ASUS P7F-C4L, P7F-CSAS, P7F-C User Manual

Download

P7F-C Series

P7F-C/SAS P7F-C/4L

Motherboard

E5217

First Edition V1 December 2009

No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR AN Y INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECI FI CATI ONS A ND INFO RMATIO N CONTAI NED IN THIS MA NU AL A RE FURNIS HED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILI TY FOR ANY ERROR S OR IN ACCURACI ES THAT M AY AP PEA R IN TH IS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or copyrights of their respective companies, and are used only for identification or explanation and to the owners’ benefit, without intent to infringe.

Contents

Notices ........................................................................................................ vii

Safety information .................................................................................... viii

About this guide ......................................................................................... ix

Typography .................................................................................................. x

P7F-C Series specications summary ...................................................... xi

Chapter 1: Product introduction

1.1 Welcome! ...................................................................................... 1-3

1.2 Package contents ......................................................................... 1-3

1.3 Serial number label ...................................................................... 1-4

1.4 Special features ............................................................................ 1-4

1.4.1 Product highlights ........................................................... 1-4

Chapter 2: Hardware information

2.1 Before you proceed ..................................................................... 2-3

2.2 Motherboard overview ................................................................. 2-4

2.2.1 Placement direction ........................................................ 2-4

2.2.2 Screw holes .................................................................... 2-4

2.2.3 Motherboard layout ......................................................... 2-5

2.2.4 Layout contents ............................................................... 2-7

2.3 Central Processing Unit (CPU) ................................................... 2-9

2.3.1 Installing the CPU ........................................................... 2-9

2.3.2 Installing the CPU heatsink and fan .............................. 2-12

2.3.3 Uninstalling the CPU heatsink and fan ......................... 2-13

2.3.4 Installing the CPU heatsink in rack ............................... 2-14

2.4 System memory ......................................................................... 2-15

2.4.1 Overview ....................................................................... 2-15

2.4.2 Memory Configurations ................................................. 2-15

2.4.3 Installing a DIMM .......................................................... 2-16

2.4.4 Removing a DIMM ........................................................ 2-16

2.5 Expansion slots .......................................................................... 2-17

2.5.1 Installing an expansion card ......................................... 2-17

2.5.2 Configuring an expansion card ..................................... 2-17

2.5.3 Interrupt assignments ................................................... 2-18

2.5.4 PCI Express x16 slots (x8 link) ..................................... 2-19

2.5.5 PCI slots ........................................................................ 2-19

2.5.6 Installing i Button ........................................................... 2-20

iii

Contents

2.5.7 Connect Thermal sensor cable ..................................... 2-20

2.6 Jumpers ...................................................................................... 2-21

2.7 Connectors ................................................................................. 2-25

2.7.1 Rear panel connectors .................................................. 2-25

2.7.2 Internal connectors ....................................................... 2-26

Chapter 3: Powering up

3.1 Starting up for the rst time ........................................................ 3-3

3.2 Powering off the computer .......................................................... 3-4

3.2.1 Using the OS shut down function .................................... 3-4

3.2.2 Using the dual function power switch .............................. 3-4

Chapter 4: BIOS setup

4.1 Managing and updating your BIOS ............................................ 4-3

4.1.1 ASUS EZ Flash 2 utility ................................................... 4-3

4.1.2 BUPDATER utility............................................................ 4-4

4.1.3 ASUS CrashFree BIOS 3 utility ...................................... 4-6

4.2 BIOS setup program .................................................................... 4-7

4.2.1 BIOS menu screen .......................................................... 4-8

4.2.2 Menu bar ......................................................................... 4-8

4.2.3 Navigation keys ............................................................... 4-8

4.2.4 Menu items ..................................................................... 4-9

4.2.5 Sub-menu items .............................................................. 4-9

4.2.6 Configuration fields ......................................................... 4-9

4.2.7 Pop-up window ............................................................... 4-9

4.2.8 Scroll bar ......................................................................... 4-9

4.2.9 General help ................................................................... 4-9

4.3 Main menu .................................................................................. 4-10

4.3.1 System Time [xx:xx:xx] ................................................. 4-10

4.3.2 System Date [Day xx/xx/xxxx] ....................................... 4-10

4.3.3 SATA1—6 .......................................................................4-11

4.3.4 Storage Configuration ................................................... 4-13

4.3.5 AHCI Configuration ....................................................... 4-14

4.3.6 System Information ....................................................... 4-15

4.4 Advanced menu ......................................................................... 4-16

4.4.1 CPU Configuration ........................................................ 4-16

4.4.2 Chipset .......................................................................... 4-20

Contents

4.4.3 Onboard Devices Configuration .................................... 4-22

4.4.4 USB Configuration ........................................................ 4-24

4.4.5 PCIPnP ......................................................................... 4-25

4.4.6 ACPI Configuration ....................................................... 4-26

4.4.7 Event Log Configuration ............................................... 4-28

4.4.8 Intel VT-d Configuration [Disabled] ............................... 4-28

4.4.9 SR-IOV Supprted [Disabled] ......................................... 4-28

4.5 Server menu ............................................................................... 4-29

4.5.1 Remote Access Configuration ....................................... 4-29

4.6 Power menu ................................................................................ 4-31

4.6.1 APM Configuration ........................................................ 4-31

4.6.2 Hardware Monitor ......................................................... 4-33

4.7 Boot menu .................................................................................. 4-34

4.7.1 Boot Device Priority ...................................................... 4-34

4.7.2 Hard Disk Drives; CDROM Drives ................................ 4-34

4.7.3 Boot Settings Configuration .......................................... 4-35

4.7.4 Security ......................................................................... 4-36

4.8 Tools menu ................................................................................. 4-38

4.8.1 ASUS EZ Flash 2 .......................................................... 4-38

4.9 Exit menu .................................................................................... 4-39

Chapter 5: RAID conguration

5.1 Setting up RAID ............................................................................ 5-3

5.1.1 RAID definitions .............................................................. 5-3

5.1.2 Installing hard disk drives ................................................ 5-4

5.1.3 Setting the RAID item in BIOS ........................................ 5-4

5.1.4 RAID configuration utilities .............................................. 5-4

5.2 Intel® Matrix Storage Manager Option ROM Utility ................... 5-5

5.2.1 Creating a RAID set ........................................................ 5-6

5.2.2 Creating a Recovery set ................................................. 5-7

5.2.3 Deleting a RAID set ........................................................ 5-9

5.2.4 Resetting disks to Non-RAID ........................................ 5-10

5.2.5 Recovery Volume Options .............................................5-11

5.2.6 Exiting the Intel® Matrix Storage Manager .................... 5-12

5.2.7 Rebuilding the RAID ..................................................... 5-12

5.2.8 Setting the Boot array in the BIOS Setup Utility ............ 5-14

5.3 LSI Logic MPT Setup Utility (P7F-C/SAS model only) ............ 5-15

Contents

5.3.1 Integrated Mirroring ....................................................... 5-15

5.3.2 Integrated Mirroring Enhanced ..................................... 5-19

5.3.3 Integrated Striping (IS) volume ..................................... 5-22

5.3.4 Managing Arrays ........................................................... 5-25

5.3.5 Viewing SAS topology ................................................... 5-30

5.3.6 Global Properties .......................................................... 5-31

5.4 LSI Software RAID Conguration Utility

(P7F-C/4L model only) ............................................................... 5-34

5.4.1 Creating a RAID set ...................................................... 5-35

5.4.2 Adding or viewing a RAID configuration ....................... 5-41

5.4.3 Initializing the virtual drives ........................................... 5-42

5.4.4 Rebuilding failed drives ................................................. 5-46

5.4.5 Checking the drives for data consistency ..................... 5-48

5.4.6 Deleting a RAID configuration ....................................... 5-51

5.4.7 Selecting the boot drive from a RAID set ...................... 5-52

5.4.8 Enabling WriteCache .................................................... 5-53

Chapter 6: Driver installation

6.1 RAID driver installation ............................................................... 6-3

6.1.1 Creating a RAID driver disk ............................................ 6-3

6.1.2 Installing the RAID controller driver ................................ 6-6

6.2 Intel® chipset device installation .............................................. 6-19

6.3 LAN driver installation ............................................................... 6-21

6.4 VGA driver installation............................................................... 6-23

6.4.1 Windows® Server 2003 ................................................. 6-23

6.5 Management applications and utilities installation ................ 6-25

6.5.1 Running the support DVD ............................................. 6-25

6.5.2 Drivers menu ................................................................. 6-25

6.5.3 Utilities menu ................................................................ 6-26

6.5.4 Make disk menu ............................................................ 6-26

6.5.5 Contact information ....................................................... 6-26

Appendix: Reference information

A.1 P7F-C/SAS Series block diagram ...............................................A-3

A.2 P7F-C/4L Series block diagram ..................................................A-4

Notices

Federal Communications Commission Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

•

This device may not cause harmful interference, and

•

This device must accept any interference received including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with manufacturer’ s instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment.

Canadian Department of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

This class B digital apparatus complies with Canadian ICES-003.

REACH

Complying with the REACH (Registration, Evaluation, Authorization, and Restriction of Chemicals) regulatory framework, we published the chemical substances in our products at ASUS REACH website at http://green.asus.com/english/REACH.htm.

vii

Safety information

Electrical safety

• To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system.

• When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.

• Before connecting or removing signal cables from the motherboard, ensure that all power cables are unplugged.

• Seek professional assistance before using an adapter or extension cord. These devices could interrupt the grounding circuit.

• Make sure that your power supply is set to the correct voltage in your area. If you are not sure about the voltage of the electrical outlet you are using, contact your local power company.

• If the power supply is broken, do not try to fix it by yourself. Contact a qualified service technician or your retailer.

Operation safety

• Before installing the motherboard and adding devices on it, carefully read all the manuals that came with the package.

• Before using the product, make sure all cables are correctly connected and the power cables are not damaged. If you detect any damage, contact your dealer immediately.

• To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots, sockets and circuitry.

• Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it may become wet.

• Place the product on a stable surface.

• If you encounter technical problems with the product, contact a qualified service technician or your retailer.

viii

This symbol of the crossed out wheeled bin indicates that the product (electrical, electronic equipment, and mercury-containing button cell battery) should not be placed in municipal waste. Check local regulations for disposal of electronic products.

About this guide

This user guide contains the information you need when installing and configuring the motherboard.

How this guide is organized

This user guide contains the following parts:

• Chapter 1: Product introduction

This chapter describes the features of the motherboard and the new technologies it supports.

• Chapter 2: Hardware information

This chapter lists the hardware setup procedures that you have to perform when installing system components. It includes description of the switches, jumpers, and connectors on the motherboard.

• Chapter 3: Powering up

This chapter describes the power up sequence and ways of shutting down the system.

• Chapter 4: BIOS setup

This chapter tells how to change system settings through the BIOS Setup menus. Detailed descriptions of the BIOS parameters are also provided.

• Chapter 5: RAID conguration

This chapter provides instructions for setting up, creating, and configuring

RAID sets using the available utilities.

• Chapter 6: Driver installation

This chapter provides instructions for installing the necessary drivers for different system components.

• Appendix: Reference information

This appendix includes additional information that you may refer to when configuring the motherboard.

Where to nd more information

Refer to the following sources for additional information and for product and software updates.

1. ASUS websites

The ASUS website provides updated information on ASUS hardware and software products. Refer to the ASUS contact information.

2. Optional documentation

Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer. These documents are not part of the standard package.

Conventions used in this guide

To make sure that you perform certain tasks properly, take note of the following symbols used throughout this manual.

DANGER/WARNING:

when trying to complete a task.

CAUTION:

when trying to complete a task.

IMPORTANT:

task.

NOTE:

task.

Information to prevent damage to the components

Instructions that you MUST follow to complete a

Tips and additional information to help you complete a

Information to prevent injury to yourself

Typography

Bold text Indicates a menu or an item to select.

Italics Used to emphasize a word or a phrase. <Key> Keys enclosed in the less-than and greater than sign means that you must press the enclosed key.

Example: <Enter> means that you must press the Enter or Return key.

<Key1+Key2+Key3> If you must press two or more keys simultaneously, the key names are linked with a plus sign (+).

Example: <Ctrl+Alt+D>

Command

exactly as shown, then supply the required item or value enclosed in brackets.

Example: At the DOS prompt, type the command line:

Means that you must type the command

format A:/S

P7F-C Series specications summary

Model Name P7F-C/SAS P7F-C/4L Processor / System Bus

Core Logic Form Factor ASUS Features FAN speed

Memory Total Slots

Expansion Slots (follow SSI Loacation #)

Storage SATA Controller

Networking LAN

Graphic VGA

control Rack Ready

(Rack and Pedestal dual use)

ASWM2.0

Capacity

Memory Type

Memory Size

Total PCI/PCI-X/ PCI-E Slots

Slot Loacation 1 Slot Loacation 2 Slot Loacation 3 Slot Loacation 4 Slot Loacation 5 Slot Loacation 6

SAS Controller

1 * Socket LGA1156 Quad Core Intel Xeon 3400 series Server Processor

Quad Core Intel Core i7-800 series Desktop Processor Quad Core Intel Core i5-700 series Desktop Processor Dual Core 32nm CPU design Ready

Dual Core/Quad Core Intel® 3420 PCH ATX, 12" * 9.6" V V

V V

V V 6/4 (RDIMM/UDIMM) Maximum up to 32GB (RDIMM)

Maximum up to 16GB (UDIMM ) Desktop Processor do not support RDIMM nor ECC UDIMM

DDR3 1066/1333 Unbuffered DIMM with ECC/ non ECC** DDR3 800/1066/1333 Reg DIMM

1 GB, 2GB, 4GB, 8GB (RDIMM) 1 GB, 2GB, 4GB (UDIMM)

6 6

1 * PCI 32bit/33 MHz 1 * PCI 32bit/33 MHz 1 * PCI 32bit/33 MHz 1 * PCI-E x16 (Gen2 x8 link) 1 * PCI 32bit/33 MHz 1 * PCI-E x16 (Gen2 x8 link) Intel® 3420:

6* SATA2 300MB/s ports Intel Matrix Storage utility supports software RAID 0, 1, 10 & 5(Windows) LSI MegaRAID driver supports software RAID 0, 1& 10(Windows & Linux) (P7F-C/4L only)

LSI 1068E 8-port SAS controller: LSI® Integrated RAID 0, 1, 1E support

2 * Marvell® 8056 PCI-E GbE LAN

XGI® Z9s DDR2 64MB

—

4 * Marvell® 8056 PCI-E GbE LAN

P7F-C Series specications summary

Onboard I/O Connectors

Rear I/O Connectors

Management Solution

Monitoring CPU

Environment

*Specications are subject to change without notice.

PSU Connector

USB Connectors

Fan Header Chassis Intruder Serial Port

Header External Serial

Port External USB

Port VGA Port RJ-45 PS/2 KB/Mouse Software

Temperature FAN RPM

24-pin ATX power connector + 8-pin ATX 12V power connector 24+4 pin power supply supported

3 (support 5 USB port) (One for internal Type A USB connector )

5* 4pin 1 1 1 1

1 1

2 2

1 1 2 4 1 1 ASWM2.0 ASWM2.0

V V

Operation temperature: 10℃—35℃ Non operation temperature: -40℃—70℃

Non operation humidity: 20%—90% ( Non condensing)

xii

This chapter describes the motherboard features and the new technologies it supports.

Product

introduction

Chapter summary

1.1 Welcome! ...................................................................................... 1-3

1.2 Package contents ......................................................................... 1-3

1.3 Serial number label ...................................................................... 1-4

1.4 Special features ............................................................................ 1-4

ASUS P7F-C Series

1.1 Welcome!

Thank you for buying an ASUS® P7F-C Series motherboard!

The motherboard delivers a host of new features and latest technologies, making it another standout in the long line of ASUS quality motherboards!

Before you start installing the motherboard, and hardware devices on it, check the items in your package with the list below.

1.2 Package contents

Check your motherboard package for the following items.

Cables SATA data cable

Accessories

Application CD Support CD Documentation User Guide

Packing Qty.

IO shield Plate for LGA1156 (1U)

If any of the above items is damaged or missing, contact your retailer.

Standard Gift Box Pack

P7F-C Series

6 -1 1 1 1 1 1 1 1

1pc per carton 10pcs per carton

Standard Bulk Pack

ASUS P7F-C Series 1-3

1.3 Serial number label

Before requesting support from the ASUS Technical Support team, you must take note of the motherboard's serial number containing 13 characters shown as the figure below. With the correct serial number of the product, ASUS Technical Support team members can then offer a quicker and satisfying solution to your problems.

xxS2xxxxxxxxx

P7F-C Series

xxS2xxxxxxxxx

Made

China

合格

1.4 Special features

1.4.1 Product highlights

Intel® LGA1156 Xeon 3400 Processor Ready

This motherboard supports the latest Intel® Xeon 3400 processors in LGA1156 package, which has memory and PCI Express controller integrated to support 2-channel (6 DIMMs) DDR3 memory and 16 PCI Express 2.0 lanes, providing great graphics performance. Intel® Xeon 3400 processor is one of the most powerful and energy efficient CPU in the world.

Intel Turbo Boost

Intel® Turbo Boost opportunistically and automatically allows the processor to run faster than the marked frequency if the processor is operating below power, temperature and current limits. This technology increases performance of both multi-threaded and single-threaded workloads.

Intel Hyper Threading

The thread-level parallelism on each processor makes more efficient use of the processor resources, higher processing throughout and improved performance on today's multi-threaded software.

Intel® EM64T

The motherboard supports Intel® processors with the Intel® EM64T (Extended Memory 64 Technology). The Intel® EM64T feature allows your computer to run on 64-bit operating systems and access larger amounts of system memory for faster and more efficient computing.

1-4 Chapter 1: Product introduction

DDR3 memory support

The P7F-C Series supports UDIMM and RDIMM DDR3 memory that features data transfer rates of 1333/1066 MHZ to meet the higher bandwidth requirements of server and workstation applications. The 2-channel DDR3 architecture boosts system performance, eliminating bottlenecks. Furthermore, the supply voltage for the memory is reduced from 1.8 V for DDR2 to just 1.5V for DDR3. This voltage reduction limits the power consumption and heat generation of DDR3 which makes it an ideal memory solution.

PCIe 2.0

This motherboard supports the latest PCIe 2.0 device for twice the current speed and bandwidth. This enhances system performance while still providing backward compatibility to PCIe 1.0 devices.

Marvell 88E8056 LAN Solution

The motherboard comes with dual/quad Gigabit LAN controllers and ports which provide a total solution for your networking needs. The onboard Marvell 88E8056 Gigabit LAN controllers use the PCI Express interface and could achieve network throughput close to Gigabit bandwidth.

Serial Attached SCSI (SAS) technology support

(P7F-C/SAS model only)

SAS is the latest storage interface for enterprise-class storage devices. Building on and improving the parallel SCSI foundation, SAS is the new industry standard that includes Serial ATA interoperability, and is projected to be the successor of the Ultra320 SCSI technology.

Enhanced Intel SpeedStep Technology (EIST)

The Enhanced Intel SpeedStep Technology (EIST) intelligently manages the CPU resources by automatically adjusting the CPU voltage and core frequency depending on the CPU loading and system speed or power requirement.

Serial ATA II technology

The motherboard supports the Serial ATA II 3 Gb/s technology through the Serial ATA interface and Intel 3420 chipset. The Serial ATA II specification provides twice the bandwidth of the current Serial ATA products with a host of new features, including Native Command Queuing (NCQ), Power Management (PM) Implementation Algorithm, and Hot Swap. Serial ATA allows thinner, more flexible cables with lower pin count and reduced voltage requirements.

ASUS P7F-C Series 1-5

USB 2.0 technology

The motherboard implements the Universal Serial Bus (USB) 2.0 specification, dramatically increasing the connection speed from the 12 Mbps bandwidth on USB

1.1 to a fast 480 Mbps on USB 2.0. USB 2.0 is backward compatible with USB 1.1.

Temperature, fan, and voltage monitoring

The CPU temperature is monitored to prevent overheating and damage. The system fan rotations per minute (RPM) is monitored for timely failure detection. The chip monitors the voltage levels to ensure stable supply of current for critical components.

1-6 Chapter 1: Product introduction

This chapter lists the hardware setup procedures that you have to perform when installing system components. It includes description of the jumpers and connectors on the motherboard.

Hardware

information

Chapter summary

2.1 Before you proceed ..................................................................... 2-3

2.2 Motherboard overview ................................................................. 2-4

2.3 Central Processing Unit (CPU) ................................................... 2-9

2.4 System memory ......................................................................... 2-15

2.5 Expansion slots .......................................................................... 2-17

2.6 Jumpers ...................................................................................... 2-21

2.7 Connectors ................................................................................. 2-25

ASUS P7F-C Series

2.1 Before you proceed

Take note of the following precautions before you install motherboard components or change any motherboard settings.

• Unplug the power cord from the wall socket before touching any component.

• Use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, before handling components to avoid damaging them due to static electricity.

• Hold components by the edges to avoid touching the ICs on them.

• Whenever you uninstall any component, place it on a grounded antistatic pad or in the bag that came with the component.

• Before you install or remove any component, ensure that the power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, and/or components.

Onboard LED

1. Standby Power LED

The motherboard comes with a standby power LED. The green LED lights up

to indicate that the system is ON, in sleep mode, or in soft-off mode. This is a reminder that you should shut down the system and unplug the power cable before removing or plugging in any motherboard component. The illustration below shows the location of the onboard LED.

ASUS P7F-C Series 2-3

2.2 Motherboard overview

Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it.

To optimize the motherboard features, we highly recommend that you install it in an ATX 1.1 compliant chassis.

Ensure to unplug the chassis power cord before installing or removing the motherboard. Failure to do so can cause you physical injury and damage motherboard components!

2.2.1 Placement direction

When installing the motherboard, ensure that you place it into the chassis in the correct orientation. The edge with external ports goes to the rear part of the chassis as indicated in the image below.

2.2.2 Screw holes

Place nine (9) screws into the holes indicated by circles to secure the motherboard to the chassis.

DO NOT overtighten the screws! Doing so can damage the motherboard.

Place this side towards

the rear of the chassis

2-4 Chapter 2: Hardware information

2.2.3 Motherboard layout

P7F-C/SAS

ASUS P7F-C Series 2-5

P7F-C/4L

2-6 Chapter 2: Hardware information

2.2.4 Layout contents

Slots/Soocket Page

1. CPU sockets

2. DDR3 sockets

3. PCI Express x 16 slot (x8 link)

4. PCI slots

Jumpers Page

1. Clear RTC RAM (CLRTC1)

2. VGA controller setting (3-pin VGA_SW1))

3. CPU Fan and Chassis Fan control setting (3-pin CPUFAN_SEL1, CHAFAN_SEL1)

4. LAN controller setting (3-pin LAN_SW1, LAN_SW2) (LAN_SW3, LAN_SW4 P7F-C/4L Model only)

5. RAID configuration utility selection (3-pin RAID_SEL1) (P7F-C/4L Model only)

6. Onboard storage setting (3-pin SAS_SW1) (P7F-C/SAS Model only)

7. Force BIOS recovery setting (3-pin RECOVERY1)

Rear panel connectors Page

1. PS/2 mouse port (green)

2. PS/2 keyboard port (purple)

3. USB 2.0 ports 1 and 2

4. Serial (COM1) port

5. Video Graphics Adapter port

6. LAN 1 (RJ-45) port

7. LAN 2 (RJ-45) port

8. LAN 2 (RJ-45) port

9. LAN 2 (RJ-45) port

2-9

2-15

2-19

2-21

2-22

2-23

2-24

2-25

ASUS P7F-C Series 2-7

Internal connectors Page

1. Serial ATA connectors (7-pin SATA1, SATA2, SATA3, SATA4; RED) (7-pin SATA5, SATA6; Black)

2. Hard disk activity LED connector (4-pin HDLED1)

3. SAS connectors (7-pin SAS1, SAS2, SAS3, SAS4; RED) (7-pin SAS5, SAS6, SAS7, SAS8; Blue) (P7F-C/SAS model only)

4. USB connector (10-1 pin USB34, USB56; A-Type USB7)

5. Serial General Purpose Input/Output connector (6-1 pin SGPIO1)

6. Serial General Purpose Input/Output connectors (6-1 pin SGPIO2/3) (P7F-C/SAS model only)

7. Serial port connector (10-1 pin COM2)

8. CPU, front and rear fan connectors (4-pin CPU_FAN1, FRNT_FAN1, FRNT_FAN2, FRNT_FAN3, REAR_FAN1)

9. ATX power connectors (24-pin EATXPWR1, 8-pin EATX12V1)

10. Thermal sensor cable connectors (3-pin TR1)

11. Parallel port connector (26-1 pin LPT1)

12. System panel connector (20-1 pin PANEL1)

13. Auxiliary panel connector (20-2 pin AUX_PANEL1)

2-26

2-27

2-28

2-29

2-30

2-31

2-32

2-33

2-8 Chapter 2: Hardware information

2.3 Central Processing Unit (CPU)

The motherboard comes with a surface mount LGA1156 socket designed for the Intel® Xeon 3400 series Processors.

• Upon purchase of the motherboard, ensure that the PnP cap is on the socket and the socket contacts are not bent. Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components. ASUS will shoulder the cost of repair only if the damage is shipment/transit-related.

• Keep the cap after installing the motherboard. ASUS will process Return Merchandise Authorization (RMA) requests only if the motherboard comes with the cap on the LGA1156 socket.

• The product warranty does not cover damage to the socket contacts resulting from incorrect CPU installation/removal, or misplacement/loss/ incorrect removal of the PnP cap.

2.3.1 Installing the CPU

To install a CPU:

1. Locate the CPU socket on the motherboard.

Before installing the CPU, ensure that the socket box is facing toward you and the load lever is on your left.

2. Press the load lever with your

Load lever

thumb (A), and then move it to the right (B) until it is released from the retention tab.

To prevent damage to the socket pins, do not remove the PnP cap unless you are installing a CPU.

ASUS P7F-C Series 2-9

Retention tab

3. Lift the load lever in the direction of the arrow until the load plate is completely lifted.

4. Remove the PnP cap from the CPU socket.

Load plate

PnP cap

Cap tab

5. Position the CPU over the socket, ensuring that the gold triangle is on the bottom-left corner of the socket, and then fit the socket alignment

CPU notches

keys into the CPU notches.

The CPU fits in only one correct orientation. DO NOT force the CPU into the socket to prevent bending the connectors on the socket and damaging the CPU!

2-10 Chapter 2: Hardware information

Gold

triangle

mark

Alignment keys

6. Apply some Thermal Interface Material to the exposed area of the CPU that the heatsink will be in contact with, ensuring that it is spread in an even thin layer.

Some heatsinks come with preapplied thermal paste. If so, skip this step.

The Thermal Interface Material is toxic and inedible. DO NOT eat it. If it gets into your eyes or touches your skin, wash it off immediately, and seek professional medical help.

7. Close the load plate (A), and then push down the load lever (B), ensuring that the front edge of the load plate slides under the retention knob (C).

8. Insert the load lever under the retention tab.

ASUS P7F-C Series 2-11

2.3.2 Installing the CPU heatsink and fan

The Intel® LGA1156 processor requires a specially designed heatsink and fan assembly to ensure optimum thermal condition and performance.

• When you buy a boxed Intel® processor, the package includes the CPU fan and heatsink assembly. If you buy a CPU separately, ensure that you use only Intel®-certified multi-directional heatsink and fan.

• Your Intel® LGA1156 heatsink and fan assembly comes in a push-pin design and requires no tool to install.

• Use an LGA1156-compatible CPU heatsink and fan assembly only. The LGA1156 socket is incompatible with the LGA775 and LGA1366 sockets in size and dimension.

If you purchased a separate CPU heatsink and fan assembly, ensure that the Thermal Interface Material is properly applied to the CPU heatsink or CPU before you install the heatsink and fan assembly.

Ensure that you have installed the motherboard to the chassis before you install the CPU fan and heatsink assembly.

To install the CPU heatsink and fan:

1. Place the heatsink on top of the installed CPU, making sure that the four fasteners match the holes on the motherboard.

2. Push down two fasteners at a time in a diagonal sequence to secure

the heatsink and fan assembly in place.

2-12 Chapter 2: Hardware information

Orient the heatsink and fan assembly such that the CPU fan cable is closest to the CPU fan connector.

3. Connect the CPU fan cable to the connector on the motherboard labeled CPU_FAN1.

DO NOT forget to connect the CPU fan connector! Hardware monitoring errors can occur if you fail to plug this connector.

2.3.3 Uninstalling the CPU

heatsink and fan

To uninstall the CPU heatsink and fan:

1. Disconnect the CPU fan cable from the connector on the motherboard.

2. Rotate each fastener counterclockwise.

3. Pull up two fasteners at a time in a diagonal sequence to disengage the heatsink and fan assembly from the motherboard.

4. Carefully remove the heatsink and fan assembly from the motherboard.

ASUS P7F-C Series 2-13

2.3.4 Installing the CPU heatsink in rack

The Intel® 1156 processors require a specially designed heatsink to ensure optimum thermal condition and performance.

• Ensure that you use qualified heatsink assembly only.

• Ensure that you have applied the thermal interface material to the top of the CPU before installing the heatsink.

1. Peel off the sticker on the heatsink metal plate and affix the plate to the back of the motherboard, matching the standoffs to the heatsink screw holes.

2. Use a Phillips screwdriver to tighten the four heatsink screws in a diagonal sequence.

Ensure that the heatsink is not skewed or tilted, otherwise the CPU will overheat.

2-14 Chapter 2: Hardware information

2.4 System memory

2.4.1 Overview

The motherboard comes with six Double Data Rate 3 (DDR3) Dual Inline Memory Modules (DIMM) sockets.

A DDR3 module has the same physical dimensions as a DDR2 DIMM but is notched differently to prevent installation on a DDR2 DIMM socket. DDR3 modules are developed for better performance with less power consumption.

The figure illustrates the location of the DDR3 DIMM sockets:

2.4.2 Memory Congurations

You may install 1 GB, 2 GB, 4 GB, 8 GB Registerd, or 1 GB, 2 GB, 4 GB Unbuffered with ECC/Non-ECC DDR3 DIMMs into the DIMM sockets using the memory configurations in this section.

RDIMM* DIMM Slot

Per Channel

3 1 Registered DDR3 ECC 1333 Single Rank, Dual Rank 3 1 Registered DDR3 ECC 1066 Quad Rank 3 2 Registered DDR3 ECC 1333 Single Rank, Dual Rank 3 2 Registered DDR3 ECC 800** Quad Rank 3 3 Registered DDR3 ECC 800** Single Rank, Dual Rank

UDIMM DIMM Slot

Per Channel

2 1 Unbuffered DDR3 1333 Single Rank, Dual Rank 2 2 Unbuffered DDR3 1333 Single Rank, Dual Rank *Support Low Voltage DIMMs; **Down from 1066 or 1333 MHz DIMM

DIMM Populated per Channel

DIMM Type Speed Rank per DIMM

• Always install DIMMs with the same CAS latency. For optimum compatibility, it is recommended that you obtain memory modules from the same vendor. DO NOT combine RDIMM and UDIMM.

• The motherboard supports x8 DRAM Only and x4 & x16 DRAM are not supported

ASUS P7F-C Series 2-15

2.4.3 Installing a DIMM

Unplug the power supply before adding or removing DIMMs or other system components. Failure to do so can cause severe damage to both the motherboard and the components.

To install a DIMM:

1. Press the retaining clips outward to unlock a DIMM socket.

2. Align a DIMM on the socket such that the notch on the DIMM

matches the break on the socket.

3. Firmly insert the DIMM into the socket until the retaining clips snap back in place and the DIMM is properly seated.

• A DDR3 DIMM is keyed with a notch so that it fits in only one direction. DO NOT force a DIMM into a socket to avoid damaging the DIMM.

• The DDR3 DIMM sockets do not support DDR and DDR2 DIMMs. DO NOT install DDR or DDR2 DIMMs to the DDR3 DIMM sockets.

2.4.4 Removing a DIMM

To remove a DIMM:

1. Simultaneously press the retaining clips outward to unlock the DIMM.

Support the DIMM lightly with your fingers when pressing the retaining clips. The DIMM might get damaged when it flips out with extra force.

DDR3 DIMM notch

Unlocked retaining clip

DDR3 DIMM notch

2. Remove the DIMM from the socket.

2-16 Chapter 2: Hardware information

2.5 Expansion slots

In the future, you may need to install expansion cards. The following subsections describe the slots and the expansion cards that they support.

Ensure to unplug the power cord before adding or removing expansion cards. Failure to do so may cause you physical injury and damage motherboard components.

2.5.1 Installing an expansion card

To install an expansion card:

1. Before installing the expansion card, read the documentation that came with it and make the necessary hardware settings for the card.

2. Remove the system unit cover (if your motherboard is already installed in a chassis).

3. Remove the bracket opposite the slot that you intend to use. Keep the screw for later use.

4. Align the card connector with the slot and press firmly until the card is completely seated on the slot.

5. Secure the card to the chassis with the screw you removed earlier.

6. Replace the system cover.

2.5.2 Conguring an expansion card

After installing the expansion card, configure the it by adjusting the software settings.

1. Turn on the system and change the necessary BIOS settings, if any. See Chapter 4 for information on BIOS setup.

2. Assign an IRQ to the card. Refer to the tables on the next page.

3. Install the software drivers for the expansion card.

When using PCI cards on shared slots, ensure that the drivers support “Share IRQ” or that the cards do not need IRQ assignments. Otherwise, conflicts will arise between the two PCI groups, making the system unstable and the card inoperable.

ASUS P7F-C Series 2-17

2.5.3 Interrupt assignments

Standard Interrupt assignments

IRQ Priority Standard function

0 1 System Timer

1 2 Keyboard Controller

2 - Programmable Interrupt

3* 11 Communications Port (COM2)

4* 12 Communications Port (COM1)

5* 13 --

6 14 Floppy Disk Controller

7* 15 --

8 3 System CMOS/Real Time Clock

9* 4 ACPI Mode when used

10* 5 IRQ Holder for PCI Steering

11* 6 IRQ Holder for PCI Steering

12* 7 PS/2 Compatible Mouse Port

13 8 Numeric Data Processor

14* 9 Primary IDE Channel

15* 10 Secondary IDE Channel

* These IRQs are usually available for ISA or PCI devices.

2-18 Chapter 2: Hardware information

2.5.4 PCI Express x16 slots (x8 link)

The onboard PCI Express x16 slots provide x8 link to CPU. These slots support VGA cards and various server class high performance add-on cards.

2.5.5 PCI slots

The PCI slot supports cards such as a LAN card, USB card, and other cards that comply with PCI 2.3 specifications.

PCI Express x16 slot

(x8 link)

PCI slot

(x8 link) PCI slot

PCI slot

ASUS P7F-C Series 2-19

2.5.6 Installing i Button

Follow the steps below to install an optional i Button on your motherboard.

1. Locate the I Button slot on the motherboard.

2. Snap the I Button in place.

2.5.7 Connect Thermal sensor cable

Follow the steps below to connect the thermal sensor cable to the connector on your motherboard.

1. Locate the TR1 connector on the motherboard.

2. Connect the thermal sensor cable to the connector.

3. Place the other end of the thermal sensor cable to the device you would like to monitor temperature.

2-20 Chapter 2: Hardware information

2.6 Jumpers

1. Clear RTC RAM (CLRTC1)

This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS. You can clear the CMOS memory of date, time, and system setup parameters by erasing the CMOS RTC RAM data. The onboard button cell battery powers the RAM data in CMOS, which include system setup information such as system passwords.

To erase the RTC RAM:

1. Turn OFF the computer and unplug the power cord.

2. Move the jumper cap from pins 1–2 (default) to pins 2–3. Keep the cap on pins 2–3 for about 5–10 seconds, then move the cap back to pins 1–2.

3. Plug the power cord and the computer turns on automatically.

4. Hold down the <Del> key during the boot process and enter BIOS setup to re-enter data.

Except when clearing the RTC RAM, never remove the cap on CLRTC jumper default position. Removing the cap will cause system boot failure!

If the steps above do not help, remove the onboard battery and move the jumper again to clear the CMOS RTC RAM data. After the CMOS clearance, reinstall the battery.

ASUS P7F-C Series 2-21

2. VGA controller setting (3-pin VGA_SW1)

This jumper allows you to enable or disable the onboard VGA controller. Set to pins 1–2 to activate the VGA feature.

3. CPU Fan and Chassis Fan control setting (3-pin CPUFAN_SEL1, CHAFAN_SEL1)

These jumpers allow you to switch for fan pin selection. The CPUFAN_SEL1 jumper is for the CPU fan control and the CHAFAN_SEL1 jumper is for the front fans and rear fans control. Set to pins 1–2 when using 4-pin fans or pins 2–3 when using 3-pin fans.

• If you use a 4-pin fan but set the jumper to pin 2-3, the fan you installed may not work.

• If you use a 3-pin fan but set the jumper for a 4-pin fan, the fan control will not work and the fan you installed will always run at full speed.

2-22 Chapter 2: Hardware information

4. LAN controller setting (3-pin LAN_SW1, LAN_SW2)

(LAN_SW3, LAN_SW4

These jumpers allow you to enable or disable the onboard Marvell

P7F-C/4L model only

)

88E8056

Gigabit LAN controllers. Set to pins 1–2 to activate the Gigabit LAN feature.–2 to activate the Gigabit LAN feature.2 to activate the Gigabit LAN feature.

5. RAID conguration utility selection (3-pin RAID_SEL1) (

P7F-C/4L model only

)

This jumper allows you to select the RAID configuration utility to use when

you create disk arrays. Place the jumper caps over pins 1–2 if you want to use the LSI Logic Embedded SATA RAID Setup Utility (default); otherwise, place the jumper caps to pins 2–3 to use the Intel® Matrix Storage Manager.

ASUS P7F-C Series 2-23

6. Onboard storage setting (3-pin SAS_SW1)

(P7F-C/SAS model only)

This jumper allows you to enable or disable the onboard LSI1068E SAS controller. Set the jumper to pins 1–2 to enable the SAS function (default).

7. Force BIOS recovery setting (3-pin RECOVERY1)

This jumper allows you to quickly update or recover the BIOS settings when it becomes corrupted.

To update the BIOS:

1. Set the jumper to pins 2–3.

2. Insert the USB flash that contains the original or latest BIOS and turn on the system to recover or update the BIOS.

3. Shut down the system.

4. Set the jumper back to pins 1–2.

5. Turn on the system.

2-24 Chapter 2: Hardware information

2.7 Connectors

2.7.1 Rear panel connectors

1. PS/2 mouse port (green). This port is for a PS/2 mouse.

2. PS/2 keyboard port (purple). This port is for a PS/2 keyboard.

3. USB 2.0 ports 1 and 2. These two 4-pin Universal Serial Bus (USB) ports

are available for connecting USB 2.0 devices.

4. Serial (COM1) port. This 9-pin communication port is for pointing devices or

other serial devices.

5. Video Graphics Adapter port. This port is for a VGA monitor or other VGA-

compatible devices.

6. LAN 1 (RJ-45) port. This port allows Gigabit connection to a Local Area

Network (LAN) through a network hub. Refer to the table below for the LAN port LED indications.

7. LAN 2 (RJ-45) port. This port allows Gigabit connection to a Local Area

Network (LAN) through a network hub. Refer to the table below for the LAN port LED indications.

8. LAN 3 (RJ-45) port.

connection to a Local Area Network (LAN) through a network hub. Refer to the table below for the LAN port LED indications.

9. LAN 4 (RJ-45) port.

connection to a Local Area Network (LAN) through a network hub. Refer to the table below for the LAN port LED indications.

(P7F-C/4L model only)

This port allows Gigabit

(P7F-C/4L model only)

This port allows Gigabit

LAN port LED indications

LED

LAN port

SPEED

LED

Activity/Link LED Speed LED

Status Description Status Description

OFF No link OFF 10 Mbps connection

GREEN Linked ORANGE 100 Mbps connection

BLINKING Data activity GREEN 1 Gbps connection

ASUS P7F-C Series 2-25

ACT/LINK

2.7.2 Internal connectors

1. Serial ATA connectors (7-pin SATA1, SATA2, SATA3, SATA4; RED)

(7-pin SATA5, SATA6; Black)

Supported by the Intel® 3420 chipset, these connectors are for the Serial ATA signal cables for Serial ATA hard disk drives that allows up to 3Gb/s of data transfer rate.

If you installed Serial ATA hard disk drives, you can create a RAID 0, RAID 1, RAID 10, or RAID 5 configuration.

• The actual data transfer rate depends on the speed of Serial ATA hard disks installed.

• The SATA connectors do not support SATA cables with latch.

2. Hard disk activity LED connector (4-pin HDLED1)

This LED connector is for the storage add-on card cable connected to the SATA or SAS add-on card. The read or write activities of any device connected to the SATA or SAS add-on card causes the front panel LED to light up.

2-26 Chapter 2: Hardware information

3. SAS connectors (7-pin SAS1, SAS2, SAS3, SAS4; Red) (7-pin SAS5, SAS6, SAS7, SAS8; Blue)

(P7F-C/SAS model only)

This motherboard comes with eight (8) Serial Attached SCSI (SAS) connectors, the next-generation storage technology that supports both Serial Attached SCSI (SAS) and Serial ATA (SATA). Each connector supports one device.

4. USB connector (10-1 pin USB34, USB56; A-Type USB7)

These connectors are for USB 2.0 ports. Connect the USB module cables to connectors USB34 and USB56, then install the modules to a slot opening at the back of the system chassis. These USB connectors comply with USB 2.0 specification that supports up to 480 Mbps connection speed.

ASUS P7F-C Series 2-27

5. Serial General Purpose Input/Output connector (6-1 pin SGPIO1)

This connector is used for the SGPIO peripherals for the LSI MegaRAID and Intel Matrix RAID SATA LED.

6. Serial General Purpose Input/Output connectors (8-1 pin SGPIO2/3)

(P7F-C/SAS model only)

These connector is used for the SAS chip SGPIO interface that controls the LED pattern generation, device information and general purpose data.

2-28 Chapter 2: Hardware information

7. Serial port connector (10-1 pin COM2)

This connector is for a serial (COM) port. Connect the serial port module cable to this connector, then install the module to a slot opening at the back of the system chassis.

8. CPU, front and rear fan connectors (4-pin CPU_FAN1, FRNT_FAN1, FRNT_FAN2, FRNT_FAN3, REAR_FAN1)

The fan connectors support cooling fans of 350 mA–740 mA (8.88 W max.) or a total of 1.75 A–3.7 A (44.4 W max.) at +12V. Connect the fan cables to the fan connectors on the motherboard, ensuring that the black wire of each cable matches the ground pin of the connector.

• DO NOT forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components.

• These are not jumpers! DO NOT place jumper caps on the fan connectors!

• All fans feature the ASUS Fan Speed Control technology.

ASUS P7F-C Series 2-29

9. ATX power connectors (24-pin EATXPWR1, 8-pin EATX12V1)

These connectors are for an ATX power supply plugs. The power supply plugs are designed to fit these connectors in only one orientation. Find the proper orientation and push down firmly until the connectors completely fit.

• DO NOT forget to connect the 24+8-pin power plugs; otherwise, the system will not boot up.

• Use of a PSU with a higher power output is recommended when configuring a system with more power-consuming devices. The system may become unstable or may not boot up if the power is inadequate.

• This motherboard supports ATX2.0 PSU or later version.

• Ensure that your power supply unit (PSU) can provide at least the minimum power required by your system.

2-30 Chapter 2: Hardware information

10. Thermal sensor cable connectors (3-pin TR1)

This connector is for temperature monitoring. Connect the thermal sensor cable to this connector and place the other end to the device, which you want to monitor temperature.

11. Parallel port connector (26-1 pin LPT1)

This connector is for a parallel port. Connect the parallel port module cable to this connector, then install the module to a slot opening at the back of the system chassis.

ASUS P7F-C Series 2-31

12. System panel connector (20-pin PANEL1)

This connector supports several chassis-mounted functions.

1. System power LED (3-pin PLED)

This 3-pin connector is for the system power LED. Connect the chassis power LED cable to this connector. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode.

2. Message LED (2-pin MLED)

This 2-pin connector is for the message LED cable that connects to the front message LED. The message LED is controlled by Hardware monitor to indicate an abnormal event occurance.

3. System warning speaker (4-pin SPEAKER)

This 4-pin connector is for the chassis-mounted system warning speaker. The speaker allows you to hear system beeps and warnings.

4. Hard disk drive activity LED (2-pin HDDLED)

This 2-pin connector is for the HDD Activity LED. Connect the HDD Activity LED cable to this connector. The IDE LED lights up or flashes when data is read from or written to the HDD.

5. ATX power button/soft-off button (2-pin PWRSW)

This connector is for the system power button. Pressing the power button turns the system on or puts the system in sleep or soft-off mode depending on the BIOS settings. Pressing the power switch for more than four seconds while the system is ON turns the system OFF.

6. Reset button (2-pin RESET)

This 2-pin connector is for the chassis-mounted reset button for system reboot without turning off the system power.

2-32 Chapter 2: Hardware information

13. Auxiliary panel connector (20-pin AUX_PANEL1)

This connector is for additional front panel features including front panel SMB, locator LED and switch, chassis intrusion, and LAN LEDs.

1. Front panel SMB (6-1 pin FPSMB)

These leads connect the front panel SMBus cable.

2. LAN activity LED (2-pin LAN1_LED, LAN2_LED)

These leads are for Gigabit LAN activity LEDs on the front panel.

3. Chassis intrusion (4-1 pin CHASSIS)

These leads are for the intrusion detection feature for chassis with intrusion sensor or microswitch. When you remove any chassis component, the sensor triggers and sends a high-level signal to these leads to record a chassis intrusion event. The default setting is short CASEOPEN and GND pin by jumper cap to disable the function.

4. Locator LED (2-pin LOCATORLED1 and 2-pin LOCATORLED2)

These leads are for the locator LED1 and LED2 on the front panel. Connect the Locator LED cables to these 2-pin connector. The LEDs will light up when the Locator button is pressed.

5. Locator Button/Swich (2-pin LOCATORBTN)

These leads are for the locator button on the front panel. This button queries the state of the system locator.

ASUS P7F-C Series 2-33

2-34 Chapter 2: Hardware information

This chapter describes the power up sequence, and ways of shutting down the system.

Powering up

Chapter summary

3.1 Starting up for the rst time ........................................................ 3-3

3.2 Turning off the computer ............................................................. 3-4

ASUS P7F-C Series

3.1 Starting up for the rst time

1. After making all the connections, replace the system case cover.

2. Be sure that all switches are off.

3. Connect the power cord to the power connector at the back of the system chassis.

4. Connect the power cord to a power outlet that is equipped with a surge protector.

5. Turn on the devices in the following order:

a. Monitor

b. External SCSI devices (starting with the last device on the chain)

c. System power

6. After applying power, the system power LED on the system front panel case lights up. For systems with SSI power supplies, the system LED lights up when you press the SSI power button. If your monitor complies with “green” standards or if it has a “power standby” feature, the monitor LED may light up or switch between orange and green after the system LED turns on.

The system then runs the power-on self-test or POST. While the tests are

running, the BIOS beeps or additional messages appear on the screen. If you do not see anything within 30 seconds from the time you turned on the power, the system may have failed a power-on test. Check the jumper settings and connections or call your retailer for assistance.

7. At power on, hold down the <Del> key to enter the BIOS Setup. Follow the instructions in Chapter 4.

ASUS P7F-C Series 3-3

3.2 Powering off the computer

3.2.1 Using the OS shut down function

If you are using Windows® 2003 Server:

1. Click the

2. Select box.

3. Select

4. Ensure that the

5. Select shutdown option from the list box.

6. If necessary, key in comments.

7. Click OK.

Start

button then click

Shut Down

Shutdown Event Tracker

from the

Planned

Shut Down

What do you want the computer to do?

check box is checked.

list

3.2.2 Using the dual function power switch

While the system is ON, pressing the power switch for less than four seconds puts the system to sleep mode or to soft-off mode, depending on the BIOS setting. Pressing the power switch for more than four seconds lets the system enter the soft-off mode regardless of the BIOS setting. Refer to section Chapter 4 for details.

4.5 Power Menu

3-4 Chapter 3: Powering up

This chapter tells how to change the system settings through the BIOS Setup menus. Detailed descriptions of the BIOS parameters are also provided.

BIOS setup

Chapter summary

4.1 Managing and updating your BIOS ............................................ 4-1
