AG-CX350
Memory Card Camera Recorder
High-End 1.0-type Handheld Camcorder with 4K/HDR/10-bit Capabilities.
Supports IP Control, NDI | HX and RTMP Streaming.
A NEW CX SERIES 4K CAMCORDER DELIVER NEXT
4K/HDR 10-BIT REC
4K (UHD)/10-bit/60p High-Quality Image Acquisition
and HDR-Compliant HLG (Hybrid Log-Gamma)
WIDE-ANGLE LENS
24.5 mm at the Wide End with a 20x Optical Zoom Lens
Panasonic developed the new CX Series of handheld camcorders, spearheaded by the
AG-CX350, to fuse video, on-air broadcasting, and communication for the next
generation. The AG-CX350 features 4K/UHD resolution, 10-bit depth, HDR-compatible
image quality, and a host of recording formats for the ultimate creativity in a compact,
lightweight body with low power consumption. It is also equipped with an RTSP/RTMP/
RTMPS function for live streaming and NDI | HX-ready IP connectivity, to serve as a live
camera, and clearly expands the usability of the handheld camcorder beyond
conventional news gathering and recording applications to meet a wide range of
professional needs.
2
GENERATION CREATIVITY AND CONNECTIVITY
LIVE STREAMING
HD Streaming Distribution Possible While Recording.
RTSP/RTMP/RTMPS Streaming Methods Supported.
NDI|HX CONNECT
Industry-First NDI| HX Compatibility* Via Camcorder.
Transmission/Remote Support by IP Connection.
* Recording, streaming and 4K output are not available when using NDI | HX mode. Industry’s first camcorder to support NDI | HX. As of June 2019 (according to a Panasonic survey).
To use this function, an activation keycode from NewTek is required. Keycodes can be purchased from the following website: http://new.tk/ndi_panasonic
3
The Wide-Angle Lens, New 1.0-type Sensor and High-Quality Pictures in 4K/HDR
Wide-Angle 24.5 mm*1 Optical 20x Zoom, Plus i.Zoom
An image shot in a room using the wide angle.
Panasonic boasts the world’s largest market share in the aspherical
lens segment. Its cutting-edge optical technology was maximized in
the development of the integrated lens used in the AG-CX350. This
lens has the industry’s widest angle of 24.5 mm*1 on the wide end
and allows recording of wide-angle images with minimal distortion,
without the use of a conversion lens. The optical 20x zoom covers
up to 490 mm telephoto in all modes. Furthermore, the i.Zoom
enables seamless zooming of up to 32x in HD or up to 24x in UHD
from the telephoto end with no degradation in resolution. The
AG-CX350 also comes with digital
2x/ 5x/ 10x zoom.
*1: In 35 mm equivalent. The AG-CX350’s wide
24.5 mm angle is the widest in the industry for
UHD/FHD (16:9). In the segment of
camcorders with integrated lens, the
Panasonic AG-UX180 achieved the industry’s
widest angle of 24 mm in UHD/24p (17:9). For
UHD/FHD (16:9), 25.4 mm is the widest angle
in the industry. (Both As of June 2019,
according to a Panasonic survey)
*2: When using the digital zoom, picture
quality degrades as the magnification rate
increases.
*2
HDR-Compliant HLG (Hybrid Log-Gamma)
HDR (High Dynamic Range) Image
The AG-CX350 features HLG (Hybrid Log-Gamma)* to support HDR
(High Dynamic Range). This achieves a wide dynamic range on
HDR-compatible TV monitors. The gamma mode can be selected
from eight modes (HD, SD, FILMLIKE 1, FILMLIKE 2, FILMLIKE 3,
FILM-REC, VIDEO-REC, HLG).
* The HLG specification was developed jointly by Japanese broadcaster NHK and the BBC
in the UK. It is defined in ARIB STD-B67 and ITU Rec. 2100.
New High-Definition, High-Sensitivity
1.0-type 15M MOS Sensor
The 1.0-type MOS (approximately
15,030,000 pixels) offers an
outstanding depth of field and
excellent balance between image
quality and sensitivity. It supports
multi-formats, such as UHD (3840
x 2160), FHD, HD and SD, and
provides images without cropping
in all modes. This MOS sensor also
boasts high sensitivity of F12 (60
Hz) /F13 (50 Hz) (in both UHD and
FHD in High Sensitivity mode).
Side Operation
4
Control Functions for Light, Smart Camera Work
Manfrotto
MVR901ECLA
Libec
ZFC-L
VariZoom
VZ-STEALTH
CX ROP
Download on the
App Store
CX ROP
CX ROP
Built-in 5-Axis Hybrid Image Stabilizer
1. Roll
5. Yaw
2. X
4. Pitch
3. Y
5-Axis Hybrid Image Stabilize
The AG-CX350 has a built-in hybrid image stabilizer that combines
optical and electronic camera shake compensation functions.
It corrects camera shake in five axial directions in all modes* including
UHD to provide powerful camera shake compensation power in
low-angle shooting, high-angle shooting and all other unstable
conditions. There are three modes to choose from: NORMAL
(standard), STABLE (effective for fixed-frame shooting) and PAN/TILT
(effective in panning and tilting).
* Excluding Super Slow and VFR modes.
Intelligent AF and Focus Assist
The AG-CX350’s auto focus system is Intelligent AF, which is
equipped with a micro drive focus unit to achieve high focusing
speed, excellent tracking performance and superb stability.
The AG-CX350 is also equipped with Expand and Peaking
(simultaneous display possible), Manual Focus Assist, LCD Touch
Focus (switchable to Auto Iris or brightness display) and One-Push
AF Focus Assist.
Cabled/Wireless Remote Control Capability
Example of Third-party Remote Controller
• Wired Remote Control with a Third-Party Controller
The remote terminal (2.5 mm super mini jack) enables the control of
the focus and zoom using a remote controller (third-party product).
• Wireless Control from a Tablet or Smartphone
The AG-CX350 can be controlled remotely and wirelessly using a
tablet/smartphone app*1 (downloadable for free from the App Store
or Google Play). In addition to zoom, i.Zoom and focus lens control,
the app enables remote control of various other functions, including
camera setting, picture quality adjustment, REC start/stop and
menu setting. What’s more, the app can be used to select the
camera to control from up to eight cameras.
*2
Manual Three Rings
The AG-CX350 comes with
Manual Three Rings for zoom,
focus and iris control. They deliver
quick response and provide tactile
feel that satisfies professionals.
The zoom lever located at the
upper section of the handle has a
multi-step variable zoom function,
allowing smooth zooming from
ultra-low speed when shooting
from low angle shooting and when
a tripod is used.
Manual Three Rings
* Pictures simulated.
* Pictures simulated.
Download on the
App Store
*1: iPad: iOS 9 or later are supported. Android devices: Android 5.0 or later are supported.
Wireless module (sold separately; AJ-WM50 or recommended third-party Wi-Fi dongle) is
required.
•2: The app does not support simultaneous/synchronous control of multiple cameras.
Camera switching takes several seconds.
5
Multi-Codec Recording of High-Quality 10-bit Images without Cropping
New HEVC Codec for High-Image-Quality
10-bit Variable Frame Rate (VFR) without Cropping
10-bit UHD/60p Recording at Low Bit Rate
The AG-CX350 is capable of recording in various formats at different
compression rates (see the table below). It can record UHD/60p
videos in high-image-quality 10-bit on an SD memory card. It also
features a new, high-efficiency HEVC codec (LongGOP, 10-bit, 4:2:0,
MOV) . When a PC with 7th Generation
Intel Core i7 processor is used, the
hardware acceleration enables native
decoding and playback. Free software,
such as VLC Media Player or QuickTime
Player, provides smooth playback on a
notebook PC or MacBook with Intel
Core i7 processor.*
* Playback may lack
smoothness depending
on the PC environment,
such as storage and
memory devices.
In UHD, variable frame rate (VFR) recording at 1 fps to 60 fps is
MOV/AVCHD/P2 MXF* File Formats Supported
The AG-CX350 records MOV files that are highly compatible and
easy to use. This file format is the same as that used on Panasonic’s
compact cinema camera, the AU-EVA1, and supports file names
with up to 20 characters, allowing recorded video clips to be easily
managed. The AG-CX350 also supports conventional AVCHD
recording, including the AVCHD 8 Mb/s mode, used widely as the
format in college and professional football coaching analysis.
And it will support the MXF P2 file format for broadcasting, enabling
possible. In FHD, super-slow can be realized at a maximum of 120
fps. Both provide high-quality 10-bit, full-frame pictures with no
image area cropping even at high frame rates.
Freeze Frame (Still Image Capture)
When playing back video clips on the AG-CX350, any desired frame
can be captured as a still image (JPEG) and recorded onto an SD
memory card. Video playback, frame advance (+/-), and still-image
captures can all be done intuitively by touch panel operation.
AVC-Intra or AVC-LongG HD recording.*
* AVC-Intra200/100/50 codec will be supported in the future. Use a microP2 card for
recording in P2 format.
Recording Format
Recording Format Pixels
MOV
(HEVC)
MOV
(AVC)
AVCHD
P2*1
(MXF)
*1: AVC-Intra200/100/50 codec will be supported in the future. *2: The bit rate increases to two times when recorded in 59.94p or 50p. *3: VFR is supported only in Progressive mode. Square
brackets [ ] indicate a system frequency of 50.00 Hz.
6
HEVC LongGOP 200M 3840 x 2160 4:2:0 10 bit 200 Mbps (VBR) 59.94p, 50p
HEVC LongGOP 150M 3840 x 2160 4:2:0 10 bit 150 Mbps (VBR) 29.97p, 25p, 23.98p
HEVC LongGOP 100M 3840 x 2160 4:2:0 10 bit 100 Mbps (VBR) 59.94p, 50p
UHD
422ALL-I 400M 3840 x 2160 4:2:2 10 bit 400 Mbps (VBR) 29.97p, 25p, 23.98p 1 to 30 fps [25 fps]
422LongGOP 150M 3840 x 2160 4:2:2 10 bit 150 Mbps (VBR) 29.97p, 25p, 23.98p 1 to 30 fps [25 fps]
420LongGOP 150M 3840 x 2160 4:2:0 8 bit 150 Mbps (VBR) 59.94p, 50p
420LongGOP 100M 3840 x 2160 4:2:0 8 bit 100 Mbps (VBR) 29.97p, 25p, 23.98p
422ALL-I 200M 1920 x 1080 4:2:2 10 bit 200 Mbps (VBR) 59.94p, 50p
422ALL-I 100M 1920 x 1080 4:2:2 10 bit 100 Mbps (VBR)
422LongGOP 100M 1920 x 1080 4:2:2 10 bit 100 Mbps (VBR) 59.94p, 50p
FHD
422LongGOP 50M 1920 x 1080 4:2:2 10 bit 50 Mbps (VBR)
PS 1920 x 1080 4:2:0 8 bit 25 Mbps (VBR) 59.94p, 50p —
PH 1920 x 1080 4:2:0 8 bit 21 Mbps (VBR) 23.98p, 59.94i, 50i —
HA 1920 x 1080 4:2:0 8 bit 17 Mbps (VBR) 59.94i, 50i —
HD PM 1280 x 720 4:2:0 8 bit 8 Mbps (VBR) 59.94p, 50p —
SD SA
AVC-Intra200*
AVC-Intra100*
AVC-Intra422 1920 x 1080 4:2:2 10 bit 200 Mbps (59.94p) 59.94p, 50p —
FHD
AVC-LongG50 1920 x 1080 4:2:2 10 bit 50 Mbps (59.94i) (VBR) 59.94i, 50i —
AVC-LongG25 1920 x 1080 4:2:2 10 bit 25 Mbps (59.94i)*2 (VBR) 59.94p, 50p, 59.94i, 50i —
AVC-LongG12 1920 x 1080 4:2:0 8 bit 12 Mbps (59.94i)*2 (VBR) 59.94p, 50p, 59.94i, 50i —
AVC-Intra200*
AVC-Intra100*
AVC-Intra50*
HD
AVC-LongG50 1280 x 720 4:2:2 10 bit 50 Mbps (59.94p) (VBR) 59.94p, 50p —
AVC-LongG25 1280 x 720 4:2:2 10 bit 25 Mbps (VBR) 59.94p, 50p —
AVC-LongG12 1280 x 720 4:2:0 8 bit 12 Mbps (VBR) 59.94p, 50p —
1
1
1
1
1
720 x 480 (59.94i)
720 x 576 (50i)
1920 x 1080 4:2:2 10 bit 200 Mbps (59.94i) 59.94i, 50i —
1920 x 1080 4:2:2 10 bit 100 Mbps (59.94i)*
1280 x 720 4:2:2 10 bit 200 Mbps (59.94p) 59.94p, 50p —
1280 x 720 4:2:2 10 bit 100 Mbps (59.94p) 59.94p, 50p —
1440 x 1080 4:2:0 10 bit 50 Mbps (59.94i) 59.94i, 50i —
1280 x 720 4:2:0 10 bit 50 Mbps (59.94p) 59.94p, 50p —
Color
Sampling
4:2:0 8 bit 9 Mbps (VBR) 59.94i, 50i —
Bit
Bit Rate File Format VFR*
Depth
2
Simulated Image
29.97p, 25p, 23.98p,
59.94i, 50i
29.97p, 25p, 23.98p,
59.94i, 50i
59.94p, 50p, 59.94i, 50i —
3
1 to 60 fps [50 fps]
(Max. 200 Mbps)
1 to 60 fps [50 fps]
(Max. 150 Mbps)
1 to 60 fps [50 fps]
Super Slow:
120 fps [100 fps]
(Max. 400 Mbps)
1 to 60 fps [50 fps]
Super Slow:
120 fps [100 fps]
(Max. 200 Mbps)
Audio
24 bit
LPCM
Dolby
Audio
24 bit
LPCM
16 bit
LPCM
24 bit
LPCM
16 bit
LPCM
Recording Recording
Recording Recording
Card Exchange
Card Exchange
Recording
Recording
Slot1
Slot2
Slot1
Slot2
Recording Recording
Recording Recording
Card Exchange
Card Exchange
Slot1
Slot2
High-Quality Image and Sound Functions for Maximum Creativity
Broadcast-Grade Picture Quality Adjustment Functions
R
Phase
Adjustment
Saturation
Adjustment
(YI-R)-R
(YI-R)
YI-(YI-R)
YI Mg
(G-YI)-YI
(G-YI)
G
(Cy-G)
Adjustment
is individually
possible to
16 axes.
Cy
R-(R-Mg)
(R-Mg)
(B-Cy)
Before
(Mg-B)
B
After
16-Axis Independent Color Correction Illustration
• 16-Axis Independent Color Correction: Provides an independent
effect to each of the 16 phases of video images. It enables color
matching of multiple cameras under the same lighting conditions as
well as creative image rendering.
• Master Detail: Adjusts the overall degree of contour enhancement.
• Skin Detail: Makes skin colors appear soft and beautiful.
• Scene Files: Six preset files are provided. You can change any of
the settings as desired.
• Other Picture Settings: Matrix tables, V detail, detail coring,
chroma level, chroma phase, color temperature, master pedestal
and knee.
24-bit PCM Audio 4-Channel Recording
The AG-CX350 enables 4-channel recording using the built-in
microphone (2-channels) and XLR (2-channels)*1. In MOV or P2 MXF
mode, 24-bit linear PCM recording delivers higher sound quality.
Other audio features include manual volumes, OSD level meter, 1
kHz test tone output*2 and headphone output
(3.5 mm-diameter stereo mini jack).
*1: When MOV or P2 MXF is selected as the main recording format. In AVC-LongG12 mode,
only 16-bit LPCM 4-channel recording is supported. And in AVCHD mode, only 2-channel
recording is possible.
*2: This output is produced when the color bar is displayed. When the 50 Hz system
frequency is selected, the output is 997 Hz.
Simultaneous Display on High-Brightness,
High-Definition LCD and High-Resolution OLED EVF
LCD Monitor Screen While Shooting (Pictures simulated)
The AG-CX350 features a new 3.2-type high-definition LCD monitor
(approximately 1,620,000 dots). This LCD monitor uses the RGBW
(red, green, blue, white) pixel structure to provide high visibility even
in bright sunlight. The 3:2 aspect ratio enables the display of
timecode and camera status without superimposing on the image.
The touch panel function allows convenient touch focus and menu
setting. The viewfinder is a high-resolution color OLED (approximately
2,360,000 dots, with an image display area of approximately
1,770,000 dots) that offers superb color reproduction. Since the
AG-CX350 newly supports simultaneous LCD and EVF outputs, the
LCD monitor can display the captured image at all times even when
you look away from the EVF.
Double Memory Card Slots Improve Recording Reliability
Two SD memory card slots capable of using SDXC/SDHC/microP2
cards*1 enable unlimited*2 relay recording by simply changing SD
memory cards. Recording reliability is further improved with
simultaneous recording and background recording. And the
AG-CX350 is equipped with Pre Rec, Interval Rec and Time Stamp
recording functions.
*1 For memory card usage conditions, see the “Recording Media” chart on page 11.
*2 If the Relay recording time reaches 10 hours, shooting will temporarily stop, and then
automatically restart a few seconds later. If it is recorded in MOV format, the file will be split
every 3 hours and recorded.
Unlimited Relay Recording
Automatically records
continuously from Slot 1 to
Slot 2. By changing a full card
with a new card, images can
be recorded continuously for
many hours.
Simultaneous Recording
Identical data is recorded
onto cards in both slots in this
dual recording mode.
Background Recording
Records ordinary Rec Start/
Stop-controlled data in Slot 1,
and records all data, even when
Slot 1 is stopped, in Slot 2.
Slot1
Slot2
Slot1
Slot2
Slot1
Slot2
Recording Recording
Card Exchange
Card Exchange
Recording Recording
Recording
Recording
Scene 1 Scene 3Scene 2
Regular Recording
Rear Terminal
7
Advanced System Functions Supporting Live Streaming and IP Connection
RTSP/RTMP/RTMPS-Compatible HD Streaming
HD streaming is possible while images are
being acquired.*1 RTSP, RTMP and RTMPS
streaming methods are compatible.*2 And
Facebook, YouTube, and other streaming
services are supported. The AG-CX350 can be
used for live coverage of concerts and sports
events as well as for live streaming of breaking
news. Multicast streaming is also supported.
*1: There are some conditions under which streaming is not
possible, such as when recording in UHD format or using NDI|HX
mode. Please see the Operating Instruction Manual for details.
*2: The P2 Network Setting Software is convenient for setting up
the RTMP and RTMPS functions. See the section, “Connectivityverified live video services,” for the live video streaming services
that have been confirmed to be compatible.
Easy IP Connection: NDI | HX Capable —
Operating Instruction
Manual
Connectivity-verified
Live Video Services
NDI | HX is enabled when optional NDI | HX licence is
purchased from NewTek
The AG-CX350 is the industry’s first camcorder to support NDI | HX.*
Equipped with NDI | HX mode, it allows video transmission and
camera control via IP connection, without using an external
converter. When connected to a system configured with the
AV-HLC100 Live Production Center and HN/UN series PTZ
integrated cameras, the AG-CX350 realizes end-to-end live video
production of live events as well as web distribution.
• NDI | HX, a technology of NewTek, Inc.
* Recording, streaming and 4K output are not available when using NDI | HX mode.
Industry’s first camcorder to support NDI | HX. As of June 2019 (according to a Panasonic
survey). To use this function, an activation keycode from NewTek is required. Keycodes can
be purchased from the following website: http://new.tk/ndi_panasonic
TC Synchro Multi-Camera Recording Supported
The TC IN/OUT terminal (BNC) allows synchronization of the time
code in multi-camera shooting. The camera number (A to Z) can be
added* to the name of the recording folder to facilitate editing.
* Only when the MOV codec is used for recording. Setting must be made in each camera.
4K Monitor/Recorder
HDMI
AG-CX350 Live Switcher
Parallel Output of SDI and HDMI
SDI and HDMI can be output in parallel. Output of UHD video via
HDMI and output of HD video in high-image-quality 10-bit, 4:2:2 via
SDI enable a variety of uses. In HLG shooting, either HDR or SDR
can be selected for each of the SDI, HDMI and LCD video outputs.
Low Power Consuming, Large-Capacity Battery, Quick Charge
The AG-CX350 boasts low power consumption of 11.5 W (in factory
setting, with no devices connected to the terminals), which is the
industry’s lowest in the UHD/HD 10-bit recording professional
camcorder segment. The maximum power consumption is only 17 W
(HEVC recording, LCD turned ON, devices connected to the
terminals).*1 With the supplied battery pack (5900 mAh), the AG-CX350
operates continuously for about 3 hours and 20 minutes. This largecapacity battery pack supports quick charges.*2 For product details,
see page 6.
*1: As of October 2019. According to a Panasonic survey.
*2 Quick charge is possible only when the AG-BRD50 battery charger is used.
Workflow
Live Video Streaming System
AG-CX350
NDI | HX Multi-Camera Live Production System
Monitor
HDMI
Remote Controller
(Focus, Zoom)
REMOTE
LAN
USB
* Wired LAN and Wi-Fi network
cannot be operated simultaneously.
LAN
(NDI | HX)
Wireless Module
AW-UE150W/K, AW-UN70W/K,
AW-HN130W/K, AW-HN70HW/HK
NDI | HX Compatible Remote Camera
Fixed Broadband Terminal
5G/4G Wi-Fi
Mobile Router
PC for CG Material
Hub
AV-HLC100
Live Production Center
Internet
iPad/Android
(CX ROP App)
Internet
Live Streaming System
Live Streaming System
8
Options
As of October, 2019
AG-VBR118G (11,800 mAh)
Battery Pack
VW-VBD58 (5,800 mAh)
Battery Pack
AG-VBR89G (8,850 mAh)
Battery Pack
AG-B23
Battery Charger
AG-VBR59 (5,900 mAh)
Battery Pack
AG-BRD50
Battery Charger
Available Battery Pack
Battery Voltage/Capacity Charge Time
AG-VBR59
(bundle)
AG-VBR89G 7.28 V 8850 mAh 65 Wh
AG-VBR118G 7.28 V 11800 mAh 86 Wh
VW-VBD58 7.2 V 5800 mAh 42 Wh
*When using bundled battery charger.
7.28 V 5900 mAh 43 Wh
Approx.
3 hours 20 min.
Approx.
4 hours
Approx.
4 hours 40 min.
Approx.
5 hours 20 min.
Continuous
Shooting Time
Approx.
3 hours 20 min.
Approx.
5 hours
Approx.
6 hours 40 min.
Approx.
3 hours 10 min.
AG-MC200G
XLR Microphone
AJ-P2M064BG
Memory Card “microP2 card B series”
AJ-WM50
Wireless Module
*Not available in some areas
SDHC/SDXC Memory Card *
* UHS Speed Class 3 (U3) SD memory card
is necessary for video recording of 100
Mbps or more. UHS Speed Class 3 (U3)
SDXC memory card of 64 GB or more is
necessary for video recording of
UHD2160/59.94p/50.00p 150 Mbps.
Connection confirmed wireless module
(including third-party products)
https://pro-av.panasonic.net/en/sales_o/p2/
server/wireless_module.html
9
Specifications
General
Power: DC 7.28 V (when the battery is used)
DC 12 V (when the AC adaptor is used)
Power Consumption: 17 W (when the LCD monitor is used)
11.5 W (1080i / 422ALL-I 100M recording, when the LCD
monitor is used, no external device connection)
Operating Temperature
Operating Humidity: 10 % to 80 % (no condensation)
Weight: Body: approx. 1.9 kg (4.19 lb)
(body only, excluding lens hood, battery, and accessories)
Shooting: approx. 2.3 kg (5.07 lb)
(including lens hood, battery, and microphone holder)
Dimensions: 180 mm (W) x 173 mm (H) x 311 mm (D)
(7-1/8 inches x 6-13/16 inches x 12-1/4 inches)
(excluding protrusion and eye cup)
Camera Unit
Pickup Device: 1.0-type (eective size) MOS solid state image sensor
Eective Pixels: 15,030,000 pixel
Lens: Optical image stabilizer lens, optical 20x motorized zoom
F value: F2.8 to F4.5
Focal length: f=8.8 mm to 176 mm
35 mm equivalent: 24.5 mm to 490 mm
Filter Diameter: 67 mm
ND Filter: Clear, 1/4, 1/16, 1/64
IR Filter: Incorporates the ON/OFF control function
Shortest Shooting Distance (M.O.D.):
Approx. 10 cm (W), 1.0 m (T) from the front lens
Gain Setting: L/M/H selector switch
–3 dB to 18 dB (Adjustable in 1 dB steps)
24 dB, 30 dB, 36 dB switched
(when assigning [S. GAIN] to the USER button)
Color Temperature Setting:
ATW, ATW LOCK, A ch, B ch,
preset 3200 K/preset 5600 K/VAR (2000 K to 15000 K)
Shutter Speed: When [SYSTEM MODE] = 59.94 Hz
• 59.94i/59.94p mode:
1/60 sec. (shutter o), 1/100 sec., 1/120 sec., 1/250 sec.,
1/500 sec., 1/1000 sec., 1/2000 sec., 1/4000 sec.,
1/8000 sec., 1/10000 sec.
• 29.97p mode:
1/30 sec., 1/50 sec. (shutter o), 1/60 sec., 1/100 sec.,
1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec.,
1/4000 sec., 1/8000 sec., 1/10000 sec.
• 23.98p mode:
1/24 sec., 1/48 sec., 1/50 sec. (shutter o), 1/60 sec.,
1/100 sec., 1/120 sec., 1/250 sec., 1/500 sec.,
1/2000 sec., 1/4000 sec., 1/8000 sec., 1/10000 sec.
When [SYSTEM MODE] = 50.00 Hz
• 50i/50p mode:
1/50 sec. (shutter o), 1/60 sec., 1/100 sec., 1/120 sec.,
1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec.,
1/4000 sec., 1/8000 sec., 1/10000 sec.
• 25p mode:
1/25 sec., 1/50 sec. (shutter o), 1/60 sec., 1/100 sec.,
1/120 sec., 1/250 sec., 1/500 sec., 1/1000 sec., 1/2000 sec.,
1/4000 sec., 1/8000 sec., 1/10000 sec.
Shutter Speed: When [SYSTEM MODE] = 59.94 Hz
(Slow Shutter) • 59.94i/59.94p mode: 1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec.,
1/15 sec., 1/30 sec.
• 23.98p mode: 1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/12 sec.
When [SYSTEM MODE] = 50.00 Hz
• 50i/50p mode: 1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec.,
1/12 sec., 1/25 sec.
• 25p mode: 1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/12 sec.
Shutter Speed: When [SYSTEM MODE] = 59.94 Hz
(Synchro Scan) • 59.94i/59.94p mode: 1/60.0 sec. to 1/7200 sec.
• 29.97p mode: 1/30.0 sec. to 1/7200 sec.
• 23.98p mode: 1/24.0 sec. to 1/7200 sec.
When [SYSTEM MODE] = 50.00 Hz
• 50i/50p mode: 1/50.0 sec. to 1/7200 sec.
• 25p mode: 1/25.0 sec. to 1/7200 sec.
Shutter Open Angle: 3.0 deg to 180.0 deg to 360.0 deg (in 0.5 deg steps)
: 0 °C to 40 °C (32 °F to 104 °F)
1/1000 sec.,
• 29.97p mode: 1/1 sec., 1/2 sec., 1/4 sec., 1/6 sec., 1/15 sec.
* AVC-Intra200/100/50 codec will be supported in the future.
VFR Recording Frame Rate:
When [SYSTEM MODE] = 59.94 Hz
1, 2, 4, 6, 9, 12, 15, 18, 20, 21, 22, 24, 25, 26, 27, 28, 30, 32,
34, 36, 40, 44, 48, 54, 60 (fps)
When [SYSTEM MODE] = 50.00 Hz
1, 2, 4, 6, 9, 12, 15, 18, 20, 21, 22, 23, 24, 25, 26, 27, 28, 30,
32, 34, 37, 42, 45, 48, 50 (fps)
Super Slow Recording
1920 x 1080 (FHD): shooting frame rate 120 fps
When [SYSTEM MODE] = 50.00 Hz
1920 x 1080 (FHD): shooting frame rate 100 fps
Sensitivity: When [HIGH SENS.] mode
F13 (2000 lx, 3200 K, 89.9 % reect, 2160/50p, 1080/50i)
Horizontal Resolution: 2000 TV or higher (UHD: center)
1000 TV or higher (FHD: center)
i.Zoom: x 32 (FHD), x 24 (UHD)
Digital Zoom: x 2/ x 5/ x 10
Lens Hood: Hood with lens cover
: When [SYSTEM MODE] = 59.94 Hz
F12 (2000 lx, 3200 K, 89.9 % reect, 2160/59.94p, 1080/59.94i)
Memory Card Recorder
Recording Media: SDHC memory card (4 GB to 32 GB),
SDXC memory card (32 GB to 128 GB)
UHS-I/UHS-II UHS Speed Class 3 supported,
Video Speed Class V90 supported
microP2 card (A series, B series)
Please see page 11 for the “Available Memory Card” table.
Recording Slot: microP2/SDXC UHS-II card slot x 2
Recording Pixels: 3840 x 2160 (UHD), 1920 x 1080 (FHD),
1440 x 1080 (HD)*, 1280 x 720 (HD),
720 x 480 (SD), 720 x 576 (SD)
System Frequency: 59.94 Hz/50.00 Hz
Recording File Format: MOV (AVC), MOV (HEVC), AVCHD, P2 MXF
Recording Format: Please see page 6 for the “Recording Format” table.
Recording Time: Please see page 11 for the “Recording Time” table.
2 Slot Functions: Relay Rec, Simultaneous Rec, Background Rec
Special Recording Functions:
Pre Rec, Interval Rec, Time Stamp
Digital Video
Quantization: MOV: 4:2:2 10 bit/4:2:0 8 bit/4:2:0 10 bit (HEVC)
AVCHD: 4:2:0 8 bit
P2: 4:2:2 10 bit/4:2:0 10 bit (AVC-intra50)*/
4:2:0 8 bit (AVC-LongG12)
Video Compression Format:
MOV: H.264/MPEG-4 AVC High Prole
H.265/MPEG-H HEVC Main10 Prole
P2: AVC-Intra422/AVC-LongG 50/AVC-LongG 25/
AVC-LongG 12： MPEG-4 AVC/H.264 High Prole
P2*: AVC-Intra200/AVC-Intra100/AVC-Intra50：
MPEG-4 AVC/H.264 Intra Prole
Digital Audio
Recording Audio Signal
AVCHD: 48 kHz/16 bit, 2 ch, Dolby Audio™
P2: 48 kHz/24 bit, 4 ch, Linear PCM
Headroom: 12 dB/18 dB/20 dB switchable (menu)
: MOV: 48 kHz/24 bit, 4 ch, Linear PCM
(In AVC-LongG12, 48 kHz/16 bit, 4 ch)
Live Streaming
Video Compression Format:
H.264/MPEG-4 AVC Main Prole, High Prole
Video Resolution: 1920 x 1080 (FHD), 1280 x 720 (HD),
640 x 360, 320 x 180
Streaming Method: Unicast, Multicast
Frame Rate: System frequency = 59.94 Hz: 24 fps, 30 fps, 60 fps
System frequency = 50.00 Hz: 25 fps, 50 fps
Bit Rate: 24 Mbps, 20 Mbps, 16 Mbps, 14 Mbps, 8 Mbps,
6 Mbps, 4 Mbps, 3 Mbps, 2 Mbps, 1.5 Mbps,
1 Mbps, 0.7 Mbps, 0.5 Mbps
Audio Compression Format:
AAC-LC, 48 kHz/16 bit, 2 ch
Network Protocol: RTSP/RTP/RTMP/RTMPS
10
As of October, 2019
Video Output
SDI OUT: BNC x 1, SDI REC REMOTE supported
HD: 0.8 V [p-p], 75 Ω SD: 0.8 V [p-p], 75 Ω,
Output format (4:2:2 10 bit):
• 1920 x 1080: 59.94p, 50p, 59.94i, 50i,
29.97Psf, 25Psf, 23.98PsF
• 1280 x 720: 59.94p, 50p
• 720 x 480: 59.94i • 720 x 576: 50i
HDMI OUT : HDMI x 1, Type A, HDMI REC REMOTE supported,
VIERA Link not supported
Output format (4:2:2 10 bit):
• 3840 x 2160: 59.94p, 50p, 29.97p, 25p, 23.98p
• 1920 x 1080: 59.94p, 50p, 59.94i, 50i, 29.97p, 25p, 23.98p
• 1280 x 720: 59.94p, 50p
• 720 x 480: 59.94p • 720 x 576: 50p
VIDEO OUT: 3.5 mm diameter mini jack, composite 1.0 V [p-p], 75 Ω
Audio Input/Output
Built-in Microphone: Stereo microphone
Input 1/2: XLR (3-pin) x 2 (INPUT1, INPUT2)
Input high impedance, LINE/MIC/MIC+48V (switchable SW)
MIC: −40 dBu/−50 dBu/−60 dBu (switchable menu)
LINE: +4 dBu/0 dBu (switchable menu)
SDI OUT: Linear PCM 4 ch
HDMI OUT: Linear PCM 2 ch
Headphone: 3.5 mm diameter stereo mini jack x 1
AV OUT: 3.5 mm diameter stereo mini jack x 1,
Output level: 600 Ω, 316 mV
Speaker: 20 mm diameter, round x 1
Other Input/Output
TC IN/OUT: BNC x 1,
Used as the input and output terminals (switchable menu)
Input: 1.0 V to 4.0 V [p-p] 10 kΩ
Output: 2.0 V ± 0.5 V [p-p] low impedance
REMOTE: 2.5 mm diameter super mini jack
LAN: RJ-45: 1000BASE-T/100BASE-TX/10BASE-T
NDI | HX supported*
*To use this function, an activation keycode from NewTek is
required. Keycodes can be purchased from the following
website: http://new.tk/ndi_panasonic
USB 2.0 HOST: Type-A, 4-pin (5 V, 0.5 A) for Wireless Module (option)
USB 3.0 DEVICE: USB 3.1 GEN1 Type-C, USB Mass storage function
No USB bus power function
DC IN 12V: DC 12 V EIAJ Type 4
Monitor/Viewnder
LCD Monitor: 3.5 type TFT LCD color monitor (3:2),
approx. 1,620,000 dots, Touch panel
video display (16: 9) area: Approx. 1,370,000 dots
Viewnder:
video display (16: 9) area: approx. 1,770,000 dots
0.39 type OLED (organic EL display), approx. 2,360,000 dots,
Included Accessories
Battery (AG-VBR59), Battery charger (AG-BRD50), AC adaptor, AC cable, Microphone
holder kit, Shoulder strap, Eye cup, Lens hood*, Grip belt* and Operating instructions
(Items marked by an asterisk (*) come already attached to the camera)
Available Memory Card
Format Memory Card Type Bit Rate / Recording Function Speed Class
400 Mbps
FHD ALL-I VFR (23.98p)/super slow
Video Speed Class V60 or faster
200 Mbps
MOV
SDXC memory card/
microP2 card B series
microP2 card A series
(64 GB)
150 Mbps
100 Mbps
FHD LongG VFR/super slow
FHD ALL-I VFR (59.94o/50p/29.97p/25p)
50 Mbps
Video Speed Class V30
UHS Speed Class 3 or faster
Video Speed Class V10
UHS Speed Class 1
Speed Class 10 or faster
AVCHD SDHC/SDXC memory card/microP2 card All Speed Class 4 or faster
P2* microP2 card
*Use a microP2 card for recording in P2 format.
All P2 recording modes
supported by the AG-CX350*
—
Recording Time
Recording Format
400 Mbps Approx. 20 min. Approx. 40 min.
200 Mbps Approx. 40 min. Approx. 1 hour 20 min.
150 Mbps Approx. 55 min. Approx. 1 hour 50 min.
100 Mbps Approx. 1 hour 20 min. Approx. 2 hours 40 min.
100 Mbps Approx. 1 hour 20 min. Approx. 2 hours 40 min.
50 Mbps Approx. 2 hours 40 min. Approx. 5 hours 20 min.
MOV
(AVC, HEVC)
UHD
FHD
PS Approx. 5 hours 20 min. Approx. 11 hours
PH Approx. 6 hours Approx. 12 hours 30 min.
AVCHD
HA Approx. 8 hours 30 min. Approx. 17 hours
PM Approx. 17 hours 10 min. Approx. 35 hours
SA Approx. 16 hours 30 min. Approx. 34 hours
AVC-Intra422/AVC-Intra200*
1
AVC-Intra100*1 (1080-59.94i/50i or 720-59.94p/50p)*2Approx. 1 hour 4 min. —
P2 MXF
AVC-Intra50*
AVC-LongG50 Approx. 2 hours 8 min. —
1
AVC-LongG25 (1080-59.94i/50i or 720-59.94p/50p)*2Approx. 4 hours 16 min. —
AVC-LongG12 (1080-59.94i/50i or 720-59.94p/50p)*2Approx. 8 hours —
*1: AVC-Intra200/100/50 codec will be supported in the future. *2: The recording time decreases to one-half when recorded in 1080-59.94p/50p.
microP2 Card
64 GB SDXC/SDHC Memory Card
Approx. 32 min.
Approx. 2 hours 8 min. —
128 GB SDXC/SDHC Memory Card
—
11
Notes R egarding N etwork Functions
•For wi reless L AN connec tion: The optional wireless module is required. For the OS, browser, device compatibility information, see “Service and Support” on the Panasonic website <https://
pro-av.panasonic.net/>. Some functions are not supported by some devices.
•For st reaming : PC must be able to access directly each other by Public IP (Global IP). Please contact your provider to get Public IP (Global IP).
Notes r egarding t he handling of p 2 files using a PC
Mounting and Transferring Files
The PC must be installed with the included P2 driver in order to recognize, copy and transfer P2 files. This driver is also necessary when using the PC card slot and when handling P2 files
stored on a hard-disk device, such as P2 store. For other operating requirements, refer to the P2 installation manual. The P2 driver and the P2 installation manual can be downloaded free from a
Panasonic website. Visit <https://pro-av.panasonic.net/en/download/>
Previe w and Nonline ar Editing
To preview (play) P2 files on a PC, it is necessary to install P2 Viewer Plus software (downloadable for free, for Windows and Mac), both from Panasonic, or P2-compatible editing software
available from other companies (for details, visit <https://pro-av.panasonic.net/en/sales_o/p2/partners.html>). Note that each software places specific requirements on the operating
environment, and the operating environment must meet additional requirements to play and edit HD content on Windows PCs and Macs. For P2 Viewer Plus download and operating
requirement information, visit <https://pro-av.panasonic.net/en/download/>. For operating requirements and details of other P2 editing software, visit the website of the relevant software
manufacturer.
Note Regarding 24 bit Audio
Clips recorded using 24 bit audio must be played back with 24 bit compatible P2 equipment or the P2 Viewer/P2 Viewer Plus. If clips are played back with equipment not compatible with 24 bit
audio, the clip number will be indicated in red and the clips will not be played back. A P2 Viewer not compatible with 24 bit audio will not reproduce the sound properly. To play back those clips,
use the latest version of P2 Viewer/P2 Viewer Plus. For the latest information on 24 bit compatible P2 equipment and P2 Viewer/P2 Viewer Plus, see “Support & Download” on the Panasonic
website <https://pro-av.panasonic.net/>.
*AVCHD and the AVCHD logo are registered trademarks of Sony Corporation and Panasonic Corporation. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo
are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries. SD Logo is a trademark. SDXC/SDHC and SDHC logo marks are the
registered trademarks. App Store is a service mark of Apple Inc. Android and Google Play are trademarks or registered trademarks of Google LLC. YouTube™ and YouTube logo are registered
trademarks of Google Inc. Facebook is a registered trademark of Facebook, Inc.
*Specifications are subject to change without notice.
2-15 Matsuba-cho, Kadoma, Osaka 571-8503 Japan
Factories of AVC Networks Company have received
ISO14001:2004-the Environmental Management System
certification. (Except for 3rd party’s peripherals.)
SP-CX350PE4Web
Broadcast and
Professional
AV Website
For more information, please visit Panasonic web site
https://pro-av.panasonic.net/en/qr/
Contact Information Facebook Mobile App
201910ZP-1 Printed in Japan
Loading...
