D-Link DCS-8000LH/B User Manual

mydlink

connected home series

Version 1.00 | July 30, 2016

User Manual

HD 180-Degree Wi-Fi Camera

DCS-8200LH

Manual Overview

D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Information in this document may become obsolete as our services and websites develop and change. Please refer to http://www.mydlink.com for the most current information. Screen shots were captured from a Galaxy S7 smartphone (Android) using the mydlink Home app version 3.0.5. Note that images may dier on iOS device.

Manual Revision

Revision Date Description

1.00 July 30, 2016 DCS-8200LH Revision A1 with rmware version 1.01

Trademarks

© 2016 D-Link Systems, Inc. All Rights Reserved. D-Link and the D-Link logo are trademarks or registered trademarks of D-Link Corporation or its subsidiaries. All other third-party marks mentioned herein may be trademarks of their respective owners. This publication may not be reproduced, in whole or in part, without prior express written permission from D-Link Systems, Inc.

Table of Contents

Product Overview .............................................................. 4

Package Contents .........................................................................4

System Requirements ................................................................. 4

Introduction ................................................................................... 5

Features ............................................................................................6

Hardware Overview ..................................................................... 7

Wireless Installation Considerations ......................................9

Installation ....................................................................... 10

mydlink Home App ....................................................................10

Mounting the Camera...............................................................13

Conguration ................................................................... 15

Using the mydlink Home App ................................................15

Live View ................................................................................17

Camera Options ..................................................................18

Change Camera Icon/Name .....................................18

Technical Specications .................................................. 34

Contacting Technical Support ........................................36

Warranty ........................................................................... 37

Registration .....................................................................43

Motion Detection ........................................................19

Sound Detection ..........................................................20

Image Settings ..............................................................21

Device Information .....................................................22

My Actions .............................................................................23

Use DCH-S150 Motion Sensor with the Camera ...28

Troubleshooting .............................................................. 33

3D-Link DCS-8200LH User Manual

Section 1 - Product Overview

DCS-8200LH HD 180-Degree Wi-Fi Camera

Power Adapter

Mounting Kit

Quick Install Guide

Product Overview

Package Contents

If any of the above items are missing, please contact your reseller.

Note: Using a power supply with a dierent voltage than the one included with your product will cause damage and void the warranty for this product.

System Requirements

Mobile Device (to use mydlink Home app)

• iPhone, iPad, or Android smartphone or tablet (Refer to the mobile app’s store page to see if your device is compatible)

Network Device and Service

• A wireless router (802.11ac/n/g) with Internet service

• An e-mail account (required to create a mydlink® account)

4D-Link DCS-8200LH User Manual

Section 1 - Product Overview

Introduction

Overview

The HD 180-Degree Wi-Fi Camera (DCS-8200LH) with 180-degree Wide Eye lens lets you see more of your home with a single camera and provides crisp HD 720p video to watch your kids or pets with wall-to-wall coverage. Night vision allows you to see in total darkness and with the microSD card slot you can record video directly from the camera so you never miss a moment. Get automatic push alert notications when sound or motion is detected. Stream live HD 720p video to your smartphone or tablet with the free mydlink Home app for remote monitoring.

Monitor Your Home with Fewer Cameras

The HD 180-Degree Wi-Fi Camera delivers the condence of HD 720p video clarity, ensuring rich detail and crisp image quality for your surveillance streaming and recording. The DCS-8200LH’s 180o Wide Eye lens uses unique hardware with dewarping technology to maximize the video quality with less distortion, letting you see more of your home at a glance. And with built-in Wireless AC, it takes advantage of the latest Wi-Fi technology to give you a high bandwidth connection to your router for streaming 720p HD video from your camera. The Wi-Fi camera is also backwards compatible and will work seamlessly with your existing wireless network. Record footage to a microSD/SDXC card for hassle-free recording and playback1.

Create Your Smart Home with mydlink® Home Products

D-Link Connected Home products work together with hundreds of device combinations to secure, connect and automate your home. Access your camera through the mydlink Home app to view and manage your HD 180-Degree Wi-Fi Camera through your tablet or mobile phone, no matter where you are. Pair your camera with other D-Link Connected Home products to take a snapshot when lights are turned on, begin recording as soon as you leave home and more4.

5D-Link DCS-8200LH User Manual

Section 1 - Product Overview

Features

Premium Resolution and Visibility

• 180o Field of View for wider camera coverage

• HD 720p resolution image quality

• 1 Megapixel progressive CMOS sensor

• See up to 16 feet in complete darkness with built-in IR LEDs

• 8x digital zoom for close-up viewing

Security

• Sound and motion detection with e-mail/push alert notications

• microSD/SDXC card slot for local recording continuously, based on event triggers or according to a schedule

• Built-in microphone

Ease of Use

• Wireless AC technology provides a reliable connection for 720p video streaming and recording

• Backwards compatible with 802.11n/g

• WPS support for easy wireless connection

• Mobile app enabled setup

Convenient Control with mydlink Support

• mydlink Home app support for iPhone, iPad, and Android devices

• View and manage remotely using just your mobile device

A microSDXC Class 6 card or above is recommended (not included). Supports card capacities up to 128GB.

Use of audio or video equipment for recording the image or audio of a person without their k nowledge and consent is prohibited in cer tain states or jurisdictions. The end-user assumes all liability for compliance with applicable

state, local and federal laws.

The DCS-8200LH is not supported by the mydlink.com web portal, mydlink Lite or mydlink + app.

Additional Connected Home products sold separately.

6D-Link DCS-8200LH User Manual

Section 1 - Product Overview

Hardware Overview

Front View

1 Microphone Records audio from the surrounding area.

2 Camera Lens Records video of the surrounding area.

3 IR (Infrared) LEDs Used to illuminate the camera's eld of view at night.

4 Light Sensor

The IR-Cut Removable sensor monitors lighting conditions and switches between color and infrared accordingly.

5 Camera Stand Use as a camera stand or a mounting bracket.

7D-Link DCS-8200LH User Manual

Section 1 - Product Overview

Back View

1 microSD Slot Insert a microSD card (not included) to store video les directly to the camera.

2 Power Connector Connects to the included 5 V DC power adapter (micro-USB connector).

Blinking Orange The camera is ready but not connected to a wireless network.

Solid Green The camera has successfully connected to a wireless network.

3 Power LED

Blinking Green The WPS process is in progress.

Blinking Red LED will blink during the reset process.

4 Reset Button Press and hold this button for 10 seconds to reset the camera back to the factory default settings.

5 WPS Button

Press this button, then press the WPS button on your router to set up a secure wireless connection automatically.

8D-Link DCS-8200LH User Manual

Section 1 - Product Overview

Wireless Installation Considerations

The DCS-8200LH lets you access your network using a wireless connection from anywhere within the operating range of your wireless network. However, the number, thickness and location of walls, ceilings, or other objects that the wireless signals must pass through, may limit the range. Typical ranges vary depending on the types of materials and background RF (radio frequency) noise in your home or business. The key to maximizing wireless range is to follow these basic guidelines:

1. Minimize the number of walls and ceilings between your adapter and other network devices (such as your Network Camera) - each wall or ceiling can reduce your adapter’s range from 3-90 feet (1-30 meters).

2. Be aware of the direct line between network devices. A wall that is 1.5 feet thick (.5 meters), at a 45-degree angle appears to be almost 3 feet (1 meter) thick. At a 2-degree angle, it looks over 42 feet (14 meters) thick. Position your devices so that the signal will travel straight through a wall or ceiling (instead of at an angle) for better reception.

3. Building Materials make a dierence. A solid metal door or aluminum studs may weaken the wireless signal. Try to position your access points, wireless routers, and other networking devices where the signal passes through drywall or open doorways. Materials and objects such as glass, steel, metal, walls with insulation, water (sh tanks), mirrors, le cabinets, brick, and concrete will degrade your wireless signal.

4. Keep your product at least 3-6 feet or 1-2 meters away from electrical devices or appliances that generate RF noise.

5. If you are using 2.4 GHz cordless phones or other radio frequency sources (such as microwave ovens), your wireless connection may degrade dramatically or drop completely. Make sure your 2.4 GHz phone base is as far away from your wireless devices as possible. The base transmits a signal even if the phone in not in use.

9D-Link DCS-8200LH User Manual

Section 2 - Installation

Installation

mydlink Home App

The camera is compatible with the mydlink Home app, which allows your camera to work together with other mydlink Home compatible devices. To install and congure your camera, follow the instructions below:

Download the free mydlink Home app on your smartphone or tablet by scanning the QR code below, or by searching for mydlink Home

in the app store for your device.

Quick Install Card

Select one of the following methods to

download the mydlink Home app:

• Search for mydlink Home at the iTunes App Store or Google Play

• Scan the QR code

• Go to http://mydlinkhomeapp.dlink.com

Launch the app and follow the instructions to

connect and congure your device.

Continue to step 3 on the back of this card.

Once installed, launch the app.

Note: iOS: If you are asked about allowing the app to access your location, select Allow.

Android: Make sure location services are turned on in your

phone’s settings.

Note: Screen shots were captured from a Galaxy S7 smartphone (Android) using the mydlink Home app version 3.0.5. Note that images may dier on iOS device and may dier from a newer version of the mydlink Home app.

10D-Link DCS-8200LH User Manual

Section 2 - Installation

Enter your mydlink email address and password. Check Remember me to have the app

save your login information and will automatically log you in when you launch the mydlink Home app. Tap Log in to continue.

If you forgot your mydlink password, tap Forgot password?.

If you do not have a mydlink account, tap Sign up and follow the instructions to create a mydlink account. It is free and you just need a valid email account.

After logging in, tap the Settings icon in the top-left corner.

Select Add New Device.

11D-Link DCS-8200LH User Manual

Section 2 - Installation

Select Scan QR Code or Manual Setup.

When you are asked to scan a QR code, use the code on the Quick Install Card in your package, or on the label attached to your device.

Follow the on-screen instructions to nish installing your camera. Once complete, you can

congure your camera. Refer to Using the mydlink Home App on page 15 to congure your camera.

Note: In order for notications to work, you must set up a rule rst using the mydlink Home app’s My Actions page. Please refer to page 23 for details on how to set up a rule.

12D-Link DCS-8200LH User Manual

Section 2 - Installation

Mounting the Camera

To mount your camera on a wall or ceiling, please follow the steps below. It is recommended that you congure the camera before mounting.

Step 1

Turn the base plate on the bottom of the camera counterclockwise with a coin to remove it.

2. Place the base plate where you want to position the camera and use a pencil to mark the holes. Make sure the holes are lined up horizontally.

3. Depending on the material of the wall or ceiling, use proper tools to drill two holes 25mm deep with a 6mm drill bit where you marked. If the wall is made out of concrete, drill the holes rst, then insert the plastic anchors to support the screws.

13D-Link DCS-8200LH User Manual
