AVR 3650, AVR 365 AVR 2650, AVR 265

Audio/video receiver

ENGLISH

Owner’s Manual

AVR

Table of Contents

INTRODUCTION 3

SUPPLIED ACCESSORIES 3

IMPORTANT SAFETY INFORMATION 3

PLACE THE RECEIVER 3

FRONT-PANEL CONTROLS 4

REAR-PANEL CONNECTORS 6

SYSTEM REMOTE CONTROL FUNCTIONS 8

ZONE 2 REMOTE CONTROL FUNCTIONS (AVR 3650/AVR 365 ONLY) 10

INTRODUCTION TO HOME THEATER 12

TYPICAL HOME THEATER SYSTEM 12

MULTICHANNEL AUDIO 12

SURROUND MODES 12

PLACE YOUR SPEAKERS 13

PLACING THE LEFT, CENTER AND RIGHT SPEAKERS 13

PLACING THE SURROUND SPEAKERS IN A

5.1-CHANNEL SYSTEM 13

PLACING THE SURROUND SPEAKERS IN A

7.1-CHANNEL SYSTEM 13

PLACING FRONT HEIGHT SPEAKERS IN A

7.1-CHANNEL SYSTEM 13

PLACING THE SUBWOOFER 13

TYPES OF HOME THEATER SYSTEM CONNECTIONS 14

SPEAKER CONNECTIONS 14

SUBWOOFER CONNECTIONS 14

SOURCE DEVICE CONNECTIONS 14

VIDEO CONNECTIONS 15

RADIO CONNECTIONS 16

NETWORK CONNECTOR 16

USB PORT 16

RS-232 CONNECTOR 16

MAKING CONNECTIONS 17

CONNECT YOUR SPEAKERS 17

CONNECT YOUR SUBWOOFER 17

CONNECT YOUR TV OR VIDEO DISPLAY 17

CONNECT YOUR AUDIO AND VIDEO SOURCE DEVICES 18

CONNECT THE BRIDGE IIIP 20

CONNECT TO YOUR HOME NETWORK 20

CONNECT THE RADIO ANTENNAS 20

INSTALL A MULTIZONE SYSTEM 21

CONNECT IR EQUIPMENT (AVR 3650/AVR 365 ONLY) 22

CONNECT THE 12V TRIGGER OUTPUT 23

CONNECT TO AC POWER 23

SET UP THE REMOTE CONTROL 23

INSTALL THE BATTERIES IN THE REMOTE CONTROL 23

PROGRAM THE REMOTE TO CONTROL YOUR SOURCE DEVICES AND TV 23

SET UP THE AVR 25

TURN ON THE AVR 25

USING THE ON-SCREEN MENU SYSTEM 25

CONFIGURE THE AVR FOR YOUR SPEAKERS 25

SET UP YOUR SOURCES 26

SET UP THE NETWORK 27

OPERATING YOUR AVR 28

CONTROLLING THE VOLUME 28

MUTING THE SOUND 28

DOLBY® VOLUME 28

LISTENING THROUGH HEADPHONES 28

SELECTING A SOURCE 28

LISTENING TO FM AND AM RADIO 29

LISTENING TO SIRIUS® SATELLITE RADIO 29

LISTENING TO MEDIA ON A USB DEVICE (AVR 3650/AVR 365) 30

LISTENING TO AN iPod/iPhone DEVICE 30

LISTENING TO INTERNET RADIO 31

LISTENING TO MEDIA VIA YOUR HOME NETWORK 32

SELECTING A SURROUND MODE 32

AUDIO EFFECTS 32

VIDEO MODES 32

ADVANCED FUNCTIONS 33

AUDIO PROCESSING AND SURROUND SOUND 33

VIDEO PROCESSING 34

MANUAL SPEAKER SETUP 36

LISTENING IN ZONE 2 39

SYSTEM SETTINGS 39

SETTINGS LOCK 40

ADVANCED REMOTE CONTROL PROGRAMMING 41

RECORDING 41

SLEEP TIMER 41

RESETTING THE REMOTE 42

PROCESSOR RESET 42

TROUBLESHOOTING 43

SPECIFICATIONS 44

APPENDIX 45

AVR

Introduction, Supplied Accessories,

Important Safety Information and Place the Receiver

Introduction

Thank you for choosing this Harman Kardon product!

For more than ﬁfty years, the Harman Kardon mission has been to share a passion for music and entertainment, using leading-edge technology to achieve premium performance. Sidney Harman and Bernard Kardon invented the receiver, a single component designed to simplify home entertainment without compromising performance. Over the years, Harman Kardon products have become easier to use, while offering more features and sounding better than ever.

The AVR 3650, AVR 2650, AVR 365 and AVR 265 7.1-channel digital audio/video receivers continue this tradition with some of the most advanced audio and video processing capabilities yet, and a wealth of listening and viewing options.

To obtain the maximum enjoyment from your new receiver, please read this manual and refer back to it as you become more familiar with its features and their operation.

If you have any questions about this product, its installation or its operation, please contact your Harman Kardon retailer or custom installer, or visit the Web site at www.harmankardon.com.

Supplied Accessories

The following accessory items are supplied with your receiver. If any of these items are missing, please contact your Harman Kardon dealer or Harman Kardon customer service at www.harmankardon.com.

System remote control •

Zone 2 remote control (AVR 3650/AVR 365 only) •

™

EzSet/EQ •

AM loop antenna •

FM wire antenna •

Six • AAA batteries (AVR 3650/AVR 365); four AAA batteries (AVR 2650/AVR 265)

AC power cord •

microphone

IMPORTANT SAFETY INFORMATION

Verify Line Voltage Before Use

The AVR 3650 and AVR 2650 have been designed for use with 120-volt AC current. The AVR 365 and AVR 265 have been designed for use with 220 – 240-volt AC current. Connection to a line voltage other than that for which your receiver is intended can create a safety and ﬁre hazard and may damage the unit. If you have any questions about the voltage requirements for your speciﬁc model, or about the line voltage in your area, contact your selling dealer before plugging the unit into a wall outlet.

Do Not Use Extension Cords

To avoid safety hazards, use only the power cord supplied with your unit. We do not recommend that extension cords be used with this product. As with all electrical devices, do not run power cords under rugs or carpets, or place heavy objects on them. Damaged power cords should be replaced immediately by an authorized service center with a cord meeting factory speciﬁcations.

Handle the AC Power Cord Gently

When disconnecting the power cord from an AC outlet, always pull the plug; never pull the cord. If you do not intend to use your receiver for any considerable length of time, disconnect the plug from the AC outlet.

Do Not Open the Cabinet

There are no user-serviceable components inside this product. Opening the cabinet may present a shock hazard, and any modiﬁcation to the product will void your warranty. If water or any metal object such as a paper clip, wire or staple accidentally falls inside the unit, disconnect it from the AC power source immediately, and consult an authorized service center.

CATV or Antenna Grounding (AVR 3650/AVR 2650)

If an outside antenna or cable system is connected to this product, be certain that it is grounded so as to provide some protection against voltage surges and static charges. Section 810 of the United States National Electrical Code, ANSI/NFPA No. 70-1984, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes and requirements of the grounding electrode.

NOTE TO CATV SYSTEM INSTALLER: This reminder is provided to call the CATV (cable TV) system installer’s attention to article 820-40 of the NEC, which provides guidelines for proper grounding and, in particular, speciﬁes that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as possible.

ENGLISH

Place the Receiver

Place the receiver on a ﬁrm and level surface. Be certain that the surface and any • mounting hardware can support the AVR’s weight.

Provide proper space above and below the receiver for ventilation. If you install the • receiver in a cabinet or other enclosed area, provide cooling air within the cabinet. Under some circumstances, a fan may be required.

Do not obstruct the ventilation slots on the top of the receiver or place objects directly • over them.

Do not place the receiver directly on a carpeted surface. •

Do not place the receiver in moist or humid locations, in extremely hot or cold locations, • in areas near heaters or heat registers, or in direct sunlight.

AVR

Front-Panel Controls

Continued on next page

Front-Panel Controls

Power

Indicator

Power Button

USB Port

Setup

Button

Info

Button

Resolution

Button

Sensor

Video Modes Button

Message

Display

Back/Exit

Button

Up/Down

Buttons

Volume

Knob

Source List

Button

Front

HDMI

Input Connector

Audio Effects Button

Surround

Modes Button

Left/Right

Buttons

Headphone Jack/

EzSet/EQ Mic Input

AVR

Front-Panel Controls, continued

Power Indicator: This LED has three possible modes:

LED is off: Indicates that the AVR is unplugged or the rear-panel Main Power switch • is off.

LED glows amber: Indicates that the AVR is in the Standby mode. •

LED glows white: Indicates that the AVR is turned on. •

IMPORTANT NOTE: If the PROTECT message ever appears on the AVR’s frontpanel message display, turn off the AVR and unplug it from the AC outlet. Check all speaker wires for a possible short-circuit (the “+” and “–” conductors touching each other or both touching the same piece of metal). If a short-circuit is not found, bring the unit to an authorized Harman Kardon service center for inspection and repair before using it again.

Power button: Press this button to turn the receiver on or to place it in the Standby mode.

Setup button: Press this button to access the AVR’s main menu.

Info button: Press this button to access the AVR’s Source submenu, which contains

the settings for the source currently playing. Use the Up/Down buttons to scroll through the different settings.

Message display: Various messages appear in this two-line display in response to commands and changes in the incoming signal. In normal operation, the current source name appears on the upper line, while the surround mode is displayed on the lower line. When the on-screen display menu system (OSD) is in use, the current menu settings appear.

IR sensor: This sensor receives infrared (IR) commands from the remote control. It is important to ensure that the sensor is not blocked. AVR 3650/AVR 365 only: If covering the IR sensor is unavoidable (such as when the receiver is installed inside of a cabinet), connect an optional infrared receiver to the Remote IR In connector on the AVR’s rear panel.

Up/Down buttons: Use these buttons to navigate the AVR’s menus.

Volume knob: Turn this knob to raise or lower the volume.

USB port: You can use this port to perform software upgrades that may be offered in

the future. Do not connect a storage device, peripheral product or a PC here, unless you are instructed to do so as part of an upgrade procedure.

HDMI (High-Deﬁnition Multimedia Interface

an HDMI-capable source component that will be used only temporarily, such as a camcorder or game console, here.

) Front Input connector: Connect

Resolution button: Press this button to access the AVR’s video output resolution

setting: 480i, 480p, 720p, 1080i, 1080p or 1080p/24Hz. Use the Up/Down and OK buttons to change the setting.

IMPORTANT NOTE: If you set the AVR’s video output resolution higher than the capabilities of the actual connection between the AVR and your TV or video display, you will not see a picture. If you are using the composite video connection from the AVR to your TV (see page 17), press the Resolution button and use the Up/Down and OK buttons to change the resolution to 480i.

Audio Effects button: Press this button to access the Audio Effects submenu, which allows you to adjust the AVR’s tone controls and other audio controls. See

Up Your Sources

Video Modes button: Press this button for direct access to the Video Modes submenu, which contains settings you can use to improve the video picture. Use the OK button to scroll through the different modes, and use the Up/Down and Left/ Right buttons to make adjustments within each mode. See page 26, for more information.

Surround Modes button: Press this button to select a listening mode. The Surround Modes menu will appear on screen, and the menu line will appear in the front-panel display. Use the Up/Down buttons to change the surround-mode category and the Left/Right buttons to change the surround mode for that category. See

Sources

Back/Exit button: Press this button to return to the previous menu or to exit the menu system.

Left/Right buttons: Use these buttons to navigate the AVR’s menus.

OK button: Press this button to select the currently highlighted item.

Headphone jack/EzSet/EQ Mic input: Connect a 1/4" stereo headphone plug

to this jack for private listening. This jack is also used to connect the supplied microphone for the EzSet/EQ procedure described in

Speakers

Source List button: Press this button to select a source device to watch/listen to. Use the Up/Down buttons to scroll through the source-device list, and press the OK button to select the source being displayed.

, on page 26, for more information.

, on page 25.

Connect Your TV or Video Display

Set Up Your Sources

Set Up Your

Conﬁgure the AVR For Your

, on

Set

, on

ENGLISH

AVR

Rear-Panel Connectors

Rear-Panel Connectors (AVR 3650 shown)

Continued on next page

Rear-Panel Connectors

Analog

Record Out

Connector

HDMI

Monitor Out

Connector

Input Connectors

HDMI Input Connectors

Composite

Video Input

Connectors

Digital Audio

Composite Video Monitor Out Connector

Composite Video Record Out Connector

Composite Video Input Connectors

SIRIUS

Tuner Connector (AVR 3650/AVR 2650)

12V Trigger Connector

Zone 2 IR In Connector (AVR 3650/AVR 365)

The Bridge IIIP Connector

Radio Antenna

Connectors

Zone 2 Out

Connector

Analog Record Out connector: Connect this analog audio output to the analog audio input of a recording device. A signal is available at this output whenever an analog audio source is playing.

HDMI Monitor Out connector: If your TV has an HDMI connector, use an HDMI cable (not included) to connect it to the AVR’s HDMI Monitor Out connector. The AVR will automatically transcode component and composite video input signals to the HDMI format (upscaling to as high as 1080p), so you do not need to make any other connections to your TV from the AVR or from any of your video source devices.

Notes on using the HDMI Monitor Out connector:

When connecting a DVI-equipped display to the HDMI Monitor Out connector, • use an HDMI-to-DVI adapter and make a separate audio connection.

Make sure the HDMI-equipped display is HDCP (High-bandwidth Digital Content • Protection)-compliant. If it isn’t, do not connect it via an HDMI connection; use an analog video connection instead and make a separate audio connection.

Subwoofer

Connector

Input Connectors

Digital Output

Connector

Analog Audio

Optical

Speaker

Connectors

Network

Connector

Main Power

Switch

HDMI Input connectors: An HDMI connection transmits digital audio and video signals between devices. If your source devices have HDMI connectors, using them will provide the best possible video and audio performance quality. Since the HDMI cable carries both digital video and digital audio signals, you do not have to make any additional audio connections for devices you connect via the HDMI connection. See

Connect Your Audio and Video Source Devices

Composite Video Input connectors: Use composite video connectors for video source devices that don’t have HDMI or component video connectors. You will also need to make an audio connection from the source device to the AVR. See

Your Audio and Video Source Devices

Digital Audio Input connectors: If your non-HDMI source devices have digital outputs, connect them to the AVR’s digital audio connectors. NOTE: Make only one type of digital connection (HDMI, optical or coaxial) from each device. See

Your Audio and Video Source Devices

AC Input

Connector

RS-232

Connector

, on page 18, for more information.

IR Remote In/Out Connectors (AVR 3650/AVR 365)

, on page 18, for more information.

Vents

Connect

Fan

AVR

Rear-Panel Connectors, continued

Composite Video Monitor Out connector: If your TV or video display does not have an HDMI connector, use a composite video cable (not included) to connect the AVR’s Composite Video Monitor Out connector to your TV’s composite video input. NOTE: The HDMI connection to your TV is preferred. If you use the composite video connection to your TV, you will not be able to view the AVR’s on-screen menus.

Composite Video Record Out connector: Connect an analog video recorder’s video input connector to the AVR’s Composite Video Rec Out connector. You can record any composite video input signal. NOTE: To record the audio and video from the source device, connect the AVR’s Analog Record Output connectors to the analog video recorder’s audio inputs.

Component Video Input connectors: If any of your video source devices have component video connectors (and do not have HDMI connectors), using the component video connectors will provide superior video performance. You will also need to make an audio connection from the device to the receiver. See

Audio and Video Source Devices

SIRIUS

Tuner connector: Connect a SIRIUSConnect™ satellite radio tuner module

here. (Not included. Available at www.sirius.com.) See

Source Devices

12V Trigger connector: This connector provides 12V DC whenever the AVR is on. It can be used to turn on and off other devices such as a powered subwoofer.

Zone 2 IR Input connector (AVR 3650/AVR 365 only): Connect a remote IR receiver located in Zone 2 of a multizone system to this jack to control the AVR (and any source devices connected to the Remote IR Output connector) from the remote zone.

The Bridge IIIP connector: Connect an optional Harman Kardon The Bridge IIIP docking station to this input. Insert the plug until it snaps into place in the connector.

IMPORTANT: Connect The Bridge IIIP only with the AVR’s power turned off.

Radio Antenna connectors: Connect the included AM and FM antennas to their

respective terminals for radio reception.

Zone 2 Out connectors: Connect these jacks to an external ampliﬁer to power the speakers in the remote zone of a multizone system.

Subwoofer connector: Connect this jack to a powered subwoofer with a line-level input. See

Analog Audio Input connectors: Use the AVR’s Analog Audio Input connectors for source devices that don’t have HDMI or digital audio connectors. See

Audio and Video Source Devices

Optical Digital Output connector: Connect a digital audio recorder’s optical digital input to the AVR’s Optical Digital Output connector. You can record both coaxial and optical digital audio signals.

, on page 18, for more information.

Connect Your Subwoofer

, on page 18, for more information.

Connect Your Audio and Video

, on page 17, for more information.

, on page 18, for more information.

Connect Your

Speaker connectors: Use two-conductor speaker wire to connect each set of terminals to the correct speaker. See information.

NOTE: The speaker connectors, also called Assigned Amp speaker connectors- are used for the surround back channels in a 7.1- channel home theater, or you can reassign them to a remote room for multizone operation or to front height channels for Dolby Pro Logic® IIz operation. See 13, for more information.

Network connector: Use a Cat. 5 or Cat. 5E cable (not supplied) to connect the AVR’s Network connector to your home network to enjoy Internet radio and content from DLNA®-compatible devices that are connected to the network. See

Home Network

Main Power switch: This mechanical switch turns the AVR’s power supply on or off. It is usually left on, and it cannot be turned on or off using the remote control.

AC Input connector: After you have made all other connections, plug the supplied AC power cord into this receptacle and into an unswitched wall outlet.

RS-232 connector: This connector is used to connect to external control hardware. Consult a certiﬁed professional installer for more information.

IR Remote In/Out connectors (AVR 3650/AVR 365 only): When the IR sensor on the front panel is blocked (such as when the AVR is installed inside a cabinet), connect an optional IR receiver to the IR Remote In jack. The IR Remote Out jack may be connected to the IR input of a compatible product to enable remote control through the AVR.

Fan Vents: These vents are used by the AVR’s fan to cool the system. Maintain a clearance of at least three inches (75mm) from the nearest surface to avoid overheating the unit. It is normal for the fan to remain off at most normal volume levels. An automatic temperature sensor turns the fan on only when it is needed.

IMPORTANT NOTE: Never block the fan vents. Doing so could allow the AVR to overheat to dangerous levels.

, on page 20, for more information.

Connect Your Speakers

Place Your Speakers

, on page 17, for more

, on page

Connect to Your

ENGLISH

AVR

System Remote Control Functions

Continued on next page

System Remote Control Functions

IR Transmitter Lens

AVR Power On/Off

Buttons

Buttons (AVR 2650/AVR 265)

Buttons

Source Selector

(AVR 3650/AVR 365)

Audio Effects

Button

Video Modes

Button

Last Channel

Button

Back/Exit

Button

OK Button

Backlight Button

(AVR 3650/AVR 365 only)

Device Power On/Off Buttons

Surround Modes Button

Number Buttons

Activity Button

Menu Button

Up/Down/Left/Right Buttons

Disc Menu Button

A/B/C/D Buttons

Volume Up/Down

Buttons

Mute Button

Info Button

AVR Button

Zone Selector

Switch

Channel Up/Down and Page Buttons

Transport Control Buttons

Sleep Button

Learn Button

(AVR 3650/AVR 365 only)

AVR

System Remote Control Functions, continued

In addition to controlling the AVR, the AVR remote is capable of controlling eight other devices, including an iPod/iPhone device docked in a The Bridge IIIP docking station connected to the AVR. During the installation process, you may program the codes for each of your source components into the remote. (See

Your Source Devices and TV

a component, press its Source Selector button to change the remote’s control mode.

A button’s function depends on which component is being controlled. See Table A13 in the Appendix for listings of the functions for each type of component. Most of the buttons on the remote have dedicated functions, although the precise codes transmitted vary depending on the speciﬁc device being controlled. Due to the wide variety of functions for various source devices, we have included only a few of the most-often used functions on the remote: alphanumeric keys, transport controls, television-channel control, menu access and power on and off. Buttons dedicated to the AVR – AVR Power On/Off, Audio Effects, Video Modes, Surround Modes, Volume, Mute and Sleep Settings – are available at any time, even when the remote is controlling another device. To return the remote to the AVR control mode at any time, press the Setup button.

AVR Power On/Off buttons: Press these buttons to turn the AVR on and off. The Main Power switch on the AVR’s rear panel must be on for this button to work.

IR Transmitter Lens: As buttons are pressed on the remote, infrared codes are emitted through this lens.

Device Power On/Off buttons: Press a device’s Source Selector button, then press these buttons to turn the device on and off.

Source Selector buttons: Press one of these buttons to select a source device, e.g., Blu-ray, Cable/Sat, Radio, etc. This action will also turn on the AVR and switch the remote’s control mode to operate the selected source device. NOTE: The ﬁrst press of the Radio Source Selector button switches the AVR to the last-used tuner band (AM, FM or SIRIUS). Each successive press changes the band.

Audio Effects button: Press this button to access the Audio Effects submenu, which allows adjustment of the AVR’s tone and other audio controls. See the

Sources

section, on page 26, for more information.

Video Modes button: Press this button for direct access to the Video Modes submenu, which contains picture adjustments you can use after you have adjusted the picture settings on your TV or video display. See the on page 33, for more information.

Surround Modes button: Press this button to access the Surround Modes submenu. Select a surround-mode category: Auto Select, Virtual Surround, Stereo, Movie, Music or Game. When you select the category, it is highlighted and the surround mode changes.

To change the surround mode for the selected category, press the OK button when the menu line is highlighted and use the Up/Down buttons to select one of the available surround-mode options. Press the OK button; or press the Back/Exit button to exit the Surround Modes menu and display the next higher menu in the hierarchy. See the

Advanced Functions

Number buttons: Use these buttons to enter numbers for radio-station frequencies or to select station presets.

Last Channel button: When controlling a cable, satellite or HDTV set-top box or a TV, press this button to return to the previous television channel.

Activity button: With this button you can program the remote to store up to 11 different Macros (Activities). (A Macro is a series of commands that are transmitted by a single button press.) Execute a Macro by pressing this button, followed by the Number button (or the AVR Power On button) into which you programmed the Macro. See

Programming Macro (Activity) Commands

, on page 23, for programming information.) To operate

section, on page 33, for more information.

, on page 41, for more information.

Program the Remote to Control

Set Up Your

Advanced Functions

section,

Back/Exit button: Press this button to return to the previous menu or to exit the menu system.

Menu button: This button is used within the tuner menus (including SIRIUS Radio) and The Bridge IIIP control menu, and is also used to display the main menu on some source devices. To display the AVR’s menu system, press the Setup button.

Up/Down/Left/Right buttons: These buttons are used to navigate the menu system and to operate the tuner.

OK button: This button is used to select items from the menu system.

Backlight button (AVR 3650/AVR 365 only): Press this button to illuminate the

buttons on the remote. Press it again to turn the backlight off, or wait 5 seconds after the last button press for the light to turn off on its own.

Disc Menu button: To display the disc’s menu while a DVD or Blu-ray Disc is playing, press the Blu-ray Source Selector button, then press this button.

A/B/C/D buttons: These buttons can be used as additional source buttons and can also operate certain functions when used with some source devices. See Table A13 in the Appendix for details. These buttons are also used with a Teletext television if your broadcast, cable or satellite provider offers Teletext service.

Volume Up/Down buttons: Press these buttons to raise or lower the volume.

Channel Up/Down and Page buttons: When the tuner has been selected, press

these buttons to select a preset radio station. While operating a cable, satellite or HDTV set-top box or a television, press these buttons to change channels.

Mute button: Press this button to mute the AVR’s speaker-output connectors and headphone jack. To restore the sound, press this button or adjust the volume.

Transport Control buttons: These buttons are used to control source devices and The Bridge IIIP.

Info button: Press to display the AVR’s Info Menu, which contains the settings for the current source.

Setup button: Press to display the AVR’s Main Menu or to switch the remote to the AVR control mode.

Sleep button: Press this button to activate the sleep timer, which turns off the receiver after a programmed period of time. Each press increases the time by 10 minutes, up to 90 minutes – ending with the “Sleep Off” message.

Learn button (AVR 3650/AVR 365 only): The AVR 3650/AVR 365 remote is capable of “learning” individual IR codes from the original remote that came with a source device. See for more information.

Zone Selector switch: Use this switch to select whether the AVR commands will affect the main listening area (Zone 1) or the remote zone of a multizone system (Zone 2). For normal operation, leave the switch in the Zone 1 position.

Program the Remote to Control Your Source Devices and TV

-capable

, on page 23,

ENGLISH

AVR

Zone 2 Remote Control Functions (AVR 3650/AVR 365 only)

Continued on next page

Zone 2 Remote Control Functions (AVR 3650/AVR 365 only)

IR Transmitter

Lens

Power Of f

Button

Source Selector

Buttons

AVR Button

Back/Exit

Button

OK Button

Zone Selector

Button

Mute Button

Sleep Button

Menu Button

Up/Down/Left/Right Buttons

Volume Up/Down Buttons

Transport Control Buttons

Zone Indicator Light

AVR

Zone 2 Remote Control Functions (AVR 3650/AVR 365 only), continued

By installing an IR receiver in the remote zone of a multizone system and connecting it to the AVR’s Zone 2 IR Input connector, you can use the Zone 2 remote to control the sound in the remote zone from within the remote zone. You can use it to control the AVR’s power, volume and mute functions or to select a source input for the remote zone, and to control a Harman Kardon source device connected to one of the AVR’s Remote IR Out connectors. See more information.

You can also use the Zone 2 remote in the main listening room to control the AVR and Harman Kardon Blu-ray Disc is in the Zone 1 control mode (the remote’s Zone Indicator light will turn green), its power, volume and mute controls will affect only the main listening area. To restore operation to the remote zone, press the remote’s Zone Selector button so that its Zone Indicator light turns red.

IR Transmitter lens: As buttons are pressed on the remote, infrared codes are emitted through this lens.

Power Off button: Press this button to turn the AVR off.

Mute button: Press to mute the AVR’s remote-zone speakers. To restore the sound,

press this button, adjust the volume or turn off the multizone system. Make sure to switch the remote to Zone 2 mode so that only the remote zone will be affected.

Source Selector buttons: With the remote in Zone 2 mode, press one of these buttons to select a source device for the remote zone. Pressing the button will also turn on the multizone system and switch the remote to the selected source device’s control mode. You may select a different external source device than that for the main room, but not different tuner bands. If you select the same source as that for the main room, any commands sent to the source device will affect both zones. The ﬁrst press of the Radio Source Selector button switches the AVR to the last-used tuner band (AM, FM or SIRIUS). Each successive press changes the band.

AVR button: Press this button to turn on the AVR and select the last-used source. This button is also used to switch the remote control to AVR control mode.

™

, DVD, CD or tape players. When the Zone 2 remote

Connect IR Equipment

, on page 22, for

Back/Exit button: Press this button to return to the previous menu or to exit the menu system.

Up/Down/Left/Right buttons: These buttons are used to navigate the menu system and to operate the tuner.

OK button: This button is used to select items from the menu system.

Volume Up/Down buttons: Press to raise or lower the volume level in the remote

zone.

Transport Control buttons: These buttons are used to control source devices and The Bridge IIIP.

Zone Selector button and Zone Indicator light: Each press of the Zone Selector button determines whether the AVR commands will affect the main listening area (Zone 1) or the remote zone (Zone 2). The Zone Indicator light will turn green when Zone 1 has been selected, and red when Zone 2 has been selected. The Zone Indicator light will also light up brieﬂy when any button is pressed.

ENGLISH

AVR

Introduction to Home Theater

This introductory section will help you to familiarize yourself with some basic concepts unique to multichannel surround-sound receivers, which will make it easier for you to set up and operate your AVR.

Typical Home Theater System

A home theater typically includes an audio/video receiver, which controls the system and supplies ampliﬁcation for the loudspeakers; a disc player; a source component for television broadcasts (cable box, satellite dish receiver, HDTV tuner or antenna connected to the TV); a TV or video display; and multiple loudspeakers.

Multichannel Audio

The main beneﬁt of a home theater system is its ability to produce “surround sound.” Surround sound uses multiple speakers and ampliﬁer channels to immerse you in the audio/video presentation for a dramatically increased sense of realism.

Your AVR may have up to seven main speakers connected directly to it, plus a subwoofer. Each main speaker is powered by its own ampliﬁer channel inside the AVR. A system with more than two speakers is called a multichannel system. The different main speaker types in a home theater system are:

Front Left and Right: • The front left and right speakers are used as in a two-channel system. In many surround-sound modes, these speakers are secondary, while the main action, especially dialogue, is reproduced by the center speaker.

Center: • When you are watching movies and television programs, the center speaker reproduces most of the dialogue and other soundtrack information, anchoring it with the picture. When you are listening to a musical program, the center speaker helps to create a seamless front soundstage, creating a realistic “you-are-there” listening experience.

Surround Left and Right: • The surround left and right speakers produce ambient sounds that help create a realistic and immersive surround-sound environment. They also help recreate directional sound effects such as aircraft ﬂyovers.

Surround Back Left and Right: • Surround back channel speakers are used with surround modes such as the Dolby Digital EX, Dolby Digital Plus, Dolby TrueHD, DTS-ES DTS-HD Master Audio™ and Logic 7® 7.1 modes that are designed for 7.1-channel systems.

The surround back channel speakers are optional. If your system does not include surround back left and right speakers, you can set up your AVR with a 5.1-channel surround-sound system in the main listening area, and you can reassign the surround back channel ampliﬁers to power loudspeakers located in another room in a multizone system. (Alternately, you can reassign the surround back channel ampliﬁers to power front height speakers for use with Dolby Pro Logic IIz. See page 36, for more information.)

Many people expect the surround speakers to play as loudly as the front speakers. Although you will calibrate all of the speakers in your system to sound equally loud at the listening position, most artists use the surround speakers for ambient effects only, and they create their programs to steer relatively little sound to these speakers.

Subwoofer: • A subwoofer is designed to play only the lowest frequencies (the deep bass). It augments smaller, limited-range main speakers that are usually used for the other channels. Many digital-format programs, such as movies recorded in Dolby Digital, contain a low-frequency effects (LFE) channel that is directed to the subwoofer. The LFE channel packs the punch of a rumbling train or airplane, or the power of an explosion, adding realism and excitement to your home theater. Some people use two subwoofers for additional power and for even distribution of the sound.

(Discrete and Matrix), DTS-HD™ High Resolution Audio,

Manual Speaker Setup

, on

Surround Modes

There are different theories as to the best way to present surround sound and to distribute each audio channel’s sounds to the surround-sound system’s speakers. A variety of algorithms have been developed in an effort to recreate the way we hear sounds in the real world, resulting in a rich variety of options. Several companies have developed different surround-sound technologies, all of which can be accurately reproduced by your AVR:

Dolby Laboratories: • Dolby TrueHD, Dolby Digital Plus, Dolby Digital, Dolby Digital EX, Dolby Pro Logic

DTS: • DTS-HD High Resolution Audio, DTS-HD Master Audio, DTS, DTS-ES (Discrete and Matrix), DTS Neo:6

HARMAN International: • Logic 7

Stereo Modes: • Generic modes that expand upon conventional two-channel stereo,

including 5CH and 7CH Stereo.

Appendix Table A12, on page 50, contains detailed explanations of the different surround-sound options available on your AVR. Digital surround-sound modes, such as the Dolby Digital and DTS modes, are available only on specially encoded programs, such as those available via HDTV, DVD and Blu-ray Disc media and digital cable or satellite television. Other surround modes may be used with digital and analog signals to create a different surround presentation or to use a different number of speakers. Surround-mode selection depends upon the number of speakers in your system, the program you are watching or listening to, and your personal tastes.

IIx and IIz.

, DTS 96/24™.

, HARMAN virtual speaker, HARMAN headphone.

AVR

Place Your Speakers

Determine the locations for your system’s speakers according to their manufacturer’s directions and the layout of your listening room. Use the illustrations below as a guide for

7.1-channel and 5.1-channel systems.

To create the most realistic surround-sound environment possible, you should place your speakers in a circle with the listening position at its center. You should angle each speaker so it directly faces the listening position. Use the diagrams below as a guide.

FL FR

SL SR

Speaker Positioning for 5.1-Channel Systems

FL FR

SL SR

SUB

NOTE: In a 7.1-channel system, you must choose to use either surround back speakers or front height speakers – you cannot use both simultaneously.

Placing the Left, Center and Right Speakers

Place the center speaker either on top of, below or mounted on the wall above or below the TV or video display screen. Place the front left and right speakers along the circle, about 30 degrees from the center speaker and angled toward the listener.

Place the front left, front right and center speakers at the same height, preferably at about the same height as the listener’s ears. The center speaker should be no more than 2 feet (0.6m) above or below the left/right speakers. If you’re using only two speakers with your AVR, place them in the front left and right positions.

Placing the Surround Speakers in a 5.1-Channel System

You should place the left and right surround speakers approximately 110 degrees from the center speaker, slightly behind and angled toward the listener. Alternatively, place them behind the listener, with each surround speaker facing the opposite-side front speaker. You should place the surround speakers 2 feet – 6 feet (0.6m – 1.8m) higher than the listener’s ears.

Placing the Surround Speakers in a 7.1-Channel System

In a 7.1-channel system, place the side surround speakers 90 degrees from the center speaker, directly to either side of the listening position. Place the surround back left and right speakers 150 degrees from the center speaker, directly facing the opposite-side front speaker. You should place all the surround speakers 2 feet – 6 feet (0.6m – 1.8m) higher than the listener’s ears.

Placing Front Height Speakers in a 7.1-Channel System

Your AVR includes Dolby Pro Logic IIz decoding, which uses the AVR’s Assigned Amp channels as front height channels. The addition of front height channels – an additional pair of speakers positioned above the front left and right speakers – produces a surroundsound experience with added depth and dimension by creating lifelike sound that comes at you from varying heights.

We recommend placing front height speakers at least 3 feet (0.9m) higher than the front left and front right speakers, and directly above or farther apart than the front left and right speakers. The higher and further apart you place the front height speakers, the more you should angle them down and in toward the listening position.

ENGLISH

SBL SBR

FHL* FHR*

* FHL and FHR speakers should be at least

(Top: with Surround Back Speakers; Bottom: with Front Height Speakers)

FL FR

SL SR

3 ft (0.9m) above the FL and FR speakers.

Speaker Positioning for 7.1-Channel Systems

SUB

NOTE: Your receiver will sound its best when the same model or brand of loudspeaker is used for all positions.

Placing the Subwoofer

Because a room’s shape and volume can have a dramatic effect on a subwoofer’s performance, it is best to experiment with placement so that you will ﬁnd the location that produces the best results in your particular listening room. With that in mind, these rules will help you get started:

Placing the subwoofer next to a wall generally will increase the amount of bass in the • room.

Placing the subwoofer in a corner generally will maximize the amount of bass in the • room.

In many rooms, placing the subwoofer along the same plane as the left and right • speakers can produce the best integration between the sound of the subwoofer and that of the left and right speakers.

In some rooms, the best performance could even result from placing the subwoofer • behind the listening position.

A good way to determine the best location for the subwoofer is by temporarily placing it in the listening position and playing music with strong bass content. Move around to various locations in the room while the system is playing (putting your ears where the subwoofer would be placed), and listen until you ﬁnd the location where the bass performance is best. Place the subwoofer in that location.

AVR

Types of Home Theater System Connections

There are different types of audio and video connections used to connect the AVR to your speakers, your TV or video display, and your source devices. The Consumer Electronics Association has established the CEA® color-coding standard.

Analog Audio Connection Color

Front Left/Right White/Red

Center Green

Surround Left/Right Blue/Gray

Surround Back/Front Height Left/Right Brown/Tan

Subwoofer Purple

Digital Audio Connection Color

Coaxial (input or output) Orange

Optical Input Black

Optical Record Output Gray

Analog Video Connection Color

Component Video Red/Green/Blue

Composite Video Yellow

Speaker Connections

Speaker cables carry an ampliﬁed signal from the AVR’s speaker terminals to each loudspeaker. They contain two wire conductors, or leads, that are differentiated in some way, such as with colors or stripes.

The differentiation helps you maintain proper polarity, without which your system’s lowfrequency performance can suffer. Each speaker is connected to the AVR’s speakeroutput terminals using two wires, one positive (+) and one negative (–). Always connect the positive terminal on the speaker, which is usually colored red, to the positive terminal on the receiver, which is colored as indicated in the Connection Color Guide Table, above. The negative terminals on the speakers and the AVR are black.

Your AVR uses binding-post speaker terminals that can accept bare-wire cables or banana plugs. Bare-wire cables are installed as shown below:

1. Unscrew Cap 3. Tighten Cap2. Insert Bare Wire

Banana plugs are inserted into the hole in the middle of the terminal cap, as shown below:

A. Tighten Cap B. Insert Banana Connector

into Hole in Cap

Subwoofer Connections

The subwoofer is a speaker dedicated to reproducing only the low (bass) frequencies, which require more power. To obtain the best results, most speaker manufacturers offer powered subwoofers that contain their own ampliﬁers. Use a single RCA audio cable to make a line-level (non-ampliﬁed) connection from the AVR’s Subwoofer connector to a corresponding input jack on the subwoofer.

Although the AVR’s purple subwoofer output looks similar to a full-range analog audio jack, it is ﬁltered so that only the low frequencies pass through it. Don’t connect this output to any device other than a subwoofer.

Source Device Connections

Audio and video signals originate in source devices (components where a playback signal originates) such as your Blu-ray Disc or DVD player, CD player, DVR (digital video recorder) or other recorder, tape deck, game console, cable or satellite television tuner, an iPod or iPhone (docked in an optional The Bridge IIIP docking station) or an MP3 player. The AVR’s FM/AM tuner also counts as a source, even though no external connections are needed other than the FM and AM antennas and an optional SIRIUS tuner module. Separate connections are required for the audio and video portions of the source device’s signal, except for digital HDMI connections. The types of connections you use will depend upon the capabilities of the source device and of your TV or video display.

Digital Audio Connections – HDMI

There are two types of audio connections – digital and analog. Digital audio signals are required for listening to sources encoded with digital surround modes, such as Dolby Digital and DTS, or for uncompressed PCM digital audio. Your AVR has three types of digital audio connections: HDMI, coaxial and optical. Do not use more than one type of digital audio connection for each source device. However, it’s okay to make both analog and digital audio connections to the same source.

Your AVR is equipped with ﬁve rear-panel HDMI input connectors, and one HDMI monitor output connector. (The AVR 3650 and AVR 365 also have a front-panel HDMI input connector.) HDMI technology enables digital audio and video information to be carried using a single cable, delivering the highest quality picture and sound. If your TV or video display device has an HDMI input connector, make a single HDMI connection from each source device to the AVR. Usually, a separate digital audio connection is not required.

The AVR’s HDMI monitor output connection contains an Audio Return Channel (ARC) that carries a digital audio signal from your TV or video display back to the AVR. It allows you to listen to HDMI devices that are connected directly to your TV (such as an Internet connection) without making an additional connection from the device to the AVR. The ARC signal is active when the TV source is selected. See for more information.

The HDMI connector is shaped for easy plug-in (see illustration, below), and HDMI cable runs are limited to about 10 feet (3m). If your video display has a DVI input and is HDCP-compliant, use an HDMI-to-DVI adapter (not included), and make a separate audio connection.

System Settings

, on page 39,

Always connect the colored (+) terminal on the AVR to the (+) terminal on the speaker (usually red), and the black (–) terminal on the AVR to the (–) terminal on the speaker (usually black).

IMPORTANT: Make sure the ( + ) and ( – ) bare wires do not touch each other or the other terminal. Touching wires can cause a short circuit that can damage your receiver or ampliﬁer.

AVR

Types of Home Theater System Connections

Digital Audio Connections – Coaxial

Coaxial digital audio jacks are usually color-coded in orange. Although they look like standard RCA-type analog jacks, you should not connect coaxial digital audio outputs to analog inputs or vice versa.

Digital Audio Connections – Optical

Optical digital audio connectors are normally covered by a shutter to protect them from dust. The shutter opens as the cable is inserted. Optical input connectors are colorcoded using a black shutter, while optical outputs use a gray shutter.

Analog Audio Connections

Two-channel analog connections require a stereo audio cable, with one connector for the left channel (white) and one for the right channel (red). These two connectors are attached to each other.

Video Connections

Many source devices output both audio and video signals (e.g., Blu-ray Disc, DVD player, cable television box, HDTV tuner, satellite box, VCR, DVR). In addition to an audio connection as described above, make a video connection for each of these source devices. Make only one type of video connection for each device.

Digital Video Connections

If you have already connected a source device to one of the AVR’s HDMI input connectors, you have automatically made a video connection for that device, since the HDMI cable carries both digital audio and digital video signals.

Analog Video Connections – Composite Video

Your AVR uses two types of analog video connections: composite video and component video.

Composite video is the basic connection most commonly available. Both the chrominance (color) and luminance (intensity) components of the video signal are transmitted using a single cable. The jack is usually color-coded yellow and looks like an analog audio jack. Do not connect a composite video jack to an analog audio or coaxial digital audio jack, or vice versa.

Analog Video Connections – Component Video

Component video separates the video signal into three components – one luminance (“Y”) and two sub-sampled color signals (“Pb” and “Pr”) – that are transmitted using three separate cables that are color-coded green (Y), blue (Pb) and red (Pr). Component video cables that join three separate green, blue and red connectors into a single cable are sold separately.

ENGLISH

For source devices that have both digital and analog audio outputs, you may make both connections. If you are going to be setting up a multizone system, remember that Zone 2 is an audio-only zone (the AVR does not have a Zone 2 video output). Therefore, make analog connections for any audio source devices (such as a CD changer) that you will want available for listening in Zone 2 at all times.

The analog connections also feed the analog record outputs. You may record materials from Blu-ray Disc recordings, DVDs or other copy-protected sources using only analog connections. Remember to comply with all copyright laws if you choose to make a copy for your own personal use.

The Bridge IIIP Connection

Your AVR includes a proprietary, dedicated connector for an optional The Bridge IIIP docking station for the iPod or iPhone. The Bridge IIIP outputs analog audio to the AVR and is available as a source to Zone 2 in a multizone system.

If your TV or video display has an HDMI connection, we recommend it as the best quality connection. Your AVR converts composite and component analog video input signals to the HDMI format, upscaling them to high-deﬁnition 1080p resolution.

AVR

Types of Home Theater System Connections

Radio Connections

Your AVR uses separate terminals for the included FM and AM antennas. The FM antenna uses a 75-ohm F-connector.

The AM antenna connector uses spring-clip terminals. After assembling the antenna as shown below, press the levers to open the connectors, insert the bare wires into the openings, and release the levers to secure the wires. The antenna wires are not polarized, so you can insert either wire into either connector.

SIRIUS Satellite Radio

To enjoy SIRIUS satellite radio, purchase a SIRIUSConnect tuner module and a subscription to the SIRIUS service. Visit www.sirius.com for information on SIRIUSConnect tuner modules. The SiriusConnect modules include an eight-pin DIN cable for connection to the eight-pin jack on the AVR, allowing you to control the tuner module via the AVR. Although you may also use a “plug-and-play” tuner module equipped with standard audio connections, you will not be able to use the AVR to control the SIRIUS tuner.

USB Port

The USB port on your AVR is used for ﬁrmware upgrades. If an upgrade for the AVR’s operating system is released in the future, you will be able to download it to the AVR using this port. Complete instructions will be provided at that time.

In addition to performing ﬁrmware upgrades, the AVR 3650/AVR 365 can play MP3 and WMA audio ﬁles from a USB device inserted into the USB port. Insert the device into the USB port with the device’s plug oriented so it ﬁts all the way into the port. You may insert or remove the device at any time – there is no installation or ejection procedure.

IMPORTANT: Do not connect a PC or other USB host/controller to the AVR’s USB port, or you may damage both the AVR and the other device.

RS-232 Connector

Your AVR’s RS-232 serial port may be connected to an external control system to allow it to transmit control commands to the AVR. The port is bidirectional so that the AVR can transmit status updates to the control device. Connecting and using the RS-232 port requires considerable technical knowledge and is best left to a professional custom installer.

Network Connector

The AVR’s Network connector allows you to enjoy Internet radio or content from other DLNA-compatible devices that are connected to the same network. Use a Cat. 5 or Cat. 5E cable to connect the AVR’s RJ-45 connector to your home network.

AVR

VR Subwoofer

Connector

Powered

Subwoofer

Single RCA Audio Cable (not supplied)

Making Connections

CAUTION: Before making any connections to the audio/video receiver, ensure that the AVR’s AC cord is unplugged from the receiver and the AC outlet. Making connections with the receiver plugged in and turned on could damage the speakers.

Connect Your Speakers

After you have placed your loudspeakers in the room as explained in on page 13, connect each speaker to its color-coded terminal on the AVR as explained in

Speaker Connections

, on page 14. Connect the speakers as shown in the illustration.

Place Your Speakers

Connect Your Subwoofer

Use a single RCA audio cable to connect the AVR’s Subwoofer connector to your subwoofer as explained in user manual for speciﬁc information about making connections to it.

AVR Subwoofer

Connector

Subwoofer Connections

Single RCA Audio Cable (not supplied)

, on page 14. Consult your subwoofer’s

Powered

Subwoofer

Connect Your TV or Video Display

If your TV has an HDMI connector: Use an HDMI cable (not included) to connect it to the AVR’s HDMI Monitor Out connector. You do not need to make any other connections to your TV from the receiver or from any of your video source components.

Receiver

HDMI Monitor Out

Connector

ENGLISH

NOTE: If you installed front height speakers, connect them as shown for the SBL and SBR speakers.

HDMI Cable

(not supplied)

If your TV does not have an HDMI connector: Use a composite video cable (not included) to connect the AVR’s Composite Monitor Out connector to your TV’s composite video connector.

Receiver

Composite

Monitor Out

Connector

Composite

Video Cable

(not supplied)

NOTE: The HDMI connection to your TV is preferred. If you use the composite video connection to your TV, you will not be able to view the AVR’s on-screen menus.

AVR

Making Connections

Connect Your Audio and Video Source Devices

Your receiver has several different types of input connectors for your audio and video source devices: HDMI, component video, composite video, optical digital audio, coaxial digital audio and analog audio. The connectors are not labeled for speciﬁc types of source devices; they are labeled numerically, so you can connect your devices according to your individual system’s makeup.

Your AVR’s various source buttons have default assignments to different input connectors (listed in the “Default Source Button” column of the table below). For ease of setup, you should connect each source device to the connector where the corresponding default

AVR Input Connector Connected Component

HDMI 1 Blu-ray Blu-ray/TV

HDMI 2 Cable/Sat Cable/Sat

HDMI 3 Game Game

HDMI 4 Media Server Media Server

HDMI 5 TV DVR

(AVR 3650/AVR 365 only) HDMI Front Aux – –

Component Video 1 A (red) A (red)

Component Video 2 B (green) B (green)

Composite Video 1 C (yellow) C (yellow)

Composite Video 2 D (blue) D (blue)

source button is assigned (e.g., connect your Blu-ray Disc player to HDMI 1). However, you can connect your source devices as you wish and re-assign any of the source buttons to any of the input connectors listed in the table according to where you actually connect each of your source devices.

As you connect your various source components, ﬁll out the “Connected Component” column in the table – it will make it easier for you to assign the various source buttons after you have completed making all of the connections. (You will make any changes to the source-button assignments and ﬁll in the “Assigned Source Button” column later in the setup process.)

Default Source Button

AVR 3650/AVR 365 AVR 2650/AVR 265

Assigned

Source Button

Optical Digital Audio 1 A (red) A (red)

Optical Digital Audio 2 B (green) B (green)

Coaxial Digital Audio Input 1 C (yellow) C (yellow)

Coaxial Digital Audio Input 2

Analog Audio In 1 D (blue) D (blue)

Analog Audio In 2 Aux

Analog Audio In 3

Monitor Output Connector Connected Component

HDMI Monitor Out — — — — — — — —

Composite Video Monitor Out — — — — — — — —

Record Output Connector Connected Component

Composite Video Rec Out — — — — — — — —

Optical Digital Audio Out — — — — — — — —

Input Connections and Assigned Source Buttons

— — — — — — — —

AVR

Making Connections

Connect Your HDMI Devices

If any of your source devices have HDMI connectors, using them will provide the best possible video and audio performance quality. Since the HDMI cable carries both digital video and digital audio signals, you do not have to make any additional audio connections for devices you connect via an HDMI cable.

Receiver

HDMI Connectors

HDMI Cable (not supplied)

To HDMI Output

HDMI-Equipped

Source Device

NOTE: If you have HDMI devices (such as an Internet connection) already connected directly to your TV, you can feed their sound to the AVR via the HDMI Monitor Out connector’s Audio Return Channel, and they will not require additional connections to the AVR.

Connect Your Component Video Devices

If any of your video source devices have component video connectors (and do not have HDMI connectors), using the component video connectors will provide superior video performance. You will also need to make an audio connection from the device to the receiver.

Connect Your Optical Digital Video Devices

If your non-HDMI source devices have optical digital outputs, connect them to the AVR’s optical digital audio connectors. NOTE: Make only one type of digital connection (HDMI, optical or coaxial) from each device.

Receiver

Digital Audio Connectors

Optical Digital Audio Cable (not supplied)

To Optical Digital Audio Output

Optical Digital-Equipped

Source Device

Connect Your Coaxial Digital Audio Devices

If your non-HDMI source devices have coaxial digital outputs, connect them to the AVR’s coaxial digital audio connectors. NOTE: Make only one type of digital connection (HDMI, optical or coaxial) from each device.

Receiver

Digital Audio Connectors

ENGLISH

Receiver

Video Connectors

Component Video Cable (not supplied)

To Component Video Outputs

Component Video-Equipped

Source Device

Connect Your Composite Video Devices

Use composite video connectors for video source devices that don’t have HDMI or component video connectors. You will also need to make an audio connection from the source device to the receiver.

Receiver

Video Connectors

Composite Video Cable (not supplied)

To Composite Video Output

Coaxial Digital Audio Cable (not supplied)

To Coaxial Digital Audio Output

Coaxial Digital-Equipped

Source Device

Connect Your Analog Audio Devices

Use the AVR’s analog audio connectors for source devices that don’t have HDMI or digital audio connectors. NOTE: If you’re installing a multizone system, make analog audio connections for any source devices you want to be able to listen to in Zone 2. Only analog sources are available in Zone 2.

Receiver

Analog Audio Connectors

Stereo Audio Cable

(not supplied)

To Stereo Analog Audio Output

Composite Video-Equipped

Source Device

Analog Source Device

AVR

Making Connections

Connect Your Audio Recorders

Connect a digital audio recorder’s optical digital input to the AVR’s optical digital output. You can record both coaxial and optical digital audio input signals.

Digital Audio Recorder Connector

Connect an analog audio recorder’s inputs to the AVR’s analog audio Rec Out connectors. You can record any analog audio input signal.

Analog Audio Recorder Connectors

Receiver

Optical Digital Audio Cable (not supplied)

To Optical Digital Record Input

Digital

Recording Device

Connect The Bridge IIIP

Connect an optional The Bridge IIIP to the AVR’s The Bridge IIIP connector. Insert the plug until it snaps into place in the connector. IMPORTANT: Connect The Bridge IIIP only

with the AVR’s power turned OFF.

AVR The Bridge IIIP Connector

The Bridge IIIP

Dock your iPod or iPhone (not included) in The Bridge IIIP, and you may listen to its audio through your high-performance audio/video system. You may also view still images or video materials stored on a photo- or video-capable iPod or iPhone that supports video browsing. You can use the AVR remote to control the iPod, with navigation messages displayed on the AVR’s front panel and on a video display connected to the AVR.

Connect to Your Home Network

Use a Cat. 5 or Cat. 5E cable (not supplied) to connect the AVR’s Network connector to your home network to enjoy Internet radio and content from DLNA-compatible devices that are connected to the network.

Stereo Audio Cable (not supplied)

To Stereo Analog Record Inputs

Analog

Recording Device

Connect Your Video Recorder

Connect an analog video recorder’s video input connector to the AVR’s Composite Video Rec Out connector. You can record any composite video signal. NOTE: To record the audio and video from the source device, connect the AVR’s analog audio Rec Out connectors to the analog video recorder’s audio inputs.

Receiver Analog Video

Recorder Connectors

Receiver Analog Audio

Recorder Connectors

Analog Audio/Video Cable (not supplied)

To Analog Audio/Video Record Inputs

Analog Video

Recording Device

Receiver Network

Connector

Cat. 5/5E Cable (not supplied)

Network

Modem

Internet

and LAN

Connect the Radio Antennas

Connect the supplied FM antenna to the AVR’s FM 75 • Ω antenna connector. For the best reception, extend the FM antenna as far as possible.

Bend and fold the base of the supplied AM antenna as shown and connect the antenna • wires to the AVR’s AM and Gnd connectors. (You can connect either wire to either connector.) Rotate the antenna as necessary to minimize background noise.

AVR

Antenna

Connectors

FM Antenna (supplied)

AM Antenna

(supplied)

Bend and fold base

AVR

Making Connections

Connect a SIRIUSConnect Radio Tuner (AVR 3650 and AVR 2650 only)

Connect the multi-pin DIN cable supplied with the SIRIUSConnect tuner to the AVR’s SIRIUS Tuner connector and to the corresponding connector on the SIRIUS module. The AVR will supply power to the SIRIUS module so you will not need to connect the power supply included with the module. You will need to purchase a SIRIUS radio subscription and activate the tuner module, following the instructions included with the SIRIUS module and from the SIRIUS Web site at www.sirius.com.

AVR

SIRIUS Tuner

Connector

SIRIUSConnect Tuner

Eight-Pin DIN Cable (supplied with SIRIUS tuner)

Install a Multizone System

IMPORTANT SAFETY NOTE: Installing a multizone system typically requires running cables inside walls. Always comply with the appropriate safety codes when installing concealed wiring, particularly all applicable building codes. Failure to do so may present a safety hazard. If you have any doubt about your ability to work with electrical wiring, hire a licensed electrician or custom installer to install the multizone system.

NOTE: Only the following analog audio sources are available to Zone 2: the internal radio

(FM, AM and SIRIUS, if connected – AVR 3650/AVR 2650 only), an iPod/iPhone device docked in a connected The Bridge IIIP, a USB memory device inserted in the AVR’s USB port (AVR 3650/AVR 365 only) and up to three source devices connected to the rear-panel Analog Audio 1, 2 and 3 connectors.

Your AVR offers two different methods of distributing audio to other areas in your home. Each requires different connections:

A. Connect the Zone 2 speakers directly to the Assigned Amp Speaker Output connectors. Assign the Assigned Amp channels to power the Zone 2 speakers (see

Manual Speaker Setup

speakers for Zone 2.

This method offers the beneﬁt of reduced cost and complexity, but your home theater system will be limited to 5.1 channels – the AVR will automatically downmix the playback of programs recorded in 6.1 or 7.1 channels to 5.1 channels.

, on page 36). This method allows you to power a single pair of

Zone 2

Speakers

ENGLISH

Speaker Wire

(not supplied)

AVR

Assigned

Amp

Speaker

Connectors

5.1-Channel

Home Theater

Speaker System

Zone 2

Main Room

Speaker Wire (not supplied)

FR LFE

SL SR

AVR

Making Connections

B. Connect an external ampliﬁer to the AVR’s Zone 2 Out connectors. This method offers the beneﬁt of retaining a 7.1-channel home theater in the main room simultaneously with multizone operation, although it does require an additional component (the Zone 2 ampliﬁer).

We recommend that you place the Zone 2 ampliﬁer in the same room as the AVR so that you can use a short length of stereo audio cable along with a long run of speaker wire to the remote room. A long run of stereo audio cable would increase the chance of signal degradation. Depending on your ampliﬁer, distribute the audio signal to a single pair of speakers or to several pairs placed in different rooms.

Zone 2

Speakers

Zone 2

Main Room

Speaker Wire

(not supplied)

Speaker Wire (not supplied)

Stereo Audio Cable

(not supplied)

Connect IR Equipment (AVR 3650/AVR 365 only)

The AVR 3650/AVR 365 is equipped with Remote IR Input and Output connectors and a Zone 2 IR Input connector that let you remotely control the AVR in a variety of situations:

When you place the AVR inside a cabinet or facing away from the listener, connect • an external IR receiver, such as the optional Harman Kardon HE 1000, to the AVR’s IR Remote In jack.

AVR

IR Remote

In Jack

External IR

Receiver

AVR and Source Devices Installed Inside of Cabinet

Zone 2 Ampliﬁer

(not supplied)

AVR

SL SR

7.1-Channel

Home Theater

Speaker System

SBL SBR

FR LFE

If any source devices are equipped with a compatible IR input, use a 1/8-inch (3.5mm) • mini-plug interconnect cable (not included) to connect the AVR’s IR Remote Out jack to the source device’s IR input.

External IR Receiver

AVR

Mono 1/8-inch (3.5mm) Mini-Plug Interconnect (not supplied)

Source Devices w/Remote In/Out Jacks

AVR

Making Connections, Set Up the Remote Control

To control more than one source device through the AVR’s IR Remote Out connector, connect all sources in “daisy chain” fashion, connecting each device’s IR output to the next device’s IR input, starting with the AVR.

If you install a multizone system, connect an IR control device to the Zone 2 IR In • connector for remote-room control of the multizone system, source devices and volume in the remote zone.

External IR

Zone 2 Speakers

AVR

If a source device is shared with the main listening area, any control commands issued to that source will also affect the main room.

Receiver

Zone 2

Main Room

Connect to AC Power

Connect the supplied AC power cord to the AVR’s AC Input connector and then to a working AC power outlet.

AVR AC Input Connector

Power Cord (supplied)

AC Power

Outlet

Set Up the Remote Control

Install the Batteries in the Remote Control

Remove the remote control’s battery cover, insert the four supplied AAA batteries as shown in the illustration, and replace the battery cover.

ENGLISH

Connect the 12V Trigger Output

If your system has equipment that can be controlled by a DC trigger signal, connect it to the AVR’s 12V Trigger connector with a mono 1/8-inch (3.5mm) mini-plug interconnect cable. The AVR will supply a 12V DC (100mA) trigger signal at this connection whenever it is powered on.

AVR

Mono 1/8-inch (3.5mm) Mini-Plug

Device with

Trigger In Connector

Interconnect (not supplied)

NOTE: Remove the protective plastic from the AVR’s front panel so it doesn’t reduce the remote control’s effectiveness.

Program the Remote to Control Your Source Devices and TV

You can program your AVR remote to control many brands and models of audio/video source devices and TVs. The remote is also ready to operate your iPod or iPhone when the iPod/iPhone is docked in a connected The Bridge IIIP (not included).

Each of the remote’s Source Selector buttons has been preprogrammed to control certain types of source devices:

Cable/Sat: Controls cable TV and satellite TV tuner boxes

Blu-ray: Controls Blu-ray Disc and DVD players

Bridge: Controls an iPod/iPhone device docked in a connected The Bridge IIIP

Radio: Controls the AVR’s built-in FM/AM tuner and a connected SIRIUSConnect tuner

TV: Controls TVs and video displays

USB (AVR 3650/AVR 365): Browses compatible media on a USB device that is

inserted in the AVR’s USB port (AVR 3650/AVR 365 only)

DVR (AVR 2650/AVR 265): Controls TiVo

Game: Controls video-game consoles

Media Server: Controls media servers

Network: Browses compatible media on DLNA-compatible devices connected to your

home network.

AUX: Controls HDTV tuner boxes, CD players, VCRs and PVDs.

Although the Source Selector buttons are preprogrammed for the device types listed above, you can reassign a Source Selector button to a different device type. See

Reassigning a Source Selector Button for a Different Device Type

recorders

, on page 24.

AVR

Set Up the Remote Control

Once you have programmed the remote, you can switch the remote’s control mode to access the functions for a particular device by pressing the remote’s Source Selector button for that device. To control the receiver, press the remote’s Setup button.

Follow these steps to program the Source Selector buttons for your source devices:

Turn on the source device you want to program the remote to control.1.

Look up the code numbers for the device in 2. Tables A14 – A24 in the Appendix. Write all the applicable code numbers in a convenient place.

Press the Source Selector button for the device and hold it as it glows red, goes dark 3. and glows red again. Then release it. The remote is now in the Programming mode.

NOTE: The remote will remain in the Programming mode for 20 seconds. If you do not complete Step 4 within 20 seconds, the remote will exit the Programming mode, and you will need to repeat Step 3.

Aim the remote at the source device and use the remote’s Number buttons to enter a 4. code number from Step 1, above.

If the device turns off, press the Source Selector button again to save the code. The a) Source Selector button will ﬂash, and the remote will exit the Programming mode.

If the device does not turn off, enter another code number. b)

If you run out of code numbers for a device, you can search through all of the codes c) in the remote’s library for dervices of its type by pressing the remote’s Up button repeatedly until the device turns off. When it does, press the Source Selector button to save the code.

Check that other functions control the device correctly. Sometimes manufacturers use 5. the same Power code for several models, while other function codes vary. Repeat this process until you’ve programmed a satisfactory code set that operates most of the device’s functions.

If you searched through the remote’s code library to ﬁnd the code, you can ﬁnd out 6. which code number you have programmed by pressing and holding the Source Selector button to re-enter the Programming Mode. Then press the remote’s OK Button, and the Source Selector button will ﬂash in the code sequence. One ﬂash represents “1,” two ﬂashes for “2,” and so forth. A series of quick ﬂashes represents “0.” Record the code number programmed for each device in Table A9 in the Appendix.

Repeat Steps 3 – 6 for each source device you want to control with the AVR remote.

Reassigning a Source Selector Button for a Different Device Type

You can reassign a Source Button to control a different device type (for example, you can program the Media Server button to control a DVD player).

Turn on the source device you want the remote to control.1.

Look up the code numbers for the device in 2. Tables A14 – A24 in the Appendix. Write all the applicable code numbers in a convenient place.

Press the Source Selector button you want to override and hold it for three seconds 3. as it glows red, goes dark and glows red again. Then release it. The remote is now in the Programming mode.

Press the Source Selector button that corresponds to the source device’s type (i.e., 4. for a DVD player, press the Blu-ray button). The Source Selector button you pressed in Step 3 will ﬂash once.

Aim the remote at the source device and use the remote’s Number buttons to enter a 5. code number from Step 2, above.

If the device turns off, press the Source Selector button from Step 3 again to a) save the code. The Source Selector button will ﬂash, and the remote will exit the Programming mode.

If the device does not turn off, enter another code number. b)

If you run out of code numbers for a device, you can search through all of the codes c) in the remote’s library for devices of its type by pressing the remote’s Up button repeatedly until the device turns off. When it does, press the Source Selector button from Step 3 to save the code.

Most of the button labels on the AVR remote describe each button’s function when the remote is used to control the AVR. However, the button may perform a different function when used to control another device. Refer to the Remote Control Function List, Table A13 in the Appendix.

You can also program the remote to perform Macros (preprogrammed code sequences that execute many code commands with a single button press), and for “punchthrough” programming (allowing the remote to operate a device’s channel or transport controls when the remote is in another device’s mode). See

Programming

Learning (AVR 3650/AVR 365 only)

If you have the device’s original remote control, you may “teach” its individual button codes into the following “destination” buttons on the AVR 3650/AVR 365 remote:

Device Power On/Off buttons, Number buttons, Last button, Back/Exit button, Menu button, Up/Down/Left/Right buttons, OK button, Disc Menu button, A/B/C/D buttons, Channel Up/Down buttons, Volume Up/Down buttons, Mute button, Transport Control buttons.

Place the two remotes with their IR transmitters facing each other, about 1 inch 1. (25mm) apart.

Press the AVR remote’s Source Selector button for the source device, then press and 2. hold the Learn button until the Source Selector button glows red. The remote is now in the Learning mode.

On the AVR remote, choose a destination button that will learn the source device 3. remote’s function. Press the destination button, and the Source Selector will ﬂash once.

On the source device’s remote, press and hold the button with the function that you 4. want to teach to the AVR remote until the Source Selector button ﬂashes three times. The source device remote’s button has now taught the AVR remote’s destination button to perform its function on that source.

You can program additional buttons for this source by repeating Steps 3 – 4. You can 5. program buttons for other sources by repeating Steps 1 – 4.

When you’re ﬁnished, press the Learn button once to exit the Learning mode, or wait for the remote to exit the Learning mode on its own after about 30 seconds.

, on page 41, for instructions on these functions.

= Destination Buttons

1 inch

(25mm)

Advanced Remote Control

Learn Button

AVR

Source Select

Select the Source Device to Enjoy

Setup Source

Setup Source Devices Connected to the AV R

Speaker Setup

Speaker Optimization, EQ

Zone 2

Manage and Control Zone 2

System

General AV R Settings

Source Select

Select the Source Device to Enjoy

Setup Source

Setup Source Devices Connected to the AV R

Speaker Setup

Speaker Optimization, EQ

Zone 2

Manage and Control Zone 2

System

General AV R Settings

Set Up the AVR

In this section, you will conﬁgure the AVR to match your actual system’s makeup. Although it’s possible to conﬁgure the AVR using only the remote and the messages on the AVR’s front-panel display, it is easier if you use the full-screen menu system.

Turn On the AVR

Set the rear-panel Main Power switch to “On.” (The front-panel Power indicator will 1. glow amber.)

Press the front-panel Power button.2.

Main Power

Switch

Unless you will not be using the receiver for an extended period of time, leave the Main Power switch set to “On.” When the Main Power switch is turned off, any settings you have programmed will be preserved for up to four weeks.

Power

Button

Set Up the AVR

The current menu, setting line or new setting will appear in the front-panel Message Display, as well as on screen.

To return to the previous menu or exit the menu system, press the Back/Exit button. Be certain all settings are correct, as any changes you have made will be retained.

Most users should follow the instructions in this basic home theater system. You may return to these menus at any time to make additional adjustments, such as those described in the

Before beginning the following setup steps, all loudspeakers, a video display and all source devices should be connected. You should be able to turn on the AVR and view the main menu when you press the AVR button. If necessary, reread the and

Set Up the Remote

sections before continuing.

Configure the AVR for Your Speakers

Plug the supplied EzSet/EQ microphone into the AVR’s Headphone connector.1.

Set Up the AVR

Advanced Functions

section to conﬁgure a

section, on page 33.

Making Connections

AVR

Headphone

Connector

ENGLISH

IMPORTANT NOTE: If the PROTECT message ever appears in the Message Display, turn off the AVR and unplug it. Check all speaker wires for a short-circuit (“+” and “–“ wires touching). If none is found, bring the unit to an authorized Harman Kardon service center for inspection and repair before using it again.

Using the On-Screen Menu System

To access the menu system, press the AVR button on the remote or the front panel. The Main Menu will appear, and if a video source is playing, it will be visible behind the menu.

NOTE: When you are using the AVR’s on-screen menu system, we recommend a video output resolution of 720p or higher for easiest viewing and for graphics that simplify some conﬁguration options. Depending on the resolution selected, the menus shown by your system may vary in appearance from the illustrations.

The Main Menu system consists of six submenus: Source Selection, Setup Source, Speaker Setup, Zone 2, System and Settings Lock. Use the Up/Down/Left/Right buttons on the remote or the front panel to navigate the menu system, and press the OK button to select a menu or setting line, or to enter a new setting.

EzSet/EQ Microphone

(supplied)

Place the microphone at ear height in your listening position. The microphone features 2. a threaded insert on the bottom for mounting on a camera tripod.

Set the volume control on your subwoofer to approximately the halfway point.3.

Turn on your TV and select the TV input where you connected the AVR in 4.

TV or Video Display

, on page 17.

Press the remote control’s AVR button. The AVR’s on-screen display (OSD) Main Menu 5. screen will appear on the TV.

Connect Your

AVR

Automatic Setup – EzSet/EQ

Automated Speaker Setup and EQ

Manual Setup

Manually Adjust Speaker Settings

Speaker Setup

Cable/Sat

Audio Effects Video Modes: Surround Modes:

Off Auto Select

720p – 60Hz No Input Off

Cable/Sat

NO AUDIO INPUT

HDMI 2

Audio Format from Source:

Video Input from Source:

Audio Input from Source:

Change Name: Adjust Lip Sync

Resolution to Display: Resolution from Source: HDMI Bypass:

Cable/Sat

Audio Effects Video Modes: Surround Modes:

Off Auto Select

720p – 60Hz No Input Off

Cable/Sat

NO AUDIO INPUT

HDMI 2

HDMI 1 HDMI 2 HDMI 3 HDMI 4 HDMI 5 HDMI Front

Component 1

Component 2 Composite 1 Composite 2

Audio Format from Source:

Video Input from Source:

Audio Input from Source:

Change Name: Adjust Lip Sync

Resolution to Display: Resolution from Source: HDMI Bypass:

Cable/Sat

Audio Effects Video Modes: Surround Modes:

Off Auto Select

720p – 60Hz No Input Off

Cable/Sat

NO AUDIO INPUT

Component 1

Analog 1

HDMI 1 HDMI 2 HDMI 3 HDMI 4 HDMI 5 HDMI Front Optical 1 Optical 2 Coaxial 1 Coaxial 2

Analog 1

Audio Format from Source:

Video Input from Source:

Audio Input from Source:

Change Name: Adjust Lip Sync

Resolution to Display: Resolution from Source: HDMI Bypass:

Use the remote’s Up/Down/Left/Right and OK buttons to select “Speaker Setup.”6.

Select “Automatic Setup – EzSet/EQ” and then select “Continue.”7.

Select the number of speakers in your system. Select “5.1” if no surround back or 8. front height speakers are present or if you will be using the Assigned Amp channels for multizone operation.

The test will begin. Make sure that the room is quiet while the test noise is playing 9. through the speakers.

When the test ﬁnishes, select “Continue,” then select “View Settings” to see the 10. results of the EzSet/EQ process, or select “Done” to exit.

NOTES:

If there are fewer than ﬁve main speakers in your system, do not use the EzSet/EQ • process. Instead, proceed as described in

If you have selected a 6.1-channel conﬁguration with a single surround back speaker, • use EzSet/EQ automatic conﬁguration for 5.1 speakers, connect the single surround back speaker to the left Assigned Amp Speaker Output connector, then conﬁgure the surround back speaker manually, as described in

Manual Speaker Setup

Manual Speaker Setup,

, on page 36.

on page 36.

Set Up the AVR

Press the Info button. The Settings menu for the selected source will reappear.4.

Select “Audio Input from Source” and select the audio input connector you want to 5. assign to the source button. Press the OK button.

Set Up Your Sources

The Setup Source menu lets you assign the correct physical audio and video connections to each source and lets you set many audio and video playback features for each source.

IMPORTANT: The “Video Input from Source,” “Audio Input from Source” and “Resolution to Display” settings are not optional and must be adjusted use your AVR to enable playback of each source. You can adjust the other settings

later. See

System Settings

the Settings menu options.

Review the input connections you listed on the 1.

Buttons

table, on page 18. Note what changes (if any) you want to make from the default source-button connector assignments that appear on the list. (If there are no changes, you can skip this section.)

To display the Source Settings menu for the active source, press the Info button on the 2. front panel or remote. Or, from the Main Menu screen, select “Setup Source” and select a source from the slide-in menu. The Settings menu for that source will appear.

Select “Video Input From Source” and select the video input connector you want to 3. assign to the source button. Press the OK button. (The setup menu will disappear from the TV.)

before

you

, on page 39, for complete information about adjusting all of

Input Connections and Assigned Source

Resolution to Display: This setting reﬂects the video output resolution, which is dependent upon the capabilities of your TV or video display.

If you connected your TV to the AVR’s HDMI Monitor Out connector, the two devices will • communicate with each other, and the AVR will automatically select the best available video output resolution. In almost all cases, you should leave the resolution set to the AVR’s automatic selection. (You can override this automatic selection if your video display’s native resolution is different from the AVR’s automatic selection.)

If you connected your TV to the AVR’s Composite Video Monitor Out connector, you •

must

set the resolution to “480i” (AVR 3650/AVR 2650) or to “576p” (AVR 365/AVR

265) to view any content.

Audio Effects: This submenu allows you to adjust the Dolby Volume and Dolby PLII/ IIx/IIz settings, the bass and treble tone controls, the LFE trim, the Equalization On/Off setting and the MP3 enhancement for each source independently. We suggest leaving this submenu at its default settings and returning to it later if your system requires ﬁnetuning. See

Audio Effects Button

, on page 34, for more information.

Video Modes: This submenu allows you to make picture adjustments for each source independently. We suggest leaving the settings at their factory defaults. You should make picture adjustments to your video display ﬁrst and use this menu only for ﬁne-tuning. See

Video Processing

, on page 34, for more information.

Surround Modes: This submenu lets you program surround modes for movies, music and games for each source independently. Digital surround signals, such as Dolby Digital and DTS bitstreams, are automatically played in their native formats, although you may change the surround mode. See

Audio Processing and Surround Sound

, on page 33, for

more information.

Audio Format from Source: This line is informational only. When a digital program is playing, its format will be identiﬁed here. When analog audio programs are playing, this line displays ANALOG.

AVR

Adjust Lip Sync

Network Settings

ID#:

Network Settings:

IP A ddress: Subnet Mask:

00 00 00 00 A0 A0

Automatic

000 . 000 . 000 . 000 000 . 000 . 000 . 000 000 . 000 . 000 . 000 000 . 000 . 000 . 000 000 . 000 . 000 . 000

Not Connected

Gateway: Primary DNS: Secondary DNS:

Network Status: Apply & Save – AV R will Enter Standby

Set Up the AVR

Resolution from Source: This line is informational only. It indicates the resolution of the video output by the source device.

HDMI Bypass: This setting allows you to bypass the AVR’s internal video processing for proper display of 3-D video content and of source devices (such as some game consoles) where the AVR's video processing can create delays that can cause synchronization errors between the sound and picture. There are three available settings:

Off: Does not bypass the AVR's internal video processing. •

On: Always bypasses the AVR's internal video processing. •

Auto: Automatically bypasses the AVR's internal video processing when 3-D content • is detected.

IMPORTANT: Once the AVR automatically switches into the bypass mode upon detecting 3-D video content, it will not automatically switch out of the bypass mode when it detects conventional 2-D video content. To turn the HDMI Bypass off you must cycle the AVR into the Standby mode and then turn it on again.

We suggest that you create an additional source conﬁguration for each of your 3-D video source devices by assigning each an unused Source Selector button on the AVR’s remote control. For example, you can assign the AVR’s “Media Server” source as the 3-D source for a 3-D-capable disc player or game, and you can assign one of the AVR’s “A/B/C/D” source buttons as the 3-D source for your cable or satellite tuner’s 3-D programming.

Creating “HDMI Bypass” Inputs

In this example, we will program the Media Server source as an HDMI Bypass source for 3-D programming:

Select “Setup Source.” The source list will appear.1.

Select “Media Server.” The Media Server setup screen will appear.2.

Select “HDMI Bypass.” A conﬁrmation screen will appear.3.

Select “OK.” The AVR will exit the menu mode.4.

Repeat Steps 1 – 4, assigning a new 3-D source for each of your 3-D-capable source devices.

Audio Auto Polling: This setting is used when both analog and digital audio connections are made for the source device. If an analog audio connection was made, select it here. When no digital signal comes from the device, the AVR will automatically switch to the analog audio input. This switch can be useful for older cable television systems that broadcast channels in both analog and digital audio. If there is no analog audio connection from the device, choose the Off setting, and the AVR will always use the digital audio connection.

Zone 2 Audio: This setting determines the audio source for Zone 2 of a multizone system. Select the analog audio input the source is connected to. Digital audio is not available to the multizone system.

To conﬁgure the next source, press the Back/Exit button, then return to the Setup Source line of the Main Menu. When you have ﬁnished conﬁguring all sources, press the Back/Exit button to clear the menus from view.

Set Up the Network

To play MP3 or WMA media located on DLNA-compatible devices connected to the network or to use the AVR’s internal Internet radio tuner to listen to audio streams, connect the AVR’s Network connector to the Ethernet port on a router or modem that has Internet access, to a home network, or to a PC.

If your network uses an automatic IP address, you should not have to perform any network setup procedures. Once you connect the AVR to your home network, the network should automatically assign the AVR an IP address, and the AVR should automatically connect to your network.

If your AVR does not automatically connect to your network (in which case the AVR will display a “Not Connected” message when you press the Network source button):

Press the Setup button, select Setup Source, then select Network on the slide-in menu. 1. The Network menu will appear.

Select Network Setup. The Network Settings menu will appear.2.

ENGLISH

Notes:

When using your AVR with these new settings, be sure to press the correct source • selectors for your 2-D and 3-D sources.

If you are viewing 3-D sources when an HDMI Bypass input is active, the • on-screen indications for volume level will not appear. This is normal, since all video processing is removed in the HDMI Bypass mode.

If your video sources are always operating at 720p or higher resolution, you may • ﬁnd the HDMI Bypass mode acceptable for normal 2-D viewing as well as for 3-D viewing. In this case, you may ﬁnd it more convenient to use the 3-D sources at all times.

If you see side-by-side or top-and-bottom images while watching a 3-D program, • manually switch to the HDMI Bypass mode.

Change Name: This selection lets you change the display name for the source, which is useful if your source’s device type is different from the source’s preprogrammed name. Select this line and use the Up/Down buttons to scroll forward or reverse through the alphanumeric characters. When the desired character appears, use the Left/Right buttons to move the cursor to the next or previous position. Move the cursor again to leave a blank space. When you have ﬁnished, press the OK Button. The name will appear on the AVR’s front panel and throughout the on-screen menu system.

Adjust Lip Sync: This selection lets you resynchronize the audio and video signals from a source to eliminate a “lip sync” problem. Lip-sync issues can occur when the video portion of a signal undergoes additional processing in either the source device or the video display. When you make a Lip Sync adjustment, the Lip Sync menu appears by itself, enabling you to view the video while listening to the audio. Use the Left/ Right buttons to delay the audio by up to 180ms.

Select Network Settings, the press the OK button twice to cycle the setting from 3. “Automatic” to “Manual” and back to “Automatic.”

Select Apply & Save. The AVR will enter the Standby mode. When you turn the AVR back 4. on, it will attempt to connect to the network.

If the AVR again fails to connect to the network, you may need to enter your network’s 5. settings manually. See complete instructions. You may need to obtain your network’s settings from your ISP or network administrator.

NOTE: We recommend that you connect the AVR to a home-network router so that it can directly access the Internet for Internet radio, or access a PC on the network for playback of content stored on the PC (see on page 32, for more information).

Network Settings

(under

General AVR Settings

Listening to Media via Your Home Network

), on page 40, for

AVR

Audio Effects – Cable/Sat

Dolby Volume:

PLIIz Height Gain: Edit: Dolby PLII Music Edit: Dolby PLIIx Music

Medium

Low

Off Off

Tone Control: Treble: Bass: LFE Tr im:

MP3 Enhancer EZSET/EQ:

Operating Your AVR

Now that you have installed your components and completed a basic conﬁguration, you are ready to begin enjoying your home theater system.

Controlling the Volume

Adjust the volume either by turning the front-panel Volume knob (clockwise to increase volume or counterclockwise to decrease volume) or by pressing the Volume Up/Down buttons on the remote. The volume is displayed as a negative number of decibels (dB) below the 0dB reference point (-90dB – +10dB).

0dB is the maximum recommended volume for your AVR. Although it’s possible to turn the volume to a higher level, doing so may damage your hearing and your speakers. For certain more dynamic audio materials, even 0dB may be too high, allowing for damage to equipment. Use caution with regard to volume levels.

To change the volume level display from the default decibel scale to a 0-to-90 scale, adjust the Volume Units setting in the System Settings menu, as described in

Settings

, on page 39.

Muting the Sound

To mute all speakers and the headphones, press the Mute button on the remote. Any recording in progress will not be affected. The MUTE message will appear in the display as a reminder. To restore the sound, press the Mute button again, or adjust the volume.

Dolby Volume

Your AVR implements Dolby Volume processing, which can improve the audio performance of the system by revealing subtle details in the sound, even at normal home-listening volumes.

One concern of the typical home theater listener is that volumes can vary widely for different programs played by a source (e.g., television commercial advertisements are often much louder than the main program). Another is that details heard in the recording studio at typically high reference volumes are lost at the lower volumes used by many listeners at home.

The AVR uses two Dolby Volume techniques to address these issues. The Leveler module maintains a consistent listening volume within a source (e.g., commercial television or different tracks on a USB drive or mix CD). The Modeler module endeavors to re-create the reference presentation that was heard in the recording studio without losing portions of the program at the typically lower volume levels often used in the home. When the Modeler module is active, you may notice details of the performance that were hidden when the program was played on other equipment.

To adjust the Dolby Volume setting, press the Audio Effects button. The Audio Effects submenu will appear.

After you highlight the Dolby Volume setting, each press of the OK button will switch to one of the options in the table below. The settings do not refer to the volume level, which is adjusted normally using the AVR’s Volume Control, but rather to the amount of Dolby Volume processing desired.

System

Operating Your AVR

Setting Effect

Off No Dolby Volume processing

Low Only Dolby Volume Modeler module is active

Medium

Max

NOTE: Dolby Volume processing is compatible with sources recorded at a sampling rate of 48kHz. High-resolution sources, such as DTS 96/24 programs, will be decoded at 48kHz. DTS 96/24 programs will be played in DTS 5.1 mode. To hear DTS 96/24 materials in high resolution, turn off Dolby Volume processing.

Dolby Volume Calibration

Dolby Volume calibration allows you to adjust the operation of the Dolby Volume circuitry to match your particular speakers and listening environment. The Dolby Volume circuitry in your AVR is factory-calibrated with average speaker sensitivity in mind; however, different speakers may have different sensitivities, which will affect the overall performance of the Dolby Volume circuitry. Use Dolby Volume calibration to adjust the calibration of the circuitry according to the speciﬁc speakers you have.

The average home audio speaker sensitivity is 88dB SPL (1 watt/1 meter). Check the sensitivity speciﬁcation for your loudspeakers, found in the owner’s manual or on the manufacturer’s Web site. If your speakers have a sensitivity rating greater than 88dB SPL, increase Dolby Volume calibration by the difference between your speakers’ sensitivity and 88dB. If they have a sensitivity rating of less than 88dB SPL, decrease Dolby Volume calibration by the difference between your speakers’ sensitivity and 88dB.

To adjust the Dolby Volume calibration, press the AVR button and select the “System” menu. Scroll to the Dolby Volume calibration line, which defaults to 0dB. Use the Left/ Right buttons to adjust the setting within the range of –10dB to +10dB.

Listening Through Headphones

Plug the 1/4-inch stereo plug on a pair of headphones into the front-panel Phones jack for private listening. The default Headphone Bypass mode delivers a conventional twochannel signal to the headphones. Press the Surround Modes button on the front panel or the remote to switch to HARMAN headphone virtual surround processing, which emulates a 5.1-channel speaker system. No other surround modes are available for the headphones.

Selecting a Source

There are three different ways to select a source:

Press the front-panel Source List button. Use the Up/Down buttons to scroll through • the sources, and press the OK button to select the source being displayed.

Using the on-screen menus, press the AVR button, highlight “Source Select” and press • the OK button. Scroll to the desired source in the slide-in menu and press the OK button.

You can directly select any source by pressing its Source Selector button on the • remote.

The AVR selects the audio and video inputs assigned to the source, and any other settings you made during setup.

The source name, the audio and video inputs assigned to the source, and the surround mode will appear on the front panel. The source name and active surround mode will also brieﬂy appear on the TV screen.

Both Modeler and Leveler modules are active; Leveler module has a value of 3

Both Modeler and Leveler modules are active; Leveler module has a value of 9

AVR

AM/FM Radio

87.50

MHz

Auto

Menu:Set Presets: Presets:

OKMENU

Video Troubleshooting Tips

If there is no picture:

Check the source selection and video input assignment. •

Check all connections for a loose or incorrect connection. •

Check the video input selection on the TV/display device. •

Press the front-panel Resolution button and use the Up/Down buttons until the • correct video output resolution is selected and a picture appears. The CANCEL message will also appear. Press the Down button to view the ACCEPT option, then press the OK button.

Additional Tips for Troubleshooting HDMI Connections

Turn off all devices (including the TV, the AVR and any source components). •

Unplug the HDMI cables, starting with the cable between the AVR and the TV, and • continuing with the cables between the AVR and each source device.

Carefully reconnect the cables from the source devices to the AVR. Connect the • cable from the AVR to the TV last.

Turn on the devices in this order: TV, AVR, source devices. •

NOTE: Depending upon the particular components involved, the complexity of the required communication between HDMI components may cause delays of up to a minute in the completion of some actions, such as input switching or switching between SD and HD channels.

Listening to FM and AM Radio

Select the Radio source. A screen similar to the one in the illustration below will appear. (Note: The SIRIUS band uses a different screen.)

Use the Up/Down buttons or the Remote’s Channel buttons to tune a station (or channel for SIRIUS Radio), as displayed on the front panel and on-screen display.

The AVR defaults to automatic tuning, meaning each press of the Up/Down buttons scans up or down the frequency band until a station with acceptable signal strength is found. To switch to manual tuning, in which each press of the Up/Down buttons steps through a single tuning frequency increment, press the remote’s Menu button. A slide-in menu will appear. Select “Mode,” and press the OK button to toggle between automatic and manual tuning modes.

Once you have tuned an FM station, toggling the Mode setting also switches the radio between stereo and monaural reception. (Mono reception may improve reception of weaker stations.)

Preset Stations

You can store a total of 30 stations (AM and FM combined) as presets. When you want to save the currently tuned station as a preset, press the OK button, and two dashes will ﬂash. Use the Number buttons to enter the desired preset number.

To tune to a preset station:

Press the Left/Right buttons. •

Press the skip forward/skip backward Transport Control buttons. •

Press the Menu button and scroll to the desired preset, then press the OK button. •

Enter the preset number using the Number buttons. For presets 10 through 30, press 0 • before the preset number. For example, to enter preset 21, press 0-2-1.

Operating Your AVR

Listening to SIRIUS Satellite Radio

SIRIUS Satellite Radio delivers a variety of commercial-free music from categories including pop, rock, country, R&B, dance, jazz, classical and many more, plus coverage of all the top professional and college sports, including play-by-play games from select leagues and teams. Additional programming includes expert sports talk, uncensored entertainment, comedy, family programming, local trafﬁc and weather, and news from your most trusted sources. SIRIUS Satellite Radio is available to residents of the U.S. (except Alaska and Hawaii) and Canada.

To listen to SIRIUS Satellite Radio, you’ll need to connect a SIRIUS tuner module (sold separately) to the AVR’s SIRIUS Tuner connector. SIRIUS tuner modules that will work with your AVR are available at www.sirius.com. Select a tuner module designated for SIRIUS-Ready is controlled by the AVR’s internal tuner, including 40 preset SIRIUS station locations and remote control. Although you may also use a SIRIUS “plug-and-play” unit with standard analog audio connections, you will not be able to enjoy the AVR’s ease of control.

Installing the SIRIUS tuner module

Once you’ve purchased a SIRIUS tuner, you’ll need to install it, activate it and subscribe to begin enjoying the service:

Using the cable included with the SIRIUS tuner module, plug the module into the SIRIUS 1. Tuner connector on the rear of the AVR.

Follow the instructions included with the SIRIUS tuner module to complete its 2. installation. NOTE: Pay particular attention to the instructions for installing and orienting the SIRIUS antenna that is included with the SIRIUS tuner module.

Call 1-888-539-SIRI (7474) or visit sirius.com (U.S.) or siriuscanada.ca (Canada) to 3. activate your SIRIUS tuner module and subscribe to the SIRIUS service.

To listen to SIRIUS radio

Select SIRIUS Radio as the source in one of these ways:

Press the Source List button on the front panel. Use the Up/Down buttons to scroll to • “SIRIUS Radio” and press the OK Button.

Press the Radio Source Selector button on the remote repeatedly until SIRIUS Radio • is selected.

There are four ways to tune a SIRIUS radio channel:

Use the Up/Down buttons or the Channel Up/Down buttons to scan through the channel • numbers.

Use the Left/Right buttons to scan through any previously programmed preset • stations.

After you have programmed presets, directly enter the preset number (1 through 40) • using the Number buttons. For two-digit positions, enter a “0” before the number.

To search for a channel, press the Menu button, then use the Up/Down buttons to cycle • through the following choices: Preset, Category, All Channels or Direct Entry. Press the OK button to select one, then use the Up/Down buttons to search for the channel (for Direct Entry, use the Number buttons to enter the channel number), then press the OK button.

The current channel number and preset location will appear in the lower line of the AVR’s front-panel Message Display. The song title, artist, channel name, channel category, channel number, preset position (if programmed) and signal-strength bars will all appear on the screen when a video display is in use. For trafﬁc and weather channels, the current city’s name will appear instead of the channel name.

Preset SIRIUS channels

You can store a total of 40 channels as presets. When the desired channel has been tuned, press the OK button, and two dashes will ﬂash on the AVR’s front-panel Message Display. Use the Number buttons to enter the desired preset number.

To tune to a preset SIRIUS channel:

Press the Left/Right buttons. •

Press the skip forward/skip backward Transport Control buttons. •

Press the Menu Button and scroll to the desired preset, then press the OK Button. •

Enter the preset number using the Number buttons. For presets 10 through 40, press 0 • before the preset number. For example, to enter preset 21, press 0-2-1.

audio components (also called SIRIUSConnect). A SIRIUSConnect module

ENGLISH

AVR

USB

Menu:Previous:Next:

USB

Browse USB

Repeat Music: Off

USB

Night Crazy

06:16/17:17

Jugalbandi

Night Crazy

Menu:Previous:Next:

The Bridge

Menu:Previous:Next:

The Bridge

Music

Photos/Manual Videos Random: Off Repeat: Off

Operating Your AVR

Listening to Media on a USB Device (AVR 3650/AVR 365)

Your AVR is compatible with MP3 and WMA media.

MP3 compatibility: Mono or stereo, contstant bit rates (CBR) from 8kbps to 320kbps, variable bit rates (VBR) from lowest to highest quality, with sample rates from 8kHz – 48kHz.

WMA compatibility: Ver. 9.2, stereo CBR with 32kHz – 48kHz sampling rate and 40kbps – 192kbps bit rate, mono CBR with 8kHz – 16kHz sampling rate and 5kbps – 16kbps bit rate, VBR Pass Encoding and Quality Encoding 10 – 98, 44kHz and 48kHz sampling rate.

No other types of media can be played.

Playing files on a USB device

Insert the USB drive into the AVR’s front-panel USB port. 1.

IMPORTANT: Do not connect a personal computer or peripheral to the USB port. USB hubs and multi-card readers are not supported.

Select the USB Source Selector button on the remote. “USB” will appear on the front-2. panel display, and the USB screen and the slide-in menu will appear.

Select “Browse USB.” The AVR will list the folders located on the drive.3.

Select a folder and press the OK button. The AVR will list all compatible audio ﬁles.4.

Select a ﬁle to begin playback. The USB play screen will appear. Any ID3 information 5. and album art will be displayed, along with the track’s elapsed/current time and icons indicating the current playback status.

NOTES:

To skip to the next track, press the Right button; to return to the previous track, press • the Left button once.

You can use the Transport Control buttons to control playback (skipping to the previous • or next track, searching at high speed forward or backward within a track, playing a ﬁle, pausing playback or stopping playback).

To repeat a ﬁle or folder, press the Menu Button and select the Repeat option. Each • press of the OK Button will change the setting from Off (no repeat) to Repeat One (ﬁle) to Repeat All (ﬁles at the current directory level of the drive). Repeat All will always be activated when Random Music playback is turned on.

To play the audio tracks in random order, press the Menu button and select the Random • Music setting. Each press of the OK button turns the setting on or off. The AVR will automatically repeat the tracks until playback is stopped manually.

To collapse a folder or return to the previous menu level, press the Back/Exit button • or the Left button.

Listening to an iPod/iPhone Device

When The Bridge IIIP is connected to its proprietary input on the AVR and an iPod or iPhone is docked, you may play the audio, video and still-image materials on your iPod or iPhone through your high-quality audio/video system, operate the iPod or iPhone using the AVR remote or the AVR’s front-panel controls, view navigation messages on the AVR’s front panel or a connected video display and charge the iPod or iPhone.

As of this writing, your AVR supports audio, video and photo playback from the following Apple products: iPod classic, iPod nano 3G, iPod nano 4G, iPod nano 5G, iPod nano 6G, iPod touch, iPod touch 2G, iPod touch 3G, iPod touch 4G, iPhone, iPhone 3G, iPhone 3GS, iPhone 4G. For the latest compatibility information, please see our Web site: www. harmankardon.com.

When you select The Bridge Source Selector button on the remote, “Bridge” will appear on the front-panel display, a The Bridge screen will appear and the slide-in menu will automatically appear.

NOTE: If the AVR doesn’t detect the iPod or iPhone, turn off the AVR, remove the iPod or iPhone from The Bridge IIIP and reset the iPod or iPhone. When the iPod or iPhone returns to its main menu, re-dock it and turn on the AVR.

The table below summarizes the controls available during normal playback with The Bridge IIIP:

iPod or iPhone Function Remote Control Key

Play Play

Pause Pause

Menu Menu

Back/Exit Back/Exit or Left Arrow

Select OK or Right Arrow

Scroll Reverse Up Arrow

Scroll Forward Down Arrow

Forward Search Forward Search

Reverse Search Reverse Search

Next Track Skip Forward or Right Arrow

Previous Track Skip Backward or Left Arrow

Page Up/Down Page Up/Down

While scrolling, hold the button to scroll faster. Use the Page Up/Down control on the remote to scroll a page at a time.

While a selection is playing, the album, artist, song title, track elapsed time, total track time and play mode icon will appear on the front-panel Message display.

AVR

The Lost Tr ansit Center

03:41/10:44

Jugalbandi

Night Crazy

Menu:Previous:Next:

The Bridge

Internet Radio

Big Blue Swing

Count Basie

Menu:Set Presets: Presets:

OKMENU

Operating Your AVR

If a video monitor is connected to the AVR and the system is not in iPod manual mode, a The Bridge screen will appear and display the play mode icon, song title, artist and album. A graphic bar indicates the current play position within the track. If random or repeat play has been programmed, an icon will appear in the upper right corner.

The screen may disappear from view, depending on the Setup and Slide-In Menus setting in the System Settings menu (described in

System Settings

, on page 39). You can restore the Now Playing screen to view by pressing either of the Left or Right buttons.

CAUTION: We strongly recommend that you use the screen saver built into your video display to avoid possible damage from “burn-in” that may occur with plasma and many CRT displays when a still image, such as a menu screen, remains on the display for an extended period of time.

Press the Menu button to view the slide-out menu:

Music: Select this to navigate the audio materials stored on the iPod or iPhone. Use the Page up/down buttons on the remote to scroll through the content a page at a time.

Photo/Manual: Select this to view still images stored on a photo-capable iPod or iPhone. The system will switch to iPod manual mode, and control will shift to the iPod. Use the screen and controls on the iPod. The AVR remote may also be used. To view photos on a video monitor connected to the AVR, select the photo and press the Play button on the iPod, or press the OK button on the remote three times.

Videos: Select this to view videos stored on an iPhone or an iPod that supports video browsing.

Notes on iPod/iPhone video playback:

Before attempting to view photos or videos stored on your device, check the Video • Settings menu on the device and make sure that the TV Out setting is set to On. The TV Signal setting should be set to match the capabilities of your video display (NTSC for the US; PAL for the EU). If your selection was playing and is paused, the iPod or iPhone requires you to reselect the video for the new TV Out setting to take effect.

If you do not see the Videos line in the menu, and the iPod supports video browsing • and has video content stored on it, you may need to turn off the AVR, remove the iPod from The Bridge IIIP, reset the iPod, turn the AVR back on and dock the iPod again. An iPhone may not need to be reset, as simply undocking and re-docking it may resolve the problem. This procedure may also help when a video program is selected but the Bridge screen appears instead of the video images.

To exit iPod manual mode, with the AVR remote in The Bridge mode, press the Menu button. To return to a previous menu level, press the Back/Exit Button or the Left button.

Repeat: Select this setting to repeat a track or all tracks in the current album or playlist. Each press of the OK button switches the setting: repeat Off, repeat One or repeat All.

Random: Select this setting for random playback, also known as “Shufﬂe Mode.” Each press of the OK button switches the setting: shufﬂe by Song, shufﬂe by Album, or Off to end random playback.

NOTE: The iTunes application allows you to exempt some tracks from Shufﬂe mode. The AVR cannot override this setting.

The AVR supports audio playback from some applications available for the iPhone and the iPod touch. Place the system in iPod manual mode by pressing the Menu button and selecting “Photo/Manual.” Then use the controls on the iPhone or iPod touch to run the application.

Due to the wide variety of applications and many factors affecting them, playback is not guaranteed.

NOTES:

The Play and Pause functions are not available unless content has been selected for • playback.

To search within a track, press and hold the forward or reverse Transport Control • button. Press the previous track Transport Control button once to skip to the beginning of the current track; press the previous track Transport Control button twice to skip to the beginning of the previous track.

Listening to Internet Radio

Your AVR’s Network connection brings you a world of MP3- and WMA-format streams via the Internet. After you have successfully connected to your home network as described in

Connect to Your Home Network Up the Network

, on page 27, press the Network Source Selector button on the remote.

Each press toggles between the Network and Internet Radio screens.

With the Internet Radio screen (above) displayed, the AVR will automatically connect to the Internet via the www.radioharmankardon.com portal. To select a stream, press the Menu button, and use the Up/Down buttons to search by category: Presets, My Favourites, Local Stations, HDi, Stations, Podcasts or My Added Stations. NOTE: The categories displayed may vary by region.

To create a Favourites list, log onto www.radioharmankardon.com from your computer. Enter your AVR’s ID # (to see the ID # with the Internet Radio screen displayed, press the Menu button, then select Help) and create an account. Favourites that you select on the Web site will be available on the AVR.

NOTE: While the Help screen is displayed, we recommend spending a few moments listening to the audio FAQs to get answers to common questions about Internet radio operation. The FAQs play in a continuous loop. To return to an Internet radio station while an FAQ is playing, press the Menu button, then the Back/Exit button, then the Back/Exit button again, and select an Internet radio station.

Navigation is similar to other slide-in menus. Scroll to the desired item and press the OK button or the Right button to select it. To return to the previous menu level (or to clear the top-level menu from view), press the Back/Exit button or the Left button.

If you know the URL (Web address) of a speciﬁc audio stream, select the Direct Station option from the menu. A live stream is required. The AVR is not able to connect to streams that require site registration or other interaction prior to playing the stream. If the AVR cannot connect to the stream, a “Station Not Live” message will appear brieﬂy, and the Internet Radio screen will remain essentially blank. Not all URLs will be accessible.

Internet Radio Presets

You can program up to 30 Internet radio stations as presets. To set a preset, ﬁrst tune the station. Press the OK button, and two dashes will ﬂash. Enter the preset number (any number from 1 through 30) using the Number buttons. The connection to the station will momentarily stop, interrupting the program, and the AVR will reconnect to the station.

To connect to a station programmed as a preset, enter its preset number using the Number buttons, or use the Left/Right buttons to select it from the preset list.

, on page 20, and set up the network as described in

Set

ENGLISH

AVR

Beanwater Junction

01.50/3:55

Jugalbandi Night Crazy

Menu:Previous:Next:

Network

Surround Modes – Cable/Sat

Auto Select – AV R Selects Best Mode Virtual Surround – For Two Speaker Systems Stereo: Movie:

Music:

Video Game:

2 CH Stereo Logic 7 Movie

Logic 7 Music

Logic 7 Game

Operating Your AVR

Listening to Media via Your Home Network

Your AVR can play MP3 and WMA audio media that is stored on a PC when both the PC and the AVR are connected to your home network router.

MP3 compatibility: Mono or stereo, contstant bit rates (CBR) from 8kbps to 320kbps, variable bit rates (VBR) from lowest to highest quality, with sample rates from 8kHz – 48kHz.

NOTES:

A PC must be running Windows Media • Media Center version 2.0 or 3.0, or Intel® Media Server. We recommend that any ﬁrewalls be turned off, although Windows Media Player may automatically make any necessary adjustments to the ﬁrewall settings to allow media sharing.

An Apple Macintosh computer must be running DLNA (Digital Living Network • Alliance)-compliant software. Examples of compatible software include the TwonkyServer™ program by PacketVideo, and EyeConnect software by Elgato Systems.

Before you can access ﬁles located on other devices via the network, each device must ﬁrst give permission to share ﬁles with the AVR:

To share media on PCs:

Open Windows Media Player.1.

Open the Library menu and select Media Sharing. The Media Sharing window will 2. appear.

Check the “Share My Media” box. An icon for the AVR will appear in the window.3.

Select the AVR icon, select “Allow,” then select “OK.”4.

The computer’s WMA and MP3 media should now be available to the AVR.

To share media on other types of computers, operating systems or media software: Check the instructions for the computer, operating system or media player.

To listen to shared media, press the Network Source Selector button. (If Internet Radio appears as the source, press the button a second time to switch from the Internet Radio source to the Network source.) The Network screen will appear.

Press the Menu button, and the slide-in menu should list all devices that allow sharing by name. Use the slide-in menu to browse the content stored in the device’s media player library. Scroll to the desired item and press the OK button or the Right button to select it. To return to the previous menu level (or to clear the menu from view from the top level), press the Back/Exit button or the Left button.

NOTES:

The Repeat settings are global for Network playback and USB playback. Changing • these settings for one of these sources will change the other source’s settings as well.

Although video content may appear in the menu, the AVR does not support video • playback from the network connection.

Selecting a Surround Mode

Selecting a surround mode can be as simple or sophisticated as your individual system and tastes. Feel free to experiment, and you may ﬁnd a few favorites for

Player version 11 or higher, Windows

certain sources or program types. You can ﬁnd more detailed information on surround

Audio Processing and Surround Sound

modes in

, on page 33.

To select a surround mode, press the Surround Modes button (front panel or remote). The Surround Modes menu will appear.

Press the Up/Down buttons repeatedly until the desired surround-mode category appears: Auto Select, Virtual Surround, Stereo, Movie, Music or Video Game. Press the OK button to change the surround-mode category.

Auto Select: For digital programs, such as a movie recorded with a Dolby Digital or DTS soundtrack, the AVR will automatically use the soundtrack’s native surround format. For two-channel analog and PCM programs, the AVR uses the Logic 7 Movie, Logic 7 Music or Logic 7 Game mode, depending on the source.

Virtual Surround: When only two main speakers are present in the system, you can use HARMAN Virtual Surround to create an enhanced soundﬁeld that virtualizes the missing speakers. Select between Wide and Reference modes.

Stereo: When you want two-channel playback, select the number of speakers you want to use for playback:

“2 CH Stereo” uses two speakers. •

“5 CH Stereo” plays the left-channel signal through the front left and surround left • speakers, the right-channel signal through the front right and surround right speakers, and a summed mono signal through the center speaker.

“7 CH Stereo” follows the same scheme as 5 CH Stereo but adds the surround back • left and surround back right speakers. This mode is available only when the surround back speakers are present and have not been reassigned to multizone or front height operation. See

Audio Processing and Surround Sound

, on page 33, for more

information.

Movie: Select from the following when you want a surround mode for movie playback: Logic 7 Movie, DTS Neo:6 Cinema or Dolby Pro Logic II (IIx or IIz when seven main speakers are present).

Music: Select from the following when you want a surround mode for music playback: Logic 7 Music, DTS Neo:6 Music or Dolby Pro Logic II (IIx or IIz when seven main speakers are present). The Dolby Pro Logic II/IIx/IIz Music mode allows access to a submenu with some additional settings. See A

udio Processing and Surround Sound

, on page 33, for

more information.

Video Game: Select from the following when you want a surround mode for game playback: Logic 7 Game or Dolby Pro Logic II (IIx/IIz when seven main speakers are present) Game.

After you have made your selection, press the Back/Exit button.

See

Audio Processing and Surround Sound

, on page 33, for more information on surround

modes.

Audio Effects

The Audio Effects buttons on the front panel and remote provide settings that let you adjust the Dolby Volume setting, tone controls, LFE trim, Equalization On/Off setting or MP3 Enhancement to improve performance. We recommended that you leave these settings at their default values until you are more familiar with your system. See

Effects Button

, on page 34, for complete information.

Audio

Video Modes

The Video Modes buttons on the front panel and remote provide settings that let you use the AVR’s video processor to ﬁne-tune the picture, if necessary, after making all adjustments on the video display. We recommend that you leave the settings at their defaults until you are completely familiar with the video performance of your system. See

Video Processing

, on page 34, for complete information.

AVR

Advanced Functions

Much of the adjusting and conﬁguration your AVR requires is handled automatically, with little intervention required on your part. You can also customize your AVR to suit your system and your tastes. In this section we will describe some of the more advanced adjustments available to you.

Audio Processing and Surround Sound

Audio signals can be encoded in a variety of formats that can affect not only the quality of the sound but the number of speaker channels and the surround mode. You may also manually select a different surround mode, when available.

Analog Audio Signals

Analog audio signals usually consist of two channels – left and right. Your AVR offers two options for analog playback:

DSP Surround Off Mode:1. The DSP Surround Off mode digitizes the incoming signal and applies the bass-management settings, including speaker conﬁguration, delay times and output levels. Select this mode when your front speakers are small, limitedrange satellites and you are using a subwoofer. To select this mode, use a digital audio input or turn the Tone Control setting off, then select 2 CH Stereo mode.

Analog Surround Modes:2. Your AVR is able to process two-channel audio signals to produce multichannel surround sound, even when no surround sound has been encoded in the recording. Among the available modes are the Dolby Pro Logic II/IIx/IIz, HARMAN Virtual Speaker, DTS Neo:6, Logic 7, 5 CH and 7 CH Stereo modes. To select one of these modes, press the Surround Modes button.

Digital Audio Signals

Digital audio signals offer greater ﬂexibility and capacity than analog signals, and allow the encoding of discrete channel information directly into the signal. The result is improved sound quality and startling directionality, since each channel’s information is transmitted discretely. High-resolution recordings sound extraordinarily distortion-free, especially in the high frequencies.

Surround Modes

Surround-mode selection depends upon the format of the incoming audio signal as well as your personal taste. Although there is never a time when all of the AVR’s surround modes are available, there is usually a wide variety of modes available for a given input. Table A12 in the Appendix, on page 50, offers a brief description of each mode and indicates the types of incoming signals or digital bitstreams the mode may be used with. Additional information about the Dolby and DTS modes is available on the companies’ Web sites: www.dolby.com and www.dtsonline.com.

When in doubt, check the jacket of your disc for more information on which surround modes are available. Usually, nonessential sections of the disc, such as trailers, extra materials or the disc menu, are available only in Dolby Digital 2.0 (two-channel) or PCM two-channel mode. If the main title is playing and the display shows one of these surround modes, look for an audio or language setup section in the disc’s menu. Also, make sure your disc player’s audio output is set to the original bitstream rather than twochannel PCM. Stop play and check the player’s output setting.

Multichannel digital recordings are produced in ﬁve-channel, six-channel or sevenchannel formats, with or without a “.1” channel. The channels included in a typical

5.1-channel recording are front left, front right, center, surround left, surround right and LFE (low-frequency effects). The LFE channel is denoted as “.1” to represent the fact that it is limited to the low frequencies. 6.1-channel recordings add a single surround back channel, and 7.1-channel recordings add surround back left and surround back right channels to the 5.1-channel conﬁguration. New formats are available in 7.1-channel conﬁgurations. Your AVR is able to play the new audio formats, delivering a more exciting home theater experience.

NOTE: To use the 6.1- and 7.1-channel surround modes, the surround back channels must be enabled. See

Digital formats include Dolby Digital 2.0 (two channels only), Dolby Digital 5.1, Dolby Digital EX (6.1), Dolby Digital Plus (7.1), Dolby TrueHD (7.1), DTS-HD High-Resolution Audio (7.1), DTS-HD Master Audio (7.1), DTS 5.1, DTS-ES (6.1 Matrix and Discrete), DTS 96/24 (5.1), two-channel PCM modes in 32kHz, 44.1kHz, 48kHz or 96kHz, and 5.1 or 7.1 multichannel PCM.

When the AVR receives a digital signal, it detects the encoding method and the number of channels, which is displayed brieﬂy as three numbers, separated by slashes (e.g., “3/2/.1”).

Manual Speaker Setup

, on page 36 for more information.

The ﬁrst number indicates the number of front channels in the signal: “1” represents a monophonic recording (usually an older program that has been digitally remastered or, more rarely, a modern program for which the director has chosen mono as a special effect). “2” indicates the presence of the left and right channels, but no center channel. “3” indicates that all three front channels (left, right and center) are present.

The second number indicates whether any surround channels are present: “0” indicates that no surround information is present. “1” indicates that a matrixed surround signal is present. “2” indicates discrete left and right surround channels. “3” is used with DTS-ES bitstreams to represent the presence of the discrete surround back channel, in addition to the side surround left and right channels. “4” is used with 7.1-channel digital formats to indicate the presence of two discrete side surround channels and two discrete back surround channels.

The third number is used for the LFE channel: “0” indicates no LFE channel. “.1” indicates that an LFE channel is present.

The 6.1-channel signals – Dolby Digital EX and DTS-ES Matrix and Discrete – each include a ﬂag that signals the receiver to decode the surround back channel, indicated as 3/2/.1 EX-ON for Dolby Digital EX materials, and 3/3/.1 ES-ON for DTS-ES materials.

Dolby Digital 2.0 signals may include a Dolby Surround ﬂag indicating DS-ON or DS-OFF, depending on whether the two-channel bitstream contains only stereo information or a downmix of a multichannel program that can be decoded by the AVR’s Dolby Pro Logic decoder. By default, these signals are played in Dolby Pro Logic IIx Movie mode.

When a PCM signal is received, the PCM message and the sampling rate (32kHz, 44.1kHz, 48kHz or 96kHz) will appear.

When only two channels – left and right – are present, the analog surround modes may be used to decode the signal into multiple channels. If you would prefer a different surround format than the native signal’s digital encoding, press the Surround Modes button to display the Surround Modes menu (see

The Auto Select option sets the surround mode to the native signal’s digital encoding, e.g., Dolby Digital, DTS, Dolby TrueHD or DTS-HD Master Audio. For two-channel materials, the AVR defaults to the Logic 7 Movie mode. If you prefer a different surround mode, select the surround-mode category: Virtual Surround, Stereo, Movie, Music or Video Game. Press the OK button to change the mode.

Each surround-mode category is set to a default surround mode:

Virtual Surround: HARMAN virtual speaker. •

Stereo: 7-CH Stereo or 5-CH Stereo (depending on how many main speakers are • present in the system).

Movie: Logic 7 Movie. •

Music: Logic 7 Music. •

Video Game: Logic 7 Game. •

You may select a different mode for each category. Below is a complete list of available surround modes. (The actual surround modes available will depend on the number of speakers in your system.)

Virtual Surround: HARMAN virtual speaker. •

Stereo: 2-CH Stereo, 5-CH Stereo or 7-CH Stereo. •

Movie: Logic 7 Movie, DTS Neo:6 Cinema, Dolby Pro Logic II Movie, Dolby Pro Logic IIx • Movie, Dolby Pro Logic IIz.

Music: Logic 7 Music, DTS Neo:6 Music, Dolby Pro Logic II Music, Dolby Pro Logic IIx • Music, Dolby Pro Logic IIz.

Video Game: Logic 7 Game, Dolby Pro Logic II Game, Dolby Pro Logic IIx Game, Dolby • Pro Logic IIz.

Once you have programmed the surround mode for each type of audio, select the line from the Surround Modes menu to override the AVR’s automatic surround-mode selection. The AVR will use the same surround mode the next time the source is selected.

NOTE: Dolby Pro Logic IIx is available only if you have set up the AVR’s Assigned Amp to Surround Back; Dolby Pro Logic IIz is available only if you have set up the AVR’s Assigned Amp to Front Height. See

Please refer to Table A12 in the Appendix for more information on which surround modes are available with different bitstreams.

Manual Speaker Setup

Selecting a Surround Mode

, on page 36, for more information.

, on page 32).

ENGLISH

AVR

Audio Effects – Cable/Sat

Dolby Volume:

PLIIz Height Gain: Edit: Dolby PLII Music Edit: Dolby PLIIx Music

Medium

Low

Off Off

Tone Control: Treble: Bass: LFE Tr im:

MP3 Enhancer EZSET/EQ:

Edit: Dolby PLIIx Music

Center Width

Dimension Panorama

Exit

Off

Video Modes – Blu-ray

Video Mode:

Picture Adjust: Overscan: Advanced Video Settings

Movie

Auto Fit Off

Audio Effects Button

To adjust other audio settings, such as the tone controls, press the Audio Effects button to display the Audio Effects menu. You can also access the menu by pressing the Info button and selecting Audio Effects.

Advanced Functions

Treble/Bass: These settings boost or cut the treble or bass frequencies by up to 10dB. Use the Left/Right buttons to change the setting. The default setting is 0dB, at the center of the bar.

LFE Trim: This setting attenuates the loudness of the LFE signal to the subwoofer. The setting defaults to the maximum of 0dB. Press the Left/Right buttons to reduce the level by up to 10dB; the setting will appear as a negative number. NOTE: This setting is effective only when a dedicated LFE-channel signal is present in the source material.

MP3 Enhancer: This setting enhances the frequency range of MP3 audio tracks. Select On, or leave the enhancer at the default Off setting when you’re listening to non-MP3 audio.

EZ Set/EQ: This setting activates or deactivates the equalization settings obtained when the EzSet/EQ II process was run. The settings are saved for reactivation at a later listening session.

When you have ﬁnished making adjustments, press the Audio Effects button or the Back/ Exit button.

NOTE: Each source has its own independent Audio Effects settings.

Dolby Volume: See

processing and its beneﬁts. Refer to the table on that page for an explanation of each of the Dolby Volume settings.

PLIIz Height Gain: When you have set the Assigned Amp to Front Height (see

Speaker Setup

, on page 36), the PLIIz Height Gain setting will become available. The front height channels can greatly improve the spatial experience of a surround-sound system. Some listeners may want the depth and dimension that height channels provide, but from a seemingly transparent experience. Other listeners may prefer to accentuate the front height channels by using a higher volume setting.

The PLIIz Height Gain control gives you the ability to change the volume of the front height channels to suit different programs. The control has three settings: Low (normal volume), Mid (moderate volume increase) and High (maximum volume increase). Note that you can also ﬁne-tune the front height channel volume levels. See

Output Levels Manually

Edit Dolby PLII/Dolby PLIIx Music: Some additional settings are available for the Dolby Pro Logic II modes. When the Dolby Pro Logic II or IIx Music modes have been selected, choose the “Edit Dolby PLII/IIx Music” submenus to adjust the Center Width, Dimension and Panorama settings.

Center Width: This setting affects how vocals sound through the three front speakers. A lower number focuses the vocal information tightly on the center channel. Higher numbers (up to 7) broaden the vocal soundstage. Use the Left/Right buttons to adjust.

Dimension: This setting affects the depth of the surround presentation, allowing you to “move” the sound toward the front or rear of the room. The setting of “0” is a neutral default. Setting “F-3” moves the sound toward the front of the room, while setting “R-3” moves the sound toward the rear. Use the Left/Right buttons to adjust it.

Panorama: With the Panorama mode turned on, some of the sound from the front speakers is moved to the surround speakers, creating an enveloping “wraparound” effect. Each press of the OK button toggles the setting On or Off.

Tone Control: This setting determines whether the treble and bass controls are active. When it’s set to Off, the tone controls are out of the circuit, with no changes to the sound. When it’s set to On, the bass and treble controls are in the circuit.

Dolby Volume

, on page 28, for an explanation of Dolby Volume

, on page 38, for details.

Video Processing

Your AVR uses leading-edge Faroudja DCDi Cinema™ video-processing technology. Incoming video signals may be upscaled up to 1080p for outstanding video quality, even with analog video sources. The Faroudja DCDi Cinema Dual 3D comb ﬁlters and 10-bit video processing eliminate the jagged edges and moiré patterns seen with less advanced

Manual

Setting Channel

processing. The AVR’s “Torino” video-processing circuitry generates on-screen graphics in high deﬁnition and blends them with the incoming video so that you can continue to watch a program while using the AVR’s system menus.

The AVR’s video processor automatically provides the best picture based on the capabilities of your video display and the incoming source video. You may experiment with the Video Modes menu adjustments to try to improve the picture further.

Adjust your video display’s picture settings before adjusting the AVR’s Video Modes settings. Access the picture settings from the Video Modes menu. Press the Video Modes button, and the Video Modes screen will appear. You can also access the menu by pressing the Info button and selecting Video Modes.

NOTE: Each source has its own independent Video Modes settings.

Video Mode: The default setting of Off passes the video signal through to the display

with only basic video processing. (NOTE: Video scaling cannot be turned off, but selecting the HDMI Bypass mode in the Info menu for a source connected to one of the HDMI Input connectors passes the video signal directly from the HDMI input connector to the HDMI Monitor Out connector, bypassing all video processing.)

Select one of these processing options to optimize the picture for the current program by applying adjustments to the brightness, contrast, color and sharpness:

Sports: For sporting events. •

Nature: For programs shot outdoors, in a natural setting. •

Movie: For movies and many television broadcasts. •

Custom: Lets you adjust the picture settings manually. The Brightness, Contrast, Color • and Sharpness settings will appear as sliders with values ranging from 0 to 100. The default setting for each adjustment is 50. Use the Left/Right buttons to change each setting’s value. See

How to Adjust the Custom Picture Settings

, on page 35, for

detailed information about making these adjustments.

Picture Adjust: This setting changes the aspect ratio (width:height ratio) of the displayed image. Widescreen (16:9) images are displayed on a full-screen (4:3) video display in letterbox format. Black bars may appear above and below the image.

When full-screen images appear on a widescreen video display, black or gray bars may appear to the left and right of the image (pillarboxing).

AVR

Advanced Video Modes – Blu-ray

Noise Reduction:

MPEG Noise Reduction:

Cross Color Suppressor:

Flesh Tone Enhancement: Black Level

Deinterlacing:

Film Mode Detect:

Off

Off Off

Off

Video Modes – Blu-ray

Video Mode:

Picture Adjust: Overscan: Advanced Video Settings Brightness Contrast Color Sharpness

Custom

Auto Fit Off

Advanced Functions

Plasma and CRT monitors may suffer from “burn-in” when the same image, such as the horizontal or vertical bars, is left on screen for a long period of time. Adjust the picture so that it ﬁlls the display’s screen. Highlight this setting and press the OK Button. Each press of the Up/Down buttons changes the setting. Press the OK button when the desired setting appears in the display box at the lower right corner of the video screen.

Auto Fit: The AVR automatically adjusts the image, as required, to ﬁt the display’s • capabilities.

Height Fit: Adjusts the image to eliminate any bars above or below it. Bars may remain • at the sides.

Width Fit: Adjusts the image to eliminate any bars on the sides. Bars may remain above • and below the image.

Zoom 1x: Displays the image as received from the source. If the image is in the 4:3 • aspect ratio, on widescreen displays the pillarbox format may be used. If the image is in the 16:9 aspect ratio, on full-screen (4:3) displays the letterbox format may be used.

Zoom 2x and Zoom 3x: Stretches the image evenly to ﬁll the screen completely. The • outer portions of the image may be cropped.

Experiment with this setting until you ﬁnd a pleasing display format for each program.

Overscan: For historical reasons, there has been a convention among video broadcasters to reserve an area around the border of a video frame, called “overscan,” that may be viewed on newer high-deﬁnition displays, although it was not visible on older analog television sets. However, since not all displays are capable of showing this portion of the frame, directors avoid placing important information in that area.

If your video display is capable of displaying the overscan area, set Overscan to On to prevent the display from showing a black border around the image, which could cause unwanted “burn-in” on some plasma and CRT displays. The AVR turns this setting off by default when the source device is connected to one of the HDMI input connectors.

Advanced Video Settings: Select this to display the Advanced Video Modes submenu. This submenu is not accessible when the Video Mode setting is set to Off.

Black Level: This setting is effective only when the AVR’s Composite Video Monitor Out connection is being used. Set the Black Level to On for a full black-level setting that provides the full dynamic range of black as presented on most DVDs. When set to Off, the Black Level setting complies with NTSC standards for video and may be more appropriate when your video display has limited video-processing capability.

Deinterlacing: Analog video in the NTSC format is interlaced. That is, each refresh of the television screen displays only half the pixels in a frame, alternating between all of the even rows of pixels and all of the odd rows. Modern video displays are capable of displaying the complete frame all at once by progressively scanning all of the rows of pixels from top to bottom. For optimal viewing on a progressive-scan display (e.g., most ﬂat-panel displays), the video images must be deinterlaced. When you are viewing images via the Composite Video Monitor Out connection, any time the AVR’s video output resolution is 480i, this setting may be turned off.

Film Mode Detect: This setting is accessible only when the Deinterlacing setting is turned on. It compensates for the different frame rates in which ﬁlm and video are shot. Film is shot at a rate of 24 frames per second (progressive scan), while video is shot at slightly less than 60 frames per second (interlaced). The AVR is able to detect whether the program was originally shot on ﬁlm and transferred to video (e.g., to create a DVD), and will compensate appropriately for any authoring errors in the conversion. Select a setting of 3:2 (for NTSC materials), 2:2 (for PAL materials), Off or Auto.

How to Adjust the Custom Picture Settings

Set the Video Mode to Custom to display the picture settings.

ENGLISH

Noise Reduction: Adjust this setting to Low, Medium or High to ﬁlter out signal noise.

MPEG Noise Reduction: This setting is designed to address two speciﬁc types of video

distortion: mosquito noise and blocking artifacts. If you see haziness or shimmering around the edges of objects or the scrolling credits in a ﬁlm, or if the image appears to “pixelate” into blocks, change the MPEG Noise Reduction setting from Off to Low, Medium or High.

Cross Color Suppressor: Turn this setting on to remove cross color artifacts, which can occur when high-frequency luminance (brightness) signals are misinterpreted as chrominance (color) signals, causing unwanted ﬂickering, ﬂashing colors or rainbow patterns. This setting is not available when you are using HDMI sources or when no video signal is present.

Flesh Tone Enhancement: Turn this setting on to enhance the ﬂesh tone of peoples’ skin. (On many TVs this enhancement will be subtle.)

With a color-bar test pattern from a test disc or other source on the TV screen, you can make the following adjustments:

The color intensity setting on your TV. •

Color adjustments using the color bars, which may be (left to right) black, white, yellow, • cyan (turquoise), green, magenta, red, blue, black.

The color transition, seen as sharp separation of the bars. •

The performance of the color circuits in your TV (with video signals); bar edges should • show no vertical crawling dots.

Use the gray scale and the black/white ﬁelds in the test pattern to adjust the brightness and contrast.

Brightness Adjustment

Turn down the color control on your TV until the color bars appear in black and white.1.

Adjust the Contrast to the lowest level where you still can see all gray-scale bars 2. separately and clearly.

Adjust the Brightness so that the bars in the gray scale are all visible. The bar farthest 3. to the left has to be as black as possible rather than gray, but the next gradation must clearly be distinct from it. The bars in the gray scale should gradually and evenly change from black to white.

AVR

Automatic Setup – EzSet/EQ

Automated Speaker Setup and EQ

Manual Setup

Manually Adjust Speaker Settings

Speaker Setup

Contrast Adjustment

Adjust the contrast on your TV until you see a bright white bar in the lower right corner 1. of the screen and a deep, dark, black bar to the left.

If the brightness of the white bar no longer increases when the Contrast is turned 2. up or the borders of white letters bloom (overlight) into the black areas (drastically decreasing the sharpness of the letters), the contrast has been turned up too much. Reduce the Contrast until these effects disappear and the video still looks realistic.

If you are watching TV with ambient daylight, adjust the contrast so that a normal 3. video picture looks the same as the surroundings in your room; that way the eye is relaxed when watching the TV picture. Reduce the setting when the surrounding light is dimmed to improve the sharpness of the picture.

The gray scale in the middle line should retain the same distinction between each 4. bar as before the contrast adjustment. If not, repeat both Step 3 of the Brightness Adjustment and the Contrast Adjustment.

Color Adjustment

When the brightness and contrast are set optimally, adjust the Color control. Set the 1. level so that the colors look strong but still natural, not overdone. If the color level is too high, depending on the TV, some of the bars will seem wider or the color intensity will not increase when the control is turned up. Test the color intensity with a video of pictures of faces, ﬂowers, fruit and vegetables.

Refer to a large white bar in your test pattern to tweak the warmth of the picture using 2. the Tint control on your TV.

Sharpness Adjustment

Contrary to intuition, the picture will appear sharper and clearer with the sharpness backed off from the maximum setting. Reduce the Sharpness setting on your television, and the setting on the AVR, if necessary, to minimize the appearance of any white lines between the bars in the gray-scale portion of the test screen.

Advanced Functions, Manual Speaker Setup

Manual Speaker Setup

Your AVR is ﬂexible and may be conﬁgured to work with most speakers and to compensate for the acoustic characteristics of your room.

The EzSet/EQ process automatically detects the capabilities of each connected speaker and optimizes the AVR’s performance with your speakers. If you are unable to run EzSet/ EQ calibration, or if you wish to set up your AVR for your speakers manually, use the Manual Speaker Setup on-screen menus.

Before beginning, place your loudspeakers as explained in the section, on page 13, and connect them to the AVR. Consult the owner’s guide for the speakers or the manufacturer’s Web site for their frequency-range speciﬁcation. Although you may set the AVR’s individual channel levels “by ear,” an SPL (sound-pressure level) meter purchased at a local electronics store will provide greater accuracy.

Record your conﬁguration settings in Tables A3 through A12 in the Appendix for easy re-entry after a system reset or after the AVR’s Master Power switch has been turned off or the unit has been unplugged for more than four weeks.

NOTE: When using the AVR’s Manual Speaker Setup menus, select a video output resolution of 720p or higher to view graphics that simplify conﬁguration.

Step One – Determine Your Speakers’ Crossover Frequencies

Without using the EzSet/EQ process, the AVR can’t detect how many speakers you’ve connected to it; nor can it determine their capabilities. Consult the technical speciﬁcations for all of your speakers and locate the frequency response, usually given as a range, e.g., 100Hz – 20kHz (±3dB). Write down the lowest frequency that each of your speakers is capable of playing (100Hz in the above example) as the crossover in Table A3 in the Appendix. NOTE: This is not the same as the crossover frequency listed in the speaker’s speciﬁcations.

For the subwoofer, write down the transducer size. The AVR’s bass management determines which speakers will be used to play back the low-frequency (bass) portion of the source program. Sending the lowest notes to small satellite speakers will result in bad sound and may even damage the speakers. The highest notes may not be heard at all through the subwoofer.

With proper bass management, the AVR divides the source signal at a crossover point. All information above that crossover point is played through your system’s speakers, and all information below the crossover point is played through the subwoofer. This way, each loudspeaker in your system will perform at its best, delivering a more powerful and enjoyable sound experience.

Step Two – Measure the Speaker Distances

Ideally, all of your speakers would be placed in a circle, with the listening position at the center. However, you may have had to place some speakers a little farther away from the listening position than others. Sounds that are supposed to arrive simultaneously from different speakers may blur, due to different arrival times.

Your AVR provides a Distance adjustment that compensates for these real-world speaker placement differences.

Measure the distance from each speaker to the listening position, and write it down in Table A4 in the Appendix. Even if all of your speakers are the same distance from the listening position, enter your speaker distances as described in

Distances

, on page 38.

Step Three – Manual Speaker Setup Menu

Now you are ready to program the receiver. Sit in your usual listening position, and make the room as quiet as possible.

With the receiver and video display turned on, press the Setup button to display the menu system. Select the Speaker Setup menu, and then select Manual Setup.

Place Your Speakers

Set the Speaker

AVR

Sub

Number of Speakers

Level Adjust

Crossover (Size)

Distance

Sub Mode:

Reset

Manual Speaker Setup

Front Left & Right

Center

Surr. Left & Right

Assigned AMP

Sub

Manual Speaker Setup

Number Of Speakers: 7.1

Surr. Back

Front Left & Right

Center

Surr. Left & Right

Surr. Back L & R

Sub Size

Reset Crossover

Manual Speaker Setup

Adjust Crossover Frequencies

12 inch

80 Hz

100 Hz

Manual Speaker Setup

If you have already run the EzSet/EQ process as explained in

Speakers

, on page 25, the AVR saved the results. To ﬁne-tune the EzSet/EQ results, or to

Conﬁgure the AVR for Your

conﬁgure the AVR from scratch, select Manual Setup. A screen similar to the one shown below will appear.

NOTE: All of the speaker setup submenus include the Back option. To save the current settings, select the Back option.

To reconﬁgure the speakers from scratch, select the Reset option.

For best results, adjust the submenus in this order: Number of Speakers, Crossover (Size), Sub Mode, Distance and Level Adjust.

Number of Speakers

This selection lets you program the correct setting for each speaker group. The settings in this menu affect the remainder of the speaker setup process and the availability of various surround modes at any time.

Select ON when the speakers are present in the system; select OFF for positions where no speakers are installed. The Front Left & Right setting is always ON and may not be disabled.

Any changes will be reﬂected in the total Number Of Speakers displayed at the top of the screen.

The Assigned AMP setting includes four options:

Surround Back: • Select the Surr. Back option if your main system is a 7.1-channel system and you are using surround back left and surround back right speakers.

Zone 2: • Select the Zone 2 option if your main system is a 5.1-channel system and you want to use the Assigned Amp speaker outputs to power speakers in Zone 2. See

Install a Multizone System

, on page 21, for more information.

Front Height: • Select the Front Height option if your main system is a 7.1-channel system and you are using Front Height speakers with Dolby Pro Logic IIz.

Off: • Select Off if you have not connected speakers to the Assigned Amp speaker outputs.

NOTE: When you set Assigned AMP to “Zone 2,” the speakers connected to the Assigned Amp outputs will not be conﬁgured during the EzSet/EQ process. Conﬁgure the speakers manually, as explained below.

When you have ﬁnished, select the Back option or use the Back/Exit button.

Crossover (Size)

After you return to the Manual Speaker Setup menu, navigate to the Crossover (Size) line and press the OK button to display the Adjust Crossover Frequencies menu.

The AVR will display only those speaker groups you set to On in the Number of Speakers menu.

Refer to Table A3 for each speaker’s crossover frequency.

For each speaker group, select one of these eight crossover frequencies: Large, 40Hz, 60Hz, 80Hz, 100Hz, 120Hz, 150Hz or 200Hz. If the speaker’s crossover frequency is below 40Hz, select the ﬁrst option, “Large.” This setting doesn’t refer to the speaker’s physical size but to its frequency response, which is also called “full range.”

Specify the size of the subwoofer’s transducer as 8, 10, 12 or 15 inches. The AVR always sets the subwoofer crossover to 100Hz but uses the transducer size for equalization.

Write down the settings in Table A6 in the Appendix.

When you have ﬁnished entering the settings, select Back or press the Back/Exit button.

Sub Mode

Move the cursor to the Sub Mode line. This setting depends upon the Crossover setting you selected for the front left and right speakers.

If you set the front speakers to a numeric crossover frequency, the subwoofer setting • will always be SUB. All low-frequency information will always be sent to the subwoofer. If you don’t have a subwoofer, either upgrade to full-range front left and right speakers or add a subwoofer at the earliest opportunity.

If you set the front speakers to LARGE, select one of the three following settings for • the subwoofer:

L/R+LFE: This setting sends all low-frequency information to the subwoofer, including a) information that would normally be played through the front left and right speakers and b) the special low-frequency effects (LFE) channel information.

OFF: Select this setting when no subwoofer is in use. All low-frequency information will be sent to the front left and right speakers.

LFE: This setting plays low-frequency information contained in the left and right program channels through the front left and right speakers, and directs only the LFE-channel information to the subwoofer.

ENGLISH

AVR

Front Left

Center Front Right Surround Right Surround Back Right Surround Back Left Surround Left Sub

Manual Speaker Setup

Adjust Speaker Distance

10.0 ft

Front Left

Center Front Right Surround Right Surround Back Right Surround Back Left Surround Left Sub Reset Levels

Manual Speaker Setup

Adjust Speaker Levels

0 dB

Test Tone Off

Set the Speaker Distances

As described above in Step Two, when you measured the distances from each of your speakers to the listening position, your AVR provides an adjustment that compensates for the different distances so that the sound from each speaker will reach the listening position at the proper time. This process will improve the clarity and detail of the sound.

On the Manual Speaker Setup menu, move the cursor to the Distance line and press the OK button to display the Adjust Speaker Distance menu.

Enter the distance from each speaker to the listening position that you measured in Step Two and recorded in Table A4 in the Appendix (see page 46). Select a speaker, then use the Left/Right buttons to change the measurement. You can enter distances between 0 and 30 feet (9.1m). The default distance for all speakers is 10 feet (3m).

The default unit of measurement is feet. To change the unit to meters, return to the main AVR menu. Select the System Settings menu, then scroll down to the General Setup section and select the Unit of Measure line. Press the OK button to change the setting.

NOTE: If you set the Assigned AMP channels to Zone 2, you will not be able to adjust their delay settings.

Step Four – Setting Channel Output Levels Manually

For a conventional stereo receiver, a simple balance control adjusts the stereo imaging by varying the relative loudness of the left and right channels. In a home theater system with up to seven main channels plus a subwoofer, achieving proper imaging becomes both more critical and more complex. The goal is to ensure that each channel is heard at the listening position with equal loudness (when signals of equal loudness are played through them).

Your AVR’s EzSet/EQ calibration can handle this critical task for you simply and automatically. However, the AVR’s Adjust Speaker Levels menu allows you to calibrate the levels manually, either using the system’s built-in test tone or while playing source material.

Press the Setup button to display the menu system, and then navigate to the Speaker Setup line. Press the OK button to display the Speaker Setup menu. Select Manual Setup, press the OK button, and then navigate to the Level Adjust line. Press the OK button to display the Adjust Speaker Levels menu.

Manual Speaker Setup

All of the system’s speakers will appear with their current level settings. You can adjust each speaker’s level between –10dB and +10dB in 1dB increments.

While making adjustments, you can measure the channel levels in one of these ways:

Preferably, use a handheld SPL meter set to the C-weighting, slow scale. Adjust each • speaker so that the meter reads 75dB when the AVR’s built-in test noise is playing.

By ear. Adjust the levels so that the test tone sounds equally loud to you when it plays • through each speaker.

To set your levels using the AVR’s internal test tone, select the menu’s Test Tone line and use the OK button to select between Auto and Manual:

Auto: The test tone will automatically circulate to all speakers, as indicated by the highlight bar. Use the Left/Right buttons to adjust the level for any speaker when the test tone is paused there. Use the Up/Down buttons to move the cursor to another line, and the test tone will follow the cursor. To stop the test tone, use the Up/Down buttons to move the cursor out of the screen’s speaker listings area.

Manual: The test tone will stay on the current speaker until you use the Up/Down buttons to move it to another speaker. Use the Left/Right buttons to adjust the level for the speaker through which the test tone is playing.

If you are using an external source to set your output levels, set Test Tone to Off, use the Up/Down buttons to navigate to each speaker, and use the Left/Right buttons to adjust the speaker’s level while the source plays. NOTE: If you are using a handheld SPL meter with external source material, such as a test disc or an audio selection, play it and adjust the AVR’s master volume control until the meter measures 75dB. Then adjust the individual speaker levels.

Reset Levels: To reset all levels to their factory defaults of 0dB, scroll down to this line at the bottom of the menu and press the OK button.

When you have ﬁnished adjusting the speaker levels, record the settings in Table A3 in the Appendix. Then select the Back option or press the Back/Exit Button.

Notes on Setting Speaker Volumes in Home Theater Systems:

While setting your system’s individual speaker volume levels is ultimately up to your personal taste, here are some ideas you may ﬁnd helpful:

For ﬁlms and video-music programs, your overall goal should be to create an • enveloping, realistic sound ﬁeld that draws you into the ﬁlm or music program without drawing your attention away from the action on the screen.

For multichannel music recordings, some music producers will create a sound ﬁeld • that places the musicians all around you; others will create a sound ﬁeld that places the musicians in front of you, with more subtle ambience in the surround speakers (as you would experience in a concert hall).

In most 5.1-channel and 7.1-channel ﬁlm soundtracks, the surround speakers are • not intended to be as loud or as active as the front speakers. Adjusting the surround speakers so they are always as loud as the front speakers could make dialogue difﬁcult to understand and will make some sound effects sound unrealistically loud.

Notes on Setting Subwoofer Volume:

Sometimes the ideal subwoofer volume setting for music is too loud for ﬁlms, while the • ideal setting for ﬁlms is too quiet for music. When setting the subwoofer volume, listen to both music and ﬁlms with strong bass content and ﬁnd a “middle ground” volume level that works for both.

If your subwoofer always seems too loud or too quiet, you may want to place it in a • different location. Placing the subwoofer in a corner will always tend to increase its bass output, while placing it away from any walls or corners will always tend to lessen its bass output.

AVR

Zone 2

Status:

Source: Volume: Assigned AMP:

Off

FM Radio

Zone 2

System Settings

Front Panel Settings Front Panel Dimmer:

On 100%

dB On

On On Auto On Off

HDMI Settings HDMI Audio to TV: HDMI Control: Audio Return Channel: Power Control: TV Control:

General AV R Settings Network Settings Volume Units: Volume Default: Volume Default Level

System Settings

Unit of Measure: Language: Dolby Vol. Calibration: RS232 Control:

Feet (ft)

English

Off

24-02-2011 03

Medium 3 seconds 30 seconds 5 minutes 10 minutes

Menu Appearance Menu Transparency: Volume/Status Messages: Menus: Setup and Slide-In Menus: Screen Saver:

System Info Software Version: Upgrade Software:

Listening in Zone 2

With the multizone system in use, you may enjoy an exciting 5.1-channel home theater presentation in the main listening area, while others listen to the same program or an entirely different source in another room. See installation information.

You control the AVR’s multizone system from the on-screen Zone 2 menu. Press the Setup button, and use the Up/Down buttons to navigate to the Zone 2 line. Press the OK button to display the Zone 2 menu.

Status: This line lets you turn Zone 2 on or off.

Source: This line lets you select the source input for Zone 2. You may select a different

source from the one currently operating in the main listening area. However, if the same source has been selected for both the main listening area and Zone 2, listeners in both areas will hear the same content.

NOTE: Only analog audio sources, including The Bridge IIIP and USB devices, are available to the multizone system. To hear digital devices such as a CD player in Zone 2, follow these steps:

In addition to making a digital audio connection, connect the source device’s analog 1. audio outputs to the AVR. Make a note in Table A5 on page 47 to record which set of analog inputs you used.

In the Info menu, scroll down to the Zone 2 Audio setting and select the analog audio 2. input. (Leave the Audio Input From Source set to the digital input.)

Volume: Highlight this line, and use the Left/Right buttons to control the volume in Zone 2.

Assigned AMP: This line lets you assign the Assigned AMP channels to “Zone 2” for multizone operation (see

Number of Speakers

to Zone 2, you may conﬁgure the main listening room for only up to 5.1 channels.

To operate the multizone system using the main remote, slide the Zone Select Switch at the bottom of the remote to the “2” position.

AVR 3650/AVR 365 only: To select a zone using the Zone 2 remote, press the Zone Selector, and the Zone Indicator light will turn green when the remote is set to operate Zone 1 or red to operate Zone 2.

System Settings

The AVR’s System Settings menu lets you customize in what way many of the AVR’s features operate. Press the Setup button and navigate to the System line. Press the OK button to display the System Settings menu.

Install a Multizone System

, on page 21, for

, on page 37). When this line is set

Manual Speaker Setup, System Settings

ENGLISH

Front-Panel Dimmer: This control sets the brightness of the AVR’s front-panel message display. Select from 100%, 50%, 25% or Off. The light inside the Volume Control will go out when the display is partly or fully dimmed, but the Power Indicator will always remain lit to remind you that the AVR is powered on.

HDMI Settings

HDMI Audio to TV: This setting determines whether HDMI audio signals are passed

through the HDMI Monitor Out connector to the video display. In normal operation, leave this setting at Off, as audio will be played through the AVR. To use the TV by itself, without the home theater system, turn this setting to On. In this case you will need to mute the TV’s speakers (or switch the setting to Off) when using the AVR for audio.

HDMI Control: This setting allows the communication of control information among the HDMI devices in your system. Turn this setting to On to allow control communication between the HDMI devices; turn the setting to Off to forbid control communication.

Audio Return Channel: Selecting “Auto” will send audio from the TV to the AVR via the HDMI Audio Return Channel (ARC) connection (which is in the HDMI cable connecting the AVR to the TV). The TV source’s “Audio Input from Source” will be automatically reassigned to the HDMI ARC connector. This way, whenever you’re watching a source that is connected directly to your TV (such as an Internet connection), you can listen to the sound through the AVR.

Power Control: This setting links the power on/off functions of the AVR to those of a TV connected to its HDMI Monitor Out connector. When Power Control is set to On, turning the TV’s power off will automatically put the AVR into the Standby mode; turning the TV’s power on will automatically turn the AVR on. NOTE: The connected TV must support the HDMI System Standby CEC (Consumer Electronics Control).

TV Control: This setting extends some audio-control functions between the AVR and a TV connected to its HDMI Monitor Out connector. When TV Control is set to On, if the TV is set to use external speakers, the TV’s internal speakers will mute, and you can use the TV’s remote to control the AVR’s volume up/down and mute functions. If the TV is set to use its internal speakers, the AVR’s output will automatically mute. NOTE: The connected TV must support the HDMI Remote Control/System Audio Control CEC (Consumer Electronics Control).

AVR

Network Settings

ID#:

Network Settings:

IP A ddress: Subnet Mask:

00 00 00 00 A0 A0

Manual

000 . 000 . 000 . 000 000 . 000 . 000 . 000 000 . 000 . 000 . 000 000 . 000 . 000 . 000 000 . 000 . 000 . 000

Not Connected

Gateway: Primary DNS: Secondary DNS:

Network Status: Apply & Save – AV R will Enter Standby

The settings lock is currently On. In order to access the settings, please select ‘Settings lock Off’.

Settings Lock

Cancel

Settings Lock Off

System Settings

General AVR Settings

Network Settings: Select this to set up your AVR for connection to your home network.

ID #: This line is informational only and identiﬁes the AVR to other devices on your • home network and the Internet for www.radioharmankardon.com.

Network Settings: Since most networks use automatic IP address settings, in most • cases you can set Network Settings to Automatic. If you are required to use a static IP address and network settings, you must obtain these settings from your ISP or network administrator. Use the OK button to set this line to “Manual.” The following settings will become active: IP Address, Subnet Mask, Gateway, Primary DNS, Secondary DNS.

Use the Number buttons to make the entries for all of these settings. When you have ﬁnished, select Apply & Save, and press the OK button. The AVR will enter the Standby mode. When you turn the AVR back on, it will attempt to connect to the network using the settings you entered. If the AVR cannot connect to the network using the manual settings, contact your ISP or network administrator for assistance.

Network Status: This line indicates the AVR’s current network-connection status • (Connected/Not Connected).

Apply & Save: Any time you make a change in any of the Network settings, the Apply & • Save line will become available. Select this line and press the OK button. The AVR will go into the Standby mode. After you turn the AVR back on, the new network settings will be in effect. IMPORTANT: You must select Apply & Save for your network

settings to take effect.

NOTE: If you have trouble connecting to the network at any time, cycle the AVR into the Standby mode, and then turn it back on.

Volume Units: This setting lets you select whether the AVR displays the volume level in

the conventional decibel scale or on a numeric scale from 0 to 100. When the decibel scale is used, 0dB is the maximum recommended volume, with lower volumes displayed as negative values. (-90dB – +10dB). The decibel scale is the default setting.

Volume Default and Volume Default Level: These two settings are used together to program the volume level when you turn on the AVR. Set Volume Default to On, and then set the Volume Default Level to the desired turn-on volume. When Volume Default is set to Off, the AVR will turn on at the last-used volume setting from the previous listening session.

Unit of Measure: Adjusts the speaker-distance settings for Manual Speaker Setup. Select between meters and feet.

Language: Select the preferred language for the AVR’s on-screen menus and displays: English, French, Spanish, German, Italian or Russian.

Dolby Volume Calibration: This setting determines the Dolby Volume calibration, as described in setting the calibration.

Dolby Volume Calibration

, on page 28. Refer to that section for details about

RS232 Control: If you have connected the AVR to an external control system via its RS-232 port, set this line to On to enable the AVR to be controlled by the external control system. Refer to the control system’s documentation for details.

Menu Appearance

Menu Transparency: This selection lets you determine whether video programs will be

visible when the menu system is in use. Select Normal for a fully transparent background, Medium for partial transparency or Opaque to completely block video programs while menus are on screen.

Volume/Status Messages: When the AVR is turned on, the volume is adjusted, the source is changed or a change in the input signal is detected, a status message will be displayed on the TV screen. Select how long the message remains visible, from 2 to 10 seconds, with a default of 3 seconds. Select “Off” if you do not wish to see the status messages on the TV screen (they will still appear on the AVR’s front-panel message display).

Menus: This setting governs how long the Surround Modes, Video Modes and Audio Effects menus remain visible after the last adjustment: 5 seconds, 10 seconds, 30 seconds, 1 minute or 5 minutes. Select “No Time-Out” to view the menus indeﬁnitely, but this setting is not recommended, due to the danger of “burn-in” on some video displays.

Setup and Slide-In Menus: This setting determines how long the setup menus (Main Menu, Speaker Setup Menu, Zone 2 Menu, all slide-in menus) remain visible after the last adjustment. Select a time-out period of 5, 10 or 15 (the default) minutes, or no time-out, which leaves the menus on screen until manually cleared. A time-out period avoids the possibility of burn-in damage to plasma or CRT displays.

Screen Saver: Program a time-out period for no activity (with no menus displayed) before the AVR’s built-in screen saver begins. Select a period of 5 minutes, 10 minutes, 20 minutes, 30 minutes or 1 hour, or turn off the screen saver. A time-out period avoids the possibility of burn-in damage to plasma or CRT displays.

System Info

Software Version: This line is informational only. From time to time, Harman Kardon

engineers may release software upgrades that improve your AVR’s performance or add features. If you are experiencing difﬁculties with the AVR, a customer-service representative may ask for the software version of your product to determine whether a later upgrade is available.

Upgrade Software: If a software upgrade is released for your AVR, installation instructions will be available in the Product Support section of the Web site or from Harman Kardon customer service. At that time, you may access this submenu to install the upgrade software.

IMPORTANT: During a system upgrade, do not power off the AVR or use any of its controls. Doing so could permanently damage the AVR.

Settings Lock

Settings Lock prevents the Setup Source, Speaker Setup and System settings menus from being inadvertently changed. With Settings Lock set to On, the screen shown below will appear whenever someone attempts to access a setting in one of those menus.

Select “Settings Lock Off” to access the settings or “Cancel” if the setting was accessed inadvertently. NOTE: If you select “Settings Lock Off,” you will need to turn the Settings Lock back on via the Settings Lock menu.

AVR

Advanced Remote Control Programming

Remote Channel-Control Punch-Through

The punch-through feature allows you to operate one component while setting certain groups of controls to operate another component. For example, while using the AVR controls for surround modes and other audio functions, you may also use the remote to operate the transport controls of your Blu-ray Disc player. Or while using the remote to control video functions on your TV, you may also use the remote to change channels on your cable box.

To program punch-through control while operating any device:

For three seconds press and hold the Source Selector button for the main device the 1. remote will be operating. The Source Selector will light up, go dark and then light up again, indicating the remote is in Program mode and that you may release the button.

Select the type of punch-through programming.2.

For channel-control punch-through, press the Channel Up button.a)

To program transport-control punch-through, press the Play transport-control b) button.

Press the Source Selector button for the device whose channel or transport controls 3. you will use while operating the device selected in the ﬁrst step. The Source Selector button will ﬂash to conﬁrm.

For example, to watch the TV while changing channels using the cable box, press and hold the TV button until it lights. Then press the Channel Up button, followed by the Cable/ SAT button.

To undo punch-through programming, follow the same steps as above, but press the same Source Selector button in Steps 1 and 3.

NOTE: The Volume and Mute controls are always dedicated to the AVR.

Programming Macro (Activity) Commands

In addition to their normal functions, you can also use the 0 – 9 Number buttons and AVR Power On button to store Macro (Activity) commands – up to 11 of them. Each Macro can send out up to 19 commands at one time from a single button push. Any AVR remote control button’s function from any mode (except the Back/Exit button, the Light button, and the Activity button) can be programmed into a Macro.

NOTE: Use caution when programming complicated Macros. It isn’t possible to program a pause or delay before sending additional commands after a “Power On” command, and the component may not be ready to respond to commands immediately after powering on.

To program a Macro:

To enter the Programming mode, simultaneously press and hold the Activity button and 1. the Number button or AVR Power On button to which you want to assign the Macro.

Press in up to 19 commands that you want stored in that Macro button. During each 2. successive button selection, the Source Selector button LED will blink once. Press the Source Selector button for each device (or Setup button for the AVR itself) before you enter individual commands. This step counts as one of the 19 commands allowed for each Macro.

You can select functions from another mode by ﬁrst pressing the corresponding Source • Selector button and then the buttons where those functions are located within that mode. Pressing a Source Selector button also counts as one command.

For power on, press the AVR or Device Power On button. •

For power off, press the AVR or Device Power Off button. •

Press the Activity button to end the programming process. The last Source Selector 3. button (or the Setup button) will ﬂash three times.

It isn’t possible to “edit” a command within a Macro. To erase the Macro:

Press and hold the Activity Button and the button into which you programmed the 1. Macro until the Source Selector or Setup button lights up.

Press the Activity button to erase the Macro.2.

Advanced Remote Control Programming

To execute a Macro:

Press the Activity button, then press the button into which you programmed the Macro.

IMPORTANT: Keep the remote aimed at the components until all of the Macro commands have been executed. The remote can take up to 10 seconds to send out 19 Macro commands.

Recording

Two-channel analog and digital audio signals, as well as composite video signals, are normally available at the appropriate recording outputs. To make a recording, connect your audio or video recorder to the appropriate AVR output connectors as described in the Making Connections section, insert blank media in the recorder and make sure the recorder is turned on and recording while the source is playing. Refer to the recording device’s instructions for complete information about making recordings.

NOTES:

The AVR does not convert analog signals to digital or vice versa.1.

HDMI and component video sources are not available for recording.2.

Please make certain that you are aware of any copyright restrictions on any material 3. you record. Unauthorized duplication of copyrighted materials is prohibited by law.

Sleep Timer

The sleep timer sets the AVR to play for up to 90 minutes and then turn off automatically.

Press the Sleep button on the remote, and the time until turn-off will be displayed. Each additional press of the Sleep button increases the play time by 10 minutes, with a maximum of 90 minutes. The SLEEP OFF setting disables the sleep timer.

When the sleep timer has been set, the front-panel display will automatically dim to half brightness.

If you press the Sleep button after the timer has been set, the remaining play time will be displayed. Press the Sleep button again to change the play time.

Updating Your Network Software

From time to time, updates to your network sofwtare may become available. To check for and download these updates:

After the AVR has connected to your network, press the remote’s Internet Radio source 1. button.

On the AVR front panel, simultaneously press and hold the Surround Modes and Back/2. Exit buttons.

Message

Display

Surround

Modes Button

Watch the front-panel Message Display for a message that the unit is checking for 3. software updates. When the message appears, release the buttons.

Back/Exit

Button

OK Button

ENGLISH

AVR

If the message indicates that an update is available, press the front-panel OK button 4. to begin the update.

During the update a progress bar and status messages will appear on the Message 5. Display. Do not touch any controls on the AVR and do not interrupt the network connection during the update.

When the update is completed the AVR will automatically power off, and after ﬁve 6. seconds will automatically power back on. Once the AVR turns back on it’s ready to use.

Resetting the Remote

To reset the remote to its factory default condition, simultaneously press and hold the TV Source Selector button and the “0” Number button. When the TV Source button relights, enter the code “333.” When the TV button goes out, and all of the Source Selector buttons ﬂash, the remote control will be reset.

Processor Reset

If the AVR behaves erratically after a power surge, ﬁrst turn off the rear-panel Main Power switch and unplug the AC power cord for at least 3 minutes. Plug the cord back in and turn the receiver on. If this procedure doesn’t help, reset the AVR’s processor as described below.

NOTE: A processor reset erases all user conﬁgurations, including video resolution, speaker and level settings, and tuner presets. After a reset, reenter all of these settings from your notes in the Appendix worksheets.

To reset the AVR’s processor:

Press the front-panel Standby/On switch to place the unit in the Standby mode (the 1. Power Indicator will turn amber).

Press and hold the front-panel OK button for at least 5 seconds until the RESET 2. message appears on the front-panel Message Display.

NOTE: After performing a processor reset, wait at least 1 minute before pressing any Source Selector buttons.

If the receiver does not function correctly after a processor reset, contact an authorized Harman Kardon service center for assistance. Authorized service centers may be located by visiting our Web site at www.harmankardon.com.

Advanced Remote Control Programming

AVR

Troubleshooting

Symptom Cause Solution

Unit does not function when Main Power switch is turned onNo AC power • Ensure that the power cord is plugged into a live AC •

Front-panel Message display lights, but there’s no sound or picture

No sound from any speaker; PROTECT message appears on Message display

No sound from center or surround speakers Incorrect surround mode •

Unit does not respond to remote control commands Weak batteries in remote •

Intermittent input connection • Dolby Digital EX •

Ampliﬁer is in protection mode due to possible short • circuit

Program material is monophonic •

Incorrect speaker conﬁguration •

Program material is stereo •

AVR not selected •

Remote sensor is obscured •

power outlet

Check if the AC outlet is switch-controlled •

Dolby Digital 2/2/.0 or .1, 3/2/.0 or .1 •

Dolby Digital Plus via HDMI connection (source device • decodes to Dolby Digital when a coaxial or optical connection is used)

Select a surround mode other than stereo •

Mono programs contain no surround information •

Check the speaker conﬁguration in the setup menu •

The surround decoder may not create center- or • surround-channel information from nonencoded programs

Change batteries in remote •

Press the Setup/AVR button •

Ensure that the AVR’s front-panel remote sensor is in • the line of sight of the remote

ENGLISH

Intermittent buzzing in tuner Local interference • Move the AVR or antenna away from computers, •

(AVR 3650/AVR 365 only): Surround-back speaker settings cannot be accessed, and the test tone does not play through the surround back speakers

(AVR 3650/AVR 2650 only): The SIRIUS Preview Channel (001) is silent

Unable to activate remote control Programming mode Source Selector button is not held for at least 3 •

Remote buttons light, but AVR does not respond Remote is in Zone 2 mode • Slide Zone Selector switch to the Zone 1 position. •

Unable to establish network connection AVR network programming requires rebooting • Cycle the AVR into the Standby mode, and then turn it •

Additional information on troubleshooting possible problems with your AVR and installation-related issues may be found in the list of “Frequently Asked Questions,” which is located in the Product Support section of our Web site: www.harmankardon.com

Multi-zone operation has been selected/Assigned AMP • channels have been assigned to Zone 2

SIRIUS tuner is not connected •

SIRIUS antenna is in an improper location •

SIRIUS signal requires a refresh •

seconds

ﬂuorescent lights, motors or other electrical appliances

Use the Speaker Setup menu to reassign the Assigned • AMP to the surround back left and right channels

Ensure that SIRIUS tuner is properly connected •

Re-locate the SIRIUS antenna according to the • recommendations in the SIRIUS tuner’s instruction manual. For further help, visit www.siriusradio.com

Visit www.siriusradio.com •

Be sure to hold the Source Selector button for at least • 3 seconds

on again

AVR

Specifications

Audio Section

Stereo power: AVR 3650/AVR 365: 110W per channel, two

Multichannel power: AVR 3650/AVR 365: 110W per channel, two

Input sensitivity/impedance: 200mV/47k ohms

Signal-to-noise ratio (IHF-A): 100dB

Surround system adjacent channel separation:

Frequency response (@ 1W): 10Hz – 130kHz (+0dB/–3dB)

High instantaneous current capability (HCC):

Transient intermodulation distortion (TIM):

Slew rate: 40V/µsec

channels driven @ 8 ohms, 20Hz – 20kHz, <0.09% THD

AVR 2650/AVR 265: 95W per channel, two channels driven @ 8 ohms, 20Hz – 20kHz, <0.09% THD

channels driven @ 8 ohms, 20Hz – 20kHz, <0.09% THD

AVR 2650/AVR 265: 95W per channel, two channels driven @ 8 ohms, 20Hz – 20kHz, <0.09% THD

Dolby Pro Logic/DPLII: 40dB

Dolby Digital: 55dB

DTS: 55dB

±35 amps

Unmeasurable

Video Section

Television format: NTSC (AVR 3650/AVR 2650);

Input level/impedance: 1Vp-p/75 ohms

Output level/impedance: 1Vp-p/75 ohms

Video frequency response (composite video):

HDMI: Version 1.4a with 12-bit Deep Color

PAL (AVR 365/AVR 265)

10Hz – 8MHz (–3dB)

General Specifications

Power requirement: 120V AC/60Hz (AVR 3650/AVR 2650);

Power consumption: <0.5W (standby);

Dimensions (W x H x D): 17-5/16" x 6-1/2" x 17-1/8"

Weight (AVR 3650/AVR 365): 27.25 lb (12.4kg)

Depth measurement includes knobs, buttons and terminal connections. Height measurement includes feet and chassis.

220V – 240V AC/50Hz – 60Hz (AVR 365/ AVR 265)

480W maximum (AVR 3650/AVR 365); 420W maximum (AVR 2650/AVR 265)

(440mm x 165mm x 435mm)

(AVR 2650/AVR 265): 24.4 lb (11.1kg)

FM Tuner Section

Frequency range: 87.5 – 108.0MHz

Usable sensitivity IHF: 1.3µV/13.2dBf

Signal-to-noise ratio (mono/stereo): 70dB/68dB

Distortion (mono/stereo): 0.2%/0.3%

Stereo separation: 40dB @ 1kHz

Selectivity (±400kHz): 70dB

Image rejection: 80dB

IF rejection: 90dB

AM Tuner Section

Frequency range: 520 – 1710kHz (AVR 3650/AVR 2650)

522 – 1620kHz (AVR 365/AVR 265)

Signal-to-noise ratio: 45dB

Usable sensitivity (loop): 500µV

Distortion (1kHz, 50% mod): 0.8%

Selectivity (±10kHz): 30dB

AVR

Appendix – Default settings, worksheets, remote product codes

Appendix

Table A1 – Recommended Source Component Connections

Device Type AVR Source Digital Audio Connection Analog Audio Connection Video Connections

Cable TV, satellite TV, HDTV or other device that delivers television programs

DVD Audio/Video, SACD, Blu-ray Disc, HD-DVD player

Media Server, including Harman Kardon DMC 1000

TV TV

Video-game console Game

Any audio or video device, e.g., CD player, camcorder, cassette deck

Recorder Any

iPod or iPhone The Bridge IIIP None The Bridge IIIP

DVR (AVR 2650/AVR 265 only)

Cable/SAT HDMI 2 Analog 1, 2 or 3 HDMI 2

Blu-ray HDMI 1 Analog 1, 2 or 3 HDMI 1

Media Server HDMI 4 Analog 1, 2 or 3 HDMI 4

HDMI 5 (AVR 3650/AVR 365); HDMI 1 (AVR 2650/AVR 265)

HDMI 3 (or HDMI front on AVR 3650/AVR 365)

AUX Coaxial or Optical Analog 1, 2 or 3

Coaxial or Optical Input and Optical Output

DVR HDMI 5 Analog 1, 2 or 3 HDMI 5

Analog 1, 2 or 3

Analog 1, 2 or 3 4

Analog 1, 2 or 3 Inputs and Rec Out

HDMI 5 (AVR 3650/AVR 365); HDMI 1 (AVR 2650/AVR 265)

HDMI 3 (or HDMI front on AVR 3650/AVR 365)

Composite Video 1 or 2 (not used for audio-only devices)

Composite Video 2 Input and Output

The Bridge IIIP for photo- and video-capable iPod and iPhone models

ENGLISH

Table A2 – Source Setting Defaults

Cable/Sat Blu-ray

Surround Modes (Auto Select)

Video Input HDMI 2 HDMI 1 HDMI 4 N/A

Audio Input HDMI 2 HDMI 1 HDMI 4 N/A

Resolution to Display*

Audio Auto Polling Off Off Off N/A Off Off Off N/A Off N/A

Zone 2 Audio — — — Radio — — Analog 2 The Bridge III — USB

Dolby Volume Medium Low Medium Medium Medium Medium Low Medium Medium Medium

* Video output resolution may vary for HDMI connections. The default HDMI resolution is 1080i for NTSC and PAL.

Logic 7 Movie

480i (NTSC); 576p (PAL)

Logic 7 Movie

480i (NTSC); 576p (PAL)

Media Server

Logic 7 Movie

480i (NTSC); 576p (PAL)

Radio TV Game AUX The Bridge

Logic 7 Movie

480i (NTSC); 576p (PAL)

Logic 7 Movie

HDMI 5 (AVR 3650/AVR 365); HDMI 1 (AVR 2650/AVR 265)

480i (NTSC); 576p (PAL)

Logic 7 Movie

HDMI 3

480i (NTSC); 576p (PAL)

Logic 7 Music Logic 7 Music Logic 7 Movie Stereo

HDMI Front (AVR 3650/AVR 365); N/A (AVR 2650/ AVR 265)

HDMI Front (AVR 3650/AVR 365); Analog 2 (AVR 2650/AVR 265)

480i (NTSC); 576p (PAL)

The Bridge III HDMI 5 N/A

480i (NTSC); 576p (PAL)

DVR (AVR 2650/ AVR 265 only)

480i (NTSC); 576p (PAL)

USB (AVR 3650/ AVR 365 only)

480i (NTSC); 576p (PAL)

AVR

Table A3 – Speaker/Channel Setting Defaults

Appendix

All Digital and Two-Chan nel Analog Audio Input Connectors

Left/Right Speakers ON

Center Speaker ON

Left/Right Surround Speakers ON

Left/Right Surround Back Speakers OFF

Subwoofer 1 ON

Subwoofer 2 ON

Left/Right Speakers Crossover Frequency 100Hz

Center Speaker Crossover Frequency 100Hz

Left/Right Surround Speakers Crossover Frequency 100Hz

Left/Right Surround Back or Left/Right Front Height Speakers Crossover Frequency

Subwoofer Mode LFE

Subwoofer Size 10 inch

Front Left Level 0dB

Center Level 0dB

Front Right Level 0dB

100Hz

Your Settings Position 1

Your Settings Position 2

Surround Right Level 0dB

Surround Back Right/Front Height Right Level 0dB

Surround Back Left/Front Height Left Level 0dB

Surround Left Level 0dB

Sub Level 0dB

Table A4 – Delay Setting Defaults

Speaker Position

Front Left 10 feet (3 meters)

Center 10 feet (3 meters)

Front Right 10 feet (3 meters)

Surround Right 10 feet (3 meters)

Surround Left 10 feet (3 meters)

Surround Back Right/Front Height Right 10 feet (3 meters)

Surround Back Left/Front Height Left 10 feet (3 meters)

Subwoofer 10 feet (3 meters)

Distance From Speaker to Listening Position

Your Delay Settings Position 1

Your Delay Settings Position 2

A/V Lip Sync Delay (See Info Settings Menu) 0mS

AVR

Table A5 – Source Settings

Appendix

Cable/Sat

Device Type USB

Surround Modes

Video Input N/A The Bridge III

Audio Input USB The Bridge III

Resolution to Display

Adjust Lip Sync

Change Name N/A N/A

Audio Auto Polling N/A N/A

Zone 2 Audio USB The Bridge III

Dolby Volume

Blu-ray Disc

Media Server

Radio TV

USB (AVR 3650/ AVR 365)

Network Game AUX The Bridge

Table A6 – Audio Effects Settings

USB (AVR 3650/ AVR 365)

Network Game AUX The Bridge

Default Cable/Sat

Blu-ray Disc

Media Server

Radio TV

DVR (AVR 2650/ AVR 265)

ENGLISH

Dolby Volume See Source

Tone Control On

Treble 0dB

Bass 0dB

LFE Trim 0dB

MP3 Enhancer

Off

AVR

Table A7 – Video Modes Settings

Appendix

Default Cable/Sat

Video Mode Off

Brightness* 50

Contrast* 50

Color* 50

Sharpness* 50

Picture Adjust Auto Adjust

Overscan Off

Noise Reduction** Off

MPEG Noise Reduction** Off

Cross Color Suppressor** Off

Flesh Tone Enhancement**

Black Level** Off

Deinterlacing** Off

Film Mode Detect** Off

Off

Blu-ray Disc

Media Server

Radio TV

USB (AVR 3650/ AVR 365)

Network Game AUX

The Bridge

DVR (AVR 2650/ AVR 265)

* Note: These settings are available only when the Video Mode is set to Custom. ** Note: These settings are displayed only when Advanced Video Settings is selected.

Table A8 – Surround Modes

Default Cable/Sat

Auto Select

Virtual Surround

Stereo 7 CH Stereo

Movie Logic 7 Movie

Music Logic 7 Music

Game Logic 7 Game

Center Width* 3

Dimension* 0

Panorama* Off

* Note: These settings are available only when Dolby Pro Logic II or IIx Music mode has been selected. Access these settings by selecting the Edit option.

Logic 7 Movie or native digital format

Harman virtual speaker

Blu-ray Disc

Media Server

Radio TV

USB (AVR 3650/ AVR 365)

Network Game AUX The Bridge

DVR (AVR 2650/ AVR 265)

AVR

Table A9 – Remote Control Codes

Source Input Device Type (if changed) Product Brand and Code Number

Cable/Sat

Appendix

Blu-ray Disc

DVR (AVR 2650/AVR 265)

Media Server

Game

AUX

Table A10 – System Settings

Feature Default Your Settings

Front Panel Dimmer On 100%

HDMI Audio to TV Off

HDMI Control Off

Audio Return Channel Off

Power Control Off

TV Control Off

Network Settings Automatic

Volume Units dB

ENGLISH

Volume Default Off

Volume Default Level –25dB

Unit of Measure Feet (AVR 3650/AVR 2650): Meters (AVR 365/AVR 265)

Language English

Dolby Volume Calibration 0dB

RS232 Control Off

Menu Transparency Medium

Volume/Status Messages 3 Seconds

Menus 1 minute

Setup and Slide-In Menus 5 minutes

Screen Saver 10 minutes

Software Version Check your unit

Table A11 – Zone 2 Settings

Source Input Default Your Settings

Status Off

Source Cable/Sat

Volume –25dB

Assigned AMP Surround Back

AVR

Table A12 – Surround Modes

Surround Mode Description Incoming Bitstream or Signal

Appendix

Dolby Digital Provides up to ﬁve separate main audio channels and a dedicated low-frequency

Dolby Digital EX An expansion of Dolby Digital 5.1 that adds a surround back channel that may be

Dolby Digital Plus An enhanced version of Dolby Digital encoded more efﬁciently, Dolby Digital Plus

Dolby TrueHD Dolby TrueHD is an expansion of MLP Lossless

Dolby Digital Stereo Delivers a two-channel downmix of Dolby Digital materials. Dolby Digital 1/0/.0 or .1, 2/0/.0 or .1, 3/0/.0 or .1, •

Dolby Pro Logic II Mode Group

Dolby Pro Logic II Movie

effects (LFE) channel.

played through one or two surround back speakers. May be manually selected when a non-EX Dolby Digital stream is detected.

has the capacity for additional discrete channels and for streaming audio from the Internet, all with enhanced audio quality. Source material may be delivered via an HDMI connection or decoded to Dolby Digital or PCM and transmitted via coaxial or optical digital audio.

™

on DVD-Audio discs. Dolby TrueHD adds the features found in Dolby Digital, such as night mode settings, while delivering fully lossless audio that is a true reproduction of studio master recordings.

Analog decoder that derives ﬁve full-range, discrete main audio channels from matrix surround-encoded or two-channel analog sources. Four variants are available.

Variant of Dolby Pro Logic II that is optimized for movie and television programs. Dolby Digital 2.0 or 2.1 •

audio, the same format used

Dolby Digital 1/0/.0 or .1, 2/0/.0 or .1, 3/0/.0 or .1, • 2/1/.0 or .1, 2/2/.0 or .1, 3/2/.0 or .1

Dolby Digital EX (played as 5.1) •

Dolby Digital Plus decoded and delivered via coaxial or optical • connection

Dolby Digital EX •

Dolby Digital 2/2/.0 or .1, 3/2/.0 or .1 •

Dolby Digital Plus via HDMI connection (source device decodes to • Dolby Digital when a coaxial or optical connection is used)

Blu-ray Disc or HD-DVD encoded with Dolby TrueHD, delivered • via HDMI

2/1/.0 or .1, 2/2/.0 or .1, 3/2/.0 or .1

Dolby Digital EX •

See below

Analog (two-channel) •

Tuner •

PCM (32kHz, 44.1kHz, 48kHz, 96kHz) •

Dolby Pro Logic II Music

Dolby Pro Logic II Game

Dolby Pro Logic II Original version of Dolby Pro Logic that steered a mono signal containing

Dolby Pro Logic IIx Mode Group

Variant of Dolby Pro Logic II that is optimized for music selections. Allows adjustment of sound-ﬁeld presentation in three dimensions:

Center Width (adjusts width of vocal soundstage) • Dimension (adjusts depth of soundstage) • Panorama (adjusts wraparound surround effect) •

Variant of Dolby Pro Logic II that emphasizes use of the surround channels and subwoofer for total immersion in the video gaming experience.

information below 7kHz to the surround channels.

An expansion of Dolby Pro Logic II that adds a surround back channel which may be played through one or two surround back speakers. The Dolby Pro Logic IIx modes may be selected not only with Dolby Digital bitstreams, but thanks to the AVR’s post-processor, they may also be used with some DTS bitstreams to add a surround back channel to 5.1 modes.

Dolby Digital 2.0 or 2.1 •

Analog (two-channel) •

Tuner •

PCM (32kHz, 44.1kHz, 48kHz, 96kHz) •

Dolby Digital 2.0 or 2.1 •

Analog (two-channel) •

Tuner •

PCM (32kHz, 44.1kHz, 48kHz, 96kHz) •

Dolby Digital 2.0 or 2.1 •

Analog (two-channel) •

Tuner •

PCM (32kHz, 44.1kHz, 48kHz, 96kHz) •

See below

AVR

Table A12 – Surround Modes – continued

Appendix

Surround Mode Description Incoming Bitstream or Signal

Dolby Pro Logic IIx Music

Dolby Pro Logic IIx Game

Dolby Pro Logic IIz An expansion of Dolby Pro Logic II that adds left and right front height channels

HARMAN virtual speaker

This mode is similar to Dolby Pro Logic II Movie, with an added surround back channel.

This mode is similar to Dolby Pro Logic II Music, including the availability of center width, dimension and panorama adjustments. Dolby Pro Logic IIx Music adds a surround back channel.

This mode is similar to Dolby Pro Logic II Game, with the added beneﬁt of a surround back channel.

that are played through two front height speakers mounted above and outside of the front left and right speakers.

Simulates 5.1 channels when only two speakers are present or a more enveloping sound ﬁeld is desired.

Dolby Digital 2/0/.0 or .1, 2/2/.0 or .1, 3/2/.0 or .1, EX •

Analog (two-channel) •

Tuner •

PCM (32kHz, 44.1kHz, 48kHz, 96kHz) •

Dolby Digital 2/0/.0 or .1, 2/2/.0 or .1, 3/2/.0 or .1, EX •

Analog (two-channel) •

Tuner •

PCM (32kHz, 44.1kHz, 48kHz, 96kHz) •

Dolby Digital 2/0/.0 or .1 •

Analog (two-channel) •

Tuner •

PCM (32kHz, 44.1kHz or 48kHz) •

Dolby Digital 2/0/.0 or .1, 2/2/.0 or .1, 3/2/.0 or .1, EX •

Analog (two-channel) •

Tuner •

PCM (32kHz, 44.1kHz, 48kHz, 96kHz) •

Dolby Digital •

Analog (two-channel) •

Tuner •

PCM (32kHz, 44.1kHz or 48kHz) •

ENGLISH

DTS Digital Using a different encoding/decoding method than Dolby Digital,

DTS Digital also provides up to ﬁve discrete main channels, plus an LFE channel.

DTS-HD DTS-HD is a new high-deﬁnition audio format that complements the high-

deﬁnition video found on Blu-ray Disc and HD-DVD discs. It is transmitted using a DTS core with high-resolution extensions. Even when only DTS 5.1 surround sound is desired (or available, if the multizone system is in use), the higher capacity of high-resolution discs serves up DTS at twice the bit rate used on DVD-Video discs.

DTS-HD Master Audio DTS-HD Master Audio technology delivers bit-for-bit reproductions of the studio

master recording in up to 7.1 channels for an incredibly accurate performance.

DTS-ES Matrix DTS Extended Surround adds a single surround back channel to DTS 5.1

digital surround sound. The Matrix version includes the surround back channel information “matrixed” into the left and right (side) surround channels for compatibility with 5.1-channel systems.

DTS-ES Discrete DTS-ES Discrete is another Extended Surround mode that adds a surround back

channel, but this information is encoded discretely on the disc and is not derived from information contained in the surround channels.

DTS Stereo Delivers a two-channel downmix of DTS Digital materials or presents a matrix-

encoded surround presentation.

DTS 1/0/.0 or .1, 2/0/.0 or .1, 3/0/.0 or .1, 3/1/.0 or .1, 2/2/.0 or • .1, 3/2/.0 or .1

DTS-ES Matrix (played as 5.1) •

DTS-ES Discrete (played as 5.1) •

Blu-ray Disc or HD-DVD discs encoded with DTS-HD modes, • delivered via HDMI connection

Blu-ray Disc or HD-DVD discs encoded with DTS-HD Master • Audio technology, delivered via HDMI connection

DTS-ES Matrix •

DTS-ES Discrete •

DTS 1/0/.0 or .1, 2/0/.0 or .1, 3/0/.0 or .1, 3/1/.0 or .1, 2/2/.0 or • .1, 3/2/.0 or .1

DTS 96/24 •

DTS-ES Matrix •

DTS-ES Discrete •

AVR

Table A12 – Surround Modes – continued

Surround Mode Description Incoming Bitstream or Signal

Appendix

DTS Neo:6 Mode Group

DTS Neo:6 Cinema

DTS Neo:6 Music

Logic 7 Mode Group

Logic 7 Movie

Logic 7 Music

DTS Neo:6 analog processing is available with DTS and DTS 96/24 signals and two-channel analog or PCM signals to create a 3-, 5- or 6-channel presentation.

Depending on the number of speakers in your system, select 3-, 5- or 6-channel modes, enhanced for movie or video presentations.

Available only in 5- and 6-channel modes, creates a surround presentation suitable for music recordings.

A HARMAN proprietary technology, Logic 7 technology enhances two-channel and matrix-encoded recordings by deriving separate information for the surround back channels. It provides more accurate placement of sound, improves panning and expands the sound ﬁeld, even when used with 5.1-channel systems. Logic 7 technology uses 96kHz processing and is available in 5.1-or 7.1-channel modes. Three variants are available.

Especially suited to two-channel sources containing Dolby Surround or matrix encoding, Logic 7 Movie mode increases center-channel intelligibility. The AVR is programmed at the factory to default to this mode for two-channel signals.

Logic 7 Music mode is well suited to conventional two-channel music recordings. Analog (two-channel) •

See below

DTS 2/2/.0 or .1, 3/2/.0 or .1 •

DTS 96/24 •

Analog (two-channel) •

PCM (32kHz, 44.1kHz or 48kHz) •

DTS 2/2/.0 or .1, 3/2/.0 or .1 •

DTS 96/24 •

Analog (two-channel) •

PCM (32kHz, 44.1kHz or 48kHz) •

See below

Analog (two-channel) •

Tuner •

PCM (32kHz, 44.1kHz, 48kHz, 96kHz) •

Tuner •

PCM (32kHz, 44.1kHz, 48kHz, 96kHz) •

Logic 7 Game

5-Channel Stereo Useful for parties, the left- and right-channel information is played through both

7-Channel Stereo Expands the 5-Channel Stereo presentation to include the surround back

2-Channel Stereo Turns off all surround processing and plays a pure two-channel signal or a

Use Logic 7 Game mode to enhance enjoyment of video-game consoles. Analog (two-channel) •

the front and surround speakers on each side, while the center speaker plays a summed mono mix.

channels.

downmix of a multichannel signal. The signal is digitized and bass management settings are applied, making it appropriate when a subwoofer is used.

Tuner •

PCM (32kHz, 44.1kHz, 48kHz, 96kHz) •

Analog (two-channel) •

Tuner •

PCM (32kHz, 44.1kHz, 48kHz, 96kHz) •

Analog (two-channel) •

Tuner •

PCM (32kHz, 44.1kHz, 48kHz, 96kHz) •

Analog (two-channel; DSP downmix available for multichannel) •

Tuner •

PCM (32kHz, 44.1kHz, 48kHz, 96kHz) •

AVR

Appendix

ENGLISH

Refer to the numbered buttons when using the Function List in Table A13.

Remote Control Function List Reference

AVR

Table A13 – Remote Control Function List

Appendix

Radio

No. Button Name AVR

01 AVR Power On AVR Power On AVR Power On AVR Power On AVR Power On AVR Power On AVR Power On AVR Power On AVR Power On 02 AVR Power Off AVR Power Off AVR Power Off AVR Power Off AVR Power Off AVR Power Off AVR Power Off AVR Power Off AVR Power Off 03 Device Power On Power On On Power On Power On 04 Device Power Off Power Off Off Power Off Power Off 05 Cable/Sat Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel 06 Blu-ray Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel 07 The Bridge Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel 08 Radio Radio Radio Radio Radio Radio Radio Radio Radio 09 TV Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel

USB (AVR 3650/AVR 365)

DVR (AVR 2650/AVR 265)

11 Game Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel 12 Media Server Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel 13 Network Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel 14 AUX Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel 15 Audio Effects Audio Effects Audio Effects Audio Effects Audio Effects Audio Effects Audio Effects Audio Effects Audio Effects 16 Video Effects Video Effects Video Effects Video Effects Video Effects Video Effects Video Effects Video Effects Video Effects 17 Surround Modes Surround Modes Surround Modes Surround Modes Surround Modes Surround Modes Surround Modes Surround Modes Surround Modes 18 1 1 1 1 1 1 1 1 1 19 2 2 2 2 2 2 2 2 2 20 3 3 3 3 3 3 3 3 3 21 4 4 4 4 4 4 4 4 4 22 5 5 5 5 5 5 5 5 5 23 6 6 6 6 6 6 6 6 6 24 7 7 7 7 7 7 7 7 7 25 8 8 8 8 8 8 8 8 8 26 9 9 9 9 9 9 9 9 9 27 Last Last Last Last Last Prev. Ch Last 28 0 0 0 0 0 0 0 0 0 29 Activity Activity Activity Activity Activity Activity Activity Activity Activity 30 Back/Exit Back/Exit Back/Exit Back/Exit Back/Exit Clear Back Back/Exit 31 Menu Menu Menu Menu Menu Menu Menu Menu Menu 32 Up Up Tune Up Tune Up Channel/Preset Up Up Up Up Up 33 Left Left Preset/Down Preset/Down Preset/Category Up Left Left Left Left 34 OK OK OK OK OK Enter Enter OK OK 35 Right Right Preset/Up Preset/Up Preset/Category Up Right Right Right Right

36* Light Light Light Light Light Light Light Light Light

37 Down Down Tune Down Tune Down Channel/Preset Down Down Down Down Down 38 Disc Menu Disc Menu Disc Menu 39 Red Angle Angle 40 Green Subtitle Subtitle 41 Yellow Audio Audio 42 Blue Zoom Zoom

Volume + Volume + Volume + Volume + Volume + Volume + Volume +

Volume – Volume – Volume – Volume – Volume – Volume – Volume – Volume – Volume –

44 Mute AVR

Channel/Page Up Channel/Preset Up Preset Up Preset Up Preset Up Page Up Channel Up Page Up

Channel/Page Down Channel/Preset Down Preset Down Preset Down Preset Down Page Down Channel Down Page Down 46 Previous Prev. Step Previous Previous 47 Pause Pause Pause Pause 48 Next Next Step Next Step Next 49 Rew G Rew G Rew G Rew G 50 Play B Play B Play B Play B 51 FF H FF H FF H FF H 52 Record Record 53 Stop Stop Stop Stop 54 Setup AVR Sel and Setup AVR Sel and Setup AVR Sel and Setup AVR Sel and Setup AVR Sel and Setup AVR Sel and Setup AVR Sel and Setup AVR Sel and Setup 55 Info Settings Info Settings Info Settings Info Settings Info Settings Info Settings Info Settings Info Settings Info Settings 56 Sleep Sleep Sleep Sleep Sleep Sleep Sleep Sleep Sleep 57 Zone Select Zone Select Zone Select Zone Select Zone Select Zone Select Zone Select Zone Select Zone Select

58* Learn Learn Learn Learn Learn Learn Learn Learn Learn

Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel

Mute AVR Mute AVR Mute AVR Mute AVR Mute AVR Mute AVR Mute AVR Mute

DVD

Media Server

TV The BridgeFM AM XM DMC1000

Volume + Volume +

* AVR 3650/AVR 365 only.

5454

AVR

Appendix

Table A13 – Remote Control Function List – continued

AUX

No. Button Name Cable/SAT Game

01 AVR Power On AVR Power On AVR Power On AVR Power On AVR Power On AVR Power On AVR Power On AVR Power On 02 AVR Power Off AVR Power Off AVR Power Off AVR Power Off AVR Power Off AVR Power Off AVR Power Off AVR Power Off 03 Device Power On Power On Play Power On Power On Power On Power On Power On 04 Device Power Off Power Off Stop Power Off Power Off Power Off Power Off Power Off 05 Cable/Sat Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel 06 Blu-ray Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel 07 The Bridge Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel 08 Radio Radio Radio Radio Radio Radio Radio Radio 09 TV Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel

USB (AVR 3650/AVR 365)

DVR (AVR 2650/AVR 265)

11 Game Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel 12 Media Server Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel 13 Network Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel 14 AUX Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel 15 Audio Effects Audio Effects Audio Effects Audio Effects Audio Effects Audio Effects Audio Effects Audio Effects 16 Video Modes Video Modes Video Modes Video Modes Video Modes Video Modes Video Modes Video Modes 17 Surround Modes Surround Modes Surround Modes Surround Modes Surround Modes Surround Modes Surround Modes Surround Modes 18 1 1 1 1 1 1 1 1 19 2 2 2 2 2 2 2 2 20 3 3 3 3 3 3 3 3 21 4 4 4 4 4 4 4 4 22 5 5 5 5 5 5 5 5 23 6 6 6 6 6 6 6 6 24 7 7 7 7 7 7 7 7 25 8 8 8 8 8 8 8 8 26 9 9 9 9 9 9 9 9 27 Last Prev. Ch Enter Prev. Ch Instant Replay Enter/Last 28 0 0 0 0 0 0 0 0 29 Activity Activity Activity Activity Activity Activity Activity Activity 30 Back/Exit Bypass Clear Exit/Cancel Exit Exit Cancel 31 Menu Menu Start Menu Menu Menu Menu 32 Up Up Up Up Up Up Up 33 Left Left Left Left Left Left Left 34 OK OK Select Enter Setup Select Enter 35 Right Right Right Right Right Right Right

36* Light Light Light Light Light Light Light Light

37 Down Down Down Down Down Down Down 38 Disc Menu OSD DVD Menu OSD AV TiVo OSD 39 Red Guide 40 Green PPV 41 Yellow Fav. Ch 42 Blue Music X Intro Scan Aspect Jump Down Skip

44 Mute AVR Mute AVR Mute AVR Mute AVR Mute AVR Mute AVR Mute AVR Mute

46 Previous Slow Down Skip Down Back Prev. Step Thumb Down Scan Down 47 Pause Pause Pause Pause Pause Pause Pause 48 Next Slow Up Skip Up Replay Next Step Thumb Up Scan Up 49 Rew G Prev. R. Search Rew G Rew G Rew G Rew G 50 Play B Play B Play B Play B Play B Play B Play B 51 FF H Next F. Search FF H FF H FF H FF H 52 Record Subtitle Time Record Record Record Record 53 Stop Stop Stop Stop Stop Stop Stop 54 Setup AVR Sel and Setup AVR Sel and Setup AVR Sel and Setup AVR Sel and Setup AVR Sel and Setup AVR Sel and Setup AVR Sel and Setup 55 Info Settings Info Settings Info Settings Info Settings Info Settings Info Settings Info Settings Info Settings 56 Sleep Sleep Sleep Sleep Sleep Sleep Sleep Sleep 57 Zone Select

58* Learn Learn Learn Learn Learn Learn Learn Learn

Volume + Volume + Volume + Volume + Volume + Volume + Volume + Volume + Volume – Volume – Volume – Volume – Volume – Volume – Volume – Volume –

Channel/Page Up Channel Up Scan Up (+10) Channel Up Page Up Channel Up Channel Up

Channel/Page Down Channel Down Scan Down Disc Skip Channel Down Page Down Channel Down Channel Down

* AVR 3650/AVR 365 only.

Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel Input Sel

CD HDTV PVD TIVO VCR

Open/Close Caption Mark Window

Random Play Fav. Ch Repeat Live TV

Repeat MTS Jump Up Slow

ENGLISH

55 55

AVR

Refer to Tables A14 through A24 when programming the codes for your components into the remote.

Table A14 – Remote Control Product Codes: TV

Appendix

TV Manufacturer/Brand Setup Code Number

ADMIRAL 192

ANAM 045 106 109 112 122

AOC 037 122 123 128

AUDIOVOX 012

BLAUPUNKT 084

BROKSONIC 205 206

CITIZEN 045 123 128 132

CONTEC 045

CRAIG 045 157 158 159

CROWN 045 132

CURTIS MATHES 123 128 132

DAEWOO

DAYTRON 128 132

DYNATECH 063

DYNEX 014

ELECTROHOME 115 132

EMERSON 045 123 128 132 139 157 158 159 162 205

FUJITSU 041 042

FUNAI 045

FUTURETECH 045

GE 029 087 121 123 128 133 145 159 163

GRUNDIG 193

HALL MARK 128

HARMAN KARDON 201

HITACHI 123 128 132 144 147

HYTEK 016

INKEL 120

JC PENNEY 115 123 128 132 145

JENSEN 019

JVC 079 087 134

KEC 045

KLH 006

KTV 045 123 132 162

LG/GOLDSTAR 002 013 101 110 122 128 132

LLOYTRON 172 173

LODGENET 069

LXI 077 145 148

MAGNAVOX 030 040 123 128 132 145 148

MARANTZ 115 123 148

MEMOREX 069 128

METZ 084

MGA 115 123 128

MITSUBISHI 077 115 123 128 160 167 168

MTC 175 176

NATIONAL 148 177 179 180 181 182

NEC 010 115 121 123 125

OLEVIA 007

045 087 102 105 106 108 111 114 116 119 127 128 132

TV Manufacturer/Brand Setup Code Number

OPTONICA 077

ORION 207 208 209 210 211

PANASONIC 087 148 169

PHILCO 045 115 123 128 132 148

PHILIPS 033 034 035 036 123 128 132 145 148

PIONEER 024 123 128

POLAROID 003 004 005 006 043

PORTLAND 128 132

PROSCAN 133

PROTON 008 059 122 128 132 165

QUASAR 032 087

RADIO SHACK 045 128 132 180 196 197

RCA 021 115 123 128 133 145 161 163

REALISTIC 045 167 196

RUNCO 044 046 152 153

SAMPO 059 123 128

SAMSUNG 020 022 124 128 132 145

SANYO 026 054

SCOTT 045 128 132

SEARS 128 132 145

SHARP 077 128 132

SIEMENS 084

SIGNATURE 069

SONY 028 031 117 130 136 194 212

SOUNDESIGN 045 128

SYLVANIA 025 123 128 145 148

SYMPHONIC 184

TANDY 077

TATUNG 063

TECHNICS 181

TECHWOOD 128

TEKNIKA 045 069 115 123 128 132

TELERENT 069

TERA 156

THOMSON 190 191

TIVO 051 052 and See Table A24

TMK 128

TOSHIBA 063 129 202

TOTEVISION 132

VIDEO CONCEPTS 160

VIDTECH 128

VIEWSONIC 011 038 039 047

VIZIO 001 002

WARDS 069 128 132 148

WESTINGHOUSE 017 018 023

YAMAHA 123 128

YORK 128

ZENITH 069 090

AVR

Appendix

Table A15 – Remote Control Product Codes: AUX-HDTV Table A16 – Remote Control Product Codes:

AUX-VCR (cont.)

TV Manufacturer/Brand Setup Code Number

APEX 614 616

DISH NETWORK 612

LG 604

MAGNAVOX 607 608 609 610 611

MOTOROLA 605

RCA 601 612

SAMSUNG 603

TATUNG 618

TIVO See Table A24

ZENITH 602 606 619

Table A16 – Remote Control Product Codes: AUX-VCR

VCR Manufacturer/Brand Setup Code Number

AIWA 340

AKAI 348 408 409 426

AUDIO DYNAMICS 318 348

BROKSONIC 410 447

CANON 435 440

CAPEHART 394

CITIZEN 434

CRAIG 345 416

DAEWOO 317 394 404

DAYTRON 394

DBX 318 348

DYNATECH 340

EMERSON 313 340 342 410 412

FISHER 317

FUNAI 340

GE 376 395 424

HARMAN KARDON 302 303 318 349

HITACHI 340 348

JC PENNEY 318 345

JENSEN 348

JVC 318 348 411 432

KENWOOD 320 348

LG/GOLDSTAR 318 407

LLOYD 340

LXI 320 340

MAGNAVOX 340

MARANTZ 318

MEMOREX 317 320 340 352 353 354 376 442

VCR Manufacturer/Brand Setup Code Number

MGA 349

MITSUBISHI 349 431

MULTITECH 340

NAD 439

NATIONAL 440

NEC 318 348

NORDMENDE 348

OPTIMUS 459

ORION 447

PANASONIC 425 450 467 472

PHILCO 340

PHILIPS 340 375

PORTLAND 394

PULSAR 376

QUASAR 301 425

RADIO SHACK 355 434 440 442 458 459

RCA 395 424 425 457 472

REALISTIC 317 320 340 345 459

SAMSUNG 345 351 395 405 409

SANSUI 348 416 447

SANYO 317 320

SCOTT 410 412

SEARS 317 320

SHARP 429 456

SONY 380 429

SOUNDESIGN 340

SYLVANIA 340

SYMPHONIC 340

TANDY 317 340

TEAC 340 348

TEKNIKA 340

THOMAS 340

TIVO See Table A24

TMK 313

TOSHIBA 412 455

TOTEVISION 345

UNITECH 345

VECTOR RESEARCH 318

VIDEO CONCEPTS 318 340

VIDEOSONIC 345

WARDS 340 345 412

YAMAHA 318 340 348

ZENITH 340 350 376 383

ENGLISH

AVR

Appendix

Table A17 – Remote Control Product Codes: AUX-CD Table A17 – Remote Control Product Codes:

AUX-CD (cont.)

CD Manufacturer/Brand Setup Code Number

ADCOM 063 069

AIWA 072 111 118 156 170

AKAI 050 177 184

AUDIO TECHNICA 053

AUDIOACCESS 125

AUDIOFILE 211

BSR 044

CALIFORNIA AUDIO 109

CAPETRONIC 070

CARRERA 087

CARVER 136 140 141 143 144 145 185 186

CASIO 117 166

CLARINETTE 166

DENON 187 188 213

EMERSON 052 093 108

FISHER 055 095

FUNAI 126

GE 164

HAITAI 099 214

HARMAN KARDON 001 002 025 054 190

HITACHI 093

INKEL 216

JC PENNEY 098 147

JENSEN 153

JVC 176 195 196

KENWOOD 030 062 078 079 148 151 176 178 181

LG/GOLDSTAR 016 087

LOTTE 108

LUXMAN 077 102

LXI 164

MAGNAVOX 039 113

MARANTZ 058 084 191 192 193

MCINTOSH 194

MCS 080 098

MITSUMI 152

MODULAIRE 166

NAD 013 074 197 198

NAKAMICHI 199 200 201

NEC 069

NIKKO 053 055

ONKYO 037 038 045 046 171 175 202 203

OPTIMUS 065 089 091 092 099 104 212

PANASONIC 075 109 119 158 183 204

PHILIPS 039 138 149 209

PIONEER 071 094 100 112 123 131 161 162 215

PROTON 210

RADIO SHACK 126 166 213

CD Manufacturer/Brand Setup Code Number

RCA 024 081 093 150

REALISTIC 058 093 095 104 105 108 164 166

SANSUI 047 081 134 157 172

SANYO 033 082 095

SCOTT 108

SHARP 058 105 114 151 159 167 180 181

SHERWOOD 003 041 058 105 133

SONY

SOUNDSTREAM 124

SYMPHONIC 059 110

TAEKWANG 177

TEAC 011 058 085 086 106 107 110 121 137 146 154

THETA DIGITAL 039

TOSHIBA 013 074 097 151 155 173

VECTOR RESEARCH 087

VICTOR 120 130

WARDS 095

YAMAHA 019 031 053 061 135 169

YORK 166

103 115 116 118 132 139 163 205 206 207 208 212 217

Table A18 – Remote Control Product Codes: DVD

DVD Manufacturer/Brand Setup Code Number

APEX DIGITAL 061

DENON 019 020 051

GE 003 004

HARMAN KARDON 001 002 032

JVC 006

LG/GOLDSTAR 005 010 055 064 066

MAGNAVOX 056

MARANTZ 059

MITSUBISHI 023

NAD 062

ONKYO 009 048

PANASONIC 008 024 030 044

PHILIPS 016 056

PIONEER 018 027 041 065

PROCEED 060

PROSCAN 003 004

RCA 003 004

SAMSUNG 017 053 054

SHARP 028

SONY 011 012 015 043 045

THOMSON 003 004

TOSHIBA 009 058 067

YAMAHA 030 063

ZENITH 005 055 064

AVR

Appendix

Table A19 – Remote Control Product Codes: SAT

SAT Manufacturer/Brand Setup Code Number

BIRDVIEW 425

CHANNEL MASTER 320 321 325 361

CHAPARRAL 315 316 451

CITOH 360

DIRECTV 309 310 314

DISH NETWORK 364

DRAKE 313 317 318 413 481

DX ANTENNA 331 352 379 483

ECHOSTAR 364 395 397 452 453 463 477 478 484 485

ELECTRO HOME 392

FUJITSU 324 329 334

GENERAL INSTRUMENT 303 311 323 365 403 454 468 474

HITACHI 304 455

HOUSTON TRACKER 463

HUGHES 305 306 437 489

JANIEL 366

JERROLD 454 468 484

LEGEND 453

MACOM 317 365 369 370 371

MAGNAVOX 461 473

MEMOREX 453

MITSUBISHI 307

MOTOROLA 312 319

NEXTWAVE 423

NORSAT 373

OPTIMUS 466

PACE 328 487

PANASONIC 353 366 457 469

PANSAT 420

PERSONAL CABLE 418

PHILIPS 375

PICO 407

PRESIDENT 381 404

RCA 301 358 439 458 465 490

REALISTIC 349 480

SAMSUNG 322 326 442

SATELLITE SERVICE CO 335 388

SCIENTIFIC ATLANTA 339 356

SONY 362 405

STAR CHOICE DBS 459

STARCAST 347

SUPER GUIDE 327 423

TELECOM 330 333 390 391 393 409

TOSHIBA 302 426 460 461 462 470

UNIDEN

ZENITH 359 384 385 387 394 419 488

323 332 348 349 350 351 354 355 381 383 389 403 466 479 480

Table A20 – Remote Control Product Codes: Game

GAME Manufacturer/ Brand

Microsoft (XBOX, XBOX 360) 001 003

NYKO (PS3) 005

SONY (PS2, PS3) 002 004

Setup Code Number

Table A21 – Remote Control Product Codes: Cable

Cable Manufacturer/Brand Setup Code Number

ABC 001 011

ALLEGRO 111

AMERICAST 212

ARCHER 112

BELCOR 113

CABLE STAR 033 113

CITIZEN 111

COMCAST 007

DIGI LINK 114

EAGLE 186

EASTERN 066 070

EMERSON 112

GENERAL INSTRUMENT 001 011 017 096 097 210

GC ELECTRONICS 113

GEMINI 032 060

HAMLIN 056 099 100 101 117 175 208

HITACHI 001 188

JASCO 111

JERROLD 001 002 011 017 073 096 097 162 188 210

LINSAY 118

MACOM 191

MAGNAVOX 017 019 068

MOVIETIME 035 039

NSC 035 190

OAK 197 220

PACE 179

PANASONIC 053 176 177 189 214

PANTHER 114

PHILIPS 013 019 020 085 090

PIONEER 001 041 119 171 209 215 216

RADIO SHACK 111 112 213

RCA 053 214

RECOTON 116

REGAL 056 099 100 101 208

REMBRANT 032

SAMSUNG 003 072 186

SCIENTIFIC ATLANTA 183 203 221 222

SEAM 121

ENGLISH

AVR

Appendix

Table A21 – Remote Control Product Codes: Cable (cont.)

Cable Manufacturer/Brand Setup Code Number

SIGNATURE 001 188

SPRUCER 053 081 177 189

STARCOM 002 011 163

STARGATE 120

TANDY 024

TELECAPATION 028

TEXSCAN 036

TFC 122

TIVO 029 030 and See Table A24

TOCOM 170 205

UNITED CABLE 011

UNIVERSAL 033 034 039 042 113

VIDEOWAY 124 211

VIEWSTAR 019 025 053 086 089 190

ZENITH 065 125 211 219

Table A22 – Remote Control Product Codes: Media Server

Manufacturer/Brand Setup Code Number

APPLE 008 009

BEYOND 003

ESCIENT (FIREBALL) 004 005 006 007

HARMAN KARDON 001 002

LOGITECH 012

MICROSOFT 003

NAIM 011

REQUEST 010

SONOS 013

Table A23 – Remote Control Product Codes: AUX-Cable/SAT Recorder (PVR)

Manufacturer/Brand Setup Code Number

DAEWOO 701 704

ECHOSTAR 714 715 716

EXPRESSVU 714

HUGHES 717 727

HYUNDAI 718

PANASONIC 710 723

PHILIPS 711 717 724 727

PROSCAN 719

RCA 719 727

REPLAYTV 708 710 712 725 726

SONICBLUE 710 712

SONY 707 713 720 721 722 723 724

Table A24 – Remote Control Product Codes: AUX- TiVo

Manufacturer/Brand Setup Code Number

COMCAST TIVO 808

COX TIVO 808

DIRECTV TIVO 806

HUMAX TIVO 803

Nero LiquidTV TIVO 805

PIONEER TIVO 801

TIVO HD XL DVR 807

TIVO HD DVR 804

TIVO SERIES2™ DT DVR 802

TOSHIBA TIVO 803

HARMAN Consumer, Inc. 8500 Balboa Boulevard, Northridge, CA 91329 USA

Harman Kardon and Logic 7 are trademarks of HARMAN International Industries, Incorporated, registered in the United States and/or other countries. EzSet/EQ is a trademark of HARMAN International Industries, Incorporated.

Blu-ray Disc is a trademark of the Blu-ray Disc Association.

CEA is a registered trademark of the Consumer Electronics Association.

DLNA is a registered trademark of the Digital Living Network Alliance.

Manufactured under license from Dolby Laboratories. Dolby, the double-D symbol and Pro Logic are registered trademarks of Dolby Laboratories. MLP Lossless is a trademark of Dolby Laboratories.

Manufactured under license under U.S. Patent #’s 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,226,616; 6,487,535; 7,003,467 and other U.S. and worldwide patents issued and pending. DTS, DTS-ES and DTS Neo:6 are registered trademarks, and DTS 96/24, DTS-HD, DTS-HD High Resolution Audio and DTS-HD Master Audio are trademarks, of DTS, Inc. © 1996-2007 DTS, Inc. All Rights Reserved.

Faroudja DCDi Cinema is a trademark of Genesis Microchip Inc.

HDMI, the HDMI logo and High-Definition Multimedia Interface are registered trademarks of HDMI Licensing LLC in the United States and other countries.

Intel is a registered trademark of Intel Corporation.

Apple, iPhone, iPod, iPod touch, iTunes and Macintosh are trademarks of Apple Inc., registered in the U.S. and other countries.

SIRIUS and all related marks and logos are trademarks of Sirius XM Radio Inc. and its subsidiaries. All other marks and logos are the property of their respective owners. All rights reserved. SIRIUS subscription sold separately. Taxes and a one-time activation fee may apply. SIRIUS tuner required (sold separately) to receive the SIRIUS service. All programming and fees subject to change. It is prohibited to copy, decompile, disassemble, reverse engineer, hack, manipulate or otherwise make available any technology or software incorporated in receivers compatible with the SIRIUS Satellite Radio System. Service not available in Alaska or Hawaii.

Teletext is a registered trademark of Teletext Ltd.

TiVo is a registered trademark of TiVo Inc. Series2 is a trademark of TiVo, Inc.

TwonkyServer is a trademark of PacketVideo Corporation.

Windows Media is a registered trademark of Microsoft Corporation in the United States and/or other countries.

Features, specifications and appearance are subject to change without notice.

www.harmankardon.com

Harman-Kardon AVR 2650, AVR 265, AVR 365, AVR 3650 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
