Yaskawa P7 User Manual

Download

P7 Drive

User Manual

Model: P7U Document Number: TM.P7.01

Quick Reference for P7 Parameters

Parameter

Number

A1-00 0 b5-07 0 E1-07 3 L4-02 2

A1-01 2 b5-08 0 E1-08 18 L4-05 1

A1-03 0 b5-09 0 E1-09 1.5 L4-06 80

A1-04 0 b5-10 1 E1-10 10.8 L5-01 0

A1-05 0 b5-11 0 E1-11 0 L5-02 0

A2-01 b5-12 0 E1-12 0 L5-03 180

A2-02 b5-13 0 E1-13 0 L6-01 6

A2-03 b5-14 1 E2-01 kVA Dep. L6-02 15

A2-04 b5-15 0 E2-03 kVA Dep. L6-03 10

A2-05 b5-16 0 E2-05 kVA Dep. L8-01 0

A2-06 b5-17 0 F6-01 1 L8-02

A2-07 b5-18 0 F6-02 0 L8-03 4

A2-08 b5-19 0 F6-03 1 L8-06

A2-09 b5-20 1 F6-05 0 L8-09 1

A2-10 b 5-21 1 H1-01 24 L 8-10 0

A2-11 b5-22 0 H1-02 14 L8-11 300

A2-12 b5-23 0 H1-03 3 L8-12 45

A2-13 b5-24 0 H1-04 4 L8-15 1

A2-14 b5-25 0 H1-05 6 L8-18 1

A2-15 b5-26 0 H2-01 0 L8-19 20

A2-16 b5-27 60 H2-02 A n1-01 1

A2-17 b 5-28 0 H3-02 100 n1-02 1

A2-18 b5-29 1 H3-03 0 n3-01 5

A2-19 b5-30 0 H3-08 2 n3-02 150

A2-20 b8-01 0 H3-09 2 n3-03 1

A2-21 b8-04 kVA Dep. H3-10 100 n3-04 40

A2-22 b8-05 20 H3-11 0 o1-01 6

A2-23 b8-06 0 H3-12 0.3 o1-02 1

A2-24 C1-01 30 H3-13 0 o1-03 0

A2-25 C1-02 30 H4-01 2 o1-05 3

A2-26 C1-03 30 H4-02 100 o1-06 0

A2-27 C1-04 30 H4-03 0 o1-07 2

A2-28 C1-09 10 H4-04 8 o1-08 3

A2-29 C1-11 0 H4-05 50 o2-01 1

A2-30 C2-01 0.2 H4-06 0 o2-02 1

A2-31 C2-02 0.2 H4-07 0 o2-03 0

A2-32 C4-01 1 H4-08 0 o2-04 kVA Dep.

b1-01 1 C4-02 200 H5-01 1F o2-0 5 1

b1-02 1 C6-01 2 H5-02 3 o2-06 1

b1-03 0 C6-02 kVA Dep. H5-03 0 o2-07 0

b1-04 1 C6-03 kVA Dep. H5-04 3 o2-08 1

b1-07 0 C6-04 kVA Dep. H5-05 1

b1-08 0 C6-05 0 H5-06 5

b1-11 0 d1-01 0 H5-07 1

b1-12 0 d1-02 0 H5-08 0

b2-01 0.5 d1-03 0 H5-09 2

b2-02 50 d1-04 0 L1-01 1

b2-03 0 d1-17 6 L1-02 8

b2-04 0 d2-01 100 L1-03 3

b2-09 0 d2-02 0 L1-04 1

b3-01 2 d2-03 0 L1-05 0.2

b3-02 120 d3-01 0 L2-01 2

b3-03 2 d3-02 0 L2-02 kVA Dep.

b3-05 0.2 d3-03 0 L2-03

b3-14 1 d3-04 1 L2-04

b4-01 0 d4-01 0 L2-05 Voltage Dep.

b4-02 0 d4-02 10 L3-01 1

b5-01 0 E1-01 240V or 480V L3-02 120

b5-02 2 E1-03 F L3-04 1

b5-03 5 E1-04 60 L3-05 1

b5-04 100 E1-05 240V or 480V L3-06 120

b5-06 100 E1-06 60 L4-01 0

Factory Setting

User

Setting

Parameter

Number

Factory

Setting

User

Setting

Parameter

Number

Factory

Setting

kVA Dep.

User

Setting

Parameter

Number

o2-10 0

o2-12 0

o2-14 0

o2-15 1

o3-01 0

o3-02 0

T1-02 kVA Dep.

T1-04 kVA Dep.

Factory Setting

kVA Dep.

User

Setting

Warnings and Cautions

This Section provides warnings and cautions pertinent to this product, that if not heeded, may result in personal injury, fatality, or equipment damage. Yaskawa is not responsible for consequences of ignoring these instructions.

WARNING

YASKAWA manufactures component parts that can be used in a wide variety of industrial applications. The selection and application of YASKAWA products remain the responsibility of the equipment designer or end user. YASKAWA accepts no responsibility for the way its products are incorporated into the final system design. Under no circumstances should any YASKAWA product be incorporated into any product or design as the exclusive or sole safety control. Without exception, all controls should be designed to detect faults dynamically and fail safely under all circumstances. All products designed to incorporate a component part manufactured by YASKAWA must be supplied to the end user with appropriate warnings and instructions as to that part’s safe use and operation. Any warnings provided by YASKAWA must be promptly provided to the end user. YASKAWA offers an express warranty only as to the quality of its products in conforming to standards and specifications published in the YASKAWA manual. NO OTHER WARRANTY, EXPR ESS OR IMPLIED, IS OFFERED. YASKAWA assumes no liability for any personal injury, property damage, losses, or claims arising from misapplication of its products.

WARNING

• Read and understand this manual before installing, operating, or servicing this Drive. All warnings, cautions, and

instructions must be followed. All activity must be performed by qualified personnel. The Drive must be installed according to this manual and local codes.

• Do not connect or disconnect wiring while the po we r is on. Do not remov e covers or tou ch ci rcuit boar ds while the po w er is

on. Do not remove or insert the digital operator while power is on.

• Before servicing, disconnect all power to the equipment. The internal capacitor remains charged even after the power supply

is turned off. Status indicator LEDs and Digital Operator display will be extinguished when the DC bus voltage is below 50 VDC. To prevent electric shock, wait at least five minutes after all indicators are OFF and measure DC bus voltage level to confirm safe level.

• Do not perform a withstand voltage test on any part of the unit. This equipment uses sensitive devices and may be damaged

by high voltage.

• The Drive is not suitable for circuits capable of delivering more than the specified RMS symmetrical amperes. Install

adequate branch short circuit protection per applicable codes. Refer to t he specification. Failure to do so may result in equipment damage and/or personal injury.

• Do not connect unapproved LC or RC interference suppression filters, capacitors, or overvoltage protection devices to the

output of the Drive. These devices may generate peak currents that exceed Drive specifications.

• To avoid unnecessary fault displays caused by contactors or output switches placed between Drive and motor, auxiliary

contacts must be properly integrated into the control logic circuit.

• YASKAWA is not res ponsible for any modification of the product made by the user ; doing so will void the warran ty. This

product must not be modified.

• Verify that the rated voltage of the Drive matches the voltage of the incoming power supply before applying power.

• To meet CE directives, proper line filters and proper installation are required.

Warnings i

WARNING

• Some drawin gs in this manual may be shown with protective cover s or shields removed, to describe details . These must be

replaced before operation.

• Observe electrostatic discharge procedures when handling circui t cards to prevent ESD damage.

• The equipment may start unexpectedly upon application of power. Clear all personnel from the drive, motor, and machine

area before applying power. Secure covers, couplings, shaft keys, and machine loads before energizing the Drive.

• Please do not connect or operate any equipment with visible damage or missing p arts. The ope rating company is respo nsible

for any injuries or equipment damage resulting from failure to heed the warnings in this manual.

 Intended Use

Drives are intended for installation in electrical systems or machinery. For use in the European Union, the installation in machinery and systems must conform to the following product standards of

the Low Voltage Directive: EN 50178, 1997-10, Equipping of Power Systems with Electronic Devices EN 60201-1, 1997-12 Machine Safety and Equipping with Electrical Devices

Part 1: General Requirements (IEC 60204-1:1997)/ EN 61010, 1997-11Safety Requirements for Information Technology Equipment (IEC 950:1991 + A1:1992 + A2:1993 + A3:1995 + A4:1996, modified)

CE certification per EN 50178 can be achieved using the line filters specified in this manual and following the appropriate installation instructions.

Other

The Drive is suitable for use on a circu it capab le of deliv ering not more than 100,000 RMS symmetrical am peres , 240Vac m aximum (240V Class) and 480Vac maximum (480V Class).

Warnings ii

Introduction

This Section describes the applicability of the Manual

The P7 Drive is a Pulse Width Modulated Drive for 3-Phase AC induction motors. This type of Drive is also known as an Adjustable Frequency Drive, Variable Frequency Drive, AC Drive, AFD, ASD, VFD, and Inverter. In this manual, the P7 Drive will be referred to as the “Drive”.

The Drive is a variable torque AC drive, designed specifically for HVAC applications in building automation, including fans, blowers and pumps. A new benchmark for size, cost, performance, benefits, and quality, the Drive includes numerous built-in features such as network communications, PI, parameter storage and copy functions.

The Drive has embedded communications for Modbus

The LCD keypad/operator is equipped with local/remote functions, copy feature, 7 language choices, and 5 lines of display with 16 characters per line. User parameter settings can be recovered at any time via “user initialization”. Optional software allows uplo ad/downlo ad, as well as graphing and monitoring of drive parameters from a PC for ease of drive management.

Built-in PI control eliminates the need for closed loop output signals from a building automation system. It includes feedback display, inverse, square root and differential control functions, and maintains setpoint for closed loop control of fans and pumps for pressure, flow, or temperature regulation.

This manual is applicable to Drives defined by model numbers CIMR-P7U_ _ _ _ . This manual reflects the Software Version 1020.

This manual is subject to change as product improvements occur. The latest version of the manual can be obtained from the Yaskawa website www.drives.com

. The date shown on the rear cover is changed when revisions are made.

protocol. An optional LONWOR KS® interface card is also available.

Introduction iii

This manual may describe trademarked equipment, which is the property of other companies. These trademarks are the property of the registered owner companies and may include the following:

Modbus L

, trademark of Schneider Automation, Inc.

ONWORKS

, trademark of Echelon Corporation

Other Documents and Manuals are available to support special use or installation of this product. These documents may be provided with the product or upon request. Contact Yaskawa Electric America, Inc. as required. Documents may include the following:

TM.P7.02.Programming… Manual included on CD ROM with product TM.AFD.11.Modbus… Manual included on CD ROM with product TM.AFD.20.L

ONWORKS… Manual included on CD ROM with product

TM.P7B.01. Bypass… This manual should be used when the Drive is packaged with Bypass Control DriveWizard ... Software and Manual…Included on CD ROM with product Option Instructions… Included on CD ROM with product

Introduction iv

Table of Contents

Quick Reference Parameter List ....................................................... Inside front cover

Warnings and Cautions................................................................................................ i

Introduction .................................................................................................................iii

Chapter 1- Physical Installation ................................................................................1-1

Model Number and Enclosure Style.........................................................................1-2

Confirmations Upon Delivery ...................................................................................1-3

Component Names ..................................................................................................1-5

Exterior and Mounting Dimensions ..........................................................................1-7

Heat Loss Data ...................................................................................................... 1-11

Checking and Controlling the Installation Site........................................................ 1-13

Installation Orientation and Clearances .................................................................1-14

Removing and Attaching the Terminal Cover.........................................................1-15

Removing/Attaching the Digital Operator and Front Cover....................................1-16

Chapter 2- Electrical Installation...............................................................................2-1

Terminal Block Configuration ...................................................................................2-2

Wiring Main Circuit Terminals...................................................................................2-3

Control Wiring ........................................................................................................2-21

Chapter 3- Digital Operator........................................................................................3-1

Digital Operator Display ........................................................................................... 3-2

Digital Operator Keys ...............................................................................................3-3

Drive Mode Indicators..............................................................................................3-4

Drive Main Menu ...................................................................................................... 3-6

Quick Setting Menu (-QUICK-)............................................................................... 3-11

Programming Menu (-ADV-)...................................................................................3-12

Example of Changing a Parameter........................................................................3-14

Table of Contents v

Chapter 4- Start Up.....................................................................................................4-1

Drive Start Up Preparation ....................................................................................... 4-2

Drive Start Up Procedures ....................................................................................... 4-5

Chapter 5- Basic Programming................................................................................. 5-1

A1 Initialization ......................................................................................................... 5-2

b1 Sequence............................................................................................................ 5-4

b2 DC Braking.......................................................................................................... 5-9

b3 Speed Search ................................................................................................... 5-11

b5 PI Function........................................................................................................ 5-15

b8 Energy Savings ................................................................................................. 5-24

C1 Accel/Decel....................................................................................................... 5-25

d2 Reference (Speed Command) Limits................................................................ 5-26

d3 Jump Frequencies............................................................................................. 5-27

E1 V/f pattern ......................................................................................................... 5-28

E2 Motor Setup ...................................................................................................... 5-31

F6 Com OPT Selection .......................................................................................... 5-32

H3 Analog Inputs....................................................................................................5-33

L2 Momentary Power Loss Ride-thru Function ...................................................... 5-39

L3 Stall Prevention ................................................................................................. 5-40

L4 Speed Command Loss Detection...................................................................... 5-43

L5 Fault Restart......................................................................................................5-44

L6 Torque Detection............................................................................................... 5-46

L8 Hardware Protection ......................................................................................... 5-48

o1 Monitor Configuration........................................................................................ 5-50

o2 Key Selections .................................................................................................. 5-54

o3 Digital Operator Copy Function.........................................................................5-56

T1 Auto-Tuning ...................................................................................................... 5-59

Table of Contents vi

Chapter 6- Diagnostic & Troubleshooting .............................................................. 6-1

Fault Detection ......................................................................................................... 6-2

Alarm Detection........................................................................................................ 6-8

Operator Programming Errors (OPE)..................................................................... 6-11

Auto-Tuning Faults.................................................................................................6-12

Digital Operator COPY Function Faults .................................................................6-13

Troubleshooting .....................................................................................................6-14

Main Circuit Test Procedure...................................................................................6-20

Drive Date Stamp Information ................................................................................ 6-24

Chapter 7- Maintenance ............................................................................................. 7-1

Periodic Inspection................................................................................................... 7-2

Preventative Maintenance........................................................................................ 7-3

Heatsink Cooling Fan Replacement.........................................................................7-4

Removing and Mounting the Terminal Card............................................................. 7-6

Appendix A - Parameters.......................................................................................... A-1

Parameter List..........................................................................................................A-2

Monitor List.............................................................................................................A-25

Fault Trace List ......................................................................................................A-27

Fault Trace History .................................................................................................A-28

Appendix B - Capacity Related Parameters............................................................ B-1

Drive Capacity Selection ..........................................................................................B-2

Parameters Affected by o-04 ...................................................................................B-3

Appendix C - Specifications ..................................................................................... C-1

Standard Drive Specification ................................................................................... C-2

Table of Contents vii

Appendix D - Communications ................................................................................ D-1

Using Modbus Communication ............................................................................... D-2

Modbus Function Code Details ............................................................................... D-7

Modbus Data Tables ............................................................................................... D-9

Modbus Self- Diagnosis ........................................................................................ D-14

Appendix E - Peripheral Devices ............................................................................. E-1

Branch Circuit Short Circuit Protection.....................................................................E-2

Branch Circuit Overload Protection..........................................................................E-5

Peripheral Devices...................................................................................................E-6

Appendix F - EMC Compatibility ...............................................................................F-1

EMC Compatibility....................................................................................................F-2

Electromagnetic Compatibility (EMC) ......................................................................F-3

Index .................................................................................................................... Index-1

Support Services ................................................................................ Inside rear cover

Table of Contents viii

Chapter 1

Physical Installation

This chapter describes the requirements for receiving and installing the Drive.

Model Number and Enclosure Style ....................................1-2

Confirmations upon Delivery ...............................................1-3

Component Names..............................................................1-5

Exterior and Mounting Dimensions......................................1-7

Heat Loss Data..................................................................1-11

Checking and Controlling the Installation Site ...................1-13

Installation Orientation and Clearances.............................1-14

Removing and Attaching the Terminal Cover ....................1-15

Removing/Attaching the Digital Operator

and Front Cover.................................................................1-16

Physical Installation 1 - 1

Model Number and Enclosure Style

Table 1.1 Model Numbers and Enclosure Style

Input

Volta ge

3-Phase

208-240Vac

208-230Vac

480 Vac

Model-Number Enclosure Style

CIMR-P7U20P4 NEMA Type 1 (IP20) 3.6 0.5/0.75 CIMR-P7U20P7 NEMA Type 1 (IP20) 4.6 1 CIMR-P7U21P5 NEMA Type 1 (IP20) 7.8 1.5/2 CIMR-P7U22P2 NEMA Type 1 (IP20) 10.8 3 CIMR-P7U23P7 NEMA Type 1 (IP20) 16.8 5 CIMR-P7U25P5 NEMA Type 1 (IP20) 23.0 7.5 CIMR-P7U27P5 NEMA Type 1 (IP20) 31.0 7.5/10 CIMR-P7U2011 NEMA Type 1 (IP20) 46.2 15 CIMR-P7U2015 NEMA Type 1 (IP20) 59.4 20 CIMR-P7U2018 NEMA Type 1 (IP20) 74.8 25 CIMR-P7U2022 NEMA Type 1 (IP20) 88.0 30 CIMR-P7U2030 NEMA Type 1 (IP20) 115.0 40 CIMR-P7U2037 Open Chassis (IP00) 162.0 50/60 CIMR-P7U2045 Open Chassis (IP00) 192.0 60/75 CIMR-P7U2055 Open Chassis (IP00) 215.0 75 CIMR-P7U2075 Open Chassis (IP00) 312.0 100/125 CIMR-P7U2090 Open Chassis (IP00) 360.0 125/150 CIMR-P7U2110 Open Chassis (IP00) 415.0 150 CIMR-P7U40P4 NEMA Type 1 (IP20) 1.8 0.5/0.75 CIMR-P7U40P7 NEMA Type 1 (IP20) 2.1 1 CIMR-P7U41P5 NEMA Type 1 (IP20) 3.7 1.5/2 CIMR-P7U42P2 NEMA Type 1 (IP20) 5.3 3 CIMR-P7U43P7 NEMA Type 1 (IP20) 7.6 5 CIMR-P7U45P5 NEMA Type 1 (IP20) 12.5 7.5 CIMR-P7U47P5 NEMA Type 1 (IP20) 17.0 10 CIMR-P7U49P0 NEMA Type 1 (IP20) 21.0 15 CIMR-P7U4011 NEMA Type 1 (IP20) 27.0 20 CIMR-P7U4015 NEMA Type 1 (IP20) 34.0 25 CIMR-P7U4018 NEMA Type 1 (IP20) 40.0 30 CIMR-P7U4024 NEMA Type 1 (IP20) 52.0 40 CIMR-P7U4030 NEMA Type 1 (IP20) 67.2 50 CIMR-P7U4037 NEMA Type 1 (IP20) 77.0 60 CIMR-P7U4045 NEMA Type 1 (IP20) 96.0 75 CIMR-P7U4055 NEMA Type 1 (IP20) 125.0 100 CIMR-P7U4075 Open Chassis (IP00) 156.0 125 CIMR-P7U4090 Open Chassis (IP00) 180.0 150 CIMR-P7U4110 Open Chassis (IP00) 240.0 200 CIMR-P7U4160 Open Chassis (IP00) 304.0 250 CIMR-P7U4185 Open Chassis (IP00) 414.0 300/350 CIMR-P7U4220 Open Chassis (IP00) 515.0 400/450 CIMR-P7U4300 Open Chassis (IP00) 675.0 500+

Rated

Output

Current

Nominal

Physical Installation 1 - 2

Confirmations upon Delivery

 Receiving Checks

Check the following items as soon as the Drive is received.

Table 1.2 Receiving Checks

Item Method

Has the correct model of Drive been delivered?

Check the model number on the nameplate on the right side of the D rive. Reconcile with packing slip and/or order informatio n.

Is the Drive damaged in any way?

Are any screws or other components loose?

If there are any irregularities in the above items, contact the shipping company, the distributor or representative who sold the Drive, or a Yaskawa office immediately.

The P7 is thoroughly tested at the factory. Any damages or shortages evident when the equipment is received must be reported immediately to the commercial carrier that transported the material. Shipping damage is not cover ed b y th e Yaskawa warranty. After unpacking and inspecting for damag e, verify that int ernal wire connect ions have not come loose durin g shipment by spot checking wire terminations with a screwdriver or the appropriate tool.

P7 Drive storage must be in a clean and dry location. Maintain the factory packaging and provide covering as needed to protect the P7 from construction site dirt, water, debris and traffic prior to and during construction.

Inspect the entire exterior of the Drive to see if there are any dents, scratc hes or other damage resulting from shipping.

Use a screwdriver or other tool to check for tightness.

 Nameplate Information

A nameplate is attached to the right side of each Drive. The following nameplate is an example for a standard Drive.

ote: The Drive Model Number and Drive Spec Number are required to completel y identify a Drive.

Fig 1.1 Drive Nameplate

Physical Installation 1 - 3

 Drive Model Numbers

The model number on the nameplate indicates the design specification, voltage, and rating of the Drive in alphanumeric codes.

CIMR – P7 U 2 0 11

AC Drive

P7 Family

No.

Spec

UL Specification

Rating

No.

Voltage

3-phase, 208-240Vac

3-phase, 480Vac

Fig 1.2 Drive Model Number Structure

 Drive Enclosure and Revision Code

The Drive SPEC number on the nameplate indicates the voltage, Drive rating, enclosure type, and the revision code of the Drive in alphanumeric codes.

011 1 A

No.

2 4

Voltage

3-phase, 208 - 240Vac

3-phase, 480Vac

Rating

Hardware Revision

No.

0 Open chassis (IEC IP00)

Enclosure Type

NEMA Type 1 (IEC IP20)

TERMS

Fig 1.3 SPEC Number Structure

Open Chassis Type (IEC IP00)

Protected so that parts of the human body cannot reach electrically charged parts from the front when the Drive is mounted in a control panel, also called (protected chassis).

NEMA Type 1 (IEC IP20)

The Drive is shielded from the exterior, and can thus be mounted to the interior wall of a building (not necessarily enclosed in a control panel). The protective structure conforms to the standards of NEMA Type 1 in the USA. All protective covers (Fig 1.4) must be installed to conform with IEC IP20 and NEMA Type 1 requirements.

Physical Installation 1 - 4

Component Names

 Models CIMR-P7U20P4 thru 2018 (25HP @ 208V/240V) and 40P4 thru 4018

(30HP @ 480V)

The external appearance, component names, and terminal arrangement of the Drive are shown in Fig 1.4. and 1.5.

Top protective cover

Front cover

Digital Operator

Terminal cover

Mounting hole

Diecast Heat Sink

Nameplate

Bottom protective cover

Fig 1.4 Drive Appearance

Fig 1.5 Terminal Arrangement (Terminal Cover Removed)

Physical Installation 1 - 5

 Models CIMR-P7U2022 thru 2110 (30HP and above @ 208V/240V) and 4030 thru

4300 (40HP and above @ 480V)

The external appearance, component names, and terminal arrangement of the Drive are shown in Fig 1.6 and 1.7.

Mounting holes

Drive cover

Cooling fan

Front cover

Digital Operator

Terminal cover

Fig 1.6 Drive Appearance

Cooling fan

Nameplate

Control circuit

terminals

Main circuit terminals

Ground terminal

Fig 1.7 Terminal Arrangement (Terminal Cover Removed)

Charge indicator

Ground terminal

Physical Installation 1 - 6

Exterior and Mounting Dimensions

DIMENSIONS: P7 (NEMA 1)

208/240V (3.6-74.8 AMPS) 480V (1.8- 40.0 AMPS)

FRONT VIEW

MOUNTING HO LES

RATED INPUT

208V

240V

480V

CIMR-P7U

FOR "A" SIZE SCREW

MODEL

20P41

20P71

21P51

22P21

23P71

27P51

20111

20151

20181

20P41

20P71

21P51

22P21

23P71

25P51

27P51

20111

20151

20181

40P41

40P71 2.1

41P51

42P21

43P71

45P51

49P01

40111

40151

RATED

OUTPUT

CURRENT

(AMPS)

3.6

4.6

7.8

10.8

31.0

46.2

59.4

74.8 13.19

3.6

4.6

7.8

10.8

16.8

23.0

31.0

46.2

59.4

74.8

3.7

5.3

7.6

12.5

21.0

27.0

34.0

40.0 40181

1.8

NOMINAL

1/2 3/4

7.5-10

1/2 3/4

7.5

1/2 3/4 -

7.5

10 17.0 47P51

FOR REFERENCE ONLY UNLESS PROPERLY ENDORSED.

IN ORDER TO ACHIEVE ADEQUATE COOL ING THE DRIVE MUST BE POSITIONED TO ALLOW A MINIMUM OF FREE AIR SPACE OF 1.2 INCHES ON SIDES AND 5 INCHES TOP AND BOTTOM

SIDE VIEW

AIR

DIMENSIONS IN INCHES

MOUNTING

H1 W1

4.96

10.47

4.96

10.47

4.96

10.47

4.96

10.47

4.96 10.47

7.32

11.22

7.32

11.22

8.50

13.19

8.50 14.96 9.45 .30

4.96

10.47

4.96

10.47

4.96

10.47

4.96

10.47

4.96

10.47

4.96

10.47

7.32

11.22

7.32

11.22

8.50

13.19

13.19 8.50 14.96 9.45 .301/4 .47 8.27

4.96

10.47

4.96

10.47

4.96

10.47

4.96

10.47

4.96

10.47

4.96

10.47

11.22 7.327.87 11.81.28

7.32

11.22

13.19

8.50 9.45

13.19 8.50

11.02 5.51

11.02

7.87

11.81

7.87

12.20

9.45

13.78

11.02

5.51

11.02

7.87

11.81

7.87

12.20

9.45

13.78

11.02

11.02 5.51

11.02

5.51

11.817.87

13.78

9.45 13.78

W HH2

5.51

.28

.30

.28

.30

.28

.30

6.30

.28

6.30

.28

6.30

.28

6.30

.28 .28 5.51 11.02 16.8

.28

7.87

.28

7.87

.47

8.27

.28

6.30

.28

6.30

.28

6.30

.28

6.30

.28

7.09

.28

7.09

.28

7.87

.28

7.87

.47

8.27

.28

6.30

.28

6.30

.28

6.30

.28

7.09

.28

7.09

.28

.28 7.87 1/44.63 6.21 3.07 1.

.28 7.871/44.63

7.87

.28

.47

8.27

.47

8.27

1.38 DIA.

(2) HOLES SIZE "J"

.87 DIA.

BOTTOM VIEW

APPROX. WEIGHT

1.10

1.38

1.73

1.73 24.2

1.10

1.38

1.73

1.10

1.10 6.6

1.10

38 13.2

1.38 13.2

1.73

9.29.04

(LBS.)

6.6

13.2

15.4

24.2

6.6

8.8

13.2

15.4

24.2

6.6

8.8

D1 B A DCE

1.54

2.32

2.58

3.07

1.54

2.32

2.58

3.07

1.54

2.32

2.58

3.07

---

#10

---

#10

---

#10

---

#10

---

4.63

1/4

4.63

1/4

5.12 .47 3.94 5.79 8.27

#10

---

#10

---

#10

---

#10

---

#10

---

#10

---

1/4

4.63

1/4

4.63

1/4

5.12

---

#10

---

#10

---

#10

---

#10

---

#10

---

1/4

4.63

1/4

5.12 6.65

1/4

5.12

3.35

5.11

5.79

3.35

4.14

5.11

5.79

3.35

4.14

5.11

5.11 11.22 7.327.87 11.81.28

5.11

5.79

DR BY APPVL.

1.97

4.73

1.97

4.73

1.97

4.73

1.97

4.73

5.52 #10 1.10 4.14 1.97 7.09 8.8

3.07

6.21

3.07

6.65

3.94

6.65

4.73

1.97

4.73

1.97

4.73

1.97

4.73

1.97

5.52

1.97

5.52

1.97

6.21

3.07

6.21

3.07

6.65

3.94

6.65

3.94

4.73

1.97

4.73

1.97

4.73

1.97

5.52

1.97

5.52

6.21

3.07 1.38 13.2

6.21

3.07

3.94

6.65

3.94

RIP 9.29.04

Physical Installation 1 - 7

DIMENSIONS: P7 (NEMA 1)

208/240V (88.0-115 AMPS) 480V (52.0-125 AMPS)

CURRENT

Physical Installation 1 - 8

APPROX. WEIGHT

(LBS.)

DIMENSIONS: P7 (PROTECTED CHASSIS)

FRONT VIEW

MOUNTING HO LES FOR "A" SIZE SCREW

208-230V (162-415 AMPS) 480V (156-304 AMPS)

AIR

FOR REFERENCE ONLY UNLESS PROPERLY ENDORSED.

IN ORDER TO ACHIEVE ADEQUATE COOLING THE DRIVE MUST BE POSITIONED TO ALLOW A MINIMUM OF FREE AIR SPACE OF 1.2 I NCHES ON SID ES AND 5 INCHES TOP AND BOTTOM

RATED INPUT

208V

230V

480V

MODEL

CIMR-P7U

20370

20450

20550

20750

20900

21100

20370

20450

20750

20900

40900

41100

41600

RATED OUTPUT CURRENT

(AMPS)

162

215

312

360

415

162

192

360

156 40750

180

240

304

AIR

NOM.

MOUNTING

H1 W1

22.64

22.64 60

27.56

32.28

125

33.66

150

50-60

22.64 23.62 9.84 14. 76 .49 125 3.94 11.81 2.46 3/8

22.64 23.62 9.84 14. 76 .49 139 5.12 12.99 2.46 3/8

100-125 312

27.56 28.54 12. 80 17.72 .49 191 5.12 13.78 2.46 3/8

150

32.2833.46 14. 57 19.69 .59 238 5.12 14.17 2.56 3/

27.56

125

27.56

150

32.28

200

33.66

250

DIMENSIONS IN INCHES

HWH2W2D

9.84

12.80

14.57

17.52

12.80

14.57

17.52

23.62

28.54

33.46

34.84

28.54

33.46

36.06

14.76

.49

14.76

.49

17.72

.49

19.69

.59 2.56

22.64 . 59

17.72

.49

17.72

.49 196

19.69

.59

22.64

.59

2.46

12.99 192

2.46

13.78

2.46 17.72 .49 12.80 27.56 28.54 100

2.56

14.96

13.78

2.46

13.78

2.46 3/8

14.17

2.56

14.96

2.56

DR BY APPVL.

11.81

14.17

RIP 9.29.04 TA 9.29.04

D1 A

3.94

5.12

5.51

5.12

5.51

APPROX. WEIGHT

(LBS.)

125

3/8

139

3/8

189

3/8

191

3/8

238

3/8

330

3/8

194

3/8

224

3/8

352

3/8

Physical Installation 1 - 9

DIMENSIONS: P7 (PROTECTED CHASSIS)

MOUNTING HOLES FOR "A" SIZE SCREWS

AIR

RATED INPUT

480V

CURRENT

CIMR-P7U

(AMPS)

414 41850

42200

43000 58.07

300-350

675

RATED

OUTPUT

MODEL

FOR REFERENCE ONLY UNLESS PROPERLY ENDORSED.

IN ORDER TO ACHIEVE ADEQUATE COOLING THE DRIVE MUST BE POSITIONED TO ALLOW A MINIMUM OF FREE AIR OF 1.2 INCHES ON SIDES AND 5 INCHES TOP AND BOTTOM

NOM.

500

MOUNTING

H1 W 1

50.00

50.00 400-450

56.70

HWH2W2D

51.38

10.63

14.37

51.38

27.95

36.06

.79

DIMENSIONS IN INCHES

16.34

3.35

16.34 515

3.35

16.34

3.66

D1 A

4.94

AIR

APPROX. WEIGHT

(LBS.)

3/8

572

3/8

616

3/8

891

RIP 8-02

DR BY

TBS 9.5.02

APPVL.

Physical Installation 1 - 10

Heat Loss Data

TYPE

CIMR-P7U

20P4 1.4 3.6 19 39 58 Self 20P7 1.8 4.6 26 42 68 Self 21P5 3.0 7.8 48 50 98 Self 22P2 4.1 10.8 68 59 127 Self 23P7 6.4 16.8 110 74 184 Fan 25P5 8.8 23 164 84 248 Fan 27P5 12 31 219 113 332 Fan

2011 18 46.2 357 168 524 Fan 2015 23 59.4 416 182 597 Fan 2018 29 74.8 472 208 680 Fan 2022 34 88 583 252 835 Fan 2030 44 115 883 333 1217 Fan 2037 62 162 1010 421 1430 Fan 2045 73 192 1228 499 1727 Fan 2055 82 215 1588 619 2206 Fan 2075 120 312 1956 844 2800 Fan 2090 140 360 2194 964 3157 Fan

2110 160 415 2733 1234 3967 Fan

Table 1.3 200V Class Heat Loss Data

Drive (Inverter) Capacity

(kVA)

Rated

Output

Current

(A)

Cooling

Fin Side

(W)

Internal

Unit Side

(W)

Total

Watt Loss

(W)

Cooling Method

Physical Installation 1 - 11

Table 1.4 400V Class Heat Loss Data

TYPE

CIMR-P7U

40P4 1.4 1.8 14 39 53 Self 40P7 1.6 2.1 17 41 58 Self 41P5 2.8 3.7 36 48 84 Self 42P2 4.0 5.3 59 56 115 Fan 43P7 5.8 7.6 80 68 140 Fan 44P0 6.6 8.7 90 70 160 Fan 45P5 9.5 12.5 127 81 209 Fan 47P5 13 17 193 114 307 Fan 49P0 16 21 232 158 390 Fan

4011 21 27 232 158 390 Fan 4015 26 34 296 169 465 Fan 4018 30 40 389 201 590 Fan 4022 38 50.4 420 233 653 Fan 4024 40 52 691 297 989 Fan 4030 51 67.2 691 297 989 Fan 4037 59 77 801 332 1133 Fan 4045 73 96 901 386 1287 Fan 4055 95 125 1204 478 1682 Fan 4075 120 156 1285 562 1847 Fan 4090 140 180 1614 673 2287 Fan 4110 180 240 1889 847 2736 Fan 4132 200 260 2388 1005 3393 Fan 4160 230 304 2636 1144 3936 Fan 4185 315 414 2791 1328 3964 Fan 4220 390 515 3797 1712 5509 Fan 4300 510 675 5838 2482 8319 Fan

Drive (Inverter)

Capacity

(kVA)

Rated

Output

Current

(A)

Cooling

Fin Side

(W)

Internal

Unit Side

(W)

Total

Watt Loss

(W)

Cooling Method

Physical Installation 1 - 12

Checking and Controlling the Installation Site

Install the Drive as described below and maintain optimum conditions.

WARNING

The Drive heatsink temperature may exceed 158°F (70°C). Therefore, mount the Drive to a surface suitable for high temperature.

 Installation Site

Locate the P7 Drive as close as possible to the motor. Install the Drive under the following conditions in UL Poll ution Degree 1 & 2 environments. This excludes wet locations

where surfaces may become conductive due to moisture and contaminant loading.

Table 1.5 Installation Site Specifications

Type Ambient Operating Temperature Humidity Plenum Rated

NEMA Type 1 14° F -to- 104°F ( - 1 0 -to- + 40 °C) 95%-RH-or-less-(no-condensation) Yes

Open Chassis 14° F -to- 113°F ( - 1 0 - to -+ 45 °C ) 9 5 % -RH-or-less-(no-condensation) No

Protective covers are attached to the top and bottom of the Drive. It is recommended to remove the protective covers before operating a CIMR-P7U2030/4055 Drive and smaller in a panel to obtain the 113°F (45°C) ambient operating temperature.

Observe the following precautions when installing the Drive:

• in a clean location which is free from oil mist and dust.

• in an environment where metal shavings, oil, water, or other foreign materials will not get into the Drive enclosure.

• in a location free from radioactive materials.

• in a location free from harmful gasses and liquids.

• in a location free from excessive vibration.

• in a location free from chlorides.

• in a location away from direct sunlight.

• on a non-combustible surface.

Controlling the Ambient Temperature

To enhance the reliability of operation, the Drive should be installed in an environment free from extreme temperature variations. If the Drive is installed in an enclosu r e, us e a cooling fan or air conditioner to maint ain the internal air temperature below 113°

F (45°C).

 Protecting the Drive from Foreign Matter

During Drive installation and project construction it is possible to have foreign matter, such as metal shavings or wire clippings, fall inside the Drive. To prevent foreign matter from falling into the Drive, place a temporary cover over the Drive.

Always remove the temporary cover from the Drive before Start-Up. Otherwise, ventilation will be reduced, causing the Drive to overheat.

Physical Installation 1 - 13

Installation Orientation and Clearances

Install the Drive vertically so as not to reduce the cooling efficiency. When installing the Drive, always provide the following installation clearances to allow normal heat dissipation. Ensure that the heatsink is against a closed surface to avoid diverting cooling air around the heatsink.

4.75 in (120 mm. minimum)

1.2 in

(30.5 MM.) min.

1.2 in

(30.5 mm. minimum)

4.75 in (50 mm. minimum)

1.2 in

(30.5 mm. minimum)

4.75 in (120 mm. minimum) Air

Vertical ClearanceHorizontal Clearance

IMPORTANT

Fig 1.8 Drive Installation Orientation and Clearance

1. The same clearance is required horizontally and vertically for both Open Chassis (IP00) and NEMA Type 1 Drives.

2. Always remove the top and bottom protection covers before installing a CIMR-P7U2018/4018 and smaller Drive in a panel. Always provide enough clearance for lifting eye bolts and the main circuit wiring when installing a CIMR-P7U2022/4030 and larger Drive in a panel.

Physical Installation 1 - 14

Removing and Attaching the Terminal Cover

Remove the terminal cover to connect cables to the control circuit and main circuit terminals.

Prior to removing any protective cover or wiring any part of the Drive, remove all power sources, including

WARNING

 Removing the Terminal Cover

 Models CIMR-P7U20P4 thru 2018 (0.5HP to 25HP @ 208V/240V) and 40P4 thru 4018

(0.5HP to 30HP @ 480V)

Loosen the screw at the bottom of the terminal cover, press in on the sides of the terminal cover in the directions of arrow 1, and then lift up on the terminal in the direction of arrow 2. Refer to Figure 1.9

 Models CIMR-P7U2022 thru 2110 (30HP to 150HP @ 208V/240V) and 4030 thru 4300

(40HP to 500HP @ 480V)

Loosen the screws on the left and right at the top of the terminal cover, pull down the terminal cover in the direction of arrow 1 and then lift up on the terminal cover in the direction of arrow 2. Refer to Figure 1.10

main input power and control circuit power. Wait a minimum of 5 minutes after power removal, before removing any cover. The charge lamp located within the Drive should be off prior to working inside. Even if the charge lamp is off, one must measure the AC input, output, and DC Bus potential to insure safe levels prior to resuming work. Failure to adhere to this warning may result in personal injury or death.

Fig 1.9 Removing the Terminal Cover

Fig 1.10 Removing the Terminal Cover

 Attaching the Terminal Cover

After wiring the terminal block, attach the terminal cover by reversing the removal procedure. For Models CIMR-P7U2018/4018 and smaller, insert the tab on the top of the terminal cover into the groove on the Drive and

press in on the bottom of the terminal cover until it snaps into place. For Drives CIMR-P7U2022/4030 and larger, insert the tab on the top of the terminal cover into the groove on the Drive, and

secure the terminal cover by lifting it up toward the top of the Drive.

Physical Installation 1 - 15

Removing/Attaching the Digital Operator and Front Cover

 Models CIMR-P7U20P4 thru 2018 (0.5HP to 25HP @ 208V/240V) and 40P4 thru

4018 (0.5HP to 30HP @ 480V)

For Models CIMR-P7U2018/4018 and smaller, remove the terminal cover and then use the following procedures to remove the Digital Operator and front cover.

Removing the Digital Operator

Press on the side of the Digital Operator in the direction of arrow 1 to unlock, then li ft the Digital Operato r in the direction of arrow 2 to remove it as shown in Fig 1.11.

Fig 1.11 Removing the Digital Operator

Removing the Front Cover

Press the left and right s ides of th e fr ont co ver in t he di recti on of arrows 1 and lift the bottom of cover in the direction of arrow 2 to remove it as shown in Fig 1.12.

Fig 1.12 Removing the Front Cover

Attaching the Front Cover

Mount the front cover to the Drive by performing the steps to remove the front cover in reverse order.

1.Do not m ount the front cover with the Digital Operator attached to the front cover; this may cause the Digital Operator to malfunction due to imperfect contact.

2.Insert the tab of the upper part of the front cover into the groove of the Drive and press the lower part of the front cover onto the Drive until the front cover snaps into place.

Physical Installation 1 - 16

 Models CIMR-P7U2022 thru 2110 (30HP to 150HP @ 208V/240V) and 4030 thru

4300 (40HP to 500HP @ 480V)

For Models CIMR-P7U2022/4030 and larger, remove the terminal cover and then use the following procedures to remove the Digital Operator and front cover.

Removing the Digital Operator

Use the same procedure for Models CIMR-P7U2018/4018 and smaller.

Removing the Front Cover

Loosen all screws on the front cover. Lift up at the location labeled 1 at the top of the control circuit terminal card and move in the direction of arrow 2.

Fig 1.13 Removing the Front Cover

 Attaching the Front Cover

Attach the front cover by reversing the procedure to remove it.

1.Confirm that the Di gital Operato r is not mounted on the front cover. Contact faults can occur if the cover is attached while the Digital Operator is mounted to it.

2.Insert the tab on the top of the front cover into the slot on the Drive and press in on the cover until it snaps into place on the

Drive.

Physical Installation 1 - 17

Attaching the Digital Operator

After attaching the front cover, mount the Digital Operator onto the Drive using the following procedure.

1. Hook the Dig ital Operator at A (two locations) on the front cover by moving in the d irection of arrow 1 as shown in the following illustration.

2.Press the Digital Operator in the direction of arrow 2 until it snaps in place at B (two locations).

IMPORTANT

Fig 1.14 Mounting the Digital Operator

1. Do not remove or attach the Digital Operator or mount or remove the front cover using methods other than those described above, damage to the Digital Operator or Drive may occur.

2. Never attach the front cover to the Drive with the Digital Operator attached to the front cover. Damage to the Digital Operator may occur. Always attach the front cover to the Drive first, and then attach the Digital Operator to the front cover.

Physical Installation 1 - 18

Chapter 2

Electrical Installation

This chapter describes wiring terminals, main circuit terminal connections, main circuit terminal wiring specifications, control circuit terminals, and control circuit wiring specifications.

Terminal Block Configuration .............................................2-2

Wiring Main Circuit Terminals............................................ 2-3

Control Wiring ................................................................. 2-21

Electrical Installation 2 - 1

Terminal Block Configuration

The wiring terminals are shown in Fig 2.1.

AC MP

-V

R- M5

R+RP

AC MA

AMS6

M3S2 S-

Control circuit terminals

SCS+A2

SN M6

S4SPS7 M4

E(G) E(G)

MCMB

Main circuit terminals

Charge indicator

Ground terminal

Control circuit terminals

Main circuit terminals

AC MP

-VIGR- M5FMR+RP

SCS+A2M2SN M6

S4SPS7 M4

E(G)

Ground terminal

Models CIMR-_ _ _2018 (25 HP, 208V)/ 4018 (30 HP, 480V) and smaller

AC MA

AMS6

MCMB

M3S2 S-

E(G)

Charge indicator

Ground terminal

Models CIMR-_ _ _2022 (30 HP, 208V)/ 4030 (40 HP, 480V) and larger

Fig 2.1 Control Circuit Terminal Layout

Electrical Installation 2 - 2

+ 222 hidden pages

Yaskawa P7 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Warnings and Cautions

Introduction

Model Number and Enclosure Style

Confirmations upon Delivery

Component Names

Exterior and Mounting Dimensions

Heat Loss Data

Checking and Controlling the Installation Site

Installation Orientation and Clearances

Removing and Attaching the Terminal Cover

Removing/Attaching the Digital Operator and Front Cover

Terminal Block Configuration
