Contents
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
80 |
Important instructions . . . . . . . . . . . . . . . . . . . . . . . . |
81 |
General description . . . . . . . . . . . . . . . . . . . . . . . . . |
82 |
The control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . |
83 |
Setting the clock / Microwave power settings . . . . . . . . . . . |
84 |
The display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
85 |
The selector knobs / Programming . . . . . . . . . . . . . . . |
86 |
Microwave programming . . . . . . . . . . . . . . . . . . . . . . |
87 |
The grilling rack / The grill function . . . . . . . . . . . . . . |
88 |
Programming the grill / the microwave + grill function . . . . |
89 |
The pizza function . . . . . . . . . . . . . . . . . . . . . . . . . . |
90 |
The pizza dish . . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
92 |
Linked programmes . . . . . . . . . . . . . . . . . . . . . . . . . . |
93 |
Recommendations . . . . . . . . . . . . . . . . . . . . . . . . . . . |
94 |
Care & cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . |
95 |
Troubleshooting guide . . . . . . . . . . . . . . . . . . . . . . . |
96 |
After Sales Service . . . . . . . . . . . . . . . . . . . . . . . . . . |
97 |
Please read this user manual carefully. It contains important instructions concerning installation, use and security measures.
79
Installation
BEFORE CONNECTION
•Check whether your oven has suffered any damage during transport (deformed door or door seal, etc.). If you see any signs of damage, contact your dealer before use.
•Verify the power voltage. If there is a PERMANENT undervoltage (200-210 volts), consult your electrical installer.
LOCATION
• The oven must be set on a work surface at least 85 cm above floor level.
•Place the oven on a flat and horizontal surface, away from any source of heat or steam. To ensure the stability of the microwave oven, the front left foot is adjustable (5 positions). Turn it to raise or lower the appliance.
•Make sure that air may circulate freely around the oven.
Leave sufficient space around the oven : |
|
|
|
|
- 5 cm between the sides of the oven |
|
|
14 cm |
|
|
|
|
||
|
|
|
|
|
and any walls or objects |
|
|
|
|
- 14 cm above the oven |
|
|
|
|
- 10 cm behind the oven. |
|
|
|
|
|
|
|
|
|
• Allow nothing to obstruct the ventilation |
5 cm |
|
||
|
|
|
|
|
louvers at the back of the appliance. |
|
|
|
|
|
|
|
|
|
• Make sure the electrical plug will be accessible after installation.
10 |
cm |
|
5 cm
ELECTRICAL CONNECTION
•Your installation must be protected by a 16 Amp thermal fuse.
•It is mandatory to use a power point withgrounda terminal, connected in accordance with current safety regulations.
•In your electrical installation, provide a device that is accessible to the installer, capable of separating the appliance from the mains power and whose contact opening is at least 3 mm at all of the poles.
•Never operate the oven if the supply cord and/ or its plug are damaged. In case of damage, call in a specialised technician trained by the manufacturer.
80
Important instructions
•Your appliance is designed exclusively for the domestic purposes of defrosting, heating or cooking foods. The manufacturer bears no responsibility in the case of improper usage.
•Only use ustensils that are suitable for use in microwave ovens.
•To avoid deterioration of your microwave oven, never operate it empty or without the turntable.
•Never tamper with the lock mechanism of your microwave oven; you could cause damage requiring repair by an authorised technician.
•When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition.
•It is not advisable to use metal recipients, forks, spoons, knives, metal ties or staples for deepfreeze bags.
•The contents of feeding bottles are baby food jars shall be stirred or shaken and the temperature checked before consumption in order to avoid burns.
•WARNING : Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use.
•WARNING : Liquids and other foods must not be heated in sealed containers they are liable to explode.
•Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode, even after microwave heating has ended.
•Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container.
•For small amounts (one sausage, a single croissant, etc.), place a glass of water alongside the food item.
•Time settings that are too long may dry out and burn the food. To avoid such incidents, never use the same cooking times as those recommended for traditional ovens.
•If smoke is observed, switch off or unplug the appliance and keep the door closed in order to stifle any flames.
•In order to evacuate moisture, your appliance is fitted with a delayed ventilation function. Depending on the applied cooking mode (solo / grill / combination), the oven ventilation will continue to operate after the cooking end.
81
General description
Identification |
Drive shaft |
Wheel |
Turntable |
label |
|
support |
|
• THE TURNTABLE :
ensures equal cooking of food throughout with no need to stir or turn the dish.
-It may be used as a cooking platter.
-Rotation is controlled by the drive shaft and the wheel support.
-The turntable revolves in both directions.
-If it does not turn, verify that all components are properly positioned.
-For easy removal, wells are provided on either side.
•TURNTABLE OFF
:
stops the turntable from revolving in order to use platters which require the entire oven space.
•THE WHEEL SUPPORT :
Do not try to rotate the roller ring manually, as you could damage the drive system. If it does not turn smoothly, make sure that there is nothing in the well beneath the turntable.
82
Control panel
A |
Display window: |
|
|
|
|
|
|
|
to simplify programming, the display indi- |
|
|
|
|||
|
cates : the time of day, the types of food |
|
|
|
|||
|
and functions, the minutes / seconds, or |
|
|
|
|||
|
weight programmed. |
|
|
|
|
||
B |
The selector knob |
|
: |
|
1 2 : 3 0 |
|
|
|
to choose the food type or function. |
|
|
||||
|
|
|
|
|
|
A |
|
C |
The selector knob |
: |
|
|
|
|
|
|
to choose the programme time or weight. |
|
|
|
|||
D-E-F The “AUTO” keys |
: |
|
|
|
|||
|
automatically set the appropriate pro- |
|
|
|
|||
|
gramme time |
according |
to the weight |
|
B |
|
|
|
and the selected food type. |
|
|
|
|||
G |
The MODE key |
: |
|
|
|
|
|
|
to choose the appropriate function. |
|
|
|
|||
H |
The GRILL/PIZZA key |
: |
|
C |
|
||
|
to directly programme the grill / microwave |
|
|
||||
|
|
|
|
||||
|
+ grill / pizza function. |
|
|
|
|
||
K |
The KEEP WARM key |
: |
|
|
|
||
|
to keep your dish warm. |
|
D |
E |
F |
||
J |
The PAUSE/CANCEL key |
: |
|
|
|
||
|
to interrupt (press once) or cancel a pro- |
G |
H |
I |
|||
|
gramme (press twice). |
|
|||||
|
|
|
|
|
|||
|
Also used to set the clock. |
|
|
|
|
||
K |
STOP-TURNTABLE key |
: |
J |
K |
L |
||
|
|
|
|||||
|
to stop the turntable from revolving. |
|
|
|
|||
L |
START key |
: |
|
|
|
M |
|
|
to start all programmes. |
|
|
|
|||
|
|
|
|
|
|||
M |
DOOR OPEN button: |
|
|
|
|
||
|
press this button to open the door or stop |
|
|
|
|||
|
the appliance. |
|
|
|
|
|
|
|
|
|
|
83 |
|
|
|
