Data Sheet
CPLN 10XRC
CPLN-RC / LCACHN-RC
These objectives are designed for observation of living cells including oocyte. Plastic vessels applicable for
Relief Contrast observations.
Please contact your sales representative for
transmission data for this objective lens.
05/12· OEH
Numerical Aperture (NA) 0.25
Working distance (W.D.) (mm) 9.7
Field Number (F.N.) 22
Cover Glass Thickness (mm) 1.5
Immersion Liquid -
Spring -
Correction Collar -
Iris Diaphragm -
Waterproof & Oil proof function -
Ultra Wide anti-reection coating -
Super apochromatic -
Brighteld Good
Darkeld Good
DIC N/A
Phase Contrast N/A
Relief Contrast Excellent
Polarized Light Limitation
Fluorescence (B, G Excitation) Limitation
UV Fluorescence (at 365nm) N/A
IR DIC N/A
Multi photon excitation N/A
Specifications, design and accessories are subject to change without any notice or obligation on the part of the manufacturer.
