Miele PUR88W Specs

30” Wall Ventilation Hood

PUR 88 W

Specification Sheets TRS 05152019

8mieleusa.com

30” Wall Ventilation Hood

SPECIFICATIONS

Overall Unit Width 29

15

Overall Unit Height - Vented 26

Overall Unit Height - Recirculated 32

/16” (685 mm) - 399/16” (1005 mm)

1

/16” (815 mm) - 4411/16” (1135 mm)

Overall Unit Depth 19

Fan

Fan Speeds 4, Including Intensive setting

Maximum CFM 625 CFM, (Reducing Collar is available to reduce air flow to less than 400 CFM)

Duct

Recommended Duct Diameter 6” (150 mm)

Electrical

Electrical Requirements 120V, 60Hz,15A

Power Cord Molded NEMA 5-15 plug, 2.5 ft (0.75 m)

Electrical Rating 359 W (Blower: 350 W; Lighting: 3x3 W)

Optional Accessories

Recirculation Kit DUW 20

OdorFree Charcoal Filter

CFM Reducing Collar R2000

Shipping

Shipping Weight 62 lbs (28 kg)

Shipping Dimensions 40

1

/8” (1020 mm) W x 263/16” (665 mm) H x 259/16” (650 mm) D

Support

Call Miele [phone]

Miele Website

20/20 Link

7

/16” (748 mm)

11

/16” (500 mm)

DKF12-900

8www.mieleusa.com

82020technologies.com

PUR 88 W
Item 28428654USA

Page 2 of 5

INSTALLATION SPECIFICATIONS

30” Wall Ventilation Hood

Page 3 of 5

INSTALLATION SPECIFICATIONS

Mounting Details

30” Wall Ventilation Hood

• Center unit over cooking surface

• Distances “S” is determined by the cooking surface. See “Distance between cooktop and hood (S)”
dimensions.

• If studs are not available in the required locations, a plywood backing (min.

1

/2” (13 mmm)) MUST be used to

reinforce support. Reinforcing material should be a󰀩xed to structural wall members. Failure to adequately
support the weight as stated may result in the ventilation system falling o󰀨 the wall, causing personal injury

and property damage.

Page 4 of 5

INSTALLATION SPECIFICATIONS

Distance Between Cooktop and
Ventilation Hood (S)

30” Wall Ventilation Hood

Specification Sheets TRS 05152019

Page 5 of 5
