IAN 115164
OIL-FILLED RADIATOR SOR 1500 A1
OIL-FILLED RADIATOR
Operating instructions
ÖLRADIATOR
Bedienungsanleitung
GB / IE Operating instructions Page 1
DE / AT / CH Bedienungsanleitung Seite 9
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
B
A
Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Proper use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Appliance description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Technical details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Initial operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Frost protection function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
GB
IE
Disposal of the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Importer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
SOR 1500 A1
1
GB
IE
OIL-FILLED RADIATOR
Introduction
Congratulations on the purchase of your new
appliance.
You have selected a high-quality product. The operating instructions are a constituent of this product.
They contain important information about safety, use
and disposal. Before using the product, familiarise
yourself with all operating and safety instructions.
Use this product only as described and only for the
specifi ed areas of application. Please also pass these
operating instructions on to any future owner(s).
Proper use
Appliance description
Figure A:
1 “Power” control lamp
2 Thermostat
3 Heat level switch
4 Ventilation slots
5 Power cable retainer
Figure B:
6 Mounting clip
7 Roller rail
8 Wing nut
This appliance in intended exclusively for heating in
domestic households. It is not suitable for commercial
or industrial applications.
Package contents
Oil-Filled Radiator
2 roller rails
1 mounting bracket
4 wing nuts
Operating instructions
Technical details
Rated voltage: 220 - 240 V ~, 50 Hz
Heat output: 1500 W
Heat levels: 1 = 600 W
2 = 900 W
3 = 1500 W
Thermostat: Infi nitely variable
Heating fi ns: 7
Suitable for
rooms of up to: approx. 30 - 40 m
NOTE
The appliance is fi tted with a tilt protection
►
switch! This means that the unit shuts down automatically if it falls over or is lying on its side.
3
2
SOR 1500 A1
Safety instructions
DANGER - RISK OF ELECTRICAL SHOCK!
► Connect the oil radiator only to correctly installed and earthed
mains sockets. Ensure that the voltage supplied through the mains
socket tallies completely with the details given on the appliance
rating plate.
► Do not kink or crush the power cable.
► To disconnect, always remove the plug itself from the mains
power socket, do not pull on the power cable.
► Never touch the oil radiator, the power cable or the plug with
wet hands.
► Do not use extension cables.
► Under no circumstances should the appliance be submersed in
GB
IE
liquids or liquids be allowed to penetrate the housing. Do not
expose the appliance to moisture and do not use it outdoors.
There is the risk of electrocution. If liquid gets into the housing,
disconnect the appliance from the mains power socket immediately
and have it repaired by a qualifi ed technician.
► Under no circumstances should the oil radiator be used in the
vicinity of water, for example in a bath, shower, washbasin or in
humid cellar rooms. The proximity of water is hazardous, even
if the appliance is switched off .
► In the event of malfunctions and before you clean the appliance,
remove the plug from the mains power socket.
► To avoid risks, have defective plugs and/or power cables
replaced immediately by qualifi ed technicians or our Customer
Service Department.
SOR 1500 A1
3
