Integra DTR-4.5 User Manual

AV Receiver
DTR-4.5
Instruction Manual
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN OR MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Important Safety Instructions
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to
persons. The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
AVIS
RISQUE DE CHOC ELECTRIQUE
NE PAS
OUVRIR
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radia­tors, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are pro­vided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience recepta­cles, and the point where they exit from the appara­tus.
11. Only use attachments/accessories specified by the manufacturer.
12.
Use only with the cart, stand,
PORTABLE CART WARNING
tripod, bracket, or table spec­ified by the manufacturer, or sold with the apparatus. When a cart is used, use cau­tion when moving the cart/ apparatus combination to avoid injury from tip-over.
S3125A
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15. Damage Requiring Service Unplug the apparatus from the wall outlet and refer servicing to qualified service personnel under the following conditions: A. When the power-supply cord or plug is damaged, B. If liquid has been spilled, or objects have fallen
into the apparatus,
C. If the apparatus has been exposed to rain or
water,
D. If the apparatus does not operate normally by
following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require extensive work by a qualified technician to restore the apparatus to its normal operation,
E. If the apparatus has been dropped or damaged in
any way, and
F. When the apparatus exhibits a distinct change in
performance this indicates a need for service.
16. Object and Liquid Entry Never push objects of any kind into the apparatus through openings as they may touch dangerous volt­age points or short-out parts that could result in a fire or electric shock. The apparatus shall not be exposed to dripping or splashing and no objects filled with liquids, such as vases shall be placed on the apparatus. Don’t put candles or other burning objects on top of this unit.
17. Batteries Always consider the environmental issues and fol­low local regulations when disposing of batteries.
18. If you install the apparatus in a built-in installation, such as a bookcase or rack, ensure that there is ade­quate ventilation. Leave 20 cm (8") of free space at the top and sides and 10 cm (4") at the rear. The rear edge of the shelf or board above the apparatus shall be set 10 cm (4") away from the rear panel or wall, creating a flue-like gap for warm air to escape.
2
Precautions
For U.S. Models
Note to CATV system installer:
This reminder is provided to call the CATV system installer’s attention to Section 820-40 of the NEC which provides guidelines for proper grounding and, in partic­ular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.
FCC Information for User
CAUTION:
The user changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protec­tion against harmful interference in a residential instal­lation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a partic­ular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encour­aged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
1. Recording Copyright
only, recording copyrighted material is illegal with­out permission of the copyright holder.
2. AC Fuse
not user-serviceable. If you cannot turn on the AV receiver, have it checked by the dealer from whom you purchased this unit.
3. Care
receiver all over with a soft cloth. For stubborn stains, use a soft cloth dampened with a weak solu­tion of mild detergent and water. Dry the AV receiver immediately afterwards with a clean cloth. Don’t use abrasive cloths, thinners, alcohol, or other chemical solvents, because they may damage the finish or remove the panel lettering.
4. Power WARNING
BEFORE PLUGGING IN THE UNIT FOR THE FIRST TIME, READ THE FOLLOWING SECTION CAREFULLY. AC outlet voltages vary from country to country. Make sure that the voltage in your area meets the voltage requirements printed on the AV receiver’s rear panel (e.g., AC 230 V, 50 Hz or AC 120 V, 60 Hz).
Setting the [Standby/On] switch to Standby does not fully shutdown the AV receiver. If you do not intend to use the AV receiver for an extended period, remove the power cord from the wall outlet.
— The AC fuse inside the AV receiver is
—Occasionally you should dust the AV
—Unless it’s for personal use
For Canadian model
NOTE:
COMPLIES WITH CANADIAN ICES-003. For models having a power cord with a polarized plug:
CAUTION:
MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
THIS CLASS B DIGITAL APPARATUS
TO PREVENT ELECTRIC SHOCK,
Modèle pour les Canadien
REMARQUE:
LA CLASSE B EST CONFORME À LA NORME NMB-003 DU CANADA.
Sur les modèles dont la fiche est polarisée:
ATTENTION:
TRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE CORRE­SPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.
CET APPAREIL NUMÉRIQUE DE
POUR ÉVITER LES CHOCS ÉLEC-
Thank you for purchasing an Integra AV Receiver. Please read this manual thoroughly before making any connections and plugging it in. Following the instructions in this manual will enable you to obtain optimum perfor­mance and listening enjoyment from your new AV Receiver. Please retain this manual for future refer­ence.
3
Precautions
—Continued
Supplied Accessories
For British models
Replacement and mounting of an AC plug on the power supply cord of this unit should be performed only by qualified service personnel.
IMPORTANT
The wires in the mains lead are coloured in accordance with the following code:
Blue: Neutral Brown: Live
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured mark­ings identifying the terminals in your plug, proceed as follows: The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black. The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red.
IMPORTANT
A 5 or 13 ampere fuse is fitted in this plug. Should the fuse need to be replaced, please ensure that the replace­ment fuse has a rating of 5 or 13 amperes and that it is approved by ASTA or BSI to BS1362. Check for the ASTA mark or the BSI mark on the body of the fuse. IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY. THERE IS A DANGER OF SEVERE ELECTRICAL SHOCK IF THE CUT OFF PLUG IS INSERTED INTO ANY 13 AMPERE SOCKET. If in any doubt, consult a qualified electrician.
For European Models
Declaration of Conformity
We,
ONKYO EUROPE ELECTRONICS GmbH LIEGNITZERSTRASSE 6, 82194 GROEBENZELL, GERMANY
declare in own responsibility, that the ONKYO product described in this instruction manual is in compliance with the corresponding technical standards such as EN60065, EN55013, EN55020 and EN61000-3-2, -3-3.
GROEBENZELL, GERMANY
I. MORI
ONKYO EUROPE ELECTRONICS GmbH
Make sure you have the following accessories:
Remote controller & three batteries (AA/R6)
Indoor FM antenna
AM loop antenna
Power cord
Left
Left
Left
Left
Front
Front
Front
Front
Right
Right
Right
Right
Zone 2
Zone 2
Zone 2
Zone 2
/
/
/
/
Surround
SP-B
SP-B
SP-B
SP-B
Zone 2
Zone 2
Zone 2
Zone 2
/
/
/
/
Front
Left
Front
Right
SP-B
Left
SP-B
Right
Surround
Front
Left
Front
Right
SP-B
Left
SP-B
Right
1
2
Speaker Cable
Left
Left
Left
Left
Left
Left
Right
Right
Surround
Surround
Surround
Surround
Right
Left
Surround
Right
Surround
Left
3
Right
Right
Right
Right
Center
Center
Zone 2
Zone 2
Zone 2
Zone 2
Surround Back
Surround Back
Surround Back
Surround Back
Zone 2
Right
Zone 2
Left
Center
Zone 2
Right
Zone 2
Left
Surround Back
Right
Surround Back
Left
Center
Surround Back
Right
Surround Back
Left
Speaker cable labels
* In catalogs and on packaging, the letter at the end of the product
name indicates the color. Specifications and operation are the same regardless of color.
4
Features
Amplifier
• 85 watts per channel into 8 ohms, 2 channels driven
from 20 Hz to 20 kHz, less than 0.08% total harmonic distortion (FTC rating)
• 5-channel amplifier
• Optimum Gain Volume Circuitry
• Zone 2 capability
• 24-bit/192 kHz D/A converters
• WRAT (Wide Range Amplifier Technology)
• Color-coded speaker terminal posts
Audio/Video
• Dolby
• DTS
• Theater-Dimensional*3 virtual surround mode
• Zone 2 out
• Composite video to S-Video and S-Video to compos-
• CinemaFILTER
• Subwoofer pre out
•4 digital inputs (2 optical, 2 coaxial), 1 digital optical
•3 component video inputs, 1 output
•4 S-Video inputs, 3 outputs
*1
Digital, Dolby Pro Logic II
*2
and DTS 96/24
ite video conversion
*4
output.
FM/AM Tuner
• 40 AM/FM presets
• AM/FM auto tuning
Others
• Easy-to-use onscreen setup menus
• Preprogrammed remote controller for use with other
AV components
*1. Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories.
*2. “DTS” and “DTS 96/24 are trademarks of Digital Theater Sys-
tems, Inc. *3. “Theater-Dimensional” is a trademark of Onkyo Corporation. *4. “CinemaFILTER” is a trademark of Onkyo Corporation. A-BUS and A-BUS Ready are registered trademarks of LeisureTech Electronics Pty Ltd Australia. “Xantech” is a registered trademark of Xantech Corporation. “Niles” is a registered trademark of Niles Audio Corporation.
5
Table of Contents
Introduction
Important Safety Instructions ..........................................................................................2
Precautions .......................................................................................................................3
Supplied Accessories.......................................................................................................4
Features .............................................................................................................................5
Tab le of Contents.............................................................................................................. 6
Front & Rear Panels..........................................................................................................8
Remote Controller...........................................................................................................12
About Home Theater .......................................................................................................19
Connecting the AV receiver
About AV Connections...................................................................................................20
Connecting Your Speakers............................................................................................. 21
Connecting Antenna.......................................................................................................23
Connecting Both Audio & Video....................................................................................25
Which Connections Should I Use? ...............................................................................25
Connecting Your TV or Projector ...................................................................................26
Connecting AV components..........................................................................................26
Connecting Audio components.....................................................................................33
Connecting Components ........................................................................................34
Connecting the Power Cords of Other Components...................................................35
Connecting the Supplied Power Cord...........................................................................35
Turning On the AV receiver............................................................................................35
Basic
First Time Setup
About the Onscreen Setup Menus ................................................................................36
Initial Setup......................................................................................................................37
Digital Input ...................................................................................................................37
Component Video Setup ...............................................................................................38
Speaker Setup .................................................................................................................39
Changing the TAPE/MD/CDR Display ............................................................................ 43
Basic Operation
Selecting the Input Source.............................................................................................44
Setting the Display Brightness......................................................................................45
Muting the AV receiver ...................................................................................................45
Using the Sleep Timer.....................................................................................................45
Using Headphones .........................................................................................................45
Displaying Source Information......................................................................................46
Using the Tuner ...............................................................................................................47
Selecting Listening Modes.............................................................................................49
Listening mode table .....................................................................................................50
About the Listening Modes............................................................................................51
Others
Troubleshooting ..............................................................................................................79
Specifications..................................................................................................................83
6
Advanced
Features
Table of Contents
—Continued
Advanced
Controlling Other Components
Entering a Remote Control Codes................................. 69
Learning Commands from Another Remote
Controller ..................................................................... 77
Using Macros................................................................... 78
Introduction ............................... 2
Connections ............................ 21
First Setup ............................... 36
Basic Operation ...................... 44
Advanced Operation............... 52
Advanced
Features
Advanced
Features
Advanced
Features
Advanced Setup
Decoder Setup................................................................. 56
Audio Adjust Functions.................................................. 57
Assigning Listening Modes to Input Sources.............. 59
Setting Preferences ........................................................ 60
Changing the Remote Controller’s ID ........................... 62
Advanced Operation
Using the Late Night Function (Dolby Digital only) ..... 52
Using the CinemaFILTER ............................................... 52
Adjusting the Bass & Treble........................................... 52
Adjusting Individual Speaker Levels............................. 53
Using the DVD Analog Multichannel Input ................... 53
Recording ........................................................................ 54
Zone 2
Connecting Zone 2.......................................................... 63
Setting the Powered Zone 2........................................... 64
Setting the zone 2 OUT................................................... 65
Using Zone 2.................................................................... 66
Using the Remote Control in Zone 2............................. 67
Advanced Setup...................... 56
Zone 2 ...................................... 63
Using the Remote Controller
with Other Components ...... 69
Troubleshooting ...................... 79
Others....................................... 83
7
Front & Rear Panels
Front Panel
1
5 678JK L N O R TP Q SM2 3 4 9
Zone 2
Standby
V
For detailed information, see the pages in parentheses.
Standby/On button (35)
A
This button is used to set the AV receiver to On or Standby.
B
Standby indicator (35)
This indicator lights up when the AV receiver is in Standby mode, and it flashes while a signal is being received from the remote controller.
Zone 2 indicator (66)
C
This indicator lights up when Zone 2 is selected.
Remote-control sensor (18)
D
This sensor receives control signals from the remote controller.
Rec Out button (54)
E
This button is used to select the input source to be recorded.
Zone 2 button (66)
F
This button is used to select the input source for Zone 2.
Level button (66)
G
This button is used to set the volume for Zone 2.
Tone button (67)
H
This button is used to adjust the bass and treble for Zone 2.
I
Controller [ ] [ ] buttons (54, 66, 67)
These buttons are used to select the input source to be recorded via the REC OUTs, to select the input source for Zone 2, and to set the volume, bass, and treble for Zone 2.
WU
J
Stereo button (49)
This button is used to select the Stereo listening mode.
K
Listening Mode [ ] [ ] buttons (49)
These buttons are used to select the listening modes.
L
Display button (46)
This button is used to display various information about the currently selected input source.
M
Display
See “Display” on page 9.
N
Memory button (48)
This button is used when storing or deleting radio presets.
O
Tuning Mode button (47)
This button is used to select the Auto or Manual tun­ing mode.
P
Dimmer button (45)
This button is used to adjust the display brightness.
Q
Setup button (37)
This button is used to access the onscreen setup menus that appear on the connected TV.
R
Arrow/Tuning/Preset & Enter buttons (37)
When the AM or FM input source is selected, the Tuning [ ] [ ] buttons are used to tune the tuner, and the Preset [ ] [ ] buttons are used to select
radio presets (see page 48). When the onscreen setup menus are used, they work as arrow buttons and are used to select and set items. The Enter but­ton is also used with the onscreen setup menus.
8
Front & Rear Panels
—Continued
Return button
S
This button is used to return to the previously dis-
played onscreen setup menu.
T
Master Volume control (44)
This control is used to adjust the volume of the AV
receiver to MIN, 1 through 99, or MAX
U
Phones jack (45)
This 1/4-inch phone jack is for connecting a stan-
dard pair of stereo headphones for private listening.
Display
1 324 5
6
Tone, [–] & [+] buttons (52)
V
These buttons are used to adjust the bass and treble.
Input selector buttons (44)
W
These buttons are used to select from the following input sources: Multi CH, DVD, VIDEO 1, VIDEO 2, VIDEO 3, TAPE, TUNER, or CD.
The [Multi CH] button selects the DVD analog mul­tichannel input.
7
For detailed information, see the pages in parentheses.
1
MUTING indicator (45)
This indicator flashes while the AV receiver is
muted.
2
REC OUT indicator (54)
This indicator lights up when the REC OUT is
selected.
3
ZONE 2 indicator (66)
This indicator lights up when Zone 2 is selected.
4
Listening mode & format indicators
These indicators show the currently selected listen-
ing mode and the format of digital input signals.
5
Tuning indicators (47)
TUNED:
receiver is tuned into a radio station.
AUTO:
ing mode is selected, and disappears when the Man-
ual Tuning mode is selected.
MEMORY:
radio stations.
FM STEREO:
AV receiver is tuned to a stereo FM station.
6
SLEEP indicator (45)
This indicator lights up when the Sleep function has
been set.
This indicator lights up when the AV
This indicator lights up when the Auto Tun-
This indicator lights up when presetting
This indicator lights up when the
Message area
7
This area of the display shows various information about the currently selected source.
9
Front & Rear Panels
Rear Panel
—Continued
9
1BCD
COMPONENT VIDEO
Y
P
B
P
R
IN IN IN
L
R
CD
5 7
OUT
IN 1IN 2IN 3
VIDEO 3 VIDEO 2
OUT OUT
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
6
RS
232
OUT
IN
8
OPTICAL
VIDEO 1
OUT
IN IN IN
OUT
IN IN
J
IN1IN2
MONITOR
DVD
OUT
V
S
FRONT SURR CENTER
SUB WOOFER
DVD
OUT
For detailed information, see the pages in parentheses.
A
COMPONENT VIDEO IN 1, 2, 3 (27, 29, 31)
These component video inputs can be used to con­nect AV components with component video outputs, such as DVD players.
B
AM ANTENNA (23)
These push terminals are for connecting an AM antenna.
C
COMPONENT VIDEO OUT (26)
This component video output can be used to con­nect a TV or projector with a component video input.
FM ANTENNA (23)
D
This jack is for connecting an FM antenna.
E
RS232 (35)
This port is for connecting the AV receiver to home automation equipment and external controllers.
IR IN/OUT (67)
F
These jacks are for connecting the remote sensors included with multiroom kits (sold separately).
12V TRIGGER OUT A/B/C (61, 67)
G
These jacks can be connected to the 12-volt trigger inputs on other components. These trigger outputs can each be assigned to an input so that when that input is selected, a 12-volt trigger signal is output.
H
A-BUS
A-BUS is a simple, efficient, elegant audio distribu­tion system. The wiring installation time is signifi­cantly reduced as only a single CAT-5 wire is run to each location. A-BUS is easy to use, reliable, affordable, and most of all, far better sounding than conventional auto former based volume controls.
KN
4.5
DIGITAL
COAXIAL
IN 1IN
2
PRE OUT
SUB WOOFER
L
ZONE 2 OUT
REMOTE CONTROL
R
UTSRQPO
VW
ZONE 2 OUT:
ZONE 2 SPEAKERS
L
R
L
L
R
R
FRONT SPEAKERS
ML
SURROUND
SPEAKERS
L
R
SPEAKER
CENTER
X
Use CAT-5 (eight conductor twisted) cable to connect directly from the receiver’s A-BUS RI45 Hub to an A-BUS keypad.
War ning:
DO NOT connect A-BUS output to any computer or network connections (i.e. ethernet). It will cause damage to the computer or network components as 24-volt power runs on this same cable to power the amplifier stages of the amplifier module.
IR OUT:
Another feature of the A-BUS system is the ability to control source equipment in another room where the A-BUS module is installed. If you wish to control another source from the receiver at the A-BUS keypad by remote control, connect A-BUS or another brands’s IR emitter on the receiver’s 40 K terminal. Then place the emitter on the remote receiver on the front panel. Typically, the emitter will work when you connect with a 40 K connector. If it does not work, try a 56 K connector.
DC IN:
Connect A-Bus power supply. Do not use any other AC Adapter on this connector as it may cause severe damage to the receiver.
MONITOR OUT (26)
I
The S-Video or composite video jack should be connected to a video input on your TV or projector.
10
Front & Rear Panels
OPTICAL DIGITAL (26, 27, 29, 31, 32, 33)
J
The optical digital audio inputs can be used to con­nect CD and DVD players, and other components with an optical digital audio output.
The optical output can be used to connect a CD recorder or other digital recorder with an optical digital input.
K
COAXIAL DIGITAL (26, 27, 29, 31, 32, 33)
The coaxial digital audio inputs can be used to con­nect CD and DVD players, and other components with a coaxial digital audio output.
ZONE 2 SPEAKERS (63)
L
These terminal posts are for connecting speakers in Zone 2.
FRONT, CENTER, & SURROUND SPEAKERS
M
(22)
These terminal posts are for connecting your front, center, and surround speakers.
N
AC OUTLETS (35)
These switched AC outlets can be used to supply power to other AV components. The type of outlet depends on the country in which you purchased your AV receiver. Some models have a single outlet.
CD IN (32)
O
This analog audio input is for connecting a CD player’s analog audio output.
TAPE IN/OUT (32)
P
This analog audio input and output are for connect­ing a recorder with an analog audio input and output (cassette, Mini Disc, etc).
Q
VIDEO 3 IN (26, 30)
Here you can connect a video source (VCR, set-top box, etc). Input jacks include S-Video, composite video, and analog audio.
R
VIDEO 2 IN/OUT (28, 30)
Here you can connect a VCR. Input and output jacks include S-Video, composite video, and analog audio.
VIDEO 1 IN/OUT (28, 30)
S
Here you can connect a VCR. Input and output jacks include S-Video, composite video, and analog audio.
T
DVD IN (27, 28)
Here you can connect a DVD player. Input jacks include S-Video, composite video, and analog audio. You can connect a DVD player’s 2-channel analog audio output or 5.1-channel analog audio output.
ZONE 2 OUT (63)
U
This analog audio output can be connected to a line input on an integrated amplifier in Zone 2.
These jacks can can be configured as either line outs or pre outs on the onscreen setup menus.
—Continued
REMOTE CONTROL (34)
V
This (Remote Interactive) jack can be con­nected to an jack on another Integra AV compo­nent. The AV receiver’s remote controller can then be used to control that component. To use , you must make an analog audio connection (RCA) between the AV receiver and the other AV compo­nent, even if they are connected digitally.
PRE OUT (34)
W
The SUBWOOFER jack is for connecting a pow­ered subwoofer.
AC INLET (35)
X
The supplied power cord should be connected here.
11
Remote Controller
In addition to controlling the AV receiver, the remote controller has several operating modes for controlling your other AV components, including Integra compo­nents connected via . Modes are selected by using the remote controller’s Remote Mode buttons.
For detailed information, see the pages in parentheses. Some of the functions described in this manual may not
work as expected with other components.
Receiver Mode
Receiver mode is used to control the AV receiver. To select Receiver mode, press the [Receiver] Remote Mode button.
RC-587M
Remote indicator
A
B
3
4
5
6 7
8
9 J
On Standby
V1 V 2 V3
123
Multi CH
456
CD Tape
789
+
10 0
--/---
Input Selector
Macro
123
Remote Mode
Receiver
DVD
Tape
Dimmer
TV Input
e
M
p
o
T
TV
I
Input
+
TV CH
DVD
-
Tuner
TV VOL
Clear
Zone 2
CD
MD/CDR
SATTV VCR Cable
Sleep
M
u
n
e
n
u
+
CH
Disc
-
Prev CH
Display Muting
Enter
E
x
i
t
R
e
t
u
r
n
VOL
e
d
i
u
G
p
u
t
e
S
This indicator lights up when the remote con­troller is transmitting commands.
T
N
Receiver
O
P
Q R
12
K
L
M
Surround
Test Tone
Direct
CH SEL
Video OffOpen/ Close
RC
-
587M
AngleSubtitleAudio
DSP DSP
-
Level
L Night
RandomRec
Last Memory
StereoAll ST
MemorySearchA-BRepeat
+
Level
Cine Fltr
S
Remote Controller
—Continued
Standby button (35)
A
This button is used to set the AV receiver to Standby.
B
On button (35)
This button is used to turn on the AV receiver.
Input Selector buttons (44)
C
These buttons are used to select the input source.
D
Multi CH button (53)
This button is used to select the DVD analog multi­channel input.
E
Remote Mode buttons
These buttons are used to select the remote control­ler modes.
F
Dimmer button (45)
This button is used to adjust the display brightness.
Arrow [ ]/[ ]/[ ]/[ ] & Enter buttons (37)
G
These buttons are used to select items on the onscreen setup menus.
CH +/– button (48)
H
This button is used to select radio presets.
Return button
I
This button is used to return to the previously dis­played onscreen setup menu.
Display button (46, 48)
J
This button is used to display various information about the currently selected input source.
Listening mode buttons (49)
K
Surrond button
This button is used to select the Dolby Digital, Pro Logic II, DTS and other listening modes.
All ST button
This button is used to select the All Ch Stereo listen­ing mode.
Stereo button
This button is used to select the Stereo listening mode.
Direct button
This button is used to select the Direct listening mode.
[ DSP] & [DSP ] buttons
These buttons are used to select the Onkyo original DSP (digital signal processor) listening modes.
L
Test Tone, CH SEL, Level- & Level+ buttons (42)
These buttons are used to adjust the level of each speaker individually. The [Level–] & [Level+] but­tons are also used to adjust the volume in Zone 2.
L Night button (52)
M
This button is used to set the Late Night function.
Macro buttons (78)
N
These buttons are used with the Macro function.
O
Sleep button (45)
This button is used to set the Sleep function.
VOL button (44)
P
This button is used to adjust the volume of the AV receiver.
Setup button (37)
Q
This button is used to access the onscreen setup menus that appear on the connected TV.
Muting button (45)
R
This button is used to mute the AV receiver.
Cine Fltr button (52)
S
This button is used to set the CinemaFILTER func­tion.
Light button
T
This button is used to turn on or off the remote con­troller’s illuminated buttons.
13
Remote Controller
A
1
B
2
3
DVD CD
4
5
On Standby
V1 V 2 V3
123
456
CD Tape
789
+
10 0
--/---
Input Selector
123
Receiver
Tape
Dimmer
TV Input
—Continued
I
Multi CH
DVD
Tuner
Clear
Macro
Remote Mode
DVD
CD
M
u
n
e
e
n
M
p
o
T
u
TV
Input
+
TV CH
-
TV VOL
Zone 2
MD/CDR
SATTV VCR Cable
Sleep
+
3
4
5
6
7
6
7 8
9
J K L M N
O
CH
Disc
-
Prev CH
Display Muting
Surround
Test Tone
R
e
t
Direct
CH SEL
Video OffOpen/ Close
Enter
E
x
i
t
u
r
n
e
d
i
u
G
p
u
t
e
S
AngleSubtitleAudio
DSP DSP
-
Level
L Night
VOL
RandomRec
Last Memory
StereoAll ST
MemorySearchA-BRepeat
+
Level
Cine Fltr
P
-
RC
587M
Round numbers are for DVD mode. Square numbers are for CD mode.
Q 8
R
9
S
T U
0
A
V W X Y
Z
B
DVD Mode
DVD mode is used to control an Integra DVD player connected to the AV receiver via .
To set the remote controller to DVD mode, press the [DVD] Remote Mode button.
Standby button
A
This button is used to set the DVD player to Standby.
On button
B
This button is used to turn on the DVD player and to set it to Standby.
Number buttons
C
These buttons are used to enter title, chapter, and track numbers, and to enter times for locating spe­cific points in time.
Top Menu button
D
This button is used to select a DVD’s top menu.
Arrow [ ]/[ ]/[ ]/[ ] & Enter buttons
E
These buttons are used to navigate DVD menus and the DVD player’s onscreen setup menus.
Disc +/– button
F
This button selects discs on a DVD changer.
Return/Exit button
G
This button is used to exit the DVD player’s onscreen setup menu.
Display button
H
This button is used to display information about the current disc, title, chapter, or track on the DVD player’s display, including the elapsed time, remain­ing time, total time, and so on.
I
Playback buttons
From left to right: Previous, Play, Next, Fast Reverse, Pause, Stop, and Fast Forward.
J
Step & Slow [ ]/[ ] buttons
These buttons are used for frame-by-frame playback and slow-motion playback.
K
Audio button
This button is used to select foreign language soundtracks and audio formats (e.g., Dolby Digital or DTS).
L
Subtitle button
This button is used to select subtitles.
M
Repeat button
This button is used to set the repeat playback func­tions.
N
A-B button
This button is used to set the A–B repeat playback function.
O
Open/Close [ ] button
This button is used to open and close the disc tray.
14
Remote Controller
Video Off button
P
This button is used to turn off the internal video cir­cuitry, eliminating any possibility of interference.
Clear button
Q
This button is used to cancel functions and to clear entered numbers.
Menu button
R
This button is used to display a DVD’s menu.
VOL button
S
This button is used to adjust the volume of the AV receiver.
Setup/Guide button
T
This button is used to access the DVD player’s onscreen setup menus.
Muting button
U
This button is used to mute the AV receiver.
V
Random button
This button is used with the random playback func­tion.
W
Angle button
This button is used to select camera angles.
X
Last Memory button
This button is used with the last memory function, which allows you to resume DVD playback from where you left off.
Y
Search button
This button is used to search for titles, chapters, tracks, and specific points in time.
Z
Memory button
This button is used with the memory playback func­tion, which allows you to create a custom playlist of titles, chapters, or tracks.
—Continued
CD Mode
CD mode is used to control an Integra CD player con­nected to the AV receiver via .
To set the remote controller to CD mode, press the [CD] Remote Mode button.
On button
1
This button is used to set the CD player to On or Standby.
Number buttons
2
These buttons are used to enter track numbers and to enter times for locating specific points in time.
3
Disc button
This button is used to select discs on a CD changer.
Display button
4
This button is used to display information about the current disc or track on the CD player’s display, including the elapsed time, remaining time, total time, and so on.
5
Playback buttons
From left to right: Previous, Play, Next, Fast Reverse, Pause, Stop, and Fast Forward.
Repeat button
6
This button is used to set the repeat playback func­tions.
7
Open/Close [ ] button
This button is used to open and close the disc tray.
Clear button
8
This button is used to cancel functions and to clear entered numbers.
9
VOL button
This button is used to adjust the volume of the AV receiver.
0
Muting button
This button is used to mute the AV receiver.
A
Random button
This button is used with the random playback func­tion.
B
Memory button
This button is used with the memory playback func­tion, which allows you to create a custom playlist of tracks.
15
Remote Controller
1
2
Tape MD/CDR
On Standby
V1 V 2 V3
123
456
CD Tape
789
+
10 0
--/---
Input Selector
123
Receiver
Tape
Dimmer
TV Input
—Continued
I
DVD
Multi CH
Tuner
Clear
Macro
Remote Mode
DVD
CD
M
u
n
e
e
n
M
p
o
T
u
TV
Input
+
TV CH
-
TV VOL
Zone 2
MD/CDR
SATTV VCR Cable
Sleep
+
1 2
3 4
CH
Disc
-
Prev
3 4
CH
Display Muting
5
6 7
Surround
8
Test Tone
9
Round numbers are for MD/CDR mode. Square numbers are for TAPE mode.
R
e
t
Direct
CH SEL
Video OffOpen/ Close
RC
Enter
E
x
i
t
u
r
n
-
587M
e
d
i
u
G
p
u
t
e
S
AngleSubtitleAudio
DSP DSP
-
Level
L Night
VOL
RandomRec
Last Memory
StereoAll ST
MemorySearchA-BRepeat
+
Level
Cine Fltr
J
K
L
M N
O
P
5
6
7 8
MD/CDR Mode
MD/CDR mode is used to control an Integra MiniDisc recorder or CD recorder connected to the AV receiver via
.
To select MD/CDR mode, press the [MD/CDR] Remote Mode button.
By default, this button is set to control a MiniDisc recorder. To control a CD recorder, it must be set to CDR (see page 69).
A
On button
This button is used to set the MD recorder or CD recorder to On or Standby.
B
Number buttons
These buttons are used to enter track numbers and to enter times for locating specific points in time.
C
Display button
This button is used to display information about the current disc or track on the MD recorder or CDR recorder’s display, including the elapsed time, remaining time, total time, and so on.
D
Play [ ] button
This button is used to start playback.
Previous & Next [ ]/[ ] buttons
E
The Previous [ ] button is used to select the pre­vious track. During playback it selects the begin­ning of the current track. The Next [ ] button is used to select the next track.
F
Pause [ ] button
This button is used to pause playback.
Rec [ ] button
G
This button is used to start recording.
H
Repeat button
This button is used to set the repeat playback func­tions.
Open/Close [ ] button
I
This button is used to eject a MiniDisc or to open and close the CD recorder’s disc tray.
Clear button
J
This button is used to cancel functions and to clear entered numbers.
VOL button
K
This button is used to adjust the volume of the AV receiver.
Muting button
L
This button is used to mute the AV receiver.
M
FR & FF [ ]/[ ] buttons
The FR [ ] button is used to start fast reverse. The FF [ ] button is used to start fast forward.
16
Remote Controller
Stop [ ] button
N
This button is used to stop playback.
Random button
O
This button is used with the random playback func­tion.
Memory button
P
This button is used with the memory playback func­tion, which allows you to create a custom playlist of tracks.
—Continued
TAPE Mode
TAPE mode is used to control an Integra cassette recorder connected to the AV receiver via .
To set the remote controller to TAPE mode, press the [Tape] Remote Mode button.
For double cassette decks, only Deck B can be con­trolled.
Play [ ] button
1
This button is used to start playback.
Previous & Next [ ]/[ ] buttons
2
The Previous [ ] button is used to select the pre­vious track. During playback it selects the begin­ning of the current track. The Next [ ] button is used to select the next track.
The Previous and Next [ ]/[ ] buttons may not work properly with some cassette tapes depending on how they were recorded.
Reverse Play [ ] button
3
This button is used to start reverse playback.
4
Rec [ ] button
This button is used to start recording.
VOL button
5
This button is used to adjust the volume of the AV receiver.
6
Muting button
This button is used to mute the AV receiver.
Rewind & FF [ ]/[ ] buttons
7
The Rewind [ ] button is used to start rewind. The FF [ ] button is used to start fast forward.
8
Stop [ ] button
This button is used to stop playback.
17
Remote Controller
—Continued
Installing the Batteries
To open the battery compartment, press
1
the small hollow and slide off the cover.
Insert the three supplied batteries (AA/R6)
2
in accordance with the polarity diagram inside the battery compartment.
Put the cover onto the remote controller
3
and slide it shut.
Notes:
• The batteries should last for about six months, although this will vary with usage.
• If the remote controller doesn’t work reliably, try replacing the batteries.
• Don’t mix new and old batteries or different types of batteries.
• If you intend not to use the remote controller for a long time, remove the batteries to prevent damage from leakage or corrosion.
• Expired batteries should be removed as soon as possi­ble to prevent damage from leakage or corrosion.
Using the Remote Controller
To use the remote controller, point it at the AV receiver’s remote control sensor, as shown below.
Remote control sensor
AV receiver
Standby indicator
30˚
Notes:
• The remote controller may not work reliably if the AV receiver is subjected to bright light, such as direct sun­light or inverter-type fluorescent lights. Keep this in mind when installing.
• If another remote controller of the same type is used in the same room, or the AV receiver is installed close to equipment that uses infrared rays, the remote control­ler may not work reliably.
• Don’t put anything, such as a book, on the remote con­troller, because the buttons may be pressed inadvert­ently, thereby draining the batteries.
• The remote controller may not work reliably if the AV receiver is installed in a rack behind colored glass doors. Keep this in mind when installing.
• The remote controller will not work if there’s an obsta­cle between it and the AV receiver’s remote control sensor.
30˚
Approx. 16 ft.
(5 m)
18
About Home Theater
Enjoying Home Theater
Thanks to the AV receiver’s superb capabilities, you can enjoy surround sound with a real sense of movement in your own home—just like being in a movie theater or concert hall. With DVDs you can enjoy DTS and Dolby Digital. With analog and digital TV you can enjoy Dolby Pro Logic II or Onkyo’s own DSP surround listening modes.
Front left and right speakers
These output the overall sound. Their role in a home theater is to provide a solid anchor for the sound image. They should be positioned facing the listener at about ear level, and equidistant from the TV. Angle them inward so as to create a triangle, with the listener at the apex.
Center speaker
This speaker enhances the front left and right speakers, making sound movements distinct and providing a full sound image. In movies it’s used mainly for dialog.
Position it close to your TV (preferably on top) facing forward at about ear level, or at the same height as the front left and right speakers.
Subwoofer
The subwoofer handles the bass sounds of the LFE (Low-Frequency Effects) channel. The vol­ume and quality of the bass output from your subwoofer will depend on its position, the shape of your listening room, and your listening posi­tion. In general, a good bass sound can be obtained by installing the subwoofer in a front corner, or at one-third the width of the wall, as shown.
Tip: To find the best position for your subwoofer, while playing a movie or some music with good bass, experiment by placing your subwoofer at various positions within the room, and choose the one that provides the most satisfying results.
Surround left and right speakers
These speakers are used for precise sound positioning and to add realistic ambience.
Position them at the sides of the listener, or slightly behind, about 2–3 feet (60–100 cm) above ear level. Ideally they should be equidistant from the listener.
19
Connecting the AV receiver
About AV Connections
• Before making any AV connections, read the manuals supplied with your other AV components.
• Don’t connect the power cord until you’ve completed and double-checked all AV connections.
Optical Digital Jacks
The AV receiver’s optical digital jacks have shutter-type covers that open when an optical plug is inserted and close when it’s removed. Push plugs in all the way.
Caution:
plug straight when inserting and removing.
AV Cables & Jacks
Video
Component video cable
S-Video cable
Composite video cable
To prevent shutter damage, hold the optical
Cable Jack Description
P
R
P
B
Y
R
P
P
B
Y
Y
P
B
PR
AV Connection Color Coding
RCA-type AV connections are usually color coded: red, white, and yellow. Use red plugs to connect right­channel audio inputs and outputs (typically labeled “R”). Use white plugs to connect left-channel audio inputs and outputs (typically labeled “L”). And use yellow plugs to connect composite video inputs and outputs.
Right (red)
Left (white)
(Yellow)
• Push plugs in all the way to make good connections (loose connec­tions can cause noise or malfunc­tions).
•To prevent interference, keep audio and video cables away from power cords and speaker cables.
Component video separates the luminance (Y) and color difference signals (PR, PB), providing the best picture quality. (Some TV manufacturers label their component video sockets slightly differently.)
S-Video separates the luminance and color signals
S
and provides better picture quality than composite video.
Composite video is commonly used on TVs, VCRs,
V
and other video equipment. Use only dedicated composite video cables.
Analog audio
Composite video
Right (red)
Left (white)
(Yellow)
Right!
Wrong!
20
Audio
Optical digital audio cable
Coaxial digital audio cable
Analog audio cable (RCA)
Multichannel analog audio cable (RCA)
Cable Jack Description
OPTICAL
Offers the best sound quality and allows you to enjoy surround sound (e.g., Dolby Digital, DTS). The audio quality is the same as for coaxial.
COAXIAL
Offers the best sound quality and allows you to enjoy surround sound (e.g., Dolby Digital, DTS). The audio quality is the same as for optical.
L
R
This cable carries analog audio. It’s the most common connection format for analog audio, and can be found on virtually all AV components.
This cable carries multichannel analog audio and it’s typically used to connect DVD players with a
5.1-channel analog audio output. Several standard analog audio cables can be used instead of a multi­channel cable.
Connecting the AV receiver
—Continued
Connecting Your Speakers
Speaker Configuration
For the best surround-sound experience, you should con­nect seven speakers and a powered subwoofer.
The following table indicates the channels you should use depending on the number of speakers that you have.
Number of speakers: 2345
Front left
Front right
Center
Surround left
Surround right
No matter how many speakers you use, a powered sub­woofer is recommended for a really powerful and solid bass.
Using Dipole Speakers
You can use dipole speakers for the surround left and right speakers. Dipole speakers output the same sound in two directions.
Dipole speakers typically have an arrow printed on them to indicate how they should be positioned. The surround left and right their arrows point toward the TV/screen, while the sur­round left and right dipolar speakers should be positioned so that their arrows point toward each other, as shown.
dipole
speakers should be positioned so that
Dipole speakers
TV/screen TV/screen
2
3
✓✓✓✓
✓✓✓✓
✓✓
Normal speakers
1
4
2
✓✓
✓✓
3
1
4
Connecting a Powered Subwoofer
Using a suitable cable, connect the AV receiver’s SUB­WOOFER PRE OUT to an input on your powered sub­woofer, as shown. If your subwoofer is unpowered and you’re using an external amplifier, connect the SUB­WOOFER PRE OUT to an input on the amp.
DIGITAL
OUT
IN1IN2
Powered
subwoofer
LINE INPUT
LINE INPUT
Y
P
B
P
R
COMPONENT VIDEO
IN IN IN
L
R
CD
OUT
IN 1IN 2IN 3
VIDEO 3 VIDEO 2
IN
OUT OUT
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
RS
232
OUT
VIDEO 1
OUT
IN IN IN
OUT
IN IN
OPTICAL
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
COAXIAL
IN 1IN
2
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
REMOTE CONTROL
SUB
R
WOOFER
Attaching the Speaker Labels
The AV receiver’s positive (+) speaker terminals are color-coded for ease of identification. (The negative (–) speaker terminals are all black.)
Speaker terminal Color
Front left, Zone 2 left White
Front right, Zone 2 right Red
Center Green
Surround left Blue
Surround right Gray
The supplied speaker labels are also color-coded and you should attach them to the positive (+) side of each speaker cable in accordance with the above table. All you need to do then is to match the color of each label to the corresponding speaker terminal.
5
1. Subwoofer
2. Front left speaker
3. Center speaker
4. Front right speaker
5. Surround left speaker
6. Surround right speaker
5
6
6
21
Connecting the AV receiver
—Continued
Speaker Connection Precautions
Read the following before connecting your speakers:
• Only connect speakers with an impedance of 6 ohms or higher. If you use speakers with a lower impedance, and use the amplifier at high volume levels for a long period of time, the built-in protection circuit may be activated.
• Disconnect the power cord from the wall outlet before making any connections.
• Read the instructions supplied with your speakers.
•Pay close attention to speaker wiring polarity. In other words, connect positive (+) terminals to only positive (+) terminals, and negative (–) terminals to only nega­tive (–) terminals. If you get them the wrong way around, the sound will be out of phase and will sound unnatural.
• Unnecessarily long, or very thin speaker cables may affect the sound quality and should be avoided.
• Be careful not to short the positive and negative wires. Doing so may damage the AV receiver.
• Don’t connect more than one cable to each speaker termi­nal. Doing so may damage the AV receiver.
• Don’t connect one speaker to several terminals.
Connecting the Speaker Cables
Strip about 5/8" (15 mm)
1
of insulation from the ends of the speaker cables, and twist the bare wires tightly, as shown.
Unscrew the terminal.
2
Fully insert the bare
3
wires.
Screw the terminal tight.
4
The following illustration shows which speaker should be connected to each pair of terminals.
5/8" (15 mm)
Surround left speaker
Front left speaker
ZONE 2 SPEAKERS
L
R
L
L
R
R
FRONT SPEAKERS
Surround right speaker
SPEAKERS
SURROUND
SPEAKER
CENTER
Front right speaker
L
R
Center speaker
22
Connecting the AV receiver
—Continued
Connecting Antenna
This section explains how to connect the supplied indoor FM antenna and AM loop antenna, and how to connect commercially available outdoor FM and AM antennas.
The AV receiver won’t pick up any radio signals without any antenna connected, so you must connect the antenna to use the tuner.
AM antenna push terminals FM antenna connector
ZONE 2 SPEAKERS
SPEAKERS
SURROUND
FRONT SPEAKERS
L
R
CENTER
SPEAKER
4.5
L
R
L
L
R
R
REMOTE CONTROL
Y
P
P
B
R
COMPONENT VIDEO
IN 1IN 2IN 3
OUT OUT
IN IN IN
L
R
CD
OUT
VIDEO 3 VIDEO 2
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
232
VIDEO 1
OUT
OUT
IN
IN IN IN
OUT
IN IN
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
IN 1IN
2
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
SUB
R
WOOFER
DIGITAL
OUT
IN1IN2
COAXIAL
OPTICAL
RS
Connecting the Indoor FM Antenna
The supplied indoor FM antenna is for indoor use only.
Attach the FM antenna, as shown.
1
Insert the plug fully into the jack.
Connecting the AM Loop Antenna
The supplied indoor AM loop antenna is for indoor use only.
Assemble the AM loop antenna, inserting
1
the tabs into the base, as shown.
Connect both wires of the AM loop
2
antenna to the AM push terminals, as shown.
(The antenna’s wires are not polarity sensitive, so they can be connected either way around).
Make sure that the wires are attached securely and that the push terminals are gripping the bare wires, not the insulation.
Push Insert wire Release
Once your AV receiver is ready for use, you’ll need to tune into an FM radio station and adjust the position of the FM antenna to achieve the best possible reception.
Use thumbtacks or something similar to
2
fix the FM antenna into position.
Thumbtacks, etc.
Caution:
Be careful that you don’t injure yourself
when using thumbtacks.
If you cannot achieve good reception with the supplied indoor FM antenna, try a commercially available out­door FM antenna instead (see page 24).
Once your AV receiver is ready for use, you’ll need to tune into an AM radio station and adjust the position of the AM antenna to achieve the best possible reception.
Keep the antenna as far away as possible from your AV receiver, TV, speaker cables, and power cords.
If you cannot achieve good reception with the supplied indoor AM loop antenna, try using it with a commer­cially available outdoor AM antenna (see page 24).
23
Connecting the AV receiver
—Continued
Connecting an Outdoor FM Antenna
If you cannot achieve good reception with the supplied indoor FM antenna, try a commercially available out­door FM antenna instead.
Notes:
• Outdoor FM antennas work best outside, but usable results can sometimes be obtained when installed in an attic or loft.
•For best results, install the outdoor FM antenna well away from tall buildings, preferably with a clear line of sight to your local FM transmitter.
• Outdoor antenna should be located away from possi­ble noise sources, such as neon signs, busy roads, etc.
•For safety reasons, outdoor antenna should be situated well away from power lines and other high-voltage equipment.
• Outdoor antenna must be grounded in accordance with local regulations to prevent electrical shock haz­ards.
Using a TV/FM Antenna Splitter
It’s best not to use the same antenna for both FM and TV reception, as this can cause interference problems. If cir­cumstances demand it, use a TV/FM antenna splitter, as shown.
Connecting an Outdoor AM Antenna
If good reception cannot be achieved using the supplied AM loop antenna, an outdoor AM antenna can be used in addition to the loop antenna, as shown.
Outdoor antenna
Insulated antenna cable
AM loop antenna
Outdoor AM antennas work best when installed outside horizontally, but good results can sometimes be obtained indoors by mounting horizontally above a window. Note that the AM loop antenna should be left connected.
Outdoor antenna must be grounded in accordance with local regulations to prevent electrical shock hazards.
24
TV/FM antenna splitter
To AV receiver To TV (or VCR)
Connecting the AV receiver
—Continued
Connecting Both Audio & Video
By connecting both the audio and video outputs of your DVD player and other AV components to the AV receiver, you can select both the audio and video simultaneously simply by selecting the appropriate input source on the AV receiver.
: Signal Flow
Video
Audio
Video
Audio
TV, projector, etc.
DVD player, etc.
Speakers (see page 22 for con-
nection information)
Which Connections Should I Use?
The AV receiver supports several connection formats for compatibility with a wide range of AV equipment. The format you choose will depend on the formats supported by your other components. Use the following sections as a guide.
For video components, you must make two connections—one for audio, one for video.
Video Connection Formats
Video equipment can be connected to the AV receiver by using any one of the following video connection formats: composite video, S-Video, or component video, the latter offering the best picture quality.
A video signal connected to a V or S IN jack will be con­verted—composite video to S-Video or S-Video to com­posite video—but only for the MONITOR OUT jacks, not the VIDEO 1 and VIDEO 2 OUT V and S jacks.
DVD player,
etc.
Output
IN
AV Receiver
MONITOR OUT
Input
TV, pro-
jector,
etc.
Composite
Composite
Composite
Composite
S-Video
S-Video
S-Video
S-Video
Component
Component
Component
Component
Audio Connection Formats
Audio equipment can be connected to the AV receiver by using any of the following audio connection formats: analog, optical, coaxial, or multichannel.
When choosing a connection format, bear in mind that the AV receiver doesn’t convert between them. For example, audio signals connected to an OPTICAL or COAXIAL input are not output by the analog TAPE OUT.
DVD player,
etc.
Output
IN
AV Receiver
OUT
Input
MD recorder,
etc.
Optical
Optical
Optical
Optical
Coaxial
Coaxial
Analog
Analog
Analog
Analog
Multi­channel
Multi­channel
Only front left and right
25
Connecting the AV receiver
—Continued
Connecting Your TV or Projector
Monitor Out
Using Composite Video
Use a composite video cable to connect the AV receiver’s V MONITOR OUT jack to a composite video input on your TV, as shown.
DIGITAL
OUT
Y
P
B
P
R
COMPONENT VIDEO
IN 1IN 2IN 3
OUT OUT
IN IN IN
L
R
CD
OUT
VIDEO 3 VIDEO 2
IN
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
232
OUT
VIDEO 1
OUT
IN IN IN
OUT
IN IN
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
IN 1IN
2
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
REMOTE CONTROL
SUB
R
WOOFER
IN1IN2
COAXIAL
OPTICAL
RS
TV, projector, etc.
Using S-Video
Use an S-Video cable to connect the AV receiver’s S MONITOR OUT jack to an S-Video input on your TV, as shown.
DIGITAL
OUT
IN1IN2
COAXIAL
OPTICAL
RS
Y
P
B
P
R
COMPONENT VIDEO
IN 1IN 2IN 3
OUT OUT
IN IN IN
L
R
CD
OUT
VIDEO 3 VIDEO 2
IN
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
232
OUT
VIDEO 1
OUT
IN IN IN
OUT
IN IN
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
IN 1IN
2
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
REMOTE CONTROL
SUB
R
WOOFER
MONITOR
OUT
VIDEO IN
MONITOR
OUT
V
S
Audio Connections
These connections will allow you to listen to audio from your TV via the AV receiver.
If your TV doesn’t have an audio output, connect the AV receiver to your VCR and use its tuner (see page 28).
Using Coaxial or Optical Connections
If you connect to a digital audio input, you’ll need to assign it (see page 37).
• Use an optical digital audio cable to connect one of the AV receiver’s OPTICAL DIGITAL IN jacks to an optical output on your TV, as shown.
OR
• Use a coaxial digital audio cable to connect one of the AV receiver’s COAXIAL DIGITAL IN jacks to a coaxial output on your TV, as shown.
DIGITAL
OUT
IN1IN2
COMPONENT VIDEO
IN 1IN 2IN 3
Y
P
B
P
R
OUT OUT
IN IN IN
L
R
CD
DIGITAL OUT
OPTICAL
OUT
VIDEO 3 VIDEO 2
OPTICAL
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
OPTICAL
RS
232
OUT
IN
OUT
IN IN IN
IN
OUT
IN IN
MONITOR
DVD
VIDEO 1
OUT
FRONT SURR CENTER
DVD
Connect one or the other
TV, projector, etc.
COAXIAL
2
V
S
L
ZONE 2 OUT
SUB
R
WOOFER
COAXIAL
IN 1IN
PRE OUT
SUB WOOFER
IN
REMOTE CONTROL
DIGITAL OUT
COAXIAL
TV, projector, etc.
Using Component Video
Use a component video cable to connect the AV receiver’s COMPONENT VIDEO OUT jacks to a com­ponent video input on your TV, as shown.
COMPONENT VIDEO
DIGITAL
OUT
IN1IN2
COAXIAL
Y
P
B
P
R
COMPONENT VIDEO
IN 1IN 2IN 3
OUT OUT
IN IN IN
L
R
CD
OUT
VIDEO 3 VIDEO 2
IN
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
RS
232
OUT
VIDEO 1
OUT
IN IN IN
OUT
IN IN
OPTICAL
DVD
FRONT SURR CENTER
Y
IN 1IN
2
MONITOR
PRE OUT
OUT
V
SUB
P
B
WOOFER
S
PR
L
ZONE 2 OUT
REMOTE CONTROL
SUB
R
WOOFER
DVD
TV, projector, etc.
26
S VIDEO IN
YPB PR
COMPONENT VIDEO IN
Using Analog Connections
If your TV doesn’t have a digital audio output, or you want to record from it, you’ll need to make the following analog audio connection.
Use an analog audio cable to connect the AV receiver’s VIDEO 3 IN L/R jacks to an analog audio output on your TV, as shown.
DIGITAL
OUT
IN1IN2
COAXIAL
OPTICAL
RS
Y
P
B
P
R
COMPONENT VIDEO
IN 1IN 2IN 3
OUT OUT
IN IN IN
L
R
CD
OUT
TAPE
232
VIDEO 3 VIDEO 2
VIDEO 1
OUT
OUT
IN
IN IN IN
OUT
IN IN
VIDEO 3 VIDEO 2 VIDEO 1
TV, projector, etc.
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
IN 1IN
2
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
REMOTE CONTROL
SUB
R
WOOFER
IN
VIDEO 3
AUDIO
OUTPUT
L
R
Connecting the AV receiver
—Continued
Connecting a DVD Player
Video Connections
You only need to use one of the following connection methods.
Using Composite Video
Use a composite video cable to connect the AV receiver’s V DVD IN jack to the composite video output on your DVD player, as shown.
DVD
IN
DIGITAL
OUT
IN1IN2
COAXIAL
OPTICAL
RS
232
COMPONENT VIDEO
OUT
IN 1IN 2IN 3
Y
VIDEO 3 VIDEO 2
VIDEO 1
OUT
OUT
IN
OUT OUT
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
IN IN IN
OUT
IN IN
P
B
P
R
IN IN IN
L
R
CD
DVD player
Using S-Video
Use an S-Video cable to connect the AV receiver’s S DVD IN jack to the S-Video output on your DVD player, as shown.
Y
P
B
P
R
OUT OUT
IN IN IN
L
R
CD
VIDEO 3 VIDEO 2
IN
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
OUT
VIDEO 1
OUT
IN IN IN
OUT
IN IN
DVD
FRONT SURR CENTER
OPTICAL
RS
232
COMPONENT VIDEO
OUT
IN 1IN 2IN 3
DVD player
Using Component Video
Use a component video cable to connect the AV receiver’s COMPONENT VIDEO IN1 jacks to the com­ponent video output on your DVD player, as shown.
•Your TV must also be connected via component video.
IN1IN2
OPTICAL
RS
232
COMPONENT VIDEO
OUT
IN 1IN 2IN 3
Y
P
B
P
R
OUT OUT
IN IN IN
L
R
CD
TAPE
VIDEO 3 VIDEO 2
OUT
IN
VIDEO 3 VIDEO 2 VIDEO 1
VIDEO 1
OUT
IN IN IN
OUT
IN IN
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
V
S
MONITOR
DVD
FRONT SURR CENTER
IN1IN2
MONITOR
OUT
DVD
OUT
SUB WOOFER
IN 1IN
2
PRE OUT
OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
REMOTE CONTROL
SUB
R
WOOFER
DVD
VIDEO OUT
DVD
DIGITAL
OUT
COAXIAL
IN 1IN
2
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
REMOTE CONTROL
SUB
R
WOOFER
IN
S VIDEO OUT
COMPONENT VIDEO
IN1
DIGITAL
COAXIAL
IN 1IN
2
PRE OUT
SUB WOOFER
L
ZONE 2 OUT
REMOTE CONTROL
R
Y
B
P
PR
Audio Connections
Using Coaxial or Optical Connections
• Use an optical digital audio cable to connect one of the AV receiver’s OPTICAL DIGITAL IN jacks to the optical output on your DVD player, as shown.
OR
• Use a coaxial digital audio cable to connect one of the AV receiver’s COAXIAL DIGITAL IN jacks to the coaxial output on your DVD player, as shown.
DIGITAL
OUT
IN1IN2
COAXIAL
OPTICAL
RS
OPTICAL
232
COMPONENT VIDEO
OUT
IN 1IN 2IN 3
Y
VIDEO 3 VIDEO 2
VIDEO 1
OUT
OUT
IN
OUT OUT
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
IN IN IN
OUT
IN IN
P
B
P
R
IN IN IN
L
IN1
R
CD
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
IN 1IN
2
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
SUB
R
WOOFER
Connect one or the other
DIGITAL OUT
OPTICAL
DIGITAL OUT
COAXIAL
DVD player
Initially, the OPTICAL IN1 jack is assigned to the DVD input source. If you connect your DVD player to a dif­ferent digital input, you’ll need to reassign the DVD input source (see page 37).
Using Analog Connections
Even if your DVD player is connected digitally (optical or coaxial), to use , or to record audio from your DVD player, you’ll need to make an analog connection as well.
Use an analog audio cable to connect the AV receiver’s DVD IN L/R jacks to the analog audio output on your DVD player, as shown.
If your DVD player has stereo (L/R) and multichannel outputs, be sure to use the left and right outputs.
FRONT
L
DIGITAL
OUT
IN1IN2
COAXIAL
OPTICAL
RS
Y
P
B
P
R
COMPONENT VIDEO
IN IN IN
L
R
CD
OUT
IN 1IN 2IN 3
VIDEO 3 VIDEO 2
IN
OUT OUT
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
232
OUT
VIDEO 1
OUT
IN IN IN
OUT
IN IN
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
IN 1IN
2
R
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
SUB
R
WOOFER
DVD
REMOTE CONTROL
DIGITAL
COAXIAL
IN
REMOTE CONTROL
DVD player
YPB PR
COMPONENT VIDEO OUT
DVD player
AUDIO
OUTPUT
LR
27
Connecting the AV receiver
Using a Multichannel Connection
—Continued
If your DVD player supports multichannel audio formats such as DVD-Audio, and it has a 5.1-channel analog audio output, you can enjoy DVD-Audio playback.
Use a multichannel analog audio cable to connect the AV receiver’s DVD IN FRONT L/R, CENTER, SURR L/R, and SUBWOOFER jacks to the 5.1-channel analog audio output on your DVD player, as shown. Alterna­tively, use several analog audio cables.
DIGITAL
OUT
IN1IN2
COAXIAL
OPTICAL
RS
COMPONENT VIDEO
OUT
IN 1IN 2IN 3
Y
P
B
P
R
OUT OUT
IN IN IN
L
R
CD
TAPE
DVD player
232
VIDEO 3 VIDEO 2
OUT
OUT
IN
IN IN IN
OUT
IN IN
VIDEO 3 VIDEO 2 VIDEO 1
VIDEO 1
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
IN 1IN
2
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
REMOTE CONTROL
SUB
R
WOOFER
Connecting a VCR for Playback
This section shows how to connect a VCR for playback so that you can watch videos via the AV receiver.
Video Connections
• Use an S-Video cable to connect the AV receiver’s S VIDEO 1 IN jack to a S-Video output on your VCR, as shown.
OR
• Use a composite video cable to connect the AV receiver’s V VIDEO 1 IN jack to a composite video output on your VCR, as shown.
An S-Video connection provides better picture quality than a composite video connection.
Audio Connections
• Use an analog audio cable to connect the AV receiver’s VIDEO 1 IN L/R jacks to an analog audio output on your VCR, as shown.
VIDEO 1
Y
P
B
P
R
L
IN
COMPONENT VIDEO
OUT OUT
IN IN IN
L
IN
R
CD
OUT
IN 1IN 2IN 3
TAPE
RS
232
VIDEO 3 VIDEO 2
OUT
OUT
IN
IN IN IN
OUT
IN IN
VIDEO 3 VIDEO 2 VIDEO 1
VIDEO 1
OPTICAL
IN1IN2
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
DIGITAL
OUT
COAXIAL
IN 1IN
2
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
REMOTE CONTROL
SUB
R
WOOFER
VIDEO OUT
S VIDEO OUT
VCR
R
Connect one or the other
AUDIO
OUTPUT
LR
28
Connecting the AV receiver
—Continued
Connecting a D-VHS VCR for Playback
Video Connections
If you connect to a component video input, you must assign it (see page 38).
Use a component video cable to connect the AV receiver’s COMPONENT VIDEO IN2 or 3 jacks to a component video output on your D-VHS VCR, as shown.
Your TV must also be connected via component video.
COMPONENT VIDEO
IN
COMPONENT VIDEO OUT
Y
RS
232
COMPONENT VIDEO
OUT
IN 1IN 2IN 3
Y
VIDEO 3 VIDEO 2
B
P
PR
P
B
P
R
OUT OUT
IN IN IN
L
R
CD
TAPE
OUT
IN
IN IN IN
IN IN
VIDEO 3 VIDEO 2 VIDEO 1
VIDEO 1
OUT
OUT
Y
B
P
PR
D-VHS VCR
OPTICAL
IN1IN2
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
DIGITAL
OUT
COAXIAL
IN 1IN
2
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
REMOTE CONTROL
SUB
R
WOOFER
Audio Connections
If you connect to a digital audio input, you'll need to assign it (see page 37).
• Use an optical digital audio cable to connect one of the AV receiver’s OPTICAL DIGITAL IN jacks to an optical output on your D-VHS VCR, as shown.
OR
• Use a coaxial digital audio cable to connect one of the AV receiver’s COAXIAL DIGITAL IN jacks to a coaxial output on your D-VHS VCR, as shown.
DIGITAL
OUT
IN1IN2
COAXIAL
OPTICAL
RS
OPTICAL
COMPONENT VIDEO
OUT
IN 1IN 2IN 3
Y
VIDEO 3 VIDEO 2
P
B
P
R
OUT OUT
IN IN IN
IN
L
R
CD
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
Connect one or the other
DIGITAL OUT
OPTICAL
232
VIDEO 1
OUT
OUT
IN
IN IN IN
OUT
IN IN
DIGITAL OUT
MONITOR
DVD
OUT
V
S
FRONT SURR CENTER
DVD
COAXIAL
IN 1IN
2
PRE OUT
SUB WOOFER
DIGIT
AL
COAXIAL
L
ZONE 2 OUT
IN
REMOTE CONTROL
SUB
R
WOOFER
D-VHS VCR
29
Connecting the AV receiver
M N
—Continued
Connecting a VCR for Recording
This section explains how to connect a VCR for recording from a TV or another VCR.
Video Connections
• Use an S-Video cable to connect the AV receiver’s S VIDEO 1 OUT jack to an S-Video input on the recording VCR. Use another S-Video cable to connect the AV receiver’s S VIDEO 3 IN jack to an S-Video output on your TV or playback VCR, as shown.
OR
• Use a composite video cable to connect the AV receiver’s V VIDEO 1 OUT jack to a composite video input on the recording VCR. Use another composite video cable to connect the AV receiver’s V VIDEO 3 IN jack to a composite video output on your TV or playback VCR, as shown.
Audio Connections
• Use an analog audio cable to connect the AV receiver’s VIDEO 1 OUT L/R jacks to an audio input on the recording VCR.
• Use an analog audio cable to connect the AV receiver’s VIDEO 3 IN L/R jacks to an audio output on your TV or playback VCR.
Playback from the Recording VCR
To play back a video in the recording VCR via the AV receiver:
• Use an S-Video cable to connect the AV receiver’s S VIDEO 1 IN jack to an S-Video output on the record­ing VCR.
OR
• Use a composite video cable to connect the AV receiver’s V VIDEO 1 IN jack to a composite video output on the recording VCR. And use an analog audio cable to connect the AV receiver’s VIDEO 1 IN L/R jacks to an audio output on the recording VCR.
Notes:
• The AV receiver must be turned on for recording. Recording is not possible while it’s in Standby mode.
• If you want to record directly from your TV or play­back VCR to the recording VCR without going through the AV receiver, connect the TV/VCR’s audio and video outputs directly to the recording VCR’s audio and video inputs. See the manuals supplied with your TV and VCR for details.
•Video signals connected to composite video inputs can only be recorded via composite video outputs. If your TV/VCR is connected to a composite video input, the recording VCR must be connected to a com­posite video output. Similarly, video signals con­nected to S-Video inputs can only be recorded via S-Video outputs. If your TV/VCR is connected to an S-Video input, the recording VCR must be connected to an S-Video output.
VIDEO
OUT
AUDIO INPUT
LR
S VIDEO IN
L
R
Connect one or the other
S VIDEO
OUT
TV
VCR (recording)
VIDEO IN
VIDEO OUT
Connect one or the other
VIDEO 1
OUT
OUT
VIDEO 3
IN
IN
AUDIO
OUTPUT
Y
P
B
P
R
R
LR
COMPONENT VIDEO
L
VCR, etc.or
IN
IN
IN 1IN 2IN 3
OUT OUT
IN IN IN
CD
TAPE
S VIDEO OUT
RS
232
OUT
VIDEO 3 VIDEO 2
OUT
IN
IN IN IN
IN IN
VIDEO 3 VIDEO 2 VIDEO 1
:
For recording For playback
:
LR
AUDIO
OUTPUT
DIGITAL
OUT
IN1IN2
COAXIAL
OPTICAL
VIDEO 1
OUT
OUT
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
IN 1IN
2
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
RE CO
SUB
R
WOOFER
30
Connecting the AV receiver
—Continued
Connecting Other Video Sources— Satellite, Cable, Set-top box, LD Player, etc.
Video Connections
You only need to use one of the following connection methods.
Using Composite Video
Use a composite video cable to connect the AV receiver’s V VIDEO 3 IN jack to a composite video output on your video source, as shown.
Using Component Video
If you connect to a component video input, you must assign it (see page 38).
Use a component video cable to connect the AV receiver’s COMPONENT VIDEO IN 2 or IN 3 jack to a component video output on your video source, as shown.
COMPONENT VIDEO
IN
Y
Y
P
B
B
P
P
R
PR
COMPONENT VIDEO
IN IN IN
L
R
CD
OUT
IN 1IN 2IN 3
VIDEO 3 VIDEO 2
IN
OUT OUT
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
RS
232
OUT
VIDEO 1
OUT
IN IN IN
OUT
IN IN
OPTICAL
IN1IN2
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
DIGITAL
OUT
COAXIAL
IN 1IN
2
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
REMOTE CONTROL
SUB
R
WOOFER
DIGITAL
OUT
IN1IN2
COAXIAL
OPTICAL
RS
Y
P
B
P
R
COMPONENT VIDEO
IN 1IN 2IN 3
OUT OUT
IN IN IN
L
R
CD
OUT
VIDEO 3 VIDEO 2
IN
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
232
OUT
VIDEO 1
OUT
IN IN IN
OUT
IN IN
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
IN 1IN
2
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
REMOTE CONTROL
SUB
R
WOOFER
VIDEO 3
IN
VIDEO OUT
Satellite, cable, set-top box, LD player, etc.
Using S-Video
Use an S-Video cable to connect the AV receiver’s S VIDEO 3 IN jack to an S-Video output on your video source, as shown.
VIDEO 3
IN
Y
P
B
P
R
COMPONENT VIDEO
IN 1IN 2IN 3
OUT OUT
IN IN IN
L
R
CD
OUT
VIDEO 3 VIDEO 2
IN
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
RS
232
OUT
OPTICAL
VIDEO 1
OUT
IN IN IN
OUT
IN IN
IN1IN2
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
DIGITAL
OUT
COAXIAL
IN 1IN
2
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
REMOTE CONTROL
SUB
R
WOOFER
COMPONENT VIDEO OUT
Y
B
P
PR
Satellite, cable, set-top box, LD player, etc.
Audio Connections
Using Optical or Coaxial Connections
If you connect to a digital audio input, you’ll need to assign it (see page 37).
• Use an optical digital audio cable to connect one of the AV receiver’s OPTICAL DIGITAL IN jacks to an optical output on your video source, as shown.
OR
• Use a coaxial digital audio cable to connect one of the AV receiver’s COAXIAL DIGITAL IN jacks to a coaxial output on your video source, as shown.
DIGITAL
IN 1IN
COAXIAL
IN
REMOTE CONTROL
OPTICAL
232
COMPONENT VIDEO
OUT
IN 1IN 2IN 3
Y
VIDEO 3 VIDEO 2
VIDEO 1
OUT
OUT
IN
OUT OUT
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
IN IN IN
OUT
IN IN
P
B
P
R
IN
IN IN IN
L
R
CD
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
2
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
SUB
R
WOOFER
DIGITAL
OUT
IN1IN2
COAXIAL
OPTICAL
RS
Satellite, cable, set-top box, LD player, etc.
S VIDEO OUT
Connect one or the other
DIGITAL OUT
OPTICAL
DIGITAL OUT
COAXIAL
Satellite, cable, set-top box, LD player, etc.
Notes:
•To connect the AV receiver to an LD player’s AC-3RF output, you need a commercially available demodula­tor.
31
Connecting the AV receiver
Using Analog Connections
—Continued
If your video source doesn’t have a digital audio output, or you want to record from it, you’ll need to make the following analog audio connection.
Use an analog audio cable to connect the AV receiver’s VIDEO 3 IN L/R jacks to the analog audio output on your video source, as shown.
IN
L
DIGITAL
OUT
IN1IN2
COAXIAL
OPTICAL
RS
232
COMPONENT VIDEO
OUT
IN 1IN 2IN 3
Y
VIDEO 3 VIDEO 2
VIDEO 1
OUT
OUT
IN
OUT OUT
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
IN IN IN
OUT
IN IN
P
B
P
R
IN IN IN
L
R
CD
Satellite, cable, set-top box, LD player, etc.
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
IN 1IN
2
PRE OUT
R
V
SUB WOOFER
S
VIDEO 3
L
ZONE 2 OUT
REMOTE CONTROL
SUB
R
WOOFER
LR
AUDIO
OUTPUT
Using Analog Connections
Even if your CD player is connected digitally (coaxial or optical), to use , or to record audio from your CD player, you’ll need to make an analog audio connection as well.
Use an analog audio cable to connect the AV receiver’s CD IN L/R jacks to the analog audio output on your CD player, as shown.
COMPONENT VIDEO
OUT
IN 1IN 2IN 3
Y
VIDEO 3 VIDEO 2
P
B
P
R
OUT OUT
IN IN IN
L
R
CD
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
CD player
232
VIDEO 1
OUT
OUT
IN
IN IN IN
OUT
IN IN
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
IN 1IN
2
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
REMOTE CONTROL
SUB
R
WOOFER
IN1IN2
COAXIAL
OPTICAL
RS
L
R
AUDIO
OUTPUT
IN
CD
DIGITAL
OUT
L
R
Connecting a Cassette Recorder
Connecting a CD Player
Using Optical or Coaxial Connections
If you connect to a digital audio input, you’ll need to assign it (see page 37).
• Use an optical digital audio cable to connect one of the AV receiver’s OPTICAL DIGITAL IN jacks to the optical output on your CD player, as shown.
OR
• Use a coaxial digital audio cable to connect one of the AV receiver’s COAXIAL DIGITAL IN jacks to the coaxial output on your CD player, as shown.
DIGITAL
COAXIAL
IN 1IN 2IN 3
IN
OUT OUT
IN IN IN
CD
TAPE
232
OUT
VIDEO 3 VIDEO 2
OUT
IN
VIDEO 3 VIDEO 2 VIDEO 1
VIDEO 1
OUT
IN IN IN
OUT
IN IN
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
V
S
Y
P
B
P
R
OPTICAL
COMPONENT VIDEO
L
R
IN1IN2
OPTICAL
RS
Connect one or the other
DIGITAL OUT
OPTICAL
DIGITAL OUT
COAXIAL
DIGITAL
OUT
COAXIAL
IN 1IN
2
PRE OUT
SUB WOOFER
L
ZONE 2 OUT
REMOTE CONTROL
SUB
R
WOOFER
IN
Use an analog audio cable to connect the AV receiver’s TAPE IN L/R jacks to the cassette recorder’s output, and use another analog audio cable to connect the AV receiver’s TAPE OUT L/R jacks to the cassette recorder’s input, as shown.
DIGITAL
OUT
IN1IN2
COAXIAL
OPTICAL
RS
232
COMPONENT VIDEO
OUT
IN 1IN 2IN 3
Y
VIDEO 3 VIDEO 2
OUT
IN
OUT OUT
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
IN IN IN
IN IN
P
B
P
R
IN IN IN
L
R
CD
Cassette recorder
/
VIDEO 1
OUT
OUT
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
IN 1IN
2
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
REMOTE CONTROL
SUB
R
WOOFER
L
R
L
R
OUT
TAPE
REC PLAY
(IN) (OUT)
IN
L
R
L
R
32
CD player
Connecting the AV receiver
—Continued
Connecting a DAT, CD, or MD Recorder
You can connect a DAT, CD, or MD recorder instead of a cassette recorder.
Analog Connections
Use an analog audio cable to connect the AV receiver’s TAPE IN L/R jacks to the recorder’s output, and use another analog audio cable to connect the AV receiver’s TAPE OUT L/R jacks to the recorder’s input, as shown.
DIGITAL
OUT
IN1IN2
COAXIAL
OPTICAL
RS
Y
P
B
P
R
COMPONENT VIDEO
IN 1IN 2IN 3
OUT OUT
IN IN IN
L
R
CD
OUT
VIDEO 3 VIDEO 2
IN
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
232
OUT
IN IN IN
IN IN
VIDEO 1
OUT
OUT
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
IN 1IN
2
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
REMOTE CONTROL
SUB
R
WOOFER
OUT
IN
L
R
TAPE
L
R
Digital Recording
If your recorder has a digital input, by connecting it to the AV receiver’s optical DIGITAL OUT jack, you can record digitally. However, because the AV receiver doesn’t convert analog input signals to digital and vice versa, only input signals connected to a DIGITAL IN jack can be recorded in this way.
DAT, CD, or MD recorder
OPTICAL
OPTICAL
Y
P
B
P
R
COMPONENT VIDEO
IN
IN IN IN
L
R
CD
OUT
IN 1IN 2IN 3
VIDEO 3 VIDEO 2
IN
OUT OUT
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
RS
232
OUT
DIGITAL IN
OPTICAL
VIDEO 1
OUT
IN IN IN
OUT
IN IN
IN1IN2
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
OPTICAL
DIGITAL
OUT
COAXIAL
IN 1IN
2
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
DIGITAL
REMOTE CONTROL
COAXIAL
SUB
R
WOOFER
IN
REC PLAY
(IN) (OUT)
L
L
DAT, CD, or MD recorder
R
Using Optical or Coaxial Connections
R
(playback only)
If you connect to a digital audio input, you’ll need to assign it (see page 37).
• Use an optical digital audio cable to connect one of the AV receiver’s OPTICAL DIGITAL IN jacks to the optical output on your recorder, as shown.
OR
• Use a coaxial digital audio cable to connect one of the AV receiver’s COAXIAL DIGITAL IN jacks to the coaxial output on your recorder, as shown.
DIGITAL
COAXIAL
IN
REMOTE CONTROL
Y
P
B
P
R
OPTICAL
COMPONENT VIDEO
IN 1IN 2IN 3
OUT OUT
IN IN IN
L
R
CD
OUT
VIDEO 3 VIDEO 2
IN
IN
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
RS
232
OUT
OPTICAL
VIDEO 1
OUT
IN IN IN
OUT
IN IN
IN1IN2
MONITOR
DVD
OUT
FRONT SURR CENTER
DVD
DIGITAL
OUT
COAXIAL
IN 1IN
2
PRE OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
SUB
R
WOOFER
Connect one or the other
OPTICAL
DIGITAL OUT
COAXIAL
DIGITAL OUT
Digital source (DAT, CD, MD player)
Note:
Don’t connect the recorder’s digital output to the AV receiver when the recorder’s digital input is connected to one of the AV receiver’s digital outputs. Doing so may create a signal loop and cause a malfunction.
Connect one or the other
DIGITAL OUT
OPTICAL
DIGITAL OUT
COAXIAL
DAT, CD, or MD recorder
33
Connecting the AV receiver
—Continued
Connecting a Turntable
Turntable with a Built-in Phono Preamp
Use an analog audio cable to connect an unused audio input on the AV receiver to the audio outputs on your turntable, as shown.
P
R
OUT OUT
IN IN IN
L
R
CD
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
IN IN
OUT
IN
CD
Turntable without a Built-in Phono Preamp
Use an analog audio cable to connect an unused audio input on the AV receiver to the audio outputs on your phono preamp, and use another analog audio cable to connect the phono preamp’s inputs to your turntable, as shown.
P
R
IN IN IN
L
R
CD
OUT OUT
TAPE
IN IN
VIDEO 3 VIDEO 2 VIDEO 1
OUT
IN
CD
Turntable with an MC (Moving Coil) Cartridge
Use an analog audio cable to connect an unused audio input on the AV receiver to the audio outputs on your phono preamp. Use another analog audio cable to con­nect the phono preamp’s inputs to your MC head amp’s outputs. And use another analog audio cable to connect the MC head amp’s inputs to your turntable, as shown.
P
R
OUT OUT
IN IN IN
L
R
CD
IN
CD
OUT
IN IN
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
Phono preamp
L
ZONE 2
FRONT SURR CENTER
OUT
REMOTE CONTROL
SUB
R
WOOFER
DVD
AUDIO
OUTPUT
L
R
L
ZONE 2
FRONT SURR CENTER
OUT
REMOTE CONTROL
SUB
R
WOOFER
DVD
Phono preamp
AUDIO
OUTPUT
L
R
L
ZONE 2
FRONT SURR CENTER
OUT
REMOTE CONTROL
SUB
R
WOOFER
DVD
AUDIO INPUT
L
R
MC head amp or
MC transformer
AUDIO
OUTPUT
L
R
AUDIO
OUTPUT
AUDIO INPUT
L
R
L
R
AUDIO
OUTPUT
AUDIO
INPUT
L
R
L
R
Connecting Components
With (Remote Interactive) you can control your
-compatible Integra CD player, DVD player, and so
on with the AV receiver’s remote controller, as follows:
•To use , you must make an analog audio con­nection between the AV receiver and the other AV components, even if they are connected digitally.
Auto Power On/Standby
When you start playback on an AV component con­nected via , if the AV receiver is in Standby, it will turn on and select that AV component as the input source automatically. Similarly, when the AV receiver is set to Standby, all components connected via also enter Standby. Note that this function will not work if the com­ponent’s power cord is connected to one of the AV receiver’s AC OUTLETS.
Direct Change
When playback is started on an AV component con­nected via , the AV receiver automatically selects that AV component as the input source.
Remote Control
You can control your -compatible Integra compo­nents with the AV receiver’s remote controller.
ZONE 2 SPEAKERS
SPEAKERS
SURROUND
232
COMPONENT VIDEO
OUT
IN 1IN 2IN 3
Y
VIDEO 3 VIDEO 2
OUT
IN
IN IN IN
P
B
P
R
OUT OUT
IN IN IN
IN IN
L
R
CD
VIDEO 3 VIDEO 2 VIDEO 1
TAPE
IN
L
R
AUDIO
OUTPUT
L
R
AUDIO
OUTPUT
L
R
IN
L
R
e.g., DVD player
e.g., MD recorder
IN 1IN
2
MONITOR
PRE OUT
DVD
VIDEO 1
OUT
OUT
V
SUB WOOFER
S
L
OUT
ZONE 2
FRONT SURR CENTER
OUT
REMOTE CONTROL
SUB
R
WOOFER
DVD
REMOTE
CONTROL
4.5
DIGITAL
OUT
IN1IN2
COAXIAL
OPTICAL
RS
Notes:
• Push plugs in all the way to make good connections.
• Use only cables for connections. No cables are supplied with this AV receiver.
• Some AV components have two jacks. You can connect either one to this AV receiver. The other jack is for connecting more -compatible components.
• Connect the AV receiver’s jack to only Integra AV components. Connecting to other manufacturer’s AV components may cause them to malfunction.
• Some components may not support all functions. Refer to the manuals supplied with your components.
L
L
R
R
L
L
SPEAKER
CENTER
R
R
FRONT SPEAKERS
34
Connecting the AV receiver
—Continued
Connecting the Power Cords of Other Components
The AV receiver has AC outlets on its rear panel that can be used to connect the power cords of AV other compo­nents that you intend to use with the AV receiver. These components can then be left turned on so that they turn on and off as and when the AV receiver is turned on and set to Standby.
AC OUTLETS
AC 120 V 60 Hz
SWITCHED
TOTAL 120W 1A MAX.
Caution:
• Make sure that the total capacity of the components that you connect to the AC OUTLETS does not exceed the stated capacity (e.g., TOTAL 120 W).
Note:
• Integra components with jacks should be con­nected directly to wall outlets, not the AV receiver’s AC OUTLETS.
• The number of AC OUTLETS, socket type, and total capacity depends on the country in which you pur­chased the AV receiver.
Connecting the Supplied Power Cord
Plug the supplied power cord into this AC INLET.
• Do not use a power cord other than the one supplied with this AV receiver. It’s designed exclusively for use with this AV receiver and should not be used with any other component.
•Never disconnect the power cord from the AV receiver while the other end is still plugged into a wall outlet. Doing so may cause an electric shock. Always discon­nect the power cord from the wall outlet first.
AC INLET
DO NOT connect the
Power cord (supplied)
power cord at this time.
Turning On the AV receiver
Standby/On
Zone 2
Standby
On
Standby
On Standby
V1 V 2 V3
123
Multi CH
456
CD
Tape
789
Phono
+
10 0
--/---
TV
I
Input
+
TV CH
DVD
-
Tuner
TV VOL
Clear
Connecting the RS232 Port
This port can be used to connect an external controller for controlling the AV receiver.
Press the [Standby/On] button. Alternatively, press the remote controller’s [Receiver] button fol­lowed by the [On] button.
Remote
controller
On
Standby
The AV receiver comes on, the display lights up, and the Standby indicator goes off.
To turn off the AV receiver, press the [Standby/On] button. The AV receiver will enter Standby mode.
Notes:
• Pressing the remote controller’s [On] button once will turn on the AV receiver. Pressing it again will turn on any components connected via .
• When the AV receiver is on Standby, it will turn on automatically when any one of its input selector but­tons is pressed.
35
First Time Setup
About the Onscreen Setup Menus
The AV receiver is configured using onscreen setup menus, which are displayed on the TV that’s connected to either of the MONITOR OUT jacks. Because they appear on your TV, they’re large and clear, making setup a breeze.
Settings are divided into two groups: When you’ve configured the settings on the Basic Setup menu correctly, you’ll be ready to enjoy movies and music. The
Advanced Setup menu contains more detailed settings for an even better sound and increased enjoyment.
Basic Setup
and
Advanced Setup
Main menus
Menu
-----------------------­Basic Setup
1.Initial Setup
2.Speaker Setup
Advanced Setup
3.Decorder Setup
4.Audio Adjust
5.Listening Mode Preset
6.Preference
Submenus
1.Initial Setup
------------------------
1.Digital Input
2.Component Video
3.Hardware Setup
2.Speaker Setup
------------------------
1.Speaker Config
2.Speaker Distance
3.Level Calibration
3.Decoder Setup
------------------------
1.Analog/PCM
2.Dolby Digital
3.DTS
4.D.F.2ch
5.Multiplex
6.Multich Input
4.Audio Adjust
------------------------
1.Mono
2.PL Music
3.Enhance
4.Orchestra
5.Unplugged
6.Studio-Mix
7.TV Logic
8.Mono Movie
9.Theater-Dimensional
5.Listening Mode Preset
------------------------
1.DVD/MULTICH
2.VIDEO1
3.VIDEO2
4.VIDEO3
5.TAPE
6.TUNER
7.CD
Basic Setup
p. 37
p. 38
p. 64, 65
p. 39
p. 41
p. 42
Advanced Setup
p. 56
p. 57
p. 57
p. 58
p. 59
36
6.Preference
------------------------
1.IntelliVolume
2.Volume Setup
3.OSD Setup
4.Remote Setup
5.Digital Format
6.12V Trigger A Setup
7.12V Trigger B Setup
8.12V Trigger C Setup
p. 60
p. 61
First Time Setup
—Continued
Initial Setup
Digital Input
If you connect a component to a digital input jack, you must assign that jack to an input selector. For example, if you connect your CD player to the OPTICAL IN2 jack, you should assign that jack to the CD input selector. By default, the OPTICAL IN1 jack is assigned to the DVD input selector, although this can be changed.
1
2, 3
1
Receiver
CD Tape
789
+
10 0
--/---
123
Receiver
Tape
Dimmer
TV Input
+
CH
Disc
-
Prev CH
Display Muting
Surround
Test Tone
Input Selector
Macro
Remote Mode
DVD
n
e
M
p
o
T
E
x
i
R
e
t
u
r
n
Direct
CH SEL
Video OffOpen/Close
u
Enter
t
Tuner
Clear
CD
M
e
n
u
e
d
i
u
G
p
u
t
e
S
AngleSubtitleAudio
DSP DSP
-
Level
TV VOL
Zone 2
MD/CDR
SATTV VCR Cable
Sleep
VOL
RandomRec
Last Memory
StereoAll ST
MemorySearchA-BRepeat
+
Level
2–4
1, 5
Press the [Receiver] button fol­lowed by the [Setup] button.
The main menu appears onscreen.
3
4
Enter
Enter
Enter
Use the Up and Down [ ]/[ ] buttons to select “1. Digital Input,” and then press [Enter].
The Digital Input menu appears.
Menu
-----------------------­Basic Setup
1.Initial Setup
1.Initial Setup
------------------------
2.Speaker Setup
1.Digital Input 1-1.Digital Input
------------------------
2.Component Video
Advanced Setup
a.DVD :OPT1
3.Hardware Setup
3.Surround Setup b.VIDEO1 :-----
4.Audio Adjust c.VIDEO2 :-----
5.Listening Mode Preset d.VIDEO3 :-----
6.Preference e.TAPE :-----
f.CD :-----
• There are no assignments for TUNER.
Use the Up and Down [ ]/[ ] buttons to select an input selec­tor, and then use the Left and
Right [ ]/[ ] buttons to select a digital input jack.
Examples:
If you connect your DVD player to the OPTICAL IN 2 jack, set “a. DVD” to “OPT2.”
If you want to listen to audio from the component connected to the COAX­IAL IN 1 jack when the VIDEO 1 input selector is selected, set “c. VIDEO1” to “COAX1.”
For input selectors that you don’t want to assign a digital input jack, leave them set to “-----.”
2
Enter
Enter
Use the Up and Down [ ]/[ ] buttons to select “1. Initial Setup,” and then press [Enter].
The Initial Setup menu appears.
5
Press the [Setup] button.
The setup menu closes.
Note:
• This procedure can also be performed on the AV receiver by using its [Setup] button, arrow buttons, and [Enter] button.
37
First Time Setup—Continued
Component Video Setup
If you connect to a COMPONENT VIDEO IN, you must assign it to an input selector. For example, if you connect your DVD player to COMPONENT IN 3, you should assign it to the DVD input selector.
Input
selector
DVD DVD IN 1
VIDEO 1 VIDEO 1 Last
VIDEO 2 VIDEO 2 Last
VIDEO 3 VIDEO 3 Last
1
Receiver
2
Enter
Enter
Analog audio
input (fixed)
COMPONENT VIDEO IN jack
Press the [Receiver] button fol­lowed by the [Setup] button.
The main menu appears onscreen.
Use the Up and Down [ ]/[ ] buttons to select “1. Initial Setup,” and then press [Enter].
The initial Setup menu appears.
4
Use the Up and Down [ ]/[ ] buttons to select an input selec-
Enter
tor, and then use the Left and Right [ ]/[ ] buttons to select:
IN1: Use the video component
connected to COMPO­NENT VIDEO IN 1.
IN2: Use the video component
connected to COMPO­NENT VIDEO IN 2.
IN3: Use the video component
connected to COMPO­NENT VIDEO IN 3.
Last: Select this for audio-only
components.
5
Press the [Setup] button.
The setup menu closes.
Notes:
• If you select Last, the video source remains the same when you select another input selector. For example, if you set VIDEO 1 to Last, select the DVD input selector, then select the VIDEO 1 input selector, you can watch a DVD while listening to audio from the component connected to the VIDEO 1 IN L/R jacks.
• This procedure can also be performed on the AV receiver by using its [Setup] button, arrow buttons, and [Enter] button.
38
3
Enter
Enter
Use the Up and Down [ ]/[ ] buttons to select “2. Component Video,” and then press the [Enter] button.
The Component Video Setup menu appears.
Menu
-----------------------­Basic Setup
1.Initial Setup
1.Initial Setup
------------------------
2.Speaker Setup
1.Digital Input 1-2.Component Video
------------------------
2.Component Video
Advanced Setup
a.DVD/MULTICH :IN1
3.Hardware Setup
3.Surround Setup b.VIDEO1 :Last
4.Audio Adjust c.VIDEO2 :Last
5.Listening Mode Preset d.VIDEO3 :Last
6.Preference
First Time Setup
—Continued
Speaker Setup
Speaker Configuration
Here you can specify which speakers are connected and their individual sizes.
For speakers with a cone diameter over 6-1/2 inches (16 cm), specify
large,
and for those with a diameter
below this, specify
1
2, 3
1
Receiver
small.
Cone diameter
CD Tape
789
+
10 0
--/---
123
Receiver
Tape
Dimmer
TV Input
+
CH
Disc
-
Prev CH
Display Muting
Surround
Input Selector
Macro
Remote Mode
DVD
n
e
M
p
o
T
E
x
i
t
R
e
t
u
r
n
Tuner
TV VOL
Clear
Zone 2
CD
MD/CDR
SATTV VCR Cable
Sleep
M
u
e
n
u
Enter
VOL
e
d
i
u
G
p
u
t
e
S
RandomRec
Last Memory
AngleSubtitleAudio
StereoAll ST
2–11
1, 12
Press the [Receiver] button fol­lowed by the [Setup] button.
The main menu appears onscreen.
3
4
5
Enter
Enter
Enter
Enter
Use the Up and Down [ ]/[ ] buttons to select “1. Speaker Config,” and then press [Enter].
The Speaker Config menu appears.
Menu
-----------------------­Basic Setup
2.Speaker Setup
1.Initial Setup
------------------------
2.Speaker Setup
1.Speaker Config 2-1.Speaker Config
------------------------
2.Speaker Distance
Advanced Setup
a.Subwoofer :Yes
3.Level Calibration
3.Surround Setup
4.Equalizer Settings
b.Front :Large
4.Audio Adjust c.Center :Small
5.Listening Mode Preset d.Surround :Small
6.Preference e.Crossover :100Hz
f.Double Bass :Off
Use the Up and Down [ ]/[ ] buttons to select “a. Subwoofer,” and then use the Left and Right
[ ]/[ ] buttons to select:
Yes:
Select if a subwoofer is con­nected.
No:
Select if no subwoofer is con­nected.
Use the Up and Down [ ]/[ ] buttons to select “b. Front,” and
then use the Left and Right [ ]/ [] buttons to select:
Small:
Select if the front speakers are small.
Large:
Select if the front speakers are large.
Note:
• If the Subwoofer setting in step 4 is set to No, this setting is fixed at Large.
2
Enter
Enter
Use the Up and Down [ ]/[ ] buttons to select “2. Speaker Setup,” and then press [Enter].
The Speaker Setup menu appears.
6
Enter
Use the Up and Down [ ]/[ ] buttons to select “c. Center,” and
then use the Left and Right [ ]/ [] buttons to select:
Small:
Select if the center speaker is small.
Large:
Select if the center speaker is large.
None:
Select if no center speaker is connected.
Note:
• If the Front setting in step 5 is set to Small, the Large option cannot be selected.
39
First Time Setup
—Continued
7
Enter
Crossover
8
Enter
Use the Up and Down [ ]/[ ] buttons to select “d. Surround,” and then use the Left and Right
[ ]/[ ] buttons to select:
Small:
Large:
Note:
• If the Front setting in step 5 is set to
Continue with step 8.
Use the Up and Down [ ]/[ ] buttons to select “g. Crossover,” and then use the Left and Right
[ ]/[ ] buttons to select a crossover frequency.
Choose a crossover frequency suitable for your setup. If you’re using a sub­woofer, choose a crossover frequency based on the diameter of your front speakers. If you’re not using a sub­woofer, use the diameter of any speaker that you specified as Small.
Select if the surround left and right speakers are small.
Select if the surround left and right speakers are large.
None:
Select if no surround left and right speakers are connected.
Small, the Large option cannot be selected.
Speaker cone
diameter
Over 8 in. 60Hz
6-1/2 to 8 in. 80Hz
5-1/4 to 6-1/2 in. 100Hz
3-1/2 to 5-1/4 in. 120Hz
Under 3-1/2 in. 150Hz
Crossover
frequency
Double Bass
With the Double Bass function, you can boost bass out­put by feeding bass sounds from the front left and right channels to the subwoofer. This function can be set only if the Subwoofer setting in step 4 is set to Yes, and the Front setting in step 5 is set to Large.
9
Enter
10
Notes:
• This procedure can also be performed on the AV receiver by using its [Setup] button, arrow buttons, and [Enter] button.
Use the Up and Down [ ]/[ ] buttons to select “g. Double Bass,” and then use the Left and
Right [ ]/[ ] buttons to select:
On:
Double Bass function on.
Off:
Double Bass function off
(default).
Press the [Setup] button.
The setup menu closes.
Notes:
• If the crossover frequency is set to a low value, and the program material doesn’t contain any sounds below that frequency, the subwoofer will not output much sound.
40
First Time Setup
—Continued
Speaker Distance
Here you can specify the distance from each speaker to the listening position so that the sound from each speaker arrives at the listener’s ears as the sound designer intended.
2, 3
1
Receiver
+
10 0
--/---
123
Dimmer
TV Input
Receiver
Tape
1
+
CH
Disc
-
Prev CH
Display Muting
Press the [Receiver] button fol­lowed by the [Setup] button.
The main menu appears onscreen.
Input Selector
Macro
Remote Mode
DVD
n
e
M
p
o
T
E
x
i
R
e
t
u
r
n
Clear
Zone 2
CD
MD/CDR
SATTV VCR Cable
Sleep
M
u
e
n
u
Enter
VOL
e
d
i
u
t
G
p
u
t
e
S
RandomRec
2–5
1, 7
4
Enter
The Speaker Distance menu appears.
Menu
-----------------------­Basic Setup
2.Speaker Setup
1.Initial Setup
------------------------
2.Speaker Setup
1.Speaker Config 2-2.Speaker Distance
------------------------
2.Speaker Distance
Advanced Setup
a.Unit :feet
3.Level Calibration
3.Surround Setup
4.Equalizer Settings
b.Front : 12ft
4.Audio Adjust c.Center : 12ft
5.Listening Mode Preset d.Surr Right : 7ft
6.Preference e.Surr Left : 7ft
f.Subwoofer : 12ft
Note:
Speakers that you set to No or None on the Speaker Configuration page (page 39) cannot be selected.
Use the Up and Down [ ]/[ ] buttons to select “a. Unit,” and
then use the Left and Right [ ]/ [] buttons to select:
feet:
Select if you want to enter distances in feet. Can be set from 1 to 30 feet in 1-foot steps.
meters:
Select if you want to enter distances in meters. Can be set from 0.3 to 9 meters in
0.3-meter steps.
2
3
Enter
Enter
Enter
Enter
Use the Up and Down [ ]/[ ] buttons to select “2. Speaker Setup,” and then press [Enter].
The Speaker Setup menu appears.
Use the Up and Down [ ]/[ ] buttons to select “2. Speaker Dis­tance,” and then press [Enter].
5
Use the Up and Down [ ]/[ ] buttons to select “b. Left,” and
Enter
then use the Left and Right [ ]/ [] buttons to specify the dis-
tance.
Specify the distance from the front left speaker to your listening position.
6
7
Repeat step 5 for all speakers.
Press the [Setup] button.
The setup menu closes.
Notes:
• The Center and Subwoofer distances can be set up to 5 ft. (1.5 m) more or less than the Front distance. For example, if the Front distance is set to 20 ft. (6 m), the Center and Subwoofer distances can be set between 15 and 25 ft. (4.5 and 7.5 m). The SurrRight, Surr Left, and Surr Back distances can be set up to 5 ft. (1.5 m) more or 15 ft. (4.5 m) less than the Front distance. For example, if the Front distance is set to 20 ft. (6 m), the SurrRight, Surr Left, and Surr Back distances can be set between 5 and 25 ft. (1.5 and 7.5 m).
• This procedure can also be performed on the AV receiver by using its [Setup] button, arrow buttons, and [Enter] button.
41
First Time Setup
—Continued
Speaker Level Calibration
Here you can adjust the level of each speaker with the built-in test tone so that the volume of each speaker is the same at the listening position.
Notes:
• The speakers cannot be calibrated while the output of the AV receiver is muted, while a pair of headphones is connected, or when using the multichannel input.
1
1
2, 3
Receiver
CD Tape
789
+
10 0
--/---
123
Receiver
Tape
Dimmer
TV Input
+
CH
Disc
-
Prev CH
Display Muting
Press the [Receiver] button fol­lowed by the [Setup] button.
The main menu appears onscreen.
Input Selector
Macro
Remote Mode
DVD
n
e
M
p
o
T
E
x
i
R
e
t
u
r
n
Tuner
TV VOL
Clear
Zone 2
CD
MD/CDR
SATTV VCR Cable
Sleep
M
u
e
n
u
Enter
VOL
e
d
i
u
t
G
p
u
t
e
S
RandomRec
2–4
1, 6
3
4
5
Enter
Enter
Enter
Use the Up and Down [ ]/[ ] buttons to select “3. Level Cali­bration,” and then press [Enter].
The Level Calibration menu appears and the pink noise test tone is output by the front left speaker.
Menu
-----------------------­Basic Setup
2.Speaker Setup
1.Initial Setup
------------------------
2.Speaker Setup
1.Speaker Config 2-3.Level Calibration
2-4.Equalizer Settings
------------------------
2.Speaker Distance
Use Settings :Manual
Advanced Setup
a.Left : 0dB
3.Level Calibration
------------------------
3.Surround Setup
4.Equalizer Settings
Left
b.Center : 0dB
4.Audio Adjust c.Right : 0dB
a. 80Hz : 0dB
5.Listening Mode Preset d.Surr Right : 0dB
b. 250Hz : 0dB
6.Preference e.Surr Left : 0dB
c. 800Hz : 0dB f.Subwoofer : 0dB
d.2.5kHz : 0dB e. 8kHz : 0dB
Note:
Speakers that you set to No or None on the Speaker Configuration page (page 39) cannot be selected.
Use the Up and Down [ ]/[ ] buttons to select each speaker,
and use the Left and Right [ ]/ [] buttons to set the volume.
The volume can be adjusted from –12 to +12 dB in 1 dB steps (–15 to +12 dB for the subwoofer).
Repeat step 4 until the volume of the test tone from each speaker is the same.
42
2
Enter
Enter
Use the Up and Down [ ]/[ ] buttons to select “2. Speaker Setup,” and then press [Enter].
The Speaker Setup menu appears.
6
Press the [Setup] button.
The setup menu closes.
Notes:
• This procedure can also be performed by using the remote controller. First press the [Test Tone] button to output the test tone. Use the [Level–] and [Level+] buttons to set the volume, and use the [CH SEL] but­ton to select the speakers.
First Time Setup
—Continued
Changing the TAPE/MD/CDR Display
If you connect an -compatible Integra MiniDisc recorder or CD recorder to the TAPE IN/OUT jacks, for
to work properly, you must change this setting.
This setting can only be changed on the AV receiver.
Zone 2
Standby
1, 2
1
2
Press the [TAPE] input selector button so that “TAPE” appears on the display.
Press and hold down the [TAPE] input selector button (about 3 seconds) to set the display.
Repeat this step to select TAPE, MD, or CDR.
43
Basic Operation
Selecting the Input Source
This section explains how to select the input source (i.e., the AV component that you want to listen to or watch).
1
AV receiver
Zone 2
Standby
or
Remote
controller
Receiver
V1 V2 V3
Multi CH
CD Tape
3
1
1
On Standby
V1 V2 V3
123
Multi CH
456
CD Tape
789
+
10 0
--/---
Input Selector
Macro
123
Remote Mode
Receiver
DVD
Tape
Dimmer
u
n
e
TV
M
p
o
Input
T
+
CH
Enter
Disc
-
E
x
i
t
Prev
R
e
t
u
CH
r
n
1
Display Muting
Use the AV receiver’s input selector buttons to select the input source.
To select the input source with the remote controller, press the [Receiver] button, and then use the Input Selector buttons.
On the remote controller, the [V1], [V2], and [V3] buttons select the VIDEO 1, VIDEO 2, and VIDEO 3 input sources respectively.
DVD
Tuner
Tuner
Clear
G
TV
I
Input
+
TV CH
DVD
-
TV VOL
Zone 2
CD
MD/CDR
SATTV VCR Cable
Sleep
M
e
n
u
3
VOL
e
d
i
u
p
u
t
e
S
44
2
3
AV receiver
Start playback on the source component.
When you select DVD or another video component, on your TV, you’ll need to select the video input that’s connected to the AV receiver’s MONITOR OUT.
On some DVD players, you may need to turn on the digital audio output.
Remote
controller
To adjust the volume, use the Master Volume control, or the remote controller’s [VOL] button.
The volume can be set to MIN, 1 through 99, or MAX.
or
VOL
The AV receiver is designed for home theater enjoyment. It has a wide volume range, allowing precise adjustment.
Basic Operation
CD Tape
Tuner
—Continued
Press [Receiver] first
Dimmer
789
+
10 0
--/---
Input Selector
Macro
123
Remote Mode
Receiver
DVD
Tape
Dimmer
TV
p
o
Input
T
TV VOL
Clear
Zone 2
CD
MD/CDR
SATTV VCR Cable
Sleep
M
u
n
e
e
n
M
u
+
CH
Enter
Disc
-
E
x
Prev
R
e
t
u
CH
r
n
Display Muting
VOL
e
d
i
i
u
t
G
p
u
t
e
S
RandomRec
Setting the Display Brightness
You can adjust the brightness of the display.
Receiver
Dimmer
Press the [Receiver] button, and then press the [Dimmer] button repeatedly to select Normal, Dim or Dimmer.
• Normal
• Dim
• Dimmer
Sleep
Muting
Using the Sleep Timer
With the sleep timer, you can set the AV receiver to auto­matically turn off after a specified period.
Press the [Receiver] button, and
Receiver
then press the [Sleep] button repeatedly to select the required sleep time.
Sleep
The sleep time can be set from 90 to 10 minutes in 10 minute steps.
The SLEEP indicator appears on the display when the sleep timer has been set, as shown. The specified sleep time appears on the display for about five seconds, then the previous display reappears.
If you need to cancel the sleep timer, press the [Sleep] button repeatedly until the SLEEP indicator disappears.
To check the time remaining until the AV receiver sleeps, press the [Sleep] button. Note that if you press the [Sleep] button while the sleep time is being displayed, you’ll shorten the sleep time by 10 minutes.
Using Headphones
You can connect a pair of stereo headphones (1/4-inch phone plug) to the AV receiver’s Phones jack for private listening, as shown.
Muting the AV receiver
You can temporarily mute the output of the AV receiver.
Press the [Receiver] button, and
Receiver
Muting
then press the [Muting] button.
The output is muted and the MUTING indicator flashes on the display, as shown.
To unmute the AV receiver, press the [Muting] button again, or adjust the volume.
The Mute function is cancelled when the AV receiver is set to Standby.
Zone 2
Standby
Phones
Notes:
•Always turn down the volume before connecting your headphones.
• The speakers are turned off while the headphones plug is inserted in the Phones jack. (Zone 2 speakers are not turned off.)
• When you connect a pair of headphones, the listening mode is set to Stereo, unless it’s already set to Stereo, Mono, or Direct. When you disconnect the head­phones, the previous listening mode is resumed.
• Only the Stereo, Direct, and Mono listening modes can be used with headphones. (The listening modes available also depends on the currently selected input source.)
• When the multichannel input is used, only the front left and right audio can be heard in the headphones.
45
Basic Operation
+
10 0
Clear
—Continued
Displaying Source Information
You can display various information about the current input source as follows.
Receiver
Display
--/---
Input Selector
Macro
123
Remote Mode
Receiver
DVD
Tape
Dimmer
e
TV
M
p
o
Input
T
Zone 2
CD
MD/CDR
SATTV VCR Cable
M
u
n
e
n
u
+
CH
Enter
Disc
-
E
x
Prev
R
e
t
u
CH
r
n
Display Muting
VOL
e
d
i
i
u
t
G
p
u
t
e
S
RandomRec
Sleep
Receiver
Press the [Receiver] button, and then press the [Display] button repeatedly to cycle through the available information.
Display
The following information can typically be displayed for input sources.
Input source &
volume
Signal format*
or sampling
frequency
Input source & listening mode
*If the input signal is analog, no format information is displayed. If the input signal is PCM, the sampling fre­quency is displayed. If the input signal is digital but not PCM, the signal format is displayed. Information is dis­played for about three seconds, then the previously dis­played information reappears.
Interpreting Surround Channel Values
ABC
A: The number of front channels (3 means front left,
front right, and center).
B: The number of surround channels (2 means surround
left and surround right).
C: LFE channel for subwoofer (1 means yes).
46
Basic Operation
—Continued
Using the Tuner
With the built-in tuner you can enjoy AM and FM radio stations. You can store your favorite stations as presets for quick selection.
Manual Tuning Mode
1
Press the [Tuning Mode] button so that the AUTO indicator disap­pears from the display.
Listening to the Radio
1
Use the [TUNER] input selector button to select either AM or FM.
In this example, FM has been selected.
Band Frequency
Tuning into Radio Stations
Zone 2
Standby
Auto Tuning Mode
2
The AV receiver changes FM frequency in 0.2 MHz steps, 10 kHz steps for AM.
In Manual Tuning mode, FM stations will be in mono.
Tuning into weak FM stereo stations
If the signal from a stereo FM station is weak, it may be
21
impossible to get good reception. In this case, switch to Manual Tuning mode and listen to the station in mono.
Press and hold the Tuning Up or Down [ ]/[ ] button.
The frequency stops changing when you release the button.
Press the buttons repeatedly to change the frequency one step at a time.
1
2
When tuned into a station, the TUNED indicator appears. When tuned into a stereo FM station, the FM STEREO indicator appears on the display, as shown.
Press the [Tuning Mode] button so that the AUTO indicator appears on the display.
Press the Tuning Up or Down [ ]/ [] button.
Searching stops when a station is found.
AUTOTUNED
FM STEREO
47
Basic Operation
—Continued
Presetting Radio Stations
32, 4
Zone 2
Standby
You can store up to 40 of your favorite radio stations as presets.
1
2
3
Tune into the station that you want to store as a preset.
Press the [Memory] button.
The MEMORY indicator appears and the preset number flashes.
While the MEMORY indicator is displayed (about 8 seconds), use the Preset [ ]/[ ] buttons to select a preset from 1 through 40.
In this example, preset #3 is selected.
Deleting Presets
2
Zone 2
Standby
1
2
Select the preset that you want to delete.
See the previous section.
While holding down the [Mem­ory] button, press the [Tuning MODE] button.
The selected preset is deleted and its number disappears from the display.
Displaying Radio Information
2
4
Press the [Memory] button again to store the station.
The station is stored and the preset number stops flashing.
Repeat this procedure for all your favorite radio stations.
Selecting Preset Stations
1
2
Use the [TUNER] input selector button to select either AM or FM.
Use the Preset [ ]/[ ] buttons, or the remote controller’s CH [+/ –] button to select a preset.
Zone 2
Standby
1
Band, preset # & frequency
Listening mode
Press the [Display] button repeatedly to cycle through the available information.
48
Basic Operation
—Continued
Selecting Listening Modes
See “About the Listening Modes” on page 51 for detailed information about the listening modes.
• The Dolby Digital and DTS listening modes can only be selected if your DVD player is connected to the AV receiver with a digital audio connection (coaxial or optical).
• Listening mode availability depends on the format of the current input signal.
Selecting on the AV receiver
Stereo
Zone 2
Standby
Listening Mode
[Stereo] button
This button selects the Stereo listening mode.
Selecting with the Remote Controller
RC-587M
Surround
Direct
[Surrond] button
This button selects the Dolby Digital, Pro Logic II, DTS, and other listening modes.
[All ST] button
This button selects the All Ch Stereo listening mode.
[Stereo] button
This button selects the Stereo listening mode.
[Direct] button
This button selects the Direct listening mode.
[ DSP] & [DSP ] buttons
These buttons select the Onkyo original DSP modes.
Display Muting
RandomRec
Last Memory
AngleSubtitleAudio
Surround
Test Tone
Direct
CH SEL
Video OffOpen/Close
StereoAll ST
MemorySearchA-BRepeat
DSP DSP
-
Level
Level
Cine Fltr
L Night
-
RC
587M
All ST Stereo
DSP
+
DSP
Listening Mode [ ] [ ] buttons
These buttons select all the listening modes that can be used with the current input source. Modes can be selected in the following order, depending on the input signal format: Direct
Mono ➔ Stereo ➔ Surround (e.g., Dolby Digital, DTS, PL II, and so on) ➔ Onkyo original DSP
49
Basic Operation
—Continued
The following table lists all the listening modes and shows which modes can be selected for each input signal format.
Input signal format
Source
Listening mode
Direct
Stereo
Mono
PLII Movie/Music/Game *3
Dolby D
DTS, DTS 96/24
Multich
Mono Movie
Enhance
Orchestra
Unplugged
Studio-Mix
TV Logic
All Ch Stereo
Full Mono
Theater-Dimensional
1. In the Direct listening modes, PCM signals at 32 kHz, 44.1 kHz, and 48 kHz are processed at 64 kHz, 88.2 kHz, and 96 kHz respectively. 96 kHz signals are processed at 48 kHz for all listening modes other than Direct, and Stereo.
2. In the Direct, Stereo, and DTS 96/24 listening modes, signals are processed as DTS 96/24. Everything else processed as DTS.
3. Cannot be selected if the Center and Surr parameters are set to “None” or the Zone 2 speakers are being used.
Analog,
PCM*1
CD, TV, LD,
VHS, MD, turntable,
radio,
cassette, DTV,
etc.
❍❍❍❍❍❍❍❍
❍❍❍❍❍❍❍❍
❍❍❍❍❍❍❍❍
*/2 2/0
Dolby D DTS/DTS 96/24*2
1/
Other */2 2/0
0,1+1
DVD, DTV, etc. DVD, LD, CD, etc. DVD
❍❍❍❍
❍❍
❍❍
1/0,
Other
1+1
❍❍ ❍
Multich
50
Basic Operation
—Continued
About the Listening Modes
With its built-in surround-sound decoders and DSP pro­grams, the AV receiver can transform your home listen­ing room into a movie theater or concert hall.
The AV receiver’s surround indicators show which speakers are active in each listening mode.
Front left Center Front right
Subwoofer
Surround
left
Direct
The selected input source is output by the front left and right speakers only, with minimal processing for a pure sound.
Stereo
The selected input source is processed as a stereo signal and output by the front left and right speakers and the subwoofer.
Mono or
Use this mode when watching an old movie with a mono soundtrack, or to select multilingual soundtracks recorded in the left and right channels of some movies. It can also be used when playing a DVD or other source with multiplexed audio, such as a karaoke DVD.
Dolby Pro Logic II
Use this mode with DVDs and vid­eos that bear the Dolby Surround logo or TV programs that feature Dolby Surround. You can also use this mode with stereo movies or TV pro­grams and the AV receiver will create a 5.1 surround mix from the 2-channel stereo.
Dolby Pro Logic II has three modes of operation; Movie mode for movies, Music mode for listening to music and Game mode for use with games consoles with 2-channel stereo outputs.
Dolby Digital
With this format you can experience the same superb sound that you get at a movie theater or concert hall. Use this mode with DVDs that bear the Dolby Digital logo.
DTS
This digital surround format offers a surround sound experience with exceptional fidelity. It uses compressed digital audio data, with six discrete channels (5.1), and the ability to handle large amounts of audio data while remaining faithful to the original. DTS provides very high-quality sound. You’ll need a DTS compatible DVD player in order to enjoy DTS material. Use this mode with DVDs, LDs, or CDs that bear the DTS logo.
Surround
right
DTS 96/24
This mode provides higher audio quality. Use it with CDs, DVDs, and LDs that bear the DTS 96/24 logo.
Onkyo Original DSP Modes
Orchestra or
Suitable for classical or operatic music. The center speaker is turned off and the surround channels are emphasized in order to widen the stereo image. In addi­tion, it simulates the natural reverberation of a large hall.
Unplugged
Suitable for acoustic instrument sounds, vocals, and jazz music. By emphasizing the front stereo image, it simu­lates the stage-front experience.
Studio-Mix
Suitable for rock and pop music. Listening to music in this mode creates a lively sound field with a powerful acoustic image, like being at a club or rock concert.
TV Logic
Adds realistic acoustics to TV programs produced in a TV studio. In addition, it adds surround effects to the entire sound and adds clarity to voices.
Enhance
This mode is ideal for enjoying music programs or TV sports programs. It provides a natural surround sound with movement in the surround speakers, creating a sound with a live feeling to it.
Mono Movie
This mode is suitable for use with old movies and other mono sound sources. The center speaker outputs the sound as it is, while reverb is applied to the sound output by the other speakers, giving presence to even mono material.
All Ch Stereo
Ideal for background music. The front and surround channels create a stereo image that fills the entire listen­ing area.
Full Mono
In this mode, all speakers output mono audio, so the music sounds the same regardless of where you are.
T-D (Theater-Dimensional) or
With this mode you can enjoy a virtual 5.1 surround sound even with only two or three speakers. This works by controlling how sounds reach the listener’s left and right ears. Good results may not be possible if there’s too much reverb, so we recommend that you use this mode in an environment with little or no natural reverb.
51
Advanced Operation
-
587M
Tuner
Clear
CD
AngleSubtitleAudio
DSP DSP
-
Level
L Night
-
TV VOL
Zone 2
MD/CDR
SATTV VCR Cable
Sleep
Last Memory
StereoAll ST
MemorySearchA-BRepeat
+
Level
Cine Fltr
Cine Fltr
Receiver
L Night
456
CD Tape
789
+
10 0
--/---
Input Selector
Macro
123
Remote Mode
Receiver
DVD
Tape
Dimmer
TV Input
Rec
Surround
Direct
Test Tone
CH SEL
Video OffOpen /Close
RC
Using the Late Night Function (Dolby Digital only)
With the Late Night function, you can reduce the dynamic range of Dolby Digital material so that you can still hear quiet parts even when listening at low volume levels—ideal for watching movies late at night when you don’t want to disturb anyone.
Using the CinemaFILTER
With the CinemaFILTER, you can soften overly bright movie soundtracks, which are typically mixed for repro­duction in a movie theater.
CinemaFILTER can be used with the following listening modes: Dolby Digital, Dolby Pro Logic II Movie, DTS, and DTS 96/24.
1
Receiver
Press the [Receiver] button, and then press the [Cine Fltr] button repeatedly to select:
On: CinemaFILTER on.
Cine Fltr
Off: CinemaFILTER off.
Adjusting the Bass & Treble
You can adjust the bass and treble for the front speakers, except when the Direct mode is selected.
Zone 2
Standby
1
Receiver
Press the [Receiver] button, and then press the [L NIGHT] button repeatedly to select:
Off: Late Night function off.
Low: Small reduction in dynamic
L Night
range.
High: Big reduction in dynamic
range.
Notes:
• The effect of the Late Night function depends on the Dolby Digital material that you are playing, and with some material there will be little or no effect.
• The Late Night function is set to Off when the AV receiver is set to Standby.
2
1
1
Press the [Tone] button repeat­edly to select either Bass or Treble.
2
Use the Tone [–]/[+] buttons to adjust.
Bass
You can boost or cut low-frequency sounds output by the front speakers from –10 dB to +10 dB in 2 dB steps.
Treble
You can boost or cut high-frequency sounds output by the front speakers from –10 dB to +10 dB in 2 dB steps.
52
Advanced Operation
On Standby
V1 V2 V3
123
Multi CH
Multi CH
Receiver
CH SEL
456
CD Tape
789
+
10 0
--/---
Input Selector
123
Receiver
Tape
Dimmer
TV Input
Rec
Surround
Test Tone
Video OffOpen /Close
Macro
Remote Mode
DVD
Direct
CH SEL
-
RC
587M
I
DVD
Tuner
Clear
CD
AngleSubtitleAudio
DSP DSP
-
Level
L Night
TV
—Continued
Input
+
TV CH
-
TV VOL
Zone 2
MD/CDR
SATTV VCR Cable
Sleep
Last Memory
StereoAll ST
MemorySearchA-BRepeat
+
Level
Cine Fltr
Level – +
Adjusting Individual Speaker Levels
You can adjust the level of individual speakers during playback. These adjustments are temporary and will be cancelled when the AV receiver is set to Standby.
1
Receiver
CH SEL
-
Level
Notes:
•You cannot use this function while the AV receiver is muted.
• Speakers that are set to No or None in the Speaker Configuration cannot be adjusted.
Press the [Receiver] button, use the [CH SEL] button to select each speaker, and use the [Level–] and [Level+] buttons to adjust the volume.
Speakers are selected in the following order: Front Left
Center → Front Right → Surr Right → Surr left → Subwoofer.
You can adjust the volume of each
+
Level
speaker from –12 dB to +12 dB (–15 dB to +12 dB for the subwoofer).
The name of the currently selected speaker and its volume appear on the display, as shown.
Using the DVD Analog Multichannel Input
The DVD analog multichannel input is for connecting components with a 5.1-channel analog audio output, such as a DVD player or MPEG decoder.
See “Using a Multichannel Connection” on page 28 for connection information.
1
Receiver
Multi CH
Notes:
•To use the bass and treble functions with the DVD analog multichannel input, select the Multich listening mode first.
Adjusting Individual Speaker Levels
You can adjust the level of individual speakers while using the DVD analog multichannel input.
1
CH SEL
-
Level
Notes:
• These speaker level settings are completely indepen­dent of those explained on pages 42 and left column.
• While the DVD analog multichannel input is selected, you can only select the Direct or Multich listening mode. If you select the DVD analog multichannel input while using another listening mode, that listen­ing mode will be cancelled.
• While the DVD analog multichannel input is selected, the Speaker Configuration settings on page 39 is ignored, and signals from the multichannel input are fed to the front left, front right, center, surround left, and surround right speakers, and subwoofer regardless of those settings.
Press the [Receiver] button fol­lowed by the [Multi CH] button so that “MCH” appears on the dis­play.
Use the remote controller’s [CH SEL] button to select each speaker, and then use the [Level–] and [Level+] buttons to adjust the volume.
The level can be adjusted from –12 to +12 dB (–30 to +12 dB for the sub-
+
Level
woofer).
53
Advanced Operation
—Continued
Recording
This section explains how to record the current input source, how to record one input source while enjoying another, and how to dub audio onto your video record­ings.
Unless you have the full consent of the copyright holder, copyright laws prohibit using your recordings for anything other than personal enjoyment!
Notes:
• The surround sound and DSP listening modes cannot be recorded.
• Copy-protected DVDs cannot be recorded.
•You cannot record from the DVD analog multichannel input.
•Various restrictions apply to digital recording. Refer to the manuals supplied with your digital recording equipment for more details.
• Digital input signals are output by only the digital out­puts, and analog input signals are output by only the analog outputs. There is no internal conversion from digital to analog or vice versa.
• DTS signals will be recorded as noise, so don’t attempt analog recording of DTS CDs or LDs.
Rec Out
2
3
4
Press the [Rec Out] button, and then use the Controller [ ]/[ ]
buttons to select “Rec Sel : Source.”
The current input source can be recorded by the recorder connected to the TAPE OUT.
Start recording on the recorder.
See your recorder’s manual for more information.
Start playback on the source component.
If you select another input source dur­ing recording, that input source will be recorded.
Recording Audio & Watching a Separate AV Source at the Same Time
While recording audio, you can watch a completely sep­arate AV Source at the same time. For example, you could watch a DVD while recording a CD to tape.
1
Press the [Rec Out] button.
Zone 2
Standby
Input Selector
Controller
Recording Audio
You can record the current audio source as follows.
1
Use the input selector buttons to select the audio component that you want to record.
2
3
4
Notes:
• Since the Zone 2 function and the REC OUT outputs use the same circuitry, you cannot record from a sepa­rate source and use Zone 2 at the same time.
•To turn off the REC OUT output (i.e., the TAPE OUT), press the [Rec Out] button, and then use the Controller [ ] [ ] buttons to select “OFF.”
Within five seconds, use the Controller [ ]/[ ] buttons to
select the audio input source that you want to record (you cannot select TAPE).
The name of the input source selected for recording appears on the display.
The specified input source can now be recorded by the recorder connected to the TAPE OUT.
Start recording on the recorder.
See your recorder’s manual for more information.
Start playback on the audio source component.
54
Advanced Operation
—Continued
AV Recording
You can record AV input sources to an AV recording component (VCR, etc) connected to the VIDEO 1 OUT or VIDEO 2 OUT. See pages 26–35 for information on connecting components.
1
Zone 2
Standby
1
2
Use the input selector buttons to select the AV component that you want to record.
Audio signals from the selected input source are output by the VIDEO 1 OUT and VIDEO 2 OUT only.
You can watch the source while record­ing, and the AV receiver’s VOLUME control has no effect on recording.
Start recording on the AV compo­nent connected to the VIDEO 1 OUT or VIDEO 2 OUT.
Recording Separate AV Sources
Here you can record audio and video from completely separate sources, allowing you to overdub audio onto your video recordings. This function takes advantage of the fact that when an audio-only input source (i.e., TAPE, TUNER, or CD) is selected, the video input source remains unchanged.
In the following example, audio from the CD player con­nected to the CD IN, and video from the camcorder con­nected to the VIDEO 3 INPUT VIDEO jack are recorded by the VCR connected to the VIDEO 1 OUT jacks.
Camcorder
video signal audio signal
DIGITAL
OUT
IN1IN2
COAXIAL
IN 1IN
2
MONITOR
PRE OUT
OUT
V
SUB WOOFER
S
L
ZONE 2 OUT
REMOTE CONTROL
SUB
R
WOOFER
DVD
Y
P
B
P
R
COMPONENT VIDEO
IN 1IN 2IN 3
OUT OUT
IN IN IN
L
R
CD
TAPE
RS
232
OUT
VIDEO 3 VIDEO 2
OUT
IN
VIDEO 3 VIDEO 2 VIDEO 1
OPTICAL
VIDEO 1
OUT
IN IN IN
OUT
IN IN
DVD
FRONT SURR CENTER
3
Start playback on the source AV component.
If you select another input source dur­ing recording, that input source will be recorded.
VCRCD player
Prepare the camcorder and CD player for
1
playback.
Prepare the VCR for recording.
2
Press the [VIDEO 3] input selector button.
3
Press the [CD] input selector button.
4
This selects the CD player as the audio source, but leaves the camcorder as the video source.
Start recording on the VCR and start play-
5
back on the camcorder and CD player.
The video from the camcorder and the audio from the CD player are recorded by the VCR.
55
Advanced Setup
Decoder Setup
Here are surround-related settings for PCM, Dolby Dig­ital, multichannel, and other input signal formats.
1
2
3
Receiver
Enter
Enter
Enter
Press the [Receiver] button fol­lowed by the [Setup] button.
The main menu appears onscreen.
Use the Up and Down [ ]/[ ] buttons to select “3. Decoder Setup,” and then press [Enter].
The Surround Setup menu appears.
Menu
-----------------------­Basic Setup
3.Decorder Setup
1.Initial Setup
------------------------
2.Speaker Setup
1.Analog/PCM
2.Dolby Digital
Advanced Setup
3.DTS
3.Surround Setup
4.D.F.2ch
4.Audio Adjust
5.Multiplex
5.Listening Mode Preset
6.Multich Input
6.Preference
Use the Up and Down [ ]/[ ] buttons to select the menu items, and then press [Enter].
3-1. Analog/PCM
These settings apply to PCM input signals from CD players and so on, and analog signals from cassette play­ers, turntables, and so on.
a. Input Channel (Mono)
This setting determines which channel is output when the Mono listening mode is used with a stereo source.
L+R:
Both the left and right channels are output (default).
Left:
Only the left channel is output.
Right:
Only the right channel is output.
b. Surround Mode
This setting determines the surround mode for analog and PCM input signals. This setting is unavailable if no center and surround speakers are connected.
You can select PLII Movie (default), PLII Music, or PLII Game.
3-2. Dolby Digital
These settings apply to Dolby Digital input signals.
a. LFE Level
With this setting, you can set the level of the LFE (Low Frequency Effects) channel for Dolby Digital sources to –
∞,
–10 dB, or 0 dB (default).
If you find that the low-frequency effects are too loud when playing Dolby Digital sources, set this to –10 dB or –∞ dB.
Enter
4
Use the Up and Down [ ]/[ ] buttons to select the settings,
Enter
and use the Left and Right [ ]/ [] buttons to set them.
The settings are explained below.
5
When you’ve finished, press the [Setup] button.
The setup menu closes.
Note:
• This procedure can also be performed on the AV receiver by using its [Setup] button, arrow buttons, and [Enter] button.
56
Advanced Setup
—Continued
3-3. DTS
These settings apply to DTS input signals.
a. LFE Level
With this setting you can set the level of the LFE (Low Frequency Effects) channel for DTS sources to –∞, –10 dB, or 0 dB (default).
If you find that the low-frequency effects are too loud when playing DTS sources, set this to –10 dB or –
dB.
3-4. D.F. 2ch
These settings apply to digital input signals, Dolby Dig­ital and so on, with only 2 channels (2/0).
a. Input Channel (Mono)
This setting determines which channel is output when the Mono listening mode is used with a stereo source.
L+R:
Both the left and right channels are output (default).
Left:
Only the left channel is output.
Right:
Only the right channel is output.
b. Surround Mode
This setting determines the default surround mode for digital input signals, Dolby Digital and so on, with only 2 channels (2/0). This setting is unavailable if no center and surround speakers are connected.
You can select PLII Movie (default), PLII Music, or PLII Game.
3-5. Multiplex
This setting applies to multiplex input signals.
a. Input Channel
This setting determines which channel is output from a stereo multiplex source. Use it to select audio channels or languages with multiplex sources, multilanguage TV broadcasts, and so on.
Main:
The main channel is output (default).
Sub:
The sub channel is output.
Main/Sub:
Both the main and sub channels are output.
3-6. Multichannel Input
These settings apply to the analog multichannel input.
a. Subwoofer Sensitivity
When using the DVD analog multichannel input, the loudness of the connected subwoofer also depends on the component that’s connected to that input. If you find that it’s too loud, set this to 0 dB, +5 dB, +10 dB, or +15 dB. The default setting is 0 dB.
Audio Adjust Functions
Here you can set listening mode-related settings and functions.
1
Receiver
2
Enter
Enter
3
Enter
Enter
4
Enter
5
Note:
• This procedure can also be performed on the AV receiver by using its [Setup] button, arrow buttons, and [Enter] button.
Press the [Receiver] button fol­lowed by the [Setup] button.
The main menu appears onscreen.
Use the Up and Down [ ]/[ ] buttons to select “4. Audio Adjust,” and then press [Enter].
The Audio Adjust menu appears.
Use the Up and Down [ ]/[ ] buttons to select menu items, and then press [Enter].
Menu
-----------------------­Basic Setup
4.Audio Adjust
1.Initial Setup
------------------------
2.Speaker Setup
1.Mono
2.PL Music
Advanced Setup
3.Enhance
3.Surround Setup
4.Orchestra
4.Audio Adjust
5.Unplugged
5.Listening Mode Preset
6.Studio-Mix
6.Preference
7.TV Logic
8.Mono Movie
9.Theater-Dimensional
Use the Up and Down [ ]/[ ] buttons to select the settings,
and use the Left and Right [ ]/ [] buttons to set them.
The settings are explained below.
When you’ve finished, press the [Setup] button.
The setup menu closes.
57
Advanced Setup
—Continued
4-1. Mono
a. Output Channel
This setting determines which speakers are used to out­put mono audio when the Mono listening mode is used.
L/R:
Mono audio is output from the front left and right speakers (default).
Center:
Mono audio is output from the center speaker.
4-2. PLII Music
a. Panorama
With this function, you can broaden the width of the front stereo image when using the Dolby Pro Logic II Music listening mode.
On:
Panorama function on.
Off:
Panorama function off (default).
b. Dimension
With this setting, you can move the sound field forward or backward when using the Dolby Pro Logic II Music listening mode. The default setting is 3. Higher settings move the sound field forward. Lower settings move it backward.
If the stereo image feels too wide, or there’s too much surround sound, move the sound field forward to improve the balance. Conversely, if the stereo image feels like it’s in mono, or there’s not enough surround sound, move it backward.
c. Center Width
With this function, you can adjust the width of the sound from the center speaker when using the Dolby Pro Logic II Music listening mode. If you’re using a center speaker, with Dolby Pro Logic II, the center channel sound is out­put by only the center speaker. (If you’re not using a cen­ter speaker, the center channel sound will be distributed to the front left and right speakers to create a phantom center). This setting controls the front left, right, and center mix, allowing you to adjust the weight of the cen­ter channel sound. It can be adjusted from 0 to 7 (default is 3).
4-3. Enhance, 4-4. Orchestra, 4-5. Unplugged, 4-6. Studio-Mix, 4-7. TV Logic & 4-8. Mono Movie
These settings apply to the Onkyo original DSP listening modes.
a. Front Effect
With this setting, you can turn off the reverb for the front speakers. This is useful when playing live material that already contains live reverberation and the reverb added by the DSP listening mode simply blurs the original sound. When the Front Effect is turned off, no reverb is added to the front left, right, and center speakers and the original reverberation can be heard as it is.
On:
Front Effect on (default).
Off:
Front Effect off.
b. Reverb Level
With this setting, you can adjust the amount of reverb to suit your listening environment, source material, and so on. The available settings are: Low, Middle (default), and High.
c. Reverb Time
With this setting, you can adjust the reverb time to suit your listening environment, source material, and so on. The available settings are: Short, Middle (default), and Long.
4-9. Theater-Dimensional
These settings apply to the Theater-Dimensional listen­ing mode.
a. Listening Angle
With this setting, you can specify the angle of the front left and right speakers relative to the listening position.
Processing for the Theater-Dimensional listening mode is based on this setting. Ideally, the front left and right speakers should be equidistant from the listening position and at an angle close to one of the two available settings.
Front left speaker
20º:
Select if the listening angle is 20 degrees.
40º:
Select if the listening angle is 40 degrees (default).
b. Center
With this setting, you can specify whether or not you’re using a center speaker. If you are, the center channel sound will be output by the center speaker when using the Theater-Dimensional listening mode. This reduces the workload of the front left and right speakers, and cre­ates a more articulate sound space.
On:
Select if using a center speaker.
Off:
Select if not using a center speaker (default).
c. Front Expand
With the Front Expander function, you can broaden the width of the front stereo image. This can be useful with narrow listening angles of 20 degrees or less.
On:
Front Expander function on.
Off:
Front Expander function off (default).
d. Dialog Enhance
With this function, you can improve the clarity of the center channel, which usually contains dialog.
On:
Dialog Enhance function on.
Off:
Dialog Enhance function off (default).
Front right speaker
20/40˚
58
Advanced Setup
e. Virtual Surr Level
—Continued
With this setting, you can adjust the level of virtual sur­round sound from –3 dB to +3 dB (default is 0 dB). If the clarity is poor, or the effect sounds unnatural, you may be able to improve it by lowering this setting.
Assigning Listening Modes to Input Sources
You can assign a default listening mode to each input source that will be selected automatically when you select each input source. For example, you can set the default listening mode to be used with Dolby Digital input signals. You can select other listening modes dur­ing playback, but the mode specified here will be resumed once the AV receiver has been set to Standby.
1
2
3
Receiver
Enter
Enter
Enter
Enter
Press the [Receiver] button fol­lowed by the [Setup] button.
The main menu appears onscreen.
Use the Up and Down [ ]/[ ] buttons to select “5. Listening Mode Preset,” and then press [Enter].
The Listening Mode Preset menu appears.
Menu
-----------------------­Basic Setup
5.Listening Mode Preset
1.Initial Setup
------------------------
2.Speaker Setup
1.DVD/MULTICH
2.VIDEO1
Advanced Setup
3.VIDEO2
3.Surround Setup
4.VIDEO3
4.Audio Adjust
5.TAPE
5.Listening Mode Preset
6.TUNER
6.Preference
7.CD
Use the Up and Down [ ]/[ ] buttons to select the input selec­tor that you want to set, and then press [Enter].
5-1.ListeningModePreset
----- DVD/MULTICH -----­ a.Ana/PCM :Last Valid b.Dolby D :Last Valid c.DTS :Last Valid d.D.F.2ch :Last Valid e.D.F.Mono:Last Valid f.Multiplex :Last Valid g.Multich :Last Valid
For input selectors that have no digital input jacks, only “a. Analog” will be available.
4
Enter
Use the Up and Down [ ]/[ ] buttons to select the signal for­mat that you want to set, and
then use the Left and Right [ ]/ [] buttons to select a listening
mode.
Only listening modes that can be used with each input signal format can be selected.
The Last Valid option means that the listening mode selected last will be used.
For “Surround”, the listening mode specified on pages 56, 57.
a. Ana/PCM:
With this setting, you can specify the listening mode to be used when an analog (CD, TV, LD, VHS, MD, turntable, radio, cassette, cable, satellite, etc) or PCM digital (CD, DVD, etc) audio signal is played.
b. Dolby D:
With this setting, you can specify the listening mode to be used when a Dolby Digital format digital audio signal is played (DVD, etc).
c. DTS:
With this setting, you can spec­ify the listening mode to be used when a DTS format digital audio signal is played (DVD, LD, CD, etc).
d. D.F. 2ch:
With this setting, you can specify the listening mode to be used when a 2-channel (2/0) digital audio signal (Dolby Digital, DTS) is played (DVD, etc).
e. D.F. Mono:
With this setting, you can specify the listening mode to be used when a mono digital audio signal is played (DVD, etc).
f. Multiplex:
With this setting, you can specify the listening mode to be used when a multiplex audio signal is played.
g. Multich:
This setting is available only when “5-1. DVD/MULTCH” is selected. With this setting, you can specify the listening mode to be used when the DVD analog multichannel input is used.
5
When you’ve finished, press the [Setup] button.
The setup menu closes.
Note:
• This procedure can also be performed on the AV receiver by using its [Setup] button, arrow buttons, and [Enter] button.
59
Advanced Setup
—Continued
Setting Preferences
This section explains the items on the Preference menu.
1
Receiver
2
Enter
Enter
3
Enter
Enter
4
Enter
5
Note:
• This procedure can also be performed on the AV receiver by using its [Setup] button, arrow buttons, and [Enter] button.
Press the [Receiver] button fol­lowed by the [Setup] button.
The main menu appears onscreen.
Use the Up and Down [ ]/[ ] buttons to select “6. Preference,” and then press [Enter].
The Preference menu appears.
Menu
-----------------------­Basic Setup
6.Preference
1.Initial Setup
------------------------
2.Speaker Setup
1.IntelliVolume
2.Volume Setup
Advanced Setup
3.OSD Setup
3.Surround Setup
4.Remote Setup
4.Audio Adjust
5.Digital Format
5.Listening Mode Preset
6.12V Trigger A Setup
6.Preference
7.12V Trigger B Setup
8.12V Trigger C Setup
Use the Up and Down [ ]/[ ] buttons to select menu items, and then press [Enter].
Use the Up and Down [ ]/[ ] buttons to select the settings,
and use the Left and Right [ ]/ [] buttons to set them.
The settings are explained below.
When you’ve finished, press the [Setup] button.
The setup menu closes.
6-1. IntelliVolume
With this preference, you can set the input level for each input source. This is useful if some of your AV compo­nents are louder or quieter than others.
While this preference is shown onscreen, you can select each input source and set the levels while listening to and comparing them.
If a component is too loud compared to your other com­ponents, use the Left [ ] button to adjust the level. If it’s too quiet, use the Right [ ] button.
• The level can be set from –12 dB to +12 dB.
6-2. Volume Setup
a. Volume Display
With this preference, you can choose how the volume level is displayed.
Absolute: Relative:
The absolute value 82 is equivalent to the relative value 0 dB.
With this preference, you can prevent the volume being set too high by specifying a maximum volume level.
When the Volume Display preference is set to Absolute, the range is from 50 to 99. When it’s set to Relative, the range is –32 dB through +17 dB. To specify no maxi­mum volume, select Off.
With this preference, you can specify the volume setting to be used each time the AV receiver is turned on.
When the a. Volume Display preference is set to Abso­lute, the range is MIN, 1 through 99, or MAX. When it’s set to Relative, the range is –∞ dB, –81 dB through +18 dB.
To use the same volume level that was used when the AV receiver was turned off, select Last.
The Power On Volume cannot be set higher than the maximum volume specified with the b. Maximum Vol­ume setting.
With this preference, you can specify the headphone vol­ume relative to the main volume. This is useful if there’s a volume difference between your speakers and your headphones. The headphone volume can be set between –12 dB and +12 dB.
Display range is MIN, 1 through 99, MAX.
Display range is –∞ dB, –81 dB, –80 dB through +18 dB.
b. Maximum Volume
c. Power On Volume
d. Headphones Level
60
Advanced Setup
—Continued
6-3. OSD Setup
a. Immediate Display
This preference determines whether or not actions, such as selecting an input source, are displayed onscreen.
Normal:
Even if this preference is set to Normal or Wide, actions are not displayed on the TV or projector that’s connected to the COMPONENT VIDEO OUT.
If the text in onscreen setup menus flickers due to com­patibility with the connected display device (TV, projec­tor, etc), set the Scan Mode to Non-Interlaced.
Interlaced: Non-Interlaced:
• Depending on the display device, when Non-Inter-
Actions displayed. Select this if you have a
standard 4:3 TV.
Wide:
Actions displayed. Select this if you have a
widescreen 16:9 TV.
Off:
Actions not displayed.
b. Scan Mode
Default.
Select if the text flickers.
laced is selected, the onscreen setup menus may not appear. If this happens, use the AV receiver’s display and repeat the procedure to revert to Interlaced.
6-4. Remote Setup
a. Remote ID
With this setting, you can change the AV Receiver’s remote control ID. You may need to change this if the remote controller’s control codes overlap with those of another Integra component located in the same room.
• If you change the AV receiver’s remote control ID, be sure to set the same ID on both the AV receiver and remote controller (see right column). The default ID for both is 1.
b. IR IN Position
When using a commercially available IR receiver, use this setting to specify its location.
Main:
Select if the IR receiver is located in the main room.
Zone 2:
Select if the IR receiver is located in, and will be used to control Zone 2.
6-5. Digital Format
b. Digital Format
This setting does not apply to input selectors not assigned to a digital input jack.
With this setting, you can set a digital input to DTS, PCM, or Auto. This can be set for each input selector individually.
Use the Up and Down [ ]/[ ] buttons to select the input selector that you want to set, and then use the Left and Right [ ]/[ ] buttons to select:
Auto:
PCM, Dolby Digital, and DTS formats are accepted. If no digital signal is present, the ana­log input is used.
DTS:
Select this option if playing a DTS CD with the Auto option produces noise while the AV receiver is identifying the DTS signal, or when using fast forward or fast reverse. Nothing is output if the input signal is not DTS.
PCM:
Select this option if playing a CD or other PCM source with the Auto option causes the tops of tracks to be clipped. Nothing is output if the input signal is not PCM.
• If there is no digital connection, only Auto appears.
• Select Auto or DTS when playing a DTS CD or LD. If you select PCM, only noise will be heard.
6-6., 6-7., 6-8. 12V Trigger Setup
When the AV receiver’s 12 V TRIGGER OUT A/B/C jack is connected to the 12 V TRIGGER IN jack on a connected component, you can specify whether or not a 12-volt trigger signal is output when that component is selected as the source for the main room, Zone 2, or both.
By default, on the Trigger A Setup menu, all input sources are set to Main. On the Trigger B and C Setup menus, all input sources are set to Off.
Off:
No trigger signal is output.
Main:
Select this if you want to output a 12-volt trig­ger signal when a connected component is selected as the source for the main room.
Zone2:
Main/Zone2:
When several components are turned on simultaneously via the 12-volt triggers, depending on the type of compo­nents, a large amount of current may be drawn momen­tarily. To prevent this, you can delay the trigger signals output by the AV receiver. In addition, by delaying the trigger signal for your power amplifier so that it’s the last component to be turned on, you can avoid the “thump” noise that’s sometimes heard when a source component is turned on.
The delay determines how long after the input source is changed on the AV receiver the trigger signal is output, and can be set to 0 sec, 1 sec, 2 sec, or 3 sec. When set to 0 sec, the trigger signal is output as soon as the input source is changed.
Select this if you want to output a 12-volt trig­ger signal when a connected component is selected as the source for Zone 2.
Select this if you want to output a 12-volt trigger signal when a connected component is selected as the source for either the main room or Zone 2.
Delay
61
Advanced Setup
—Continued
Changing the Remote Controller’s ID
If several Integra components are used in the same room, the remote controller’s control codes may overlap with those of another component. To differentiate the remote controller’s control codes, you can change its ID to another number.
Notes:
If you change the remote controller’s ID, be sure to set the same ID on both the remote controller and AV receiver (see 6-4. Remote Setup on page 61). The default ID for both is 1.
On Standby
V1 V2 V3
123
456
CD Tape
789
+
10 0
--/---
Input Selector
123
1
1
2
Receiver
Tape
Dimmer
Press and hold down the [Receiver] but­ton, and then press the TV [Input] button.
Use the number buttons to enter a remote control ID.
Multi CH
Macro
Remote Mode
DVD
DVD
Tuner
Clear
TV
I
Input
+
TV CH
-
TV VOL
Zone 2
CD
MD/CDR
SATTV VCR Cable
Sleep
1
Number buttons
You can enter 1, 2, or 3.
62
Zone 2
Connecting Zone 2
With the Zone 2 function, you can enjoy one input source in the main room and a different source in another room.
There are two connection methods: using a receiver/inte­grated amp in Zone 2 or using only a pair of speakers in Zone 2.
Using a Receiver/Integrated Amp in Zone 2
With this connection method, you can use 5.1 surround sound in the main room and play a different AV source in Zone 2. The volume for Zone 2 is set on the receiver/ integrated amp.
• Use an RCA audio cable to connect the AV receiver’s ZONE 2 OUT L/R jacks to an analog audio input on your receiver/integrated amp.
• Connect the Zone 2 speakers to the speaker terminals on the receiver/integrated amp.
Main room
TV
AV receiver
Using Only Speakers in Zone 2
With this connection method, you can use stereo sound in the main room and play a different AV source in Zone 2. The volume for Zone 2 is set on the AV receiver.
• Set the Powered Zone 2 setting to Activated (see page 64).
• Connect your Zone 2 speakers to the AV receiver’s ZONE 2 SPEAKERS terminals.
Main room
TV
AV receiver
Zone 2
LR
Zone 2
IN
L
R
TV
Receiver/
integrated amp
The AV receiver’s ZONE 2 OUT jacks can also be used as pre outs, although, in this case, the volume cannot be controlled solely on the connected amplifier. See “Set­ting the Zone 2 Out” on page 65 for details.
63
Zone 2
789
—Continued
Setting the Powered Zone 2
To use Zone 2, you must make this setting. It enables the speakers connected to the ZONE 2 SPEAKERS termi­nals so that they produce sound when Zone 2 is used.
TV VOL
Input Selector
Macro
Remote Mode
DVD
n
e
M
p
o
T
E
x
i
R
e
t
u
r
n
Direct
CH SEL
Video OffOpen /Close
u
t
Enter
Clear
CD
M
e
n
u
e
d
i
u
G
p
u
t
e
S
AngleSubtitleAudio
DSP DSP
-
Level
Zone 2
MD/CDR
SATTV VCR Cable
Sleep
VOL
RandomRec
Last Memory
StereoAll ST
MemorySearchA-BRepeat
+
Level
2–4
1, 5
1
1
2, 3
Receiver
+
10 0
--/---
123
Receiver
Tape
Dimmer
TV Input
+
CH
Disc
-
Prev CH
Display Muting
Surround
Test Tone
Press the [Receiver] button fol­lowed by the [Setup] button.
The main menu appears onscreen.
4
5
Enter
Use the Up and Down [ ]/[ ] buttons to select “a. Powered Zone 2,” and use the Left and
Right [ ]/[ ] buttons to select:
Menu
-----------------------­Basic Setup
1.Initial Setup
1.Initial Setup
------------------------
2.Speaker Setup
1.Digital Input 1-3.Hardware Setup
------------------------
2.Component Video
Advanced Setup
a.Powered Zone2
3.Hardware Setup
3.Surround Setup :Not Activated
4.Audio Adjust b.Zone2 Out
5.Listening Mode Preset :Fixed
6.Preference
Not Activated:
Zone 2 SPEAKERS
terminals deactivated.
Activated:
Zone 2 SPEAKERS termi-
nals activated. When Zone 2 is activated and turned on
(see page 66), the speakers connected to the ZONE 2 SPEAKERS terminals output sound, but the speakers con­nected to the SURROUND SPEAK­ERS and CENTER SPEAKER terminals do not. (When Zone 2 is acti­vated but not used, the surround speak­ers and center speaker work as normal.)
Press the [Setup] button.
The setup menu closes.
64
2
3
Use the Up and Down [ ]/[ ] buttons to select “1. Initial
Enter
Setup,” and then press [Enter].
The Initial Setup menu appears.
Enter
Use the Up and Down [ ]/[ ] buttons to select “3. Hardware
Enter
Setup,” and then press [Enter].
The Hardware Setup menu appears.
Enter
Note:
• This procedure can also be performed on the AV receiver by using its [Setup] button, arrow buttons, and [Enter] button.
Zone 2
789
—Continued
Setting the Zone 2 Out
The ZONE 2 OUT L/R jacks can also be used as pre outs.
TV VOL
Input Selector
Macro
Remote Mode
DVD
n
e
M
p
o
T
E
x
i
t
R
e
t
u
r
n
Direct
CH SEL
Video OffOpen /Close
u
Enter
Clear
CD
M
e
n
u
e
d
i
u
G
p
u
t
e
S
AngleSubtitleAudio
DSP DSP
-
Level
Zone 2
MD/CDR
SATTV VCR Cable
Sleep
VOL
RandomRec
Last Memory
StereoAll ST
MemorySearchA-BRepeat
+
Level
2–4
1, 5
1
2
1
2, 3
Receiver
Enter
+
10 0
--/---
123
Receiver
Tape
Dimmer
TV Input
+
CH
Disc
-
Prev CH
Display Muting
Surround
Test Tone
Press the [Receiver] button fol­lowed by the [Setup] button.
The main menu appears onscreen.
Use the Up and Down [ ]/[ ] buttons to select “1. Initial Setup,” and then press [Enter].
The Initial Setup menu appears.
3
4
5
Enter
Enter
Enter
Use the Up and Down [ ]/[ ] buttons to select “3. Hardware Setup,” and then press [Enter].
The Hardware Setup menu appears.
Menu
-----------------------­Basic Setup
1.Initial Setup
1.Initial Setup
------------------------
2.Speaker Setup
1.Digital Input 1-3.Hardware Setup
------------------------
2.Component Video
Advanced Setup
a.Powered Zone2
3.Hardware Setup
3.Surround Setup :Not Activated
4.Audio Adjust b.Zone2 Out
5.Listening Mode Preset :Fixed
6.Preference
Use the Up and Down [ ]/[ ] buttons to select “b. Zone 2 Out,”
and use the Left and Right [ ]/ [] buttons to select:
Menu
------------------------
Basic Setup
1.Initial Setup
1.Initial Setup
------------------------
2.Speaker Setup
1.Digital Input 1-3.Hardware Setup
------------------------
2.Component Video
Advanced Setup
a.Powered Zone2
3.Hardware Setup
3.Surround Setup :Not Activated
4.Audio Adjust b.Zone2 Out
5.Listening Mode Preset :Fixed
6.Preference
Fixed:
The ZONE 2 OUT L/R jacks work as line outs, and you can control the volume solely on the connected amplifier.
Variable:
The ZONE 2 OUT L/R jacks work as pre outs. Since the output level is controlled by the AV receiver’s Mas­ter Volume control, you cannot control the volume solely on the connected amplifier.
Press the [Setup] button.
The setup menu closes.
Enter
65
Zone 2
—Continued
Using Zone 2
Here you can turn on Zone 2, select an input source, and adjust the volume.
On Standby
1
2
V1 V2 V3
123
456
CD Tape
789
+
10 0
--/---
Input Selector
123
Receiver
Tape
Surround
Test Tone
Multi CH
Macro
Remote Mode
DVD
Direct
CH SEL
Video OffOpen /Close
RC
-
587M
TV
I
DVD
Tuner
Clear
CD
AngleSubtitleAudio
DSP DSP
-
Level
L Night
Input
+
TV CH
-
TV VOL
Zone 2
MD/CDR
SATTV VCR Cable
Last Memory
StereoAll ST
MemorySearchA-BRepeat
Level
Cine Fltr
Note:
To control Zone 2 with the remote controller, you must press the [ZONE 2] button first.
4
1–4
+
3
3
Level
4
Zone 2
-
Zone 2
Standby
To set Zone 2 to the same source as the main room, press the [ZONE 2] button, and then use the Controller [ ]/[ ] buttons to select “Zone 2 Sel: Source.”
To adjust the Zone 2 volume with the remote controller, press the [ZONE 2] button, and then use the [Level–] and [Level+] buttons.
To do this on the AV receiver,
+
Level
press the Zone 2 [Level] button, and then use the Controller [ ]/ [] buttons.
If the Zone 2 receiver/integrated amp is connected to the AV receiver’s ZONE 2 OUT L/R jacks, use the volume control on the receiver/integrated amp.
To turn off Zone 2 with the remote controller, press the [ZONE 2] button followed by the [Standby] button.
To do this from the AV receiver, press the [ZONE 2] button, and
then use the Controller [ ]/[ ] buttons to select OFF.
1
Zone 2
On
2
Zone 2
V1 V2 V3
Multi CH
CD Tape
Point the remote controller at the AV receiver and press the [ZONE 2] button followed by the [On] button.
To select the Zone 2 input source with the remote controller, press the [ZONE 2] button followed by an input selector button.
If you select AM or FM, you can use the remote controller’s [TUNER] but-
DVD
ton to select the band.
To perform steps 1 and 2 on the
Tuner
AV receiver, press the [ZONE 2] button, and then use the Control-
ler [ ]/[ ] buttons within five seconds.
The name of the selected Zone 2 source appears on the display.
Notes:
• If the Sleep function has been set, the Zone 2 compo­nent will turn off along with the AV receiver when the specified sleep time expires. To use the Sleep function with Zone 2 only, set the Sleep function and then set the AV receiver to Standby.
• Only analog input sources are output by the ZONE 2 OUT and ZONE 2 SPEAKERS terminals. Digital input sources are not output. If no sound is heard when an input source is selected, check if it’s connected to an analog input.
• Since the Zone 2 function and the REC OUT outputs use the same circuitry, if the [Rec Out] function is used, Zone 2 will be turned off.
• While Zone 2 is being used, listening modes that need surround speakers are unavailable.
• While Zone 2 is on, functions will not work.
•You can’t select different radio stations for Zone 2 and the main room. For example, if you an FM station for the main room, that station will also be used in Zone 2.
66
Zone 2
—Continued
Using the 12V Trigger
When the AV receiver’s 12 V TRIGGER OUT A/B/C jack is connected to the 12 V TRIGGER IN jack on a connected component, the AV receiver can be configured so that the component is turned on automatically when Zone 2 is used. See page 61 for details.
Adjusting the Bass & Treble for Zone2
You can adjust the bass and treble for Zone2.
1
Zone 2
Standby
2
1
Press the [Tone] button repeat­edly to select either Bass or Treble.
Using the Remote Control in Zone 2
To use the remote controller to control the AV receiver from Zone 2, you’ll need one of the following commer­cially available multiroom remote control kits:
• Multiroom Kits such as those made by Niles and Xan­tech.
These kits can also be used when the AV receiver is not in line of sight of the remote controller, for example, when it’s installed inside a cabinet.
Using a Multiroom Kit with Zone 2
In the following diagram, an IR receiver picks up the infrared signals from the remote controller in Zone 2 and feeds them to the AV receiver in the main room via the connecting block.
• On the Remote Setup menu, set the IR IN Position set­ting to “Zone 2” (see page 61).
Connecting block
IR Receiver
Remote controller
2
Bass
You can boost or cut low-frequency sounds output by the front speakers from –10 dB to +10 dB in 2 dB steps.
Treble
You can boost or cut high-frequency sounds output by the front speakers from –10 dB to +10 dB in 2 dB steps.
Use the Controller [ ]/[ ] but­tons to adjust.
Main room Zone 2
Signal flow
Connect the miniplug cable from the connecting block to the AV receiver’s IR IN jack as shown below.
from the connecting block
Miniplug cable
67
Zone 2
—Continued
Using a Multiroom Kit with a Cabinet
In the following diagram, an IR receiver picks up the infrared signals from the remote controller and feeds them to the AV receiver in the cabinet via the connecting block.
• On the Remote Setup menu, set the IR IN Position set­ting to “Main” (see page 61).
IR Receiver
Remote controller
IR IN
Inside cabinet
Connecting block
Signal flow
Controlling Out-of-range Components
If another AV component is out of range of its remote controller, you can use a commercially available IR emitter to retransmit the remote controller signals received at the AV receiver’s IR IN, as shown below.
IR Receiver
IR IN
IR OUT
Connecting block
DTR-4.5
IR Emitter
Remote controller
Other
component
Connect the IR emitter to the AV receiver’s IR OUT, and place the IR emitter in front of the other AV component’s remote control sensor (usually located on the front panel), as shown below. See the instructions supplied with the IR emitter.
Mini plug
Other component
Emitter
IR Emitter
from connecting block
Miniplug cable
DTR-4.5
Only remote controller signals received by the AV receiver’s IR IN are fed through to the IR OUT. Signals picked up by the AV receiver’s remote control sensor are not output.
68
Signal flow
Remote control sensor
Signal flow
Controlling Other Components
You can use the AV Receiver’s remote controller (RC­587M) to control your other components, including those made by other manufacturers. This chapter explains how to:
• Enter the remote control code for a component that you want to control (e.g., DVD, TV, VCR).
• Learn commands directly from another component’s remote controller (see page 77).
• Program the Macro function to perform a sequence of actions with a single press of a button (see page 78).
Entering Remote Control Codes
Entering the appropriate remote control code for each Remote Mode button will allow you to control your other components with the remote controller. You’ll need to perform this procedure for each component that you want to control.
For the [DVD], [TV], [VCR], [CABLE], and [SAT] but­tons, choose a code from the respective category. For the [CD] and [MD/CDR] buttons, you can choose a code from any category. Remote control codes cannot be entered for the [Receiver] and [ZONE 2] buttons.
1
On Standby
2
3
2
V1 V2 V3
123
456
CD Tape
789
+
10 0
--/---
Input Selector
123
Receiver
Tape
Dimmer
TV Input
+
CH
Disc
-
Prev CH
Display Muting
Look up the remote control code for your component.
See “Remote Control Codes” on page 71.
Multi CH
Macro
Remote Mode
DVD
n
e
M
p
o
T
E
x
R
e
t
u
r
n
TV
I
Input
+
TV CH
DVD
-
Tuner
TV VOL
Clear
Zone 2
CD
MD/CDR
SATTV VCR Cable
Sleep
M
u
e
n
u
Enter
VOL
e
d
i
i
u
t
G
p
u
t
e
S
2
Remote Mode
Receiver
DVD
Tape
Standby
3
V1 V2 V3
123
Multi CH
456
CD Tape
789
0
4
While holding down the Remote Mode button that you want to
CD
MD/CDR
enter the code for, press the
SATTV VCR Cable
[Standby] button.
Within 30 seconds, use the num­ber buttons to enter the 4-digit remote control code.
DVD
Tuner
Select the remote controller mode, point the remote control­ler at the component, and check its operation.
Remote controller buttons that can be used in DVD mode are shown on page 14. Those that can be used with the TV, VCR, CABLE, and SAT modes are shown on pages 75, 76.
If the remote controller works OK, the code has been entered correctly. If not, try again or try another code.
Codes for Integra DVD Players
The remote control code for an Integra DVD player depends on whether it’s connected via , as follows:
5001:
Use this code if you’ve connected an cable and an analog audio cable to your DVD player. This is the default setting, so if you’re using
, you don’t need to change anything. Point the remote controller at the AV receiver to operate the DVD player.
5002:
Use this code if your DVD player doesn’t have an jack, or you’re not using . Point the remote controller at the DVD player to operate it.
Setting the [MD/CDR] Button to CDR
By default, the [MD/CDR] button is set to control a MiniDisc recorder. To control a CD recorder, it must be set to CDR. The codes are as follows:
6002:
Code for controlling an CD recorder.
6003:
Code for controlling an MD recorder (default).
69
Controlling Other Components
Standby
Receiver
On Standby
V1 V2 V3
123
456
CD Tape
789
+
10 0
--/---
Input Selector
123
Receiver
Tape
Dimmer
TV Input
Multi CH
Macro
Remote Mode
DVD
u
n
e
M
p
o
T
DVD
Tuner
Clear
M
TV
I
Input
+
TV CH
-
TV VOL
Zone 2
CD
MD/CDR
SATTV VCR Cable
Sleep
e
n
u
—Continued
TV
Remote Mode
+
CH
Enter
Disc
-
E
x
Prev
R
e
t
u
CH
r
Display Muting
VOL
e
d
i
i
u
t
G
p
u
t
e
n
S
Resetting Remote Mode Buttons
If you’ve entered another code for one of these button and now want to return to the default, perform the fol­lowing procedure.
By default, some REMOTE MODE buttons are prepro­grammed with remote control codes for controlling Inte­gra components connected via .
Resetting the Remote Controller
Here you can reset the remote controller to its default settings.
1
2
Receiver
Standby
Receiver
While holding down the [Receiver] button, press the [Standby] button.
Release both buttons and wait five sec­onds.
Press the [Receiver] button again.
The remote controller is reset.
1
Receiver
Tape
2
Receiver
Tape
Remote Mode
DVD
Remote Mode
DVD
While holding down the Remote Mode button that you want to
CD
MD/CDR
reset, press the TV [ ] button.
SATTV VCR Cable
Release both buttons and wait two sec­onds.
Press the Remote Mode button again.
CD
MD/CDR
The Remote Mode button is reset.
SATTV VCR Cable
70
Controlling Other Components
—Continued
Remote Control Codes
When two or more codes are given, try each one in turn, and choose the one that works best.
Depending on the manufacturer and component, the remote controller may not work as expected.
DVD (DVD player)
Manufacturer Control code
Aiwa 5010
Akai 5019
Apex 5015, 5016
CyberHome 5027
Denon 5017, 5020
GE 5003
Hitachi 5009
Integra 5001, 5002
Integra Research 5001, 5002
JVC 5023
Kenwood 5017
Magnavox 5004, 5021
Marantz 5025, 5026
Mitsubishi 5005
Onkyo 5001, 5002
Panasonic 5011, 5017, 5020
Philips 5004, 5021, 5028
Pioneer 5006
Proscan 5003
RCA 5003
Sanyo 5012
Sony
Technics 5020
Thomson 5022, 5024
Toshiba 5008, 5021
Xbox 5022
Yamaha 5020
Zenith 5014, 5021
SAT (satellite receiver)
Manufacturer Control code
Alba 4014, 4017, 4025, 4027
Allsat 4015, 4027
Alltech 4022, 4025
Amstrad
Anglo 4025
Ankaro 4025
Anttron 4017
Apollo 4017
Arcon 4016
Armstrong 4013
Asat 4016
Astra 4013, 4016, 4024
Astro 4019, 4020
AudioTon 4015
Bush 4012, 4014
Condor 4024
5007, 5013, 5018, 5029
4013, 4019, 4025, 4030, 4031
SAT (satellite receiver)
Manufacturer Control code
Conrad 4024
Cosat 4015, 4023
Crown 4013
Daewoo 4016, 4017, 4025
Diamond 4022
Dishnet 4008
Dual 4016
Echostar 4010, 4018, 4025
Einhell 4013, 4017, 4025
Elta 4015, 4017
Engel 4025
Eurosat 4013, 4022
Eurosky 4013, 4024
Eurostar 4024
Fagor 4015, 4023
Ferguson 4012
Fidelity 4030
Fracarro 4017
FTE 4025, 4030
Fuba 4017
Galaxis 4015, 4023
GE 4001, 4002
General Instruments 4003
GMI 4013
Grundig 4021, 4029, 4031
Hinari 4017
Hirschmann 4019, 4035
Hitachi 4036, 4037
Hughes Network Systems
Huth 4013, 4015, 4024
Imperial 4014
Intertronic 4013
Intervision 4015, 4023, 4024
Johansson 4015
JVC 4009, 4021
Kathrein 4025
Kolon 4017
K-SAT 4025
Kyostar 4017
Lasat 4013, 4020, 4024
Lenco 4016, 4017, 4025
Lennox 4023
Loewe 4013
Lorenzen 4024
Macab 4022
Manhattan 4015, 4020, 4023
Maspro 4021, 4025
Matsui 4021
Mediamarkt 4013
Medion 4025
Metronic 4013, 4017, 4020
Micro Technology 4025
Minerva 4021
Morgan’s 4013, 4015, 4025
Mysat 4025
Neuhaus 4019, 4023, 4024, 4025
Neusat 4025
4011
SAT (satellite receiver)
Manufacturer Control code
Nikko 4013, 4025, 4027
Nokia 4033
Nordmende 4017, 4020
Oceanic 4022
Octagon 4016, 4017
Okano 4013
Optex 4015, 4023
Orbit 4016
Orbitech 4017, 4019
Pace 4012, 4026, 4031
Pacific 4022
Palladium 4013, 4017, 4021
Palsat 4019
Panasonic 4006, 4031
Panda 4024
Philips 4021, 4029
Phonotrend 4015, 4023
Predki 4017
Premier 4023
Primestar 4007
Proscan 4001, 4002
Protek 4022
Pye 4021
Quelle 4024
Radix 4035
RCA 4001, 4002
Roadster 4025
Rover 4025
Saba 4014, 4020, 4024, 4027
Samsung 4017
Satcom 4024
SatPartner 4017, 4020, 4027, 4030
Schneider 4029
Sedea Electronique 4017
Seemann 4013
SEG 4017, 4028
Seleco 4015, 4023
Skymaster 4025, 4034
Skyvision 4015
Sony 4005, 4031
Strong
Sunstar
Techniland
TechniSat
Teco
Teleciel
Telefunken
Teleka
Telemaster
Telewire
Tensai
Thomson
Thorens
Tonna
Toshiba
Tr iasat
4016, 4017, 4020
4013
4015, 4023
4019
4013, 4016
4027
4017
4013
4020
4015, 4023
4016
4024, 4025
4022
4015, 4023, 4025
4004
4019
71
Controlling Other Components
—Continued
SAT (satellite receiver)
Manufacturer Control code
Tr istar
Unisat
Universum 4021, 4024
Vor tec 4017
Wela 4025
Zehnder 4020
Zenith 4032
4016
4013
CBL (cable receiver)
Manufacturer Control code
ABC 3001, 3002, 3021
Archer 3006
Cabletime 3028, 3032
Cableview 3004
Contec 3009
Eastern 3010
GE 3001, 3002
Gemini 3011
General Instruments 3002, 3022
Grundig 3031
Hamlin 3012
Hitachi 3002
Jerrold
Magnavox 3014
Memorex 3015
Movie Time 3016
NEC 3003
Nokia 3033
NSC 3016
Oak 3009
Panasonic 3020
Philips 3007, 3008, 3014
Pioneer 3017, 3024
Proscan 3001, 3002
RCA 3004, 3020, 3022
Realistic 3006
Sagem 3034
Salora 3029
Samsung 3017
Signature 3002
Sprucer 3020
Standard Component
Starcom 3011, 3021
Stargate 3011
Tele+1 3030
Tocom 3013
United Cable 3021, 3023
Universal 3005, 3006
Videoway 3025
View Star 3009, 3014, 3016
Zenith 3019
3002, 3011, 3013, 3021, 3022, 3023, 3026
3018
VCR
Manufacturer Control code
Aiwa 2012, 2046, 2047
Akai 2003, 2004, 2022
Alba
Anitech 2033
ASA 2034
Baird 2036
Bell & Howell 2007
Blaupunkt 2039, 2042
Bush
Canon 2010, 2011
Carver 2014
Cimline 2033
Citizen 2008, 2009
Colortyme 2005
Craig 2008
Crown 2033
Curtis Mathes
Cyrus 2034
Daewoo 2012
Dansai 2033
Decca 2034
Dimensia 2001, 2026
Dumont 2034, 2036, 2037
Elcatech 2033
Emerson 2003, 2010, 2012, 2022
ESC 2043
Ferguson 2035
Finlandia 2034, 2036
Finlux 2034, 2036, 2037
Firstline 2033, 2041
Fisher 2007, 2030, 2036
Fuji 2004, 2010, 2024
Funai 2012
Garrard 2012
GE
GEC 2034
GoldHand 2033
GoldStar 2005, 2009
Goodmans 2031, 2033
Gradiente 2012
Graetz 2036, 2043
Granada 2030, 2034, 2036
Grandin 2033
Grundig
Harman Kardon 2005
HCM 2033, 2044
Hinari
Hitachi
Ingersol 2028
Interfunk 2034
ITT 2030, 2036, 2043, 2048
JC Penney
2033, 2041, 2044, 2045, 2047
2033, 2041, 2044, 2045, 2047
2001, 2005, 2008, 2009, 2010, 2011, 2023, 2026
2001, 2002, 2008, 2010, 2011, 2023, 2025, 2026
2029, 2033, 2034, 2039, 2040, 2042, 2044
2028, 2033, 2043, 2044, 2047
2013, 2021, 2025, 2028, 2037, 2038, 2043
2005, 2006, 2007, 2008, 2010, 2011, 2013, 2014, 2021
VCR
Manufacturer Control code
Jensen 2013
JVC
Kaisui 2033
Kendo 2041, 2046
Kenwood 2005, 2006, 2007, 2009
Kodak 2010
Loewe 2028, 2034
Logik 2028, 2043
Luxor 2030, 2031, 2036
Magnavox
Marantz
Matsui 2028, 2041, 2046, 2047
Matsushita 2010
Memorex
Metz 2039
MGA 2022
Minerva 2039
Minolta 2013, 2021
Mitsubishi 2013, 2022, 2032, 2034
Motorola 2010
MTC 2008
Multitech 2008, 2012, 2033
NEC
Neckermann 2034
Nesco 2033
NOBLEX 2008
Nokia 2030, 2036, 2043
Nordmende 2048
Okano 2046
Olympus 2010
Optonica 2017
Orion
Osaki 2033
Otto Versand 2034
Palladium 2033
Panasonic 2010, 2011, 2042
Pentax 2013, 2021, 2025, 2037
Pentex Research 2009
Philco 2010, 2011, 2014
Philips
Phonola 2034
Pioneer 2006, 2013, 2032, 2034
Proline 2044
Proscan 2001, 2002, 2026
Pye 2034
Quasar 2010, 2011
Quelle 2034
Radio Shack 2017
Radio Shack/ Realistic
Radiola 2034
2005, 2006, 2007, 2009, 2032, 2035, 2040, 2048
2010, 2011, 2014, 2019, 2020
2005, 2006, 2007, 2009, 2010, 2014, 2031, 2034
2007, 2008, 2010, 2012, 2019, 2030, 2036
2005, 2006, 2007, 2009, 2032
2028, 2041, 2045, 2046, 2047
2010, 2014, 2017, 2034, 2048
2007, 2008, 2010, 2011, 2012, 2017
72
Controlling Other Components
—Continued
VCR
Manufacturer Control code
RCA
Realistic
Rex 2048
Roadstar 2033, 2043
Runco 2019
Saba 2040, 2048
Saisho 2028, 2041
Salora 2030
Samsung 2008, 2043, 2049
Sansui 2006, 2032
Sanyo 2007, 2008, 2030, 2036
Saville 2047
SBR 2034
Schaub Lorenz 2036
Schneider 2033, 2034
Scott 2015
Sears 2007, 2010, 2013, 2021
SEG 2043
SEI 2028, 2034
Sharp 2016, 2017, 2031
Shintom 2004, 2033, 2036
Shorai 2028
Siemens 2034, 2036, 2039
Singer 2010
Sinudyne 2028, 2034
Sonolor 2030, 2031
Sony 2004, 2018, 2024
STS 2010, 2021
Sunkai 2046
Sylvania 2010, 2011, 2012, 2014
Symphonic 2012
Tandy 2007
Tatung 2034
Teac 2012
Technics 2010, 2042
Teknika 2010, 2012
Telefunken 2048
Thomson 2048
Thorn 2035, 2036
Toshiba
Totevision 2008
Uher 2043
Unitech 2008
Universum 2034, 2039, 2043
Vector Research 2005, 2006
Video Concepts 2005, 2006, 2022
Wards
XR-1000 2010, 2012
Yamaha 2005, 2006, 2007, 2009
Yo ko 2043
Zenith 2004, 2019, 2024
2001, 2002, 2003, 2008, 2010, 2013, 2021, 2023, 2025, 2026, 2027
2007, 2008, 2010, 2011, 2012, 2017
2013, 2015, 2022, 2034, 2048
2008, 2010, 2012, 2013, 2017, 2021, 2027
TV
Manufacturer Control code
Admiral 1026, 1040, 1062
Akai 1002, 1067
Akura 1045
Alba 1035, 1043
Amplivision 1063
Amstrad 1035, 1067
Amtron 1009
Anam National 1003, 1009
Anitech 1035
AOC 1004, 1005, 1006
Arc en Ciel 1066
Arcam 1063
ASA 1040
Audiovox 1009
Autovox 1040, 1068
Baird 1069
Bang & Olufsen 1040
Baur
Beko 1052
Bell & Howell 1010, 1017
Binatone 1063
Blaupunkt
Boots 1063
Brionvega 1040
Bruns 1040
BSR 1048
Bush
Cascade 1035
Celebrity 1002
Century 1040
Cimline 1035, 1043
Citizen
Clatronic 1052
Colortyme 1004, 1006
Condor 1052
Contec 1035
Contec/Cony 1007, 1009
Continental Edison 1066
Craig 1009
Crosley 1040
Crown 1009, 1014, 1035, 1052
Curtis Mathes
Daewoo
Daytron 1004, 1006, 1025, 1035
Decca 1067
Dimensia 1001, 1034
Dixi 1035
Dual 1057, 1068
Dumont 1004, 1039, 1040
Electroband 1002
Electrohome
Elta 1035
1036, 1054, 1055, 1058, 1059, 1068
1041, 1042, 1044, 1058, 1059
1035, 1043, 1048, 1050, 1053, 1057
1004, 1006, 1009, 1017, 1022, 1025
1001, 1004, 1006, 1010, 1017, 1022, 1025, 1034
1004, 1005, 1006, 1025, 1035, 1053
1002, 1003, 1004, 1006, 1008
TV
Manufacturer Control code
Emerson
Envision 1004, 1006
Erres 1037
Europhon 1067
Fidelity 1068
Finlux 1039, 1040, 1067
Firstline
Fisher
Formenti 1040
Frontech 1045, 1062
Fujitsu 1070
Funai 1009, 1045, 1048, 1070
GE
GEC 1038, 1063, 1067, 1069
Geloso 1035
Genexxa 1062
GoldStar
Goodmans 1043, 1053, 1063
Gorenje 1052
Graetz 1062, 1069
Granada 1063, 1067
Grundig
Hallmark 1004, 1006
Hanseatic 1060, 1068
Hantarex 1067
HCM 1035
Hinari 1035, 1043
Hitachi
Huanyu 1053
ICE 1045, 1063
Imperial 1052
Infinity 1014
Inno Hit 1056, 1067
Interfunk 1055, 1062, 1066, 1069
Intervision 1045, 1063
ITT 1062, 1068, 1069
JBL 1014
JC Penney
Jensen 1004, 1006
JVC
Kaisui 1035, 1063
Kapsch 1062, 1069
Kathrein 1060
Kawasho 1002, 1004, 1006
Kendo 1043
Kenwood 1004, 1006, 1008
Kloss Novabeam 1009
Kor ting 1040
KTV 1009, 1025
LG 1005
1004, 1006, 1007, 1009, 1010, 1017, 1025, 1027, 1029, 1033, 1040, 1070
1035, 1043, 1048, 1049, 1063
1010, 1017, 1052, 1063, 1068
1001, 1003, 1004, 1006, 1011, 1012, 1019, 1034
1004, 1005, 1006, 1007, 1008, 1025, 1047, 1063
1039, 1041, 1042, 1058, 1059, 1064
1004, 1006, 1007, 1013, 1027, 1038, 1062, 1063, 1069
1001, 1004, 1005, 1006, 1011, 1012, 1016, 1019, 1022, 1025, 1034
1007, 1012, 1013, 1015, 1033
73
Controlling Other Components
—Continued
TV
Manufacturer Control code
Loewe 1014, 1040, 1055
Luxman 1004, 1006
LXI
M Electronic 1035, 1053, 1062, 1063
Magnadyne 1040, 1067, 1068
Magnafon 1067
Magnavox
Marantz 1004, 1006, 1014, 1060
Matsui
Megatron 1006
Memorex
Metz 1040, 1051, 1058
MGA 1004, 1005, 1006, 1008
Minerva 1039, 1058, 1059, 1064
Mitsubishi
Mivar 1047, 1056, 1067
Motorola 1003, 1026
MTC
Multitech 1009, 1035
NAD 1006, 1016
NEC 1003, 1004, 1005, 1006
Neckermann
Nikkai 1045
Nikko 1006
Oceanic 1062
Onwa 1009
Optonica 1021, 1026
Orion
Osaki 1045, 1063
Otto Versand
Palladium 1052
Panasonic
Pathe Marconi 1066
Philco
Philips
Phoenix 1040
Phonola 1037, 1040
Pioneer 1004, 1006, 1027, 1062
Por tland 1004, 1005, 1006, 1025
Price Club 1022
Prism 1012
Profex 1035
Proline 1049
Proscan 1001, 1034
Protech 1035, 1045, 1063
Proton 1004, 1006, 1007
Pye 1037
1001, 1006, 1010, 1014, 1016, 1017, 1034
1004, 1006, 1008, 1014, 1018, 1020
1035, 1043, 1048, 1050, 1063, 1064, 1067, 1068
1005, 1006, 1010, 1017, 1035
1004, 1005, 1006, 1008, 1040, 1055, 1058
1004, 1005, 1006, 1022, 1055
1040, 1041, 1054, 1059, 1060
1029, 1043, 1048, 1049, 1050, 1067, 1068
1036, 1041, 1043, 1054, 1055, 1058, 1059, 1060, 1063
1003, 1012, 1014, 1031, 1044, 1046, 1051, 1061, 1062, 1069
1003, 1004, 1005, 1006, 1007, 1008, 1014, 1018, 1040
1003, 1004, 1007, 1008, 1014, 1018, 1019, 1020, 1037, 1038, 1040, 1053, 1059, 1060
74
TV
Manufacturer Control code
Quasar 1003, 1012, 1031
Quelle
Radio Shack 1010, 1017, 1034
Radio Shack/ Realistic
Radiola 1037
Radiomarelli 1040, 1067
RCA
Realistic 1010, 1017, 1034
Rex 1045, 1062
RFT 1040
Roadstar 1035, 1045
Saba 1040, 1062, 1066, 1069
Saisho
Salora 1062
Sambers 1056, 1067
Sampo 1004, 1006, 1025
Samsung
Sansui 1029
Sanyo 1004, 1010, 1017
SBR 1037, 1038
Schaub Lorenz 1069
Schneider 1068
Scott
Sears
SEG 1045, 1063
SEI
Seleco 1062
Sharp
Shorai 1048
Siarem 1040, 1067
Siemens 1041, 1042, 1058, 1059
Singer 1040
Sinudyne
Solavox 1062
Sonoko 1035
Sonolor 1062
Sony
Soundesign 1004, 1006, 1009, 1070
Starlite 1009
Stern 1062
Sunkai 1043, 1048, 1049, 1050
Sylvania
Symphonic 1009, 1028
Tandy 1026, 1062, 1063
Tashiko 1038, 1063
Tatung 1003, 1063, 1067
Te c 1063
1036, 1039, 1054, 1055, 1058, 1059, 1068
1001, 1004, 1006, 1007, 1009, 1010, 1017, 1021, 1025
1001, 1003, 1004, 1005, 1006, 1008, 1027, 1034
1035, 1043, 1045, 1067, 1068
1004, 1005, 1006, 1007, 1008, 1022, 1025, 1035, 1045, 1047, 1052, 1056, 1060, 1063, 1065
1004, 1006, 1007, 1009, 1070
1001, 1004, 1006, 1008, 1010, 1015, 1016, 1017, 1028, 1034, 1070
1036, 1040, 1048, 1067, 1068
1004, 1006, 1007, 1021, 1023, 1025, 1026
1036, 1040, 1043, 1067, 1068
1002, 1030, 1032, 1036, 1054
1004, 1006, 1008, 1014, 1018, 1020
TV
Manufacturer Control code
Technics 1012, 1044, 1061
Techwood 1004, 1006, 1012
Teknika
Teleavia 1066
Telecaption 1024
Telefunken 1066
Teletech 1035
Teleton 1063
Tensai 1048
Thomson 1066
Thorn 1054, 1055, 1058
Toshiba
Totevision 1025
Tr iumph 1067
Universal 1011, 1019
Universum 1045, 1052, 1058
Voxson 1040, 1062
Waltham 1063
Wards
Watt Radio 1068
Wega 1040
Ya maha 1004, 1005, 1006, 1008
Yo ko 1045, 1063
Zenith 1004
1004, 1005, 1006, 1007, 1009, 1022, 1025, 1031, 1070
1010, 1016, 1017, 1022, 1024, 1039
1001, 1004, 1005, 1006, 1008, 1011, 1014, 1018, 1019, 1020, 1021, 1034, 1070
Controlling Other Components
—Continued
To control another component, point the remote control­ler at it and use the buttons as explained below (you must select the appropriate remote control mode first).
Controlling a TV
Standby
On
Number
buttons
Press [TV]
first
CH
[On], [Standby]
TV [ ]
Number buttons
[CH +/–]
[TV INPUT]
VOL [ ]/[ ]
On Standby
V1 V2 V 3
123
456
CD Tape
789
+
10 0
--/---
123
Receiver
Tape
Dimmer
TV Input
+
CH
Disc
-
Prev CH
Display Muting
Surround
Test Tone
Multi CH
Input Selector
Macro
Remote Mode
DVD
M
p
o
T
E
R
e
t
u
Direct
CH SEL
Video OffOpen/Close
RC
TV
I
Input
+
TV CH
DVD
-
Tuner
TV VOL
Clear
Zone 2
CD
MD/CDR
SATTV VCR Cable
Sleep
M
u
n
e
e
n
u
Enter
VOL
e
d
i
x
i
u
t
G
p
u
t
r
e
n
S
RandomRec
Last Memory
AngleSubtitleAudio
StereoAll ST
MemorySearchA-BRepeat
DSP DSP
-
Level+Level
Cine Fltr
L Night
-
587M
Set the TV to On or Standby
Tu rn the TV on or off
Enter numbers
Select channels on the TV
Select inputs on the TV
Adjust the TV’s volume
*
TV TV Input
TV CH +/–
TV VOL
VOL
*
*
*
Controlling a Cable Receiver
Standby
On
Number
buttons
CH
[On], [Standby]
[CH +/–]
Number buttons
The following buttons control the AV Receiver. [VOL]: Adjusts the volume of the AV receiver. [Muting]: Mutes the AV Receiver.
On Standby
V1 V2 V 3
123
456
CD Tape
789
+
10 0
--/---
123
Receiver
Tape
Dimmer
TV Input
+
CH
Disc
-
Prev CH
Display Muting
Surround
Test Tone
Multi CH
Input Selector
Macro
Remote Mode
DVD
e
M
p
o
T
E
x
R
e
t
u
r
Direct
CH SEL
Video OffOpen/Close
RC
TV
I
Input
+
TV CH
DVD
-
Tuner
TV VOL
Clear
Zone 2
CD
MD/CDR
SATTV VCR Cable
M
u
n
e
n
u
Enter
VOL
e
d
i
i
u
t
G
p
u
t
e
n
S
RandomRec
Last Memory
AngleSubtitleAudio
StereoAll ST
MemorySearchA-BRepeat
DSP DSP
-
Level+Level
Cine Fltr
L Night
-
587M
Press [CABLE] first
Sleep
Set the cable receiver to On or Standby
Select cable channels
Enter numbers
Buttons marked with an asterisk can always be used to
*
control a TV regardless of the currently selected remote controller mode.
The following buttons control the AV Receiver. [VOL]: Adjusts the volume of the AV receiver. [Muting]: Mutes the AV Receiver.
75
Controlling Other Components
—Continued
Controlling a VCR
Standby
On
Press
[VCR] first
CH
Rec
Dimmer
TV Input
Prev CH
Display Muting
On Standby
I
V1 V2 V 3
123
DVD
Multi CH
456
CD Tape
Tuner
789
Clear
+
10 0
--/---
Input Selector
Macro
123
Remote Mode
Receiver
DVD
CD
Tape
M
u
n
e
M
p
o
T
+
CH
Enter
Disc
-
E
x
i
u
t
G
R
e
t
u
r
n
S
AngleSubtitleAudio
Surround
Direct
DSP DSP
Test Tone
CH SEL
Video OffOpen/Close
L Night
-
RC
587M
Controlling a Satellite Receiver
TV
Input
+
TV CH
-
TV VOL
Zone 2
MD/CDR
SATTV VCR Cable
Sleep
e
n
u
VOL
e
d
i
p
u
t
e
-
RandomRec
Last Memory
StereoAll ST
MemorySearchA-BRepeat
Level+Level
Cine Fltr
,
Sdandby
On
Number
buttons
Enter
CH
On Standby
V1 V2 V 3
CD Tape
+
--/---
123
Receiver
Tape
Dimmer
TV Input
+
CH
Disc
-
Prev CH
Display Muting
Surround
Test Tone
I
123
DVD
Multi CH
456
Tuner
789
Clear
10 0
Input Selector
Macro
Remote Mode
DVD
CD
M
u
n
e
e
n
M
u
p
o
T
Enter
e
E
d
i
x
i
u
t
G
R
e
p
t
u
u
t
r
e
n
S
AngleSubtitleAudio
Direct
DSP DSP
-
CH SEL
Video OffOpen/Close
L Night
-
RC
587M
TV
TV CH
TV VOL
RandomRec
Last Memory
StereoAll ST
MemorySearchA-BRepeat
Level+Level
Cine Fltr
Input
+
-
Zone 2
MD/CDR
SATTV VCR Cable
Sleep
VOL
Press [SAT] first
[On], [Standby]
[CH +/–]
[]
[]
[]
[]
[]
REC [ ]
Set the VCR to On or Standby
Selects channels on the VCR
Play
Stop
Rewind
Fast forward
Pause
Record
The following buttons control the AV Receiver. [VOL]: Adjusts the volume of the AV receiver. [Muting]: Mutes the AV Receiver.
[On], [Standby]
[CH +/–]
[ ]/[ ]/[ ]/[ ]
[Enter]
Number buttons
Set the satellite receiver to On or Standby
Select satellite channels
Select menu items
Confirm selection
Enter numbers
The following buttons control the AV Receiver. [VOL]: Adjusts the volume of the AV receiver. [Muting]: Mutes the AV Receiver.
76
Controlling Other Components
—Continued
Learning Commands from Another Remote Controller
The AV receiver’s remote controller can learn the com­mands of other remote controllers simply by pointing them at each other. For example, by transmitting the Play command from your CD player’s remote controller, the remote controller can learn it and then transmit the same command when its Play [ ] button is pressed in CD mode.
This is convenient when you want to add commands to buttons after entering a remote control code (page 69).
1
Receiver
Tape
2
1, 4
Remote Mode
DVD
On
On Standby
V1 V2 V3
123
456
CD Tape
789
+
10 0
--/---
Input Selector
123
Receiver
Dimmer
TV Input
Tape
1
+
CH
Disc
-
Prev CH
While holding down the Remote Mode button that you want to
CD
MD/CDR
learn the command, press the
SATTV VCR Cable
[On] button.
On the AV receiver’s remote con­troller, press the button you want to learn the new command.
Multi CH
Macro
Remote Mode
DVD
n
e
M
p
o
T
E
x
i
t
R
e
t
u
r
n
TV
I
Input
+
TV CH
DVD
-
Tuner
TV VOL
Clear
Zone 2
CD
MD/CDR
SATTV VCR Cable
Sleep
M
u
e
n
u
Enter
VOL
e
d
i
u
G
p
u
t
e
S
3
Point the remote controllers at each other, about 2 to 6 inches (5–15 cm) apart, and then, on the other remote controller, press the button whose command you want to learn.
About 2 to 6 inches (5–15 cm
RC-587M
4
To teach the AV receiver’s remote controller more new commands, repeat steps 2 and 3.
Press the [On] button when you’ve fin­ished.
Notes:
• The following buttons cannot be taught new com­mands: Remote Mode, Macro [1], [2], [3], TV [ ], TV [Input], TV CH [+]/[–], TV VOL [ ]/[ ].
• The AV receiver’s remote controller can learn up to approximately 150 commands. However, the com­mands of some remote controllers may use a lot of memory, in which case, this will be reduced.
• By default, the AV receiver’s remote controller knows the commands for controlling an Integra CD player, cassette deck, DVD player, and MD player (e.g., Play, Stop, Pause, etc., buttons). These buttons can learn new commands, although the defaults will be restored if the remote controller is reset.
•To learn a new command for a button that has already learned one, simply repeat this procedure.
• Like most remote controllers, the AV receiver’s remote controller uses infrared. Commands from remote controllers that don’t use infrared cannot be learnt.
• When the remote controller’s batteries expire, all learned commands will be lost and will have to be learned all over again, so don’t discard your other remote controllers.
77
Controlling Other Components
—Continued
Using Macros
With the Macro function, you can program the remote controller’s Macro buttons to perform a sequence of actions with just one button press. For example, nor­mally you need to perform the following actions to play a CD:
1. Press the Remote Mode
[[[[RRRReeeecccceeeeiiiivvvveeeerrrr]]]]bbbbuuuuttttttttoooonnnn
select Receiver mode.
2. Press the [On] button to turn on the AV receiver.
3. Press the [CD] Input Selector button to select the CD input source.
4. Press the Remote Mode [CD] button to select the CD remote controller mode.
5. Press the Play [ ] button to start playback on the CD player.
With the Macro function, you can program one of the Macro buttons to perform all five actions in one go.
Making Macros
There are three Macro buttons, and each button can be programmed with a different macro in each remote con­troller mode. Each macro can perform up to eight actions.
1
1
Dimmer
TV Input
Prev CH
Display Muting
On Standby
V1 V2 V3
123
456
CD Tape
789
+
10 0
--/---
Input Selector
123
Receiver
Tape
+
CH
Disc
-
Multi CH
Macro
Remote Mode
DVD
u
n
e
M
p
o
T
E
x
i
t
R
e
t
u
r
n
TV
I
Input
+
TV CH
DVD
-
Tuner
TV VOL
Clear
Zone 2
CD
MD/CDR
SATTV VCR Cable
Sleep
M
e
n
u
Enter
VOL
e
d
i
u
G
p
u
t
e
S
to
2
On the remote controller, press the buttons whose actions you want to program into the macro in the order you want them per­formed.
For example, to program the previous CD example into a macro, press the fol­lowing buttons: Remote Mode [Receiver], [On], Input Selector [CD], Remote Mode [CD], Play [ ].
3
When you’ve finished, press the Macro button again.
Notes:
• If after programming a macro you teach one of the buttons in that macro a new command, then the macro will no longer work properly. In this case, you must program the macro again.
Running Macros
Programmed macros can be run as follows.
1
Press the Macro [1], [2], or [3] button.
The actions in the macro are performed in the order in which they were pro­grammed.
78
1
Remote Mode
Receiver
DVD
CD
Tape
123
MD/CDR
Macro
While holding down the Remote Mode button for the mode that you want to learn the macro,
SATTV VCR Cable
press Macro button [1], [2], or [3].
The Remote indicator lights up.
Troubleshooting
If you have any trouble using the AV receiver, look for a solution in this section. If you can’t resolve the issue yourself, contact the dealer from whom you purchased this unit.
Power
Can’t turn on the AV receiver?
• Make sure that the power cord is properly plugged into the wall outlet.
• Unplug the power cord from the wall outlet, wait five seconds or more, then plug it in again.
The AV receiver turns off as soon as it’s turned on?
• The amp protection circuit has been activated. Remove the power cord from the wall outlet immedi­ately and contact the dealer from whom you purchased this unit.
Audio
There’s no sound, or it’s very quiet?
• Make sure that all audio connecting plugs are pushed in all the way (page 20).
• Make sure that the inputs and outputs of all compo­nents are connected properly (page 20).
• Make sure that the polarity of the speaker cables is correct, and that the bare wires are in contact with metal part of each speaker terminal (page 22)
• Make sure that the input source is properly selected (page 44).
• Make sure that the speaker cables are not shorting.
• Check the volume. It can be set to MIN, 1 through 99, or MAX (page 44). The AV receiver is designed for home theater enjoyment. It has a wide volume range, allowing precise adjustment.
• If the MUTING indicator is shown on the display, press the remote controller’s [Muting] button to unmute the AV receiver (page 45).
• While a pair of headphones is connected to the Phones jack, no sound is output by the speakers (page 45).
• Check the digital audio output setting on the con­nected device. On some games consoles, such as those that support DVD, the default setting is off.
•With some DVD-Video discs, you need to select an audio output format from a menu.
• If your turntable doesn’t have a built-in phono preamp, you must connect one between it and the AV receiver. If your turntable uses an MC cartridge, you must con­nect an MC head amp, or an MC transformer and phono equalizer.
• Make sure that none of the connecting cables are bent, twisted, or damaged.
• Not all listening modes use all speakers (page 51).
• Specify the speaker distances (page 41) and adjust the individual speaker levels (page 42).
• Make sure that the speaker setup microphone is not still connected.
Only the front speakers produce sound?
• When the Stereo listening mode is selected, only the front speakers and subwoofer produce sound.
• When the Direct listening mode is selected, only the front speakers produce sound.
• Make sure the speakers are configured correctly (page 39).
Only the center speaker produces sound?
• If you use the Pro Logic II Movie or Pro Logic II Music listening mode with a mono source, such as an AM radio station or mono TV program, the sound is concentrated in the center speaker.
• Make sure the speakers are configured correctly (page 39).
The surround speakers produce no sound?
• When the Stereo or Direct, listening mode is selected, the surround speakers produce no sound (page 51).
• Depending on the source and current listening mode, not much sound may be produced by the surround speakers. Try selecting another listening mode.
• Make sure the speakers are configured correctly (page 39).
The center speaker produces no sound?
• When the Mono, Stereo, Direct, or Orchestra listening mode is selected, the center speaker produces no sound (page 51).
• Make sure the speakers are configured correctly (page 39).
79
Troubleshooting
—Continued
The subwoofer produces no sound?
• When you play source material that contains no infor­mation in the LFE channel, the subwoofer produces no sound.
• Make sure the speakers are configured correctly (page 39).
There’s no sound with a certain signal format?
• Check the digital audio output setting on the con­nected device. On some games consoles, such as those that support DVD, the default setting is off.
•With some DVD-Video discs, you need to select an audio output format from a menu.
• Depending on the input signal, some listening modes cannot be selected (page 50).
Can’t get 5.1 playback?
• If the Zone 2 speakers are being used, you can use ste­reo sound in the main room.
The volume cannot be set to 99?
• When the levels of all speakers have been calibrated (page 42), the maximum volume setting may change.
Noise can be heard?
• Using cable ties to bundle audio cables with power cords, speaker cables, and so on may degrade the audio performance, so don’t do it.
• An audio cable may be picking up interference. Try repositioning your cables.
The Late Night function doesn’t work?
• Make sure the source material is Dolby Digital (page 52).
The DVD analog multichannel input doesn’t work?
• Check the DVD analog multichannel input connec­tions (page 28).
•To select the DVD analog multichannel input, press the [Multi CH] input selector button.
• Check the audio output settings on your DVD player.
About DTS signals
• When DTS program material ends and the DTS bit­stream stops, the AV receiver remains in DTS listen­ing mode and the DTS indicator remains on. This is to prevent noise when you use the pause, fast forward, or fast reverse function on your player. If you switch your player from DTS to PCM, because the AV receiver does not switch formats immediately, you may not hear any sound, in which case you should stop your player for about three seconds, and then resume play­back.
•With some CD and LD players, you won’t be able to playback DTS material properly even though your player is connected to a digital input on the AV receiver. This is usually because the DTS bitstream has been processed (e.g., output level, sampling rate, or frequency response changed) and the AV receiver doesn’t recognize it as a genuine DTS signal. In such cases, you may hear noise.
• When playing DTS program material, using the pause, fast forward, or fast reverse function on your player may produce a short audible noise. This is not a mal­function.
Video
There’s no picture?
• Make sure that all video connecting plugs are pushed in all the way (page 20).
• Make sure that each video component is properly con­nected.
• If your video component is connected to a component video input, your TV must be connected to the compo­nent video output (page 25).
• On your TV, make sure that the video input to which the AV receiver is connected is selected.
The onscreen menus don’t appear?
• Make sure that the video settings are correct (page 38).
• On your TV, make sure that the video input to which the AV receiver is connected is selected.
• Depending on the display device, when the “b. Scan Mode” setting on the “6-3. OSD Setup” menu is set to Non-Interlaced, the onscreen setup menus may not appear. If this happens, use the AV receiver’s display and change that setting to Interlaced.
80
Troubleshooting
—Continued
Tuner
Reception is noisy, FM stereo reception is noisy, or the FM STEREO indicator doesn’t appear?
• Relocate your antenna.
•Move the AV receiver away from your TV or com­puter.
• Listen to the station in mono (page 47).
• When listening to an AM station, operating the remote controller may cause noise.
•Passing cars and airplanes can cause interference.
• Concrete walls weaken radio signals.
• If nothing improves the reception, install an outdoor antenna.
Remote Controller
The remote controller doesn’t work?
• Make sure that the batteries are installed with the cor­rect polarity (page 18).
• Install new batteries. Don’t mix different types of bat­teries, or old and new batteries (page 18).
• Make sure that the remote controller is not too far away from the AV receiver, and that there’s no obstruction between the remote controller and the AV receiver’s remote control sensor (page 18).
• Make sure that the AV receiver is not subjected to direct sunshine or inverter-type fluorescent lights. Relocate if necessary.
• If the AV receiver is installed in a rack or cabinet with colored-glass doors, the remote controller may not work reliably when the doors are closed.
• Make sure you’ve selected the correct remote control­ler mode (page 12).
• When using the remote controller to control other manufacturers’ AV components, some buttons may not work as expected.
• Make sure you’ve entered the correct remote control code.
Can’t control other components?
• If it’s an Integra component, make sure that the cable and analog audio cable are connected properly. Connecting only an cable won’t work (page 34).
• Make sure you’ve selected the correct remote control­ler mode (page 12).
• If you connect an MD recorder or CD recorder to the TAPE jacks, be sure to set make the necessary setting (pages 43 and 69).
• When learning commands, make sure that the trans­mitting ends of both remote controllers are pointing at each other.
• Are you trying to learn from a remote controller that cannot be used for learning? Some commands cannot be learnt, especially those that transmit several instructions with a single button press.
• The wrong remote control code has been entered.
• The entered remote control code may not be correct. If more than one code is listed, try each one.
•With some AV components, certain buttons may not work as expected, and some may not work at all.
•To control Integra components, point the remote con­troller at the AV receiver.
•To control another manufacturer’s component, point the remote controller at that component.
Recording
Can’t record?
• On your recorder, make sure the correct input is selected (e.g., digital or analog).
Zone 2
Zone 2 has turned off?
•Was the Sleep function set? The Sleep function turns off Zone 2 as well as the AV receiver. To set the Sleep function for Zone 2 only, see page 66.
There’s no sound?
• Since the Zone 2 function and the REC OUT outputs use the same circuitry, you cannot use Zone 2 and record at the same time. When the [Rec Out] button is pressed, Zone 2 is turned off.
• Only components connected to analog inputs can be played in Zone 2.
81
Troubleshooting
—Continued
Others
The sound changes when I connect my head­phones?
• When a pair of headphones is connected, the listening mode is set to Stereo, unless it’s already set to Stereo or Direct. When you disconnect the headphones, the previous listening mode will be resumed.
The speaker volume cannot be set as required?
• When the volume is adjusted on the onscreen setup menus, the maximum possible volume setting may change.
The speaker distance cannot be set as required?
• In some cases, corrected values suitable for home the­ater use may be set automatically.
The display doesn’t work?
• Actions are not displayed on the TV or projector that’s connected to the COMPONENT VIDEO OUT.
How do I change the language of a multiplex source?
• Use the “a. Input Channel” setting on the “3-5. Multi­plex” menu to select Main or Sub (page 57).
The AV receiver contains a microcomputer for signal pro­cessing and control functions. In very rare situations, severe interference, noise from an external source, or static electricity may cause it to lockup. In the unlikely event that this happens, unplug the power cord from the wall outlet, wait at least five seconds, and then plug it back in again.
Onkyo is not responsible for damages (such as CD rental fees) due to unsuccessful recordings caused by the unit’s malfunction. Before you record important data, make sure that the material will be recorded cor­rectly.
Resetting the AV receiver to its factory defaults To reset the AV receiver to its factory defaults, turn it on and, while holding down the [VIDEO 1] button, press the [Standby/On] button. “CLEAR” will appear on the display and the AV receiver will enter Standby mode.
The AV receiver uses a battery-less memory backup system in order to retain radio presets and other set­tings when it’s unplugged or in the case of a power fail­ure. Although no batteries are required, the AV receiver must be plugged into an AC outlet in order to charge the backup system.
82
Specifications
Amplifier Section
Power Output (2 channels driven): Dynamic Power 220 W + 220 W (3Ω,Front)
THD (Total Harmonic Distortion) Damping Factor 60 (Front,1kHz,8 Input Sensitivity and Impedance Output Level and Impeadance Frequency Response 10 Hz–100 kHz/ +1 dB-3 dB (Direct
Tone Control ±10 dB, 50 Hz (BASS)
SN Ratio 106 dB (LINEIHF-A) Speaker Impedance 6
85 W + 85 W (8Ω,20Hz–20kHz, FTC)
165 W + 165 W (4 100 W + 100 W (8
0.08 % (Power Rated)
200 mV/ 47 k
200 mV/ 470
mode)
±10 dB, 10 kHz (TREBLE)
– 8
,Front)
,Front)
)
(LINE)
(REC OUT)
Video Section
Input Sensitivity/Output Level and Impedance 1 Vp-p /75
0.7 Vp-p /75
0.28 Vp-p /75
1 Vp-p /75 Component Video Frequency Response 5 Hz – 50 MHz
(Component and S-Video Y)
(Component Pb/Cb,Pr/Cr)
(S-Video C)
(Composite)
Tuner Section
FM
Tuning Frequency Range
Usable Sensitivity Stereo:17.2 dBf 2 µV(75
S/N Ratio Stereo: 70 dB (IHF-A)
THD Stereo: 0.3 % (1kHz)
Frequency Response 30 Hz–15 kHz / ±1 dB Stereo Separation 45 dB ( 1kHz )
AM
Tuning Frequency Range
Usable Sensitivity 30 µV S/N Ratio 40 dB THD 0.70%
87.5 MHz– 107.9 MHz
Mono: 11.2 dBf 1 µV(75
Mono:76 dB (IHF-A)
Mono:0.2 % (1kHz)
530 kHz–1700 kHz
Ω Ω
IHF)
IHF)
General
Power Supply AC 120 V, 60 Hz Power Comsumption 5.7A Stand-by Power Comsumption 1.0 W Dimensions(W x H x D) 17-1/8" W x 6-7/8" H x 16-7/8" D inches Weight 27.6 lbs
Video Inputs
Component Video Input 1,2,3 S-Video Compatible Jack Input DVD,VIDEO1,VIDEO2,VIDEO3 A/V Input DVD,VIDEO1,VIDEO2,VIDEO3
Video Outputs
Component Video Output OUT S-Video Compatible Jack Output MONITOR OUT,VIDEO1,VIDEO2 A/V Output MONITOR OUT,VIDEO1,VIDEO2
Audio Inputs
Digital Inputs Optical : 2
Analog Inputs DVD(MULTICHANNEL),VIDEO1,
Multichannel Inputs 6
Audio Outputs
Digital Outputs 1 (Optical) Analog Outputs TAPE,VIDEO1,VIDEO2 Subwoofer Pre Outputs 1 Speaker Outputs 7 Phones 1
Other Jacks
RS-232 Control 1 IR Input/Output 1 12V Trigger Out 3
Specifications and features are subject to change without notice.
Coaxial : 2
VIDEO2,VIDEO3,TAPE,CD
83
Integra Division of
ONKYO U.S.A. CORPORATION
18 park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 http://www.integrahometheater.com
Integra Division of
ONKYO CORPORATION
Sales & Product Planning Div.: 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8023 Fax: 072-831-8124
SN 29343826
(C) Copyright 2004 ONKYO CORPORATION Japan. All rights reserved.
84
En
I0408-1
* 2 9 3 4 3 8 2 6 *
Loading...
