Xilinx ML605 User Manual

ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

© Copyright 2009–2012 Xilinx, Inc. Xilinx, the Xilinx logo, Artix, ISE, Kintex, Spartan, Virtex, Zynq, and other designated brands included herein are trademarks of Xilinx in the United States and other countries. All other trademarks are the property of their respective owners.

DISCLAIMER

The information disclosed to you hereunder (the “Materials”) is provided solely for the selection and use of Xilinx products. To the maximum extent permitted by applicable law: (1) Materials are made available "AS IS" and with all faults, Xilinx hereby DISCLAIMS ALL WARRANTIES AND CONDITIONS, EXPRESS, IMPLIED, OR STATUTORY, INCLUDING BUT NOT LIMITED TO WARRANTIES OF MERCHANTABILITY, NON-INFRINGEMENT, OR FITNESS FOR ANY PARTICULAR PURPOSE; and (2) Xilinx shall not be liable (whether in contract or tort, including negligence, or under any other theory of liability) for any loss or damage of any kind or nature related to, arising under, or in connection with, the Materials (including your use of the Materials), including for any direct, indirect, special, incidental, or consequential loss or damage (including loss of data, profits, goodwill, or any type of loss or damage suffered as a result of any action brought by a third party) even if such damage or loss was reasonably foreseeable or Xilinx had been advised of the possibility of the same. Xilinx assumes no obligation to correct any errors contained in the Materials, or to advise you of any corrections or update. You may not reproduce, modify, distribute, or publicly display the Materials without prior written consent. Certain products are subject to the terms and conditions of the Limited Warranties which can be viewed at http://www.xilinx.com/warranty.htm support terms contained in a license issued to you by Xilinx. Xilinx products are not designed or intended to be fail-safe or for use in any application requiring fail-safe performance; you assume sole risk and liability for use of Xilinx products in Critical Applications:

http://www.xilinx.com/warranty.htm#critapps

; IP cores may be subject to warranty and

Revision History

The following table shows the revision history for this document.

Date Version Revision

8/17/09 1.0 Initial Xilinx release.

11/17/09 1.1 • Updated Figure 1-1, Figure 1-2, Figure 1-3, Figure 1-11, and Figure 1-14.

•Added Figure 1-7, Figure 1-8, Figure 1-10, and Figure 1-13.

• Updated Ta bl e 1-1 5 and Ta b le 1 -18 .

• Updated Appendix C, VITA 57.1 FMC LPC (J63) and HPC (J64) Connector Pinout and

Appendix D, ML605 Master UCF.

• Minor typographical edits.

01/15/10 1.2 • Updated Figure 1-2, Figure 1-3, Figure 1-17, Ta bl e 1 -3 , Tab le 1 -8 , Tab le 1- 9, Tab l e B -3 4,

and Tab le B- 35 . Miscellaneous typographical edits.

1/21/10 1.2.1 • Corrected typos in Ta bl e 1- 31 and Figure 1-28.

05/18/10 1.3 Updated 7. Clock Generation, including Tab le 1 -7 . Updated Package Placement column

in Tab le 1 -8 . Updated Figure 1-17. Added notes about FMC HPC J64 and J63 connectors to 19. VITA 57.1 FMC HPC Connector and 20. VITA 57.1 FMC LPC Connector, respectively. Updated description of PMBus Pod and TI Fusion Digital Power Software GUI in Onboard Power Regulation. Updated Tab le B - 35 , Appendix C, VITA 57.1 FMC

LPC (J63) and HPC (J64) Connector Pinout, and Appendix D, ML605 Master UCF.

10/12/10 1.4 Updated description of Fusion Digital Power Software in Onboard Power Regulation.

02/15/11 1.5 Revised note in Tab l e 1 -6 . Revised oscillator manufacturer information from Epson to

SiTime on page page 14, page 29 and page 78.

07/18/11 1.6 Corrected “jitter” to “stability” in section

Oscillator (Differential), page 29. Added Table 1-32, page 69, and table notes in Tab le 1 -3 1. Revised the FPGA U1 Pins for IIC_SDA_MAIN and IIC_SCL_MAIN in Table 1-18, page 46.

ML605 Hardware User Guide www.xilinx.com UG534 (v1.8) October 2, 2012

Date Version Revision

06/19/12 1.7 Added [Ref 4] link to Oscillator (Differential), page 29. Revised Oscillator Socket (Single-

Ended, 2.5V), page 29. Revised Figure 1-10, page 33.

10/02/12 1.8 Updated Figure 1-2, page 13. Added Regulatory and Compliance Information, page 95.

UG534 (v1.8) October 2, 2012 www.xilinx.com ML605 Hardware User Guide

ML605 Hardware User Guide www.xilinx.com UG534 (v1.8) October 2, 2012

Preface: About This Guide

Guide Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Additional Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Additional Support Resources. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Chapter 1: ML605 Evaluation Board

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Additional Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Related Xilinx Documents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Detailed Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

1. Virtex-6 XC6VLX240T-1FFG1156 FPGA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

I/O Voltage Rails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

2. 512 MB DDR3 Memory SODIMM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

3. 128 Mb Platform Flash XL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

4. 32 MB Linear BPI Flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

ML605 Flash Boot Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

5. System ACE CF and CompactFlash Connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

6. USB JTAG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

7. Clock Generation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Oscillator (Differential) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Oscillator Socket (Single-Ended, 2.5V) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

SMA Connectors (Differential) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

8. Multi-Gigabit Transceivers (GTX MGTs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

9. PCI Express Endpoint Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

10. SFP Module Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

11. 10/100/1000 Tri-Speed Ethernet PHY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

SGMII GTX Transceiver Clock Generation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

12. USB-to-UART Bridge. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

13. USB Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

14. DVI Codec . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

15. IIC Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

8 Kb NV Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

16. Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Ethernet PHY Status LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

FPGA INIT and DONE LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

17. User I/O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

User LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

User Pushbutton Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

User DIP Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

User SMA GPIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

LCD Display (16 Character x 2 Lines). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

18. Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Power On/Off Slide Switch SW2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

ML605 Hardware User Guide www.xilinx.com 5

UG534 (v1.8) October 2, 2012

FPGA_PROG_B Pushbutton SW4 (Active-Low). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

SYSACE_RESET_B Pushbutton SW3 (Active-Low) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56

System ACE CF CompactFlash Image Select DIP Switch S1. . . . . . . . . . . . . . . . . . . . . . 57

Mode, Osc Enable, Boot EEPROM Select, and Addr Select DIP Switch S2 . . . . . . . . . . . 58

19. VITA 57.1 FMC HPC Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

20. VITA 57.1 FMC LPC Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

21. Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

AC Adapter and Input Power Jack/Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Onboard Power Regulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

22. System Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Configuration Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Appendix A: References

Appendix B: Default Switch and Jumper Settings

Appendix C: VITA 57.1 FMC LPC (J63) and HPC (J64) Connector Pinout

Appendix D: ML605 Master UCF

Appendix E: Regulatory and Compliance Information

Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Directives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Electromagnetic Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Markings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

6 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

About This Guide

This manual accompanies the Virtex®-6 FPGA ML605 Evaluation Board and contains information about the ML605 hardware and software tools.

Guide Contents

This manual contains the following chapters:

• Chapter 1, ML605 Evaluation Board, provides an overview of the embedded development board and details the components and features of the ML605 board.

• Appendix B, Default Switch and Jumper Settings.

• Appendix C, VITA 57.1 FMC LPC (J63) and HPC (J64) Connector Pinout.

• Appendix D, ML605 Master UCF.

• Appendix A, References.

Preface

Additional Documentation

The following documents are also available for download at

http://www.xilinx.com/support/documentation/virtex-6.htm

• Virtex-6 Family Overview

The features and product selection of the Virtex-6 family are outlined in this overview.

• Virtex-6 FPGA Data Sheet: DC and Switching Characteristics

This data sheet contains the DC and Switching Characteristic specifications for the Virtex-6 family.

• Virtex-6 FPGA Packaging and Pinout Specifications

This specification includes the tables for device/package combinations and maximum I/Os, pin definitions, pinout tables, pinout diagrams, mechanical drawings, and thermal specifications.

• Virtex-6 FPGA Configuration Guide

This all-encompassing configuration guide includes chapters on configuration interfaces (serial and SelectMAP), bitstream encryption, boundary-scan and JTAG configuration, reconfiguration techniques, and readback through the SelectMAP and JTAG interfaces.

• Virtex-6 FPGA Clocking Resources User Guide

This guide describes the clocking resources available in all Virtex-6 devices, including the MMCM and PLLs.

ML605 Hardware User Guide www.xilinx.com 7

UG534 (v1.8) October 2, 2012

Preface: About This Guide

• Virtex-6 FPGA Memory Resources User Guide

• Virtex-6 FPGA SelectIO Resources User Guide

• Virtex-6 FPGA GTX Transceivers User Guide

• Virtex-6 FPGA Embedded Tri-Mode Ethernet MAC User Guide

• Virtex-6 FPGA DSP48E1 Slice User Guide

• Virtex-6 FPGA System Monitor User Guide

The functionality of the block RAM and FIFO are described in this user guide.

This guide describes the SelectIO™ resources available in all Virtex-6 devices.

This guide describes the GTX transceivers available in all Virtex-6 FPGAs except the XC6VLX760.

This guide describes the dedicated Tri-Mode Ethernet Media Access Controller available in all Virtex-6 FPGAs except the XC6VLX760.

This guide describes the architecture of the DSP48E1 slice in Virtex-6 FPGAs and provides configuration examples.

The System Monitor functionality available in all Virtex-6 devices is outlined in this guide.

• Virtex-6 FPGA PCB Design Guide

This guide provides information on PCB design for Virtex-6 devices, with a focus on strategies for making design decisions at the PCB and interface level.

Additional Support Resources

To search the database of silicon and software questions and answers or to create a technical support case in WebCase, see the Xilinx website at:

http://www.xilinx.com/support

8 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

ML605 Evaluation Board

Overview

The ML605 board enables hardware and software developers to create or evaluate designs targeting the Virtex®-6 XC6VLX240T-1FFG1156 FPGA.

The ML605 provides board features common to many embedded processing systems. Some commonly used features include: a DDR3 SODIMM memory, an 8-lane PCI Express® interface, a tri-mode Ethernet PHY, general purpose I/O, and a UART. Additional user desired features can be added through mezzanine cards attached to the onboard high-speed VITA-57 FPGA Mezzanine Connector (FMC) high pin count (HPC) expansion connector, or the onboard VITA-57 FMC low pin count (LPC) connector.

Features, page 10 provides a general listing of the board features with details provided in Detailed Description, page 13.

Chapter 1

Additional Information

Additional information and support material is located at:

• http://www.xilinx.com/ml605

This information includes:

• Current version of this user guide in PDF format

• Example design files for demonstration of Virtex-6 FPGA features and technology

• Demonstration hardware and software configuration files for the System ACE™ CF controller, Platform Flash configuration storage device, and linear flash chip

• Reference design files

• Schematics in PDF and DxDesigner formats

• Bill of materials (BOM)

• Printed-circuit board (PCB) layout in Allegro PCB format

• Gerber files for the PCB (Many free or shareware Gerber file viewers are available on the internet for viewing and printing these files.)

• Additional documentation, errata, frequently asked questions, and the latest news

For information about the Virtex-6 family of FPGA devices, including product highlights, data sheets, user guides, and application notes, see the Virtex-6 FPGA documentation page at http://www.xilinx.com/support/documentation/virtex-6.htm

ML605 Hardware User Guide www.xilinx.com 9

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

Features

The ML605 provides the following features:

• 1. Virtex-6 XC6VLX240T-1FFG1156 FPGA

• 2. 512 MB DDR3 Memory SODIMM

• 3. 128 Mb Platform Flash XL

• 4. 32 MB Linear BPI Flash

• 5. System ACE CF and CompactFlash Connector

• 6. USB JTAG

• 7. Clock Generation

• Fixed 200 MHz oscillator (differential)

• Socketed 2.5V oscillator (single-ended)

• SMA connectors (differential)

• SMA connectors for MGT clocking

• 8. Multi-Gigabit Transceivers (GTX MGTs)

• FMC - HPC connector

• FMC - LPC connector

•SMA

•PCIe

• SFP Module connector

• Ethernet PHY SGMII interface

• 9. PCI Express Endpoint Connectivity

• Gen1 8-lane (x8)

• Gen2 4-lane (x4)

• 10. SFP Module Connector

• 11. 10/100/1000 Tri-Speed Ethernet PHY

• 12. USB-to-UART Bridge

• 13. USB Controller

• 14. DVI Codec

• 15. IIC Bus

•IIC EEPROM - 1KB

• DDR3 SODIMM socket

•DVI CODEC

• DVI connector

• FMC HPC connector

• FMC LPC connector

• SFP module connector

10 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

• 16. Status LEDs

•Ethernet status

•FPGA INIT

•FPGA DONE

•System ACE CF Status

• 17. User I/O

• USER LED Group 1 - GPIO (8)

• USER LED Group 2 - directional (5)

• User pushbuttons - directional (5)

• CPU reset pushbutton

• User DIP switch - GPIO (8-pole)

• User SMA GPIO connectors (2)

• LCD character display (16 characters x 2 lines)

• 18. Switches

• Power on/off slide switch

• System ACE CF reset pushbutton

• System ACE CF bitstream image select DIP switch

• Configuration MODE DIP switch

• 19. VITA 57.1 FMC HPC Connector

• 20. VITA 57.1 FMC LPC Connector

• 21. Power Management

• PMBus voltage and current monitoring via TI power controller

• 22. System Monitor

• Configuration Options

• 3. 128 Mb Platform Flash XL

• 4. 32 MB Linear BPI Flash

• 5. System ACE CF and CompactFlash Connector

• 6. USB JTAG

Overview

ML605 Hardware User Guide www.xilinx.com 11

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

JTAG USB Mini-B USB JTAG Circuit

VITA 57.1 FMC

HPC Connector

VITA 57.1 FMC LPC Connector

Virtex-6

FPGA

XC6VLX240T - 1FFG1156

System ACE CF

S.A. CompactFlash

S.A. 8-bit MPU I/F

User LED/SW

User DIP SW

User LCD

200 MHz LVDS Clock

SMA Clock

User S.E. 2.5V Clock

USB Controller

Host Type “A”

Peripheral Mini-B

Connectors

CP2103 USB-TO-UART

Bridge

USB Mini-B

Platform Flash

Linear BPI Flash

DVI Codec VGA Video

DVI Video Connector

10/100/1000 Ethernet PHY MII/GMII/RMII

SYSMON I/F

INIT, DONE LEDs

PROG PB, MODE SW

IIC Bus

IIC EEPROM

FMC HPC

DDR3 SODIMM IIC

FMC LPC

SFP Module

Connector

SGMII

PCIe X8 Edge Connector

MGT SMA REF Clock

MGT RX/TX SMA Port

UG534_01_092709

SODIMM Socket

204-pin, DDR3

Decoupling Caps

MEM Vterm

Regulator

BANK32 BANK12, 13

BANK14,22 BANK23,24

BANK112,113

BANK24 BANK34

BANK32

BANK33

BANK116

BANK33 BANK34

BANK15,16

BANK34,116

BANK0

BANK24,34 BANK14

BANK114 BANK115

BANK24

BANK14, 33, 36

BANK 25, 35 BANK 26, 36

Block Diagram

Figure 1-1 shows a high-level block diagram of the ML605 and its peripherals.

X-Ref Target - Figure 1-1

Detailed Description

16b

16c

18a

18b

18c18

17c

17b

17f

21a

21b

21c

21d

(on backside)

17a

16a

UG534_02_091312

17e

Figure 1-2 shows a board photo with numbered features corresponding to Tab le 1 -1 and

the section headings in this document.

X-Ref Target - Figure 1-2

Detailed Description

Figure 1-2: ML605 Board Photo

The numbered features in Figure 1-2 correlate to the features and notes listed in Ta bl e 1 -1 .

Table 1-1: ML605 Features

Schematic

Page

Number Feature Notes

1 Virtex-6 FPGA XC6VLX240T-1FFG1156 2 - 12

2 DDR3 SODIMM Micron 512 MB MT4JSF6464HY-1G1 15

3 128 Mb Platform Flash XL Xilinx XCF128X-FTG64C 25

4 Linear BPI Flash Numonyx JS28F256P30T95 26

System ACE CF controller, CF

connector

JTAG cable connector (USB

Mini-B)

Xilinx XCCACE-TQ144I (bottom of board)

USB JTAG download circuit 46

ML605 Hardware User Guide www.xilinx.com 13

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

Table 1-1: ML605 Features (Cont’d)

Number Feature Notes

Clock generation

a. 200 MHz oscillator (on backside)

8GTX RX/TX port SMA x4 30

10 SFP connector and cage AMP 136073-1 23

b. Oscillator socket, singleended

c. SMA connectors SMA pair 30

d. MGT REFCLK SMA connectors

PCIe Gen1 (8-lane), Gen2 (4-lane)

Ethernet (10/100/1000) with SGMII

USB Mini-B, USB-to-UART bridge

200 MHz OSC, oscillator socket, SMA connectors

SiTime 200 MHz 2.5V LVDS OSC 30

MMD Components 66 MHz 2.5V 30

SMA pair 30

Card edge connector, 8-lane 21

Marvell M88E1111 EPHY 24

Silicon Labs CP2103GM bridge 33

Schematic

Page

USB-A Host, USB Mini-B

peripheral connectors

14 Video - DVI connector Chrontel CH7301C-TF Video codec 28, 29

IIC NV EEPROM, 8 Kb

(on backside)

Status LEDs 13, 24, 31

a. Ethernet status Right-angle link rate and direction

b. FPGA INIT, DONE Init (red), Done (green) 31

c. System ACE CF status Status (green), Error (red) 13

User I/O 31

a. User LEDs, green (8) User I/O (active-High) 30, 31, 33

b. User pushbuttons, N.O. momentary (5)

c. User LEDs, green (5) User I/O (active-High) 31

d. User DIP switch (8-pole) User I/O (active-High) 31

e. User GPIO SMA connectors

Cypress CY7C67300-100AXI controller

ST Microelectronics M24C08WDW6TP

LEDs

User I/O (active-High) 31

SMA pair 30

f. LCD 16 character x 2 line display

14 www.xilinx.com ML605 Hardware User Guide

Displaytech S162D BA BC 33

UG534 (v1.8) October 2, 2012

Table 1-1: ML605 Features (Cont’d)

Detailed Description

Number Feature Notes

Switches 13, 25, 39

a. Power On/Off Slide switch 39

b. FPGA_PROG_B

19 FMC - HPC connector Samtec ASP-134486-01 16 -19

20 FMC - LPC connector Samtec ASP-134603-01 20

pushbutton

c. System ACE CF Image Select

d. Mode Switch 6-pole DIP switch (active-High) 25

Power management 35 - 44

a. PMBus controllers 2 x TI UCD9240PFC 35, 40

b. Voltage regulators

c. 12V power input connector

d. 12V power input connector

active-Low 13

4-pole DIP switch (active-High) 25

2 x PTD08A020W, 3 x PTD08A010W

6-pin Molex mini-fit connector 39

4-pin ATX disk type connector 39

Schematic

Page

36-38, 43,

System Monitor Interface

connector

System ACE Error DS30 LED

disable jumper J69

2x6 DIP male pin header 34

Jumper on = enable LED Jumper off = disable LED

1. Virtex-6 XC6VLX240T-1FFG1156 FPGA

A Virtex-6 XC6VLX240T-1FFG1156 FPGA is installed on the embedded development board.

Keep-Out areas and drill holes are defined around the FPGA to support an Ironwood Electronics SG-BGA-6046 FPGA socket.

References

See the Virtex-6 FPGA Data Sheet. [Ref 4]

Configuration

The ML605 supports configuration in the following modes:

• Slave SelectMAP (using Platform Flash XL with the onboard 47 MHz oscillator)

• Master BPI-Up (using Linear BPI Flash device)

•JTAG (using the included USB-A to Mini-B cable)

• JTAG (using System ACE CF and CompactFlash card)

ML605 Hardware User Guide www.xilinx.com 15

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

The ML605 supports Master BPI-Up, JTAG, and Slave SelectMAP. These are selected by setting M[2:0] options 010, 101 and 110 shown in Tab le 1 -2 .

Table 1-2: Virtex-6 FPGA Configuration Modes

Configuration Mode M[2:0] Bus Width

Master Serial

Master SPI

(2)

Master BPI-Up

Master BPI-Down

Master SelectMAP

JTAG 101 1 Input (TCK)

Slave SelectMAP 110 8, 16, 32 Input

Slave Serial

Notes:

1. The parallel configuration modes bus is auto-detected by the configuration logic.

2. In Master configuration mode, the CCLK pin is the clock source for the Virtex-6 FPGA internal configuration logic. The Virtex-6 FPGA CCLK output pin must be free from reflections to avoid double-clocking the internal configuration logic. See the Virtex-6 FPGA Configuration User Guide for more details. [Ref 5]

3. This is the default setting due to internal pull-up termination on mode pins.

(3)

(2)

(1)

CCLK Direction

000 1Output

001 1Output

010 8, 16 Output

011 8, 16 Output

100 8, 16 Output

111 1 Input

For an overview on configuring the FPGA, see Configuration Options, page 76.

Note:

page 79) is M[2:0]=010, which selects Master BPI-Up at board power-on. Switch S1 position 4 must

be OFF to disable the System ACE controller from attempting to boot if a CF card is present.

The mode switches are part of DIP switch S2. The default mode setting (see Table B-34,

References

See the Virtex-6 FPGA Configuration User Guide for detailed configuration information.

[Ref 5]

I/O Voltage Rails

There are 16 I/O banks available on the Virtex-6 device. The voltage applied to the FPGA I/O banks used by the ML605 board is summarized in Tab le 1 -3 .

Table 1-3: Voltage Rails

U1 FPGA Bank I/O Rail Voltage

Bank 0 VCC2V5_FPGA 2.5V

Bank 12

(1)

Bank 13 VCC2V5_FPGA 2.5V

Bank 14 VCC2V5_FPGA 2.5V

Bank 15 VCC2V5_FPGA 2.5V

FMC_VIO_B_M2C 2.5V

Bank 16 VCC2V5_FPGA 2.5V

Bank 22 VCC2V5_FPGA 2.5V

Bank 23 VCC2V5_FPGA 2.5V

16 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

Table 1-3: Voltage Rails (Cont’d)

U1 FPGA Bank I/O Rail Voltage

Bank 24 VCC2V5_FPGA 2.5V

Bank 25 VCC1V5_FPGA 1.5V

Bank 26 VCC1V5_FPGA 1.5V

Bank 32 VCC2V5_FPGA 2.5V

Bank 33 VCC2V5_FPGA 2.5V

Bank 34 VCC2V5_FPGA 2.5V

Bank 35 VCC1V5_FPGA 1.5V

Bank 36 VCC1V5_FPGA 1.5V

Notes:

1. The VITA 57.1 specification stipulates that the Bank 12 voltage named FMC_VIO_B_M2C is supplied by the FMC card plugged onto the relevant FMC connector (ML605 J64). FMC_VIO_B_M2C cannot exceed the base board (ML605) Vadj of the FMC connector. The ML605 FMC Vadj maximum is 2.5V.

Detailed Description

References

See the Xilinx Virtex-6 FPGA documentation for more information at

http://www.xilinx.com/support/documentation/virtex-6.htm

2. 512 MB DDR3 Memory SODIMM

A 512MB DDR3 SODIMM is provided as a flexible and efficient form-factor volatile memory for user applications. The ML605 SODIMM socket is wired to support a maximum SODIMM size of 2 GB.

The ML605 DDR3 64-bit wide interface has been tested to 800 MT/s.

The DDR3 interface is implemented in FPGA banks 25, 26, 35, and 36. DCI VRP/N resistor connections are only implemented banks 26 and 36. DCI functionality in banks 25 and 35 is achieved in the UCF by cascading DCI between adjacent banks as follows:

CONFIG DCI_CASCADE = "36 35"; CONFIG DCI_CASCADE = "26 25";

Tab le 1 -4 shows the connections and pin numbers for the DDR3 SODIMM.

Table 1-4: DDR3 SODIMM Connections

U1 FPGA Pin Schematic Net Name

L14 DDR3_A0 98 A0

J1 SODIMM

Pin Number Pin Name

A16 DDR3_A1 97 A1

B16 DDR3_A2 96 A2

E16 DDR3_A3 95 A3

D16 DDR3_A4 92 A4

J17 DDR3_A5 91 A5

ML605 Hardware User Guide www.xilinx.com 17

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

Table 1-4: DDR3 SODIMM Connections (Cont’d)

U1 FPGA Pin Schematic Net Name

A15 DDR3_A6 90 A6

B15 DDR3_A7 86 A7

G15 DDR3_A8 89 A8

F15 DDR3_A9 85 A9

M16 DDR3_A10 107 A10/AP

M15 DDR3_A11 84 A11

H15 DDR3_A12 83 A12_BC_N

J15 DDR3_A13 119 A13

D15 DDR3_A14 80 A14

C15 DDR3_A15 78 A15

K19 DDR3_BA0 109 BA0

J19 DDR3_BA1 108 BA1

J1 SODIMM

Pin Number Pin Name

L15 DDR3_BA2 79 BA2

J11 DDR3_D0 5 DQ0

E13 DDR3_D1 7 DQ1

F13 DDR3_D2 15 DQ2

K11 DDR3_D3 17 DQ3

L11 DDR3_D4 4 DQ4

K13 DDR3_D5 6 DQ5

K12 DDR3_D6 16 DQ6

D11 DDR3_D7 18 DQ7

M13 DDR3_D8 21 DQ8

J14 DDR3_D9 23 DQ9

B13 DDR3_D10 33 DQ10

B12 DDR3_D11 35 DQ11

G10 DDR3_D12 22 DQ12

M11 DDR3_D13 24 DQ13

C12 DDR3_D14 34 DQ14

A11 DDR3_D15 36 DQ15

G11 DDR3_D16 39 DQ16

F11 DDR3_D17 41 DQ17

D14 DDR3_D18 51 DQ18

C14 DDR3_D19 53 DQ19

18 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

Table 1-4: DDR3 SODIMM Connections (Cont’d)

U1 FPGA Pin Schematic Net Name

G12 DDR3_D20 40 DQ20

G13 DDR3_D21 42 DQ21

F14 DDR3_D22 50 DQ22

H14 DDR3_D23 52 DQ23

C19 DDR3_D24 57 DQ24

G20 DDR3_D25 59 DQ25

E19 DDR3_D26 67 DQ26

F20 DDR3_D27 69 DQ27

A20 DDR3_D28 56 DQ28

A21 DDR3_D29 58 DQ29

E22 DDR3_D30 68 DQ30

E23 DDR3_D31 70 DQ31

Detailed Description

J1 SODIMM

Pin Number Pin Name

G21 DDR3_D32 129 DQ32

B21 DDR3_D33 131 DQ33

A23 DDR3_D34 141 DQ34

A24 DDR3_D35 143 DQ35

C20 DDR3_D36 130 DQ36

D20 DDR3_D37 132 DQ37

J20 DDR3_D38 140 DQ38

G22 DDR3_D39 142 DQ39

D26 DDR3_D40 147 DQ40

F26 DDR3_D41 149 DQ41

B26 DDR3_D42 157 DQ42

E26 DDR3_D43 159 DQ43

C24 DDR3_D44 146 DQ44

D25 DDR3_D45 148 DQ45

D27 DDR3_D46 158 DQ46

C25 DDR3_D47 160 DQ47

C27 DDR3_D48 163 DQ48

B28 DDR3_D49 165 DQ49

D29 DDR3_D50 175 DQ50

B27 DDR3_D51 177 DQ51

G27 DDR3_D52 164 DQ52

A28 DDR3_D53 166 DQ53

ML605 Hardware User Guide www.xilinx.com 19

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

Table 1-4: DDR3 SODIMM Connections (Cont’d)

U1 FPGA Pin Schematic Net Name

E24 DDR3_D54 174 DQ54

G25 DDR3_D55 176 DQ55

F28 DDR3_D56 181 DQ56

B31 DDR3_D57 183 DQ57

H29 DDR3_D58 191 DQ58

H28 DDR3_D59 193 DQ59

B30 DDR3_D60 180 DQ60

A30 DDR3_D61 182 DQ61

E29 DDR3_D62 192 DQ62

F29 DDR3_D63 194 DQ63

E11 DDR3_DM0 11 DM0

B11 DDR3_DM1 28 DM1

J1 SODIMM

Pin Number Pin Name

E14 DDR3_DM2 46 DM2

D19 DDR3_DM3 63 DM3

B22 DDR3_DM4 136 DM4

A26 DDR3_DM5 153 DM5

A29 DDR3_DM6 170 DM6

A31 DDR3_DM7 187 DM7

E12 DDR3_DQS0_N 10 DQS0_N

D12 DDR3_DQS0_P 12 DQS0_P

J12 DDR3_DQS1_N 27 DQS1_N

H12 DDR3_DQS1_P 29 DQS1_P

A14 DDR3_DQS2_N 45 DQS2_N

A13 DDR3_DQS2_P 47 DQS2_P

H20 DDR3_DQS3_N 62 DQS3_N

H19 DDR3_DQS3_P 64 DQS3_P

C23 DDR3_DQS4_N 135 DQS4_N

B23 DDR3_DQS4_P 137 DQS4_P

A25 DDR3_DQS5_N 152 DQS5_N

B25 DDR3_DQS5_P 154 DQS5_P

G28 DDR3_DQS6_N 169 DQS6_N

H27 DDR3_DQS6_P 171 DQS6_P

D30 DDR3_DQS7_N 186 DQS7_N

20 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

Table 1-4: DDR3 SODIMM Connections (Cont’d)

U1 FPGA Pin Schematic Net Name

C30 DDR3_DQS7_P 188 DQS7_P

F18 DDR3_ODT0 116 ODT0

E17 DDR3_ODT1 120 ODT1

E18 DDR3_RESET_B 30 RESET_B

K18 DDR3_S0_B 114 S0_B

K17 DDR3_S1_B 121 S1_B

D17 DDR3_TEMP_EVENT 198 EVENT_B

B17 DDR3_WE_B 113 WE_B

C17 DDR3_CAS_B 115 CAS_B

L19 DDR3_RAS_B 110 RAS_B

M18 DDR3_CKE0 73 CKE0

Detailed Description

J1 SODIMM

Pin Number Pin Name

M17 DDR3_CKE1 74 CKE1

H18 DDR3_CLK0_N 103 CK0_N

G18 DDR3_CLK0_P 101 CK0_P

L16 DDR3_CLK1_N 104 CK1_N

K16 DDR3_CLK1_P 102 CK1_P

The Memory Interface Generator (MIG) tool guidelines specify a set of U1 FPGA “No Connect” pins. These should be added to the UCF as CONFIG PROHIBIT pins as follows:

CONFIG PROHIBIT = H22; CONFIG PROHIBIT = F21; CONFIG PROHIBIT = B20; CONFIG PROHIBIT = F19;

CONFIG PROHIBIT = C13; CONFIG PROHIBIT = M12; CONFIG PROHIBIT = L13; CONFIG PROHIBIT = K14;

CONFIG PROHIBIT = F25; CONFIG PROHIBIT = C29; CONFIG PROHIBIT = C28; CONFIG PROHIBIT = D24;

References

See the Micron Technology, Inc. for more information [Ref 22].

In addition, see the Virtex-6 FPGA Memory Interface Solutions User Guide [Ref 6] and the Virtex-6 FPGA Memory Resources User Guide [Ref 9].

ML605 Hardware User Guide www.xilinx.com 21

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

3. 128 Mb Platform Flash XL

A 128 Mb Xilinx XCF128X-FTG64C Platform Flash XL device is used with an onboard 47 MHz oscillator (X4) to configure the FPGA in less than 100 ms from power valid as required by the PCI Express Card Electromechanical Specification. This allows the PCIe interface to be recognized and enumerated when plugged into a host PC.

To achieve the fastest configuration speed, the FPGA mode pins are set to Slave SelectMAP and the onboard 47 MHz clock source external to the FPGA is used for configuration. Configuration DIP switch S2, switch 1, controls the 47 MHz oscillator enable as outlined in

18. Switches, page 55.

See S2 switch setting details in Table 1-26, page 58. Also, see the FPGA Design

Considerations for the Configuration Flash, page 25 for FPGA design recommendations.

4. 32 MB Linear BPI Flash

A Numonyx JS28F256P30 Linear BPI Flash memory (P30) on the ML605 provides 32 MB of non-volatile storage that can be used for configuration as well as software storage. The Linear BPI Flash shares the dual use configuration pins in parallel with the XCF128 Platform Flash XL.

The P30_CS net is used to select the P30 or the XCF128. Power-on configuration is selected by the P30_CS net which is tied to a dip switch S2 (selects pullup/pulldown) and is also wired to an FPGA non-config pin. The dip switch allows power selection for the configuration device P30 or XCF128XL. The dip switch selection can be overridden by the FPGA after configuration by controlling the logic level of the P30_CS signal.

X-Ref Target - Figure 1-3

See S2 switch setting details in Table 1-26, page 58. For an overview on configuring the FPGA, see Configuration Options, page 76.

Figure 1-3 shows a block diagram for the Platform Flash and BPI Flash.

FPGA U1 Bank 34

S2 SWITCH 6 ON = U4 BPI Upper Half OFF = U4 BPI Lower Half

FPGA U1 Bank 24

FLASH_A[22:0]

FLASH_A[23]

VCC2V5

S2-6510

U27

PLATFORM

FLASH

BPI

FLASH

A23

4.7K

FLASH_D[15:0]

VCC2V5

PLATFLASH_FCS_B

VCC2V5

510

VCC2V5

FLASH_CE_B

S2-2

FPGA U1

S1 Switch 4

OFF = Disable System ACE, enable U4/U27 flash boot ON = Enable System ACE boot when CF card is present

Bank 24

U10

P30_CS_SEL (FPGA U1 pin AJ12)

4.7K

4 3

S2 SWITCH 2 ON = U4 BOOT OFF = U27 BOOT

FPGA_FCS_B

FPGA U1 Bank 24

UG534_03_011110

Figure 1-3: Platform Flash and BPI Flash Block Diagram

22 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

ML605 Flash Boot Options

The ML605 has two parallel wired flash memory devices as shown in Figure 1-3. At ML605 power-up, before FPGA configuration, DIP switch S2 switch 2 selects which flash device, U4 (BPI) or U27 (Platform Flash), provides the boot bitstream. Typically S2 switch 2 will be open/OFF to select the U27 Platform Flash. Given that the mode switches (S2 switch 3/M0, switch 4/M1 and switch 5/M2) are set to Slave SelectMAP mode, then U27, driven at 47 MHz, can load a PCIe core bitstream before a host PC motherboard can scan its PCIe slots.When S2 switch 2 is closed/ON at power up, the FPGA will be configured from the BPI flash device U4. Note that U4 address bit A23 is switched by S2 switch 6, which allows the lower or upper half of U4 to be chosen as a data source.

Tab le 1 -5 shows the connections and pin numbers for the boot flash devices.

Table 1-5: Platform Flash and BPI Flash Connections

Detailed Description

U1 FPGA Pin Schematic Net Name

Pin Number Pin Name Pin Number Pin Name

AL8 FLASH_A0 29 A1 A1 A00

AK8 FLASH_A1 25 A2 B1 A01

AC9 FLASH_A2 24 A3 C1 A02

AD10 FLASH_A3 23 A4 D1 A03

C8 FLASH_A4 22 A5 D2 A04

B8 FLASH_A5 21 A6 A2 A05

E9 FLASH_A6 20 A7 C2 A06

E8 FLASH_A7 19 A8 A3 A07

A8 FLASH_A8 8 A9 B3 A08

A9 FLASH_A9 7 A10 C3 A09

D9 FLASH_A10 6 A11 D3 A10

C9 FLASH_A11 5 A12 C4 A11

D10 FLASH_A12 4 A13 A5 A12

C10 FLASH_A13 3 A14 B5 A13

U4 BPI Flash U27 Platform Flash

F10 FLASH_A14 2 A15 C5 A14

F9 FLASH_A15 1 A16 D7 A15

AH8 FLASH_A16 55 A17 D8 A16

AG8 FLASH_A17 18 A18 A7 A17

AP9 FLASH_A18 17 A19 B7 A18

AN9 FLASH_A19 16 A20 C7 A19

AF10 FLASH_A20 11 A21 C8 A20

AF9 FLASH_A21 10 A22 A8 A21

AL9 FLASH_A22 9 A23 G1 A22

AA23 FLASH_A23 26 A24 NC A23

ML605 Hardware User Guide www.xilinx.com 23

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

Table 1-5: Platform Flash and BPI Flash Connections (Cont’d)

U1 FPGA Pin Schematic Net Name

U4 BPI Flash U27 Platform Flash

Pin Number Pin Name Pin Number Pin Name

AF24 FLASH_D0 34 DQ0 F2 DQ00

AF25 FLASH_D1 36 DQ1 E2 DQ01

W24 FLASH_D2 39 DQ2 G3 DQ02

V24 FLASH_D3 41 DQ3 E4 DQ03

H24 FLASH_D4 47 DQ4 E5 DQ04

H25 FLASH_D5 49 DQ5 G5 DQ05

P24 FLASH_D6 51 DQ6 G6 DQ06

R24 FLASH_D7 53 DQ7 H7 DQ07

G23 FLASH_D8 35 DQ8 E1 DQ08

H23 FLASH_D9 37 DQ9 E3 DQ09

N24 FLASH_D10 40 DQ10 F3 DQ10

N23 FLASH_D11 42 DQ11 F4 DQ11

F23 FLASH_D12 48 DQ12 F5 DQ12

F24 FLASH_D13 50 DQ13 H5 DQ13

L24 FLASH_D14 52 DQ14 G7 DQ14

M23 FLASH_D15 54 DQ15 E7 DQ15

J26 FLASH_WAIT 56 WAIT NA

(1)

AF23 FPGA_FWE_B 14 /WE G8 /W

AA24 FPGA_FOE_B 32 /OE F8 /G

K8 FPGA_CCLK NA

AC23 PLATFLASH_L_B NA

Y24 FPGA_FCS_B

(1)

PLATFLASH_FCS_B

FLASH_CE_B

(2)

(3)

(4)

(1)

30 /OE NA

(1)

F1 K

H1 /L

(1)

B4 /E

(1)

Notes:

1. Not Applicable

2. FPGA control flash memory select signal connected to pin U10.3

3. Platform Flash select signal connected to pin U10.6

4. BPI Flash select signal connected to pin U10.4

(1)

24 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

Detailed Description

FPGA Design Considerations for the Configuration Flash

After FPGA configuration, the FPGA design can disable the configuration flash or access the configuration flash to read/write code or data.

When the FPGA design does not use the configuration flash, the FPGA design must drive the FPGA FCS_B pin High in order to disable the configuration flash and put the flash into a quiescent, low-power state. Otherwise, the Platform Flash XL, in particular, can continue to drive its array data onto the data bus causing unnecessary switching noise and power consumption.

For FPGA designs that access the flash for reading/writing stored code or data, connect the FPGA design or EDK embedded memory controller (EMC) peripheral to the flash through the pins defined in Tab le 1 -5 , pag e 2 3.

The Platform Flash XL defaults to a synchronous read mode. Typically, the Platform Flash XL requires an initialization procedure to put the Platform Flash XL into the common, asynchronous read mode before accessing stored code or data. To put the Platform Flash XL into asynchronous read mode, apply the Set Configuration Register command sequence. See the Platform Flash XL High-Density Configuration and Storage Device Data Sheet for details on the Set Configuration Register command. [Ref 17]

References

See the Numonyx StrataFlash Embedded Memory Data Sheet. [Ref 24]

Visit the Xilinx Platform Flash information.

Also, see the Platform Flash XL High-Density Configuration and Storage Device Data Sheet

[Ref 17] and the Virtex-6 Configuration User Guide [Ref 10].

product page and click the Resources tab for more

ML605 Hardware User Guide www.xilinx.com 25

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

5. System ACE CF and CompactFlash Connector

The Xilinx System ACE CompactFlash (CF) configuration controller allows a Type I or Type II CompactFlash card to program the FPGA through the JTAG port. Both hardware and software data can be downloaded through the JTAG port. The System ACE CF controller supports up to eight configuration images on a single CompactFlash card. The configuration address switches allow the user to choose which of the eight configuration images to use.

The CompactFlash (CF) card shipped with the board is correctly formatted to enable the System ACE CF controller to access the data stored in the card. The System ACE CF controller requires a FAT16 file system, with only one reserved sector permitted, and a sector-per-cluster size of more than one (UnitSize greater than 512). The FAT16 file system supports partitions of up to 2 GB. If multiple partitions are used, the System ACE CF directory structure must reside in the first partition on the CompactFlash, with the xilinx.sys file located in the root directory. The xilinx.sys file is used by the System ACE CF controller to define the project directory structure, which consists of one main folder containing eight sub-folders used to store the eight ACE files containing the configuration images. Only one ACE file should exist within each sub-folder. All folder names must be compliant to the DOS 8.3 short file name format. This means that the folder names can be up to eight characters long, and cannot contain the following reserved characters: < > " / \ |. This DOS 8.3 file name restriction does not apply to the actual ACE file names. Other folders and files may also coexist with the System ACE CF project within the FAT16 partition. However, the root directory must not contain more than a total of 16 folder and/or file entries, including deleted entries. When ejecting or unplugging the CompactFlash device, it is important to safely stop any read or write access to the CompactFlash device to avoid data corruption.

System ACE CF error and status LEDs indicate the operational state of the System ACE CF controller:

• A blinking red error LED indicates that no CompactFlash card is present.

• A solid red error LED indicates an error condition during configuration.

• A blinking green status LED indicates a configuration operation is ongoing.

• A solid green status LED indicates a successful download.

Note:

jumper is installed during operations utilizing the CompactFlash card.

Jumper J69 can be removed to disable the Red Error LED circuit. It is recommended that this

Every time a CompactFlash card is inserted into the System ACE CF socket, a configuration operation is initiated. Pressing the System ACE CF reset button re-programs the FPGA.

Note:

for more details.

System ACE CF configuration is enabled by way of DIP switch S1. See 18. Switches, page 55

The System ACE CF MPU port is connected to the FPGA. This connection allows the FPGA to use the System ACE CF controller to reconfigure the system or access the CompactFlash card as a generic FAT file system.

26 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

Tab le 1 -6 lists the System ACE CF connections.

Table 1-6: System ACE CF Connections

Detailed Description

U1 FPGA Pin Schematic Net Name

U19 XCCACETQ144I

Pin Number Pin Name

AM15 SYSACE_D0 66 MPD00

AJ17 SYSACE_D1 65 MPD01

AJ16 SYSACE_D2 63 MPD02

AP16 SYSACE_D3 62 MPD03

AG16 SYSACE_D4 61 MPD04

AH15 SYSACE_D5 60 MPD05

AF16 SYSACE_D6 59 MPD06

AN15 SYSACE_D7 58 MPD07

AC15 SYSACE_MPA00 70 MPA00

AP15 SYSACE_MPA01 69 MPA01

AG17 SYSACE_MPA02 68 MPA02

AH17 SYSACE_MPA03 67 MPA03

AG15 SYSACE_MPA04 45 MPA04

AF15 SYSACE_MPA05 44 MPA05

AK14 SYSACE_MPA06 43 MPA06

AJ15 SYSACE_MPBRDY 39 MPBRDY

AJ14 SYSACE_MPCE 42 MPCE

L9 SYSACE_MPIRQ 41 MPIRQ

AL15 SYSACE_MPOE 77 MPOE

AL14 SYSACE_MPWE 76 MPWE

AC8 SYSACE_CFGTDI 81 CFGTDI

AE8 FPGA_TCK 80 CFGTCK

AD8 FPGA_TDI 82 CFGTDO

AF8 FPGA_TMS 85 CFGTMS

AE16 CLK_33MHZ_SYSACE

Notes:

1. The System ACE CF clock is sourced from U28 33.000 MHz osc.

(1)

93 CLK

References

See the System ACE CF product page and the System ACE CompactFlash Solution Data Sheet.

[Ref 18]

ML605 Hardware User Guide www.xilinx.com 27

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

6. USB JTAG

JTAG configuration is provided through onboard USB-to-JTAG configuration logic where a computer host accesses the ML605 JTAG chain through a Type-A (computer host side) to Type-Mini-B (ML605 side) USB cable.

The JTAG chain of the board is illustrated in Figure 1-4. JTAG configuration is allowable at any time under any mode pin setting. JTAG initiated configuration takes priority over the mode pin settings.

X-Ref Target - Figure 1-4

J17 J18

3.3V 2.5V

J22

USB Mini-B

FMC HPC FMC LPC

TDI TDO

TDI

J64

TDO

J63

System ACE CF FPGA

TSTTDI CFGTDO

U19

TSTTDO CFGTDI

TDI

TDO

UG534_04_081309

Figure 1-4: JTAG Chain Diagram

FMC bypass jumpers J17 and J18 must be connected between pins 1-2 (bypass) to enable JTAG access to the FPGA on the basic ML605 board (without FMC expansion modules installed), as shown in Figure 1-5 and Figure 1-6. When either or both VITA 57.1 FMC expansion connectors are populated with an expansion module that has a JTAG chain, the respective jumper(s) must be set to connect pins 2-3 in order to include the FMC expansion module's JTAG chain in the main ML605 JTAG chain.

X-Ref Target - Figure 1-5

J17

FMC_TDI_BUF

FMC_LPC_TDI

FMC_HPC_TDO

Bypass FMC HPC J64 = Jumper 1-2

Include FMC HPC J64 = Jumper 2-3

H - 1x3

UG534_05_081309

Figure 1-5: VITA 57.1 FMC HPC (J64) JTAG Bypass Jumper J17

X-Ref Target - Figure 1-6

J18

FMC_LPC_TDI

SYSACE_TDI

FMC_LPC_TDO

Bypass FMC LPC J63 = Jumper 1-2

Include FMC LPC J63 = Jumper 2-3

H - 1x3

UG534_06_081309

Figure 1-6: VITA 57.1 FMC LPC (J63) JTAG Bypass Jumper J18

28 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

The JTAG chain can be used to program the FPGA and access the FPGA for hardware and software debug.

The JTAG connector (USB Mini-B J22) allows a host computer to download bitstreams to the FPGA using the Xilinx iMPACT software tool. In addition, the JTAG connector allows debug tools such as the ChipScope™ Pro Analyzer tool or a software debugger to access the FPGA. The iMPACT software tool can also program the BPI flash via the USB J22 connection. iMPACT can download a temporary design to the FPGA through the JTAG. This provides a connection within the FPGA from the FPGA's JTAG port to the FPGA's BPI interface. Through the connection made by the temporary design in the FPGA, iMPACT can indirectly program the BPI flash or the Platform Flash XL from the JTAG USB J22 connector.

For an overview on configuring the FPGA, see Configuration Options, page 76.

7. Clock Generation

There are three FPGA fabric clock sources available on the ML605 (refer to Ta bl e 1 -7 ).

Oscillator (Differential)

The ML605 has one 2.5V LVDS differential 200 MHz oscillator (U11) soldered onto the board and wired to an FPGA global clock input. The 200 MHz signal names are SYSCLK_N and SYSCLK_P.

Detailed Description

• Crystal oscillator: SiTime SiT9102AI-243N25E200.00000

• Frequency stability: 50 ppm

For more details, see the SiTime SiT9102 data sheet [Ref 25]. For more information about LVDS clocking, refer to DS152 [Ref 4].

Oscillator Socket (Single-Ended, 2.5V)

One populated single-ended clock socket (X5) is provided for user applications. The X5 socket is populated with a 66 MHz 2.5V single-ended MMD Components MBH2100H-

66.000 MHz oscillator. The 66 MHz signal name is USER_CLOCK.

For more information about LVDS clocking, refer to DS152 [Ref 4].

ML605 Hardware User Guide www.xilinx.com 29

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

Silkscreened outline has beveled corner

UG534_07_092109

Socket has notch in crossbar

X-Ref Target - Figure 1-7

Figure 1-7: ML605 Oscillator Socket Pin 1 Location Identifiers

30 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

X-Ref Target - Figure 1-8

Detailed Description

Oscillator body has one square corner

Oscillator top has corner dot marking

UG534_08_092109

Figure 1-8: ML605 Oscillator Pin 1 Location Identifiers

SMA Connectors (Differential)

A high-precision clock signal can be provided to the FPGA using differential clock signals through the onboard 50Ω SMA connectors J58(P)/J55(N). This differential user clock has the signal names USER_SMA_CLOCK_N and USER_SMA_CLOCK_P.

ML605 Hardware User Guide www.xilinx.com 31

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

GTX SMA Clock

The ML605 includes a pair of SMA connectors for a GTX (MGT) Clock as described in

Figure 1-9 and Tab le 1 -7 .

X-Ref Target - Figure 1-9

SMA_REFCLK_N SMA_REFCLK_P

C61 1

0.1UF

10V

C62 1

0.1UF

10V

SMA_REFCLK_C_N1

X5R

SMA_REFCLK_C_P1

X5R

J30 32K10K-400E3

4 5 6 7

SIG

GND1 GND2 GND3 GND4 GND5 GND6 GND7

J31 32K10K-400E3

4 5 6 7

SIG

GND1 GND2 GND3 GND4 GND5 GND6 GND7

Figure 1-9: GTX SMA Clock

Table 1-7: ML605 Clock Connections

U1 FPGA Pin Schematic Net Name SMA Pin

H9 SYSCLK_N U11.5

J9 SYSCLK_P U11.4

U23 USER_CLOCK X5.5

F5 SMA_REFCLK_N J30.1

F6 SMA_REFCLK_P J31.1

M22 USER_SMA_CLOCK_N J55.1

L23 USER_SMA_CLOCK_P J58.1

UG534_09_081309

32 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

8. Multi-Gigabit Transceivers (GTX MGTs)

X-Ref Target - Figure 1-10

Note: xxx MHz = user specified frequency

100 MHz in from PCIe Fingers

(HCSL)

FMC#1 HPC xxx MHz LVDS GBTCLK0 AC coupling on Mezz

FMC#1 HPC CLK2_M2C

(LVDS)

FMC#1 HPC xxx MHz LVDS GBTCLK1 AC coupling on Mezz

FMC#1 HPC CLK3_M2C

(LVDS)

Detailed Description

The ML605 provides access to 20 MGTs.

• Eight (8) of the MGTs are wired to the PCIe x8 Endpoint (P1) edge connector fingers

• Eight (8) of the MGTs are wired to the FMC HPC connector (J64)

• One (1) MGT is wired to SMA connectors (J26, J27)

• One (1) MGTs is wired to the FMC LPC connector (J63)

• One (1) MGT is wired to the SFP Module connector (P4)

• One (1) MGT is used for an SGMII connection to the Ethernet PHY (U80)

ICS

854104

ICS

854104

ICS

854104

SGMII 125 MHz LVDS

SMA xxx MHz LVDS

100 MHz LVDS

FMC#2 LPC xxx MHz GBTCLK0 LVDS

ICS874001

No Connect

(LVDS)

To FPGA CLK2_M2C_IO CC pin

(LVDS)

To FPGA CLK3_M2C_IO CC pin

AC coupling on Mezz

250 MHz LVDS

No Connect

GTX_X0Y19

GTX_X0Y18

REFCLK0

REFCLK1

GTX_X0Y17

GTX_X0Y16

GTX_X0Y15

GTX_X0Y14

REFCLK0

REFCLK1

GTX_X0Y13

GTX_X0Y12

GTX_X0Y11

GTX_X0Y10

REFCLK0

REFCLK1

GTX_X0Y09

GTX_X0Y08

GTX_X0Y07

GTX_X0Y06

REFCLK0

REFCLK1

GTX_X0Y05

GTX_X0Y04

GTX_X0Y03

GTX_X0Y02

REFCLK0

REFCLK1

GTX_X0Y01

GTX_X0Y00

SGMII

SMA

SFP

FMC#2

PCIe Lane1 PCIe Lane 2

PCIe Lane 3

BANK_115BANK_114BANK_113BANK_112 BANK_116

PCIe Lane 4

PCIe Lane 5

PCIe Lane 6

PCIe Lane 7

PCIe Lane 8

FMC#1

FMC#1 FMC#1

FMC#1

FMC#1 FMC#1

PCIe

UG534_10_021012

Figure 1-10: MGT Clocking

References

See the Virtex-6 FPGA GTX Transceivers User Guide. [Ref 12]

ML605 Hardware User Guide www.xilinx.com 33

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

UG534_11_100809

Bank 115

ICS874001

ICS854104

REFCLK+,-

PERp,n[7:0]

PCIE_TX[7:0]_P/N

PCIE_RX[7:0]_P/N

MGTREFCLK0 P/N

PETp,n[7:0]

PCIE_CLK_Q0_P/N

Note: PCIe edge connector signal nomenclature is from perspective of the system/motherboard.

PCIE_100M_MGT1_P/N

PCIE_100M_MGT0_P/N

PCIE_100M_MGT0_C_P/N PCIE_250M_MGT1_C_P/N

PCIE_250M_MGT1_P/N

CLK/NCLK

PCIe

8-Lane

Edge

Connector

MGTTX P/N[3:0]

MGTRX P/N[3:0]

Bank 114

MGTREFCLK0 P/N

MGTTX

P/N[7:4]

MGTRX P/N[7:4]

U14

Q1/NQ1

Q0/NQ0

CLK/NCLKU9Q/NQ

J42

H-2X3

PCIE_PRSNT_B

PCIE_PRSNT_X8

PCIE_PRSNT_X4

PCIE_PRSNT_X1

UG534_12_111709

9. PCI Express Endpoint Connectivity

The 8-lane PCIe edge connector performs data transfers at the rate of 2.5 GT/s for a Gen1 application and 5.0 GT/s for a Gen2 application. The Virtex FPGA GTX MGTs are used for the multi-gigabit per second serial interfaces.

The ML605 board trace impedance on all PCIe lanes supports both Gen1 and Gen2 applications. The ML605 supports up to Gen1 x8 and Gen2 x4 as shipped with a -1 speed grade for the LX240T device.

Figure 1-11 is a diagram of the PCIe MGT bank 114 and 115 clocking.

X-Ref Target - Figure 1-11

34 www.xilinx.com ML605 Hardware User Guide

Figure 1-11: PCIe MGT Banks 114 and 115 Clocking

PCIe lane width/size is selected via jumper J42 as shown in Figure 1-12. The default lane size selection is 1-lane (J42 pins 1 and 2 jumpered).

X-Ref Target - Figure 1-12

Figure 1-12: PCIe Lane Size Select Jumper J42

UG534 (v1.8) October 2, 2012

Tab le 1 -8 shows the PCIe connector (P1) that provides up to 8-lane access through the GTX

transceivers to the Virtex-6 FPGA integrated Endpoint block for PCIe designs.

Table 1-8: PCIe Edge Connector Connections

Detailed Description

U1 FPGA

F1 PCIE_TXO_P A16 PERp0

F2 PCIE_TXO_N A17 PERn0

H1 PCIE_TX1_P A21 PERp1

H2 PCIE_TX1_N A22 PERn1

K1 PCIE_TX2_P A25 PERp2

K2 PCIE_TX2_N A26 PERn2

M1 PCIE_TX3_P A29 PERp3

M2 PCIE_TX3_N A30 PERn3

P1 PCIE_TX4_P A35 PERp4

P2 PCIE_TX4_N A36 PERn4

T1 PCIE_TX5_P A39 PERp5

T2 PCIE_TX5_N A40 PERn5

V1 PCIE_TX6_P A43 PERp6

V2 PCIE_TX6_N A44 PERn6

Schematic Net Name

P1 PCIe Edge Connector

Pin Number Pin Name

Description

Integrated Endpoint block transmit pair

Package

Placement

GTXE1_X0Y15

GTXE1_X0Y14

GTXE1_X0Y13

GTXE1_X0Y12

GTXE1_X0Y11

GTXE1_X0Y10

GTXE1_X0Y9

Y1 PCIE_TX7_P A47 PERp7

Y2 PCIE_TX7_N A48 PERn7

J3 PCIE_RXO_P B14 PETp0

J4 PCIE_RXO_N B15 PETn0

K5 PCIE_RX1_P B19 PETp1

K6 PCIE_RX1_N B20 PETn1

L3 PCIE_RX2_P B23 PETp2

L4 PCIE_RX2_N B24 PETn2

N3 PCIE_RX3_P B27 PETp3

N4 PCIE_RX3_N B28 PETn3

R3 PCIE_RX4_P B33 PETp4

R4 PCIE_RX4_N B34 PETn4

U3 PCIE_RX5_P B37 PETp5

U4 PCIE_RX5_N B38 PETn5

W3 PCIE_RX6_P B41 PETp6

W4 PCIE_RX6_N B42 PETn6

Integrated Endpoint block transmit pair

Integrated Endpoint block receive pair

GTXE1_X0Y8

GTXE1_X0Y15

GTXE1_X0Y14

GTXE1_X0Y13

GTXE1_X0Y12

GTXE1_X0Y11

GTXE1_X0Y10

GTXE1_X0Y9

ML605 Hardware User Guide www.xilinx.com 35

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

Table 1-8: PCIe Edge Connector Connections (Cont’d)

U1 FPGA

Schematic Net Name

AA3 PCIE_RX7_P B45 PETp7

AA4 PCIE_RX7_N B46 PETn7

P1 PCIe Edge Connector

Description

Pin Number Pin Name

Integrated Endpoint block receive pair

P6 PCIE_100M_MGT0_P U14.16 Q0 Sourced from U14 ICS854104

P5 PCIE_100M_MGT0_N U14.15 NQ0 clock driver

V6 PCIE_250M_MGT1_P U9.18 Q Sourced from U9 ICS874001

V5 PCIE_250M_MGT1_N U9.17 NQ clock multiplier/driver

U14.6 PCIE_CLK_QO_P A13 REFCLK+ Integrated Endpoint block

differential clock pair from PCIe

U14.7 PCIE_CLK_QO_N A14 REFCLK-

edge connector

J42.2,4,6 PCIE_PRSNT_B A1 PRSNT#1 J42 Lane Size Select jumper

Integrated Endpoint block wake

AD22 PCIE_WAKE_B B11 WAKE#

signal, not connected on ML605 board

AE13 PCIE_PERST_B A11 PERST

Notes:

1. PCIE_TXn_P/N pairs are capacitively coupled to FPGA

2. PCIE_100M_MGT0_P/N pairs are capacitively coupled to FPGA

3. PCIE_250M_MGT1_P/N pairs are capacitively coupled to FPGA

4. PCIE_PERST_B is level-shifted by U32

5. For ML605, access is through MGT Banks 114 and 115

Integrated Endpoint block reset signal

Package

Placement

GTXE1_X0Y8

IBUF_

GTXE1_X0Y6

IBUF_

GTXE1_X0Y4

The PCIe interface obtains its power from the DC power supply provided with the ML605 or through the 12V ATX power supply connector. The PCIe edge connector is not used for any power connections.

The board can be powered by one of two 12V sources; J60, a 6-pin (2x3) molex-type connector and J25, a 4-pin (inline) ATX disk drive type connector.

The 6-pin molex-type connector provides 60W (12V @ 5A) from the AC power adapter provided with the board while the 4-pin ATX disk drive connector is provided for users who want to power their board while it is installed inside a PC chassis.

For applications requiring additional power, such as the use of expansion cards drawing significant power, a larger AC adapter might be required. If a different AC adapter is used, its load regulation should be better than ±10%.

ML605 power switch SW2 turns the board on and off by controlling the 12V supply to the board.

Caution!

connector (J25) at the same time as this will result in damage to the board. See Figure 1-23,

page 55. Never connect an auxiliary PCIe 6-pin molex power connector to J60 6-pin molex on

the ML605 board as this could result in damage to the PCIe motherboard and/or ML605 board. The 6-pin molex connector is marked with a no PCIe power label to warn users of the potential hazard.

Never apply power to the power brick connector (J60) and the 4-pin ATX disk drive

36 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

References

See the following websites for more Virtex-6 FPGA Integrated Endpoint Block for PCI Express information:

• http://www.xilinx.com/products/ipcenter/V6_PCI_Express_Block.htm

• http://www.xilinx.com/support/documentation/ipbusinterfacei-o_pci-

express_v6pciexpressendpointblock.htm

In addition, see the PCI Express specifications for more information. [Ref 27]

10. SFP Module Connector

The board contains a small form-factor pluggable (SFP) connector and cage assembly that accepts SFP modules. The SFP interface is connected to MGT Bank 116 on the FPGA. The SFP module serial ID interface is connected to the “SFP” IIC bus (see 15. IIC Bus, page 44 for more information). The control and status signals for the SFP module are connected to jumpers and test points as described in Tab le 1- 9. The SFP module connections are shown in Table 1-10, page 38.

Table 1-9: SFP Module Control and Status

Detailed Description

SFP Control/Status

Signal

SFP_TX_FAULT

SFP_TX_DISABLE

SFP_MOD_DETECT

SFP_RT_SEL

SFP_LOS

Board Connection

Test Point J52

High = Fault

Low = Normal Operation

Jumper J65

Off = SFP Disabled

On = SFP Enabled

Test Point J53

High = Module Not Present

Low = Module Present

Jumper J54

Jumper Pins 1-2 = Full Bandwidth

Jumper Pins 2-3 = Reduced Bandwidth

Test Point J51

High = Loss of Receiver Signal

Low = Normal Operation

ML605 Hardware User Guide www.xilinx.com 37

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

Table 1-10: SFP Module Connections

U1 FPGA Pin Schematic Net Name

E3 SFP_RX_P 13 RDP_13

E4 SFP_RX_N 12 RDN_12

C3 SFP_TX_P 18 TDP_18

C4 SFP_TX_N 19 TDN_19

V23 SFP_LOS 8 LOS

AP12 SFP_TX_DISABLE

Notes:

1. The SFP TX Disable pin 3 is driven by transistor Q22, the base of which is driven by the FPGA signal SFP_TX_DISABLE_FPGA.

11. 10/100/1000 Tri-Speed Ethernet PHY

The ML605 utilizes the onboard Marvell Alaska PHY device (88E1111) for Ethernet communications at 10, 100, or 1000 Mb/s. The board supports MII, GMII, RGMII, and SGMII interfaces from the FPGA to the PHY (Tab le 1 -11 ). The PHY connection to a userprovided Ethernet cable is through a Halo HFJ11-1G01E RJ-45 connector with built-in magnetics.

(1)

P4 SFP Module Connector

Pin Number Pin Name

3TX_DISABLE

Table 1-11: PHY Default Interface Mode

Jumper Settings

Mode

J66 J67 J68

GMII/MII to copper

(default)

SGMII to copper,

no clock

Jumper over pins 1-2 Jumper over pins 1-2 No jumper

Jumper over pins 2-3 Jumper over pins 2-3 No jumper

RGMII Jumper over pins 1-2 No jumper Jumper on

On power-up, or on reset, the PHY is configured to operate in GMII mode with PHY address 0b00111 using the settings shown in Ta bl e 1 -1 2. These settings can be overwritten via software commands passed over the MDIO interface.

Table 1-12: Board Connections for PHY Configuration Pins

Connection on

CFG0 V

Board

2.5V PHYADR[2] = 1 PHYADR[1] = 1 PHYADR[0] = 1

Definition and Value

Bit[2]

Bit[1]

Definition and Value

Bit[0]

Definition and Value

CFG1 Ground ENA_PAUSE = 0 PHYADR[4] = 0 PHYADR[3] = 0

CFG2 V

CFG3 V

CFG4 V

2.5V ANEG[3] = 1 ANEG[2] = 1 ANEG[1] = 1

2.5V ANEG[0] = 1 ENA_XC = 1 DIS_125 = 1

2.5V HWCFG_MD[2] = 1 HWCFG_MD[1] = 1 HWCFG_MD[0] = 1

38 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

Detailed Description

VDDA_SGMIICLK

ICS84402II

VDDA VDD

VDD_SGMIICLK

SGMIICLK_QO_C_P

SGMIICLK_QO_P

SGMIICLK_QO_N

SGMIICLK_QO_C_N

NQ0

GND

XTAL_OUT

XTAL_IN

U82

125.00 MHz Clock

GND_SGMIICLK

SGMIICLK_XTAL_OUT

SGMIICLK_XTAL_IN

25.000MHZ

R132 DNP 1% 1/16W

C55 1

0.1UF

10V 2

X5R

C347

33PF

50V

NPO

C56 1

0.1UF

10V 2

X5R

C348

33PF

50V

NPO

UG534_13_111709

Table 1-12: Board Connections for PHY Configuration Pins (Cont’d)

X-Ref Target - Figure 1-13

Connection on

Board

Definition and Value

Bit[2]

Bit[1]

Definition and Value

CFG5 VCC 2.5V DIS_FC = 1 DIS_SLEEP = 1 HWCFG_MD[3] = 1

CFG6 PHY_LED_RX SEL_BDT = 0 INT_POL = 1 75/50Ω= 0

SGMII GTX Transceiver Clock Generation

An Integrated Circuit Systems ICS844021I chip generates a high-quality, low-jitter, 125MHz LVDS clock from an inexpensive 25-MHz crystal oscillator. This clock is sent to the GTX driving the SGMII interface. Series AC coupling capacitors are also present to allow the clock input of the FPGA to set the common mode voltage.

Figure 1-13: Ethernet SGMII Clock - 125 MHz

Bit[0]

Tab le 1 -13 shows the connections and pin numbers for the PHY.

Table 1-13: Ethernet PHYConnections

U80 M88E1111

U1 FPGA Pin Schematic Net Name

Pin Number Pin Name

AN14 PHY_MDIO 33 MDIO

AP14 PHY_MDC 35 MDC

AH14 PHY_INT 32 INT_B

AH13 PHY_RESET 36 RESET_B

AL13 PHY_CRS 115 CRS

AK13 PHY_COL 114 COL

AP11 PHY_RXCLK 7 RXCLK

AG12 PHY_RXER 8 RXER

AM13 PHY_RXCTL_RXDV 4 RXDV

AN13 PHY_RXD0 3 RXD0

AF14 PHY_RXD1 128 RXD1

AE14 PHY_RXD2 126 RXD2

AN12 PHY_RXD3 125 RXD3

ML605 Hardware User Guide www.xilinx.com 39

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

Table 1-13: Ethernet PHYConnections (Cont’d)

U1 FPGA Pin Schematic Net Name

Pin Number Pin Name

AM12 PHY_RXD4 124 RXD4

AD11 PHY_RXD5 123 RXD5

AC12 PHY_RXD6 121 RXD6

AC13 PHY_RXD7 120 RXD7

AH12 PHY_TXC_GTXCLK 14 GTXCLK

AD12 PHY_TXCLK 10 TXCLK

AH10 PHY_TXER 13 TXER

AJ10 PHY_TXCTL_TXEN 16 TXEN

AM11 PHY_TXD0 18 TXD0

AL11 PHY_TXD1 19 TXD1

AG10 PHY_TXD2 20 TXD2

AG11 PHY_TXD3 24 TXD3

AL10 PHY_TXD4 25 TXD4

AM10 PHY_TXD5 26 TXD5

U80 M88E1111

AE11 PHY_TXD6 28 TXD6

AF11 PHY_TXD7 29 TXD7

A3 SGMII_TX_P 113 SIN_P

A4 SGMII_TX_N 112 SIN_N

B5 SGMII_RX_P 107 SOUT_P

B6 SGMII_RX_N 105 SOUT_N

References

See the Marvell Alaska Gigabit Ethernet Transceivers product page for more information.

[Ref 28]

Also, see the LogiCORE™ IP Tri-Mode Ethernet MAC User Guide. [Ref 19]

40 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

12. USB-to-UART Bridge

The ML605 contains a Silicon Labs CP2103GM USB-to-UART bridge device (U34) which allows connection to a host computer with a USB cable. The USB cable is supplied in this evaluation kit (Type A end to host computer, Type Mini-B end to ML605 connector J21).

Tab le 1 -14 details the ML605 J21 pinout.

Xilinx UART IP is expected to be implemented in the FPGA fabric (for instance, Xilinx XPS

UART Lite. The FPGA supports the USB-to-UART bridge using four signal pins: Transmit

(TX), Receive (RX), Request to Send (RTS), and Clear to Send (CTS).

Silicon Labs provides royalty-free Virtual COM Port (VCP) drivers which permit the CP2103GM USB-to-UART bridge to appear as a COM port to host computer communications application software (for example, HyperTerm or TeraTerm). The VCP device driver must be installed on the host PC prior to establishing communications with the ML605. Refer to the evaluation kit Getting Started Guide for driver installation instructions.

Table 1-14: USB Type B Pin Assignments and Signal Definitions

Detailed Description

USB Connector

1 VBUS +5V from host system (not used)

2 USB_DATA_N Bidirectional differential serial data (N-side)

3 USB_DATA_P Bidirectional differential serial data (P-side)

4 GROUND Signal ground

Signal Name Description

Table 1-15: USB-to-UART Connections

U1 FPGA Pin

T24 RTS, output USB_1_CTS 22 CTS, input

T23 CTS, input USB_1_RTS 23 RTS, output

J25 TX, data out USB_1_RX 24 RXD, data in

J24 RX, data in USB_1_TX 25 TXD, data out

UART function

in FPGA

Schematic Net

Name

U34 CP2103GM

UART Function

in CP2103GM

References

Refer to the Silicon Labs website for technical information on the CP2103GM and the VCP drivers.

In addition, see some of the Xilinx UART IP specifications at:

• http://www.xilinx.com/support/documentation/ip_documentation/xps_uartlite.pdf

• http:

ML605 Hardware User Guide www.xilinx.com 41

UG534 (v1.8) October 2, 2012

www.xilinx.com/support/documentation/ip_documentation/xps_uart16550.pdf

Chapter 1: ML605 Evaluation Board

13. USB Controller

The ML605 provides USB support via a Cypress CY7C67300 EZ-Host™ Programmable Embedded USB Host and Peripheral Controller (U81). The host port is a USB Type-A connector (J5). A USB keyboard (without an internal USB hub) will be able to connect to this USB Host port to demonstrate functionality. The peripheral port is a USB Type Mini-B (J20).

Table 1-16: USB Controller Connections

U1 FPGA

Y32 USB_A0_LS 52 GPIO19_A0_CS0_52

W26 USB_A1_LS 50 50_GPIO20_A1_CS1

W27 USB_CS_B_LS 49 49_GPIO21_CS_N

R33 USB_D0_LS 94 GPIO0_D0_94

R34 USB_D1_LS 93 GPIO1_D1_93

T30 USB_D2_LS 92 GPIO2_D2_92

T31 USB_D3_LS 91 GPIO3_D3_91

T29 USB_D4_LS 90 GPIO4_D4_90

V28 USB_D5_LS 89 GPIO5_D5_89

V27 USB_D6_LS 87 GPIO6_D6_87

U25 USB_D7_LS 86 GPIO7_D7_86

Y28 USB_D8_LS 66 GPIO8_D8_MISO_66

W32 USB_D9_LS 65 GPIO9_D9_nSSI_65

W31 USB_D10_LS 61 GPIO10_D10_SCK_61

Y29 USB_D11_LS 60 GPIO11_D11_MOSI_60

Schematic Net Name

Number

Pin Name

U81 USB Controller

W29 USB_D12_LS 59 GPIO12_D12_59

Y34 USB_D13_LS 58 GPIO13_D13_58

Y33 USB_D14_LS 57 GPIO14_D14_57

Y31 USB_D15_LS 56 GPIO15_D15_SSI_N_56

Y27 USB_INT_LS 46 46_GPIO24_INT_IORDY_IRQ0

W25 USB_RD_B_LS 47 47_GPIO23_RD_N_IOR

T25 USB_RESET_B_LS 85 RESET_N_85

V25 USB_WR_B_LS 48 48_GPIO22_WR_N_IOW

References

See the Cypress CY7C67300 Data Sheet for more information. [Ref 29]

In addition, see the USB Specifications for more information. [Ref 30]

The FPGA requires implementation of a peripheral controller in order to communicate with the Cypress USB device. See the XPS External Peripheral Controller (EPC) v1.02a Data Sheet for more information. [Ref 20]

42 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

14. DVI Codec

The ML605 features a DVI connector (P3) to support an external video monitor. The DVI circuitry utilizes a Chrontel CH7301C (U38) capable of 1600 X 1200 resolution with 24-bit color. The video interface chip drives both the digital and analog signals to the DVI connector. A DVI monitor can be connected to the board directly. A VGA monitor can also be connected to the board using the supplied DVI-to-VGA adaptor. The Chrontel CH7301C is controlled by way of the video IIC bus.

The DVI connector (Ta bl e 1 -17 ) supports the IIC protocol to allow the board to read the monitor's configuration parameters. These parameters can be read by the FPGA using the DVI IIC bus (see 15. IIC Bus, page 44).

Table 1-17: DVI Controller Connections

Detailed Description

U1 FPGA Pin Schematic Net Name

AJ19 DVI_D0 63 D0

AH19 DVI_D1 62 D1

AM17 DVI_D2 61 D2

AM16 DVI_D3 60 D3

AD17 DVI_D4 59 D4

AE17 DVI_D5 58 D5

AK18 DVI_D6 55 D6

AK17 DVI_D7 54 D7

AE18 DVI_D8 53 D8

AF18 DVI_D9 52 D9

AL16 DVI_D10 51 D10

AK16 DVI_D11 50 D11

AD16 DVI_DE 2 DE

AN17 DVI_H 4 H

U38 Chrontel CH7301C

Pin Number Pin Name

AP17 DVI_RESET_B_LS 13 RESET_B

AD15 DVI_V 5 V

AC17 DVI_XCLK_N 56 XCLK_N

AC18 DVI_XCLK_P 57 XCLK_P

No Connect DVI_GPIO0 8 GPIO0

No Connect DVI_GPIO1 7 GPIO1

ML605 Hardware User Guide www.xilinx.com 43

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

15. IIC Bus

The ML605 implements four IIC bus interfaces at the FPGA.

The "MAIN" IIC bus hosts four items:

• FPGA U1 Bank 34 "MAIN" IIC interface

•8Kb NV Memory U6

• FMC HPC connector J64

• DDR3 SODIMM Socket J1

The "DVI" IIC bus hosts two items:

• FPGA U1 Bank 34 "DVI" IIC interface

• DVI codec U38 and DVI connector J63

The "LPC" IIC bus hosts two items:

• FPGA U1 Bank 33 "LPC" IIC interface

• FMC LPC connector J63

The "SFP" IIC bus hosts two items:

• FPGA U1 Bank 13 "SFP" IIC interface

• SFP module connector P4

The ML605 IIC bus topology is shown in Figure 1-14.

44 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

X-Ref Target - Figure 1-14

BANK 34

BANK 13

BANK 34

FPGA IIC

INTERFACE

BANK 33

J63

FMC LPC

COLUMN C

2 Kb EEPROM on

any FMC LPC

Mezzanine Card

Addr: 0b1010001

DVI CONN

Addr: 0b1010000

U38

DVI CODEC CHRONTEL CH730C-TF

Addr: 0b1110110

IIC_SDA_MAIN_LS

IIC_SCL_MAIN_LS IIC_SDA_SFP IIC_SCL_SFP

IIC_SDA_DVI

IIC_SCL_DVI

FMC_LPC_IIC_SDA_LS

FMC_LPC_IIC_SCL_LS

LEVEL

SHIFTER

FMC_LPC_IIC_SCL

FMC_LPC_IIC_SDA

IIC_CLK_DVI_F

IIC_SDA_DVI_F

LEVEL

SHIFTER

LEVEL

SHIFTER

LEVEL

SHIFTER

IIC_SCL_MAIN

IIC_SDA_MAIN

SFP_MOD_DEF2

SFP_MOD_DEF1

Detailed Description

ST MICRO

M24C08-WDW6TP

Addr: 0b1010100 through

0b1010111

J64

FMC HPC

COLUMN C

2 Kb EEPROM on

any FMC LPC

Mezzanine Card

Addr: 0b1010000

DDR3 SODIMM

SOCKET

Addr: 0b1010011 2 Kb EEPROM Addr: 0b0011011 Temperature Sensor

SFP MODULE CONNECTOR

Addr: 0b1010000

UG534_14_092109

Figure 1-14: IIC Bus Topology

ML605 Hardware User Guide www.xilinx.com 45

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

8 Kb NV Memory

The ML605 hosts an 8 Kb ST Microelectronics M24C08-WDW6TP IIC parameter storage memory device (U6). The IIC address of U7 is 0b1010100, and U6 is not write protected (WP pin 7 is tied to GND).

The IIC memory is shown in Figure 1-15.

X-Ref Target - Figure 1-15

VCC3V3

IIC SCL MAIN

IIC SDA MAIN

R414

1/16W

05%

R305 DNP 1% 1/16W

IIC Address = 0b1010100

1/16W

R414

R413

SCL

SDA

M24C08-WDW6TP

VCC GND

VCC3V3 VCC3V3

Figure 1-15: IIC Memory U6

Table 1-18: IIC Memory Connections

IIC Memory U6

FPGA U1 Pin Schematic Net Name

Pin Number Pin Name

Not Applicable Tied to GND 1 A0

Not Applicable Tied to GND 2 A1

C65 X5R 10V

0.1UF

UG534_15_072109

Not Applicable Pulled up (0Ω) to VCC3V3 3 A2

AE9 IIC_SDA_MAIN 5 SDA

AK9 IIC_SCL_MAIN 6 SCL

Not Applicable Tied to GND 7 WP

References

See the ST Micro M24C08 Data Sheet for more information. [Ref 31]

In addition, see the Xilinx XPS IIC Bus Interface (v2.00a) Data Sheet. [Ref 21]

46 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

Detailed Description

16. Status LEDs

Tab le 1 -19 defines the status LEDs.

Table 1-19: Status LEDs

Designator Signal Name Color Label Description

DS1 SYSACE_STAT_LED GREEN System ACE CF

Status LED

DS2 TI_PWRGOOD and

MGT_TI_PWRGOOD

DS13 FPGA_DONE GREEN DONE FPGA configured successfully

DS23 LED_GRN GREEN STATUS USB JTAG Connection Status

LED_RED RED

DS25 12V GREEN 12V 12V Power On

DS27 MGT_AVCC GREEN AVCC GD MGT AVCC Power On

DS28 MGT_AVTT GREEN MGT_AVTT MGT AVTT Power On

DS29 DDR3_VTTDDR_PWRGOOD GREEN DDR3 PWR GD DDR3 VTTDDR Power Good

DS30 SYSACE_ERR_LED RED System ACE CF

DS31 FPGA_INIT_B RED INIT FPGA Initialization in progress

DS32 DVI_GPIO1_FMC_C2M_PG GREEN FMC PWR GD FMC Power Good

GREEN POWER GOOD Both UCD9240 controllers

Error LED

System ACE CF Status

report power good

(Dual LED)

System ACE CF Error

ML605 Hardware User Guide www.xilinx.com 47

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

Direction Indicator

Link Rate

(Mbps)

DUP TX RX

100

1000

End view of ML605 Ethernet jack and status LEDs when installed vertically in a PC chassis

UG534_16_101209

Ethernet PHY Status LEDs

The Ethernet PHY status LEDs are mounted to be visible when the ML605 board is installed into a PC motherboard. They are mounted in right-angle, plastic housings and can be seen on the connector end of the board. This cluster of six LEDs is installed adjacent to the RJ45 Ethernet jack P2.

X-Ref Target - Figure 1-16

Figure 1-16: Ethernet PHY Status LEDs

48 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

X-Ref Target - Figure 1-17

FPGA INIT B

NDS336P

FPGA_DONE

VCC2V5

Q14

R419 330 5% 1/16W

27.4 1% 1/16W

DS31

DS13

3 2

LED-RED-SMT

LED-GRN-SMT

UG534_17_050510

Detailed Description

FPGA INIT and DONE LEDs

The typical Xilinx FPGA power up and configuration status LEDs are present on the ML605.

The red INIT LED DS31 comes on momentarily after the FPGA powers up and during its internal power-on process. The DONE LED DS13 comes on after the FPGA programming bitstream has been downloaded and the FPGA successfully configured.

ML605 Hardware User Guide www.xilinx.com 49

UG534 (v1.8) October 2, 2012

Table 1-20: FPGA INIT and DONE LED Connections

17. User I/O

The ML605 provides the following user and general purpose I/O capabilities:

• User LEDs (8) with parallel wired GPIO male pin header

• User Pushbutton (5) switches with associated direction LEDs

• CPU Reset pushbutton switch

•User DIP switch (8-pole)

• User SMA GPIO

• LCD Display (16 char x 2 lines)

Figure 1-17: FPGA INIT and DONE LEDs

FPGA U1 Pin Schematic Net Name Controlled LED

P8 FPGA_INIT_B DS31 INIT, Red

R8 FPGA_DONE DS13 DONE, Green

Chapter 1: ML605 Evaluation Board

User LEDs

The ML605 provides two groups of active-High LEDs as described in Figure 1-18 and

Tab le 1 -2 1.

X-Ref Target - Figure 1-18

J62

GPIO_LED_0 GPIO_LED_1

GPIO_LED_2 GPIO_LED_3

GPIO_LED_4

GPIO_LED_5

GPIO_LED_6

GPIO_LED_7

1 2

H-1X8

LED-GRN-SMT

27.4 1% 1/16W

GPIO_LED_C

GPIO_LED_W GPIO_LED_E

GPIO_LED_S

GPIO_LED_N

DS14

LED-GRN-SMT

27.4 1%

1/16W

DS21

LED-GRN-SMT

27.4 1%

1/16W

DS22

This group of LEDs is mounted adjacent to their respective “direction” pushbuttons, as seen on the right side of the LCD on the board photo (Figure 1-2).

DS15

LED-GRN-SMT

27.4 1%

1/16W

DS10

LED-GRN-SMT

DS20

LED-GRN-SMT

GPIO_LED_N_R

R13

27.4 1%

1/16W

27.4 1% 1/16W

DS18

DS9

LED-GRN-SMT

GPIO_LED_S_R

R14

27.4 1% 1/16W

LED-GRN-SMT

R10

27.4 1% 1/16W

DS19

GPIO_LED_E_R

DS11

LED-GRN-SMT

R15

27.4 1% 1/16W

LED-GRN-SMT

R11

27.4 1% 1/16W

DS17

LED-GRN-SMT

GPIO_LED_W_R

R16

27.4 1%

1/16W

DS12

LED-GRN-SMT

R12

27.4 1%

1/16W

DS16

LED-GRN-SMT

GPIO_LED_C_R

R17

27.4 1%

1/16W

UG534_18_081109

Figure 1-18: User LEDs and GPIO Connector, Directional LEDs

Note:

50 www.xilinx.com ML605 Hardware User Guide

See User Pushbutton Switches, page 51 for more details about the LEDs.

UG534 (v1.8) October 2, 2012

Table 1-21: User LED Connections

CPU RESET

VCC1V5

Pushbutton

4.7K

R401

1/16W

sw10

UG534_19_072109

FPGA U1 Pin Schematic Net Name GPIO J62 Pin Controlled LED

AC22 GPIO_LED_0 1 DS12

AC24 GPIO_LED_1 2 DS11

AE22 GPIO_LED_2 3 DS9

AE23 GPIO_LED_3 4 DS10

AB23 GPIO_LED_4 5 DS15

AG23 GPIO_LED_5 6 DS14

AE24 GPIO_LED_6 7 DS22

AD24 GPIO_LED_7 8 DS21

AP24 GPIO_LED_C – DS16

AD21 GPIO_LED_W – DS17

AE21 GPIO_LED_E – DS19

AH28 GPIO_LED_S – DS18

Detailed Description

X-Ref Target - Figure 1-19

AH27 GPIO_LED_N – DS20

User Pushbutton Switches

The ML605 provides six active-High pushbutton switches:

• SW5, SW6, SW7, SW8 and SW9, arranged in a diamond configuration to depict “directional” headings North, South, East, West and Center respectively

• SW10 CPU Reset pushbutton

The six pushbuttons all have the same active-High topology as the sample shown in

Figure 1-19. The five directional pushbuttons are assigned as GPIO and the sixth is assigned

as CPU_RESET. Figure 1-19 and Tabl e 1 -2 2, pag e 5 2 describe the pushbutton switches.

ML605 Hardware User Guide www.xilinx.com 51

UG534 (v1.8) October 2, 2012

Figure 1-19: User Pushbutton Switch (Typical)

Chapter 1: ML605 Evaluation Board

Table 1-22: User Pushbutton Switch Connections

X-Ref Target - Figure 1-20

User DIP Switch

The ML605 includes an active-High eight pole DIP switch as described in Figure 1-20 and

Tab le 1 -2 3.

GPIO DIP SW1 GPIO DIP SW2 GPIO DIP SW3 GPIO DIP SW4 GPIO DIP SW5 GPIO DIP SW6

GPIO DIP SW7 GPIO DIP SW8

U1 FPGA Pin Schematic Net Name

A19 GPIO_SW_N SW5.2

A18 GPIO_SW_S SW6.2

G17 GPIO_SW_E SW7.2

H17 GPIO_SW_W SW8.2

G26 GPIO_SW_C SW9.2

H10 CPU_RESET SW10.2

Pushbutton

Switch Pin

SW1

1 2

4 5 6 7

VCC1V5

16 15

14 13 12

11 10

RP7

4.7K

4.7K61

4.7K

RP7

4.7K

RP7

4.7K

SDMX-8-X

Figure 1-20: User 8-pole DIP Switch

Table 1-23: User DIP Switch Connections

U1 FPGA Pin Schematic Net Name DIP Switch Pin

D22 GPIO_DIP_SW1 SW1.1

C22 GPIO_DIP_SW2 SW1.2

L21 GPIO_DIP_SW3 SW1.3

L20 GPIO_DIP_SW4 SW1.4

C18 GPIO_DIP_SW5 SW1.5

B18 GPIO_DIP_SW6 SW1.6

K22 GPIO_DIP_SW7 SW1.7

K21 GPIO_DIP_SW8 SW1.8

UG534_20_072109

52 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

X-Ref Target - Figure 1-21

UG534_21_072109

USER SMA GPIO N

J56 32K10K-400E3

J76 32K10K-400E3

GND1

SIG

GND2 GND3 GND4 GND5 GND6 GND7

GND1 GND2 GND3 GND4 GND5 GND6 GND7

USER SMA GPIO P

4 5 6 7

Detailed Description

User SMA GPIO

The ML605 includes an pair of SMA connectors for GPIO as described in Figure 1-21 and

Tab le 1 -2 4.

Figure 1-21: User SMA GPIO

Table 1-24: User SMA Connections

U1 FPGA Pin Schematic Net Name SMA Pin

W34 USER_SMA_GPIO_N J56.1

V34 USER_SMA_GPIO_P J57.1

ML605 Hardware User Guide www.xilinx.com 53

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

LCD Display (16 Character x 2 Lines)

The ML605 board has a 16-character x 2-line LCD (Display Tech S162D BA BC, installed onto J41 2x7 header) on the board to display text information. Potentiometer R270 adjusts the contrast of the LCD. A ST2378E (U33) 2.5V-to-5V level-shifter is used to shift the voltage level between the FPGA and the LCD. The data interface to the LCD is connected to the FPGA to support 4-bit mode only. The LCD module has a connector that allows the LCD to be removed from the board to access to the components below it.

X-Ref Target - Figure 1-22

LCD_DB7 LCD_DB5

LCD_E LCD_RS

Caution!

NC NC

Care should be taken not to scratch or damage the surface of the LCD window.

VCC5

J41

2 3 4 56 7 8 910

11 12

LCD_DB6 LCD_DB4 NC NC LCD_RW LCD_VEE

13 14

SSW-107-01-T-D

Figure 1-22: LCD Header J41 and Contrast Trimpot R270

Table 1-25: LCD Header Connections

U1 FPGA Pin Schematic Net Name J41 Pin

32 32

VCC5

R158

6.81K

R270 0-2K

1/2W 20%

silkscreen: “LCD Contrast”

UG534_22_073109

AD14 LCD_DB4_LS 4

AK11 LCD_DB5_LS 3

AJ11 LCD_DB6_LS 2

AE12 LCD_DB7_LS 1

AC14 LCD_RW_LS 10

T28 LCD_RS_LS 11

AK12 LCD_E_LS 9

54 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

X-Ref Target - Figure 1-23

UG534_23 _081209

N/C

12v

N/C

COM

39-30-1060

ATX Peripheral Cable Connector can plug into J25 when ML605 is in PC and the desk top AC adapter (brick) is not used.

J25

J60

12V

COM

350211-1

VCC12_P_IN

DPDT

VCC12_P

C280 330UF

16V ELEC

SW2

1201M2S3ABE2

R346

E1 E1

E2 E2

0.001R

I2I1

0.5% Y14880R00100B09R

R322

1.00K 1% 1/16W

DS25

LED-GRN-SMT

CAUTION!

DO NOT plug a PC ATX power supply 6-pin connector into the J60 connector on the ML605 board. The ATX 6-pin connector has a different pinout than J60 and will damage the ML605 board and void the board warranty.

DO NOT plug an auxilliary PCIe 6-pin molex power connector into the J60 connector as this could damage the PCIe motherboard and/or the ML605 board. J60 is marked with a NO PCIE POWER label to warn users of the poten- tial hazard.

DO NOT apply power to J60 and the 4-pin ATX disk drive connector J25 at the same time as this will d

amage the

ML605 board.

PCIe

Power

18. Switches

The ML605 Evaluation board includes the following switches:

• Power On/Off Slide Switch SW2

• FPGA_PROG_B SW4 (active-Low)

• SYSACE_RESET_B SW3 (active-Low)

• System ACE CF CompactFlash Image Select DIP Switch S1 (active-High)

• MODE, Boot EEPROM Select and CCLK Osc Enable DIP switch S2 (active-High)

Power On/Off Slide Switch SW2

SW2 is the ML605 board main power on/off switch. Sliding the switch actuator from the off to on position applies 12V power from either J60 (6-pin Mini-Fit) or J25 (4-pin ATX) power connector to the VCC12_P power plane via the 1m resistor R346. See 22. System Monitor, page 71 for further details on 12V input current sensing. Green LED DS25 will illuminate when the ML605 board power is on. See section

21. Power Management, page 67 for details on the onboard power system.

Detailed Description

Ω 1% 3W series current sense

ML605 Hardware User Guide www.xilinx.com 55

UG534 (v1.8) October 2, 2012

Figure 1-23: Power On/Off Slide Switch SW2

Chapter 1: ML605 Evaluation Board

FPGA_PROG_B Pushbutton SW4 (Active-Low)

This switch grounds the FPGA's PROG_B pin when pressed. This action clears the FPGA. See the Virtex-6 FPGA Data Sheet for more information on clearing the contents of the FPGA. [Ref 4]

X-Ref Target - Figure 1-24

VCC2V5

RP4

4.7K

FPGA PROG

Pushbutton

FPGA_PROG_B

SW4

Silkscreen:

PROG

UG534_24_073109

Figure 1-24: FPGA PROG_B Pushbutton SW4

SYSACE_RESET_B Pushbutton SW3 (Active-Low)

When the System ACE CF configuration mode pin is high (enabled by closing DIP switch S1 switch 4), the System ACE CF controller configures the FPGA from the CompactFlash card when a card is inserted or the SYSACE RESET button is pressed. See 5. System ACE

CF and CompactFlash Connector, page 26 for more details.

X-Ref Target - Figure 1-25

silkscreen:

SYSACE_RESET_B

“SYSACE RESET”

Pushbutton

SW3

UG534_25_073109

Figure 1-25: System ACE CF RESET_B Pushbutton SW3

56 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

Detailed Description

System ACE CF CompactFlash Image Select DIP Switch S1

System ACE CF CompactFlash (CF) image select DIP switch S1, switches 1–3, select which CF resident bitstream image is downloaded to the FPGA (Figure 1-26). S1 switches 1–3 offer eight binary addresses. When ON (High), the S1 switch 4 enables the System ACE CF controller to configure the FPGA from the CF card when a card is inserted or when the SYSACE RESET button is pressed. See 5. System ACE CF and CompactFlash Connector,

page 26 for more details about the System ACE controller.

X-Ref Target - Figure 1-26

VCC2V5

1/16W

510

1/16W

510

1/16W

510

R62

5 6 7

SDMX-4-X

2 1

123 4

R60

1.00K

1/16W

R59

1.00K

1/16W

1.00K

R61

1.00K

1/16W

SYSACE_CFGMODEPIN SYSACE_CFGADDR2 SYSACE_CFGADDR1 SYSACE_CFGADDR0

1/16W

R58

UG534_26_110409

R55

R64

R63

Figure 1-26: System ACE CF CompactFlash Image Select DIP Switch S1

Note:

S1 switch 4 is the System ACE controller enable switch. When ON, this switch allows the System ACE to boot at power-on if it finds a CF card present. In order to boot from BPI Flash U4 or Xilinx Platform Flash (U27) without System ACE contention, S1 switch 4 must be OFF.

ML605 Hardware User Guide www.xilinx.com 57

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

UG534_27_110409

SDMX-6-X

123 4

VCC2V5

1/16W

510

R57

1/16W

510

R52

R51

510

1/16W

CCLK EXTERNAL

P30_CS_SEL

FPGA_M0

FPGA_M1

FPGA_M2

FLASH_A23

1/16w5%1/16w5%1/16w5%1/16w5%1/16w5%1/16w

R43

R50

R53

R54

R55

R56

4.7K

Mode, Osc Enable, Boot EEPROM Select, and Addr Select DIP Switch S2

DIP switch S2 is a multi-purpose selector switch (Figure 1-27 and Table 1-27, page 59).

FPGA Mode: S2 switches 3, 4, and 5 control the FPGA mode (Ta bl e 1 -2 6).

Oscillator Enable: S2 switch 1, CCLK_EXTERNAL, controls the enable pin of the 47 MHz

oscillator SiT8102 (X4). When switch 1 is closed (CCLK_EXTERNAL High), X4 drives a 47 MHz clock onto the FPGA_CCLK signal.

Boot EEPROM Select: S2 switch 2 is used to select the between the Xilinx Platform Flash or the Numonyx Linear BPI Flash for the FPGA boot memory device.

Upper or Lower Address Select: S2 switch 6 is used to select the upper or lower half of flash memory U4 as the source of the FPGA bitstream image. When FLASH_A23 is High, the upper half of the address is selected. When FLASH_A23 is Low, the lower half of the address is selected.

X-Ref Target - Figure 1-27

Figure 1-27: Multi-Purpose Select DIP Switch S2

Tab le 1 -2 6 shows the FPGA configuration modes controlled by S2 switches 3, 4, and 5.

Table 1-26: ML605 Configuration Modes

Configuration Mode M[2:0] Bus Width CCLK

Master BPI-Up 010 8, 16 Output

JTAG 101 1 Input (TCK)

Slave SelectMAP 110 8, 16, 32 Input

58 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

Table 1-27: Switch S2 Configuration Details

Switch Configuration Mode/Method

Detailed Description

Switch Net Name

S2.1 CCLK_EXTERNAL Off On Off

S2.2 P30_CS_SEL On

S2.3 FPGA_M0 On Off Off

S2.4 FPGA_M1 Off On On

S2.5 FPGA_M2 On On Off

S2.6 FLASH_A23 Off Don't Care Off

Notes:

1. In JTAG mode, S2.2 is shown as ON for FPGA access to the P30 Linear Flash. Alternatively, set S2.2 to OFF for FPGA access to the Platform Flash XL.

2. In Master BPI mode, S2.6 is shown as OFF for selecting initial configuration from BPI address 0x000000. Alternatively, set S2.6 to ON to select initial configuration from BPI address 0x800000.

System ACE CF

See 3. 128 Mb Platform Flash XL, page 22 and 4. 32 MB Linear BPI Flash, page 22 for details.

19. VITA 57.1 FMC HPC Connector

The ML605 implements both the High Pin Count (HPC, J64) and Low Pin Count (LPC, J63) connector options of VITA 57.1.1 FMC specification. This section discusses the FMC HPC J64 connector.

JTAG

(1)

Slave SelectMAP

Platform Flash XL

Off On

Master BPI

P30 Linear Flash

(2)

Note:

from the ML605 board.

The FMC HPC J64 connector is a keyed connector oriented so that a plug-on card faces away

The FMC standard calls for two connector densities: a High Pin Count (HPC) and a Low Pin Count (LPC) implementation. A common 10 x 40 position (400 pin locations) connector form factor is used for both versions. The HPC version is fully populated with 400 pins present, and the LPC version is partially populated with 160 pins.

The 10 x 40 rows of a FMC HPC connector provides connectivity for:

• 160 single-ended or 80 differential user-defined signals

• 10 MGTs

•2 MGT clocks

•4 differential clocks

• 159 ground, 15 power connections

Of the above signal and clock connectivity capability, the ML605 implements the following subset:

• 78 differential user defined pairs:

• 34 LA pairs

• 24 HA pairs

• 20 HB pairs

•8 MGTs

ML605 Hardware User Guide www.xilinx.com 59

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

•2 MGT clocks

•4 differential clocks

Note:

at 2.5V (non-adjustable). The 2.5V rail cannot be turned off. The ML605 VITA 57.1 FMC interfaces are compatible with 2.5V mezzanine cards capable of supporting 2.5V VADJ.

The ML605 board VADJ voltage for the FMC HPC and LPC connectors (J64 and J63) is fixed

Tab le 1 -2 8 shows the VITA 57.1 FMC HPC connections. The connector pinout is in Appendix C, VITA 57.1 FMC LPC (J63) and HPC (J64) Connector Pinout.

Any signal named FMC_HPC_xxxx that is wired between a U1 FPGA pin and some other device does not appear in this table.

Table 1-28: VITA 57.1 FMC HPC Connections

J64 FMC

HPC Pin

A2 FMC_HPC_DP1_M2C_P AE3 B12 FMC_HPC_DP7_M2C_P AP5

A3 FMC_HPC_DP1_M2C_N AE4 B13 FMC_HPC_DP7_M2C_N AP6

A6 FMC_HPC_DP2_M2C_P AF5 B16 FMC_HPC_DP6_M2C_P AM5

A7 FMC_HPC_DP2_M2C_N AF6 B17 FMC_HPC_DP6_M2C_N AM6

A10 FMC_HPC_DP3_M2C_P AG3 B20 FMC_HPC_GBTCLK1_M2C_P AK6

A11 FMC_HPC_DP3_M2C_N AG4 B21 FMC_HPC_GBTCLK1_M2C_N AK5

A14 FMC_HPC_DP4_M2C_P AJ3 B32 FMC_HPC_DP7_C2M_P AP1

A15 FMC_HPC_DP4_M2C_N AJ4 B33 FMC_HPC_DP7_C2M_N AP2

A18 FMC_HPC_DP5_M2C_P AL3 B36 FMC_HPC_DP6_C2M_P AN3

A19 FMC_HPC_DP5_M2C_N AL4 B37 FMC_HPC_DP6_C2M_N AN4

A22 FMC_HPC_DP1_C2M_P AD1

A23 FMC_HPC_DP1_C2M_N AD2

A26 FMC_HPC_DP2_C2M_P AF1

A27 FMC_HPC_DP2_C2M_N AF2

A30 FMC_HPC_DP3_C2M_P AH1

Schematic Net Name

U1 FPGA

J64 FMC

HPC Pin

Schematic Net Name

U1 FPGA

A31 FMC_HPC_DP3_C2M_N AH2

A34 FMC_HPC_DP4_C2M_P AK1

A35 FMC_HPC_DP4_C2M_N AK2

A38 FMC_HPC_DP5_C2M_P AM1

A39 FMC_HPC_DP5_C2M_N AM2

C2 FMC_HPC_DP0_C2M_P AB1 D4 FMC_HPC_GBTCLK0_M2C_P AD6

C3 FMC_HPC_DP0_C2M_N AB2 D5 FMC_HPC_GBTCLK0_M2C_N AD5

C6 FMC_HPC_DP0_M2C_P AC3 D8 FMC_HPC_LA01_CC_P AK19

C7 FMC_HPC_DP0_M2C_N AC4 D9 FMC_HPC_LA01_CC_N AL19

60 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

Table 1-28: VITA 57.1 FMC HPC Connections (Cont’d)

Detailed Description

J64 FMC

HPC Pin

Schematic Net Name

U1 FPGA

J64 FMC

HPC Pin

Schematic Net Name

U1 FPGA

C10 FMC_HPC_LA06_P AG20 D11 FMC_HPC_LA05_P AG22

C11 FMC_HPC_LA06_N AG21 D12 FMC_HPC_LA05_N AH22

C14 FMC_HPC_LA10_P AM20 D14 FMC_HPC_LA09_P AM18

C15 FMC_HPC_LA10_N AL20 D15 FMC_HPC_LA09_N AL18

C18 FMC_HPC_LA14_P AN19 D17 FMC_HPC_LA13_P AP19

C19 FMC_HPC_LA14_N AN20 D18 FMC_HPC_LA13_N AN18

C22 FMC_HPC_LA18_CC_P AH25 D20 FMC_HPC_LA17_CC_P AN27

C23 FMC_HPC_LA18_CC_N AJ25 D21 FMC_HPC_LA17_CC_N AM27

C26 FMC_HPC_LA27_P AP30 D23 FMC_HPC_LA23_P AL26

C27 FMC_HPC_LA27_N AP31 D24 FMC_HPC_LA23_N AM26

C30 IIC_SCL_MAIN_LS

C31 IIC_SDA_MAIN_LS

(1)

AK9 D26 FMC_HPC_LA26_P AM25

AE9 D27 FMC_HPC_LA26_N AL25

D29 FMC_HPC_TCK_BUF

D30 FMC_TDI_BUF

D31 FMC_HPC_TDO

D33 FMC_TMS_BUF

(2)

U88.15

J17.1

J17.3

U88.17

E2 FMC_HPC_HA01_CC_P AD29 F1 FMC_HPC_PG_M2C_LS

(1)

J27

E3 FMC_HPC_HA01_CC_N AC29 F4 FMC_HPC_HA00_CC_P AE33

E6 FMC_HPC_HA05_P AB27 F5 FMC_HPC_HA00_CC_N AF33

E7 FMC_HPC_HA05_N AC27 F7 FMC_HPC_HA04_P AB28

E9 FMC_HPC_HA09_P AB30 F8 FMC_HPC_HA04_N AC28

E10 FMC_HPC_HA09_N AB31 F10 FMC_HPC_HA08_P AG31

E12 FMC_HPC_HA13_P AE31 F11 FMC_HPC_HA08_N AF31

E13 FMC_HPC_HA13_N AD31 F13 FMC_HPC_HA12_P AD32

E15 FMC_HPC_HA16_P AC33 F14 FMC_HPC_HA12_N AE32

E16 FMC_HPC_HA16_N AB33 F16 FMC_HPC_HA15_P AB32

E18 FMC_HPC_HA20_P V32 F17 FMC_HPC_HA15_N AC32

E19 FMC_HPC_HA20_N V33 F19 FMC_HPC_HA19_P U33

E21 FMC_HPC_HB03_P AL30 F20 FMC_HPC_HA19_N U32

E22 FMC_HPC_HB03_N AM31 F22 FMC_HPC_HB02_P AP32

E24 FMC_HPC_HB05_P AN33 F23 FMC_HPC_HB02_N AP33

ML605 Hardware User Guide www.xilinx.com 61

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

Table 1-28: VITA 57.1 FMC HPC Connections (Cont’d)

J64 FMC

HPC Pin

Schematic Net Name

U1 FPGA

J64 FMC

HPC Pin

Schematic Net Name

U1 FPGA

E25 FMC_HPC_HB05_N AN34 F25 FMC_HPC_HB04_P AM33

E27 FMC_HPC_HB09_P AL34 F26 FMC_HPC_HB04_N AL33

E28 FMC_HPC_HB09_N AK34 F28 FMC_HPC_HB08_P AK33

E30 FMC_HPC_HB13_P AH33 F29 FMC_HPC_HB08_N AK32

E31 FMC_HPC_HB13_N AH32 F31 FMC_HPC_HB12_P AJ31

E33 FMC_HPC_HB19_P AL31 F32 FMC_HPC_HB12_N AJ32

E34 FMC_HPC_HB19_N AK31 F34 FMC_HPC_HB16_P AH29

F35 FMC_HPC_HB16_N AH30

G2 FMC_HPC_CLK1_M2C_P AP20 H2 FMC_HPC_PRSNT_M2C_L

(1)

G3 FMC_HPC_CLK1_M2C_N AP21 H4 FMC_HPC_CLK0_M2C_P K24

G6 FMC_HPC_LA00_CC_P AF20 H5 FMC_HPC_CLK0_M2C_N K23

G7 FMC_HPC_LA00_CC_N AF21 H7 FMC_HPC_LA02_P AC20

G9 FMC_HPC_LA03_P AC19 H8 FMC_HPC_LA02_N AD20

G10 FMC_HPC_LA03_N AD19 H10 FMC_HPC_LA04_P AF19

AP25

G12 FMC_HPC_LA08_P AK22 H11 FMC_HPC_LA04_N AE19

G13 FMC_HPC_LA08_N AJ22 H13 FMC_HPC_LA07_P AK21

G15 FMC_HPC_LA12_P AM21 H14 FMC_HPC_LA07_N AJ21

G16 FMC_HPC_LA12_N AL21 H16 FMC_HPC_LA11_P AM22

G18 FMC_HPC_LA16_P AP22 H17 FMC_HPC_LA11_N AN22

G19 FMC_HPC_LA16_N AN23 H19 FMC_HPC_LA15_P AM23

G21 FMC_HPC_LA20_P AK23 H20 FMC_HPC_LA15_N AL23

G22 FMC_HPC_LA20_N AL24 H22 FMC_HPC_LA19_P AN25

G24 FMC_HPC_LA22_P AP27 H23 FMC_HPC_LA19_N AN24

G25 FMC_HPC_LA22_N AP26 H25 FMC_HPC_LA21_P AN29

G27 FMC_HPC_LA25_P AN28 H26 FMC_HPC_LA21_N AP29

G28 FMC_HPC_LA25_N AM28 H28 FMC_HPC_LA24_P AN30

G30 FMC_HPC_LA29_P AL28 H29 FMC_HPC_LA24_N AM30

G31 FMC_HPC_LA29_N AK28 H31 FMC_HPC_LA28_P AK27

G33 FMC_HPC_LA31_P AL29 H32 FMC_HPC_LA28_N AJ27

G34 FMC_HPC_LA31_N AK29 H34 FMC_HPC_LA30_P AJ24

G36 FMC_HPC_LA33_P AH23 H35 FMC_HPC_LA30_N AK24

62 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

Table 1-28: VITA 57.1 FMC HPC Connections (Cont’d)

Detailed Description

J64 FMC

HPC Pin

Schematic Net Name

U1 FPGA

J64 FMC

HPC Pin

Schematic Net Name

U1 FPGA

G37 FMC_HPC_LA33_N AH24 H37 FMC_HPC_LA32_P AG25

H38 FMC_HPC_LA32_N AG26

J2 FMC_HPC_CLK3_M2C_P

J3 FMC_HPC_CLK3_M2C_N

(2)

U84.6 K4 FMC_HPC_CLK2_M2C_P

U84.7 K5 FMC_HPC_CLK2_M2C_N

(2)

J6 FMC_HPC_HA03_P AA25 K7 FMC_HPC_HA02_P AB25

J7 FMC_HPC_HA03_N Y26 K8 FMC_HPC_HA02_N AC25

J9 FMC_HPC_HA07_P AA26 K10 FMC_HPC_HA06_P AA28

J10 FMC_HPC_HA07_N AB26 K11 FMC_HPC_HA06_N AA29

J12 FMC_HPC_HA11_P AG33 K13 FMC_HPC_HA10_P AD34

J13 FMC_HPC_HA11_N AG32 K14 FMC_HPC_HA10_N AC34

J15 FMC_HPC_HA14_P AA30 K16 FMC_HPC_HA17_CC_P V30

J16 FMC_HPC_HA14_N AA31 K17 FMC_HPC_HA17_CC_N W30

J18 FMC_HPC_HA18_P T33 K19 FMC_HPC_HA21_P U31

J19 FMC_HPC_HA18_N T34 K20 FMC_HPC_HA21_N U30

U83.6

U83.7

J21 FMC_HPC_HA22_P U28 K22 FMC_HPC_HA23_P U26

J22 FMC_HPC_HA22_N V29 K23 FMC_HPC_HA23_N U27

J24 FMC_HPC_HB01_P AN32 K25 FMC_HPC_HB00_CC_P AF30

J25 FMC_HPC_HB01_N AM32 K26 FMC_HPC_HB00_CC_N AG30

J27 FMC_HPC_HB07_P AJ34 K28 FMC_HPC_HB06_CC_P AF26

J28 FMC_HPC_HB07_N AH34 K29 FMC_HPC_HB06_CC_N AE26

J30 FMC_HPC_HB11_P AJ29 K31 FMC_HPC_HB10_P AF28

J31 FMC_HPC_HB11_N AJ30 K32 FMC_HPC_HB10_N AF29

J33 FMC_HPC_HB15_P AE28 K34 FMC_HPC_HB14_P AE27

J34 FMC_HPC_HB15_N AE29 K35 FMC_HPC_HB14_N AD27

J36 FMC_HPC_HB18_P AD25 K37 FMC_HPC_HB17_CC_P AG27

J37 FMC_HPC_HB18_N AD26 K38 FMC_HPC_HB17_CC_N AG28

Notes:

1. Signals ending with _LS are not directly connected to the FMC HPC connector. _LS signals are connected between the listed U1 FPGA pin and a level shifter device. The signal connected between the shifted side of said device and the FMC HPC pin listed has the same signal name, without the _LS on the end.

2. These signals do not connect to U1 FPGA pins. The pin numbers in the right-hand column identify the device and pin these signals are connected to (U88.17 = U88 pin 17, and so on).

ML605 Hardware User Guide www.xilinx.com 63

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

Table 1-29: Power Supply Voltages for HPC Connector

Voltag e Su pp l y

Allowable

Voltag e Ra ng e

No Pins Max Amps Tolerance

Max Capacitive

Load

VADJ Fixed 2.5V 4 4 +/- 5% 1000 uF

VIO_B_M2C 0-VADJ 2 1.15 +/- 5% 500 uF

VREF_A_M2C 0-VADJ 1 1 mA +/- 2% 10 uF

VREF_B_M2C 0-VIO_B_M2C 1 1 mA +/- 2% 10 uF

3P3VAUX 3.3V 1 20 mA +/- 5% 150 uF

3P3V 3.3V 4 3 +/- 5% 1000 uF

12P0V 12V 2 1 +/- 5% 1000 uF

64 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

20. VITA 57.1 FMC LPC Connector

The ML605 implements both the High Pin Count (HPC, J64) and Low Pin Count (LPC, J63) connector options of VITA 57.1.1 FMC specification. This section discusses the FMC LPC J63 connector.

Detailed Description

Note:

from the ML605 board.

The FMC LPC J63 connector is a keyed connector oriented so that a plug-on card faces away

The FMC standard calls for two connector densities: a High Pin Count (HPC) and a Low

Pin Count (LPC) implementation. A common 10 x 40 position (400 pin locations) connector form factor is used for both versions. The HPC version is fully populated with 400 pins present, and the LPC version is partially populated with 160 pins.

The 10 x 40 rows of a FMC LPC connector provides connectivity for:

• 68 single-ended or 34 differential user defined signals

•1 MGT

•1 MGT clock

•2 differential clocks

• 61 ground, 10 power connections

Of the above signal and clock connectivity capability, the ML605 implements the full set:

• 34 differential user-defined pairs:

• 34 LA pairs

•1 MGT

•1 MGT clock

•2 differential clocks

Signaling Speed Ratings:

• Single-ended: 9 GHz / 18 Gb/s

• Differential

• Optimal Vertical: 9 GHz / 18 Gb/s

• Optimal Horizontal: 16 GHz / 32 Gb/s

• High Density Vertical 7 GHz / 15 Gb/s

Mechanical specifications:

• Samtec SEAM/SEAF Series

• 1.27mm x 1.27mm (0.050" x 0.050") pitch

The Samtec connector system is rated for signaling speeds up to 9 GHz (18 Gb/s) based on a -3 dB insertion loss point within a two-level signaling environment.

Note:

at 2.5V (non-adjustable). The 2.5V rail cannot be turned off. The ML605 VITA 57.1 FMC interfaces are compatible with 2.5V mezzanine cards capable of supporting 2.5V VADJ.

The ML605 board VADJ voltage for the FMC HPC and LPC connectors (J64 and J63) is fixed

ML605 Hardware User Guide www.xilinx.com 65

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

Tab le 1 -3 0 shows the VITA 57.1 FMC LPC connections. The connector pinout is in Appendix C, VITA 57.1 FMC LPC (J63) and HPC (J64) Connector Pinout.

Any signal named FMC_LPC_xxxx that is wired between a U1 FPGA pin and some other device does not appear in this table.

Table 1-30: VITA 57.1 FMC LPC Connections

J63 FMC

LPC Pin

C2 FMC_LPC_DP0_C2M_P D1 D4 FMC_LPC_GBTCLK0_M2C_P M6

C3 FMC_LPC_DP0_C2M_N D2 D5 FMC_LPC_GBTCLK0_M2C_N M5

C6 FMC_LPC_DP0_M2C_P G3 D8 FMC_LPC_LA01_CC_P F31

C7 FMC_LPC_DP0_M2C_N G4 D9 FMC_LPC_LA01_CC_N E31

C10 FMC_LPC_LA06_P K33 D11 FMC_LPC_LA05_P H34

C11 FMC_LPC_LA06_N J34 D12 FMC_LPC_LA05_N H33

C14 FMC_LPC_LA10_P F30 D14 FMC_LPC_LA09_P L25

C15 FMC_LPC_LA10_N G30 D15 FMC_LPC_LA09_N L26

C18 FMC_LPC_LA14_P C33 D17 FMC_LPC_LA13_P D34

C19 FMC_LPC_LA14_N B34 D18 FMC_LPC_LA13_N C34

C22 FMC_LPC_LA18_CC_P L29 D20 FMC_LPC_LA17_CC_P N28

C23 FMC_LPC_LA18_CC_N L30 D21 FMC_LPC_LA17_CC_N N29

C26 FMC_LPC_LA27_P R31 D23 FMC_LPC_LA23_P R28

C27 FMC_LPC_LA27_N R32 D24 FMC_LPC_LA23_N R27

Schematic Net Name

U1 FPGA

J63 FMC

LPC Pin

D26 FMC_LPC_LA26_P L33

Schematic Net Name

U1 FPGA

D27 FMC_LPC_LA26_N M32

G2 FMC_LPC_CLK1_M2C_P F33 H2 FMC_LPC_PRSNT_M2C_L AD9

G3 FMC_LPC_CLK1_M2C_N G33 H4 FMC_LPC_CLK0_M2C_P A10

G6 FMC_LPC_LA00_CC_P K26 H5 FMC_LPC_CLK0_M2C_N B10

G7 FMC_LPC_LA00_CC_N K27 H7 FMC_LPC_LA02_P G31

G9 FMC_LPC_LA03_P J31 H8 FMC_LPC_LA02_N H30

G10 FMC_LPC_LA03_N J32 H10 FMC_LPC_LA04_P K28

G12 FMC_LPC_LA08_P J30 H11 FMC_LPC_LA04_N J29

G13 FMC_LPC_LA08_N K29 H13 FMC_LPC_LA07_P G32

G15 FMC_LPC_LA12_P E32 H14 FMC_LPC_LA07_N H32

G16 FMC_LPC_LA12_N E33 H16 FMC_LPC_LA11_P D31

G18 FMC_LPC_LA16_P A33 H17 FMC_LPC_LA11_N D32

G19 FMC_LPC_LA16_N B33 H19 FMC_LPC_LA15_P C32

66 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

Table 1-30: VITA 57.1 FMC LPC Connections (Cont’d)

Detailed Description

J63 FMC

LPC Pin

G21 FMC_LPC_LA20_P P29 H20 FMC_LPC_LA15_N B32

G22 FMC_LPC_LA20_N R29 H22 FMC_LPC_LA19_P M30

G24 FMC_LPC_LA22_P N27 H23 FMC_LPC_LA19_N N30

G25 FMC_LPC_LA22_N P27 H25 FMC_LPC_LA21_P R26

G27 FMC_LPC_LA25_P P31 H26 FMC_LPC_LA21_N T26

G28 FMC_LPC_LA25_N P30 H28 FMC_LPC_LA24_P N32

G30 FMC_LPC_LA29_P N34 H29 FMC_LPC_LA24_N P32

G31 FMC_LPC_LA29_N P34 H31 FMC_LPC_LA28_P N33

G33 FMC_LPC_LA31_P M31 H32 FMC_LPC_LA28_N M33

G34 FMC_LPC_LA31_N L31 H34 FMC_LPC_LA30_P M26

G36 FMC_LPC_LA33_P K32 H35 FMC_LPC_LA30_N M27

G37 FMC_LPC_LA33_N K31 H37 FMC_LPC_LA32_P N25

Schematic Net Name

U1 FPGA

J63 FMC

LPC Pin

H38 FMC_LPC_LA32_N M25

Schematic Net Name

U1 FPGA

References

See the data sheet for the ROHS compliant FMC HPC Samtec SEARAY connector (carrier side socket ASP-134486-01; module side plug ASP-134488-01), and the high-speed characterization report for this connector system on the Samtec website. [Ref 32]

21. Power Management

AC Adapter and Input Power Jack/Switch

The ML605 is powered from a 12V source that is connected through a 6-pin (2X3) rightangle Mini-Fit type connector J60. The AC-to-DC power supply included in the kit has a mating 6-pin plug.

When the ML605 is installed into a table top or tower PC's PCIe slot, the ML605 is typically powered from the PC ATX power supply. One of the ATX hard disk type 4-pin power connectors is plugged into ML605 connector J25. The ML605 can be powered with the AC power adapter even when plugged into a PC PCIe motherboard slot; however, users are cautioned not to also connect an ATX 4-pin power connector to J25. See the caution notes below and in Figure 1-23, page 55.

Caution!

The ATX 6-pin connector has a different pinout than ML605 J60, and connecting the ATX 6-pin connector will damage the ML605 and void the board warranty.

Caution! DO NOT apply power to J60 and the 4-pin ATX disk drive connector J25 at the same

time as this will damage the ML605 board. Refer to Figure 1-23, page 55 for details.

DO NOT plug a PC ATX power supply 6-pin connector into ML605 connector J60.

The ML605 power can be turned on or off through the board mounted slide switch SW2. When the switch is in the on position, a green LED (DS25) is illuminated.

ML605 Hardware User Guide www.xilinx.com 67

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

Onboard Power Regulation

Figure 1-28 shows the ML605 onboard power supply architecture. The ML605 uses power

solutions from Texas Instruments.

X-Ref Target - Figure 1-28

12V

PWR Jack

J25/J60

Power Supply

Linear Regulator TL1963

5.0V@1.5A max U8

Power Controller 1 UCD9240PFC U24

Switching Module PTD08A020W

1.00V@20A max U42

Switching Module PTD08A010W

2.50V@10A max U91

Switching Module PTD08A020W

2.5V@20A max U43

Linear Regulator TL1963A

1.8V@500mA max U79

VCC5

VCCINT

VCC2V5, FPGA_VCC2V5

VCCAUX

VCC1V8

Power Controller 2 UCD9240PFC U25

Switching Regulator UCD7230RG

1.00V@6A max U35

Switching Regulator UCD7230RG

1.20V@6A max U36

Switching Module PTD08A010W

1.5V@10A max U20

Switching Module PTD08A010W

3.3V@10A max U21

Sink/Source DDR Regulator

Linear Regulator TPS51200

0.75V@3A max U17

Figure 1-28: ML605 Onboard Power Regulators

MGT_AVCC

MGT_AVTT

VCC1V5, FPGA_VCC1V5

VCC3V3

VTTDDR

UG534_28_060311

68 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

Table 1-31: Onboard Power System Devices

Detailed Description

Device Type

UCD9240PFC

(1)

Reference

Designator

Description

U24 PMBus Controller - Core (Addr = 52) 35

Power Rail

Net Name

Power Rail

Voltag e

Schematic

Page

PTD08A020W U42 20A 0.6V - 3.6V Adj. Switching Regulator VCCINT_FPGA 1.00V 36

PTD08A020W U43 20A 0.6V - 3.6V Adj. Switching Regulator VCC2V5_FPGA 2.50V 37

PTD08A010W U91 10A 0.6V - 3.6V Adj. Switching Regulator VCCAUX 2.50V 38

UCD9240PFC

(2)

U25 PMBus Controller - Aux (Addr = 53) 40

UCD7230RGWR U35 6A 0.6V - 3.6V Adj. Switching Regulator MGT_AVCC 1.00V 41

UCD7230RGWR U36 6A 0.6V - 3.6V Adj. Switching Regulator MGT_AVTT 1.20V 42

PTD08A010W U20 10A 0.6V - 3.6V Adj. Switching Regulator VCC_1V5 1.50V 43

PTD08A010W U21 10A 0.6V - 3.6V Adj. Switching Regulator VCC_3V3 3.30V 44

TPS79518DCQR U79 500 mA Fixed Linear Regulator VCC_1V8 1.80V 45

TPS51200DRCT U17 3A DDR3 VTERM Tracking Linear

VTTDDR 0.75V 45

Regulator

TPS51200DRCT U17 10 mA Tracking Reference output VTTVREF 0.75V 45

TL1963 U8 1.5A Fixed Linear Regulator VCC5 5.00V 35

Notes:

1. See Tab le 1 -3 2., part 1 (addr 52)

2. See Tab le 1 -3 2., part 2 (addr 53)

Table 1-32: Power Rail Specifications (UCD9240 PMBus Controllers at Addresses 52 and 53)

Device Rail #

UCD9240 (Addr 52)

UCD9240 (Addr 53)

Rail

Name

Rail

Rail #1MGT

Rail #2MGT

Rail #3VCC1V5

Rail

Response

Shut

down

Shut

down

Schematic

Rail Name

VCCINT 1 0.925 0.9 5

VCC2V5 2.5 2.313 2.25 10 2.75

VCCAUX 2.5 2.325 2.25 5 2.8 9

_AVCC

_AVTT

_FPGA

VCC3V3 3.3 3.052 2.97 5 5 0 0 3.63

Vout

PG On

(V)

1.025 0.948 0.923

1.25 1.156 1.125 1.375

1.5 1.388 1.35 10 10 1.65

PG Off

(V)

Delay

(ms)

520

Off

Rise

Delay

(ms)

10510

510

Fall

(ms)

Vout Over Fault

(V)

1.1

1.128

Iout

Over

Fault

(A)

14.5

Response

Shut

down

Shut

down

Tem p

Over Fault

(°C)

Response

Shut

down

Shut

down

ML605 Hardware User Guide www.xilinx.com 69

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

Voltage and current monitoring and control are available for selected power rails through Texas Instruments’ Fusion Digital Power™ graphical user interface (GUI). Both onboard TI power controllers are wired to the same PMBus. The PMBus connector, J3, is provided for use with the TI USB Interface Adapter PMBus pod (TI part number EVM USB-TO-GPIO; refer to http://focus.ti.com/docs/toolsw/folders/print/usb-to-gpio.html board is shipped with a TI flyer containing information that allows the user to purchase this EVM at a discount.

TI provides the Fusion Digital Power Designer software package (http://focus.ti.com/docs/toolsw/folders/print/fusion_digital_power_designer.html which includes several tools capable of communicating with the UCD92xx series of controllers from a Windows-based host computer via the PMBus pod. The ML605 onboard connector J3 is wired for the TI EVM interface and provides access to the PMBUS and UCD9240s for monitoring purposes. This is the simplest and most convenient way to monitor the power rails. See Tab le 1 -3 1 and Ta bl e 1 -3 2.

For details concerning the use of the Fusion software tool, refer to the documentation offered in the Fusion Digital Power Designer GUI help system (select Help → Documentation and Help Center).

References

For more detailed information about this technology and the various power management controllers and regulator modules offered by Texas Instruments, visit

http://www.ti.com/ww/en/analog/digital-power/index.html

). The ML605

)

70 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

22. System Monitor

The System Monitor provides information regarding the FPGA on-chip temperature and power supply conditions via JTAG and an internal FPGA interface. The System Monitor can also be used to monitor external analog signals via 17 external analog input channels. For more information regarding this functionality, which is featured on every Virtex-6 family member, see http://www.xilinx.com/systemmonitor

This section provides a brief overview of the System Monitor related functionality that is supported on the ML605.

Reference and Power Supply

The System Monitor has dedicated analog power supply pins and supports the use of an external 1.25V reference IC (U23) for the analog-to-digital conversion process. An option (using jumper J19) to select an on-chip reference is also provided; however, the highest accuracy over a temperature range of -40°C to +125°C is obtained using an external reference. Figure 1-29 illustrates the power supply and reference options on the ML605. For a more detailed discussion of these requirements, see the Virtex-6 FPGA System Monitor User Guide. [Ref 15]

X-Ref Target - Figure 1-29

VCC2V5

Detailed Description

Ferrie Bead

GND

Analog Supply Filter

C78

X5R

10V

0.1UF

1.25V

SYSMON_AVDD

J19

C79 X5R 10V

0.1UF

C190

X5R

6.3V 1UF

VCC5

U23

REF3012

REF3012AIDBZT

12 IN

GND

C191

X5R

6.3V 1UF

AGND

OUT

Jumper on pins 1-2 Default Setting:

1-2 Select External Reference

AGND

2-3 Select On-Chip Reference

Figure 1-29: System Monitor External Reference

SYSMON_VREFP

C383

X5R 10V

0.1UF

AGND

UG534_29_081209

ML605 Hardware User Guide www.xilinx.com 71

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

System Monitor

Header

Dedicated Analog Inputs

FPGA Thermal Diode access

To Measure VCCINT Current:

Jumper on 9-11, 10-12

Connect Vccint shunt to Vp,Vn

Vccint_shunt_N

Vccint_shunt_P

C169

0.01UF

16V

X7R

FPGA_DX_N

FPGA_DX_P

SYSMON_AVDD

1.25V Reference

910

1211

J35

SYSMON_VP

SYSMON_VN

R232

100

1/16W

1%1%

1/16W

100

R233

AGND

Anti-alias Filter

UG534_37 _081209

System Monitor Header (J35)

Figure 1-30 shows the pinout for the System Monitor 12-pin header. The header provides

user access to the analog power supply (A

Figure 1-29, page 71. Access to the FPGA thermal diode and dedicated analog input

channel (Vp/Vn) is also provided on this header. The header can be used to connect user specific analog signals and sensors to the system monitor.

) and the 1.25V reference shown in

Vdd

The kelvin points for a 5 mΩ current sensing shunt in the FPGA 1V V

core supply are

ccint

also available on this header. By connecting header pins 9 to 11 and 10 to 12 using jumpers, the system monitor can be used to monitor the FPGA core current and power consumption. This can be used to collect useful power information about a particular design or implementation.

X-Ref Target - Figure 1-30

72 www.xilinx.com ML605 Hardware User Guide

Figure 1-30: System Monitor Header (J35)

UG534 (v1.8) October 2, 2012

X-Ref Target - Figure 1-31

ML605 Board Power Monitor

In addition to monitoring the FPGA core supply power consumption, two auxiliary analog input channels (of the 16 that are available) are used to implement a power monitor for the entire ML605 board. The board power is monitored at the 12V power input connector.

Figure 1-31 shows how the power monitor is implemented and connected to the System

Monitor auxiliary input channels 12 and 13. A simple resistor divider is used to monitor the 12V supply voltage and to provide a reference voltage to an instrumentation amplifier (InAmp). The voltage on the auxiliary channel 12 is equal to supply voltage divided by 24 (~ 0.5V).

The InAmp is used to amplify (by a factor of 50) the voltage dropped across a 2 mΩ current sense shunt. The voltage at the output of the InAmp is proportional to the current. The voltage on auxiliary channel 13 = Current (amps) x 0.002 x 50. (e.g., 5A = 0.5V).

12V Supply Monitor

2m ±1%

Detailed Description

11.5k ±0.5%

499 ±0.5%

~0.5V

~470

100nF

V+

REF

IN+

INA213

SC70-6

Package

50V/V

IN-

OUT

~470

10nF

GND

10nF

Figure 1-31: ML605 12V Power Monitor

10nF

AUXP[13]

Current Channel

AUXN[13]

AUXP[12]

Voltage Channel

AUXN[12]

UG534_38 _081209

ML605 Hardware User Guide www.xilinx.com 73

UG534 (v1.8) October 2, 2012

Chapter 1: ML605 Evaluation Board

Fan Controller

In highly demanding situations, active thermal management in the form of a heat sink and fan may be required. In order to support this, drive circuitry for an external fan has been provided on the ML605. A fan with tach output can be connect at header J59 as shown in

Figure 1-32. The fan PWM signal is generated by the FPGA and the tach input can be used

to close the control loop and regulate the fan speed. Alternatively, the FPGA temperature as recorded by the System Monitor can be used to close the PWM control loop for the fan.

X-Ref Target - Figure 1-32

VCC12_P

SM_FAN_PWM

VCC2V5

R369

10.0K 1%

1/16W

1N4148

R367

10.0K 1%

1/16W

GND

12V

Tach

J59

Q24

D16

NDT3055L

Figure 1-32: ML605 Fan Driver

R368

10.0K

1/16W

R358

4.75K 1%

SM_FAN_TACH

UG534_39 _081209

74 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

Detailed Description

9240

DGND1

AGND1

PMBus Connector

19 36

209

12 3 56

8 10

PMBUS_DATA

PMBUS_ALERT

R301 100K

5% 5%

100K

R299 R300

100K 5%

PMBUS_CLK PMBUS_CTRL

R335

1.0M 5%

TI_V3P3

UDC9240

NC NC NC

IO_L9P_MRCC_34_L10

IO_L9N_MRCC_34_M10

IO_L10P_MRCC_34_AC10

IO_L10N_MRCC_34_AB10

IO_L11P_SRCC_34_AH9

IO_L11N_SRCC_34_AJ9

6vlx240tff1156

BANK 34

L10

M10

AC10

AB10

AH9

AJ9 PMBUS_CTRL_LS

SM_FAN_PWM

SM_FAN_TACH

PMBUS_ALERT_LS

PMBUS_CLK_LS

PMBUS_DATA_LS

UG534_35_081209

FPGA Power Supply Margining

The PMBus (IIC), which provides access to the 2 x UDC9240 power controllers, can also be accessed via FPGA I/O in addition to a dedicated header (J3), see Figure 1-33. A full description of the UDC9240 functionality is outside the scope of this user guide. However, this useful feature can be used, for example, to margin the FPGA and board power supplies when evaluating a design. The System Monitor provides accurate measurements of the on-chip supply voltages as the FPGA supplies are margined. The PMBus (and fan) connections are shown in Figure 1-32.

X-Ref Target - Figure 1-33

ML605 Hardware User Guide www.xilinx.com 75

UG534 (v1.8) October 2, 2012

Figure 1-33: UDC9240 PMBus Access

System Monitor ML605 Demonstration Design

The various features described in this section are easily evaluated using a MicroBlaze™ based reference designed provided with the ML605 Evaluation Board. This reference design supports a UART based interface using a terminal program such as Hyperterminal to provide information on the FPGA power supplies, temperature, and power consumption. In addition, the UART interface can be used to margin the FPGA supplies over the PMBus.

The System Monitor functionality can also be accessed at any time via JTAG using the ChipScope Pro Analyzer tool without design modifications or cores inserted into a user design. The ChipScope Pro Analyzer tool automatically connects to the System Monitor via a JTAG cable after a connection is established.

References

For more information on using the System Monitor and an overview of the tool support for this feature, see the

Virtex-6 FPGA System Monitor User Guide. [Ref 15]

Chapter 1: ML605 Evaluation Board

Configuration Options

The FPGA on the ML605 Evaluation Board can be configured by the following methods:

• 3. 128 Mb Platform Flash XL, page 22

• 4. 32 MB Linear BPI Flash, page 22

• 5. System ACE CF and CompactFlash Connector, page 26

• 6. USB JTAG, page 28

For more information, see the Virtex-6 FPGA Configuration User Guide at

http://www.xilinx.com/support/documentation/user_guides/ug360.pdf

Table 1-33: Mode Switch S2 Settings

Mode Pins (M2,M1,M0) Configuration Mode

With the mode set to JTAG 101, the ML605 will not attempt to boot or load a bitstream from either of the Flash devices. If a CompactFlash (CF) card is installed in the CF socket U73, System ACE CF will attempt to load a bitstream from the CF card image address pointed to by the image select switch S1. With no CF card present, the ML605 can be configured via the onboard JTAG controller and USB download cable as described above.

110 Slave SelectMAP

010 BPI Mode

101 JTAG

With the mode set to either Slave SelectMAP 110, or BPI Mode 010, the FPGA will attempt to configure itself from the selected Flash device as described in 3. 128 Mb Platform Flash

XL, page 22.

Note:

System ACE to boot at power-on if it finds a CF card present. In order to boot from BPI Flash U4 or Xilinx Platform Flash (U27) without System ACE contention, S1 switch 4 must be OFF.

S1 switch 4 is the System ACE controller enable switch. When ON, this switch allows the

76 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

References

This section provides references to documentation supporting Virtex-6 FPGAs, tools, and IP. For additional information, see www.xilinx.com/support/documentation/index.htm

Documents supporting the ML605 Evaluation Board:

1. UG535, ML605 Reference Design User Guide

2. UG525

3. DS150

4. DS152

5. UG360

6. UG406

7. UG361

8. UG362

9. UG363

10. UG364

11. UG365

12. UG366

13. UG369

14. DS186

15. UG370

16. DS715

17. DS617

18. DS080

19. UG138

20. DS581

21. DS606

Appendix A

, Getting Started with the Xilinx Virtex-6 FPGA ML605 Evaluation Kit

, Virtex-6 Family Overview

, Virtex-6 FPGA Data Sheet: DC and Switching Characteristics

, Virtex-6 FPGA Configuration User Guide

, Virtex-6 FPGA Memory Interface Solutions User Guide

, Virtex-6 FPGA SelectIO Resources User Guide

, Virtex-6 FPGA User Guide: Clocking Resources

, Virtex-6 FPGA Memory Resources User Guide

, Virtex-6 FPGA Configurable Logic Block User Guide

, Virtex-6 FPGA Packaging and Pinout Specifications

, Virtex-6 FPGA GTX Transceivers User Guide

, Virtex-6 FPGA DSP48E1 Slice User Guide

, Virtex-6 FPGA Memory Interface Solutions Data Sheet

, Virtex-6 FPGA System Monitor User Guide

, Virtex-6 FPGA Integrated Block v1.2 for PCI Express Data Sheet

, Platform Flash XL High-Density Configuration and Storage Device Data Sheet

, System ACE CompactFlash Solution Data Sheet

, LogiCORE™ IP Tri-Mode Ethernet MAC v4.2 User Guide

, XPS External Peripheral Controller (EPC) v1.02a Data Sheet

, XPS IIC Bus Interface (v2.00a) Data Sheet

ML605 Hardware User Guide www.xilinx.com 77

UG534 (v1.8) October 2, 2012

Appendix A: References

Additional documentation:

22. Micron Technology, Inc., DDR3 SODIMM Specification (MT4JSF6464HY-1G1)

23. Winbond, Serial Flash Memory Data Sheet (W25Q64VSFIG)

24. Numonyx, Embedded Flash Memory Data Sheet (TE28F128J3D-75)

25. SiTime,

26. MMD Components

27. PCI SIG

28. Marvell

29. Cypress Semiconductor

30. USB Implementers Forum, Inc.

31. ST Micro

32. Samtec, Inc.

Oscillator Data Sheet (SiT9102AI-243N25E200.00000)

, MBH Series Data Sheet (MBH2100H-66.000 MHz)

, PCI Express Specifications

, Alaska Gigabit Ethernet Transceivers Product Page

, CY7C67300 Data Sheet

, USB Specifications

, M24C08 Data Sheet

78 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

Appendix B

Default Switch and Jumper Settings

Tab le B- 34 : Default Switch Settings

REFDES Function/Type Default

SW2 Board power slide-switch off

User GPIO 8-pole DIP switch

8 off

7 off

6 off

SW1

5 off

4 off

3 off

2 off

1 off

System ACE CF configuration and image select 4-pole DIP switch

4 SysACE Mode = 1

3SysAce CFGAddr 2 = 0 off

2SysAce CFGAddr 1 = 0 off

1SysAce CFGAddr 0 = 0 off

FPGA mode, boot PROM select and FPGA CCLK select 6-pole DIP switch

6 FLASH_A23 = 0 off

5M2 = 0 off

3M0 = 0 off

M1 = 1 M[2:0] = 010 = Master BPI-Up

(1)

off

2 CS_SEL = 1 = boot from BPI Flash on

1 EXT_CCLK = 0 off

Notes:

1. S1 position 4 is the System ACE controller enable switch. When ON, this switch allows the System ACE to boot at power on if it finds a CF card present. In order to boot from BPI Flash or Xilinx Platform Flash without System ACE contention, S1 switch 4 must be OFF.

ML605 Hardware User Guide www.xilinx.com 79

UG534 (v1.8) October 2, 2012

Appendix B: Default Switch and Jumper Settings

Tab le B- 35 : Default Jumper Settings

Jumper REFDES Function Default

J69 System ACE CF Error LED Enable Jump 1-2

GMII:

J66

J67

J68 J66 pins 1-2, J68 ON: RGMII, modified MII in Cu no jumper

FMC JTAG Bypass:

J18 exclude FMC LPC connector Jump 1 - 2

J17 exclude FMC HPC connector Jump 1 - 2

System Monitor:

J19 Test_mon_vrefp sourced by U23, REF3012 Jump 1 - 2

J35 measure voltage across R-kelvin on VCCINT

SFP Module:

J54 Full BW Jump 1 - 2

J65 SFP Enable Jump 1 - 2

PCIe Lane Size:

J42 1 lane Jump 1 - 2

pins 1-2: GMII/MII to Cu pins 2-3: SGMII to Cu, no clk

Jump 1 - 2

Jump 9 - 11,

Jump 10 - 12

80 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

Appendix C

VITA 57.1 FMC LPC (J63) and HPC (J64) Connector Pinout

Figure C-34 shows the pinout of the FMC LPC connector. Pins marked NC are not

X-Ref Target - Figure C-34

KJ H G FE D C BA

1 NC NC VR EF_A_M2C GND NC NC PG_C2M GND NC NC 2 NC NC PR SNT_M2C_L CLK 1_M2C_P NC NC G ND DP0_C2M_P NC NC 3 NC NC GND C LK 1_M2C_N NC NC GND DP 0_C2M_N NC NC 4 NC NC CLK0_M2C _P GND NC NC G BT CLK0_M2C_P GND NC NC 5 NC NC CLK0_M2C_N GND NC NC G BT CLK0_M2C_N GND NC NC 6 NC NC GND LA00_P _C C NC NC G ND DP0_M2C_P NC NC 7 NC NC LA02_P LA00_N_C C NC NC G ND DP 0_M2C_N NC NC 8 NC NC LA02_N GND NC NC LA01_P _C C GND NC NC

9 NC NC GN D LA03_P NC NC LA01_N _CC G ND NC NC 10 N C NC L A04_P LA03_N NC NC GND L A06_P NC NC 11 N C NC L A04_N GND NC NC L A05_P LA06_N NC NC 12 NC NC G ND LA08_P NC NC LA05_N GND NC NC 13 N C NC L A07_P LA08_N NC NC GND G ND NC NC 14 N C NC L A07_N GND NC NC L A09_P LA10_P NC NC 15 N C NC G ND LA12_P NC NC LA09_N LA10_N NC NC 16 N C NC L A11_P LA12_N NC NC GND G ND NC NC 17 NC NC LA11_N GND NC NC LA13_P GND NC NC 18 N C NC G ND LA16_P NC NC LA13_N LA14_P NC NC 19 N C NC L A15_P LA16_N NC NC GND L A14_N NC NC 20 NC NC LA15_N GND NC NC LA17_P _C C G ND NC NC 21 N C NC G ND LA20_P NC NC LA17_N_CC G ND NC NC 22 N C NC L A19_P LA20_N NC NC GND LA18_P_C C NC NC 23 NC NC LA19_N GND NC NC LA23_P LA18_N_C C NC NC 24 NC NC G ND LA22_P NC NC LA23_N GND NC NC 25 N C NC L A21_P LA22_N NC NC GND G ND NC NC 26 N C NC L A21_N GND NC NC L A26_P LA27_P NC NC 27 N C NC G ND LA25_P NC NC LA26_N LA27_N NC NC 28 N C NC L A24_P LA25_N NC NC GND G ND NC NC 29 NC NC LA24_N GND NC NC TCK GND NC NC 30 N C NC G ND LA29_P NC NC TD I S CL NC NC 31 N C NC L A28_P LA29_N NC NC TDO S DA NC NC 32 NC NC LA28_N GND NC NC 3P3VAUX GND NC NC 33 N C NC G ND LA31_P NC NC TMS G ND NC NC 34 N C NC L A30_P LA31_N NC NC TR ST _L GA0 NC N C 35 NC NC LA30_N GND NC NC GA1 12P0V NC NC 36 NC NC G ND LA33_P NC NC 3P 3V GND NC NC 37 N C NC L A32_P LA33_N NC NC GND 12P0V NC NC 38 NC NC LA32_N GND NC NC 3P3V G ND NC NC 39 NC NC G ND VADJ NC NC GND 3P3V NC NC 40 NC NC VADJ G ND NC NC 3P 3V GND NC NC

connected.

Figure C-34: FMC LPC Connector Pinout

For more information, refer to the VITA 57.1 FMC LPC Connections table (Ta b le 1 -3 0 ).

ML605 Hardware User Guide www.xilinx.com 81

UG534 (v1.8) October 2, 2012

Appendix C: VITA 57.1 FMC LPC (J63) and HPC (J64) Connector Pinout

KJHGFEDCBA

1 VREF_B_M2C GND VREF_A_M2C GND PG_M2C GND PG_C2M GND RES1 GND

2 GND C LK3_M2C_P P RS NT_M2C_L CLK1_M2C_P GND H A01_P _CC G ND DP0_C2M_P GND DP1_M2C_P

3 GND C LK3_M2C_N G ND CLK1_M2C_N GND HA01_N_CC G ND DP0_C2M_N GND DP1_M2C_N

4 CLK2_M2C_P GND C LK0_M2C_P G ND HA00_P _CC GND GBTCLK 0_M2C_P G ND DP9_M2C_P G ND

5 CLK2_M2C_N GND C LK0_M2C_N G ND HA00_N_CC G ND GBTC LK 0_M2C_N GND DP9_M2C_N G ND

6 GND HA03_P GND LA00_P _CC G ND HA05_P GND DP0_M2C _P GND DP2_M2C_P

7 HA02_P HA03_N LA02_P LA00_N_C C H A04_P HA05_N GND DP0_M2C_N GND DP2_M2C_N

8 HA02_N GND LA02_N GND HA04_N GND L A01_P _CC G ND DP8_M2C_P G ND

9 GND HA07_P GND LA03_P GND HA09_P LA01_N_CC G ND DP8_M2C_N G ND

10 H A06_P HA07_N LA04_P LA03_N HA08_P HA09_N GND LA06_P GND DP3_M2C_P

11 HA06_N GND L A04_N GND HA08_N GND LA05_P LA06_N GND DP3_M2C_N

12 GND HA11_P GND LA08_P GND H A13_P LA05_N GND DP7_M2C _P GND

13 H A10_P HA11_N LA07_P LA08_N HA12_P HA13_N GND G ND DP7_M2C_N GND

14 HA10_N GND L A07_N GND HA12_N GND LA09_P LA10_P GND DP4_M2C _P

15 GND HA14_P GND LA12_P GND H A16_P LA09_N LA10_N GND DP4_M2C_N

16 HA17_P _CC HA14_N LA11_P LA12_N HA15_P HA16_N GND G ND DP6_M2C_P GND

17 HA17_N_CC G ND LA11_N GND HA15_N GND LA13_P GND DP6_M2C_N GND

18 GND HA18_P GND LA16_P GND H A20_P LA13_N LA14_P GN D DP5_M2C_P

19 H A21_P HA18_N LA15_P LA16_N HA19_P HA20_N GND LA14_N GND DP5_M2C_N

20 HA21_N GND L A15_N GND HA19_N GND LA17_P _CC G ND GBTC LK1_M2C_P G ND

21 GND HA22_P GND LA20_P GND H B03_P LA17_N_C C G ND GBTC LK1_M2C_N G ND

22 H A23_P HA22_N LA19_P LA20_N HB02_P HB03_N GND LA18_P _CC G ND DP1_ C2M_P

23 HA23_N GND L A19_N GND HB02_N GND LA23_P LA18_N_C C GND DP1_C2M_N

24 GND HB01_P GND LA22_P GND H B05_P LA23_N GND DP9_C2M_P GND

25 HB00_P _CC HB01_N LA21_P LA22_N HB04_P HB05_N GND G ND DP9_C2M_N G ND

26 HB00_N_CC G ND LA21_N GND HB04_N GND LA26_P LA27_P GND DP2_C 2M_P

27 GND HB07_P GND LA25_P GND H B09_P LA26_N LA27_N GND DP2_C 2M_N

28 HB06_P _CC HB07_N LA24_P LA25_N HB08_P HB09_N GND G ND DP8_C2M_P GND

29 HB06_N_CC G ND LA24_N GND HB08_N GND T CK GN D D P8_C2M_N GND

30 GND HB11_P GND LA29_P GND H B13_P TD I S CL GND DP3_C 2M_P

31 H B10_P HB11_N LA28_P LA29_N HB12_P HB13_N TDO SDA GND DP3_C2M_N

32 HB10_N GND L A28_N GND HB12_N GND 3P3VAUX GND DP7_C 2M_P GN D

33 GND HB15_P GND LA31_P GND H B19_P TMS G ND DP7_ C2M_N GND

34 H B14_P HB15_N LA30_P LA31_N HB16_P HB19_N TRST_L GA0 G ND DP4_C2M_P

35 HB14_N GND L A30_N GND HB16_N GND G A1 12P0V G ND DP4_C2M_N

36 GND HB18_P GND LA33_P GND H B21_P 3P3V GND DP6_C 2M_P GND

37 HB17_P _CC HB18_N LA32_P LA33_N HB20_P HB21_N GND 12P0V DP6_C2M_N GND

38 HB17_N_CC G ND LA32_N GND HB20_N GND 3P3V G ND GND DP5_C 2M_P

39 G ND VIO_B_M2C G ND VADJ GN D V ADJ GND 3P3V GND DP5_C2M_N

40 VIO_B _M2C GND VADJ GND VADJ GND 3P3V GND RES0 GND

Figure C-35 shows the pinout of the FMC HPC connector.

X-Ref Target - Figure C-35

Figure C-35: FMC HPC Connector Pinout

For more information, refer to the VITA 57.1 FMC HPC Connections table (Ta ble 1 -2 8).

82 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

Appendix D

ML605 Master UCF

The UCF template is provided for designs that target the ML605. Net names provided in the constraints below correlate with net names on the ML605 schematic. On identifying the appropriate pins, the net names below should be replaced with net names in the user RTL. See the Constraints Guide

Users can refer to the UCF files generated by tools such as MIG (Memory Interface Generator for memory interfaces) and BSB (Base System Builder) for more detailed information concerning the I/O standards required for each particular interface. The FMC connectors J63 and J64 are connected to 2.5V V implements customer-specific circuitry, the FMC bank I/O standards must be uniquely defined by each customer.

The latest version of the UCF can be found on the ML605 board documentation website at

http://www.xilinx.com/ml605

NET "CLK_33MHZ_SYSACE" LOC = "AE16"; ## 93 on U19 NET "CPU_RESET" LOC = "H10"; ## 2 on SW10 pushbutton (active-High) ## NET "DDR3_A0" LOC = "L14"; ## 98 on J1 NET "DDR3_A1" LOC = "A16"; ## 97 on J1 NET "DDR3_A2" LOC = "B16"; ## 96 on J1 NET "DDR3_A3" LOC = "E16"; ## 95 on J1 NET "DDR3_A4" LOC = "D16"; ## 92 on J1 NET "DDR3_A5" LOC = "J17"; ## 91 on J1 NET "DDR3_A6" LOC = "A15"; ## 90 on J1 NET "DDR3_A7" LOC = "B15"; ## 86 on J1 NET "DDR3_A8" LOC = "G15"; ## 89 on J1 NET "DDR3_A9" LOC = "F15"; ## 85 on J1 NET "DDR3_A10" LOC = "M16"; ## 107 on J1 NET "DDR3_A11" LOC = "M15"; ## 84 on J1 NET "DDR3_A12" LOC = "H15"; ## 83 on J1 NET "DDR3_A13" LOC = "J15"; ## 119 on J1 NET "DDR3_A14" LOC = "D15"; ## 80 on J1 NET "DDR3_A15" LOC = "C15"; ## 78 on J1 NET "DDR3_BA0" LOC = "K19"; ## 109 on J1 NET "DDR3_BA1" LOC = "J19"; ## 108 on J1 NET "DDR3_BA2" LOC = "L15"; ## 79 on J1 NET "DDR3_CAS_B" LOC = "C17"; ## 115 on J1 NET "DDR3_CKE0" LOC = "M18"; ## 73 on J1 NET "DDR3_CKE1" LOC = "M17"; ## 74 on J1 NET "DDR3_CLK0_N" LOC = "H18"; ## 103 on J1 NET "DDR3_CLK0_P" LOC = "G18"; ## 101 on J1 NET "DDR3_CLK1_N" LOC = "L16"; ## 104 on J1 NET "DDR3_CLK1_P" LOC = "K16"; ## 102 on J1 NET "DDR3_D0" LOC = "J11"; ## 5 on J1 NET "DDR3_D1" LOC = "E13"; ## 7 on J1 NET "DDR3_D2" LOC = "F13"; ## 15 on J1 NET "DDR3_D3" LOC = "K11"; ## 17 on J1 NET "DDR3_D4" LOC = "L11"; ## 4 on J1

for more information.

banks. Because each user’s FMC card

cco

ML605 Hardware User Guide www.xilinx.com 83

UG534 (v1.8) October 2, 2012

Appendix D: ML605 Master UCF

NET "DDR3_D5" LOC = "K13"; ## 6 on J1 NET "DDR3_D6" LOC = "K12"; ## 16 on J1 NET "DDR3_D7" LOC = "D11"; ## 18 on J1 NET "DDR3_D8" LOC = "M13"; ## 21 on J1 NET "DDR3_D9" LOC = "J14"; ## 23 on J1 NET "DDR3_D10" LOC = "B13"; ## 33 on J1 NET "DDR3_D11" LOC = "B12"; ## 35 on J1 NET "DDR3_D12" LOC = "G10"; ## 22 on J1 NET "DDR3_D13" LOC = "M11"; ## 24 on J1 NET "DDR3_D14" LOC = "C12"; ## 34 on J1 NET "DDR3_D15" LOC = "A11"; ## 36 on J1 NET "DDR3_D16" LOC = "G11"; ## 39 on J1 NET "DDR3_D17" LOC = "F11"; ## 41 on J1 NET "DDR3_D18" LOC = "D14"; ## 51 on J1 NET "DDR3_D19" LOC = "C14"; ## 53 on J1 NET "DDR3_D20" LOC = "G12"; ## 40 on J1 NET "DDR3_D21" LOC = "G13"; ## 42 on J1 NET "DDR3_D22" LOC = "F14"; ## 50 on J1 NET "DDR3_D23" LOC = "H14"; ## 52 on J1 NET "DDR3_D24" LOC = "C19"; ## 57 on J1 NET "DDR3_D25" LOC = "G20"; ## 59 on J1 NET "DDR3_D26" LOC = "E19"; ## 67 on J1 NET "DDR3_D27" LOC = "F20"; ## 69 on J1 NET "DDR3_D28" LOC = "A20"; ## 56 on J1 NET "DDR3_D29" LOC = "A21"; ## 58 on J1 NET "DDR3_D30" LOC = "E22"; ## 68 on J1 NET "DDR3_D31" LOC = "E23"; ## 70 on J1 NET "DDR3_D32" LOC = "G21"; ## 129 on J1 NET "DDR3_D33" LOC = "B21"; ## 131 on J1 NET "DDR3_D34" LOC = "A23"; ## 141 on J1 NET "DDR3_D35" LOC = "A24"; ## 143 on J1 NET "DDR3_D36" LOC = "C20"; ## 130 on J1 NET "DDR3_D37" LOC = "D20"; ## 132 on J1 NET "DDR3_D38" LOC = "J20"; ## 140 on J1 NET "DDR3_D39" LOC = "G22"; ## 142 on J1 NET "DDR3_D40" LOC = "D26"; ## 147 on J1 NET "DDR3_D41" LOC = "F26"; ## 149 on J1 NET "DDR3_D42" LOC = "B26"; ## 157 on J1 NET "DDR3_D43" LOC = "E26"; ## 159 on J1 NET "DDR3_D44" LOC = "C24"; ## 146 on J1 NET "DDR3_D45" LOC = "D25"; ## 148 on J1 NET "DDR3_D46" LOC = "D27"; ## 158 on J1 NET "DDR3_D47" LOC = "C25"; ## 160 on J1 NET "DDR3_D48" LOC = "C27"; ## 163 on J1 NET "DDR3_D49" LOC = "B28"; ## 165 on J1 NET "DDR3_D50" LOC = "D29"; ## 175 on J1 NET "DDR3_D51" LOC = "B27"; ## 177 on J1 NET "DDR3_D52" LOC = "G27"; ## 164 on J1 NET "DDR3_D53" LOC = "A28"; ## 166 on J1 NET "DDR3_D54" LOC = "E24"; ## 174 on J1 NET "DDR3_D55" LOC = "G25"; ## 176 on J1 NET "DDR3_D56" LOC = "F28"; ## 181 on J1 NET "DDR3_D57" LOC = "B31"; ## 183 on J1 NET "DDR3_D58" LOC = "H29"; ## 191 on J1 NET "DDR3_D59" LOC = "H28"; ## 193 on J1 NET "DDR3_D60" LOC = "B30"; ## 180 on J1 NET "DDR3_D61" LOC = "A30"; ## 182 on J1 NET "DDR3_D62" LOC = "E29"; ## 192 on J1 NET "DDR3_D63" LOC = "F29"; ## 194 on J1 NET "DDR3_DM0" LOC = "E11"; ## 11 on J1 NET "DDR3_DM1" LOC = "B11"; ## 28 on J1 NET "DDR3_DM2" LOC = "E14"; ## 46 on J1 NET "DDR3_DM3" LOC = "D19"; ## 63 on J1 NET "DDR3_DM4" LOC = "B22"; ## 136 on J1 NET "DDR3_DM5" LOC = "A26"; ## 153 on J1

84 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

NET "DDR3_DM6" LOC = "A29"; ## 170 on J1 NET "DDR3_DM7" LOC = "A31"; ## 187 on J1 NET "DDR3_DQS0_N" LOC = "E12"; ## 10 on J1 NET "DDR3_DQS0_P" LOC = "D12"; ## 12 on J1 NET "DDR3_DQS1_N" LOC = "J12"; ## 27 on J1 NET "DDR3_DQS1_P" LOC = "H12"; ## 29 on J1 NET "DDR3_DQS2_N" LOC = "A14"; ## 45 on J1 NET "DDR3_DQS2_P" LOC = "A13"; ## 47 on J1 NET "DDR3_DQS3_N" LOC = "H20"; ## 62 on J1 NET "DDR3_DQS3_P" LOC = "H19"; ## 64 on J1 NET "DDR3_DQS4_N" LOC = "C23"; ## 135 on J1 NET "DDR3_DQS4_P" LOC = "B23"; ## 137 on J1 NET "DDR3_DQS5_N" LOC = "A25"; ## 152 on J1 NET "DDR3_DQS5_P" LOC = "B25"; ## 154 on J1 NET "DDR3_DQS6_N" LOC = "G28"; ## 169 on J1 NET "DDR3_DQS6_P" LOC = "H27"; ## 171 on J1 NET "DDR3_DQS7_N" LOC = "D30"; ## 186 on J1 NET "DDR3_DQS7_P" LOC = "C30"; ## 188 on J1 NET "DDR3_ODT0" LOC = "F18"; ## 116 on J1 NET "DDR3_ODT1" LOC = "E17"; ## 120 on J1 NET "DDR3_RAS_B" LOC = "L19"; ## 110 on J1 NET "DDR3_RESET_B" LOC = "E18"; ## 30 on J1 NET "DDR3_S0_B" LOC = "K18"; ## 114 on J1 NET "DDR3_S1_B" LOC = "K17"; ## 121 on J1 NET "DDR3_TEMP_EVENT" LOC = "D17"; ## 198 on J1 NET "DDR3_WE_B" LOC = "B17"; ## 113 on J1 ## NET "DVI_D0" LOC = "AJ19"; ## 63 on U38 (thru series R111 47.5 ohm) NET "DVI_D1" LOC = "AH19"; ## 62 on U38 (thru series R110 47.5 ohm) NET "DVI_D2" LOC = "AM17"; ## 61 on U38 (thru series R109 47.5 ohm) NET "DVI_D3" LOC = "AM16"; ## 60 on U38 (thru series R108 47.5 ohm) NET "DVI_D4" LOC = "AD17"; ## 59 on U38 (thru series R107 47.5 ohm) NET "DVI_D5" LOC = "AE17"; ## 58 on U38 (thru series R106 47.5 ohm) NET "DVI_D6" LOC = "AK18"; ## 55 on U38 (thru series R105 47.5 ohm) NET "DVI_D7" LOC = "AK17"; ## 54 on U38 (thru series R104 47.5 ohm) NET "DVI_D8" LOC = "AE18"; ## 53 on U38 (thru series R103 47.5 ohm) NET "DVI_D9" LOC = "AF18"; ## 52 on U38 (thru series R102 47.5 ohm) NET "DVI_D10" LOC = "AL16"; ## 51 on U38 (thru series R101 47.5 ohm) NET "DVI_D11" LOC = "AK16"; ## 50 on U38 (thru series R100 47.5 ohm) NET "DVI_DE" LOC = "AD16"; ## 2 on U38 (thru series R112 47.5 ohm) NET "DVI_GPIO1_FMC_C2M_PG_LS" LOC = "K9"; ## 18 on U32 (not wired to U38) NET "DVI_H" LOC = "AN17"; ## 4 on U38 (thru series R113 47.5 ohm) NET "DVI_RESET_B_LS" LOC = "AP17"; ## 2 on U32 (DVI_RESET_B pin 13 on U38) NET "DVI_V" LOC = "AD15"; ## 5 on U38 (thru series R114 47.5 ohm) NET "DVI_XCLK_N" LOC = "AC17"; ## 56 on U38 NET "DVI_XCLK_P" LOC = "AC18"; ## 57 on U38 ## NET "FLASH_A0" LOC = "AL8"; ## 29 on U4, A1 on U27 NET "FLASH_A1" LOC = "AK8"; ## 25 on U4, B1 on U27 NET "FLASH_A2" LOC = "AC9"; ## 24 on U4, C1 on U27 NET "FLASH_A3" LOC = "AD10"; ## 23 on U4, D1 on U27 NET "FLASH_A4" LOC = "C8"; ## 22 on U4, D2 on U27 NET "FLASH_A5" LOC = "B8"; ## 21 on U4, A2 on U27 NET "FLASH_A6" LOC = "E9"; ## 20 on U4, C2 on U27 NET "FLASH_A7" LOC = "E8"; ## 19 on U4, A3 on U27 NET "FLASH_A8" LOC = "A8"; ## 8 on U4, B3 on U27 NET "FLASH_A9" LOC = "A9"; ## 7 on U4, C3 on U27 NET "FLASH_A10" LOC = "D9"; ## 6 on U4, D3 on U27 NET "FLASH_A11" LOC = "C9"; ## 5 on U4, C4 on U27 NET "FLASH_A12" LOC = "D10"; ## 4 on U4, A5 on U27 NET "FLASH_A13" LOC = "C10"; ## 3 on U4, B5 on U27 NET "FLASH_A14" LOC = "F10"; ## 2 on U4, C5 on U27 NET "FLASH_A15" LOC = "F9"; ## 1 on U4, D7 on U27 NET "FLASH_A16" LOC = "AH8"; ## 55 on U4, D8 on U27 NET "FLASH_A17" LOC = "AG8"; ## 18 on U4, A7 on U27

ML605 Hardware User Guide www.xilinx.com 85

UG534 (v1.8) October 2, 2012

Appendix D: ML605 Master UCF

NET "FLASH_A18" LOC = "AP9"; ## 17 on U4, B7 on U27 NET "FLASH_A19" LOC = "AN9"; ## 16 on U4, C7 on U27 NET "FLASH_A20" LOC = "AF10"; ## 11 on U4, C8 on U27 NET "FLASH_A21" LOC = "AF9"; ## 10 on U4, A8 on U27 NET "FLASH_A22" LOC = "AL9"; ## 9 on U4, G1 on U27 NET "FLASH_A23" LOC = "AA23"; ## 26 on U4 NET "FLASH_D0" LOC = "AF24"; ## 34 on U4 (thru series R215 100 ohm), F2 on U27 NET "FLASH_D1" LOC = "AF25"; ## 36 on U4 (thru series R216 100 ohm), E2 on U27 NET "FLASH_D2" LOC = "W24"; ## 39 on U4 (thru series R217 100 ohm), G3 on U27 NET "FLASH_D3" LOC = "V24"; ## 41 on U4 (thru series R218 100 ohm), E4 on U27 NET "FLASH_D4" LOC = "H24"; ## 47 on U4 (thru series R219 100 ohm), E5 on U27 NET "FLASH_D5" LOC = "H25"; ## 49 on U4 (thru series R220 100 ohm), G5 on U27 NET "FLASH_D6" LOC = "P24"; ## 51 on U4 (thru series R221 100 ohm), G6 on U27 NET "FLASH_D7" LOC = "R24"; ## 53 on U4 (thru series R222 100 ohm), H7 on U27 NET "FLASH_D8" LOC = "G23"; ## 35 on U4 (thru series R223 100 ohm), E1 on U27 NET "FLASH_D9" LOC = "H23"; ## 37 on U4 (thru series R224 100 ohm), E3 on U27 NET "FLASH_D10" LOC = "N24"; ## 40 on U4 (thru series R225 100 ohm), F3 on U27 NET "FLASH_D11" LOC = "N23"; ## 42 on U4 (thru series R226 100 ohm), F4 on U27 NET "FLASH_D12" LOC = "F23"; ## 48 on U4 (thru series R227 100 ohm), F5 on U27 NET "FLASH_D13" LOC = "F24"; ## 50 on U4 (thru series R228 100 ohm), H5 on U27 NET "FLASH_D14" LOC = "L24"; ## 52 on U4 (thru series R229 100 ohm), G7 on U27 NET "FLASH_D15" LOC = "M23"; ## 54 on U4 (thru series R230 100 ohm), E7 on U27 NET "FLASH_WAIT" LOC = "J26"; ## 56 on U4 NET "FPGA_FWE_B" LOC = "AF23"; ## 14 on U4, G8 on U27 NET "FPGA_FOE_B" LOC = "AA24"; ## 32 on U4, F8 on U27 NET "FPGA_CCLK" LOC = "K8"; ## F1 on U27 NET "PLATFLASH_L_B" LOC = "AC23"; ## H1 on U27 NET "FPGA_FCS_B" LOC = "Y24"; ## 30 on U4, B4 on U27 (U10 and switch S2.2 setting ## select either U4 or U27) ## NET "FMC_HPC_CLK0_M2C_N" LOC = "K23"; ## H5 on J64 NET "FMC_HPC_CLK0_M2C_P" LOC = "K24"; ## H4 on J64 NET "FMC_HPC_CLK1_M2C_N" LOC = "AP21"; ## G3 on J64 NET "FMC_HPC_CLK1_M2C_P" LOC = "AP20"; ## G2 on J64 NET "FMC_HPC_CLK2_M2C_IO_N" LOC = "AC30"; ## 15 on U83 NET "FMC_HPC_CLK2_M2C_IO_P" LOC = "AD30"; ## 16 on U83 NET "FMC_HPC_CLK2_M2C_MGT_C_N" LOC = "AB5"; ## 2 on series C399 0.1uF NET "FMC_HPC_CLK2_M2C_MGT_C_P" LOC = "AB6"; ## 2 on series C398 0.1uF NET "FMC_HPC_CLK3_M2C_IO_N" LOC = "AF34"; ## J3 on J64 NET "FMC_HPC_CLK3_M2C_IO_P" LOC = "AE34"; ## J2 on J64 NET "FMC_HPC_CLK3_M2C_MGT_C_N" LOC = "AH5"; ## 2 on series C397 0.1uF NET "FMC_HPC_CLK3_M2C_MGT_C_P" LOC = "AH6"; ## 2 on series C396 0.1uF NET "FMC_HPC_DP0_C2M_N" LOC = "AB2"; ## C3 on J64 NET "FMC_HPC_DP0_C2M_P" LOC = "AB1"; ## C2 on J64 NET "FMC_HPC_DP0_M2C_N" LOC = "AC4"; ## C7 on J64 NET "FMC_HPC_DP0_M2C_P" LOC = "AC3"; ## C6 on J64 NET "FMC_HPC_DP1_C2M_N" LOC = "AD2"; ## A23 on J64 NET "FMC_HPC_DP1_C2M_P" LOC = "AD1"; ## A22 on J64 NET "FMC_HPC_DP1_M2C_N" LOC = "AE4"; ## A3 on J64 NET "FMC_HPC_DP1_M2C_P" LOC = "AE3"; ## A2 on J64 NET "FMC_HPC_DP2_C2M_N" LOC = "AF2"; ## A27 on J64 NET "FMC_HPC_DP2_C2M_P" LOC = "AF1"; ## A26 on J64 NET "FMC_HPC_DP2_M2C_N" LOC = "AF6"; ## A7 on J64 NET "FMC_HPC_DP2_M2C_P" LOC = "AF5"; ## A6 on J64 NET "FMC_HPC_DP3_C2M_N" LOC = "AH2"; ## A31 on J64 NET "FMC_HPC_DP3_C2M_P" LOC = "AH1"; ## A30 on J64 NET "FMC_HPC_DP3_M2C_N" LOC = "AG4"; ## A11 on J64 NET "FMC_HPC_DP3_M2C_P" LOC = "AG3"; ## A10 on J64 NET "FMC_HPC_DP4_C2M_N" LOC = "AK2"; ## A35 on J64 NET "FMC_HPC_DP4_C2M_P" LOC = "AK1"; ## A34 on J64 NET "FMC_HPC_DP4_M2C_N" LOC = "AJ4"; ## A15 on J64 NET "FMC_HPC_DP4_M2C_P" LOC = "AJ3"; ## A14 on J64 NET "FMC_HPC_DP5_C2M_N" LOC = "AM2"; ## A39 on J64 NET "FMC_HPC_DP5_C2M_P" LOC = "AM1"; ## A38 on J64 NET "FMC_HPC_DP5_M2C_N" LOC = "AL4"; ## A19 on J64

86 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

NET "FMC_HPC_DP5_M2C_P" LOC = "AL3"; ## A18 on J64 NET "FMC_HPC_DP6_C2M_N" LOC = "AN4"; ## B37 on J64 NET "FMC_HPC_DP6_C2M_P" LOC = "AN3"; ## B36 on J64 NET "FMC_HPC_DP6_M2C_N" LOC = "AM6"; ## B17 on J64 NET "FMC_HPC_DP6_M2C_P" LOC = "AM5"; ## B16 on J64 NET "FMC_HPC_DP7_C2M_N" LOC = "AP2"; ## B33 on J64 NET "FMC_HPC_DP7_C2M_P" LOC = "AP1"; ## B32 on J64 NET "FMC_HPC_DP7_M2C_N" LOC = "AP6"; ## B13 on J64 NET "FMC_HPC_DP7_M2C_P" LOC = "AP5"; ## B12 on J64 NET "FMC_HPC_GBTCLK0_M2C_N" LOC = "AD5"; ## D5 on J64 NET "FMC_HPC_GBTCLK0_M2C_P" LOC = "AD6"; ## D4 on J64 NET "FMC_HPC_GBTCLK1_M2C_N" LOC = "AK5"; ## B21 on J64 NET "FMC_HPC_GBTCLK1_M2C_P" LOC = "AK6"; ## B20 on J64 NET "FMC_HPC_HA00_CC_N" LOC = "AF33"; ## F5 on J64 NET "FMC_HPC_HA00_CC_P" LOC = "AE33"; ## F4 on J64 NET "FMC_HPC_HA01_CC_N" LOC = "AC29"; ## E3 on J64 NET "FMC_HPC_HA01_CC_P" LOC = "AD29"; ## E2 on J64 NET "FMC_HPC_HA02_N" LOC = "AC25"; ## K8 on J64 NET "FMC_HPC_HA02_P" LOC = "AB25"; ## K7 on J64 NET "FMC_HPC_HA03_N" LOC = "Y26"; ## J7 on J64 NET "FMC_HPC_HA03_P" LOC = "AA25"; ## J6 on J64 NET "FMC_HPC_HA04_N" LOC = "AC28"; ## F8 on J64 NET "FMC_HPC_HA04_P" LOC = "AB28"; ## F7 on J64 NET "FMC_HPC_HA05_N" LOC = "AC27"; ## E7 on J64 NET "FMC_HPC_HA05_P" LOC = "AB27"; ## E6 on J64 NET "FMC_HPC_HA06_N" LOC = "AA29"; ## K11 on J64 NET "FMC_HPC_HA06_P" LOC = "AA28"; ## K10 on J64 NET "FMC_HPC_HA07_N" LOC = "AB26"; ## J10 on J64 NET "FMC_HPC_HA07_P" LOC = "AA26"; ## J9 on J64 NET "FMC_HPC_HA08_N" LOC = "AF31"; ## F11 on J64 NET "FMC_HPC_HA08_P" LOC = "AG31"; ## F10 on J64 NET "FMC_HPC_HA09_N" LOC = "AB31"; ## E10 on J64 NET "FMC_HPC_HA09_P" LOC = "AB30"; ## E9 on J64 NET "FMC_HPC_HA10_N" LOC = "AC34"; ## K14 on J64 NET "FMC_HPC_HA10_P" LOC = "AD34"; ## K13 on J64 NET "FMC_HPC_HA11_N" LOC = "AG32"; ## J13 on J64 NET "FMC_HPC_HA11_P" LOC = "AG33"; ## J12 on J64 NET "FMC_HPC_HA12_N" LOC = "AE32"; ## F14 on J64 NET "FMC_HPC_HA12_P" LOC = "AD32"; ## F13 on J64 NET "FMC_HPC_HA13_N" LOC = "AD31"; ## E13 on J64 NET "FMC_HPC_HA13_P" LOC = "AE31"; ## E12 on J64 NET "FMC_HPC_HA14_N" LOC = "AA31"; ## J16 on J64 NET "FMC_HPC_HA14_P" LOC = "AA30"; ## J15 on J64 NET "FMC_HPC_HA15_N" LOC = "AC32"; ## F17 on J64 NET "FMC_HPC_HA15_P" LOC = "AB32"; ## F16 on J64 NET "FMC_HPC_HA16_N" LOC = "AB33"; ## E16 on J64 NET "FMC_HPC_HA16_P" LOC = "AC33"; ## E15 on J64 NET "FMC_HPC_HA17_CC_N" LOC = "W30"; ## K17 on J64 NET "FMC_HPC_HA17_CC_P" LOC = "V30"; ## K16 on J64 NET "FMC_HPC_HA18_N" LOC = "T34"; ## J19 on J64 NET "FMC_HPC_HA18_P" LOC = "T33"; ## J18 on J64 NET "FMC_HPC_HA19_N" LOC = "U32"; ## F20 on J64 NET "FMC_HPC_HA19_P" LOC = "U33"; ## F19 on J64 NET "FMC_HPC_HA20_N" LOC = "V33"; ## E19 on J64 NET "FMC_HPC_HA20_P" LOC = "V32"; ## E18 on J64 NET "FMC_HPC_HA21_N" LOC = "U30"; ## K20 on J64 NET "FMC_HPC_HA21_P" LOC = "U31"; ## K19 on J64 NET "FMC_HPC_HA22_N" LOC = "V29"; ## J22 on J64 NET "FMC_HPC_HA22_P" LOC = "U28"; ## J21 on J64 NET "FMC_HPC_HA23_N" LOC = "U27"; ## K23 on J64 NET "FMC_HPC_HA23_P" LOC = "U26"; ## K22 on J64 NET "FMC_HPC_HB00_CC_N" LOC = "AG30"; ## K26 on J64 NET "FMC_HPC_HB00_CC_P" LOC = "AF30"; ## K25 on J64 NET "FMC_HPC_HB01_N" LOC = "AM32"; ## J25 on J64 NET "FMC_HPC_HB01_P" LOC = "AN32"; ## J24 on J64

ML605 Hardware User Guide www.xilinx.com 87

UG534 (v1.8) October 2, 2012

Appendix D: ML605 Master UCF

NET "FMC_HPC_HB02_N" LOC = "AP33"; ## F23 on J64 NET "FMC_HPC_HB02_P" LOC = "AP32"; ## F22 on J64 NET "FMC_HPC_HB03_N" LOC = "AM31"; ## E22 on J64 NET "FMC_HPC_HB03_P" LOC = "AL30"; ## E21 on J64 NET "FMC_HPC_HB04_N" LOC = "AL33"; ## F26 on J64 NET "FMC_HPC_HB04_P" LOC = "AM33"; ## F25 on J64 NET "FMC_HPC_HB05_N" LOC = "AN34"; ## E25 on J64 NET "FMC_HPC_HB05_P" LOC = "AN33"; ## E24 on J64 NET "FMC_HPC_HB06_CC_N" LOC = "AE26"; ## K29 on J64 NET "FMC_HPC_HB06_CC_P" LOC = "AF26"; ## K28 on J64 NET "FMC_HPC_HB07_N" LOC = "AH34"; ## J28 on J64 NET "FMC_HPC_HB07_P" LOC = "AJ34"; ## J27 on J64 NET "FMC_HPC_HB08_N" LOC = "AK32"; ## F29 on J64 NET "FMC_HPC_HB08_P" LOC = "AK33"; ## F28 on J64 NET "FMC_HPC_HB09_N" LOC = "AK34"; ## E28 on J64 NET "FMC_HPC_HB09_P" LOC = "AL34"; ## E27 on J64 NET "FMC_HPC_HB10_N" LOC = "AF29"; ## K32 on J64 NET "FMC_HPC_HB10_P" LOC = "AF28"; ## K31 on J64 NET "FMC_HPC_HB11_N" LOC = "AJ30"; ## J31 on J64 NET "FMC_HPC_HB11_P" LOC = "AJ29"; ## J30 on J64 NET "FMC_HPC_HB12_N" LOC = "AJ32"; ## F32 on J64 NET "FMC_HPC_HB12_P" LOC = "AJ31"; ## F31 on J64 NET "FMC_HPC_HB13_N" LOC = "AH32"; ## E31 on J64 NET "FMC_HPC_HB13_P" LOC = "AH33"; ## E30 on J64 NET "FMC_HPC_HB14_N" LOC = "AD27"; ## K35 on J64 NET "FMC_HPC_HB14_P" LOC = "AE27"; ## K34 on J64 NET "FMC_HPC_HB15_N" LOC = "AE29"; ## J34 on J64 NET "FMC_HPC_HB15_P" LOC = "AE28"; ## J33 on J64 NET "FMC_HPC_HB16_N" LOC = "AH30"; ## F35 on J64 NET "FMC_HPC_HB16_P" LOC = "AH29"; ## F34 on J64 NET "FMC_HPC_HB17_CC_N" LOC = "AG28"; ## K38 on J64 NET "FMC_HPC_HB17_CC_P" LOC = "AG27"; ## K37 on J64 NET "FMC_HPC_HB18_N" LOC = "AD26"; ## J37 on J64 NET "FMC_HPC_HB18_P" LOC = "AD25"; ## J36 on J64 NET "FMC_HPC_HB19_N" LOC = "AK31"; ## E34 on J64 NET "FMC_HPC_HB19_P" LOC = "AL31"; ## E33 on J64 NET "FMC_HPC_LA00_CC_N" LOC = "AF21"; ## G7 on J64 NET "FMC_HPC_LA00_CC_P" LOC = "AF20"; ## G6 on J64 NET "FMC_HPC_LA01_CC_N" LOC = "AL19"; ## D9 on J64 NET "FMC_HPC_LA01_CC_P" LOC = "AK19"; ## D8 on J64 NET "FMC_HPC_LA02_N" LOC = "AD20"; ## H8 on J64 NET "FMC_HPC_LA02_P" LOC = "AC20"; ## H7 on J64 NET "FMC_HPC_LA03_N" LOC = "AD19"; ## G10 on J64 NET "FMC_HPC_LA03_P" LOC = "AC19"; ## G9 on J64 NET "FMC_HPC_LA04_N" LOC = "AE19"; ## H11 on J64 NET "FMC_HPC_LA04_P" LOC = "AF19"; ## H10 on J64 NET "FMC_HPC_LA05_N" LOC = "AH22"; ## D12 on J64 NET "FMC_HPC_LA05_P" LOC = "AG22"; ## D11 on J64 NET "FMC_HPC_LA06_N" LOC = "AG21"; ## C11 on J64 NET "FMC_HPC_LA06_P" LOC = "AG20"; ## C10 on J64 NET "FMC_HPC_LA07_N" LOC = "AJ21"; ## H14 on J64 NET "FMC_HPC_LA07_P" LOC = "AK21"; ## H13 on J64 NET "FMC_HPC_LA08_N" LOC = "AJ22"; ## G13 on J64 NET "FMC_HPC_LA08_P" LOC = "AK22"; ## G12 on J64 NET "FMC_HPC_LA09_N" LOC = "AL18"; ## D15 on J64 NET "FMC_HPC_LA09_P" LOC = "AM18"; ## D14 on J64 NET "FMC_HPC_LA10_N" LOC = "AL20"; ## C15 on J64 NET "FMC_HPC_LA10_P" LOC = "AM20"; ## C14 on J64 NET "FMC_HPC_LA11_N" LOC = "AN22"; ## H17 on J64 NET "FMC_HPC_LA11_P" LOC = "AM22"; ## H16 on J64 NET "FMC_HPC_LA12_N" LOC = "AL21"; ## G16 on J64 NET "FMC_HPC_LA12_P" LOC = "AM21"; ## G15 on J64 NET "FMC_HPC_LA13_N" LOC = "AN18"; ## D18 on J64 NET "FMC_HPC_LA13_P" LOC = "AP19"; ## D17 on J64 NET "FMC_HPC_LA14_N" LOC = "AN20"; ## C19 on J64

88 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

NET "FMC_HPC_LA14_P" LOC = "AN19"; ## C18 on J64 NET "FMC_HPC_LA15_N" LOC = "AL23"; ## H20 on J64 NET "FMC_HPC_LA15_P" LOC = "AM23"; ## H19 on J64 NET "FMC_HPC_LA16_N" LOC = "AN23"; ## G19 on J64 NET "FMC_HPC_LA16_P" LOC = "AP22"; ## G18 on J64 NET "FMC_HPC_LA17_CC_N" LOC = "AM27"; ## D21 on J64 NET "FMC_HPC_LA17_CC_P" LOC = "AN27"; ## D20 on J64 NET "FMC_HPC_LA18_CC_N" LOC = "AJ25"; ## C23 on J64 NET "FMC_HPC_LA18_CC_P" LOC = "AH25"; ## C22 on J64 NET "FMC_HPC_LA19_N" LOC = "AN24"; ## H23 on J64 NET "FMC_HPC_LA19_P" LOC = "AN25"; ## H22 on J64 NET "FMC_HPC_LA20_N" LOC = "AL24"; ## G22 on J64 NET "FMC_HPC_LA20_P" LOC = "AK23"; ## G21 on J64 NET "FMC_HPC_LA21_N" LOC = "AP29"; ## H26 on J64 NET "FMC_HPC_LA21_P" LOC = "AN29"; ## H25 on J64 NET "FMC_HPC_LA22_N" LOC = "AP26"; ## G25 on J64 NET "FMC_HPC_LA22_P" LOC = "AP27"; ## G24 on J64 NET "FMC_HPC_LA23_N" LOC = "AM26"; ## D24 on J64 NET "FMC_HPC_LA23_P" LOC = "AL26"; ## D23 on J64 NET "FMC_HPC_LA24_N" LOC = "AM30"; ## H29 on J64 NET "FMC_HPC_LA24_P" LOC = "AN30"; ## H28 on J64 NET "FMC_HPC_LA25_N" LOC = "AM28"; ## G28 on J64 NET "FMC_HPC_LA25_P" LOC = "AN28"; ## G27 on J64 NET "FMC_HPC_LA26_N" LOC = "AL25"; ## D27 on J64 NET "FMC_HPC_LA26_P" LOC = "AM25"; ## D26 on J64 NET "FMC_HPC_LA27_N" LOC = "AP31"; ## C27 on J64 NET "FMC_HPC_LA27_P" LOC = "AP30"; ## C26 on J64 NET "FMC_HPC_LA28_N" LOC = "AJ27"; ## H32 on J64 NET "FMC_HPC_LA28_P" LOC = "AK27"; ## H31 on J64 NET "FMC_HPC_LA29_N" LOC = "AK28"; ## G31 on J64 NET "FMC_HPC_LA29_P" LOC = "AL28"; ## G30 on J64 NET "FMC_HPC_LA30_N" LOC = "AK24"; ## H35 on J64 NET "FMC_HPC_LA30_P" LOC = "AJ24"; ## H34 on J64 NET "FMC_HPC_LA31_N" LOC = "AK29"; ## G34 on J64 NET "FMC_HPC_LA31_P" LOC = "AL29"; ## G33 on J64 NET "FMC_HPC_LA32_N" LOC = "AG26"; ## H38 on J64 NET "FMC_HPC_LA32_P" LOC = "AG25"; ## H37 on J64 NET "FMC_HPC_LA33_N" LOC = "AH24"; ## G37 on J64 NET "FMC_HPC_LA33_P" LOC = "AH23"; ## G36 on J64 NET "FMC_HPC_PG_M2C_LS" LOC = "J27"; ## F1 on J64 NET "FMC_HPC_PRSNT_M2C_L" LOC = "AP25"; ## H2 on J64 ## NET "FMC_LPC_CLK0_M2C_N" LOC = "B10"; ## H5 on J63 NET "FMC_LPC_CLK0_M2C_P" LOC = "A10"; ## H4 on J63 NET "FMC_LPC_CLK1_M2C_N" LOC = "G33"; ## G3 on J63 NET "FMC_LPC_CLK1_M2C_P" LOC = "F33"; ## G2 on J63 NET "FMC_LPC_DP0_C2M_N" LOC = "D2"; ## C3 on J63 NET "FMC_LPC_DP0_C2M_P" LOC = "D1"; ## C2 on J63 NET "FMC_LPC_DP0_M2C_N" LOC = "G4"; ## C7 on J63 NET "FMC_LPC_DP0_M2C_P" LOC = "G3"; ## C6 on J63 NET "FMC_LPC_GBTCLK0_M2C_N" LOC = "M5"; ## D5 on J63 NET "FMC_LPC_GBTCLK0_M2C_P" LOC = "M6"; ## D4 on J63 NET "FMC_LPC_IIC_SCL_LS" LOC = "AF13"; ## 2 of Q26 NET "FMC_LPC_IIC_SDA_LS" LOC = "AG13"; ## 2 of Q27 NET "FMC_LPC_LA00_CC_N" LOC = "K27"; ## G7 on J63 NET "FMC_LPC_LA00_CC_P" LOC = "K26"; ## G6 on J63 NET "FMC_LPC_LA01_CC_N" LOC = "E31"; ## D9 on J63 NET "FMC_LPC_LA01_CC_P" LOC = "F31"; ## D8 on J63 NET "FMC_LPC_LA02_N" LOC = "H30"; ## H8 on J63 NET "FMC_LPC_LA02_P" LOC = "G31"; ## H7 on J63 NET "FMC_LPC_LA03_N" LOC = "J32"; ## G10 on J63 NET "FMC_LPC_LA03_P" LOC = "J31"; ## G9 on J63 NET "FMC_LPC_LA04_N" LOC = "J29"; ## H11 on J63 NET "FMC_LPC_LA04_P" LOC = "K28"; ## H10 on J63 NET "FMC_LPC_LA05_N" LOC = "H33"; ## D12 on J63

ML605 Hardware User Guide www.xilinx.com 89

UG534 (v1.8) October 2, 2012

Appendix D: ML605 Master UCF

NET "FMC_LPC_LA05_P" LOC = "H34"; ## D11 on J63 NET "FMC_LPC_LA06_N" LOC = "J34"; ## C11 on J63 NET "FMC_LPC_LA06_P" LOC = "K33"; ## C10 on J63 NET "FMC_LPC_LA07_N" LOC = "H32"; ## H14 on J63 NET "FMC_LPC_LA07_P" LOC = "G32"; ## H13 on J63 NET "FMC_LPC_LA08_N" LOC = "K29"; ## G13 on J63 NET "FMC_LPC_LA08_P" LOC = "J30"; ## G12 on J63 NET "FMC_LPC_LA09_N" LOC = "L26"; ## D15 on J63 NET "FMC_LPC_LA09_P" LOC = "L25"; ## D14 on J63 NET "FMC_LPC_LA10_N" LOC = "G30"; ## C15 on J63 NET "FMC_LPC_LA10_P" LOC = "F30"; ## C14 on J63 NET "FMC_LPC_LA11_N" LOC = "D32"; ## H17 on J63 NET "FMC_LPC_LA11_P" LOC = "D31"; ## H16 on J63 NET "FMC_LPC_LA12_N" LOC = "E33"; ## G16 on J63 NET "FMC_LPC_LA12_P" LOC = "E32"; ## G15 on J63 NET "FMC_LPC_LA13_N" LOC = "C34"; ## D18 on J63 NET "FMC_LPC_LA13_P" LOC = "D34"; ## D17 on J63 NET "FMC_LPC_LA14_N" LOC = "B34"; ## C19 on J63 NET "FMC_LPC_LA14_P" LOC = "C33"; ## C18 on J63 NET "FMC_LPC_LA15_N" LOC = "B32"; ## H20 on J63 NET "FMC_LPC_LA15_P" LOC = "C32"; ## H19 on J63 NET "FMC_LPC_LA16_N" LOC = "B33"; ## G19 on J63 NET "FMC_LPC_LA16_P" LOC = "A33"; ## G18 on J63 NET "FMC_LPC_LA17_CC_N" LOC = "N29"; ## D21 on J63 NET "FMC_LPC_LA17_CC_P" LOC = "N28"; ## D20 on J63 NET "FMC_LPC_LA18_CC_N" LOC = "L30"; ## C23 on J63 NET "FMC_LPC_LA18_CC_P" LOC = "L29"; ## C22 on J63 NET "FMC_LPC_LA19_N" LOC = "N30"; ## H23 on J63 NET "FMC_LPC_LA19_P" LOC = "M30"; ## H22 on J63 NET "FMC_LPC_LA20_N" LOC = "R29"; ## G22 on J63 NET "FMC_LPC_LA20_P" LOC = "P29"; ## G21 on J63 NET "FMC_LPC_LA21_N" LOC = "T26"; ## H26 on J63 NET "FMC_LPC_LA21_P" LOC = "R26"; ## H25 on J63 NET "FMC_LPC_LA22_N" LOC = "P27"; ## G25 on J63 NET "FMC_LPC_LA22_P" LOC = "N27"; ## G24 on J63 NET "FMC_LPC_LA23_N" LOC = "R27"; ## D24 on J63 NET "FMC_LPC_LA23_P" LOC = "R28"; ## D23 on J63 NET "FMC_LPC_LA24_N" LOC = "P32"; ## H29 on J63 NET "FMC_LPC_LA24_P" LOC = "N32"; ## H28 on J63 NET "FMC_LPC_LA25_N" LOC = "P30"; ## G28 on J63 NET "FMC_LPC_LA25_P" LOC = "P31"; ## G27 on J63 NET "FMC_LPC_LA26_N" LOC = "M32"; ## D27 on J63 NET "FMC_LPC_LA26_P" LOC = "L33"; ## D26 on J63 NET "FMC_LPC_LA27_N" LOC = "R32"; ## C27 on J63 NET "FMC_LPC_LA27_P" LOC = "R31"; ## C26 on J63 NET "FMC_LPC_LA28_N" LOC = "M33"; ## H32 on J63 NET "FMC_LPC_LA28_P" LOC = "N33"; ## H31 on J63 NET "FMC_LPC_LA29_N" LOC = "P34"; ## G31 on J63 NET "FMC_LPC_LA29_P" LOC = "N34"; ## G30 on J63 NET "FMC_LPC_LA30_N" LOC = "M27"; ## H35 on J63 NET "FMC_LPC_LA30_P" LOC = "M26"; ## H34 on J63 NET "FMC_LPC_LA31_N" LOC = "L31"; ## G34 on J63 NET "FMC_LPC_LA31_P" LOC = "M31"; ## G33 on J63 NET "FMC_LPC_LA32_N" LOC = "M25"; ## H38 on J63 NET "FMC_LPC_LA32_P" LOC = "N25"; ## H37 on J63 NET "FMC_LPC_LA33_N" LOC = "K31"; ## G37 on J63 NET "FMC_LPC_LA33_P" LOC = "K32"; ## G36 on J63 NET "FMC_LPC_PRSNT_M2C_L" LOC = "AD9"; ## H2 on J63 ## ## NET "FPGA_CCLK" LOC = "K8"; ## SEE NET "FLASH_NN" GROUP NET "FPGA_DONE" LOC = "R8"; ## 2 on "DONE" LED DS13 NET "FPGA_DX_N" LOC = "W17"; ## 4 on J35 NET "FPGA_DX_P" LOC = "W18"; ## 2 on J35 ## NET "FPGA_FCS_B" LOC = "Y24"; ## SEE NET "FLASH_NN" GROUP ## NET "FPGA_FOE_B" LOC = "AA24"; ## SEE NET "FLASH_NN" GROUP

90 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

## NET "FPGA_FWE_B" LOC = "AF23"; ## SEE NET "FLASH_NN" GROUP ## NET "FPGA_INIT_B" LOC = "P8"; ## 1 on Q14 ("INIT" LED DS31 driver) NET "FPGA_M0" LOC = "U8"; ## 3 on S2 DIP switch (active-High) NET "FPGA_M1" LOC = "W8"; ## 4 on S2 DIP switch (active-High) NET "FPGA_M2" LOC = "V8"; ## 4 on S2 DIP switch (active-High) NET "FPGA_PROG_B" LOC = "L8"; ## 1 on SW4 pushbutton (active-Low) NET "FPGA_TCK" LOC = "AE8"; ## 80 on U19 NET "FPGA_TDI" LOC = "AD8"; ## 82 on U19 NET "FPGA_TMS" LOC = "AF8"; ## 85 on U19 NET "FPGA_VBATT" LOC = "N8"; ## 1 on B1 (battery + terminal) ## NET "GPIO_DIP_SW1" LOC = "D22"; ## 1 on SW1 DIP switch (active-High) NET "GPIO_DIP_SW2" LOC = "C22"; ## 2 on SW1 DIP switch (active-High) NET "GPIO_DIP_SW3" LOC = "L21"; ## 3 on SW1 DIP switch (active-High) NET "GPIO_DIP_SW4" LOC = "L20"; ## 4 on SW1 DIP switch (active-High) NET "GPIO_DIP_SW5" LOC = "C18"; ## 5 on SW1 DIP switch (active-High) NET "GPIO_DIP_SW6" LOC = "B18"; ## 6 on SW1 DIP switch (active-High) NET "GPIO_DIP_SW7" LOC = "K22"; ## 7 on SW1 DIP switch (active-High) NET "GPIO_DIP_SW8" LOC = "K21"; ## 8 on SW1 DIP switch (active-High) ## NET "GPIO_LED_0" LOC = "AC22"; ## 2 on LED DS12, 1 on J62 NET "GPIO_LED_1" LOC = "AC24"; ## 2 on LED DS11, 2 on J62 NET "GPIO_LED_2" LOC = "AE22"; ## 2 on LED DS9, 3 on J62 NET "GPIO_LED_3" LOC = "AE23"; ## 2 on LED DS10, 4 on J62 NET "GPIO_LED_4" LOC = "AB23"; ## 2 on LED DS15, 5 on J62 NET "GPIO_LED_5" LOC = "AG23"; ## 2 on LED DS14, 6 on J62 NET "GPIO_LED_6" LOC = "AE24"; ## 2 on LED DS22, 7 on J62 NET "GPIO_LED_7" LOC = "AD24"; ## 2 on LED DS21, 8 on J62 ## NET "GPIO_LED_C" LOC = "AP24"; ## 2 on LED DS16 NET "GPIO_LED_E" LOC = "AE21"; ## 2 on LED DS19 NET "GPIO_LED_N" LOC = "AH27"; ## 2 on LED DS20 NET "GPIO_LED_S" LOC = "AH28"; ## 2 on LED DS18 NET "GPIO_LED_W" LOC = "AD21"; ## 2 on LED DS17 ## NET "GPIO_SW_C" LOC = "G26"; ## 2 on SW9 pushbutton (active-High) NET "GPIO_SW_E" LOC = "G17"; ## 2 on SW7 pushbutton (active-High) NET "GPIO_SW_N" LOC = "A19"; ## 2 on SW5 pushbutton (active-High) NET "GPIO_SW_S" LOC = "A18"; ## 2 on SW6 pushbutton (active-High) NET "GPIO_SW_W" LOC = "H17"; ## 2 on SW8 pushbutton (active-High) ## NET "IIC_SCL_DVI" LOC = "AN10"; ## 2 on Q5, 15 on U38 NET "IIC_SCL_MAIN_LS" LOC = "AK9"; ## 2 on Q19 NET "IIC_SCL_SFP" LOC = "AA34"; ## 2 on Q23 NET "IIC_SDA_DVI" LOC = "AP10"; ## 2 on Q6, 14 on U38 NET "IIC_SDA_MAIN_LS" LOC = "AE9"; ## 2 on Q20 NET "IIC_SDA_SFP" LOC = "AA33"; ## 2 on Q21 ## NET "LCD_DB4_LS" LOC = "AD14"; ## 4 on J41 NET "LCD_DB5_LS" LOC = "AK11"; ## 3 on J41 NET "LCD_DB6_LS" LOC = "AJ11"; ## 2 on J41 NET "LCD_DB7_LS" LOC = "AE12"; ## 1 on J41 NET "LCD_E_LS" LOC = "AK12"; ## 9 on J41 NET "LCD_RS_LS" LOC = "T28"; ## 11 on J41 NET "LCD_RW_LS" LOC = "AC14"; ## 10 on J41 ## NET "P30_CS_SEL" LOC = "AJ12"; ## 2 on S2 DIP switch (active-High),1 on U10 ## NET "PCIE_100M_MGT0_N" LOC = "P5"; ## 15 on U14 NET "PCIE_100M_MGT0_P" LOC = "P6"; ## 16 on U14 NET "PCIE_250M_MGT1_N" LOC = "V5"; ## 18 on U9 NET "PCIE_250M_MGT1_P" LOC = "V6"; ## 17 on U9 NET "PCIE_PERST_B_LS" LOC = "AE13"; ## 4 on U32 NET "PCIE_RX0_N" LOC = "J4"; ## B15 on P1

ML605 Hardware User Guide www.xilinx.com 91

UG534 (v1.8) October 2, 2012

Appendix D: ML605 Master UCF

NET "PCIE_RX0_P" LOC = "J3"; ## B14 on P1 NET "PCIE_RX1_N" LOC = "K6"; ## B20 on P1 NET "PCIE_RX1_P" LOC = "K5"; ## B19 on P1 NET "PCIE_RX2_N" LOC = "L4"; ## B24 on P1 NET "PCIE_RX2_P" LOC = "L3"; ## B23 on P1 NET "PCIE_RX3_N" LOC = "N4"; ## B28 on P1 NET "PCIE_RX3_P" LOC = "N3"; ## B27 on P1 NET "PCIE_RX4_N" LOC = "R4"; ## B34 on P1 NET "PCIE_RX4_P" LOC = "R3"; ## B33 on P1 NET "PCIE_RX5_N" LOC = "U4"; ## B38 on P1 NET "PCIE_RX5_P" LOC = "U3"; ## B37 on P1 NET "PCIE_RX6_N" LOC = "W4"; ## B42 on P1 NET "PCIE_RX6_P" LOC = "W3"; ## B41 on P1 NET "PCIE_RX7_N" LOC = "AA4"; ## B46 on P1 NET "PCIE_RX7_P" LOC = "AA3"; ## B45 on P1 NET "PCIE_TX0_N" LOC = "F2"; ## A17 on P1 NET "PCIE_TX0_P" LOC = "F1"; ## A16 on P1 NET "PCIE_TX1_N" LOC = "H2"; ## A22 on P1 NET "PCIE_TX1_P" LOC = "H1"; ## A21 on P1 NET "PCIE_TX2_N" LOC = "K2"; ## A26 on P1 NET "PCIE_TX2_P" LOC = "K1"; ## A25 on P1 NET "PCIE_TX3_N" LOC = "M2"; ## A30 on P1 NET "PCIE_TX3_P" LOC = "M1"; ## A29 on P1 NET "PCIE_TX4_N" LOC = "P2"; ## A36 on P1 NET "PCIE_TX4_P" LOC = "P1"; ## A35 on P1 NET "PCIE_TX5_N" LOC = "T2"; ## A40 on P1 NET "PCIE_TX5_P" LOC = "T1"; ## A39 on P1 NET "PCIE_TX6_N" LOC = "V2"; ## A44 on P1 NET "PCIE_TX6_P" LOC = "V1"; ## A43 on P1 NET "PCIE_TX7_N" LOC = "Y2"; ## A48 on P1 NET "PCIE_TX7_P" LOC = "Y1"; ## A47 on P1 NET "PCIE_WAKE_B_LS" LOC = "AD22"; ## B11 on P1 ## NET "PHY_COL" LOC = "AK13"; ## 114 on U80 NET "PHY_CRS" LOC = "AL13"; ## 115 on U80 NET "PHY_INT" LOC = "AH14"; ## 32 on U80 NET "PHY_MDC" LOC = "AP14"; ## 35 on U80 NET "PHY_MDIO" LOC = "AN14"; ## 33 on U80 NET "PHY_RESET" LOC = "AH13"; ## 36 on U80 NET "PHY_RXCLK" LOC = "AP11"; ## 7 on U80 NET "PHY_RXCTL_RXDV" LOC = "AM13"; ## 4 on U80 NET "PHY_RXD0" LOC = "AN13"; ## 3 on U80 NET "PHY_RXD1" LOC = "AF14"; ## 128 on U80 NET "PHY_RXD2" LOC = "AE14"; ## 126 on U80 NET "PHY_RXD3" LOC = "AN12"; ## 125 on U80 NET "PHY_RXD4" LOC = "AM12"; ## 124 on U80 NET "PHY_RXD5" LOC = "AD11"; ## 123 on U80 NET "PHY_RXD6" LOC = "AC12"; ## 121 on U80 NET "PHY_RXD7" LOC = "AC13"; ## 120 on U80 NET "PHY_RXER" LOC = "AG12"; ## 9 on U80 NET "PHY_TXCLK" LOC = "AD12"; ## 10 on U80 NET "PHY_TXCTL_TXEN" LOC = "AJ10"; ## 16 on U80 NET "PHY_TXC_GTXCLK" LOC = "AH12"; ## 14 on U80 NET "PHY_TXD0" LOC = "AM11"; ## 18 on U80 NET "PHY_TXD1" LOC = "AL11"; ## 19 on U80 NET "PHY_TXD2" LOC = "AG10"; ## 20 on U80 NET "PHY_TXD3" LOC = "AG11"; ## 24 on U80 NET "PHY_TXD4" LOC = "AL10"; ## 25 on U80 NET "PHY_TXD5" LOC = "AM10"; ## 26 on U80 NET "PHY_TXD6" LOC = "AE11"; ## 28 on U80 NET "PHY_TXD7" LOC = "AF11"; ## 29 on U80 NET "PHY_TXER" LOC = "AH10"; ## 13 on U80 ## ## NET "PLATFLASH_L_B" LOC = "AC23"; ## SEE NET "FLASH_NN" GROUP ##

92 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

NET "PMBUS_ALERT_LS" LOC = "AH9"; ## 2 on Q15 NET "PMBUS_CLK_LS" LOC = "AC10"; ## 2 on Q18 NET "PMBUS_CTRL_LS" LOC = "AJ9"; ## 2 on Q16 NET "PMBUS_DATA_LS" LOC = "AB10"; ## 2 on Q17 ## NET "SFP_LOS" LOC = "V23"; ## 8 on P4 NET "SFP_RX_N" LOC = "E4"; ## 12 on P4 NET "SFP_RX_P" LOC = "E3"; ## 13 on P4 NET "SFP_TX_DISABLE_FPGA" LOC = "AP12"; ## 1 on Q22 NET "SFP_TX_N" LOC = "C4"; ## 19 on P4 NET "SFP_TX_P" LOC = "C3"; ## 18 on P4 ## NET "SGMIICLK_QO_N" LOC = "H5"; ## 2 on series C55 0.1uF NET "SGMIICLK_QO_P" LOC = "H6"; ## 2 on series C56 0.1uF NET "SGMII_RX_N" LOC = "B6"; ## 1 on series C163 0.01uF NET "SGMII_RX_P" LOC = "B5"; ## 1 on series C162 0.01uF NET "SGMII_TX_N" LOC = "A4"; ## 1 on series C164 0.01uF NET "SGMII_TX_P" LOC = "A3"; ## 1 on series C165 0.01uF ## NET "SMA_REFCLK_N" LOC = "F5"; ## 1 on series C61 0.1uF NET "SMA_REFCLK_P" LOC = "F6"; ## 1 on series C62 0.1uF NET "SMA_RX_N" LOC = "D6"; ## 1 on series C57 0.1uF NET "SMA_RX_P" LOC = "D5"; ## 1 on series C58 0.1uF NET "SMA_TX_N" LOC = "B2"; ## 1 on J27 SMA NET "SMA_TX_P" LOC = "B1"; ## 1 on J26 SMA ## NET "SM_FAN_PWM" LOC = "L10"; ## 1 on Q24 NET "SM_FAN_TACH" LOC = "M10"; ## 2 on R368 ## NET "SYSACE_CFGTDI" LOC = "AC8"; ## 81 on U19 NET "SYSACE_D0" LOC = "AM15"; ## 66 on U19 NET "SYSACE_D1" LOC = "AJ17"; ## 65 on U19 NET "SYSACE_D2" LOC = "AJ16"; ## 63 on U19 NET "SYSACE_D3" LOC = "AP16"; ## 62 on U19 NET "SYSACE_D4" LOC = "AG16"; ## 61 on U19 NET "SYSACE_D5" LOC = "AH15"; ## 60 on U19 NET "SYSACE_D6" LOC = "AF16"; ## 59 on U19 NET "SYSACE_D7" LOC = "AN15"; ## 58 on U19 NET "SYSACE_MPA00" LOC = "AC15"; ## 70 on U19 NET "SYSACE_MPA01" LOC = "AP15"; ## 69 on U19 NET "SYSACE_MPA02" LOC = "AG17"; ## 68 on U19 NET "SYSACE_MPA03" LOC = "AH17"; ## 67 on U19 NET "SYSACE_MPA04" LOC = "AG15"; ## 45 on U19 NET "SYSACE_MPA05" LOC = "AF15"; ## 44 on U19 NET "SYSACE_MPA06" LOC = "AK14"; ## 43 on U19 NET "SYSACE_MPBRDY" LOC = "AJ15"; ## 39 on U19 NET "SYSACE_MPCE" LOC = "AJ14"; ## 42 on U19 NET "SYSACE_MPIRQ" LOC = "L9"; ## 41 on U19 NET "SYSACE_MPOE" LOC = "AL15"; ## 77 on U19 NET "SYSACE_MPWE" LOC = "AL14"; ## 76 on U19 ## NET "SYSCLK_N" LOC = "H9"; ## 5 on U11, 5 on U89 (DNP) NET "SYSCLK_P" LOC = "J9"; ## 4 on U11, 4 on U89 (DNP) ## NET "USB_1_CTS" LOC = "T24"; ## 22 on U34 NET "USB_1_RTS" LOC = "T23"; ## 23 on U34 NET "USB_1_RX" LOC = "J25"; ## 24 on U34 NET "USB_1_TX" LOC = "J24"; ## 25 on U34 ## NET "USB_A0_LS" LOC = "Y32"; ## 14 on U30 NET "USB_A1_LS" LOC = "W26"; ## 2 on U29 NET "USB_CS_B_LS" LOC = "W27"; ## 18 on U29 NET "USB_D0_LS" LOC = "R33"; ## 8 on U31 NET "USB_D1_LS" LOC = "R34"; ## 14 on U31 NET "USB_D2_LS" LOC = "T30"; ## 6 on U31

ML605 Hardware User Guide www.xilinx.com 93

UG534 (v1.8) October 2, 2012

Appendix D: ML605 Master UCF

NET "USB_D3_LS" LOC = "T31"; ## 16 on U31 NET "USB_D4_LS" LOC = "T29"; ## 4 on U31 NET "USB_D5_LS" LOC = "V28"; ## 18 on U31 NET "USB_D6_LS" LOC = "V27"; ## 2 on U31 NET "USB_D7_LS" LOC = "U25"; ## 12 on U30 NET "USB_D8_LS" LOC = "Y28"; ## 14 on U29 NET "USB_D9_LS" LOC = "W32"; ## 8 on U29 NET "USB_D10_LS" LOC = "W31"; ## 12 on U29 NET "USB_D11_LS" LOC = "Y29"; ## 2 on U30 NET "USB_D12_LS" LOC = "W29"; ## 18 on U30 NET "USB_D13_LS" LOC = "Y34"; ## 4 on U30 NET "USB_D14_LS" LOC = "Y33"; ## 16 on U30 NET "USB_D15_LS" LOC = "Y31"; ## 6 on U30 NET "USB_INT_LS" LOC = "Y27"; ## 6 on U29 NET "USB_RD_B_LS" LOC = "W25"; ## 16 on U29 NET "USB_RESET_B_LS" LOC = "T25"; ## 8 on U30 NET "USB_WR_B_LS" LOC = "V25"; ## 4 on U29 ## NET "USER_CLOCK" LOC = "U23"; ## 5 on X5 NET "USER_SMA_CLOCK_N" LOC = "M22"; ## 1 on J55 SMA NET "USER_SMA_CLOCK_P" LOC = "L23"; ## 1 on J58 SMA NET "USER_SMA_GPIO_N" LOC = "W34"; ## 1 on J56 SMA NET "USER_SMA_GPIO_P" LOC = "V34"; ## 1 on J57 SMA ## NET "VAUX_CURR_N" LOC = "P26"; ## 1 on series R373 1.00K NET "VAUX_CURR_P" LOC = "P25"; ## 1 on series R370 1.00K NET "VAUX_VOLT_N" LOC = "M28"; ## 1 on series R371 1.00K NET "VAUX_VOLT_P" LOC = "L28"; ## 1 on series R372 1.00K

94 www.xilinx.com ML605 Hardware User Guide

UG534 (v1.8) October 2, 2012

Regulatory and Compliance Information

This product is designed and tested to conform to the European Union directives and standards described in this section.

Declaration of Conformity

To view the Declaration of Conformity online, visit:

http://www.xilinx.com/support/documentation/boards_and_kits/ ce-declarations-of-conformity-xtp251.zip

Directives

Appendix E

Standards

Electromagnetic Compatibility

Safety

2006/95/EC, Low Voltage Directive (LVD)

2004/108/EC, Electromagnetic Compatibility (EMC) Directive

EN standards are maintained by the European Committee for Electrotechnical Standardization (CENELEC). IEC standards are maintained by the International Electrotechnical Commission (IEC).

EN 55022:2010, Information Technology Equipment Radio Disturbance Characteristics – Limits

and Methods of Measurement

EN 55024:2010, Information Technology Equipment Immunity Characteristics – Limits and Methods of Measurement

This is a Class A product. In a domestic environment, this product can cause radio interference, in which case the user might be required to take adequate measures.

IEC 60950-1:2005, Information technology equipment – Safety, Part 1: General requirements

EN 60950-1:2006, Information technology equipment – Safety, Part 1: General requirements

ML605 Hardware User Guide www.xilinx.com 95

UG534 (v1.8) October 2, 2012

Appendix E: Regulatory and Compliance Information

Markings

This product complies with Directive 2002/96/EC on waste electrical and electronic equipment (WEEE). The affixed product label indicates that the user must not discard this electrical or electronic product in domestic household waste.

This product complies with Directive 2002/95/EC on the restriction of hazardous substances (RoHS) in electrical and electronic equipment.

This product complies with CE Directives 2006/95/EC, Low Voltage Directive (LVD) and 2004/108/EC, Electromagnetic Compatibility (EMC) Directive.

96 www.xilinx.com ML605 Hardware User Guide
