6" LED Downlight

Specifications

LC6ML

2400 & 3000 Lumens
120V-277V, 347V
0-10V Dimming

DATE: TYPE:

FIRM NAME:

PROJECT:

APPLICATIONS:

LiteFrame Commercial LC6ML is a 6" commercial
grade LED downlight with available outputs between
2400-3000 lumens. This is suitable to replace most CFL
downlighting applications, while realizing substantial
energy and maintenance savings. Rated for a minimum
of 50,000 hours life (70% lumen maintenance) with
ambient plenum temperatures up to 25ºC. Free Air Flow
around fixture is required for optimal life performance.
This product is not recommended for use with 3rd party
"FIREHAT" or insulation barriers.

HOUSING:

One-piece 22 gauge non-corrosive steel platform. Pre­wired J-box with snap-on cover for easy access. Snap­in connection from driver compartment allows easy
installation of light engine/trim assembly and can be
upgraded to accommodate technology improvements.
Approved for 8 (4 in/4 out) No. 12 AWG conductors
rated for 90°C through wiring.

REFLECTOR:

High purity aluminum, Alzak, iridescence suppressed,
semi-diffuse reflector. Self-trim standard. Painted white
self-trim (WT) available as option.

LED LIGHT ENGINE:

The LC6ML uses mid power Nichia LEDs, specifically
mixed to provide a minimum of 80 CRI with 3 SDCM
color consistency. The use of multiple mid power LEDs
allows for optimal thermal management by effectively
spreading the heat over a larger area and eliminating
hot spots on the LEDs. A diffuse, yet highly transmissive
lens obscures the view of the LEDs and creates a smooth,
even look from below. The light engine is available in
multiple Kelvin temperatures and the system is designed
to provide optimal life and lumen maintenance (50,000
hours at 70% lumen maintenance). The reflector/light
engine assembly is mechanically retained to the housing.

Order housing, reflector, and accessories separately

CATALOG NUMBER:

HOUSING

❑ LC6ML

Medium
Lumen

0-10V
Dimming to
10%

DRIVER

OPTIONS

Standard 0-10V
10% Dimming

❑ DM1

0-10V 1%

Dimming

VOLTAGE

Standard
120V-277V

❑ 347

347V

120V-277V

1

See Central Inverter compatibility note and web

links on page 4.

2

Damp location only

3

Not available in 40K or 50K

4

CP must be selected on both housing and trim

5

Not compatible with WW option

6

WW must be selected on trim

7

Not compatible with CP

8

Not compatible with WWCP

9

EM must be selected on both the housing and the trim,

not compatible with WW trim

10

IP65 and VR cannot be chosen together,

not compatible with WT, WF, or EM

HOUSING

OPTION

❑ EM

Integral Battery

7,8

❑ EMR

Remote Battery
Pack

❑ CP

Chicago

❑ WWCP

Wall Wash
Chicago

A Division of Hubbell Lighting, Inc.

2,9

Pack

2

4,5

Plenum

Plenum
Housing

BUY

Maximum Ceiling Thickness 1

LED DRIVER:

The LC6ML utilizes a constant current LED

WET

LOCATION

AMERICAN

SOLUTIONS

See Certification

driver that is capable of running both lumen
outputs, resulting in a reduction of housing
skus and simplified specification. The driver
is UL8750, Class II compliant and universal
120V-277V.

DIMMING:

Comes standard with flicker-free 0-10V
dimming to 10%. 0-10V to 1% dimming
option is also available. See list of
compatible dimmers on page (4). For the
sizing of the control circuit, the dimming

12 3/4"

circuit may require up to 1.2mA of sink
current.

INSTALLATION:

Light commercial bar hangers included (not
with WWCP option). Universal adjustable
mounting brackets also accept ½" EMT
conduit or 1½" or ¾" lathing channel (by
others) or Prescolite 24" bar hangers (B24
or B6). Wall wash orientation may be field
adjusted in 90º increments to housing.

CERTIFICATIONS:

CSA certified to US and Canadian safety

6 1/2"

standards. Suitable for wet locations
(EM, EMR & WW damp location).
This product qualifies as a “designated
country construction material” per FAR

52.225-11 Buy American-Construction.
Materials under Trade Agreements effective
6/10/2020. See Buy American Solutions.

WARRANTY:

1 1/4"

* See page 4 for LC6ML WWCP
and EM line art

5 3/4"

7"

5 year warranty. See www.prescolite.com
for details.

TRIM

-

APERTURE

❑ 6LCML

Medium
Lumen Clear
Alzak
Reflector

6

OUTPUT KELVIN CRI

2400
Lumen

3000
Lumen

❑ 27K

2700
Kelvin

❑ 30K

3000
Kelvin

❑ 35K

3500
Kelvin

❑ 40K

4000
Kelvin

❑ 50K

5000
Kelvin

❑ 8

❑ 9

❑ 24L

❑ 30L

REF. FINISH/

COLOR OPTION

Standard
Semi-Diffuse

80+

Clear Alzak

CRI

❑ WH

3

90+
CRI

EXAMPLE:

Painted
Matte
White
Reflector
and

Flange

LC6MLDM1-6LCML30L35K9WH

REFLECTOR

OPTIONS

❑ WT

Painted White
Flange only

❑ WF

Wide Flange

2,7

❑ WW

Wall Wash

4,5

❑ CP

Chicago

Plenum

2,9

❑ EM

Pre-punched
reflector to
accept integral
test switch

10

❑ IP65

Flush Lens,
IP65/66 rated

10

❑ VR

Vandal Resistant
Flush Lens,
IP65/66 rated

In a continuing effort to offer the best product possible we reserve the right to change, without
notice, specifications or materials that in our opinion will not alter the function of the product.

Web: www.prescolite.com • Tech Support: [phone]

Ceiling Cutout: 61/4"

1

/4"

For conversion to millimeters,

multiply inches by 25.4

Not to Scale

9 1/8"

- ACCESSORIES

❑ B24

Set of two(2) 24" bar
hangers for T-bar ceilings

❑ B6

Set of two (2) bar hangers for
ceiling joist up to 24" centers

❑ SCA6D_

Sloped ceiling adapter (see
note on page 4)

❑ LiteGear

Inverter, single phase central
lighting, 125VA-250VA

❑ LPS Series

LitePower micro-inverter, 20VA-

1

1

55VA

LFR-LED-043

PHOTOMETRIC DATA

NVLAP LAB CODE: 201003-0

®

45˚

60˚

75˚

90˚

NVLAP LAB CODE: 201003-0

®

PAGE: 3 OF 8

PHOTOMETRIC DATA

LiteFrame - 6" LC6ML Downlight

DRIVER DATA 6LCML24Lxxx 6LCML30Lxxx

Input Voltage 120-277V 120-277V
Input Frequency 50/60 Hz 50/60 Hz
Input Current 0.271 (120v) 0.346 (120v)

0.117 (277v) 0.150 (277v)
Input Power 32.5W 41.5W
Constant Current Output 675mA 675mA

Lumen Multiplier Table

Photometrics for the LC6ML are published below at a
nominal 3000 Kelvin temperature. This table may be
used to approximate the lumen values at different Kelvin
temperatures. Power consumption would stay the same.

Power Factor ≥0.90 ≥0.90
THD <20% <20%
EMI Filtering FCC 47CFR FCC 47CFR
Part 15, Class A Part 15, Class A
Operating Temperature -30ºC to +35ºC -30ºC to +25ºC
Dimming 0-10V to 10% 0-10V to 10%
Over-voltage, over-current, short-circuit protected

5000 Kelvin 1.14
4000 Kelvin 1.03
3500 Kelvin 1.00
3000 Kelvin 1.00
2700 Kelvin 0.91

LC6ML 6LCML24L30K8

LED Light Engine: 3000K, 80+ CRI
System Wattage: 32.5W
Fixture Delivered Lumens: 2375
Fixture Efficacy: 73.1
Spacing Criteria: 1.1

CANDELA

DISTRIBUTION

90˚

90º

DEG CANDELA

0 1642

75˚

550

75º

550

60˚

60º

5 1621
15 1501
25 1540
35 1133
45 444

1100

1100

45º

45˚

55 27
65 6
75 2

1650

1650

0˚ 15˚ 30˚

0º 15º 30º

Test No. 9495
Tested at 25ºC Ambient in accordance to IESNA LM-79-2008

LC6ML 6LCML30L30K8

LED Light Engine: 3000K, 80+ CRI

85 0
90 0

System Wattage: 41.5W
Fixture Delivered Lumens: 2993
Fixture Efficacy: 72.1
Spacing Criteria: 1.1

CANDELA

DISTRIBUTION

DEG CANDELA

0 2061

5 2040
15 1890

700

90º

75º

700

60º

25 1914

45º

35 1444
45 567
55 33
65 8
75 2
85 0

1400

1400

2100

2100

0º 15º 30º

90 0

Test No. 9430
Tested at 25ºC Ambient in accordance to IESNA LM-79-2008

ZONAL LUMEN SUMMARY

ZONE LUMENS %LUMINAIRE
0-30 1286 54.2
0-40 1976 83.2
0-60 2367 99.6
0-90 2375 100.0
90-180 0 0.0
0-180 2375 100.0

COEFFICIENTS OF UTILIZATION Zonal Cavity Method

80% 70% 50% 30% 10%

Ratio

Room Cavity

70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10

113 110 107 105 110 108 105 103 104 102 100 100 98 97 96 95 94

1

106 101 97 93 104 99 95 92 96 93 90 93 90 88 90 88 86

2

100 93 87 83 98 92 86 82 89 84 81 86 83 80 84 81 78

3

94 86 79 75 92 84 79 74 82 77 73 80 76 72 78 75 72

4

88 79 72 68 87 78 72 67 76 71 67 74 70 66 73 69 65

5

83 73 66 62 82 72 66 61 71 65 61 69 64 60 68 63 60

6

78 68 61 56 77 67 61 56 66 60 56 64 59 55 63 59 55

7

74 63 56 52 72 62 56 51 61 55 51 60 55 51 59 54 51

8

69 59 52 48 68 58 52 47 57 51 47 56 51 47 55 50 47

9

66 55 48 44 65 54 48 44 53 48 44 53 47 44 52 47

10

LC6ML 6LCML24L30K8

ZONAL LUMEN SUMMARY

ZONE LUMENS %LUMINAIRE
0-30 1609 53.7
0-40 2484 83.0
0-60 2983 99.7
0-90 2993 100.0
90-180 0 0.0
0-180 2993 100.0

COEFFICIENTS OF UTILIZATION Zonal Cavity Method

80% 70% 50% 30% 10%

Ratio

Room Cavity

70 50 30 10 70 50 30 10 50 30 10 50 30 10 50 30 10

113 110 107 105 110 108 105 103 104 102 100 100 98 97 96 95 94

1

106 101 96 93 104 99 95 92 96 93 90 93 90 88 90 88 86

2

100 93 87 83 98 91 86 82 89 84 81 86 83 80 84 81 78

3

94 86 79 75 92 84 79 74 82 77 73 80 76 72 78 75 72

4

88 79 72 68 87 78 72 67 76 71 67 74 70 66 73 69 65

5

83 73 66 61 82 72 66 61 71 65 61 69 64 60 68 63 60

6

78 68 61 56 77 67 61 56 66 60 56 64 59 55 63 59 55

7

74 63 56 51 72 62 56 51 61 55 51 60 55 51 59 54 51

8

69 59 52 47 68 58 52 47 57 51 47 56 51 47 55 50 47

9

66 55 48 44 64 54 48 44 53 48 44 52 47 43 52 47

10

LC6ML 6LCML30L30K8

LUMINANCE DATA IN CANDELA/SQ. METER

Angle in Vertical AVERAGE

45° 37467
55° 2809

65° 847
75° 461

85° 0

% Eective Ceiling Cavity Reectance

20% Eective Floor Cavity Reectance

% Wall Reectance

43

Test No. 9495

LUMINANCE DATA IN CANDELA/SQ. METER

Angle in Vertical AVERAGE

45° 47846
55° 3433

65° 1130
75° 461

85° 0

% Eective Ceiling Cavity Reectance

20% Eective Floor Cavity Reectance

% Wall Reectance

43

Test No. 9430

Web: www.prescolite.com • Tech Support: [phone]

701 Millennium Boulevard • Greenville, SC 29607 U.S.A. •

Copyright ©2018 Prescolite, Inc., a division of Hubbell Lighting, Inc. All Rights Reserved

Specifications subject to change without notice. • Printed in U.S.A. • LFR-LED-043 • 6/13/18

Phone (864)

678-1000

PHOTOMETRIC DATA

NVLAP LAB CODE: 201003-0

®

PAGE: 3 OF 8

NVLAP LAB CODE: 201003-0

®

LiteFrame - 6" LC6ML Downlight

LC6ML 6LCML24L30K8 WW

LED Light Engine: 3000K, 80+ CRI
System Wattage: 32.4W
Fixture Delivered Lumens: 2331
Fixture Efficacy: 71.9

CANDELA DISTRIBUTION

DEG 0 90 180

0 1850 1850 1850

5 1842 1907 1894
15 1594 1742 1702
25 1261 1804 1837

650

90˚

90º

75˚

75º

650

60˚

60º

35 994 936 771

1300

1300

45˚

45º

45 514 261 223
55 290 9 8
65 72 3 3

1950

1950

0˚ 15˚ 30˚

0º 15º 30º

LEGEND:

0-deg

0-deg:

90-deg

90-deg:
180-deg:

180-deg

75 12 2 2
85 1 0 0
90 0 0 0

Test No. 9496
Tested at 25ºC Ambient in accordance to IESNA LM-79-2008

LUMINANCE DATA IN CANDELA/SQ. METER

Angle in Vertical 0 DEG 90 DEG 180 DEG

45° 43374 22024 18818
55° 30169 936 832

65° 10166 424 424
75° 2767 461 461

85° 685 0 0

1’ 2’ 3’ 4’ UNITS ON UNITS ON

2.5’ DISTANCE FIXTURE MOUNTED OUT FROM WALLS

▼▼▼▼▼

1 7 4 1 0 0 7 4 7 7 1 7
2 30 20 5 1 0 32 21 32 31 9 31
3 29 21 11 2 0 33 33 33 30 22 30
4 27 24 13 5 1 38 39 38 30 26 30
5 18 17 14 7 3 31 37 31 24 29 24
6 12 12 11 8 4 29 28 29 20 24 20
7 9 8 8 7 4 26 23 26 18 18 18
8 7 6 6 6 4 21 20 21 16 14 16
9 5 5 4 4 4 17 17 17 14 12 14

LC6ML 6LCML24L30K8 WW

DISTANCE FROM CEILING IN FEET

FOOTCANDLE DISTRIBUTION ON WALL SURFACE (Direct Only)

MULTIPLE UNITS

3’ CENTER 4’ CENTER

▼▼▼ ▼▼

Test No. 9496

▼

LC6ML 6LCML30L30K8 WW

LED Light Engine: 3000K, 80+ CRI
System Wattage: 41.4W
Fixture Delivered Lumens: 2905
Fixture Efficacy: 70.2

800

800

90˚

90º

75˚

75º

60˚

60º

CANDELA DISTRIBUTION

DEG 0 90 180

0 2251 2251 2251

5 2278 2341 2329
15 1997 2175 2129
25 1565 2211 2239
35 1197 1194 1007

1600

1600

45˚

45º

45 630 332 293
55 354 13 11
65 92 5 4

2400

2400

0˚ 15˚ 30˚

0º 15º 30º

LEGEND:

0-deg

0-deg:

90-deg

90-deg:

180-deg

180-deg:

75 15 3 3

85 1 0 0
90 0 0 0

Test No. 9432
Tested at 25ºC Ambient in accordance to IESNA LM-79-2008

LUMINANCE DATA IN CANDELA/SQ. METER

Angle in Vertical 0 DEG 90 DEG 180 DEG

45° 53162 28016 24725
55° 36827 1352 1144

65° 12989 706 565
75° 3458 692 692

85° 685 0 0

1’ 2’ 3’ 4’ UNITS ON UNITS ON

2.5’ DISTANCE FIXTURE MOUNTED OUT FROM WALLS

▼▼▼▼▼

1 9 5 1 0 0 9 5 9 9 2 9
2 37 24 6 1 0 39 26 39 37 11 37
3 36 27 14 3 1 42 41 42 37 27 37
4 32 29 16 7 2 47 48 47 36 33 36
5 22 21 17 9 4 39 46 39 29 35 29
6 15 14 14 10 5 36 35 36 25 29 25
7 11 11 10 9 5 32 29 32 22 23 22
8 8 8 7 7 5 26 25 26 20 18 20
9 6 6 6 5 5 21 22 21 17 15 17

LC6ML 6LCML30L30K8 WW

DISTANCE FROM CEILING IN FEET

FOOTCANDLE DISTRIBUTION ON WALL SURFACE (Direct Only)

MULTIPLE UNITS

3’ CENTER 4’ CENTER

▼▼▼ ▼▼

Test No. 9432

▼

Web: www.prescolite.com • Tech Support: [phone]

701 Millennium Boulevard • Greenville, SC 29607 U.S.A. •

Copyright ©2018 Prescolite, Inc., a division of Hubbell Lighting, Inc. All Rights Reserved

Specifications subject to change without notice. • Printed in U.S.A. • LFR-LED-043 • 6/13/18

Phone (864)

678-1000

PHOTOMETRIC DATA

LiteFrame - 6" LC6ML Downlight

Dimming Compatibility Table

Dimming Ballast Manufacturer Web Link

DM/DM1 Lutron DVTV
DM/DM1 Leviton AWRMG-7xx,

http://bit.ly/11jSvZg
http://bit.ly/1BJn2R9

AWSMG-7xx,

AWSMT-7xx

Central Inverters

For full fixture output in back-up mode, we recommend you visit www.dual-lite.com for your Central Lighting Inverter options. Please contact your local
Hubbell representative for any assistance with proper sizing and loading of your inverter selection. Central lighting inverters must be ordered separately.

LiteGear: www.dual-lite.com/products/litegear_lg_series
LPS Series: www.dual-lite.com/products/lps

SCA6D_

When ordering a sloped ceiling adapter, specify the degree of slope in 1º increments, maximum of 35º. For a more precise degree or wet ceiling
applications, please contact factory. Sloped ceiling adapter and housing must be installed at the same time.

11-3/4"

15-1/4"

5"

11"

14-1/2"

7-1/4"

5-3/4"

7"

LC6ML WWCP LC6ML EM

1-1/4"

Web: www.prescolite.com • Tech Support: [phone]

701 Millennium Boulevard • Greenville, SC 29607 U.S.A. •

Copyright ©2018 Prescolite, Inc., a division of Hubbell Lighting, Inc. All Rights Reserved

Specifications subject to change without notice. • Printed in U.S.A. • LFR-LED-043 • 6/13/18

Phone (864)

678-1000
