Alcatel-Lucent 7450 ESS
E t h e r n e t S e r v i c e S w i t c h | R e l e a s e 7 . 0
The Alcatel-Lucent 7450 Ethernet Service Switch (ESS) is a high performance MPLS-enabled Carrier Ethernet platform providing high-speed Ethernet service delivery and high-density service aggregation at the Carrier Ethernet service edge. With industry-leading throughput, density, reliability and service depth, the 7450 ESS is the platform of choice to enable wide scale Carrier Ethernet adoption, implementation, and transformation.
The Alcatel-Lucent 7450 ESS is the industry’s most advanced MPLSenabled Carrier Ethernet platform. With terabit capacity, leading port densities, advanced MPLS capabilities, and best-in-class service attributes all in a highly reliable and feature-rich platform, the 7450 ESS is a field-proven, highly-scalable platform designed to support residential triple play services, business VPN services and mobile backhaul applications at the Carrier Ethernet service edge. The 7450 ESS integrates the scalability, resiliency and predictability of MPLS along with the bandwidth and economics of Ethernet to enable a metro-wide, converged packet aggregation infra structure using Carrier Ethernet to deliver next-generation services.
The Metro Ethernet Forum certified (MEF-9, MEF-14) Alcatel-Lucent 7450 ESS provides unmatched service depth to set a new market benchmark for the delivery of advanced services with predictable, differentiated service level agreements (SLAs). Advanced service delivery includes both multipoint and point-to-point business VPN services, such as virtual private LAN services (VPLS), Ethernet LAN (ELAN) services,
Ethernet access to IP VPNs, virtual leased line (VLL) services, Ethernet Line (ELine) services, and Ethernet access to enhanced Internet services. It also includes high-density, service-aware aggregation of residential triple
play and mobile traffic over IP/MPLS infrastructures.
Leveraging the carrier-optimized and highly fault-tolerant Service Router Operating System (SR OS) — a common element across the Alcatel-Lucent Service Router portfolio — the 7450 ESS provides advanced hierarchical quality of service (H-QoS), highly flexible serviceaware QoS, and operations, administra tion and maintenance (OA&M) toolkit to enable next-generation service delivery. For more advanced service delivery, the 7450 ESS features Integrated Service Adapters (ISAs) to provide high performance L3 through L7 application-specific processing for the monetization and optimization of advanced residential triple play and business VPN services.
The Alcatel-Lucent 7450 ESS is available in five chassis options:
•7450 ESS-12: 12-slot platform, delivering up to 1 Tb/s (half duplex) of throughput
•7450 ESS-7: 7-slot platform, delivering up to 500 Gb/s (half duplex) of throughput
•7450 ESS-6: 6-slot platform, delivering up to 320 Gb/s (half duplex) of throughput
•7450 ESS-6V: 6-slot platform, delivering up to 320 Gb/s (half duplex) of throughput
•7450 ESS-1: Single-slot platform, delivering up to 40 Gb/s (half duplex) of throughput
With five platform options, the Alcatel-Lucent 7450 ESS allows service providers, ILECs, multiservice operators (MSOs), mobile operators, city carriers, Internet service providers, application service providers and industry and public sector (IPS) customers to build-out costoptimized, next-generation infrastructures for a right-sized solution for any network environment. Each system offers leading throughput and density, the ability to mix and match a wide range of Ethernet and packet over SONET/SDH interface adapters, and exceptional portability of adapters across platforms.
Alcatel-Lucent is committed to providing environmentally friendly solutions. Energy efficiency and environmental responsibility are built into the platform design, research and development programs, manufacturing processes, and life cycle management. As a result, the 7450 ESS delivers some of the highest levels of energy efficiency in the market and can play a major role in helping service providers reduce their overall energy consumption and carbon footprint.
Features
•Terabit routing capacity to meet ever increasing bandwidth requirements in Carrier Ethernet networking environments
¬Up to 1 Tb throughput (half duplex) in 1/3 of a telco rack
¬50 Gb/s (full duplex) slots with no tradeoff between terabit performance and advanced service delivery
¬Migration path to multi-terabit system capacity with 100 Gb/s (full duplex) slots planned on existing system, leveraging breakthrough in-house developed FP2 silicon— without a forklift upgrade
•A wide range of high-density, flexible Ethernet and SONET/SDH interface options enabling costeffective Carrier Ethernet service delivery and aggregation
¬Full compliment of 10M/100M/1G/ 10G Ethernet interfaces with SFP/ XFP/copper support
-Up to 400 GigE ports/chassis; 1,200 GigE ports/rack
-Up to 80 10GigE ports/chassis; 240 10GigE ports/rack
-Support for synchronous Ethernet (Sync-E) on MDA-XPs
¬10GigE MDA with integrated tunable DWDM optics and Sync-E support integrates transponders into the adapter
¬10GigE and GigE High-Scale MDA supports up to 20k subscribers with 160,000 ingress queues
and 160,000 egress queues per adapter
¬Flexible half-slot configurations for maximum resource use and minimized cost
¬Mix-and-match interface types at the IOM level and/or between chassis
¬SONET/SDH interface adapter options include the following multi-port SONET/SDH MDAs:
-OC-3c/STM-1c, OC12-c/STM-4c and OC-48c/STM-16c
•Comprehensive MPLS-enabled Carrier
Ethernet to support a full range of residential, business and mobile service applications
¬Advanced MPLS and IP feature set includes RSVP-TE, LDP, T-LDP, PWE3, fast reroute (FRR), OSPF, IS-IS and RIP
¬Fully featured Layer 2 VPNs using VPLS, H-VPLS and VLLs
¬Ethernet support includes IEEE 802.1Q (VLAN tagging), IEEE 802.1ad (QinQ or Stacked VLANs), IEEE 802.1s (Multiple Spanning Tree), IEEE 802.1w (Rapid Spanning Tree), IEEE 802.1ah (Provider Backbone Bridges), synchronous Ethernet
¬Seamless integration with IP/MPLS provider edge
-Layer 2 VPNs over MPLS
-Ethernet access to IP VPN and enhanced Internet services
¬Layer 2 tunneling protocol (L2TP), point-to-point protocol (PPP) and BGP-based auto-discovery for VPLS.
¬Equal Cost Multipath Protocol (ECMP) supports LDP and LDP- over-RSVP-TE tunnels
¬Flexible deployment options include full mesh, point-to-point, ring and dual-homed topologies
¬MEF-9 and MEF-14 certified platform supporting any service over any port
•High-availability architecture with proven, industry-leading feature set
¬Non-stop services for VLL, VPLS and enhanced Internet services
¬Non-stop routing on IS-IS, OSPF, RSVP-TE, LDP, IGMP snooping and graceful restart helper mode
¬In-service software upgrade (ISSU) support leverages non-stop services and non-stop routing
2 Alcatel-Lucent 7450 ESS | Release 7.0 | Data Sheet
¬Link and node resiliency features include FRR, multi-chassis LAG, multi-chassis ring, multi-chassis APS and dual-homed connections
¬FRR includes one-to-one and/or facility backup LSPs along with primary and secondary LSPs
¬BFD support includes RSVP-TE, OSPF, IS-IS and static routes
¬Modular and fault-tolerant operating system
¬Packet processing, queuing, and buffering are fully distributed on line cards
¬Fully redundant common equipment with hot-swappable components
•Advanced, highly flexible serviceaware QoS with service-based queuing, policing, and shaping and per-service guarantees
¬Service and network level queuing
¬Granular shaping, policing, marking of traffic and services
¬H-QoS with advanced scheduling and accounting
¬Up to 64,000 service queues, 1M hierarchical policers and 2M
2-tier MAC FIBs per Input/Output Module (IOM)
•Service specialization using Integrated
Service Adapter (ISA) modules for high performance Layer 3 to Layer 7 application-specific processing within the platform for the monetization and optimization of advanced residential and business VPN services
¬Application Assurance Integrated Service Adapter (AA-ISA) enables managed online services and application assurance VPN services
¬Video Integrated Service Adapter (Video-ISA) enables local ad insertion and assured linear TV applications
•Extensive service-aware OAM toolkit provides precise SLA-based service control
¬ITU-T Y.1731 and IEEE 802.1ag for performance and fault management
¬IEEE 802.3ah for Ethernet first mile OAM
¬Service Assurance Agent (SAA) for performance measurement
¬VPLS OAM
¬Service ping
¬LSP ping and traceroute IP ping and trace route
¬Virtual circuit connectivity verification and type-length- value (TLV) status
•Service-aware management portfolio for assured, simplified, and integrated operations across network and service management layers
¬5620 Service Aware Manager (SAM)
¬5650 Control Plane Manager (CPAM)
¬5670 Reporting and Analysis Manager (RAM)
¬5750 Subscriber Services Controller (SSC)
¬Alcatel-Lucent OSS Connected Partner Program
¬Service Portals
•Common portfolio OS with the
Alcatel-Lucent purpose-built and fault tolerant Service Router Operating System (SR OS)
¬Supported across the Service Router portfolio: 7450 ESS, 7210 Service Access Switch (SAS), 7705 Service Access Router (SAR), 7750 SR and the 7710 SR
•Robust security features protect the node, network, and users from fraud, spoofing, and attack
¬Control Processor Module queuing to mitigate DoS attacks
¬Control protocol authentication
¬Flexible filter policies on ingress or egress to an interface or service
¬MAC and IP layer ACL filtering at line rate
¬Anti-spoofing filters
¬Flexible filter policies on ingress or egress to an interface or service
¬SSL management traffic encryption
¬Radius/TACACS+ servers
¬SNMPv3 traps
¬Service mirroring, lawful intercept, robust authentication and logging
•Environmental friendly platform supporting leading power efficiency and a wide range of eco-friendly features designed to safeguard the environment, minimize power and footprint consumption, and lower operational costs
Benefits
•Deliver ubiquitous services with massive scale and reach
¬Consolidate next-generation residential, business and mobile services on a single platform at the Carrier Ethernet service edge
¬High performance MPLS and IP protocols and traffic engineering capabilities for efficient, reliable transport of any service or application and seamless integration with the IP/MPLS provider edge
¬VPLS, VLL, E-line and E-LAN services leverage MPLS to provide seamless Carrier Ethernet service reach over metro, national and international geographies
¬PBB and MPLS/VPLS integration innovation enhances network and service scalability — both in terms of reach and MAC addressing — to support the expansion of Carrier Ethernet VPN service into new territories
¬Provide enhanced scale and service granularity for very largescale deployments with massive subscriber services engineered for oversubscription and low average bandwidth using the HS-MDA
•Increase revenues with innovative, differentiated services
¬Highly flexible service-aware QoS along with a highly available platform ensures the support of residential triple play, business VPN and mobile services with predictable SLAs
Alcatel-Lucent 7450 ESS | Release 7.0 | Data Sheet |
3 |
