SLIM FOLIO PRO
Complete Setup Guide
CONTENTS
English . . . . . . . . . . . . . . . . .3
Français . . . . . . . . . . . . . . . .8
Español . . . . . . . . . . . . . . . . 13
Português . . . . . . . . . . . . . . 18
For iPad Pro 11-inch and iPad Pro 12.9-inch (3rd generation)
KNOW YOUR PRODUCT
Holder for Apple Pencil
(2nd gen) and other
digital pencils
iPad holder
SLIM FOLIO PRO
Magnetic latch
Magnetic dock
Shortcut keys
Keyboard
USB-C
charging port
Charging and pairing
indicator light
English 3
31 2
#
!
@
SETTING UP THE CASE
1. Lay keyboard case at and slide iPad into
thebottom part of the holder.
2. Snap the top corners in place to secure iPad.
TURNING ON THE KEYBOARD
This product has an automatic wake/sleep feature.
Anytime you dock the iPad in the upright typing
position, the keyboard will automatically turn on.
When lifted out of type mode, the keyboard will
automatically turn o to save battery.
PAIRING IPAD WITH KEYBOARD
1. Place iPad in the upright typing position.
Theindicator light will blink, which means
thekeyboard is ready to pair.
Light isn’t blinking?
Go to iPad Settings > Bluetooth > On. Then press
the Bluetooth button located in the top row of
your keyboard. Hold for 2 seconds until the status
light blinks. The keyboard is discoverable for 2
minutes.
X
2. Go to Settings > Bluetooth > Devices > Slim Folio Pro.
3. A 6-digit code will appear on your iPad screen.
Using the Slim Folio Pro keyboard, type in the
numbers.
4. Press the ENTER key. Now you’re ready to type!
Note: If you want to use another iPad with this
keyboard case, you will need to go through the
pairing process again.
XX
______
Bluetooth
XXXXXX
______
Sl im Fol io P ro
English 4
THREE USE MODES
Type mode
Fold the latch back until it magnetizes to the front
of the case. Dock iPad in the upright position and
type away.
Sketch mode
Lift iPad from magnetic dock and collapse into
sketch mode. Since the keyboard is only on when
iPad is in type mode, there is no need to worry about
unintentional typing.
Read mode
Open the case and fold the keyboard back. The
magnetic latch will keep the two sides of the case
held together while you read. Since the keyboard is
only on when iPad is in type mode, there is no need
to worry about unintentional typing.
REMOVING YOUR IPAD
1. To detach your iPad from the case, lay it on
a atsurface.
2. Push back the top corners of the case, one at
a time, and then lift your iPad out of the cradle.
HOW TO STORE APPLE PENCIL (2ND GEN)
The sides of Slim Folio Pro are left open, so you can
magnetically attach Apple Pencil (2nd gen) to the
side of the iPad Pro while the case is on. There is also
a slit on the inside of the Slim Folio Pro magnetic
latch to keep Apple Pencil (2nd gen) secure in transit.
English 5
LED LIGHT INDICATORS
LED Behavior Status
Blinking green Battery is charging
Solid green Battery is fully charged (100%)
Red Battery level is low (less than 10%), recharge the battery
Blinking white Fast: Keyboard is in discovery mode, ready for pairing
Slow: Keyboard is trying to reconnect to iPad
Solid white Bluetooth™ pairing or reconnection is successful
SHORTCUT KEYS
Home
shift
Switch
language
Keyboard
brightness
down
ctrl
Keyboard
brightness
up
Search Virtual
keyboard
Previous
track
CHARGE THE BATTERY
To check battery life, press the battery check button.
If the status light is red, the keyboard needs to be
charged. Use a USB-C cable. This is the same cable
that is used to charge iPad Pro 11-inch and 12.9-inch
(3rd generation).
1. Plug one end of the USB-C cable into the iPad
charging port. Plug the other end into a USB-C
port on your computer or a wall power adaptor.
2. Charge the battery until the status light turns
solid green.
Play/
pause
Next
track
Mute Volu me
down
Volu me upLock
screen
Bluetooth Battery
check
BATTERY INFORMATION
• A fully charged battery provides about 3 months
of use when the keyboard is used about two hours
a day.
• Charge the battery if the status light turns red
briey after the keyboard turns on.
• The keyboard enters sleep mode automatically
ifnot used for a while in the typing position.
Pressany key to wake it.
• Once iPad is disconnected from magnetic
dock,the keyboard will automatically shut o
tosave power.
English 6
BATTERY REMOVAL FOR RECYCLING
1. Pry o top cover of the keyboard with a screwdriver.
2. Detach battery from circuit board and remove battery.
3. Seperate your product and battery from household
waste for recycling, where possible, according to
locallaws.
4. For more information, contact your local authority or
place of purchase or visit www.logitech.com/recycling
Battery
Battery
English 7
