User Guide

Aastra 7147a -

analogue terminal

EN/LZT 102 4162 R1B

Aastra 7147a Medium Analogue Telephone 2

Table of Contents

Introduction 4 Important User information 5 Telephone Parts 6 Telephone layout 6 Cable inlets and MW switch 8 Incoming calls 9 Outgoing calls 10 During calls 12 Call forwarding 13 Optional Call handling Features 16 Call records/Call log 22 Speed Dial Memory 23 Caller ID display 24 Phone Setting 25 System Dependent Phone Setting 27 Telephone Specification 29 Wall Mounting 31

Aastra 7147a Medium Analogue Telephone 3

Introduction

Aastra 7147a is an easy managed line-powered analogue phone. It supports, call log, message waiting, volume adjustment, configuration lock. This user guide describes the features of the Aastra 7147a when it is connected to MX-ONE Telephony system, Telephony Switch or Telephony server.

The latest version of the user guide can be downloaded from:

http://www.aastra.com

Aastra 7147a Medium Analogue Telephone 4

Important User information

Safety Instructions

Save these instructions

Read these safety instructions before use!

Note: When using your telephone or connected equipment, the following basic safety precautions should always be followed to reduce risk of fire, electrical shock and other personal injury.

• Follow instructions in the equipment's user guide or other documentation.

• Always install equipment in a location and environment fo r which it is designed.

• Headsets used with this equipment must comply with EN/IEC 60950-1

• Do not make any changes or modifications to equipment without seeking approval

from the party responsible for complia n ce . Una ut ho ri zed cha n ge s or modif i cat i on s could void the user's authority to operate the equipment.

• Do not use the telephone to report a gas leak in the vicinity of the leak.

• Do not spill liquid of any kind on the product or use the equipment near water, for

example, near a bathtub, washbowl, and kitchen sink, in a wet basement or near a swimming pool.

• Do not insert any object into equipment slots that is not part of the product or auxiliary product.

• Do not disassemble the product. Contact a qualified service agency when service or repair work is required.

• Do not use a telephone (other than cordless type) during an electrical storm.

Disposal of the product

Your product should not be placed in municipal waste. Pleas e check local regulations for disposal of electronic products

Aastra 7147a Medium Analogue Telephone 5

Telephone Parts

When you unpack your phone, you should ensure that you have all of the following items. If any part is missing, contact the supplier of your phone

Telephone layout

Aastra 7147a Medium Analogue Telephone 6

Table with Key-symbols

Symbols /

Keys

Speed-dial

M0-M7

Flash key

French Spanish German Portuguese Dutch

Numérotation abrégée Touche M0-M7

Touche R-Flash

Teclas programables M0-M7

Tecla Flash R- Taste

Kurzwahl M0-M7

Discagem rápida M0-M7

Flash Haakcontact

Snel-kiezen

M0-M7

Redial / Pause key

0-9, * and # (dial keys)

Volume keys

Mute key

Call list key

Save key

Delete key

Music on hold

Message waiting

Touche Rappel / Mise en attente

0-9, * and # (touches de

numérotation) Touches de réglage volume

Touche secret Act./desactivMicro

Touche Journal d'appel

Touche de sauvegarde

Touche d'Effacement

Musique d'attente

Message en attente

Rellamada/ Pausa

0-9, * and # (digitos)

Volumen Lautstärketasten Volume

(Mute) silencio Stumm taste

lista de llamadas Anrufliste Lista de

Salvar Speichertaste Salvar Opslaan

Borrado Löschtaste Excluir

Música en espera

Mensaje en espera

Wahlwiederholung / Pausentaste

0-9, * and # (Zifferntasten)

Musik bei Warten

Nachricht wartet

Rediscagem/tecla de pausa

0-9, * and # (Dígitos)

Mudo Mute-toets

chamadas

Música em espera

Mensagem em espera

Nummerherhaling / Pauzetoets

0-9, * and # (bel toetsen)

Volume toetsen

Oproep lijst

Verwijderen

Muziek tijdens wachten

Wachtend

bericht

Speaker / Headset key

Haut-parleur / Casque

Altavoz / Tecla de manos libre

Lautsprecher / Kopfhörertaste

Aastra 7147a Medium Analogue Telephone 7

Alto-falante / Fone de ouvido

Luidspreker / hoofdtelefoon

Cable inlets and MW switch

Symbols

Line socket

OFF / Hi Volt / MW(-) / MW(+)

Headset Jack

Handset Jack

Data Jack

Aastra 7147a Medium Analogue Telephone 8

French Spanish German Portuguese Dutch

Prise ligne téléphonique

ARRET / Haute Tension / MW(-) / MW(+) Prise pour casque Prise pour combiné Prise pour données

Puerto conneccion de linea DE / Alto voltaje / MW(-) / MW(+ )

Puerto de auricular

Puerto de microtelefono

Puerto de datos Datenbuchse

Anschlussbuchse Conector de

linha telefônica

AUS/Spannung/ MW(-) / MW(+

Kopfhörerbuchse Conector do

Hörerbuchse Conector do

OFF / Hi Volt / MW(-) / MW(+)

fone de ouvido

monofone Conector de

linha de dados

Lijnpoort

UIT / Hi Volt / MW(-) / MW(+)

Hoofdtelefoon aansluiting

Telefoonhoor n aansluiting

Data aansluiting

Incoming calls

To answer an incoming call

Lift the handset or press without lifting the handset.

Answer a second call

A call waiting tone will inform you, during conversation that a second call is waiting. You have two options: Option 1:

1. Replace the handset. The new call will be signaled on your phone

2. Lift the handset to receive the call.

Option 2:

1. Ask the party you are speaking with to wait

2. Press

3. Lift the handset to receive the new call

4. Press 2 to return to the first call (Sweden, press

After finishing the call, replace the handset to receive the first call again.

and replace the handset. The waiting call will start ringing.

)

Answer a call from another extension

You can answer a call to another extension from any phone in your office:

1. Lift the handset and call the ringing extension.

2. You receive a busy tone, press numeric key, 8 (France:4. Sweden: 6)

Mute ring signal

Press to mute the ring signal (LED flashing)

Do not disturb, DND

When you activate DND, calls to your extension is not shown. Outgoing calls can be made as usual.

Activate DND : Lift the handset and press numeric keys * 2 7 #. Replace the handset. Deactivate DND: Lift the handset and press numeric keys # 2 7 #. Replace the handset

Call duration timer for incoming calls

A call duration timer for incoming calls starts 5 seconds after “off hook” status is established. The call duration is stored in the call list with the caller ID information

Outgoing calls

Dial and Pre-di al

Dial Pick up the handset or press

Press numeric keys, (if required also * # or Pre-dial

During on-hook, press the keys for the number to be dialed (max. 32 digits). press 1,1s.

or pick up the handset, the phone will dial out the number in.

Call by Handsfree

1. Press

2. To hang up the phone, press

3. When you are in handset mode, you can switch to handsfree mode by pressing

and enter the number by using the dial pad

for hands free / headset operation.

to dial out).

again

Call by Headset

1. Insert a headset to the phone

2. Press

3. To hang up the phone, press

4. When you are in handset mode, you can switch to headset mode by pressing

and enter the number

again.

Redial

1. Press

2. Lift the handset or press either

, the display shows the last number you have dialed

to dial out

Last External Number Redial

1. Lift the handset and press numeric key * * *

(Finland and Sweden: * * 0)

Dial Back from Call Record

1. Press

2. Press wish to ca ll

3. Lift the handset or press either

repeatedly to scroll the list and select call record that you

Speed-dial by Memory Keys (M0-M7)

1. Pick up the handset or press

2. Press memory key (M0 to M7)

Call Back

If a called extension is busy or there is no answer:

1. At busy tone, Press numeric key 6 (Finland , France and Sweden: 5)

Replace the handset

3. Lift the handset when you are called back If all external lines are busy (after dialing the digit or digits to get the line:

1. At busy tone, Press numeric key, 6 (Finland, France, Sweden: 5).

2. Dial the external number and press #

3. Replace the handset

4. Lift the handset when you are called back

Cancel cal l back

Cancel single call back: Lift the handset and press numeric keys # 3 7* , ext number, #. Replace the handset Cancel all callbacks Replace the handset.

: Lift the handset and press numeric key # 3 7 #.

Protection (Data Privacy)

Protection allows you to make a call without any disturbances, e.g. intrusion. The feature is automatically cancelled when the call is finished

Lift the handset and Press numeric keys * 41 #

Number presentation restriction

If you do not want your name and number to be displayed to the person you are calling.

1. Lift the handset and press numeric keys * 4 2 #

2. Dial the number

Call duration timer for out going calls

A call duration timer for outgoing calls starts 5 seconds after “off hook” status is established. The call duration is stored in the call list with the caller ID information.

During calls

Mute

1. When a call is in progress, press to mute (LED flashing).

2. To speak to the caller, press again (LED off).

Mute with music / Music on hold

1. When a call is in progress, press

2. Press

again or toggle the hook switch to resume the call (LED off).

Inquiry

1. When a call is in progress, press

2. Call 3

3. Return to the first call by pressing, 2

Refer back (Switch back) Press, 2 to refer back to the other party

party and wait for an answer

to hold the call (LED on).

(Sweden: )

Transfer

1. When a call is in progress, press

2. Call 3

party and wait for an answer. Replace the handset

before or after the answer

Conference

1. When a call is in progress, press,

2. Call 3

3. After answer, press numeric key, 3 Repeat the procedure to add more conference members (max 7 members)

party

Hold / Park a call

1. When a call is in progress, Press and replace the handset

2. Lift the handset to resume the call on your own extension

To resume the call from on another extension:

1. Lift the handset

2. Call the extension where the call was put on hold

3. Press numeric key 8

(France: 4. Sweden:6)

Call forwarding

Diversion

If you do not want to be disturbed or will be out of office, you can have all calls to your extension diverted to a preprogrammed answering position. Diversion can be made direct, on no answer, on busy or to another information service facility. As a reminder that your telephone is diverted, you will hear a special dial tone each time you lift the handset to make a call.

Order direct diversion from your own extension The call can be diverted to an individual position or up to three determined

common answering positions (depending on the type of the incoming call). Preprogrammed by your system administrator.

1. Lift the handset and Press numeric keys * 21 # (UK: *2# )

2. Replace the handset

Cancel diversion from your own extension

1. Lift the handset and press numeric keys # 21 # ( UK: # 2 # )

2. replace the handset

To order diversion when there is no answer

1. Lift the handset and Press numeric keys * 211 #

*61# )

2. Replace the handset

(Finland and Norway:

Cancel diversion when there is no answer:

1. Lift the handset and press numeric keys # 211 #

2. Replace the handset

Diversion when the caller receives a busy tone

1. Lift the handset and Press numeric keys * 212 #

*67# )

2. Replace the handset

( UK: #61# )

(Finland and Norway:

Cancel diversion when the caller receives a busy tone:

1. Lift the handset and press numeric keys # 212 #

2. Replace the handset

( UK: # 67 # ),

Internal Follow me

All calls to your extension are diverted to an extension of your choice, within the private network. For example, when you are working in another room and want your calls to follow you to that answering position. When your telephone has Follow-me you can still make calls from it as usual. As a reminder that your telephone has Follow-me, you will hear a special dial tone each time you lift the handset to make a call.

Ordering Follow-me from your own phone

1. Lift the handset (dial tone) and press numeric keys * 2 1 *

2. Dial extension number of the answering position and press # (Special dial tone)

3. Replace the handset

Canceling Follow-me from your own phone

1. Lift the handset (special dial tone) and press numeric keys # 21 #

(ordinary dial tone)

2. Replace the handset

Ordering Follow-me from another phone You can order Follow-me of your own extension number from another telephone. The first step is to allow that Follow-me is permitted to be done from another telephone. Do the following from your own telephone:

1. Lift the handset (dial tone) and press numeric keys * 2 1 *

2. Dial own extension number and press #

3. Replace the handset

To order Follow me from another telephone:

1. Lift the handset (dial tone) and press numeric keys * 2 1 *

2. Dial own extension number * the extension number of the new answering position # (special dial tone)

3. Replace the handset

Canceling Follow-me from another phone

1. Lift the handset (dial tone) and dial # 21*

2. Dial own extension number # (dial tone)

3. Replace the handset

(UK:#2# )

(UK:*2* )

( UK:*2* )

Ordering Follow-me remotely With this feature you can order follow-me of any extension number from any

telephone. The prerequisite is that all the involved telephones have the right service profile. To order remote programming of follow-me, do the following:

1. Lift the handset (dial tone) and press numeric keys * 2 1 *

2. Extension number to divert * extension number of the new

answering position #

3. Wait for special dial tone

4. Replace the handset

Canceling Follow-me remotely To cancel remote programming of Follow-me from another telephone than

the telephone with diverted number:

1. Lift the handset and wait for the dial tone

2. Press numeric keys # 2 1 *

3. Dial diverted extension number and press #

4. Replace the handset

( UK:*2* )

External Follow me

1. Lift the handset and press numeric keys * 2 2 #

2. Dial external line code and external number press #

3. Replace the handset Cancel

: Lift handset and press numeric keys # 2 2 # . Replace the handset.

General Cancelation

Cancel all activated features: Lift the handset and Press numeric keys # 001 #

Optional Call handling Features

The features below may not be available in your telephony system. Please contact your system administrator.

Free seating

1. Log on: Lift the handset and press numeric keys *11*

2. Dial Authorization code and press numeric keys * Own extension number, press #

Log off

Personal Number

With the personal numbers and profiles feature you can be reached on your normal office phone number even if you are out of the office. A search profile (1-5) can be designed to fit the situation (in the office, traveling, at home, and so on). Both internal and external phone numbers can be used in a profile. Your search profile is programmed or modified by system administrator.

When the feature is activated, incoming calls are transferred to selected phones or back-up services in the order that you choose. If an answering position in the profile is busy, the call can be transferred to another predefined position in the profile (Voice Mail or a colleague). You can handle the profiles from your own office phone. How to do. this is described in this section (an operator can also assist you). You can also use any of the Personal Assistant applications if available. Contact your system administrator for more information. When out of the office, the feature Direct Inward System Access (DISA) can be used, if available in your system. How to use DISA is described in this section.

Activate or change profile from own extension

: Lift handset and press numeric keys #11#, Replace the handset.

1. Lift handset and press numeric keys *1 0 * ( 1- 5 ) #

2. Replace the handset

Canceling a profile from your phone

1. Lift handset and press numeric keys #10 #

2. Replace the handset

Voice Mail

Enter your mailbox:

1. Lift handset and dial the voice mail number and follow recorded

instruction. Note: if the number to the voice mail system has been programmed on the

message waiting key you can also press that key to enter the mailbox

Call Waiting

If you urgently wish to contact a busy extension or external line, you can notify the extension by a call waiting signal:

1. At busy tone, press numeric keys, 5 ( Finland, France: 6 Sweden:4).

2. Wait on line

Account Code

This feature is used to charge a call to an account number or to prevent unauthorized calls from your phone. The account code can have 1-15 digits.

1. Lift handset and press numeric keys * 6 1 * account code #

2. Dial the digit or digits to get an external line or external line

Absence Information

The absent information is used to inform the caller why you are absent and when you will return. Contact your system administrator regarding the available absence codes.

With return date and time

1. Lift the handset and press numeric keys * 2 3 *

2. Enter absence code (0-9) and press numeric key *

3. Enter the date or time (MMDD) or time (HHMM), press # Cancel:

Without return date and time

1. Lift the handset and press numeric key * 2 3 *

2. Enter absence code (0-9) and press numeric key # Cancel

Lift handset and press numeric keys # 2 3 #, Replace the handset.

: Lift handset and press numeric keys # 2 3 #, Replace the handset

Order for another extension:

1. Lift the handset and press numeric keys * 2 3 0 *

2. Dial the extension number and press *

3. Enter the absence code (0-9), press * Enter date or time (MMDD) or time (HHMM), for the other persons return, Press #, Replace the handset.

Cancel: press #, Replace the handset

Lift handset and press numeric key #230* Dial extension number and

Parallel Ringing

This feature makes it possible for an incoming call to ring on several phones simultaneously and for the call to be answered on any of the phones. The feature requires all the phones involved to be defined in a parallel ringing list.

To disable the parallel ringing temporarily:

1. Lift the handset and press numeric key * 2 1 *

2. Dial extension number and press, #, Replace the handset

To restore Parallel Ringing: Lift the handset and press numeric key # 21 #, Replace the handset

Intrusion on a busy extension

You can intrude on an ongoing call on a busy extension: Lift the handset and Press numeric key 4,

Before the intrusion a warning tone is sent to the parties in the ongoing call.

(France and Sweden: 8)

Group features

Group Call – pick - up In a call-pick-up group, any member can answer any individual call to group member.

Lift the handset and Press numeric key 8 to answer the call

Sweden: 0)

(Finland and

Common bell group Calls are signaled on a common bell. Lift the handset and Press numeric key, 8, to answer the call

Sweden: 0)

(Finland and

Group hunting As a member of a group of extensions that is called by a common number, you can temporarily leave the group.

1. Lift the handset and Press numeric keys * 2 1 *

( U.K: *2*)

2. Dial your own extension number and press #, Replace the handset

To re-enter the group:

Lift the handset and press numeric keys # 21 #

(UK:#2#), Replace the

handset.

If you are authorized, you can divert all calls to a group, to another extension or another group:

1. Lift the handset and press numeric keys * 2 4 *

2. Dial number of the group to be diverted, Press numeric key *

3. Dial extension number to the new answering position, press #

4. Replace the handset

To cancel the diversion:

1. Lift the handset and press numeric keys # 2 4 *

2. Dial the number of the group that has been diverted

3. Press numeric key #

4. Replace the handset

Direct inward system Access - DISA

If you are assigned to use this feature and you are working externally, you can call your office and get access to an external line in order to make business calls.

With common authorization code:

1. Lift the handset and call the DISA feature in your office.

2. You receive dial tone, press numeric key: * 7 2 *

3. Dial the authorization code and press numeric key #

4. You receive a dial tone, Dial external number

With individual Authorization code:

1. Lift the handset and call the DISA feature in your office.

2. You receive dial tone, press numeric key: * 7 5 *

3. Dial the authorization code and press numeric key *

4. You receive a dial tone, Dial external number, press *

5. Dial your own extension number and press #

6. You receive a dial tone. Dial external number

Authorization code, Common

If you are authorized to use a common authorization code (1 to 7 digits) you can temporarily change any phone used within the telephone system to the authority level connected to this code.

For a single call:

1. Lift the handset and press numeric key * 7 2 *

2. Enter authorization code and press #

3. You receive a verification tone, Dial the digit or digits to get an

external line and the external number.

To open an extension for several calls:

1. Lift the handset and press numeric key # 7 3 *

2. Enter authorization code and press #

3. You receive a verification tone.

To lock an extension:

1. Lift the handset and press numeric key * 73*

2. Enter authorization code and press #

3. You receive a verification tone.

Authorization code, individual

If you are authorized to use an individual authorization code (1-7 digits, affiliated to your own extension) you can lock your own extension to a common authority level, e.g. when out of the office. You can also temporarily change any other phone used within the telephone system to the same authority level as you have on your own phone. The individual code can be changed from your own extension.

To lock the phone:

1. Lift the handset and press numeric keys * 76 *

2. Enter authorization code and press #

3. You receive a verification tone.

To make calls with your authority level when your phone is locked:

1. Lift the handset and press numeric key *75 *

2. Enter authorization code and press #

3. Dial the digit or digits to get an external line and the external number.

To open your phone:

1. Lift the handset and press numeric key # 76 *

2. Enter authorization code and press #

3. You receive a verification tone.

To assign your own authority level to another phone:

1. Lift the handset and press numeric key * 75 *

2. Enter authorization code and press *

3. You receive verification tone

4. Enter your own extension number and press #

5. You receive verification tone, Dial the digit or digits to get an

external line and the external number.

To change your individual authorization code:

1. Lift the handset and press numeric keys * 74 *

2. Enter old authorization code and press *

3. Enter new authorization code and press #

4. You receive verification tone

Call records/Call log

View Call Records

1. Press [ ] to view the call list

2. Press [

Save a Call Record

] repeatedly to scroll the list

To store one telephone number from the Call Records list to one of the memory keys:

1. Press the Call list key [

2. Press the Save key [

3. Press the memory key you want to use for this telephone number (M0 to M7).

4. Sign the number card

] until you see the number you want to save

]

Delete Call Records

1. Press [ ] and Press [ ] to delete record

Dial from Call record

1. Select the call record that you wish to call.

2. Lift the handset or press [

]

Speed Dial Memory

There are eight memory keys (M0-M7) for storing frequently used number.

Save a Memory

1. Replace the handset on the phone

2. Select and press one of the memory keys (M0 to M7)

3. Press [

4. Press [

] and enter the number to be saved ] key again to complete saving

Dial from a Memory key

1. Pick up the handset or press [ ]

2. Select and press one of the memory keys (M0 to M7)

Delete Memory key

1. Replace the handset on the phone

2. Press memory key (M0 to M7)

3. Press [

]

Caller ID display

After receiving a new incoming call, the number will be displayed on LCD and hold for 10s. During this time, if received another new call, it will continue to display for 10s and display corresponding call.

Example: display content “12:00 9/3” indicates the time and date.

12:00 9/3

0755123456

The call list shows incoming; missed and outgoing calls. Scroll down the list by pressing the call list key repeatedly.

If the record is full, the next incoming call will replace the oldest record one by one.

• Missed call is indicated by the handset icon with a cross

• Incoming call is indicated by the handset icon with an arrow pointing

to it

• Out going call is indicated by the handset icon with an arrow directed from the handset

12:08 8/3

131256585621

Note: “22” indicates the position number in the call list.

Phone Setting

Set Ring Volume

Three levels of ring volume is provided: High, Low, Ringer off

1. Place the handset on the phone

2. Press ‘Volume +’ to increase ring volume

3. Press ‘Volume –‘ to decrease ring volume.

To disable the ring signal for incoming calls press the ‘Volume–‘ until you reach Silence level or press [ ] during on-hook. The Mute LED will remain

ON during on-hook to indicate the ring is now in silence.

Set Handset Volume

Four levels of handset volume is provided: Level 1 to 4

1. Pick up the handset

2. Press ‘Volume +’ to increase the handset volume

3. Press ‘Volume –‘ to decrease the handset volume

Set Headset Volume

Four levels of headset volume is provided: Level 1 to 4

1. Plug in the headset

2. Press [

3. Press ‘Volume +’ to increase the handset volume

4. Press ‘Volume –‘ to decrease the handset volume

Set Handsfree Volume

Eight levels of handsfree volume is provided: Level 1- 8

1. Pick up handset

2. Press [

3. Press ‘Volume +’ to increase the handsfree volume

4. Press ‘Volume –‘ to decrease the handsfree volume

]

Set password

A 4 digits combination password can be set to the phone in order to lock some critical parameters settings and speed dial memories from changing by unauthorized users.

Change password

1. During On-hook, press [ save] + [#]+[0]+[5]+[#]+[XXXX]+[#] +[YYYY]+[#]+[YYYY]+[#].

2. [ XXXX] is the old password; [ YYYY] is the new password. (Default

0000)

The saved new password will be asked for only when the phone is locked

To lock the phone

1. During On-hook, press [save]+[XXXX]+[#] (XXXX is the set password)

To unlock the phone

1. During On-hook, press [delete]+[XXXX]+[#] (XXXX is the set password)

Set time and date

1. In idle state, press [save] for 3 seconds to enter the time/date setting mode

2. Enter the number for HH:MM DD/MM (or MM/DD depends on the date format selected). For example, 17:30 28/06, press [1]+[7]+[3]+[0]+[2]+[8]+[0]+[6]. The corresponding digit of time/date icon flashes to indicate which digit is being entered.

Set Ring Melody

1. During On-hook, press [save]+[#]+[0]+[2]+[#]+[X]+[#].

2. X could be set from 1 to 8 (melodies 1~8).

LCD Contrast

1. During On-hook, press [save]+[#]+[0]+[3]+[#]+[X]+[#]

2. X could be set from 1 to 4 (Level 1~4).

System Dependent Phone Setting

Message Waiting Function (MW)

The telephone is equipped with a Message waiting key with a built in LED. If you have a voice mail box it is possible to get an indication on the telephone when you have received a new voice mail. Then the LED will be lighted ON or flashing in blue. The voice mail box can be reached by pressing the MW button.

Enable the MW function on your telephone

To enable the MW function it is required to make two settings: I. Set the MW switch to the position that is supported by the telephony

system. Alternatives are: MW-, MW+, HV.

II. You must store the number to the voicemail box in the MW memory of

the telephone.

I) Setting the Message Waiting Switch The Message Waiting switch (at the back of the phone) is used to select the

appropriate MW mode (HV / + / - ). Please check which MW type the PBX system supports.

1. Set the MW switch Note: If the LED is steady active, change the message waiting switch position.

II) Save your voice mail number in the telephone

1. Place the handset on the phone and press [ ]

2. Press [

3. Press [

4. The “save” successes with confirmation tone

] and enter the number to be saved ] key again to complete saving

Disable the message waiting function:

I). Change the MW switch at the back of the telephone to “OFF”. II). Delete the number to the voice mail box from the MW memory:

1. Place the handset on the phone

2. Press [ ]

3. Press [

4. The “delete” successes with confirmation tone

]

Dial from a MWM

1. Pick up the handset or press ‘Speaker/Handset’

2. Press the [ ]

Set Flash time

Different combination of key sequences are used on different parameter settings as shown in the table below

Parameter Programming key sequence Lock

Protected

Set flash time

[save]+[#]+[0]+[1]+[#]+[X]+[#] Yes 1: 100ms

Valid Settings

2: 200ms 3: 300ms 4: 400ms 6: 600ms 9: 900ms

Default

100ms

Telephone Specification

Main Characteristics

Professional Telephone Single line

Signaling

Market Certification Europe (CE)

Body Color Dark grey

Features

Visual indicator for incoming call Flashing LED

DTMF dialing Yes

Number memory Stores 8 telephone numbers

Last number Redial Yes

Flash function (R)

Programmable flash time

Hearing aid compatible Yes

Volume control

Microphone Mute Yes

Music on Hold

Message Waiting (MW )

Caller ID display

100 ms (default), 200 ms, 300 ms, 400 ms,

4 alternatives supported: MW+/MW-/HV/Off

FSK and DTMF signaling – according to

selected parts of ETSI EN300 659-1, -2, -3

Analog (DTMF)

100 ms (default)

600 ms, 900 ms

Handset / Headset (4 levels)

Handsfree (8 levels)

Yes

Call List (incoming/ missed and outgoing) 60 call records

Reset calling/redial list Erase content

Call Timer Yes

Real time clock Yes

Moth / Date presentation Yes

Delete calling/redial list yes

Handsfree Loudspeake r or Default (Headset disabled)

Headset pre-set mode (Hands free disabled)

Configuration Lock (4-digit pass code)

Ringer melody 8 types Ringer volume 2 levels

Ringer silence Yes

Data port For connecting the PC to the telephone line

speed-dial memory and critical phone

settings are lockable

Hardware

1st line with icons and time/date display with

2 line display

2nd line with 16 numeric characters (7-

Speed dialing keys 8

Memory card 1 Redial/Pause 1

icons

segment)

Flash key (R) 1

Mute key with LED 1

Handsfree / Headset pre-set key with

LED

Hold key with LED 1

MW with LED indicator 1

Volume control 2

Save 1

Call list key 1

Delete key 1

Handset receiver Electro-dynamic

Microphone Electret Tone ringer Piezo type

Headset interface 1

Data port 1

Accessories

Connection cable, RJ11/ RJ45

Number card 1 pcs (not included)

1 pcs, 2 meters (not included)

Wall Mounting

________________________________________________________________________________

Trademark

Aastra is a registered trademark of Aastra Technologies Limited. All other trademarks mentioned herein are the property of their respective

________________________________________________________________________________

Disclaimer

Aastra Technologies Limited will not accept liability for any damages and/or long distance charges, which result from unauth orized and/or unlawful use. While every effort has been made to ensure accuracy, Aastra editorial errors or omissions cont a ined wit h in this docu men ta t ion. The information contained in this documentation is subject to change without notice.

Technologies Limited will not be liable for technical or

________________________________________________________________

Declaration of conformity

Hereby, Aastra Telecom Sweden AB, Box 42214, SE-126 17 Stockholm, declares that this telephone is in conformity with the essential requirements and other relevant provisions of the European Directive 1999/5/EC (R&TTE Directive).

Details to be found at: http://www.aastra.com

AASTRA 7147a User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
