E5254
Eee PC
User Manual
Windows® 7 Edition
Eee PC 1008P Series
15G06Q209001
Table of Contents....................................................................................................................... |
ii |
About This User’s Manual....................................................................................................... |
iv |
Notes for This Manual.............................................................................................................. |
iv |
Safety Precautions..................................................................................................................... |
v |
Transportation Precautions.................................................................................... |
vi |
Charging Your Batteries.......................................................................................... |
vii |
Airplane Precautions................................................................................................ |
vii |
Chapter 1: |
Knowing the Parts |
|
Top Side..................................................................................................................................... |
|
1-2 |
Bottom Side............................................................................................................................. |
|
1-6 |
Right Side.................................................................................................................................. |
|
1-8 |
Left Side..................................................................................................................................... |
|
1-9 |
Rear Side.................................................................................................................................. |
|
1-10 |
Keyboard Usage................................................................................................................... |
|
1-11 |
Special Function Keys.......................................................................................... |
1-11 |
|
Touchpad Usage................................................................................................................... |
|
1-13 |
Multi-finger gesture input................................................................................. |
1-13 |
Chapter 2: |
Getting Started |
|
Installing and uninstalling the battery pack................................................................ |
2-2 |
|
Powering on your Eee PC.................................................................................................... |
2-4 |
|
First-time Startup................................................................................................................... |
|
2-5 |
Desktop..................................................................................................................................... |
|
2-7 |
Network Connection............................................................................................................ |
|
2-8 |
Configuring a wireless network connection................................................. |
2-8 |
|
Local Area Network................................................................................................ |
2-9 |
|
Browsing web pages............................................................................................ |
2-12 |
Chapter 3: |
Using the Eee PC |
|
ASUS Update. |
.......................................................................................................................... |
3-2 |
Updating ........................................................the BIOS through the Internet |
3-2 |
|
Updating ...........................................................the BIOS through a BIOS file |
3-3 |
|
Bluetooth Connection ...............................................................(on selected models) |
3-4 |
ii |
Table of Contents |
Super Hybrid Engine............................................................................................................. |
3-6 |
Super Hybrid Engine Modes............................................................................... |
3-6 |
Eee Docking............................................................................................................................. |
3-7 |
Eee Amuse................................................................................................................. |
3-7 |
Eee Sharing................................................................................................................ |
3-8 |
Eee Xperience........................................................................................................... |
3-8 |
Eee Tools..................................................................................................................... |
3-9 |
Boingo (on selected models)............................................................................................. |
3-9 |
Digital Zoom Control (on selected models)............................................................... |
3-10 |
Function keys.......................................................................................................... |
3-10 |
Microsoft® Office Trial.......................................................................................................... |
3-12 |
Chapter 4: |
Support DVD & System Recovery |
|
Support DVD information................................................................................................... |
4-2 |
|
Running the support DVD................................................................................... |
4-2 |
|
Drivers menu............................................................................................................ |
|
4-3 |
Utilities menu........................................................................................................... |
|
4-3 |
Contact....................................................................................................................... |
|
4-3 |
Other information................................................................................................... |
4-3 |
|
System Recovery.................................................................................................................... |
|
4-4 |
Using Recovery Partition (F9 Recovery).......................................................... |
4-4 |
|
Using the Support DVD........................................................................................ |
4-4 |
|
Boot Booster............................................................................................................................ |
|
4-6 |
Appendix |
|
|
Declarations and Safety Statements............................................................................... |
A-2 |
|
Copyright Information. |
..................................................................................................... |
A-12 |
Limitation of Liability......................................................................................................... |
|
A-13 |
Service and Support.......................................................................................................... |
|
A-13 |
ASUS Eee PC |
iii |
You are reading the Eee PC User’s Manual.This User’s Manual provides information regarding the various components in the Eee PC and how to use them.The following are major sections of this User’s Manual:
1.Knowing the Parts
Provides information on the Eee PC’s components.
2.Getting Started
Provides information on getting started with the Eee PC.
3.Using the Eee PC
Provides information on using the Eee PC’s utilities.
4.Support DVD and System Recovery
Gives you information on support DVD contents and system recovery.
5.Appendix
Gives you safety statements.
The actual bundled operating system and applications differ by models and territories.There may be differences between your Eee PC and the pictures shown in this manual. Please accept your Eee PC as being correct.
A few notes and warnings are used throughout this guide, allowing you to complete certain tasks safely and effectively.These notes have different degrees of importance as follows:
WARNING! Important information that must be followed for safe operation.
IMPORTANT! Vital information that must be followed to prevent damage to data, components, or persons.
TIP: Tips for completing tasks.
NOTE: Information for special situations.
iv |
Table of Contents |
The following safety precautions will increase the life of the Eee PC. Follow all precautions and instructions. Except as described in this manual, refer all servicing to qualified personnel. Do not use damaged power cords, accessories, or other peripherals. Do not use strong solvents such as thinners, benzene, or other chemicals on or near the surface.
Disconnect the AC power before cleaning.Wipe the Eee PC using a clean cellulose sponge or chamois cloth dampened with a solution of nonabrasive detergent and a few drops of warm water and remove any extra moisture with a dry cloth.
DO NOT place on uneven or unstable work surfaces. Seek servicing if the casing
has been damaged.
DO NOT expose to dirty or dusty environments. DO NOT operate during a gas leak.
DO NOT place or drop objects on top and do not shove any foreign objects into the Eee PC.
DO NOT expose to strong magnetic or electrical fields.
DO NOT press or touch the display panel. Do not place together with small items that may scratch or enter the Eee PC.
DO NOT leave the Eee PC on your lap or any part of the body to prevent discomfort or injury from heat exposure.
DO NOT expose to or use near liquids, rain, or moisture. DO NOT use the modem during electrical storms.
Battery safety warning: DO NOT throw the battery in fire. DO NOT short circuit the
contacts. DO NOT disassemble the battery.
ASUS Eee PC
SAFE TEMP:This Eee PC
should only be used in environments with ambient temperatures
between 5°C (41°F) and 35°C (95°F)
DO NOT carry or cover a Eee PC that is powered ON with any materials that will reduce air circulation
such as a carrying bag.
INPUT RATING: Refer to the rating label on the bottom of the Eee PC and be sure that your power adapter complies with the rating.
Incorrect installation of battery may cause explosion and damage the Eee PC.
DO NOT throw the Eee PC in municipal waste.This product has been designed to enable proper reuse of parts and recycling.The symbol of the crossed out wheeled bin indicates that the product (electrical, electronic equipment and mercury-containing button cell battery) should not be placed in municipal waste. Check local regulations for disposal of electronic products.
DO NOT throw the battery in municipal waste.The symbol of the crossed out wheeled bin indicates that the battery should not be placed in municipal waste.
To prepare your Eee PC for transport, you should turn it OFF and disconnect all external peripherals to prevent damage to the connectors.The hard disk drive’s head retracts when the power is turned OFF to prevent scratching of the hard disk surface during transport.
Therefore, you should not transport your Eee PC while the power is still ON. Close the display panel to protect the keyboard and display panel.
The Eee PC’s surface is easily dulled if not properly cared for. Be careful not to rub or scrape surfaces when transporting your Eee PC.You can put your Eee PC in a carrying case for protection from dirt, water, shock, and scratches.
vi |
Table of Contents |
If you intend to use battery power, be sure to fully charge your battery pack before going on long trips. Remember that the power adapter charges the battery pack as long as it is plugged into the computer and an AC power source. Be aware that it takes much longer to charge the battery pack when the Eee PC is in use.
Remember to fully charge the battery (8 hours or more) before first use and whenever it is depleted to prolong battery life.The battery reaches its maximmum capacity after a few full charging and discharging cycles.
Contact your airline if you want to use the Eee PC on the airplane. Most airlines have restrictions for using electronic devices. Most airlines allow electronic use only between and not during takeoffs and landings.
There are three main types of airport security devices: X-ray machines (used on items placed on conveyor belts), magnetic detectors (used on people walking through security checks), and magnetic wands (hand-held devices used on people or individual items).You can send your Eee PC and diskettes through airport X-ray machines. However, it is recommended that you do not send your Eee PC or diskettes through airport magnetic detectors or expose them to magnetic wands.
ASUS Eee PC |
vii |
viii |
Table of Contents |
Top Side
Bottom Side
Right Side
Left Side
Rear Side
Keyboard Usage
Touchpad Usage
Chapter 1: |
1 |
|
|
Knowing the Parts |
Refer to the diagram below to identify the components on this side of the Eee PC.
The top side may vary in appearance depending on model.
1
2
3
4 |
5 |
6 |
7
8
The keyboard differs for each territory.
1-2 |
Chapter 1: Knowing the Parts |
1 Built-in Camera
2 Array Microphone (Built-in)
The built-in array microphone is more clear and echo-free
compared with traditional single microphones.
3 Display Panel
The display resolution supports up to 1024x600 pixels only under Win7 OS. Applications that require higher resolution support may not function normally.
4 Instant keys
Express Gate Button / Super Hybrid Power button (on selected models)
When the Eee PC is turned off, pressing this button will launch Express Gate. Express Gate is an ASUS exclusive OS that provides you with quick access to the Internet and key applications without entering the Windows® OS.
Under the Windows OS, this button functions as the Super Hybrid Power button.The button toggles power savings between various power saving modes.You can also control the function by press <Fn> + <Space Bar>.
Touchpad Off key
Toggles the touchpad ON/OFF.You can also turn on/off the function by pressing <Fn> + <F3>.
(Continued on the next page)
ASUS Eee PC |
1-3 |
5 Status Indicators
Battery Charge Indicator
The battery charge indicator (LED) shows the battery
charging status as follows:
Powered ON
High battery power |
With Adapter |
Without Adapter |
|
Green ON |
Off |
||
(95%–100%) |
|||
|
|
||
Medium battery power |
Orange ON |
Off |
|
(11%–94%) |
|
|
|
Low battery power |
Orange Blinking |
Orange Blinking |
|
(0%–10%) |
|||
|
|
Powered OFF
High battery power |
With Adapter |
Without Adapter |
|
Green ON |
Off |
||
(95%–100%) |
|||
|
|
||
Medium battery power |
|
|
|
Orange ON |
Off |
||
(11%–94%) |
|
|
|
Low battery power |
Orange Blinking |
Off |
|
(0%–10%) |
|||
|
|
Hard Disk Drive (HDD) Indicator
The hard disk drive indicator blinks when data is written to or read from the disk drive.
Wireless/Bluetooth Indicator (Bluetooth on selected models)
This is only applicable on models with built-in wireless LAN/Bluetooth.When the built-in wireless LAN/Bluetooth is enabled, this indicator lights.
Capital Lock Indicator
Indicates that capital lock [Caps Lock] is activated when lighted.
1-4 |
Chapter 1: Knowing the Parts |
6 |
Power Switch |
The power switch allows powering ON and OFF the Eee PC and recovering from STR. Press the switch once to turn ON and hold it to turn OFF the Eee PC.The power switch only works when the display panel is opened.
Power Indicator
The power indicator lights when the Eee PC is turned ON and blinks slowly when the Eee PC is in the Save-to-RAM (Suspend) mode.This indicator is OFF when the Eee PC is turned OFF.
7 Keyboard
The keyboard provides keys with comfortable travel (depth at which the keys can be depressed) and palm rest for both hands.
The keyboard differs depending on model.
8 Touchpad and Buttons
The touchpad and its buttons comprises a pointing device that provides the same functions as a desktop mouse.
ASUS Eee PC |
1-5 |
Refer to the diagram below to identify the components on this side of the Eee PC.
The bottom side may vary in appearance depending on model.
1
2
5
4
3
The bottom of the Eee PC can get very hot. Be careful when handling the Eee PC while it is in operation or recently been in operation. High temperatures are normal during charging or operation. DO NOT use on soft surfaces such as beds or sofas, which may block the vents. DO NOT PUT THE Eee PC ON YOUR
LAP OR OTHER PARTS OF THE BODY TO AVOID INJURY FROM THE HEAT.
1VGA door
The VGA door is for the installation of a VGA dongle (optional).
2 Memory Compartment
The memory module is secured in a dedicated compartment.
1-6 |
Chapter 1: Knowing the Parts |
3 |
Audio Speaker System |
The built-in stereo speaker system allows you to hear audio without additional attachments.The multimedia sound system features an integrated digital audio controller that produces rich, vibrant sound (results improved with external stereo headphones or speakers). Audio features are software controlled.
4 Battery Pack
The battery pack is automatically charged when connected to an AC power source and maintains power to the Eee PC
when AC power is not connected.This allows use when moving temporarily between locations. Battery time varies by usage and by the specifications for this Eee PC.The battery pack cannot be disassembled and must be purchased as a single unit.
5 Battery Lock - Manual
The manual battery lock is used to keep the battery pack secured. Move the manual lock to the unlocked position to insert or remove the battery pack. Move the manual lock to the locked position after inserting the battery pack.
ASUS Eee PC |
1-7 |
Refer to the diagram below to identify the components on this side of the Eee PC.
1 |
2 |
3 |
4 |
5 |
1Battery Compartment Cover
Remove the battery compartment cover before installing or uninstalling the battery pack.
2 USB Port (2.0/1.1)
The USB (Universal Serial Bus) port is compatible with USB 2.0 or USB 1.1 devices such as keyboards, pointing devices, cameras, and storage devices, connected in a series up to 12Mbits/sec (USB 1.1) and 480Mbits/sec (USB 2.0). Also, the USB supports hot-swapping function.
3 Microphone Jack
4
5
The microphone jack is designed to connect the microphone used for Skype, voice narrations, or simple audio recordings.
Headphone Output Jack
The 1/8” stereo headphone jack (3.5mm) connects the Eee PC’s audio out signal to amplified speakers or headphones. Using this jack automatically disables the built-in speakers.
LAN Port
The eight-pin RJ-45 LAN port (10/100M bit) supports a standard Ethernet cable for connection to a local network.The built-in connector allows convenient use without additional adapters.
1-8 |
Chapter 1: Knowing the Parts |
Refer to the diagram below to identify the components on this side of the Eee PC.
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
1 |
2 |
3 |
|
|
4 |
5 |
||||||
1 |
|
Power (DC) Input |
|
|
|
|
The supplied power adapter converts AC power to DC power for use with this jack. Power supplied through this jack supplies power to the Eee PC and charges the internal battery pack.To prevent damage to the Eee PC and battery pack, always use the supplied power adapter.
CAUTION: MAY BECOME WARM TO HOT WHEN IN USE. BE SURE NOT TO COVER THE ADAPTER AND KEEP IT AWAY FROM YOUR BODY.
2 |
Mini VGA Connector |
The mini VGA connector is for the VGA dongle to connect to a standard VGA-compatible device such as a monitor or projector to allow viewing on a larger external display.
3 USB Port (2.0/1.1)
4Air Vents
The air vents allow cool air to enter and warm air to exit the Eee PC.
Ensure that paper, books, clothing, cables, or other objects do not block any of the air vents or else overheating may occur.
5 |
Memory Card Slot |
The built-in memory card reader can read SD/SDHC/MMC cards.
ASUS Eee PC |
1-9 |
Refer to the diagram below to identify the components on this side of the Eee PC.
1 |
2 |
3 |
1 Battery Charge Indicator
The battery charge indicator (LED) shows the status of the battery’s power. Refer to the LED status table on pages 1-3 to 1-4.
2 |
Power Indicator |
The power indicator lights when the Eee PC is turned ON and blinks slowly when the Eee PC is in the Save-to-RAM (Suspend) mode.This indicator is OFF when the Eee PC is turned OFF.
3Air Vents
The air vents allow cool air to enter and warm air to exit the Eee PC.
Ensure that paper, books, clothing, cables, or other objects do not block any of the air vents or else overheating may occur.
1-10 |
Chapter 1: Knowing the Parts |
The following defines the colored hot keys on the Eee PC’s keyboard.The colored commands can only be accessed by first pressing and holding the function key while pressing a key with a colored command. Some function icons appear in the Notification area after activation.
The Hot Key locations on the function keys may vary depending on model but the functions should remain the same. Follow the icons whenever your hot key locations do not match the manual.
Zz Icon (F1): Places the Eee PC in suspend mode (Save-to-RAM).
Radio Tower (F2) (Wireless Models Only):Toggles
the internal wireless LAN or Bluetooth (on selected models) ON or OFF with an on-screen-display. When enabled, the corresponding wireless indicator will light.
The default setting is WLAN ON / Bluetooth OFF.
Touchpad (F3):Toggles the touchpad ON/OFF.
Resolution Selection (F4): Press to adjust the display resolution.
The Touchpad (<Fn> + <F3>) and Resolution Selection (<Fn> + <F4>) functions are available on selected models.
The display resolution supports up to 1024x600 pixels only under Win7 OS. Applications that require higher resolution support may not function normally.
Sun Down Icon (F5): Decreases the display brightness.
Sun Up Icon (F6): Increases the display brightness.
Crossed Screen Icon (F7):Turns off the display backlight.
ASUS Eee PC |
1-11 |
LCD/Monitor Icons (F8):Toggles between the Eee PC’s
LCD display and an external monitor.
Task Manager Icon (F9): Initiates the Task Manager to view the application process or terminates applications.
Crossed Speaker Icon (F10): Mutes the speaker.
Volume Down Icon (F11): Decreases speaker volume.
Volume Up Icon (F12): Increases the speaker volume.
Super Hybrid Engine (Fn+Space Bar): Toggles among
various power saving modes.The selected mode is shown on the display.
Num Lk (Insert):Toggles the numeric keypad
(number lock) ON and OFF. Allows use of a larger portion of the keyboard for number entering.
Scr Lk (Delete): Toggles the “Scroll Lock” ON and OFF.
Allows you to use a larger portion of the keyboard for cell navigation.
Pg Up (↑): Press to scroll up in documents or the web browser.
Pg Dn (↓): Press to scroll down in documents or the web browser.
Home (←): Press to move the pointer to the beginning of the line.
End (→): Press to move the pointer to the end of the line.
Windows icon: Displays the start menu.
Menu with pointer icon : Activates the properties menu
and is equivalent to right-clicking the touchpad/mouse on an object.
1-12 |
Chapter 1: Knowing the Parts |
