s DS
-K1T671TM
-3XF terminal is an access control device
integrated
DS-K1T671TM-3XF
Temperature Screening Terminal1
S-K1T671TM-
with HAT (High Accuracy Temperature)/EST (Elevated Skin Temperature)
screening. It can quickly measure skin-surface temperature and notify the user
about abnormal readings. This product is perfect for many applications,
including office buildings, transportation hubs, retail facilities, education
centers, and many others.
Available Model: DS-K1T671TM-3XF
•
Vanadium Oxide Uncooled Sensor Measures Target’s Temperature
•
Range: 86° to 113° F (30° to 45° C), Accuracy: ±0.5° C w/o Black Body Calibration
•
Recognition Distance: 0.3 m to 2 m
•
Fast Temp. Measurement Mode: Detects Face, Takes Skin-Surface Temp.
w/o Identity Authentication
•
Multiple Authentication Modes: Card/Temperature, Face/Temperature, Card/Face/Temperature, etc.
•
Face Mask Detection: If Maskless Face Detected, Voice Reminder Prompt Sounds
- Face Mask Alert: Authentication or Attendance Is Valid
- Forced Mask Wearing Alert: Authentication or Attendance Fails
•
Displays Temperature Measurement Results on Authentication Page
•
Triggers Voice Prompt when Detecting Abnormal Temperature
•
Configurable Door Status (Open/Close) when Detecting Abnormal Temperature
•
Transmits Online and Offline Temperature Information to Client Software via TCP/IP Communication
and Saves Data on Client Software
•
Face Recognition Duration <0.2 s/User; Face Recognition Accuracy Rate ≥99%
•
50,000 Face Capacity, 50,000 Card Capacity, and 100,000 Event Capacity
•
Suggested Height for Face Recognition: Between 1.4 m and 1.9 m
•
Attendance Status: Check In, Check Out, Break In, Break Out, Overtime In, Overtime Out
•
Watchdog Design and Tamper Function
•
Audio Prompt for Authentication Result
•
NTP, Manual Time Synchronization, and Auto Synchronization
•
Connects to External Access Controller or Wiegand Card Reader via Wiegand Protocol
•
Connects To Secure Door Control Unit via RS-485 Protocol To Avoid Door Opening if Terminal Destroyed
•
Imports and Export Data to the Device from the Client Software
1
U.S.
Disclaimer: Hikvision USA Inc. products depicted herein are not FDA approved medical devices and are not intended for use in the diagnosis of
disease or other conditions, or in the cure, mitigation, treatment, or prevention of disease. When configured correctly, the Hikvision products
discussed herein can identify elevated human skin-surface temperature relative to a sample population.
Canada
Disclaimer: Hikvision’s Thermographic Cameras are designed for immediate detection and preliminary screening of elevated skin-surface
temperature in high-traffic areas. When measuring core body temperature, please verify through the use of clinical measurement devices
and/or by consulting a medical professional. Hikvision’s Thermographic Cameras must be used in accordance with local laws and regulations.
Notes
Biometric recognition products are not 100% applicable to anti-spoofing environments. If you require a higher security level, use multiple
authentication modes.
In order to get an accurate temperature reading, wait 90 minutes for the device to warm up after the device is powered on.
© 2020 Hikvision USA Inc. • All Rights Reserved • Specifications subject to change without notice.
Hikvision USA Inc., 18639 Railroad Street, City of Industry, CA 91748, USA • Hikvision Canada, 4848 rue Levy, St-Laurent, Quebec, Canada, H4R 2P1
Tel: +1-909-895-0400 • Toll Free in USA: +1-866-200-6690 • E-Mail: sales.usa@hikvision.com • www.hikvision.com 061720NA
Specifications
Model DS-K1T671TM-3XF
Operating System Linux
Sensor Vanadium oxide uncooled sensor
Resolution 120 × 160
Temperature Measurement
Temperature Range 86° to 113° F (30° to 45° C)
Temperature Accuracy ±0.9° F (±0.5° C) without black body calibration
Measuring Distance 0.98 ft to 6.5 ft (0.3 m to 2 m)
Screen
Camera 2 MP dual-lens camera, WDR
Indicator Supported
Face
Face Recognition Duration ＜0.2 s per person
Face Recognition Distance 0.98 ft to 6.5 ft (0.3 m to 2 m)
Card
Card Presenting Duration ＜1 s
Card Presenting Distance 0" to 1.97" (0 cm to 5 cm)
Event Capacity 100,000
Interface
Network 10/100/1000 Mbps self-adaptive
Tamper Supported
Working Temperature
Other
Application Environment Indoor and windless environment use only
* WARNING: Do not expose the equipment to direct sunlight, low ventilation, or a heat source such as a heater or radiator (ignoring this
warning can cause fire danger).
Frame Rate 25 fps
Screen 7 inch touch screen
Ratio 16:9
Resolution 1024 × 600
Recognition Mode Face: 1:1 and 1:N
Face Capacity 50,000
Card Capacity 50,000
Card Type M1 card
Network × 1, RS-485 × 1, Wiegand × 1, USB × 2, alarm output
× 1, alarm input × 2, lock ×1, door contact × 1, exit button ×
1, tamper × 1
Working Voltage
Working Humidity 10% to 90% (non-condensing)
Application Indoor
Brackets
12 VDC/2 A
Power supply (DS-KP12V-3A): not included
32° to 122° F (0° to 50° C)
For temperature measurement: 50° to 95° F (10° to 35° C)
Wall mount (included)
Floor Stand (DS-KAB671-B): not included
Desk Stand (DS-DM0701BL): not included
