RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
English Edition
Visit our website (www.zalman.co.kr) and watch the RESERATOR 1 installation
video to facilitate the installation process.
※ Please read this manual thoroughly before installation.
※ The specifications of this product and its components may change without prior notice to improve the performance thereof.
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
2
1. Make sure that the power source’s output voltage and frequency are compatible with
the power input requirements of the water pump before installing. (Input voltage and
frequency of the water pump can be located on the box and sink cover.)
2.Do not place in dusty or humid conditions, under direct sunlight, or near a heat source
such as a room heater.
3. Do not drop or subject to excessive force.
4. Check CPU socket compatibility first.
5. Familiarize yourself with this manual.
6. Do not mix any contaminant with the coolant when filling, for it may cause product
failure.
7. Use of a multiple-outlet power strip is recommended, for you can connect or disconnect
power to the PC and the Reserator 1’s pump simultaneously.
Cautions & Warnings
When Installing
1. Always turn on the water pump first before using the system.
2. If the coolant isn’t circulating or the pump is making a strange noise, turn off the pc
system immediately.
3. Do not place any object on the product.
4. Install on a flat surface with no vibration or slant; do not tilt or lay horizontally.
5. Use distilled or tap water for coolant, regularly check the amount of coolant, and
replenish as needed.
6. If a leak is found, turn off the system immediately and examine the problem before
using the system again.
7. If the system will not be used for an extended period of time, turn off the water pump.
8. When moving the system, separate the reserator from the PC case before moving.
9. Make sure to not let any air bubbles into the Water Block and tubes while in use.
10. Always check that the water pump is properly functioning.
When in Use
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
3
English
Reserator 1 is designed with an optimal heat dissipation area based on Zalman
Tech’s HCET (High Capacity Extrusion Technique) and high efficiency cooling
technology. As a result, this product achieves excellent cooling performance
even with natural convection, making it the world’s first fanless, noiseless watercooling system. The reservoir, radiator, and the water pump are conveniently
integrated into one assembly, and the heatsink is anodized to prevent corrosion
and rust. In addition, the kit includes the high-performance ZM-WB2 Gold water
block which is not susceptible to galvanic corrosion.
1. Features
Contents
Cautions & Warnings
Contents
1. Features
3
2. Specifications
4
3. Installation View
5
4. Components
6
5. Installation
8
6. Installing External Water Pump
14
7. Separate Reserator and Water Block
17
8. FAQ
20
9. Exploded View
21
Zalman Noise Prevention System
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
4
1.1 Reserator (Reservoir + Radiator + Water Pump)
Reserator is a compound word derived from ‘Reservoir’ and
‘Radiator’- it acts as a reservoir while radiating heat. This product
works well with natural convection and integrates a water pump
inside for convenience.
1.2 CPU Water Block(ZM-WB2 Gold)
The system includes Zalman’s new CPU cooling component,
ZM-WB2 Gold, which performs superbly and installs easily.
1.3 Flow Indicator
This component is connected in-line with the circulation tube to
check the circulation of the coolant. When the coolant is actively
circulating, the cap inside the flow indicator shakes rapidly,
providing easy indication of the circulation status.
2.1 Reserator (Reservoir + Radiator + Water Pump)
Dissipation Area : 1.274 ㎡
Weight : 6.5kg
Dimensions : 150(L) x 150(W) x 592(H) mm
Material : Anodized Pure Aluminum
Coolant Capacity : 2.5ℓ Maximum
Integrated Water Pump : 5 W, Qmax 300ℓ/h(A type : 220 V-60 Hz, B type : 230 V-50 Hz,
C type : 120 V-60 Hz, D type : 110 V-60 Hz)
Maximum Lift : 0.5 m
2.2 CPU Water Block(ZM-WB2 Gold)
Weight : 447g
Material : Pure Aluminum Cover, Gold-Plated Pure Copper Base
Dimensions : 64 x 31mm
Compatibility : Intel Pentium 4 (Socket 478), AMD Athlon / Duron / Athlon XP (Socket 462),
AMD AMD64 (Athlon 64 / Athlon 64 FX / Opteron) (Socket 754 / 940)
2. Specifications
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
5
English
3. Installation View
CPU Water Block
(ZM-WB2 Gold)
Universal Fitting
Silicone Tube
Flow Indicator
Reserator
GPU Water Block
(ZM-GWB, Option)
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
6
4. Components
4.1 Reserator 1 Main Assembly 1SET
4.3 Flow Indicator 1EA
4.4 Universal Fitting 2EA
4.5 Silicone Tube 1SET
4.6 Spare parts
Sealing Bolt B 1EA Cable Fitting 1EA
Compression Fitting 1EA O-Ring B 1EA
4. 2 CPU Water Block
(ZM-WB2 Gold) 1SET
Please refer to the separately provided
manual for the ZM-WB2 Gold.
Silicone Tube 1SET
Clamp 4EA
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
7
English
Options
●●
GPU Water Block
Water block for cooling the GPU on a graphics card.
This product is sold separately and available in two
versions for compatibility with ATI Radeon and NVIDIA
GeForce GPUs.
●●
ZM-WB2 Gold
Dual CPU users can buy an additional unit of ZM-WB2
Gold for installation on the second CPU.
●●
Silicone Tube
If the included silicone tube is found to be short or you
need to use the tube on another system, additional
tubes can be bought separately
(base length is 3 m, 12 x 8 mm).
●●
Heatpipe HDD Cooler
This component cools the heat generated from the hard
disk drive and reduces the vibration that is passed on to
the system case.
●●
Power Supply Unit
By implementing heat-sensor circuitry that controls the
cooling fan’s speed in relation to the temperature within
the power supply, emanating noise has been greatly
reduced, making this component suitable for noiseless
systems.
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
8
5. Installation
5.1 Determine the Placement of the Reserator 1
The reserator’s placement should be determined with regard to the connected PC. Place it
upright next to or slightly above the PC. Note that if the Reserator is placed lower than the
PC, the silicone tube’s internal air pressure may prevent proper initial operation.
5.2 Install the CPU Water Block (ZM-WB2 Gold)
1) Refer to the manual included with ZM-WB2 Gold on how to install.
2) ZM-WB2 Gold can be installed on Socket 478, 462, 754, and 940.
3) If a water block from another manufacturer is to be installed, refer to the manual included
with that product on how to install.
4) If interference occurs while installing, stop the installation.
5) Only 13 x 10 mm or 12 x 8 mm silicone tubes can be used with this product.
( X ) ( X ) ( X )
( O )
( O )
Intel Pentium 4
Socket 478 CPU
AMD Athlon/Duron/Athlon XP
Socket 462 CPU
AMD AMD64(Athlon
64/Athlon 64 FX/Opteron)
Socket 754/940 CPU
If a GPU water block is installed, connect the CPU water block’s exit hole with the
GPU water block.
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
9
English
5.3 Connect the CPU Water Block with the Universal Fitting
Use the silicone tubes to connect the CPU water block with the universal fitting. Be careful
with the tubes so that they are not twisted and not too long to interfere with other components.
Slot Hole
CPU Water Block
(ZM-WB2 Gold)
CPU Water Block
(ZM-WB2 Gold)
GPU Water Block
(ZM-GWB, Option)
Universal Fitting
Fitting Cap
Fitting Cap
Slot Hole
Universal Fitting
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
10
5.4 Fasten the Universal Fitting
If you want to drill the holes in the
side of the case for fastening, each
of them should be 16 mm in diameter.
The tube holes should be made at
the same height as the slot holes at
the back of the case.
Universal Fitting
Fitting Nut
Fitting Cap
If the universal fitting is to be fastened on the PCI slot hole in the back of the case, separate
the fitting cap and the fitting nut from the universal fitting. Then, insert the universal fitting into
the PCI slot hole from the inside towards the outside as shown and fasten with fitting nuts.
ф16 Hole
Connecting Fitting and Silicone Tube - The Easy Way
1) Slide the Fitting Cap over the silicone tube
2) Push the silicone tube all the way inside the Fitting socket.
3) Screw on the Fitting Cap until it is completely fastened.
4) Pull the silicone tube slightly with your hands to see if it is loose. Cut about 100 mm
of the silicone tube and use it around the Fitting Cap to fasten the cap easily.
Be careful not to have the silicone tube fold or twist, as scratches and damage may
lead to leaks.
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
11
English
5.5 Connect the Reserator with the Universal Fitting
Using silicone tubes, connect the IN / OUT compressing fittings, the flow indicator, and the
universal fitting as shown above. The flow indicator is used to check the circulation of the
coolant, so it should be placed where it is easily visible.
Note) The flow indicator must be installed in the direction shown.
Fitting Cap
Fitting Socket
IN Compression Fitting
Universal Fitting
Fitting Cap
Flow Indicator
OUT Compression Fitting
IN Compression Fitting OUT Compression Fitting
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
12
5.6 Confirm Correct Installation
5.7 Add Coolant
1) Check that the placement of the product confirms to section 5.1.
2) Confirm that the coolant circulation path is correct, as shown below.
3) Lightly tug the silicone tube connected to each of the Compression Fittings and the
Universal Fitting to check for loose ends.
1) Take off the Reserator’s cover.
2)
Fill the Reserator to 80~90% of its height.
Distilled water is recommended, but
tap water can be used instead.
Reserator 1’s maximum capacity is 2.5
liters. When adding the coolant, make
sure that no contaminant is introduced.
Reserator OUT Flow Indicator
CPU Water Block
Integrated
Water Pump
Reserator
Reserator IN
GPU Water Block
Radiate Heat
Absorb Heat
Sink Cover
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
13
English
5.8 Leakage Inspection and Test Run
1) Turn off the PC’s power completely before starting
leakage inspection.
2) Confirm that the coolant is adequately filled.
It should be filled to about 80~90% of the Reserator’s
capacity.
3) Check each fitting for leaks. If there is a leak,
circuitry and other components may short circuit
and malfunction, so be careful.
4) Only if there is no leak in any of the fittings and the
Fitting Sockets, turn on the water pump. If the
coolant does not circulate properly, turn the pump
on and off repeatedly to eliminate air bubbles.
5) While the pump is turned on, check the circulation
status with the flow indicator. If the coolant is
circulating well, the cap inside the flow indicator
vibrates rapidly.
6) Leave on for an hour and check for leaks.
7) If there are no leaks, turn on the PC’s power and
use the system.
Coolant refers to a circulating fluid that absorbs heat from heat sources such as a CPU
and a GPU, and dissipates it at the radiator. Typically recommended coolant used in a
water cooling system is distilled water, but tap water can also be used. To prevent
galvanic corrosion, special coolants such as antifreeze are sometimes used.
(Zalman’s ZM-WB2 Gold is gold-plated, so galvanic corrosion does not occur.)
What is a Coolant?
80~90%
Compression
Fitting
Cap
OFF ON
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
14
6.
Installing the External Water Pump
If the integrated water pump is broken or you need a water pump of higher capacity, you
can install an external water pump as shown below.
6.1 Separate the Integrated Water Pump
Water Pump
Compression Fitting
Sealing Bolt A
1) Separate the sink base - take off the sink base from
the product as shown.
2) Unscrew the fixing bolts on the water pump -
Separate the fixing plate and the fixing bolts by
unscrewing the fixing bolts on the sink base with a
screwdriver.
3) Detach the water pump power switch - separate the
power switch from the power cable.
4) Take off the Sealing Bolt A - separate the Sealing
Bolt A from the sink base.
Fixing Plate
Fixing Bolt
Water Pump
Sealing Bolt A
Power Switch
Compression Fitting
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
15
English
5) Take out the power cable - pull the
water pump power cable out through
the cable hole.
6)Remove the cable fitting - take the
cable fitting out of the hole as shown
by using a screwdriver or an awl.
7) Remove the integrated water pump pull the water pump off the sink base
as shown.
8)Put on the Sealing Bolt B - after
removing the cable fitting, screw on
the Sealing Bolt B. Fasten until tight. If
this is not done properly it may cause
leakage.
9)Reassemble the sink base - after all
the steps are taken, reattach the sink
base to the main body firmly. Take
proper care in doing this as leakage
may result if not done correctly.
Sealing Bolt A
Water Pump
Compression
Fitting
Cable Fitting
Cable Fitting
Sealing Bolt B
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
16
6.2 Install the External Water Pump
6.3 Cautions on Choosing and Installing an External Water Pump
After determining the placement of the external water pump, check the components that create
a path as shown above. It is recommended that the installation is done in such a manner.
1) When installing an external water pump, confirm the coolant entrance and
exit holes before connection.
2) Check that the chosen water pump’s holes are compatible with the provided silicone tube.
3) Zalman Tech is not responsible for performance degradation or malfunction of a
system that arises from using an external water pump.
CPU Water Block
(ZM-WB2 Gold)
GPU Water Block
(ZM-GWB, Option)
Universal Fitting
Silicone Tube
Flow Indicator
External Water
Pump
Reserator
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
17
English
7.
Separate the Reserator and Water Block
When moving this product to another location, or replacing the coolant or the water block,
separate the Reserator and the water block from the silicone tubes as shown below.
7.1 Moving the Reserator or Changing the Coolant
1) Turn off the PC’s power.
2) Using the tube clamps, as shown
in the diagram, insert the tubes in
to both sides of the Universal Fitting.
If the press clip isn’t properly tightened,
there may be leaks, so make sure
that the silicone tube is placed in
the middle of the clamp.
3) Turn clamp screw until it is tight.
4)Unscrew the Universal Fitting
Caps on the outside of the case
one by one. If you unscrew the
Fitting Socket Caps inside the
case, residual coolant may spill into
the case.
Computer Case
Clamp
Silicone
Tube
Universal Fitting
Silicone
Tube
Clamp
OUTSIDE INSIDE
①
②
③
④
PCI Slot Hole
Clamp
IN Compression
Fitting
OUT Compression Fitting
Clamp
Flow Indicator
Press Clip
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
18
7.2 Replacing the CPU Water Block
5) Move the Reserator or change the
coolant inside.
1) Turn off the PC’s power.
2) Separate the CPU water block from
the mainboard.
Hand Screw
Retention Clip
CPU Water Block
(ZM-WB2 Gold)
Clip Support
Retention Guide
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
19
English
3) To let the residual coolant flow back
to the Reserator, place the CPU
water block higher than the coolant
level of the Reserator.
4) Fasten the Clamp on the entrance
and the exit tubes of the CPU water
block.
5) Unscrew the Fitting Caps from the
CPU water block. Residual coolant
inside the tube and the water block
may flow out, so clean up using a
paper towel or a piece of cloth.
6) Replace the CPU water block.
Clamp
Compression
Fitting
Compression
Fitting Cap
CPU Water Block
(ZM-WB2 Gold)
Clamp
CPU Water Block
(ZM-WB2 Gold)
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
20
8. FAQ
8.1 When the Coolant isn’t Circulating
(1) Check that the water pump is connected to the power.
(2) Verify that the pump is properly functioning. Remove the Reserator’s sink cover and
look inside to see if there is movement in the coolant. If there is none, contact the
distributor where you purchased the product.
(3) Make sure that the Reserator is installed correctly. It must be placed at the same level
as the PC, or slightly higher.
(4) Check if the coolant is flowing in the right direction.
(5) Inspect for any twists or folds in the silicone tubes of the system.
(6) Durning initial operation, the coolant may not properly circulate due to internal air
pressure. In this case, repeatedly turn the water pump on and off at a 10-second
interval and shake the silicone tubes to help get the air bubbles out. Once they are out
of the system the coolant should be circulating properly.
8.2 When There is a Leak at a Compression Fitting or Universal
Fitting Socket
(1) Turn off the system.
(2) Make sure the silicone tube is pushed all the way into the end of the Fitting Socket.
(3) Check to see that the tube is cut cleanly and squarely.
(4) Verify that the Fitting Cap has been screwed all the way into the end of the fitting Socket.
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
21
English
9. Exploded View
Sink Cover
Sink Body
Pump Fixing Bolt
Compression
Fitting
Water Block
Cover
Water Block
Base
Water Pump
Cable Fitting
Sink Base
Stand
Sealing Bolt A
Compression Fitting
Compression
Fitting
Pump Fixing Plate
Reserator
ZM-WB2 Gold
RESERATOR 1
www.zalman.co.kr www.zalmanusa.com
22
Zalman Noise Prevention System
When building a noiseless computer, use Zalman’s Noiseless Power Supply, Northbridge
Cooler, Case Fan, Video Card Cooler, and HDD Cooler to achieve stable performance
and maintain a noiseless environment.
Power Supply
ZM400A-APF
Northbridge Cooler
ZM-NB47J
Noiseless Fan
HDDCooler
ZM-2HC2
VGA Cooler
ZM80C-HP
Loading...
