HP ZBook Studio G7 Datasheet

Datasheet

HP ZBook Studio G7 Mobile Workstation

The new standard for the serious creator

Real-time rendering. Sleek design. An impressive combination of power and size. Ready for a workflow revolution? With NVIDIA® Quadro® graphics combined with the remarkable power of Z, pro-grade performance has never looked or felt better.

HP recommends Windows 10 Pro for business

Pro-grade performance. Stable and certified

Powerful performance. Uncompromising reliability. With NVIDIA® Quadro® graphics, universal software certification, 8-core Intel® Xeon® processors and up to 32GB memory, your workforce can render, design, simulate & analyze with complete confidence.

Engineered to go mobile

Introducing HP’s smallest 15" laptop for creators. Our groundbreaking design packs a nearly borderless screen and long-lasting battery life into a lightweight, scratch resistant aluminum frame.

Ingenious design. Revolutionary experience.

Tirelessly re-engineered from the ground up, this is superior design. Vapor chamber cooling and liquid-crystal polymer thermals equip you to run at max performance. Our astonishingly quiet, comfortable keyboard keeps you in the zone.

Work anywhere without compromising on performance or security with Windows 10 Pro, powered by HP’s collaboration and connectivity technology.

Experience high-end visualization and seamlessly render your biggest projects with the next generation NVIDIA® Quadro® T-Series and RTX graphics; Certified and supported for the apps you use every day.

Take multitasking to the next level with up to the 10th gen Intel® Core™ i9 or Intel® Xeon® processor designed to handle complex, multi-threaded apps like Adobe Premier Pro®, and boost your speed on single threaded apps like Autodesk 3ds Max.

Power through projects with up to 32 GB RAM for fast rendering, editing and simulating. Blitz through multiple tasks and ditch external drives with up to 2 TB local NVMe storage. Speakers custom tuned by Bang and Olufsen surround you in a rich sound space so you hear music

the way the audio engineers intended. Featuring the most powerful speakers with the greatest levels of bass on any HP notebook.

Connect to everything you need with a wide-range of connectivity options: Dual USB-C® Thunderbolt™, HDMI or Mini DisplayPort™, USB 3.0 charging port, headphone jack, and AC port.

A completely revamped standby system means you're ready to work the moment inspiration strikes. With no sleep mode and no off mode, the modern standby keeps your rig connected and on demand whenever you need it.

Transfer files over Wi-Fi® up to 3x faster with Wi-Fi 6. Instantly protect against visual hacking with HP Sure View Reflect, and defend against firmware and

malware attacks with HP Sure Start Gen6 and HP Sure Sense. A highly recyclable & lightweight aluminum exterior with 5x the abrasion resistance of painted

carbon fiber allows for a more durable, thin, and recyclable device. Our ZBook Studio G7 was designed to undergo extensive testing, and has passed 21 of the MIL-STD

810H Test

7,8

10,11

13,14,15

Data sheet | HP ZBook Studio G7 Mobile Workstation

HP recommends Windows 10 Pro for business

HP ZBook Studio G7 Mobile Workstation Specifications Table

Available Operating Systems

Windows 10 Pro 64 – HP recommends Windows 10 Pro for business Windows 10 Home 64 Windows 10 Pro for Workstations 64 Ubuntu 20.04 FreeDOS 3.0

Processor family

10th Generation Intel® Core™ i5 processor; 10th Generation Intel® Core™ i7 processor; 10th Generation Intel® Core™ i9 processor; 10th Generation Intel® Xeon® processor

Available Processors

Intel® Core™ i7-10750H with Intel® UHD Graphics (2.6 GHz base frequency, up to 5.0 GHz with Intel® Turbo Boost Technology, 12 MB L3 cache, 6 cores); Intel® Core™ i5-10400H with Intel® UHD Graphics (2.6 GHz base frequency, up to 4.6 GHz with Intel® Turbo Boost Technology, 8 MB L3 cache, 4 cores), supports Intel® vPro® Technology; Intel® Core™ i7-10850H with Intel® UHD Graphics (2.7 GHz base frequency, up to 5.1 GHz with Intel® Turbo Boost Technology, 12 MB L3 cache, 6 cores), supports Intel® vPro® Technology; Intel® Core™ i9-10885H with Intel® UHD Graphics (2.4 GHz base frequency, up to 5.3 GHz with Intel® Turbo Boost Technology, 16 MB L3 cache, 8 cores), supports Intel® vPro® Technology; Intel® Xeon® W-10885M with Intel® UHD Graphics (2.4 GHz base frequency, up to 5.3 GHz with Intel® Turbo Boost Technology, 16 MB L3 cache, 8 cores), supports Intel® vPro® technology

Maximum memory

32 GB DDR4-2933 non-ECC SDRAM Memory soldered down. Supports dual channel memory.

Internal storage

256 GB up to 2 TB PCIe® Gen 3 x 4 NVMe™ M.2 SSD up to 512 GB PCIe® NVMe™ M.2 SED SSD

Display size (diagonal, metric) 39.6 cm (15.6")

Display

39.6 cm (15.6") diagonal, FHD (1920 x 1080), IPS, anti-glare, 400 nits, low power, 72% NTSC; 39.6 cm (15.6") diagonal, FHD (1920 x

1080), IPS, anti-glare, 1000 nits, 72% NTSC, HP Sure View Reflect integrated privacy screen; 39.6 cm (15.6") diagonal, 4K UHD (3840 x

2160), IPS, anti-glare, 600 nits, HDR 400, 100% DCI-P3, Next Gen HP DreamColor; 39.6 cm (15.6") diagonal, 4K UHD (3840 x 2160), touch, UWVA, BrightView, Corning® Gorilla® Glass 6, 400 nits, HDR 500, 100% DCI-P3

Available Graphics

Integrated: Intel® UHD Graphics Discrete: NVIDIA® Quadro® T1000 with Max-Q Design (4 GB GDDR6 dedicated); NVIDIA® Quadro® T2000 with Max-Q Design (4 GB GDDR6 dedicated); NVIDIA® Quadro RTX™ 3000 with Max-Q Design (6 GB GDDR6 dedicated); NVIDIA® Quadro RTX™ 4000 with Max-Q Design (8 GB GDDR6 dedicated); NVIDIA® Quadro RTX™ 5000 with Max-Q Design (16 GB GDDR6 dedicated)

Audio

Audio by Bang & Olufsen, stereo speakers (2 tweeters & 2 woofers), HP World Facing Microphone dual array digital microphones, functions keys for volume up and down, combo microphone/headphone jack, HD audio with 150Hz Bass Roll off

Expansion slots 1 SD 4.0 media card reader (SD 4.0 supports next generation secure digital and is compatible to SD, SDHC, SDXC media)

Ports and Connectors

Right side: 1 power connector; 1 HDMI or 1 Mini DisplayPort™; 2 SuperSpeed USB Type-C® 10Gbps signaling rate Left side: 1 headphone/microphone combo; 1 SuperSpeed USB Type-A 5Gbps signaling rate (charging)

Input devices

HP Z Command Keyboard – spill-resistant, full-size, backlit keyboard with drain and DuraKeys; HP Premium Quiet Keyboard – spillresistant, full-size, backlit keyboard with drain and DuraKeys ;

Communications WLAN: Intel® Wi-Fi 6 AX201 (2x2) and Bluetooth® 5 combo, vPro™; Intel® Wi-Fi 6 AX201 (2x2) and Bluetooth® 5 combo, non-vPro™ ;

Camera 720p HD with Temporal Noise Reduction webcam with IR

Software

Bing search for IE11; Buy Office; HP Hotkey Support; HP Noise Cancellation Software; HP Performance Advisor; Native Miracast support; HP Connection Optimizer; HP ZCentral Remote Boost Software

Security management

Absolute persistence module; HP Device Access Manager; HP Power On Authentication; Trusted Platform Module TPM 2.0 Embedded Security Chip; Master Boot Record security; Pre-boot authentication; Microsoft Security Defender; HP Sure Click; HP Secure Erase; HP Manageability Integration Kit; HP Sure Sense; HP Sure Recover Gen3; HP BIOSphere Gen6; HP Sure Start Gen6; HP Sure Run Gen3; HP Sure Admin; HP Image Assistant; HP Client Security Manager Gen6; MS Bitlocker Encryption; HP Proactive Security; Nano Security Lock Slot

Fingerprint reader Fingerprint reader (select models)

Power HP Smart 150 W External AC Power Adapter; HP Slim Smart 200 W External AC Power Adapter

Battery type HP Long Life 6-cell, 83 Wh Li-ion polymer

Battery life Up to 18 hours

Battery recharge time Supports battery HP fast charge: approximately 50% in 30 minutes

Dimensions 35.4 x 23.46 x 1.79 cm (non-touch); 35.4 x 23.46 x 1.75 cm (touch)

Weight Starting at 1.74 kg (Weight varies by configuration and components.)

Energy efficiency compliance ENERGY STAR® certified and EPEAT® Gold registered configurations available

Sustainable impact specifications Low halogen

Warranty 3 year (3-3-0) limited warranty and service offering includes 3 years of parts and labor. Terms and conditions vary by country.



1,47

2,3,4,5,6,49

8,9

10,50

15,25,26,27,28,29

15,18,19,20,21,22

12,13,21,22

11,52

12,13,52,54

14,55

16,17

30,31,32,33

34,35,36,37,38,39,40,41,42,43

45, 53
