Quick start guide
CVA 30xx
These short instructions are not a substitute
for the Operating instruction booklet supplied
with your coffee machine.
Please read the Operating instruction booklet supplied
with your machine before using it for the first time and
take note of the Warning and Safety instructions as well
as the full descriptions on how to use your machine.
en - GB, AU, NZ
M.-Nr. 07 478 730
a Master switch
b Capsule plate (replaced with the descaling funnel when descaling
is carried out)
c Brew unit
d Capsule carousel
e Carousel runners
f Water container
g Drip tray with grid
h Waste container
Using the coffee machine - first steps
Controls
s On/Off sensor
< Left arrow sensor, for scrolling through the various programme options
OK Sensor for confirming the selection of a programme option and for saving
a setting
> Right arrow sensor, for scrolling through the various programme options
/ Drinks selection sensor (coffee or espresso)
Display
Drinks selection sensor: K = Coffee type, L= Steam, o = Hot water
User profile: n for up to 9 different users
Maintenance programmes: G = Maintenance, k = Descaling
Settings: C = For customising your machine
Filling the water container
^ Fill the water
container with
fresh, cold tap
water up to the
"Max." marker.
Filling the capsule carousel
^
Pull the carousel
runners a out as
far as possible.
Making coffee / espresso
^
Use the drinks
selection sensor
to select coffee
or espresso.
^
Use an arrow
sensor to select
the coffee type
and touch the
OK sensor.
^
Fill the chambers c in the capsule
carousel b with capsules. Make sure
you put them in correctly with the foil
facing downwards.
^
Double portion
Wait until "Double portion?" appears in
the display and touch the OK sensor.
Notes on operation
Programming the amount: Setting the portion size for coffee and espresso
Use the drinks
^
sensor / to
select the type of
coffee you want
(coffee or
espresso).
Chamber symbols in the display
K1 = A type of coffee has been allocated to the chamber;
the chamber has been filled
K, = A type of coffee has been allocated to the chamber; the chamber is empty
K? = The chamber has not been allocated with a type of coffee
Allocating a type of coffee
^ Select Settings
C and touch the
OK sensor.
Place a cup
^
under the spout.
^ Select "Allocate
type" and touch
the OK sensor.
Touch the OK
^
sensor until
"Prog. the
amount" appears
in the display.
^ Select the
chamber you
want (1-5) and
touch the OK
sensor.
Touch the OK
^
sensor again as
soon as the cup
is filled to the
level you want
and "Save"
appears in the
display.
^ Select "Select".
Then select the
type of coffee
from those available and touch
the OK sensor.
Renaming a type of coffee
^
Use one of the
arrow sensors to
select the letters
you want and
touch the OK
sensor when
appropriate.
Selecting or creating a User profile
^
Use one of the
arrow sensors to
select User
profile n and
touch the OK
sensor when
appropriate.
Made a mistake?
Select the bin and
touch the OK
sensor = the last
letter will be
deleted.
^
Proceed as
described in
"Allocating a type
of coffee" and
"Renaming a
type of coffee".
Save?
Select OK and
touch the OK
sensor.
Do not save?
Select "Back" and
touch the OK
sensor.
Important care tips
All parts except the capsule plate and the plastic grille are dishwasher safe.
Before use:
It is very important to programme the water hardness level into the machine to
^
prevent limescale building up too quickly. See "Settings: Water hardness" in the
Operating instruction booklet.
Regular maintenance:
Follow all maintenance instructions that appear in the display.
^
^ The machine
door - follow the
"Cleaning and
care" instructions
in the Operating
instruction
booklet carefully.
^
Clean the capsule carousel and the
carousel runners in the dishwasher.
^ Clean all parts of
the drip tray.
^ Wipe the small
drip tray inside
the door.
^
Wipe the area
underneath the
carousel runners,
especially the
sensor and the
recess.
^ Wipe the interior
with a damp
cloth.
^
Clean the cover
of the coffee
spout in the
dishwasher.
In addition, clean the capsule plate approx. once a month using a cleaning
tablet (make sure you use the correct tablet):
Fill a tumbler with
^
hot water and
dissolve a clean
ing tablet
(approx. 1 cm
diameter, pack of
10) in it.
-
Remove the capsule plate.
^
Place the capsule plate in the
^
cleaning solution and leave for
approx. one hour. After an hour,
remove the capsule plate, rinse it
thoroughly and dry it.
Descaling the machine (approx. 30 mins)
Important: Only use the descaling tablets supplied (approx. 5 cm diameter, pack
of 6) and wipe up any spills immediately to avoid damage to the front of the
machine.
^ Select "Descale"
k and touch the
OK sensor.
^ Remove the
capsule plate
and fit the
coloured
descaling funnel.
^ Follow the
instructions in
the display.
