BERTAZZONI PROFESSIONAL SERIES
24” SEGMENTED COOKTOP
PM24 4 00 X
HIGHLIGHTS
• Front-mounted knobs control reliable ignition systems
with all the Bertazzoni safety feature.
• The one-touch, child safety ignition system lets you
light and adjust burners with one hand.
• The thermocouple safety system automatically stops
the gas flow if the flame goes out, even when electrical
power is cut.
FEATURES
Aluminum Burners 4
Rapid (1x) 11000 Btu/h
Semi-rapid (2x) 6500 Btu/h
Auxiliary (1x) 3400 Btu/h
Maintop stainless steel
Worktop controls knobs
Knobs solid metal
Grates cast iron
One hand ignition yes
TECHNICAL SPECIFICATIONS
Electrical Requirements 120 V 60 Hz
Max Amp usage, power rating 0,1 A - 10 W
Certification CSA
Warranty 2 years parts and labor
ACCESSORIES
A LP conversion kit for all burners is included
TO COOK BEAUTIFULLY
WWW.BERTAZZONI.COM
PM24 4 00 XE
min
INSTALLATION INSTRUCTIONS
PM24 4 00 X
2"
6" 25⁄32 min
20" 15⁄32
11
⁄16
22" 1⁄8
17" 15⁄32
23" 13⁄16
11
19"
2" 11⁄16
⁄16
2" 6⁄8
13
Bertazzoni recommends to operate the appliance after it has been
installed in a cabinet.
The kitchen cabinets shall be made of materials capable of
withstanding temperatures at least 117°F (65°C) above room
temperature in order to avoid possible damage to the cabinets
during appliance usage.
⁄16
8" 27⁄32
2" 11⁄16
Disclaimer: while every effort has been made to insure the accuracy of the information contained in
this brochure, Fratelli Bertazzoni reserves the right to change any part of the information at any time
without notice.
Fratelli Bertazzoni, Bertazzoni and the winged wheel brand icon are registered trademarks of
Bertazzoni Spa.
