HAND-HELD VACUUM CLEANER SAS 7.4 LI C2
HAND-HELD VACUUM CLEANER
Operating instructions
HANDSTAUBSAUGER
Bedienungsanleitung
IAN 311850
ΕΠΑΝΑΦΟΡΤΙΖΟΜΕΝΟ
ΣΚΟΥΠΑΚΙ ΧΕΙΡΟΣ
Οδηүίες χρήσης
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of
the device.
Πριν ξεκινήσετε την ανάγνωση, ανοίξτε τη σελίδα με τις εικόνες και εξοικειωθείτε με όλες τις λειτουργίες
της συσκευής.
Klappen Sie vor dem Lesen die Seite mit den Abbildungen aus und machen Sie sich anschließend mit allen
Funktionen des Gerätes vertraut.
GB / IE / NI / CY Operating instructions Page 1
GR / CY Οδηүίες χρήσης Σελίδα 15
DE / AT / CH Bedienungsanleitung Seite 29
q
1
2
0
9
8
7
6
3
4
5
Contents
Introduction ...................................................2
Intended use ..................................................2
Package contents ..............................................2
Description of the appliance .....................................3
Technical data .................................................3
Important safety instructions .....................................4
Prior to first use ................................................6
Information about the batteries ..................................7
Installation of the wall bracket ...................................7
Charging .....................................................8
Operation ....................................................9
Cleaning .....................................................11
Disposal .....................................................12
Kompernass Handels GmbH warranty ............................13
Service ................................................................ 14
Importer ............................................................... 14
SAS 7.4 LI C2
GB│IE│NI│CY
│
1 ■
Introduction
Congratulations on the purchase of your new appliance.
You have selected a high-quality product. The operating instructions are part of this
product. They contain important information on safety, usage and disposal. Before
using the product, familiarise yourself with all operating and safety instructions. Use
the product only as described and for the specified areas of application. Please also
pass on these operating instructions to any future owner.
Intended use
This handheld vacuum cleaner may only be used to vacuum dry or wet surfaces,
or dry or wet materials and liquids. Do not vacuum people or animals with this
appliance. Any other usage of or modification to the appliance is deemed to be
improper and carries a significant risk of accidents. The manufacturer accepts no
liability for damages that result from improper use of the appliance or are caused
by the incorrect operation of it. The appliance is not intended for commercial use.
Package contents
▯ Hand-Held Vacuum Cleaner
▯ Crevice tool
▯ Wet suction nozzle
▯ Wall bracket
▯ Mounting kit
▯ Mains adapter
▯ Operating instructions
■ 2 │ GB
Check the package contents for completeness directly after unpacking.
│IE│NI│
CY
SAS 7.4 LI C2
Description of the appliance
1 Wet suction nozzle
2 Crevice nozzle
3 Wall bracket
4 Mains adapter
5 Barrel plug
6 On/off switch
7 Charge indicator lamp (red/green)
8 Release button
9 Dust filter bag
0 Dust filter
q Dirt container
NOTE
► This appliance is supplied with non-charged batteries. The batteries must be
charged before first use.
Technical data
Mains adapter 4
Input voltage/current 100 - 240 V ~ (AC), 50/60 Hz, 0,2 A
Output voltage/current 9.6 V
Polarity of the barrel plug
Protection class
Type designation ZDM096050BS-C
Protection type
Appliance
Input voltage/current 9,6 V
Collection volume
Rechargeable batteries
Capacity 2000 mAh
Rechargeable battery 7.4 V (2 x 3.7 V Lithium-ion rechargeable batteries)
Battery charging time (with
completely discharged battery)
Running time with full charge Approx. 22 minutes
terminal outside)
II /
IP20 - Protected against solid foreign bodies
with a diameter of ≥ 12.5 mm / No protection
against water
Dust: max. 400 ml
Liquids: max. 150 ml
Approx. 5 hours
(direct current) / 500 mA
(positive terminal inside, negative
(double insulation)
(direct current) / 500 mA
SAS 7.4 LI C2
GB│IE│NI│CY
│
3 ■
Important safety instructions
DANGER – ELECTRIC SHOCK!
Do not charge or use the appliance outdoors.
► Never use the handheld vacuum cleaner if the cable, plug
or casing are damaged.
► To avoid risks, arrange to have damaged power cables
and/or plugs replaced as soon as possible by a qualified
specialist.
► Have all repairs carried out by a specialist workshop. Under
no circumstances should you open the appliance yourself.
Repairs that are not carried out by a specialist workshop
could lead to physical injuries.
► Before switching on the appliance, make sure that the mains
voltage corresponds to the voltage indicated in the technical
data for the appliance.
► Never touch the mains adapter or the appliance with wet or
damp hands.
► Do not use the mains adapter with an extension cable; con-
nect the mains adapter directly to a power socket.
WARNING! RISK OF INJURY!
► Do not change any accessories while the appliance is
switched on.
► Do not use the handheld vacuum cleaner for vacuuming up
sharp objects or glass shards.
► Never vacuum up burning matches, glowing ashes or ciga-
rette butts.
■ 4 │ GB
│IE│NI│
CY
SAS 7.4 LI C2
WARNING! RISK OF INJURY!
► Do not use the handheld vacuum cleaner for vacuuming up
chemical products, stone dust, gypsum, cement or similar
particles.
► This appliance is not suitable for use with inflammable and
explosive substances or chemical and aggressive liquids.
► Always store the appliance indoors. To prevent accidents,
keep the appliance in a dry location when not in use.
► Under extreme conditions, leaks in the battery cells may oc-
cur. In the event that battery fluid comes into contact with skin
or eyes, the affected area must be rinsed off with water immediately. Contact a physician.
► This appliance may be used by children aged 8 years and
above and by persons with limited physical, sensory or mental
capabilities or lack of experience and knowledge, provided
that they are under supervision or have been told how to use
the appliance safely and are aware of the potential risks.
► Children must not use the appliance as a plaything.
► Cleaning and user maintenance tasks may not be carried
out by children unless they are supervised.
► Take special care when using the handheld vacuum cleaner
on stairs.
CAUTION! PROPERTY DAMAGE!
► Use only accessories recommended by the manufacturer.
► The mains adapter may not be used for other purposes.
Never carry the wall bracket or the mains adapter by the
cable. Do not pull on the cable when you want to move the
appliance.
► Always grip the power plug to disconnect the appliance
from the power supply.
SAS 7.4 LI C2
GB│IE│NI│CY
│
5 ■
CAUTION! PROPERTY DAMAGE!
► Always be sure to keep the handheld vacuum cleaner away
from heating elements, ovens or other heated appliances
and surfaces.
► Make sure that the ventilation slits are never obstructed.
A blocked ventilation circuit can result in overheating and
damage to the appliance.
► This product contains rechargeable batteries. Do not throw
the batteries into a fire and do not subject them to high temperatures. There is a risk of explosion!
► Do not use the handheld vacuum cleaner without the dust
filter inserted.
► Do not use the mains adapter for a different product and do
not attempt to charge this appliance with a different mains
adapter. Use only the mains adapter supplied with this appliance.
► Never attempt to recharge non-rechargeable batteries.
► The batteries in this appliance cannot be replaced.
Prior to first use
■ Remove all packaging materials from the appliance.
■ Press the dust filter bag 9 and the dust filter 0 a little way into the dirt
container q. They might have loosened during transport and thus not be
positioned correctly inside the dirt container q.
■ Place the dirt container q on the motor unit:
– Push the plastic tab on the underside of the handheld vacuum cleaner
into the recess on the dirt container q.
– Press the release button 8 and push the dirt container q onto the motor
unit at the same time.
– Let go of the release button 8 so that the restraint engages in the recess.
The dirt container q is now firmly seated on the motor unit.
■ 6 │ GB
│IE│NI│
CY
SAS 7.4 LI C2
Information about the batteries
■ This handheld vacuum cleaner is powered by rechargeable lithium-ion batteries.
Before using the handheld vacuum cleaner for the first time, the batteries must
be charged. The charge indicator lamp 7 lights up red during charging. As
soon as the batteries are fully charged, the charge indicator lamp 7 lights
up green.
■ For care of the batteries, we recommend the following: once the batteries
have been charged, disconnect the mains adapter 4 from the mains socket.
Do not plug the mains adapter 4 back into the mains socket until the charge
indicator lamp 7 flashes green.
■ If the handheld vacuum cleaner is deep-discharged, the charge indicator
lamp 7 flashes alternately red and green (approx. 1 minute). In this case,
switch off the appliance and start charging.
Installation of the wall bracket
DANGER – ELECTRIC SHOCK!
► Ensure that there are no power cables or other conduits or pipes in the wall
at the location where you intend to bore the holes for the wall bracket 3.
Drilling into a current-carrying electric cable can be potentially fatal!
1) Place the barrel plug 5 of the mains adapter 4 into the wall bracket 3 as
shown in the following diagram:
– Open up the small cover.
– First, feed the cable through the cable routing and then push the barrel
plug 5 into the opening in the wall bracket 3 so that it is firmly in place.
– Then close the small cover again.
SAS 7.4 LI C2
GB│IE│NI│CY
│
7 ■
2) Select a suitable installation location for the wall bracket 3:
3) Drill two holes about 34 mm apart. Use the wall bracket 3 to mark the holes,
4) Push the wall plugs into the holes and then screw the wall bracket 3 firmly
5) You can place the nozzles on the accessories holder on the side.
6) Connect the mains adapter 4 to a mains power socket.
Charging
NOTE
■ Place the handheld vacuum cleaner from above into the wall bracket 3 so
■ When charging is complete, which can take around 5 hours with fully dis-
■ Do not recharge the batteries again until the handheld vacuum cleaner's
It must be possible to remove the handheld vacuum cleaner easily and there
must be an accessible mains power socket for the mains adapter 4.
to ensure the correct spacing. The drill holes must be suitable for 6 mm wall
plugs.
into place using the screws.
► Ensure that the on/off switch 6 has been pushed back (and thus the appli-
ance is switched off) before starting the charging process.
that the barrel plug 5 slips into the socket on the handheld vacuum cleaner.
The charge indicator lamp 7 lights up red and the charging process begins.
charged batteries, the appliance automatically switches to a trickle charge
(maintenance function). The charge indicator lamp 7 lights up green.
Nevertheless, in order to avoid possible damage to the batteries, do not
leave the appliance permanently connected to the mains adapter 4.
suction power becomes appreciably weaker and the charge indicator lamp 7
flashes green.
■ 8 │ GB
NOTE
► If the handheld vacuum cleaner is deep-discharged, the charge indicator
lamp 7 flashes alternately red and green (approx. 1 minute). In this case,
switch off the appliance and start charging.
► The handheld vacuum cleaner can also be charged directly via the mains
adapter 4. To do this, remove the barrel plug 5 with a slight twist from
the wall bracket 3 and insert it into the socket on the handheld vacuum
cleaner.
│IE│NI│
CY
SAS 7.4 LI C2
Operation
CAUTION!
► The suction opening must always be open and may not be blocked. Block-
ages lead to overheating and damage to the motor.
NOTICES
► Make certain that the dust filter 0 is always inserted before using the
appliance.
► When vacuuming liquid, do not exceed the MAX marking in dirt container q.
1) Remove the handheld vacuum cleaner from the wall bracket 3 or, if you are
not using the wall bracket 3 remove the barrel plug 5 from the socket.
2) If required, place the appropriate nozzle in the suction opening.
The crevice tool 2 and the wet suction nozzle 1 are kept in the space-saving
accessory storage in the handle.
NOTE
► After you have vacuumed up liquids, immediately clean the dirt container q.
Otherwise, bacteria or mould will build up inside! Ensure that the dust filter
bag 9 is completely dry before using the appliance again.
3) To switch the appliance on, slide the on/off switch 6 forwards. The charge
indicator lamp 7 lights up green.
4) When you have finished using the appliance, slide the on/off switch 6 to
the rear.
– the crevice nozzle 2, to clean narrow and difficult to reach locations.
– the wet suction nozzle 1 to vacuum up liquids.
SAS 7.4 LI C2
GB│IE│NI│CY
│
9 ■
NOTE
► If you have vacuumed liquids, always carry the appliance with the wet
suction nozzle 1 pointing downwards:
► If you carry the appliance horizontally or with the wet suction nozzle 1
pointing upwards, it is possible that liquid can leak out:
■ 10 │ GB
NOTE
► Place the handheld vacuum cleaner in the wall bracket 3 and start the
charging process once the vacuum power has become noticeably weaker
and the charge indicator lamp 7 flashes green.
│IE│NI│
CY
SAS 7.4 LI C2
Cleaning
To achieve the best results, empty the dirt container q and clean the dust filter 0
after every use.
CAUTION! MATERIAL DAMAGE!
1) To open the dirt container q, press the release button 8 and remove the
2) Remove the dust filter 0 from the dirt container q.
3) Empty the dirt container q.
4) Pull the dust filter bag 9 with its holder out of the dust filter 0.
5) Rinse the dust filter bag 9 out in cold water and wait until it is completely
6) Reinsert the dust filter 0 into the dirt container q. When doing so, ensure
7) Replace the dirt container q on the motor unit again:
8) Clean the housing and both nozzles with a lightly moistened cloth. For stubborn
9) Dry all parts thoroughly before using the appliance again or storing it.
► Do not use aggressive, chemical or abrasive cleaning agents. These could
damage the outer surfaces of the appliance.
dirt container q.
dry before reinserting it into the dust filter 0. Do not dry it with hot air.
that the dust filter 0 is seated squarely and that the rubber lip seals the dirt
container q.
– Push the plastic tab on the underside of the handheld vacuum cleaner
into the recess on the dirt container q.
– Press the release button 8 and push the dirt container q onto the motor
unit at the same time.
– Let go of the release button 8 so that the restraint engages in the recess.
The dirt container q is now firmly seated on the motor unit.
soiling use a mild detergent on the cloth.
SAS 7.4 LI C2
GB│IE│NI│CY
│
11 ■
Loading...
