KEYENCE XG User Manual

Data Logging and Remote Control Software for the XG Series

XG VisionTerminal

96107E

User's Manual

Read this manual before using this system.

Always keep this manual in a safe place

for future reference.

Introduction

This manual explains how to install, handle, and operate the data logging and remote control software for

the machine vision system XG Series (XG-8000/XG-7000: herein referred to as the [XG Series], XG

VisionTerminal [herein referred to as XG Vision Terminal]. It also covers precautions regarding use of the

software. Read this manual thoroughly to understand the XG VisionTerminal functions in order to

maximize performance of the system.

Additionally, this manual can be used in conjunction with Ver. 5.∗ for the XG-8000 or Ver.4.∗ for the XG-

7000 but understand that in addition to the restrictions for the specific version that are described as

"notes" there may be slight differences in the screen structure and other such elements when reading this

manual.

Always keep this manual in a safe place for future reference.

Please ensure the manual is passed to the end user of the software.

Related manuals

When using the XG Vision Terminal, read all the various manuals included with the XG Series that will be

used.

Symbols

The following warning symbols are used to ensure safety and to prevent human injury and/or damage to

property when using the system.

DANGER

Indicates that the operator is at risk of death or serious physical injury if the system is improperly

operated or this precaution is not followed.

Warning

Indicates that the operator is at risk of physical injury if the system is improperly operated or this

precaution is not followed.

Caution

Indicates that property could be damaged (product malfunction, etc.) if the system is improperly

operated or this precaution is not followed.

Note

Indicates important operating procedures that could be easily overlooked.

Reference

Indicates items to enhance system understanding and other useful information.

Introduction

Trademarks

• Microsoft, Windows, Windows Vista ,and Excel are either registered trademarks or trademarks of

Microsoft Corporation in the United States and/or other countries.

• "SD Memory Card" is a registered trademark of the SD Association.

• Other company names and product names noted in this document are registered trademarks or

trademarks of their respective companies. The ™ mark and ® mark have been omitted in this manual.

Introduction

General Cautions

• Before using the XG VisionTerminal to communicate with the XG Series controller, confirm that all

system functions of the XG controller are working properly.

• Before starting or operating the system, check to make sure all system functions are working correctly.

• If the system is operated beyond its published specifications or if the system is modified, its functions

and performance cannot be guaranteed.

• Please note that when the system is used in combination with other devices, its functions and

performance may be negatively affected.

• Do not use the system to protect the human body.

Precautions

• Do not launch more than one instance of the XG VisionTerminal.

Software License Agreement

NOTICE TO USER: PLEASE READ THIS SOFTWARE LICENSE AGREEMENT ("THIS AGREEMENT")

CAREFULLY. BY USING ALL OR ANY PORTION OF THE XG VisionTerminal ("THIS SOFTWARE"), YOU

ARE AGREEING TO BE BOUND BY ALL THE TERMS AND CONDITONS OF THIS AGREEMENT. IF YOU

DO NOT AGREE TO THE TERMS OF THIS AGREEMENT, DO NOT USE THIS SOFTWARE.

If you install, copy and or use all or a portion of this Software on a device or computer, you will be

deemed to have agreed to all the terms of this Agreement, and this Agreement will come into effect.

1. Definitions

1.1 "Use" or "using" refers to the accessing, installing, downloading, copying, operating and or

otherwise benefiting from the utilization of this Software.

1.2 "This Software" denotes the software and all associated documentation provided by KEYENCE.

1.3 "User" or "User's" infers the company or persons who have had the license to use this Software

granted to them by KEYENCE.

2. Grant of License.

2.1 In compliance with all of the terms and conditions of this Agreement, KEYENCE grants the non-

exclusive and non-transferable license to install and use this Software.

2.2 The granting of the license permits the single reproduction and or copying of this Software for the

User's backing up or archiving purposes.

2.3. This Software maybe installed on multiple devices and computers for the User's benefit and use.

2.4. The transfer of this Software via devices and computers with this Software installed on them by the

User to third parties is permitted. In such a case, the third party who receives this Software may

continue to use this Software in the same manner as the previous User.

2.5. With the transfer of this Software to a third party, the original User may install this Software to

additional devices and computers for further use as required. In such a case, the third party who

receives this Software may continue to use this Software in the same manner as the previous User.

2.6. The User maintains and guarantees that any thirdparties (as detailed in the previous two sections)

who receive and use this Software agree to this license Agreement and comply with all the terms

and conditions.

3. Restrictions.

3.1. This Software may not be modified by the User in any form except from the installation of updates or

new functions provided by KEYENCE.

3.2. The reverse engineering, decompiling or disassembling of this Software by any persons are not

permitted.

3.3. Without the prior permission of KEYENCE, the User may not reproduce or copy this Software for

selling or distributing to a third party

4. Intellectual Property Rights.

Except as stated herein, KEYENCE reserves all rights, titles and interests in this Software, along with all

associated copyrights, trademarks, and other intellectual property rights.

Software License Agreement

5. Disclaimer.

This Software is licensed to the User "AS IS" and without any warranty of any kind. In no event does

KEYENCE or its suppliers accept or assume any liability for any damages, claims, costs or profit loss as

a result of operating this Software.

6. Termination.

6.1 Under this Agreement the User's license will automatically terminate if this Software and any

associated copies of this Software are destroyed or voluntarily returned to KEYENCE.

6.2 Under this Agreement the User's license will terminate immediately and automatically without any

notice from KEYENCE if there is any failure to comply with any of the terms and conditions of this

Agreement. Upon termination, the using of this Software shall cease, and all copies (full or partial)

of this Software should be destroyed or returned to KEYENCE.

6.3 Compensation will be sought by KEYENCE should any violation or breach of this Agreement result

in any incurred costs or lost profit to KEYENCE.

7. Governing Law.

7.1 This Agreement will be governed by and construed in accordance with the substantive laws of

Japan.

7.2 If any part of this Agreement is found void and unenforceable, the rest of this Agreement will remain

intact, valid and enforceable according to the associated terms and conditions.

Contents

Introduction .............................................................2

General Cautions ..................................................4

Precautions ...........................................................4

Software License Agreement ..................................5

Contents ..................................................................7

Chapter 1 Introduction

Confirming the Package Contents ...................... 1-1

Overview of the XG VisionTerminal .................... 1-2

System Configuration .......................................... 1-3

System Operating Environment .......................... 1-4

Chapter 2 Preparations

Installing the XG VisionTerminal ......................... 2-1

New Installation from the CD-ROM ....................2-1

Uninstalling the Software ...................................2-3

Downloading and Installing the Latest

Version .........................................................2-3

Starting and Exiting XG VisionTerminal .............. 2-5

Starting XG VisionTerminal ................................2-5

Exiting XG VisionTerminal ..................................2-5

Understanding the Respective Windows ............ 2-6

Basic Window ....................................................2-6

Toolbar ...............................................................2-7

Connecting to the XG Series ............................... 2-8

Before Connecting .............................................2-8

Ethernet (1:1) Connection ..................................2-8

LAN Connection ................................................2-9

USB Connection ..............................................2-10

Chapter 3 Typical Uses

Typical Uses of XG VisionTerminal ..................... 3-1

Controlling the XG Series Remotely

(Remote Desktop) .......................................... 3-2

1. Registering a Controller .................................3-2

2. Connecting to the Controller ..........................3-3

3. Displaying the Remote Desktop ....................3-3

4. Controlling the Remote Desktop ....................3-4

Logging Data from the XG Series ....................... 3-6

1. Registering a Controller .................................3-6

2. Connecting to the Controller ..........................3-7

3. Start Logging .................................................3-7

4. Viewing the Log .............................................3-8

Chapter 4 XG VisionTerminal

Application Menu

XG VisionTerminal Application Menu .................. 4-1

File Menu ............................................................. 4-2

Creating a New Settings File (New) ..................4-2

Opening a Settings File (Open) .........................4-2

Saving the Settings File (Save) ..........................4-2

Saving the Settings File (Save as) ..................... 4-3

Exiting the XG VisionTerminal (Exit) ..................4-3

View Menu ........................................................... 4-4

Show/Hide the Connections view

(Connections) ..............................................4-4

Operating the Remote Desktop

(Show Handheld Controller View) ................ 4-4

Temporarily Disabling Remote Desktop

Operations (Locking Handheld Controller) .. 4-6

Changing the Displayed Contents for Each

Connection ...................................................4-6

Connections Menu .............................................. 4-9

Registering a New Connection

(Add Connection) ........................................4-9

Operation Menu ................................................. 4-10

Connecting to All Registered XG Series

controllers (Connect All) ............................4-10

Disconnecting the Connected XG Series

Controllers (Disconnect All) ....................... 4-10

Starting Logging (Start Logging) .....................4-10

Stopping Logging (Stop Logging) ..................4-10

Window Menu .................................................... 4-11

Switching View Layout in the XG VisionTerminal

Window (Select Layout). ............................4-11

Aligning the Views in the XG VisionTerminal

Window (Arrangement) ..............................4-11

Bringing a View to the front (View Name) ........4-11

Settings Menu ................................................... 4-12

Acquiring a File From a Connected

XG Series Controller (Acquire File) ............ 4-12

Changing the XG VisionTerminal Global

Settings (Options) ......................................4-13

Observing 3D images (3D viewer) ..................4-14

Help Menu ......................................................... 4-16

Displaying the Help File (Help) .......................4-16

Displaying the Version Number of the XG

VisionTerminal (Version Info) .....................4-16

Chapter 5 Appendix

Error Messages ................................................... 5-2

Contents

Chapter

Introduction

Confirming the Package Contents

This package contains the following equipment and accessories. Check that all accessories are included before using this system.

V-Works for XG (Integrated Management Software for

the XG Series machine vision system)

(Model Number: XG-H7E or XG-H8NE)

1 x CD-ROM

• This disc contains the installer, program files, and PDF

instruction manual files for the XG VisionTerminal. Keep

this disc in a safe place following installation.

• A backup should be made in case the CD-ROM or case

are accidently damaged.

Note

While we have taken the utmost care in packing these

components, should you find any items missing or damaged,

please notify your nearest KEYENCE sales office.

Introduction

Reference

For details on the contents of the CD-ROM, see the Installation CD

Instructions found in the CD-ROM case.

1-1

Overview of the XG VisionTerminal

The XG VisionTerminal is specifically designed for the machine vision system XG Series.

Overview

The XG VisionTerminal uses a remote desktop function that allows you to issue console commands from the PC and view the monitor output from the XG Series on your PC.

Connection via Ethernet or USB

The XG VisionTerminal also collects image and measurement data from the XG Series via an Ethernet or USB connection.

Note

The XG Vision Terminal Ver. 4.* has some items that are unsupported for log data collection and remote desktop between it and the XG-8000 Series. When connecting with XG-8000 Series, use XG VisionTerminal Ver.5.0 or later, and when using the 3D viewer (Page 4-14), use XG VisionTerminal Ver.5.3 or later.

Major functions

Remote desktop

The XG VisionTerminal allows you to view the monitor output from the XG Series on a PC. Not only is it possible to update and check image output in real time, it is also possible to operate the XG Series directly with a PC mouse.

Data acquisition (logging)

The XG VisionTerminal can collect and store inspection results, images, and archived data output from the XG Series. A log view provides the most recent results in real time.

Console input

While using the remote desktop, users can send console button instructions to the XG Series. In addition to clicking console buttons visualized on the PC, users can also use a joypad connected to the PC to send instructions.

File acquisition

The XG VisionTerminal can acquire files from the SD1 or SD2 card of the XG Series controller containing program files, global settings, and archived images for storage on the PC.

1-2

System Configuration

Example of a standard system of XG-7000 Series setup with two cameras using the XG VisionTerminal.

Controller XG-7700/7500/7000

Handheld Controller (OP-84231, option)

SD card (OP-87133, 512 MB*) (Loaded in slot SD1 on controller)

*XG-7700 comes with 1 GB

Camera cable CA-CN3 (3 m)/ CA-CH3* (3 m) (option)

* Used to connect high-speed cameras

System Configuration

Introduction

24 V DC power supply

CA-U3 (option)

Monitor CA-MP81 (option)

Camera 1

Supported cameras (option)

Camera 2

XG-200C XG-S200C XG-200M XG-S200M XG-H100C XG-H100M XG-H500C XG-H500M

Lenses (option)

/XG-035C

/XG-S035C

/XG-035M

/XG-S035M

/XG-H035C

/XG-H035M

/XG-H200C

/XG-H200M

*1 XG-7700/7500 only. *2 XG-7700 only.

Connection cable product numbers

• Ethernet cable (1 Gbps, cross): OP-66843

• USB cable (Ver 2.0): OP-66844

Note

• Ethernet connection supports up to 8 controllers.

• Ethernet and USB connections may be used at the same time, but only one USB connection is allowed.

1-3

System Operating Environment

The XG VisionTerminal requires a personal computer that meets the following conditions.

Supported OS Microsoft Windows XP Home Edition/Professional SP 2 or later

Microsoft Windows Vista Home Basic, Home Premium, Business, Ultimate, Enterprise

Microsoft Windows 7 Home Premium, Professional, Ultimate, Enterprise

• Supports the 32bit/64-bit version of Microsoft Windows 7 only. For all other operating systems,

only the 32-bit version is supported.

• Operating systems not listed are not supported.

Runtime environment • CPU:

Minimum: Core2Duo (1.06 GHz or faster) or an equivalent processor.

Recommended: Core2Duo (1.80 GHz or faster) or an equivalent processor.

• RAM: 1 GB or more (2 GB or higher for Ver. 5.0 or later).

• HDD: 500 MB or higher available space. *Additional available space is required for storing

images.

• Monitor: 1024 x 768 resolution of higher (1280 x 1024 resolution or higher recommended).

• Optical drive: An optical drive is required to use the installation CD-ROM.

• USB port: USB port must be Ver. 2.0 compatible if using the USB connection.

Note

Only one XG Series controller can be connected to the USB port.

1-4

Chapter

Preparations

Installing the XG VisionTerminal

Installation procedures will differ depending on whether the program is being installed from the CD-ROM or by downloading from the User Support page.

Reference

This example below explains the installation procedures for

Windows XP.

Preparations

New Installation from the CD-ROM

Install the XG VisionTerminal from the CD-ROM by using the following procedures.

Note

• If the PC you are installing to does not have the necessary

runtime components used by this software, you will be asked to

install those components. Follow the instructions and install all

components as necessary.

• Do not connect the USB cable to the PC and XG Series

controller prior to installation.

• Installation must be performed by a user with Administrator

privileges.

• Uninstall any previous version of this software (Page 2-3).

• When installing on a notebook PC, be sure to connect the AC

adapter power supply.

1 Insert the XG-H7N or XG-H8N CD-ROM into the CD-

ROM drive of the PC.

The installation guide appears.

Reference

If the installation guide does not appear, double-click

\XG\VisionTerminal\setup.exe located on the CD-ROM.

2 Click [Install XG VisionTerminal Ver.[the version the

will be installed]].

The installer launches and the [Installer Language]

appears.

Reference

If the installer does not appear, double-click setup.exe in the

CD-ROM menu.

2-1

Installing the XG VisionTerminal

3 Select language and click [OK].

[Setup Wizard for XG VisionTerminal] appears.

Reference

The version number will differ depending on the model and

period when purchased.

4 Click [Next].

The [User License Agreement] appears.

5 Follow the on-screen instructions to complete the

installation.

6 When the [Installation completed] menu appears,

click [Finish].

The XG VisionTerminal installation is completed.

• The shortcut icon for the [XG VisionTerminal Ver. ∗.∗]

appears on the desktop.

• A shortcut will be added to the Windows Start menu under

KEYENCE Applications → V-Works for XG Ver. ∗.∗ → XG

VisionTerminal Ver. ∗.∗.

2-2

Installing the XG VisionTerminal

Uninstalling the Software Downloading and Installing the

Uninstall the XG VisionTerminal using [Add/Remove Programs] in the Windows Control Panel.

1 Click the Start menu and select [Control Panel].

The [Control Panel] appears.

2 Double-click the [Add/Remove Programs] icon.

The [Add/Remove Programs] menu appears.

Latest Version

Note

• If the PC you are installing to does not have the necessary runtime components used by this software, you will be asked to install those components. Follow the instructions and install all components.

• Do not connect the USB cable to the PC and XG Series prior to installation.

• Installation must be performed by a user with Administrator privileges.

Preparations

3 Select [XG VisionTerminal Ver. ∗.∗] and click

[Remove].

A confirmation screen appears.

4 Click [Yes].

The XG VisionTerminal is removed.

Reference

If asked to confirm whether to delete shared files, click [Yes] to

remove all files.

1 Uninstall any previous version of the XG

VisionTerminal.

2 Download the latest files from the User Support

page.

XG Series Users Support page

http://www.keyence.com.sg/support/index.php

3 Double-click the downloaded file.

The installer launches and the [Installer Language]

appears.

4 Select language and click [OK].

[Setup Wizard for XG VisionTerminal] appears.

Reference

The version number will differ depending on the model and

period when purchased.

2-3

Installing the XG VisionTerminal

5 Click [Next].

The [User License Agreement] appears.

6 Follow the on-screen instructions to complete the

installation.

7 When the [Installation completed] menu appears,

click [Finish].

The XG VisionTerminal installation is completed.

• The shortcut icon for the [XG VisionTerminal Ver. ∗.∗]

appears on the desktop.

• A shortcut will be added to the Windows Start menu under

KEYENCE Applications → V-Works for XG Ver. ∗.∗ → XG

VisionTerminal Ver. ∗.∗.

2-4

Starting and Exiting XG VisionTerminal

This section explains how to start and exit the XG VisionTerminal.

Starting XG VisionTerminal

Click the shortcut in the Windows Start menu under

All Programs → KEYENCE Applications → V-Work s

for XG Ver. ∗.∗ → XG VisionTerminal Ver. ∗.∗.

Or, double-click the shortcut icon for the [XG

VisionTerminal Ver.

The initial window appears.

∗.∗] on the desktop.

Exiting XG VisionTerminal

Click [File], and then [Exit].

Or, click the close button at the upper right of the

window.

The XG VisionTerminal exits.

Preparations

Reference

• After the XG VisionTerminal has been launched for the first

time, it will automatically load the last saved settings files.

• If [Automatic connection on startup] and [Start logging on

startup] are selected in the [Options] menu (Page 4-13),

the XG VisionTerminal will automatically begin logging the

next time it is started.

2-5

Understanding the Respective Windows

(5) Remote desktop

Basic Window

The basic window for the XG VisionTerminal is outlined below.

(1) (3)(2)

This view shows monitor output from the connected XG Series controller. See "Controlling the XG Series Remotely (Remote Desktop)" (Page 3-2) for more details.

(1) Controller view

This view displays the name of the XG Series controllers that the XG VisionTerminal is connected to, as well as logging information and a remote desktop operation menu.

(2) Menu bar

This bar displays the menus for executing commands. See "XG VisionTerminal Application Menu" (Page 4-1) for more details.

(3) Toolbar

This bar contains button icons for the major commands. Clicking an icon executes the command. See "Toolbar" (Page 2-7) for more details.

(4) Log Summary view

This view shows the most recent data as it is being logged. See "Viewing logs (Log Summary)" (Page 4-6) for more details.

(6) Handheld controller view

This view allows you to operate the handheld controller from the XG VisionTerminal while displaying the remote desktop view. See "Operating the Remote Desktop (Show Handheld Controller View)" (Page 4-4) for more details.

2-6

(7) 3D viewer

By using information acquired from the 3D camera or LJ-V, the 3D image of object for the inspection is displayed (supported by XG VisionTerminal Ver.5.3 or later versions). See "Observing 3D images (3D viewer)" (Page 4-14) for more details.

+ 40 hidden pages
