1. Product Lineup
Nominal Capacity |
Model |
|
Refrigerant |
Power Supply |
|
|
|
|
|
|
|
Ton |
Model Name |
|
Function |
V, Ph, Hz |
|
|
|
||||
|
|
|
|
|
|
5 |
MRBT-60CWN1-R |
|
Cooling only |
|
380-415V, 3Ph,50Hz |
|
|
|
|
|
|
6.2 |
MRBT-062CWN1-R |
|
Cooling only |
|
|
|
|
|
|
|
|
6.2 |
MRCT-062EWN1-R |
|
Cooling + EAH |
|
|
|
|
|
|
|
|
6.2 |
MRBT-062HWN1-R |
|
Heat pump |
|
|
|
|
|
|
|
|
7.5 |
MRBT-075CWN1-R |
|
Cooling only |
|
|
|
|
|
|
|
|
7.5 |
MRCT-075EWN1-R |
|
Cooling + EAH |
|
|
|
|
|
|
|
|
7.5 |
MRBT-075HWN1-R |
|
Heat pump |
|
|
|
|
|
|
|
|
8.5 |
MRBT-085CWN1-R |
|
Cooling only |
|
|
|
|
|
|
|
|
8.5 |
MRCT-085EWN1-R |
|
Cooling +EAH |
|
|
|
|
|
|
|
|
8.5 |
MRBT-085HWN1-R |
|
Heat pump |
|
|
|
|
|
|
|
|
10 |
MRBT-100CWN1-R |
|
Cooling only |
|
|
10 |
MRCT-100EWN1-R |
|
Cooling + EAH |
|
|
10 |
MRBT-100HWN1-R |
|
Heat pump |
|
|
12.5 |
'MRBT-125CWN1-R |
|
Cooling only |
R410A |
380-415V, 3Ph,50Hz |
|
|
|
|
|
|
12.5 |
'MRBT-125HWN1-R |
|
Heat pump |
|
|
|
|
|
|||
15 |
MRBT-150CWN1-R |
|
Cooling only |
|
|
|
|
|
|
|
|
15 |
MRCT-150EWN1-R |
|
Cooling + EAH |
|
|
|
|
|
|
|
|
15 |
MRBT-150HWN1-R |
|
Heat pump |
|
|
|
|
|
|
|
|
17.5 |
MRBT-175CWN1-R |
|
Cooling only |
|
|
|
|
|
|
|
|
17.5 |
MRCT-175EWN1-R |
|
Cooling + EAH |
|
|
17.5 |
MRBT-175HWN1-R |
|
Heat pump |
|
|
20 |
MRBT-200CWN1-R |
|
Cooling only |
|
|
|
|
|
|
|
|
20 |
MRCT-200EWN1-R |
|
Cooling +EAH |
|
|
|
|
|
|
|
|
20 |
MRBT-200HWN1-R |
|
Heat pump |
|
|
|
|
|
|
|
|
30 |
MRCT-300CWN1-R |
|
Cooling only |
|
|
|
|
|
|
|
|
30 |
MRCT-300EWN1-R |
|
Cooling +EAH |
|
|
30 |
MRCT-300HWN1-R |
|
Heat pump |
|
|
Note:Please refer to specification tables for accurate cooling or heating capacity with Kw or Btu/h unit.
2
MCAC-RTSM-2014-06 R410A Tropical Rooftop Package Unit 50Hz
2. External Appearance
5Ton |
6.2&7.5Ton |
|
8.5&10Ton |
12.5Ton |
15&17.5&20Ton |
30Ton |
3
MCAC-RTSM-2014-06 |
R410A Tropical Rooftop Package Unit 50Hz |
3. Nomenclature
M R B T- 062 C W N1- R
Power supply
R:380~400V/380~415V,3Ph,50Hz
Refrigerate type
N1:R410A
Omit for R22
Wired controller
Function mode
C:Cooling only
E:Electric heater and cooling
H:Heat pump
Cooling capacity
XXX: ton (6.2ton)
XX:1000Btu/h
Working condition
T: Tropical application
Omit for T1 condition
Air outlet way
A:optional two air outlet ways: side and bottom
B:optional two air outlet ways: side and bottom
C:one air outlet way: side
D:one air outlet way: bottom
Rooftop package
Midea
4
MCAC-RTSM-2014-06 |
R410A Tropical Rooftop Package Unit 50Hz |
4. Features
1.The adoption of anticorrosive-box
The reinforced anticorrosion by using galvanization armor plate and coated with man-composed paint. The appearance is stylish and easy for maintenance.
(Has been passed 1000 hours salt spray test)
2.The adoption of credible protection system
2.1 The protection of compressor
High-pressure protection, low-pressure protection, compressor’s current protection and so on.The series’ protectors can ensure compressor operating normally.
It adopts independent system, except for protection of sequence and wired controller output, any related protection to its corresponding compressor. Once a compressor protection energized, the corresponding compressor will stop, the others working still.
2.2 Fan motor
The fan motors for evaporator have over-heat protection and over-current protection function. The fan motors for condenser have the temperature controller protection function.
3. Energy saving design
3.1 High efficiency compressor
Using professional compressor, heat exchanger and optimum connection pipe, the compressor can startup under low power input. Provide maximum reliability, efficiency and quiet operation.
Two refrigerant circuits on larger units (above 12.5ton) provide efficient part load performance.
Standard low and high pressure safety switches.
Well compressor control
Compressor staging is controlled directly by the control temperature. When the control temperature is warmer than the cooling set point, cooling is staged up; when the control temperature is cooler than the cooling set point, cooling is staged down. However, a stage change can only occur when the control temperature is outside the dead band. Staging is constrained by an inter-stage delay timer. These constraints protect the compressors from short cycling while eliminating temperature variations near the diffusers.
3.2 Condenser
By using high-efficient thin wing, the condenser has high-efficient heat exchanger, the energy waste decreases greatly.
3.3 Evaporator
By using the high-efficient, super thin wing and inner grooved copper pipe, the evaporators get the higher capacity and the lower noise level.
3.4 The heat insulation of indoor unit
The heat insulation of indoor unit can availably decrease heat loss.
3.5 The control and refrigerant cycle system
There are two independent refrigerant cycle systems, the capacity output is adjusted automatically by
5
MCAC-RTSM-2014-06 |
R410A Tropical Rooftop Package Unit 50Hz |
different demand, save energy when one control system is in running according to low capacity output.
4. Optional collocation
4.1 Operation in high temperature
The air-conditioner designed for high temperature operating, even when the ambient temperature reaches up to 52 125 .
4.2 Strong air flow
Large air volume from the air inlet is forced ventilating by the condenser fan.
4.3 Minimum installation arrangement
The installation is fast and low cost with the easy installation and ready operation.
4.4 Pre-drilled duct flange
Flanges are prepared at the supply and return duct connections so that they can reduce duct connection work at site.
Flange
4.5 Quiet operation
Noise and vibration have been effectively reduced by adopting new style hermetic compressor. The centrifugal fan and fan casing are optimum shaped for efficient and low noise operation.
5. Cabinet
5.1Sloped drain pan and drain pipe.
5.2Cabinets have forklift and lifting holes for easy transportation.
5.3Cabinets have fresh air function, and the filter can be washable.
Fresh air inlet
5.4 External pressure gauge ports.
With the gauge ports mounted externally, an accurate diagnostic of system operation can be performed quickly and easily without disrupting airflow.
5.5 Durable construction.
Weather-resistant construction with capped seams and sloped top panels.
G90 galvanized heavy gauge plate conforming to ASTM-A-653, Zinc content of galvanized plate is 275 g/m2 .
6
MCAC-RTSM-2014-06 |
R410A Tropical Rooftop Package Unit 50Hz |
Electric heater assembly (optional)
Condenser fan motor
Highly efficient enhanced copper tube/Aluminum fin outdoor coil
Highly efficient enhanced copper tube / aluminum fin indoor coil
Decorative protective coil guard
Compressor contactor
Low voltage terminal block
Blower motor with slide-out blower assembly
Compressor |
Heavy gauge removable |
|
base rails |
5ton
6. Optional supply/return airflow design, from side or bottom, It could be flexibly applied to multi-position. The rooftop and ground installation are optional.
7. Certificate of compressor
The compressors have CE certified, UL certified.
7
MCAC-RTSM-2014-06 |
R410A Tropical Rooftop Package Unit 50Hz |
5. List of Functions
5.1 Standard specifications
A. General
The units are convertible airflow. All units shall be factory assembled, internally wired, fully charged refrigerant and 100% run tested to check cooling and heating operation, fan and blower rotation, and control sequence before leaving the factory. Wiring internal to the unit shall be colored and numbered for simplified identification. The unit is provided with an integral weather resistant control panel.
B. Unit enclosure
Panels are of heavy gauge, G-90 galvanized steel sheet with removable access panels, completely weatherized for outdoor installation and properly reinforced and brazed. Panels and access door are provided for inspection and access for all internal parts. Enclosures are provided with adequately reinforced points of support for setting in the unit. Steel sheet panels are zinc-coated and galvanized by the hot dip process of lock forming quality conforming to ASTMA 653 commercial weight G-90, followed by baked on electrostatic polyester dry powder coat paint, on all external panel.
C. Compressor
Compressors are scroll for all the models. They are provided with all the standard controls and accessories necessary for safe operation. These are equipped with internal motor protector; factory installed crank case heater and rubber vibration isolator for quiet and efficient operation.
D. Air-cooled condensing section
1.The air-cooled condensing section is enclosed within the unit housing and consists of condenser coil, fan(s) electric motor(s) and inherently protected compressor(s). Inner grooved copper tubes with wall thickness of 0.3mm, mechanically bonded to enhanced louvered aluminum fins are standard for all condenser coils. As an option, enhanced coated aluminum fins may be provided. Tube support sheets are galvanized steel, formed to provide structural strength.
2.Fans are propeller type, direct driven, upward discharge and provided with fan grille mounted on the casing.
3.Motors are totally enclosed air-over type with class F insulation. Inherent thermal protection is automatic reset type.
E. Evaporator coil section
1.All cooling coils are of enhanced louvered fins and inner grooved copper tubes with wall thickness of 0.3mm, mechanically bonded to aluminum fins. As option, enhanced coated aluminum fins may be provided. Tube support sheets are galvanized steel, formed to provide structural strength.
2.Drainage pan: An insulated drainage pan made of G-90 galvanized steel is provided, for additional corrosion protection.
3.Insulation: Insulation is supplied in adequate density and thickness for all units to prevent condensation from forming on the unit casing. Insulation meets the requirements of NFPA 90A and is protected against deterioration and erosion from air currents.
F. Evaporator fan
Evaporator fan is of centrifugal forward-curved blade design capable of handling total required CFM and static pressure in the low and the medium ranges. Casings are made of galvanized steel. Blower motors are of open drip proof type (totally enclosed types are optional) and conform to NEMA MG-1 and MG-2. Blower motor is mounted on adjustable base and secured by locking device. Pillow block bearing are selected for at 200,000 hours average life at design operating conditions. Shaft is turned, ground and
8
MCAC-RTSM-2014-06 |
R410A Tropical Rooftop Package Unit 50Hz |
polished from solid steel. Fans and pulleys are keyed to shaft and designed for continuous operation at maximum motor horse power and fan speed. All rotating components and assemblies are statically and dynamically balanced and every unit is vibration tested before shipment from the factory.
G. Electronic thermostats
General information: A dedicated electronic thermostat is supplied with unit controls as standard. This thermostat controls one or two stage heating and cooling applications. The thermostat normally displays room temperature and mode of operation.
The temperature can be set by up/down buttons for both cooling and heating cycles. The thermostat also allows you to select continuous fan operation, or have the fan on intermittent operation with the equipment. It also displays the status of unit, thus providing maximum information for the end user.
5.2 Electric auxiliary heater
Electric auxiliary heaters are the resistance open coil type and conform to the requirements of UL 573 or equivalent. Electrical characteristics, kW capacities and number of stages are as indicated. Airflow switches, fusible links and overheat limit thermostats are provided to shut-off power in case of airflow failure/overheat. Electric heater kit is installed as an externally mounted kit at the supply opening.
5.3 Standard features/options/accessories
Description |
Standard features |
Options |
Accessories |
|
(factory installed) |
(field installed) |
|||
|
|
|||
|
|
|
|
|
Horizontal discharge |
|
|
|
|
|
|
|
|
|
Compressor crankcase heaters |
|
|
|
|
|
|
|
|
|
Evaporator fan-belt driven |
|
|
|
|
|
|
|
|
|
Evaporator fan motor-ODP type(TEFC type optional) |
|
|
|
|
|
|
|
|
|
Condenser fan-direct drive, propeller type(Except 5ton) |
|
|
|
|
|
|
|
|
|
Condenser fan-direct drive, axial type(Only 5ton) |
|
|
|
|
|
|
|
|
|
Condenser fan motor-totally enclosed air-over type |
|
|
|
|
|
|
|
|
|
Electric auxiliary heater |
|
|
|
|
|
|
|
|
|
Filter, Nylon(Thickness 10&12.5mm, except 5ton) |
|
|
|
|
|
|
|
|
|
Filter, aluminum(Thickness 25mm) |
|
|
|
|
|
|
|
|
|
Compressor overload protection |
|
|
|
|
|
|
|
|
|
Low &high pressure switch |
|
|
|
|
|
|
|
|
|
Cooling & heating thermostat |
|
|
|
|
|
|
|
|
|
Condenser fan guard |
|
|
|
|
|
|
|
|
|
Condenser coil guard |
|
|
|
|
|
|
|
|
|
Wired controller KJR-12B |
|
|
|
|
|
|
|
|
|
Wired controller KJR-23B |
|
|
|
|
|
|
|
|
|
Wired controller KJR-25B |
|
|
|
|
|
|
|
|
|
Drainage pipe |
|
|
|
|
|
|
|
|
|
Drainage outlet |
|
|
|
|
|
|
|
|
|
Snap ring |
|
|
|
|
|
|
|
|
9
MCAC-RTSM-2014-06 |
|
|
|
R410A Tropical Rooftop Package Unit 50Hz |
|
||||
6. Specifications |
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
Nominal ton |
|
|
|
5 |
6.2 |
6.2 |
6.2 |
|
|
|
|
|
|
|
|
|
|
|
|
Model |
|
|
|
MRBT-60CWN1-R |
MRBT-062CWN1-R |
MRCT-062EWN1-R |
MRBT-062HWN1-R |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Btu/h |
59000 |
75000 |
75000 |
75000 |
|
|
|
Cooling Capacity 1 |
|
|
|
|
|
|
|
|
|
|
kW |
17 |
22 |
22 |
22 |
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
Power Input 1 |
|
kW |
5.6 |
7.7 |
7.7 |
7.7 |
|
Cooling |
|
|
|
|
|
|
|
|
|
|
|
Btu/h |
51200 |
62700 |
62700 |
62700 |
|
||
|
|
|
|
|
|||||
|
|
Cooling Capacity 2 |
|
|
|
|
|
|
|
|
|
|
kW |
15 |
18.4 |
18.4 |
18.4 |
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
Power Input 2 |
|
kW |
6.7 |
8.6 |
8.6 |
8.6 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Btu/h |
- |
- |
47800 |
89000 |
|
|
|
Heating Capacity |
|
|
|
|
|
|
|
Heating |
|
kW |
- |
- |
14 |
26 |
|
||
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
Power Input |
|
kW |
- |
- |
14 |
7.6 |
|
|
|
|
|
|
|
|
|
|
|
Capacity steps |
|
% |
0/100 |
0/100 |
0/100 |
0/100 |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
Power supply |
|
V/Ph/Hz |
380-415/3/50 |
380-415/3/50 |
380-415/3/50 |
380-415/3/50 |
|
Electrical |
|
|
|
|
|
|
|
|
|
|
Max. input |
|
kW |
8.1 |
10.9 |
10.9 |
11.3 |
|
|
data |
|
consumption |
|
|
|||||
|
|
|
|
|
|
|
|
||
|
|
Max. current |
|
A |
18 |
20.1 |
20.1 |
21 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Indoor fan air flow |
|
CFM |
1800 |
2600 |
2600 |
2600 |
|
|
|
|
|
|
|
|
|
|
|
|
|
ESP |
|
Pa |
50 |
60 |
60 |
60 |
|
|
|
|
|
|
|
|
|
|
|
Performance |
|
EER 1 |
|
Btu/W.h |
10.4 |
9.7 |
9.7 |
9.7 |
|
|
|
|
|
|
|
|
|
|
|
|
|
EER 2 |
|
Btu/W.h |
7.6 |
7.3 |
7.3 |
7.3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
COP |
|
Btu/W.h |
/ |
/ |
/ |
11.6 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Number of rows |
|
|
4 |
2 |
2 |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
1.6 |
1.6 |
1.6 |
1.6 |
|
|
|
Fin spacing |
|
|
|
|
|
|
|
|
|
|
inch |
1/16'' |
1/16'' |
1/16'' |
1/16'' |
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
7.94 |
7.94 |
7.94 |
7.94 |
|
Indoor Coil |
|
Tube diameter |
|
|
|
|
|
|
|
|
|
inch |
5/16'' |
5/16'' |
5/16'' |
5/16'' |
|
||
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
837×704 |
880X847 |
880X847 |
880X847 |
|
|
|
Coil length X height |
|
|
|
|
|
|
|
|
|
|
inch |
32.9x27.7 |
34.6x33.3 |
34.6x33.3 |
34.6x33.3 |
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
Number of circuits |
|
|
12 |
10 |
10 |
10 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
|
FC centrifugal |
FC centrifugal |
FC centrifugal |
FC centrifugal |
|
|
|
|
|
|
|
|
|
|
|
|
|
Quantity |
|
|
1 |
1 |
1 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
282 |
254 |
254 |
254 |
|
|
|
Diameter(Width) |
|
|
|
|
|
|
|
|
|
|
inch |
11.1 |
10 |
10 |
10 |
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
Indoor fan |
|
Drive type |
|
|
Direct |
Belt |
Belt |
Belt |
|
|
|
|
|
|
|
|
|
|
|
|
|
Motors quantity |
|
|
1 |
1 |
1 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor model |
|
|
YDK550-4E |
YFD90L-4-1.5 |
YFD90L-4-1.5 |
YFD90L-4-1.5 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor output |
|
kW |
0.55 |
1.5 |
1.5 |
1.5 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor rpm |
|
r/min |
948 |
1400 |
1400 |
1400 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
|
Scroll |
Scroll |
Scroll |
Scroll |
|
|
|
|
|
|
|
|
|
|
|
|
|
Quantity |
|
|
1 |
1 |
1 |
1 |
|
|
|
|
|
|
|
|
|
|
|
Compressor |
|
Model |
|
|
ZP67KCE-TFD-522 |
SH090A4ALC |
SH090A4ALC |
SH090A4ALC |
|
|
|
|
|
|
|
|
|
|
|
|
|
Brand |
|
|
Copeland |
Danfoss |
Danfoss |
Danfoss |
|
|
|
|
|
|
|
|
|
|
|
|
|
Capacity |
|
Btu/h |
55000 |
76090 |
76090 |
76090 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
10 |
|
MCAC-RTSM-2014-06 |
|
|
|
|
R410A Tropical Rooftop Package Unit 50Hz |
|
||||
|
|
Input |
|
|
kW |
5.2 |
7.185 |
7.185 |
7.185 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Rated load |
Amps |
A |
11.8 |
14.3 |
14.3 |
14.3 |
|
|
|
|
(RLA) |
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Locked |
rotor |
A |
74 |
20 |
20 |
20 |
|
|
|
|
Amps(LRA) |
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Refrigerant oil charge |
ml |
1656 |
3000 |
3000 |
3000 |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
Number of rows |
|
|
|
3 |
3 |
3 |
3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
1.3 |
1.6 |
1.6 |
1.6 |
|
|
|
Fin spacing |
|
|
|
|
|
|
|
|
|
|
|
|
inch |
1/16" |
1/16" |
1/16" |
1/16" |
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
7.94 |
7.94 |
7.94 |
7.94 |
|
Outdoor Coil |
|
Tube diameter |
|
|
|
|
|
|
|
|
|
|
inch |
5/16" |
5/16" |
5/16" |
5/16" |
|
|||
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
(outer2124/middle207 |
1404X968 |
1404X968 |
1404X968 |
|
|
|
|
|
|
4/inner2024) X 756 |
|
||||
|
|
Coil length X height |
|
|
|
|
|
|||
|
|
inch |
(outer83.6/middle81.7 |
55.3 X38.1 |
55.3 X38.1 |
55.3 X38.1 |
|
|||
|
|
|
|
|
|
|||||
|
|
|
|
|
/inn9.7er7) X 29.8 |
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Number of circuits |
|
16 |
21 |
21 |
21 |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
|
|
Axial fan |
Propeller |
Propeller |
Propeller |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Quantity |
|
|
|
1 |
1 |
1 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
600 |
650 |
650 |
650 |
|
|
|
Diameter(Width) |
|
|
|
|
|
|
|
|
|
|
|
|
inch |
23.62 |
25.6 |
25.6 |
25.6 |
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
Outdoor Fan |
|
Drive type |
|
|
|
direct |
Direct |
Direct |
Direct |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motors quantity |
|
|
|
1 |
1 |
1 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor model |
|
|
|
YDK230-6G-6 |
YS600-6P |
YS600-6P |
YS600-6P |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor output |
|
|
kW |
0.23 |
0.6 |
0.6 |
0.6 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor rpm |
|
|
r/min |
915 |
930 |
930 |
930 |
|
|
|
|
|
|
|
|
|
|
|
|
Outdoor sound pressure level |
|
|
dB(A) |
62.9 |
70.3 |
70.3 |
70.3 |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
|
|
R410A |
R410A |
R410A |
R410A |
|
|
|
|
|
|
|
|
|
|
|
|
Refrigerant |
|
Refrigerant volume |
Kg |
5 |
5.2 |
5.2 |
5.2 |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
Refrigerant Control |
|
Capillary |
Capillary |
Capillary |
Capillary |
|
||
|
|
|
|
|
|
|
|
|
|
|
Standard controller |
|
|
|
KJR-12B |
KJR-12B |
KJR-12B |
KJR-12B |
|
||
|
|
|
|
|
|
|
|
|
|
|
Operation temp |
|
|
|
|
17~30 |
17~30 |
17~30 |
17~30 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Outdoor |
|
Cooling |
|
|
|
18~52 |
18~52 |
18~52 |
18~52 |
|
ambient |
|
|
|
|
|
|
|
|
|
|
|
Heating |
|
|
|
- |
- |
- |
-10~24 |
|
|
temp |
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Net(W×H×D) |
|
|
mm |
1920X840X1068 |
1630 X1068X1065 |
1630 X1068X1065 |
1630 X1068X1065 |
|
Dimensions |
|
|
|
|
|
|
|
|
|
|
|
Packing(W×H×D) |
mm |
1955X870X1085 |
1700X1110X1155 |
1700X1110X1155 |
1700X1110X1155 |
|
|||
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Net weight |
|
|
Kg(Ibs) |
230(507) |
315(694.4) |
323(712) |
320(705.4) |
|
Weight |
|
|
|
|
|
|
|
|
|
|
|
Gross weight |
|
|
Kg(Ibs) |
234(516) |
335(738.5) |
343(756) |
340(749.6) |
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
|
|
Nylon |
Nylon |
Nylon |
Nylon |
|
|
|
|
|
|
|
|
|
|
|
|
Filter |
|
Quantity |
|
|
Pieces |
1 |
2 |
2 |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Size (W×H×D) |
|
|
mm |
410 X 495 X 25 |
447 X 885 X 10 |
447 X 885 X 10 |
447 X 885 X 10 |
|
|
|
|
|
|
|
|
|
|
|
|
Shipping |
|
Qty'Per |
|
|
Pieces |
12/24/36 |
12/28/28 |
12/28/28 |
12/28/28 |
|
|
20'/40'/40'HQ |
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
Note: |
|
|
|
|
|
|
|
|
|
|
The data are based on the following conditions:
Cooling: (1): Indoor Temperature 26.7°C(80°F) DB / 19.4°C(67°F) WB; - Outdoor Temperature 35°C(95°F) DB. (2): Indoor Temperature 26.7°C(80°F) DB / 19.4°C(67°F) WB; - Outdoor Temperature 46°C(114°F) DB.
Heating and Power input: Indoor Temperature 20°C(68°F) DB/15°C(59°F) WB; - Outdoor Temperature 7°C(44.6°F) DB/6°C(42.8°F) DB Electrical data: Indoor Temperature 32°C(90°F) DB / 24°C(74°F) WB; - Outdoor Temperature 52°C(125°F) DB
11
|
MCAC-RTSM-2014-06 |
|
|
|
R410A Tropical Rooftop Package Unit 50Hz |
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Nominal ton |
|
|
|
(Ton) |
7.5 |
7.5 |
7.5 |
8.5 |
8.5 |
|
||
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
||
Model |
|
|
|
|
MRBT-075CWN1-R |
MRCT-075EWN1-R |
MRBT-075HWN1-R |
MRBT-085CWN1-R |
MRCT-085EWN1-R |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Btu/h |
89000 |
89000 |
89000 |
103000 |
103000 |
|
|
|
|
Cooling Capacity 1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
kW |
26 |
26 |
26 |
30 |
30 |
|
||
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Power Input 1 |
|
kW |
9.2 |
9.2 |
9.2 |
10.4 |
10.4 |
|
|
Cooling |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Btu/h |
74500 |
74500 |
74500 |
85600 |
85600 |
|||
|
|
|
|
|
|
|||||||
|
|
|
Cooling Capacity 2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
kW |
21.8 |
21.8 |
21.8 |
25.1 |
25.1 |
|
||
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Power Input 2 |
|
kW |
9.9 |
9.9 |
9.9 |
11.4 |
11.4 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Btu/h |
- |
47800 |
102000 |
- |
71700 |
|
|
|
|
Heating Capacity |
|
|
|
|
|
|
|
|
|
Heating |
|
|
kW |
- |
14 |
30 |
- |
21 |
|
|||
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Power Input |
|
kW |
- |
14 |
8.8 |
- |
21 |
|
|
|
|
|
|
|
|
|
|
|
|
|||
Capacity steps |
|
|
% |
0/100 |
0/100 |
0/100 |
0/100 |
0/100 |
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Power supply |
|
V/Ph/Hz |
380-415/3/50 |
380-415/3/50 |
380-415/3/50 |
380-415/3/50 |
380-415/3/50 |
|
Electrical |
|
|
|
|
|
|
|
|
|
|
||
|
Max. input |
|
kW |
13 |
13 |
13.5 |
14 |
14 |
|
|||
|
|
|
|
|
|
|||||||
data |
|
|
|
|
|
|
|
|
|
|
||
|
Max. current |
|
A |
25 |
25 |
25.6 |
26.3 |
26.3 |
||||
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Indoor fan air |
|
CFM |
3000 |
3000 |
3000 |
3600 |
3600 |
|
|
|
|
|
flow |
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
ESP |
|
Pa |
60 |
60 |
60 |
75 |
75 |
|
Performance |
|
|
|
|
|
|
|
|
|
|||
EER 1 |
|
Btu/W.h |
9.7 |
9.7 |
9.7 |
9.8 |
9.8 |
|
||||
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
EER 2 |
|
Btu/W.h |
7.5 |
7.5 |
7.5 |
7.7 |
7.7 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
COP |
|
Btu/W.h |
/ |
/ |
11.6 |
/ |
/ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Number of rows |
|
2 |
2 |
2 |
3 |
3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
1.6 |
1.6 |
1.6 |
1.4 |
1.4 |
|
|
|
|
|
Fin spacing |
|
|
|
|
|
|
|
|
|
|
|
|
inch |
1/16'' |
1/16'' |
1/16'' |
1/18'' |
1/18'' |
|||
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
7.94 |
7.94 |
7.94 |
7.94 |
7.94 |
|
Indoor Coil |
|
Tube diameter |
|
|
|
|
|
|
|
|||
|
inch |
5/16'' |
5/16'' |
5/16'' |
5/16'' |
5/16'' |
||||||
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
Coil length X |
mm |
880X847 |
880X847 |
880X847 |
1117X792 |
1117X792 |
||
|
|
|
|
height |
|
|
|
|
|
|
||
|
|
|
|
inch |
34.6x33.3 |
34.6x33.3 |
34.6x33.3 |
44 X31.2 |
44 X31.2 |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Number of circuits |
|
10 |
10 |
10 |
18 |
18 |
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
Type |
|
FC centrifugal |
FC centrifugal |
FC centrifugal |
FC centrifugal |
FC centrifugal |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Quantity |
|
1 |
1 |
1 |
1 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
254 |
254 |
254 |
305 |
305 |
|
|
|
|
|
Diameter(Width) |
|
|
|
|
|
|
|
|
|
|
|
|
inch |
10 |
10 |
10 |
12 |
12 |
|
||
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
||||
Indoor fan |
|
Drive type |
|
Belt |
Belt |
Belt |
Belt |
Belt |
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motors quantity |
|
1 |
1 |
1 |
1 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
Motor model |
|
YFD90L-4-1.5 |
YFD90L-4-1.5 |
YFD90L-4-1.5 |
YFD90L-4-1.5 |
YFD90L-4-1.5 |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor output |
kW |
1.5 |
1.5 |
1.5 |
1.5 |
1.5 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor rpm |
r/min |
1400 |
1400 |
1400 |
1400 |
1400 |
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
Type |
|
Scroll |
Scroll |
Scroll |
Scroll |
Scroll |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Quantity |
|
1 |
1 |
1 |
1 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
Model |
|
SH105A4ALC |
SH105A4ALC |
SH105A4ALC |
SH120A4ALC |
SH120A4ALC |
||
Compressor |
|
|
|
|
|
|
|
|
|
|
||
|
Brand |
|
Danfoss |
Danfoss |
Danfoss |
Danfoss |
Danfoss |
|||||
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
Capacity |
Btu/h |
91500 |
91500 |
91500 |
102200 |
102200 |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
12 |
|
MCAC-RTSM-2014-06 |
|
|
|
R410A Tropical Rooftop Package Unit 50Hz |
||||||||
|
|
Input |
|
kW |
8.472 |
8.472 |
|
8.472 |
9.462 |
9.462 |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Rated load Amps |
A |
16.7 |
16.7 |
|
16.7 |
20.7 |
20.7 |
|
||
|
|
(RLA) |
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Locked |
rotor |
A |
142 |
142 |
|
142 |
142 |
142 |
|
|
|
|
Amps(LRA) |
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Refrigerant |
oil |
ml |
3000 |
3000 |
|
3000 |
3300 |
3300 |
|
|
|
|
charge |
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Number of rows |
|
3 |
3 |
|
3 |
3 |
3 |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
1.6 |
1.6 |
|
1.6 |
1.6 |
1.6 |
|
|
|
|
Fin spacing |
|
|
|
|
|
|
|
|
|
|
|
|
|
inch |
1/16" |
1/16" |
|
1/16" |
1/16" |
1/16" |
|||
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
7.94 |
7.94 |
|
7.94 |
7.94 |
7.94 |
|
|
Outdoor Coil |
|
Tube diameter |
|
|
|
|
|
|
|
|
|
|
inch |
5/16" |
5/16" |
|
5/16" |
5/16" |
5/16" |
||||||
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Coil length X |
|
mm |
1404X968 |
|
1404X968 |
|
1404X968 |
1748X880 |
1748X880 |
|
|
|
height |
|
|
|
|
|
|
|
|
|
|
|
|
|
inch |
55.3 X38.1 |
55.3 X38.1 |
|
55.3 X38.1 |
68.8X34.6 |
68.8X34.6 |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Number of circuits |
|
21 |
21 |
|
21 |
20 |
20 |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
|
Propeller |
|
Propeller |
|
Propeller |
Propeller |
Propeller |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Quantity |
|
|
1 |
1 |
|
1 |
1 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
650 |
650 |
|
650 |
700 |
700 |
|
|
|
|
Diameter(Width) |
|
|
|
|
|
|
|
|
|
|
|
|
inch |
25.6 |
25.6 |
|
25.6 |
27.6 |
27.6 |
|
|||
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Outdoor Fan |
|
Drive type |
|
|
Direct |
|
Direct |
|
Direct |
Direct |
Direct |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motors quantity |
|
1 |
1 |
|
1 |
1 |
1 |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor model |
|
|
YS600-6P |
|
YS600-6P |
|
YS600-6P |
YS1100-6 |
YS1100-6 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor output |
|
kW |
0.6 |
0.6 |
|
0.6 |
1.1 |
1.1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor rpm |
|
r/min |
930 |
930 |
|
930 |
940 |
940 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Outdoor sound pressure level |
|
dB(A) |
70.3 |
70.3 |
|
70.3 |
72.2 |
72.2 |
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
|
R410A |
|
R410A |
|
R410A |
R410A |
R410A |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Refrigerant |
|
Refrigerant |
|
Kg |
5.6 |
5.6 |
|
6 |
6.5 |
6.5 |
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
Refrigerant Control |
|
Capillary |
|
Capillary |
|
Capillary |
Capillary |
Capillary |
||
|
|
|
|
|
|
|
|
|
|
|
||
Standard controller |
|
|
KJR-12B |
|
KJR-12B |
|
KJR-12B |
KJR-12B |
KJR-12B |
|||
|
|
|
|
|
|
|
|
|
|
|
||
Operation temp |
|
|
|
17~30 |
17~30 |
|
17~30 |
17~30 |
17~30 |
|||
|
|
|
|
|
|
|
|
|
|
|
||
Outdoor |
|
Cooling |
|
|
18~52 |
18~52 |
|
18~52 |
18~52 |
18~52 |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
ambient temp |
|
Heating |
|
|
- |
- |
|
-10~24 |
- |
- |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Net(W×H×D) |
|
mm |
|
1630 X1068X1065 |
|
2165X1002X1335 |
||||
Dimensions |
|
|
|
|
|
|
|
|
|
|
|
|
|
Packing(W×H×D) |
mm |
|
1700X1110X1155 |
|
2220X1040X1410 |
||||||
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Net weight |
|
Kg(Ibs) |
315(694.4) |
|
323(712) |
|
380(837.7) |
445(981) |
455(1003) |
|
Weight |
|
|
|
|
|
|
|
|
|
|
|
|
|
Gross weight |
|
Kg(Ibs) |
335(738.5) |
|
343(756) |
|
390(859.8) |
458(1009.7) |
468(1031.7) |
||
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
||
|
|
Type |
|
|
Nylon |
|
Nylon |
Nylon |
Nylon |
Nylon |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
Filter |
|
Quantity |
|
Pieces |
2 |
|
2 |
|
2 |
2 |
2 |
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
Size (W×H×D) |
mm |
447 X 885 X 10 |
|
447 X 885 X 10 |
447 X 885 X 10 |
566 X 814 X 10 |
566 X 814 X 10 |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
Shipping |
|
Qty'Per |
|
Pieces |
12/28/28 |
|
12/28/28 |
|
12/28/28 |
8/16/16 |
8/16/16 |
|
|
20'/40'/40'HQ |
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
Note: |
|
|
|
|
|
|
|
|
|
|
|
|
The data are based on the following conditions:
Cooling: (1): Indoor Temperature 26.7°C(80°F) DB / 19.4°C(67°F) WB; - Outdoor Temperature 35°C(95°F) DB. (2): Indoor Temperature 26.7°C(80°F) DB / 19.4°C(67°F) WB; - Outdoor Temperature 46°C(114°F) DB.
Heating and Power input: Indoor Temperature 20°C(68°F) DB/15°C(59°F) WB; - Outdoor Temperature 7°C(44.6°F) DB/6°C(42.8°F) DB Electrical data: Indoor Temperature 32°C(90°F) DB / 24°C(74°F) WB; - Outdoor Temperature 52°C(125°F) DB
13
MCAC-RTSM-2014-06 |
|
|
R410A Tropical Rooftop Package Unit 50Hz |
||||||
|
|
|
|
|
|
|
|
|
|
Nominal ton |
|
|
|
8.5 |
10 |
10 |
10 |
|
|
|
|
|
|
|
|
|
|
|
|
Model |
|
|
|
MRBT-085HWN1-R |
MRBT-100CWN1-R |
MRCT-100EWN1-R |
MRBT-100HWN1-R |
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Btu/h |
103000 |
120000 |
120000 |
120000 |
|
|
|
Cooling Capacity 1 |
|
|
|
|
|
|
|
|
|
kW |
30 |
35 |
35 |
35 |
|
||
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
Power Input 1 |
kW |
10.4 |
11.8 |
11.8 |
11.8 |
|
|
Cooling |
|
|
|
|
|
|
|
|
|
|
|
|
Btu/h |
85600 |
100000 |
100000 |
100000 |
|
|
|
|
|
|
|
|||||
|
|
Cooling Capacity 2 |
|
|
|
|
|
|
|
|
|
kW |
25.1 |
29.3 |
29.3 |
29.3 |
|
||
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
Power Input 2 |
kW |
11.9 |
13.1 |
13.1 |
13.1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Btu/h |
120000 |
- |
71700 |
126000 |
|
|
|
Heating Capacity |
|
|
|
|
|
|
|
Heating |
|
kW |
35 |
- |
21 |
37 |
|
||
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
Power Input |
kW |
10.1 |
- |
21 |
10.9 |
|
|
|
|
|
|
|
|
|
|
|
|
Capacity steps |
|
|
% |
0/100 |
0/100 |
0/100 |
0/100 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Power supply |
V/Ph/Hz |
380-415/3/50 |
380-415/3/50 |
380-415/3/50 |
380-415/3/50 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Max. input |
|
|
|
|
|
|
Electrical data |
|
|
kW |
14.8 |
16.8 |
16.8 |
17.6 |
|
|
|
|
|
consumption |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Max. current |
A |
27.5 |
30 |
30 |
31 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Indoor fan air flow |
CFM |
3600 |
3800 |
3800 |
3800 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
ESP |
Pa |
75 |
75 |
75 |
75 |
|
|
|
|
|
|
|
|
|
|
|
Performance |
|
EER 1 |
Btu/W.h |
9.8 |
10.2 |
10.2 |
10.2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
EER 2 |
Btu/W.h |
7.5 |
7.6 |
7.6 |
7.6 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
COP |
Btu/W.h |
11.6 |
/ |
/ |
11.6 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Number of rows |
|
3 |
3 |
3 |
3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
1.4 |
1.4 |
1.4 |
1.4 |
|
|
|
|
Fin spacing |
|
|
|
|
|
|
|
|
|
inch |
1/18'' |
1/18'' |
1/18'' |
1/18'' |
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
7.94 |
7.94 |
7.94 |
7.94 |
|
Indoor Coil |
|
Tube diameter |
|
|
|
|
|
|
|
|
inch |
5/16'' |
5/16'' |
5/16'' |
5/16'' |
|
|||
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
1117X792 |
1117X792 |
1117X792 |
1117X792 |
|
|
|
|
Coil length X height |
|
|
|
|
|
|
|
|
|
inch |
44 X31.2 |
44 X31.2 |
44 X31.2 |
44 X31.2 |
||
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Number of circuits |
|
18 |
18 |
18 |
18 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
FC centrifugal |
FC centrifugal |
FC centrifugal |
FC centrifugal |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Quantity |
|
1 |
1 |
1 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
305 |
305 |
305 |
305 |
|
|
|
|
Diameter(Width) |
|
|
|
|
|
|
|
|
|
inch |
12 |
12 |
12 |
12 |
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
Indoor fan |
|
Drive type |
|
Belt |
Belt |
Belt |
Belt |
||
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
Motors quantity |
|
1 |
1 |
1 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor model |
|
YFD90L-4-1.5 |
YFD90L-4-1.5 |
YFD90L-4-1.5 |
YFD90L-4-1.5 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor output |
kW |
1.5 |
1.5 |
1.5 |
1.5 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor rpm |
r/min |
1400 |
1400 |
1400 |
1400 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
Scroll |
Scroll |
Scroll |
Scroll |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Quantity |
|
1 |
1 |
1 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Model |
|
SH120A4ALC |
SH140A4ALC |
SH140A4ALC |
SH140A4ALC |
|
Compressor |
|
|
|
|
|
|
|
||
|
Brand |
|
Danfoss |
Danfoss |
Danfoss |
Danfoss |
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
Capacity |
Btu/h |
102200 |
119000 |
119000 |
119000 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Input |
kW |
9.462 |
10.862 |
10.862 |
10.862 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Rated load Amps |
A |
20.7 |
21.4 |
21.4 |
21.4 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
14 |
|
MCAC-RTSM-2014-06 |
|
|
|
R410A Tropical Rooftop Package Unit 50Hz |
|||||
|
(RLA) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Locked |
rotor |
|
|
|
|
|
|
|
|
|
|
|
A |
142 |
147 |
147 |
147 |
|
|
Amps(LRA) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Refrigerant oil charge |
ml |
3300 |
3300 |
3300 |
3300 |
|
||
|
|
|
|
|
|
|
|
|
|
|
Number of rows |
|
|
3 |
3 |
3 |
3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
1.6 |
1.6 |
1.6 |
1.6 |
|
|
Fin spacing |
|
|
|
|
|
|
|
|
|
|
inch |
1.6 |
1/16" |
1/16" |
1/16" |
|
||
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
7.94 |
7.94 |
7.94 |
7.94 |
|
|
Tube diameter |
|
|
|
|
|
|
|
|
Outdoor Coil |
|
inch |
5/16" |
5/16" |
5/16" |
5/16" |
|
||
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
1748X880 |
1748X880 |
1748X880 |
1748X880 |
|
|
Coil length X height |
|
|
|
|
|
|
||
|
|
|
|
inch |
68.8X34.6 |
68.8X34.6 |
68.8X34.6 |
68.8X34.6 |
|
|
|
|
|
|
|
|
|
|
|
|
Number of circuits |
|
|
20 |
20 |
20 |
20 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
|
Propeller |
Propeller |
Propeller |
Propeller |
||
|
|
|
|
|
|
|
|
|
|
|
Quantity |
|
|
1 |
1 |
1 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
700 |
700 |
700 |
700 |
|
|
Diameter(Width) |
|
|
|
|
|
|
|
|
|
|
inch |
27.6 |
27.6 |
27.6 |
27.6 |
|
||
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
Outdoor Fan |
Drive type |
|
|
Direct |
Direct |
Direct |
Direct |
||
|
|
|
|
|
|
|
|
|
|
|
Motors quantity |
|
|
1 |
1 |
1 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor model |
|
|
YS1100-6 |
YS1100-6 |
YS1100-6 |
YS1100-6 |
||
|
|
|
|
|
|
|
|
|
|
|
Motor output |
|
kW |
1.1 |
1.1 |
1.1 |
1.1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor rpm |
|
r/min |
940 |
940 |
940 |
940 |
|
|
|
|
|
|
|
|
|
|
|
|
Outdoor sound pressure level |
|
dB(A) |
72.2 |
72.2 |
72.2 |
72.2 |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
|
R410A |
R410A |
R410A |
R410A |
|
|
|
|
|
|
|
|
|
|
|
Refrigerant |
|
Refrigerant volume |
Kg |
6.8 |
6.7 |
6.7 |
7.5 |
|
|
|
|
|
|
|
|
|
|
||
|
|
Refrigerant Control |
|
Capillary |
Capillary |
Capillary |
Capillary |
||
|
|
|
|
|
|
|
|
|
|
Standard controller |
|
|
|
|
KJR-12B |
KJR-12B |
KJR-12B |
KJR-12B |
|
|
|
|
|
|
|
|
|
|
|
Operation temp |
|
|
|
|
17~30 |
17~30 |
17~30 |
17~30 |
|
|
|
|
|
|
|
|
|
|
|
Outdoor ambient |
|
Cooling |
|
|
18~52 |
18~52 |
18~52 |
18~52 |
|
|
|
|
|
|
|
|
|
|
|
temp |
|
Heating |
|
|
-10~24 |
- |
- |
-10~24 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Net(W×H×D) |
|
mm |
2165X1002X1335 |
2165X1002X1335 |
2165X1002X1335 |
2165X1002X1335 |
|
Dimensions |
|
|
|
|
|
|
|
|
|
|
Packing(W×H×D) |
mm |
2220X1040X1415 |
2220X1040X1415 |
2220X1040X1415 |
2220X1040X1415 |
|||
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
Net weight |
|
Kg(Ibs) |
450(990) |
445(981) |
455(1003) |
450(992) |
|
Weight |
|
|
|
|
|
|
|
|
|
|
Gross weight |
|
Kg(Ibs) |
463(1018.6) |
458(1009.7) |
468(1031.7) |
463(1020.7) |
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
|
Nylon |
Nylon |
Nylon |
Nylon |
|
|
|
|
|
|
|
|
|
|
|
Filter |
|
Quantity |
|
Pieces |
2 |
2 |
2 |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Size (W×H×D) |
|
mm |
566 X 814 X 10 |
566 X 814 X 10 |
566 X 814 X 10 |
566 X 814 X 10 |
|
|
|
|
|
|
|
|
|
|
|
Shipping |
|
Qty'Per |
|
Pieces |
8/16/16 |
8/16/16 |
8/16/16 |
8/16/16 |
|
|
20'/40'/40'HQ |
|
|
||||||
|
|
|
|
|
|
|
|
|
|
Note: |
|
|
|
|
|
|
|
|
|
The data are based on the following conditions:
Cooling: (1): Indoor Temperature 26.7°C(80°F) DB / 19.4°C(67°F) WB; - Outdoor Temperature 35°C(95°F) DB. (2): Indoor Temperature 26.7°C(80°F) DB / 19.4°C(67°F) WB; - Outdoor Temperature 46°C(114°F) DB.
Heating and Power input: Indoor Temperature 20°C(68°F) DB/15°C(59°F) WB; - Outdoor Temperature 7°C(44.6°F) DB/6°C(42.8°F) DB Electrical data: Indoor Temperature 32°C(90°F) DB / 24°C(74°F) WB; - Outdoor Temperature 52°C(125°F) DB
15
|
MCAC-RTSM-2014-06 |
|
|
|
|
R410A Tropical Rooftop Package Unit 50Hz |
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Nominal ton |
|
|
|
|
|
|
12.5 |
12.5 |
15 |
15 |
15 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Model |
|
|
|
|
|
|
MRBT-125CWN1 |
MRBT-125HWN1 |
MRBT-150CWN1 |
MRCT-150EWN1 |
MRBT-150HWN1 |
|
|
|
|
|
|
|
|
|
-R |
-R |
-R |
-R |
-R |
|
||
|
|
|
|
|
|
|
|
|
|
|||||
|
|
Cooling Capacity |
|
|
Btu/h |
150000 |
150000 |
180000 |
180000 |
180000 |
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
1 |
|
|
|
|
|
kW |
43 |
43 |
53 |
53 |
53 |
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Power Input 1 |
|
|
|
|
kW |
15.3 |
15.3 |
18.6 |
18.6 |
18.6 |
|
|
|
Cooling |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Cooling Capacity |
|
|
Btu/h |
125600 |
125600 |
159600 |
159600 |
159600 |
|
||||
|
|
|
|
|
||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
2 |
|
|
|
|
|
kW |
34.2 |
34.2 |
46.7 |
46.7 |
46.7 |
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Power Input 2 |
|
|
|
|
kW |
16.8 |
16.8 |
21.3 |
21.3 |
21.3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Btu/h |
- |
175000 |
- |
102400 |
191000 |
|
|
|
|
Heating Capacity |
|
|
|
|
|
|
|
|
|
|
||
|
Heating |
|
|
|
kW |
- |
49 |
- |
30 |
56 |
|
|||
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Power Input |
|
|
|
|
kW |
- |
14.2 |
- |
30 |
17.5 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Capacity steps |
|
|
|
|
% |
0/50/100 |
0/50/100 |
0/50/100 |
0/50/100 |
0/50/100 |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Power supply |
|
|
V/Ph/Hz |
380-415/3/50 |
380-415/3/50 |
380-415/3/50 |
380-415/3/50 |
380-415/3/50 |
|
||
|
Electrical |
|
|
|
|
|
|
|
|
|
|
|
||
|
Max. input |
|
|
|
kW |
22 |
22.2 |
27 |
27 |
27.8 |
|
|||
|
data |
consumption |
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Max. current |
|
|
|
A |
41.6 |
41.8 |
53 |
53 |
54.7 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Indoor |
air |
|
|
CFM |
5200 |
5200 |
6600 |
6600 |
6600 |
|
|
|
|
|
flow |
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
ESP |
|
|
|
|
Pa |
90 |
90 |
90 |
90 |
90 |
|
|
Performance |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
EER 1 |
|
|
|
Btu/W.h |
9.8 |
9.8 |
9.7 |
9.7 |
9.7 |
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
EER 2 |
|
|
|
Btu/W.h |
7.5 |
7.5 |
7.5 |
7.5 |
7.5 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
COP |
|
|
|
Btu/W.h |
- |
11.8 |
/ |
/ |
11 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Number of rows |
|
|
3 |
3 |
3 |
3 |
3 |
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
1.5 |
1.5 |
1.4 |
1.4 |
1.4 |
|
|
|
|
Fin spacing |
|
|
|
|
|
|
|
|
|||
|
|
|
|
inch |
1/16'' |
1/16'' |
1/18'' |
1/18'' |
1/18'' |
|
||||
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
7 |
7 |
7.94 |
7.94 |
7.94 |
|
|
Indoor Coil |
Tube diameter |
|
|
|
|
|
|
|
|
||||
|
|
inch |
9/32'' |
9/32'' |
5/16'' |
5/16'' |
5/16'' |
|
||||||
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Coil length X |
|
mm |
1182X1008 |
1182X1008 |
1607X880 |
1607X880 |
1607X880 |
|
|||
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
height |
|
|
|
|
inch |
46.5x40 |
46.5x40 |
63.3X346. |
63.3X346. |
63.3X346. |
|
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
Number of circuits |
16+8 |
16+8 |
10+10 |
10+10 |
10+10 |
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
|
|
|
|
Centrifugal |
Centrifugal |
FC centrifugal |
FC centrifugal |
FC centrifugal |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Quantity |
|
|
|
|
|
1 |
1 |
1 |
1 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
383 |
383 |
383 |
383 |
383 |
|
|
|
|
Diameter(Width) |
|
|
|
|
|
|
|
|
|||
|
|
|
|
inch |
15 |
15 |
15 |
15 |
15 |
|
||||
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
Indoor fan |
Drive type |
|
|
Belt |
Belt |
Belt |
Belt |
Belt |
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
Motors quantity |
|
|
1 |
1 |
1 |
1 |
1 |
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
Motor model |
|
|
Y2-100L2-4 |
Y2-100L2-4 |
YFD132S-4-5.5 |
YFD132S-4-5.5 |
YFD132S-4-5.5 |
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
Motor output |
|
kW |
2.7 |
2.7 |
5.5 |
5.5 |
5.5 |
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
Motor rpm |
|
r/min |
1420 |
1420 |
1440 |
1440 |
1440 |
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
|
|
|
|
Scroll |
Scroll |
Scroll |
Scroll |
Scroll |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Quantity |
|
|
|
|
|
2 |
2 |
2 |
2 |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
ZP61KCE-TFD-5 |
ZP61KCE-TFD-5 |
|
|
|
|
|
|
|
Model |
|
|
|
|
|
22 |
22 |
SH105A4ALC |
SH105A4ALC |
SH105A4ALC |
|
|
|
|
|
|
|
|
|
+ZP120KCE-TFD |
+ZP120KCE-TFD |
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
-522 |
-522 |
|
|
|
|
|
Compressor |
Brand |
|
|
|
|
|
Copeland |
Copeland |
Danfoss |
Danfoss |
Danfoss |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Capacity |
|
|
|
|
Btu/h |
50000+99500 |
50000+99500 |
91500 |
91500 |
91500 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Input |
|
|
|
|
kW |
4.75+9.2 |
4.75+9.2 |
8.472 |
8.472 |
8.472 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Rated |
load |
|
|
A |
10.9+20 |
10.9+20 |
16.7 |
16.7 |
16.7 |
|
|
|
|
|
Amps (RLA) |
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
Locked |
rotor |
|
|
A |
64+118 |
64+118 |
156 |
156 |
156 |
|
|
|
|
|
Amps(LRA) |
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
16 |
|
|
MCAC-RTSM-2014-06 |
|
|
|
|
R410A Tropical Rooftop Package Unit 50Hz |
|
|||||
|
|
|
Refrigerant oil |
|
|
ml |
1685+3253 |
1685+3253 |
3000 |
3000 |
3000 |
|
|
|
|
charge |
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Number of rows |
|
|
3.5 |
4.5 |
3 |
3 |
3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
1.5 |
1.5 |
1.6 |
1.6 |
1.6 |
|
|
|
|
Fin spacing |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
inch |
1/16" |
1/16" |
1/16" |
1/16" |
1/16" |
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
7 |
7 |
7.94 |
7.94 |
7.94 |
|
|
|
|
Tube diameter |
|
|
|
|
|
|
|
|
|
|
Outdoor Coil |
|
|
|
inch |
9/32" |
9/32" |
5/16" |
5/16" |
5/16" |
|
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
1770X1050+854X |
1770X1050+854X |
2179X1100 |
2179X1100 |
2179X1100 |
|
|
|
|
|
|
|
|
|
||||||
|
|
|
Coil length X |
|
|
1050 |
1050 |
|
||||
|
|
|
|
|
|
|
|
|
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
height |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
inch |
70x41+33.6x41 |
70x41+33.6x41 |
85.8X43.3 |
85.8X43.3 |
85.8X43.3 |
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Number of |
|
|
|
16+9 |
16+9 |
12+12 |
12+12 |
12+12 |
|
|
|
|
circuits |
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
|
Propeller |
Propeller |
Propeller |
Propeller |
Propeller |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Quantity |
|
|
1 |
1 |
2 |
2 |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
650 |
650 |
650 |
650 |
650 |
|
|
|
|
Diameter(Width) |
|
|
|
|
|
|
|
|
|
|
|
|
|
inch |
25-19/32 |
25-19/32 |
25.6 |
25.6 |
25.6 |
|
||
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Outdoor Fan |
|
Drive type |
|
|
Direct |
Direct |
Direct |
Direct |
Direct |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motors quantity |
|
|
1 |
1 |
2 |
2 |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor model |
|
|
YS1100-6 |
YS1100-6 |
YS600-6P |
YS600-6P |
YS600-6P |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor output |
|
|
kW |
1.3 |
1.3 |
0.6 X 2 |
0.6 X 2 |
0.6 X 2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor rpm |
|
|
r/min |
940 |
940 |
930 |
930 |
930 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Outdoor sound pressure level |
|
dB(A) |
72.3 |
72.3 |
72.4 |
72.4 |
72.4 |
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
|
R410A |
R410A |
R410A |
R410A |
R410A |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Refrigerant |
|
Refrigerant |
|
|
Kg |
4.6+2.2 |
5.4+3 |
5.8 X 2 |
5.8 X 2 |
6.5 X 2 |
|
|
|
volume |
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Refrigerant Control |
Capillary |
Capillary |
Capillary |
Capillary |
Capillary |
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Standard controller |
|
|
KJR-12B |
KJR-12B |
KJR-12B |
KJR-12B |
KJR-12B |
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Operation temp |
|
|
|
|
17~30 |
17~30 |
17~30 |
17~30 |
17~30 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Outdoor |
|
Cooling |
|
|
18~52 |
18~52 |
18~52 |
18~52 |
18~52 |
|
|
|
ambient |
|
|
|
|
|
|
|
|
|
|
|
|
|
Heating |
|
|
- |
-10~24 |
- |
- |
-10~24 |
|
||
|
temp |
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Net(W×H×D) |
|
mm |
2230x1245x1400 |
2230x1245x1400 |
2229X1245X1825 |
2229 |
2229 |
|
|
|
|
|
|
X1245X1825 |
X1245X1825 |
|
||||||
|
Dimensions |
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Packing(W×H× |
|
mm |
2265x1280x1455 |
2265x1280x1455 |
2236 |
2236 |
2236 |
|
|
|
|
|
D) |
|
X1280X1855 |
X1280X1855 |
X1280X1855 |
|
||||
|
|
|
|
|
|
|
|
|||||
|
|
|
Net weight |
kg(Ibs) |
520 |
550 |
710/ (1565.3) |
720/ (1609.3) |
730/ (1609.3) |
|
||
|
Weight |
|
|
|
|
|
|
|
|
|
|
|
|
|
Gross weight |
kg(Ibs) |
535 |
565 |
730(1609.3) |
740(1653.4) |
750(1653.4) |
|
|||
|
|
|
|
|||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
|
Nylon |
Nylon |
Nylon |
Nylon |
Nylon |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Filter |
|
Quantity |
|
Pieces |
2 |
2 |
2 |
2 |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Size (W×H×D) |
|
|
mm |
605x1045x12.5 |
605x1045x12.5 |
900 X 815 X 12.5 |
900 X 815 X 12.5 |
900 X 815 X 12.5 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Shipping |
|
Qty'Per |
|
Pieces |
4/8/16 |
4/8/16 |
3/6/12 |
3/6/12 |
3/6/12 |
|
|
|
|
20'/40'/40'HQ |
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Note: |
|
|
|
|
|
|
|
|
|
|
|
The data are based on the following conditions:
Cooling: (1): Indoor Temperature 26.7°C(80°F) DB / 19.4°C(67°F) WB; - Outdoor Temperature 35°C(95°F) DB. (2): Indoor Temperature 26.7°C(80°F) DB / 19.4°C(67°F) WB; - Outdoor Temperature 46°C(114°F) DB.
Heating and Power input: Indoor Temperature 20°C(68°F) DB/15°C(59°F) WB; - Outdoor Temperature 7°C(44.6°F) DB/6°C(42.8°F) DB Electrical data: Indoor Temperature 32°C(90°F) DB / 24°C(74°F) WB; - Outdoor Temperature 52°C(125°F) DB
17
|
MCAC-RTSM-2014-06 |
|
|
|
|
|
R410A Tropical Rooftop Package Unit 50Hz |
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Nominal ton |
|
|
|
|
|
17.5 |
17.5 |
17.5 |
20 |
20 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Model |
|
|
|
|
|
MRBT-175CW |
MRCT-175EWN1- |
MRBT-175HWN1- |
MRBT-200CWN1- |
MRCT-200EWN1 |
|
|
|
|
|
|
|
|
N1-R |
R |
R |
R |
-R |
|
||
|
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
Btu/h |
210000 |
210000 |
210000 |
240000 |
240000 |
|
|
|
Cooling Capacity 1 |
|
|
|
|
|
|
|
|
|
||
|
|
|
kW |
60 |
60 |
60 |
70 |
70 |
|
||||
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Power Input 1 |
|
|
kW |
20 |
20 |
20 |
23.6 |
23.6 |
|
||
|
Cooling |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Btu/h |
180600 |
180600 |
180600 |
213000 |
213000 |
|
|
|
|
|
|
|
|
|
|
||||||
|
|
Cooling Capacity 2 |
|
|
|
|
|
|
|
|
|
||
|
|
|
|
kW |
52.9 |
52.9 |
52.9 |
62.4 |
62.4 |
|
|||
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Power Input 2 |
|
|
kW |
23.5 |
23.5 |
23.5 |
27.7 |
27.7 |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Btu/h |
- |
102400 |
191000 |
- |
133100 |
|
|
|
Heating Capacity |
|
|
|
|
|
|
|
|
|
||
|
Heating |
|
|
kW |
- |
30 |
67 |
- |
39 |
|
|||
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Power Input |
|
|
|
kW |
- |
30 |
19.8 |
- |
39 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Capacity steps |
|
|
% |
0/50/100 |
0/50/100 |
0/50/100 |
0/50/100 |
0/50/100 |
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Power supply |
|
V/Ph/Hz |
380-415/3/50 |
380-415/3/50 |
380-415/3/50 |
380-415/3/50 |
380-415/3/50 |
|
||
|
Electrical |
|
|
|
|
|
|
|
|
|
|
||
|
Max. input |
|
|
kW |
30.1 |
30.1 |
30.7 |
35 |
35 |
|
|||
|
data |
consumption |
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Max. current |
|
|
A |
57.8 |
57.8 |
58.2 |
66 |
66 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Indoor |
fan air |
|
|
CFM |
7300 |
7300 |
7300 |
8400 |
8400 |
|
|
|
|
flow |
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
ESP |
|
|
|
Pa |
90 |
90 |
90 |
100 |
100;; |
|
|
Performance |
|
|
|
|
|
|
|
|
|
|
|
|
|
EER 1 |
|
|
Btu/W.h |
10.2 |
10.2 |
10.2 |
10.1 |
10.1 |
|
|||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
EER 2 |
|
|
Btu/W.h |
7.7 |
7.7 |
7.7 |
7.6 |
7.6 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
COP |
|
|
Btu/W.h |
/ |
/ |
11.5 |
/ |
/ |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Number of rows |
|
|
|
3 |
3 |
3 |
3 |
3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
1.4 |
1.4 |
1.4 |
1.6 |
1.6 |
|
|
|
|
Fin spacing |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
inch |
1/18'' |
1/18'' |
1/18'' |
1/16'' |
1/16'' |
|
||
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
7.94 |
7.94 |
7.94 |
7.94 |
7.94 |
|
|
Indoor Coil |
Tube diameter |
|
|
|
|
|
|
|
|
|
||
|
|
|
inch |
5/16'' |
5/16'' |
5/16'' |
5/16'' |
5/16'' |
|
||||
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Coil length X |
|
|
mm |
1607X880 |
1607X880 |
1607X880 |
1882X1012 |
1882X1012 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
height |
|
|
|
inch |
63.3X346. |
63.3X346. |
63.3X346. |
74.1X39.8 |
74.1X39.8 |
|
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Number of |
|
|
|
10+10 |
10+10 |
10+10 |
11+12 |
11+12 |
|
|
|
|
|
circuits |
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
|
|
|
FC centrifugal |
FC centrifugal |
FC centrifugal |
FC centrifugal |
FC centrifugal |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Quantity |
|
|
|
1 |
1 |
1 |
1 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
383 |
383 |
383 |
452 |
452 |
|
|
|
|
Diameter(Width) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
inch |
15 |
15 |
15 |
17.8 |
17.8 |
|
||
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Indoor fan |
Drive type |
|
|
|
Belt |
Belt |
Belt |
Belt |
Belt |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
||
|
Motors quantity |
|
|
|
1 |
1 |
1 |
1 |
1 |
|
|||
|
|
|
|
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor model |
|
|
|
YFD132S-4-5. |
YFD132S-4-5.5 |
YFD132S-4-5.5 |
YFD132S-4-5.5 |
YFD132S-4-5.5 |
|
|
|
|
|
|
|
|
5 |
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor output |
|
|
kW |
5.5 |
5.5 |
5.5 |
5.5 |
5.5 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor rpm |
|
|
r/min |
1440 |
1440 |
1440 |
1440 |
1440 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
|
|
|
Scroll |
Scroll |
Scroll |
Scroll |
Scroll |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Quantity |
|
|
|
2 |
2 |
2 |
2 |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Model |
|
|
|
|
SH120A4ALC |
SH105A4ALC |
SH120A4ALC |
SH140A4ALC |
SH140A4ALC |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Brand |
|
|
|
|
Danfoss |
Danfoss |
Danfoss |
Danfoss |
Danfoss |
|
|
Compressor |
|
|
|
|
|
|
|
|
|
|
|
|
|
Capacity |
|
|
Btu/h |
102200 |
102200 |
102200 |
119000 |
119000 |
|
|||
|
|
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Input |
|
|
|
kW |
9.462 |
9.462 |
9.462 |
10.862 |
10.862 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Rated |
load |
|
|
A |
20.7 |
20.7 |
20.7 |
21.4 |
21.4 |
|
|
|
|
Amps (RLA) |
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
Locked |
rotor |
|
|
A |
142 |
142 |
142 |
147 |
147 |
|
|
|
|
Amps(LRA) |
|
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
18 |
|
|
MCAC-RTSM-2014-06 |
|
|
|
R410A Tropical Rooftop Package Unit 50Hz |
|
|||||
|
|
|
Refrigerant oil |
|
ml |
3300 |
3300 |
3300 |
3300 |
3300 |
|
|
|
|
charge |
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Number of rows |
|
3 |
3 |
3 |
4 |
4 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
1.6 |
1.6 |
1.6 |
1.6 |
1.6 |
|
|
|
|
Fin spacing |
|
|
|
|
|
|
|
|
|
|
|
|
inch |
1/16" |
1/16" |
1/16" |
1/16" |
1/16" |
|
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
7.94 |
7.94 |
7.94 |
7.94 |
7.94 |
|
|
Outdoor Coil |
Tube diameter |
|
|
|
|
|
|
|
|
|
|
|
inch |
5/16" |
5/16" |
5/16" |
5/16" |
5/16" |
|
|||
|
|
|
|
||||||||
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Coil length X |
|
mm |
2179X1100 |
2179X1100 |
2179X1100 |
2650X1100 |
2650X1100 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
height |
|
inch |
85.8X43.3 |
85.8X43.3 |
85.8X43.3 |
104.3X43.3 |
104.3X43.3 |
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Number of |
|
|
12+12 |
12+12 |
12+12 |
11+12 |
11+12 |
|
|
|
|
circuits |
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
Propeller |
Propeller |
Propeller |
Propeller |
Propeller |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Quantity |
|
2 |
2 |
2 |
2 |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
650 |
650 |
650 |
750 |
750 |
|
|
|
|
Diameter(Width) |
|
|
|
|
|
|
|
|
|
|
|
inch |
25.6 |
25.6 |
25.6 |
29.5 |
29.5 |
|
||
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Outdoor Fan |
Drive type |
|
Direct |
Direct |
Direct |
Direct |
Direct |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motors quantity |
|
2 |
2 |
2 |
2 |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor model |
|
YS1100-6 |
YS1100-6 |
YS1100-6 |
YS1500-6 |
YS1500-6 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor output |
|
kW |
1.3 X 2 |
1.3 X 2 |
1.3 X 2 |
1.5 X 2 |
1.5 X 2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor rpm |
|
r/min |
940 |
940 |
940 |
910 |
910 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Outdoor sound pressure level |
|
dB(A) |
72.4 |
72.4 |
72.4 |
74.2 |
74.2 |
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
R410A |
R410A |
R410A |
R410A |
R410A |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Refrigerant |
|
Refrigerant |
|
Kg |
5.2X 2 |
5.2 X 2 |
5.6 X 2 |
8.1 X 2 |
8.1 X 2 |
|
|
|
volume |
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Refrigerant Control |
|
Capillary |
Capillary |
Capillary |
Capillary |
Capillary |
|
|
|
|
|
|
|
|
|
|
|
|
||
|
Standard controller |
|
KJR-12B |
KJR-12B |
KJR-12B |
KJR-12B |
KJR-12B |
|
|||
|
|
|
|
|
|
|
|
|
|||
|
Operation temp |
|
17~30 |
17~30 |
17~30 |
17~30 |
17~30 |
|
|||
|
|
|
|
|
|
|
|
|
|
||
|
Outdoor |
|
Cooling |
|
18~52 |
18~52 |
18~52 |
18~52 |
18~52 |
|
|
|
ambient |
|
|
|
|
|
|
|
|
|
|
|
|
Heating |
|
- |
- |
-10~24 |
- |
- |
|
||
|
temp |
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Net(W×H×D) |
mm |
2229 |
2229 |
2229 |
2753 |
2753 |
|
|
|
|
|
X1245X1825 |
X1245X1825 |
X1245X1825 |
X1245X2157 |
X1245X2157 |
|
|||
|
Dimensions |
|
|
|
|
|
|||||
|
|
Packing(W×H×D) |
mm |
2236 |
2236 |
2236 |
2760 |
2760 |
|
||
|
|
|
|
||||||||
|
|
|
X1280X1855 |
X1280X1855 |
X1280X1855 |
X1280X2175 |
X1280X2175 |
|
|||
|
|
|
|
|
|
|
|||||
|
|
|
Net weight |
Kg(Ibs) |
710/ (1565.3) |
720/ (1609.3) |
730/ (1609.3) |
925(2039.2) |
940(2072.3) |
|
|
|
Weight |
|
|
|
|
|
|
|
|
|
|
|
|
Gross weight |
Kg(Ibs) |
730(1609.3) |
740(1653.4) |
750(1653.4) |
940(2072.3) |
955(2105.4) |
|
||
|
|
|
|
||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
Nylon |
Nylon |
Nylon |
Nylon |
Nylon |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Filter |
|
Quantity |
|
Pieces |
2 |
2 |
2 |
3 |
3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Size (W×H×D) |
|
mm |
900 X 815 X |
900 X 815 X 12.5 |
900 X 815 X 12.5 |
640 X 1008 X |
640 X 1008 X |
|
|
|
|
|
12.5 |
12.5 |
12.5 |
|
||||
|
|
|
|
|
|
|
|
|
|||
|
Shipping |
|
Qty'Per |
|
Pieces |
3/6/12 |
3/6/12 |
3/6/12 |
3/4/8 |
3/4/8 |
|
|
|
20'/40'/40'HQ |
|
|
|||||||
|
|
|
|
|
|
|
|
|
|
|
|
Note:
The data are based on the following conditions:
Cooling: (1): Indoor Temperature 26.7°C(80°F) DB / 19.4°C(67°F) WB; - Outdoor Temperature 35°C(95°F) DB. (2): Indoor Temperature 26.7°C(80°F) DB / 19.4°C(67°F) WB; - Outdoor Temperature 46°C(114°F) DB.
Heating and Power input: Indoor Temperature 20°C(68°F) DB/15°C(59°F) WB; - Outdoor Temperature 7°C(44.6°F) DB/6°C(42.8°F) DB Electrical data: Indoor Temperature 32°C(90°F) DB / 24°C(74°F) WB; - Outdoor Temperature 52°C(125°F) DB
19
|
MCAC-RTSM-2014-06 |
|
|
|
R410A Tropical Rooftop Package Unit 50Hz |
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
Nominal ton |
|
|
|
|
20 |
30 |
30 |
30 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Model |
|
|
|
|
MRBT-200HWN1-R |
MRCT-300CWN1-R |
MRCT-300EWN1-R |
MRCT-300HWN1-R |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Btu/h |
240000 |
358000 |
358000 |
358000 |
|
|
|
Cooling Capacity 1 |
|
|
|
|
|
|
||
|
|
kW |
70 |
105 |
105 |
105 |
|
|||
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Power Input 1 |
|
kW |
23.6 |
35.8 |
35.8 |
35.8 |
|
|
|
Cooling |
|
|
|
|
|
|
|
|
|
|
|
|
|
Btu/h |
213000 |
328600 |
328600 |
328600 |
|
|
|
|
|
|
|
|
|||||
|
|
Cooling Capacity 2 |
|
|
|
|
|
|
||
|
|
kW |
62.4 |
96 |
96 |
96 |
|
|||
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Power Input 2 |
|
kW |
27.7 |
43.8 |
43.8 |
43.8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Btu/h |
256000 |
- |
133000 |
358000 |
|
|
|
Heating Capacity |
|
|
|
|
|
|
|
|
|
Heating |
|
kW |
75 |
- |
39 |
105 |
|
||
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
Power Input |
|
kW |
23.4 |
- |
39 |
34.8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Capacity steps |
|
|
|
% |
0/50/100 |
0/50/100 |
0/50/100 |
0/50/100 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Power supply |
V/Ph/Hz |
380-415/3/50 |
380-415/3/50 |
380-415/3/50 |
380-415/3/50 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Electrical data |
|
Max. input |
|
kW |
35.7 |
48 |
48 |
48.6 |
|
|
|
consumption |
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Max. current |
|
A |
69.2 |
92 |
92 |
93.1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Indoor fan air flow |
CFM |
8400 |
13400 |
13400 |
13400 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
ESP |
|
Pa |
100 |
250 |
250 |
250 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Performance |
|
EER 1 |
|
Btu/W.h |
10.1 |
10.8 |
10.8 |
10.8 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
EER 2 |
|
Btu/W.h |
7.6 |
7.5 |
7.5 |
7.5 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
COP |
|
Btu/W.h |
11 |
- |
- |
10.3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Number of rows |
|
3 |
3 |
3 |
3 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
1.6 |
1.5 |
1.5 |
1.5 |
|
|
|
|
Fin spacing |
|
|
|
|
|
|
|
|
|
|
|
inch |
1/16'' |
1/16'' |
1/16'' |
1/16'' |
|
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
7.94 |
7 |
7 |
7 |
|
|
Indoor Coil |
|
Tube diameter |
|
|
|
|
|
|
|
|
|
inch |
5/16'' |
9/32'' |
9/32'' |
9/32'' |
|
|||
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Coil length X |
|
mm |
1882X1012 |
1882X1428 |
1882X1428 |
1882X1428 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
height |
|
inch |
74.1X39.8 |
74.1X56.2 |
74.1X56.2 |
74.1X56.2 |
|
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Number of circuits |
|
11+12 |
17+17 |
17+17 |
17+17 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
|
FC centrifugal |
FC centrifugal |
FC centrifugal |
FC centrifugal |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Quantity |
|
|
1 |
1 |
1 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
452 |
500 |
500 |
500 |
|
|
|
|
Diameter(Width) |
|
|
|
|
|
|
|
|
|
|
inch |
17.8 |
19.7 |
19.7 |
19.7 |
|
||
|
|
|
|
|
|
|||||
|
Indoor fan |
|
|
|
|
|
|
|
|
|
|
|
Drive type |
|
|
Belt |
Belt |
Belt |
Belt |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motors quantity |
|
1 |
1 |
1 |
1 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor model |
|
|
YFD132S-4-5.5 |
Y(2)132M-4-7.5 |
Y(2)132M-4-7.5 |
Y(2)132M-4-7.5 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor output |
|
kW |
5.5 |
7.5 |
7.5 |
7.5 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Motor rpm |
|
r/min |
1440 |
1440 |
1440 |
1440 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
|
Scroll |
Scroll |
Scroll |
Scroll |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Quantity |
|
|
2 |
2 |
2 |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Model |
|
|
SH140A4ALC |
SH184A4ALC |
SH184A4ALC |
SH184A4ALC |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Brand |
|
|
Danfoss |
Danfoss |
Danfoss |
Danfoss |
|
|
|
|
|
|
|
|
|
|
|
|
|
Compressor |
|
Capacity |
|
Btu/h |
119000 |
152426 |
152426 |
152426 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Input |
|
kW |
10.862 |
13.732 |
13.732 |
13.732 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Rated load Amps |
A |
21.4 |
27.6 |
27.6 |
27.6 |
|
|
|
|
|
(RLA) |
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Locked |
rotor |
A |
147 |
197 |
197 |
197 |
|
|
|
|
Amps(LRA) |
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Refrigerant |
oil |
ml |
3300 |
3600 |
3600 |
3600 |
|
|
|
|
charge |
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
Outdoor Coil |
|
Number of rows |
|
4 |
4 |
4 |
4 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
20 |
|
|
MCAC-RTSM-2014-06 |
|
|
R410A Tropical Rooftop Package Unit 50Hz |
|
|||
|
|
|
mm |
1.6 |
1.5 |
1.5 |
1.5 |
|
|
|
Fin spacing |
|
|
|
|
|
|
|
|
inch |
1/16" |
1/16" |
1/16" |
1/16" |
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
|
mm |
7.94 |
7 |
7 |
7 |
|
|
|
Tube diameter |
|
|
|
|
|
|
|
|
inch |
5/16" |
9/32" |
9/32" |
9/32" |
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
Coil length X |
mm |
2650X1100 |
2650X1512 |
2650X1512 |
2650X1512 |
|
|
|
|
|
|
|
|
|
|
|
|
height |
|
|
|
|
|
|
|
|
inch |
104.3X43.3 |
104.3X59.5 |
104.3X59.5 |
104.3X59.5 |
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
|
Number of circuits |
|
11+12 |
12+12 |
12+12 |
12+12 |
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
Propeller |
Propeller |
Propeller |
Propeller |
|
|
|
|
|
|
|
|
|
|
|
|
Quantity |
|
2 |
2 |
2 |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
|
mm |
750 |
750 |
750 |
750 |
|
|
|
Diameter(Width) |
|
|
|
|
|
|
|
|
inch |
29.5 |
29.5 |
29.5 |
29.5 |
|
|
|
|
|
|
|||||
|
|
|
|
|
|
|
|
|
|
Outdoor Fan |
Drive type |
|
Direct |
Direct |
Direct |
Direct |
|
|
|
|
|
|
|
|
|
|
|
|
Motors quantity |
|
2 |
2 |
2 |
2 |
|
|
|
|
|
|
|
|
|
|
|
|
Motor model |
|
YS1500-6 |
YS1500-6 |
YS1500-6 |
YS1500-6 |
|
|
|
|
|
|
|
|
|
|
|
|
Motor output |
KW |
1.5 X 2 |
1.5 X 2 |
1.5 X 2 |
1.5 X 2 |
|
|
|
|
|
|
|
|
|
|
|
|
Motor rpm |
r/min |
910 |
910 |
910 |
910 |
|
|
|
|
|
|
|
|
|
|
|
Outdoor sound pressure level |
dB(A) |
74.2 |
75.1 |
75.1 |
75.4 |
|
|
|
|
|
|
|
|
|
|
|
|
|
Type |
|
R410A |
R410A |
R410A |
R410A |
|
|
|
|
|
|
|
|
|
|
|
Refrigerant |
Refrigerant |
Kg |
8.8 X 2 |
8.3 X 2 |
8.3 X 2 |
9.4 X 2 |
|
|
volume |
|
||||||
|
|
|
|
|
|
|
|
|
|
|
Refrigerant Control |
|
Capillary |
Capillary |
Capillary |
Capillary |
|
|
|
|
|
|
|
|
|
|
|
Standard controller |
|
|
KJR-12B |
KJR-12B |
KJR-12B |
KJR-12B |
|
|
|
|
|
|
|
|
|
|
|
Operation temp |
|
|
17~30 |
17~30 |
17~30 |
17~30 |
|
|
|
|
|
|
|
|
|
|
|
Outdoor ambient |
Cooling |
|
18~52 |
18~52 |
18~52 |
18~52 |
|
|
|
|
|
|
|
|
|
|
|
temp |
Heating |
|
-10~24 |
|
|
-10~24 |
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
Net(W×H×D) |
mm |
2753 X1245X2157 |
2753 X1674X2157 |
2753 X1674X2157 |
2753 X1674X2157 |
|
|
Dimensions |
|
|
|
|
|
|
|
|
Packing(W×H×D) |
mm |
2760 X1280X2175 |
2755 X1690X2180 |
2755 X1690X2180 |
2755 X1690X2180 |
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
Net weight |
Kg(Ibs) |
940(2072.3) |
1100(2425) |
1130(2491.2) |
1130(2491.2) |
|
|
Weight |
|
|
|
|
|
|
|
|
Gross weight |
Kg(Ibs) |
955(2105.4) |
1110(2447) |
1140(2513.2) |
1140(2513.2) |
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
|
|
|
Type |
|
Nylon |
Nylon |
Nylon |
Nylon |
|
|
|
|
|
|
|
|
|
|
|
Filter |
Quantity |
Pieces |
3 |
3 |
3 |
3 |
|
|
|
|
|
|
|
|
|
|
|
|
Size (W×H×D) |
mm |
640 X 1008 X 12.5 |
1492 X 640 X 12.5 |
1492 X 640 X 12.5 |
1492 X 640 X 12.5 |
|
|
|
|
|
|
|
|
|
|
|
Shipping |
Qty'Per |
Pieces |
3/4/8 |
2/4/4 |
2/4/4 |
2/4/4 |
|
|
20'/40'/40'HQ |
|
||||||
|
|
|
|
|
|
|
|
|
Note:
The data are based on the following conditions:
Cooling: (1): Indoor Temperature 26.7°C(80°F) DB / 19.4°C(67°F) WB; - Outdoor Temperature 35°C(95°F) DB. (2): Indoor Temperature 26.7°C(80°F) DB / 19.4°C(67°F) WB; - Outdoor Temperature 46°C(114°F) DB.
Heating and Power input: Indoor Temperature 20°C(68°F) DB/15°C(59°F) WB; - Outdoor Temperature 7°C(44.6°F) DB/6°C(42.8°F) DB
Electrical data: Indoor Temperature 32°C(90°F) DB / 24°C(74°F) WB; - Outdoor Temperature 52°C(125°F) DB
21
MCAC-RTSM-2014-06 |
R410A Tropical Rooftop Package Unit 50Hz |
7. Dimensional Drawings
7.15ton
22
MCAC-RTSM-2014-06 |
R410A Tropical Rooftop Package Unit 50Hz |
7.26.2&7.5ton
23
MCAC-RTSM-2014-06 |
R410A Tropical Rooftop Package Unit 50Hz |
7.38.5&10ton
24
MCAC-RTSM-2014-06 |
R410A Tropical Rooftop Package Unit 50Hz |
7.412.5ton
2214
1388
Filter occess door |
135 |
Drain connection hole
Maintain orifice for air supply motor
774 2229
800
400 863
1245
131
1400
126
115
Control and comperssor access panel
Hole for control wires
Hole for power wires
Hole for other purpose
500 |
1029 |
|
Control electric heater box access panel
Hole for electric heater power wires |
577 |
|
|
|
|
313 |
|
|
|
Horizontal supply opening |
|
360 |
143 |
|
|
|
|||
|
|
|
||
|
|
|
|
55 |
Horizontal return opening |
|
|
|
|
Fresh air
25
MCAC-RTSM-2014-06 |
R410A Tropical Rooftop Package Unit 50Hz |
7.515&17.5ton
26
MCAC-RTSM |
Unit 50Hz |
7.620ton
27
MCAC-RTSM-2014-06 |
R410A Tropical Rooftop Package Unit 50Hz |
7.730ton
|
1 |
|
|
|
4 |
|
|
Drain connection hole |
|
2 |
|
|
|
|
|
|
|
8 |
|
|
|
3 |
|
|
|
|
9 |
Maintain orifice for air supply motor
2 |
|
|
9 |
|
7 |
|
1 |
||
|
5 |
|
7 |
|
|
|
3 |
|
|
Control and comperssor access panel |
|
|||
Hole for control wires
Hole for power wires
Hole for other purpose
9 |
|
9 |
|
|
7 |
1 |
|
3 |
|
|
5 |
2 4 1
|
0 |
2 |
|
8 |
|
18
|
0 |
7 |
|
8 |
|
2157
294
1656
142
Electric heater control box access panel |
888 |
|
|
Hole for electric heater power wires |
652 |
|
|
Horizontal supply opening |
266 |
|
522 |
Horizontal return opening
644
120
1512
144 55
870
Fresh air
Filter access door
|
|
Hole for bottom installation |
16-15×20 |
|
|
|
|
|
142 |
|
|
|
|
324 |
|
|
|
|
870 |
|
|
|
|
2157 |
|
|
|
|
678 |
862 |
917 |
730 |
135 |
|
|
2693 |
|
|
|
|
2753 |
|
|
|
28
MCAC-RTSM-2014-06 |
R410A Tropical Rooftop Package Unit 50Hz |
|
|
8. Wiring Diagrams
8.15ton
MRBT-60CWN1-R
S 1
Switch SW3 to the "ON" position |
R T 3 - 1 R T 4 |
|
|
|
|
|
|
|
|
|
|
|
|
to use 12B wire controller; |
|
R T 3 |
- 2 |
R T 1 |
R T 2 - 1 |
R T 2 - 2 |
switch SW3 to the "1" position |
X p 1 |
X p 2 |
|
|
|
|
to use Honeywell wire controller. |
|
|
|
|
||
X s 1 |
X s 2 |
|
|
|
|
|
S 2
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
C N 9 |
|
C N 2 0 |
|
C N 2 1 |
|
C N 2 3 |
C N 2 4 |
C N 2 5 |
|
|
C N 4 2 |
|
|
C N 1 3 |
|
|
|
|
|
|
|
|
|
||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
MAIN CONTROL BOARD |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
4 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
0 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
N |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
C |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
FAN2 |
FAN1 |
COMP
|
|
202096090259 |
||
|
|
WIRING DIAGRAM |
||
|
CODE |
|
|
PART NAME |
|
|
|
|
|
|
COMP |
|
|
COMPRESSOR |
|
|
|
|
|
|
FAN1 |
|
|
INDOOR FAN |
|
FAN2 |
|
|
OUTDOOR FAN |
|
CAP1 |
|
|
INDOOR FAN CAP |
|
CAP2 |
|
|
OUTDOOR FAN CAP |
|
XP1~2 Xp8 |
|
|
CONNECTORS |
|
|
|
|
|
|
XS1~2 Xs8 |
|
|
CONNECTORS |
|
|
|
|
|
|
RT1 RT3-1 |
|
|
TEMP.SENSOR |
|
|
|
|
10K RESISTANCE |
|
|
|
|
|
|
|
|
|
|
|
KM1 |
|
|
AC CONTACTOR |
|
|
|
|
|
|
T2 |
|
|
TRANSFORMER(24V~) |
|
T1 |
|
|
TRANSFORMER |
|
|
|
|
|
|
K1 |
|
|
COMP.TEMP. SWITH |
|
RY |
|
|
RELAY |
|
H/L-PRO |
|
|
HIGH/LOW PRESS SWITCH |
|
XT1 |
|
|
5-WAY TERMINAL |
|
|
|
|
|
|
XT2-5 |
|
|
MIDDLE TERMINAL |
|
|
|
|
|
|
Xt6 |
|
|
SMALL 6-WAY TERMINAL |
|
|
|
|
|
POWER
29
MCAC-RTSM-2014-06 |
R410A Tropical Rooftop Package Unit 50Hz |
|
|
8.2 6.2ton MRBT-062CWN1-R
30
Loading...
