RF Remote

owner’s manual

For Use with GPSMAP 4000/5000 Series Chartplotters

190-00856-00_0A.indd 1 6/22/2007 1:05:28 PM

© 2007 Garmin Ltd. or its subsidiaries

All rights reserved. Except as expressly provided herein, no part of this manual
may be reproduced, copied, transmitted, disseminated, downloaded or stored in
any storage medium, for any purpose without the express prior written consent
of Garmin. Garmin hereby grants permission to download a single copy of this
manual onto a hard drive or other electronic storage medium to be viewed and
to print one copy of this manual or of any revision hereto, provided that such
electronic or printed copy of this manual must contain the complete text of
this copyright notice and provided further that any unauthorized commercial
distribution of this manual or any revision hereto is strictly prohibited.

Information in this document is subject to change without notice. Garmin reserves
the right to change or improve its products and to make changes in the content
without obligation to notify any person or organization of such changes or
improvements. Visit the Garmin Web site (www.garmin.com) for current updates
and supplemental information concerning the use and operation of this and other
Garmin products.

Garmin® is a trademark of Garmin Ltd. or its subsidiaries, registered in the USA
and other countries. GPSMAP® is a trademark of Garmin Ltd. or its subsidiaries.
This trademark may not be used without the express permission of Garmin.

Refer to your chartplotter owner’s manual or product information sheet to view
the warranty, warnings, cautions, and the software license agreement.

Visit the Garmin Web site (www.garmin.com) for current updates and
supplemental information concerning the use and operation of this and other
Garmin products.

June 2007 Part Number 190-00856-00 Rev. A Printed in Taiwan

190-00856-00_0A.indd 2 6/22/2007 1:05:28 PM

RF Remote Owner’s Manual 1

IntroductIon

IntroductIon

The 4000/5000 Series RF Remote is for use with the following
Garmin chartplotters:

GPSMAP 4008 GPSMAP 5008

GPSMAP 4012 GPSMAP 5012

GPSMAP 4208 GPSMAP 5208

GPSMAP 4212 GPSMAP 5212

The remote is used to control the 4000/5000 screens. It can be used
up to 10 meters (32 feet) from the chartplotter and does not need to
be pointed directly at your chartplotter.

The remote operates on 2 AAA batteries (not included). To replace
the batteries, use a small Phillips screwdriver to open the access
cover on the rear panel. Use alkaline batteries for best results.

•

•

•

•
