HP LaserJet 3200 Getting Started Guide
Installation checklist
Tear out this checklist now to use as you proceed through this guide. For each major
step in the installation process, you can check your wo rk by answering the question s on
the checklist. See “Using the installation checklist” on page 7 for more information.
1 What type of phone line did you
decide to use (page 8)?
o Dedicated line for fax calls.
o Shared line for fax calls and voice
calls.
Continue to “Computer and network
requirements” on page 9.
2 What type of installation did you
choose (page 9)?
o Standalone. Continue to “Checking
the contents of the box” on page 12.
o Direct. Continue to “If you chose
network connection or direct
connection:” on page 10.
o Network. Continue to “If you chose
network connection or direct
connection:” on page 10.
3 Does your computer or network
meet the requirements (page 11)?
o Yes. Continue to “Checking the
contents of the box” on page 12.
• Gather this information: the
product serial number and model
number (on the back of the
product), the item missing, and the
purchase date. Then, call HP
Customer Care at (208) 323-2551.
5 Were you able to install the toner,
attach the supports, and load
media into the paper input tray
(page 20)?
o Yes. Continue to “Connecting the
product” on page 21.
o No. Review pages 18, 19, and 20.
6 After you connect the power cord,
does READY appear on the control
panel display (page 28)?
o Yes. Continue to “Testing the
hardware” on page 29.
o No. See chapter 3, “Installation
troubleshooting,” on page 53.
7 Were you able to print and copy
the demonstration page (page 29)?
o No. You should decide whether you
want to upgrade your computer,
network, or HP JetDirect print server,
to use a different computer, or to
change the type of installation you
want. When you are ready, continue
to “Checking the contents of the box”
on page 12.
4 Does the box contain all of the
items it should (page 13)?
o Yes. Continue to “Recording
important information” on page 13.
o No. Do one of the following:
• Contact the dealer for details
about getting the missing item.
o Yes. Continue to “Completing
installation” on page 30.
o No. Try again to print and copy the
page, making sure you press COPY
(not FAX/SEND, which would try to
send the page as a fax). If you try
again and still cannot print and copy
the demonstration page, see “HP
Customer Care” on page 56.
For direct connect installations
or network installations:
8 Did the test page print (page 38 for
direct, or page 41 for network)?
o Yes. You have finished installing the
software and setting the required
settings. Continue to "Completing
software installation" (on page 38 for
direct connect installations, or on
page 41 for network installations).
o No. Do the following:
• See chapter 3, “Installation
troubleshooting,” on page 53 to
check for solutions to messages
and common installation issues.
• If the troubleshooting section does
not resolve the issue, see “HP
Customer Care” on page 56.
9 Did the document print (page 42)?
o Yes. The new equipment is working
correctly with your computer.
• If you completed a direct connect
installation, and want to allow
other computers on your network
print to the product, see “Sharing
the product (for printing only)” on
page 43. (If you do not want to
share the product, you have
completed installation. Continue to
chapter 4, “Now that installation is
complete . . .,” on page 55.)
• If you completed a network
installation, Continue to chapter 4,
“Now that installation is complete .
. .,” on page 55.
o No. Do the following:
• See chapter 3, “Installation
troubleshooting,” on page 53 to
check for solutions to messages
and common installation issues.
• If the troubleshooting section does
not resolve the issue, see “HP
Customer Care” on page 56.
For standalone installations:
10 After you set the time and date,
does the control panel read READY,
followed by the date and time you
set (page 45)?
o Yes. Continue to “To set the fax
header” on page 46.
o No. Do the following:
• If the control panel display does
not read READY, or does not show
the correct time and date,
complete all of the steps under "To
set the time and date" again.
• If the control panel display
contains information about an
error, see chapter 3, “Installation
troubleshooting,” on page 53.
When the control panel reads READY,
followed by the correct time and date,
continue to “To se t the fax header” on
page 46.
11 Does the control panel display
show the answer mode setting that
you chose (page 48)?
o Yes. If you have ring pattern service,
continue to “Enabling answer ring
patterns” on page 49; if you do not
have ring pattern service, continue to
“To print a configuration report” on
page 51.
o No. Try again to set the answer
mode.
12 Do the settings you entered appear
correctly?
o Yes. You have completed the
required settings. Continue to
chapter 4, "Now that installation is
complete . . ."
o No. See “HP Customer Care” on
page 56.
HP LaserJet 3200 Product
Getting Started Guide
Copyright Information
© 2000 Hewlett-Packard
Company
All Rights Reserved.
Reproduction, adaptations, or
translation without prior written
permission is prohibited except
as allowed under copyright
laws.
Part number C7052-90904
First edition, October 2000
Printed in USA
Warranty
The information contained in
this document is subject to
change without notice.
Hewlett-Packard makes no
warranty of any kind with
respect to this information.
HEWLETT-PACKARD
SPECIFICALLY DISCLAIMS
THE IMPLIED WARRANTY OF
MERCHANTABILITY AND
FITNESS FOR A PARTICULAR
PURPOSE.
Hewlett-Packard shall not be
liable for any direct, indirect,
incidental, consequential, or
other damage alleged in
connection with the furnishing or
use of this information.
NOTICE TO U.S.
GOVERNMENT USERS:
RESTRICTED RIGHTS
COMMERCIAL COMPUTER
SOFTWARE: “Use, duplication,
or disclosure by the
Government is subject to
restrictions as set forth in
subparagraph (c) (1)(ii) of the
Rights in Technical Data Clause
at DFARS 52.227-7013.”
Trademark Credits
Microsoft, Windows, and MSDOS are U.S. registered
trademarks of Microsoft
Corporation.
ENERGY STAR is a U.S.
registered service mark of the
U.S. EPA.
All other products mentioned
herein may be trademarks of
their respective companies.
This product is
approved for use only
in the United States.
Local country laws may prohibit
the use of this product outside
of the countries specified. It is
strictly forbidden by law in most
countries to connect
nonapproved telecommunications equipment (fax
machines) to public telephone
networks.
Safety Information
WARNING!
Potential Shock Hazard
Always follow basic safety
precautions when using this
product to reduce risk of injury
from fire or electric shock.
1 Read and understand all
instructions in the user
guide.
2 Observe all warnings and
instructions marked on the
product.
3 Use only a grounded
electrical outlet when
connecting the
HP LaserJet 3200 product
to a power source. If you
don’t know whether the
outlet is grounded, check
with a qualified electrician.
4 Do not touch the contacts
on the end of the
telephone cord or any of
the sockets on the
HP LaserJet 3200 product.
Replace damaged cords
immediately.
5 Never install telephone
wiring during a lightning
storm.
6 Unplug this product from
wall outlets and telephone
jacks before cleaning.
7 Do not install or use this
product near water or
when you are wet.
8 Install the product securely
on a stable surface.
9 Install the product in a
protected location where
no one can step on or trip
over the line cord and the
line cord will not be
damaged.
10 If the product does not
operate normally, see the
online user guide.
11 Refer all servicing
questions to qualified
personnel.
Information regarding FCC
Class B, Parts 15 and 68
requirements can be found in
the user guide.
Hewlett-Packard Company
11311 Chinden Boulevard
Boise, Idaho 83714 U.S.A.
Contents
1 Introduction
Setup requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Phone line requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Computer and network requirements . . . . . . . . . . . . . . . . . . . .9
Checking the contents of the box . . . . . . . . . . . . . . . . . . . . . . . . .12
Recording important information. . . . . . . . . . . . . . . . . . . . . . .13
Hardware overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
2 Installation
Setting up hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Toner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Supports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Paper/media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Connecting the product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Connecting the phone line . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Connecting additional devices . . . . . . . . . . . . . . . . . . . . . . . .25
Connecting power and testing. . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Connecting power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Testing the hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Completing installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Direct connect installation (USB cable). . . . . . . . . . . . . . . . . .31
Direct connect installation (parallel cable) . . . . . . . . . . . . . . .34
Network installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Standalone installation (no computer) . . . . . . . . . . . . . . . . . .44
3 Installation troubleshooting
4 Now that installation is complete . . .
Using the HP LaserJet 3200 product . . . . . . . . . . . . . . . . . . . . . .55
HP Customer Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Warranty statement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Limited Warranty for Toner Cartridge Life. . . . . . . . . . . . . . . . . . .61
FCC regulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
Additional regulatory statements. . . . . . . . . . . . . . . . . . . . . . . . . .62
EN 5
6 EN
1Introduction
Thank you for purchasing the HP LaserJet 3200 product, a
powerful business tool with the capabilities of a full range of
office equipment: use the product to print, fax, copy, and scan.
Increase your productivity by doing more than one task at a time.
Use this guide to help you:
l check phone line and compu ter requirements
l check the contents of the box
l set up the product hardware
l connect the product to your phone line and to other devices,
such as answering machines and computers
l verify that you have successfully installed the product
Using the installation checklist
Several times during the installation process, you will be
prompted to
Check your work.
When you encounter a "check your work," see the installation
checklist inside the front cover of this guide. The checklist lists all
of the task checks to help you install the produ ct, step -b y-step,
and, for each check, you get directions to your next step.
EN 7
Setup requirements
Phone line requirements
Connect the HP LaserJet 3200 product to the phone line in one of two
ways:
l a dedicated line for fax calls
l a shared line for both fax calls and voice calls
In most cases, you can choose either one. However, th e product only
works with analog, rather than digital, telephone lines (analog is
common) and some phone-system features, such as call waiting and
voice mail, might interfere with the correct operation of the pro duct.
HP recommends that you get a second phone line dedicated to fax
calls if your phone system has call waiting or voice mail. Contact your
local phone company to add a second phone line.
CAUTION If you live in an area that is subject to frequent electrical storms or if
you experience frequent power outages, HP strongly recomme nds that
you purchase a telephone line surge protector, available at local
computer or electronics retailers. Electrical surges and power
interruptions can damage the product.
Check your work #1.
Which type of phone line did you decide to use?
8 Chapter 1 - Introduction EN
Computer and network requirements
The product has three installations to choose from; each has different
computer and network requirements and varying available features:
l Direct connection to a computer
l Network connection with an HP JetDirect Print Server
l Standalone, to use the pr oduct as a fa x mach ine and cop ier, not
connected to a computer or network
The table below details the features availabl e and th e inst alla tio ns
with which the features work.
Feature Direct Network Standalone
Faxing to and from the product using the
control panel
Copying using the control panel XXX
Control panel access to setup options, fax
and copy options, one-touch keys, and
speed-dial and group-dial codes
Printing from the computer XX
Access to PC Fax Phone Books XX
Color scanning from the product to the
computer
Faxing electronic documents from the
computer (PC faxing)
Optical character recognition (OCR) software
for converting scanned text to editable text
Special copying features, such as collation for
large documents
Quick access through the software to product
setup options, fax options, and setup for onetouch keys and speed-dial codes
XXX
XXX
XX
XX
XX
XX
XX
Note When the computer in a direct connection installation is on a local are a
network, the product can be shared with other computers on the
network. Users of shared computers can only print from their
computers to the product.
Check your work #2
Which type of installation did you choose?
EN Setup requirements 9
If you chose the standalone installation:
There are no computer or network requirements; skip the remainder
of this section and continue to “Checking the contents of the box” on
page 12.
If you chose network connection or direct
connection:
All of the computers that will use the product software must be PCcompatible computers that meet the following minimum requirements:
l 486 33 MHz processor or better (or a Pentium 90 MHz processor
or better for Microsoft Windows NT 4.0 or Windows 2000)
l Windows 95, 98, 2000, 2000 Milennium Edition, or NT 4.0
operating system
l 32 MB or more of RAM for Windows 95 or 98; 64 MB or more of
RAM for Windows 2000, or NT 4.0
l 175 MB or more of free ha rd-disk space
Note For a direct connection, the computer should have USB port or a
dedicated IEEE-1284 bidirectional or ECP-compliant parallel port
available. If the parallel port has another device attached to it, such as
an external storage device, that device must be d isconnected.
If you chose network connection:
In addition to having the network computers meet the requirements
shown above, you must have the following:
l An installed network that uses t he TCP/IP or the IPX/SPX
network protocol.
l An appropriate cable for the type of network connection. The
cable is used to connect the print server to a net work jack, and is
not included with the product. If you do not know what type of
cable you need, ask the person who installed the network.
10 Chapter 1 - Introduction EN
l A supported HP JetDirect Print Server (not included). Your choice
of print server depends on the type of network connection you
have and the number of devices you want to connect to the print
server.
• HP JetDirect 70X (J4155A) for a Home PNA network.
• HP JetDirect 170X (J3258B — J3258A is not supported) for
a 10Base-T network connection, if you only need to connect
the product to this print server.
• HP JetDirect 300X (J3263) with a firmware revision of
H.08.00 or higher* for a 10Base-T or 10/100Base-TX network
connection, if you only need t o connect the product to this print
server.
• HP JetDirect 500X (J3265) with a firmware revision of
J.08.00 or higher* for a BNC, 10Base-T, or 10/100Base-TX
network connection, if you need to connect the pr oduct and up
to two other devices to this print server.
• HP JetDirect 500X (J3264) with a firmware revision of
J.08.00 or higher* for a Token Ring network connection. You
can connect the product and up to two other devices to this
print server.
*You can check the firmware revision number by printing a
configuration page for the print server. Instructions for prin ting the
configuration page appear later in this guide.
Note HP recommends against using HP JetDirect Print Servers that are
older than the print servers listed above.
Check your work #3
Does your computer or network meet the requirements?
EN Setup requirements 11
Checking the contents of the box
1
2
3
5
6
Unpack the box and check to see that it includes the following items:
1 HP LaserJet 3200 product
2 Four media supports and one support extension
3 Power cord
4 Telephone cord
5 Software and documentation on CD-ROM
6 Toner cartridge
Save the box and packing material in case you move or ship the
product later.
4
12 Chapter 1 - Introduction EN
Check your work #4
Does the box contain all of the items it should?
Recording important information
Take a moment now to write the model and serial numbers, which are
located on the back of the product, and the date of purchase on the
inside front cover of this guide. HP Customer Care will ask for this
information if you call with a question.
Also, locate your sales receipt or proof of purchase and tape it or
staple it to the inside, back cover of this guide.
When you are ready, continue to “Hardware overview” on page 14.
EN Checking the contents of the box 13
Hardware overview
Place the product on a sturdy, level surface in a well-ventilated area
that meets the following environmental requirements:
l temperature: 15° to 32.5° Celsius (59° to 90.5° Fahrenheit)
l humidity: 10% to 80% relat ive humidity (no condensation)
l install away from direct sunlight, open flames, and ammonia
fumes
l install with enough sp ace around the product to allow for proper
access and ventilation, as shown in the figure below:
439 mm (17.3 inches)
395 mm (15.5 inches) 678 mm (26.7 inches)
14 Chapter 1 - Introduction EN
Then, make sure you can identify the parts shown in this overview.
4
3
2
1
1 Front paper path door
2 Document output slot
3 Control panel/document release door
4 Printer door
5 Printer door release latches
5
EN Hardware overview 15
8
7
6
6 Document feeder tray
7 Paper output bin
8 Single-sheet input tray
9 Paper input tray
10 Paper input guides
11 Special media lever
10
9
11
When you are comfortable with parts identification, cont inue to
Chapter 2, Installation.
16 Chapter 1 - Introduction EN
2Installation
HP LaserJet 3200 product installation involves one of the follow ing
installation paths, depending upon the type of installation you chose:
Direct connection to a computer
Set up hardware
1
Set up phone connections, including attaching other telephone
2
line devices
Connect power
3
Connect the product to the computer
4
Install the software
5
Network connection
Set up hardware
1
Set up phone connections, including attaching other telephone
2
line devices
Connect power
3
Connect the product to a supported HP JetDirect Print Server
4
Install the software
5
Standalone
1 Set up hardware
2 Set up phone connections, including attaching other telephone
line devices
3 Connect power
4 Set the date and time, fax header, and other required items on the
product
EN 17
Setting up hardware
1
2
Toner
HP recommends using HP LaserJet
toner cartridges, which are designed to
work with the product to give you optimal
image quality and reliability.
CAUTION
To prevent damage, do not expose the
toner cartridge to light for more than a
few minutes.
To install the toner cartridge
1 Press the two printer door release
latches and open the printer door.
3
4
2 Shake the toner cartridge several
times from side to side (about twice
per second) to distribute the toner
evenly.
3 Grasp the end of the clear sealing
tape on the side of the cartridge and
pull firmly to remove the entire
length of the tape (about twice as
long as the cartridge).
4 Hold the cartridge by the handle,
with the arrows facing the product,
and slide the cartridge into the black
grooves in the product. Rotate the
cartridge firmly into place and close
the printer door.
5 Close the front paper path door.
5
Note
If toner gets on your clothing, wipe it off
with a dry cloth and wash the clothing in
cold water. Hot water and heat from a
dryer can set toner into fabric.
18 Chapter 2 - Installation EN
1
a b
c
Supports
d
To support media feeding into and
coming out of the product, four supports
should be installed.
e
2
3
4
To attach supports
1 Locate the four supports and the
extension
a paper input support
b paper output support
c document feeder support
d document output support
e document output support
extension
2 Insert the paper input support into
the groove on the paper input tray,
and then insert the paper output
support into the groove on the pap er
output bin.
3 Insert the document feeder support
into the grooves on the back of the
document feeder tray.
4 Hang the document output support
from the slots in the document
output support extension, and then
press the two parts together un til the
extension clicks into place on both
sides.
5
EN Setting up hardware 19
5 Squeeze the ends of the document
output support, insert it into the
holes on the document output slot,
and release the support.
Loading...
