ASUS ET2400I, ET2400IN, ET2400INT, ET2400IT User Manual

English

User Manual

ET24 Series

English

E6515

Second Edition V2

March 2011

Copyright © 2011 ASUSTeK COMPUTER INC. All Rights Reserved.

No part of this manual, including the products and software described in it, may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except documentation kept by the purchaser for backup purposes, without the express written permission of ASUSTeK COMPUTER, INC. (“ASUS”).

Products and corporate names mentioned in this manual may or may not be registered trademarks or copyrights of their respective companies, and are used for identification purposes only. All trademarks are the property of their respective owners.

Every effort has been made to ensure that the contents of this manual are correct and up to date. However, the manufacturer makes no guarantee regarding the accuracy of its contents, and reserves the right to make changes without prior notice.

Contents
Contents.....................................................................................................	3
Notices.....................................................................................................................................................	5
Federal Communications Commission Statement..........................................................	5
Canadian Department of Communications Statement................................................	6
IC Radiation Exposure Statement for Canada...................................................................	6
Declaration of Conformity (R&TTE directive 1999/5/EC)...............................................	6
CE Mark Warning..........................................................................................................................	7
Wireless Operation Channel for Different Domains........................................................	7
France Restricted Wireless Frequency Bands....................................................................	8
REACH..............................................................................................................................................	9
Global Environmental Regulation Compliance and Declaration ............................	10
ASUS Recycling/Takeback Services.....................................................................................	10
ENERGY STAR complied product.........................................................................................	11
Notes for this manual........................................................................................................................	11
Safety information.............................................................................................................................	12
Setting up your system...........................................................................................................	12
Care during use..........................................................................................................................	12
Sound Pressure Warning.........................................................................................................	13
TV Tuner (on selected models).............................................................................................	13
Adapter.........................................................................................................................................	13
DC Fan Warning..........................................................................................................................	13
Welcome...................................................................................................	14
Package contents...............................................................................................................................	14
Getting to know your All-in-one PC.......................................................	15
Front view.............................................................................................................................................	15
Rear view...............................................................................................................................................	17
Side views.............................................................................................................................................	19
Using the touch screen....................................................................................................................	21
Showing the touch pointer....................................................................................................	21
Cleaning the touch screen.....................................................................................................	22
Using the keyboard...........................................................................................................................	23

English

English

Function keys..............................................................................................................................	24
Positioning your All-in-one PC...............................................................	25
Placing on the desktop....................................................................................................................	25
Mounting to the wall........................................................................................................................	26
Setting up your All-in-one PC.................................................................	28
Connecting the wired keyboard and mouse...........................................................................	28
Connecting the wireless keyboard and mouse.......................................................................	28
Powering on the system..................................................................................................................	29
Powering off.........................................................................................................................................	29
Configuring a wireless connection..............................................................................................	30
Configuring a wired connection...................................................................................................	31
Using a static IP..........................................................................................................................	31
Using a dynamic IP (PPPoE)...................................................................................................	33
Bluetooth Wireless Connection.....................................................................................................	36
Configuring the audio output.......................................................................................................	38
Speaker configurations...........................................................................................................	38
Connecting to speakers..........................................................................................................	38
Configuring audio output settings..............................................................................................	39
Overclocking your All-in-one PC...................................................................................................	40
Using 3D Vision Glasses..........................................................................	41
Charging your 3D Vision glasses...................................................................................................	41
Configuring 3D Vision setup..........................................................................................................	41
Enjoying 3D Vision.............................................................................................................................	42
Adjusting the Refresh rate..............................................................................................................	43
Replacing or upgrading memory...........................................................	44
Recovering your system..........................................................................	45
Using the hidden partition.............................................................................................................	45
Recovering the OS to the Factory Default Partition (F9 Recovery)..........................	45
Backing up the Factory Default Environment Data
to a USB Drive (F9 Backup).....................................................................................................	45
Using the USB storage device (USB Restore)............................................................................	46
Technical support for nVIDIA 3D Vision Glasses.....................................................................	47

Notices

Federal Communications Commission Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

•This device may not cause harmful interference, and

•This device must accept any interference received including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance

with manufacturer’s instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment to an outlet on a circuit different from that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

CAUTION: Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the equipment.

RF exposure warning

This equipment must be installed and operated in accordance with provided instructions and the antenna(s) used for this transmitter must be installed to provide a separation distance

of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provide with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.

English

All-in-one PC ET24 Series

English

Canadian Department of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

This class B digital apparatus complies with Canadian ICES-003.

IC Radiation Exposure Statement for Canada

This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment.To maintain compliance with IC RF exposure compliance requirements, please avoid direct contact to the transmitting antenna during transmitting. End users must follow the specific operating instructions for satisfying RF exposure compliance.

Operation is subject to the following two conditions:

•This device may not cause interference and

•This device must accept any interference, including interference that may cause undesired operation of the device.

Declaration of Conformity (R&TTE directive 1999/5/EC)

The following items were completed and are considered relevant and sufficient:

•Essential requirements as in [Article 3]

•Protection requirements for health and safety as in [Article 3.1a]

•Testing for electric safety according to [EN 60950]

•Protection requirements for electromagnetic compatibility in [Article 3.1b]

•Testing for electromagnetic compatibility in [EN 301 489-1] & [EN 301 489-17]

•Effective use of the radio spectrum as in [Article 3.2]

•Radio test suites according to [EN 300 328-2]

All-in-one PC ET24 Series

CE Mark Warning

This is a Class B product, in a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.

CE marking for devices without wireless LAN/Bluetooth

The shipped version of this device complies with the requirements of the EEC directives 2004/108/EC“Electromagnetic compatibility”and 2006/95/EC“Low voltage directive”.

CE marking for devices with wireless LAN/ Bluetooth

This equipment complies with the requirements of Directive 1999/5/EC of the European Parliament and Commission from 9 March, 1999 governing Radio and Telecommunications Equipment and mutual recognition of conformity.

Wireless Operation Channel for Different Domains

N. America	2.412-2.462 GHz	Ch01 through CH11
Japan	2.412-2.484 GHz	Ch01 through Ch14
Europe ETSI	2.412-2.472 GHz	Ch01 through Ch13

English

All-in-one PC ET24 Series

English

France Restricted Wireless Frequency Bands

Some areas of France have a restricted frequency band. The worst case maximum authorized power indoors are:

•10mW for the entire 2.4 GHz band (2400 MHz–2483.5 MHz)

•100mW for frequencies between 2446.5 MHz and 2483.5 MHz

Channels 10 through 13 inclusive operate in the band 2446.6 MHz to 2483.5 MHz.

There are few possibilities for outdoor use: On private property or on the private property of public persons, use is subject to a preliminary authorization procedure by the Ministry of Defense, with maximum authorized power of 100mW in the 2446.5–2483.5 MHz band. Use outdoors on public property is not permitted.

In the departments listed below, for the entire 2.4 GHz band:

•Maximum authorized power indoors is 100mW

•Maximum authorized power outdoors is 10mW

Departments in which the use of the 2400–2483.5 MHz band is permitted with an EIRP of less than 100mW indoors and less than 10mW outdoors:

01	Ain	02	Aisne	03	Allier	05	Hautes Alpes
08	Ardennes	09	Ariège	11	Aude	12	Aveyron	16	Charente
24	Dordogne	25	Doubs	26	Drôme	32	Gers	36	Indre
37	Indre et Loire	41	Loir et Cher 45 Loiret			50	Manche	55	Meuse
58	Nièvre	59	Nord	60	Oise	61	Orne	63	Puy du Dôme
64	Pyrénées Atlantique		66	Pyrénées Orientales		67	Bas Rhin	68	Haut Rhin
70	Haute Saône		71	Saône et Loire		75	Paris	82	Tarn et Garonne
84	Vaucluse		88	Vosges		89	Yonne
90	Territoire de Belfort		94	Val de Marne

This requirement is likely to change over time, allowing you to use your wireless LAN card in more areas within France. Please check with ART for the latest information (www.arcep.fr)

Your WLAN Card transmits less than 100mW, but more than 10mW.

All-in-one PC ET24 Series

NO DISASSEMBLY

The warranty does not apply to the products that have been disassembled by users

Lithium-Ion Battery Warning

CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions.

No Exposure to Liquids

DO NOT expose to or use near liquids, rain, or moisture.This product is not waterproof or oil-proof.

This symbol of the crossed out wheeled bin indicates that the product (electrical, electronic equipment, and mercury-containing button cell battery) should not be placed in municipal waste. Check local regulations for disposal of electronic products.

DO NOT throw the battery in municipal waste.The symbol of the crossed out wheeled bin indicates that the battery should not be placed in municipal waste.

REACH

Complying with the REACH (Registration, Evaluation, Authorization, and Restriction of Chemicals) regulatory framework, we publish the chemical substances in our products at ASUS REACH website at http://csr.asus.com/english/REACH.htm.

English

All-in-one PC ET24 Series

English

Global Environmental Regulation Compliance and Declaration

ASUS follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASUS product is in line with global environmental regulations. In addition, ASUS disclose the relevant information based on regulation requirements.

Please refer to http://csr.asus.com/english/Compliance.htm for information disclosure based on regulation requirements ASUS is complied with:

Japan JIS-C-0950 Material Declarations EU REACH SVHC

Korea RoHS

Swiss Energy Laws

ASUS Recycling/Takeback Services

ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components as well as the packaging materials. Please go to http://csr.asus.com/english/Takeback.htm for detailed recycling information in different regions.

10 All-in-one PC ET24 Series

ENERGY STAR complied product

ENERGY STAR is a joint program of the U.S. Environmental Protection Agency and the U.S. Department of Energy helping us all save money and protect the environment through energy efficient products and practices.

All ASUS products with the ENERGY STAR logo comply with the ENERGY STAR standard, and the power management feature is enabled by default.The computer is automatically set to sleep after 15 minutes of user inactivity.To wake your computer, click the mouse or press any key on the keyboard.

Please visit http://www.energy.gov/powermanagement for detail information on power management and its benefits to the environment. In addition, please visit http://www. energystar.gov for detail information on the ENERGY STAR joint program.

Notes for this manual

To ensure that you perform certain tasks properly, take note of the following symbols used throughout this manual.

WARNING: Vital information that you MUST follow to prevent injury to yourself.

IMPORTANT: Instructions that you MUST follow to complete a task.

TIP: Tips and useful information that help you complete a task.

NOTE: Additional information for special situations.

All illustrations and screenshots in this manual are for reference only. Actual product specifications and software screen images may vary with territories.Visit the ASUS website at www.asus.com for the latest information.

English

All-in-one PC ET24 Series 11

English

Safety information

Your All-in-one PC ET24 Series is designed and tested to meet the latest standards of safety for information technology equipment. However, to ensure your safety, it is important that you read the following safety instructions.

Setting up your system

•Read and follow all instructions in the documentation before you operate your system.

•Do not use this product near water or a heated source such as a radiator.

•Set up the system on a stable surface.

•Openings on the chassis are for ventilation. Do not block or cover these openings. Ensure that you leave plenty of space around the system for ventilation. Never insert objects of any kind into the ventilation openings.

•Use this product in environments with ambient temperatures between 0˚C and 40˚C.

•If you use an extension cord, ensure that the total ampere rating of the devices plugged into the extension cord does not exceed its ampere rating.

Care during use

•Do not walk on the power cord or allow anything to rest on it.

•Do not spill water or any other liquids on your system.

•When the system is turned off, a small amount of electrical current still flows. Always unplug all power, modem, and network cables from the power outlets before cleaning the system.

•The touch screen requires periodic cleaning to achieve the best touch sensitivity. Keep the screen clean from foreign objects or excessive dust accumulation.To clean the screen:

•Turn off the system and disconnect the power cord from the wall.

•Spray a small amount of a household glass cleaner onto the supplied cleaning cloth and gently wipe the screen surface.

•Do not spray the cleaner directly on the screen.

•Do not use an abrasive cleaner or a coarse cloth when cleaning the screen.

•If you encounter the following technical problems with the product, unplug the power cord and contact a qualified service technician or your retailer.

•The power cord or plug is damaged.

•Liquid has been spilled into the system.

•The system does not function properly even if you follow the operating instructions.

•The system was dropped or the cabinet is damaged.

•The system performance changes.

12 All-in-one PC ET24 Series

Sound Pressure Warning

Excessive sound pressure from earphones or headphones can cause hearing damage or loss. Adjustment of the volume control as well as the equalizer to settings other than the center position may increase the earphones or headphones output voltage and the sound pressure level.

TV Tuner (on selected models)

Note to CATV System Installer—This reminder is provided to call the CATV systems installer’s attention to Section 820-93 of the National Electric Code, which provides guidelines for proper grounding and, in particular, specify that the Coaxial cable shield be connected to the grounding system of the building as close to the point of cable entry as practical.

Adapter

1.Adapter information (varies with the purchased model)

a.Input voltage: 100–240Vac Input frequency: 50–60Hz

Rating output current: 120W (19V, 6.3A) Rating output voltage: 19Vdc

b.Input voltage: 100–240Vac Input frequency: 50–60Hz

Rating output current: 90W (19V, 4.7A) Rating output voltage: 19Vdc

c.Input voltage: 100–240Vac Input frequency: 50–60Hz

Rating output current: 65W (19V, 3.4A) Rating output voltage: 19Vdc

2.The socket outlet must be near to the unit and easily accessible.

DC Fan Warning

Please note that the DC fan is a moving part that may cause DANGER. Ensure to keep your body from the moving fan blades.

English

All-in-one PC ET24 Series 13

English

Welcome

Congratulations on your purchase of All-in-one PC ET24 Series.The following illustration displays the package contents of your new product. If any of the following items is damaged or missing, contact your retailer.

Package contents

All-in-one PC ET24 Series	Keyboard (wired or wireless)	Mouse (wired or wireless)
		Quick	Guide

AC adapter	Power cord	Quick start guide

Warranty card

3D Vision glasses

TV USB dongle (optional)

KBM USB receiver dongle (optional)

Remote Control

Note:

1.The number and content of the discs may vary with territories.

2.The keyboard, mouse, power supply,TV USB dongle, remote control, and KBM USB receiver dongle illustrations are for reference only. Actual product specifications may vary with territories.

3.The 3D Vision glasses are not prescription eyewear, sunglasses, nor a protective goggle. DO NOT use the glasses for any general eyewear purposes (e.g., driving, reading, protection from sunlight or ultraviolet light, etc.) as such use may cause injury.

14 All-in-one PC ET24 Series

Getting to know your All-in-one PC

Front view

Refer to the following diagram to identify the components on this side of the system.

1

2

3

4

English

All-in-one PC ET24 Series 15
