Model #: |
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
Model: |
Glass Door Floral Case: |
GDM-12FC-HC-LD Swing Door Refrigerator with Hydrocarbon Refrigerant & LED Lighting |
|
|
|
|
|
GDM-12FC-HC-LD
The world’s #1 manufacturer of glass door merchandisers.
Factory engineered, self-contained, capillary tube system using environmentally friendly R290 hydro carbon refrigerant
that has zero (0) ozone depletion potential (ODP), & three (3) global warming potential (GWP).
Energy efficient, factory balanced, refrigeration system holds 35°F (1.6°C).
Exterior - non-peel or chip black laminated vinyl; durable and permanent.
Interior - attractive, NSF approved, black aluminum interior liner with stainless steel floor.
Self closing door. Positive seal, torsion type closure system.
“Low-E”, double pane thermal insulated glass door assembly with mitered plastic channel frame. The latest in energy efficient technology.
Adjustable, heavy duty black PVC coated shelves.
LED interior lighting provides more even lighting throughout the cabinet. Safety shielded.
Door decal
Entire cabinet structure is foamed-in- place using a high density, polyurethane insulation that has zero ozone depletion potential (ODP) and zero global warming potential (GWP).
Bottom mounted units feature
”No stoop” lower shelf to maximize product visibility.
Storage on top of cabinet.
Easily accessible condenser coil for cleaning.
ROUGH-IN DATA
Specifications subject to change without notice. Chart dimensions rounded up to the nearest 1/8" (millimeters rounded up to next whole number).
|
|
|
Cabinet Dimensions |
|
|
|
Cord |
Crated |
||
|
|
|
|
(inches) |
|
|
|
|
||
|
|
|
|
|
|
|
|
Length |
Weight |
|
|
|
|
|
(mm) |
|
|
|
|
||
|
|
|
|
|
|
|
NEMA |
(total ft.) |
(lbs.) |
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|||
Model |
Doors |
Shelves W |
D† |
H |
HP |
Voltage |
Amps Config. |
(total m) |
(kg) |
|
GDM-12FC-HC-LD |
1 |
2 |
247/8 |
231/8 |
623/8 |
1/6 |
115/60/1 |
2.0 |
5-15P |
9 |
233 |
|||||
|
|
|
|
|
|
|
632 |
588 |
1585 |
N/A |
|
N/A |
▲ |
2.74 |
106 |
|
† Depth does not include 13/8" (35 mm) for door handle and 1" (26 mm) for rear bumpers. |
|
|
|
▲ Plug type varies by country. |
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
APPROVALS: |
|
|
AVAILABLE AT: |
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
MADE IN |
|
|
|
|
|
|
|
|
|
|
||||
|
|
TRUE REFRIGERATION® |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
U.S.A. |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
SINCE 1945 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
7/16 |
|
|
|
Printed in U.S.A. |
|
|
|
|
|
|
|
|
|
|||
