HP ZBook 15 G2 Mobile Workstation
Maintenance and Service Guide
© Copyright 2014 Hewlett-Packard
Development Company, L.P.
Bluetooth is a trademark owned by its
proprietor and used by Hewlett-Packard
Company under license. Intel and Core are U.S.
registered trademarks of Intel Corporation.
Microsoft and Windows are U.S. registered
trademarks of Microsoft Corporation. SD Logo
is a trademark of its proprietor.
The information contained herein is subject to
change without notice. The only warranties for
HP products and services are set forth in the
express warranty statements accompanying
such products and services. Nothing herein
should be construed as constituting an
additional warranty. HP shall not be liable for
technical or editorial errors or omissions
contained herein.
First Edition: September 2014
Document Part number: 768562-001
Product notice
This guide describes features that are common
to most models. Some features may not be
available on your computer.
Not all features are available in all editions of
Windows 8. This computer may require
upgraded and/or separately purchased
hardware, drivers, and/or software to take full
advantage of Windows 8 functionality. See
http://www.microsoft.com for details.
Software terms
By installing, copying, downloading, or
otherwise using any software product
preinstalled on this computer, you agree to be
bound by the terms of the HP End User License
Agreement (EULA). If you do not accept these
license terms, your sole remedy is to return the
entire unused product (hardware and
software) within 14 days for a refund subject
to the refund policy of your place of purchase.
For any further information or to request a full
refund of the computer, please contact your
local point of sale (the seller).
Safety warning notice
WARNING! To reduce the possibility of heat-related injuries or of overheating the computer, do not place
the computer directly on your lap or obstruct the computer air vents. Use the computer only on a hard, flat
surface. Do not allow another hard surface, such as an adjoining optional printer, or a soft surface, such as
pillows or rugs or clothing, to block airflow. Also, do not allow the AC adapter to contact the skin or a soft
surface, such as pillows or rugs or clothing, during operation. The computer and the AC adapter comply with
the user-accessible surface temperature limits defined by the International Standard for Safety of
Information Technology Equipment (IEC 60950).
iii
iv Safety warning notice
Table of contents
1 Product description ....................................................................................................................................... 1
2 External component identification ................................................................................................................. 7
Display ................................................................................................................................................................... 7
Top ......................................................................................................................................................................... 8
TouchPad ............................................................................................................................................. 8
Lights ................................................................................................................................................... 9
Buttons, speakers, and fingerprint reader (select models only) ..................................................... 10
Keys ................................................................................................................................................... 11
Front ..................................................................................................................................................................... 12
Left ....................................................................................................................................................................... 13
Right ..................................................................................................................................................................... 14
Rear ...................................................................................................................................................................... 15
Bottom ................................................................................................................................................................. 16
Service tag ........................................................................................................................................................... 18
3 Illustrated parts catalog .............................................................................................................................. 19
Computer major components ............................................................................................................................. 19
LED display assembly subcomponents ............................................................................................................... 25
Bracket Kit ........................................................................................................................................................... 26
Cable Kit ............................................................................................................................................................... 27
Plastics Kit ........................................................................................................................................................... 28
Mass storage devices .......................................................................................................................................... 29
Miscellaneous parts ............................................................................................................................................. 30
Sequential part number listing ........................................................................................................................... 31
4 Removal and replacement procedures preliminary requirements .................................................................... 38
Tools required ...................................................................................................................................................... 38
Service considerations ........................................................................................................................................ 38
Plastic parts ....................................................................................................................................... 38
Cables and connectors ...................................................................................................................... 39
Drive handling ................................................................................................................................... 39
Grounding guidelines ........................................................................................................................................... 39
Electrostatic discharge damage ....................................................................................................... 39
Packaging and transporting guidelines ......................................................................... 41
Workstation guidelines ................................................................................ 41
v
5 Removal and replacement procedures for Customer Self-Repair parts ............................................................. 43
Component replacement procedures ................................................................................................................. 43
Battery ............................................................................................................................................... 44
Service cover ..................................................................................................................................... 45
Hard drive .......................................................................................................................................... 46
Optical drive ...................................................................................................................................... 48
WWAN module ................................................................................................................................... 50
Solid-state drive (M.2) ....................................................................................................................... 52
WLAN module .................................................................................................................................... 53
Primary memory module .................................................................................................................. 55
Keyboard ........................................................................................................................................... 57
Expansion memory module .............................................................................................................. 61
6 Removal and replacement procedures for Authorized Service Provider parts ................................................... 63
Component replacement procedures ................................................................................................................. 63
RTC battery ........................................................................................................................................ 63
Top cover ........................................................................................................................................... 65
Fingerprint reader board ................................................................................................................... 69
Function button board ...................................................................................................................... 71
Power button board .......................................................................................................................... 73
ExpressCard assembly ...................................................................................................................... 74
Smart card reader ............................................................................................................................. 76
Audio/USB board ............................................................................................................................... 77
USB board .......................................................................................................................................... 78
Speakers ............................................................................................................................................ 80
Fan/heat sink assembly .................................................................................................................... 81
Processor ........................................................................................................................................... 84
Graphics board .................................................................................................................................. 85
Display assembly .............................................................................................................................. 87
System board .................................................................................................................................... 94
Power connector cable ...................................................................................................................... 98
RJ-45 (network) cable ..................................................................................................................... 100
7 Computer Setup (BIOS), MultiBoot, and HP PC Hardware Diagnostics (UEFI) in Windows 8.1 ............................. 103
Using Computer Setup ....................................................................................................................................... 103
Starting Computer Setup ................................................................................................................ 103
Navigating and selecting in Computer Setup ................................................................................. 103
Restoring factory settings in Computer Setup ............................................................................... 104
Updating the BIOS ........................................................................................................................... 104
Determining the BIOS version ...................................................................................... 104
vi
Downloading a BIOS update ......................................................................................... 105
Using MultiBoot ................................................................................................................................................. 106
About the boot device order ........................................................................................................... 106
Choosing MultiBoot preferences .................................................................................................... 106
Setting a new boot order in Computer Setup .............................................................. 106
Dynamically choosing a boot device using the f9 prompt ........................................... 107
Setting a MultiBoot Express prompt ............................................................................ 107
Entering MultiBoot Express preferences ..................................................................... 107
Using HP PC Hardware Diagnostics (UEFI) ........................................................................................................ 108
Downloading HP PC Hardware Diagnostics (UEFI) to a USB device ............................................... 108
Using HP Sure Start ........................................................................................................................................... 109
8 Computer Setup (BIOS), MultiBoot, and HP PC Hardware Diagnostics (UEFI) in Windows 7 ................................ 110
Using Computer Setup ....................................................................................................................................... 103
Starting Computer Setup ................................................................................................................ 110
Navigating and selecting in Computer Setup ................................................................................. 110
Restoring factory settings in Computer Setup ............................................................................... 111
Updating the BIOS ........................................................................................................................... 104
Determining the BIOS version ...................................................................................... 111
Downloading a BIOS update ......................................................................................... 112
Using MultiBoot ................................................................................................................................................. 113
About the boot device order ........................................................................................................... 113
Choosing MultiBoot preferences .................................................................................................... 113
Setting a new boot order in Computer Setup .............................................................. 113
Dynamically choosing a boot device using the f9 prompt ........................................... 114
Setting a MultiBoot Express prompt ............................................................................ 114
Entering MultiBoot Express preferences ..................................................................... 114
Using HP PC Hardware Diagnostics (UEFI) (select models only) ...................................................................... 114
Downloading HP PC Hardware Diagnostics (UEFI) to a USB device ............................................... 115
Using HP Sure Start ........................................................................................................................................... 115
9 Specifications ........................................................................................................................................... 116
Computer specifications .................................................................................................................................... 116
Hard drive specifications ................................................................................................................................... 117
10 Backup and recovery in Windows 8.1 ......................................................................................................... 118
Backing up your information ............................................................................................................................. 118
Performing a system recovery .......................................................................................................................... 118
Using the Windows recovery tools ................................................................................................. 118
Using f11 recovery tools ................................................................................................................. 119
vii
Using Windows operating system media (purchased separately) ................................................ 120
Using Windows Refresh or Windows Reset .................................................................................... 120
Using HP Software Setup ................................................................................................................ 120
11 Backup and recovery in Windows 7 ............................................................................................................ 121
Creating recovery media and backups .............................................................................................................. 121
Guidelines ........................................................................................................................................ 121
Creating recovery media with HP Recovery Disc Creator ............................................................... 121
Creating recovery media .............................................................................................. 122
Backing up your information .......................................................................................................... 122
Performing a system recovery .......................................................................................................................... 123
Using the Windows recovery tools ................................................................................................. 123
Using f11 recovery tools (select models only) ............................................................................... 124
Using Windows 7 operating system media .................................................................................... 124
12 Statement of memory volatility ................................................................................................................ 126
Nonvolatile memory usage ............................................................................................................................... 128
Questions and answers ..................................................................................................................................... 130
Using HP Sure Start (select models only) ......................................................................................................... 131
13 Power cord set requirements .................................................................................................................... 132
Requirements for all countries ......................................................................................................................... 132
Requirements for specific countries and regions ............................................................................................. 132
14 Recycling ................................................................................................................................................ 134
Index ........................................................................................................................................................... 135
viii
1 Product description
Category Description
Product Name HP ZBook 15 G2 Mobile Workstation
Processors
●
Intel® Quad Core® i7-4910MQ 2.90-GHz (SC turbo up to 3.90-GHz) processor (1600-MHz
front-side bus (FSB), 8.0-MB L3 cache, 47 W)
●
Intel Quad Core i7-4810MQ 2.80-GHz (SC turbo up to 3.80-GHz) processor (1600-MHz
FSB, 6.0-MB L3 cache, 47 W)
●
Intel Quad Core i7-4710MQ 2.50-GHz (SC turbo up to 3.50-GHz) processor (1600-MHz
FSB, 6.0-MB L3 cache, 47 W)
●
Intel Quad Core i7-4610M 3.00-GHz (SC turbo up to 3.70-GHz) processor (1600-MHz
FSB, 4.0-MB L3 cache, 37 W)
●
Intel Dual Core i5-4340M 2.90-GHz (SC turbo up to 3.60-GHz) processor (1600-MHz
FSB, 3.0-MB L3 cache, 37 W)
●
Intel Dual Core i5-4210M 2.60-GHz (SC turbo up to 3.20-GHz) processor (1600-MHz
FSB, 3.0-MB L3 cache, 37 W)
Chipset Mobile Intel QM87
Graphics Switchable graphics:
●
NVIDIA® Quadro® K2100M NVIDIA N15P-Q3 with 2-GB GDDR5 graphics subsystem
memory (128-MB×16, 1.35-V, 1500-MHz, qty 8, 128-bit, FBW)
●
NVIDIA Quadro K1100M NVIDIA N15P-Q1 with 2-GB GDDR5 graphics subsystem memory
(128-MB×16, 1.35-V, 1400-MHz, qty 8, 128-bit, FBW)
●
NVIDIA Quadro K610M NVIDIA N15M-Q2 with 1-GB GDDR5 graphics subsystem memory
(128-MB×16, 1.35-V, 1300-MHz, qty 4, 64-bit, FBW)
●
AMD FirePro M5100) with 2-GB GDDR5 graphics subsystem memory (128-MB×16, 1.5V, 1125-MHz, qty 8, 128-bit, FBW)
Support for hybrid (switchable) graphics
Support for open GL
Support for DisplayPort 1.2
Support for up to 4 total displays (through APR)
Support for NVIDIA Mosaic Technology
Panel
●
15.6-in, Quad HD+, AG, LED, UWVA (3200×1800 resolution, 300 nits) with or without
camera
●
15.6-in, full-high definition (FHD), AntiGlare (AG), light-emitting diode (LED), UWVA
(1920×1080 resolution, 300 nits), with or without camera
●
15.6-in, FHD, AG, LED, SVA (1280×1024 resolution), with or without camera
All panels are 16:9 aspect ratio
Memory Four customer-accessible/upgradable memory module slots
Support for DDR3L 1600-MHz PC3-12800 dual channel memory
Support for 32768-MB of system RAM in the following configurations:
1
Category Description
●
32768-MB total system memory (8192-MB×4)
●
16384-MB total system memory (8192-MB×2 or 4096-MB×4)
●
8192-MB total system memory (8192-MB×1, 4096-MB×2)
●
4096-MB total system memory (4096-MB×1)
MiniCard solid-state drive 512-GB mSATA SSD
256-GB mSATA SSD
Hard drive Support for 6.35-cm (2.5-in) hard drives in 7.0-mm (.28-in) and 9.5-mm (.37-in) thickness
Support for Serial ATA
Support for 3D DriveGuard hard drive protection
Support toolless removal
Support for the following hard drives:
●
1-TB, 7200-rpm
●
750-GB, 7200-rpm
●
500-GB, 7200-rpm
●
500-GB, 7200-rpm, self-encrypting drive
●
500-GB, 5400-rpm, self-encrypting drive, FIPS
Support for the following 6.35-cm (2.5-in) solid-state drives:
●
512-GB SATA-3 self-encrypting, OPAL2
●
512-GB SATA-3
●
256-GB SATA-3
●
256-GB SATA-3 self-encrypting, OPAL2
●
256-GB SATA-3 self-encrypting, OPAL1
●
240-GB SATA-3
●
180-GB SATA-3
●
128-GB SATA-3
Upgrade drive Support for the following 9.5-mm (.37-in) , SATA optical drives:
●
Blu-ray R/RE DVD±RW SuperMulti Double-Layer Drive
●
Blu-ray ROM DVD±RW SuperMulti Double-Layer Drive
●
DVD±RW SuperMulti Double-Layer Drive
Support for 6.35-cm (2.5-in) 750-GB, 7200-rpm SATA hard drive in 7.0-mm (.28-in) and 9.5mm (.37-in) thicknesses
Support for the following 6.35-cm (2.5-in) drives:
●
1-TB, 7200-rpm
●
512-GB SATA-3 self-encrypting SSD, OPAL2
●
512-GB SSD
●
256-GB SED SSD, OPAL2
Supports for no Upgrade drive option (bezel)
2 Chapter 1 Product description
Category Description
Audio and video Stereo speakers
Dual array microphone
HD Audio with DTS Studio sound
Integrated HD 720p webcam (fixed [no tilt], activity LED, 1280×720 by 30 frames per second)
Support for no webcam option
Ethernet Intel I217-LM 10/100/1000 Ethernet, with Intel I217-LM Gigabit Network Connection
Support for Power Optimizer
Intel Stable Image Platform Program (SIPP)
Wireless Integrated wireless local area network (WLAN) options by way of wireless module
Two WLAN antennas built into display assembly
Support for the following WLAN formats:
●
Intel Dual Band Wireless-AC 7260 802.11 AC 2x2 WiFi + BT 4.0 Combo Adapter
●
Intel Dual Band Wireless-N 7260AN 802.11 a/b/g/n (2x2) WiFi + BT 4.0 combo
●
Intel Dual Band Wireless-N 7260NB 802.11 a/b/g/n (2x2) WiFi
Integrated wireless wide area network (WWAN) options by way of wireless module (select
models only)
Two WWAN antennas built into display assembly
Security provided by subscriber identify module (SIM), slot located in battery bay
Support for the following WWAN formats:
●
HP hs3110 HSPA+ Mobile Broadband Module
●
HP lt4211 LTE/EV-DO/HSPA+ Gobi 4G Module
●
HP lt4112 LTE/HSPA+ Mobile Broadband Module
External media cards ExpressCard – 54mm
Integrated SD UHS-II flash media slot
Supports next generation SD (Secure Digital); Backward compatible with SDHC, SDXC
Ports
●
Multi-Pin AC Port
●
Combination mic-in/stereo headphone jack
●
Battery (secondary) connector
●
DisplayPort 1.2
●
Docking
●
RJ-45 (Ethernet)
●
Thunderbolt 2
●
USB 3.0 (2)
●
USB 3.0 charging (1)
●
USB: 2.0 (1)
●
VGA (Dsub 15 pin) supporting: 1920×1200 external resolution @ 75 Hz, hot plug and
unplug and autodetection for correct output to wide-aspect vs. standard aspect video
3
Category Description
Docking Docking support for HP Docking Station
Docking support for HP Advanced Docking Station
Keyboard/pointing devices Full-size, island-style, backlit (and non-backlit) keyboard with numeric keypad
Gesture support: MultiTouch gestures enabled, two-finger scrolling, and pinchzoom as default
Support for Windows 8 dual-point (pointing stick with 3 pointing stick buttons plus TouchPad
with 3 TouchPad buttons)
DuraKeys
Spill Resistant with drain
TouchPad requirements:
●
On/off button
●
Glass with chemical etched surface (DuraPad)
●
Support for 2-way scroll
●
Taps enabled by default
●
Gestures enabled by default:
◦
2-finger scrolling
◦
2-finger zoom (pinch)
●
Image sensor TouchPad
Power requirements Support for the following AC adapters:
●
200-W, HP Smart Adapter, slim
●
150-W, HP Smart Adapter, slim
3-wire plug (with ground pin)
Power requirements (continued) Support for the following batteries
●
9-cell, 100-WHr, 3.0-AHr, Li-ion battery
●
9-cell, 73-WHr, 2.2-AHr, Li-ion battery
●
8-cell, 83-WHr, 2.8-AHr, Li-ion battery
●
8-cell, 75-WHr, 2.8-AHr, Li-ion battery
Security Support security lock
Trusted platform module (TPM) 1.2 (Infineon; soldered down) and TPM Enhanced Drive Lock
(For the People's Republic of China and Asia Pacific countries and regions, disabled
but available)
Fingerprint reader
Integrated smart card reader
Preboot authentication (password, smart card)
Operating system Preinstalled:
●
Windows 8.1 CH 64-bit (only available in the People's Republic of China with Hardware
Kit)
●
Windows 8.1 EM 64-bit
●
Windows 8.1 ML 64-bit
4 Chapter 1 Product description
Category Description
●
Windows 8.1 CH 64 CPPP
●
Windows 8.1 Professional 64-bit
●
Windows 8.1 Professional 64-bit MSNA
●
Windows 8.1 Professional 64-bit for Education
●
Windows 8 Professional 64-bit DPK with Windows 7 Professional 64-bit Image
●
Windows 8 Professional 64-bit DPK with Windows 7 Professional 64-bit Image MSNA
●
Windows 7 Professional 64-bit
●
Windows 7 Professional 64-bit MSNA
●
FreeDOS 2.0
●
Ubuntu Linux
Restore media-DRDVD:
●
DRDVD Windows 8.1 (available with any Windows 8.1 loc, required any Windows 8.1
Professional downgrade operating system)
●
DRDVD Windows 7 Service Pack 1 (available with any Windows 8.1 or Windows 7
Professional downgrade loc)
●
SRDVD Ubuntu Linux
Operating system (continued) Restore media-OSDVD:
●
Windows 8.1 64-bit (for service only)
●
Windows 8.1 Country-Specific 64-bit (for service only)
●
Windows 8.1 Emerging Market 64-bit (for service only)
●
Windows 8.1 Professional 64-bit (only available and required with Windows 8.1
downgrade operating systems)
●
Windows 7 Professional 64-bit, Service Pack 1 (available with any Windows 8.1
Professional or Windows 7 Professional downgrade loc, not available in the People's
Republic of China)
Certified:
●
Microsoft WHCK
●
SuSE Linux Enterprise (SLED) Service Pack 2, 64-bit
Web-only support:
●
Windows 8.1 Enterprise 64-bit
●
Windows 7 Enterprise 64-bit, Service Pack 1
●
Windows 7 Enterprise 32-bit, Service Pack 1
●
Windows 7 Professional 32-bit, Service Pack 1
●
Windows 7 Ultimate 64-bit, Service Pack 1
●
Windows 7 Ultimate 32-bit, Service Pack 1
Serviceability End user replaceable parts:
●
AC adapter
●
Battery (system)
●
Hard drive
5
Category Description
●
Keyboard
●
Memory modules (4, 2 expansion and 2 primary)
●
mSATA SSD
●
Optical drive
●
SSD
●
WLAN module
●
WWAN module
6 Chapter 1 Product description
2 External component identification
Display
Component Description
(1) WLAN antennas * Send and receive wireless signals to communicate with wireless local
area networks (WLAN).
(2) WWAN antennas * (select models only) Send and receive wireless signals to communicate with wireless wide
area networks (WWAN).
(3) Internal microphones Record sound.
(4) Webcam light (select models only) On: The webcam is in use.
(5) Webcam (select models only) Records video and captures photographs. Some models allow you to
video conference and chat online using streaming video.
For information on using the webcam, select Start > All Programs >
Communication and Chat > HP WebCam.
(6) Internal display switch Turns off the display or initiates Sleep if the display is closed while
the power is on.
NOTE: The display switch is not visible from the outside of the
computer.
*The antennas are not visible on the outside of the computer. For optimal transmission, keep the areas immediately around the
antennas free from obstructions. To see wireless regulatory notices, see the section of the Regulatory, Safety, and Environmental
Notices that applies to your country or region. To access the user guides, select Start > Help and Support > User Guides.
Display 7
Top
TouchPad
Component Description
(1) Pointing stick Moves the pointer and selects or activates items on the screen.
(2) Left pointing stick button Functions like the left button on an external mouse.
(3) TouchPad on/off button Turns the TouchPad on and off.
(4) TouchPad zone Reads your finger gestures to move the pointer and select or
activate items on the screen.
NOTE: The TouchPad also supports edge-swipe gestures. For
more information, see Edge swipes (select models only) on
page 34.
(5) Left TouchPad button Functions like the left button on an external mouse.
(6) Right pointing stick button Functions like the right button on an external mouse.
(7) Center pointing stick button Functions like the center button on an external mouse.
(8) Center TouchPad button Functions like the center button on an external mouse.
(9) Right TouchPad button Functions like the right button on an external mouse.
8 Chapter 2 External component identification
Lights
Component Description
(1)
Power light
●
On: The computer is on.
●
Blinking: The computer is in the Sleep state, a powersaving state. The computer shuts off power to the display
and other unneeded components.
●
Off: The computer is off or in Hibernation. Hibernation is a
power-saving state that uses the least amount of power.
NOTE: For select models, the Intel® Rapid Start Technology
feature is enabled at the factory. Rapid Start Technology allows
your computer to resume quickly from inactivity.
(2) Caps lock light On: Caps lock is on, which switches the keys to all capital letters.
(3)
Microphone mute light
●
Amber: microphone sound is off.
●
Off: microphone sound is on.
(4) Num lock light On: Num lock is on.
(5)
Wireless light On: An integrated wireless device, such as a wireless local area
network (WLAN) device and/or a Bluetooth® device, is on.
NOTE: On some models, the wireless light is amber when all
wireless devices are off.
(6)
Mute light
●
Amber: Computer sound is off.
●
Off: Computer sound is on.
Top 9
Buttons, speakers, and fingerprint reader (select models only)
Component Description
(1)
Power button
●
When the computer is off, press the button to turn on the
computer.
●
When the computer is on, press the button briefly to initiate
Sleep.
●
When the computer is in the Sleep state, press the button
briefly to exit Sleep.
●
When the computer is in Hibernation, press the button
briefly to exit Hibernation.
CAUTION: Pressing and holding down the power button will
result in the loss of unsaved information.
If the computer has stopped responding and Windows®
shutdown procedures are ineffective, press and hold the power
button for at least 5 seconds to turn off the computer.
NOTE: For select models, the Intel® Rapid Start Technology
feature is enabled at the factory. Rapid Start Technology allows
your computer to resume quickly from inactivity.
To learn more about your power settings: Select Start > Control
Panel > System and Security > Power Options.
(2) Speakers Produce sound.
(3)
Wireless button Turns the wireless feature on or off but does not establish a
wireless connection.
(4)
Volume mute button Mutes and restores speaker sound.
(5) Fingerprint reader (select models only) Allows a fingerprint logon to Windows, instead of a password
logon.
10 Chapter 2 External component identification
Keys
Component Description
(1) esc key Displays system information when pressed in combination with
the fn key.
(2) fn key Executes frequently used system functions when pressed in
combination with a function key, the num lk key, the esc key, or
the b key.
(3)
Windows button Displays the Windows Start menu.
(4) Function keys Execute frequently used system functions when pressed in
combination with the fn key.
(5) num lk key Alternates between the navigational and numeric functions on
the integrated numeric keypad.
(6) Integrated numeric keypad When num lk has been enabled, it can be used like an external
numeric keypad.
Top 11
Front
Component Description
(1)
Wireless light On: An integrated wireless device, such as a wireless local
area network (WLAN) device and/or a Bluetooth® device, is
on.
NOTE: On some models, the wireless light is amber when
all wireless devices are off.
(2)
Power light
●
On: The computer is on.
●
Blinking: The computer is in the Sleep state, a powersaving state. The computer shuts off power to the
display and other unneeded components.
●
Off: The computer is off or in Hibernation.
Hibernation is a power-saving state that uses the
least amount of power.
NOTE: For select models, the Intel® Rapid Start
Technology feature is enabled at the factory. Rapid Start
Technology allows your computer to resume quickly from
inactivity.
(3)
AC adapter/Battery light
●
White: The computer is connected to external power
and the battery is charged from 90 to 99 percent.
●
Amber: The computer is connected to external power
and the battery is charged from 0 to 90 percent.
●
Blinking amber: A battery that is the only available
power source has reached a low battery level. When
the battery reaches a critical battery level, the
battery light begins blinking rapidly.
●
Off: The battery is fully charged.
(4)
Hard drive/optical drive light
●
Blinking white: The hard drive or optical drive is being
accessed.
●
Amber: HP 3D DriveGuard has temporarily parked the
hard drive.
12 Chapter 2 External component identification
Left
Component Description
(1)
Security cable slot Attaches an optional security cable to the computer.
NOTE: The security cable is designed to act as a deterrent, but
it may not prevent the computer from being mishandled or
stolen.
(2)
USB 2.0 port Connects an optional USB device, such as a keyboard, mouse,
external drive, printer, scanner or USB hub.
(3) Vent Enables airflow to cool internal components.
NOTE: The computer fan starts up automatically to cool
internal components and prevent overheating. It is normal for
the internal fan to cycle on and off during routine operation.
(4)
Thunderbolt DisplayPort Connects an optional high-resolution display device or a high-
performance data device.
NOTE: Thunderbolt is new technology. Install all the latest
drivers for your Thunderbolt device before connecting the
device to the Thunderbolt DisplayPort. Thunderbolt cable and
Thunderbolt device (sold separately) must be compatible with
Windows. To determine whether your device is Thunderbolt
Certified for Windows, go to
https://thunderbolttechnology.net/
products.
(5)
Dual-Mode DisplayPort Connects an optional digital display device, such as a high-
performance monitor or projector.
(6)
USB 3.0 charging (powered) port Connects an optional USB device, such as a keyboard, mouse,
external drive, printer, scanner or USB hub. Standard USB ports
will not charge all USB devices or will charge using a low
current. Some USB devices require power and require you to use
a powered port.
NOTE: USB charging ports can also charge select models of
cell phones and MP3 players, even when the computer is off.
(7) Smart card reader Supports optional smart cards.
(8)
ExpressCard slot or smart card reader
(depending on the configuration)
Supports optional ExpressCards or smart cards.
Left 13
Right
Component Description
(1) Memory card reader Reads optional memory cards that store, manage, share, or
access information.
(2)
Audio-out (headphone)/Audio-in (microphone)
jack
Connects optional powered stereo speakers, headphones,
earbuds, a headset, or a television audio cable. Also connects
an optional headset microphone. This jack does not support
optional microphone-only devices.
WARNING! To reduce the risk of personal injury, adjust the
volume before putting on headphones, earbuds, or a headset.
For additional safety information, see the Regulatory, Safety,
and Environmental Notices. To access the user guides, select
Start > Help and Support > User Guides.
NOTE: When a device is connected to the jack, the computer
speakers are disabled.
NOTE: Be sure that the device cable has a 4-conductor
connector that supports both audio-out (headphone) and
audio-in (microphone).
(3)
USB 3.0 port Connects an optional USB device, such as a keyboard, mouse,
external drive, printer, scanner, or USB hub.
(4) Upgrade bay (optical drive shown) (select
models only)
Depending on your computer model, reads an optical disc or
reads and writes to an optical disc.
(5) Optical drive eject button (select models only) Releases the optical drive disc tray.
(6)
External monitor port Connects an external VGA monitor or projector.
14 Chapter 2 External component identification
Rear
Component Description
(1)
USB 3.0 port Connects an optional USB device, such as a keyboard,
mouse, external drive, printer, scanner or USB hub.
(2)
Power connector Connects an AC adapter.
(3)
AC adapter/battery light
●
White: The computer is connected to external
power and the battery is charged from 90 to 99
percent.
●
Amber: The computer is connected to external
power and the battery is charged from 0 to 90
percent.
●
Blinking amber: A battery that is the only
available power source has reached a low
battery level. When the battery reaches a
critical battery level, the battery light begins
blinking rapidly.
●
Off: The battery is fully charged.
(4)
RJ-45 (network) jack/lights Connects a network cable.
●
Green (left): The network is connected.
●
Amber (right): The network is showing activity.
Rear 15
Bottom
Component Description
(1)
Battery release latch Releases the battery from the battery bay.
(2) Battery bay Holds the battery.
(3)
SIM slot Supports a wireless subscriber identity module (SIM). The
SIM slot is located inside the battery bay.
(4)
Docking connector Connects an optional docking device.
(5) Accessory battery connector Connects an optional accessory battery.
(6)
Service door release lock Locks the service door.
(7)
Service door release latch Releases the service door on the computer.
(8) Vents (3) Enable airflow to cool internal components.
16 Chapter 2 External component identification
Component Description
NOTE: The computer fan starts up automatically to cool
internal components and prevent overheating. It is normal
for the internal fan to cycle on and off during routine
operation.
(9)
Service door Provides access to the hard drive bay, the wireless LAN
(WLAN) module slot, the WWAN module slot, and the
memory module slots.
CAUTION: To prevent an unresponsive system, replace
the wireless module only with a wireless module
authorized for use in the computer by the governmental
agency that regulates wireless devices in your country or
region. If you replace the module and then receive a
warning message, remove the module to restore
computer functionality, and then contact support. To
access Help and Support, select Start > Help and Support.
Bottom 17
Service tag
When ordering parts or requesting information, provide the computer serial number and model number
provided on the service tag.
Item Description Function
(1) Product name This is the product name affixed to the front of
the computer.
(2) Serial number (s/n) This is an alphanumeric identifier that is unique to each
product.
(3) Part number/Product number (p/n) This number provides specific information about
the product's hardware components. The part number
helps a service technician to determine what
components and parts are needed.
(4) Warranty period This number describes the duration of the warranty
period for the computer.
(5) Model description This is the alphanumeric identifier used to locate
documents, drivers, and support for the computer.
18 Chapter 2 External component identification
3 Illustrated parts catalog
Computer major components
Computer major components 19
Item Component Spare part number
(1) Display assembly: The DreamVision display assembly is spared as a whole unit assembly only. The LED display assembly
is spared at the subcomponent level only. For more LED display assembly spare part information, see
LED display
assembly subcomponents on page 25.
15.6-in, FHD, UWVA, DreamVision display assembly equipped with a webcamera 735965-001
15.6-in, FHD, UWVA, DreamVision display assembly not equipped with a webcamera 735964-001
Hinge Cover Kit, includes: 734294-001
(2a) Hinge cover (includes HP logo)
(2b) Left-side rear corner cover
(2c) Right-side-side rear corner cover
(3) Keyboard (includes keyboard cable):
Keyboard with backlight and pointing stick (includes keyboard cable, backlight cable, and pointing stick cable):
For use in Belgium 733688-A41
For use in Brazil 733688-201
For use in Bulgaria 733688-261
For use in Canada 733688-DB1
For use in the Czech Republic and Slovakia 733688-FL1
For use in Denmark 733688-081
For use in France 733688-051
For use in Germany 733688-041
For use in Greece 733688-151
For use in Hungary 733688-211
For use in Iceland 733688-DD1
For use in India 733688-D61
For use in Israel 733688-BB1
For use in Italy 733688-061
For use in Japan 733688-291
For use in Latin America 733688-161
For use in the Netherlands 733688-B31
For use in Northwest Africa 733688-FP1
For use in Norway 733688-091
For use in Portugal 733688-131
For use in Romania 733688-271
For use in Russia 733688-251
For use in Saudi Arabia 733688-171
For use in Slovenia 733688-BA1
20 Chapter 3 Illustrated parts catalog
Item Component Spare part number
For use in South Korea 733688-AD1
For use in Spain 733688-071
For use in Sweden and Finland 733688-B71
For use in Switzerland 733688-BG1
For use in Taiwan 733688-AB1
For use in Thailand 733688-281
For use in Turkey 733688-141
For use in Turkey (F) 733688-541
For use in the United Kingdom and Singapore 733688-031
For use in the United States 733688-001
Keyboard with pointing stick (includes keyboard cable and pointing stick cable):
For use in Belgium 745663-A41
For use in Brazil 745663-201
For use in Bulgaria 745663-261
For use in Canada 745663-DB1
For use in the Czech Republic and Slovakia 745663-FL1
For use in Denmark 745663-081
For use in France 745663-051
For use in Germany 745663-041
For use in Greece 745663-151
For use in Hungary 745663-211
For use in Iceland 745663-DD1
For use in Israel 745663-BB1
For use in Italy 745663-061
For use in Japan 745663-291
For use in Latin America 745663-161
For use in the Netherlands 745663-B31
For use in Northwest Africa 745663-FP1
For use in Norway 745663-091
For use in Portugal 745663-131
For use in Romania 745663-271
For use in Russia 745663-251
For use in Saudi Arabia 745663-171
For use in Slovenia 745663-BA1
Computer major components 21
Item Component Spare part number
For use in South Korea 745663-AD1
For use in Spain 745663-071
For use in Sweden and Finland 745663-B71
For use in Switzerland 745663-BG1
For use in Taiwan 745663-AB1
For use in Thailand 745663-281
For use in Turkey
For use in Turkey F
745663-141
745663-541
For use in the United Kingdom and Singapore 745663-031
For use in the United States 745663-001
(4) Primary memory module (PC3L, 12800, 1600-MHz):
8-GB 693374-001
4-GB 691740-001
(5) Top cover (includes TouchPad, TouchPad cable, and TouchPad bracket) 734281-001
(6) Power button board (includes cable) 734285-001
(7) Function button board (includes cable and double-sided adhesive) 734284-001
(8) Fingerprint reader board (includes cable and double-sided adhesive) 734286-001
(9) ExpressCard assembly (includes activity LEDs and Thunderbolt port, Dual Mode
DisplayPort, and USB port)
794579-001
(10) Smart card reader (includes cable) 742159-001
(11) Audio/USB board (includes SD Card reader) 734288-001
(12) Fan/heat sink assembly (includes replacement thermal material):
For use only with an NVIDIA Quadro K1100M NVIDIA N15P-Q1 graphics board, spare part
number 785223-001
734289-001
For use only with an NVIDIA Quadro K610M NVIDIA N15M-Q2 graphics board, spare part
number 785225-001
734290-001
For use only with an NVIDIA Quadro K2100M NVIDIA N15P-Q3 graphics board, spare part
number 785224-001
734291-001
For use only with an AMD FirePro M5100 graphics board, spare part number 784470-001 784469-001
(13) Processor (includes replacement thermal material):
Intel Quad Core i7-4910MQ 2.90-GHz (SC turbo up to 3.90-GHz) processor (1600-MHz FSB,
8.0-MB L3 cache, 47 W)
778693-001
Intel Quad Core i7-4810MQ 2.80-GHz (SC turbo up to 3.80-GHz) processor (1600-MHz FSB,
6.0-MB L3 cache, 47 W)
778692-001
Intel Quad Core i7-4710MQ 2.50-GHz (SC turbo up to 3.50-GHz) processor (1600-MHz FSB,
6.0-MB L3 cache, 47 W)
773212-001
Intel Quad Core i7-4610M 3.00-GHz (SC turbo up to 3.70-GHz) processor (1600-MHz FSB,
4.0-MB L3 cache, 37 W)
765141-001
22 Chapter 3 Illustrated parts catalog
Item Component Spare part number
Intel Dual Core i5-4340M 2.90-GHz (SC turbo up to 3.60-GHz) processor (1600-MHz FSB,
3.0-MB L3 cache, 37 W)
765142-001
Intel Dual Core i5-4210M 2.60-GHz (SC turbo up to 3.20-GHz) processor (1600-MHz FSB,
3.0-MB L3 cache, 37 W)
768420-001
(14) Graphics board (includes replacement thermal material):
NVIDIA Quadro K1100M NVIDIA N15P-Q1 graphics board 785223-001
NVIDIA Quadro K610M NVIDIA N15M-Q2 graphics board 785225-001
NVIDIA Quadro K2100M NVIDIA N15P-Q3 graphics board 785224-001
AMD FirePro M5100 graphics board 784470-001
(15) USB board (includes cable and double-sided adhesive) 734293-001
(16) Speakers (include cable) 734292-001
(17) RJ-45 (network) cable (included in the Cable Kit, spare part number 785222-001)
(18) Power connector cable (included in the Cable Kit, spare part number 785222-001)
(19) System board (includes battery connector bracket and replacement thermal material):
For use only on computer models equipped with an Intel Quad Core processor and the
Windows 8 Professional operating system
784468-601
For use only on computer models equipped with an Intel Quad Core processor and the
Windows 8 Standard operating system
784468-501
For use only on computer models equipped with an Intel Quad Core processor and without
the Windows operating system
784468-001
For use only on computer models equipped with an Intel Dual Core processor and the
Windows 8 Professional operating system
784467-601
For use only on computer models equipped with an Intel Dual Core processor and the
Windows 8 Standard operating system
784467-501
For use only on computer models equipped with an Intel Dual Core processor and without
the Windows operating system
784467-001
(20) Base enclosure (includes 4 rubber feet, battery lock latch, battery release latch, and RJ-45
cover)
785221-001
(21) Expansion memory modules (2, PC3L, 12800, 1600-MHz):
8-GB 693374-001
4-GB 691740-001
(22) Solid-state drive (SSD), 2.5-inch:
512-GB, SATA-3 795962-001
256-GB, SATA-3 795959-001
256-GB, SATA-3, self-encrypting drive (SED), OPAL 1 795960-001
256-GB, SATA-3, self-encrypting drive (SED), OPAL 2 795961-001
240-GB, SATA-3 795958-001
180-GB, SATA-3 795957-001
Computer major components 23
Item Component Spare part number
128-GB, SATA-3 795956-001
Solid-state drive (SSD), M.2 (not illustrated):
256-GB, M.2 795955-001
(23) WWAN module:
HP lt4111 LTE/EV-DO/HSPA+ Mobile Broadband Module (for use in the United States and
Canada)
740011-001
HP lt4111 LTE/EV-DO/HSPA+ Mobile Broadband Module 748021-001
HP hs3110 HSPA+ Mobile Broadband Module 748599-001
(24) WLAN module:
Intel Dual Band Wireless-AC 7260 802.11 AC 2x2 WiFi + BT 4.0 Combo Adapterr 710663-001
Intel Dual Band Wireless-N 7260AN 802.11 a/b/g/n (2x2) WiFi + BT 4.0 combo 717379-001
Intel Dual Band Wireless-N 7260NB 802.11 a/b/g/n (2x2) WiFi 717380-001
Intel Dual Band Wireless-N 7260AN 802.11 a/b/g/n (2x2) WiFi + BT 4.0 combo (for use in
Indonesia)
747833-001
(25) Hard drive (does not include hard drive bracket or screws):
1-TB, 7200-rpm, 9.5-mm 766644-001
1-TB, 5400-rpm, 2.5-in 778192-001
750-GB, 7200-rpm, 2.5-in 778191-001
500-GB, 7200-rpm, 7.0-mm 703267-001
500-GB, 5400-rpm, 7.0-mm, FIPS 730946-001
500-GB, 7200-rpm, 7.0-mm, self-encrypting 703268-001
Hard Drive Hardware Kit (not illustrated, includes hard drive bracket and screws) 734280-001
(26) Optical drive (includes bezel and bracket):
Blu-ray R/RE DVD±RW SuperMulti Double-Layer Drive 735600-001
Blu-ray ROM DVD±RW SuperMulti Double-Layer Drive 735599-001
DVD±RW SuperMulti Double-Layer Drive 735602-001
Hard drive upgrade bay 734298-001
(27) RTC battery (includes cable and double-sided adhesive) 734300-001
(28) Service cover 734278-001
(29) Battery:
9-cell, 100-WHr, 3.0-AHr, Li-ion battery 634087-001
9-cell, 73-WHr, 2.2-AHr, Li-ion battery 634089-001
8-cell, 83-WHr, 2.8-AHr, Li-ion battery 708456-001
8-cell, 75-WHr, 2.8-AHr, Li-ion battery 708455-001
24 Chapter 3 Illustrated parts catalog
LED display assembly subcomponents
Item Component Spare part number
(1) Display bezel:
For use only on computer models equipped with a webcamera 734301-001
For use only on computer models not equipped with a webcamera 734302-001
For use only on computer models equipped with a QHD+ display and with a webcamera 784471-001
For use only on computer models not equipped with a QHD+ display and with a webcamera 784472-001
For use only on computer models equipped with an Innolux display and a webcamera 784473-001
For use only on computer models not equipped with an Innolux display and a webcamera 784474-001
(2) Display panel:
15.6-in, FHD, UWVA, LED display panel 735607-001
15.6-in, FHD, SVA, LED display panel 735604-001
15.6-in, QHD+, UWVA, LED display panel 797849-001
(3) Webcamera/microphone module (includes double-sided adhesive) 784208-001
Microphone module (includes double-sided adhesive) 735370-001
LED display assembly subcomponents 25
Item Component Spare part number
(4) Display hinges (includes left and right hinges and display panel cable bracket) 784464-001
(5) Display Panel Support Kit (includes display enclosure, display panel cable, and wireless
antenna cables and transceivers)
784466-001
Bracket Kit
Item Component Spare part number
Bracket Kit, includes: 734299-001
(1) Security cable lock bracket
(2) Fingerprint reader board bracket
26 Chapter 3 Illustrated parts catalog
Cable Kit
Item Component Spare part number
Cable Kit, includes: 785222-001
(1) RJ-45 (network) cable
(2) Power connector cable
Replacement thermal material (not illustrated)
Cable Kit 27
Plastics Kit
Item Component Spare part number
Plastics Kit, includes: 734297-001
(1) ExpressCard reader bezel
(2) Fingerprint reader blank cover
(3) Fingerprint reader bezel
(4) SD card reader bezel
(5) System lens
28 Chapter 3 Illustrated parts catalog
Mass storage devices
Item Component Spare part number
(1) Solid-state drive, 2.5-inch
512-GB, SATA-3 795962-001
256-GB, SATA-3 795959-001
256-GB, SATA-3, self-encrypting drive (SED), OPAL 1 795960-001
256-GB, SATA-3, self-encrypting drive (SED), OPAL 2 795961-001
240-GB, SATA-3 795958-001
180-GB, SATA-3 795957-001
128-GB, SATA-3 795956-001
(2) Solid-state drive, M.2
256-GB 795955-001
Hard Drive Hardware Kit, includes: 734280-001
(3) Hard drive bracket
Screws (not illustrated)
Mass storage devices 29
Item Component Spare part number
(4) Hard drive (does not include hard drive bracket or screws):
1-TB, 7200-rpm, 9.5-mm 766644-001
1-TB, 5400-rpm, 2.5-in 778192-001
750-GB, 7200-rpm, 2.5-in 778191-001
500-GB, 7200-rpm, 7.0-mm 703267-001
500-GB, 5400-rpm, 7.0-mm, FIPS 730946-001
500-GB, 7200-rpm, 7.0-mm, self-encrypting 703268-001
(5) Optical drive (includes bezel and bracket):
Blu-ray R/RE DVD±RW SuperMulti Double-Layer Drive 735600-001
Blu-ray ROM DVD±RW SuperMulti Double-Layer Drive 735599-001
DVD±RW SuperMulti Double-Layer Drive 735602-001
Hard drive upgrade bay 734298-001
Miscellaneous parts
Component Spare part number
AC adapter:
200-W HP Smart adapter (PFC, 3-wire, 4.5-mm) 693708-001
150-W HP Smart adapter (PFC, 3-wire, 4.5-mm) 693707-001
Power cord (3-pin, black, 1.83-m):
For use in APD 491683-D91
For use in Argentina 490371-D01
For use in Australia 490371-011
For use in Brazil 490371-202
For use in Denmark 490371-081
For use in Europe 490371-021
For use in India 490371-D61
For use in Israel 490371-BB1
For use in Italy 490371-061
For use in Japan 490371-291
For use in North America 490371-001
491683-001
For use in the People's Republic of China 490371-AA1
For use in Singapore 491683-AF1
30 Chapter 3 Illustrated parts catalog
Component Spare part number
For use in South Africa 490371-AR1
For use in South Korea 490371-AD1
For use in Switzerland 490371-111
For use in Thailand 490371-201
For use in the United Kingdom and Singapore 490371-031
491683-031
Power cord (3-pin, black, 1.00-m):
For use in Taiwan 755530-AB1
Docking station, cable lock 575921-001
HP Ultraslim Keyed Cable Lock 703372-001
HP DisplayPort to HDMI 1.4 Adapter 749288-001
Screw Kit 734282-001
Mouse
HP USB laser 674318-001
HP Wireless 691922-001
HP Professional Slim Top Load 703888-001
Sequential part number listing
CSR flag designations: A = Mandatory; B = Optional; C = Service technician recommended; N = Non-user
replaceable
Spare part
number
CSR
flag
Description
490371-001 A Power cord for use in North America (3-pin, black, 1.83-m)
490371-011 A Power cord for use in Australia (3-pin, black, 1.83-m)
490371-021 A Power cord for use in Europe (3-pin, black, 1.83-m)
490371-031 A Power cord for use in the United Kingdom and Singapore (3-pin, black, 1.83-m)
490371-061 A Power cord for use in Italy (3-pin, black, 1.83-m)
490371-081 A Power cord for use in Denmark (3-pin, black, 1.83-m)
490371-111 A Power cord for use in Switzerland (3-pin, black, 1.83-m)
490371-201 A Power cord for use in Thailand (3-pin, black, 1.83-m)
490371-202 A Power cord for use in Brazil (3-pin, black, 1.83-m)
490371-291 A Power cord for use in Japan (3-pin, black, 1.83-m)
490371-AA1 A Power cord for use in the People's Republic of China (3-pin, black, 1.83-m)
490371-AD1 A Power cord for use in South Korea (3-pin, black, 1.83-m)
Sequential part number listing 31
Spare part
number
CSR
flag
Description
490371-AR1 A Power cord for use in South Africa (3-pin, black, 1.83-m)
490371-BB1 A Power cord for use in Israel (3-pin, black, 1.83-m)
490371-D01 A Power cord for use in Argentina (3-pin, black, 1.83-m)
490371-D61 A Power cord for use in India (3-pin, black, 1.83-m)
491683-001 A Power cord for use in North America(3-pin, black, 1.83-m)
491683-031 A Power cord for use in the United Kingdom (3-pin, black, 1.83-m)
491683-AF1 A Power cord for use in Singapore (3-pin, black, 1.83-m)
491683-D91 A Power cord for use in APD (3-pin, black, 1.83-m)
575921-001 A Docking station, cable lock
634087-001 A 9-cell, 100-WHr, 3.0-AHr, Li-ion battery
634089-001 A 9-cell, 73-WHr, 2.2-AHr, Li-ion battery
674318-001 A Mouse, HP USB laser
691740-001 A 4-GB memory module (PC3L, 12800, 1600-MHz)
691922-001 A Mouse, wireless
693374-001 A 8-GB memory module (PC3L, 12800, 1600-MHz)
693707-001 A 150-W HP Smart adapter (PFC, 3-wire, 4.5-mm)
693708-001 A 200-W HP Smart adapter (PFC, 3-wire, 4.5-mm)
703267-001 A 500-GB, 7200-rpm, SATA, 7.0-mm hard drive (does not include hard drive bracket or screws)
703268-001 A 500-GB, 7200-rpm, SATA, 7.0-mm self-encrypting drive (SED, does not include hard drive bracket or
screws)
703372-001 A HP Ultraslim Keyed Cable Lock
703888-001 A HP Professional Slim Top Load
708455-001 A 8-cell, 75-WHr, 2.8-AHr, Li-ion battery
708456-001 A 8-cell, 83-WHr, 2.8-AHr, Li-ion battery
710663-001 A Intel Dual Band Wireless-AC 7260 802.11 AC 2x2 WiFi + BT 4.0 Combo Adapter
717379-001 A Intel Dual Band Wireless-N 7260AN 802.11 a/b/g/n (2x2) WiFi + BT 4.0 combo
717380-001 A Intel Dual Band Wireless-N 7260NB 802.11 a/b/g/n (2x2) WiFi
730946-001 A 500-GB, 5400-rpm, SATA, 7.0-mm FIPS hard drive (does not include hard drive bracket or screws)
NOTE: The hard drive bracket and screws are included in the Hard Drive Hardware Kit, spare part number
734280-001.
733688-001 A Keyboard with backlight and pointing stick for use in the United States (includes keyboard cable, backlight
cable, and pointing stick cable)
733688-031 A Keyboard with backlight and pointing stick for use in the United Kingdom and Singapore (includes keyboard
cable, backlight cable, and pointing stick cable)
733688-041 A Keyboard with backlight and pointing stick for use in Germany (includes keyboard cable, backlight cable,
and pointing stick cable)
32 Chapter 3 Illustrated parts catalog
Spare part
number
CSR
flag
Description
733688-051 A Keyboard with backlight and pointing stick for use in France (includes keyboard cable, backlight cable, and
pointing stick cable)
733688-061 A Keyboard with backlight and pointing stick for use in Italy (includes keyboard cable, backlight cable, and
pointing stick cable)
733688-071 A Keyboard with backlight and pointing stick for use in Spain (includes keyboard cable, backlight cable, and
pointing stick cable)
733688-081 A Keyboard with backlight and pointing stick for use in Denmark (includes keyboard cable, backlight cable,
and pointing stick cable)
733688-091 A Keyboard with backlight and pointing stick for use in Norway (includes keyboard cable, backlight cable, and
pointing stick cable)
733688-131 A Keyboard with backlight and pointing stick for use in Portugal (includes keyboard cable, backlight cable,
and pointing stick cable)
733688-141 A Keyboard with backlight and pointing stick for use in Turkey (includes keyboard cable, backlight cable, and
pointing stick cable)
733688-151 A Keyboard with backlight and pointing stick for use in Greece (includes keyboard cable, backlight cable, and
pointing stick cable)
733688-161 A Keyboard with backlight and pointing stick for use in Latin America (includes keyboard cable, backlight
cable, and pointing stick cable)
733688-171 A Keyboard with backlight and pointing stick for use in Saudi Arabia (includes keyboard cable, backlight cable,
and pointing stick cable)
733688-201 A Keyboard with backlight and pointing stick for use in Brazil (includes keyboard cable, backlight cable, and
pointing stick cable)
733688-211 A Keyboard with backlight and pointing stick for use in Hungary (includes keyboard cable, backlight cable, and
pointing stick cable)
733688-251 A Keyboard with backlight and pointing stick for use in Russia (includes keyboard cable, backlight cable, and
pointing stick cable)
733688-261 A Keyboard with backlight and pointing stick for use in Bulgaria (includes keyboard cable, backlight cable, and
pointing stick cable)
733688-271 A Keyboard with backlight and pointing stick for use in Romania (includes keyboard cable, backlight cable,
and pointing stick cable)
733688-281 A Keyboard with backlight and pointing stick for use in Thailand (includes keyboard cable, backlight cable,
and pointing stick cable)
733688-291 A Keyboard with backlight and pointing stick for use in Japan (includes keyboard cable, backlight cable, and
pointing stick cable)
733688-541 A Keyboard with backlight and pointing stick for use in Turkey F (includes keyboard cable, backlight cable,
and pointing stick cable)
733688-A41 A Keyboard with backlight and pointing stick for use in Belgium (includes keyboard cable, backlight cable, and
pointing stick cable)
733688-AB1 A Keyboard with backlight and pointing stick for use in Taiwan (includes keyboard cable, backlight cable, and
pointing stick cable)
733688-AD1 A Keyboard with backlight and pointing stick for use in South Korea (includes keyboard cable, backlight cable,
and pointing stick cable)
733688-B31 A Keyboard with backlight and pointing stick for use in the Netherlands (includes keyboard cable, backlight
cable, and pointing stick cable)
Sequential part number listing 33
Spare part
number
CSR
flag
Description
733688-B71 A Keyboard with backlight and pointing stick for use in Sweden and Finland (includes keyboard cable,
backlight cable, and pointing stick cable)
733688-BA1 A Keyboard with backlight and pointing stick for use in Slovenia (includes keyboard cable, backlight cable,
and pointing stick cable)
733688-BB1 A Keyboard with backlight and pointing stick for use in Israel (includes keyboard cable, backlight cable, and
pointing stick cable)
733688-BG1 A Keyboard with backlight and pointing stick for use in Switzerland (includes keyboard cable, backlight cable,
and pointing stick cable)
733688-D61 A Keyboard with backlight and pointing stick for use in India (includes keyboard cable, backlight cable, and
pointing stick cable)
733688-DB1 A Keyboard with backlight and pointing stick for use in Canada (includes keyboard cable, backlight cable, and
pointing stick cable)
733688-DD1 A Keyboard with backlight and pointing stick for use in Iceland (includes keyboard cable, backlight cable, and
pointing stick cable)
733688-FL1 A Keyboard with backlight and pointing stick for use in the Czech Republic and Slovakia (includes keyboard
cable, backlight cable, and pointing stick cable)
733688-FP1 A Keyboard with backlight and pointing stick for use in Northwest Africa (includes keyboard cable, backlight
cable, and pointing stick cable)
734278-001 A Service cover
734280-001 A Hard Drive Hardware Kit
734281-001 N Top cover (includes TouchPad, TouchPad cable, and TouchPad bracket)
734282-001 N Screw Kit
734284-001 N Function button board (includes cable and double-sided adhesive)
734285-001 N Power button board (includes cable)
734286-001 N Fingerprint reader board (includes cable and double-sided adhesive)
734288-001 N Audio/USB board (includes SD Card reader)
734289-001 N Fan/heat sink assembly for use only with an NVIDIA Quadro K1100M NVIDIA N15P-Q1 graphics board
(includes replacement thermal material)
734290-001 N Fan/heat sink assembly for use only with an NVIDIA Quadro K610M NVIDIA N15M-Q2 graphics board
(includes replacement thermal material)
734291-001 N Fan/heat sink assembly for use only with an NVIDIA Quadro K2100M NVIDIA N15P-Q3 graphics board
(includes replacement thermal material)
734292-001 N Speakers
734293-001 N USB board (includes cable and double-sided adhesive)
734294-001 N Display hinge cover (includes HP logo)
734297-001 N Plastics Kit
734298-001 A Hard drive upgrade bay
734299-001 N Bracket Kit
734300-001 N RTC battery (includes cable and double-sided adhesive)
34 Chapter 3 Illustrated parts catalog
Spare part
number
CSR
flag
Description
734301-001 N Display bezel for use only on computer models equipped with a webcamera
734302-001 N Display bezel for use only on computer models not equipped with a webcamera
735370-001 N Microphone module (includes double-sided adhesive)
735599-001 A Blu-ray ROM DVD±RW SuperMulti Double-Layer Drive
735600-001 A Blu-ray R/RE DVD±RW SuperMulti Double-Layer Drive
735602-001 A DVD±RW SuperMulti Double-Layer Drive
735604-001 N 15.6-in, FHD, SVA, LED display panel
735607-001 N 15.6-in, FHD, UWVA, LED display panel
735964-001 N 15.6-in, FHD, UWVA, DreamVision display assembly not equipped with a webcamera
735965-001 N 15.6-in, FHD, UWVA, DreamVision display assembly equipped with a webcamera
740011-001 A HP lt4111 LTE/EV-DO/HSPA+ Mobile Broadband Module (for use in the United States and Canada)
742159-001 N Smart card reader (includes cable)
745663-001 A Keyboard with pointing stick for use in the United States (includes keyboard cable and pointing stick cable)
745663-031 A Keyboard with pointing stick for use in the United Kingdom and Singapore (includes keyboard cable and
pointing stick cable)
745663-041 A Keyboard with pointing stick for use in Germany (includes keyboard cable and pointing stick cable)
745663-051 A Keyboard with pointing stick for use in France (includes keyboard cable and pointing stick cable)
745663-061 A Keyboard with pointing stick for use in Italy (includes keyboard cable and pointing stick cable)
745663-071 A Keyboard with pointing stick for use in Spain (includes keyboard cable and pointing stick cable)
745663-081 A Keyboard with pointing stick for use in Denmark (includes keyboard cable and pointing stick cable)
745663-091 A Keyboard with pointing stick for use in Norway (includes keyboard cable and pointing stick cable)
745663-131 A Keyboard with pointing stick for use in Portugal (includes keyboard cable and pointing stick cable)
745663-141 A Keyboard with pointing stick for use in Turkey (includes keyboard cable and pointing stick cable)
745663-151 A Keyboard with pointing stick for use in Greece (includes keyboard cable and pointing stick cable)
745663-161 A Keyboard with pointing stick for use in Latin America (includes keyboard cable and pointing stick cable)
745663-171 A Keyboard with pointing stick for use in Saudi Arabia (includes keyboard cable and pointing stick cable)
745663-201 A Keyboard with pointing stick for use in Brazil (includes keyboard cable and pointing stick cable)
745663-211 A Keyboard with pointing stick for use in Hungary (includes keyboard cable and pointing stick cable)
745663-251 A Keyboard with pointing stick for use in Russia (includes keyboard cable and pointing stick cable)
745663-261 A Keyboard with pointing stick for use in Bulgaria (includes keyboard cable and pointing stick cable)
745663-271 A Keyboard with pointing stick for use in Romania (includes keyboard cable and pointing stick cable)
745663-281 A Keyboard with pointing stick for use in Thailand (includes keyboard cable and pointing stick cable)
745663-291 A Keyboard with pointing stick for use in Japan (includes keyboard cable and pointing stick cable)
745663-541 A Keyboard with pointing stick for use in Turkey F (includes keyboard cable and pointing stick cable)
Sequential part number listing 35
Spare part
number
CSR
flag
Description
745663-A41 A Keyboard with pointing stick for use in Belgium (includes keyboard cable and pointing stick cable)
745663-AB1 A Keyboard with pointing stick for use in Taiwan (includes keyboard cable and pointing stick cable)
745663-AD1 A Keyboard with pointing stick for use in South Korea (includes keyboard cable and pointing stick cable)
745663-B31 A Keyboard with pointing stick for use in the Netherlands (includes keyboard cable and pointing stick cable)
745663-B71 A Keyboard with pointing stick for use in Sweden and Finland (includes keyboard cable and pointing
stick cable)
745663-BA1 A Keyboard with pointing stick for use in Slovenia (includes keyboard cable and pointing stick cable)
745663-BB1 A Keyboard with pointing stick for use in Israel (includes keyboard cable and pointing stick cable)
745663-BG1 A Keyboard with pointing stick for use in Switzerland (includes keyboard cable and pointing stick cable)
745663-DB1 A Keyboard with pointing stick for use in Canada (includes keyboard cable and pointing stick cable)
745663-DD1 A Keyboard with pointing stick for use in Iceland (includes keyboard cable and pointing stick cable)
745663-FL1 A Keyboard with pointing stick for use in the Czech Republic and Slovakia (includes keyboard cable and
pointing stick cable)
745663-FP1 A Keyboard with pointing stick for use in Northwest Africa (includes keyboard cable and pointing stick cable)
747833-001 A Intel Dual Band Wireless-N 7260AN 802.11 a/b/g/n (2x2) WiFi + BT 4.0 combo (for use in Indonesia)
748021-001 A HP lt4111 LTE/EV-DO/HSPA+ Mobile Broadband Module
748599-001 A HP hs3110 HSPA+ Mobile Broadband Module
749288-001 A HP DisplayPort to HDMI 1.4 Adapter
755530-AB1 A Power cord for use in Taiwan (3-pin, black, 1.00-m)
765141-001 N Intel Quad Core i7-4610M 3.00-GHz (SC turbo up to 3.70-GHz) processor (1600-MHz FSB, 4.0-MB L3 cache,
37 W; includes replacement thermal material)
765142-001 N Intel Dual Core i5-4340M 2.90-GHz (SC turbo up to 3.60-GHz) processor (1600-MHz FSB, 3.0-MB L3 cache,
37 W; includes replacement thermal material)
766644-001 A 1-TB, 7200-rpm, SATA, 9.5-mm hard drive (does not include hard drive bracket or screws)
768420-001 N Intel Dual Core i5-4210M 2.60-GHz (SC turbo up to 3.20-GHz) processor (1600-MHz FSB, 3.0-MB L3 cache,
37 W; includes replacement thermal material)
773212-001 N Intel Quad Core i7-4710MQ 2.50-GHz (SC turbo up to 3.50-GHz) processor (1600-MHz FSB, 6.0-MB L3 cache,
47 W; includes replacement thermal material)
778191-001 A 750-GB, 7200-rpm, SATA, 2.5-in hard drive (does not include hard drive bracket or screws)
778192-001 A 1-TB, 5400-rpm, SATA, 2.5-in hard drive (does not include hard drive bracket or screws)
778692-001 N Intel Quad Core i7-4810MQ 2.80-GHz (SC turbo up to 3.80-GHz) processor (1600-MHz FSB, 6.0-MB L3 cache,
47 W; includes replacement thermal material)
778693-001 N Intel Quad Core i7-4910MQ 2.90-GHz (SC turbo up to 3.90-GHz) processor (1600-MHz FSB, 8.0-MB L3 cache,
47 W; includes replacement thermal material)
784208-001 N Webcamera/microphone module (includes double-sided adhesive)
784464-001 C Hinge Kit (includes left and right hinges and display panel cable bracket)
784466-001 C Display Panel Support Kit (includes display enclosure, display panel cable, and wireless antenna cables and
transceivers)
36 Chapter 3 Illustrated parts catalog
Spare part
number
CSR
flag
Description
784467-001 N System board for use only on computer models equipped with an Intel Dual Core processor and without the
Windows operating system (includes battery connector bracket and replacement thermal material)
784467-501 N System board for use only on computer models equipped with an Intel Dual Core processor and the
Windows 8 Standard operating system (includes battery connector bracket and replacement
thermal material)
784467-601 N System board for use only on computer models equipped with an Intel Dual Core processor and the
Windows 8 Professional operating system (includes battery connector bracket and replacement
thermal material)
784468-001 N System board for use only on computer models equipped with an Intel Quad Core processor and without the
Windows operating system (includes battery connector bracket and replacement thermal material)
784468-501 N System board for use only on computer models equipped with an Intel Quad Core processor and the
Windows 8 Standard operating system (includes battery connector bracket and replacement
thermal material)
784468-601 N System board for use only on computer models equipped with an Intel Quad Core processor and the
Windows 8 Professional operating system (includes battery connector bracket and replacement
thermal material)
784469-001 C Fan/heat sink assembly for use only with an AMD FirePro M5100 graphics board, spare part number
784470-001
784470-001 C AMD FirePro M5100 graphics board
784471-001 N Display bezel for use only on computer models equipped with a QHD+ display and a webcamera
784472-001 N Display bezel for use only on computer models not equipped with a QHD+ display and a webcamera
784473-001 N Display bezel for use only on computer models equipped with an Innolux display and a webcamera
784474-001 N Display bezel for use only on computer models not equipped with an Innolux display and a webcamera
785221-001 N base enclosure
785222-001 N Cable Kit (includes power connector cable and RJ-45 (network) cable and replacement thermal material)
785223-001 N NVIDIA Quadro K1100M NVIDIA N15P-Q1 graphics board
785224-001 N NVIDIA Quadro K2100M NVIDIA N15P-Q3 graphics board
785225-001 N NVIDIA Quadro K610M NVIDIA N15M-Q2 graphics board
794579-001 N ExpressCard assembly (includes activity LEDs and Thunderbolt port, Dual Mode DisplayPort, and USB port)
795955-001 A 256-GB solid-state drive (SSD), M.2
795956-001 A 128-GB, SATA-3, solid-state drive (SSD), 2.5-inch
795957-001 A 180-GB, SATA-3, solid-state drive (SSD), 2.5-inch
795958-001 A 240-GB, SATA-3, solid-state drive (SSD), 2.5-inch
795959-001 A 256-GB, SATA-3, solid-state drive (SSD), 2.5-inch
795960-001 A 256-GB, SATA-3, solid-state drive (SSD), 2.5-inch, self-encrypting (SED) OPAL 1
795961-001 A 256-GB, SATA-3, solid-state drive (SSD), 2.5-inch, self-encrypting (SED) OPAL 2
795962-001 A 512-GB, SATA-3, solid-state drive (SSD), 2.5-inch
797849-001 N 15.6-in, FHD, UWVA, LED display panel
Sequential part number listing 37
4 Removal and replacement procedures
preliminary requirements
Tools required
You will need the following tools to complete the removal and replacement procedures:
●
Flat-bladed screw driver
●
Magnetic screw driver
●
Phillips P0 and P1 screw drivers
Service considerations
The following sections include some of the considerations that you must keep in mind during disassembly
and assembly procedures.
NOTE: As you remove each subassembly from the computer, place the subassembly (and all accompanying
screws) away from the work area to prevent damage.
Plastic parts
CAUTION: Using excessive force during disassembly and reassembly can damage plastic parts. Use care
when handling the plastic parts. Apply pressure only at the points designated in the
maintenance instructions.
38 Chapter 4 Removal and replacement procedures preliminary requirements
Cables and connectors
CAUTION: When servicing the computer, be sure that cables are placed in their proper locations during the
reassembly process. Improper cable placement can damage the computer.
Cables must be handled with extreme care to avoid damage. Apply only the tension required to unseat or
seat the cables during removal and insertion. Handle cables by the connector whenever possible. In all cases,
avoid bending, twisting, or tearing cables. Be sure that cables are routed in such a way that they cannot be
caught or snagged by parts being removed or replaced. Handle flex cables with extreme care; these cables
tear easily.
Drive handling
CAUTION: Drives are fragile components that must be handled with care. To prevent damage to
the computer, damage to a drive, or loss of information, observe these precautions:
Before removing or inserting a hard drive, shut down the computer. If you are unsure whether the computer
is off or in Hibernation, turn the computer on, and then shut it down through the operating system.
Before handling a drive, be sure that you are discharged of static electricity. While handling a drive, avoid
touching the connector.
Before removing a diskette drive or optical drive, be sure that a diskette or disc is not in the drive and be sure
that the optical drive tray is closed.
Handle drives on surfaces covered with at least one inch of shock-proof foam.
Avoid dropping drives from any height onto any surface.
After removing a hard drive, an optical drive, or a diskette drive, place it in a static-proof bag.
Avoid exposing an internal hard drive to products that have magnetic fields, such as monitors or speakers.
Avoid exposing a drive to temperature extremes or liquids.
If a drive must be mailed, place the drive in a bubble pack mailer or other suitable form of protective
packaging and label the package “FRAGILE.”
Grounding guidelines
Electrostatic discharge damage
Electronic components are sensitive to electrostatic discharge (ESD). Circuitry design and structure
determine the degree of sensitivity. Networks built into many integrated circuits provide some protection,
but in many cases, ESD contains enough power to alter device parameters or melt silicon junctions.
A discharge of static electricity from a finger or other conductor can destroy static-sensitive devices or
microcircuitry. Even if the spark is neither felt nor heard, damage may have occurred.
An electronic device exposed to ESD may not be affected at all and can work perfectly throughout a normal
cycle. Or the device may function normally for a while, then degrade in the internal layers, reducing its life
expectancy.
Grounding guidelines 39
CAUTION: To prevent damage to the computer when you are removing or installing internal components,
observe these precautions:
Keep components in their electrostatic-safe containers until you are ready to install them.
Before touching an electronic component, discharge static electricity by using the guidelines described in this
section.
Avoid touching pins, leads, and circuitry. Handle electronic components as little as possible.
If you remove a component, place it in an electrostatic-safe container.
The following table shows how humidity affects the electrostatic voltage levels generated by
different activities.
CAUTION: A product can be degraded by as little as 700 V.
Typical electrostatic voltage levels
Relative humidity
Event 10% 40% 55%
Walking across carpet 35,000 V 15,000 V 7,500 V
Walking across vinyl floor 12,000 V 5,000 V 3,000 V
Motions of bench worker 6,000 V 800 V 400 V
Removing DIPS from plastic tube 2,000 V 700 V 400 V
Removing DIPS from vinyl tray 11,500 V 4,000 V 2,000 V
Removing DIPS from Styrofoam 14,500 V 5,000 V 3,500 V
Removing bubble pack from PCB 26,500 V 20,000 V 7,000 V
Packing PCBs in foam-lined box 21,000 V 11,000 V 5,000 V
40 Chapter 4 Removal and replacement procedures preliminary requirements
Packaging and transporting guidelines
Follow these grounding guidelines when packaging and transporting equipment:
●
To avoid hand contact, transport products in static-safe tubes, bags, or boxes.
●
Protect ESD-sensitive parts and assemblies with conductive or approved containers or packaging.
●
Keep ESD-sensitive parts in their containers until the parts arrive at static-free workstations.
●
Place items on a grounded surface before removing items from their containers.
●
Always be properly grounded when touching a component or assembly.
●
Store reusable ESD-sensitive parts from assemblies in protective packaging or nonconductive foam.
●
Use transporters and conveyors made of antistatic belts and roller bushings. Be sure that mechanized
equipment used for moving materials is wired to ground and that proper materials are selected to avoid
static charging. When grounding is not possible, use an ionizer to dissipate electric charges.
Workstation guidelines
Follow these grounding workstation guidelines:
●
Cover the workstation with approved static-shielding material.
●
Use a wrist strap connected to a properly grounded work surface and use properly grounded tools and
equipment.
●
Use conductive field service tools, such as cutters, screw drivers, and vacuums.
●
When fixtures must directly contact dissipative surfaces, use fixtures made only of static-safe
materials.
●
Keep the work area free of nonconductive materials, such as ordinary plastic assembly aids
and Styrofoam.
●
Handle ESD-sensitive components, parts, and assemblies by the case or PCM laminate. Handle these
items only at static-free workstations.
●
Avoid contact with pins, leads, or circuitry.
●
Turn off power and input signals before inserting or removing connectors or test equipment.
Grounding guidelines 41
Equipment guidelines
Grounding equipment must include either a wrist strap or a foot strap at a grounded workstation.
●
When seated, wear a wrist strap connected to a grounded system. Wrist straps are flexible straps with a
minimum of one megohm ±10% resistance in the ground cords. To provide proper ground, wear a strap
snugly against the skin at all times. On grounded mats with banana-plug connectors, use alligator clips
to connect a wrist strap.
●
When standing, use foot straps and a grounded floor mat. Foot straps (heel, toe, or boot straps) can be
used at standing workstations and are compatible with most types of shoes or boots. On conductive
floors or dissipative floor mats, use foot straps on both feet with a minimum of one megohm resistance
between the operator and ground. To be effective, the conductive must be worn in contact with the
skin.
The following grounding equipment is recommended to prevent electrostatic damage:
●
Antistatic tape
●
Antistatic smocks, aprons, and sleeve protectors
●
Conductive bins and other assembly or soldering aids
●
Nonconductive foam
●
Conductive tabletop workstations with ground cords of one megohm resistance
●
Static-dissipative tables or floor mats with hard ties to the ground
●
Field service kits
●
Static awareness labels
●
Material-handling packages
●
Nonconductive plastic bags, tubes, or boxes
●
Metal tote boxes
●
Electrostatic voltage levels and protective materials
The following table lists the shielding protection provided by antistatic bags and floor mats.
Material Use Voltage protection level
Antistatic plastics Bags 1,500 V
Carbon-loaded plastic Floor mats 7,500 V
Metallized laminate Floor mats 5,000 V
42 Chapter 4 Removal and replacement procedures preliminary requirements
5 Removal and replacement procedures for
Customer Self-Repair parts
NOTE: The Customer Self-Repair program is not available in all locations. Installing a part not supported by
the Customer Self-Repair program may void your warranty. Check your warranty to determine if Customer
Self-Repair is supported in your location.
Component replacement procedures
NOTE: Please read and follow the procedures described here to access and replace Customer Self-Repair
parts successfully.
NOTE: Details about your computer, including model, serial number, product key, and length of warranty,
are on the service tag at the bottom of your computer. See Service tag on page 16 for details.
This chapter provides removal and replacement procedures for Customer Self-Repair parts.
There are as many as 16 screws that must be removed, replaced, and/or loosened when servicing Customer
Self-Repair parts. Make special note of each screw size and location during removal and replacement.
Component replacement procedures 43
Battery
Description Spare part number
9-cell, 100-WHr, 3.0-AHr, Li-ion battery 634087-001
9-cell, 73-WHr, 2.2-AHr, Li-ion battery 634089-001
8-cell, 83-WHr, 2.8-AHr, Li-ion battery 708456-001
8-cell, 75-WHr, 2.8-AHr, Li-ion battery 708455-001
Before removing the battery, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
Remove the battery:
WARNING! To reduce potential safety issues, use only the user-replaceable battery provided with the
computer, a replacement battery provided by HP, or a compatible battery purchased from HP.
CAUTION: Removing a user-replaceable battery that is the sole power source for the computer can cause
loss of information. To prevent loss of information, save your work or shut down the computer through
Windows before removing the battery.
1. Turn the computer upside down on a flat surface.
2. Slide the battery release latch (1) to release the battery.
NOTE: The battery release latch automatically returns to its original position.
3. Pivot the battery (2) upward.
4. Remove the battery (3) from the computer.
Reverse this procedure to install the battery.
44 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
Service cover
Description Spare part number
Service cover 734278-001
Before removing the service cover, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44).
Remove the service cover:
1. Slide the service cover release latch to the left (1), and then remove the optional Phillips PM2.0×4.5
screw (if the screw is being used) (2).
NOTE: If you want to use the optional screw, it is stored inside the service cover.
2. Slide the release latch again (3) to release the service cover.
3. Slide the service cover toward the front of the computer (4), and then lift to remove the service cover
(5).
Reverse this procedure to install the service cover.
Component replacement procedures 45
Hard drive
NOTE: The hard drive spare part kit does not include the hard drive bracket or screws. These components
are included in the Hard Drive Hardware Kit, spare part number 734280-001.
Description Spare part number
Hard drive, 2.5-inch
1-TB, 7200-rpm, 9.5-mm 766644-001
1-TB, 5400-rpm, 2.5-in 778192-001
750-GB, 7200-rpm, 2.5-in 778191-001
500-GB, 7200-rpm, 7.0-mm 703267-001
500-GB, 5400-rpm, 7.0-mm, FIPS 730946-001
500-GB, 7200-rpm, 7.0-mm, self-encrypting 703268-001
Solid-state drive (SSD), 2.5-inch
512-GB, SATA-3 795962-001
256-GB, SATA-3 795959-001
256-GB, SATA-3, self-encrypting drive (SED), OPAL 1 795960-001
256-GB, SATA-3, self-encrypting drive (SED), OPAL 2 795961-001
240-GB, SATA-3 795958-001
180-GB, SATA-3 795957-001
128-GB, SATA-3 795956-001
Before removing the hard drive, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44).
5. Remove the service cover (see
Service cover on page 45).
Remove the hard drive:
1. Loosen the 3 hard drive captive screws (1).
2. Pull the hard drive tab (2) to the left to disconnect the hard drive.
46 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
3. Lift the hard drive (3), and then pull the hard drive out of the hard drive bay.
4. If it is necessary to disassemble the hard drive, perform the following steps:
a. Position the hard drive with the hard drive tab toward you.
b. Remove the four Phillips PM3.0×3.5 screws (1) that secure the hard drive bracket to the
hard drive.
c. Remove the hard drive bracket (2) from the hard drive.
The hard drive bracket and screws are available in the Hard Drive Hardware Kit, spare part number
734280-001.
Component replacement procedures 47
Reverse this procedure to install the hard drive.
Optical drive
NOTE: The optical drive spare part kit includes a bezel and bracket.
Description Spare part number
Blu-ray R/RE DVD±RW SuperMulti Double-Layer Drive 735600-001
Blu-ray ROM DVD±RW SuperMulti Double-Layer Drive 735599-001
DVD±RW SuperMulti Double-Layer Drive 735602-001
Hard drive upgrade bay 734298-001
Before removing the optical drive, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44).
5. Remove the service cover (see
Service cover on page 45).
Remove the optical drive:
1. Position the computer with the left side toward you.
2. Loosen the captive screw (1) that secures the optical drive to the computer.
48 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
3. Insert a thin tool into the optical drive tab access (2) and press the tab to the left to release the optical
drive from the computer.
4. Remove the optical drive (3).
Reverse this procedure to install the optical drive.
Component replacement procedures 49
WWAN module
Description Spare part number
HP lt4111 LTE/EV-DO/HSPA+ Mobile Broadband Module (for use in the United States and Canada) 740011-001
HP lt4111 LTE/EV-DO/HSPA+ Mobile Broadband Module 748021-001
HP hs3110 HSPA+ Mobile Broadband Module 748599-001
CAUTION: To prevent an unresponsive system, replace the wireless module only with a wireless module
authorized for use in the computer by the governmental agency that regulates wireless devices in your
country or region. If you replace the module and then receive a warning message, remove the module to
restore device functionality, and then contact technical support.
Before removing the WWAN module, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44).
5. Remove the service cover (see
Optical drive on page 48).
Remove the WWAN module:
1. Disconnect the WWAN antenna cables (1) from the terminals on the WWAN module.
NOTE: The WWAN antenna cable labeled “5” connects to the WWAN module “Main” terminal labeled
“5”. The WWAN antenna cable labeled “6” connects to the WWAN module “Aux/GPS” terminal labeled
“6”.
2. Remove the Phillips PM2.0×3.25 screw (2) that secures the WWAN module to the system board. (The
WWAN module tilts up.)
50 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
3. Remove the WWAN module (3) by pulling the module away from the slot at an angle.
NOTE: If the WWAN antenna cables are not connected to the terminals on the WWAN module, protective
sleeves should be installed on the antenna connectors, as shown in the following illustration.
Reverse this procedure to install the WWAN module.
Component replacement procedures 51
Solid-state drive (M.2)
Description Spare part number
256-GB SATA-3 self-encrypting SSD 795955-001
Before removing the solid-state drive, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44).
5. Remove the service cover (see
Service cover on page 45).
Remove the solid-state drive:
1. Remove the Phillips PM2.0×3.5 screw (1) that secures the solid-state drive to the system board.
2. Remove the solid-state drive (2) by pulling the drive away from the slot at an angle.
Reverse this procedure to install the solid-state drive.
52 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
WLAN module
Description Spare part number
Intel Dual Band Wireless-AC 7260 802.11 AC 2x2 WiFi + BT 4.0 Combo Adapter 710663-001
Intel Dual Band Wireless-N 7260AN 802.11 a/b/g/n (2x2) WiFi + BT 4.0 combo 717379-001
Intel Dual Band Wireless-N 7260NB 802.11 a/b/g/n (2x2) WiFi 717380-001
Intel Dual Band Wireless-N 7260AN 802.11 a/b/g/n (2x2) WiFi + BT 4.0 combo (for use in Indonesia) 747833-001
CAUTION: To prevent an unresponsive system, replace the wireless module only with a wireless module
authorized for use in the computer by the governmental agency that regulates wireless devices in your
country or region. If you replace the module and then receive a warning message, remove the module to
restore device functionality, and then contact technical support.
Before removing the WLAN module, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44).
5. Remove the service cover (see
Service cover on page 45).
Remove the WLAN module:
1. Disconnect the WLAN antenna cables (1) from the terminals on the WLAN module.
NOTE: The WLAN antenna cable labeled “1” connects to the WLAN module “Main” terminal labeled
“1”. The WLAN antenna cable labeled “2” connects to the WLAN module “Aux” terminal labeled “2”.
2. Remove the Phillips PM2.0×3.0 screw (2) that secures the WLAN module to the system board. (The
WLAN module tilts up.)
Component replacement procedures 53
3. Remove the WLAN module (3) by pulling the module away from the slot at an angle.
NOTE: If the WLAN antenna cables are not connected to the terminals on the WLAN module, protective
sleeves should be installed on the antenna connectors, as shown in the following illustration.
Reverse this procedure to install the WLAN module.
54 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
Primary memory module
Description Spare part number
8-GB (PC3L, 12800, 1600-MHz) 693374-001
4-GB (PC3L, 12800, 1600-MHz) 691740-001
Update BIOS before adding memory modules
Before adding new memory, make sure you update the computer to the latest BIOS.
CAUTION: Failure to update the computer to the latest BIOS prior to installing new memory may result in
various system problems.
To update BIOS:
1. Navigate to
www.hp.com.
2. Click Support & Drivers > click Drivers & Software.
3. In the Enter a product name/number box, type the computer model information, and then click Search.
4. Click the link for the computer model.
5. Select the operating system, and then click Next.
6. Under Step 2: Select a Download, click the BIOS link.
7. Click the link for the most recent BIOS.
8. Click the Download button, and then follow the on-screen instructions.
Before removing a memory module, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44).
5. Remove the service cover (see
Optical drive on page 48).
Remove the memory module:
1. Spread the retaining tabs (1) on each side of the memory module slot to release the memory module.
(The memory module tilts up.)
Component replacement procedures 55
2. Remove the memory module (2) by pulling the module away from the slot at an angle.
Reverse this procedure to install a memory module.
56 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
Keyboard
For use in country or region Spare part
number
For use in country or region Spare part number
Keyboard with backlight and pointing stick (includes keyboard cable, backlight cable, and pointing stick cable):
For use in Belgium 733688-A41 For use in Northwest Africa 733688-FP1
For use in Brazil 733688-201 For use in Norway 733688-091
For use in Bulgaria 733688-261 For use in Portugal 733688-131
For use in Canada 733688-DB1 For use in Romania 733688-271
For use in the Czech Republic and Slovakia 733688-FL1 For use in Russia 733688-251
For use in Denmark 733688-081 For use in Saudi Arabia 733688-171
For use in France 733688-051 For use in Slovenia 733688-BA1
For use in Germany 733688-041 For use in South Korea 733688-AD1
For use in Greece 733688-151 For use in Spain 733688-071
For use in Hungary 733688-211 For use in Sweden and Finland 733688-B71
For use in Iceland 733688-DD1 For use in Switzerland 733688-BG1
For use in India 733688-D61 For use in Taiwan 733688-AB1
For use in Israel 733688-BB1 For use in Thailand 733688-281
For use in Italy 733688-061 For use in Turkey
For use in Turkey F
733688-141
733688-541
For use in Japan 733688-291 For use in the United Kingdom
and Singapore
733688-031
For use in Latin America 733688-161 For use in the United States 733688-001
For use in the Netherlands 733688-B31
Keyboard with pointing stick (includes keyboard cable and pointing stick cable):
For use in Belgium 745663-A41 For use in Northwest Africa 745663-FP1
For use in Brazil 745663-201 For use in Norway 745663-091
For use in Bulgaria 745663-261 For use in Portugal 745663-131
For use in Canada 745663-DB1 For use in Romania 745663-271
For use in the Czech Republic and Slovakia 745663-FL1 For use in Russia 745663-251
For use in Denmark 745663-081 For use in Saudi Arabia 745663-171
For use in France 745663-051 For use in Slovenia 745663-BA1
For use in Germany 745663-041 For use in South Korea 745663-AD1
For use in Greece 745663-151 For use in Spain 745663-071
For use in Hungary 745663-211 For use in Sweden and Finland 745663-B71
For use in Iceland 745663-DD1 For use in Switzerland 745663-BG1
For use in Israel 745663-BB1 For use in Taiwan 745663-AB1
Component replacement procedures 57
For use in country or region Spare part
number
For use in country or region Spare part number
For use in Italy 745663-061 For use in Thailand 745663-281
For use in Japan 745663-291 For use in Turkey
For use in Turkey F
745663-141
745663-541
For use in Latin America 745663-161 For use in the United Kingdom
and Singapore
745663-031
For use in the Netherlands 745663-B31 For use in the United States 745663-001
Before removing the keyboard, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44).
5. Remove the service cover (see
Service cover on page 45).
6. Remove the optical drive (see
Optical drive on page 48).
Remove the keyboard:
1. Loosen the two captive screws that secure the keyboard to the computer.
2. Partially open the computer.
3. Rest and secure the computer on its left side.
58 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
4. Insert a thin tool into the keyboard release hole in the optical drive bay, and then press on the back of
the keyboard until the keyboard disengages from the computer.
5. Turn the computer right-side up, with the front toward you.
6. Open the computer as far as it will open.
7. Lift the rear edge of the keyboard until it rests at an angle.
8. Swing the rear edge of the keyboard (1) up and forward until it rests upside down on the palm rest.
9. Release the zero insertion force (ZIF) connector (2) to which the keyboard cable is attached, and then
disconnect the keyboard cable from the system board.
10. Release the ZIF connector (3) to which the pointing stick cable is attached, and then disconnect the
pointing stick cable from the system board.
Component replacement procedures 59
11. Remove the keyboard (4).
Reverse this procedure to install the keyboard.
60 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
Expansion memory module
Description Spare part number
8-GB (PC3L, 12800, 1600-MHz) 693374-001
4-GB (PC3L, 12800, 1600-MHz) 691740-001
Update BIOS before adding memory modules
Before adding new memory, make sure you update the computer to the latest BIOS.
CAUTION: Failure to update the computer to the latest BIOS prior to installing new memory may result in
various system problems.
To update BIOS:
1. Navigate to
www.hp.com.
2. Click Support & Drivers > click Drivers & Software.
3. In the Enter a product name/number box, type the computer model information, and then click Search.
4. Click the link for the computer model.
5. Select the operating system, and then click Next.
6. Under Step 2: Select a Download, click the BIOS link.
7. Click the link for the most recent BIOS.
8. Click the Download button, and then follow the on-screen instructions.
Before removing a memory module, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44).
5. Remove the service cover (see
Optical drive on page 48).
Remove the memory module:
1. Spread the retaining tabs (1) on each side of the memory module slot to release the memory module.
(The memory module tilts up.)
Component replacement procedures 61
2. Remove the memory module (2) by pulling the module away from the slot at an angle.
Reverse this procedure to install a memory module.
62 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
6 Removal and replacement procedures for
Authorized Service Provider parts
CAUTION: Components described in this chapter should only be accessed by an authorized service provider.
Accessing these parts can damage the computer or void the warranty.
Component replacement procedures
This chapter provides removal and replacement procedures for Authorized Service Provider only parts.
There are as many as 74 screws that must be removed, replaced, and/or loosened when servicing the
computer. Make special note of each screw size and location during removal and replacement.
RTC battery
Description Spare part number
RTC battery (includes cable and double-sided adhesive) 734300-001
Before removing the RTC battery, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44).
5. Remove the service cover (see
Service cover on page 45).
Remove the RTC battery:
1. Disconnect the RTC battery cable (1) from the system board.
Component replacement procedures 63
2. Detach the RTC battery (2) from the base enclosure. (The RTC battery is attached to the base enclosure
with double-sided adhesive.)
3. Remove the RTC battery and cable.
Reverse this procedure to install the RTC battery.
64 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
Top cover
Description Spare part number
Top cover (includes TouchPad, TouchPad cable, and TouchPad bracket) 734281-001
Before removing the top cover, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44), and then remove the following components:
a. Service cover (see
Service cover on page 45)
b. Hard drive (see
Hard drive on page 46)
c. Optical drive (see
Optical drive on page 48)
d. Keyboard (see
Keyboard on page 57)
NOTE: When replacing the top cover, be sure to remove the following components from the defective top
cover and install them on the replacement top cover:
●
Function button board (see
Function button board on page 71)
●
Power button board (see
Power button board on page 73)
●
Fingerprint reader board (see
Fingerprint reader board on page 69)
Remove the top cover:
1. Close the computer.
2. Turn the computer upside down with the front toward you.
3. Remove the eight Torx T8M2.5×6.5 screws that secure the top cover to the computer.
Component replacement procedures 65
4. Remove the following screws that secure the top cover to the computer:
(1) Three Torx T8M2.5×4.5 screws in the optical drive bay
(2) Four Torx T8M2.5×4.5 screws in the battery bay
(3) Two Phillips PM2.0×3.0 screws in the hard drive bay
5. Turn the computer right side up with the front toward you.
6. Open the computer.
7. Release the ZIF connector (1) to which the power button board cable is attached, and then disconnect
the power button board cable from the system board.
8. Release the ZIF connector (2) to which the function button board cable is attached, and then disconnect
the function button board cable from the system board.
66 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
9. Remove the Torx T8M2.5×6.5 screw (3) that secures the top cover to the computer.
10. Lift the rear edge of the top cover (1) until the left and right sides and the front edge detach from the
computer.
11. Slide the top cover (2) forward until the fingerprint reader board cable and the TouchPad cable are
accessible.
12. Release the ZIF connector to which the fingerprint reader board cable is attached, and then disconnect
the fingerprint reader board cable (3) from the system board.
13. Release the ZIF connector to which the TouchPad cable is attached, and then disconnect the TouchPad
cable (4) from the system board.
Component replacement procedures 67
14. Remove the top cover (5).
Reverse this procedure to install the top cover.
68 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
Fingerprint reader board
Description Spare part number
Fingerprint reader board (includes cable and double-sided adhesive) 734286-001
Before removing the fingerprint reader board, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44), and then remove the following components:
a. Service cover (see
Service cover on page 45)
b. Hard drive (see
Hard drive on page 46)
c. Optical drive (see
Optical drive on page 48)
d. Keyboard (see
Keyboard on page 57)
e. Top cover (see
Top cover on page 65)
Remove the fingerprint reader board:
1. Turn the top cover upside down with the front toward you.
2. Remove the Phillips PM2.0×3.0 screw (1) that secures the fingerprint reader board and bracket to the
top cover.
3. Slide the fingerprint reader board (2) bracket forward and remove it.
The fingerprint reader board bracket is available in the Bracket Kit, spare part number 734299-001.
4. Detach the fingerprint reader board cable (3) from the top cover. (The fingerprint reader board cable is
attached to the top cover with double-sided adhesive.)
Component replacement procedures 69
5. Remove the fingerprint reader board (4) and cable.
Reverse this procedure to install the fingerprint reader board.
70 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
Function button board
Description Spare part number
Function button board (includes cable and double-sided adhesive) 734284-001
Before removing the function button board, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44), and then remove the following components:
a. Service cover (see
Service cover on page 45)
b. Hard drive (see
Hard drive on page 46)
c. Optical drive (see
Optical drive on page 48)
d. Keyboard (see
Keyboard on page 57)
e. Top cover (see
Top cover on page 65)
Remove the function button board:
1. Detach the function button board cable from the top cover. (The function button board cable is attached
to the top cover with double-sided adhesive.)
2. Turn the top cover upside down, with the front toward you.
3. Release the function button board cable through the opening (1) in the top cover.
4. Remove the Phillips PM2.0×3.0 screw (2) that secures the function button board to the top cover.
Component replacement procedures 71
5. Lift the right side of the function button board (3) until it rests at an angle.
6. Remove the function button board (4) by sliding it up and to the right at an angle.
Reverse this procedure to install the function button board.
72 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
Power button board
Description Spare part number
Power button board (includes cable) 734285-001
Before removing the power button board, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44), and then remove the following components:
a. Service cover (see
Service cover on page 45)
b. Hard drive (see
Hard drive on page 46)
c. Optical drive (see
Optical drive on page 48)
d. Keyboard (see
Keyboard on page 57)
e. Top cover (see
Top cover on page 65)
Remove the power button board:
1. Turn the top cover upside down, with the front toward you.
2. Remove the Phillips PM2.0×3.0 screw (1) that secures the power button board to the top cover.
3. Release the clips (2) that secure the power button board to the top cover.
4. Remove the power button board (3) and cable
Component replacement procedures 73
Reverse this procedure to install the power button board.
ExpressCard assembly
Description Spare part number
ExpressCard assembly (includes activity LEDs and Thunderbolt port, Dual Mode DisplayPort, and USB
port)
794579-001
Before removing the ExpressCard assembly, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44), and then remove the following components:
a. Service cover (see
Service cover on page 45)
b. Hard drive (see
Hard drive on page 46)
c. Optical drive (see
Optical drive on page 48)
d. Keyboard (see
Keyboard on page 57)
e. Top cover (see
Top cover on page 65)
Remove the ExpressCard assembly:
1. Remove the Torx T8M2.5×4.5 screw (1) that secures the system lens to the base enclosure.
2. Remove the system lens (2).
The system lens is available in the Plastics Kit, spare part number 734297-001.
3. Remove the three Torx T8M2.5×4.5 screws (3) that secure the ExpressCard assembly to the
base enclosure.
74 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
4. Disconnect the ExpressCard assembly (4) from the system board by lifting up on the right side of the
assembly.
5. Remove the the ExpressCard assembly.
Reverse this procedure to install the ExpressCard assembly.
Component replacement procedures 75
Smart card reader
Description Spare part number
Smart card reader (includes cable) 742159-001
Before removing the smart card reader, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44), and then remove the following components:
a. Service cover (see
Service cover on page 45)
b. Hard drive (see
Hard drive on page 46)
c. Optical drive (see
Optical drive on page 48)
d. Keyboard (see
Keyboard on page 57)
e. Top cover (see
Top cover on page 65)
f. ExpressCard assembly (see
ExpressCard assembly on page 74)
Remove the smart card reader:
1. Release the ZIF connector (1) to which the smart card reader cable is attached, and then disconnect the
smart card reader cable from the system board.
2. Remove the two Torx T8M2.5×4.5 screws (2) that secure the smart card reader to the base enclosure.
3. Remove the smart card reader (3).
76 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
Reverse this procedure to install the smart card reader and cable.
Audio/USB board
Description Spare part number
Audio/USB board (includes SD Card reader) 734288-001
Before removing the audio/USB board, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44), and then remove the following components:
a. Service cover (see
Service cover on page 45)
b. Hard drive (see
Hard drive on page 46)
c. Optical drive (see
Optical drive on page 48)
d. Keyboard (see
Keyboard on page 57)
e. Top cover (see
Top cover on page 65)
Remove the audio/USB board:
1. Remove the four Torx T8M2.5×4.5 screws (1) that secure the audio/USB board to the base enclosure.
Component replacement procedures 77
2. Disconnect the audio/USB board (2) from the system board by lifting up on the left side of the audio/
USB board.
3. Remove the audio/USB board.
Reverse this procedure to install the audio/USB board.
USB board
Description Spare part number
USB board (includes cable and double-sided adhesive) 734293-001
Before removing the USB board, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44), and then remove the following components:
a. Service cover (see
Service cover on page 45)
b. Hard drive (see
Hard drive on page 46)
c. Optical drive (see
Optical drive on page 48)
d. Keyboard (see
Keyboard on page 57)
e. Top cover (see
Top cover on page 65)
Remove the USB board:
78 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
1. Release the ZIF connector (1) to which the USB board cable is attached, and then disconnect the USB
board cable from the system board.
2. Detach the USB board cable (2) from the base enclosure. (The USB board cable is attached to the
base enclosure with double-sided adhesive.)
3. Remove the Torx T8M2.5×4.5 screw (3) that secures the USB board to the base enclosure.
4. Remove the USB board and cable.
Reverse this procedure to install the USB board.
Component replacement procedures 79
Speakers
Description Spare part number
Speakers (includes cable) 734292-001
Before removing the speakers, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44), and then remove the following components:
a. Service cover (see
Service cover on page 45)
b. Hard drive (see
Hard drive on page 46)
c. Optical drive (see
Optical drive on page 48)
d. Keyboard (see
Keyboard on page 57)
e. Top cover (see
Top cover on page 65)
Remove the speakers:
1. Disconnect the speaker cable (1) from the system board.
2. Remove the two Phillips PM2.0×3.0 screws (1) that secure the speakers to the base enclosure.
3. Remove the speakers (3) and cable.
Reverse this procedure to install the speakers.
80 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
Fan/heat sink assembly
NOTE: The fan/heat sink assembly spare part kit includes replacement thermal material.
Description Spare part number
For use only with an NVIDIA Quadro K1100M NVIDIA N15P-Q1 graphics board, spare part number
785223-001
734289-001
For use only with an NVIDIA Quadro K610M NVIDIA N15M-Q2 graphics board, spare part number
785225-001
734290-001
For use only with an NVIDIA Quadro K2100M NVIDIA N15P-Q3 graphics board, spare part number
785224-001
734291-001
For use only with an AMD FirePro M5100 graphics board, spare part number 784470-001 784469-001
Before removing the fan/heat sink assembly, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44), and then remove the following components:
a. Service cover (see
Service cover on page 45)
b. Hard drive (see
Hard drive on page 46)
c. Optical drive (see
Optical drive on page 48)
d. Keyboard (see
Keyboard on page 57)
e. Top cover (see
Top cover on page 65)
Remove the fan/heat sink assembly:
1. Disconnect the fan cable (1) from the system board.
2. Following the 1 through 4 sequence stamped into the processor heat sink, loosen the four Phillips
captive screws (2) that secure the processor heat sink to the system board.
3. Following the 5 through 8 sequence stamped into the graphics board heat sink, loosen the four Phillips
captive screws (3) that secure the graphics board heat sink to the system board.
Component replacement procedures 81
4. Remove the fan/heat sink assembly (4).
NOTE: Due to the adhesive quality of the thermal material located between the fan/heat sink
assembly and the system board components, it may be necessary to move the fan/heat sink assembly
from side to side to detach it.
NOTE: The thermal material must be thoroughly cleaned from the surfaces of the fan/heat sink assembly
and the system board components each time the fan/heat sink assembly is removed. Replacement thermal
material is included with the fan/heat sink assembly, processor, and system board spare part kits.
●
Various thermal pads are used on the graphics board components (1) and (7) and the heat sink sections
(2) and (8) that service them
●
Thermal paste is used on the processor (3) and the heat sink section (4) that services it
●
Thermal paste is used on the graphics board processor (5) and the heat sink section (6) that services it
82 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
Reverse this procedure to install the fan/heat sink assembly.
Component replacement procedures 83
Processor
NOTE: The processor spare part kit includes replacement thermal material.
Description Spare part number
Intel Quad Core i7-4910MQ 2.90-GHz (SC turbo up to 3.90-GHz) processor (1600-MHz FSB, 8.0-MB L3
cache, 47 W)
778693-001
Intel Quad Core i7-4810MQ 2.80-GHz (SC turbo up to 3.80-GHz) processor (1600-MHz FSB, 6.0-MB L3
cache, 47 W)
778692-001
Intel Quad Core i7-4710MQ 2.50-GHz (SC turbo up to 3.50-GHz) processor (1600-MHz FSB, 6.0-MB L3
cache, 47 W)
773212-001
Intel Quad Core i7-4610M 3.00-GHz (SC turbo up to 3.70-GHz) processor (1600-MHz FSB, 4.0-MB L3
cache, 37 W)
765141-001
Intel Dual Core i5-4340M 2.90-GHz (SC turbo up to 3.60-GHz) processor (1600-MHz FSB, 3.0-MB L3
cache, 37 W)
765142-001
Intel Dual Core i5-4210M 2.60-GHz (SC turbo up to 3.20-GHz) processor (1600-MHz FSB, 3.0-MB L3
cache, 37 W)
768420-001
Before removing the processor, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44), and then remove the following components:
a. Service cover (see
Service cover on page 45)
b. Hard drive (see
Hard drive on page 46)
c. Optical drive (see
Optical drive on page 48)
d. Keyboard (see
Keyboard on page 57)
e. Top cover (see
Top cover on page 65)
f. Fan/heat sink assembly (see
Fan/heat sink assembly on page 81)
Remove the processor:
1. Use a Torx8 screw driver (1) to turn the processor locking screw one-half turn counterclockwise (2),
until you hear a click.
84 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
2. Lift the processor (3) straight up, and remove it.
NOTE: The gold triangle (4) on the processor must be aligned with the triangle icon embossed on the
processor socket when you install the processor.
Reverse this procedure to install the processor.
Graphics board
NOTE: The graphics board spare part kit includes replacement thermal material.
Description Spare part number
NVIDIA Quadro K1100M NVIDIA N15P-Q1 graphics board 785223-001
NVIDIA Quadro K610M NVIDIA N15M-Q2 graphics board 785225-001
NVIDIA Quadro K2100M NVIDIA N15P-Q3 graphics board 785224-001
AMD FirePro M5100 graphics board 784470-001
Before removing the graphics board, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44), and then remove the following components:
a. Service cover (see
Service cover on page 45)
b. Hard drive (see
Hard drive on page 46)
Component replacement procedures 85
c. Optical drive (see Optical drive on page 48)
d. Keyboard (see
Keyboard on page 57)
e. Top cover (see
Top cover on page 65)
f. Fan/heat sink assembly (see
Fan/heat sink assembly on page 81)
Remove the graphics board:
1. Remove the two Torx T8M2.5×4.5 screws (1) that secure the graphics board to the system board. (The
graphics board tilts up.)
2. Remove the graphics board (2) by pulling the board away from the slot at an angle.
Reverse this procedure to install the graphics board.
86 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
Display assembly
NOTE: The DreamVision display assembly is spared as a whole unit assembly only. The LED display
assembly is spared at the subcomponent level only. For more LED display assembly spare part information,
see the individual removal subsections.
Description Spare part number
15.6-in, FHD, UWVA, DreamVision display assembly equipped with a webcamera 735965-001
15.6-in, FHD, UWVA, DreamVision display assembly not equipped with a webcamera 735964-001
To remove the display assembly and access the LED display assembly subcomponents, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 44), and then remove the following components:
a. Service cover (see
Service cover on page 45)
b. Hard drive (see
Hard drive on page 46)
c. Optical drive (see
Optical drive on page 48)
d. Keyboard (see
Keyboard on page 57)
e. Top cover (see
Top cover on page 65)
Remove the display assembly:
1. Close the computer.
2. Turn the computer upside down, with the rear toward you.
3. Make sure that the WWAN antenna cables are disconnected from the WWAN module (see
WWAN module
on page 50).
4. Make sure that the WLAN antenna cables are disconnected from the WLAN module (see
WLAN module
on page 53).
Component replacement procedures 87
5. Release the wireless antenna cables (1) from the routing clips (2) and channels built into the
base enclosure.
6. Turn the computer right side up, with the rear toward you.
7. Remove the four Torx T8M2.0×3.0 screws (1) that secure the hinge cover to the computer.
8. Remove the hinge cover (2).
The hinge cover is available using spare part number 734294-001.
88 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
9. Remove the two Torx T8M2.5×4.5 screws that secure the display assembly to the base enclosure.
10. Position the computer with the front toward you.
11. Open the computer as far as it will open.
12. Remove the Phillips PM2.0×3.0 screw (1) that secures the display panel cable and bracket to the system
board.
13. Remove the display panel cable bracket (2).
The display panel cable bracket is included in the Hinge Kit, spare part number 784464-001.
14. Disconnect the display panel cable (3) from the system board.
15. Detach the display panel cable (4) from the base enclosure. (The display panel cable is attached to the
base enclosure with double-sided adhesive.)
Component replacement procedures 89
16. Release the wireless antenna cables from the routing channels built into the base enclosure.
17. Remove the two Torx T8M2.5×6.5 screws (1) that secure the display assembly to the base enclosure.
18. Remove the display assembly (2).
NOTE: Steps 19 through 22 apply only to LED display assemblies.
19. If it is necessary to replace the display bezel or any of the LED display assembly subcomponents:
90 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
a. Remove the two screw covers (1) and the two Phillips PM2.0×5.5 screws (2) that secure the
display bezel to the display assembly.
The screw covers are available in all LED display assembly subcomponent spare part kits.
b. Flex the inside edges of the top edge (1), the left and right sides (2), and the bottom edge (3) of
the display bezel until the bezel disengages from the display enclosure.
c. Remove the display bezel (4).
The display bezel is available using the following spare part numbers:
734301-001: Models with a webcam
734302-001: Models without a webcam
784471-001: Models with a QHD+ display and a webcam
784472-001: Models with a QHD+ display and without a webcam
784473-001: Models with an Innolux display panel and a webcam
784474-001: Models with an Innolux display panel and without a webcam
Component replacement procedures 91
20. If it is necessary to replace the display panel:
a. Remove the four Phillips PM2.0×3.0 screws that secure the display panel to the display enclosure.
CAUTION: Before turning the display panel upside down, make sure the work surface is clear of
tools, screws, and any other foreign objects. Failure to follow this caution can result in damage to
the display panel.
b. Lift the top edge of the display panel (1) and swing it up and forward until it rests upside down in
front of the display enclosure.
c. Release the adhesive strip (2) that secures the display panel cable connector to the display panel.
d. Disconnect the display panel cable (3) from the display panel.
e. Remove the display panel.
The display panel is available using spare part numbers 735607-001 (15.6-in, FHD, UWVA, LED
display panel), 735604-001 (15.6-in, FHD, SVA, LED display panel) and 797849-001 (15.6-in, QHD
+, UWVA, LED display panel).
21. If it is necessary to replace the webcamera/microphone module or microphone module:
CAUTION: Handle the webcamera/microphone module and microphone module with caution. These
modules have a thin profile and are susceptible to damage when not handled carefully.
92 Chapter 6 Removal and replacement procedures for Authorized Service Provider parts
