JVC RX-5062S Instruction Manual
AUDIO/VIDEO CONTROL RECEIVER
RX-5062S
English
TA/NEWS/INFO
INSTRUCTIONS
DISPLAY MODE
LVT1507-012A
[US]
Warnings, Cautions, and Others /
Caution––STANDBY/ON button!
Disconnect the mains plug to shut the power off completely (the
STANDBY lamp goes off). When installing the apparatus, ensure
that the plug is easily accessible.
The STANDBY/ON button in any position does not disconnect
the mains line.
• When the unit is on standby, the STANDBY lamp lights red.
• When the unit is turned on, the STANDBY lamp goes off.
The power can be remote controlled.
CAUTION
To reduce the risk of electrical shocks, fire, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose this appliance to rain or moisture.
CAUTION
• Do not block the ventilation openings or holes.
(If the ventilation openings or holes are blocked by a
newspaper or cloth, etc., the heat may not be able to
get out.)
• Do not place any naked flame sources, such as
lighted candles, on the apparatus.
• When discarding batteries, environmental problems
must be considered and local rules or laws governing
the disposal of these batteries must be followed strictly.
• Do not expose this apparatus to rain, moisture,
dripping or splashing and that no objects filled with
liquids, such as vases, shall be placed on the
apparatus.
Caution: Proper Ventilation
To avoid risk of electric shock and fire and to protect from damage.
Locate the apparatus as follows:
Front: No obstructions open spacing.
Sides: No obstructions in 10 cm from the sides.
Top: No obstructions in 10 cm from the top.
Back: No obstructions in 15 cm from the back.
Bottom: No obstructions, place on the level surface.
In addition, maintain the best possible air circulation as illustrated.
Spacing 15 cm or more
Wall or obstructions
RX-5062S
Front
Stand height 15 cm or more
Floor
G-1
[European Union only]
Table of Contents
Remote
NOT
Parts Identification ...................................... 2
Getting Started ........................................... 4
Before Installation ...................................................................... 4
Checking the Supplied Accessories ........................................... 4
Putting Batteries in the Remote Control .................................... 4
Adjusting the Voltage Selector ................................................... 4
Connecting the FM and AM Antennas ....................................... 4
Connecting the Speakers and Subwoofer ................................... 5
Connecting Audio/Video Components ....................................... 6
7 Analog Connections ............................................................... 6
7 Digital Connections ................................................................ 8
Connecting the Power Cord ....................................................... 8
Basic Operations ......................................... 9
Daily Operational Procedure ...................................................... 9
Turning On the Power ................................................................ 9
Selecting the Source to Play ....................................................... 9
Adjusting the Volume ............................................................... 10
Turning On and Off the Subwoofer Sound .............................. 11
Selecting the Analog or Digital Input Mode ............................ 11
Changing the Display Brightness ............................................. 12
Attenuating the Input Signal .................................................... 12
Changing the Source Name ...................................................... 12
Muting the Sound ..................................................................... 13
Using the Sleep Timer .............................................................. 13
Adjusting Sound ........................................ 21
Basic Adjustment Items ............................................................ 21
Basic Procedure ........................................................................ 21
7 Adjusting the Equalization Patterns ..................................... 22
7 Adjusting the Speaker Output Levels ................................... 22
7 Adjusting the Sound Parameters for the Surround
and DSP Modes .................................................................... 22
Using the Surround Modes ..........................
Reproducing Theater Ambience ................................................ 23
Introducing the Surround Modes ............................................. 23
Activating the Surround Modes ............................................... 25
7 Auto Surround Function ....................................................... 25
7 Activating the Surround Modes Manually ........................... 25
23
Using the DSP Modes ................................ 26
Reproducing the Sound Field ................................................... 26
Introducing the DSP Modes ..................................................... 26
Activating the DSP Modes ....................................................... 27
Operating JVC’s Audio/Video Components ... 28
Operating Audio Components .................................................. 28
Operating Video Components .................................................. 29
Troubleshooting ......................................... 30
English
Receiving Radio Broadcasts ........................ 14
Setting the AM Tuner Interval Spacing .................................... 14
Tuning in to Stations Manually ................................................ 14
Using Preset Tuning ................................................................. 14
Selecting the FM Reception Mode ........................................... 15
Basic Settings ........................................... 16
Quick Speaker Setup ................................................................ 16
Basic Setting Items ................................................................... 17
Basic Procedure ........................................................................ 17
7 Setting the Speakers ............................................................. 18
7 Setting the Speaker Distance ................................................ 18
7 Setting the Bass Sounds ....................................................... 18
7 Selecting the Main or Sub Channel ...................................... 19
7 Setting for Effective Surround Operations ........................... 20
7 Setting the Digital Input Terminals ...................................... 20
Specifications............................................ 31
This mark indicates that ONLY the remote control
CAN be used for the operation explained.
This mark indicates that the remote control
CANNOT be used for the operation explained.
Use the buttons and controls on the front panel.
1
Parts Identification
STANDBY
STANDBY/ON
PHONES
SURROUND
DSP
SPEAKERS
ON/OFF
SUBWOOFER OUT FM MODE MEMORY
ON/OFF
FM/AM TUNING
SURROUND/DSP
OFF
DIMMER
MASTER VOLUME
INPUT DIGITAL
RX—6030V
AUDIO/VIDEO CONTROL RECEIVER
SETTING
MULTI JOG
PUSH SET
QUICK SPEAKER
SETUP
ADJUST
EXIT
INPUT ANALOG
INPUT ATT
FM/AM PRESET
DVD VCR CD AMTV SOUND TAPE/CDR
SOURCE NAME
AUX FM
3D - PHONIC
DUAL
MONO
H.PHONESBDSP
DIGITAL EQ
INPUT ATT
VOLUME
PRO LOGIC
VIRTUAL SB
TUNED
STEREO
AUTO MUTING
SLEEP
96/24
1
2
3
4
5
w
r
t
i
o
;a
d
f
ye
u
6
7 8 9 p
q
s
3D - PHONIC
DUAL
MONO
H.PHONE
SB
DSP
DIGITAL EQ
INPUT ATT
VOLUME
PRO LOGIC
VIRTUAL SB
TUNED
STEREO
AUTO MUTING
SLEEP
96/24
-
$%
!
@
1324567890=~
#
English
See pages in parentheses for details.
1 STANDBY/ON
2 SURROUND/DSP OFF button (25, 27)
3 DSP button (26 – 28)
4 SURROUND button (25)
5 Remote sensor
6 Display (For details, see “Display” below.)
7 Source selection buttons (9, 12)
AUX, DVD, VCR, TV SOUND, CD, TAPE/CDR (SOURCE
NAME), FM, AM
8 INPUT ANALOG button (12)
INPUT ATT button (12)
9 INPUT DIGITAL button (11)
p DIMMER button (12)
button and STANDBY lamp (9, 14)
Front Panel
q MASTER VOLUME control (10)
w PHONES jack (11)
e AUX input jacks (7)
r SPEAKERS ON/OFF button (11)
t SUBWOOFER OUT ON/OFF button (11)
y FM/AM TUNING 5/∞ buttons (14)
u FM/AM PRESET 5/∞ buttons (14)
i FM MODE button (15)
o MEMORY button (14)
; SETTING button (17)
a QUICK SPEAKER SETUP button (16)
s MULTI JOG (PUSH SET) dial (16, 17, 21)
d EXIT button (17, 21)
f ADJUST button (21)
Display
See pages in parentheses for details.
1 ANALOG indicator (12)
2 DUAL MONO indicator (24)
3 H.PHONE indicator (11, 24, 26)
4 3D-PHONIC indicator (24, 26, 27)
5 VIRTUAL SB indicator (20)
PRO LOGIC II indicator (23, 25, 26)
6
7 DSP indicator (24, 26, 27)
8 DIGITAL EQ indicator (22)
9 TUNED indicator (14)
2
0 STEREO indicator (14)
- INPUT ATT indicator (12)
= AUTO MUTING indicator (15)
~ SLEEP indicator (13)
! VOLUME indicator (9, 10)
@ Digital signal format indicators (11)
# Speaker indicators and signal indicators (10)
$ CH– indicator (14)
% Main display
Remote Control
AUDIO
TV
VCR
DVD
TEST
EFFECT
MENU
ENTER LEVEL
RETURN
SURROUND/
DSP
CD-DISC
SLEEP
REC PAUSE
FM MODE
SURROUND
DSP
DIMMER TV/VIDEO MUTING
OFF
VCR CH
TV CH
VOLUME
SURR R
SURR L
SUBWFR
CENTER
FRONT R
FRONT L
100
1
4
7/P
10
2
5
8
0
3
6
9
10
TV VOLUME
STANDBY/ON
A/V CONTROL
RECEIVER
TAPE/CDR CD DVD AUX
FM/AM TV SOUND VCR
ANALOG/
DIGITAL
REW FF
1
4
-
#
$
@
!
%
3
7
6
9
0
&
^
5
8
=
2
~
CD
IN
OUT
(REC)
IN
(PLAY)
OUT
(REC)
VCR
TV SOUND
IN
CENTER
SPEAKER
SURROUND
SPEAKERS
RIGHT LEFT
FRONT
SPEAKERS
RIGHT LEFT
AUDIO
RIGHT LEFT
IN
(PLAY)
TAPE
/CDR
DIGITAL 1(DVD)
DIGITAL 2(CD)
DIGITAL IN
SUBWOOFER
OUT
AUDIO
MONITOR
OUT
DVD
IN
OUT
(REC)
VCR
IN
(PLAY)
DVD
IN
RIGHT LEFT
AM
LOOP
AM EXT
ANTENNA
816–
VOLTAGE SELECTOR
220V
230V - 240V
127V
110V
CAUTION:SPEAKER IMPEDANCE
1 5
96 78
2 43
See pages in parentheses for details.
1 Number buttons for selecting preset channels (15, 28)
Number buttons for sound adjustment (22, 28)
Number buttons for operating audio/video components (28, 29)
2 SOUND button (22, 28)
3 REC PAUSE button (29)
4 Source selection buttons (9, 10)
TAPE/CDR, CD, DVD, AUX, FM/AM, TV SOUND, VCR
5 FM MODE button (15, 28)
6 SURROUND button (25, 28)
7 DIMMER button (12, 28)
8 TV/VIDEO button (29)
9 VCR CH +/– buttons (29)
0 TV CH +/– buttons (29)
- STANDBY/ON
buttons (9, 28, 29)
AUDIO, TV, VCR, DVD
= SLEEP button (13, 28)
~ Operating buttons for audio/video components
3, 8, 7, ¢/4, FF/REW (28, 29)
! CD-DISC button (29)
@ ANALOG/DIGITAL button (11, 12, 28)
# SURROUND/DSP OFF button (25, 27, 28)
$ DSP button (26 – 28)
% MUTING button (13, 28)
^ VOLUME +/– button (10, 28)
& TV VOLUME +/– buttons (29)
English
Note:
When you press the one of the audio source selection buttons—
TAPE/CDR, CD, and FM/AM—on the remote control, the receiver
automatically turns on.
Rear Panel
See pages in parentheses for details.
1 DIGITAL IN terminals (8)
• Coaxial: DIGITAL 1 (DVD)
• Optical: DIGITAL 2 (CD)
2 AUDIO input/output jacks (6, 7)
• Input: CD IN, TAPE/CDR IN (PLAY), VCR IN (PLAY),
• Output: TAPE/CDR OUT (REC), VCR OUT (REC),
TV SOUND IN, DVD IN
SUBWOOFER OUT
3 VIDEO input/output jacks (7)
• Input: DVD IN, VCR IN (PLAY)
• Output: MONITOR OUT, VCR OUT (REC)
4 ANTENNA terminals (4, 5)
5 VOLTAGE SELECTOR switch (4)
6 CENTER SPEAKER terminals (5)
7 SURROUND SPEAKERS terminals (5)
8 FRONT SPEAKERS terminals (5)
9 AC power cord (8)
3
AM
LOOP
AM EXT
ANTENNA
AM
LOOP
AM EXT
ANTENNA
AM
LOOP
AM EXT
ANTENNA
Do not connect the AC power cord until all other connections
VOLTAGE SELECTOR
220V
230V - 240V
127V
110V
have been made.
Getting Started
This section explains how to connect audio/video components and speakers to the receiver, and how to connect the
power supply.
English
Before Installation
Adjusting the Voltage Selector
General Precautions
• Be sure your hands are dry.
•Turn the power off to all components.
• Read the manuals supplied with the components you are going to connect.
Locations
• Install the receiver in a location that is level and protected from
moisture and dust.
•The temperature around the receiver must be between –5˚C and 35˚C.
• Make sure there is good ventilation around the receiver. Poor
ventilation could cause overheating and damage the receiver.
Handling the receiver
• Do not insert any metal object into the receiver.
• Do not disassemble the receiver or remove screws, covers, or cabinet.
• Do not expose the receiver to rain or moisture.
Checking the Supplied Accessories
Check to be sure you have all of the following items, which are
supplied with the receiver.
The number in the parentheses indicates quantity of the pieces supplied.
• Remote Control (1)
• Batteries (2)
• AM Loop Antenna (1)
• FM Antenna (1)
•AC Plug Adaptor (1)
If anything is missing, contact your dealer immediately.
Before connections, always do the following first if necessary.
Select the correct voltage with the VOLTAGE SELECTOR switch
on the rear using a screw driver.
Check to be sure if the voltage mark is set to the voltage for the area
where you use this unit.
Voltage mark
Connecting the FM and AM Antennas
FM antenna connections
Putting Batteries in the Remote Control
Before using the remote control, insert the two supplied batteries first.
1
2
R6(SUM-3)/
AA(15F)
3
1Press and slide the battery cover on the back of
the remote control.
2 Insert the batteries.
• Make sure to match the polarity: (+) to (+) and (–) to (–).
3Replace the cover.
If the remote control cannot transmit signals or operate the receiver
correctly, replace the batteries. Use two R6(SUM-3)/AA(15F) type
dry-cell batteries.
Note:
Supplied batteries are for the initial setup. Replace for continued use.
CAUTION:
Follow these precautions to avoid leaking or cracking cells:
• Place batteries in the remote control so they match the
polarity: (+) to (+) and (–) to (–).
• Use the correct type of batteries. Batteries that look similar
may differ in voltage.
• Always replace both batteries at the same time.
• Do not expose batteries to heat or flame.
4
A
Extend the supplied FM antenna
horizontally.
Connect the supplied FM antenna as temporary measure to the
FM 75 Ω COAXIAL terminal—A
If reception is poor, connect the outdoor FM antenna (not
supplied)—B
1 Disconnect the supplied FM antenna.
2 Connect a 75 Ω coaxial cable (with the standard type connector).
(IEC or DIN45325).
B
FM Antenna
(supplied)
Outdoor FM Antenna Cable
(not supplied)
AM
LOOP
AM EXT
ANTENNA
CENTER
SPEAKER
SURROUND
SPEAKERS
RIGHT
LEFT
FRONT
SPEAKERS
RIGHT
LEFT
CAUTION:SPEAKER IMPEDANCE
+
–
+
–
To center speaker
To right front speaker
To right surround speaker
To left surround
speaker
To left
front speaker
RIGHT
LEFT
+
–
RIGHT
LEFT
+
–
RIGHT
LEFT
+
–
Do not connect the AC power cord until all other connections
have been made.
AM antenna connections
1
Outdoor single vinyl-covered wire (not supplied)
AM Loop Antenna
(supplied)
Snap the tabs on the loop into
the slots of the base to
assemble the AM loop
antenna.
2
Connecting the Speakers and Subwoofer
You can connect five speakers (a pair of front speakers, a center
speaker, and a pair of surround speakers) and a subwoofer.
CAUTIONS:
• Use only the speakers of the SPEAKER IMPEDANCE
indicated by the speaker terminals.
• Do not connect more than one speaker to each speaker
terminal.
Connecting the speakers
1
2
3
4
1Twist and remove the insulation at the end of
each speaker cord.
2Press and hold the clamp of the speaker terminal.
3 Insert the speaker cord.
4 Release the finger from the clamp.
English
Turn the loop until you have the best reception.
Notes:
• If the AM loop antenna wire is covered with vinyl,
remove the vinyl by twisting it as illustrated.
• Make sure the antenna conductors do not touch any
other terminals, connecting cords and power cord.
This could cause poor reception.
• If reception is poor, connect an outdoor single vinyl-covered wire
(not supplied) to the AM EXT terminal. (Keep the AM loop antenna
connected.)
For each speaker (except for a subwoofer), connect the (+) and
(–) terminals on the rear panel to the (+) and (–) terminals
marked on the speakers.
5
SUBWOOFER
OUT
OUT
(REC)
IN
(PLAY)
TAPE
/CDR
L
R
R
L
CD
IN
R
L
Getting Started
45 – 60
Do not connect the AC power cord until all other connections
have been made.
Connecting the subwoofer
English
You can enhance the bass by connecting a subwoofer.
Connect the input jack of a powered subwoofer to the rear panel,
using a cable with RCA pin plugs (not supplied).
Powered subwoofer
Placing speakers
Front speakers (L/R) and center speaker (C)
• Place these speakers at the same height from the floor, at or near
ear level.
•Array across the front of the viewing area.
Surround speakers (LS/RS)
• Place these speakers alongside and slightly to the rear of (but not
behind) the listening position; well above ear level (60 cm to
90 cm higher).
•Point these speakers directly across the listening area, but not at
the listener’s ears.
Subwoofer (S.WFR)
•You can place it wherever you like since bass sound is nondirectional. Normally place it in front of you.
Connecting Audio/Video Components
When connecting individual components, refer also to the manuals
supplied with them.
Analog Connections
Audio component connections
Use the cables with RCA pin plugs (not supplied).
• Connect the white plug to the audio left jack, and the red plug to
the audio right jack.
CAUTION:
If you connect a sound-enhancing device such as a graphic
equalizer between the source components and this receiver,
the sound output through this receiver may be distorted.
CD player
CD player
To audio
output
Cassette deck/CD recorder
L
R
C
S.WFR
LS
RS
After connecting the speakers, set the speaker installation
information properly. You can use Quick Speaker Setup for
it (see page 16).
6
Cassette deck or CD recorder
To audio input
To audio output
Note:
When connecting a CD recorder to the TAPE/CDR jacks, change the
source name to “CDR,” which will be shown on the display when it is
selected as the source. See page 12 for details.
AUDIO
DVD
IN
RIGHT LEFT
A
B
DVD
IN
DVD
R
L
MONITOR
OUT
TV SOUND
IN
AUDIO
RIGHT LEFT
A
B
R
L
OUT
(REC)
VCR
IN
(PLAY)
OUT
(REC)
VCR
IN
(PLAY)
R
L
R
L
A B DC
Do not connect the AC power cord until all other connections
R
L
A
B
have been made.
Video component connections
Use the cables with RCA pin plugs (not supplied).
Connect the white plug to the audio left jack, the red plug to the
audio right jack, and the yellow plug to the video jack.
VCR
DVD player
English
DVD player
Å To composite video output
ı To left/right front channel audio output (or to audio-mixed
VCR
output if necessary)
Å To audio input
ı To audio output
Ç To composite video input
Î To composite video output
Note:
To enjoy Dolby Digital and DTS multi-channel software (including Dual
Mono software), connect the DVD player through the digital input/
output terminals.
TV
Video camera, etc.
The AUX input jacks on the front panel are convenient when
connecting and disconnecting the component frequently.
Connect the TV to appropriate MONITOR OUT jacks to view
the playback picture from any other connected video
components.
Å To audio output
ı To composite video input
TV
Video camera, etc.
Å To audio output
ı To composite video output
7
DIGITAL 1(DVD)
DIGITAL 2(CD)
DIGITAL IN
Getting Started
Do not connect the AC power cord until all other connections
have been made.
Digital Connections
English
By connecting the receiver and the source component through the
digital terminals, sound reproduction quality will be much improved.
In addition, you can enjoy multi-channel reproduction and some
other convenient functions.
IMPORTANT:
• When connecting a video component using the digital
terminals, you also need to connect it to the video jacks on
the rear. Without connecting it to the video jacks, you can
view no playback picture.
• After connecting the components using the DIGITAL IN
terminals, set the following correctly if necessary.
– Set the digital input (DIGITAL IN) terminal setting correctly.
For details, see “Setting the Digital Input Terminals” on
page 20.
– Select the digital input mode correctly. For details, see
“Selecting the Analog or Digital Input Mode” on page 11.
Digital input terminals
You can connect any digital components having coaxial or optical
digital output terminal.
Digital coaxial cable (not supplied)
between digital coaxial terminals
Connecting the Power Cord
Before plugging the receiver into an AC outlet, make sure that all
connections have been made.
Plug the power cord into an AC outlet.
•Keep the power cord away from the connecting cables and the
antenna. The power cord may cause noise or screen interference.
Notes:
• The preset settings such as preset channels and sound adjustment
may be erased in a few days in the following cases:
– When you unplug the power cord.
– When a power failure occurs.
• If the wall outlet does not match the AC plug, use the supplied AC
plug adaptor.
CAUTIONS:
• Do not plug in before setting the VOLTAGE SELECTOR
switch on the rear of the unit and all connection procedures
are complete.
• Do not touch the power cord with wet hands.
• Do not pull on the power cord to unplug the cord. When
unplugging the cord, always grasp the plug so as not to
damage the cord.
Digital optical cable (not supplied)
between digital optical terminals
When the component has a digital
coaxial output terminal, connect it to
the DIGITAL 1 (DVD) terminal, using a
digital coaxial cable (not supplied).
When the component has a digital
optical output terminal, connect it to the
DIGITAL 2 (CD) terminal, using a digital
optical cable (not supplied).
Before connecting a digital
optical cable, unplug the
protective plug.
Note:
When shipped from the factory, the DIGITAL IN terminals have been
set for use with the following components:
– DIGITAL 1 (coaxial): For DVD player
– DIGITAL 2 (optical): For CD player
8
Basic Operations
VOLUME
DVD VCR CD AMTV SOUND TAPE/CDR
SOURCE NAME
AUX FM
TAPE/CDR CD DVD
FM/AM TV SOUND VCR
AUX
VOLUME
The following operations are commonly used when you play any sound sources.
Operations hereafter will be explained using the buttons on the front panel.
You can also use the buttons on the remote control for the same functions if they have the same and similar names/marks.
Daily Operational Procedure
Selecting the Source to Play
When you have connected digital source components using the
digital terminals, first change the input mode for these components
to the digital input mode (see page 11).
1 Tu rn on the power.
• See “Turning On the Power” below.
Press one of the source selection buttons.
2 Select the source.
• See “Selecting the Source to Play” to the right.
Selected source name appears.
3 Adjust the volume.
• See “Adjusting the Volume” on page 10.
4 Select the Surround or DSP modes.
• See “Activating the Surround Modes” (page 25) and
“Activating the DSP Modes” (page 27).
English
Turning On the Power
Press STANDBY/ON (or STANDBY/ON AUDIO on
the remote control).
The STANDBY lamp goes off.
Current source name appears.
Current volume level appears.
To turn off the power (into standby mode),
press STANDBY/ON (or STANDBY/ON AUDIO on the
remote control) again.
The STANDBY lamp lights up.
On the front panel
On the remote control
Notes:
• When connecting a CD recorder to the TAPE/CDR jacks, change
the source name shown on the display. For details, see page 12.
• By pressing the one of the audio source selection buttons—TAPE/
CDR, CD, and FM/AM—on the remote control, you can turn on the
receiver and select the audio source.
Note:
A small amount of power is consumed in standby mode. To turn off
the power completely, unplug the AC power cord.
9
Loading...
