r e f r i g er a t o r
INSTRUCTION BOOKLET
ERC3700X
818 38 48--00/4 |
GB |
Safety instructions GB
Your new fridge may have other functions compared to your previous one.
Carefully read these instructions to learn how the appliance works and how to care for it. Keep the instruction booklet. It will come in handy if you later sell the cabinet or give it to somebody else.
These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or using the appliance. Your safety is of paramount importance. If you are unsure about any of the meanings or warnings contact the Customer Care Department.
For the User |
· Do not keep carbonised drinks or bottles in the |
· The cabinet is intended for keeping foodstuff in a |
freezer compartment. The glass bottles may |
normal household as explained in this instruction |
break. |
booklet. |
· The cabinet is heavy. The edges and projecting |
· Do not keep explosive gases or liquids in the |
parts of the cabinet may be sharp. Be careful |
refrigerator or freezer compartment. They may |
when moving the cabinet and always use gloves. |
explode and cause injury and material damage. |
Child Safety |
· Do not let sharp objects come into contact with |
|
the refrigerating system on the back of and inside |
· Pay attention so that small children do not gain |
the cabinet. If the refrigerating system is |
access to the operating controls or the inside of |
punctured, the cabinet will be damaged and |
the cabinet. |
foodstuff inside may spoil. |
|
Scrapping old cabinets |
|
The symbol on the product or on its packaging indicates that this product may not be treated as household
waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negativ consequences for the environment and human health, which could otherwise be caused by inappropriate waste
handling of this product. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.
Contents |
GB |
Safety instructions . . . . . . . . . . . . . . . . . 2
Scrapping old cabinets . . . . . . . . . . . . . . . . . . . . . . . 2
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Description of the Appliance . . . . . . . . 3
Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Maintenance and Cleaning . . . . . . . . . . 6
Removing the ventilation grille . . . . . . . . . . . . . . . . 6 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 Defrosting the fridge . . . . . . . . . . . . . . . . . . . . . . . . 6 To change the light bulb . . . . . . . . . . . . . . . . . . . . . 7 When the appliance is not in use . . . . . . . . . . . . . . . 7
Before use . . . . . . . . . . . . . . . . . . . . . . . . . 3
Using the fridge . . . . . . . . . . . . . . . . . . . . 4
To start the fridge and set the correct temperature . 4 Temperature inside the fridge . . . . . . . . . . . . . . . . . 4 Measuring the temperature . . . . . . . . . . . . . . . . . . . 4 Switching off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 Cabinet interior . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Hints and Tips . . . . . . . . . . . . . . . . . . . . . 5
Saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Food Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Protect the environment . . . . . . . . . . . . . . . . . . . . . . 6
Something Not Working . . . . . . . . . . . . 7
Guarantee Conditions . . . . . . . . . . . . . . . . . . . . . . . 8
Service and Spare Parts . . . . . . . . . . . . . . . . . . . . . . 8
Technical specification . . . . . . . . . . . . . 8
Installation . . . . . . . . . . . . . . . . . . . . . . . . 8
Mains Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Remove the transport supports . . . . . . . . . . . . . . . . 9 Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 Installing the cabinet . . . . . . . . . . . . . . . . . . . . . . . . 9 Door Reversal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . 10
Electrolux 818 38 48-00/4
2
Description of the Appliance |
GB |
|||
1 |
7 |
Model ERC3700X |
|
|
|
|
|
|
|
2 |
4 |
|
|
|
1 |
1. |
glass shelf |
|
|
|
|
|||
|
|
2. |
bottle shelf |
|
1 |
4 |
3. |
bottle shelf |
|
|
8 |
4. |
door shelf |
|
1 |
|
5. |
vegetable drawer |
|
5 5 |
4 |
6. |
ventilation grille |
|
1 |
|
7. |
butter compartment |
|
1 |
|
|
||
|
8. |
egg holder |
|
|
|
|
|
||
1 |
3 |
|
|
|
5 |
|
|
|
|
6
Control Panel
A |
B |
A. Green indicator lamp |
B. Thermostat control |
Lights when the fridge is operating. |
Use to switch on and set the desired temperature in |
|
the fridge. |
Before use |
GB |
Position and clean the cabinet as explained in the section "Installation".
Check that the drain hose at the rear of the cabinet discharges into the drip tray.
Before inserting the power plug into the outlet and switching on the cabinet for the first time, leave it standing upright for about 4 hours. Otherwise the compressor may sustain damage. This time will allow the oil sufficient time to return to the compressor.
Electrolux 818 38 48-00/4
3
Using the fridge |
GB |
To start the fridge and set the correct temperature
Turn the thermostat control to the desired position. MIN The lowest position of the thermostat control results in the highest temperature inside the cabinet. MAX The highest position of the thermostat control results in the lowest temperature inside the cabinet. H : Switched off.
Allow the cabinet to run for a period of 24 hours whenever the temperature setting is changed. This will allow the temperature to stabilise inside the cabinet.
Temperature inside the fridge
A suitable temperature inside the fridge is approx. +5°C. If the thermostat control is set to a too cold temperature, food with a high water content may start to freeze if it has been placed in the coldest places in the fridge. The picture shows the coldest and warmest places inside the fridge.
(+ warm, - cold)
Meat, fish and milk should be put in the coldest part of the cabinet.
The temperature will be affected by:
·How often the door is opened
·How much food is stored
·Position of the appliance (See chapter Installation)
Measuring the temperature
If the temperature is measured using a standard, single thermometer, this should be put in a glass of water centrally placed inside the cabinet. This will reflect the temperature inside the food products. Do not place the thermometer hanging or lying directly on the shelf.
Hints:
·Distribute foodstuffs to allow cold air to circulate freely between the products.
·Do not place food products directly against the cooling plate on the rear wall since they may freeze in this case.
·Also never put warm products into the cabinet. Wait until they have cooled down.
·Cover all foods properly to avoid odours and flavours from tainting other food.
Switching off
Turn the control anti-clockwise past the click position to "•".
Remove the power supply plug from the wall socket.
++
--
-- --
-- |
|
|
-- |
+ |
|
+ |
||
+ |
||
+ |
||
|
||
+ |
|
Electrolux 818 38 48-00/4
4
