Thank you for purchasing your new Logitech® QuickCam®,

1

the world’s most popular web cameras.

Camera Features

1

Privacy shade

Lens

Flexible base

Snapshot button

Activity light

Microphone

English

1

Install the Software

2

2

1.

Install the software

2.

During software installation, you are prompted to connect the camera USB cable to the USB port:

•

Wait

until you receive the software prompt

USB port.

• Complete software and hardware installation by following the on-screen instructions. These
instructions include an audio tuning wizard, which will ensure optimum audio performance.
See the

FIRST

and follow the on-screen instructions.

Audio Setup Guide

before

for more information.

inserting the cable into the computer’s

2

English

Launch the Software

3

4

5

3

1.

To launch the software, double-click the Logitech® QuickCam® shortcut on the desktop,
or click Start on the Windows® Taskbar, and then select Programs\Logitech\Logitech QuickCam.

2.

Choose your favorite video instant messaging application, or choose one of the other available
software activities.

Position the Camera and Your Speakers

4

1.

Place the camera in the middle of your computer monitor
for optimal eye contact.

2.

The camera can be placed on a tabletop or held in your hand
to snap a picture or video.

3.

Pivot the camera up or down for the best position.

4.

If you are using the camera with desktop speakers (not included),
angle the speakers slightly away from the computer monitor
to ensure optimum audio performance during video calls.

Audio Setup

5

If you plan to use the camera’s integrated microphone or a headset,
you must configure it to perform properly. Follow the instructions
in the Audio Setup Guide to complete this task.

English

3

6

6

7

Tips

Lighting.

of lighting conditions. However, for best results shoot videos with bright light sources behind
the camera and out of the picture area whenever possible. Click on the QuickCam® icon in
the Windows® system tray and select Camera Settings for additional video controls, such as Low Light
Filter and Color Boost.

Digital Pan, Tilt, and Zoom.

your camera is in use, to access the Digital Pan, Tilt, and Zoom features. Use your mouse and keyboard
to pan left and right, tilt up and down, or Zoom in or out while doing video instant messaging
or recording videos. (Refer to the software help system for more information.)

Face Tracking.

your movements.

Echo Cancellation.

optimum audio performance. Please see the

Taking Still Pictures.

pictures with your camera.

Software Updates.

system tray and select Check for Updates, or go to

To learn more about your camera and its software, access the Logitech QuickCam® software
(
information about Logitech QuickCam web cameras, as well as other Logitech® products,
please visit

The Logitech® RightLight™ Technology will automatically provide the best image in a variety

Use the Quick Assistant, which is displayed automatically when

Activate face-tracking from within “Camera Controls” so that the camera can follow

Run the Audio Tuning wizard from the Logitech® QuickCam® software to ensure

Use the QuickCapture™ feature from the QuickCam software to take still

To check for new software updates, click on the QuickCam icon in the Windows

Learning More About the Camera

7

Programs\Logitech\Logitech QuickCam

www.logitech.com

.

Audio Setup Guide

http://

), and then click the Help button. For additional support

for more information.

www.logitech.com/support

.

4

English

8

Warranty

Limited Warranty.

defects in material and workmanship for a period of two (2) years from the date of purchase. Logitech's limited warranty is
nontransferable and is limited to the original purchaser. This warranty gives you specific legal rights, and you may also have other rights
which vary under local laws.

Remedies.

or replace the hardware, or (b) refund the price paid, provided that the hardware is returned to the point of purchase or such other
place as Logitech may direct, with a copy of the sales receipt. Any replacement hardware will be warranted for the remainder of
the original warranty period or thirty (30) days, whichever is longer. These remedies are void if failure of the hardware has resulted from
accident, abuse, misapplication, or any unauthorized repair, modification or disassembly. Further, for cordless devices, these remedies
are void if you use battery types other than those recommended by Logitech. Upon request from Logitech, you must prove the date
of the original purchase of the hardware by a dated bill of sale or dated itemized receipt.

DISCLAIMER OF WARRANTY.

LOGITECH AND ITS SUPPLIERS EXPRESSLY DISCLAIM ALL OTHER WARRANTIES, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OF THIRD-PARTY RIGHTS WITH RESPECT
TO THE HARDWARE, SOFTWARE, DOCUMENTATION AND ANY OTHER MATERIALS PROVIDED BY LOGITECH AND/OR ITS SUPPLIERS,
AND ANY WARRANTIES OF NON-INTERFERENCE OR ACCURACY OF INFORMATIONAL CONTENT. NO LOGITECH DEALER, AGENT,
OR EMPLOYEE IS AUTHORIZED TO MAKE ANY MODIFICATION, EXTENSION, OR ADDITION TO THIS WARRANTY. Some jurisdictions
do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.

LIMITATION OF LIABILITY.

PRODUCTS OR SERVICES, LOST PROFITS, LOSS OF INFORMATION OR DATA, OR ANY OTHER SPECIAL, INDIRECT, CONSEQUENTIAL,
OR INCIDENTAL DAMAGES ARISING IN ANY WAY OUT OF THE SALE OF, USE OF, OR INABILITY TO USE ANY LOGITECH PRODUCT OR SERVICE,
EVEN IF LOGITECH HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO CASE SHALL LOGITECH'S AND ITS SUPPLIERS' TOTAL
LIABILITY EXCEED THE ACTUAL MONEY PAID FOR THE LOGITECH PRODUCT OR SERVICE GIVING RISE TO THE LIABILITY. Some jurisdictions
do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply
to you. The above limitations will not apply in case of personal injury where and to the extent that applicable law requires such liability.

Logitech camera products are intended to be used in a lawful manner.

prohibited by local laws in some countries or states, such as the surreptitious recording of audio and/or video communications for certain
purposes. If you have any question about whether a proposed use of your product is lawful, you should consult a local legal authority
before proceeding.

UL Testing.

Logitech warrants that any hardware product accompanying this documentation shall be free from significant

Logitech’s entire liability and your exclusive remedy for any breach of warranty shall be, at Logitech’s option, to: (a) repair

THE WARRANTIES EXPRESSLY SET FORTH IN THIS AGREEMENT REPLACE ALL OTHER WARRANTIES.

IN NO EVENT WILL LOGITECH OR ITS SUPPLIERS BE LIABLE FOR ANY COSTS OF PROCUREMENT OF SUBSTITUTE

Certain uses of digital PC camera products may be

Your product is UL tested and should only be used with other UL listed devices.
