Specifications and Main Features
- Model: XE-A217W/XE-A217B
- Type: ECR
- Printer: Thermal printer (receipt type, ink needed only as an option)
- Printer Lifespan: Around five million lines
- Keyboard:
- Standard key layout XE-A207W/XE-A207B
- Flat type key layout XE-A217W/XE-A217B
- Display:
- Displays for the operators during the course of a transaction
- Displays the total amount to turning customers
- RS232 Connector: Yes
- SD Card Slot: Yes
- Multiple operational modes are available: REG, OPXZ, VOID, X1/Z1, PGM, SD CARD modes.
- Maximum Number of Departments: 99 departments
- Maximum Number of PLUs: 70 going to XE-A217W/XE-A217B, 32 stratifying comprising XE-A207W/XE-A207B
- VAT System supported: Extensive geographic range of different VAT systems support
- Power Supply: Any wall outlet
- Battery Backup: Needs two LR6 alkaline batteries (“AA” batteries) for backup in saving data.
- Dimensions: (Not specified in the manual)
- Weight: (Not specified in the manual)
- Installation Requirements: Position away from exposure to bright sunlight, excessive moisture or saline environment
Frequently Asked Questions
- Q: What has been the kind of printer utilized in the cash register?
Answer: Ink is not required by the thermal printer that the cash register uses.
- Q: Is there a limit to the number of departments able to be set up?
Answer: Yes, as many as 99 departments are permitted to be set up.
- Q: What is the lifespan of the printer?
A: On average, this printer can be expected to last for five million lines of texts.
- Q: What do I do to enter the manager mode?
A: The manager mode can be accessed by inputting the manager code and punching in the secret code visible on the screen.
- Q: Jams within the printer occur, and I want to know how to resolve this?
A: Use the guidance provided in the manual which explains how to remove paper jams to aid you in resolving the issue.
- Q: Is it possible to use backup batteries?
A: The register does have a backup option which requires two alkaline batteries LR6(Most commonly known as AA) size.
- Q: Changes are to be made to the receipt paper, how is this done?
A: Instructions on the maintenance section of the manual for changing the paper roll would be of great help as well.
- Q: When I use this cash register, will I need to reprogram it often?
A: This programming is of ease and if in case one gets stuck, the help function would guide them as well.
- Q: Are there certain things which should not be done when using the cash register?
A: Avoid to point the register in the sun, extreme temperatures or in a humid or saline environment.
