Operating Instructions
Healthy dehumidification operation
1 |
Press the Start/Stop button. |
The unit will respond with |
a beep.
2 |
Open the door of the remote controller. To select Healthy |
DehumidificationOperation , press the Operation Mode |
Selection button.
Each time the button is pressed, the operation mode is shifted in the direction of the arrow.
<![endif]>
HSILGNE
Cooling |
Auto |
Healthy |
|
|
Dehumidification |
ON
3Set the fan speed again with the door of the remote controller still closed.
You can select the fan speed in four steps-low, medium, high, or CHAOS. Each time the button is pressed, the fan speed mode is shifted.
Natural wind by the CHAOS logic
For fresher feeling, press the Indoor Fan Speed Selector and set to CHAOS mode. In this mode, the wind blows like a natural breeze by automatically changing fan speed according to the CHAOS logic.
During Healthy Dehumidification Operation
If you select the dehumidification mode on the operation selection button, the A/C starts to run the dehumidification function. It automatically sets the room temp. and airflow volume to the best condition for dehumidification, based on the sensed current room temp.
In this case, however, the setting temp. is not displayed on the remote controller and you are not able to control the room temp. either.
During the healthy dehumidification function, the airflow volume is automatically set according to the optimization algorithm responding to the current room temp. status, so that the room condition is kept healthy and comfortable even in the very humid season.
Owner’s Manual 17
