Agilent Technologies FS2010 User Manual

FuturePlus Systems Corporation

FS2010 Users Manual

For use with Agilent Logic Analyzers

Revision – 1.1

How to reach us ......................................................................................... 4

Product Warranty....................................................................................... 5

Limitation of Warranty...................................................................................5

Exclusive Remedies ....................................................................................................5

Assistance..........................................................................................................5

Introduction................................................................................................ 6

How to Use This Manual .................................................................................6

Analyzing the PCI-X Local Bus................................................................ 7

Accessories Supplied........................................................................................7

Minimum Equipment Required......................................................................7

Additional Equipment Required.....................................................................7

Signal Naming Conventions............................................................................8

Determining which logic analyzer card is the Master...................................8

Configuration Files...........................................................................................9

Connecting the 167xx Agilent logic analyzer to the FS2010.......................10

How to install a PCI-X add-in card into the FS2010 ..................................10

System operation with the PCI-X add-in card ............................................10

Setting up the 167xx Analyzer.......................................................................11

Setting up the 1680/90/900 Analyzer............................................................12

1680/90/900 Licensing....................................................................................12

Loading 1680/90/900 configuration files ......................................................12

Connecting the 1680/90/9xx Agilent logic analyzer to the FS2010 ............12

Offline Analysis ..............................................................................................13

The Format Menu..........................................................................................16

The PCI-X Transaction Decode Software....................................................17

FS2010 Software and Timing mode........................................................ 18

The ADDR, ADDR_B and DATA variables............................................................18

The CYCLE variable................................................................................................19

Bit Re-ordering.........................................................................................................20

State Analysis........................................................................................... 21

Acquiring Data...............................................................................................21

Configuring the Workspace for PCI-X Analysis.........................................22

The State Listing Display...............................................................................23

Functionality of the FS2010 Transaction Decode Software .......................25

Timing Analysis ....................................................................................... 26

Acquiring Data...............................................................................................26

The Waveform Display..................................................................................27

Use of EyeFinder/Eyescan.............................................................................27

Transaction Viewer.................................................................................. 28

General Information................................................................................ 29

Characteristics................................................................................................29

State/Timing Adapter Probe Interface Compatibility...............................................29

Card Edge Extender Connector ................................................................................29

Standards Supported................................................................................................. 29

Power Requirements.................................................................................................29

Logic Analyzer Required..........................................................................................29

Number of Probes Used............................................................................................29

Minimum Clock Period (State).................................................................................29

Etch length................................................................................................................30

Operations.................................................................................................................30

Environmental Temperature.....................................................................................30

Altitude.....................................................................................................................30

Humidity...................................................................................................................30

Testing and Troubleshooting....................................................................................30

Servicing...................................................................................................................30

Signal Connections.........................................................................................30

The State/Timing Adapter Probe interface pinout....................................................30

J2 Signal Connector ................................................................................ 31

J3 Signal Connections............................................................................. 33

J4 Signal Connections............................................................................. 35

How to reach us

For Technical Support:

FuturePlus Systems Corporation 36 Olde English Road Bedford NH 03110 TEL: 603-471-2734 FAX: 603-471-2738 On the web http://www.futureplus.com

For Sales and Marketing Support: FuturePlus Systems Corporation TEL: 719-278-3540 FAX: 719-278-9586 On the web http://www.futureplus.com

FuturePlus Systems has technical sales representatives in several major countries. For an up to date listing please see

http://www.futureplus.com/contact.html.

Agilent Technologies is also an authorized reseller of many FuturePlus products. Contact any Agilent Technologies sales office for details

Product Warranty

This FuturePlus Systems product has a warranty against defects in material and workmanship for a period of 1 year from the date of shipment. During the warranty period, FuturePlus Systems will, at its option, either replace or repair products proven to be defective. For warranty service or repair, this product must be returned to the factory.

Due to the complex nature of the FS2010 and the wide variety of customer target implementations, the FS2010 has a 30 day acceptance period by the customer from the date of receipt. If the customer does not contact

FuturePlus Systems within 30 days of the receipt of the product it will be said that the product has been accepted by the customer. If the customer is not satisfied with the FS2010 they may return the FS2010 within 30 days for a refund.

For products returned to FuturePlus Systems for warranty service, the Buyer shall prepay shipping charges to FuturePlus Systems and FuturePlus Systems shall pay shipping charges to return the product to the Buyer. However, the Buyer shall pay all shipping charges, duties, and taxes for products returned to FuturePlus Systems from another country.

FuturePlus Systems warrants that its software and hardware designated by FuturePlus Systems for use with an instrument will execute its programming instructions when properly installed on that instrument. FuturePlus Systems does not warrant that the operation of the hardware or software will be uninterrupted or error-free.

Limitation of Warranty

Exclusive Remedies

Assistance

The foregoing warranty shall not apply to defects resulting from improper or inadequate maintenance by the Buyer, Buyer-supplied software or interfacing, unauthorized modification or misuse, operation outside of the environmental specifications for the product, or improper site preparation or maintenance. NO OTHER WARRANTY IS EXPRESSED OR IMPLIED. FUTUREPLUS SYSTEMS SPECIFICALLY DISCLAIMS THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

THE REMEDIES PROVIDED HEREIN ARE BUYER’S SOLE AND EXCLUSIVE REMEDIES. FUTUREPLUS SYSTEMS SHALL NOT BE LIABLE FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, WHETHER BASED ON CONTRACT, TORT, OR ANY OTHER LEGAL THEORY.

Product maintenance agreements and other customer assistance agreements are available for FuturePlus Systems products. For assistance, contact Technical Support.

Introduction

The FS2010 is a 32/64 bit, 0 to 133Mhz PCI-X State and Timing adapter probe for use with Agilent logic analyzers. This card has a universal card edge connector and a 3.3v extender card connector. The FS2010 PCI-X State/Timing adapter probe and extender card performs three functions.

• The first is to act as an extender card, physically extending a module up approximately 1.5 inches from the motherboard connector.

• The second is to provide a complete timing analysis interface between any PCI-X add-in slot and Agilent Logic Analyzers.

• The third is to provide a complete state analysis interface and software decode of the PCI-X traffic between any PCI-X add-in slot and Agilent Logic Analyzers.

The State/Timing Adapter Probe interface is a passive bus monitor which does not assert any signals on the PCI-X bus. Because the FS2010 interface does not actively buffer the PCI-X bus signals, negligible skew is introduced.

How to Use This Manual

The configuration software on the diskette sets up the format menu of the logic analyzer for compatibility with your PCI-X bus.

This manual is organized to help you quickly find the information you need.

• Analyzing the PCI-X Local Bus chapter introduces you to the FS2010 and lists the minimum equipment required and accessories supplied for PCI-X bus analysis.

• The State Analysis chapter explains how to configure the FS2010 to perform state analysis on your PCI-X bus.

• The Timing Analysis chapter explains how to configure the FS2010 to perform timing analysis on your PCI-X bus.

• The General Information chapter provides information on the operating characteristics, the test point and cable header pinout and the mechanical drawing for the FS2010 module.

Analyzing the PCI-X Local Bus

This chapter introduces you to the FS2010 and lists the minimum equipment required and accessories supplied for PCI-X Local Bus analysis. This chapter also contains information that is common to both state and timing analysis.

Accessories Supplied

Minimum Equipment Required

The FS2010 product consists of the following accessories:

• The FS2010 probe.

• 1 Diskette containing the configuration files and the FS2010 PCI-X

decoder for 167xx analyzer.

• A CD containing the setup file to install the configuration files and protocol decoder on the 1680/90/900 analyzer or to use as an offline viewer.

• This operating manual on CD, Quick Start sheet, and SW Entitlement certificates for the software.

The minimum equipment required for analysis of a PCI-X Local Bus consists of the following equipment:

• Agilent 16700 analysis frame with the 16715 analyzer card or better.

• Revision 2.80.00 or better of the Agilent Logic analysis frame

software.

• 1680/90/900 Logic analyzer or PC containing Agilent 1680/90/900 OS version 3.00.00 or better.

• The FS2010 Product

• A PCI-X target bus

Additional Equipment Required

The type of logic analyzer card used will determine the correct type of termination adapter needed. For analyzer cards that use the 40 pin header, 1671x, 1674x, 16750/1/2, 1691x you will need the E5385A (FuturePlus number is FS1015) termination adapter cables. For analyzer cards that use the 90 pin header, 16753/4/5/6, 1695x you will need the E5378A (FuturePlus number is FS1014) termination adapter. A total of 3 adapter cables are required for 64 bit data width capture.

Signal Naming Conventions

Determining which logic analyzer card is the Master

This operating manual uses the same signal notation as the PCI-X LOCAL BUS SPECIFICATION - REVISION 1.0 That is, a # symbol at the end of a signal name indicates that the signal’s active state occurs when it is at a low voltage. The absence of a # symbol indicates that the signal is active at a high voltage.

When connecting the logic analyzer cards to the FS2010 it is necessary to know which logic analyzer card in which slot has been configured as the Master and which one has been configured as the Expander. Refer to the SYSTEM view of your 1670x or 1690x mainframe to determine how the cards have been configured.

Configuration Files

167xx Analyzer 169xx Analyzer File name for

State/Timing Analysis

16715/6/7/9 or 1674X or 16750/1/2

16753/4/5/6 16753/4/5/6,

*For 32 bit analysis load the timing or state configuration file into a single logic analyzer card. If you are using a 16910 card then only one card is required for 64 bit analysis.

1680/90, 16750/1/2, 1691x

1691x

CP210_1 *2 card state

CP210_2 *2 card timing

CP210_3 1 card eyefinder

CP210_4 1 card eyescan

Description

analysis

config

Connecting the 167xx Agilent logic analyzer to the FS2010

Master POD 1 J2 odd J CLK Master POD 2 J2 even Master POD 3 J3 odd Master POD 4 J3 even Expander POD 1 J4 odd optional 64 bit Expander POD 2 J4 odd optional 64 bit

The following explains how to connect the logic analyzer to the FS2010 for either state or timing analysis:

1. Connect the logic analyzer PODs 3 adapter cables, either the

E5378A or E5385A depending on the logic analyzer cards used.

2. Plug the Adapter cables into the probe as shown in the table

below.

167XX/1655X PCI-X Analysis Probe

connector

Comment

How to install a PCI-X add-in card into the FS2010

System operation with the PCI-X add-in card

The card edge connector of the FS2010 module can accommodate one 64 or 32 bit 3.3V PCI-X add-in card. To install simply align the module with the connector and gently push the module in until it is seated in the connector. There is sufficient clearance for the add-in card front plate. The FS2010/PCI-X add-in card combination can then be installed in any slot of the PCI-X Local bus.

When removing the PCI-X add-in card from the card edge extender connector grasp the FS2010 with one hand and the PCI-X add-in card with the other. Gently rock the PCI-X add-in card until it is free from the connector.

The nature of an extender card is that it extends the etch length of the bus. Due to the sensitivity of some PCI-X designs, extending the etch length can interfere with the PCI-X add-in card operation. Operation of the PCI-X add-in card when installed in the card edge extender connector is not guaranteed.

Setting up the 167xx Analyzer

167xx Licensing

To install the FS2010 software, insert the diskette labeled 16700/702 Installation disk for the FS2010 into the Agilent 16700 diskette drive. From the SYSTEM ADMINISTRATION TOOLS select INSTALL under SOFTWARE. From the SOFTWARE INSTALL screen select the FLEXIBLE DISK and APPLY. Once the title appears select it and then select INSTALL.

This procedure does not need to be repeated. It only needs to be done the first time the PCI-X Analysis Probe is used.

When this has completed, load the appropriate configuration file from the /configs/FuturePlus/FS2010 directory. Refer to the table on the following pages for a list of analyzers and corresponding configuration files.

The FS2010 product is a licensed product, which is locked to a single Agilent 1670x frame. Complete instructions for licensing this software are detailed on the Entitlement Certificate that is enclosed with this product.

The licensing area for the 1670x mainframe is found under System Administration. Once you are at the licensing area choose the Processor/Bus Solutions tab, in here you will find the PCIX inverse assembler listed. Type your password in the space provided to enable the use of the inverse assembler. A demo period is provided by typing the word demo into the password space next to the product name.

The following picture shows the licensing area after pressing the licensing button on the previous screen. This is where you would enter the password you will receive after following the instructions on the SW License Entitlement Certificate.
