Logitech MK620 User Manual

Getting started with
Logitech® Wireless Combo MK620
Contents
English
What’s in the box, 3 Setup, 4
www.logitech.com/support/mk620
Features and troubleshooting, 10
What’s in the box
AA
Logitech Wireless Combo MK620
OFFON
K520 M705
English  3
1
Logitech Wireless Combo MK620
Set-up
USB
4  English
2
ii
Logitech Wireless Combo MK620
i
8 8
8 8
English  5
Logitech Wireless Combo MK620
iii
8 8
iv
OFFON
6  English
ii
i
3
M620
Logitech Wireless Combo MK620
English  7
iii
iv
M620
M620
Logitech Wireless Combo MK620
8  English
Logitech Wireless Combo MK620
Your Keyboard and mouse are now ready for use. You can download the Logitech®
SetPoint
Software if you want to customize your keyboard keys and mouse buttons.
www.logitech.com/downloads
English  9
Logitech Wireless Combo MK620
Keyboard features: F-key usage
User-friendly enhanced F-keys let you launch applications easily. To use the enhanced functions (yellow icons), first press and hold the key; second, press the F-key you want to use.
Tip In the software (SetPoint) settings, you can invert the FN mode if you prefer to access
directly the enhanced functions without having to press the FN key.
10  English
2nd - Press an F-key
1st - Press and hold the FN key
OFFON
Keyboard features
Logitech Wireless Combo MK620
OFFON
English  11
Logitech Wireless Combo MK620
Keyboard features
1. Multimedia navigation
2. Volume adjustment
3. Application zone
+ F1 Launches Internet browser
+ F2 Launches e-mail application
+ F3 Launches Windows Search*
+ F4 Launches media player
4. Windows view controls
+ F5 Flip
+ F6 Shows Desktop
+ F7 Minimizes window
+ F8 Restores minimized windows
* One Touch Search if the SetSpoint® software is installed. † Application Switcher if the SetSpoint® software is installed.
12  English
5. Convenience zone
6. Battery status indicator
7. Keyboard power switch
8. Internet navigation
+ F9 My Computer
+ F10 Locks PC
+ F11 Puts PC in standby mode
+ F12 Keyboard battery status check
• Internet back & forward navigation
• Internet favorites
• Launches calculator
Mouse features
1
Logitech Wireless Combo MK620
Scroll Wheel
1
5
2
3
4
8
7
9
Scroll Wheel Mode Shift Button
Application switch
6
10
1
2
3
English  13
Logitech Wireless Combo MK620
Mouse features
1. Scroll Wheel – Press for middle button; tilts for side-to-side scrolling.*
2. Scroll Wheel Mode Shift Button – Press to shift between hyper-fast (free-spinning)
and precision (click-to-click) scrolling.
3. Back and Forward Buttons* – Press to flip between web pages.
4. Application Switch* – Press rubber grip to switch between applications.
5. Battery Indicator Light – Turns red when a couple weeks of battery life remain.
6. On/O Button – Slide to turn mouse on and o.
7. Battery Door Release – Press where indicated and slide door o mouse. Reduce weight
by installing a single battery.
8. Laser engine – Delivers smooth, responsive, and precise cursor control.
9. Slots – Use to remove worn mouse feet.
10. Receiver storage.
* Application Switcher and side-to-side scrolling require Logitech software (SetPoint). Depending on your operating system, the back, forward, and middle buttons may also require Logitech software.
14  English
OFF
Logitech Wireless Combo MK620
Battery management
Your keyboard and mouse have up to three years of battery life.*
Battery sleep mode
Did you know that your keyboard and mouse go into sleep mode after you stop using them for a few minutes? This feature helps limit battery usage and eliminates the need to keep switching your devices on and o. Both your keyboard and mouse are up and running immediately once you begin using them again.
How to check the battery level for the keyboard
Press and hold the FN key, then press the F12 key: If the LED glows green, the batteries are good. If the LED blinks red, the battery level is low and you should consider changing batteries. You can also turn the keyboard o then back on using the On/O switch on top of the keyboard.
Battery status indicator
How to check the battery level for the mouse
Turn the mouse o then back on using the On/O switch on the mouse bottom. If the LED on top of the mouse glows green for 10 seconds, the batteries are good. If the LED blinks red,
Mouse bottom
M620
On/O switch
the battery level is low and you should consider changing batteries.
Mouse top
LED
* Battery life varies with usage and computing conditions. Heavy usage usually results in shorter battery life.
English  15
Logitech Wireless Combo MK620
Plug it. Forget it. Add to it.
You’ve got a Logitech® Unifying receiver. Now add a compatible wireless keyboard or mouse that uses the same receiver. It’s easy. Just start the Logitech® Unifying software* and follow the onscreen instructions. For more information and to download the software, visit www.logitech.com/unifying
OFFON
16  English
Logitech Wireless Combo MK620
Troubleshooting
Keyboard and mouse are not working
Check the USB connection. Also, try changing USB ports.
Move closer? Try moving the keyboard and mouse closer to the Unifying receiver.
Check battery installation. Also check the battery power of each device.
(See Battery management for more information.)
M620
8 8
On the mouse bottom, slide the On/O switch right to turn on the mouse. The Battery LED on the mouse top case should light green for 10 seconds. (See Battery management for more information.)
Mouse bottom
M620
On/O switch
English  17
Logitech Wireless Combo MK620
Troubleshooting
Are you experiencing slow or jerky cursor movement? Try the mouse on a dierent surface (e.g., deep, dark surfaces may aect how the cursor moves on the computer screen).
Is the keyboard turned on? Slide the keyboard O/On switch to the On position, as shown in the image below. The keyboard Status icons should light up.
OFFON
Re-establish the connection. Use the Unifying software to reset the connection between the keyboard/mouse and Unifying receiver. Refer to the Unifying section in this guide for more information (p. 16).
Visit www.logitech.com/comfort for more information about using your product, and for ergonomics.
18  English
M/N:C-U0008
FCC ID: JNZCU0008 IC: 4418A-CU0008 MADE IN CHINA
19
www.logitech.com/support/MK620
© 2014 Logitech. All rights reserved. Logitech, the Logitech logo, and other Logitech marks are owned by Logitech and may be registered. All other trademarks are the property of their respective owners. Logitech assumes no responsibility for any errors that may appear in this manual. Information contained herein is subject to change without notice.
621-000413.003
