Asus P5Q SE/R User Manual

Motherboard

P5Q SE/R

E3751

First Edition July 2008

No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identication or explanation and to the owners’ benet, without intent to infringe.

iii

Notices ........................................................................................................ vii

Safety information .................................................................................... viii

About this guide ......................................................................................... ix

P5Q SE/R specications summary ........................................................... xi

Chapter 1: Product introduction

1.1 Welcome! ...................................................................................... 1-1

1.2 Package contents .........................................................................

1-1

1.3 Special features ............................................................................

1-2

1.3.1 Product highlights ...........................................................

1-2

1.3.2 ASUS unique features ....................................................

1-3

1.3.3 ASUS Stylish features .....................................................

1-5

1.3.4 ASUS Intelligent Overclocking features ..........................

1-5

Chapter 2: Hardware information

2.1 Before you proceed ..................................................................... 2-1

2.2 Motherboard overview .................................................................

2-2

2.2.1 Placement direction ........................................................

2-2

2.2.2 Screw holes ....................................................................

2-2

2.2.3 Motherboard layout .........................................................

2-3

2.2.4 Layout contents ...............................................................

2-4

2.3 Central Processing Unit (CPU) ...................................................

2-6

2.3.1 Installing the CPU ...........................................................

2-7

2.3.2 Installing the CPU heatsink and fan ................................

2-9

2.3.3 Uninstalling the CPU heatsink and fan ..........................

2-11

2.4 System memory .........................................................................

2-12

2.4.1 Overview .......................................................................

2-12

2.4.2 Memory congurations ..................................................

2-14

2.4.3 Installing a DIMM ..........................................................

2-17

2.4.4 Removing a DIMM ........................................................

2-17

2.5 Expansion slots ..........................................................................

2-18

2.5.1 Installing an expansion card .........................................

2-18

2.5.2 Conguring an expansion card .....................................

2-18

2.5.3 Interrupt assignments ...................................................

2-19

2.5.4 PCI slots ........................................................................

2-20

2.5.5 PCI Express x1 slots .....................................................

2-20

2.5.6 PCI Express 2.0 x16 slot ...............................................

2-20

Contents

2.6 Jumpers ...................................................................................... 2-21

2.7 Connectors .................................................................................

2-23

2.7.1 Rear panel connectors ..................................................

2-23

2.7.2 Internal connectors .......................................................

2-24

Chapter 3: Powering up

3.1 Starting up for the rst time ........................................................ 3-1

3.2 Turning off the computer .............................................................

3-2

3.2.1 Using the OS shut down function ....................................

3-2

3.2.2 Using the dual function power switch ..............................

3-2

Chapter 4: BIOS setup

4.1 Managing and updating your BIOS ............................................ 4-1

4.1.1 ASUS Update utility ........................................................

4-1

4.1.2 Creating a bootable oppy disk .......................................

4-4

4.1.3 ASUS EZ Flash 2 utility ...................................................

4-5

4.1.4 AFUDOS utility ................................................................

4-6

4.1.5 ASUS CrashFree BIOS 3 utility ......................................

4-8

4.2 BIOS setup program ....................................................................

4-9

4.2.1 BIOS menu screen ........................................................

4-10

4.2.2 Menu bar .......................................................................

4-10

4.2.3 Navigation keys .............................................................

4-10

4.2.4 Menu items ....................................................................

4-11

4.2.5 Sub-menu items .............................................................

4-11

4.2.6 Conguration elds ........................................................

4-11

4.2.7 Pop-up window ..............................................................

4-11

4.2.8 Scroll bar ........................................................................

4-11

4.2.9 General help ..................................................................

4-11

4.3 Main menu ..................................................................................

4-12

4.3.1 System Time ................................................................

4-12

4.3.2 System Date ................................................................

4-12

4.3.3 Legacy Diskette A ........................................................

4-12

4.3.4

SATA 1~6 .........................................................................................4-13

4.3.5 Storage Conguration ...................................................

4-14

4.3.6 System Information .......................................................

4-15

Contents

4.4 Ai Tweaker menu ........................................................................ 4-16

4.4.1 Ai Overclock Tuner ........................................................

4-16

4.4.2 FSB Strap to North Bridge ............................................

4-17

4.4.3 DRAM Frequency .........................................................

4-17

4.4.4 DRAM Timing Control ...................................................

4-17

4.4.5 DRAM Static Read Control ...........................................

4-19

4.4.6 DRAM Read Training ....................................................

4-19

4.4.7 MEM. OC Charger ........................................................

4-19

4.4.8 Ai Clock Twister

............................................................. 4-19

4.4.9 Ai Transaction Booster ..................................................

4-20

4.4.10 CPU Voltage ................................................................

4-20

4.4.11 FSB Termination Voltage

............................................... 4-20

4.4.12 Memory Voltage ............................................................

4-20

4.4.13 North Bridge Voltage .....................................................

4-20

4.4.14 SB Voltage ...................................................................

4-21

4.4.15 Load-Line Calibration ....................................................

4-21

4.4.16 CPU GTL Reference .....................................................

4-21

4.4.17 CPU Spread Spectrum .................................................

4-21

4.4.18 PCIE Spread Spectrum .................................................

4-21

4.5 Advanced menu .........................................................................

4-22

4.5.1 Trusted Computing ........................................................

4-22

4.5.2 CPU Conguration ........................................................

4-23

4.5.3 Chipset ..........................................................................

4-25

4.5.4 OnBoard Devices Conguration ...................................

4-26

4.5.5 USB Conguration ........................................................

4-27

4.5.6 PCI PnP ........................................................................

4-28

4.6 Power menu ................................................................................

4-29

4.6.1 Suspend Mode ..............................................................

4-29

4.6.2 ACPI 2.0 Support .........................................................

4-29

4.6.3 ACPI APIC Support ......................................................

4-29

4.6.4 APM Conguration ........................................................

4-30

4.6.5 Hardware Monitor .........................................................

4-31

4.7 Boot menu ..................................................................................

4-33

4.7.1 Boot Device Priority ......................................................

4-33

4.7.2 Boot Settings Conguration ..........................................

4-34

Contents

4.7.3 Security ......................................................................... 4-35

4.8 Tools menu .................................................................................

4-37

4.8.1 ASUS EZ Flash 2 ..........................................................

4-37

4.8.2 Express Gate ...............................................................

4-38

4.8.3 AI NET 2

........................................................................ 4-38

4.8.4 ASUS O.C. Prole .........................................................

4-39

4.9 Exit menu ....................................................................................

4-40

Chapter 5: Software support

5.1 Installing an operating system ................................................... 5-1

5.2 Support DVD information ............................................................

5-1

5.2.1 Running the support DVD ...............................................

5-1

5.2.2 Drivers menu ...................................................................

5-2

5.2.3 Utilities menu ..................................................................

5-3

5.2.4 Make Disk menu .............................................................

5-5

5.2.5 Manual menu ..................................................................

5-6

5.2.6 ASUS Contact information ..............................................

5-6

5.2.7 Other information ............................................................

5-7

5.3 Software information ...................................................................

5-9

5.3.1 ASUS MyLogo2™ ...........................................................

5-9

5.3.2 Audio congurations ......................................................

5-11

5.3.3 ASUS PC Probe II .........................................................

5-15

5.3.4 ASUS AI Suite ...............................................................

5-21

5.3.5 ASUS AI Booster ...........................................................

5-23

5.3.6 ASUS AI Nap ................................................................

5-24

5.3.7 ASUS Fan Xpert ...........................................................

5-25

5.3.8 ASUS EPU-4 Engine ....................................................

5-26

5.3.9 ASUS Express Gate .....................................................

5-30

5.4 RAID congurations ..................................................................

5-39

5.4.1 RAID denitions ............................................................

5-39

5.4.2 Installing Serial ATA hard disks .....................................

5-40

5.4.3 Intel

RAID congurations ............................................. 5-40

5.5 Creating a RAID driver disk .......................................................

5-48

5.5.1 Creating a RAID driver disk without entering the OS ....

5-48

5.5.2 Creating a RAID/SATA driver disk in Windows

............ 5-48

vii

Appendix: CPU features

A.1 Intel® EM64T ..................................................................................A-1

Using the Intel® EM64T feature ......................................................A-1

A.2 Enhanced Intel SpeedStep

Technology (EIST) ........................A-1

A.2.1 System requirements ......................................................

A-1

A.2.2 Using the EIST ................................................................

A-2

A.3 Intel

Hyper-Threading Technology ...........................................A-3

Using the Hyper-Threading Technology ........................................ A-3

viii

Notices

Federal Communications Commission Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

•

This device may not cause harmful interference, and

•

This device must accept any interference received including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with manufacturer’s instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Canadian Department of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

This class B digital apparatus complies with Canadian ICES-003.

The use of shielded cables for connection of the monitor to the graphics card is

required to assure compliance with FCC regulations. Changes or modications

to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment.

Safety information

Electrical safety

•

To prevent electrical shock hazard, disconnect the power cable from the

electrical outlet before relocating the system.

•

When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.

•

Before connecting or removing signal cables from the motherboard, ensure that all power cables are unplugged.

•

Seek professional assistance before using an adpater or extension cord. These devices could interrupt the grounding circuit.

•

Make sure that your power supply is set to the correct voltage in your area. If you are not sure about the voltage of the electrical outlet you are using, contact your local power company.

•

If the power supply is broken, do not try to x it by yourself. Contact a qualied

service technician or your retailer.

Operation safety

•

Before installing the motherboard and adding devices on it, carefully read all the manuals that came with the package.

•

Before using the product, make sure all cables are correctly connected and the power cables are not damaged. If you detect any damage, contact your dealer immediately.

•

To avoid short circuits, keep paper clips, screws, and staples away from connectors, slots, sockets and circuitry.

•

Avoid dust, humidity, and temperature extremes. Do not place the product in any area where it may become wet.

•

Place the product on a stable surface.

•

If you encounter technical problems with the product, contact a qualied

service technician or your retailer.

This symbol of the crossed out wheeled bin indicates that the product (electrical and electronic equipment, Mercury-containing button cell battery) should not be placed in municipal waste. Check local regulations for disposal of electronic products.

About this guide

This user guide contains the information you need when installing and conguring

the motherboard.

How this guide is organized

This guide contains the following parts:

• Chapter 1: Product introduction

This chapter describes the features of the motherboard and the new technology it supports.

• Chapter 2: Hardware information

This chapter lists the hardware setup procedures that you have to perform when installing system components. It includes description of the switches, jumpers, and connectors on the motherboard.

• Chapter 3: Powering up

This chapter describes the power up sequence and ways of shutting down the system.

• Chapter 4: BIOS setup

This chapter tells how to change system settings through the BIOS Setup menus. Detailed descriptions of the BIOS parameters are also provided.

• Chapter 5: Software support

This chapter describes the contents of the support DVD that comes with the motherboard package.

• Appendix: CPU features

The Appendix describes the CPU features and technologies that the motherboard supports.

Where to nd more information

Refer to the following sources for additional information and for product and software updates.

1. ASUS websites

The ASUS website provides updated information on ASUS hardware and software products. Refer to the ASUS contact information.

2. Optional documentation

Your product package may include optional documentation, such as warranty

yers, that may have been added by your dealer. These documents are not

part of the standard package.

Conventions used in this guide

To make sure that you perform certain tasks properly, take note of the following symbols used throughout this manual.

DANGER/WARNING: Information to prevent injury to yourself

when trying to complete a task.

CAUTION: Information to prevent damage to the components

when trying to complete a task.

NOTE: Tips and additional information to help you complete a

task.

IMPORTANT: Instructions that you MUST follow to complete a

task.

Typography

Bo l d t ex t Indicates a menu or an item to select.

Italics

Used to emphasize a word or a phrase.

<Key> Keys enclosed in the less-than and greater-than sign means that you must press the enclosed key. Example: <Enter> means that you must press the Enter or Return key.

<Key1>+<Key2>+<Key3> If you must press two or more keys simultaneously, the key names are linked with a plus sign (+). Example: <Ctrl>+<Alt>+<D>

Command Means that you must type the command exactly as shown, then supply the required item or value enclosed in brackets. Example: At the DOS prompt, type the command line: afudos /i[lename]

afudos /iP5QSER.ROM

xii

P5Q SE/R specications summary

(continued on the next page)

CPU LGA775 socket for Intel® Core™2 Extreme /

Core™2 Quad / Core™2 Duo / Pentium

dual-core /

Celeron

dual-core / Celeron® processors

Compatible with Intel® 05B/05A/06 processors

Chipset Intel® P45 / ICH10R with Intel® Fast Memory Access

Technology

System Bus 1600 / 1333 / 1066 / 800 MHz

Memory Dual-channel memory architecture

- 4 x 240-pin DIMM sockets support unbuffered non-ECC DDR2 1200 / 1066 / 800 / 667 MHz memory modules

- Supports up to 16GB system memory

• Refer to www.asus.com for the memory QVL (Qualied Vendors List.)

• When installing total memory of 4GB capacity or more, Windows® 32-bit operation system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended.

Expansion Slots 1 x PCI Express 2.0 x16 slot

2 x PCI Express x1 slots 3 x PCI slots

Storage Southbridge

- 6 x Serial ATA 3.0Gb/s ports Marvell® 88SE6102

- 1 x UltraDMA 133 / 100 / 66 for up to 2 PATA devices

ASUS Unique Features ASUS Power Saving Solution:

- ASUS EPU-4 Engine

- ASUS AI Nap

ASUS Exclusive Feature:

- ASUS Express Gate

ASUS Quiet Thermal Solution:

- ASUS Fan Xpert

- ASUS Fanless Design: Heatsink Solution

ASUS EZ DIY:

- ASUS Q-Connector

- ASUS O.C. Prole

- ASUS CrashFree BIOS 3

- ASUS EZ Flash 2

Other Features ASUS MyLogo2

xiii

P5Q SE/R specications summary

ASUS Exclusive Overclocking Features

Intelligent overclocking tools:

- ASUS AI Booster utility

Precision Tweaker:

- vCore: Adjustable CPU voltage at 0.00625V increment

- vDIMM: 5-step DRAM voltage control

SFS (Stepless Frequency Selection):

- FSB tuning from 200MHz to 800 MHz at 1MHz increment

- PCI Express frequency tuning from 100MHz to 180MHz at 1 MHz increment

Overclocking protection:

- ASUS C.P.R. (CPU Parameter Recall)

LAN Atheros L1E Gigabit LAN controller featuring AI NET 2

Audio Realtek® ALC 1200 8-channel High-Denition Audio

CODEC

- Supports Jack-Detection, Multi-streaming, and Front Panel Jack-Retasking

- Coaxial S/PDIF out port at back I/O

- ASUS Noise Filtering

USB 12 x USB 2.0 ports (6 ports at mid-board, 6 ports at back

panel)

Back Panel I/O Ports 1 x PS/2 keyboard port

1 x PS/2 mouse port 1 x Coaxial S/PDIF Out port 1 x RJ-45 port 6 x USB 2.0/1.1 ports 8-channel audio I/O ports

Internal I/O Connectors 3 x USB connectors support 6 additional USB ports

1 x Floppy disk drive connector 1 x IDE connector 6 x Serial ATA connectors 1 x CPU fan connector 1 x Chassis fan connector 1 x Power fan connector 1 x COM connector 1 x TPM connector 1 x S/PDIF Out header 1 x Chassis intrusion connector 1 x Front panel audio connector 1 x CD audio in connector 1 x 24-pin ATX power connector 1 x 4-pin ATX 12V power connector System panel connector (Q-Connector)

(continued on the next page)

xiv

P5Q SE/R specications summary

BIOS Features 8Mb Flash ROM, AMI BIOS, PnP, DMI 2.0, WfM 2.0,

SM BIOS 2.3, ACPI 2.0a, ASUS EZ Flash 2, ASUS CrashFree BIOS 3

Manageability WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE

Accessories 1 x UltraDMA 133 / 100 / 66 cable

1 x Floppy disk drive cable 2 x Serial ATA cables 1 x 2-port Serial ATA power cable 1 x I/O shield User manual 2 in 1 Q-connector

Support DVD Drivers

ASUS PC Probe II ASUS Update Express Gate ASUS AI Suite Anti-Virus software (OEM version)

Form factor ATX form factor: 12 in x 7.6 in (30.5 cm x 19.3 cm)

*Specications are subject to change without notice.

Product

introduction

This chapter describes the motherboard features and the new technologies it supports.

ASUS P5Q SE/R

Chapter summary

1.1 Welcome! ...................................................................................... 1-1

1.2 Package contents .........................................................................

1-1

1.3 Special features ............................................................................

1-2

ASUS P5Q SE/R 1-1

1.1 Welcome!

Thank you for buying an ASUS® P5Q SE/R motherboard!

The motherboard delivers a host of new features and latest technologies, making it another standout in the long line of ASUS quality motherboards!

Before you start installing the motherboard, and hardware devices on it, check the items in your package with the list below.

If any of the above items is damaged or missing, contact your retailer.

1.2 Package contents

Check your motherboard package for the following items.

Motherboard ASUS P5Q SE/R motherboard

Cables 2 x Serial ATA signal cables

1 x 2-port Serial ATA power cable 1 x Ultra DMA 133/100/66 cable 1 x Floppy disk drive cable

Accessories 1 x I/O shield

2 in 1 Q-Connector

Application DVD ASUS motherboard support DVD

Documentation User guide

1-2 Chapter 1: Product Introduction

1.3 Special features

1.3.1 Product highlights

Green ASUS

This motherboard and its packaging comply with the European Union’s Restriction

on the use of Hazardous Substances (RoHS). This is in line with the ASUS vision

of creating environment-friendly and recyclable products/packaging to safeguard

consumers’ health while minimizing the impact on the environment.

Intel® Core™2 Extreme / Core™2 Quad / Core™2 Duo CPU support

This motherboard supports the latest Intel® Core™2 processor in the LGA775 package and Intel’s 45nm multi-core processors. With the new Intel

Core™

microarchitecture technology and 1333/1066/800 MHz FSB, the Intel

Core™2 is

one of the most powerful and energy efcient CPUs in the world. See page 2-6 for

details.

Intel® P45 Chipset

The Intel® P45 Express Chipset is designed to support dual-channel DDR2

1066/800/667MHz architecture, 1333/1066/800 FSB (Front Side Bus), PCIe

2.0, and multi-core CPUs. It supports Intel Fast Memory Access technology that

signicantly optimizes the use of available memory bandwidth and reduces the

latency of the memory accesses.

PCI Express 2.0 support

The motherboard supports the latest PCI Express 2.0 devices for double speed and bandwidth which enhances system performance.See page 2-20 for details.

FSB 1600 support

ASUS’s exclusive overclocking design now unleashes the ultimate potential of the Intel® Core™2 processor. With the new Intel 45nm micro-architecture technology

and FSB 1600 / 1333 / 1066 / 800 MHz, this motherboard allows you to enjoy the latest technology supported by one of the most powerful and energy efcient CPUs

in the world.

Serial ATA 3Gb/s technology

This motherboard supports the hard drives based on the Serial ATA (SATA)

3Gb/s storage specication, delivering enhanced scalability and doubling the bus

bandwidth for high-speed data retrieval and saves.

ASUS P5Q SE/R 1-3

1.3.2 ASUS unique features

ASUS Exclusive features

Express Gate

Taking only 5 seconds to go online from bootup, Express Gate is the one-stop

gateway to instant fun! It’s a unique motherboard built-in OS. You can utilize the

most popular Instant Messengers (IM) like MSN, Skype, Google talk, QQ, and Yahoo! Messenger to keep in touch with friends, or quickly check on the weather and e-mails just before leaving your house. What’s more, the user-friendly picture manager lets you view your pictures without entering Windows at anytime! See pages 5-30 to 5-38 for details.

• The actual boot time depends on the hardware conguration and the prodict

model.

• ASUS Express Gate supports le uploading from USB drives and

downloading to USB drives only.

ASUS Power Saving Solution

ASUS Power Saving solution intelligently and automatically provides balanced computing power and energy consumption.

ASUS EPU-4 Engine

The new ASUS EPU - the world’s rst power saving engine, has been

upgraded to a new four-engine version, which provides total system power savings by detecting current PC loadings and intelligently moderating power in real-time. The EPU automatically provides the most appropriate power usage for the CPU, VGA card, hard drives, CPU fan, and chassis fan

- helping save power and money.

AI Nap

With AI Nap, the system can continue running at minimum power and noise when you are temporarily away. To wake the system and return to the OS environment, simply click the mouse or press a key. See page 5-24 for details.

1-4 Chapter 1: Product Introduction

ASUS Quiet Thermal Solution

ASUS Quiet Thermal solution makes system more stable and enhances the overclocking capability.

Fan Xpert

ASUS Fan Xpert intelligently allows users to adjust both the CPU and chassis fan speed according to different ambient temperature, which is caused by different climate conditions in different geographic regions and system

loading. Built-in variety of useful proles offer exible controls of fan speed to

achieve a quiet and cool environment.

ASUS EZ DIY

ASUS EZ DIY feature collection provides you easy ways to install computer components, update the BIOS or back up your favorite settings.

ASUS Q-Connector

ASUS Q-Connector allows you to easily connect or disconnect the chassis front panel cables to the motherboard. This unique module eliminates the trouble of connecting the system panel cables one at a time and avoiding wrong cable connections. See page 2-33 for details.

ASUS O.C. Prole

The motherboard features the ASUS O.C. Prole that allows users to

conveniently store or load multiple BIOS settings. The BIOS settings can be

stored in the CMOS or a separate le, giving users freedom to share and

distribute their favorite settings. See page 4-39 for details.

ASUS CrashFree BIOS 3

The ASUS CrashFree BIOS 3 allows users to restore corrupted BIOS data

from a USB ash disk containing the BIOS le. See page 4-8 for details.

ASUS EZ Flash 2

EZ Flash 2 is a user-friendly BIOS update utility. Simply press the predened

hotkey to launch the utility and update the BIOS without entering the OS. Update your BIOS easily without preparing a bootable diskette or using an

OS-based ash utility. See pages 4-5 and 4-37 for details.

ASUS P5Q SE/R 1-5

1.3.3 ASUS Stylish features

ASUS MyLogo2™

This feature allows you to convert your favorite photo into a 256-color boot logo for a more colorful and vivid image on your screen. See pages 5-9 and 5-10 for details.

1.3.4 ASUS Intelligent Overclocking features

AI Booster

The ASUS AI Booster allows you to overclock the CPU speed in Windows environment without the hassle of booting the BIOS. See page 5-23 for details.

Precision Tweaker

This feature allows you to ne tune the CPU/memory voltage and gradually increase the memory Front Side Bus (FSB) and PCI Express frequency at 1MHz

increment to achieve maximum system performance. See pages 4-16 to 4-21 for details.

C.P.R. (CPU Parameter Recall)

The C.P.R. feature of the motherboard BIOS allows automatic re-setting to the BIOS default settings in case the system hangs due to overclocking. When the system hangs due to overclocking, C.P.R. eliminates the need to open the system chassis and clear the RTC data. Simply shut down and reboot the system, and the BIOS automatically restores the CPU default setting for each parameter.

1-6 Chapter 1: Product Introduction

Hardware

information

This chapter lists the hardware setup procedures that you have to perform when installing system components. It includes description of the jumpers and connectors on the motherboard.

ASUS P5Q SE/R

Chapter summary

2.1 Before you proceed ..................................................................... 2-1

2.2 Motherboard overview .................................................................

2-2

2.3 Central Processing Unit (CPU) ...................................................

2-6

2.4 System memory .........................................................................

2-12

2.5 Expansion slots ..........................................................................

2-18

2.6 Jumpers ......................................................................................

2-21

2.7 Connectors .................................................................................

2-23

ASUS P5Q SE/R 2-1

2.1 Before you proceed

Take note of the following precautions before you install motherboard components or change any motherboard settings.

• Unplug the power cord from the wall socket before touching any component.

• Use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, before handling components to avoid damaging them due to static electricity.

• Hold components by the edges to avoid touching the ICs on them.

• Whenever you uninstall any component, place it on a grounded antistatic pad or in the bag that came with the component.

• Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, and/or components.

Onboard LED

The motherboard comes with a standby power LED that lights up to indicate that the system is ON, in sleep mode, or in soft-off mode. This is a reminder that you should shut down the system and unplug the power cable before removing or plugging in any motherboard component. The illustration below shows the location of the onboard LED.

P5Q SE/R

P5Q SE/R Onboard LED

SB_PWR

Standby

Power

OFF

Powered

Off

2-2 Chapter 2: Hardware information

P5Q SE/R

2.2 Motherboard overview

Before you install the motherboard, study the conguration of your chassis to ensure that the motherboard ts into it.

Ensure to unplug the power cord before installing or removing the motherboard. Failure to do so can cause you physical injury and damage motherboard components.

Do not overtighten the screws! Doing so can damage the motherboard.

2.2.1 Placement direction

When installing the motherboard, ensure that you place it into the chassis in the correct orientation. The edge with external ports goes to the rear part of the chassis as indicated in the image below.

2.2.2 Screw holes

Place six (6) screws into the holes indicated by circles to secure the motherboard to the chassis.

Place this side towards the rear of the chassis

ASUS P5Q SE/R 2-3

2.2.3 Motherboard layout

Refer to 2.7 Connectors for more information about rear panel connectors and internal connectors.

30.5cm (12in)

P5Q SE/R

AUDIO

LAN1_USB12

USB34

USB56

PS/2KBMS T:Mouse B:Keyboard

LGA775

DDR2 DIMMB1 (64 bit,240-pin module)

DDR2 DIMMB2 (64 bit,240-pin module)

DDR2 DIMMA1 (64 bit,240-pin module)

DDR2 DIMMA2 (64 bit,240-pin module)

19.3cm (7.6in)

CPU_FAN

Intel P45

Intel

ICH10R

CHASSIS

CLRTC

FLOPPY

PCIEX16

PCI1

PCI2

PCI3

PCIEX1_1

PCIEX1_2

CR2032 3V Lithium Cell

CMOS Power

8Mb BIOS

USBPW7-10

USBPW1112

Super I/O

SPDIF_OUT

AAFP

ALC 1200

COM1

PS2_USBPW56

ATX12V

EATXPWR

PANEL

SB_PWR

ICS

9LPRS916JGLF

CHA_FAN

PWR_FAN

SPDIF_O1

USB1112 USB78 USB910

Marvell

88SE6102

EPU

TPM

2-4 Chapter 2: Hardware information

2.2.4 Layout contents

Slots Page

1. DDR2 DIMM slots 2-12

2. PCI slots

2-20

3 PCI Express x1 slots

2-20

4. PCI Express 2.0 x16 slot

2-20

Jumpers Page

1. Clear RTC RAM (3-pin CLRTC) 2-21

2. Keyboard power (3-pin PS2_USBPW56)

2-22

3. USB device wake-up (3-pin USBPW7-10, USBPW1112) 2-22

Rear panel connectors Page

1. PS/2 mouse port (green) 2-23

2. LAN (RJ-45) port

2-23

3. Rear Speaker Out port (black)

2-23

4. Center/Subwoofer port (orange)

2-23

5. Line In port (light blue)

2-23

6. Line Out port (lime)

2-23

7. Microphone port (pink)

2-23

8. Side Speaker Out port (gray)

2-23

9. USB 2.0 ports 1 and 2

2-24

10. USB 2.0 ports 3 and 4

2-24

11. Coaxial S/PDIF Out port

2-24

12. USB 2.0 ports 5 and 6

2-24

13. PS/2 keyboard port (purple)

2-24

ASUS P5Q SE/R 2-5

Internal connectors Page

1. Floppy disk drive connector (34-1 pin FLOPPY) 2-24

2. IDE connector (40-1 pin PRI_EIDE

) 2-25

3. ICH10R Serial ATA connectors (7-pin SATA1-6

) 2-26

4. Digital audio connector (4-1 pin SPDIF_OUT) 2-27

5. TPM connector (20-1 pin TPM)

2-27

6. USB connectors (10-1 pin USB78, USB910, USB1112

) 2-28

Optical drive audio connector (4-pin CD) 2-28

8. CPU, chassis, and power fan connectors (4-pin CPU FAN, 3-pin CHA_FAN, 3-pin PWR_FAN

)

2-29

9. Serial port connector (10-1 pin COM1)

2-29

10. Chassis intrusion connector (4-1 pin CHASSIS)

2-30

11. Front panel audio connector (10-1 pin AAFP)

2-30

12. ATX power connectors (24-pin EATXPWR, 4-pin EATX12V)

2-31

13. System panel connector (20-8-pin PANEL

)

• System power LED (2-pin PLED)

• Hard disk drive activity LED (2-pin IDE_LED)

• System warning speaker (4-pin SPEAKER)

• ATX power button/soft-off button (2-pin PWRSW)

• Reset button (2-pin RESET)

2-32

ASUS Q-connector (system panel) 2-33

2-6 Chapter 2: Hardware information

2.3 Central Processing Unit (CPU)

The motherboard comes with a surface mount LGA775 socket designed for the Intel® Core™2 Extreme / Core™2 Quad / Core™2 Duo / Pentium

dual-core /

Celeron® dual-core / Celeron® processors.

•

Upon purchase of the motherboard, ensure that the PnP cap is on the socket and the socket contacts are not bent. Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components. ASUS will shoulder the cost of repair only if the damage is shipment/transit-related.

•

Keep the cap after installing the motherboard. ASUS will process Return

Merchandise Authorization (RMA) requests only if the motherboard comes

with the cap on the LGA775 socket.

• The product warranty does not cover damage to the socket contacts resulting from incorrect CPU installation/removal, or misplacement/loss/ incorrect removal of the PnP cap.

• Ensure that all power cables are unplugged before installing the CPU.

• Connect the chassis fan cable to the CHA_FAN connector to ensure system stability.

• Due to chipset limitation, we recommend you use FSB 800 MHz CPU or

above.

+ 132 hidden pages
