Item #______________________________________

Quantity____________________________________

C.S.I. Section 11400 

















THE EDGE12





701 S Ridge Avenue, Troy, OH 45374



SLICER





1-888-4HOBART • www.hobartcorp.com





















































STANDARD FEATURES

MODEL

■ 1-Speed, 1/2 H.P. Knife Drive Motor

The Edge12 Slicer – 120/60/1

Manual Slicer and 12" Knife Diameter

■ 4 Amp (1.4 Amp on higher voltage unit)

The Edge12 Slicer – 220-240/50-60/1



■ Poly-V Belt Drive System

Manual Slicer and 12" Knife Diameter

■ 45° Product Table

Specifications, Details and Dimensions on Inside and Back.



■ Sanitary Anodized Aluminum Base







Anodized Aluminum Carriage and Knife Cover

Gauge Plate Interlock

Carriage System Interlock

Removable Carriage System

12" Diameter Chrome-Plated Carbon Steel Knife

Top-Mounted Borazon Stone Sharpener

Permanent Knife Ring Guard

Removable Product Deflector

Rear-Mounted Removable Meat Grip with Contoured Handle

SLICER EDGE12 THE

F40328 – The Edge12 Slicer

Page 1 of 4

THE EDGE12 SLICER

701 S Ridge Avenue, Troy, OH 45374

1-888-4HOBART • www.hobartcorp.com

SOLUTIONS / BENEFITS

1-Speed, 12 H.P. Knife Drive Motor

Durability and performance

Poly V-Belt Drive System

Performance, durability, reduced maintenance

Design extends belt life while producing optimal slicing results

Quieter operating slicer

More economical for service and repairs with reduced parts and reduced service time

Full Gravity Feed

Full 45° angle feed requires less mechanical pressure.

Sanitary Anodized Aluminum Base

Improved sanitation, labor savings

One piece base makes cleaning easy

No cracks/crevices or bolt holes where product can lodge and bacteria may grow

Easy cleaning and durable finish

Anodized Aluminum Carriage and Knife Cover

Improved sanitation, durability

Maximum sanitation and minimal cleanup time

Corrosion resistant, impact resistant

Gauge Plate Interlock

Ease of cleaning

Gauge plate must be closed to remove carriage for cleaning and cannot be opened when carriage­ is removed

Protects knife edge during cleaning procedures

Carriage System Interlock

Will not remove if gauge plate indicator is not closed

Removable Carriage System

Improves Sanitation

Removable for complete cleaning and sanitation procedures

12" Diameter Chrome-Plated Carbon Steel Knife

Reduced cost of ownership, improved yield ■ Thin edge design improves yield

Top Mounted Borazon Stone Sharpener

Ease of use, improved sanitation

Single action sharpens and hones in just five seconds

Removable and submersible for easy cleaning and sanitation

Permanently Mounted Ring Guard

Protection

■ Protects knife during operation and cleaning

Removable Rear Deflector

Improved sanitation, ease of use

Allows access for thorough cleaning

No tools required means easy removal during cleaning

Removable Meat Grip

Ease of cleaning and use

Removable meat grip allows for easy cleaning and meat grip extension ensures oversized loaves are secured

Page 2 of 4

F40328 – The Edge12 Slicer
