Harman Kardon AVR-330 Service manual

harman/kardon
AVR330
7 X 55W 7.1 CHANNEL A/V RECEIVER
SERVICE MANUAL
ESD WAR N ING……………………………….2
LEAKAGE TESTING……………….…..…....3
BASIC SPECIFICATIONS…………………..4 FRO NT PANEL CO NTRO L S ………..…..…..5 REAR PANEL CONNECTIONS………….…7 REMOTE CONTROL FUNCTIONS……….10 TROUBLESHOOTING GUIDE…...……..…14 PROCESSOR RESET……………….….…..14 DISASSEM BLY………………………………15
BULLETIN HK 2003-10…….........................16
harman/kardon, Inc. 250 Crossways Park Dr. Woodbury, New York 11797 Rev1 11/2004
TECH TI P H KT T 2003- 01……………..…….18
UNIT EXPLOD ED VIEW…………………....19
BLOCK DIAGRAM……………….…………20
AMP BIAS ADJUSTMENT………………....21
PCB DRAWINGS……………….……..……22 ELECTRICAL PARTS LIST…….………….28 SEMICONDUCTOR PINOUTS………….…68 SCHEMATICS………………………………109
WIRING DIAGRAM…………………….......125
PACKAGING…………………………..……126
AVR330 harman/kardon
2
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called
Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field effect transistors and
semiconductor "chip" components.
The following techniques should be used to help reduce the incidence of component damage caused by static electricity.
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any electrostatic charge on
your body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging wrist strap device,
which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as aluminum foil, to
prevent electrostatic charge build-up or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static" can generate electrical charges
sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical change sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most replacement
ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or comparable conductive material.)
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material to the
chassis or circuit assembly into which the device will be installed.
CAUTION :
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the brushing together
or your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity sufficient to damage an ES devices.
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
Each precaution in this manual should be followed during servicing.
Components identified with the IEC symbol in the parts list are special significance to safety. When replacing a component identified with
, use only the replacement parts designated, or parts with the same ratings or resistance, wattage, or voltage that are designated in the
parts list in this manual. Leakage-current or resistance measurements must be made to determine that exposed parts are acceptably
insulated from the supply circuit before retuming the product to the customer.
SAFETY PRECAUTIONS
The following check should be performed for the continued protection of the customer and service technician.
LEAKAGE CURRENT CHECK
Measure leakage current to a known earth ground (water pipe, conduit, etc.) by connecting a leakage current tester between the earth ground and all exposed metal parts of the appliance (input/output terminals, screwheads, metal overlays, control shaft, etc.). Plug the AC line cord of the appliance directly into a 120V AC 60Hz outlet and turn the AC power switch on. Any current measured must not exceed o.5mA.
ANY MEASUREMENTS NOT WITHIN THE LIMITS OUTLINED ABOVE ARE INDICATIVE OF A POTENTIAL SHOCK HAZARD AND MUST BE CORRECTED BEFORE RETURNING THE APPLIANCE TO THE CUSTOMER.
3
AVR330 harman/kardon
Reading should not be above
0.5mA Device under test
Leakage current tester
Test all exposed metal surfaces
Also test with plug reversed (Using AC adapter plug as required)
Earth ground
AC Leakage Test
4
AVR330 harman/kardon
AVR 330 TECHNICAL SPECIFICATIONS
Audio Section
Stereo Mode Continuous Average Power (FTC)
65 Watts per channel, 20Hz–20kHz, @ <0.07% THD, both channels driven into 8 ohms
Seven-Channel Surround Modes Power per Individual Channel
Front L&R channels: 55 Watts per channel @ <0.07% THD, 20Hz–20kHz into 8 ohms
Center channel: 55 Watts @ <0.07% THD, 20Hz–20kHz into 8 ohms
Surround (L & R side, L & R back) channels: 55 Watts per channel @ <0.07% THD, 20Hz–20kHz into 8 ohms
Input Sensitivity/Impedance
Linear (High-Level) 200mV/47k ohms Signal-to-Noise Ratio (IHF-A) 100dB Surround System Adjacent Channel Separation
Pro Logic I/II 40dB
Dolby Digital (AC-3) 55dB
DTS 55dB
Frequency Response
@ 1W (+0dB, –3dB) 10Hz –130kHz High Instantaneous
Current Capability (HCC) ±35 Amps Transient Intermodulation
Distortion (TIM) Unmeasurable Slew Rate 40V/µsec
FM Tuner Section
Frequency Range 87.5–108.0MHz
Usable Sensitivity IHF 1.3µV/13.2dBf
Signal-to-Noise Ratio Mono/Stereo 70/68dB
Distortion Mono/Stereo 0.2/0.3%
Stereo Separation 40dB @ 1kHz
Selectivity ±400kHz, 70dB
Image Rejection 80dB
IF Rejection 90dB
AM Tuner Section
Frequency Range 330–1710kHz Signal-to-Noise Ratio 45dB Usable Sensitivity Loop 500µV Distortion 1kHz, 50% Mod 0.8% Selectivity ±10kHz, 30dB
Video Section
Television Format NTSC Input Level/Impedance 1Vp-p/75 ohms Output Level/Impedance 1Vp-p/75 ohms
Video Frequency Response (Composite and S-Video) 10Hz–8MHz (–3dB)
Video Frequency Response (Component Video) 10Hz–30MHz (–3dB)
General
Power Requirement AC 120V/60Hz Power Consumption 118W idle, 890W maximum
(7 channels driven)
Dimensions (Product) (Shipping) Width 17.3 inches (440mm) 21.5 inches (545mm) Height 6.6 inches (168mm) 9.9 inches (251mm) Depth 15 inches (381mm) 17.9 inches (455mm)
Weight (Product) (Shipping)
30.6 lb (13.9kg) 35.2 lb (16kg)
Depth measurement includes knobs, buttons and terminal connections. Height measurement includes feet and chassis. All features and specifications are subject to change without notice.
Harman Kardon and Power for the Digital Revolution are registered trademarks of Harman International Industries, Incorporated.
TM
is a trademark of Harman International Industries, Incorporated (patent no. 5,386,478).
*Manufactured under license from Dolby Laboratories. “Dolby,” “Pro Logic” and the Double-D symbol
are trademarks of Dolby Laboratories.
DTS, DTS Surround, DTS-ES and DTS Neo:6 are registered trademarks of Digital Theater Systems, Inc.
VMAx is a registered trademark of Harman International Industries, Incorporated, and is an implementation of Cooper Bauck Transaural Stereo under patent license.
Logic 7 is a registered trademark of Harman International Industries, Incorporated.
TECHNICAL SPECIFICATIONS 4
TECHNICAL SPECIFICATIONS
FRONT-PANEL CONTROLS
1 Main Power Switch: Press this button to apply power to the AVR 330.When the switch is pressed in, the unit is in a Standby mode, as indicated by the amber LED
2 above the Standby/On Switch 3.
This button MUST be pressed in to operate the unit. To turn the unit off and prevent the use of the remote control, this switch should be pressed until it pops out from the front panel and the word “OFF” is seen at the top of the switch.
NOTE: This switch is normally left in the “ON” position.
2 Power Indicator: This LED lights amber when the unit is in the Standby mode to signal that the AVR is ready to be turned on. When the unit is in operation, the indicator is blue.
3 Standby/On Switch: When the Main Power Switch
1
is “ON,” press this button to turn on the
AVR 330; press it again to turn the unit off. The
Power
Indicator
3
turns blue when the unit is on.
4 Headphone Jack: This jack may be used to listen to the AVR 330’s output through a pair of headphones. The speakers will automatically be turned off when the headphone jack is in use.
5 Tone Mode: Pressing this button enables or dis- ables the Bass and Treble tone controls.When the but­ton is pressed so that
TONE IN appears in the
Lower Display Line ¯, the Bass and Treble Ú controls may be used to adjust the output signals.
When the button is pressed once or twice so that the words
TONE OUT appear in the Lower Display
Line
¯, the output signal will be “flat,” no matter how
the actual
Bass and Treble Controls Ú are
adjusted.
6 Speaker Select Button: Press this button to begin the process of configuring the unit to match the
type of speakers used in your listening room. (See pages 17 and 20–22 for more information on speaker setup and configuration.)
7 Surround Mode Group Selector: Press this but- ton to select the top-level group of surround modes. Each press of the button will select the current or last used mode in each of the surround mode groups (e.g., Dolby, DTS, DTS Neo:6, Logic 7, DSP, Stereo). When the button is pressed so that the name of the desired surround mode group appears in the on­screen display and in the
Lower Display Line ¯,
press the
Surround Mode Selector 8 to cycle
through the individual modes available. For example, press this button to select Dolby modes, and then press the
Surround Mode Selector 8 to choose
from the various mode options. 8 Surround Mode Selector: Press this button
to select from among the available surround mode
1 Main Power Switch 2 Power Indicator 3 Standby/On Switch 4 Headphone Jack 5 Tone Mode 6 Speaker Selector 7 Surround Mode Group Selector 8 Surround Mode Selector 9 Tuning Selector )
/
Buttons
! Tuner Band Selector
@ Set Button # Digital Input Selector $ Preset Station Selector % Delay Adjust Selector ^ Input Source Selector & Tuner Mode Selector * Optical 3 Digital Input ( Coaxial 3 Digital Input Ó Video 4 Video Input Jacks Ô Video 4 Audio Input JacksBass Control
Ò Balance Control Ú Treble Control Û Channel Adjust Selector Ù Volume Control ı Input Indicators ˆ Speaker/Channel Input Indicators ˜ Upper Display Line ¯ Lower Display Line ˘ Surround Mode Indicators ¸ Remote Sensor Window
DIGITAL LOGIC 7
VID 1
DVD CD FMAM TAPE 68CH
VID 2 VID 3 VID 4
PRO LOGIC 3 STEREO DSP
5 CH. STEREO SURR. OFF
1
2
6
7
#
¸ ˆ
Ú
Ô
(
*
Û
Ù
ı
8
)
!
@
)
&
%
3
4
˘
¯
˜
5
9
$
^
Ò
Ó
FRONT-PANEL CONTROLS
FRONT-PANEL CONTROLS 55
NOTE: To make it easier to follow the instructions that refer to this illustration, a larger copy may be downloaded from the Product Support section for this product at www.harmankardon.com.
5
AVR330 harman/kardon
options for the mode group selected. The specific modes will vary based on the number of speakers available, the mode group and if the input source is digital or analog. For example, press the
Surround
Mode Group Selector
7 to select a mode grouping such as Dolby or Logic 7, and then press this button to see the specific mode choices available. For more information on mode selection, see page 26.
9 Tuning Selector: Press the left side of the button to tune lower-frequency stations and the right side of the button to tune higher-frequency stations. When the tuner is in the Manual mode, each tap will increase or decrease the frequency by one increment. When the tuner receives a strong enough signal for adequate reception,
MANUAL TUNED will appear in the
on-screen display and the
Lower Display Line ¯.
When the tuner is in the Auto mode, press the button once, and the tuner will scan for a station with accept­able signal strength. When the next station with a strong signal is tuned the scan will stop andthe on­screen display and the
Lower Display Line ¯ will
indicate
AUTO TUNED. When an FM Stereo sta-
tion is tuned, the display will read
AUTO ST
TUNED
.
To switch back and forth between the Auto and Manual tuning modes, press the
Tuning Mode
Selector
&.
) /Buttons: When configuring the AVR 330’s
settings, use these buttons to select from the available choices
.
! AM/FM Selector: Press this button to turn the AVR on and to select the Tuner as the input source. Press it again to switch between the AM and FM fre­quency bands. (See page 29 for more information on the tuner.)
@ Set Button: When making choices during the setup and configuration process, press this button to enter the desired setting into the AVR 330’s memory.
# Digital Input Selector: Press this button to select one of the digital inputs or the analog input for any source. (See pages 26–29 for more information on digital audio.)
$ Preset Station Selector: Press this button to scroll up or down through the list of stations that have been entered into the preset memory. (See page 29 for more information on tuner presets.)
% Delay Adjust Selector: Press this button to begin the steps required to enter delay settings. (See page 22 for more information on delay times.)
^ Input Source Selector: Press this button to change the input by scrolling up or down through the list of
Input Indicators ı.
& Tuner Mode Selector: Press this button to select
Auto or Manual tuning. When the button is pressed so that
AUTO appears in the Lower Display Line ¯,
the tuner will search for the next station with an accept­able signal when the
Tuning Selector 9u
is pressed. When the button is pressed so that MANUAL appears in the Lower Display Line ¯, each press of the
Tuning Selector 9u will
increase the frequency.This button may also be used to switch between Stereo and Mono modes for FM radio reception. When weak reception is encountered, press the button so that
MANUAL appears in the Lower
Display Line
¯ and on the on-screen display to switch to Mono reception. Press it again to switch back to Stereo mode. (See page 29 for more information on using the tuner.)
* Optical 3 Digital Input: Connect the optical digital audio output of an audio or video product to this jack. When the input is not in use, be certain to keep the plastic cap installed to avoid dust contamination that might degrade future performance.
( Coaxial 3 Digital Input: This jack is used for connection to the output of portable audio devices, video game consoles or other products that have a coax digital audio jack.
Ó Video 4 Video Input Jacks: These jacks may be used for temporary connection to the composite or S­Video output of video games, camcorders or other portable video products.You may make a connection to either jack at any time, but not to both simultane­ously.
Ô Video 4 Audio Input Jacks: These audio jacks may be used for temporary connection to video games or portable audio/video products such as cam­corders and portable audio players.
Bass Control: Turn this control to modify the low­frequency output of the left/right channels by as much as ±10dB.
Ò Balance Control: Turn this control to change the relative volume for the front left/right channels.
NOTE: For proper operation of the surround modes this control should be at the midpoint or “12 o’clock” position.
Ú Treble Control:Tu rn this control to modify the high frequency output of the left/right channels by as much as ±10dB.
Û Channel Adjust Selector: Press this button to begin the process of trimming the channel output lev­els using an external audio source. (For more informa­tion on output level trim adjustment, see page 30.)
Ù Volume Control: Turn this knob clockwise to increase the volume, counterclockwise to decrease the volume. If the AVR 330 is muted, adjusting the Volume Control Ù will automatically release the unit from the silenced condition.
ı Input Indicators: The current selected source will appear as one of these indicators. Note that when the unit is turned on, the entire list of available modes will light briefly, and then revert to normal operation with only the active mode indicator illuminated.
ˆ Speaker/Channel Input Indicators: These indi- cators are multipurpose, indicating both the speaker type selected for each channel and the incoming data­signal configuration. The left, center, right, right surround and left surround speaker indicators are composed of three boxes, while the subwoofer is a single box. The center box lights when a “small” speaker is selected, and the two outer boxes light when “large” speakers are selected. When none of the boxes are lit for the center, surround or subwoofer channels, no speaker has been assigned that position. (See page 20 for more informa­tion on configuring speakers.) The letters inside each box displays the active input channels. For standard analog inputs, only the L and R will light, indicating a stereo input. For a digital source, the indicators will light to display the channels being received at the digital input. When the letters flash, the digital input has been interrupted. (See page 28 for more information on the Channel Indicators.)
˜ Upper Display Line: Depending on the unit’s sta- tus, a variety of messages will appear here. In normal operation, this line will show the current input source and which analog or digital input is in use.When the tuner is the input, this line will identify the station as AM or FM and show the frequency and preset number, if any.
¯ Lower Display Line: Depending on the unit’s sta- tus, a variety of messages will appear here. In normal operation, the current surround mode will show here.
˘ Surround Mode Indicators: The current selected surround mode will appear as one of these indicators. Note that when the unit is turned on, the entire list of available modes will light briefly, and then revert to normal operation with only the active mode indicator illuminated.
¸ Remote Sensor Window: The sensor behind this window receives infrared signals from the remote control. Aim the remote at this area and do not block or cover it.
FRONT-PANEL CONTROLS
6 FRONT-PANEL CONTROLS
6
AVR330 harman/kardon
38
REAR-PANEL CONNECTIONS 7
ª
¡
£
°
b
d
g
j
ki
a
37
35
32
¢
§
¤
·
c
e
f
h
31
41
39
38
36
34
33
40
REAR-PANEL CONNECTIONS
¡ Multiroom Audio OutputsCD Audio Inputs £ Tape Outputs ¢ Remote IR InputMultiroom IR Input
§ Remote IR OutputPreamp Outputs
Subwoofer Output ª Front Speaker OutputsSurround Back/Multiroom Speaker OutputsSurround Speaker Outputs ¤ Center Speaker OutputVideo 2 Component Video InputsDVD Component Video Inputs
Component Video Monitor OutputsFan VentsAC Power Cord ° Switched AC Accessory Outlet
· Unswitched AC Accessory Outlet a Optical Digital Audio Output b Coaxial Digital Audio Output c S-Video Monitor Output d Coaxial Digital Audio Inputs e DVD S-Video Input f Video 1 S-Video Input g Optical Digital Audio Inputs h Video 1 S-Video Output i Video 2 S-Video Input
j 6/8-Channel Direct Inputs k Video 2 S-Video Output
Video 3 S-Video Input Video Monitor Output DVD Audio/Video Inputs Video 1 Audio/Video Inputs Video 1 Audio/Video Outputs Video 2 Audio/Video Inputs Video 2 Audio/Video Outputs Video 3 Audio/Video Inputs Tape Inputs AM Antenna Terminals FM Antenna Jack
NOTE: To assist in making the correct connections for multichannel input, output and speaker connections, all connection jacks and terminals are color-coded in conformance with the CEA standards as follows:
Front Left: White Front Right: Red Center: Green
Surround Left: Blue Surround Right: Gray Surround Back Left: Brown Surround Back Right: Tan Subwoofer: Purple Coaxial Digital Audio: Orange Composite Video: Yellow
Component Video “Y”: Green Component Video “Pr”: Red Component Video “Pb”: Blue
¡ Multiroom Audio Outputs: Connect these jacks to the optional external audio power amplifier and video distribution system that delivers the source selected for multizone distribution.
CD Audio Inputs: Connect these jacks to the analog audio output of a compact disc player or changer.
£
Tape Outputs: Connect these jacks to the
RECORD/INPUT
jacks of an audio recorder.
¢ Remote IR Input: If the AVR 330’s front-panel IR sensor is blocked due to cabinet doors or other obstructions, an external IR sensor may be used. Connect the output of the sensor to this jack.
Multiroom IR Input: Connect the output of an IR sensor in a remote room to this jack to operate the AVR 330’s multiroom control system.
§ Remote IR Output: This connection permits the IR sensor in the receiver to serve other remote con­trolled devices. Connect this jack to the “IR IN” jack on Harman Kardon (or other compatible) equipment.
NOTE: To make it easier to follow the instructions that refer to this illustration, a larger copy may be downloaded from the Product Support section for this product at www.harmankardon.com.
7
AVR330 harman/kardon
31 32 33 34 35 36 37 38 39 40 41
8 REAR-PANEL CONNECTIONS
REAR-PANEL CONNECTIONS
Preamp Outputs: Connect these jacks to an optional, external power amplifier for applications where higher power is desired.
Subwoofer Output: Connect this jack to the line- level input of a powered subwoofer. If an external sub­woofer amplifier is used, connect this jack to the sub­woofer amplifier input.
ª Front Speaker Outputs: Connect these outputs to the matching + or – terminals on your left and right speakers.When making speaker connections always make certain to maintain correct polarity by connecting the color-coded (white for front left and red for front right) (+) terminals on the AVR 330 to the red (+) terminals on the speakers and the black (–) terminals on the AVR 330 to the black (–) terminals on the speakers. See page 15 for more information on speaker polarity.
Surround Back/Multiroom Speaker Outputs:
These speaker terminals are normally used to power the surround back left/surround back right speakers in a 7.1 channel system. However, they may also be used to power the speakers in a second zone, which will receive the output selected for a multiroom system. To change the output fed to these terminals from the default of the Surround Back speakers to the Multiroom Output, you must change a setting in the Advanced Menu of the OSD system. See page 31 for more information on configuring this speaker output. In normal surround system use, the brown and black ter­minals are the surround back left channel positive (+) and negative (–) connections and the tan and black terminals are the surround back right positive (+) and negative (–) terminals. For multiroom use, connect the brown and black SBL terminals to the red and black connections on the left remote zone speaker and con­nect the tan and black SBR terminals to the red and black terminals on the right remote zone speaker.
Surround Speaker Outputs: Connect these out- puts to the matching + and – terminals on your sur­round channel speakers. In conformance with the CEA color-code specification, the blue terminal is the posi­tive, or “+,” terminal that should be connected to the red (+) terminal on the Surround Left speaker with older color-coding, while the gray terminal should be connected to the red (+) terminal on the Surround Right speaker with the older color-coding. Connect the black (–) terminal on the AVR to the matching black negative (–) terminals for each surround speaker. (See page 15 for more information on speaker polarity.)
¤ Center Speaker Output: Connect these outputs to the matching + and – terminals on your center channel speaker. In conformance with the CEA color­code specification, the green terminal is the positive, or “+,” terminal that should be connected to the red (+) terminal on speakers with the older color-coding.
Connect the black (–) terminal on the AVR to the black (–) terminal on your speaker. (See page 15 for more information on speaker polarity.)
Video 2 Component Video Inputs: Connect the Y/Pr/Pb component video outputs of an HDTV set-top converter, satellite receiver or other video source device with component video outputs to these jacks.
DVD Component Video Inputs: Connect the Y/Pr/Pb component video outputs of a DVD player to these jacks.
Component Video Monitor Outputs: Connect these outputs to the component video inputs of a video projector or monitor. When a source connected to one of the
Component Video Inputs ‹› is selected, the signal will be sent to these jacks.
Fan Vents: These ventilation holes are the output of the AVR 330’s airflow system. To ensure proper operation of the unit and to avoid possible damage to delicate surfaces, make certain that these holes are not blocked and that there is at least three inches of open space between the vent holes and any wooden or fabric surface. It is normal for the fan to remain off at most normal volume levels. An automatic tempera­ture sensor turns the fan on only when it is needed.
AC Power Cord: Connect the AC power cord to a non-switched AC wall outlet.
° Switched AC Accessory Outlet: These outlets may be used to power any device you wish to have turned on when the AVR 330 is turned on.
· Unswitched AC Accessory Outlet: This outlet may be used to power any AC device. The power will remain on at this outlet regardless of whether the AVR 330 is on or off.
NOTE: The total power consumption of all devices connected to the accessory outlets should not exceed 100 watts.
a Optical Digital Audio Output: Connect this jack to the optical digital input connector on a CD-R/RW, MiniDisc or other digital recorder.
b Coaxial Digital Audio Output: Connect this jack to the coaxial digital input of a CD-R/RW, MiniDisc or other digital recorder.
c S-Video Monitor Output: When your television or other video display is equipped with an S-Video input and you are using at least one source with S-Video capability, connect this jack to the S-Video input on the display.
d Coaxial Digital Audio Inputs: Connect the coax digital output from a DVD player, HDTV receiver,
LD
player
or CD player to these jacks.The signal may be a
Dolby Digital signal, DTS signal or a standard PCM digital source. Do not connect the RF digital output of an LD player to these jacks.
e DVD S-Video Input: Connect the S-Video output of a DVD player or other video source to this jack.
f Video 1 S-Video Input: If the product connected to the
Video 1 Audio Inputs has S-Video capability,
connect this jack to the PLAY/OUT S-Video jack on that unit and then make certain that the
S-Video
Monitor Output
c is connected as described above.
g Optical Digital Audio Inputs: Connect the optical
digital output from a DVD player, HDTV receiver, LD player or CD
player to these jacks.The signal may be a Dolby Digital signal, a DTS signal or a standard PCM digital source.
h Video 1 S-Video Output: If the product connect­ed to the
Video 1 Audio Outputs has S-Video
capability, connect this jack to the REC/IN S-Video jack on that unit.
i Video 2 S-Video Input: If the product connected to the
Video 2 Audio Inputs has S-Video capability,
connect this jack to the PLAY/OUT S-Video jack on that unit and then make certain that the
S-Video
Monitor Output
c is connected as described above.
j 8-Channel Direct Inputs: These jacks are used
for connection to source devices such as DVD-Audio or SACD players with discrete analog outputs. Depending on the source device in use, all eight jacks may be used, though in many cases only connections to the front left/right, center, surround left/right and LFE (subwoofer input) jacks will be used for standard 5.1 audio signals.
k Video 2 S-Video Output: If the product connect­ed to the
Video 2 Audio Outputs has S-Video
capability, connect this jack to the REC/IN S-Video jack on that unit.
Video 3 S-Video Input: If the product connected to
the
Video 3 Audio Inputs has S-Video capability,
connect this jack to the PLAY/OUT S-Video jack on that unit and then make certain that the
S-Video
Monitor Output
c is connected as described above.
Video Monitor Output: Connect this jack to the
composite video input of a TV monitor or video projec­tor to view the on-screen menus and the output of a standard video source.
DVD Audio/Video Inputs: Connect the composite
video and L/R analog audio output jacks of a DVD player or other video source to these jacks.
REAR-PANEL CONNECTIONS
8 REAR-PANEL CONNECTIONS
8
AVR330 harman/kardon
31
32
33
34
35
36
37
38
REAR-PANEL CONNECTIONS 9
REAR-PANEL CONNECTIONSREAR-PANEL CONNECTIONS
Video 1 Audio/Video Inputs: Connect the com-
posite video and L/R analog audio PLAY/OUT jacks of a VCR or other video source to these jacks.
Video 1 Audio/Video Outputs: Connect the
composite video and L/R analog audio REC/IN jacks of a VCR or other video recording device such as a DVD recorder or PVR to these jacks.
Video 2 Audio/Video Inputs: Connect the com-
posite video and L/R analog audio PLAY/OUT jacks of a VCR or other video source to these jacks.
Video 2 Audio/Video Outputs: Connect the
composite video and L/R analog audio REC/IN jacks of a VCR or other video recording device such as a DVD recorder or PVR to these jacks.
Video 3 Audio/Video Inputs: Connect the com-
posite video and L/R analog audio PLAY/OUT jacks of a VCR or other video source to these jacks.
Tape Inputs:
Connect these jacks to the PLAY/OUT
jacks of an audio recorder.
AM Antenna Terminals: Connect the AM loop
antenna supplied with the receiver to these terminals. If an external AM antenna is used, make connections to the
AM and GND terminals in accordance with the
instructions supplied with the antenna.
FM Antenna Jack: Connect the supplied indoor (or
an optional external) FM antenna to this terminal.
Note on video connections: When connecting a source device, such as a VCR, DVD player, cable or satellite set­top box or video game, to the AVR, use either a compos­ite or S-Video connection for each input, but not both.
9
AVR330 harman/kardon
34
35
36
37
38
39
40
41
MAIN REMOTE CONTROL FUNCTIONS
10 MAIN REMOTE CONTROL FUNCTIONS
a Power Off Button b IR Transmitter Window c Program/SPL Indicator d Power On Button e Input Selectors f AVR Selector g AM/FM Tuner Select h Dim Button i Test Button j Sleep Button k DSP Surround Mode Selector l Night Mode m Channel Select Button n
⁄/¤
Buttons
o
‹/›
Buttons
p Set Button q Digital Select r Numeric Keys s Tuner Mode t Direct Button u Tuning Up/Down v OSD Button w Dolby Mode Selector x DTS Digital Mode Selector y Logic 7 Mode Select Button z Skip Up/Down Buttons ` Transport Controls
28
Stereo Mode Select Button
29
DTS Neo:6 Mode Select
30
Macro Buttons
31
Disc Skip Button
32
Preset Up/Down
33
Clear Button
34
Memory Button
35
Delay/Prev. Ch.
36
Speaker Select
37
Multiroom
38
Volume Up/Down
39
TV/Video Selector
40
SPL Selector
41
6-Channel/8-Channel Direct Input
42
Mute
43
EzSet Sensor Microphone
NOTE:
• The function names shown here are each button’s feature when used with the AVR 330. Most buttons have additional functions when used with other devices. See pages 39–40 for a list of these functions.
• To make it easier to follow the instructions that refer to this illustration, a larger copy may be downloaded from the Product Support section for this product at www.harmankardon.com.
s
a
bc
d
e
f
g
h
j
n
n
p
o
o
q
r
t
v
`
32
30
29
28
36
37
38
39
40
z
x
35
POWER
MUTE
AVR
DVD
AM/FM
CD
TAPE
VID 2
VCR
TV
CBL/SAT
6/8 CH SPL
VID 1
VID 3 VID 4
OFF
ON
SLEEP
T/V
SURR.
CH.
VOL.
G
U
I
D
E
C
H
.
E
X
I
T
D
I
G
I
T
A
L
M
E
N
U
S
P
K
R
P
R
E
V
.
C
H
.
D
E
L
A
Y
SET
1
2
3
4
7
6
5
9
0
TU
N
-M
M
EM
M
2
M
3
M
4
D
.SKIP
M
1
D
IRECT
O
SD
TU
N
IN
G
D
O
LB
Y
D
TS SU
RR
D
TS N
EO
:6
STEREO
LO
G
IC 7
SKIP
UP
DOWN
PRESET
CLEA
R
TEST
NIGHT M-ROOM
330
8
l
u
DIM
i
k
m
34
33
w
y
41
43
TM
31
42
10
AVR330 harman/kardon
MAIN REMOTE CONTROL FUNCTIONS
MAIN REMOTE CONTROL FUNCTIONS 11MAIN REMOTE CONTROL FUNCTIONS 11
IMPORTANT NOTE: The AVR 330’s remote may be programmed to control up to eight devices, including the AVR 330. Before using the remote, it is important to remember to press the Input Selector Button e that corresponds to the unit you wish to operate. In addition, the AVR 330’s remote is shipped from the factory to operate the AVR 330 and most Harman Kardon CD or DVD players and cassette decks.The remote is also capable of operating a wide variety of other products using the control codes that are part of the remote. Before using the remote with other products, follow the instructions on pages 35–36 to program the proper codes for the products in your system.
It is also important to remember that many of the but­tons on the remote take on different functions, depend­ing on the product selected using the Device Control Selectors.The descriptions shown here primarily detail the functions of the remote when it is used to operate the AVR 330. (See page 36 for information about alternate functions for the remote’s buttons.)
a Power Off Button: Press this button to place the AVR 330 or a selected device in the Standby mode. Note that this will turn off the main room functions, but if the Multiroom system is activated, it will continue to function.
b IR Transmitter Window: Point this window towards the AVR 330 when pressing buttons on the remote to make certain that infrared commands are properly received.
c Program/SPL Indicator: This three-color indica- tor is used to guide you through the process of pro­gramming the remote, and it is also used as a level indicator when using the remote’s EzSet capabilities. (See page 23 for more information on setting output levels, and see page 35 for information on program­ming the remote.)
d Power On Button: Press this button to turn on the power to a device selected by pressing one of the
Input Selectors e.
e Input Selectors: Pressing one of these buttons
will perform three actions at the same time. First, if the AVR 330 is not turned on, this will power up the unit. Next, it will select the source shown on the button as the input to the AVR 330. Finally, it will change the remote control so that it controls the device selected. After pressing one of these buttons you must press the
AVR Selector Button f again to operate the
AVR 330’s functions with the remote.
f AVR Selector: Pressing this button will switch the remote so that it will operate the AVR 330’s functions. If the AVR 330 is in the Standby mode, it will also turn the AVR 330 on.
g AM/FM Tuner Select: Press this button to select the AVR 330’s tuner as the listening choice. Pressing this button when the tuner is already in use will select between the AM and FM bands.
h Dim Button: Press this button to activate the Dimmer function, which reduces the brightness of the front panel display, or turns it off entirely. The first press of the button shows the default state, which is full bright­ness by indicating
DIMMER FULL in the Lower
Display Line
¯. Press the button again within five
seconds to reduce the brightness by 50%, as indicated by
DIMMER HALF showing in the Lower
Display Line
¯. Press the button again within five
seconds and the main display will go completely dark. Note that this setting is temporary, in that regardless of any changes, the display will always return to full bright­ness when the AVR is turned on. In addition, both the Power Indicator 2 and the blue accent lighting inside the volume control will always remain at full brightness regardless of the setting. This is to remind you that the AVR is still turned on.
i Test Button: Press this button to begin the sequence used to calibrate the AVR 330’s output levels. (See page 23 for more information on calibrating the AVR 330.)
j Sleep Button: Press this button to place the unit in the Sleep mode.After the time shown in the display, the AVR 330 will automatically go into the Standby mode. Each press of the button changes the time until turn-off in the following order:
This button is also used to change channels on your TV when the TV is selected.
When the AVR 330 remote is being programmed with the codes to operate another device, this button is also used in the “Auto Search” process. (See page 35 for more information on programming the remote.)
k DSP Surround Mode Selector: Press this but- ton to cycle through the DSP, VMAx and Stereo sur­round modes such as Hall, Theater, VMAx Near and Far, and Surround Off. This button is also used to tune channels when the TV is selected using the device Input Selector e.When the AVR 330 remote is being programmed with the codes of another device, this button is also used in the “Auto Search” process. (See page 35 for more information on programming the remote.)
l Night Mode: Press this button to activate the Night mode.This mode is available in specially encoded digital sources, and it preserves dialogue (center channel) intelligibility at low volume levels.
m Channel Select Button: This button is used to start the process of setting the AVR 330’s output levels to an external source. Once this button is pressed, use the
⁄/¤
Buttons n
to select the channel being adjusted,
then press the Set Button p, followed by the
⁄/¤
Buttons
n again, to change the level setting. (See
page 30 for more information.)
n
⁄/¤
Buttons: These multipurpose buttons are
used to change or scroll through items in the on­screen menus, make configuration settings such as digital inputs or delay timing, or to select surround modes.When changing a setting, first press the button for the function or setting to be changed (e.g., press the
DSP Surround Mode Selector k to select a
sound field mode or the
Digital Select Button q
to change a digital input) and then press one of these buttons to scroll through the list of options or to increase or decrease a setting. The sections in this manual describing the individual features and functions contain specific information on using these buttons for each application.
o
/
Buttons: These buttons are used to change
the menu selection or setting during some of the setup procedures for the AVR 330.
p Set Button: This button is used to enter settings into the AVR 330’s memory. It is also used in the setup procedures for delay time, speaker configuration and channel output level adjustment.
q Digital Select: Press this button to assign one of the digital inputs
*(wz to a source. (See
page 26 for more information on using digital inputs.)
r Numeric Keys: These buttons serve as a 10- button numeric keypad to enter tuner preset positions. They are also used to select channel numbers when TV, Cable or SAT has been selected on the remote, or to select track numbers on a CD, DVD or LD player, depending on how the remote has been programmed.
s Tuner Mode: Press this button when the tuner is in use to select between automatic tuning and manual tuning. When the button is pressed so that MANUAL appears in the Lower Display Line ¯, pressing the
Tuning Buttons u9≠will move
the frequency up or down in single-step increments. When the FM band is in use, pressing this button when a station’s signal is weak will change to monau­ral reception. (See page 29 for more information.)
90
min
80
min
70
min
60
min
50
min
40
min
30
min
20
min
10
min
OFF
MAIN REMOTE CONTROL FUNCTIONS
11
AVR330 harman/kardon
12 MAIN REMOTE CONTROL FUNCTIONS
MAIN REMOTE CONTROL FUNCTIONS
t Direct Button: Press this button when the tuner is in use to start the sequence for direct entry of a sta­tion’s frequency. After pressing the button, simply press the proper
Numeric Keys r to select a sta-
tion. (See page 29 for more information on the tuner.)
u Tuning Up/Down: When the tuner is in use, these buttons will tune up or down through the selected fre­quency band. If the
Tuner Mode Button s& has
been pressed so that
AUTO appears in the on-
screen and
Lower Display Line ¯, pressing and
holding either of the buttons for three seconds will cause the tuner to seek the next station with acceptable signal strength for quality reception. When
MANUAL
appears in the Lower Display Line ¯, pressing these buttons will tune stations in single-step increments. (See page 29 for more information.)
v OSD Button: Press this button to activate the On-Screen Display (OSD) system used to set up or adjust the AVR 330’s parameters.
w Dolby Mode Selector: This button is used to select from among the available Dolby Surround pro­cessing modes. Each press of this button will select one of the Dolby Pro Logic II modes or Dolby 3 Stereo.When a Dolby Digital-encoded source is in use, the Dolby Digital mode may also be selected. (See page 27 for the available Dolby surround mode options.)
x DTS Digital Mode Selector: When a DTS- encoded digital source is selected, each press of this button will scroll through the available DTS modes.The specific choice of modes will vary according to whether or not the source material contains DTS-ES 6.1 Discrete encoding. When a DTS source is not in use, this button has no function. (See page 27 for the avail­able DTS Digital options.)
y Logic 7 Mode Select Button: Press this button to select from among the available Logic 7 surround modes. (See page 27 for the available Logic 7 options.)
z Skip Up/Down Buttons: These buttons do not have a direct function with the AVR 330, but when used with a compatibly programmed CD or DVD changer they will change to the previous disc in the changer or carousel.
` Transport Controls: These buttons do not have any functions for the AVR 330, but they may be programmed for the forward/reverse play operation of a wide variety of CD or DVD players, and audio or video cassette recorders. (See page 36 for more information.)
Stereo Mode Select Button: Press this button
to select a stereo listening mode.When the button is pressed so that
DSP SURR OFF appears in the
Lower Display Line ¯, the AVR will operate in a
bypass mode with true, fully analog, two-channel left/right stereo mode with no surround processing or bass management, as opposed to other modes where digital processing is used. When the button is pressed so that
SURROUND OFF appears in the Lower
Display Line
¯, you may enjoy a two-channel pres-
entation of the sound along with the benefits of bass management. Depending on whether your system is configured for 5.1 or 6.1/7.1 channels, the next press of the button will cause either
5CHSTERO or 7
CH STEREO
to appear, and the stereo signal will be routed to all five ( or seven) speakers. (See page 27 for more information on stereo playbaqck modes.)
DTS Neo:6 Mode Select: Press this button to
select a DTS Neo:6 mode.These modes take a two­channel stereo- or matrix surround-encoded source and create a full five-, six- or seven-channel sound field. (See page 27 for the available DTS Neo:6 options.)
Macro Buttons: Press these buttons to store or
recall a “Macro”, which is a preprogrammed sequence of commands stored in the remote. (See page 35 for more information on storing and recalling macros.)
Disc Skip Button: This button has no direct
function for the AVR 330 but is most often used to change to the next disc in a CD or DVD player when the remote is programmed for that type of device. (See page 36 for more information on using the remote with products other than the AVR 330.)
Preset Up/Down: When the tuner is in use,
press these buttons to scroll through the stations programmed into the AVR 330’s memory. When some source devices, such as CD players,VCRs and cassette decks, are selected using the device
Input
Selectors
e, these buttons may function as
Chapter Step or Track Advance.
Clear Button: Press this button to clear incorrect
entries when using the remote to directly enter a radio station’s frequency.
Memory Button: Press this button to enter a
radio station into the AVR 330’s preset memory. First, tune the desired station, and then press this button. Two underline indicators will flash at the right side of the
Upper Display Line ˜, and within five seconds
press the
Numeric Keys r for the preset number
between 01 and 30 that you wish to assign to the station. (See page 29 for more information.)
Delay/Prev Ch.: Press this button to begin
the process for setting the delay times used by the AVR 330 when processing surround sound. After pressing this button, the delay times are entered by pressing the
Set Button p and then using the
⁄/¤
Buttons n to change the setting. Press the
Set Button p again to complete the process.
(See page 22 for more information.)
Speaker Select: Press this button to begin
the process of configuring the AVR 330’s bass man­agement system for use with the type of speakers used in your system. Once the button has been pressed, use the
⁄/¤
Buttons n to select the
channel you wish to set up. Press the
Set Button
p and then select another channel to configure. When all adjustments have been completed, press the
Set Button p twice to exit the settings and
return to normal operation. (See page 20 for more information.)
Multiroom: Press this button to activate the
multiroom system or to begin the process of changing the input or volume level for the second zone. (See pages 31 and 33 for more information on the Multiroom system.)
Volume Up/Down: Press these buttons to raise
or lower the system volume.
TV/Video Selector: This button does not have a
direct function on the AVR 330, but when used with a compatibly programmed VCR, DVD or satellite receiver that has a “TV/Video” function, pressing this button will switch between the output of the player or receiver and the external video input to that player. Consult the owner’s manual for your specific player or receiver for the details of how it implements this function.
SPL Selector: This button activates the
AVR 330’s EzSet function to quickly and accurately calibrate the AVR 330’s output levels. Press and hold the button for three seconds and then release it. Press the “
5” or “7Numeric Key r to indicate whether
you are using a 5.1-channel or a 6.1/7.1-channel speaker system with the AVR 330.The test tone will begin circulating, and the
Program/SPL Indicator
c will change colors. During this sequence, EzSet will automatically adjust the output levels for all chan­nels until they are equal, as shown by the
Program/
SPL Indicator
c lighting green for each channel. Press this button again when the adjustment is com­plete to turn off the test tone. (See page 23 for more information on EzSet.)
6-Channel/8-Channel Direct Input: Press
this button to select the device connected to the 8-Channel Direct Inputs j as the audio source. (See page 25 for more information.)
12 MAIN REMOTE CONTROL FUNCTIONS
12
AVR330 harman/kardon
28
29
30
31
32
33
34
35
36
37
38
39
40
41
When you wish to use the 6-Channel/8-Channel Direct Input
j in conjunction with a video source, you must first select the video source by pressing one of the
Input Selectors e, then press this button to
choose the device connected to the
6-Channel/8-
Channel Direct Input
j as the audio source.
Mute: Press this button to momentarily silence
the AVR 330 or TV set being controlled, depending on which device has been selected. When the AVR 330 remote is being programmed to operate another device, this button is pressed with the
Input Selector Button
e to begin the programming process. (See page 35 for more information on programming the remote.)
Ez Set Sensor Microphone: The sensor micro-
phone for the EzSet microphone is behind these slots. When using the remote to calibrate speaker output levels using EzSet, be sure that you do not hold the remote in a way that covers these slots. (See page 23 for more information on using EzSet.)
MAIN REMOTE CONTROL FUNCTIONS 13
MAIN REMOTE CONTROL FUNCTIONS
13
AVR330 harman/kardon
42
43
14
AVR330 harman/kardon
TROUBLESHOOTING GUIDE
TROUBLESHOOTING GUIDE
SYMPTOM CAUSE SOLUTION
Unit does not function when Main • No AC power • Make certain AC power cord is plugged into Power Switch is pushed a live outlet
• Check to see whether outlet is switch-controlled
Display lights, but no sound • Intermittent input connections • Make certain that all input and speaker connections or picture are secure
Mute is on • Press Mute Button
• Volume control is down • Turn up volume control
Unit turns on, but front-panel • Display brightness is turned off • Follow the instructions in the Display Brightness section display does not light up on page 31 so that the display is set to VFD FULL
No sound from any speaker; • Amplifier is in protection mode • Check speaker wire connections for shorts at receiver and light around power switch is red due to possible short speaker ends
• Amplifier is in protection mode • Contact your local Harman Kardon service center due to internal problems
No sound from surround or • Incorrect surround mode • Select a mode other than Stereo center speakers • Input is monaural • There is no surround information from mono sources
• Incorrect configuration • Check speaker mode configuration
• Stereo or Mono program material • The surround decoder may not create center- or rear-channel
information from nonencoded programs
42
Unit does not respond to • Weak batteries in remote • Change remote batteries remote commands • Wrong device selected • Press the AVR selector
• Remote sensor is obscured • Make certain front-panel sensor is visible to remote,
or connect remote sensor
Intermittent buzzing in tuner • Local interference • Move unit or antenna away from computers, fluorescent
lights, motors or other electrical appliances
Letters flash in the channel indicator • Digital audio feed paused • Resume play for DVD display and digital audio stops • Check that Digital Input is selected
Fan does not appear to operate • Additional cooling may not be required • The fan is activated only when additional cooling is required due to
high internal temperature. It is normal for the fan to be inactive at normal volume levels.
Processor Reset
In the rare case where the unit’s operation or the dis­plays seem abnormal, the cause may involve the erratic operation of the system’s memory or microprocessor.
To correct this problem, first unplug the unit from the AC wall outlet and wait at least three minutes. After the pause, reconnect the AC power cord and check the unit’s operation. If the system still malfunctions, a sys­tem reset may clear the problem.
NOTE: Resetting the processor will erase any configu­ration settings you have made for speakers, output levels, surround modes and digital input assignments, as well as the tuner presets.After a reset, the unit will be returned to the factory presets, and all settings for these items must be reentered.
If the system is still operating incorrectly, there may have been an electronic discharge or severe AC line interference that has corrupted the memory or microprocessor.
To clear the AVR 330’s entire system memory includ­ing tuner presets, output level settings, delay times and speaker configuration data, press and hold the
Mode Button
will turn on automatically.
5 buttons for three seconds. The unit
Tone
TROUBLESHOOTING GUIDE 14
If these steps do not solve the problem, consult an authorized Harman Kardon service center.
DISASSEMBLY
15
1) REMOVAL OF TOP COVER
AVR330 harman/kardon
3) PRINCIPAL PARTS LOACTION
TUNER
MODULE
VIDEO PCB
2) REMOVAL OF FRONT PANEL
TRANS FORMER
FRONT PCB
INPUT PCB
MAIN PCB
16
AVR330 harman/kardon
harman/kardon
Service bulletin # H/K2003-10 December 2003 To: All harman/kardon Service Centers Models: AVR130, AVR230, AVR330, HK3380, HK3480 Subject: Volume Level Changes On early versions of the AVR130,AVR230,AVR330,HK3380,HK3480, when the volume control is turned, the
volume level and display may be erratic, and not track accurately, or the level may progress in an unintended direction. This may happen on a random basis and depends on where the volume control knob is positioned after a volume adjustment. During a running production change, new volume encoders were installed.
In the event you receive an AVR model listed above with the complaint “The volume control on my receiver does not track accurately when turned”, perform the following procedure:
REPLACE VR74 (AVR130/230/330) or VR81 (HK3380/3480) VOLUME ENCODER
Note: It is important that t he various screws do not get mixed up and inserted in other locations upon reassembly. Mak e
note or label eac h r emoved screw set; keep them apar t from other screw sets.
1) Remove the top cover, (13) Phillips screws.
2) Remove the volume, bass, treble and balance knobs by pulling them straight out and off. If a tool is necessary for removal of the smaller knobs, make sure the jaws are insulated to avoid knob damage.
3) Remove the (10) Phillips screws holding the front panel ass’y to the chassis: (6) at the bottom and (4) at the sides.
4) Cut all plastic cable ties that would prevent you detaching the front panel ass’y from the chassis. Draw a diagram if necessary, for a location reminder, to aid reassembly.
5) Unplug connector CN15 (6 cond) or CN89 (7 cond) at the left side of the unit. See below.
6) Remove single ground screw at the left side of the unit, near CN15 or CN89. (Black wire)
7) Unplug connector CN72 (32 cond) or CN81 (20 cond) on the DSP PCB, coming from the top of the front panel ass’y. See below.
8) There should now be enough slack in the connecting cables to lift and detach the front panel ass’y from the chassis. Pull the front panel as far away as the remaining connecting wires will allow, enough to tilt and gain access to the rear of the Tone/Volume PCB. See illustrat ion Page 2.
9) Remove the (10) screws or (9) screws holding the Tone/Volume PCB to the front panel.
10) Detach and pull back the PCB; unplug top connector CN84 (7 cond) or CN83 (4 cond) if necessary.
11) Remove and replace VR74 or VR81 (5 soldered pads) with hk part# HSR2A029Z.
12) Reassemble in reverse order, taking care to replace all connectors, cable ties, and ground screw.
13) Power up receiver, and test volume control to assure setting no longer changes settings by itself, or when the volume knob is tapped.
Warranty labor rate: MAJOR repair
Service Bulletin
17
AVR330 harman/kardon
Model
AVR130
AVR130
AVR230
AVR230
AVR330
AVR330
HK3380
HK3380
HK3480
HK3480
Serial Number
120V
AN0006-01000
to
AN0006-13800 AN0006-13801
and above
AN0007-01000
to
AN0007-11400 AN0007-11401
and above
AN0008-01000
to
AN0008-08524 AN0008-08525
and above
AN0015-01000
to
AN0015-02728 AN0015-02729
and above
AN0016-01000
to AN0016-01864 AN0016-01865
and above
STATUS ACTION
Volume control may not track accurately when
turned; erratic operation
Modified By Factory NONE REQUIRED
Volume control may not track accurately when
turned; erratic operation
Modified By Factory NONE REQUIRED
Volume control may not track accurately when
turned; erratic operation
Modified By Factory NONE REQUIRED
Volume control may not track accurately when
turned; erratic operation
Modified By Factory NONE REQUIRED
Volume control may not track accurately when
turned; erratic operation
Modified By Factory NONE REQUIRED
Change VR74
Rotary encoder
Change VR74
Rotary encoder
Change VR74
Rotary encoder
Change VR81
Rotary encoder
Change VR81
Rotary encoder
18
AVR330 harman/kardon
harman/kardon TECH TIPS
Troubleshooting tips and solutions to common service problems
For models: AVR7000/7200/8000 TIP# HKTT2003-01 Rev1
AVR100/200/300/500 AVR110/210/310/510
AVR120/220/320/520 AVR125/225/325/525 AVR130/230/330/430/630
DPR1001 HK3370/3470/3375/3475
Subject: Backup Memory on AVR/DPR/HK series receivers
In the event of the complaint: “the receiver is losing its memory (any programmed system settings) when the unit is turned off, or after the unit is unplugged (briefly*)”:
Check and replace:
Model Designator Location Description Part number
AVR7000 C730 Front PCB 0.047 Farad 5.5v capacitor AVR7200 C106 Front PCB 0.047 Farad 5.5v capacitor # 55134360 AVR8000 C726 Front PCB 0.047 Farad 5.5v capacitor AVR100/200 C412 Front PCB 0.047 Farad 5.5v capacitor # CEGT-B473J-0J0 AVR300 C906 Front PCB 0.1Farad 5.5v capacitor
AVR500 C906 Front PCB 0.1Farad 5.5v capacitor AVR110/210/310/510
AVR120/220/320/520 AVR125/225 C734, C885 Front PCB two 0.1F capacitors in parallel # BCESOHD104 AVR325/525 C106 Front PCB 0.047 Farad 5.5v capacitor # 55134360 AVR130/230/330 BAT1 Front PCB 3.6v Battery # HABGP40BVH3A3H AVR430/630 C657 DSP PCB 0.047 Farad 5.5v capacitor # CEZXA0479MN-5 DPR1001 BC601 Main PCB 0.1Farad 5.5v capacitor # CEGT-B104J-0J0 HK3370/3470 C301 Front PCB 0.1Farad 5.5v capacitor # CEGT-B104J-0J0 HK3375/3475 C301 Front PCB 0.1Farad 5.5v capacitor # CEGT-B104J-0J0
C216 Front PCB 0.047 Farad 5.5v capacitor # 55134360
# 55134360 or # J3432147324X
# 55230310NR or # 55134360
# J4433210421X or # P10791-ND # J4433210421X or # P10791-ND
* After approximately two weeks of being disconnected from A C suppl y , even a normally func tioning rec eiv er may lose any program med settings and switch t o default settings.
A VR33 0 EX P LODED V I EW
CKC1B145S46
19
20
AVR330 harman/kardon
BLOCK DIAGRAM
21
AVR330 harman/kardon
AMPLIFIER SECTION BIAS ADJUSTMENT
Measurement condition
. No input signal or volume position is minimum.
Standard value.
. Ideal current = 48mA ( ± 5%) . Ideal DC Voltage = 25.92mV ( ± 5%)
CUP11651X (BIAS PCB)
...... ......
VR87
CN81
VR86
CN82
VR82
CN86
VR81
DC VOLTMETER..............Connect to CN81,CN82,CN83,CN84,CN85,CN86,CN87
NO. Channel Adjust for
1 Front Left 25.92mV (±5%) 2 Front Right 25.92mV (±5%)
3 Center
4 Surround Left
5 Surround Right
6 7
Surround Back Left
Surround Back Right
25.92mV (±5%)
25.92mV (±5%)
25.92mV (±5%)
25.92mV (±5%)
25.92mV (±5%)
Adjustment
VR82(ONLY AVR230/330)
VR81(ONLY AVR330)
CN87
VR83 VR84 VR85 VR86 VR87
22
AVR330 harman/kardon
VIDEO BOARD
23
AVR330 harman/kardon
FRONT BOARD
24
AVR330 harman/kardon
BOTTOM VIEW
INPUT BOARD
25
AVR330 harman/kardon
TOP VIEW
INPUT BOARD
CAM350󰼿PRO󰼿V󰼿7.6󰼿:󰼿Mon󰼿Sep󰼿01󰼿10:29:56󰼿2003󰼿-󰼿(Untitled)
26
MAIN BOARD 1 (AMP)
27
AVR330 harman/kardon
MAIN BOARD 2 (BIAS & REGULATOR)
28
AVR330 harman/kardon
AVR330 Electrical Parts List
Ref. Designator Part Number Description
FRONT PCB ASS'Y
Capacitors
C703 HCBS1H821KBT CAP , CERAMIC 820PF 50V K C704 HCEA1VH100T CAP , ELECT 10UF 35V C712 HCEA1HH1R0T CAP , ELECT 1UF 50V C713 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z C714 HCBS1H151KBT CAP , CERAMIC 150PF 50V K C715 HCEA1HH4R7T CAP , ELECT 4.7UF 50V C716 HCEA1CH331T CAP , ELECT 330UF 16V C717 HCBS1H221KBT CAP , CERAMIC 220PF 50V K C718 HCBS1H221KBT CAP , CERAMIC 220PF 50V K C719 HCBS1H181KBT CAP , CERAMIC 180PF 50V K C720 HCBS1H181KBT CAP , CERAMIC 180PF 50V K C721 HCBS1H181KBT CAP , CERAMIC 180PF 50V K C722 HCEA1CH101T CAP , ELECT 100UF 16V C723 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z C724 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z C725 CCKT1H473ZF CAP , CERAMIC 0.047UF 50V ZF C726 HCEA0JH102T CAP , ELECT 1000UF 6.3V C727 HCBS1H221KBT CAP , CERAMIC 220PF 50V K C728 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z C729 CCKT1H473ZF CAP , CERAMIC 0.047UF 50V ZF C730 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z C731 HCEA1HH100T CAP , ELECT 10UF 50V C732 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z C733 HCEA1EH470T CAP , ELECT 47UF 25V C735 HCEA1VH100T CAP , ELECT 10UF 35V C736 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z C737 HCBS1H180JT CAP , CERAMIC 18PF 50V C738 HCBS1H180JT CAP , CERAMIC 18PF 50V C770 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z C771 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z C773 HCEA1VH100T CAP , ELECT 10UF 35V C774 HCEA1VH100T CAP , ELECT 10UF 35V C775 HCBS1H151KBT CAP , CERAMIC 150PF 50V K C776 HCBS1H151KBT CAP , CERAMIC 150PF 50V K C777 HCEA1VH100T CAP , ELECT 10UF 35V C778 HCEA1VH100T CAP , ELECT 10UF 35V C779 HCEA1CKS470T CAP, ELECT 47UF 16V C780 HCEA1CKS470T CAP, ELECT 47UF 16V C781 HCEA1CKS100T CAP , ELECT 10UF 16V C782 HCEA1CKS100T CAP , ELECT 10UF 16V C785 HCBS1H470JT CAP , CERAMIC 47PF 50V J C786 HCBS1H470JT CAP , CERAMIC 47PF 50V J C787 HCEA1CKS100T CAP , ELECT 10UF 16V C788 HCEA1CKS100T CAP , ELECT 10UF 16V C789 HCEA1CKS100T CAP , ELECT 10UF 16V C790 HCEA1CKS100T CAP , ELECT 10UF 16V C791 HCEA1CKS470T CAP, ELECT 47UF 16V C792 HCEA1CKS470T CAP, ELECT 47UF 16V C793 KCFE1J183JBT CAP , FILM 0.018UF 63V J C794 KCFE1J183JBT CAP , FILM 0.018UF 63V J C795 KCFE1J823JBT CAP , FILM 0.082UF 63V J C796 KCFE1J823JBT CAP , FILM 0.082UF 63V J C797 KCFE1J332JBT CAP , FILM 0.0033UF 63V J C798 KCFE1J332JBT CAP , FILM 0.0033UF 63V J C799 KCFE1J183JBT CAP , FILM 0.018UF 63V J C800 KCFE1J183JBT CAP , FILM 0.018UF 63V J
29
AVR330 harman/kardon
Ref. Designator Part Number Description
FRONT PCB ASS'Y
C805 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z C806 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z C807 CCKT1H104ZF CAP , CERAMIC 50V 0.1UF C808 CCKT1H181KB CAP , CERAMIC 180PF 50V KB C809 HCEA1AH471T CAP , ELECT 470UF 10V C810 HCEA1CH101T CAP , ELECT 100UF 16V C811 HCEA1CH101T CAP , ELECT 100UF 16V C812 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z C813 HCEA1HH4R7T CAP , ELECT 4.7UF 50V C814 HCEA1HH4R7T CAP , ELECT 4.7UF 50V C815 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z C816 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z C850 HCBS1H471KBT CAP , CERAMIC 470PF 50V C851 HCBS1H471KBT CAP , CERAMIC 470PF 50V C852 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z C855 HCBS1H101KBT CAP , CERAMIC 100PF 50V K C856 HCBS1H101KBT CAP , CERAMIC 100PF 50V K C857 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z C858 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z C859 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z C860 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z C861 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z C862 HCBS1H101KBT CAP , CERAMIC 100PF 50V K C863 HCBS1H101KBT CAP , CERAMIC 100PF 50V K C864 HCEA1VH100T CAP , ELECT 10UF 35V C865 CCKT1H473ZF CAP , CERAMIC 0.047UF 50V ZF C866 HCEA1CKS100T CAP , ELECT 10UF 16V C867 HCEA1CKS100T CAP , ELECT 10UF 16V C868 HCEA1CKS470T CAP, ELECT 47UF 16V C869 HCEA1CKS470T CAP, ELECT 47UF 16V C870 HCBS1H681KBT CAP , CERAMIC 680PF 50V C871 HCBS1H681KBT CAP , CERAMIC 680PF 50V C872 HCEA1CH331T CAP , ELECT 330UF 16V C873 HCEA1CH331T CAP , ELECT 330UF 16V C874 HCBS1H101KBT CAP , CERAMIC 100PF 50V K C875 HCBS1H473ZFT CAP , CERAMIC 0.047UF 50V Z C876 HCBS1H473ZFT CAP , CERAMIC 0.047UF 50V Z C877 HCBS1H473ZFT CAP , CERAMIC 0.047UF 50V Z C878 HCBS1H473ZFT CAP , CERAMIC 0.047UF 50V Z C880 HCEA1AH221T CAP , ELECT 220UF 10V C882 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z C886 HCEA0JH102T CAP , ELECT 1000UF 6.3V C889 HCBS1H220JT CAP , CERAMIC 22PF 50V C890 HCBS1H220JT CAP , CERAMIC 22PF 50V C891 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z C892 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z C893 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z C894 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z C895 HCEA1AH471T CAP , ELECT 470UF 10V C896 HCBS1H223ZFT CAP , CERAMIC 0.022UF 50V Z C897 HCEA1AH471T CAP , ELECT 470UF 10V C900 HCBS1H104ZFT CAP , CERAMIC 0.1UF 50V Z C902 HCEA1HH2R2T CAP , ELECT 2.2UF 50V C853 KCKDKS472ME CAP , CERAMIC(X1/Y2/SC) 0.0047UF/2.5KV
Semiconductors
D724 HVD1SS133MT DIODE 1SS133T-77 D725 HVD1SS133MT DIODE 1SS133T-77 D726 HVD1SS133MT DIODE 1SS133T-77 D727 HVD1SS133MT DIODE 1SS133T-77
30
AVR330 harman/kardon
Ref. Designator Part Number Description
FRONT PCB ASS'Y
D728 HVD1SS133MT DIODE 1SS133T-77 D729 HVD1SS133MT DIODE 1SS133T-77 D730 HVD1SS133MT DIODE 1SS133T-77 D761 HVD1SS133MT DIODE 1SS133T-77 D774 HVD1SS133MT DIODE 1SS133T-77 D775 HVD1SS133MT DIODE 1SS133T-77 D776 KVD1N4003ST DIODE 1N4003 D777 HVD1SS133MT DIODE 1SS133T-77 D778 KVD1N4003ST DIODE 1N4003 D779 HVD1SS133MT DIODE 1SS133T-77 D783 HVD1SS133MT DIODE 1SS133T-77 D784 HVD1SS133MT DIODE 1SS133T-77 D785 HVD1SS133MT DIODE 1SS133T-77 D786 HVDMTZJ5.6BT DIODE , ZENER 5.6V ZENER D787 HVDMTZJ5.6BT DIODE , ZENER 5.6V ZENER D788 HVDMTZJ5.6BT DIODE , ZENER 5.6V ZENER D789 HVDMTZJ5.6BT DIODE , ZENER 5.6V ZENER IC87 HVIRE5VL28CATZ IC , RESET 2.8V I.C , RESET Q701 HVTKRC107MT TRANSISTOR NPN KRC107M Q702 HVTKRC107MT TRANSISTOR NPN KRC107M Q703 HVTKRC107MT TRANSISTOR NPN KRC107M Q704 HVTKRC107MT TRANSISTOR NPN KRC107M Q705 HVTKRC107MT TRANSISTOR NPN KRC107M Q706 HVTKRC107MT TRANSISTOR NPN KRC107M Q722 HVTKRA107MT TRANSISTOR NPN KRA107M Q723 HVTKRC107MT TRANSISTOR NPN KRC107M Q724 HVTKRC107MT TRANSISTOR NPN KRC107M Q725 HVTKRC107MT TRANSISTOR NPN KRC107M Q726 HVTKRC107MT TRANSISTOR NPN KRC107M Q727 HVTKRC107MT TRANSISTOR NPN KRC107M Q728 HVTKRC107MT TRANSISTOR NPN KRC107M Q729 HVTKRC107MT TRANSISTOR NPN KRC107M Q731 KVTKSA1175YT TRANSISTOR NPN KSA1175Y Q732 HVTKRC107MT TRANSISTOR NPN KRC107M Q733 KVTKSC2785YT TRANSISTOR NPN KSC2785Y Q734 HVTKTC2874BT TRANSISTOR , NPN, MUTE KTC2874B Q735 HVTKTC2874BT TRANSISTOR , NPN, MUTE KTC2874B Q736 HVTKTC2874BT TRANSISTOR , NPN, MUTE KTC2874B Q737 HVTKTC2874BT TRANSISTOR , NPN, MUTE KTC2874B Q738 HVTKRC107MT TRANSISTOR NPN KRC107M Q739 HVTKTA1271YT TRANSISTOR PNP KTA1271Y Q740 HVTKRC107MT TRANSISTOR NPN KRC107M Q741 HVTKRC107MT TRANSISTOR NPN KRC107M Q743 HVTKRA107MT TRANSISTOR NPN KRA107M D702 CVD52CSBBCEAB2 BLUE L.E.D D703 CVD52CSBBCEAB2 BLUE L.E.D D704 CVD52CSBBCEAB2 BLUE L.E.D D706 CVD52CSBBCEAB2 BLUE L.E.D D707 CVD52CSBBCEAB2 BLUE L.E.D D723 CVD50BOGDWGA L.E.D , 2 COLOR IC72 BVIMB90F482APFG330 IC , FLASH U-COM FUJITSU IC73 HRVRPM6938H4 SENSOR , REMOTE RPM6938-H4 IC74 HVIS3F84BB I.C , FLASH U-COM S3F84BB IC75 HVI74ACT04MTR I.C , HEX IC76 HVITC74HCU04AFN IC , INVERTER TC74HCU04AFN IC80 HVIHCF4053M013T I.C S.T IC81 HVINJM2068MDTE1 I.C , OP AMP NJM2068MD-TE1 IC82 HVINJM2068MDTE1 I.C , OP AMP NJM2068MD-TE1 IC83 HVI74ACT04MTR I.C , HEX IC84 HVI74ACT04MTR I.C , HEX IC85 HVIRH5VT18C I.C , RESET 1.8V I.C , RESET
Loading...
+ 96 hidden pages
