24-Port Gigabit L2 Managed Switch
with 4 Combo SFP Slots
TL-SG3424
Overview
TP-LINK 24-Port Gigabit L2 Managed Switch with 4 Combo SFP Slots TL-SG3424 is
equipped with 24 gigabit RJ45 ports and 4 combo SFP slots. The switch provides high
performance, enterprise-level QoS, advanced security strategies and rich layer 2 management features. The JetStream
the ideal small and medium business solution.
TP-LINK L2 managed switch TL-SG3424 has robust security and management features. The
IP-MAC-Port-VID Binding and Access Control List (ACL) functions protect against broadcast
storm, ARP and Denial-of-Service(DoS) attacks, etc. Quality of Service (QoS, L2 to L4)
provides enhanced trac management capabilities to move your data smoother and
faster. Anymore, the easy-to-use web management interfaces, along with CLI, SNMP and
RMON, mean faster setup and conguration with less downtime. For workgroup and
departments requiring cost-sensitive Layer 2 Switch and gigabit capability, TP-LINK
JetStream L2 managed Switch TL-SG3424 provides you the ideal access-edge solution.
gigabit L2 managed switch TL-SG3424 is cost-eective for
www.tp-link.com
Copyright © 2014 TP-LINK Technologies Co., Ltd. All rights reserved.
Layer 2 Features
Link Aggregation Control Protocol
(LACP)
4K VLAN
GVRP (GARP VLAN Registration
Protocol)
STP/RSTP/MSTP
IGMP Snooping
Port Isolation
Datasheet
TP-LINK JetStream
24-Port Gigabit L2 Managed Switch
with 4 Combo SFP Slots
TL-SG3424
Quality of Service
4 priority queues
Support IEEE 802.1P
DSCP QoS
Security Strategies
IP-MAC-Port-VID Binding
Access Control List (L2~L4 ACL)
802.1x and RADIUS Authentication
Support DoS defend
Port Security
SSL and SSH encryptions
IPv6 Support
Dual IPv4/IPv6 Stack
MLD Snooping
PMTU Discovery
IPv6 Neighbor Discovery
Management
Web-based GUI
Command Line Interface
SNMP v1/v2c/v3
RMON (1,2,3,9 group)
Secure Networking
TP-LINK JetStream switch TL-SG3424 provides IP-MAC-Port-VID Binding, Port Security, Storm control and
DHCP Snooping protecting against broadcast storms, ARP attacks, etc. They integrate some typical DoS
attacks to select. You can protect these attacks more easily ever than before. In addition, the Access
Control Lists (ACL, L2 to L4) feature restricts access to sensitive network resources by denying packets
based on source and destination MAC address, IP address, TCP/UDP ports and even VLAN ID. Moreover,
the switches support 802.1X authentication, which is used in conjunction with a RADIUS server to
require some authentication information before access to the network is allowed. Guest VLAN function
supports to enable the non-802.1X clients to access the specic network resource.
Advanced QoS features
To integrate voice, data and video service on one network, the switches apply rich QoS policies. Adminis-
trator can designate the priority of the trac based on a variety of means including IP or MAC address,
TCP or UDP port number, etc, to ensure that voice and video are always clear, smooth and jitter free. In
conjunction with the Voice VLAN the switches supporting, the voice applications will operate with much
smoother performance.
Abundant Layer 2 features
For more application of layer 2 switch, TL-SG3424 supports a complete lineup of layer 2 features,
including 802.1Q tag VLAN, Port Mirroring, STP/RSTP/MSTP, Link Aggregation Control Protocol and
802.3x Flow Control function. Any more, the switches provide advanced features for network mainte-
nance. Such as Loop Back Detection, Cable Diagnostics and IGMP Snooping. IGMP snooping ensures the
switch intelligently forward the multicast stream only to the appropriate subscribers while IGMP
throttling & ltering restrict each subscriber on a port level to prevent unauthorized multicast access.
IPv6 Support
TL-SG3424 supports various IPv6 functions such as Dual IPv4/IPv6 Stack, MLD Snooping, Path Maximum
Transmission Unit (PMTU) Discovery and IPv6 Neighbor Discovery. TL-SG3424 is certied IPv6 Ready
Logo, which guarantees your network is ready for the Next Generation Network (NGN) without upgrad-
ing your network equipment.
24 / 7
Global technical support
Details:http://www.tp-link.com/
support/Localesupport.asp
German/Austrian/Swiss users are
not included
www.tp-link.com
Enterprise Level Management Features
TP-LINK JetStream L2 Managed switch TL-SG3424 is easy to use and manage. It supports various
user-friendly standard management features, such as intuitive web-based Graphical User Interface
(GUI)or industry-standard Command Line Interface(CLI), either administration trac can be protected
through SSL or SSH encryptions. SNMP (v1/2/3) and RMON support enables the switch to be polled for
valuable status information and send traps on abnormal events. In addition, integrated NDP/NTDP
protocol, the switches support to be managed by the commander switch through IP clustering function
more easily.
Copyright © 2014 TP-LINK Technologies Co., Ltd. All rights reserved.
Specifications
Physical features & Performance
Product Picture
Datasheet
Model
Physical Features
10/100/1000Mbps
RJ45 Ports
Connector
Power Supply
FAN Quantity
Certication
Dimensions(W × D × H)
Environment
Performance
Switch Capacity
Forwarding Rate
MAC Address Table
Packet Buer Memory
Jumbo Frame
Combo Gigabit
SFP slots*
Console Port
TL-SG3424
24
4
1
100-240VAC, 50/60Hz
0
CE, FCC
17.3 × 8.7 × 1.7 in. (440 × 220 × 44 mm)
19-inch Rack mount Steel Case, 1U Height
Operating Temperature: 0°C~40°C (32°F~104°F), Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing, Storage Humidity: 5%~90% non-condensing
48Gbps
35.7Mpps
8k
512KB
10240 Bytes
Software Features
L2 Switching Features
Link Aggregation
– Support static link aggregation
– Support 802.3ad LACP
– Up to 8 aggregation groups, containing 8 ports per
group
Spanning Tree Protocol(STP)
– IEEE 802.1D Spanning Tree Protocol
– IEEE 802.1s Multiple Spanning Tree Protocol
– IEEE 802.1w Rapid Spanning Tree Protocol
– STP Security: Loop back detection, TC Protect, BPDU
Filter/Protect, Root Protect
www.tp-link.com
Multicast
– Support IGMP Snooping V1/V2/V3, up to 256 groups
– Support multicast VLANs, IGMP Immediate Leave,
Unknown IGMP Throttling, IGMP Filtering, Static
Multicast IP
VLAN
– Support IEEE802.1Q with 4K VLANs simultaneously
(out of 4K VIDs)
– Support Port VLAN, Protocol VLAN and MAC-based
VLAN
– Support GARP/GVRP feature
IEEE 802.3x ow control for Full Duplex mode and
backpressure for Half Duplex mode
Copyright © 2014 TP-LINK Technologies Co., Ltd. All rights reserved.
Datasheet
Quality of Service (QoS)
Support 802.1p CoS/DSCP priority
Support 4 priority queues
Queue scheduling: SP, WRR, SP+WRR
Port/Flow- based Rate Limiting
Voice VLAN assure voice applications much
smoother performance
Advanced Security Strategies
IP-MAC-Port-VID Binding
Static/Dynamic Port Security (MAC-based)
DoS defend feature
Dynamic ARP Inspection
802.1x authentication
– Support 802.1x port/MAC based authentication
– Support Radius authentication and accountability
– Guest VLAN
Access Control List (ACL)
– L2~L4 package ltering based on source and
destination MAC address, IP address, TCP/UDP
ports, 802.1p, DSCP, protocol and VLAN ID
– Time based ACL
Support Broadcast, Multicast and Unknown
unicast Storm Control
Secure web management through HTTPS and
SSLv2/v3/TLSv1
Secure remote command line interface(CLI)
management with SSH v1/V2
IPv6 applications
– DHCPv6 Client
– Ping6
– Tracert6
– Telnet(v6)
– IPv6 SNMP
– IPv6 SSH
– IPv6 SSL
– Http/Https
– IPv6 TFTP
Management
Support Web-based GUI management mode
Support Command Line Interface(CLI) through
console port, telnet management mode
SNMP v1/v2c/v3
RMON (1, 2, 3, 9 groups)
DHCP/BOOTP Client
DHCP Snooping
DHCP Option 82
CPU Monitoring
Port Mirroring (Many to One)
Cable Diagnostics feature
Ping/Tracert feature
SNTP
Integrated NDP/NTDP feature
System Log
Ethernet Protocols
IPv6 Support
IPv6 Dual IPv4/IPv6 stack
Multicast Listener Discovery (MLD) Snooping
IPv6 neighbor discovery (ND)
Path maximum transmission unit (MTU) discovery
Internet Control Message Protocol (ICMP) version 6
TCPv6/UDPv6
www.tp-link.com
IEEE 802.3i 10BASE-T
IEEE 802.3u 100BASE-TX/FX
IEEE 802.3ab 1000BASE-T
IEEE 802.3z 1000BASE-X
IEEE 802.3av GVRP
IEEE 802.3ad Link Aggregation
IEEE 802.3x Flow control
IEEE 802.1p QoS
Copyright © 2014 TP-LINK Technologies Co., Ltd. All rights reserved.
Datasheet
IEEE 802.1q VLANs / VLAN tagging
IEEE 802.1v Protocol VLAN
IEEE 802.1d Spanning Tree Protocol (STP)
IEEE 802.1w Rapid Spanning Tree (RSTP)
IEEE 802.1s Multiple Spanning Tree (MSTP)
IEEE 802.1x Network Login Security
MIBs
MIB II (RFC1213)
Interface MIB (RFC2233)
Ordering information
Host switch
Product Model
TL-SG3424
SFP Modules
Product Model
TL-SM311LS
TL-SM311LM
TL-SM321A
TL-SM321B
Media Converter
Product Model
MC210CS
MC200CM
MC220L
MC1400
Description
JetStream 24-Port Gigabit L2 Managed Switch with 4 Combo SFP Slots
Description
Gigabit SFP module, Single-mode, LC interface, Up to 10km distance
Gigabit SFP module, Multi-mode, LC interface, Up to 550m distance
Gigabit WDM Bi-Directional SFP Module, single-mode, LC connector, TX:1550nm/RX:1310nm, 10km
Gigabit WDM Bi-Directional SFP Module, single-mode, LC connector, TX:1310nm/RX:1550nm, 10km
Description
Gigabit single-mode SC SFP Transceiver, up to 15Km, chassis mountable
Gigabit multi-mode SC SFP Transceiver, up to 550m, chassis mountable
Gigabit SFP slot supporting mini-GBIC modules, chassis mountable
14-slot power supply chassis for TP-LINK Media Converter, 19-inch rack-mountable
Ethernet Interface MIB (RFC1643)
Bridge MIB (RFC1493)
P/Q-Bridge MIB (RFC2674)
RMON MIB (RFC2819)
RMON2 MIB (RFC2021)
Radius Accounting Client MIB (RFC2620)
Radius Authentication Client MIB (RFC2618)
Remote Ping, Traceroute MIB (RFC2925)
Support TP-LINK private MIBs
* TL-SG3424 support 100/1000Mbps SFP module at full-duplex mode. When using the SFP port with a 100M module or a gigabit
module, you need to congure its corresponding Speed and Duplex mode through rmware.
By factory default, the Speed and Duplex mode of SFP port is 1000Mbps Full-duplex.
