PS800 TREADMILL
|
OWNER'S |
Model TPS800-17 |
MANUAL |
Version 072517 |
* Assembly Guide & Warranty Card Included |
PS800 TREADMILL OWNER’S MANUAL
IMPORTANT:
All Products shown are prototype. Actual product delivered may vary. Product specifications, features & software are subject to change without notice. For the most up to date owner’s manual please visit www.truefitness.com.
For documents in additional languages please visit www.truefitness.com/resources/document-library/
IMPORTANTE:
Todos los productos mostrados son prototipos. La realidad el producto suministrado puede diferir. Especificaciones de productos, características y software están sujetas a cambios sin previo aviso. Para la más actualizada de este manual del propietario, por favor visite www.truefitness.com
Para los documentos en otros idiomas, por favor visite www.truefitness.com/resources/document-library/
IMPORTANT:
Tous les produits présentés sont prototype. Le produit réel livré peut varier.
Spécifications du produit, caractéristiques et logiciels sont sujettes à modification sans préavis. Pour la plus à jour le manuel du propriétaire s’il vous plaît visitez www.truefitness.com.
Pour documents dans des langues supplémentaires, veuillez www.truefitness.com/resources/document-library/ de visite
www.truefitness.com
www.truefitness.com/resources/document-library/
هام:
جميع المنتجات المعروضة هي النموذج . المنتج الفعلي تسليمها قد تختلف.
مواصفات المنتج، و الميزات و البرامج تخضع للتغيير دون إشعار .
ل معظم ما يصل إلى دليل المالك تاريخ يرجى زيارة www.truefitness.com
للمستندات بلغات إضافية، يرجى زيارة www.truefitness.com/resources/document-library/
WICHTIG:
Alle hier gezeigten Produkte sind Prototypen. Das tatsächliche Produkt ausgeliefert wird, kann variieren. Produkt-Spezifikationen, Funktionen und Software können sich ohne vorherige Ankündigung ändern. In den meisten Fällen bis zu Bedienungsanleitung Bisher besuchen Sie bitte www.truefitness.com.
Für Dokumente in weiteren Sprachen finden Sie unter www.truefitness.com/resources/document-library/
BELANGRIJK:
Alle getoonde producten zijn prototype. Daadwerkelijke product geleverd kan verschillen.
Product specificaties, eigenschappen & software zijn onderhevig aan verandering zonder kennisgeving. Voor de meest actuele handleiding van de eigenaar kunt u terecht www.truefitness.com.
Voor documenten in andere talen kunt u terecht op www.truefitness.com/resources/document-library/
ВАЖНО:
Все товары указаны прототипа. Фактический продукт, поставляемый могут отличаться. Технические характеристики, особенности и программного обеспечения могут быть изменены без предварительного уведомления.
Для получения самой последней на сегодняшний день руководство по эксплуатации пожалуйста, посетите www. truefitness.com
.Для документов на другие языки, пожалуйста, посетите www.truefitness.com/resources/document-library/
Truefitness.com / 800.426.6570 / 636.272.7100
PS800 TREADMILL OWNER’S MANUAL
Frank Trulaske began TRUE Fitness over thirty-five year ago with the simple philosophy of delivering superior fitness products, service and support. Today, TRUE is the global leader in premium fitness equipment for the commercial and residential markets. Our goal is to be the leader in technology, innovation, performance, safety and style. TRUE has received many awards for its product over the years and remains the benchmark for the industry. Fitness facilities and consumers invest in TRUE products for their durable commercial platforms used in all its products, both commercial and residential alike.
The proud manufacturing tradition of quality and the culture of innovation at TRUE have given rise to a full line of extraordinary cardio and strength equipment. As a result, people all over the world are benefiting from the TRUE experience. Innovation across the full product line has made TRUE successful and is a trademark of the TRUE heritage. TRUE’s patented Heart Rate Control technology is just one of the remarkable ways we deliver simple and superior performance every user can enjoy, and most importantly, use to achieve personal health and fitness goals.
At the heart of our success is the relentless and systematic life testing of both our products and their components. We have dedicated employees who understand our philosophy is to deliver the best products in the world.
Our goal is to deliver the world’s best premium equipment for our customers’ health and fitness solutions.
Truefitness.com / 800.426.6570 / 636.272.7100
PS800 TREADMILL OWNER’S MANUAL
TABLE OF CONTENTS:
Chapter 1: Safety Instructions
Safety Instructions |
1 |
Space Requirements |
4 |
Use of Safety Key |
4 |
Grounding Instructions |
5 |
Power Requirements |
6 |
Warning Decals |
7 |
Chapter 2: Assembly Guide
Safety Instructions |
8 |
Pre-Assembly Checklist |
9 |
Space Requirements |
10 |
Chapter 3: Product Overview
Treadmill Overview |
15 |
Chapter 4: Programming & Operation
Heart Rate Monitoring |
17 |
Heart Rate Control |
18 |
Program Descriptions |
19 |
Console Overview |
21 |
Console Navigation |
23 |
User Profiles |
26 |
Bluetooth Functions |
27 |
Advanced Console Functions |
29 |
Chapter 5: Care & Maintenance
Care & Maintenance |
35 |
Cleaning the Equipment |
35 |
Running Belt Alignment |
36 |
Tensioning the Running Belt |
37 |
Treadmill Lubrication |
37 |
Leveling the Treadmill |
37 |
Other Scheduled Preventive Maintenance |
38 |
Long Term Storage |
38 |
Chapter 6: Customer Service
Contacting Service |
39 |
Contacting Sales |
39 |
Reporting Freight Claims or Parts Damage |
40 |
Chapter 7: Additional Information
Troubleshooting Guide |
41 |
Product Specifications |
47 |
Warranty Registration |
49 |
Truefitness.com / 800.426.6570 / 636.272.7100
CHAPTER 1: SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE SAFETY INSTRUCTIONS
This equipment is intended for a commercial or institutional setting. This owner’s manual should be accessible to all personal trainers, faculty, and members.
WARNING:
ALL EXERCISERS MUST READ ALL INSTRUCTIONS BEFORE USING THE EQUIPMENT.
WARNING:
Heart rate monitoring systems may be inaccurate for some individuals. Over-exercising may result in serious injury or death. If you feel faint, stop exercising immediately.
WARNING:
Equipment should be immediately taken out of use if it fails to work properly or when a warning is presented electronically.
TRUE STRONGLY recommends seeing a physician for a complete medical exam before undertaking an exercise program, particularly if the user has a family history of high blood pressure or heart disease, is over the age of 45, smokes, has high cholesterol, is obese or has not exercised regularly in the past year. Additionally, TRUE recommends consulting a fitness professional on the correct use of this product. If at any time while exercising the user experiences faintness, dizziness, pain or shortness of breath, he or she must stop immediately.
WARNING:
To reduce the risk of electrical shock, always unplug this TRUE product before cleaning or attempting any maintenance activity. Do not handle the plug with wet hands.
WARNING:
To reduce the risk of burns, fire, electric shock or injury, it is imperative to connect each product to a properly grounded 110V electrical outlet. A risk of electrical shock may result from improper connection of the equipment’s grounding
conductor. Check with a qualified electrician if you are unsure about proper grounding techniques. Do not modify the plug provided with this product. If it will not fit an electrical outlet, have a proper outlet installed by a qualified electrician. Your TRUE Fitness product must be properly grounded to reduce risk of shock if the equipment malfunctions. Your equipment is equipped with an electrical cord, which includes an equipment grounding conductor and a grounding plug. The plug must be inserted into an outlet that has been properly installed and grounded in accordance with all local codes and ordinances. A temporary adapter cannot be used to connect this plug to a two-pole receptacle in North America. If a properly
grounded 15 amp outlet is not available, a qualified electrician must install one.
WARNING:
Do not move the equipment by lifting the console. Do not use the console as a handlebar during a workout.
WARNING:
This product contains chemicals known to the state of California to cause cancer and birth defects or other reproductive harm.
WARNING:
Keep equipment stable on flat ground. |
|
Truefitness.com / 800.426.6570 / 636.272.7100 |
1 |
CHAPTER 1: SAFETY INSTRUCTIONS
WARNING:
Replace warning labels that may be worn, damaged or missing
WARNING:
Replace any non-working or damaged components; remove the unit from service until repair is performed.
WARNING:
To reduce the risk of burns, fire and electric shock or injury to persons, follow these instructions:
•This appliance should never be left unattended when plugged in.
•Do not use any type of extension cord with this product.
•Unplug it from the outlet when not in use and before any servicing.
•Do not operate the equipment while being covered with a blanket, plastic, or anything that insulates or stops airflow.
WARNING:
Risk of personal injury-crushing hazard when equipment is in operation - Keep feet, hands, and fingers away from moving parts.
CAUTION:
•Health related injuries may result from incorrect or excessive use of exercise equipment.
•Do not use typing or web surfing features at excessive speeds. Always stabilize yourself by holding a stationary handle when using typing or web surfing features. (Varies by console option)
•Do not use the contact heart rate grips as a handlebar during a workout.
•Any changes or modifications to this equipment could void the product warranty.
•To disconnect, turn power OFF at the ON/OFF switch if applicable, then remove plug from electrical outlet.
•Never operate a TRUE product if it has a damaged power cord or electrical plug, or if it has been dropped, damaged, or even partially immersed in water. Contact TRUE Customer Service for a replacement.
•Use a TRUE AC power cord or AC/DC adapter only.
*Note the plug configuration for the power adapter may vary by country.
•Position this product so the power cord plug is accessible to the user.
•Keep the power cord away from heated surfaces. Do not pull the equipment by the power cord or use the cord as a handle. Do not run the power cord along the side or under the equipment.
•If the electrical supply cord is damaged it must be replaced by the manufacturer, an authorized service agent, or a similarly qualified person to avoid a hazard.
•Do not use this product in areas where aerosol spray products are being used or where oxygen is being administered. Such substances create the danger of combustion and explosion.
•Always follow the console instructions for proper operation.
•Close supervision is necessary when used near children under the age of 15, or disabled persons.
•Do not use this product outdoors, near water, while wet, or in areas of high humidity including extreme temperature changes.
•Never operate a TRUE product with the air openings blocked. Keep air openings free of lint, hair or any obstructing material.
•Never insert objects into any openings in this product. If an object should drop inside, turn off the power, unplug the power cord from the outlet and carefully retrieve it. If the item cannot be reached, contact TRUE Customer Service.
•Never place liquids of any type directly on the unit except in the accessory tray or bottle holders. Containers with lids are recommended.
2 |
Truefitness.com / 800.426.6570 / 636.272.7100 |
CHAPTER 1: SAFETY INSTRUCTIONS
CAUTION (CONTINUED):
•Wear shoes with rubber or high traction soles. Do not use shoes with heels, leather soles, cleats or spikes. Make sure no stones are embedded in the soles. Do not use this product in bare feet. Keep all loose clothing, shoelaces and towels away from moving parts.
•Do not reach into or underneath the unit, or tip it on its side during operation.
•Use correct ergonomic positioning while running on equipment.
•Do not allow animals on or near the equipment while in operation.
•Use the side handrails whenever additional stability is required. In case of emergency, such as tripping,
the side handrails should be grabbed and the user should place his/her feet on the side platforms. The front handle bars should be used to grasp the heart rate sensors or to rest the hand on while operating the activity zone keys, but not for stability, emergency, or continuous use.
•Do not exceed maximum user weight of 350 lbs (159 kg).
•Do not use if you have a cold or fever.
•When using this exercise machine, basic precautions should always be followed.
•Use this equipment only for its intended use as described in this manual.
•Do not use attachments not recommended by the manufacturer.
•Allow only trained personnel to service this equipment.
•Avoid the possibility of bystanders being struck or caught between moving parts by making sure that they are out of reach of the equipment while it is in motion.
•This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
•Children shall not play with the appliance.
•Cleaning and user maintenance shall not be made by children without supervision.
•Allow only one person at a time on the equipment while it’s operating.
•It is the sole responsibility of the owner/operator to ensure regular and scheduled maintenance is performed.
•To avoid injury stand on the side rails before starting the equipment.
•Avoid exiting equipment while leaving the tread belt in motion.
•Never walk or jog backwards on the equipment.
•Do not change the incline of the equipment by placing objects under it.
•To avoid serious injury, do not touch the incline rack while the equipment is in use.
•To avoid serious injury, do not touch the belt while the equipment is in use.
•Do not operate under blanket or pillow. Excessive heating can occur and cause fire, electric shock, or injury to persons.
•See Grounding Instructions.
•On the machine power switch, the “1” means that the machine power is switched “ON” and the “0” means the machine power is switched “OFF”.
CAUTION
•To avoid serious injury, do not touch the incline rack while the treadmill is in use.
•To avoid serious injury, do not touch the belt while the treadmill is in use.
Truefitness.com / 800.426.6570 / 636.272.7100 |
3 |
CHAPTER 1: SAFETY INSTRUCTIONS
SPACE REQUIREMENTS:
TRUE’s recommendation is to leave a minimum of 20” (0.5m) on each side of the treadmill and a 79” (2 m) safety zone at the rear of the treadmill. (See Fig 1)
Fig. 1
USE OF SAFETY KEY (E-STOP):
•Attach the safety clip to your clothing before each workout and when treadmill is in use. (See Fig. 2)
•Attach the magnetic key to the treadmill.
Fig. 2
1 |
Clothing |
2 |
Clip |
3 |
Console |
3 |
|
1 |
|
2 |
|
4 |
Truefitness.com / 800.426.6570 / 636.272.7100 |
CHAPTER 1: SAFETY INSTRUCTIONS
GROUNDING INSTRUCTIONS:
This product must be grounded, if it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment-ground- ing conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.
DANGER:
•Improper connection of the equipment-grounding conductor can result in a risk of electric shock.
•Check with a qualified electrician or serviceman if you are in doubt as to whether the product is properly grounded. Do not modify the plug provided with the product. If it will not fit the outlet, have a proper outlet installed by a qualified electrician.
•Do not remove the motor cover or you may risk injury due to electric shock.
•The 120-V model is for use on a nominal 120-V circuit and has a grounding plug that looks like the plug illustrated in figure A. Make sure the product is connected to an outlet having the same configuration as the plug. No adapter should be used with this product.
•The 230-V model is for use on a circuit having a nominal rating more than 120-V and is factory-equipped with
a specific electric cord and has a grounding plug that looks like the plug illustrated in figure B. Make sure that the product is connected to an outlet having the same configuration as the plug in Figure B. No adapter should be used with this product. If the product must be reconnected for use on a different type of electric circuit, the reconnection should be made by qualified service personnel.
Truefitness.com / 800.426.6570 / 636.272.7100 |
5 |
CHAPTER 1: SAFETY INSTRUCTIONS
6 |
Truefitness.com / 800.426.6570 / 636.272.7100 |
CHAPTER 1: SAFETY INSTRUCTIONS
WARNING DECALS:
WARNING:
Replace warning labels that may be worn, damaged or missing.
To replace any worn or missing warning decals contact TRUE FITNESS by visiting www.truefitness.com or contact customer service at 800-883-8783.
SAMPLE
COMPLIANCES:
This equipment complies with all applicable codes and regulations. For a complete list of compliances, please visit www.truefitness.com
Truefitness.com / 800.426.6570 / 636.272.7100 |
7 |
CHAPTER 2: ASSEMBLY GUIDE
IMPORTANT SAFETY INSTRUCTIONS
•Read and understand all instructions and warnings prior to use.
•Obtain a medical exam before beginning any exercise program. If at any time during exercise you feel faint, dizzy, or experience pain, stop and consult your physician.
•Obtain proper instruction prior to use.
•This treadmill is intended for in-home use only.
•Inspect the treadmill for incorrect, worn, or loose components and do not use until
corrected, replaced, or tightened prior to use.
•Do not wear loose or dangling clothing while using the treadmill.
•Care should be used when mounting or dismounting the treadmill.
•Read, understand, and test the emergency stop procedures before use.
•Disconnect all power before servicing the treadmill.
•Do not exceed maximum user weight of 350 lbs.
•Keep the top side of the moving surface clean and dry.
•Keep children and animals away.
•Use caution when moving and assembling treadmill.
•All exercise equipment is potentially hazardous. If attention is not paid to the conditions of equipment usage, death, or serious injury could occur.
•Save these instructions.
Basic Guidelines for Setting up the Treadmill:
After removing the treadmill from the packaging, place your treadmill on a clean, level surface. Make sure the electrical cord easily reaches a grounded three-pronged outlet and has enough slack to allow the deck to incline without tightening the cord. Do not allow the treadmill assembly to rest on the cord.
Important Electrical Requirements – 120V:
Your TRUE treadmill requires a dedicated 120 volt, alternating current (AC), 20 amp grounded outlet circuit. This means nothing else can be plugged into the same circuit. Most power circuits are rated for this 120V AC 20 amp requirement, but you must ensure the treadmill does not share the circuit with anything else.
DANGER:
Do not use an extension cord or ungrounded outlet:
The ground helps prevent electrical damage to your treadmill and enhances your safety by helping to prevent shock. Check with a qualified electrician or serviceman if you are in doubt as to whether the treadmill is properly grounded. Do not modify the plug provided with the treadmill if it will not fit the outlet. Have a proper outlet installed by a qualified electri-
cian.
8 |
Truefitness.com / 800.426.6570 / 636.272.7100 |
CHAPTER 2: ASSEMBLY GUIDE
PRE-ASSEMBLY CHECKLIST:
Item |
Description |
QTY: |
A |
Console Assembly |
1 |
B |
Base |
1 |
C |
Pedestal Upright (L) |
1 |
D |
Pedestal Upright (R) |
1 |
E |
Sport Bottle |
1 |
F |
Tablet Holder |
1 |
G |
Bolt Cover |
2 |
H |
Cable Cover |
1 |
-- |
Hardware Pack |
1 |
Truefitness.com / 800.426.6570 / 636.272.7100 |
9 |
CHAPTER 2: ASSEMBLY GUIDE
TREADMILL ASSEMBLY STEPS:
STEP 1 Remove Motor Cover:
a) Remove the 9 screws securing the motor cover to the treadmill frame.
b) Remove the motor cover and set to the side.
STEP 2 Install Pedestal Uprights:
a) Slide the left and right pedestal uprights into place.
*DO NOT PINCH CABLES
b) Install 4 bolts and washers into each pedestal, but do not fully tighten.
10 |
Truefitness.com / 800.426.6570 / 636.272.7100 |
CHAPTER 2: ASSEMBLY GUIDE
TREADMILL ASSEMBLY STEPS (CONTINUED):
STEP 3 Lower Data Cable:
a) Connect the data cable coming from the bottom of the left pedestal upright to the lower control board as shown.
STEP 4 Console Assembly:
a) Place the console assembly on the pedestal uprights and secure with 4 bolts. b)Attach the left and right bolt covers by snapping them into place.
Truefitness.com / 800.426.6570 / 636.272.7100 |
11 |
CHAPTER 2: ASSEMBLY GUIDE
TREADMILL ASSEMBLY STEPS (CONTINUED):
STEP 5 Data Cable & Cable Cover:
a) Connect the lower control wire coming out of left upright with the upper control wire attached in the console.
b) Install the wire cover with 2 bolts to the upper console cover.
STEP 6 Secure Pedestal Uprights:
a) Fully tighten the 8 bolts from Step 2. b) Tighten the hex head bolt on the front of each pedestal upright and then tighten the nut.
12 |
Truefitness.com / 800.426.6570 / 636.272.7100 |
CHAPTER 2: ASSEMBLY GUIDE
TREADMILL ASSEMBLY STEPS (CONTINUED):
STEP 7 Re-Install Motor Cover:
a) Re-install the motor cover as shown.
STEP 8 Tablet Holder:
a) Slide the tablet holder into the slots on the back of the console assembly.
b) Secure the tablet holder with two screws.
Truefitness.com / 800.426.6570 / 636.272.7100 |
13 |
CHAPTER 2: ASSEMBLY GUIDE
TREADMILL ASSEMBLY STEPS (CONTINUED):
STEP 9 Rear Foot Leveling:
a) Ensure treadmill incline rack wheels and rear feet are resting on the floor and not on cardboard, packaging, etc.
b) Using the pliers to loosen the wing-nut
(A) counter-clockwise.
c) Using a level or estimating by sight, turn section (B) of foot counter-clockwise to a proper height.
d) Tighten wing-nut (A) to secure (B) section.
NOTE: Same adjustment applies to both sides.
STEP 10 Safety Key:
a) Remove packaged Safety key from hardware kit.
b) Cut off the shorter piece of string as shown.
c) Attach Safety Key magnet to front of console as shown below.
d) Attach clip to clothing at the beginning of any workout.
NOTE: Read the entire Owner’s Manual before attempting any workout.
NOTE: Remove Safety Key from treadmill after each use.
14 |
Truefitness.com / 800.426.6570 / 636.272.7100 |
CHAPTER 3: PRODUCT OVERVIEW
TREADMILL OVERVIEW:
Console Assembly
Safety (E-Stop) Key
Contact Heart Rate Pads
Straddle Covers |
Belt |
Belt Adjustment Bolts
Leveling Feet |
Adjustable Soft Select |
On/Off Switch |
|
|
Circuit Breaker |
|
|
Power Cord |
Truefitness.com / 800.426.6570 / 636.272.7100 |
15 |
CHAPTER 3: PRODUCT OVERVIEW
TREADMILL OVERVIEW (CONTINUED):
Console Assembly:
The console allows the user to set up a workout program and control the treadmill during a workout *For console overview and operation instructions refer to chapter 4.
Contact Heart Rate Pads:
Allows the user to check their heart rate without wearing a wireless chest strap.
*For increased safety and accuracy this feature should only be used when the belt speed is below 4 mph.
Safety (E-Stop) Key:
A tethered safety device designed to attach to both the user and the treadmill console. Removal of the key from the console will stop belt motion to prevent injury in an emergency.
*The safety key must be in place on the treadmill, and should be attached to the user’s clothing. The treadmill will not operate if the safety key is not attached to the treadmill.
Belt:
The moving surface of the treadmill on which the user walks or runs.
Straddle Covers:
Stationary covers on either side of the belt, which allows the user to safely straddle the belt during startup or in the event of an emergency.
Belt Adjustment Bolts:
An adjustment system that allows the users to adjust the belt tracking and tension as needed.
On/Off Switch:
Allows users or faculty to turn the power on or off to the treadmill.
Circuit Breaker:
A safety device designed to protect the treadmill from excessive electrical current.
Power Cord:
Delivers power from the wall outlet to the treadmill.
Leveling Feet:
An adjustable system used to aid in the leveling the treadmill.
Adjustable Soft Select:
Allows users to “personalize” the walking surface from soft to firm or anywhere in between.
16 |
Truefitness.com / 800.426.6570 / 636.272.7100 |
Loading...
