Hp LASERJET 3200 Parameter Settings

HP LaserJet 3200 Product - Parameter Settings

Introduction

프린터의 파라미터 값들을 변경하기 위해서 * 키와 # 키를 동시에 누른 후 ENTER키를 눌러 Developer’s 메뉴로 들어간다. 프린터의 디스플레이 창에 “Developer’s menu/r/w parameter 라는 메시지가 나타나면 ENTER키를 눌러 이 메뉴안으로 이동한다. 프린터에 설치된 펌웨어의 버전에 따라 디스플레이창 맨아래 줄에 “LIU ID”또는 “param ver code”등이 나타난다. 아래의 테이블을 참조하여 필요한 파라미터를 찾는다. 그리고 변경할 파라미터의 숫자를 입력한다. 디스플레이 창은 입력한 숫자에 따라 파라미터의 이름이 나타난다. Enter 키를 누르면 현재 설정되어있는 값이 나타난다. 이 기능을 취소하기 위해서 파라미터값이 나타났을 때 STOP/CLEAR 키를 누른다. 값을 변경하기 위해서는 ENTER키를 누른다음 숫자키를 사용하여 원하는 값으로 변경한다. 파라미터 값이 재 설정 된다. 그리고 디스플레이 창은 다시 “Ready”로 바뀐다. STOP/CLEAR 키를 눌러 Developer’s 메뉴를 빠져 나온다.

NOTE: 이 문서에서는 미국의 설정값을 기본값으로 하고 있다. 하지만 다른

국가들의 기본값도 함께 언급을 해놓았으므로 정확한 정보를 제공한다.

Parameter settings (fax data store parameters)

팩스 데이터 파라미터들은 각 지역의 통신사와 HP LaserJet3200 제품과의 설정값을 조정한다. 장치의 제어판(Control Panel)의 Developer’s 메뉴를 통하여 파라미터 설정으로 접근할 수 있다. 이 메뉴로 들어가서 다음의 단계를 따른다.(디스플레이창에 “R/W Parameter” 가 나타나 있을 것이다.)

?? 파라미터의 ID 번호를 입력한 후 < 또는 > 버튼을 눌러 특정 파라미터를 찾는다. 현재 설정값이

나타날 것 이다.

?? 새로운 값을 입력하여, 장치에 인식을 시킨다.

CAUTION: 장치는 새로운 설정 값이 올바른 값인지 아닌지 경고 메시지를

사용자에게 알려주지 않는다.

Accessing the Developer's menu

Developer’s 메뉴는 제조, 서비스 또는 개발 엔지니어들을 위해 고안 되었다. 이 메뉴는 지역 통신사의 특성에 맞게 팩스 파라미터를 조정하고 또는 테스트하기 위함이다. 그러므로 한번 이 메뉴를 빠져 나왔을때에는 메뉴가 사라질 것이며 다시 Developer’s 메뉴로 이동하기 위해서 위의 단계를 다시 반복해야 한다.

NOTE: 이 메뉴는 개발을 위해 만들어 졌으며, 각 국가별로 번역되어 있지

않다.

1. 장치가 “Ready”상태인지 확인 한다.

2. ENTER/MENU 키를 눌러 메인 메뉴 시스템으로 들어간다.

3. *키와 # 키를 동시에 누른 후 손을 뗀다.

4. < 또는 > 키를 이용하여 파라미터 변수들을 확인한다.

Control panel messages

팩스 파라미터 값이 많기 때문에 LCD 에 모두 표시 할 수는 없다. 대신 아래의 분리된 테이블에 모든 파라미터 숫자, 이름, 값 그리고 기본설정을 표기해 놓았다.

Description Display

MENU: Data store DEVELOPER'S MENU R/W PARAMETER

SET: Select parameter R/W PARAMETER >[PARAMETER NAME]

SET: Parameter value [PARAMETER NAME] >######

ACK: Parameter setting [PARAMETER NAME] >######

Line interface identification

Parameter Description

1 u16bit parameter version code. The default value is 1. N/A

Units Country

Default

2 LIU ID interface code. This value is set by the firmware.

The value depends upon which LIU is installed in the unit.

N/A U.S.

Euro Rare

6 3 5

3 LIU COUNTRY is the country code that determines

appropriate country specific telecom parameters. This is the country in which the unit is intended to operate.

N/A Argentina

Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

16 23 34 45 15 6 40 46 47 39 49 29 62

44 21 51 4 27 13 35 19 43 56 50 64 30 55 41 36 7 63 31 15

Ring detection and auto answering

Parameter Description

Units

Country

Default

4 Auto answer enable. Modified by the user

through the fax receive setup menu answer mode. If TRUE, the device will automatically answer and attempt to receive a fax after the set number of rings to answer. The default value is true for all countries.

5 Auto answer ring cadences. Determines

the types of rings that are counted. The HP LaserJet 3200 can be set to detect combinations of single, double, or triple rings. This parameter is selected by the user from the fax receive setup menu answer ring pattern. Values of 4 and 5

cannot be set through the user menu and have not been tested.

6 Auto answer ring count. Minimum number

of rings that must be detected before the unit will automatically answer if auto answer enabled is TRUE. Users select the ring count from fax receive setup menu rings to answer.

0 = False 1 = True

0=All rings 1=Single rings 2=Double rings

3=Triple rings 4=Single or double rings 5=Single or triple rings 6=Double or

triple rings

rings U.S.

All countries 0

All other countries

5 2

7 Ring detect low frequency. Minimum valid

frequency for the incoming ring signal.

8 Ring detect high frequency. Maximum valid

frequency for the incoming ring signal.

1 Hz (10 Hz to 99 Hz)

Australia France New Zealand U.K. All other

countries

Australia New Zealand All other

countries

13 23 13 14 15

58 58 68

9 Ring envelope minimum ON time.

Minimum time an entire ring signal must be present to be counted as 1 ring. The entire ring signal may consist of several ring bursts separated by periods of silence.

1 ms (50 ms to 10000 ms)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

150 180 150 150 150 150 150 300 500 250 150 150 150

300 150 150 150 150 150 300 180 150 150 150 250 150 700 300 150 150 250 300 150

10 Ring envelope maximum ON time.

Maximum time an entire ring signal can be present to be counted as 1 ring. The entire ring signal may consist of several ring bursts se parated by periods of silence.

1 ms (50 ms to 10000 ms)

All countries 8000

11 Ring envelope minimum OFF time.

Minimum time between ring envelops, where each ring envelope may consist of a single or multiple rings. Once this time has expired the ring count is incremented.

12 Ring envelope maximum OFF time.

Maximum time between ring envelops after which the ring count is reset to zero. When this period of silence is expired all ringing

is considered complete.

13 Ring burst minimum ON time. Minimum

time a single ring signal must be active before it is counted. If this time is not exceeded, the ring burst is ignored.

14 Ring burst minimum OFF time. Minimum

time that must occur between two- ring bursts if they are to be counted as two individual bursts.

1 ms (200 ms to 20000 ms)

1 ms (50 ms to 1000 ms)

All countries 1000

All countries 8000

Germany Portugal Russia Ukraine All other

countries

Germany New Zealand Portugal Russia Ukraine All other

countries

200 200 200 200 100

200 350 200 200 200 100

15 Minimum number of rings. This is the

minimum ring count the user can enter. This is used for data entry validation only.

1 ring (1 ring to 15 rings)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

1 2 1 2 1 1 1 2 3 2 1 2 1

2 1 1 1 1 1 2 2 2 1 1 2 1 1 2 2 1 2 2 1

16 Maximum number of rings. This is the

maximum ring count that the user can enter. This is used for data entry validation only.

1 ring (1 ring to 15 rings)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

6 6 6 5 9 6 6 7 5 6 6 6 6

6 6 6 6 6 6 7 6 6 6 6 6 6 6 7 6 6 6 6 9

Eavesdrop detection and auto answering

Parameter Description Units Country Default

17 Silent detect enable. Incoming faxes are

detected through the presence of CNG tone or a sufficient period of silence. If TRUE then silent detection is attempted. Selected by the user from the fax receive setup menu, silence detection.

18 Parallel detect enable. If TRUE,

eavesdrop detection is attempted when either a parallel or downstream telephone

(or TAM) answers. If FALSE, detection is attempted only with a downstream device.

19 Eavesdrop evaluation time. Eavesdrop is

automatically started (and restarted) when each ring ends. It is automatically deactivated after this time.

20 CNG tone minimum ON time is the

minimum time a CNG tone must be present for the tone sequence to be valid.

21 CNG tone maximum ON time is the

maximum time a CNG tone can be present for the tone sequence to be valid.

0 = False 1 = True

1 sec (10 sec to 120 sec)

1 ms (100 ms to 1000 ms)

All countries

0

1

60

400

600

22 CNG tone minimum OFF time is the

minimum period of silence that must exist between CNG tones for the tone

sequence to be valid.

23 CNG tone maximum OFF time. Maximum

period of silence that can exist between CNG tones for the tone sequence to be valid.

24 CNG tone maximum dropout time.

Maximum duration of dropout, which can interrupt a CNG tone. If the dropout is less

than this time, the CNG tone will be processed as a single continuous tone.

25 CNG tone minimum count. Minimum

number of CNG tones that must be detected for an incoming fax to be detected.

26 CNG tone detect threshold. Sets the

detection threshold for any received CNG tone. If the CNG tone is below this level it

will not be detected.

1 ms (1000 ms to 15000 ms)

1 ms (0 ms to 500 ms)

1 tone (1 tone to 15 tones)

-0.1 dBm (260 to 500, which is -26.0

to -50.0 dBm)

All countries

France All other

countries

2200

3600

100

2

450 350

27 CNG filter bandwidth. Tone filter

bandwidth used for CNG tone detection.

20 = 20 Hz 40 = 40 Hz 60 = 60 Hz 80 = 80 Hz

All countries

60

28 CNG sidetone frequencies. Indicates the

frequency combination that is used to identify CNG sidetones.

29 CNG sidetone frequency 1. The presence

of sidetones may indicate that the current signal is not a valid CNG signal.

30 CNG sidetone frequency 2. The presence

of sidetones may indicate that the current signal is not a valid CNG signal.

31 CNG sidetone frequency 1 bandwidth.

Tone filter bandwidth used for CNG tone detection.

32 CNG sidetone frequency 2 bandwidth.

Tone filter bandwidth used for CNG tone detection.

33 Silence detect time minimum. An incoming

fax will be detected if this period of silence is detected. Silent detection is only intended to apply to downstream TAMs. Silent detection will only start aft er an OGM has been detected and if downstream activity is detected.

1 = 1 2 = 2 3 = 1 and 2 5 = 1 or 2

1 Hz (300 Hz to 2100 Hz)

20 = 20 Hz 40 = 40 Hz 60 = 60 Hz 80 = 80 Hz

1 ms (1000 ms to 15000 ms)

All countries

3

1000

1300

40

3000

34 Silence detect noise time. Minimum time

noise must be detected for the OGM to be considered present. Once the OGM is detected, silence detected is started.

35 DTMF code first char. First digit of the 3-

digit DTMF start sequence used to start a fax receive session when in manual

receive mode. The DTMF code may be entered from either a parallel or a downstream telephone. This feature is active only when extension phone is enabled.

36 DTMF code second char. Second digit of

the DTMF start sequence used to start a fax receive.

1 ms (1000 ms to 15000 ms)

35 = "#" 42 = "*" 48 = "0" 49 = "1" 50 = "2" 51 = "3" 52 = "4" 53 = "5" 54 = "6" 55 = "7" 56 = "8" 57 = "9"

Units: same as parameter 35

All countries

1000

49

50

37 DTMF code third char. Third digit of the

DTMF start sequence used to start a fax receive.

Connection establishment

Parameter Description Units Country Default

Units: same as parameter 35

All countries

51

38 Off hook delay time. Specifies the

minimum time between the completion of an outgoing or incoming call and the automatic dialing of the next outgoing call.

1 ms (0 ms to 15000 ms)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

5000 5000 5000 5000 5000 5000 5000 7000 6500 7000 5000 5000 5000

3500 5000 5000 5000 5000 5000 7000 5000 7000 5000 5000 7000 5000 5000 7000 5000 5000 7000 3500 5000

39 Pre OFF hook shunt. Defines the time the

LIU shunt will be active. The shunt is activated just as the device goes OFF hook. Not supported by all LIUs.

1 ms (0 ms to 1000 ms)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

0 0 1000 1000 0 0 1000 1000 1000 1000 1000 0 0

1000 0 1000 0 0 0 1000 0 1000 0 1000 0 0 1000 1000 1000 0 0 1000 0

40 Modem loop current test enable. Controls

if a modem loop current test is performed after the LaserJet 3200 has connected to the external line and before automatic dialing is started. If TRUE, the 3200 will test for the presence of loop current after going OFF hook prior to dialing. If loop current is not detected, the fax session is aborted.

0 = False 1 = True

All countries 0

41 Modem loop current detection time

minimum. Minimum time that continuous modem loop current must be present when the machine first connects and a loop current test is performed. Also, this is the minimum time that loop current must be absent once dialing has completed, when performing the loop current failure test.

42 Modem loop current evaluation time.

Maximum time the machine will wait for loop current before dialing when performing a loop current test.

43 Telset loop current test enable. Controls

whether a telset loop current test is performed before the LaserJet 3200 is connected to the external line. The presence of loop current would indicate that a downstream telephone is active. If TRUE, the machine will check for telset

loop cur rent.

44 Telset loop current minimum on time.

Minimum time that continuous telset loop current must be present to be evaluated as present. Once present, the line is considered unavailable.

1 ms (0 ms to 15000 ms)

0 = False 1 = True

1 ms (50 ms to 15000 ms)

All countries 0

All countries 1

All countries 50 mS

45 Telset loop current minimum off time.

46 Obsolete Line type. Determines the type of

Pause control

Parameter Description Units Country Default

Minimum time that continuous telset loop current must be absent to be evaluated as

absent. Once absent, the line is considered available.

telephone line that the HP LaserJet 3200 is connected to. This can either be the public switched telephone network (PSTN) or a private branch exchange (PBX). The different selections cause the device to make different checks for dial tone.

1 ms (50 ms to 15000 ms)

0=PSTN 1=PBX

France All Other

countries

All countries 0

5000

1000

47 PSTN pre dial pause mode. Specifies what

type of pause the LaserJet 3200 will perform before dialing when configured for PSTN operation. If BLIND WAIT, the unit will look for a dial tone and dial immediately if detected, or will dial after the blind dial delay time has elapsed. If CHECK FOR TONE, a PSTN dial tone must be detected before dialing. The value 2 is no longer used.

0 = Blind Wait 1 = Check for

tone 2 = Check for

special tone

France Hungary All other

countries

1 1 0

48 Obsolete

PBX pre dial pause mode. Specifies what type of pause the LaserJet 3200 will perform before dialing when configured for PBX operation. If BLIND WAIT, the device

will delay PBX WAIT BEFORE BLIND DIALING before dialing. If CHECK FOR TONE, it will attempt to detect a PSTN dial tone. If CHECK FOR SPECIAL TONE, it will attempt to detect a special tone. The default value is 0 for all countries. The

value 2 is no longer used.

0 = Blind Wait 1 = Check for

tone 2 = Check for

special tone

49 PSTN blind dial wait time. Delay from OFF

hook to the start of dialing when blind dialing, no dial tone is detected, and the unit is configured for PSTN operation.

1 ms (500 ms to 15000 ms)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

3000 2200 3000 3000 3000 3200 3000 3500 2000 2500 3000 3000 3000

3500 3000 3000 3000 3000 3000 5000 2200 3000 3000 3500 2500 3000 3000 5000 3500 3000 2500 3500 3000

50 Obsolete

PBX blind dial wait time. The delay from OFF hook to the start of dialing when blind dialing, no dial tone is detected, and the unit is configured for PBX operation.

1 ms (0 ms to 15000 ms)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

2000 2000 2000 2000 2000 2000 2000 5000 2000 3000 2000 2000 2000

2000 2000 2000 2000 2000 2000 3500 2000 3500 2000 2000 3000 2000 2000 3500 2000 2000 3000 2000 2000

51 Time of each pause. Duration of the delay

when pause characters in a dial string are interpreted as delays.

1 ms (500 ms to 8000 ms)

France All other

countries

2000

3000

52 Number of user entered pauses allowed.

Dial tone detection

Parameter Description Units Country Default

Maximum number of pauses that a user can enter in a dial string.

1 pause (1 pause to 36 pauses)

All countries 36

53 PSTN dial tone evaluation time.

Maximum total time that the LaserJet 3200 will wait for PSTN dial tone.

1 ms (1000 ms to 30000 ms)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

10000 5000 10000 10000 10000 10000 10000 18000 10000 15000 10000 10000 10000

8000 10000 10000 10000 10000 10000 18000 5000

15000 10000 10000 15000 10000 10000 18000 10000 10000 15000 8000 10000

54 PSTN dial tone detect frequencies.

Indicates the frequency combination that is used to identify a PSTN dial tone.

1 = 1 2 = 2 3 = 1 and 2 5 = 1 or 2 6 = 1 or 2 or 3

Germany Netherlands All other

countries

6 6 5

55 PSTN dial tone detection time minimum.

Indicates the total time a PSTN dial tone sequence must be present for a PSTN

dial tone to be detected.

56 PSTN dial tone minimum on time. This is

the minimum duration of a cadenced PSTN dial tone must be present for a

cadenced sequence to be valid.

57 PSTN dial tone maximum on time.

Maximum duration a cadenced PSTN dial tone can be present for a cadenced sequence to be valid. The dial tone is continuous.

1 ms (100 ms 15000 ms)

1 ms (0 ms to 20000 ms)

1 ms (0 ms to 4000 ms)

Australia Belgium

Finland France Netherlands Portugal Spain Sweden All other

countries

All countries 0

200 700

1500 1800 1500 950 1200 1500 500

58 PSTN dial tone minimum off time. The

minimum period of silence that must exist between cadenced PSTN dial tones if the

tone sequence is to be valid.

59 PSTN dial tone maximum off time.

Maximum period of silence that can exist between cadenced PSTN dial tones if the tone sequence is to be valid.

1 ms (0 ms to 2000 ms)

All countries 0

Spain All other

countries

200 0

60 PSTN dial tone detect threshold. Sets the

detection threshold for a PSTN dial tone. If below this level, the PSTN tone will not be detected.

-0.1 dBm (260 to 510 which is -26.0 to -

51.0 dBm)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

320 320 320 320 320 450 320 400 400 350 320 320 320

320 320 320 320 320 320 280 320 320 320 380 350 320 350 400 320 320 350 320 320

61 PSTN dial tone frequency 1. The center

frequency for the first component of the PSTN dial tone.

1 Hz (300 Hz to 700 Hz)

Australia Germany Hungary Netherlands All other

countries

380 410 370 300 350

62 PSTN dial tone frequency 2. Center

frequency for the second component of the PSTN dial tone.

63 PSTN dial tone frequency 3. Center

frequency for the third component of the PSTN dial tone.

64 PSTN dial tone frequency 1 bandwidth.

Tone filter bandwidth used for dial tone detection.

1 Hz (0 Hz to 700 Hz)

20 = 20 Hz 40 = 40 Hz 60 = 60 Hz 80 = 80 Hz 100 = 100 Hz 200 = 200 Hz

Australia Germany Hungary Netherlands Spain All other

countries

Germany Netherlands All other

countries

All countries 100

470 435 470 400 450 440

460 500 0

65 PSTN dial tone frequency 2 bandwidth.

Tone filter bandwidth used for dial tone detection.

66 PSTN dial tone frequency 3 bandwidth.

Tone filter bandwidth used for dial tone detection.

67 Obsolete

SPCL dial tone evaluation time. Maximum total time that the LaserJet 3200 will wait for special dial tone.

Units: same as parameter 64

1 ms (0 ms to 30000 ms)

New Zealand All other

countries

Germany Netherlands All other

countries

Ireland U.K. All other

countries

0 100

100 100 0

8000 8000 0

68 Obsolete

Special dial tone detect. Indicates the frequency combination that is used to identify a special dial tone.

0 = no freq. 1 = 1 2=2 3=1 and 2 5=1 or 2 6=1 or 2 or 3

Ireland U.K. All other

countries

1 1 0

69 Obsolete Special dial tone detection time minimum.

The total time a special dial tone sequence must be present for a special

dial tone to be detected.

70 Obsolete Special dial tone minimum on time.

Minimum duration a cadenced special dial tone must be present for the

cadenced sequence to be valid.

71 Obsolete Special dial tone maximum on time.

Maximum duration a cadenced special dial tone can be present for a cadenced sequence to be valid.

72 Obsolete Special dial tone minimum off time.

Minimum period of silence that must exist between cadenced special tones if the tone sequence is to be valid.

73 Obsolete Special dial tone maximum off time.

Maximum period of silence that can exist between cadenced special tones if the

tone sequence is to be valid.

1 ms (0 ms to 15000 ms)

1 ms (0 ms 2000 ms)

1 ms (0 ms to 4000 ms)

1 ms (0 ms to 2000 ms)

Ireland U.K.

All other countries

All countries 0

1000 1000

0

74 Obsolete Special dial tone detect threshold. Sets

the detection threshold for special dial tones. If the special dial tone is below this level it will not be detected.

75 Obsolete Special dial tone frequency 1. Center

frequency for the first component of the special dial tone.

76 Obsolete Special dial tone frequency 2. Center

frequency for the second component of the special dial tone.

1 (0 to 510) Ireland

U.K. All other

countries

1 Hz (0 Hz to 700 Hz)

Ireland U.K. All other

countries

All countries 0

350 350 0

1111 1111 0

77 Obsolete Special dial tone frequency 3. Center

frequency for the third component of the special dial tone.

1 Hz (0 Hz to 700 Hz)

Ireland U.K. All other

countries

80 80 0

Dialing

78 Obsolete SPCL dial tone frequency 1 bandwidth.

Tone filter bandwidth used for special dial tone detection.

79 Obsolete SPCL dial tone frequency 2 bandwidth.

Tone filter bandwidth used for special dial tone detection.

80 Obsolete SPCL dial tone frequency 3 bandwidth.

Tone filter bandwidth used for special dial tone detection.

Parameter Description Units Country Default

81 PSTN signaling. Indicates which type of

signaling is used for dialing. This parameter is set by the user from the Dialing menu. If parameter 104 (pulse dial disable) is set , the user menu item to change this parameter will not show up in the Dialing menu.

Pulse dialing should not be enabled for Australia or New Zealand, as the LJ 3200 does not meet regulatory pulse dialing requirements in those countries.

20 = 20 Hz 40 = 40 Hz

Units: same as parameter 78

0 = DTMF 1 = Pulse

All countries 0

82 Pre dial shunt. The duration that the dial

shunt relay is activated prior to pulse dialing the first digit in a dial string. Not present on all LIUs.

1 ms (0 ms to 1000 ms)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

0 0 250 250 0 0 250 250 250 250 250 0 0

250 0 250 0 0 0 250 0 250 0 250 0 0 250 250 250 0 0 250 0

83 Post dial shunt. The duration that the dial

shunt relay remains active after the pulse dialing the last digit in a dial string. Not present on all LIUs.

1 ms (0 ms to 1000 ms)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

0 0 250 250 0 0 250 250 250 250 250 0 0

250 0 250 0 0 0 250 0 250 0 250 0 0 250 250 250 0 0 250 0

84 Dial pulse break time. The duration that the

dial pulse relay will be opened to cause a break of loop current during pulse dialing.

1 ms (10 ms to 100 ms)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

67 67 60 67 60 62 60 61 66 60 62 67 67

67 60 60 66 67 67 61 67 60 67 67 60 67 67 61 67 67 60 67 60

85 Dial pulse make time. The duration that the

dial pulse relay will be closed to cause a make of loop current during pulse dialing.

1 ms (10 ms to 100 ms)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

33 33 40 33 40 38 40 39 32 40 38 33 33

33 40 40 34 33 33 39 33 40 33 33 40 33 33 39 33 33 40 33 40

86 Dial pulse inter-digit time. The duration

between digits when pulse dialing, measured from the end of the last make to the start of the first break of the next digit.

1 ms (400 ms to 1500 ms)

Argentina Austria France Mexico Russia Ukraine All other

countries

850 850 900 850 500 500 800

87 DTMF duration and interdigit time. Duration

of each DTMF signal and the duration of the interdigit silence.

1 ms (40 ms to 200 ms)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

70 85 90 90 70 70 90 90 90 90 90 70 80

90 70 90 100 70 70 90 85 90 80 90 90 70 150 90 85 70 90 90 70

88 Open flash time. Controls the duration of

the open flash when the LaserJet 3200 is configured to produce this flash type.

1 ms (50 ms to 2000 ms)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

800 800 110 110 800 800 110 110 270 110 110 110 110

110 800 110 800 110 800 110 800 110 110 110 110 110 110 110 110 110 110 110 800

89 Phone inactivity abort timer. Specifies the

time from end of dialing until the unit disconnects if no response is detected from the answering machine. (Note: This parameter is active when the T30 inactivity abort timer, parameter 13 1, is active. Change parameter 131 also when this parameter is changed.)

1 sec (0 sec to 255 sec)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

59 60 59 59 59 49 59 59 140 80 59 59 59

55 59 59 45 59 59 59 60 59 59 59 80 59 9 59 59 59 80 55 59

Call progress

Parameter Description Units Country Default

90 Busy tone detect enable. If TRUE,

busy tone detection is enabled at the completion of dialing. If FALSE, no busy tone will be detected and the call will either connect or fail due to no answer.

91 Busy tone frequencies. Indicates the

frequency combination that is used to identify the call progress tone.

0 = False 1 = True

1 = 1| 2 = 2

3 = 1 and 2 5 = 1 or 2

All countries 1

All countries 5

92 Busy tone minimum on time. Minimum

duration a call progress tone must be present for a cadenced sequence to be valid.

1 ms (50 ms to 2000 ms)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

150 200 150 150 150 150 150 150 150 100 150 150 150

200 150 150 150 150 150 150 200 150 150 150 100 150 150 150 150 150 100 200 150

93 Busy tone maximum on time.

Maximum duration a call progress tone can be present for a cadenced sequence to be valid.

1 ms (50 ms to 4000 ms)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

750 750 700 700 750 750 700 700 700 700 700 700 700

600 750 700 750 800 750 700 750 700 700 700 700 800 50000 700 700 700 700 600 750

94 Busy tone minimum off time. Minimum

period of silence that must exist between cadenced call progress tones if the tone sequence is to be valid.

1 ms (0 ms to 2000 ms)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

150 275 150 150 150 150 150 150 150 200 150 150 150

290 150 150 150 150 150 150 275 150 150 150 100 150 150 150 150 150 100 290 150

95 Busy tone maximum off time.

Maximum period of silence that can exist between cadenced call progress tones if the tone sequence is to be valid.

1 ms (50 ms to 4000 ms)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

750 750 700 700 750 750 700 700 700 700 700 700 700

600 750 700 750 800 750 700 750 700 700 700 700 800 700 700 700 700 700 600 750

96 Complex impedance enable. Enables

complex impedance mode when off hook.

0 = False 1 = True

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

0 1 1 1 0 0 1 1 1 1 1 0 0

1 0 1 0 0 0 1 1 1 0 1 0 0 1 1 1 0 0 1 0

97 Busy tone frequency 1. The center

frequency for the first component of the call progress tone.

1 Hz (300 Hz to 700 Hz)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

620 400 400 400 620 620 400 400 400 400 400 400 370

400 620 400 620 400 620 390 400 400 350 325 400 400 400 400 400 400 400 400 620

98 Busy tone frequency 2. The center

frequency for the second component of the call progress tone.

1 Hz (0 Hz to 700 Hz)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

480 500 500 500 480 480 500 500 500 500 500 500 470

500 480 500 480 500 480 490 500 500 450 425 500 500 500 500 500 500 500 500 480

99 Busy tone frequency 1 bandwidth.

Tone filter bandwidth used for busy tone detection.

20 = 20 Hz 40 = 40 Hz 60 = 60 Hz 80 = 80 Hz 100 = 100 Hz 200 = 200 Hz

Argentina Canada China Israel Korea Mexico U.S. All other

countries

200 200 200 200 200 200 200 100

100 Busy tone frequency 2 bandwidth.

Tone filter bandwidth used for busy tone detection.

101 Busy tone detect time minimum.

Disconnect if busy detected. Specifies the duration a busy sequence must be detected. If a valid busy sequence is detected the call is aborted.

102 CED and busy detect threshold. Sets

the detection threshold for the CED and busy tone. f the CED or busy tone

is below this level, it will not be detected.

Units: Same as parameter 99.

1 ms (1000 ms to 30000 ms)

-0.1 dBm (260 to 510, which is

-26.0 to -51.0 dBm)

Argentina Canada China Israel Korea Mexico U.S. All other

countries

France All other

countries

France All other

countries

200 200 200 200 200 200 200 100

6000

10000

430 (-43.0 dBm) 470 (-47.0 dBm)

103 Eavesdrop tone fi lter gain. Gain

applied to the CNG signal to improve detection over an OGM. This parameter is only used when SILENCE DETECT ENABLE is set to FALSE.

0.1 dBm (0 to

150)

All countries 0 (0 dBm)

104 Pulse dial disable. Removes the

dialing mode menu item from the fax send setup user menu, so the user cannot select pulse dial mode. The LaserJet 3200 does not meet pulse dialing regulatory requirements in Australia and New Zealand.

105 Spare 105. N/A All countries 0

Modem configuration

Parameter Description Units Country Default

0 = False 1 = True

Australia New Zealand All other

countries

1 1 0

106 Equalizer. Used to select the

transmission compromise equalizer.

0 = None 1 = Programmabl e

2 = Cable

All countries 0

107 LIU receive loss. Specifies the LIU

receive loss. The receive loss is introduced between the modem and the external telephone line interface jack. It is used to correctly adjust the internal modem receive level so that the receive level at the telephone line interface jack is as specified by M ODEM MINIMUM CARRIER DETECTION LEVEL.

-0.1 dB (0 to

100)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

50 50 30 30 50 50 30 30 30 30 30 50 50

30 50 30 50 50 50 30 50 30 50 30 50 50 30 30 30 50 50 30 50

108 LIU transmit loss. Speci fies the LIU

transmit loss. This transmission loss is introduced between the modem and the telephone line interface jack. It is used to correctly adjust the modem and DTMF transmit levels so that the level at the telephone line interface jack is as specified by the MODEM TRANSMIT LEVEL.

-0.1 dB (0 to

100)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

80 80 113 113 80 80 113 113 113 113 113 80 80

113 80 113 80 80 80 113 80 113 80 113 80 80 113 113 113 80 80 113 80

109 DTMF transmit level high group. The

DTMF transmit level for the high group of frequencies in the DTMF tone pair.

-0.1 dBm (0 to 150)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

60 60 80 80 60 60 80 80 80 80 80 60 60

80 40 80 60 75 60 80 60 80 60 80 60 60 80 80 80 60 60 80 60

110 DTMF transmit delta low group. The

relative transmit level (“twist”) of the low group of frequencies in the DTMF tone pair.

-0.1 dB (0 to

40)

Russia Ukraine All other

countries

30 (-3.0 dB) 30 (-3.0 dB) 20 (-2.0 dB)

111 Modem minimum carrier detection level.

Specifies the minimum modem receive level that is presented from the PSTN at

the external telephone interface jack.

-0.1 dBm (350 to 510)

Russia Ukraine

All other countries

430 (-

43.0 dBm)

430 (-

43.0 dBm) 440 (-

44.0 dBm)

112 Tone transmit level. Specifies the CNG

and CED tone level that is presented to the PSTN at the external telephone line interface jack.

-0.1 dBm (0 to 255)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

100 100 105 105 100 100 105 105 105 105 105 100 100

105 100 105 100 100 100 105 100 115 100 105 100 100 105 105 105 100 100 105 100

113 Data transmit level. Specifies the data

transmit level that is presented to the PSTN at the external telephone line interface jack. The default value is 100 (-

0.1 dBm) for all countries.

-0.1 dBm (0 to 255)

Norway Poland All other

countries

110 80 100

114 V17 14400 EQM threshold. The Eye

Quality Monitor measures the received signal quality. When the EQM exceeds

the threshold set here during training (TCF), the modem drops to a lower speed. Consult the Modem Designer's Guide before changing any of the EQM thresholds.

115 V17 12000 EQM threshold. The default

value is 128 for all countries.

116 V17 9600 EQM threshold 1 (0 to

117 V17 7200 EQM threshold. 1 (0 to

118 V33 14400 EQM threshold. The default

value sometimes shows up as -1 on data store reports.

119 V33 12000 EQM threshold. The default

value sometimes shows up as -1 on data store reports.

1 (0 to

65535)

1 (0 to

65535)

1 (0 to

65535)

1 (0 to

65535)

All countries 48

All countries 128

All countries 440

All countries 1024

All countries 65535

120 V29 9600 EQM threshold. 1 (0 to

65535)

121 V29 7200 EQM threshold. 1 (0 to

65535)

122 V29 4800 EQM threshold. The default

value sometimes shows up as -1 on data store reports.

123 V27 4800 EQM threshold. 1 (0 to

124 V27 2400 EQM threshold. 1 (0 to

1 (0 to

65535)

All countries 900

All countries 1700

All countries 65535

All countries 2400

All countries 5500

125 Echo protect mode. Enables transmission

of an echo protect tone prior to the transmission of the training sequence.

0 = Echo protect all modulations except V.29

1 = Enable on all

modulations 2 = Disable

on all modulations

All countries 0

126 Percent of contiguous 0s during training

(TCF) required. The value 0 disables this check.

127 No carrier timer. If carrier is lost for this

duration during high speed receive, the session fails with result code 283. The value 0 disables this check.

128 Recv flag after ABIDL enable. When set

to TRUE, the modem waits for flags after detecting ABIDL before generating an

interrupt again.

129 V.34 block error threshold. All countries 9011

Fax session configuration

Parameter Description Units Country Default

Percentage (0 to 95)

1 ms (0 ms to 30000 ms)

0 = False 1 = True

All countries 80

Germany Russia Spain Ukraine All other

countries

All countries 1

6000 6000 5500 6000 10000

130 Answer inactivity abort timer. Specifies the

time from going OFF hook and waiting for an incoming fax handshake, until the LaserJet 3200 disconnects because no incoming fax activity is detected.

1 sec (0 sec to 255 sec)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

30 40 30 30 30 30 30 40 46 40 30 30 30

40 30 30 30 30 30 40 40 40 30 30 40 30 30 40 40 30 40 40 30

131

Originate inactivity abort timer. Specifies the time from starting t.30 until the LaserJet 3200 disconnects because no fax is detected. (Note: This timer is active when the phone inactivity timer, parameter 89, is active. Change parameter 89 also when this parameter is changed.)

1 sec (0 sec to 255 sec)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

59 60 59 59 59 49 59 59 140 80 59 59 59

55 59 59 45 59 59 59 60 59 59 59 80 59 59 59 55 59 80 55 59

132 T5 timer. Determines the maximum time

that a transmitting machine will wait for a receiving machine to stop sending RNR.

1 sec (0 sec to 1000 sec)

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

240 60 240 240 240 240 240 60 60 60 240 240 240

60 240 240 240 240 240 60 60 60 240 240 60 240 240 60 60 240 60 60 240

133 DTS Compliance Enable. German DTS

compliance requires a slightly different T30 implementation. The differences are primarily concerned with handling voice interrupts. If the value = 1 (True), the T30 operation will comply with the DTS requirement. If 0 (False), the T30 operation will comply with the CCITT requirement. (This parameter may also be known as "BZT compliance", since BZT is the testing organization.)

0 = False 1 = True

Germany Russia Ukraine All other

countries

1 1 1 0

134 Manual dial abort timer. Currently only

used when DTS compliance, parameter 133, is 1. This timer replaces the originate

inactivity timer, parameter 131, when manual dialing is used. (In the T.30 spec, this timer is T1. Parameter 131 is T1 plus additional time for the underlying phone system to make the connection.)

Redial and automatic dialing

Parameter Description Units Country Default

135 Redial on busy enable. Determines the

condition when redialing may occur. If TRUE, then automatic redialing occurs

when a call fails due to detection of a valid busy tone sequence.

136 Redial on no answer enable. Determines

the condition when redialing may occur. If TRUE, then automatic redialing occurs when a call fails due to no answer.

137 Repeat call attempt timer 1. Specifies the

amount of time between repeat call attempts to the same number when the number of repeat call attempts is less than or equal to parameter 139.

1 sec (0 sec to 255 sec)

0 = False 1 = True

1 sec (0 sec to 1000 sec)

Germany Russia Ukraine All other

countries

All countries

Malaysia All other

countries

40 40 40 0

1

0

120 60

138 Repeat call attempt timer 2. Specifies the

amount of time between repeat call attempts to the same number when the

number of repeat call attempts is greater than parameter 139 and less than or equal to parameter 140.

139 Number of call attempts timer 1. Specifies

the number of repeat calls that are attempted using parameter 137 as the interval between call attempts. When this number of repeat calls has been attempted, redialing will continue using parameter 138.

1 sec (0 sec to 1000 sec)

1 retry (0 retries to 15 retries)

All countries

300

1

140 Number of call attempts timer 2. Specifies

the number if repeat calls that are attempted using parameter 138 as the interval between call attempts.

1 retry (0 retries to 15 retries)

Belgium France Italy Korea Malaysia Spain All other

countries

3 3 3 2 1 3 4

141 Obsolete

Blacklist enable. If TRUE, creates a list of numbers which have failed on all re-dial attempts.

Miscellaneous country and T30 settings

Parameter Description Units Country Default

142 Obsolete

143 Redial on no answer maximum attempts.

144 Monitor dial post dial delay. This timer

Paper size. Determines default paper size. Selected by the user using the Paper Size menu.

Some country regulations limit the number of redials when busy is not detected. At each call failure, if there was no answer and the number of redials already equals this count, no more redials will be attempted.

specifies how long to wait after monitor dialing to start T.30. T.30 waits an additional 2 seconds before sending CNG tones.

0 = False 1 = True

1 = Exec 2 = Letter

1 retry (0 retries to 15 retries

1 ms (100 ms to 65000 ms)

France All other

countries

Canada U.S. All other

countries

Germany France Poland Ukraine Russia All other

countries

1 0

1 1 2

100 100 900 100 100 2000

145 Obsolete

146 Obsolete

Scan cycle time. N/A

147 User interface time format. 0 = AM/PM

1 = 24 hr

Argentina Australia Austria Belgium Canada China Denmark Finland France Germany Greece Hong Kong Hungary

Ireland Israel Italy Korea Malaysia Mexico Netherlands New Zealand Norway Poland Portugal Russia Singapore Spain Sweden Switzerland Taiwan Ukraine U.K. U.S.

0 0 1 1 0 0 1 1 1 1 1 0 1

1 1 1 0 0 0 1 0 1 1 1 1 0 1 1 1 0 1 1 0

148 User interface date format. 0 = mmddyy

1 = ddmmyy 2 = yymmdd

Canada China U.S. All other

countries

0 0 0 1

149 User interface language invalid – not sure

how, or if, this is used in the LaserJet 3200.

NOTE: All parameters above 149 are not country specific.

Transmission/reception settings/T30

Parameter Descriptions Units

150 Maximum DIS FIF size. Some older fax machines may

not understand the longer DIS sent when the LaserJet 3200 answers. (When those machines were

manufactured, the DIS was 4 bytes). Setting this parameter to 4 will limit the DIS to 4 bytes for compatibility with older machines. (The 300 DPI capability is lost.) The default value is 255.

151 Transmit resolution maximum. Setting this parameter

will have no effect because it is set to the front panel resolution when a session starts.

152 Transmit data encoding maximum. The default value is

2.

N/A All countries 0

1 byte (4 bytes to 255 bytes)

0 = Std 1 = Fine 2 = 300 dpi

0 = MH 1 = MR 2 = MMR

153 Transmit data rate maximum. The default value is 26. 0 = V.17 14400

1 = V.17 12000 2 = V.17 9600 3 = V.17 7200 4 = V.33 14400 5 = V.33 12000 6 = V.29 9600 7 = V.29 7200 8 = V.29 4800 9 = V.27 4800 10 = V.27 2400 11 = V.21 300 12 = V.34 1200 13 = V.34 2400 14 = V.34 4800 15 = V.34 7200 16 = V.34 9600 17 = V.34 12000 18 = V.34 14400 19 = V.34 16800 20 = V.34 19200 21 = V.34 21600 22 = V.34 24000 23 = V.34 26400 24 = V.34 28800 25 = V.34 31200 26 = V.34 33600

154 Transmit ECM enable. The default value is 1. 0 = False

1 = True

155 Obsolete

156 Transmit ECM frame size. The default value is 256. 64 = 64 bytes

157 Receive resolution maximum. The default value is 2. 0 = Std

158 Receive data encoding max. The default value is 2. 0 = MH

159 Receive data rate max. Given the way a fax receiver

160 Receive ECM enable. The default value is 1. 0 = False

Transmit BFT enable. The default value is 0. (This feature is not implemented.)

advertises its capabilities, only the following choices are valid: 0, 6, 9, 10 and 26. The default value is 26.

0 = False 1 = True

256 = 256 bytes

1 = Fine 2 = 300 dpi

1 = MR 2 = MMR

Units: same as parameter 153

1 = True

161 Obsolete

Receive BFT enable. The default value is 0. (This feature is not implemented.)

0 = False 1 = True

162 Receive minimum scan line time. This parameter

defines how long the sender must take to send each line when the session is non-ECM. The default value is 0. (5/5 means 5 ms for std and 5 ms for fine. 20/10 means 20 ms for std and 10 ms for fine.)

0 = 0/0 ms 1 = 5/5 ms 2 = 10/10 ms 3 = 20/20 ms 4 = 40/40 ms 5 = 10/5 ms 6 = 20/10 ms

7 = 40/20 ms

163 Ignore first DIS. If an international connection has a lot

164 Pre DCS delay. Delay from receiving DIS or FTT to

Fax data

Parameter Descriptions Units

165 ECM no frame abort timer. The default value is 180. If the

166 Non ECM no EOL abort timer. The default value is 13. If the

167 Non ECM errored line threshold. When the number of

168 Send ECM timeout. The default value is 300. If the timer

of echo, ignoring the first DIS may help the line stabilize. The default value is 0.

sending DCS message. Default is 500 mS.

timer expires, the result stored in the fax log is 282 (if no page data received) or 285 (if a partial page was received).

timer expires, the result stored in the fax log is 281 (if no page data received) or 284 (if a partial page was received).

errored lines on a page exceeds this percentage, an RTN is sent indicating that the next page should be sent at a lower

data rate. The default value is 10 percent.

expires, the result stored in the fax log is 390.

0 = False 1 = True

1 mS (0 to 1000)

1 sec (0 sec to 1000 sec)

Percentage (0 to 100)

1 sec (0 sec to 1000 sec)

169 Send non ECM timeout. The default value is 300. If the

User interface

Parameter Descriptions Units

170 Ring noise enable. The default value is 2. 1 = Disabled

171 Key beep enable. The default value is 2. 1 = Disabled

172 Line monitor (speaker) mode. Selects the speaker

timer expires, the result stored in the fax log is 391.

mode for line monitoring. When set to 0, the speaker is turned on during dialing. When set to 1, the speaker is left on always. "Speaker enable always" is used for test purposes only. The default value is 0.

1 sec (0 sec to 1000 sec)

2 = Enabled

0 = Speaker enabled while dialing. 1 = Speaker enabled always (whenever off hook).

173 Ring volume. Speaker volume for the phone ring.

Modified by the user from the volume settings menu. The default value is 1.

0 = Off 1 = Soft 2 = Medium 3 = Loud

174 Key press (beep) volume. Speaker volume for key

press beeps. Modified by the user from the volume settings menu. The default value is 1.

175 Monitor volume. Speaker volume when monitoring the

phone line during dialing. Modified by the user via the front panel volume key. The default value is 96.

176 Default fax contrast. Modified by the user from the fax

send setup menu. The default value is 0.

177 Default fax photo mode. Enable or disable fax photo

mode scanning. Modified by the user from the fax send setup menu, default resolution. The default value is 0.

178 Default send fax resolution. Modified by the user from

the fax send setup menu, default resolution. The default value is 1.

179

Obsolete

Number speed dials. Number of speed dials the device has for a given device derivative. The default value is 100.

0 = Off 1 = Soft 2 = Medium 3 = Loud

0 = Off 96 = Soft 160 = Medium 200 = Loud

the range is:

-125 (least contrast) to 125 (highest contrast) in 25 unit increments

0 = False 1 = True

0 = Std 1 = Fine 2 = 300 dpi

1 speed dial (40 to 100)

180 Obsolete

181 Obsolete

182

Obsolete

Miscellaneous

Parameter Descriptions Units

183 Auto fax log. If true, the fax activity log report prints after every 40 fax

184 Obsolete Fax fixed reduction. Amount of reduction applied to received faxes.

185 Fax auto reduction. If true, unit will reduce incoming fax image size to

Fax additional wait. N/A

Fax compression factor. N/A

Document memory size. N/A

sessions. Set by the user through the reports menu, fax activity log, automatic log printing. The default value is 1.

Only used when automatic fax reduction is not enabled. The default value is 100%.

fit on the current page whenever possible. The default value is 1.

0 = False 1 = True

Percentage

0 = False 1 = True

186 TTI (transmit terminal identification) control. If TRUE, the header

information will be included on each fax page sent by the LaserJet

3200. The default value is 1.

Image adjustments and miscellaneous

Parameter Descriptions Units

0 = False 1 = True

187 Maximum auto reduction. Limits the amount of scaling on auto

reduction. Scaling down too far results in unreadable faxes. This tends to occur when the sending fax jams or double

feeds a document. The default value is 60.

188 Obsolete

189 Obsolete

190 Obsolete

191 Obsol ete

192 Obsolete

193 Cioca register (in codec) default value. This value is written to

194 Cioca register (in codec) value when in eavesdrop mode. This

Fax backup reception. Default is 1. 0 = False

Transmit fail if remote end doesn’t support JPEG. 0 = False

Transmit fail if remote end doesn’t support color. 0 = False

T.30 transmit color. 0 = False

T.30 receive color. 0 = False

a modem control register and should not be changed without a detailed understanding of the consequences.

value is written to a modem control register and should not be changed without a detailed understanding of the consequences.

Percentage (60 to 100)

1 = True

195 Ciocb register (in codec) default value for U.S. liu. This value

is written to a modem control register and should not be changed without a detailed understanding of the consequences.

196 Ciocb register (in codec) eavesdrop value for U.S. liu. This

value is written to a modem control register and should not be changed without a detailed understanding of the consequences.

197 Ciocb register (in codec) default value for Euro liu. This value

is written to a modem control register and should not be changed without a detailed understanding of the consequences.

198 Ciocb register (in codec) eavesdrop value for Euro liu. This

value is written to a modem control register and should not be changed without a detailed understanding of the consequences.

199 Ciocb register (in codec) default value for Rare liu. This value

is written to a modem control register and should not be changed without a detailed understanding of the consequences.

200 Ciocb register (in codec) eavesdrop value for Rare liu. This

value is written to a modem control register and should not be changed without a detailed understanding of the consequences.

201 Fax receive disposition. This is used in combination with the

fax forwarding object to determine whether to print, forward, or upload the fax.

202 Fax download all pages. Used during a fax download from a

host. False means to start the outgoing fax session after the

1 = print 4 = upload else print 6 = forward else print

0 = false 1 = true

first page is downloaded, true means to download all pages before starting the fax session. The default valu e is 0.

This information is subject to change without notice and

is provided "as is" with no warranty.

Hewlett-Packard shall not be liable for any direct,

indirect, special, incidental, or consequential damages

in connection with the use of this material.

Hp LASERJET 3200 Parameter Settings

Specifications and Main Features

Frequently Asked Questions

User Manual
