like muting the device. In
other cases tapping a button will open a new screen with options. Most of these functions are shortcuts. They are accessible from the menu system.
35
VX6020
There are more functions available than the number of buttons in the menu. In Settings, you can choose the function of each button. The following options are available:
Button Description Shortcut for:
Master Volume slider This slider adjusts the sound
volume of the device. All sounds of the application are aected.
This switch mutes all sounds
,
of the device. Tap again to re­enable sounds.
This function lets you search for a Place along your route or around your current location if there is no route calculated.
More / Settings / Sound and Warnings / Volume / Master slider
More / Settings / Sound and Warnings / Volume / Master switch
Find / Find Places / Quick Search
This button opens the list of your Favorite destinations.
This button opens the History list. You can select one of your previous destinations.
This button opens the route editing function.
This button opens the route related settings.
This button opens the map related settings.
Find / Favorite
Find / History
My Route / Edit Route
More / Settings / Route Settings
More / Settings / Map Settings
36
VX6020
This button opens a special screen with information about the current position and a button to search for nearby emergency or roadside assistance. For details, see the next chapter.
This button cancels the route and stops navigation. The button is replaced with the next one if waypoints are given.
This button skips the next waypoint from the route.
This button opens a 2D map scaled and positioned to show the entire route.
This button opens the Visual Guidance settings screen.
n/a
My Route / Cancel Route
n/a
My Route / Overview
More / Settings / Visual Guidance
This button lets you bypass parts of the recommended route.
This button opens the Trip Monitor screen where you can manage your previously saved trip logs and track logs.
This button opens the list of maneuvers (the itinerary).
With this function you can save the active route for later use.
My Route / Avoidances
More / Trip Monitor
Tap the top of the Map screen during navigation.
My Route / More / Save Route
37
VX6020
With this function you can replace the active route with a previously saved route.
With this function you can search for Places of Interest in various dierent ways.
This button opens the Map screen and starts simulating the active route.
This button opens the GPS Information screen with satellite position and signal strength information.
My Route / More / Load Route
Find / Find Places
My Route / More / Simulate Navigation
Tap the top of the Map screen when there is no GPS reception.
38
VX6020
Checking the Details of the Current Position (Where Am I?)
Opened from the Quick menu, this screen contains information about the current position (or about the last known position if GPS reception is not available) and a button to search for useful Places nearby.
Information On This Screen:
and : Latitude and Longitude (coordinate of the current position in WGS84 format).
: Altitude (elevation information coming from the GPS receiver - often inaccurate).
: House number on the left.
: House number on the right.
• In the middle of the screen you can see whether the position is current, or the time left since it was last updated.
• Address details (when available) of the current position are also displayed at the bottom.
39
VX6020
You can also perform some actions on this screen:
Tap to save the current position as a Favorite destination.
You can also search for assistance near your current position. Tap to open a new screen for the Quick search:
The following services can be searched around the current position or the last known position:
: Car repair and roadside assistance services
: Medical and emergency services
: Police stations
: Gas stations
Tap any of the buttons, select a Place from the list, and navigate to it.
40
VX6020
NAVIGATING
You can set up your route in dierent ways:
• If you need a route for immediate navigation, you can select the destination and start navigating to it right away (normal navigation).
• You can also plan a route independently of your current GPS position or even without GPS reception (to achieve this, you need to turn o the GPS receiver and set a new starting point in My Route / Edit Route by tapping the ag icon at the current position).
You can plan routes with multiple destinations. Select the rst destination. Then select a second destination and add it to your route to create a multi-point route. You can add as many destinations to your route as you like.
SELECTING THE DESTINATION OF A ROUTE
iGO primo oers you several ways of choosing your destination:
• Enter a full address or a part of an address, for example a street name without a house number or the names of two intersecting streets.
• Enter an address with ZIP code. This way you do not need to select the name of the city and the search for street names might be faster as well.
• Use a built-in Place of Interest as your destination.
• Select a location on the map with the Find on Map feature.
• Use a previously saved Favorite destination.
• Select a location from the History of previously used destinations.
• Enter the coordinate of the destination.
• Use the location where a photo was taken.
Entering an Address or a Part of the Address
If you know at least a part of the address, it is the quickest way to select the destination of the route.
Using the same screen, you can nd an address by entering:
• the exact address, including house number
• the center of a city/town
• an intersection
• the midpoint of a street
• any of the above, starting the search with the ZIP code.
41
VX6020
Entering an Address (United States)
To enter an address as the destination, do as follows:
1. If you are on the Map screen, tap to return to the
Navigation menu.
2. In the Navigation menu, tap the following buttons: , .
3. By default, iGO primo proposes the country and state where you are. If
needed,
tap , enter the rst few letters of the destination country or state on the keyboard, and select one from the list. If you select a country without a state, you can search for a city/town in all its states.
4. Select a new city/town:
a. Tap . The city/town of your current location is oered by
default. For a local search, tap to accept it, otherwise continue with entering the destination city/town name. b. Start entering the name of the city/town on the keyboard. c. Find the city/town you need:
• The most likely city/town name is always shown in the input eld.
To accept it, tap .
42
VX6020
• If the desired name does not show up, the names that match the string appear in a list after entering a couple of characters (to open the list of
results before it appears automatically, tap ). Select the city/ town from the list.
5. Enter the street name:
a. Tap . b. Start entering the street name on the keyboard. c. Find the street you need:
• The most likely street name is always shown in the input eld.
To accept it, tap .
• If the desired name does not show up, the names that match the string appear in a list after entering a couple of characters (to open the list of results
before it appears automatically, tap ). Select the street from the list.
43
VX6020
6. Enter the house number:
a. Tap . b. Enter the house number on the keyboard. (To enter letters, tap ).
c. Tap to nish entering the address. (If the entered house number cannot be found, the midpoint of the street is selected as the destination.)
7. A full screen map appears with the selected point in the middle. If necessary,
tap the map somewhere else to modify the destination. The Cursor ( )
appears at the new location. Tap to conrm the destination,
or tap to select a dierent destination.
44
VX6020
8. After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated.
Tap to modify route parameters, or tap and start your journey.
Tip!
If you know that you will use this destination frequently, before
tapping to conrm the destination, put it on the list of your
Favorites rst: tap then , give a name for the new
Favorite, and tap to save the location. The map with the destination returns automatically. Now you can start your journey.
45
VX6020
Entering an Address (Canada)
To enter an address as the destination, do as follows:
1. If you are on the Map screen, tap to return to the Navigation menu.
2. In the Navigation menu, tap the following buttons: , .
3. By default, iGO primo proposes the country, state and city where you are. If
needed, tap , enter the rst few letters of the destination country or state on the keyboard, and select one from the list. If you select a country without a state, you can search for a city/town in all its states.
4. If needed, select a new city/town:
a. Tap . b. Start entering the name of the city/town on the keyboard. c. Find the city/town you need:
• The most likely city/town name is always shown in the input eld.
To accept it, tap .
46
VX6020
• If the desired name does not show up, the names that match the string appear in a list after entering a couple of characters (to open the list of
results before it appears automatically, tap ). Select the city/ town from the list.
5. Enter the street name:
a. Tap . b. Start entering the street name on the keyboard. c. Find the street you need:
• The most likely street name is always shown in the input eld.
To accept it, tap .
• If the desired name does not show up, the names that match the string appear in a list after entering a couple of characters (to open the list of
results before it appears automatically, tap ). Select the street from the list.
47
VX6020
6. Enter the house number:
a. Tap . b. Enter the house number on the keyboard. (To enter letters, tap ).
c. Tap to nish entering the address. (If the entered house number cannot be found, the midpoint of the street is selected as the destination.)
7. A full screen map appears with the selected point in the middle. If necessary,
tap the map somewhere else to modify the destination. The Cursor ( )
appears at the new location. Tap to conrm the destination,
or tap to select a dierent destination.
48
VX6020
8. After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated.
Tap to modify route parameters, or tap and start your journey.
49
VX6020
Entering an Address Starting with the Street Name (in the United States only)
You can leave the city/town name empty and start the search with the street name. This way you can search in all streets of a state. Do as follows:
1. If you are on the Map screen, tap to return to the
Navigation menu.
2. In the Navigation menu, tap the following buttons: , .
3. By default, iGO primo proposes the country and state where you are. If needed, tap the button with the name of the country, enter the rst few letters of the destination country or state on the keyboard, and select a country and state from the list. If you select the country without a state, this function cannot work.
4. Enter the street name:
a. Tap . b. Start entering the street name on the keyboard. c. Find the street you need:
• The most likely street name is always shown in the input eld.
To accept it, tap .
50
VX6020
• If the desired name does not show up, the names that match the string appear in a list after entering a couple of characters (to open the list of
results before it appears automatically, tap ). Select the street from the list.
5. Enter the house number:
a. Tap . b. Enter the house number on the keyboard. (To enter letters, tap ).
c. Tap to nish entering the address. (If the entered house number cannot be found, the midpoint of the street is selected as the destination.)
6. A full screen map appears with the selected point in the middle. If necessary,
tap the map somewhere else to modify the destination. The Cursor ( )
appears at the new location. Tap to conrm the destination,
or tap to select a dierent destination.
51
VX6020
7. After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated.
Tap to modify route parameters, or tap and start your journey.
52
VX6020
Entering the Midpoint of a Street as the Destination
You can navigate to the midpoint of a street if the house number is not available:
1. If you are on the Map screen, tap to return to the Navigation menu.
2. In the Navigation menu, tap the following buttons: , .
3. Select the country, state and city as described earlier.
4. Enter the street name:
a. Tap . b. Start entering the street name on the keyboard. c. Find the street you need:
• The most likely street name is always shown in the input eld.
To accept it, tap .
• If the desired name does not show up, the names that match the string appear in a list after entering a couple of characters (to open the list of
results before it appears automatically, tap ). Select the street from the list.
53
VX6020
5. Instead of entering the house number, tap . The midpoint of the street is selected as the destination.
6. A full screen map appears with the selected point in the middle. If necessary,
tap the map somewhere else to modify the destination. The Cursor ( )
appears at the new location. Tap to conrm the destination,
or tap to select a dierent destination.
7. After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated.
Tap to modify route parameters, or tap and start your journey.
54
VX6020
Selecting an Intersection as the Destination
To enter an address as the destination, do as follows:
1. If you are on the Map screen, tap to return to the
Navigation menu.
2. In the Navigation menu, tap the following buttons: , .
3. Select the country, state and city as described earlier.
4. Enter the street name:
a. Tap . b. Start entering the street name on the keyboard. c. Find the street you need:
• The most likely street name is always shown in the input eld.
To accept it, tap .
• If the desired name does not show up, the names that match the string appear in a list after entering a couple of characters (to open the list of
results before it appears automatically, tap ). Select the street from the list.
55
VX6020
5. Enter the intersecting street name:
Tap .
• If only a few intersecting streets exist, their list appears immediately.
• In case of a longer street, the keyboard screen appears. Start entering the name of the intersecting street on the keyboard.
As soon as the street names that match the entered string can be shown on one screen, their list appears automatically. Select from the list.
6. A full screen map appears with the selected point in the middle. If necessary,
tap the map somewhere else to modify the destination. The Cursor ( )
appears at the new location. Tap to conrm the destination,
or tap to select a dierent destination.
56
VX6020
7. After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated.
Tap to modify route parameters, or tap and start your journey.
57
VX6020
Selecting a City/Town Center as the Destination
The city/town center is not the geometric center of the city but an arbitrary point the map creators have chosen. In towns and villages, it is usually the most important intersection; in larger cities, it is one of the important intersections.
1. If you are on the Map screen, tap to return to the
Navigation menu.
2. In the Navigation menu, tap the following buttons: , .
3. Select the country and state as described earlier.
4. Select the destination city/town:
a. Tap . b. Start entering the name of the city/town on the keyboard. c. Find the city/town you need:
• The most likely city/town name is always shown in the input eld.
To accept it, tap .
• If the desired name does not show up, the names that match the string appear in a list after entering a couple of characters (to open the list of
results before it appears automatically, tap ). Select the city/ town from the list.
58
VX6020
5. Instead of entering the street name, tap . This way the center of the displayed city/town becomes the destination of the route.
6. A full screen map appears with the selected point in the middle. If necessary,
tap the map somewhere else to modify the destination. The Cursor ( )
appears at the new location. Tap to conrm the destination,
or tap to select a dierent destination.
7. After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated.
Tap to modify route parameters, or tap and start your journey.
59
VX6020
Entering an Address with a ZIP Code
1. All of the above address searching possibilities can be performed with
entering the ZIP code instead of the city name. Find below an example with a full address:
1. If you are on the Map screen, tap to return to the
Navigation menu.
2. In the Navigation menu, tap the following buttons: , .
3. Select the country and state as described earlier.
4. Enter a new city/town using its ZIP code:
a. Tap .
b. Tap to open the numeric keypad. c. Start entering the ZIP code. d. Find the city/town you need:
• The most likely ZIP code is always shown in the input eld.
To accept it, tap .
• If the desired number does not show up, open the list of results by
tapping . Select the ZIP code from the list.
60
VX6020
5. Enter the street name:
a. Tap . b. Start entering the street name on the keyboard. c. Find the street you need:
• The most likely street name is always shown in the input eld.
To accept it, tap .
• If the desired name does not show up, the names that match the string appear in a list after entering a couple of characters (to open the list of
results before it appears automatically, tap ). Select the street from the list.
6. Enter the house number:
a. Tap . b. Enter the house number on the keyboard. (To enter letters, tap ).
c. Tap to nish entering the address. (If the entered house number cannot be found, the midpoint of the street is selected as the destination.)
61
VX6020
7. A full screen map appears with the selected point in the middle. If necessary,
tap the map somewhere else to modify the destination. The Cursor ( )
appears at the new location. Tap to conrm the destination,
or tap to select a dierent destination.
8. After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated.
Tap to modify route parameters, or tap and start your journey.
62
VX6020
Tips on Entering Addresses Quickly
When you are entering the name of a city/town or a street:
• Only those letters are oered on the keyboard that appear in possible search results. All other characters are grayed out.
• As you are typing, the most likely result is always displayed in the input eld. If
the guess is correct, tap to select it.
• After entering a couple of letters, tap to list the items that contain the specied letters.
You can speed up nding an intersection:
• Search rst for the street with a less common or less usual name; fewer letters are enough to nd it.
• If one of the streets is shorter, search for that one rst. You can then nd the second one faster.
You can search for both the type and the name of a road. If the same word appears in several names, for example in the name of streets, roads and avenues, you can obtain the result faster if you enter the rst letter of the street type: For example, enter ‘PI A’ to obtain Pine Avenue and skip all Pine Streets and Pickwick Roads.
You can also search in ZIP codes. As ZIP codes consist of only a few characters, this is usually faster than entering the name of the city/town.
63
VX6020
Selecting the Destination from the Places of Interest
You can select your destination from the Places of Interest included with iGO primo. Using the same screen, you can nd a Place in dierent ways:
• with the Quick search feature, you can quickly nd a nearby Place by its name
• with the Preset search feature, you can nd frequently searched types of Places with only a few screen taps
• you can search for a Place by its category
• you can search for a Place by its name.
In addition, you can search for special services from the ‘Where Am I?’ screen.
Quick Search for a Place of Interest
The Quick search feature lets you quickly nd a Place by its name. The search is always carried out:
• along the recommended route if it exists or
• around your current location if there is no destination given.
1. Start the Quick search function:
• If you are on the Map screen, tap and then tap .
• If you are in the Navigation menu, tap , and then
tap .
2. Using the keyboard, start entering the name of the Place.
3. After entering a few letters, tap to open the list of Places with
names containing the entered character sequence.
64
VX6020
4. (Optional) The Places in the list are ordered by the length of the necessary
detour (when navigating a route) or by their distance from the current position (when no destination is given).
If you need to reorder the list, tap .
5. Browse the list if necessary and tap one of the list items. A full screen map
appears with the selected point in the middle. The name and address of the Place is displayed at the top of the screen.
6. (Optional) Tap to see the details of the selected Place. Tap
to return to the map.
7. If necessary, tap the map somewhere else to modify the destination. The
Cursor ( ) appears at the new location. Tap to conrm the
destination, or tap to select a dierent destination.
8. After a short summary of the route parameters, the map appears showing the
entire route. The route is automatically calculated.
Tap to modify route parameters, or tap and start your journey.
65
VX6020
Searching for a Place of Interest Using Preset Categories
The Preset search feature lets you quickly nd the most frequently selected types of Places.
1. If you are on the Map screen, tap to return to the
Navigation menu.
2. In the Navigation menu, tap the following buttons: , .
3. The preset search categories appear:
• If an active route exists, gas stations are searched along the route.
• If there is no active route (destination is not selected), they are searched around the current position.
• If the current position is not available either (no GPS signal), they are searched around the last known position.
• If an active route exists, parking lots are searched around the destination of the route.
• If there is no active route (destination is not selected), they are searched around the current position.
• If the current position is not available either (no GPS signal), they are searched around the last known position.
• If an active route exists, restaurants are searched along the route.
• If there is no active route (destination is not selected), they are searched around the current position.
• If the current position is not available either (no GPS signal), they are searched around the last known position.
• If an active route exists, accommodation is searched around the destination of the route.
• If there is no active route (destination is not selected), they are searched around the current position.
• If the current position is not available either (no GPS signal), they are searched around the last known position.
66
VX6020
4. Tap any of the quick search buttons to get an instant list of Places.
5. (Optional) The Places in the list are ordered by their distance from the current or last known position, from the destination or by the length of the necessary detour. If you need to reorder the list, tap .
6. Browse the list if necessary and tap one of the list items. A full screen map appears with the selected point in the middle. The name and address of the Place is displayed at the top of the screen.
7. (Optional) Tap to see the details of the selected Place. Tap to return to the map.
8. If necessary, tap the map somewhere else to modify the destination. The
Cursor ( ) appears at the new location. Tap to conrm the
destination, or tap to select a dierent destination.
67
VX6020
9. After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated.
Tap to modify route parameters, or tap and start your journey.
68
VX6020
Searching for a Place of Interest by Category
You can search for Places of Interest by their categories and subcategories.
1. If you are on the Map screen, tap to return to the
Navigation menu.
2. In the Navigation menu, tap the following buttons: , .
3. Tap .
4. Select the area around which the Place should be searched for:
• Tap to search around the current position or if it is not available, around the last know position. (The result list will be ordered by the distance from this position.)
• Tap to search for a place within a selected city/town. (The result list will be ordered by the distance from the center of the selected city/ town.)
• Tap to search for a place around the destination of the active route. (The result list will be ordered by the distance from the destination.)
• Tap to search along the active route, and not around a given point. This is useful when you search for a later stopover that results in a minimal detour only, such as searching for upcoming gas stations or restaurants. (The result list will be ordered by the length of the necessary detour.)
69
VX6020
5. (Optional) If you have selected , select the city/town to search in.
6. Select one of the main Place categories (e.g. Accommodation) or
tap to list all Places around the selected location or along the route.
7. Select one of the Place subcategories (e.g. Hotel or Motel) or
tap to list all Places in the selected main category around the selected location or along the route.
70
VX6020
8. Sometimes the list of brands in the selected Place subcategory appears. Select
one brand or tap to list all Places in the selected subcategory around the selected location or along the route.
9. Finally, the results appear in a list.
10. (Optional) The Places in the list are ordered by their distance from the current or last known position, from the selected city/town, from the destination or by the length of the necessary detour.
If you need to reorder the list, tap .
11. Browse the list if necessary and tap one of the list items. A full screen map appears with the selected point in the middle. The name and address of the Place is displayed at the top of the screen.
12. (Optional) Tap to see the details of the selected Place. Tap to return to the map.
13. If necessary, tap the map somewhere else to modify the destination. The
Cursor ( ) appears at the new location. Tap to conrm the
destination, or tap to select a dierent destination.
71
VX6020
14. After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated.
Tap to modify route parameters, or tap and start your journey.
72
VX6020
Searching for a Place of Interest by Name
You can search for Places of Interest by their names. You can search around dierent locations or along your route in the whole Place database or in one Place category or subcategory only.
1. If you are on the Map screen, tap to return to the
Navigation menu.
2. In the Navigation menu, tap the following buttons: , .
3. Tap .
4. Select the area around which the Place should be searched for:
• Tap to search around the current position or if it is not available, around the last know position. (The result list will be ordered by the distance from this position.)
• Tap to search for a place within a selected city/town. (The result list will be ordered by the distance from the center of the selected city/ town.)
• Tap to search for a place around the destination of the active route. (The result list will be ordered by the distance from the destination.)
• Tap to search along the active route, and not around a given point. This is useful when you search for a later stopover that results in a minimal detour only, such as searching for upcoming gas stations or restaurants. (The result list will be ordered by the length of the necessary detour.)
73
VX6020
5. (Optional) If you have selected , select the city/town to search in.
6. Tap to search in all Places, or select one of the main Place categories (e.g. Accommodation) to search in.
7. Tap to search in the selected Place category or select one of the Place subcategories (e.g. Hotel or Motel) to search in.
74
VX6020
8. Tap if you have not done it before.
9. Using the keyboard, start entering the name of the Place.
10. After entering a few letters, tap to open the list of Places with names containing the entered character sequence.
11. (Optional) The Places in the list are ordered by their distance from the current or last known position, from the selected city/town, from the destination or by the length of the necessary detour.
If you need to reorder the list, tap .
75
VX6020
12. Browse the list if necessary and tap one of the list items. A full screen map appears with the selected point in the middle. The name and address of the Place is displayed at the top of the screen.
13. (Optional) Tap to see the details of the selected Place. Tap to return to the map.
14. If necessary, tap the map somewhere else to modify the destination. The
Cursor ( ) appears at the new location. Tap to conrm the
destination, or tap to select a dierent destination.
15. After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated.
Tap to modify route parameters, or tap and start your journey.
76
VX6020
Selecting Nearby Assistance from ‘Where Am I?’
You can quickly search for nearby assistance from the ‘Where Am I?’ screen.
1. On the Map screen, tap to open the Quick menu.
2. Tap , and then .
3. Preset search categories appear, all for searching around the current position (or around the last known position if the current position is not available):
: Car repair and roadside assistance services
: Medical and emergency services
: Police stations
: Gas stations
77
VX6020
4. Tap any of the quick search buttons to get an instant list of that type of Places.
5. (Optional) The Places in the list are ordered by their distance from the current or last known position, from the selected city/town, from the destination or by the length of the necessary detour.
If you need to reorder the list, tap .
6. Browse the list if necessary and tap one of the list items. A full screen map appears with the selected point in the middle. The name and address of the Place is displayed at the top of the screen.
7. (Optional) Tap to see the details of the selected Place. Tap to return to the map.
78
VX6020
8. If necessary, tap the map somewhere else to modify the destination. The
Cursor ( ) appears at the new location. Tap to conrm the
destination, or tap to select a dierent destination.
9. After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated.
Tap to modify route parameters, or tap and start your journey.
79
VX6020
Selecting a Map Location as the Destination
1. If you are on the Map screen, tap to return to the
Navigation menu.
2. In the Navigation menu, tap the following buttons: , .
3. Locate your destination on the map: move and scale the map as needed.
4. Tap the location that you want to select as your destination.
The Cursor ( ) appears.
5. Tap to select the Cursor as the destination.
6. After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated.
Tap to modify route parameters, or tap and start your journey.
80
VX6020
Selecting the Destination from Your Favorites
You can select a location that you have already saved as a Favorite to be your destination.
1. Access the list of Favorites:
• If you are on the Map screen, tap and then tap .
• If you are in the Navigation menu, tap and then tap .
2. The list of Favorite destinations is displayed.
3. Tap the Favorite that you want to set as your destination. If necessary, browse
down to see more of the list or tap and enter a few letters from the name of the Favorite destination.
4. A full screen map appears with the selected point in the middle. The
Cursor ( ) appears at the new location. Tap to conrm the
destination, or tap to select a dierent destination.
81
VX6020
5. After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated.
Tap to modify route parameters, or tap and start your journey.
82
VX6020
Selecting One of the Most Likely Destinations (Smart History)
The destinations that you have set earlier appear in the History list. Two of those recent destinations are shown in the Destination menu for easy access. Smart History oers these locations based on your navigation habits, using parameters like the current time of day, the day of week, and the current location. The more you use the navigation software, the better it can guess your desired destination.
1. If you are on the Map screen, tap to return to the
Navigation menu.
2. In the Navigation menu, tap .
3. Tap the or the destination in the History eld.
4. A full screen map appears with the selected point in the middle. The
Cursor ( ) appears at the new location. Tap to conrm the
destination, or tap to select a dierent destination.
83
VX6020
5. After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated.
Tap to modify route parameters, or tap and start your journey.
84
VX6020
Selecting a Recent Destination from the History
The destinations that you have set earlier appear in the History.
1. Access the History:
• If you are on the Map screen, tap and then tap .
• If you are in the Navigation menu, tap and then tap .
2. The list of recent destinations appear. Smart History promotes three destinations to the rst page based on your previous routes (most likely destinations). The rest of the destinations are ordered by time they were last selected. If necessary, scroll the list to see earlier destinations.
3. Select a destination from the list.
4. A full screen map appears with the selected point in the middle. The
Cursor ( ) appears at the new location. Tap to conrm the
destination, or tap to select a dierent destination.
85
VX6020
5. After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated.
Tap to modify route parameters, or tap and start your journey.
86
VX6020
Entering the Coordinates of the Destination
You can also select a destination by entering its coordinate. Do as follows:
1. If you are on the Map screen, tap to return to the
Navigation menu.
2. In the Navigation menu, tap .
3. Open the menu and tap .
4. You can enter the latitude and longitude values in any of the following formats: decimal degrees; degrees and decimal minutes; or degrees, minutes and decimal seconds.
5. (Optional) If necessary, tap then and enter the coordinate in UTM format.
6. When nished, tap .
87
VX6020
7. A full screen map appears with the selected point in the middle. The
Cursor ( ) appears at the new location. Tap to conrm the
destination, or tap to select a dierent destination.
8. After a short summary of the route parameters, the map appears showing the entire route. The route is automatically calculated.
Tap to modify route parameters, or tap and start your journey
88
VX6020
Building a Route from the List of Destinations (Create Route)
You can also build your route destination by destination from the My Route menu.
1. If you are on the Map screen, tap to return to the
Navigation menu.
2. In the Navigation menu, tap .
3. Tap .
4. There is only one line in the list of route points, the start point of the route, normally the current GPS position.
5. Tap to select the destination.
6. The Destination menu appears and you can select the destination of the route the same way as described in the previous sections.
89
VX6020
7. When the new destination is selected, the list returns.
8. To add more destinations, tap where you want to insert the new route point in the list, and repeat the above procedure.
90
VX6020
VIEWING THE ENTIRE ROUTE ON THE MAP
It is easy to get a map overview of the active route. Do as follows:
1. If you are on the Map screen, tap to return to the
Navigation menu.
2. In the Navigation menu, tap .
3. Tap . The active route is displayed in its full length on the map together with additional information and controls.
91
VX6020
CHECKING ROUTE PARAMETERS AND ACCESSING ROUTE RELATED FUNCTIONS
You can check dierent parameters of the route recommended by iGO primo.
1. If you are on the Map screen, tap to return to the
Navigation menu.
2. In the Navigation menu, tap .
3. The following pieces of information are displayed:
• The name and/or address of the destination.
• Warning icons (if any). They provide extra information about your route (e.g. unpaved roads or toll roads to be taken).
• The total time of the route.
• The total length of the route.
• Estimated delay calculated from trac events on your route.
• The symbol of the vehicle type used in route calculation.
• The route planning method (e.g. Fast).
4. You have the following options on this screen (for detailed instructions on how to use them, see the next chapter):
• Tap to edit the route: to add or remove destinations or change their sequence. You can also set a route start point other than your current location. This can be useful to plan and save a future trip.
• Tap to display the entire route on the map.
• Tap to bypass a part of the route.
• Tap to delete the active route.
• Tap to open a list with more options like selecting from route alternatives, changing route parameters, simulating the route, saving the active route or loading a previously saved route.
• Tap to return to the Navigation menu.
92
VX6020
MODIFYING THE ROUTE
When navigation is already started, there are several ways to modify the active route. The following sections show some of those options.
Selecting a New Destination When Already Having a Route: New Route, Waypoint or Final Destination
If you already have a recommended route and you select a new destination as described in the above sections, the application will ask you whether to start a new route, add a new waypoint (intermediate destination) to the route or append the newly selected destination at the end of the current route.
• Tap to plan a new route to the newly selected location. The previous destination and waypoint(s) are deleted.
• Tap to add the newly selected location as an intermediate destination to your route. The other destinations of the route remain intact. Note: the new waypoint is placed among destinations to keep the route optimal. To decide where a waypoint should appear, use the Edit Route feature.
• Tap to append the newly selected destination at the end of the route. The other destinations of the route remain intact. The previous nal destination is now the last waypoint.
93
VX6020
Setting a New Starting Position for the Route
For normal navigation, all routes are planned from the current position. In order to check future routes, simulate them or see their length in time and distance, you can turn o the GPS receiver. Then you can set the starting point of the route to a dierent location than the current GPS position.
1. If you are on the Map screen, tap to return to the Navigation menu.
2. In the Navigation menu, tap .
3. If you already have a route, tap .
If you are starting a new route, tap .
94
VX6020
4. The rst line is the start of the route, normally the current GPS position.
Tap and conrm your action at the warning message.
5. The Destination menu appears and you can select the start point of the route
the same way you select a destination.
6. When the new start point is set, tap .
7. The map returns with a transparent Vehimarker (showing that there is no GPS
reception). If an active route already existed, it is now recalculated starting from the selected location.
8. To return to normal navigation, tap .
95
VX6020
Editing the List of Destinations (Edit Route)
You can edit the route by modifying the list of destinations. You can add or remove destinations, modify the start position or reorder the list.
1. If you are on the Map screen, tap to return to the Navigation menu.
2. In the Navigation menu, tap .
3. If you already have a route, tap .
4. You have the following options:
• Tap to add a new destination.
• Tap to delete a destination.
• Tap to modify the start point of the route.
• Tap to reorder the list. You can do it manually or you can let the application optimize the route for you.
96
VX6020
Pausing the Active Route
You do not need to pause the active route: when you start driving again, iGO primo restarts the voice instructions from your position.
Canceling the Active Route
To cancel the navigated route, do one of the following:
• If you are on the Map screen, tap and then tap .
(If you have a route with waypoints, you need to tap until all waypoints are deleted.)
• In the Navigation menu, tap and then tap . The active route is deleted with all its waypoints.
97
VX6020
Checking Route Alternatives when Planning the Route
You can select from dierent route alternatives or change the route planning method after you have selected a new destination. Do as follows:
1. Select a destination as explained earlier, and go to the route conrmation
screen.
2. Tap .
3. Tap .
4. You see the basic details of three route alternatives with the selected route
planning method. Tap any of them to see it on the map.
98
VX6020
5. Or if you cannot nd a good alternative, tap and scroll down for
routes with dierent routing methods.
6. Select one of the route alternatives and tap to return to the
previous screen. iGO primo recalculates the route. The orange line now shows the new recommended route.
Checking Route Alternatives for an Existing Route
To recalculate the active route with a dierent route planning method, you can modify the Route settings. There is another way to do this and to compare dierent route alternatives with the same route planning method. Do as follows:
1. If you are on the Map screen, tap to return to the
Navigation menu.
2. In the Navigation menu, tap .
99
VX6020
3. Tap .
4. Tap .
5. You see the basic details of three route alternatives with the selected route
planning method. Tap any of them to see it on the map.
6. Or if you cannot nd a good alternative, tap and scroll down for
routes with dierent routing methods.
7. Select one of the route alternatives then tap and hold for a few
seconds to return to the Map screen. iGO primo recalculates the route. The orange line now shows the new recommended route.
100
Loading...
