DPX-U5130BT DPX-U5130

DUAL DIN SIZED CD RECEIVER

INSTRUCTION MANUAL

Contents

Before use 4

Safety precaution Important information Regulatory Compliance

Appendix 5

Trademarks Speciﬁcations

Basic operations 8

Component names Preparations How to select the item Adjusting the clock General operations

Audio adjustments 11

Audio control

Listen to the iPod 12

Models of iPods/iPhones that can be connected

to this unit Playing music Music search Alphabet search Skip search ratio setting Play function APP & iPod Mode

Pandora® internet radio 15

Requirements Pandora® internet radio Listening to the Pandora® internet radio Basic operation Station search New station registration Station preset memory Preset tuning Pandora source control

Aha Radio 18

Requirements Aha™ Listening to the Aha Radio Basic operations Station search Calling a number in the content

Listen to the CD/ Audio le 20

Playing music Music search Skip search ratio setting Play function Direct music search About the Audio ﬁle About the USB device About “KENWOOD Music Editor Light” and

“KENWOOD Music Control” About the discs used with this unit Handling discs

Listen to the tuner 23

Listening to the radio Station preset memory Auto memory Preset tuning Tuner setting Direct access tuning Frequency Step Setting

Listen to the AUX 25

Start listening Auxiliary input display setting

Display settings 26

Illumination color selection Adjusting the Illumination color Display & Illumination setting Text Display Selection Text scroll

General settings 28

Muting the audio upon reception of a phone call Demonstration mode setting Initial settings

Registering a Bluetooth

(Function of DPX-U5130BT) 30

About the Bluetooth module Registering a Bluetooth device Selecting the Bluetooth device you wish to

connect Deleting a registered Bluetooth device Bluetooth device registration test

DPX-U5130BT/ DPX-U5130

Hands-free phoning

(Function of DPX-U5130BT) 32

Receiving a call Calling a number in the phone book Alphabet search Dialing a number Calling a number in the call log Speed dialing (Preset dial) Registering in the preset dial number list During a call Switching between Two Connected Cell-phones Clearing the disconnection message Making a call by voice dialing Display of phone number types (categories)

Bluetooth audio

(Function of DPX-U5130BT) 35

Before use Basic operations Play function

Bluetooth settings

(Function of DPX-U5130BT) 36

Registering the PIN code Downloading the phone book Deleting the phone book Displaying the ﬁrmware version Bluetooth detail setting

Basic operation of remote control 38

Before using remote control Basic opreation

Troubleshooting guide 40

Setting error Operation/wiring error Error messages

Accessories/ Installation Procedure 43

Connecting Wires to Terminals 44

Installation 46

English

Before use

Safety precaution

# WARNING

To prevent injuries or a re, take the following precautions:

• Stop the car before operating the unit.

• To prevent a short circuit, never put or leave any

metallic objects (such as coins or metal tools) inside the unit.

! CAUTION

• Adjust the volume so that you can hear the sound outside the car. Driving with the volume too high may cause an accident.

• Wipe oﬀ the dirt on the panel with a dry silicon or soft cloth.

Failure to observe this precaution may result in damage to the monitor or unit.

• If you experience problems during installation, consult your Kenwood dealer.

Condensation

When the car is air-conditioned, moisture may collect on the laser lens. This may cause disc read errors. In this case, remove the disc and wait for the moisture to evaporate.

How to reset your unit

If the unit fails to operate properly, press the Reset button. The unit returns to the factory settings when the Reset button is pressed.

Important information

Notes

• If you experience problems during installation, consult your Kenwood dealer.

• When you purchase optional accessories, check with your Kenwood dealer to make sure that they can work with your model and in your area.

• Characters that conform to ISO 8859-1 can be displayed.

• The illustrations of the display and panel appearing in this manual are examples used to explain more clearly how the controls are used. Therefore, what appears on the display in the illustrations may diﬀer from what appears on the display on the actual equipment, and some of the images on the display may be inapplicable.

Regulatory Compliance

The marking of products using lasers

The label is attached to the chassis/case and says that the component uses laser beams that have been classified as Class 1. It means that the unit is utilizing laser beams that are of a weaker class. There is no danger of hazardous radiation outside the unit.

DPX-U5130BT/ DPX-U5130

Reset button

Appendix

Trademarks

• The “AAC” logo is a trademark of Dolby Laboratories.

• “Made for iPod” and “Made for iPhone” mean that an

electronic accessory has been designed to connect speciﬁcally to iPod or iPhone, respectively, and has been certiﬁed by the developer to meet Apple performance standards. Apple is not responsible for the operation of this device or its compliance with safety and regulatory standards. Please note that the use of this accessory with iPod or iPhone may aﬀect wireless performance.

• iPhone, iPod, iPod classic, iPod nano, and iPod touch are trademarks of Apple Inc., registered in the U.S. and other countries.

• iTunes is a trademark of Apple Inc.

• Microsoft and Windows Media are either registered

trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

• The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by JVC KENWOOD Corporation is under license. Other trademarks and trade names are those of their respective owners.

• PANDORA, the PANDORA logo, and the Pandora trade dress are trademarks or registered trademarks of Pandora Media, Inc., used with permission.

• aha, the Aha logo, and the Aha trade dress are trademarks or registered trademarks of HARMAN International Industries, used with permission.

• Android is a trademark of Google Inc.

• BlackBerry®, RIM®, Research In Motion® and related

trademarks, names and logos are the property of Research In Motion Limited and are registered and/or used in the U.S. and countries around the world. Used under license from Research In Motion Limited.

English

Appendix

Speciﬁcations

FM tuner section

Frequency range

200 kHz space : 87.9 MHz – 107.9 MHz 50 kHz space : 87.5 MHz – 108.0 MHz

Usable sensitivity (S/N = 26dB)

: 7.2dBf (0.63 μV/75 Ω)

Quieting Sensitivity (DIN S/N = 46dB)

: 15.2dBf (1.6 μV/75 Ω)

Frequency response (±3 dB)

: 30 Hz – 15 kHz

Signal to Noise ratio (MONO)

: 75 dB

Stereo separation (1 kHz)

: 45 dB

AM tuner section

Frequency range

Band1 (MW) : 530 kHz – 1700 kHz (10 kHz space) : 531 kHz – 1611 kHz (9 kHz space) Band2 (SW1) : 2940 kHz – 7735 kHz (5 kHz space) Band3 (SW2) : 9500 kHz – 10135 kHz / 11580 kHz

- 18135 kHz (5 kHz space)

Usable sensitivity (S/N = 20dB)

MW : 31 dBµ (36 µV) SW : 32 dBµ (40 µV)

CD player section

Laser diode

: GaAlAs

Digital ﬁlter (D/A)

: 8 Times Over Sampling

D/A Converter

: 24 Bit

Spindle speed (Audio ﬁles)

: 500 – 200 rpm (CLV)

Wow & Flutter

: Below Measurable Limit

Frequency response (±1 dB)

: 20 Hz – 20 kHz

Total harmonic distortion (1 kHz)

: 0.01 %

Signal to Noise ratio (1 kHz)

: 105 dB

Dynamic range

: 90 dB

MP3 decode

: Compliant with MPEG-1/2 Audio Layer-3

WMA decode

: Compliant with Windows Media Audio

AAC decode

: AAC-LC “.m4a” ﬁles

USB interface

USB Standard

: USB1.1/ 2.0 (Full speed)

File System

: FAT12/ 16/ 32

Maximum Supply current

: DC 5 V = 1 A

MP3 decode

: Compliant with MPEG-1/2 Audio Layer-3

WMA decode

: Compliant with Windows Media Audio

AAC decode

: AAC-LC “.m4a” ﬁles

WAV decode

: Linear-PCM

DPX-U5130BT/ DPX-U5130

Audio section

Maximum output power

: 50 W x 4

Full Bandwidth Power (at less than 1% THD)

: 22 W x 4

Speaker Impedance

: 4 – 8 Ω

Tone action

Bass : 100 Hz ±8 dB Middle : 1 kHz ±8 dB Treble : 12.5 kHz ±8 dB

Preout level/ Load (CD)

: 2500 mV/10 kΩ

Preout impedance

: ≤ 600 Ω

Bluetooth section (DPX-U5130BT)

Version

: Bluetooth Ver.2.1+EDR Certiﬁed

Frequency range

: 2.402 – 2.480 GHz

Output Power

: +4dBm (MAX), 0dBm (AVE) Power Class 2

Maximum Communication range

: Line of sight approx.10m (32.8 ft)

Proﬁles

: HFP (Hands Free Proﬁle) : SPP (Serial Port Proﬁle) : PBAP (Phonebook Access Proﬁle) : OPP (Object Push Proﬁle) : A2DP (Advanced Audio Distribution Proﬁle) : AVRCP (Audio/Video Remote Control Proﬁle)

General

Operating voltage

DPX-U5130BT

: 14.4 V (10.5 – 16V allowable)

DPX-U5130

: 14.4 V (11 – 16V allowable)

Maximum Current consumption

: 10 A

Installation Size (W x H x D)

: 182 x 111 x 157 mm

Weight

: 1.5 kg

Specications subject to change without notice.

Auxiliary input

Frequency response (±3 dB)

: 20 Hz – 20 kHz

Input Maximum Voltage

: 1200 mV

Input Impedance

: 10 kΩ

English

Basic operations

Component names

(2) (2)(3)(1)

(13)

(12)(5) (8) (9) (10) (11)(6)(7)

(1) Disk slot

Insert a disc (label side up) in this slot.

(2) [1] - [6] button

When listening to the radio, press the button to call a registered station. When listening to the CD/USB/iPod, press the button to perform the following operations:

- DPX-U5130BT [1] [2] : Selecting an audio ﬁle folder.

- [3] : Selecting Random Play.

- [4] : Selecting Repeat Play.

- [5] : Selecting App & iPod Control Mode.

(3) [G] button

Press the button to eject the disc.

(4) [SRC] button

Press the button to switch among sources.

(5) USB terminal

Connect the iPod or USB device to this terminal.

(6) Auxiliary input

Connect the output of an external device using a stereo mini-jack.

(7) [1] button

When listening to the iPod, audio file, or CD, press the button to enter the search mode. When listening to the radio, press the button to select a band.

(8) [DISP] button

Press the button to switch between display modes.

(9) [6] button

In each of the selected modes, press the button to return to the previous item.

(14)

(16)

(10) [Control knob] (Volume knob)

In the normal mode, turn the knob to adjust the volume or press the knob to turn down the volume quickly. In the Function mode, turn the knob to select an item or press the knob to determine the selection.

(11) [E]/ [F] button

Press the button to select a song or station.

(12) [L] button

Press the button to switch between play/pause.

DPX-U5130BT [7] button

(13)

(17)(4) (15)

Press the button to select the Phone Book.

DPX-U5130 [S] button

(14)

Press the button to select an audio file folder or broadcast band (AM), or use it as a thumbs down button on Pandora.

DPX-U5130BT [Ú] button

(15)

Press the button to make, answer, or disconnect a hands-free call.

DPX-U5130 [R] button

(16)

Press the button to select an audio file folder or broadcast band (FM), or use it as a thumbs up button on Pandora.

(17) [AUDIO] button

Press the button to enter the Audio Control mode.

DPX-U5130BT/ DPX-U5130

Preparations

DISP OFF MODE

Exiting the Demonstration mode

Turn o the Demonstration mode when you use the unit for the rst time after installation.

 Press the [Control knob] to quit the

Demonstration mode when the message “CANCEL DEMO PRESS VOLUME KNOB” appears (approx. 15 seconds).

 Turn the [Control knob] to select the “YES” and

then press the [Control knob].

The Demonstration mode can also be canceled in the Function Setting mode. Refer to <Demonstration mode setting> (page 28).

How to select the item

For how to select setting items such as a function setting item, see the following example:

Example: Adjusting the text scroll of the display

 Press and hold the [AUDIO] button.

“Function” appears and enters the Function setting mode.

 Select the Text scroll function item

DEMO MODE

SETTINGS

INITIAL SET

Turn the [Control knob] to select “SETTINGS”, and then press the [Control knob]. Next, turn the [Control knob] to select “DISP & KEY”, and then press the [Control knob]. Finally, turn the [Control knob] to select “TEXT SCROLL, and then press the [Control knob].

Press the [6] button to return to the previous item.

CLOCK

DISP & KEY

TUNER SET

DISP DIMMER

TEXT SCROLL

 Turn the [Control knob] to select a value

(AUTO, ONCE, OFF), and then press the [Control knob].

The previous item appears.

 Press and hold the [6] button.

Exit the Function setting mode.

About the description in this manual

“Function” appears and enters the Function setting mode.

2 Use the [Control knob] to select “SETTINGS”

> “TEXT SCROLL”.

& KEY” 3 Use the [Control knob] to select a value (AUTO, ONCE, OFF).

> “DISP

English

Basic operations

Adjusting the clock



Press and hold the [Control knob].

The hour display blinks.

 Turn the [Control knob] to adjust the hour,

and then press the [Control knob].

The minute display blinks.

 Turn the [Control knob] to adjust the minute,

and then press the [Control knob].

General operations

Power

Turn the power on by pressing the [SRC] button. Press and hold [SRC] button to turn the power o.

Source selection

Press the [SRC] button.

Pressing the button switches among sources.

Source Display

Standby “STANDBY” Tuner “TUNER” USB “USB” iPod[1] “iPod” Pandora® internet radio[1] “PANDORA” aha™[1][2] “AHA” Bluetooth audio[2] “BT AUDIO” CD[1] “CD” Auxiliary Input “AU X”

[1] This source can be selected only when it can be played. [2] Function of DPX-U5130BT.

Source switching setting

• “PANDORA”, “AHA”, and “AUX” sources are not selectable when not in use. For more details, see <Initial settings> (page 29).

Volume

Turn the [Control knob].

USB terminal

A USB device or iPod can be connected. The CA-U1EX (optional accessories) or KCAiP102 (optional accessories) is recommended to connect a USB device or iPod.

Auxiliary input

A portable audio device can be connected with a stereo mini-plug (3.5 mm ø).

DPX-U5130BT/ DPX-U5130

Audio adjustments

Audio control

You can adjust the audio control items.

 Select the source.

Refer to <Source selection> (page 10).

 Press the [AUDIO] button.

Enter the Audio control mode.

 Use the [Control knob] to select a audio item.

For how to use the [Control knob], refer to <How to select the item> (page 9).

Display Audio setting item Range

“SUB-W LEVEL”[2][3] Subwoofer level “BASS LEVEL” Bass level “MID LEVEL” Middle level “TRE LEVEL” Treble level “EQ PRO”

“BASS ADJUST”

“BASS CTR FRQ” Bass Center Frequency “BASS LEVEL” Bass level “BASS Q FACTOR” Bass Q Factor “BASS EXTEND” Bass Extend

“MID ADJUST”

“MID CTR FRQ” Middle Center

Frequency “MID LEVEL” Middle level “MID Q FACTOR” Middle Q Factor

“TRE ADJUST”

“TRE CTR FRQ” Treble Center

Frequency “TRE LEVEL” Treble level

“PRESET EQ” Preset Equalizer curve

“BASS BOOST” Bass Boost

“LOUDNESS” Loudness “BALANCE” Balance “FADER” Fader

“SUBWOOFER SET”[3] Subwoofer output “DETAILED SET”

“HPF”[6] High Pass Filter

“LPF

Low Pass Filter SUBWOOFER”[2] [3]

“SUB-W

Subwoofer Phase PHASE”[2][3][4]

“SUPREME

Supreme setting SET”[5]

“VOLUME

Volume oﬀset OFFSET”

–15 — +15 (dB) (0) –8 — +8 (dB) (8) –8 — +8 (dB) (2) –8 — +8 (dB) (3)

60/ 80/ 100/ 200 (Hz) –8 — +8 (dB) (8)

1.00/ 1.25/ 1.50/ 2.00 OFF/ ON

0.5/ 1.0/ 1.5/ 2.5 (kHz)

–8 — +8 (dB) (2)

0.75/ 1.00/ 1.25

10.0/ 12.5/ 15.0/

17.5 kHz –8 — +8 (dB) (3) “ROCK”/ “POPS”/

“EASY”/ “TOP40”/ “JAZZ”/ ”POWERFUL”/ “NATURAL”/ “USER”[1]

“OFF”/ “LV1 ”/ “LV2”/ ”LV3”

“OFF”/ “LV1”/ “LV2” Left 15 — Right 15 (0) Rear 15 — Front

15 (0) OFF/ ON

Through/ 100/ 120/ 150 (Hz)

85/ 120/ 160/ Through (Hz)

Reverse (180°)/

Normal (0°) ON/ OFF

–8 — ±0 (dB) (AUX: -8 — +8) (0)

( : Factory setting) [1] “USER”: The customized Bass, Middle, and Treble settings

are eﬀective.

[2] “SUB-W LEVEL”/ “LPF SUBWOOFER”/ “SUB-W PHASE” is

selectable only if “SUBWOOFER SET” is set to “ON”.

[3] SUB-W LEVEL”/ “SUBWOOFER SET”/ “LPF SUBWOOFER”/

“SUB-W PHASE” is selectable only if “SWITCH PREOUT ” is set to “SUB-W”. (DPX-U5130 only : See <“SWITCH PREOUT”> (page 29).

[4] “SUB-W PHASE” is selectable only if a setting other than

“THROUGH” is selected for “LPF SUB-W”.

[5] “SUPREME SET” is selectable only when playing back an

MP3/WMA/AAC/WAV disc, USB device or iPod.

[6] Function of DPX-U5130BT.

Adjusting Bass, Middle, and Treble levels

• You can set Bass, Middle, and Treble levels for each source.

 Use the [Control knob] to select a value.

The previous item appears.

Exit the Audio control mode.

Press and hold the [6] button.

About Supreme

• Technology to extrapolate and supplement with proprietary algorithm, the high-frequency range that is cut oﬀ when encoding at low bit rate. Supplementing is optimized by compression format (AAC, MP3, WMA or WAV) and processed according to bit rate. The eﬀect is negligible with music that is encoded at high bit rate, variable bit rate or has minimal high frequency range.

English

Listen to the iPod

Models of iPods/iPhones that can be connected to this unit

Made for

• iPod nano (6th generation)

• iPod nano (5th generation)

• iPod nano (4th generation)

• iPod nano (3rd generation)

• iPod nano (2nd generation)

• iPod nano (1st generation)

• iPod with video

• iPod classic

• iPod touch (4th generation)

• iPod touch (3rd generation)

• iPod touch (2nd generation)

• iPod touch (1st generation)

• iPhone 4S

• iPhone 4

• iPhone 3GS

• iPhone 3G

• iPhone

• For information on the compatibility with iPod/

iPhone software, visit www.kenwood.com/cs/ce/ ipod/.

• Types of available control vary depending on the type of connected iPod. Visit www.kenwood.com/ cs/ce/ipod/ for further details.

• The word “iPod” appearing in this manual indicates the iPod or the iPhone connected with the iPod connection cable (optional accessory).

• Refer to the web site for connectable iPods and iPod connection cables.

www.kenwood.com/cs/ce/ipod/

Notes

• If you start playback after connecting the iPod, the music that was playing on the iPod is played ﬁrst. In this case, “RESUMING” appears without displaying a folder name, etc. Changing the browse item will display a correct title, etc.

• You cannot operate the iPod if “KENWOOD” or “ä” appears on the iPod.

Playing music

Playing an iPod

Connect the iPod to the USB terminal using the KCA-iP102 connecter (optional accessory).

When it is connected, the source is switched automatically and playback starts.

When playback of iPod touch or iPhone does not start

• If an unsupported application has started when connecting iPod touch or iPhone, “APP&iPod MODE” appears and sometimes playback does not starts. Press the [5] button (DPX-U5130BT) or press and hold the [iPod] button

(DPX-U5130).

Selecting a song

Press the [E] or [F] button.

Fast-forwarding or fast-backwarding a song

Press and hold the [E] or [F] button.

Pause and play a song

Press the [L] button.

Removing iPod

Press the [SRC] button to switch the source to a device other than iPod, Pandora Internet radio, and Aha Radio, and then remove the iPod. Data contained in the iPod may be damaged if you remove it when it is used as the active source.

DPX-U5130BT/ DPX-U5130

Music search

You can search for the song you want to play.

 Press the [1] button.

“SEARCH” appears and enters the Music search mode.

 Search for a song

Operation type Operation

Selecting items Turn the [Control knob]. Determining selection Press the [Control knob]. Skip Search Press the [E] or [F]./

Press and hold the [E] or [F].

Returning to previous item Press the [6] button. Returning to Top menu Push the [5] button.

- indicator: Audio ﬁle _ indicator: Artist ` indicator: Album ; indicator: Folder

Canceling the Music search mode

Press and hold the [6] button.

Undisplayable titles

• If a song name can not be displayed for some reason, browse item name and digits are displayed (ex. PLIST***) instead.

Items Display

Playlists “PLIST***” Artists “ART***” Albums “ALB***” Songs “PRGM***” Podcasts “PDCT***” Genres “GEN***” Composers “COM***”

Alphabet search

You can select an alphabetic character from the list in the browse item (artist, album, etc.) currently selected.

 Press the [1] button.

“SEARCH” appears and enters the Music search mode.

 Press the [1] button.

Enter the Alphabet search mode and “SEARCH <_ >” appears.

 Select a character.

Operation type Operation

Entry of character Turn the [Control knob]. Movement of character

entry position Determination of entered

character

Returning to the Music search mode.

Canceling the Alphabet search mode

Press and hold the [6] button.

Alphabet search notes

• Turning the [Control knob] fast in the Music search mode allows you to enter the alphabet search mode.

• The time of Alphabet search may become long depending on the number of items (songs) in iPod.

• To search for a character other than A to Z and 1, enter “*”.

• If the ﬁrst character string begins with an article “a”, “an”,

or “the” in the alphabet search mode, it is searched for in deﬁance of the article.

Press the [E] or [F].

Press the [Control knob].

English

Listen to the iPod

Skip search ratio setting

You can change the ratio of skip performed as mentioned in <Skip Search> (page 13).

 Select the iPod source.

Refer to <Source selection> (page 10).

 Press and hold the [AUDIO] button.

Enter the Function setting mode.

 Use the [Control knob] to select “SETTINGS” >

“SKIP SEARCH”.

For how to use the [Control knob], refer to <How to select the item> (page 9).

 Use the [Control knob] to select a ratio (0.5, 1,

5, 10).

The previous item appears.

Exit the Function setting mode

Press and hold the [6] button.

Play function

Repeat play

Press the [4] button.

Switches between Repeat (“FILE REPEAT”) and off (“REPEAT OFF”) when pressed.

Random play

Press the [3] button.

Randomly plays the music. Pressing the button toggles the setting between Random play on (“FOLDER RANDOM”) and off (“RANDOM OFF”). Press this button again cancels the Random play.

All Random play

Press and hold the [3] button.

All songs in iPod are played at random. Pressing the button toggles the setting between All random play on (“ALL RANDOM”) and off (“RANDOM OFF”). Press this button again cancels the All Random play.

Notes

• The time required to turn on the all random function may become longer depending on the number of songs in iPod.

• Turning on the all random function changes the iPod browse item to “Songs”. This browse item will not be changed even if the all random function is turned oﬀ.

• If the browse item is changed to search for music while the all random function is on, the all random function is turned oﬀ and the songs in the browse item are played at random.

APP & iPod Mode

Allowing you to operate iPod with the control on the iPod.

Press the [5] button.

When the APP & iPod mode is selected, ”MODE ON” appears.

Canceling the APP & iPod mode

Press the [5] button.

Operation when “APP&iPod MODE” is “ON”

• When “APP&iPod MODE” is set to “ON”, this unit can control only the “Pause and play”, “Selecting a song”, and “Fast Forward or Fast Backward of the Song” functions.

DPX-U5130BT/ DPX-U5130

Pandora® internet radio (Function of iPhone®/ Bluetooth device)

Requirements Pandora® internet radio

Requirements for listening to the Pandora® internet radio are as follows:

• In the application on your device, log in and create an account with Pandora.

(If you are not already a registered user, an account can also be created at www.pandora.com.)

• Internet connection by 3G, LTE, EDGE, or WiFi.

iPhone or iPod touch

• Use an Apple iPhone or iPod touch running under iOS3 or later.

• Search for “Pandora” in the Apple iTunes App Store to ﬁnd and install the most current version of the Pandora® application on your device.

• iPhone/ iPod touch connected to this unit with a KCA-iP102.

Android™

• Visit the Google play and search for Pandora to install.

• Bluetooth must be built in and the following proﬁles must be supported.

- SPP (Serial Port Proﬁle)

- A2DP (Advanced Audio Distribution Proﬁle)

BlackBerry®

• Visit www.pandora.com from the built in browser to download the Pandora application.

• Bluetooth must be built in and the following proﬁles must be supported.

- SPP (Serial Port Proﬁle)

- A2DP (Advanced Audio Distribution Proﬁle)

Notes

• Pandora® is currently available only in the U.S, Australia and New Zealand.

• Because Pandora® is a third-party service, the speciﬁcations are subject to change without prior notice. Accordingly, compatibility may be impaired or some or all of the services may become unavailable.

• Some functions of Pandora® cannot be operated from this unit.

• For issues using the application, please contact Pandora® at pandora-support@pandora.com

Listening to the Pandora® internet radio

Android or BlackBerry (DPX-U5130BT only)

• You need to register your cell-phone before using it with this unit. See <Registering a Bluetooth device> (page 30).

• Disconnect the iPhone or iPod touch.

 Connect the Android/BlackBerry smartphone

via Bluetooth.

Speakers from which audio is output change depending on the Bluetooth setting “BT HF/AUDIO”. The default is Front. See <Bluetooth detail setting> (page 37).

 Open the Pandora® application on your

device.

 Press the [SRC] button to select a Pandora

(“PANDORA”) source.

Refer to <Source selection> (page 10).

iPhone or iPod touch

 Open the Pandora® application on your

device.

 Open the cover.  Connect the iPod to the USB terminal using

the KCA-iP102 connecter (optional accessory).

The source switches, and broadcasting starts automatically from your current station.

English

Pandora® internet radio

Basic operation

Thumbs up

DPX-U5130BT

Press and hold the [1] button.

DPX-U5130

Press and hold the [R] button.

Thumbs down

DPX-U5130BT

Press and hold the [2] button.

DPX-U5130

Press and hold the [S] button.

Song skip

Press the [F].

Pause and play a song

Press the [L] button.

Station search

You can select the station you want to listen to from your station list.

 Press the [1] button.

“SEARCH” appears and enter the Station List mode.

 Use the [Control knob] to select a sort type.

For how to use the [Control knob], refer to <How to select the item> (page 9). “A-Z”: Stations are displayed in alphabetical order. “By Date”: Stations are displayed in date order.

 Use the [Control knob] to select a station.

DPX-U5130BT/ DPX-U5130

New station registration

You can search for a desired station. You can register the displayed station as a new station in your station list.

 Press and hold the [1] button.

“NEW STATION” appears and enter the New station registration.

 Use the [Control knob] select a search method.

For how to use the [Control knob], refer to <How to select the item> (page 9).

- “FROM ARTIST”: Searches for a song by the name of the artist you are listening to.

- “FROM TRACK”: Searches for a song by the name of the track you are listening to.

When you select a search method, a new station name is created.

 Use the [Control knob] to select a station.

The broadcast from the selected station is received and the station is registered in the station list.

Station preset memory

You can store a station in the memory.

 Press the [E] or [F] button to select the

station.

 Press and hold the button ([3] to [5]) to which

you want to assign the selected station.

“STORED” appears and the channel is registered.

Preset tuning

Recalling a channel from the memory.

Press the button ([3] to [5]) corresponding to the station you want to listen to.

Pandora source control

You can turn on/o the Pandora source.

 Press and hold the [AUDIO] button.

Enter the Function setting mode.

 Use the [Control knob] to select “INITIAL SET”

> “PANDORA SRC”.

For how to use the [Control knob], refer to <How to select the item> (page 9).

 Use the [Control knob] to select a Pandora

source control method.

“ON”: Turns on the Pandora source. “OFF”: Turns off the Pandora source.

Exit the Function setting mode

Press and hold the [6] button.

English

Aha Radio (Function of iPhone®/ Android)

Requirements Aha™

Requirements for listening to Aha™ are as follows:

• In the application on your device, log in and create a free account with Aha.

• Internet connection by 3G, LTE, EDGE, or WiFi.

iPhone or iPod touch

• Use an Apple iPhone or iPod touch running iOS4 or later.

• Search for “Aha” in the Apple iTunes App Store to ﬁnd and install the most current version of the Aha™ application on your device.

• iPhone/ iPod touch connected to this unit with a KCA-iP102.

Android™

• Use Android OS 2.2 or later.

• Download the Aha™ application to your

smartphone from the Google play.

• Bluetooth must be built in and the following proﬁles must be supported.

- SPP (Serial Port Proﬁle)

- A2DP (Advanced Audio Distribution Proﬁle)

Notes

• Because Aha™ is a third-party service, the speciﬁcations are subject to change without prior notice. Accordingly, compatibility may be impaired or some or all of the services may become unavailable.

• Some Aha™ functionality cannot be operated from this unit.

Listening to the Aha Radio

Android or BlackBerry (DPX-U5130BT only)

• You need to register your cell-phone before using it with this unit. See <Registering a Bluetooth device> (page 30).

• Disconnect the iPhone or iPod touch.

 Connect the Android/BlackBerry smartphone

via Bluetooth.

Speakers from which audio is output change depending on the Bluetooth setting “BT HF/AUDIO”. The default is Front. See <Bluetooth detail setting> (page 37).

 Open the Aha Radio application on your

device.

 Press the [SRC] button to select an Aha Radio

(“AHA”) source.

Refer to <Source selection> (page 10).

iPhone or iPod touch

 Open the Aha Radio application on your

device.

 Open the cover.  Connect the iPod to the USB terminal using

the KCA-iP102 connecter (optional accessory).

 Press the [SRC] button to select an Aha Radio

(“AHA”) source.

Refer to <Source selection> (page 10).

DPX-U5130BT/ DPX-U5130

Basic operations

Pause and play a content

Press the [L] button.

Selecting a content

Press the [E] or [F] button.

Forward 30 seconds a content

Press and hold the [F] button.

Backward 15 seconds a content

Press and hold the [E] button.

“Likes” current content

Press the [1] button.

To unvote, press the button again.

“Dislikes” current content

Press the [2] button.

To unvote, press the button again.

Station search

You can select the station you want to listen to from your station list.

 Press the [1] button.

“SEARCH” appears and enter the Station List mode.

 Use the [Control knob] to select a station.

For how to use the [Control knob], refer to <How to select the item> (page 9).

 Use the [Control knob] to select a content.

Calling a number in the content

You can call the phone number obtained from the content from a smartphone connected to this unit via Bluetooth.

 Press the [3] button.

“MAKE A CALL” appears.

 Press the [Control knob] to make a call.

“CALL” appears.

Canceling the conﬁrmative display

Press and hold the [6] button.

Disconnecting a call

Press the [Ú] button.

English

Listen to the CD/ Audio le

Playing music

Playing a disc

Insert a disc in the Disc slot. When it is inserted, the source is switched automatically and playback starts.

Playing a USB device

Connect a USB device to the USB terminal using the CA-U1EX connecter (500 mA Max.:optional accessory).

When it is connected, the source is switched automatically and playback starts.

Selecting an audio ﬁle folder

DPX-U5130BT

Press the [1] or [2] button.

DPX-U5130

Press the [R] or [S] button.

Selecting a song (track or ﬁle)

Press the [E] or [F] button.

Fast-forwarding or fast-backwarding a song (track or ﬁle)

Press and hold the [E] or [F] button.

Pause and play a song (track or ﬁle)

Press the [L] button.

Removing disc

Press the [G] button.

Removing USB device

Press the [SRC] button to switch the source to a device other than USB, and then remove the USB device. Data contained in the USB device may be damaged if you remove it when it is used as the active source.

Music search

You can select the music you want to listen to from the device or media being played now.

 Press the [1] button.

“SEARCH” appears and enters the Music search mode.

 Search for music

Audio ﬁle

Operation type Operation

Selecting folders/ﬁles Turn the [Control knob]. Determining selection Press the [Control knob]. Skip Search (Music Editor media) Press the [E] or [F]./

Returning to previous folder Press the [6] button. Returning to root folder Press the [5]. Cancellation of Music search mode Press and hold the [6] button.

- indicator: Audio ﬁle ; indicator: Folder

CD source

Operation type Operation

Selecting track Turn the [Control knob]. Determining selection Press the [Control knob]. Returning to ﬁrst track Press the [5]. Cancellation of Music

search mode

Press and hold the [E] or [F].

Press and hold the [6] button.

Skip search ratio setting

You can change the ratio of skip performed as mentioned in <Skip Search (Music Editor media)> (page 20).

 Select the USB source.

Refer to <Source selection> (page 10).

 Press and hold the [AUDIO] button.

Enter the Function setting mode.

 Use the [Control knob] to select “SETTINGS” >

“SKIP SEARCH”.

For how to use the [Control knob], refer to <How to select the item> (page 9).

 Use the [Control knob] to select a ratio.

The previous item appears.

Exit the Function setting mode

Press and hold the [6] button.

DPX-U5130BT/ DPX-U5130

Play function

(6)

Repeat play

Press the [4] button.

Switches between Track Repeat (“TRACK REPEAT ”) and OFF (“REPEAT OFF”) when pressed while playing a CD. Switches between File Repeat (“FILE REPEAT ”), Folder Repeat (“FOLDER REPEAT”), and OFF (“REPEAT OFF”) when pressed while playing an Audio file.

Random play

Press the [3] button.

Randomly plays the music in the disc or folder. When Random Play is turned on, “DISC RANDOM”/ “FOLDER RANDOM” appears. Press this button again cancels the Random play.

All Random play

Press and hold the [3] button.

All songs in the disc/USB are played at random. Pressing the button toggles the setting between All random play on (“ALL RANDOM”) and off (“RANDOM OFF”). Press this button again cancels the All Random play.

Direct music search

(Function of remote control)

You can search for music by entering the track number.

 Press the [DIRECT] button on the remote

control.

“– –” appears and enter the Direct Music search mode.

 Press the number buttons on the remote

control to enter the music number.

 Press the [ENT] button on the remote control.

Canceling the Direct music search mode

Press the [6] button on the remote control.

About the Audio ﬁle

• Playable Audio les

AAC-LC (.m4a), MP3 (.mp3), WMA (.wma), WAV of USB device (.wav)

• Playable disc media

CD-R/RW/ROM

• Playable disc le formats

ISO 9660 Level 1/2, Joliet, Long ﬁle name.

• Playable USB devices

USB mass storage class

• Playable USB device le systems

FAT12, FAT16, FAT32

Even if the audio ﬁles comply with the standards listed above, playback may be impossible depending on the type or condition of the medium or device.

• Playback order of the Audio les

In the example of folder/ﬁle tree shown below, ﬁles are played in the order of number from (1) to (6).

CD/USB(1)

(1)

(2)

(4)

(3)

(5)

;: folder

-: Audio ﬁle

For the online manual describing audio ﬁles, visit www.kenwood.com/cs/ce/audioﬁle/. In this online manual, detailed information and notes which are not provided in this manual are provided. Make sure to read through the online manual as well.

What is a USB device?

• In this manual, the term “USB device” indicates a ﬂash memory or digital audio player which has a USB terminal.

English

Listen to the CD/ Audio le

About the USB device

• When the USB device is connected to this unit, it is charged when this unit is powered.

• Install the USB device in the place where it will not prevent you from driving your vehicle properly.

• You cannot connect a USB device via a USB hub or multi card reader.

• Save backups of the audio ﬁles used with this unit. The ﬁles can be erased depending on the operating condition of the USB device.

We shall not be liable for any damage arising out of erasure of the stored data.

• No USB device comes with this unit. You need to purchase a commercially available USB device.

• When connecting the USB device, use of the CA-U1EX (option) is recommended.

• Normal playback is not guaranteed when a cable other than the USB compatible cable is used. Connecting a cable whose total length is longer than 4 m can result in abnormal playback.

About “KENWOOD Music Editor Light” and “KENWOOD Music Control”

• This unit supports the PC application “KENWOOD Music Editor Light” (hereinafter “KME-Light”), and Android™ application “KENWOOD Music Control” (hereinafter “KMC”).

• When you use the audio ﬁle with database information added by the “KENWOOD Music Editor Light” or “KENWOOD Music Control”, you can search for a ﬁle by title, album or artist name using Music Search.

• “KENWOOD Music Editor Light” and “KENWOOD Music Control” are available from the following web site: www.kenwood.com/cs/ce/

About the discs used with this unit

• This unit can only play the CDs with .

• The following discs cannot be used:

- A discs that is not round

- A discs with coloring on the recording surface or a disc that is dirty

- A recordable/rewritable disc that has not been ﬁnalized (For the ﬁnalization process, refer to the instruction manual that came with your disc writing software or your disc recorder.)

- An 8 cm (3 inch) disc (An attempt to insert using an adapter can cause malfunction.)

Handling discs

• Do not touch the recording surface of the disc.

• Do not stick tape etc. on the disc, or use a disc with

tape stuck on it.

• Do not use any accessories for the disc.

• Do not use any solvents to clean discs. Use a dry

silicon or soft cloth.

• Clean the disc by moving the cloth outward from the center of the disc.

• When removing a disc from this unit, pull it out horizontally.

• If the center hole or outside rim of a disc has burrs, remove them before inserting a disc.

DPX-U5130BT/ DPX-U5130

Listen to the tuner

Listening to the radio

Selecting a tuner source

Press the [SRC] button to select a “TUNER”.

Selecting a band

Press the [1] button.

Pressing the button switches the receiving band (FM1, FM2, FM3, MW, SW1, SW2).

Selecting a station

Press the [E] or [F] button. The tuning mode can be changed. Refer to <Tuner setting> (page 23).

Station preset memory

You can store a station in the memory.

 Press the [E] or [F] button to select the

channel.

 Press and hold the button ([1] to [6]) to which

you want to assign the selected station.

“STORED” appears and the station is registered.

About the Mix station preset mode

• In this mode, diﬀerent bands and tuner sources can be saved in the same preset layer, which allows you to recall the desired station without switching between bands or tuner sources.

Auto memory

You can register 6 (FM)/ 6 (AM) stations with good reception automatically.

 Select the Tuner source.

Refer to <Source selection> (page 10).

 Press and hold the [AUDIO] button.

Enter the Function setting mode.

 Use the [Control knob] to select “SETTINGS” >

“AUTO MEMORY”.

For how to use the [Control knob], refer to <How to select the item> (page 9).

 Use the [Control knob] to select “YES”.

When 6 (FM)/ 6 (AM) stations that can be received are stored in the memory, the process in this mode is completed.

Preset tuning

Recalling a station from the memory.

 Press the [1] button to select a band.  Press the button ([1] to [6]) corresponding to

the station you want to listen to.

Tuner setting

You can set up the tuner.

 Select the Tuner source.

Refer to <Source selection> (page 10).

 Press and hold the [AUDIO] button.

Enter the Function setting mode.

 Use the [Control knob] to select “SETTINGS”.

For how to use the [Control knob], refer to <How to select the item> (page 9).

 Use the [Control knob] to select a Tuner

setting item

Display Description

“LOCAL SEEK”

“SEEK MODE”

“MONO SET”

( : Factory setting)

Only stations whose reception is good are searched in auto seek tuning. (FM only)

“ON” / “OFF”

Sets the tuning mode.

“AUTO1”: Automatic search for a station. “AUTO2”: Search in order of the stations in the preset

memory. “MANUAL”: Normal manual tuning.

You can reduce the noise when stereo broadcasts are received as monaural. (FM only)

“ON” / “OFF”

 Use the [Control knob] to select a setting.

The previous item appears.

Exit the Function setting mode.

Press and hold the [6] button.

English

Listen to the tuner

Direct access tuning

(Function of remote control) You can search for a station directly by entering frequency.

 Press the [DIRECT] button on the remote

control.

“– – – –” appears and enter the Direct access tuning mode.

 Press the number buttons on the remote

control to enter the frequency.

Example:

Desired frequency Press the following buttons

92.1 MHz (FM) [9], [2], [1] 810 kHz (AM) [8], [1], [0]

 Press the [ENT] button on the remote control.

Canceling Direct access tuning mode

Press the [6] button on the remote control.

Frequency Step Setting

Changing the tuning frequency step. The original setting is FM band 50 kHz, and AM band 9 kHz.

 Press and hold the [SRC] button to turn the

power OFF.

 While pressing the [1] and [5] buttons, press

the [SRC] button to switch the frequency step.

Release your fingers from the button after the display appears. The frequency step changes to FM band 200 kHz, and AM band 10 kHz.

Notes

• When the same operation is repeated, the frequency step returns to the original setting.

• When the frequency step is changed, the frequencies in the memory are deleted.

DPX-U5130BT/ DPX-U5130

Listen to the AUX

Start listening



Connect a portable audio player with 3.5 mm stereo mini plug audio cable (commercially available).

 Select the AUX source.

Refer to <Source selection> (page 10).

 Turn on the portable audio player and start

playback.

Auxiliary input display setting

You can set the display when switched the AUX source.

 Select the AUX source.

Refer to <Source selection> (page 10).

 Press and hold the [AUDIO] button.

Enter the Function setting mode.

 Use the [Control knob] to select “SETTINGS” >

“AUX NAME SET”.

For how to use the [Control knob], refer to <How to select the item> (page 9).

 Use the [Control knob] to select a display

(“AUX”, “DVD”, “PORTABLE”, “GAME”, “VIDEO”, or “TV”).

Exit the Function setting mode.

Press and hold the [6] button.

English

Display settings

Illumination color selection

You can select the illumination color of the panel.

 Press and hold the [AUDIO] button.

Enter the Function setting mode.

 Use the [Control knob] to select “SETTINGS” >

“DISP & KEY” > “COLOR SELEC T”.

For how to use the [Control knob], refer to <How to select the item> (page 9).

 Use the [Control knob] to select a illumination

part.

Display Part

“ALL” All “DISP” Display “KEY” Button

 Use the [Control knob] to select a color

(“VARIABLE SCAN”/ “COLOR01” — “COLOR24”).

Exit the Function setting mode.

Press and hold the [6] button.

Adjusting the Illumination color

You can adjust the illumination color of the panel.

 Select the illumination color you want to

adjust.

Select from among “COLOR01” to “COLOR24” with reference to <Illumination color selection> (page 26).

 Press and hold the [Control knob].

The RGB value of the selected illumination color appears and enters the Detail color adjustment mode.

 Set the color.

Operation type Operation

To select the color to adjust (Red, Green, or Blue)

To adjust color (Range: 0 – 9) Turn the [Control knob]. Determination of the adjusted color. Press the [Control knob].

The color you created can be called by selecting “USER”.

Exit the Function setting mode.

Press and hold the [6] button.

Press the [E] or [F].

Display & Illumination setting

You can set the display and illumination.

 Press and hold the [AUDIO] button.

Enter the Function setting mode.

 Use the [Control knob] to select “SETTINGS” >

“DISP & KEY”.

For how to use the [Control knob], refer to <How to select the item> (page 9).

 Use the [Control knob] to select a Display &

Illumination setting item.

Display Description

“DISP DIMMER”

“TEXT SCROLL”

“DISP OFF MODE” Sets the clock and button illumination when

“CLOCK”

“KEY ILLUMI”

“ILLUMI DIMMER”

“BT DVC STATUS” You can display the connection status, signal

( : Factory setting)

Dims the display part in conjunction with the Light switch of the vehicle.

“DIM OFF”: Does not dim the display. “DIM AUTO”: Dims the display in conjunction

with the Light switch of the vehicle.

“DIM MANUAL1”: Dims the display constantly. “DIM MANUAL2”: Dims the display darker

than that in the Manual1 mode. Sets the method of scrolling to view hidden

texts.

“SCROLL AUTO” : Scrolls. “SCROLL ONCE” : Scrolls once. “SCROLL OFF” : Does not scroll.

“DISP OFF MODE” is selec ted as described in <Text Display Selection> (page 27).

“CLOCK ON” : Displays the clock. “CLOCK OFF” : Dims the clock.

“KEY ON” : Turns on the button illumination. “KEY OFF” : Dims the button illumination.

Reduces the key Illumination brightness.

“DIM OFF”: Does not dim the illumination. “DIM AUTO”: Dims the illumination in

conjunction with the Light switch of the vehicle. “DIM MANUAL1”: Dims the illumination constantly. “DIM MANUAL2”: Dims the illumination darker than that in the Manual1 mode.

strength, and battery level. HF-CON : Connection status for cell-phone. (1/: One cell-phone is connected, 1/2: Two cell-phones are connected, NO: No cell-phone is connected.) AD-CON : Connection status for BT Audio. (YES: Connected, NO: Not connected) BATT : Battery level of cell-phone. SIGNAL : Signal strength of cell-phone. (Function of DPX-U5130BT)

DPX-U5130BT/ DPX-U5130

 Use the [Control knob] to select a setting.

The previous item appears.

Exit the Function setting mode.

Press and hold the [6] button.

Text Display Selection

You can change the information displayed on each of the following sources:

 Press the [DISP].

On Audio ﬁle/ iPod source

Information Display

Title and Artist name “TITLE/ARTIST” Album and Artist name “ALBUM/ARTIST” Folder name “FOLDER NAME” File name “FILE NAME” Play time “P-TIME” Display oﬀ “DISP OFF MODE”

On Pandora source

Information Display

Station name “STATION NAME” Title and Artist name “TITLE/ARTIST” Album and Artist name “ALBUM/ARTIST” Play time “P-TIME” Display oﬀ “DISP OFF MODE”

DPX-U5130BT

On Aha Radio source

Information Display

Content Provider “PROVIDER“ Content information 1 “CONTENT INFO1” Content information 2 “CONTENT INFO2” Content rating information “CONTENT RATE” Station name “STATION NAME“ Display oﬀ “DISP OFF MODE”

On CD source

Information Display

Disc title “DISC TITLE” Track title “TRACK TITLE” Play time “P-TIME” Display oﬀ “DISP OFF MODE”

On Tuner source

Information Display

Frequency “FREQUENCY” Display oﬀ “DISP OFF MODE”

DPX-U5130BT

On Bluetooth audio source

Information Display

Title and Artist name “TITLE/ARTIST” Album and Artist name “ALBUM/ARTIST” Play time “P-TIME” Display oﬀ “DISP OFF MODE”

On Standby/ Auxiliary input source

Information Display

Source name “SOURCE NAME” Display oﬀ “DISP OFF MODE”

Text display notes

• When you select the Display oﬀ mode, the display setting of each source will be changed to the Display oﬀ.

• If the selected display item does not have any information, alternative information appears.

• If you select “FOLDER NAME” while playing music on the iPod, names will be displayed depending on the currently selected browsing items.

• If you select the APP & iPod Control mode while playing music on the iPod, “APP&iPod MODE” appears.

• If all characters cannot be displayed while music is played on the iPod, the ﬁle number in the list appears.

Information Display

Music title “TITLE***” Folder name “FOLDER***” File name “FILE***”

Text scroll

Press and hold the [DISP].

The displayed text scrolls.

English

General settings

Muting the audio upon reception of a phone call

Function of DPX-U5130

The audio system automatically mutes when it receives an incoming call.

When a call comes in

“CALL” appears. The audio system pauses.

Listening to the audio during a call

Press the [SRC] button.

The “CALL” display disappears and the audio system comes back ON.

When the call ends

Hang up the phone.

The “CALL” display disappears and the audio system comes back ON.

To use this function

• To use the TEL Mute feature, you need to hook up the MUTE wire to your telephone using a commercial telephone accessory. Refer to <Connecting Wires to Terminals> (page

44).

Demonstration mode setting

You can turn on/o the demonstration mode.

 Press and hold the [AUDIO] button.

Enter the Function setting mode.

 Use the [Control knob] to select “DEMO

MODE”.

For how to use the [Control knob], refer to <How to select the item> (page 9).

 Use the [Control knob] to select a setting

(“ON” or “OFF”).

Exit the Function setting mode.

Press and hold the [6] button.

DPX-U5130BT/ DPX-U5130

Initial settings

You can congure initial settings of this unit.

 Select the Standby source.

Refer to <Source selection> (page 10).

 Press and hold the [AUDIO] button.

Enter the Function setting mode.

 Use the [Control knob] to select “INITIAL SET”.

For how to use the [Control knob], refer to <How to select the item> (page 9).

 Use the [Control knob] to select an Initial

setting item.

Display Description

“PRESET TYPE”

“KEY BEEP”

“PANDORA SRC”

“AHA SRC”

“BUILT-IN AUX”

“CD READ”

“SWITCH PREOUT”

Sets the Tuner preset type. “TYPE NORMAL”: 1 station can be assigned to 1 preset button in each of 4 bands (FM1, FM2, FM3, and AM), i.e., a total of 24 stations (6 stations x 4 bands) can be preset. “TYPE MIX”: A total of 6 stations can be assigned to a total of 6 preset buttons regardless of band (FM1, FM2, FM3, and AM). You can recall a preset station without switching between bands.

Setting the operation check sound (beep sound) ON/OFF.

“ON” / “OFF”

Sets whether to display Pandora during source selection.

“ON” / “OFF”

Sets whether to display aha during source selection.

“ON” / “OFF”

(Function of DPX-U5130BT) Sets whether to display AUX during source

selection.

“ON” / “OFF”

Sets the method for reading CD. When unable to play a special format CD, set this setting to “2” to force playing. Note that some music CDs may be unplayable even when set to “2”. In addition, audio ﬁles cannot be played when set to “2”. Normally, keep this set to “1”. 1: Automatically distinguishes between the audio ﬁle disc and music CD when playing a disc. 2: Forces playing as a music CD.

Switches the preout between rear output and subwoofer output.

“REAR”: Rear output “SUB-W”: Subwoofer output

(Function of DPX-U5130)

“SP SELECT” Sets the speaker type so that the System Q

value is optimal.

“OFF”: OFF “5/4”: For 5 & 4 in. speaker “6*9/6”: For 6 & 6x9 in. speaker “O.E.M.”: For the OEM speaker

“F/W UPDATE” Upgrades the ﬁrmware.

When the ﬁrmware version appears, press [Control knob]. Selecting “YES” and then pressing the [Control knob] starts upgrading the ﬁrmware. For how to update the ﬁrmware, access our web site. http://www.kenwood.com/cs/ce/

( : Factory setting)

 Use the [Control knob] to select a setting.

The previous item appears.

Exit the Function setting mode.

Press and hold the [6] button.

English

Registering a Bluetooth (Function of DPX-U5130BT)

About the Bluetooth module

This unit conforms to the following Bluetooth speciﬁcations:

Version Bluetooth Ver.2.1+EDR Certiﬁed Proﬁle HFP (Hands Free Proﬁle)

SPP (Serial Port Proﬁle) PBAP (Phonebook Access Proﬁle) OPP (Object Push Proﬁle) A2DP (Advanced Audio Distribution Proﬁle) AVRCP (Audio/Video Remote Control Proﬁle)

For the cell-phones veriﬁed for compatibility, access the following URL:

http://www.kenwood.com/cs/ce/bt/

Notes

• The units supporting the Bluetooth function have been certiﬁed for conformity with the Bluetooth Standard following the procedure prescribed by Bluetooth SIG. However, it may be impossible for such units to communicate with your cell-phone depending on its type.

• HFP is a proﬁle used to make a hands-free call.

• OPP is a proﬁle used to transfer data such as a phone book

between units.

Registering a Bluetooth device

You can register your Bluetooth device in this unit.

 Start registering a unit by operating the

Bluetooth device. By operating the Bluetooth device, register the hands-free unit or audio unit (pairing).

Select “DPX-U51**BT” (for DPX-U5130BT) from the list of found units.

 If “PAIRING PASS ****** (Bluetooth device

name) PRESS VOLUME KNOB” appears, proceed to step 4.

 Input the PIN code (“0000”) in the Bluetooth

device.

Check that registration is complete on the Bluetooth device. PIN code is set to “0000” as the default. You can change this code. See <Registering the PIN code> (page 36) “PAIRING PASS ****** (Bluetooth device name) PRESS VOLUME KNOB” appears.

 Press the [Control knob].

Pairing starts. When is it completed, “PAIRING OK” appears.

Bluetooth module that can be used with this unit

• For details on the Bluetooth cell-phone with the hands-free function, see <About the Bluetooth module> (page 30).

About automatic connection of the iPod touch or iPhone

through Bluetooth

• This unit is compatible with an Apple Auto Pairing function. Connecting the iPod touch or iPhone to this unit with USB cable will automatically register it as a Bluetooth device. See <“AUTO PAIRING”> (page 37).

1. The Bluetooth function of the iPod touch or iPhone is turned on ﬁrst.

2. Connect an iPod touch or iPhone to the USB terminal.

3. Press the volume knob to pair once you have conﬁrm the passcode.

When registration is impossible

• If there are 5 Bluetooth devices registered, you cannot register a new Bluetooth device.

• When any error code appears while the pairing is in progress, refer to <Error messages> (page 41).

When SMS is received

• When the connected Bluetooth device receives SMS, “SMS RECEIVE” is displayed on this unit.

Selecting the Bluetooth device you wish to connect

When two or more Bluetooth devices have already been registered, you need to select the Bluetooth device you wish to use.

 Press the [Ú] button.

“BT MODE” appears and enter the Bluetooth mode.

 Use the [Control knob] to select “SETTINGS”

> “PAIRING” > “PHONE SELECT” (to select the cell-phone) or “AUDIO SELECT” (to select the audio player).

For how to use the [Control knob], refer to <How to select the item> (page 9). “(name)” appears.

 Use the [Control knob] to select an Bluetooth

device.

‘*(name)’ or ‘-(name)’ appears. “*”: The selected Bluetooth device is busy. “-”: The selected Bluetooth device is on standby. “ “ (blank): The Bluetooth device is deselected.

Exit the Bluetooth mode.

Press the [Ú] button.

DPX-U5130BT/ DPX-U5130

When no device can be selected

• If a cell-phone is already selected, deselect it, and then select a diﬀerent one.

• If you cannot select a device using the audio player, connect the device with the audio player.

Deleting a registered Bluetooth device

You can delete a registered Bluetooth device.

 Press the [Ú] button.

“BT MODE” appears and enter the Bluetooth mode.

 Use the [Control knob] to select “SETTINGS” >

“PAIRING” > “DEVICE DELETE”.

For how to use the [Control knob], refer to <How to select the item> (page 9). “(name)” appears.

 Use the [Control knob] to select an Bluetooth

device.

 Use the [Control knob] to select “YES”.

“COMPLETED” appears.

Exit the Bluetooth mode.

Press the [Ú] button.

When a registered device is deleted

• When a registered cell-phone is deleted, its phone Book, and log are also deleted.

Bluetooth device registration test

You can check whether a Bluetooth device can be registered by operating this unit.

 Press the [Ú] button.

“BT MODE” appears and enter the Bluetooth mode.

 Use the [Control knob] to select “BT TEST

MODE”.

For how to use the [Control knob], refer to <How to select the item> (page 9). “PLEASE PAIR YOUR PHONE” appears.

 By operating the Bluetooth device, register

the hands-free unit or audio unit (pairing).

Select “DPX-U51**BT” (for DPX-U5130BT) from the list of found units.

 If “(Bluetooth device name)” appears, proceed

to step 6.

 Input the PIN code (“0000”) in the Bluetooth

device.

 Use the [Control knob] to select an Bluetooth

device.

When pairing is completed successfully, a connection test starts automatically. When the connection test is completed, test results are displayed on a function basis (“OK”: Enabled; “NG”: Disabled).

Display Description

“PAIRING” Registration in this unit “HF CNT” Hands-free phoning “AUD CNT” Audio playback “PB DL” Phone Book downloading

 Press the [Control knob].

Exit the test mode.

English

Hands-free phoning (Function of DPX-U5130BT)

Receiving a call

You can answer a phone call

Press the [Ú] button.

The following operations disconnect the line

• Inserting a CD.

• Connecting a USB device.

Rejecting an incoming call

Press the [SRC] button.

Calling a number in the phone book



Press the [7] button.

 Search for a name in the phone book.

Operation type Operation

Selection of name list Turn the [Control knob]. Switching to number list Press the [Control knob].

 Search for a number in the phone book.

Operation type Operation

Selection of number list Turn the [Control knob]. Switching to name list Press the [6].

 Press the [Control knob].

Make a call.

When there is no phone book

• If the phone book has not yet been downloaded automatically, download it according to <Downloading the phone book> (page 36).

Display of phone book

• During search, a non-accent character such as “u” is searched for instead of an accent character such as “ü”.

Alphabet search

You can search for a name in the phone book by the alphabet.

 Press the [7] button.  Press the [1] button.

Enter the Alphabet search mode and “<ABCDEFGHIJK>” appears.

 Search for a name in the phone book.

Operation type Operation

Selection of initial Turn the [Control knob]. Page feeding of

alphabetical list Determine the initial Press the [Control knob].

Press the [E] or [F].

 Use the [Control knob] to select a name.  Search for a number in the phone book.

Operation type Operation

Selection of number list Turn the [Control knob]. Switching to name list Press the [6].

 Press the [Control knob].

Make a call.

Canceling the Alphabet search mode

Press and hold the [6] button.

Dialing a number



Press the [Ú] button.

“BT MODE” appears and enter the Bluetooth mode.

 Use the [Control knob] to select “NUMBER

DIAL”.

For how to use the [Control knob], refer to <How to select the item> (page 9).

 Enter a phone number.

Operation type Operation

Selection of number Turn the [Control knob]. Selection of digit Press the [E] or [F].

 Press the [Control knob].

Make a call.

Number of digits that can be input

• You can input a maximum of 32 digits.

DPX-U5130BT/ DPX-U5130

Calling a number in the call log



Press the [Ú] button.

“BT MODE” appears and enter the Bluetooth mode.

 Use the [Control knob] to select “CALL

HISTORY”.

For how to use the [Control knob], refer to <How to select the item> (page 9).

 Turn the [Control knob] to select a name and

phone number.

I : Incoming calls O : Outgoing calls M : Missed calls

 Press the [Control knob].

Make a call.

Registering in the preset dial number list



Press the [Ú] button.

“BT MODE” appears and enter the Bluetooth mode.

 Enter the phone number you wish to register

Enter the phone number with reference to the following: <Calling a number in the phone book> (page

32) <Dialing a number> (page 32) <Calling a number in the call log> (page 33)

 Press and hold number button ([1] to [6]).

During a call

Speed dialing (Preset dial)



Press the [Ú] button.

“BT MODE” appears and enter the Bluetooth mode.

 Press number button ([1] to [6]).  Press the [Control knob].

Make a call.

Registering a dial number

• You need to register the preset dial number. Refer to <Registering in the preset dial number list> (page 33).

Disconnecting a call

Press the [SRC] button.

Switching to the Private mode

Press the [L] button.

Pressing this knob each time switches between the private talk mode (“PV TALK”) and hands-free talk mode (“HF TALK”).

When the previous source is restored in the Private mode

• Depending on the type of your cell-phone, switching to the private talk mode may select the source that was used before commencing the hands-free connection. If this happens, the source cannot be switched back to the hands-free talk mode by operating this unit. Operate your cell-phone to return to the hands-free talk mode.

Adjusting the voice volume during a call

Turn the [Control knob].

English

Hands-free phoning

Switching between Two Connected Cell-phones

When two Bluetooth devices are connected, you can assign the Bluetooth device to be used in priority to the other Bluetooth device.

When selecting the priority device using the button

 Press the [Ú] button.

“BT MODE” appears and enter the Bluetooth mode.

 Press and hold [Ú] button.

The device given priority is changed.

When selecting the priority device from the menu

 Press the [Ú] button.

“BT MODE” appears and enter the Bluetooth mode.

 Use the [Control knob] to select “DVC

PRIORITY”.

For how to use the [Control knob], refer to <How to select the item> (page 9).

 Turn the [Control knob] to select a “MAIN” or

“SUB”.

 Press the [Control knob].

When Sub is selected, the device given priority is changed.

Exit the Bluetooth mode.

Press the [Ú] button.

Notes

• You cannot switch between the connected cell-phones during downloading of the Phone Book.

• Only the main cell-phone from which you can make a call.

• Both the main and sub cell-phones can receive an

incoming call.

• If the other cell-phone receives an incoming call while you are talking on the active cell-phone, you must ﬁnish the current call to answer the incoming call to the other cellphone.

• If the main cell-phone is disconnected when it is taken out of the vehicle, the sub cell-phone becomes the main cellphone if it is held connected. When the disconnected cellphone is brought back into the vehicle, it is reconnected as the sub cell-phone.

Clearing the disconnection message

Press the [Ú] button.

“HF DISCONCT” disappears.

Making a call by voice dialing

You can make a voice call using the voice recognition function of the cell-phone.

 Press and hold the [Ú] button to start voice

recognize.

“VOICE CONTROL” appears.

 Pronounce the name registered in the cell-

phone.

Make a call.

Canceling the voice recognize

Press and hold the [Ú] button.

About voice recognition

• If “NO SUPPORT” appears, your cell-phone does not support the voice recognition function.

• If “N/A VOICE TAG” appears, your cell-phone cannot start voice recognition.

• If your voice cannot be recognized, a message appears. Press and hold the volume knob to terminate voice recognition. Retry it again from the beginning.

• Audio sound is not output during voice recognition.

Display of phone number types (categories)

The category items in the phone book are displayed as follows:

Display Information

Home

Mobile

Oﬃce

General

Other

DPX-U5130BT/ DPX-U5130

Bluetooth audio (Function of DPX-U5130BT)

Before use

• You need to register your Bluetooth audio player before using it with this unit. For more details, see <Registering a Bluetooth device> (page 30).

• You need to select the Bluetooth audio player you wish to connect. Refer to <Selecting the Bluetooth device you wish to connect> (page 30).

Basic operations

Selecting a Bluetooth audio source

Select the Bluetooth audio source.

Refer to <Source selection> (page 10).

Pause and play a song

Press the [L] button.

Selecting a song

Press the [E] or [F] button.

Fast-forwarding or fast-backwarding a song

Press and hold the [E] or [F] button.

Selecting an audio ﬁle folder

Press the [1] or [2] button.

Preparation for using a Bluetooth audio player

• All or some of the operations above cannot be performed if the Bluetooth audio player is not ready for remote control.

• Switching between Bluetooth audio sources does not start or stop playback automatically. Perform the operation for starting or stopping playback.

• Some audio players cannot be controlled remotely or reconnected after Bluetooth disconnection. Operate the main unit of the audio player to connect a Bluetooth device.

Play function

Random play

Press the [3] button.

Switches between Folder Random (“FOLDER RANDOM”), All Random (“ALL RANDOM”), and OFF (“RANDOM OFF”).

Repeat play

Press the [4] button.

Switches between File Repeat (“FILE REPEAT ”), All Repeat (“ALL REPEAT”), and OFF (“REPEAT OFF”).

Functions that can be used

• The available playback functions diﬀer depending on the type of the connected Bluetooth audio player.

English

Bluetooth settings (Function of DPX-U5130BT)

Registering the PIN code

By operating the Bluetooth device, specify the PIN code necessary for registering this unit.

 Press the [Ú] button.

“BT MODE” appears and enter the Bluetooth mode.

 Use the [Control knob] to select “SETTINGS” >

“DETAILED SET” > “PIN CODE EDIT”.

For how to use the [Control knob], refer to <How to select the item> (page 9).

 Input the PIN code

Operation type Operation

Selection of numbers Turn the [Control knob]. Movement to the next digit Press the [F]. Deletion of the last digit Press the [E]. Transmission of PIN code Press the [Control knob].

If “COMPLETED” appears and registration is complete.

Exit the Bluetooth mode.

Press the [Ú] button.

Notes on PIN code input

• By default, “0000” is speciﬁed.

• A PIN code can be speciﬁed with up to eight digits.

Downloading the phone book

If the phone book is not downloaded automatically to this unit to which a cell-phone -which is not compatible with PBAP- is connected, download it in the following manner:

 Press the [Ú] button.

“BT MODE” appears and enter the Bluetooth mode.

 Use the [Control knob] to select “SETTINGS” >

“TRANSFER PB”.

For how to use the [Control knob], refer to <How to select the item> (page 9). When downloading starts, “PB DL ###” appears.

Exit the Bluetooth mode.

Press the [Ú] button.

Maximum number of phone numbers that can be

registered

• Up to 400 phone numbers can be registered for each registered cell-phone.

• Up to 32 digits can be registered for each phone number along with up to 50* characters representing a name. (* 50: Number of alphabetical characters. Fewer characters can be input depending on the type of characters.)

Cancellation of downloading

• To cancel downloading of the phone book data, operate the cell-phone.

DPX-U5130BT/ DPX-U5130

Deleting the phone book

You can delete the phone book stored in this unit to which a cell-phone − which is not compatible with PBAP − is connected.

 Press the [7] button.  Search for a number/name in the phone book.

Operation type Operation

Selection of name list and number list Turn the [Control knob]. Switching to number list Press the [Control knob]. Switching to name list Press the [6].

 Press and hold the [Control knob].  Use the [Control knob] to select the item to be

deleted.

For how to use the [Control knob], refer to <How to select the item> (page 9).

Display Item to be deleted

“DELETE ONE” When a name is selected, all phone numbers

registered to the name are deleted. When a phone number is selected, only the selected phone number is deleted.

“DELETE ALL” When a name is selected, all the registered phone

books are deleted. When a phone number is selected, all the phone books having the name to which the selected number are deleted.

 Use the [Control knob] to select “YES”.

“COMPLETED” appears.

Displaying the ﬁrmware version

You can view the version of the rmware of this unit.

 Press the [Ú] button.

“BT MODE” appears and enter the Bluetooth mode.

 Use the [Control knob] to select “SETTINGS” >

“DETAILED SET” > “BT F/W UPDATE”.

For how to use the [Control knob], refer to <How to select the item> (page 9). The firmware version appears.

Exit the Bluetooth mode.

Press the [Ú] button.

How to update

• For how to update the ﬁrmware, access our web site. www.kenwood.com/cs/ce/bt/

Bluetooth detail setting

You can congure the initial settings of this unit.

 Press the [Ú] button.

“BT MODE” appears and enter the Bluetooth mode.

 Use the [Control knob] to select “SETTINGS” >

“DETAILED SET”.

For how to use the [Control knob], refer to <How to select the item> (page 9).

 Use the [Control knob] to select an Bluetooth

detail setting item.

Display Description

“AUTO ANSWER”

“RECONNECT”

“AUTO PAIRING”

“BT HF/AUDIO”

“CALL BEEP”

“MIC GAIN”

“ECHO CANCEL”

( : Factory setting)

Automatically answers a call after lapse of the preset time interval. “OFF”: Does not answer the phone call automatically. “1” – “8” – “99”: Automatically answers the phone call after lapse of 1 – 99 seconds.

When set to “ON”, starts re-pairing with the registered Bluetooth device automatically when it becomes unpaired.

“ON” / “OFF”

When set to “ON”, performs Bluetooth pairing automatically when the iPhone is connected to the USB terminal.

“ON” / “OFF”

Speciﬁes the output speakers for hands-free voice communication and Bluetooth audio sound. “FRONT” : Outputs sound from the front speakers. “ALL” : Outputs sound from the front and rear speakers.

Sets whether to output a beep from the speaker when a call comes in.

“ON” : Outputs a beep. “OFF” : Does not output a beep.

Adjusts the sensitivity of the microphone for telephone call or adjusts the voice of the caller.

“-20” – ”0” – “+8”

Sets the echo cancellation level.

“1” – ”4” – “10”

 Use the [Control knob] to select a setting.

The previous item appears.

Exit the Bluetooth mode.

Press the [Ú] button.

English

Basic operation of remote control

Before using remote control

Preparing the remote control unit

Pull the battery sheet out from the remote control unit in the direction of the arrow.

Changing the battery of the remote control unit

(1)

(2)

Use a commercially available button battery (CR2025). Insert the battery with the + side facing upward, following the illustration inside the case.

(1) Keep on sliding. (2) Pull out.

! CAUTION

• Keep battery out of reach of children and in original package until ready to use. Dispose of used batteries promptly. If swallowed contact physician immediately.

• Do not leave the battery near re or under direct sunlight. A re, explosion or excessive heat generation may result.

• Do not set the remote control in hot places such as on the dashboard.

• The Lithium battery is in danger of explosion if replaced incorrectly. Replace only with the same or equivalent type.

Basic opreation

VOL

5/∞

DIRECT/OK

0 — 9

General control

• Volume control: [VOL]

• Source selection: [SRC]

Press and hold to turn oﬀ the power.

• Volume reduction: [AT T] When the button is pressed again, the volume

returns to the previous level.

• Returning to previous item: [6]

• Selection of item: [R]/[S]

• Determination: [ENT]

• Enter Audio Control mode: [AUD]

About power on

• The remote control cannot be used to turn the power on. Press the [SRC] button on the main unit.

On Tuner source

• Band selection: [FM]/[AM]

• Station selection: [E]/[F]

• Recall preset stations: [1] – [6]

On CD/Audio ﬁle source

• Music selection: [E]/[F]

• Folder selection: [FM]/[AM]

• Pause/Play: [ENT]

• Enter the Music search mode: [R]/[S]

• Selecting folders/les during Music search

mode: [R]/[S]

• Returning to previous folder: [6]

SRC

ATT

ENT

AUD

DPX-U5130BT/ DPX-U5130

On iPod source

• Enter Music search mode: [R]/[S]

• Selecting items during Music search mode: [R]/

[S]

• Returning to previous item: [6]

• Pause/Play: [ENT]

On Pandora internet radio source

• Song skip: [F]

• Pause/Play: [ENT]

• Enter the station list mode: [R]/[S]

- Select item: [R]/[S]

- Exit the station list mode: [6]

On Aha source

• Selecting a content: [E]/[F]

• Pause/Play: [ENT]

• Enter the station search mode: [R]/[S]

- Select item: [R]/[S]

- Exit the station search mode: [6]

Hands-free phone control

Making a call

• Enter Bluetooth mode: [Ú]

• Select a dialing method: [R]/[S] Á [ENT]

• Number dial input:

- Input a digit: [0] – [9]

- Input “+”: [F]

- Input “#”: [FM]

- Input “*”: [AM]

- Clear the entered phone number: [E]

• Make a call: [ENT]

Receiving a call

• Answer the call: [Ú]

During a call

• End the call: [Ý]

English

Troubleshooting guide

Setting error

Some functions of this unit may be disabled by some settings made on this unit.

ö Cannot set up display.

Í The demonstration mode is not turned oﬀ as

mentioned in <Demonstration mode setting> (page

28).

ö Cannot set up the subwoofer. ö Cannot set up the low pass lter. ö No output from the subwoofer.

Í “SUBWOOFER SET” is not set to ON as mentioned in

<Audio control> (page 11).

ö Cannot set up the subwoofer phase.

Í “LPF SUBWOOFER” is set to “THROUGH” as mentioned

in <Audio control> (page 11).

Operation/wiring error

What might seem to be a malfunction in your unit may just be the result of a slight operation error or a wiring error. Before calling for service, rst check the following table for possible problems.

General

ö The key beep does not sound

Í The Preout jack is in use.

ò The key beep cannot be output from the Preout

jack.

ö Sound cannot be heard.

Í Adjust the volume to the optimum level. Í Check the cords and connections.

Tuner source

ö Radio reception is poor.

Í The car antenna is not extended.

ò Pull the antenna out all the way.

Disc source

ö The specied disc does not play, but another one

plays instead.

Í The speciﬁed CD is quite dirty.

ò Clean the CD with reference to <Handling discs>

(page 22).

Í The disc is severely scratched.

ò Try another disc instead.

ö Disc cannot be ejected.

Í The unit is malfunctioning for some reason.

ò Press and hold [G] to forcibly eject the disc. Be

careful not to drop the disc when it is ejected. If this does not solve the problem, reset the unit.

Audio le source

ö The sound skips when an Audio le is being played.

Í The media is scratched or dirty.

ò Clean the CD with reference to <Handling discs>

(page 22).

Í The recording condition is bad.

ò Play the media again or use another media.

Bluetooth source

ö The hands-free talk volume is low.

Í The hands-free talk volume can be adjusted

independently.

ò Adjust it during hands-free talk. “MIC GAIN” of

<Bluetooth detail setting> (page 37).

ö No beep is heard at reception of an incoming call.

Í No beep is heard depending on the type of your cell-

phone.

ò The “CALL BEEP” of <Bluetooth detail setting>

(page 37) is set ON.

ö Voice is not recognized.

Í The vehicle window is open. If the surrounding noise

is large, voice cannot be recognized properly.

ò Close the vehicle windows to reduce noise.

Í Small voice. If voice is too small, it cannot be

recognized properly.

ò Speak into the microphone a little more loudly

and naturally.

ö The sound from the Bluetooth audio player is

discontinuous.

Í Another Bluetooth device is aﬀecting the Bluetooth

communication. Turn oﬀ another Bluetooth device. Move another Bluetooth device away from this unit.

Í Another Bluetooth device or proﬁle is used for

communication. The downloading of the Phone book disconnects the sound.

DPX-U5130BT/ DPX-U5130

Error messages

The messages shown below indicates your system condition.

ö “PROTECT” (blink)

Í The speaker wire has short-circuited or touched

the chassis of the vehicle, and then the protection function has been activated.

ò Lay or insulate the speaker cable properly and

press the Reset button. If “PROTEC T” does not disappear, consult your nearest service center.

Disc/ USB/ iPod Messages

ö “COPY PRO”

Í A copy-protected ﬁle is played.

ö “iPod ERROR”

Í Connection to the iPod has failed.

ò Remove the iPod/ iPhone and then reconnect it. ò Reset iPod/ iPhone.

ö “NA DEVICE”

Í An unsupported USB device is connected.

ò Check that the connected USB device is

supported. See <About the USB device> (page

22).

Í Connection to the iPod has failed.

ò Check that the connected iPod is supported. See

<Models of iPods/iPhones that can be connected to this unit> (page 12) for information on supported iPods.

ö “NA FILE”

Í An Audio ﬁle is played in a format that is not

supported by this unit.

ö “NO DEVICE”

Í A USB device is selected as a source although no USB

device is connected.

ò Change the source to any source other than the

USB device. Connect an USB device, and change the source to the USB device again.

ö “NO MUSIC”

Í The connected USB device contains no playable

audio ﬁle.

Í A medium that does not have playable data has been

played.

ö “PLEASE EJECT”

Í The unit is malfunctioning for some reason.

ò Press and hold [G]. ò Press the reset button on the unit. If the “PLEASE

EJECT” code does not disappear, consult your nearest service center.

ö “READ ERROR”

Í The ﬁle system of the connected USB device is

broken.

ò Copy the ﬁles and folders for the USB device

again. If “Read Error” is still displayed, initialize the USB device or use another USB device.

ö “TOC ERROR”

Í The CD is quite dirty. The CD is upside-down. The CD

is scratched a lot.

Í The disc is unreadable.

ö “USB ERROR”

Í Some trouble may have occurred to the connected

USB device.

ò Remove the USB device, then cycle the power

switch to ON. If the same display is repeated, use another USB device.

Bluetooth Messages

ö “AUD DISCONCT”

Í The unit cannot communicate with the Bluetooth

audio player.

ö “DEVICE FULL”

Í 5 Bluetooth device have already been registered. No

more Bluetooth devices are registered.

ö “HF DISCONCT”

Í The unit cannot communicate with the cell-phone.

ö “HF ERROR 68”

Í The unit cannot communicate with the cell-phone.

ò Cycle the power switch. If this message still

appears, press the Reset button on the control unit.

ö “HF ERROR 89”

Í Update of the ﬁrmware has failed.

ò Retry update of the ﬁrmware.

ö “NO DATA”

Í There is no outgoing call list. Í There is no incoming call list. Í There is no missed call list. Í There is no phone book list. Í Data is not contained in the phone book.

ö “NO ENTRY”

Í The cell-phone has not been registered (pairing).

ö “NO ACTIVE DVC”

Í No cell-phone is connected.

ö “NO NUMBER”

Í The calling party does not notify a caller ID. Í There is no phone number data.

ö “NO SUPPORT”

Í Your cell-phone does not support the voice

recognition function.

ö “N/A VOICE TAG”

Í Your cell-phone cannot start voice recognition.

ö “PAIRING NG”

Í Pairing error.

English

Troubleshooting guide

Pandora Messages

ö “ADD ERROR”

Í Registration of the station has failed.

ö “CHECK DEVICE”

Í Any device ready for Pandora internet radio

reception is not connected to this unit.

Í Pandora application has not started, you have not

signed in, or system maintenance is in progress.

ö “CONNECT ERROR”

Í Communication is unstable.

ö “LICENSE ERROR”

Í The Pandora® internet radio is accessed from a

country to which it is not delivered.

ö “NO CONTENT”

Í There is no receivable content.

ö “NO SKIPS”

Í No more skips are allowed now.

Retry after a while.

ö “NO STATIONS”

Í There is no receivable station.

ö “NOT EXIST”

Í The registered station has been deleted or the device

is not the registered one.

ö “RATING ERROR”

Í Registration of Thumbs Up/Down has failed.

ö “SEARCH ERROR”

Í No station could be searched for.

ö “STATION LIMT”

Í The number of registered stations has reached the

upper limit.

ò Retry after deleting an unnecessary station.

ö “UPGRADE APP”

Í The Pandora application is an older version which

the unit can not support. Conﬁrm that the Pandora application is the latest version.

Aha Messages

ö “ACTN DISABLED”

Í You performed an unavailable operation.

ö “AHA APP UPDATE REQUIRED”

Í Upgrade the aha application to the latest version.

ö “AHA UNAVAILABLE”

Í Your smartphone cannot be connected to Aha Radio

server.

ö “CHECK APP”

Í Log in to aha.

ö “CHECK DEVICE”

Í Aha application has not started, you have not signed

in, or system maintenance is in progress.

ö “CONNECT PHONE”

Í Connect the cell-phone.

ö “LOGIN FAILED”

Í Logging in to aha has failed.

ö “NETWORK UNAVAILABLE”

Í The network has been disconnected.

ö “NO CONTENT”

Í There is no receivable content.

ö “POOR GPS”

Í The GPS reception condition of your smartphone is

poor.

DPX-U5130BT/ DPX-U5130

Accessories/ Installation Procedure

Installation accessories

..........1

..........6

..........2

6 (DPX-U5130BT only)

3 m .....1

Installation Procedure

 To prevent a short circuit, remove the key from the

ignition and disconnect the - battery.

 Make the proper input and output wire

connections for each unit.

 Connect the speaker wires of the wiring harness.  Connect the wiring harness wires in the following

order: ground, battery, ignition.

 Connect the wiring harness connector to the unit.  Install the unit in your car.  Reconnect the - battery.  Press the reset button.

# WARNING

• If you connect the ignition wire (red) and the battery wire (yellow) to the car chassis (ground), you may cause a short circuit, that in turn may start a fire. Always connect those wires to the power source running through the fuse box.

CAUTION

• Mounting and wiring this product requires skills and experience. For safety’s sake, leave the mounting and wiring work to professionals.

• Make sure to ground the unit to a negative 12V DC power supply.

• Do not install the unit in a spot exposed to direct sunlight or excessive heat or humidity. Also avoid places with too much dust or the possibility of water splashing.

• Do not use your own screws. Use only the supplied screws. Using wrong screws, could damage the unit.

• If the power is not turned ON (“PROTECT” appears), the speaker wire may have a short-circuit or touched the chassis of the vehicle and the protection function may have been activated. Therefore, the speaker wire should be checked.

• If your car’s ignition key switch does not have an ACC position, connect the ignition wires to a power source that can be turned on and off with the ignition key. If you connect the ignition wires to a constant-voltage power source, as with battery wires, the battery may die.

• If the console has a lid, make sure to install the unit so that the faceplate will not hit the lid when it is closed or opened.

• If the fuse blows, first make sure the wires are not touching other parts to cause a short circuit, and then replace the old fuse with one with a new the same rating.

• Insulate unconnected wires with vinyl tape or other similar materials. To prevent a short circuit, do not remove the caps on the ends of the unconnected wires and terminals.

• Connect the speaker wires correctly to the corresponding terminals. The unit may be damaged or fail to work if you share the - wires or ground them to any metal part in the car.

• When connecting only two speakers, connect the connectors either to both of the front output terminals or to both of the rear output terminals (do not mix front and rear terminals). For example, if you connect the + connector of the left speaker to a front output terminal, do not connect the - connector to a rear output terminal.

• After the installing the unit, check whether the brake lamps, blinkers, wipers, etc. on the car are working properly.

• Mount the unit so that the mounting angle is 30° or less.

• Reception may become poor if there are metal objects near

the Bluetooth antenna. (DPX-U5130BT only)

Bluetooth antenna unit

For Good Reception

To assure good reception, note the following:

• Communicate with the cell-phone within the lineof-sight distance of 10 m (30 ft). The communication range becomes shorter depending on the surrounding environment. The communication range also becomes shorter when there is an obstacle between this unit and the cell-phone. The above maximum communication range (10 m) is not always assured.

• A broadcast station or walkie-talkie located nearby can interfere with communication due to a too strong signal.

English

Connecting Wires to Terminals

Microphone input (DPX-U5130BT only)

Microphone (Accessory6)

Ignition key switch

To front left speaker

To front right speaker

To rear left speaker

To rear right speaker

Car fuse box

ACC

Antenna Cord

FM/AM antenna input

White

White/Black

Gray

Gray/Black

Green

Green/Black

Purple

Purple/Black

Red (Ignition wire)

Car fuse box

(Main fuse)

Battery

DPX-U5130BT/ DPX-U5130

Yellow (Battery wire)

Black (Ground wire) · (To car chassis)

–

Fuse (10A)

Wiring harness (Accessory 1)

Blue/White (Power control wire)

Rear output (DPX-U5130BT only)

Front output

Sub Woofer output (DPX-U5130BT only) Rear output/ Sub Woofer output (DPX-U5130 only)

If no connections are made, do not let the wire come out from the tab.

When using the optional power ampliﬁer, connect

P.CONT

to its power control terminal.

Blue (Antenna control wire)

Brown (Mute control wire)

Orange/ White (Dimmer control wire)

Light Blue/ Yellow (Steering remote control wire)

ANT. CONT

MUTE

ILLUMI

REMOTE CONT

STEERING WHEEL REMOTE INPUT

Depending on what antenna you are using, connect either to the control terminal of the motor antenna, or to the power terminal for the booster ampliﬁer of the ﬁlm-type or short pole type antenna. (Max 300mA, 12V DC)

Connect to the terminal that is grounded when either the telephone rings or during conversation.

To connect the Kenwood navigation system,

⁄

consult your navigation manual.

To car light control switch

To use the steering wheel remote control feature, an exclusive remote adapter (not supplied) that matches your car is required.

English

Installation

Install onto the car bracket using the supplied screws (M5 × 8 mm). The holes of the car bracket to use will diﬀer depending on the car model.

Accessory 3 (M5 × 8 mm) or Accessory 4 (M5 × 8 mm)

Installing Toyota Cars

Install onto the car bracket using the supplied screws (Accessory 4). Use the mounting holes (¦ in the illustration shown below) that ﬁt the car bracket.

Car Bracket

Installing Nissan Cars that uses accessory 3

Install onto the car bracket using the supplied screws (Accessory 3). Use the mounting holes (¦ in the illustration shown below) that ﬁt the car bracket.

Accessory 3 (M5 × 8 mm)

Accessory 5 (Only for NISSAN car)

For the car bracket that uses accessory 3, use accessory 5.

Car Bracket

Accessory 4 (M5 × 8 mm)

Accessory 2 (Only for TOYOTA car)

DPX-U5130BT/ DPX-U5130

Car Bracket

DPX-U5130BT only

Installation the Microphone Unit

 Check the installation position of the microphone

(accessory 6).

 Remove oil and other dirt from the installation surface.  Install the microphone.  Lay the cable up to the unit with it secured at several

positions using tape or the like.

⁄

• Install the microphone as far as possible from the cellphone.

Accessory 6

Fix a cable with a commercial item of tape.

Peel off the release coated paper of double-face adhesive tape to secure the microphone on the place shown above.

Adjust the direction of the microphone to the driver.

English

Kenwood DPX-U5130, DPX-U5130BT User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
