CONFIDENTIAL
XE-A207W/A207B/A217W/A217B/A307
European version
PC-LINK Specifications
(Subject to change for improvement)
SHARP CORPORATION
BUSINESS SOLUTIONS PROMOTION GROUP
SYSTEM EQUIPMENT DIVISON
XE-A207/A217/A307 PCLINK
SHARP Confidential
1
1 OUTLINE .................................................................................................................................................. 2
2 SYSTEM REQUIREMENTS ..................................................................................................................... 2
2.1 OPERATING SYSTEM ............................................................................................................................. 2
2.2 RUNTIME ENVIRONMENT ....................................................................................................................... 2
3 SYSTEM CONFIGURATION .................................................................................................................... 2
4 FUNCTIONS ............................................................................................................................................. 3
4.1 SETTING AND COMMUNICATION FUNCTION .............................................................................................. 3
4.2 PLURAL DATA SET MANAGEMENT. ........................................................................................................... 4
4.3 MULTI- LANGUAGE SUPPORT ................................................................................................................. 4
4.4 CHARACTER EXCHANGE SUPPORT. ......................................................................................................... 4
5 INSTALLATION ........................................................................................................................................ 4
6 EACH FUNCTIONS .................................................................................................................................. 5
6.1 START UP ............................................................................................................................................. 5
6.2 TERMINATION........................................................................................................................................ 5
6.3 TITLE BAR ............................................................................................................................................. 6
6.4 MENU BAR ............................................................................................................................................ 6
6.5 FILE ..................................................................................................................................................... 7
6.6 EXEC ................................................................................................................................................... 9
6.7 RECORD ..............................................................................................................................................11
6.8 ABOUT ................................................................................................................................................11
6.9 DEPARTMENT PROGRAMMING .............................................................................................................. 12
6.10 PLU PROGRAMMING ........................................................................................................................ 15
6.11 PLU/EAN PROGRAMMING ................................................................................................................ 18
6.12 LOGO PROGRAMMING (THERMAL LOGO) .......................................................................................... 21
6.13 LOGO TEXT PROGRAMMING ............................................................................................................. 23
6.14 VAT ID PROGRAMMING .................................................................................................................... 24
6.15 ALL RAM BACKUP/RESTORE ........................................................................................................... 25
6.16 VAT/TAX RATE PROGRAMMING......................................................................................................... 27
7 INTERNAL DATA HANDLING ............................................................................................................... 28
8 DISPLAY ................................................................................................................................................. 31
8.1 DATA TRANSMISSION ........................................................................................................................... 31
8.2 STATUS INDICATION ............................................................................................................................. 31
9 AVAILABLE CHARACTERS .................................................................................................................. 33
10 MESSAGES ............................................................................................................................................ 34
11 RESTRICTIONS ..................................................................................................................................... 44
XE-A207/A217/A307 PCLINK
SHARP Confidential
2
PC
ECR
RS-232
SD CARD
1 Outline
This software edit and keep the various preset data for ECR (XE-A207, XE-A217, XE-A307). <2 The data are exchanged to ECR via RS232 or SD Card. <2
* XE-A207 means XE-A207W and XE-A207B. <2 * XE-A217 means XE-A217W and XE-A217B. <2
2 System Requirements
2.1 Operating System
Windows XP Professional SP3 (32-bit edition) Windows Vista Ultimate SP2 (32-bit edition / 64-bit edition) <1 Windows 7 Ultimate (32-bit edition / 64-bit edition)
2.2 Runtime Environment
.NET Framework 3.5 or upper version is necessary.
3 System Configuration
This software is working under following system configuration.
In case of RS-232, it can read and write ECR data directly by cable connection between ECR and PC In case of SD Card, the data which can be read and write on ECR/POS are stored on SD Card. The data is exchanged by the SD Card function of ECR/POS.
The software provide above communication function and data read/write function.
XE-A207/A217/A307 PCLINK
SHARP Confidential
3
2 0 7
2 1 7
3 0 7
DATA
FUNCTION
DIRECTION
MEDIA
FILE NAME
DEPT
DATA ENTRY
(Department)
UPLOAD
ECR -> PC
RS-232
DOWNLOAD
PC -> ECR
RS-232
IMPORT
SD -> PC
SD CARD
DEPTDT
EXPORT
PC -> SD
SD CARD
DEPTDT
x PLU
DATA ENTRY
UPLOAD
ECR -> PC
RS-232
DOWNLOAD
PC -> ECR
RS-232
IMPORT
SD -> PC
SD CARD
PLUDT
EXPORT
PC -> SD
SD CARD
PLUDT
x x
PLU/EAN
DATA ENTRY
UPLOAD
ECR -> PC
RS-232
DOWNLOAD
PC -> ECR
RS-232
IMPORT
SD -> PC
SD CARD
PLUDT
EXPORT
PC -> SD
SD CARD
PLUDT
LOGO TEXT
DATA ENTRY
UPLOAD
ECR -> PC
RS-232
DOWNLOAD
PC -> ECR
RS-232
IMPORT
SD CARD->PC
SD CARD
LOGODT
EXPORT
PC -> SD CARD
SD CARD
LOGODT
TAX
DATA ENTRY
(VAT/TAX rate)
UPLOAD
ECR -> PC
RS-232
DOWNLOAD
PC -> ECR
RS-232
IMPORT
SD -> PC
SD CARD
TAXTB
EXPORT
PC -> SD
SD CARD
TAXTB
VAT ID
DATA ENTRY
UPLOAD
ECR -> PC
RS-232
DOWNLOAD
PC -> ECR
RS-232
LOGO
DOWNLOAD
PC -> ECR
RS-232
(Graphic logo)
EXPORT
PC -> SD
SD CARD
TMLOG1TB
ALL RAM
UPLOAD
ECR -> PC
RS-232
DOWNLOAD
PC -> ECR
RS-232
Function
DATA ENTRY
Add, delete ,edit, store, read the data Please refer Data Control Function.
UPLOAD
Read the data from ECR/POS.
DOWNLOAD
Write the data into ECR/POS
IMPORT
Read the data from SD CARD.
EXPORT
Write the data onto SD CARD.
4 Functions
This software have following functions.
4.1 Setting and communication function
DATA The data of setting (All ram means the dead copy of ECR/POS RAM .(Except internal memory)
FUNCTION The following data can be controlled.
DIRECTION The direction of data movement.
MEDIA The media for each function.
XE-A207/A217/A307 PCLINK
SHARP Confidential
4
for XE-A207
for XE-A217
PC-LINK_A207V.exe
PC-LINK_A217V.exe
CustomControlLibrary.dll
CustomControlLibrary.dll
ECR_Lib.dll
ECR_Lib.dll
EcrDataCtrl.dll
EcrDataCtrl.dll
ELMid.dll
ELMid.dll
pictcnv.dll
pictcnv.dll
logoconv.ini
logoconv.ini
de/CustomControlLibrary.resources.dll
de/CustomControlLibrary.resources.dll
de/PC-LINK_A207V.resources.dll
de/PC-LINK_A217V.resources.dll
es/CustomControlLibrary.resources.dll
es/CustomControlLibrary.resources.dll
es/PC-LINK_A207V.resources.dll
es/PC-LINK_A217V.resources.dll
fr/CustomControlLibrary.resources.dll
fr/CustomControlLibrary.resources.dll
fr/PC-LINK_A207V.resources.dll
fr/PC-LINK_A217V.resources.dll
sv/CustomControlLibrary.resources.dll
sv/CustomControlLibrary.resources.dll
sv/PC-LINK_A207V.resources.dll
sv/PC-LINK_A217V.resources.dll
for XE-A307
PC-LINK_A307V.exe
CustomControlLibrary.dll
ECR_Lib.dll
EcrDataCtrl.dll
ELMid.dll
pictcnv.dll
logoconv.ini
de/CustomControlLibrary.resources.dll
de/PC-LINK_A307V.resources.dll
es/CustomControlLibrary.resources.dll
es/PC-LINK_A307V.resources.dll
fr/CustomControlLibrary.resources.dll
fr/PC-LINK_A307V.resources.dll
sv/CustomControlLibrary.resources.dll
sv/PC-LINK_A307V.resources.dll
4.2 Plural data set management.
This software can manage plural data set by folder.
4.3 Multi- Language support
Each message and text of this software can be changed from English to other country language. (e.g. French, German, Spanish Swedish etc.) by resource file for each language.
4.4 Character exchange support.
Character code is different between PC and ECR. This software supports exchanging characters.
5 Installation
Software installation is by copying the program files, (not use installer) Software un-installation is also by deleting the program files.(not use un-installer) That means the setting data is not stored on registry, stored in setting files and stored in same folder than the data.
List of program files <1
XE-A207/A217/A307 PCLINK
SHARP Confidential
5
Item
Default
DEPT
No record is created.
<1
PLU/EAN
PLU/EAN is not created.
LOGO
No default data
LOGO TEXT
All text are filled by space.
VAT ID
0
6 Each Functions
6.1 Start up
1. ECR data is automatically loaded that are saved at the last time.
2. If there is no ECR data on the PC, default data is set as follows.
3. Dept. screen is always displayed just after start up.
4. This software cannot run a plural number at the same time on the same PC.
6.2 Termination
1. ECR data is saved automatically into a folder that has been selected.
2. Window position and size is saved. Window will be shown in same position and size at next time.
The above data (position, size, setting data) is recorded in the following file and folder. <1 File name <1 A207: setting207.xml <1 A217: setting217.xml <1 A307: setting307.xml <1 Folder name <1 XP : Document and Settings\(user name)\Application Data\PC_TOOL\Temp <1 Vista: Users\(user name)\AppData\Roaming\PC_TOOL\Temp <1 7 : Users\(user name)\AppData\Roaming\PC_TOOL\Temp <1
XE-A207/A217/A307 PCLINK
SHARP Confidential
6
Title
List
Contents
1
File(F)
Open(O) ...
You can select the folder which the data base are stored.
Export/Import(T) ...
Control SD data: Export and Import ECR data into/from SD card.
Setting(S) ...
You can set general setting of this software,
Exit(X)
Terminate the software.
2
Exec(E)
Receive(R)
Receive from ECR via RS232
Select and Send(S) ...
Send to ECR via RS232.
3
Record(R)
New(N)
You can add new PLU/EAN or Department code
Delete(D)
You can delete PLU/EAN or Department code
4 About(A)
This shows software name and version information.
6.3 Title bar
Program title is always displayed on title bar. <2
"PC-LINK for XE-A207" is displayed for XE-A207. <2 "PC-LINK for XE-A217" is displayed for XE-A217. <2 "PC-LINK for XE-A307" is displayed for XE-A307. <2
6.4 Menu bar
This software contains following menu items.
XE-A207/A217/A307 PCLINK
SHARP Confidential
7
Button
Functionality
Export
Programming data is saved into specified folder on SD CARD.
Import
Programming data is loaded from specified folder on SD CARD.
New Folder
Create a new user folder on SD CARD.
6.5 File
This menu item can be operated in case of any TAB is selected.
Open Load ECR data from selected folder. Selected folder is set as current DATA FOLDER. <2
Export/Import
Following windows is shown after select this menu item.
Then, following function can be executed.
Export: DEPT, PLU(/EAN), TAX, LOGO TEXT and LOGO data is saved to SD CARD. <2 If no record is displayed on DEPT tab, then DEPT data is not saved to SD CARD. <2 If no record is displayed on PLU(/EAN) tab, then PLU(/EAN) data is not saved to SD CARD. <2 If no file is selected on LOGO tab, then LOGO data is not saved to SD CARD. <2
Import: DEPT, PLU(/EAN), TAX and LOGO TEXT is loaded from SD CARD. <2 If no file to be loaded is in SD CARD, error message is displayed. <2
XE-A207/A217/A307 PCLINK
SHARP Confidential
8
Group
Item
Explanation
Default Value
<1
Data Folder(F)
Data folder to save each data set.
(*1)
<1
RS232C
Port Number(P)
RS-232 port number
1
<1
Baud Rate(B)
Communication speed. 38400bps 19200bps 9600bps 4800bps
19200
<1
Duplex(D)
HALF(Half duplex mode) FULL(Full duplex mode)
FULL
<1
ECR
Terminal No.(T)
Terminal No. of target ECR. (*2) (1-999999)
1
<1
Export operation
1. Select SD CARD Drive
2. Select “User Folder”
3. Then press "Export" button.
Import operation
1. Select SD CARD Drive
2. Select “User Folder”
3. Then press "Import" button.
Create folder operation
1. Select SD CARD Drive
2. Then press "New folder" button.
3. Following window is shown and enter the folder name.
Setting Setting items are as follows.
(*1) XP: Documents and Settings\(user name)\My Documents\SHARP_ECR\A207\SHOP_NAME1 <1 Documents and Settings\(user name)\My Documents\SHARP_ECR\A217\SHOP_NAME1 <1 Documents and Settings\(user name)\My Documents\SHARP_ECR\A307\SHOP_NAME1 <1 Vista, 7: Users\(user name)\Documents\SHARP_ECR\A207\SHOP_NAME1 <1 Users\(user name)\Documents\SHARP_ECR\A217\SHOP_NAME1 <1 Users\(user name)\Documents\SHARP_ECR\A307\SHOP_NAME1 <1 (*2) The item of group "ECR" should be set the same value of ECR setting. <1 (PGM MODE - SETTING - DEVICE CONFIG - ONLINE - TERMINAL No.) <1
Exit Terminate the PC-LINK software.
XE-A207/A217/A307 PCLINK
SHARP Confidential
9
Button
Functionality
All Select
All items are selected.
All Clear
All items are deselected.
SEND
Selected data will be sent.
Cancel
Cancel this command and close this dialog.
6.6 Exec
This menu item can be operated in case of any TAB is selected.
Receive Data of current TAB is received from connected ECR via RS-232. If "PLU" tab is selected and executed this command, then "PLU" data will be received from ECR.
Select and Send Data of current TAB is sent to connected ECR via RS-232.
In case of "PLU" or "DEPT", programming data can be sent partially. Following dialog is shown and you can select the data which should be sent.
In case of "DEPT" tab.
XE-A207/A217/A307 PCLINK
SHARP Confidential
10
Button
Functionality
All Select
All items are selected.
All Clear
All items are deselected.
SEND
Selected data will be sent.
Cancel
Cancel this command and close this dialog.
In case of "PLU" tab and "PLU/EAN" tab
XE-A207/A217/A307 PCLINK
SHARP Confidential
11
Group
Item
default
<1
TEXT
DPT.xx
xx: Department number
<1
PRICE
0
<1
TAXABLE
Tax1 Selected
<1 Tax2 Not selected
<1
Tax3 Not selected
<1 Tax4 Not selected
<1
PROGRAM
Amount Entry Type
OPEN
Selected
<1
PRESET
Not selected
<1
Sales Type
NORMAL
Selected
<1
SICS
Not selected
<1
HALO 99999999
<1 Group No. 01
<1
Group
Item
Value
<1
TEXT
P.xxxxxxxxxxxxxx
<1
PRICE
0 <1
PROGRAM
Dept No.
1
<1
Amount Entry Type OPEN
Not selected
<1
PRESET
Selected
<1
Auto Delete by Z1
Selected
For XE-A307 only
<1
6.7 Record
This menu item can be operated in case of "DEPT" tab or "PLU"("PLU/EAN") tab is selected. <1
New
Create a DEPT or PLU(EAN) record. <1
Code entry window comes up after this menu selected A new record is created with following default data.
DEPT <1
PLU(EAN) <1
If entered code is already exists, following error is shown. “Entered code already exist.”
Delete
Delete selected DEPT or PLU(EAN) record. <1
6.8 About
This menu item can be operated in case of any TAB is selected. A window that shows software name and version information comes up.
XE-A207/A217/A307 PCLINK
SHARP Confidential
12
A
B
6.9 Department programming
DEPT programming is available on "DEPT" tab
Screen construction This TAB is constructed by 2 panes.
Pane A shows list of department. Pane B shows detail of selected department.
Department record can not be added or deleted. Number of department is determined by setting item "Number of Dept."
XE-A207/A217/A307 PCLINK
SHARP Confidential
13
Item
Explanation
Text
Max 16 characters can be entered.
Price
Max 8 digits can be entered. Tab position is determined by regional setting of Windows.
Taxable
Maximum 6 4 taxable can be set. Please check the taxable number that should be set.
<1
Amount Entry Type
You can choose "OPEN" and "PRESET". If you check both of "OPEN" and "PRESET", it means "OPEN&PRESET" If both checks are excluded, it means "INHIBIT"
Sales Type
"NORMAL", "SICS", "SIF" can be selected.
<1
HALO
Open amount limitation.
Group No.
1 - 15 12 can be set. You can enter Group No. or select from list. Group list is shown when you push the "assist." button.
<1
Method
Operation
By selecting from list
Click the department on the list(Pane A).
By entering department code
1. Click the department code (See below, "a" is department code display.) then code entry window comes up.
2. Enter department code.
By increasing/decreasing operation.
See below, "b" is increase/decrease button. Click "<" to select smaller code from current code. Click ">" to select bigger code from current code.
Button
Functionality
RECEIVE
Receive all department preset data from ECR via RS-232.
SEND
Send all department preset data to ECR via RS-232.
a
b
Programming items. Following items can be programmed.
Selecting Department. You can select a department by following ways.
Data Transmission Data Transmission can be made by pressing "RECEIVE" or "SEND" button.
If you need to send only assigned department, please select "Select and Send" from "Exec" menu.
XE-A207/A217/A307 PCLINK
SHARP Confidential
14
Method
Operation
From context menu on the list
1. Somewhere on Pane A, click the right mouse button to open shortcut menu. Then select "New" on the shortcut menu.
2. Code entry window comes appear.
3. Enter Department code.
From menu bar
1.Select "Exec" menu on the menu bar.
2.Select "New" in "Exec" menu
3. Code entry window comes appear.
4. Enter Department code.
Method
Operation
From context menu on the list
1. Select the Department code which is to delete on the Pane A.
2. Click the right mouse button on the Pane A to open shortcut menu. Then select "Delete" on the shortcut menu.
3. Confirmation dialog comes appear and select "YES", then assigned Department code is deleted.
From menu bar
1. Select the Department code which is to delete on the Pane A.
2.Select "Exec" menu on the menu bar.
3.Select "Delete in "Exec" menu.
4. Confirmation dialog comes appear and select "YES", then assigned Department code is deleted.
Create Department code You can create a Department by following ways.
Delete Department code You can delete a Department by following ways.
XE-A207/A217/A307 PCLINK
SHARP Confidential
15
A
B
6.10 PLU programming
PLU programming is available for XE-A207 and XE-A217 on "PLU" tab.
Screen construction This TAB is constructed by 2 panes.
Pane A shows list of PLU. Pane B shows detail of selected PLU.
XE-A207/A217/A307 PCLINK
SHARP Confidential
16
Item
Explanation
Text
Max 16 characters can be entered.
Price
Max 8 digits can be entered. Tab position is determined by regional setting of Windows.
Sign
<1
Dept. No.
1 - 99 can be entered.
Amount Entry Type
You can choose "OPEN" and "PRESET". If you check both of "OPEN" and "PRESET", it means "OPEN&PRESET" If both checks are excluded, it means "INHIBIT"
Method
Operation
By selecting from list
Click the PLU on the list (Pane A).
By entering PLU code
1.Click the PLU code (See below, "a" is PLU code display.) then code entry window comes up.
2.Enter PLU code.
<3
By increasing/decreasing operation
See below, "b" is increase/decrease button. Click "<" to select smaller code from current code. Click ">" to select bigger code from current code.
b
a
Programming items.
Following items can be programmed.
Selecting PLU
You can select a PLU by following ways.
XE-A207/A217/A307 PCLINK
SHARP Confidential
17
Method
Operation
From context menu on the list
1. Somewhere on Pane A, click the right mouse button to open shortcut menu. Then select "New" on the shortcut menu.
2. Code entry window comes appear.
3. Enter PLU code.
From menu bar
1.Select "Exec" menu on the menu bar.
2.Select "New" in "Exec" menu
3. Code entry window comes appear.
4. Enter PLU code.
Method
Operation
From context menu on the list
1. Select the PLU code which is to delete on the Pane A.
2. Click the right mouse button on the Pane A to open shortcut menu. Then select "Delete" on the shortcut menu.
3. Confirmation dialog comes appear and select "YES", then assigned PLU code is deleted.
From menu bar
1. Select the PLU code which is to delete on the Pane A.
2.Select "Exec" menu on the menu bar.
3.Select "Delete in "Exec" menu.
4. Confirmation dialog comes appear and select "YES", then assigned PLU code is deleted.
Button
Functionality
RECEIVE
Receive all department preset data from ECR via RS-232.
SEND
Send all department preset data to ECR via RS-232.
Create PLU code You can create a PLU by following ways.
Delete PLU code You can delete a PLU by following ways.
Data Transmission Data Transmission can be made by pressing "RECEIVE" or "SEND" button.
If you need to send only assigned PLU, please select "Select and Send" from "Exec" menu.
XE-A207/A217/A307 PCLINK
SHARP Confidential
18
A
B
6.11 PLU/EAN programming
PLU/EAN programming is available for XE-A307 on "PLU/EAN" tab.
Screen construction This TAB is constructed by 2 panes.
Pane A shows list of PLU/EAN. Pane B shows detail of selected PLU/EAN.
XE-A207/A217/A307 PCLINK
SHARP Confidential
19
Item
Explanation
Text
Max 16 characters can be entered.
Price
Max 8 digits can be entered. Tab position is determined by regional setting of Windows.
Sign
<1
Dept. No.
1 - 99 can be entered.
Amount Entry Type
You can choose "OPEN" and "PRESET". If you check both of "OPEN" and "PRESET", it means "OPEN&PRESET". If both checks are excluded, it means "INHIBIT" This item can be selected only for PLU (5-digits) code.
<3
Auto Delete by Z1
Auto record delete at the timing of Z1 report. This item can be selected except for PLU (5-digits) code.
Method
Operation
By selecting from list
Click the PLU/EAN on the list (Pane A).
By entering PLU/EAN code
1.Click the PLU/EAN code (See below, "a" is PLU/EAN code display.) then code entry window comes up.
2.Enter PLU/EAN code.
<3
By increasing/decreasing operation
See below, "b" is increase/decrease button. Click "<" to select smaller code from current code. Click ">" to select bigger code from current code.
b
a
Programming items.
Following items can be programmed.
Selecting PLU/EAN
You can select a PLU/EAN by following ways.
XE-A207/A217/A307 PCLINK
SHARP Confidential
20
Method
Operation
From context menu on the list
1. Somewhere on Pane A, click the right mouse button to open shortcut menu. Then select "New" on the shortcut menu.
2. Code entry window comes appear.
3. Enter PLU/EAN code.
From menu bar
1.Select "Exec" menu on the menu bar.
2.Select "New" in "Exec" menu
3. Code entry window comes appear.
4. Enter PLU/EAN code.
Method
Operation
From context menu on the list
1. Select the PLU/EAN code which is to delete on the Pane A.
2. Click the right mouse button on the Pane A to open shortcut menu. Then select "Delete" on the shortcut menu.
3. Confirmation dialog comes appear and select "YES", then assigned PLU/EAN code is deleted.
From menu bar
1. Select the PLU/EAN code which is to delete on the Pane A.
2.Select "Exec" menu on the menu bar.
3.Select "Delete in "Exec" menu.
4. Confirmation dialog comes appear and select "YES", then assigned PLU/EAN code is deleted.
Button
Functionality
RECEIVE
Receive all department preset data from ECR via RS-232.
SEND
Send all department preset data to ECR via RS-232.
Create PLU/EAN code You can create a PLU/EAN by following ways.
Delete PLU/EAN code You can delete a PLU/EAN by following ways.
Data Transmission Data Transmission can be made by pressing "RECEIVE" or "SEND" button.
If you need to send only assigned PLU/EAN, please select "Select and Send" from "Exec" menu.
XE-A207/A217/A307 PCLINK
SHARP Confidential
21
B C D
6.12 LOGO programming (Thermal Logo)
Thermal logo data download is available on LOGO Tab.
Screen construction
This TAB is constructed only HEADER LOGO select & send. <1
XE-A207/A217/A307 PCLINK
SHARP Confidential
22
Color
Monochrome (Black and White)
Size
Width 360pixel <1 Height 130 pixel
Method
Operation
By entering file path
Enter or select location of logo data file.
By Drag & Drop
Logo data can be set by Drag & Drop operation into C area. (See screen sample of previous page.)
Button
Functionality
SEND
Send logo data to ECR via RS-232.
Programming items. This software doesn't support create and edit logo data.
Logo data should be created another PC software (like Paintbrush). This software supports only download of graphic logo data.
Requirement about bitmap The bit map image file should meet following requirement.
If assigned Bitmap does not satisfy above requirement, error message will be shown.
Assignment of Logo data You can set Logo data by following ways.
Data Transmission Data Transmission can be made by pressing ""SEND" button.
Both of Header logo and Footer logo data is sent. If one of them isn't assigned, only assigned data is sent.
XE-A207/A217/A307 PCLINK
SHARP Confidential
23
Item
Explanation
Logo Text
30characters / line and Max. 6lines of Logo text can be programmed.
Button
Functionality
RECEIVE
Receive all Logo text data from ECR via RS-232.
SEND
Send all Logo text data to ECR via RS-232.
6.13 LOGO text programming
Logo text programming is available on LOGO TEXT Tab.
Screen construction This TAB is constructed only Logo text entry.
Programming items.
Data Transmission Data Transmission can be made by pressing "RECEIVE" or "SEND" button.
XE-A207/A217/A307 PCLINK
SHARP Confidential
24
Item
Explanation
VAT ID
Max. 10 digits VAT ID can be programmed.
Button
Functionality
RECEIVE
Receive VAT ID data from ECR via RS-232.
SEND
Send VAT ID data to ECR via RS-232.
6.14 VAT ID programming
VAT ID programming is available on VAT ID Tab.
Screen construction This TAB is constructed only VAT ID entry.
Programming items.
Data Transmission Data Transmission can be made by pressing "RECEIVE" or "SEND" button.
ECR side should be set as Sweden fiscal mode.
XE-A207/A217/A307 PCLINK
SHARP Confidential
25
A
B
6.15 ALL RAM Backup/Restore
ALL RAM Backup/Restore is available on "ALL RAM" Tab.
Screen construction
This TAB is constructed by 2 panes. <1 Pane A is for all RAM receiving from ECR. <1 Pane B is for all RAM sending to ECR. <1
Programming items. ALL RAM data can not be modified. This supports only upload and download of ALL RAM data.
XE-A207/A217/A307 PCLINK
SHARP Confidential
26
Button
Functionality
BACKUP
Receive ALL RAM data from ECR via RS-232. Location and name of the file that the ALL RAM data is stored in is specified by "BACKUP FILE". If BACKUP button is clicked, then all RAM data is received and the file is overwritten by the new data.
<3 <3
RESTORE
Send ALL RAM data to ECR via RS-232. The transmitted data were appointed in "RESTORE". ALL RAM data file location is assigned by "RESTORE FILE"
C
Data Transmission Data Transmission can be made by pressing "RECEIVE" or "SEND" button.
Note area <3 Only PC-LINK for XE-A307 has note area on ALL RAM tab. <3
XE-A207/A217/A307 PCLINK
SHARP Confidential
27
Item
Explanation
Tax rate
3 digits integer + 4 digits decimal can be programmed for each rate. Minus sign can be programmed.
Lower Tax Limit
Max 5 digits value can be programmed.
Button
Functionality
RECEIVE
Receive TAX rate data from ECR via RS-232.
<3
SEND
Send TAX rate data to ECR via RS-232.
<3
6.16 VAT/TAX rate programming
VAT/TAX rate programming is available on TAX Tab.
Screen construction This TAB is constructed only Tax programming entry.
Programming items.
Data Transmission Data Transmission can be made by pressing "RECEIVE" or "SEND" button.
XE-A207/A217/A307 PCLINK
SHARP Confidential
28
Kind of data
File name
DEPT data
DEPT.xml
PLU(/EAN) data
PLU.xml
Logo Text data
LOGOTEXT.xml
TAX data
TAX.xml
VAT ID data
VAT-ID.xml
ALL RAM data
(file name is specified by user)
7 Internal data handling
Each programming data is stored in specified data folder in PC.
XML DATA FORMAT
DEPT data and PLU data are stolen in following XML format. The others are stolen in the same format as ER-A280V.
XE-A207/A217/A307 PCLINK
SHARP Confidential
29
<?xml version="1.0" encoding="UTF-8" standalone="yes"?> <FILE xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"> <RECORD DEPT_CODE="01"> <FIELD1> <PROGRAM> <ENTRY_TYPE>Open</ENTRY_TYPE> <ITEM_TYPE>NORMAL</ITEM_TYPE> </PROGRAM> <TAX> <TAXABLE1>No</TAXABLE1> <TAXABLE2>No</TAXABLE2> <TAXABLE3>No</TAXABLE3> <TAXABLE4>No</TAXABLE4> </TAX> <HALO>99999999</HALO> <GROUP_NUMBER>1</GROUP_NUMBER> </FIELD1> <FIELD3> <PRICE>0</PRICE> </FIELD3> <FIELD4> <TEXT>DPT.01</TEXT> </FIELD4> </RECORD> <RECORD DEPT_CODE="02"> <FIELD1> <PROGRAM> <ENTRY_TYPE>Open</ENTRY_TYPE> <ITEM_TYPE>NORMAL</ITEM_TYPE> </PROGRAM> <TAX> <TAXABLE1>No</TAXABLE1> <TAXABLE2>No</TAXABLE2> <TAXABLE3>No</TAXABLE3> <TAXABLE4>No</TAXABLE4> </TAX> <HALO>99999999</HALO> <GROUP_NUMBER>1</GROUP_NUMBER> </FIELD1> <FIELD3> <PRICE>0</PRICE> </FIELD3> <FIELD4> <TEXT>DPT.02</TEXT> </FIELD4> </RECORD> </FILE>
←This line can be omitted.<FIELD1> <1 ←This line can be omitted.<PROGRAM> <1
←This line can be omitted.<PROGRAM> <1 ←This line can be omitted.<TAX> <1
←This line can be omitted.<TAX> <1
←This line can be omitted.<FIELD1> <1 ←This line can be omitted.<FIELD3> <1
←This line can be omitted.<FIELD3> <1 ←This line can be omitted.<FIELD4> <1
←This line can be omitted.<FIELD4> <1
←This line can be omitted.<FIELD1> <1 ←This line can be omitted.<PROGRAM> <1
←This line can be omitted.<PROGRAM> <1 ←This line can be omitted.<TAX> <1
←This line can be omitted.<TAX> <1
←This line can be omitted.<FIELD1> <1 ←This line can be omitted.<FIELD3> <1
←This line can be omitted.<FIELD3> <1 ←This line can be omitted.<FIELD4> <1
←This line can be omitted.<FIELD4> <1
<Example> DEPT.xml
XE-A207/A217/A307 PCLINK
SHARP Confidential
30
<?xml version="1.0" encoding="UTF-8" standalone="yes"?> <FILE xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"> <RECORD PLU_CODE="00000000000001"> <TYPE>0</TYPE> <FIELD1> <DEPARTMENT>1</DEPARTMENT> <PROGRAM> <AUTO_DELETE_BY_Z1>Yes</AUTO_DELETE_BY_Z1> <ENTRY_TYPE>Preset</ENTRY_TYPE> </PROGRAM> </FIELD1> <FIELD3> <PRICE>0</PRICE> </FIELD3> <FIELD4> <TEXT>P.00000000000001</TEXT> </FIELD4> </RECORD> <RECORD PLU_CODE="04903333025367"> <TYPE>1</TYPE> <FIELD1> <DEPARTMENT>1</DEPARTMENT> <PROGRAM> <AUTO_DELETE_BY_Z1>Yes</AUTO_DELETE_BY_Z1> <ENTRY_TYPE>Preset</ENTRY_TYPE> </PROGRAM> </FIELD1> <FIELD3> <PRICE>0</PRICE> </FIELD3> <FIELD4> <TEXT>P.00000000000002</TEXT> </FIELD4> </RECORD> </FILE>
←This line can be omitted.<FIELD1> <1
←This line can be omitted.<PROGRAM> <1
←This line can be omitted.<PROGRAM> <1 ←This line can be omitted.<FIELD1> <1 ←This line can be omitted.<FIELD3> <1
←This line can be omitted.<FIELD3> <1 ←This line can be omitted.<FIELD4> <1
←This line can be omitted.<FIELD4> <1
←This line can be omitted.<FIELD1> <1
←This line can be omitted.<PROGRAM> <1
←This line can be omitted.<PROGRAM> <1 ←This line can be omitted.<FIELD1> <1 ←This line can be omitted.<FIELD3> <1
←This line can be omitted.<FIELD3> <1 ←This line can be omitted.<FIELD4> <1
←This line can be omitted.<FIELD4> <1
<Example> PLU.xml
XE-A207/A217/A307 PCLINK
SHARP Confidential
31
8 Display
8.1 Data transmission
A modal dialog is displayed during communication with ECR.
The dialog has CANCEL button. If CANCEL button is clicked, then the communication with ECR is stopped. When communication error occurs, error message is displayed by pop-up.
8.2 Status indication
XE-A207/A217/A307 PCLINK
SHARP Confidential
32
Number
Meaning
Conceivable cause
0
Communication is successfully completed.
3
FDS file access error
Program bug or PC has some trouble about file access.
4
TEXT file access error
Program bug or PC has some trouble about file access.
11
text – binary exchange error
Program bug or data error.
21
protocol error
Program bug.
23
FDS packet data error.
Communication data lost.
31
DSR signal off error
There is some trouble in connection.
32
DCD signal off error
There is some trouble in connection.
33
DCD signal on error
There is some trouble in connection.
34
CTS signal off error
There is some trouble in connection.
35
Not connected
There is some trouble in connection.
36
ECR has been sent EOT.
Configuration mismatch between PC and ECR. 38
Retry over error
ECR doesn't respond.
39
Time out error
ECR doesn't respond.
40
Not connected
There is some trouble in connection.
41
Connection has been established.
Program bug.
50
Program error
Program bug.
55
Memory allocate error
Program bug.
Data transmission status is shown as follows.
XE-A207/A217/A307 PCLINK
SHARP Confidential
33
032
033
034
035
036
037
038
039
040
041
042
043
044
045
046
047
032- 047
! " # $ % & ' ( ) * + , - .
/
048
049
050
051
052
053
054
055
056
057
058
059
060
061
062
063
048- 063
0 1 2 3 4 5 6 7 8 9 : ; < = >
?
064
065
066
067
068
069
070
071
072
073
074
075
076
077
078
079
064-079
@ A B C D E F G H I J K L M N
O
080
081
082
083
084
085
086
087
088
089
090
091
092
093
094
095
080-095
P Q R S T U V W X Y Z
[
＼
]
^
(DC)
096
097
098
099
100
101
102
103
104
105
106
107
108
109
110
111
096-111
` a b c d e f g h i j k l m n
o
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
112-127
p q r s t u v w x y z { | } ~
⌂
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
128-143
Ç ü é â ä à å ç ê ë è ï î Ì Ä
Å
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
144-159
É æ Æ ô ö ò û ù ÿ Ö Ü ø £ Ø ×
ƒ
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
160-175
á í ó ú ñ Ñ ª º ¿
® č ½ ¼ ¡ « »
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
176-191
░ ▒ ▓
│ ď Á Â À
© ĕ ║
ň
Ř
¢
¥
š
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
192-207
ť ŧ ž Č ─ Ď ã Ã Ě Ň Ř Š Ť ═ Ŧ
¤
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
208-223
ð Ð Ê Ë È € Í Î Ï Ž ┌ █ ▄ ¦ Ì
▀
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
224-239
Ó ß Ô Ò õ Õ µ þ Þ Ú Û Ù ý Ý ¯
´
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
240-255
- ± = ¾ ¶ § ÷ ¸ ° ¨ · ¹ ³ ²
9 Available characters
The following characters are available in this "Programming tool". They are converted between PC and ECR.
Code table for alpha descriptor programming （Code page 850）
(DC) Double-size character code
■Shaded characters are Czech characters.
The character '_' is converted to ECR "Double Character" CODE.
XE-A207/A217/A307 PCLINK
SHARP Confidential
34
English
1
User folder cannot be added.
2
Application error.
3
Communication error.
4
Already same DEPT code exists.
5
The file is duty over.
6
The file doesn't exist, or path is illegal.
7
Invalid character is used.
8
The file is not bitmap file.
9
The file is not found.
10
The file format is not supported color.
11
The file is not supported size.
12
Failed to save the file. Do you want to exit PC-LINK?
13
Input the folder path.
14
Folder cannot be make.
15
PC-LINK for XE-A207 has already started.
*1
16
Export folder is not specified.
17
Import folder is not specified.
18
Picture convert DLL is not found.
19
Drive is not specified.
20
The path doesn't exist.
21
Already same PLU/EAN code exists.
22
The file cannot be preserved.
23
Failed in export.
24
Failed in import.
25
Do you want to change this setting?
26
Do you want to execute export?
27
Do you want to execute import?
28
Do you want to delete the DEPT Code?
29
ERROR
30
Do you want to load data from the new folder?
<3
31
Do you want to delete the PLU/EAN Code?
32
Max value is {x}.
33
Min value is {x}.
34
Digit number at the right of decimal point is {x}.
35
Out of range
36
Input some value.
37
XML file is broken. PC-LINK operates in the initial state.
38
Invalid PLU/EAN code
39
VAT ID is only for Sweden fiscal mode.
<3
40
ALL RAM will be taken more than 30 minutes.
<3
10 Messages
*1 Model name is replaced on XE-A217 or XE-A307 by each model. <1
XE-A207/A217/A307 PCLINK
SHARP Confidential
35
English
A
01: GROUP1 02: GROUP2 03: GROUP3 04: GROUP4 05: GROUP5 06: GROUP6 07: GROUP7 08: GROUP8 09: GROUP9 10: MINUS DEPT. 11: HASH DEPT. 12: HASH MINUS DEPT. 13: BR DEPT. 14: BR MINUS DEPT.
B
Folder name requirement. * MAX. 8 characters * Available characters A-Z , 0-9 , ! , # , $ , % , & , „ , ( , ) , - , @ , ^ , _ , ` , { , } , ~
C
Graphical picture data : 360(w) x 130(h) pixels <1 Type: monochrome(black/white) File Type: BMP
A: Explanation of dept group number. B: Explanation folder name specification. C: Explanation of graphic logo specification
XE-A207/A217/A307 PCLINK
SHARP Confidential
36
German
1
Verzeichnis kann nicht hinzugefügt werden.
2
Anwendungsfehler.
3
Kommunikationsfehler.
4
Warengruppennummer existiert bereits.
5
Die Datei hat zu hohen Schwarzanteil.
6
Die Datei existiert nicht oder falscher Pfad.
7
Ungültige(r) Buchstaben verwendet.
8
Die Datei ist keine Bitmap-Datei.
9
Die Datei konnte nicht gefunden werden.
10
Die Farbe des Dateiformats wird nicht unterstützt.
11
Die Grösse der Datei wird nicht unterstützt.
12
Die Datei konnte nicht gesichert werden. Möchten Sie PC-LINK beenden?
13
Den Verzeichnispfad eingeben.
14
Verzeichnis kann nicht erstellt werden.
15
PC-LINK für die XE-A207 ist bereits gestartet.
*1
16
Exportverzeichnis ist nicht angegeben.
17
Importverzeichnis ist nicht angegeben.
18
Bildkonvertier (pictcnv)-DLL konnte nicht gefunden werden.
19
Laufwerk ist nicht angegeben.
20
Der Pfad existiert nicht.
21
PLU/EAN Code existiert bereits.
22
Die Datei kann nicht erhalten werden.
23
Export fehlgeschlagen.
24
Import fehlgeschlagen.
25
Möchten Sie die Programmierung ändern?
26
Möchten Sie den Export ausführen?
27
Möchten Sie den Import ausführen?
28
Möchten Sie die Warengruppennummer löschen?
29
Fehler! 30
Möchten Sie Daten von dem neuen Verzeichnis laden?
31
Möchten Sie den PLU/EAN Code löschen?
32
Maximaler Wert ist {x}.
<1
33
Minimaler Wert ist {x}.
<1
34
Stellenanzahl hinter dem Dezimalpunkt ist {x}.
<1
35
Ausserhalb des Bereichs.
36
Einige Werte eingeben.
37
XML-Datei ist beschädigt. PC-LINK verwendet den Auslieferungszustand.
38
Ungültiger PLU/EAN Code
39
MwSt-Nr. nur im schwedischen Fiskalmodus gültig.
<3
40
Gesamt RAM Datensicherungsdauer über 30 Minuten.
<3
*1 Model name is replaced on XE-A217 or XE-A307 by each model. <1
XE-A207/A217/A307 PCLINK
SHARP Confidential
37
German
A
01: Hauptgruppe 1 02: Hauptgruppe 2 03: Hauptgruppe 3 04: Hauptgruppe 4 05: Hauptgruppe 5 06: Hauptgruppe 6 07: Hauptgruppe 7 08: Hauptgruppe 8 09: Hauptgruppe 9 10: Minus-Hauptgruppe 11: Extra-Hauptgruppe 12: Extra-Minus-Hauptgruppe 13: Pfand-Hauptgruppe 14: Pfand-Minus-Hauptgruppe
B
Verzeichnisanforderung: *Maximal 8 Zeichen *Verwendbare Zeichen A-Z , 0-9 , ! , # , $ , % , & , „ , ( , ) , - , @ , ^ , _ , ` , { , } , ~
C
Grafische Logodaten: 360(B) x 130(H) Pixel <1 Typ: Monochrome (schwarz/weiss) Dateityp: BMP
A: Explanation of dept group number. B: Explanation folder name specification. C: Explanation of graphic logo specification
XE-A207/A217/A307 PCLINK
SHARP Confidential
38
French
1
Dossier utilisateur ne peut pas être ajouté
2
Erreur Application
3
Erreur Communication
4
Code DEPT existe déjà
5
Le fichier est duty over
6
Le fichier n'existe pas ou mauvais chemin.
7
Caractère invalide utilisé.
8
Ce n'est pas un fichier image.
9
Fichier non trouvé.
10
Le format de fichier ne supporte pas la couleur.
11
Le fichier ne supporte pas cette taille
12
Erreur de sauvegarde fichier.Voulez-vous quitter PC-LINK?
13
Entrer le chemin du dossier.
14
Dossier ne peut être créé.
15
PC-LINK pour XE-207 est déjà démarré.
*1
16
Export dossier non spécifié.
17
Import dossier non spécifié.
18
Image de conversion DLL non trouvé.
19
Disque non spécifié.
20
Le chemin n'existe pas.
21
Code PLU/EAN existe déjà.
22
Le fichier ne peut pas être préservé.
23
Erreur en export.
24
Erreur en import.
25
Voulez-vous changer ce paramètre?
26
Voulez-vous exécuter l'export?
27
Voulez-vous exécuter l'import?
28
Voulez-vous effacer le code DEPT?
29
ERREUR
30
Voulez-vous charger les formes de données dans un nouv.Dossier?
31
Voulez-vous effacer le code PLU/EAN?
32
Valeur maxi est {x}.
33
Valeur minii est {x}.
34
Le nombre de chiffre après le point décimal est {x}.
35
En dehors de la plage
36
Entrer une valeur.
37
Fichier XML cassé. PC-LINK opère dans l'état initial.
38
Code PLU/EAN incorrect
39
N°TVA : uniquement utilisé en Suède
<3
40
ALL RAM : le transfert peut dure plus de 30 minutes.
<3
*1 Model name is replaced on XE-A217 or XE-A307 by each model. <1
XE-A207/A217/A307 PCLINK
SHARP Confidential
39
French
A
01: GROUP1 02: GROUP2 03: GROUP3 04: GROUP4 05: GROUP5 06: GROUP6 07: GROUP7 08: GROUP8 09: GROUP9 10: DEPT NEGATIF 11: DEPT HORS C.A. 12: DEPT HORS C.A. NEGATIF 13: DEPT CONSIGNE 14: DEPT CONSIGNE NEGATIF
B
Nom du dossier requis * MAX. 8 caractères * Caractères disponible A-Z , 0-9 , ! , # , $ , % , & , „ , ( , ) , - , @ , ^ , _ , ` , { , } , ~
C
Image graphique : 360(w) x 130(h) pixels <1 Type: monochrome(noir/blanc) Type fichier: BMP
A: Explanation of dept group number. B: Explanation folder name specification. C: Explanation of graphic logo specification
XE-A207/A217/A307 PCLINK
SHARP Confidential
40
Spanish
1
No se puede crear carpeta
2
Error de aplicacion
3
Error de comunicación
4
Codigo de DEPT repetido
5
Exceso de % de negro en el fichero.
6
El fichero no existe o ruta ilegal
7
Carácter invalido
8
El fichero no es de tipo BMP
9
Fichero no encontrado
10
Fichero de color no soportado
11
Tamaño del fichero invalido
12
No se pudo grabar. Salir del PC-LINK?
13
Teclear ruta de la carpeta
14
No se pudo crear la carpeta.
15
PC-LINK ya ejecutandose
16
Carpeta de exportacion no especificada
17
Carpeta de importacion no especificada
18
DLL conversion dibujo no encontrada
19
Unidad no especificada
20
La ruta no existe
21
Codigo PLU/EAN repetido
22
El fichero no se puede guardar.
23
Fallo en exportacion
24
Fallo en importacion
25
Quiere cambiar estos parametros?
26
Quiere ejecutar la exportacion?
27
Quiere ejecutar la importacion?
28
Quiere borrar el codigo de DEPT?
29
ERROR 30
Quiere recuperar datos de la nueva carpeta?
31
Quiere borrar el codigo de PLU/EAN?
32
Valor maximo {x}
33
Valor minimo {x}
34
Numero de digitos a la derecha del decimal es {x}
35
Fuera de rango
36
Teclear algun valor
37
Fichero XML roto. PC-LINK fuciona como al inicio
38
Codigo PLU/EAN invalido
39
IVA ID es solo para el modo fiscal de Suecia
<3
40
TODA LA RAM tardará más de 30 minutos
<3
XE-A207/A217/A307 PCLINK
SHARP Confidential
41
Spanish
A
01: GRUPO1 02: GRUPO2 03: GRUPO3 04: GRUPO4 05: GRUPO5 06: GRUPO6 07: GRUPO7 08: GRUPO8 09: GRUPO9 10: MINUS DEPT. 11: HASH DEPT. 12: HASH MINUS DEPT. 13: BR DEPT. 14: BR MINUS DEPT.
B
Nombre carpeta necesario. * MAX. 8 caracteres * Caracteres dsiponibles A-Z , 0-9 , ! , # , $ , % , & , „ , ( , ) , - , @ , ^ , _ , ` , { , } , ~
C
Tamaño grafico : 360(w) x 130(h) pixels <1 Tipo: monocromo(blanco/negro) Tipo fichero: BMP
A: Explanation of dept group number. B: Explanation folder name specification. C: Explanation of graphic logo specification
XE-A207/A217/A307 PCLINK
SHARP Confidential
42
Swedish
1
Folder kan inte läggas till.
2
Applikationsfel.
3
Kommunikationsfel.
4
Varugruppen finns redan.
5
För mycket svärta i bilden.
6
Filen kunde inte hittas.
7
Ogiltigt tecken.
8
Detta är inte en bitmap-fil.
9
Filen hittades ej.
10
Bilden får ej innehålla färg.
11
Filen har fel storlek.
12
Kunde inte spara filen. Avsluta PCLINK?
13
Ange sökväg.
14
Folder kunde inte skapas.
15
PC-LINK för XE-A207 körs redan.
*1
16
Exportfolder ej specificerad.
17
Importfolder ej specificerad.
18
DLL för bildkonvertering hittades ej.
19
Enhetsbeteckning saknas.
20
Sökvägen finns ej.
21
PLU/EAN kod finns redan.
22
Filen kan inte sparas.
23
Export misslyckades.
24
Import misslyckades.
25
Vill du ändra denna inställning?
26
Vil du starta export?
27
Vill du starta import?
28
Vill du ta bort varugruppen?
29
FEL 30
Vill du ladda data från den nya foldern?
31
Vill du ta bort PLU/EAN koden?
32
Max värde är (x).
33
Min värde är (x).
34
Antal siffror efter decimalpunkt är (x).
35
Utanför giltigt område.
36
Ange ett värde.
37
XML-fil defekt. PC-LINK initieras.
38
Ogiltig PLU/EAN kod
39
VAT ID gäller endast för Sverige.
<3
40
ALL RAM tar mer än 30 minuter.
<3
*1 Model name is replaced on XE-A217 or XE-A307 by each model. <1
XE-A207/A217/A307 PCLINK
SHARP Confidential
43
Swedish
A
01: GRUPP1 02: GRUPP2 03: GRUPP3 04: GRUPP4 05: GRUPP5 06: GRUPP6 07: GRUPP7 08: GRUPP8 09: GRUPP9 10: MINUS VGR. 11: HASH VGR. 12: HASH MINUS VGR. 13: PANT VGR. 14: PANT (-) VGR.
B
Foldernamn specifikation. * MAX. 8 tecken * Tillåtna tecken A-Z , 0-9 , ! , # , $ , % , & , „ , ( , ) , - , @ , ^ , _ , ` , { , } , ~
C
Storlek grafisk bild : 360(b) x 130(h) pixels Typ: monokrom (svart/vit) Filtyp: BMP
<1
A: Explanation of dept group number. B: Explanation folder name specification. C: Explanation of graphic logo specification
XE-A207/A217/A307 PCLINK
SHARP Confidential
44
Language
Message
English
The file is duty over.
German
Die Datei hat zu hohen Schwarzanteil.
French
Le fichier est duty over
Spanish
Exceso de % de negro en el fichero.
Swedish
För mycket svärta i bilden.
6dot
6dot
Black area in this rectangle area must be under 30%.
11 Restrictions
Following operation is restricted.
1. You must not perform operation to enter into standby during communication. If stand by timer is set by power option of Windows, it is ignored during communication.
2. Graphic Logo data must be fit for following specification.
2-1. Height must be 130dot, width must be 360 dot. <1 2-2. It must be monochrome color. 2-3. Area of black must be less than 35% of all area. 2-4. When the number of dot of the line which drew on the cross direction is more than 55% of the width,
black area of following rectangle area must be under 30%.
If your graphic logo data is restricted by 2-3 and 2-4, you will see following message. And you have to modify your graphic logo data to fit above restriction. These message are displayed when “SEND” key is pressed in “LOGO” tab or “Export/Import” is selected from “File” menu.
I
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
