Peerless-AV PLA60-UNLP User Manual

Installation and Assembly:

Articulating Swivel Arm for 37" - 60" Flat Panel Displays

Models: PLA60, PLA60-S, PLAV60, PLAV60-S

Max UL Load Capacity:

175 lb (79 kg)

2300 White Oak Circle • Aurora, Il 60502 • [phone] • Fax: [phone] • www.peerlessmounts.com

ISSUED: 05-02-06 SHEET #: 202-9112-4 06-01-11

Note: Read entire instruction sheet before you start installation and assembly.

WARNING

•Do not begin to install your Peerless product until you have read and understood the instructions and warnings contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, for US customers please call Peerless customer care at 1-800-865-2112, for all international customers, please contact your local distributor.

•This product should only be installed by someone of good mechanical aptitude, has experience with basic building construction, and fully understands these instructions.

•Make sure that the supporting surface will safely support the combined load of the equipment and all attached hardware and components.

•Never exceed the Maximum Load Capacity. See page one.

•If mounting to wood wall studs, make sure that mounting screws are anchored into the center of the studs. Use of an "edge to edge" stud fi nder is highly recommended.

•Always use an assistant or mechanical lifting equipment to safely lift and position equipment.

•Tighten screws fi rmly, but do not overtighten. Overtightening can damage the items, greatly reducing their holding power.

•This product is intended for indoor use only. Use of this product outdoors could lead to product failure and personal injury.

•This product was designed to be installed on the following wall construction only;

WALL CONSTRUCTION		HARDWARE REQUIRED
•	Wood Stud	Included
•	Wood Beam	Included
•	Solid Concrete	Included
•	Cinder Block	Included
•	Metal Stud	Do not attach except with Peerless Metal Stud Accessory Kit
		(not evaluated by UL)
•	Brick	Contact Qualifi ed Professional (not evaluated by UL)
•	Other or unsure?	Contact Qualifi ed Professional

Tools Needed for Assembly

•stud fi nder ("edge to edge" stud fi nder is recommended)

•drill

•3/16" (5mm) drill bit for wood studs

•3/8" (10mm) masonry drill bit for concrete

•7/16" socket wrench with extension (recommended)

•level

•phillips screwdriver

Accessories

• External Wall Plate (WSP716, WSP716-S, WSP724, WSP724-S) (Metal Stud not evaluated by UL)

Table of Contents
Parts List............................................................................................................................................................................	3, 4
Installation to Double Wood Stud Wall ...................................................................................................................................	5
Installation to Solid Concrete or Cinder Block ........................................................................................................................	6

2 of 10

ISSUED: 05-02-06 SHEET #: 202-9112-4 06-29-11

Before you start make sure all parts listed are included with your product.

Parts List

				PLA60	PLA60-S	PLAV60	PLAV60-S
		Description	Qty.	Part #	Part #	Part #	Part #
	A	wall plate	1	201-1040	201-4040	201-1040	201-4040
	B	tilt-roll assembly	1	201-1093	201-4093	201-1048	201-4048
	C	arm assembly	1	201-1072	201-4072	201-1049	201-4049
	D	wall support arm axle	1	201-1041	201-1041	201-1041	201-1041
	E	vinyl trim	3	600-1012	600-1012	600-1012	600-1012
	F	M10 x 1.5 x 15 mm screw bolt	8	520-9262	520-9262	520-9262	520-9262
	G	.505 x .75 x .062" nylon washer	1	540-1074	540-1074	540-1074	540-1074
	H	tilt adjustment knob	1	560-0108	560-0108	560-0108	560-0108
	I	carriage bolt 3/8"-16 x 3.25"	1	520-1315	520-1315	520-1315	520-1315
	J	1.525 x 2 x .062" delrin washer	2	540-1070	540-1070	540-1070	540-1070
	K	#8-32 x .375" socket head cap screw	1	520-1210	520-1210	520-1210	520-1210
	L	plastic finishing cap	8	590-1123	590-1123	590-1123	590-1123
	M	holding pin	1	580-1166	580-1166	580-1166	580-1166
	N	retainer plug	1	590-1007	590-1007	590-1007	590-1007
	O	5/16 x 3" wood screw	8	520-1243	520-1243	520-1243	520-1243
	P	.250 x 1 x .068" washer	8	540-1063	540-1063	540-1063	540-1063
	Q	9/64" allen wrench	1	560-9728	560-9728	560-9728	560-9728
	R	cable management clips	4	590-1166	590-1166	590-1166	590-1166
	S	cable tie	4	590-1168	590-1168	590-1168	590-1168
	T	36" polyester mesh sleeve	1	600-1015	600-1015	600-1015	600-1015
	U	6 mm allen wrench	1	560-9716	560-9716	560-9716	560-9716
	V	10 mm allen wrench	1	n/a	n/a	560-9727	560-9727
	W	concrete anchor	8	590-0321	590-0321	590-0321	590-0321

Some parts may appear slightly different than illustrated.

	A	B	C	D E	F	G
				K	L	M
	H		I	J
N	O	P		R		S
				Q

W

T

U	V

3 of 10

ISSUED: 05-02-06 SHEET #: 202-9112-4 06-29-11
