HP Deskjet 693C User Manual

DeskJet 693C
© 2004 Hewlett-Packard 1
HP Parts Reference Guide™
www.hp.com/go/hpparts
Electronic Accessories
Cable (Interface)
5063-1256 IEEE-1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36 pin Centronics (M) connector (type B) - 2.0m
(6.6ft) long
5063-1257 IEEE-1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36 pin Centronics (M) connector (type B) - 3.0m
(9.8ft) long
C2950A IEEE-1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36 pin Centronics (M) connector (type B) - 2.0m
(6.6ft) long
5063-1256 New Part for C2950A
C2951A IEEE-1284 Bi-Tronics parallel cable - DB-25 (M) connector (type A) to 36 pin Centronics (M) connector (type B) - 3.0m
(9.8ft) long
C2990A IEEE-1284 Bi-Tronics parallel cable - DB-25 (M) (type A) to 36 pin (M) Centronics (type B) - 1.8m (6ft) long
NO LONGER SUPPLIED
C2991A IEEE-1284 Bi-Tronics parallel cable - DB-25 (M) (type A) to 36 pin (M) Centronics (type B) - 3.0m (10ft) long
NO LONGER SUPPLIED
Fax
C2970A HP PrinterPal accessory - Adds (External) fax capabilities to the deskjet/deskwriter printer
NO LONGER SUPPLIED
Electronics/Power Supply
PC Board
C2164-60008 Sensor PC board - Contains optical media sensors and mechanical switch for access door C6417-69055 Main logic board - Includes logic, power supply, motor and head driver electronics
NO LONGER SUPPLIED
Power Cord
8120-6312 AC power cord (Black) - 18 AWG, two conductor, 1.8m (6.6ft) long - Has straight (F) C7 receptacle (For 240V in
Australia, Argentina, New Zealand, and China)
8120-6313 AC power cord (Black) - 18 AWG, two conductor, 1.8m (6.0ft) long - Has straight (F) C7 receptacle (For 120V in USA,
Canada, Mexico, Latin America, and Taiwan)
8120-6314 AC power cord (Black) - 18 AWG, two conductor, 1.8m (6.0ft) long - Has straight (F) C7 receptacle (For 220V in South
America, Switzerland, Denmark, Netherlands, and France)
8120-6315 AC Power cord (Black) - 18 AWG, two conductor, 1.8m (6.0ft) long - Has straight (F) C7 receptacle (For 240V in the UK
and Singapore) 8120-6316 AC Power cord (Black) - 18 AWG, two conductor, 1.8m (6.0ft) long - Has straight (F) C7 receptacle (For 100V in Japan) 8120-6317 AC power cord (Black) - 18 AWG, two conductor, 1.8m (6.0ft) long - Has straight (F) C7 receptacle (For 220V in South
Africa, India, and Saudi Arabia) 8120-8441 AC power cord (Black) - 18 AWG, two conductor, 1.8m (6.0ft) long - Has straight (F) C7 receptacle (For 220V in Korea) 8121-0702 AC power cord (Black) Volex Z730966 - Two conductor, 1.8m (6.0ft) long - Has straight (F) C7 receptacle (For 240V in
India)
Power Module
0950-3490 Power supply module (Yokogawa AT7001A) - 100-240VAC input, 50/60Hz, 400mA - 24VDC output, 500mA - Requires
separate AC power cord - Not for use in Korea 9100-5124 Power supply module (transformer) - 120VAC input, 58-62Hz - 30VDC output, 400mA - Does not require separate AC
power cord - USA, Canada, Mexico - (C2175A, C2183A) 9100-5126 Power supply module (transformer) - 220VAC input, 58-62Hz - 30VDC output, 400mA - Korea 9100-5127 Power supply module (transformer) - 240VAC input, 58-62Hz - 30VDC output, 400mA - Australia 9100-5128 Power supply module (transformer) - 220VAC input, 48-52Hz - 30VDC output, 400mA - South Africa 9100-5129 Power supply module - 220VAC input, 48-52Hz - 30VDC output, 400mA - China, Argentina
NO LONGER SUPPLIED 9100-5130 Power supply module (transformer) - 100VAC input, 48-66Hz - 30VDC output, 400mA - Japan 9100-5131 Power supply module (transformer) - 240VAC input, 48-52Hz - 30VDC output, 400mA - U. K.
NO LONGER SUPPLIED
DeskJet 693C
© 2004 Hewlett-Packard 2
HP Parts Reference Guide™
www.hp.com/go/hpparts
Electronics/Power Supply
Power Module
9100-5132 Power supply module (transformer) - 230VAC input, 48-52Hz - 30VDC output, 400mA - Europe 9100-5348 Power supply module (transformer) - 220VAC input, 48-52Hz - 30VDC output, 400mA - For Hong Kong 9100-5590 Power supply module (NMB Corp. CS9-1472) - 220VAC input, 50Hz - 30VDC output, 400mA - China, Brazil, Philippines 9100-5602 Power supply module (NMB Corp. CS9-1477) - 220VAC input, 50Hz - 30VDC output, 400mA, 12 watts - India
NO LONGER SUPPLIED
External Case Parts
Cover
C4549-40001 Top cover - Main upper housing with molded input tray - Does NOT include cartridge access top cover - Quartz Gray C4549-67809 Ink cartridge access cover assembly - Includes printer nameplate
NO LONGER SUPPLIED C5884-40009 I/O cover - Allows access to logic PCA I/O port connector - Quartz Gray
Door
C4549-40011 Ink cartridge access cover (L-shaped, Quartz Gray plastic) - Lift-up top/front cover - Does NOT include nameplate
Foot
C2128-40063 Rubber foot
Keypad
C4549-60020 Keypad assembly - Includes 'Power' and 'Resume' switches, plus 'Power' and 'Status' LED displays - Quartz Gray
Nameplate/Logo
C4589-40001 Nameplate - C4589A DeskJet 693C printer
Other Accessories
CD-ROM (Support)
C6450-60020 DeskJet and DeskWriter service manual on CD-ROM - Version 4.1 C6450-60021 DeskJet and DeskWriter service manual on CD-ROM - Version 4.1
Cartridge
51629A Black print cartridge (High capacity) - Prints approximately 650 pages based on 5% density on a 8in by 10in print area
(for USA) 51629AA Black print cartridge (High capacity) - Prints approximately 650 pages based on 5% density on a 8in by 10in print area
(for Asia/Pacific) 51629AC Black print cartridge (high capacity) - Prints approximately 650 pages based on 5% density on a 8in by 10in print area
(for Canada) 51629AE Black print cartridge (High capacity) - Prints approximately 650 pages based on 5% density on a 8in by 10in print area
(for Europe) 51629AL Black print cartridge (High Capacity) - Prints approximately 650 pages based on 5% density on a 8in by 10in print area
(for Latin America) 51629G Black Print Cartridge (Regular) - Prints approximately 325 pages based on 5% density on a 8in by 10in print area (for
USA) 51629GA Black print cartridge (Regular) - Prints approximately 325 pages based on 5% density on a 8in by 10in print area (for
Asia Pacific) 51629GC Black print cartridge (Regular) - Prints approximately 325 pages based on 5% density on a 8 inch by 10 inch print area
(for canada) 51629GE Black print cartridge (Regular) - Prints approximately 325 pages based on 5% density on a 8 inch by 10 inch print area
(for Europe) 51629GL Black print cartridge (Regular) - Prints approximately 325 pages based on 5% density on a 8 inch by 10 inch print area
(for Latin America) 51629TE Black print cartridges (Regular) - (2 pack of 51629A) - Each prints approximately 325 pages based on 5% density on a 8
inch by 10 inch print area (for Europe) 51649A Tri-color ink print cartridge - Prints approximately 310 pages based on 13.5% total density (4.5% for each color) on a 8
inch by 10 inch print area (for USA)
DeskJet 693C
© 2004 Hewlett-Packard 3
HP Parts Reference Guide™
www.hp.com/go/hpparts
Other Accessories
Cartridge
51649AA Tri-color ink print cartridge - Prints approximately 310 pages based on 13.5% total density (4.5% for each color) on a 8
inch by 10 inch print area (for Asia/Pacific) 51649AC Tri-color ink print cartridge - Prints approximately 310 pages based on 13.5% total density (4.5% for each color) on a 8
inch by 10 inch print area (for Canada) 51649AE Tri-color ink print cartridge - Prints approximately 310 pages based on 13.5% total density (4.5% for each color) on a 8
inch by 10 inch print area (for Europe) 51649AL Tri-color ink print cartridge - Prints approximately 310 pages based on 13.5% total density (4.5% for each color) on a 8
inch by 10 inch print area (for Latin America) 51649G Tri-color ink economy print cartridge - Prints approximately 155 pages based on 13.5% total density (4.5% for each on a
8 inch by 10 inch print area (for USA) 51649GA Tri-color ink economy print cartridge - Prints approximately 155 pages based on 13.5% total density (4.5% for each on a
8 inch by 10 inch print area (for Asia/Pacific) 51649GE Tri-color ink economy print cartridge - Prints approximately 155 pages based on 13.5% total density (4.5% for each on a
8 inch by 10 inch print area (for Europe) 51649GL Tri-color ink economy print cartridge - Prints approximately 155 pages based on 13.5% total density (4.5% for each on a
8 inch by 10 inch print area (for Latin America) C1816A Color InkJet photo cartridge - For high definition printing and reproduction of photographs (for USA) C1816AA Color InkJet photo cartridge - For high definition printing and reproduction of photographs (for Asia/Pacific) C1816AC Color InkJet photo cartridge - For high definition printing and reproduction of photographs (for Canada)
NO LONGER SUPPLIED C1816AE Color InkJet photo cartridge - For high definition printing and reproduction of photographs (for Europe) C1816AL Color InkJet photo cartridge - For high definition printing and reproduction of photographs (for Latin America) C6612AN Black print cartridge (High capacity) - (2 pack of 51629A) each prints approximately 650 pages based on 5% density on
a 8 inch (20.3cm) by 10 inch (25.4cm) print area (for USA)
NO LONGER SUPPLIED C6617AN Tri-color ink print cartridges - (2 pack of 51649A) - Each prints approximately 310 pages based on 13.5% total density
on a 8 inch (20.3cm) by 10 inch (25.4cm) print area (for USA)
NO LONGER SUPPLIED
Garage
C4562-60018 Garage assembly - Holds print cartridge when not in use - Also referred to as a 'Cartridge humidor'
Kit
C4583A HP photo color kit - Includes InkJet photo cartridge, cartridge storage container(garage) and instruction guide - For use
in Asia Pacific C4584A HP photo color kit - Includes InkJet photo cartridge, cartridge storage container(garage) and instruction guide - For use
in Europe and China C4585A HP photo color kit - Includes InkJet photo cartridge, cartridge storage container (garage) and instruction guide
NO LONGER SUPPLIED C4590A HP photo color kit - Includes InkJet photo cartridge, cartridge storage container(garage) and instruction guide - For use
in Latin America
Lubricant
6040-0858 Special lubricating oil - For carriage slider rod surface - 4oz (113g) plastic bottle of synthetic oil
Manual
C4562-60100 C4562A DeskJet 690C user's manual kit (Arabic)
NO LONGER SUPPLIED C4562-60101 C4562A DeskJet 690C user's manual kit (Czechoslovakian)
NO LONGER SUPPLIED C4562-60102 C4562A DeskJet 690C user's manual kit (Danish)
NO LONGER SUPPLIED C4562-60103 C4562A DeskJet 690C user's manual kit (Dutch)
NO LONGER SUPPLIED
