1 Setting up the all-in-one
Step 1: Prepare the location
Place the all-in-one on a sturdy, level surface in a well-ventilated area. Make sure that the air vents are
not blocked and all doors can open freely.
(15.5 inches)
393 mm
497 mm
(19.6 inches)
406 mm
(15.98 inches)
Step 2: Regulate the environment
Do not place the all-in-one in direct sunlight or in an area that has abrupt temperature and humidity
changes. The recommended ranges are 15 to 32.5°C (59 to 90.5°F) and 10 to 80% relative humidity.
ENWW Step 1: Prepare the location 1
Step 3: Verify the package contents
1 automatic document feeder (ADF) input tray
2 HP LaserJet 3052/3055 all-in-one
3 power cord
4 fax cord (HP LaserJet 3055 all-in-one only)
5 print cartridge
NOTE The USB and network cables are not included.
6
7
8
9
10 control-panel faceplate (if not already installed)
Start Guide and support flyer
CD-ROMs containing software and electronic User Guide
media input tray
output bin support
2 Chapter 1 Setting up the all-in-one ENWW
Step 4: Remove all packing tape
Check the all-in-one thoroughly and remove all the packing tape.
ENWW Step 4: Remove all packing tape 3
Step 5: Locate the all-in-one parts
4
5
3
6
2
1
1 tray 1
2 priority input slot
3 output bin
4 automatic document feeder (ADF) input tray
5 ADF output bin
6 control panel
7 cartridge-door release
7
9
10
8
8 interface ports
9 security-lock slot
10 power switch
11 power connector
4 Chapter 1 Setting up the all-in-one ENWW
11
Step 6: Install the control-panel faceplate (if not already
installed)
NOTE The control panel for the HP LaserJet 3055 all-in-one is shown.
1. Align the control-panel faceplate with the all-in-one.
2. Beginning in the center of the faceplate and working outward, press the faceplate until it snaps into
place.
3
2
1
1
3
2
NOTE Make sure that the faceplate is aligned correctly and is not pressing any buttons.
The control panel includes the following areas:
3
1
1 fax controls (HP LaserJet 3055 all-in-one only)
2 alphanumeric buttons
3 display and menu controls
4 copy controls
5 scan controls
2
4
5
ENWW Step 6: Install the control-panel faceplate (if not already installed) 5
