Intel 7265NG User Manual

User Guide

© Copyright 2015 Hewlett-Packard

Development Company, L.P.

Bluetooth is a trademark owned by its proprietor and used by Hewlett-Packard Company under license. Intel and Centrino are trademarks of Intel Corporation in the U.S. and other countries. SD Logo is a trademark of its proprietor. Java is a U.S. trademark of Sun Microsystems, Inc. Microsoft and Windows are U.S. registered trademarks of the Microsoft group of companies.

The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

First Edition: February 2015

Document Part Number: 784275-001

Product notice

This user guide describes features that are common to most models. Some features may not be available on your computer.

This computer may require upgraded and/ or separately purchased hardware and/or a DVD drive to install the Windows 7 software and take full advantage of Windows 7 functionality. See http://windows.microsoft.com/en-us/ windows7/get-know-windows-7 for details.

To access the latest user guide, go to http://www.hp.com/support, and select your country. Select Drivers & Downloads, and then follow the on-screen instructions.

Software terms

By installing, copying, downloading, or otherwise using any software product preinstalled on this computer, you agree to be bound by the terms of the HP End User License Agreement (EULA). If you do not accept these license terms, your sole remedy is to return the entire unused product (hardware and software) within 14 days for a full refund subject to the refund policy of your seller.

For any further information or to request a full refund of the price of the computer, please contact your seller.

Safety warning notice

WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not place the computer directly on your lap or obstruct the computer air vents. Use the computer only on a hard, flat surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to contact the skin or a soft surface, such as pillows or rugs or clothing, during operation. The computer and the AC adapter comply with the user-accessible surface temperature limits defined by the International Standard for Safety of Information Technology Equipment (IEC 60950-1).

iii

iv Safety warning notice

Table of contents

1 Welcome ...........................................................................................................................................................		1
	Finding information ...............................................................................................................................	2
2	Getting to know your computer .........................................................................................................................	3
	Top .......................................................................................................................................................	3
	TouchPad ............................................................................................................................	3
	Lights ...................................................................................................................................	4
	Buttons, speakers, and fingerprint reader ............................................................................	5
	Keys .....................................................................................................................................	6
	Right .....................................................................................................................................................	7
	Left .......................................................................................................................................................	8
	Display ..................................................................................................................................................	9
	Bottom ................................................................................................................................................	10
3 Connecting to a network .................................................................................................................................		11
	Connecting to a wireless network .......................................................................................................	11
	Using the wireless controls ................................................................................................	11
	Turning wireless devices on or off .....................................................................	11
	Using HP Connection Manager (select models only) ........................................	12
	Using the wireless button ..................................................................................	12
	Using operating system controls .......................................................................	12
	Using a WLAN (select models only) ..................................................................................	12
	Using an Internet service provider ....................................................................	13
	Setting up a WLAN ............................................................................................	13
	Configuring a wireless router ............................................................................	13
	Protecting your WLAN .......................................................................................	14
	Connecting to a WLAN ......................................................................................	14
	Using Bluetooth wireless devices (select models only) .....................................................	14
	Connecting to a wired network (via optional docking device or mini docking station cable) ..............	15
	Connecting to a local area network (LAN) .........................................................................	15
4	Navigating using the keyboard, touch gestures and pointing devices ............................................................	17
	Using pointing devices .......................................................................................................................	17
	Setting pointing device preferences ...................................................................................	17
	Using the TouchPad ..........................................................................................................	17
	Turning the TouchPad off and on ......................................................................	17

v

Using TouchPad Gestures ................................................................................	17
Tapping .............................................................................................	18
Scrolling ............................................................................................	19
Pinching/zooming .............................................................................	19
Rotating (select models only) ...........................................................	20
Using the keyboard ............................................................................................................................	20
Identifying the hot keys ......................................................................................................	20
Using keypads ...................................................................................................................	21
Using the embedded numeric keypad ...............................................................	21
Turning the embedded numeric keypad on and off ..........................	22
Switching key functions on the embedded numeric keypad .............	22
Using an optional external numeric keypad ......................................................	22
5 Multimedia .......................................................................................................................................................	23
Audio ..................................................................................................................................................	23
Connecting speakers .........................................................................................................	23
Adjusting the volume .........................................................................................................	23
Connecting headphones/microphone ................................................................................	23
Checking audio functions on the computer ........................................................................	24
Webcam .............................................................................................................................................	24
Video ..................................................................................................................................................	24
VGA (via optional docking device or mini docking station cable) ......................................	25
DisplayPort (via optional docking device) ..........................................................................	25
Connecting wired displays using MultiStream Transport (via optional docking device) ....	26
HDMI ..................................................................................................................................	27
Configuring audio for HDMI ...............................................................................................	28
Intel Wireless Display (select models only) .......................................................................	28
6 Power management ........................................................................................................................................	29
Shutting down the computer ...............................................................................................................	29
Setting power options .........................................................................................................................	29
Using power-saving states .................................................................................................	29
Initiating and exiting Sleep ................................................................................	30
Initiating and exiting Hibernation .......................................................................	30
Using the power meter and power settings .......................................................	30
Setting password protection on wakeup ...........................................................	31
Using battery power ...........................................................................................................	31
Factory-sealed battery ......................................................................................	31
Finding additional battery information ...............................................................	31
Using Battery Check .........................................................................................	32
Displaying the remaining battery charge ...........................................................	32

vi

	Maximizing battery discharge time ....................................................................	32
	Managing low battery levels ..............................................................................	32
	Identifying low battery levels .............................................................	32
	Resolving a low battery level ............................................................	33
	Conserving battery power .................................................................................	33
	Using external AC power ...................................................................................................	33
7	External cards and devices .............................................................................................................................	35
	Using Micro SD memory cards ...........................................................................................................	35
	Inserting a digital card ........................................................................................................	35
	Removing a digital card .....................................................................................................	35
	Using a USB device ...........................................................................................................................	36
	Connecting a USB device ..................................................................................................	36
	Removing a USB device ....................................................................................................	37
	Using optional external devices ..........................................................................................................	37
	Using optional external drives ............................................................................................	37
	Using the docking connector .............................................................................................	38
8	Drives ..............................................................................................................................................................	40
	Using hard drives ...............................................................................................................................	40
	Improving hard drive performance .....................................................................................	40
	Using Disk Defragmenter ..................................................................................	40
	Using Disk Cleanup ...........................................................................................	40
	Using optional external optical drives (select models only) ................................................................	40
	Identifying the installed optional external optical drive .......................................................	41
	Inserting an optical disc .....................................................................................................	41
	Tray-load ...........................................................................................................	41
	Slot-load ............................................................................................................	41
	Removing an optical disc ...................................................................................................	42
	Tray-load ...........................................................................................................	42
	When the disc tray opens normally ..................................................	42
	When the disc tray fails to open normally .........................................	43
	Slot-load ............................................................................................................	43
	Sharing optical drives ........................................................................................................	44
9	Security ...........................................................................................................................................................	45
	Protecting the computer .....................................................................................................................	45
	Using passwords ................................................................................................................................	45
	Setting passwords in Windows ..........................................................................................	46
	Setting passwords in Computer Setup ..............................................................................	47

vii

Managing a BIOS administrator password ........................................................................	47
Entering a BIOS administrator password ..........................................................	48
Managing a Computer Setup DriveLock password ...........................................................	48
Setting a DriveLock password ...........................................................................	49
Entering a DriveLock password ........................................................................	49
Changing a DriveLock password ......................................................................	50
Removing DriveLock protection ........................................................................	50
Using Computer Setup Automatic DriveLock ....................................................................	51
Entering an Automatic DriveLock password .....................................................	51
Removing Automatic DriveLock protection .......................................................	51
Using antivirus software .....................................................................................................................	52
Using firewall software .......................................................................................................................	52
Installing critical security updates .......................................................................................................	52
Using HP Client Security (select models only) ...................................................................................	53
Installing an optional security cable ....................................................................................................	53
Using the fingerprint reader ................................................................................................................	53
Locating the fingerprint reader ...........................................................................................	53
10 Maintenance .................................................................................................................................................	55
Cleaning your computer .....................................................................................................................	55
Cleaning the display, sides, and cover ..............................................................................	55
Cleaning procedures ..........................................................................................................	55
Cleaning the display ..........................................................................................	55
Cleaning the sides and cover ............................................................................	55
Cleaning the TouchPad and keyboard ..............................................................	55
Updating programs and drivers ..........................................................................................................	56
Using SoftPaq Download Manager ....................................................................................................	56
11 Backup and recovery ....................................................................................................................................	57
Creating recovery media and backups ...............................................................................................	57
Guidelines ..........................................................................................................................	57
Creating recovery media with HP Recovery Disc Creator .................................................	57
Creating recovery media ...................................................................................	58
Backing up your information ..............................................................................................	58
Performing a system recovery ............................................................................................................	59
Using the Windows recovery tools .....................................................................................	59
Using f11 recovery tools (select models only) ...................................................................	60
Using Windows 7 operating system media ........................................................................	60

viii

12 Computer Setup (BIOS), MultiBoot, and HP PC Hardware Diagnostics (UEFI) ...........................................		62
Using Computer Setup .......................................................................................................................		62
	Starting Computer Setup ...................................................................................................	62
	Navigating and selecting in Computer Setup .....................................................................	62
	Restoring factory settings in Computer Setup ...................................................................	63
	Updating the BIOS .............................................................................................................	63
	Determining the BIOS version ...........................................................................	63
	Downloading a BIOS update .............................................................................	64
Using MultiBoot ..................................................................................................................................		65
	About the boot device order ...............................................................................................	65
	Choosing MultiBoot preferences ........................................................................................	65
	Setting a new boot order in Computer Setup ....................................................	65
	Dynamically choosing a boot device using the f9 prompt .................................	66
	Setting a MultiBoot Express prompt ..................................................................	66
	Entering MultiBoot Express preferences ...........................................................	66
Using HP PC Hardware Diagnostics (UEFI) (select models only) .....................................................		66
	Downloading HP PC Hardware Diagnostics (UEFI) to a USB device ...............................	67
13 Support	.........................................................................................................................................................	68
Contacting .............................................................................................................................support		68
Labels .................................................................................................................................................		68
14 Specifications ................................................................................................................................................		70
Input .........................................................................................................................................power		70
Operating .......................................................................................................................environment		70
Appendix A .......................................................................................	Traveling with or shipping your computer	71
Appendix B ..............................................................................................................................	Troubleshooting	72
Troubleshooting .................................................................................................................resources		72
Resolving ................................................................................................................................issues		72
....................................................................................	The computer is unable to start up	72
............................................................................................	The computer screen is blank	72
....................................................................................	Software is functioning abnormally	73
.......................................................................................	The computer is unusually warm	73
......................................................................................	An external device is not working	73
................................................................	The wireless network connection is not working	73
...........	The optional external optical disc tray does not open for removal of a CD or DVD	74
.....................................	The computer does not detect the optional external optical drive	74
..................................................................	An optional external optical disc does not play	75

ix

A movie is not visible on an external display .....................................................................	75
The process of burning an optional external disc does not begin, or it stops before
completion .........................................................................................................................	75
Appendix C Electrostatic discharge ...................................................................................................................	76
Index ...................................................................................................................................................................	77

x

1Welcome

After you set up and register the computer, it is important to take the following steps:

●Connect to the Internet—Set up your wired or wireless network so that you can connect to the Internet. For more information, see Connecting to a network on page 11.

●Update your antivirus software—Protect your computer from damage caused by viruses. The software is preinstalled on the computer. For more information, see Using antivirus software on page 52.

●Get to know your computer—Learn about your computer features. Refer to Getting to know your computer on page 3 and Navigating using the keyboard, touch gestures and pointing devices on page 17 for additional information.

●Find installed software—Access a list of the software preinstalled on the computer:

Select Start > All Programs. For details about using the software included with the computer, see the software manufacturer's instructions, which may be provided with the software or on the manufacturer's website.

●Back up your hard drive by creating recovery discs or a recovery flash drive. See Backup and recovery on page 57.

1

Finding information

The computer comes with several resources to help you perform various tasks.

	Resources	For information about
	Setup Instructions poster	● How to set up the computer
		● Help to identify computer components
	Help and Support	●	Operating system information
	To access Help and Support, select Start > Help and	● Software, driver, and BIOS updates
	Support.	●	Troubleshooting tools
	To access the latest user guide, go to
		● How to access support
	http://www.hp.com/support, and select your country.
	Select Drivers & Downloads, and then follow the on-
	screen instructions.
	Regulatory, Safety, and Environmental Notices	● Regulatory and safety information
	To access the user guides, select Start > Help and	●	Battery disposal information
	Support > User guides.
	Safety & Comfort Guide	● Proper workstation setup, posture, health, and work habits
	To access the user guides, select Start > Help and	● Electrical and mechanical safety information
	Support > User guides.
	– or –
	Go to http://www.hp.com/ergo.
	Worldwide Telephone Numbers booklet	HP support telephone numbers
	This booklet is provided with your computer.

HP website

To access the latest user guide, go to http://www.hp.com/support, and select your country. Select Drivers & Downloads, and then follow the onscreen instructions.

●Support information

●Ordering parts and finding additional help

●Accessories available for the device

Limited Warranty*

Warranty information

To access this guide, selectStart > Help and Support > User guides > View Warranty Information.

– or –

Go to http://www.hp.com/go/orderdocuments.

*You can find the expressly provided HP Limited Warranty applicable to your product located with the user guides on your computer and/or on the CD/DVD provided in the box. In some countries/regions, HP may provide a printed HP Limited Warranty in the box. For some countries/regions where the warranty is not provided in printed format, you may request a printed copy from http://www.hp.com/go/orderdocuments or write to:

●North America: Hewlett-Packard, MS POD, 11311 Chinden Blvd., Boise, ID 83714, USA

●Europe, Middle East, Africa: Hewlett-Packard, POD, Via G. Di Vittorio, 9, 20063, Cernusco s/Naviglio (MI), Italy

●Asia Pacific: Hewlett-Packard, POD, P.O. Box 200, Alexandra Post Office, Singapore 911507

When you request a printed copy of your warranty, please include your product number, warranty period (found on your service label), name, and postal address.

IMPORTANT: Do NOT return your HP product to the addresses above. For U.S. support, go to http://www.hp.com/go/ contactHP. For worldwide support, go to http://welcome.hp.com/country/us/en/wwcontact_us.html.

2 Chapter 1 Welcome

2Getting to know your computer

Top

TouchPad

Component		Description
(1)	TouchPad zone	Moves the pointer and selects or activates items on the
		screen.
(2)	Left TouchPad button	Functions like the left button on an external mouse.
(3)	Right TouchPad button	Functions like the right button on an external mouse.

Top 3

Lights

	Component			Description
	(1)		Power light	● On: The computer is on.
				● Blinking: The computer is in the Sleep state.
				● Off: The computer is off.
	(2)		Caps lock light	On: Caps lock is on.
	(3)		TouchPad light	● Amber: The TouchPad is off.
				● Off: The TouchPad is on.
			Mute light	● Amber: Computer sound is off.
	(4)
				● Off: Computer sound is on.
			Microphone mute light	● Amber: Microphone sound is off.
	(5)
				● Off: Microphone sound is on.
	(6)		Wireless light	● White: An integrated wireless device, such as a
				wireless local area network (WLAN) device and/or a
				Bluetooth® device, is on.
				● Amber: All wireless devices are off.
			Num lock light	On: Num lock is on.
	(7)

4Chapter 2 Getting to know your computer

Buttons, speakers, and fingerprint reader

	Component			Description
	(1)		Power button	● When the computer is off, press the button to turn on
				the computer.
				● When the computer is on, press the button briefly to
				initiate Sleep.
				● When the computer is in the Sleep state, press the
				button briefly to exit Sleep.
				● When the computer is in Hibernation, press the button
				briefly to exit Hibernation.
				CAUTION: Pressing and holding down the power button
				will result in the loss of unsaved information.
				If the computer has stopped responding and Windows®
				shutdown procedures are ineffective, press and hold the
				power button for at least 5 seconds to turn off the computer.
				If the computer has stopped responding and the previous
				shutdown procedures are ineffective, press and hold the
				power button for 15 seconds to perform a hardware reset
				turning off the computer immediately.
				To learn more about your power settings: Select Start >
				Control Panel > System and Security > Power Options.
	(2)		Speaker grill	Produce sound.
			Fingerprint reader	Allows a fingerprint logon to Windows, instead of a password
	(3)
				logon.

Top 5

Keys

	Component			Description
	(1)		esc key	Displays system information when pressed in combination
				with the fn key.
	(2)		fn key	Executes frequently used system functions when pressed in
				combination with a function key, the num lk key, the esc
				key, or the b key.
	(3)		Windows button	Displays the Windows Start menu.
	(4)		Function keys	Execute frequently used system functions when pressed in
				combination with the fn key.
	(5)		Embedded numeric keypad	When the keypad is turned on, it can be used like an
				external numeric keypad.
				Each key on the keypad performs the function indicated by
				the icon in the upper-right corner of the key.
			num lk key	Turns the embedded numeric keypad on and off when
	(6)
				pressed in combination with the fn key.

6Chapter 2 Getting to know your computer

Right

	Component			Description
			Audio-out (headphone) jack/Audio-in	Produces sound when connected to optional powered
	(1)
			(microphone) jack	stereo speakers, headphones, earbuds, a headset, or
				television audio. Also connects an optional headset
				microphone.
				WARNING! To reduce the risk of personal injury, adjust
				the volume before putting on headphones, earbuds, or a
				headset. For additional safety information, see the
				Regulatory, Safety, and Environmental Notices. To access
				the user guides, select Start > Help and Support > User
				Guides.
				NOTE: When a device is connected to the jack, the
				computer speakers are disabled.
				NOTE: Be sure that the device cable has a 4-conductor
				connector that supports both audio-out (headphone) and
				audio-in (microphone).
			USB 3.0 charging port	Connects an optional USB device. The USB charging port
	(2)
				can also charge select models of cell phones and MP3
				players, even when the computer is off.
				NOTE:
					The battery can be depleted quickly if you charge
				multiple	devices while operating on battery power.
				NOTE: For details about different types of USB ports, see
				Using a USB device on page 36.
			Docking connector	Connects an optional docking device or mini docking
	(3)
				station cable.
			AC adapter/Battery light	● White: The computer is connected to external power
	(4)
				and the battery is charged from 90 to 99 percent.
				● Amber: The computer is connected to external power
				and the battery is charged from 0 to 90 percent.
				● Blinking amber: A battery that is the only available
				power source has reached a low battery level. When
				the battery reaches a critical battery level, the battery
				light begins blinking rapidly.
				● Off: The battery is fully charged.
			Power connector	Connects an AC adapter.
	(5)

Right 7

Left

	Component				Description
	(1)		Security cable slot		Attaches an optional security cable to the computer.
					NOTE: The security cable is designed to act as a
					deterrent, but it may not prevent the computer from being
					mishandled or stolen.
	(2)		HDMI port		Connects an optional video or audio device, such as a
					high-definition television, any compatible digital or audio
					component, or a high-speed HDMI device.
	(3)		USB 3.0 charging port		Connects an optional USB device. The USB charging port
					can also charge select models of cell phones and MP3
					players, even when the computer is off.
					NOTE:
						The battery can be depleted quickly if you charge
					multiple	devices while operating on battery power.
					NOTE: For details about different types of USB ports, see
					Using a USB device on page 36.
	(4)		Micro SD memory card reader		Supports micro Secure Digital (SD) memory cards.

8Chapter 2 Getting to know your computer

Display

	Component			Description
			Internal microphones (2)	Record sound.
	(1)
				On: The webcam is in use.
	(2)		Webcam light
				Records video and captures still photographs.
	(3)		Webcam
				For information on using the webcam, select Start > All
				Programs > Communication and Chat > Cyberlink YouCam.
			Internal display switch	Turns off the display or initiates Sleep if the display is closed
	(4)
				while the power is on.
				NOTE: The display switch is not visible on the outside of the
				computer.
				Send and receive wireless signals to communicate with wireless
	(5)		WLAN antennas (2)* (select models only)
				local area networks (WLAN).

(6)Near Field Communication (NFC) antenna* (select models only)

Send and receive wireless signals to communicate and transfer data/info to and from your NFC-compatible devices.

*The antennas are not visible on the outside of the computer. For optimal transmission, keep the areas immediately around the antennas free from obstructions. To see wireless regulatory notices, see the section of the Regulatory, Safety, and Environmental Notices that applies to your country or region. To access the user guides, select Start > Help and Support > User Guides.

Display 9

Bottom

Component		Description
(1)	Docking device receptors (2)	Connects an optional docking device.

10 Chapter 2 Getting to know your computer

3Connecting to a network

Your computer can travel with you wherever you go. But even at home, you can explore the globe and access information from millions of websites using your computer and a wired or wireless network connection. This chapter will help you get connected to that world.

Connecting to a wireless network

Wireless technology transfers data across radio waves instead of wires. Your computer is equipped with one or more of the following wireless devices:

●Wireless local area network (WLAN) device (select models only)—Connects the computer to wireless local area networks (commonly referred to as Wi-Fi networks, wireless LANs, or WLANs) in corporate offices, your home, and public places such as airports, restaurants, coffee shops, hotels, and universities. In a WLAN, the mobile wireless device in your computer communicates with a wireless router or a wireless access point.

●Bluetooth device (select models only)—Creates a personal area network (PAN) to connect to other Bluetooth-enabled devices such as computers, phones, printers, headsets, speakers, and cameras. In a PAN, each device communicates directly with other devices, and devices must be relatively close together—typically within 10 meters (approximately 33 feet) of each other.

For more information about wireless technology, see the information and website links provided in Help and Support. To access Help and Support, select Start > Help and Support.

Using the wireless controls

You can control the wireless devices in your computer using these features:

●Wireless button, wireless switch, or wireless key (referred to in this chapter as the wireless button)

●Operating system controls

Turning wireless devices on or off

You can use the wireless button or HP Connection Manager (select models only) to turn on and turn off wireless devices.

NOTE: A computer may have a wireless button, a wireless switch, or a wireless key on the keyboard. The term wireless button is used throughout this guide to refer to all types of wireless controls.

To turn off wireless devices using HP Connection Manager:

▲Right-click the HP Connection Manager icon in the notification area, at the far right of the taskbar, and then click the power button next to the desired device.

-or-

Select Start > All Programs > Productivity and Tools > HP Connection Manager, and then click the power button next to the desired device.

Connecting to a wireless network 11

Using HP Connection Manager (select models only)

HP Connection Manager provides a central location for managing your wireless devices, and an interface for sending and receiving SMS (text) messages. HP Connection Manager allows you to manage the following devices:

●Wireless local area network (WLAN)/Wi-Fi

●Bluetooth

HP Connection Manager provides information and notifications on connection status, power status, and SMS messages. Status information and notifications are provided in the notification area, at the far right of the taskbar.

To open HP Connection Manager:

▲ Click the HP Connection Manager icon in the taskbar. -or-

Select Start > All Programs > Productivity and Tools > HP Connection Manager. For more information, see the HP Connection Manager software Help.

Using the wireless button

The computer has a wireless button, one or more wireless devices, and one or two wireless lights, depending on the model. All of the wireless devices on your computer are enabled at the factory, so the wireless light is on (white) when you turn on the computer.

The wireless light indicates the overall power state of your wireless devices, not the status of individual devices. If the wireless light is white, at least one wireless device is on. If the wireless light is off, all wireless devices are off.

NOTE: On some models, the wireless light is amber when all wireless devices are off.

Because the wireless devices are enabled at the factory, you can use the wireless button to turn on or turn off the wireless devices simultaneously.

Using operating system controls

The Network and Sharing Center allows you to set up a connection or network, connect to a network, manage wireless networks, and diagnose and repair network problems.

To use operating system controls:

▲ Select Start > Control Panel > Network and Internet > Network and Sharing Center. For more information, access Help and Support by selecting Start > Help and Support.

Using a WLAN (select models only)

With a WLAN device, you can access a wireless local area network (WLAN), which is composed of other computers and accessories that are linked by a wireless router or a wireless access point.

NOTE: The terms wireless router and wireless access point are often used interchangeably.

12 Chapter 3 Connecting to a network

●A large-scale WLAN, such as a corporate or public WLAN, typically uses wireless access points that can accommodate a large number of computers and accessories and can separate critical network functions.

●A home or small office WLAN typically uses a wireless router, which allows several wireless and wired computers to share an Internet connection, a printer, and files without requiring additional pieces of hardware or software.

To use the WLAN device in your computer, you must connect to a WLAN infrastructure (provided through a service provider or a public or corporate network).

Using an Internet service provider

When you are setting up Internet access in your home, you must establish an account with an Internet service provider (ISP). To purchase Internet service and a modem, contact a local ISP. The ISP will help set up the modem, install a network cable to connect your wireless computer to the modem, and test the Internet service.

NOTE: Your ISP will give you a user ID and a password to use for Internet access. Record this information and store it in a safe place.

Setting up a WLAN

To set up a WLAN and connect to the Internet, you need the following equipment:

●A broadband modem (either DSL or cable) (1) and high-speed Internet service purchased from an Internet service provider

●A wireless router (2) (purchased separately)

●A wireless computer (3)

NOTE: Some modems have a built-in wireless router. Check with your ISP to determine what type of modem you have.

The illustration below shows an example of a wireless network installation that is connected to the Internet.

As your network grows, additional wireless and wired computers can be connected to the network to access the Internet.

For help in setting up your WLAN, see the information provided by your router manufacturer or your ISP.

Configuring a wireless router

For help in setting up a WLAN, see the information provided by your router manufacturer or your ISP.

NOTE: It is recommended that you initially connect your new wireless computer to the router by using the network cable provided with the router. When the computer successfully connects to the Internet, disconnect the cable, and access the Internet through your wireless network.

Connecting to a wireless network 13

Protecting your WLAN

When you set up a WLAN or access an existing WLAN, always enable security features to protect your network from unauthorized access. WLANs in public areas (hotspots) like coffee shops and airports may not provide any security. If you are concerned about the security of your computer in a hotspot, limit your network activities to email that is not confidential and basic Internet surfing.

Wireless radio signals travel outside the network, so other WLAN devices can pick up unprotected signals. Take the following precautions to protect your WLAN:

●Use a firewall.

A firewall checks both data and requests for data that are sent to your network, and discards any suspicious items. Firewalls are available in both software and hardware. Some networks use a combination of both types.

●Use wireless encryption.

Wireless encryption uses security settings to encrypt and decrypt data that is transmitted over the network. For more information, access Help and Support by selecting Start > Help and Support.

Connecting to a WLAN

To connect to the WLAN, follow these steps:

1.Turn on the computer. Be sure that the WLAN device is on. If the device is on, the wireless light is on. If the wireless light is off, press the wireless button.

NOTE: On some models, the wireless light is amber when all wireless devices are off.

2.Click the network status icon in the notification area, at the far right of the taskbar.

3.Select a WLAN to connect to.

4.Click Connect.

If the WLAN is a security-enabled WLAN, you are prompted to enter a security code. Type the code, and then click OK to complete the connection.

NOTE: If no WLANs are listed, you may be out of range of a wireless router or access point.

NOTE: If you do not see the WLAN you want to connect to, click Open Network and Sharing Center. and then click Set up a new connection or network. A list of options is displayed, allowing you to manually search for and connect to a network or to create a new network connection.

5.Follow the on-screen instructions to complete the connection.

After the connection is made, place the mouse pointer over the network status icon in the notification area, at the far right of the taskbar, to verify the name and status of the connection.

NOTE: The functional range (how far your wireless signals travel) depends on WLAN implementation, router manufacturer, and interference from other electronic devices or structural barriers such as walls and floors.

Using Bluetooth wireless devices (select models only)

A Bluetooth device provides short-range wireless communications that replace the physical cable connections that traditionally link electronic devices such as the following:

14 Chapter 3 Connecting to a network

●Computers (desktop, notebook, PDA)

●Phones (cellular, cordless, smart phone)

●Imaging devices (printer, camera)

●Audio devices (headset, speakers)

●Mouse

Bluetooth devices provide peer-to-peer capability that allows you to set up a personal area network (PAN) of Bluetooth devices. For information about configuring and using Bluetooth devices, see the Bluetooth software Help.

Connecting to a wired network (via optional docking device or mini docking station cable)

A local area network (LAN) is a wired connection. A LAN connection uses a RJ-45 network cable (sold separately) and an optional docking device or mini docking station cable.

WARNING! To reduce the risk of electric shock, fire, or damage to the equipment, do not plug a modem cable or telephone cable into an RJ-45 (network) jack.

Connecting to a local area network (LAN)

Use a LAN connection if you want to connect the computer (via the optional docking device or mini docking station cable) directly to a router in your home (instead of working wirelessly), or if you want to connect to an existing network at your office.

Connecting to a LAN requires an 8-pin, RJ-45 network cable and optional docking device or mini docking station cable.

To connect the network cable, follow these steps:

1.Plug the network cable into the network jack (1) on the optional docking device or mini docking station cable connected to the computer.

Connecting to a wired network (via optional docking device or mini docking station cable) 15

2.Plug the other end of the network cable into a network wall jack (2) or router.

NOTE: If the network cable contains noise suppression circuitry (3), which prevents interference from TV and radio reception, orient the circuitry end of the cable toward the computer.

16 Chapter 3 Connecting to a network

4Navigating using the keyboard, touch gestures and pointing devices

Your computer allows navigation using touch gestures (select models only) in addition to the keyboard and mouse. Touch gestures can be used on your computer TouchPad.

Select computer models have special action keys or hot key functions on the keyboard to perform routine tasks.

Using pointing devices

NOTE: In addition to the pointing devices included with your computer, you can use an external USB mouse (purchased separately) by connecting it to one of the USB ports on the computer.

Setting pointing device preferences

Use Mouse Properties in Windows to customize settings for pointing devices, such as button configuration, click speed, and pointer options.

To access Mouse Properties:

●Select Start > Devices and Printers. Then right-click the device representing your computer, and select Mouse settings.

Using the TouchPad

NOTE: Your TouchPad is equipped with a capacitive image sensor. This sensor supports the forceenabled gesture continuation feature for navigating, scrolling, and pinching/zooming. This feature enables these TouchPad gestures to repeatedly continue as long as finger force is being applied to the TouchPad during the gesturing technique. Additionally, the TouchPad detects the force of the finger pressure being applied while using these gestures. Press your fingers down on the TouchPad with force while gesturing to accelerate the gesture motion. The classic TouchPad gestures described in the section below are also supported.

To move the pointer, slide one finger across the TouchPad in the direction you want the pointer to go. Use the left and right TouchPad buttons like the buttons on an external mouse.

Turning the TouchPad off and on

To turn the TouchPad off and on, press fn+f2.

Using TouchPad Gestures

Your TouchPad allows you to navigate the pointing device on the screen by using your fingers to control the pointer action.

The TouchPad supports a variety of gestures. To use TouchPad gestures, place two fingers on the TouchPad at the same time.

NOTE: TouchPad gestures are not supported in all programs.

Using pointing devices 17

To view the demonstration of a gesture:

1.Click the Show hidden icons icon in the notification area, at the far right of the taskbar.

2.Click the Synaptics Pointing Device icon, and then click Pointing Device Properties.

3.Click the Device Settings tab, select the device in the window that is displayed, and then click Settings.

4.Select the gesture to activate the demonstration.

To turn the gestures off or on:

1.Click the Show hidden icons icon in the notification area, at the far right of the taskbar.

2.Click the Synaptics Pointing Device icon, and then click Pointing Device Properties.

3.Click the Device Settings tab, select the device in the window that is displayed, and then click Settings.

4.Select the check box next to the gesture that you want to turn on or off.

5.Click Apply, and then click OK.

Tapping

To make an on-screen selection, use the Tap function on the TouchPad.

●Tap one finger on the TouchPad zone to make a selection. Double-tap an item to open it.

18 Chapter 4 Navigating using the keyboard, touch gestures and pointing devices

Scrolling

Scrolling is useful for moving up, down, or sideways on a page or image.

●Place two fingers slightly apart on the TouchPad zone and then drag them up, down, left, or right.

Pinching/zooming

Pinching and zooming allow you to zoom out or in on images or text.

●Zoom in by placing two fingers together on the TouchPad zone and then moving your fingers apart.

●Zoom out by placing two fingers apart on the TouchPad zone and then moving your fingers together.

Using pointing devices 19

Rotating (select models only)

Rotating allows you to turn items such as photos.

●Anchor the forefinger of your left hand in the TouchPad zone. Using your right hand, slide your forefinger in a sweeping motion from 12 o’clock to 3 o’clock. To reverse the rotation, move your forefinger from 3 o’clock to 12 o’clock.

Using the keyboard

The keyboard and mouse allow you to type select items, scroll and to perform the same functions as using touch gestures. The keyboard also allows you to use action keys and hot keys to perform specific functions.

NOTE: Depending on the country or region, your keyboard may have different keys and keyboard functions than those discussed in this section.

Identifying the hot keys

A hot key is a combination of the fn key (1) and either the esc key (2), or one of the function keys (3). To use a hot key:

▲Briefly press the fn key, and then briefly press the second key of the hot key combination.

Hot key combination	Description
fn+esc	Displays system information.
fn+f2	Turns the TouchPad on and off.
fn+f3	Initiates Sleep, which saves your information in system memory. The display and other system
	components turn off and power is conserved.
	To exit Sleep, briefly press the power button.
	CAUTION: To reduce the risk of information loss, save your work before initiating Sleep.
fn+f4	Switches the screen image among display devices connected to the system. For example, if a
	monitor is connected to the computer via the optional docking device, fn+f4 alternates the screen
	image from computer display to monitor display to simultaneous display on both the computer and
	the monitor.
	Most external monitors receive video information on the computer using the external VGA video
	standard. The fn+f4 hot key can also alternate images among other devices that are receiving video
	information on the computer.

20 Chapter 4 Navigating using the keyboard, touch gestures and pointing devices
