Quick Guide
CVA 407x
This Quick Guide does not replace
the Operating manual.
Please read all instructions, especially
the "Important Safety Instructions",
before using the coffee system.
UV
M.-Nr. 06 929 340
Making coffee
2 coffees or 2 espresso
Select "2 portions" when displayed.
^
Cancel the preparation
Select "Stop" to cancel the process.
^
Cappuccino
Set a mug of
^
milk under the
intake hose.
Setting the serving sizes for coffee, espresso, cappuccino milk froth
Set the cup
^
under the froth
dispenser.
Select
^
"Cappuccino"
and follow the
display
messages.
^ Press and hold the touch control of the desired drink until "Serving setting" is
displayed under the type of drink.
^
Release the touch control.
^
Select "OK" once the cup is filled to your desire.
Setting the espresso serving size for cappuccino
^
When the request is shown, set the cup under the under the dispenser. Press
and hold "Cappuccino" until the display shows "Serving setting".
Espresso and coffee made from ground coffee
^
Pull out the cover
for the ground
coffee funnel.
^
Lift the funnel lid, a.
^
Place one spoonful of ground coffee
into the funnel, b, (using the
supplied spoon) and close the lid.
^
Follow the display messages.
Cleaning and Care
All parts can be cleaned in the dishwasher, except the brew unit and the bean
container.
Before the first use
It is important to program the water hardness. It will determine how frequently
^
the unit must be descaled. See "Settings - Water hardness".
Regular Maintenance
Follow all maintenace requests which show regularly in the display.
^
In addition please clean regularly
^ The door - See
"Cleaning and
Care" in the
manual.
^
The interior with
a damp cloth.
Vacuum dry
ground coffee.
Message "Cleaning must be started" (= Degreasing the brew unit)
^
Take out the
funnel cover.
^ The drip parts in
the dishwasher.
^
The bean
container
manually with a
warm water and
dish soap.
^ The drip tray at
the lower part of
the inner door.
^
Wipe the connector in the door
between brew unit and coffee
dispenser with a damp cloth.
Lubricate the gasket once a month
with the enclosed silicone.
^
Insert the cleaning tablet in the funnel,
close the lid. Follow the display
messages.
^ The water tank
niche.
Cleaning the brew unit
Press the button
^
on the brew unit
handle, a, and
turn the handle
to the left, b.
Press the brew
^
unit catch, c,
downwards and
pull the brew unit
out.
Cleaning the cappuccinatore
Rub off any coffee residue from the
^
filters with a sponge. Dry the funnel.
Lubricate the
^
gaskets with the
supplied silicone
grease.
^ Turn the cover
above the spout
to the left, a.
^ Pull the froth
dispenser out of
the machine, b,
holding it by the
spout and the
^ Pull all pieces
apart. Remove
the piece with
the gaskets by
turning and
pulling it apart.
Blow the holes
out.
^ Reassemble the
parts. The raised
parts (see arrow)
must point
downwards.
intake hose.
Descaling (approx. 20 minutes)
Important: Only use the enclosed descaling tablets for descaling. Insert the des
caling funnels so that the descaling solution cannot spill and damage the exterior.
^
^
Fill the water tank
with lukewarm
tap water to the
mark k.
Set the descaling
funnels under the
coffee
dispensers.
^
Follow the
display
messages.
Dissolve
2 descaling
tablets in the
water.
00 / 3306
-
